Beautiful Enterprise Co., Ltd. Bluetooth Plug-In Wall Speaker
Users Manual
Before using your new product, please read these instructions to prevent any damage.
USER GUIDE
Bluetooth Plug-in
Wall Speaker
NS-SPBTP1-W
v1
R2
2
NS-SPBTP1-W Bluetooth Plug-in Wall Speaker
www.insigniaproducts.com
NS-SPBTP1-W
Bluetooth Plug-in Wall Speaker
Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Safety information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Setting up your Bluetooth speaker. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Using your Bluetooth speaker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Charging an external device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Maintaining. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Legal notices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
ONE-YEAR LIMITED WARRANTY - INSIGNIA . . . . . . . . . . . . . . . . . . . . . . .13
Introduction
Congratulations on your purchase of a high-quality Insignia product. Your
NS-SPBTP1-W represents the state-of-the-art in Bluetooth plug-in speaker
design and is designed for reliable and trouble-free performance.
Safety information
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol indicates that dangerous voltage constituting a risk
of electric shock is present within your speaker. This label is
located on the back of your speaker.
This symbol indicates that there are important operating and
maintenance instructions in the literature accompanying your
speaker.
3
NS-SPBTP1-W Bluetooth Plug-in Wall Speaker
www.insigniaproducts.com
Important safety instructions
1Read these instructions.
2Keep these instructions.
3Heed all warnings.
4Follow all instructions.
5Do not use this apparatus near water.
6Clean only with a dry cloth.
7Do not block any ventilation openings. Install in accordance with the
manufacturer's instructions.
8Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
9Do not defeat the safety purpose of the polarized or grounding-type
plug. A polarized plug has two blades with one wider than the other. A
grounding type plug has two blades and a third grounding prong. The
wide blade or the third prong are provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10 Protect the power cord from being walked on or pinched particularly
at plugs, convenience receptacles, and the point where they exit from
the apparatus.
11 Only use attachments/accessories specifed by the manufacturer.
12 Use only with the cart, stand, tripod, bracket or table specifed by the
manufacturer, or sold with the apparatus. When a cart is used, use
caution when moving the cart/apparatus combination to avoid injury
from tip-over.
Portable cart warning (symbol provided by RETAC)
13 Unplug this apparatus during lightning storms or when unused for
long periods of time.
14 Refer all servicing to qualified service personnel. Servicing is required
when the apparatus has been damaged in any way, such as
power-supply cord or plug is damaged, liquid has been spilled or
objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has been
dropped.
15 To reduce the risk of fire or electric shock, do not expose this device to
rain, moisture, dripping, or splashing, and no objects filled with liquids,
such as vases, shall be placed on it.
4
NS-SPBTP1-W Bluetooth Plug-in Wall Speaker
www.insigniaproducts.com
16 The wall plug is the disconnecting device. The plug must remain
readily operable.
17 The batteries (battery pack & batteries installed) shall not be exposed
to excessive heat such as sunshine, fire or the like.
18 Do not place any naked _ame sources, such as lighted candles, on the
apparatus.
19 The battery used in this product must be properly recycled or
disposed of. Please contact your local recycling center for proper
battery handling and disposal instructions.
5
NS-SPBTP1-W Bluetooth Plug-in Wall Speaker
www.insigniaproducts.com
Features
• Bluetooth connectability
• Built-in power adapter
• Built-in rechargable battery
Package contents
• Bluetooth plug-in speaker
•Quick Setup Guide
#Item Description
1 / (power/pair)
button
• Press and hold for three seconds to turn this system on.
• Press and hold for two seconds to put this system into pairing mode.
• Press and release to turn this system off.
2 Volume+/– buttons Press to increase or decrease the volume level of playback.
3 Battery/pairing indicator • Indicates the battery charging status.
• Indicates the pairing states.
4 AC power plugs (foldable) Fold down, then plug into a wall outlet to charge your speaker.
5AUX IN jack Plug an external audio device into this jack to hear the playback from this speaker.
6 USB charge port Connect an external device to this port to charge it.
6
NS-SPBTP1-W Bluetooth Plug-in Wall Speaker
www.insigniaproducts.com
Setting up your Bluetooth speaker
Your plug-in wall speaker is typically used while plugged into a wall
socket. You can also use the speaker unplugged, with the built-in
rechargable battery.
Charging the battery
Your speaker has a built-in rechargable battery, which must be charged to
use the speaker.
• Fold down the AC power plug from the speaker body and plug it into
an AC wall outlet.
• The battery/pairing indicator turns red when the battery is charging
and turns off when the battery is fully charged.
7
NS-SPBTP1-W Bluetooth Plug-in Wall Speaker
www.insigniaproducts.com
Using your Bluetooth speaker
Turning on and pairing your speaker
1Press and hold the / (power/pair) button for three seconds to
turn on your speaker.
2Press and hold the / (power/pair) button for two seconds to
enter pairing mode. The pair indicator light flashes blue rapidly.
3Open the Bluetooth settings on your Bluetooth-enabled device. After
the speaker is recognized, “NS-SPBTP1” appears in the list of Bluetooth
devices.
4Select “NS-SPBTP1” to pair with your device. The pair indicator light
turns solid blue when your speaker is successfully connected. You can
use your paired device to control playback.
Controlling the volume
• You can change the playback volume by either pressing the
VOLUME+ or – buttons on the top of your speaker, or changing the
volume on your paired device. For maximum volume, turn both to
maximum.
Notes
• On most devices no password is needed to pair, however,
if a password is requested, the default password is 0000.
• Before playing back via Bluetooth, make sure that the
audio cable has been removed from the AUX IN jack of
your speaker.
8
NS-SPBTP1-W Bluetooth Plug-in Wall Speaker
www.insigniaproducts.com
Connecting two Bluetooth devices simultaneously
1Press and hold the / (power/pair) button for two seconds to
disconnect the current Bluetooth connection and enter pairing mode,
then follow steps 3 and 4 in “Turning on and pairing your speaker” on
page 7, to establish a Bluetooth connection with another device.
2On the initial Bluetooth device, select NS-SPBTP1 from the list of
available Bluetooth devices to resume the connection. Now, both
Bluetooth devices are simultaneously connected to this speaker.
3Start playback on one of the paired devices to streaming music to this
system. If you want to play from the other paired device, pause the
current playback and start playback on the other paired device.
Playing music from a non-Bluetooth external sound source
1Connect a non-Bluetooth external sound source, such as an MP3
player, by plugging an audio cable with a 3.5 mm plug (not included)
into the AUX IN jack on the right side of your speaker.
2Start playback on the external device.
3Press VOLUME + or – to adjust the volume.
4Control playback using the controls on the external device.
Note
•If the connected external device is playing music at a
normal volume level, your speaker plays from that
source. If the connected external device has no sound or
the volume level is too low, your speaker continues
Bluetooth playback.
•When playing music via audio cable, it is suggested that
you pause the Bluetooth sound source paired to your
speaker or disconnect the Bluetooth device.
9
NS-SPBTP1-W Bluetooth Plug-in Wall Speaker
www.insigniaproducts.com
Charging an external device
You can charge an external device with a USB cable when your speaker is
plugged into an AC wall outlet.
• To charge your external device, plug a USB cable from the device (such
as a mobile phone, tablet, or wireless headset) into the USB port on the
side of your speaker.
Troubleshooting
Notes
• Your speaker must be plugged into an AC wall outlet to
be able to charge an external device.
• The maximum output current of the USB port is 1000mA
when the system is idle. The output current is 500mA
when this system is playing music.
Problem Solution
My speaker won’t turn on. • Make sure that the battery is charged or your speaker is plugged into an AC wall
outlet.
The built-in battery won’t
charge.
• Make sure that the speaker is not exposed to excessive heat (above 140°F [60°C]). Try
charging the battery again when the temperature returns to normal.
No sound. • Make sure that the battery is charged and your speaker is turned on.
• Make sure that your external device, if connected, is turned on and playing.
• Make sure that the volume on your external device is turned up and is not set to mute.
• Make sure that the volume is not extremely low.
My external device won’t
play.
• Make sure that the battery is charged and your speaker is turned on.
• Make sure that the external device is not paused or muted.
• Make sure that there are songs on your external device.
10
NS-SPBTP1-W Bluetooth Plug-in Wall Speaker
www.insigniaproducts.com
Maintaining
• To prevent fire or shock hazard, disconnect your speaker from the AC
wall outlet when cleaning.
• The finish on your speaker may be cleaned with a dust cloth and cared
for as other furniture. Use caution when cleaning and wiping the plastic
parts.
• If the speaker becomes dirty or smudged with fingerprints it may be
cleaned with a soft cloth slightly dampened with a mild soap and water
solution. Never use abrasive cloths or polishes as these will damage the
finish of your speaker.
Specifications
My external audio device
(MP3 player) won't play.
• Make sure that your external device is on and charged.
• Make sure that your external device is not paused or muted.
• Make sure that the audio cable is fully inserted into the external device and the AUX
IN jack on your speaker.
• Make sure that there are songs in your external device.
• Make sure that your external device is working properly before you connect it to your
speaker.
Caution
• Never allow water or other liquids to get inside your
speaker.
• Modifying or tampering with the internal components of
your speaker can cause a malfunction and might
invalidate its warranty. If your speaker is not performing
as it should, take it to the local dealer for assistance.
General
Bluetooth 3.0 + EDR, support A2DP, SBC
Power requirement Built-in battery
Power supply AC 120V~60Hz (built-in 300 mAh Li-ion rechargable battery)
Battery Built-in 300 mAh Li-ion rechargable battery to support music playback > 2.5 hours.
Audio output power Typical 3 W
USB port Supports 5 V at 1 A charging current (no audio playback)
Dimensions (HxWxD) 3.7 × 3.7 × 1.4 in (9.5 × 9.5 × 3.5 cm)
Problem Solution
11
NS-SPBTP1-W Bluetooth Plug-in Wall Speaker
www.insigniaproducts.com
Legal notices
FCC Part 15
This device complies with Part 15 of the FCC Rules. Operation of this product is
subject to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
This equipment has been tested and found to comply within the limits for a class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced technician for help.
FCC warning
Changes or modifications not expressly approved by the party responsible for
compliance with the FCC Rules could void the user’s authority to operate this
equipment.
Canada IC statement
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is
subject to the following two conditions: (1) this device may not cause interference, and (2)
this device must accept any interference, including interference that may cause undesired
operation of the device.
This equipment complies with IC radiation exposure limits set forth for an uncontrolled
environment.
For compatibility between the system and another device with Bluetooth technology,
consult the device's documentation and dealer. In some countries, there may be restrictions
on using Bluetooth devices. Check with your local authorities.
is a registered trademark of Bluetooth SIG, Inc.
12
NS-SPBTP1-W Bluetooth Plug-in Wall Speaker
www.insigniaproducts.com
13
NS-SPBTP1-W Bluetooth Plug-in Wall Speaker
www.insigniaproducts.com
ONE-YEAR LIMITED WARRANTY - INSIGNIA
Definitions:
The Distributor* of Insignia branded products warrants to you, the original purchaser of this new
Insignia-branded product (“Product”), that the Product shall be free of defects in the original
manufacturer of the material or workmanship for a period of one (1) year from the date of your purchase
of the Product (“Warranty Period”).
For this warranty to apply, your Product must be purchased in the United States or Canada from a Best
Buy branded or Future Shop branded retail store or online at www.bestbuy.com, www.bestbuy.ca, or
www.futureshop.ca and is packaged with this warranty statement.
How long does the coverage last?
The Warranty Period lasts for 1 year (365 days) from the date you purchased the Product. Your purchase
date is printed on the receipt you received with the Product.
What does this warranty cover?
During the Warranty Period, if the original manufacture of the material or workmanship of the Product is
determined to be defective by an authorized Insignia repair center or store personnel, Insignia will (at its
sole option): (1) repair the Product with new or rebuilt parts; or (2) replace the Product at no charge with
new or rebuilt comparable products or parts. Products and parts replaced under this warranty become
the property of Insignia and are not returned to you. If service of Products or parts are required after the
Warranty Period expires, you must pay all labor and parts charges. This warranty lasts as long as you own
your Insignia Product during the Warranty Period. Warranty coverage terminates if you sell or otherwise
transfer the Product.
How to obtain warranty service?
If you purchased the Product at a Best Buy or Future Shop retail store location, please take your original
receipt and the Product to any Best Buy or Future Shop store. Make sure that you place the Product in its
original packaging or packaging that provides the same amount of protection as the original packaging. If
you purchased the Product from a Best Buy or Future Shop online web site (www.bestbuy.com,
www.bestbuy.ca, or www.futureshop.ca), mail your original receipt and the Product to the address listed
on the web site. Make sure that you put the Product in its original packaging or packaging that provides
the same amount of protection as the original packaging.
To obtain warranty service, in the United States call 1-888-BESTBUY, Canada call 1-866-BESTBUY for Future
Shop call 1-800-663-2275. Call agents may diagnose and correct the issue over the phone.
Where is the warranty valid?
This warranty is valid only in the United States and Canada at Best Buy or Future Shop branded retail
stores or websites to the original purchaser of the product in the county where the original purchase was
made.
What does the warranty not cover?
This warranty does not cover:
• Customer instruction/education
•Installation
•Set up adjustments
• Cosmetic damage
• Damage due to weather, lightning, and other acts of God, such as power surges
•Accidental damage
•Misuse
•Abuse
•Negligence
14
NS-SPBTP1-W Bluetooth Plug-in Wall Speaker
www.insigniaproducts.com
• Commercial purposes/use, including but not limited to use in a place of business or in communal areas
of a multiple dwelling condominium or apartment complex, or otherwise used in a place of other than
a private home.
• Modification of any part of the Product, including the antenna
• Display panel damaged by static (non-moving) images applied for lengthy periods (burn-in).
• Damage due to incorrect operation or maintenance
• Connection to an incorrect voltage or power supply
• Attempted repair by any person not authorized by Insignia to service the Product
• Products sold “as is” or “with all faults”
• Consumables, including but not limited to batteries (i.e. AA, AAA, C etc.)
• Products where the factory applied serial number has been altered or removed
• Loss or Theft of this product or any part of the product
• Display panels containing up to three (3) pixel failures (dots that are dark or incorrectly illuminated)
grouped in an area smaller than one tenth (1/10) of the display size or up to five (5) pixel failures
throughout the display. (Pixel based displays may contain a limited number of pixels that may not
function normally.)
• Failures or Damage caused by any contact including but not limited to liquids, gels or pastes.
REPAIR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS YOUR EXCLUSIVE REMEDY FOR BREACH
OF WARRANTY. INSIGNIA SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES
FOR THE BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT, INCLUDING, BUT NOT
LIMITED TO, LOST DATA, LOSS OF USE OF YOUR PRODUCT, LOST BUSINESS OR LOST PROFITS. INSIGNIA
PRODUCTS MAKES NO OTHER EXPRESS WARRANTIES WITH RESPECT TO THE PRODUCT, ALL EXPRESS AND
IMPLIED WARRANTIES FOR THE PRODUCT, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES
OF AND CONDITIONS OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN
DURATION TO THE WARRANTY PERIOD SET FORTH ABOVE AND NO WARRANTIES, WHETHER EXPRESS OR
IMPLIED, WILL APPLY AFTER THE WARRANTY PERIOD. SOME STATES, PROVINCES AND JURISDICTIONS DO
NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY
NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE
OTHER RIGHTS, WHICH VARY FROM STATE TO STATE OR PROVINCE TO PROVINCE.
Contact Insignia:
For customer service please call 1-877-467-4289
www.insigniaproducts.com
INSIGNIA is a trademark of Best Buy and its affiliated companies.
Registered in some countries.
Distributed by Best Buy Purchasing, LLC
7601 Penn Ave South, Richfield, MN 55423 U.S.A.
©2014 Best Buy. All rights reserved.
Made in China
www.insigniaproducts.com
1-877-467-4289 (U.S. and Canada) or 01-800-926-3000 (Mexico)
INSIGNIA is a trademark of Best Buy and its affiliated companies.
Registered in some countries.
Distributed by Best Buy Purchasing, LLC
7601 Penn Ave South, Richfield, MN 55423 U.S.A.
©2014 Best Buy. All rights reserved.
Made in China.
V1 ENGLISH
14-0887
