Users Manual
SFQ-05
Sound Rise
Wireless Speaker with Alarm Clock
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
Safety Information
WARNINGS:
.1.
The lightning flash with arrowhead symbol,
within an equilateral triangle is intended to
alert the user to the presence of uninsulated
"dangerous voltage" within the product's
enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
DO NOT REMOVE COVER or OPEN THE CABINET.
Dangerous high voltages are present inside the enclosure.
No user serviceable parts inside. Leave all servicing to
qualified service personnel.
10. Protect the power cord from being walked
on or pinched particularly at plugs, convenience
receptacles, and the point where they exit
from the apparatus.
11. Only use attachments/accessories specified
by the manufacturer.
12. Use only with the cart, stand, tripod, bracket
or table specified by the manufacturer, or
sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning
storms or when unused for long periods of
time.
14. Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way,
such as power-supply cord or plug is damaged,
liquid has been spilled or objects have
fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not
operate normally, or has been dropped.
15. Apparatus shall not be exposed to dripping
or splashing and no objects filled with
liquids, such as vase,shall not be placed on
the apparatus.
16. The mains plug is used as disconnect device
and it shall remain readily operable during
intended use. In order to disconnect the
mains plug from the mains completely, the
mains plug should be disconnected from
the mains socket outlet completely.
17. The batteries (battery pack & batteries installed)
shall not be exposed to excessive heat such
as sunshine, fire or the like.
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these Instructions.
3. Heed all Warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install
in accordance with the manufacturer's
instructions.
8. Do not install near any heat sources such as
radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
9. Do not defeat the safety purpose of the
polarized or grounding - type plug. A polarized
plug has two blades with one wider than
the other. A grounding type plug has two
blades and a third grounding prong. The
wide blade or the third prong is provided for
your safety. If the provided plug does not fit
into your outlet, consult an electrician for
replacement of the obsolete outlet.
PORTABLE CART WARNING
(Symbol provided by RETAC)
.2.
Reorient or relocate the receiving antenna.
Increase the separation between the equipment
and receiver.
Connect the equipment into an outlet on a
circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio TV
technician for help.
Warnings: The device meets the exemption
from the routine evaluation limits in section 2.5
of RSS 102 and users can obtain Canadian
information on RF exposure and compliance
from the Canadian Representative Burnport
Holdings Ltd. 72MT Belcher Pls, East, Calgary,
Alberta, T2Z 2G1, CANADA. Tel: 403-257-4961
FCC&IC Radiation Exposure Statement
This equipment complies with FCC radiation
exposure limits set forth for an uncontrolled
environment and meets the exemption from
the routine evaluation limits in section 2.5 of
RSS 102.
1. This Transmitter must not be co-located or
operating in conjunction with any other
antenna or transmitter.
2. This equipment complies with FCC RF
radiation exposure limits set forth for an
uncontrolled environment. This equipment
should be installed and operated with a
minimum distance of 20 centimeters from
user and bystanders.
For compatibility between the SFQ-05 system
and another device with Bluetooth technology,
consult the device's documentation and dealer.
In some countries, there may be restrictions on
using Bluetooth devices. Check with your local
authorities.
is a registered trademark of Bluetooth
SIG, Inc
Please read rating label at the bottom of system
for power input and other safety information.
18. Do not place any naked flame sources, such
as lighted candles, on the apparatus.
19. The battery used in this product must be
properly recycled or disposed of. Please
contact your local recycling center for proper
battery handling and disposal instructions.
FCC and IC Information:
This device complies with Part 15 of the FCC
Rules and RSS-210 of the IC Rules. Operation is
subject to the following two conditions: (1) This
device may not cause harmful interference, and
(2) this device must accept any interference
received, including interference that may cause
undesired operation.
Canada IC statments
Le présent appareil est conforme aux CNR
d'Industrie Canada applicables aux appareils
radio exempts de licence. L'exploitation est
autorisée aux deux conditions suivantes : (1)
l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout
brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le
fonctionnement.
Warning: Changes or modifications to this unit
not expressly approved by the party responsible
for compliance could void the user's authority to
operate the equipment.
Note: This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment generates,
uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the
instructions, may cause harmful interference to
radio communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning
the equipment off and on, the user is
encouraged to try to correct the interference by
one or more of the following measures:
.3.
15 cm
(5- 15/16")
10 cm
(3- 15/16")
15 cm
(5-15/
16")
15 cm
(5-15/
16")
15 cm
(5-15/
16")
Front View:
Side View:
Front side Back side
QDID:
CAUTION
-
Proper Installation
Install the system in a place which is level, dry
and neither too hot nor too cold. The appropriate
temperature is between 5 oC and 35 oC.
Install the system in a location with adequate
ventilation to prevent internal heat from
building up inside the unit.
Leave sufficient distance between the system
and TV.
Keep the system away from TV to avoid
interference with TV.
CAUTION
-
Proper Ventilation
To avoid risk of electric shock and fire, and to
prevent damage, locate the apparatus as
follows:
Front: No obstructions and open spacing.
Sides / Top / Back: No obstructions should be
placed in the areas shown by the dimensions
below.
Bottom: Place on the level surface. Maintain an
adequate air path for ventilation by placing on a
stand with a height of 10 cm (3-15/16") or more.
Information for Users on Disposal of Old
Equipment
[European Union]
This symbol indicates that the
electrical and electronic equipment
should not be disposed as
general household waste at its
end-of-life. Instead, the product
should be handed over to the
applicable collection point for
the recycling in accordance
with your national legislation.
By disposing of this product correctly, you will
help to conserve natural resources and will help
prevent potential negative effects on the
environment and human health that could
otherwise be caused by inappropriate waste
handling of this product. For more information
about collection point and recycling of this
product, please contact your local municipal
office, your household waste disposal service or
the shop where you purchased the product.
Penalties may be applicable for incorrect
disposal of this waste, in accordance with
national legislation.
[Other Countries outside the European
Union]
If you wish to dispose of this product, please do
so in accordance with applicable national
legislation or other rules in your country for the
treatment of old electrical and electronic
equipment.
Attention:
This symbol is
only valid in the
European Union.
.4.
Getting Started ............................................................................................................... 5
Package Contents .............................................................................................................................................................. 5
Connecting the AC Adapter ........................................................................................................................................... 5
System Overview ............................................................................................................ 6
Front of the System ........................................................................................................................................................... 6
Rear of the System ............................................................................................................................................................ 6
Display Window ................................................................................................................................................................. 6
Selecting the Sound Source .......................................................................................... 7
Basic Operations ............................................................................................................ 8
Turning on/off the System ............................................................................................................................................. 8
Setting the Clock ............................................................................................................................................................... 8
Adjusting the Volume ...................................................................................................................................................... 8
Sound Mode ........................................................................................................................................................................ 8
Bluetooth ........................................................................................................................ 9
Downloading the Soundfreaq App ............................................................................................................................. 9
Establishing a Bluetooth Connection ......................................................................................................................... 9
Using Multiple Bluetooth Devices ............................................................................................................................... 10
Playing back from Macbook or Macbook Pro ......................................................................................................... 10
Playing back from PC/Notebook .................................................................................................................................. 10
iPod ................................................................................................................................. 11
Setting an iPod on the Unit ........................................................................................................................................... 11
Listening to an iPod .......................................................................................................................................................... 11
Charging an iPod ............................................................................................................................................................... 11
FM ................................................................................................................................... 13
Listening to FM Stations ................................................................................................................................................. 13
Presetting Stations ............................................................................................................................................................ 14
External Device ...............................................................................................................14
Listening to an external device .................................................................................................................................... 14
Charging an External Device ........................................................................................ 15
Using the Timer .............................................................................................................. 15
Setting the Sleep Timer ................................................................................................................................................... 15
Setting the Daily Timer .................................................................................................................................................... 15
Troubleshooting ............................................................................................................ 17
Technical Specifications ................................................................................................ 18
Contents
.5.
Package Contents
Examine whether the following package contents are all included:
Main Unit
Getting Started
AC Adaptor
Connecting the AC Adaptor
WARNING! For optimal performance, use only
the supplied AC adaptor.
• Ensure that power supply outlet matches with
the unit AC's input 100-240V~, 50/60Hz
before connection.
Connect one end of the AC adaptor to the DC
IN jack of the unit and the other end to a power
outlet.
FM Antenna
Power outlet
.6..8.
System Overview
Front View
Back View
1
2
5
6
7
8
9
3
4
10 11 12 13 14
1. Display Window
2. Sound source button
Tap repeatedly to select one of four sound
sources or enter clock setting mode.
3. Sound eect button
Toggle among Bright, Warm and Flat modes.
4. / button
Change the value for the clock, day of the
week, and alarm setting.
Adjust the volume level from 00 to 30.
5. Set button
In clock and alarm setting mode, conme the
setting.
In Bluetooth mode, place the System into
pairing mode.
In FM tuner mode, switch the frequency and
channel number.
6. / Alarm on/o button
Tap to activate or cancel the alarm.
7. Sleep button
Tap repeatedly to set the sleep timer.
8. iPod connector
9. Power/Power indicator/Snooze button
Switch between the power-on and standby
modes.
Stop temporarily the alarm sound when the
alarm is sounding.
10.Power jack
11.USB power port
12.AUX IN jack
For transmitting an audio input signals from
an external device.
13.FM jack
14.Switch button
Adjust the brightness of backlight, press with
the tip of a ponited object repeatedly to
make the display glow brighter or dimmer.
Five levels of brightness are provided to
match your bedroom environment.
Adjust the DST (Daylight Saving Time)
depending on your location and the time of
year.
.7.
Display Window
1
2
3
4 5 6
9
7
8
13 12
10
11
1. Alarm indicator
Appears when the alarm is on. Disappears
when the alarm is o.
2. Snooze indicator
Blinks while snoozing, indicating that the
alarm is paused.
3. Sleep indicator
Appears when the sleep timer is set.
4. Day of the week indicator
5. Weekday / Weekend /All days indicator
6. Bright / Warm sound eect indicator
7. AM / PM indicator
8. USB indicator
Appears when charging an external device.
9. Bell indicator
Appears when selecting the bell sound to
wake up you.
10.Sound source indicator
To indicate the currently selected sound
source.
11.Multi-functional display to indicate the
current time, alarm time, volume level,
channel, frequency, etc.
12. DST (Daylight Saving Time) indicator
Appears when the DST is activated.
13. Speaker indicator
Appears when adjusting the volume level.
Selecting the Sound Source
This system enables you to access four sound sources - Bluetooth, iPod, FM tuner and External
device.
• If you use the Soundfreaq Remote App, press the SOURCE button repeatedly on the App.
• Or, tap the button repeatedly on the System.
.8.
Basic Operation
Turning on/off the System
Press the “Power” button on the front of the
System.
The indicator on the button lights up.
Press the button again to turn o the System.
POWER button and indicator
System Dispaly
Setting the Clock and Day of Week
Note: In the clock setting mode, if the System is
idle for 30 seconds, it will turn off automatically.
1. Press the “Power” button to turn on the
System.
2. Tap the button repeatedly to select the
clock setting mode. No sound source
indicator appears on the display.
3. Tap the SET button to enter the clock setting
mode. The “Hour digit” starts blinking.
4. Tap the / to adjust the hour.
5. Tap the SET button to conrm the setting.
6. Repeat 4 and 5 to adjust the minute and
AM/PM. When the clock setting is completed,
the hour digit, minute digit and AM/PM will
blink together. Tap the SET button to conrm
the clock setting, and then enter to the “day
of week” setting.
7. Tap the / to adjust the day of week.
M-Monday, T-Tuesday, W-Wednesday,
Th-Thursday, Fr-Friday, Sat-Saturday,
Sun-Sunday.
8. Tap the SET button to conrm the setting.
Adjusting the Volume
You can adjust the volume level from 0 to 30
When one of sound sources is selected by
tapping the and buttons.
During the process of adjusting, the indicator
will appear on the display.
Sound Mode
Sound modes can be selected to enhance the
type of music being played.
Tap the TONE to select the sound mode.
Each time you tap the button, the sound mode
changes as follows:
“BRIGHT” “WARM” Cancel sound mode
.9.
Establishing a Bluetooth Connection
Notes:
• If your mobile phone supports A2DP
protocol, its music will play through the unit.
• You can make a Bluetooth connection with
an iPhone/iPad/iPod touch or any other
Bluetooth-enabled devices with iOS.
1. Press the “Power” button to turn on the
System.
• The indicator on the button is solid on when
the unit is powered on.
2. Tap the button repeatedly to select the
Bluetooth mode.
• The indicator appears on the display and
blinks slowly.
3. Tap the SET button on top of unit to put
Sound Rise in pairing mode.
• The indicator starts blinking at a fast rate.
• If you hold the SET button for more than
3 seconds during the process of pairing,
the operation will be cancelled.
4. During this period, you can operate the
mobile phone, iPad or Bluetooth-enabled
device to pair with the unit within a 33 feet
(10m) range.
• Please check the user manual of the iPad or
Bluetooth-enabled device with which you
are initiating pair to learn about Bluetooth
connection with any other devices.
5. Once the unit is detected and its name
"Sound Rise" appears on the display of your
Bluetooth-enabled device, key in the default
password "1234" if a prompt requests it.
Bluetooth
Downloading the Soundfreaq App
We have developed an App to give
you full control from your iPhone/
iPad/iPod touch while playing audio
over the Bluetooth wireless
connection, please download the
"SoundFreaq Remote" App for FREE.
After paring an iOS device with Sound Rise, you
can download the free Soundfreaq Remote App
in the Apple website and on our website:
www.soundfreaq.com
When the App installation is finished, you can
control the playback from your iOS device. The
app can be used as a remote control.
Warning!
Do not unplug the AC adaptor from the System
when playing back a track over the Bluetooth
connection.
Soundfreaq
POWER button and indicator
SET buttonSource button
.10.
• The indicator starts blinking quickly to
indicate that the unit and your device have
entered into the connection mode.
• After a Bluetooth connection is established
successfully, the indicator will be solid on.
6. Select the desired music and press "Play"
button on your device. The unit automatically
starts playing back the music.
• Try again above steps 3 to 5 if the pair
indicator starts blinking slowly after 3
minutes, the pair was unsuccessful.
Using Multiple Bluetooth Devices
Only one device can be used at a time, but you
can switch between different Bluetooth devices.
Make sure each device you want to use has
already been paired, to switch devices:
1. On Sound Rise, press the pair button.
2. On Bluetooth device, select the connection to
Sound Rise.
This device is now the connected device to
Sound Rise, (the previous connected device is
now disconnected). Repeat those steps to
switch the connected device again.
Note: If the unit has no sound output, please
check if the volume level of your Bluetooth
device connected to the unit is set to the
minimum, or the Bluetooth device is muted.
Playing back from Macbook or
Macbook Pro
1. In the desktop screen, Select the
“Open Bluetooth Preference”.
2. If there is any old “Sound Rise” records,
remove them. Click the “Continue” button to
proceed pairing process.
3. Once completed, the pairing success
screen will come out.
Note: Don’t quit the page immediately. You
may notice that the previous dialog screen
still shows the device not connected.
Just ignore it. It’s confusing to the user.
In fact, it’s connected already.
4. Open iTune, play a song. Then use the
mouse to click the Bluetooth icon at the top
right hand corner of the desktop screen,
select the “Sound Rise” option and then
select the “Use as Audio Device (Stereo)”.
After a while (a few seconds), the music will
come out from the SFQ-05. If not, select the
“Use as Audio Device (Stereo)” once again.
The Sound Quality should be good.
Playing back from PC/Notebook
1. Press the “Start” button to open the “Device
and Printers” dialog box.
2. Turn on the SFQ-05 system and press the
PAIR button on the unit to put the unit into
the pair mode.
3. Select the “Add a device” in the “Device and
Printer” dialog box. The “Sound Rise” icon
will appear on the display.
4. Double click the “Sound Rise” icon and wait
until the device has been added
successfully.
5. Click the “Close” button to close the “Device
and Printer” dialog box. A ”Sound Rise” icon
appears in the dialog box.
6. Double click the “Sound Rise” icon and the
device connection screen will be shown.
7. Click the “Connect” button in the “Music and
Audio” option.
8. Once connected, the pair indicator on the
unit will be solid on and the connection
success screen will be shown.
iPod
.11.
Setting an iPod on the Unit
• Compatible iPod models are including:
Most Apple iPod models with 30-pin dock
connectors as follows: iPad, iPod nano 6th
generation, iPod nano 5th generation (video
camera), iPod nano 4th generation (video),
iPod nano 3rd generation (video), iPod nano
2nd generation (aluminum), iPod nano 1st
generation, iPod 4th generation (color
display), iPhone, iPhone 3G/3GS, iPhone 4,
iPod classic, iPod 5th generation (video), iPod
4th generation, iPod touch 4th generation,
iPod touch 3rd generation, iPod touch 2nd
generation, iPod touch 1st generation, iPod
mini.
1. Remove the dock cover from the iPod
connector.
2. Connect your iPod. Make sure the connector
plug of unit is firmly inserted into the
connector port of iPod.
Note: In this user manual, “iPod” is used as a
general reference to functions on an iPod,
iPhone or iPad, unless otherwise specied by the
text or illustrations.
Notes:
• If you are docking your device with a case,
you can remove the spacer pad to secure a
better t and connection. Both the dock
cover and spacer pad can be conveniently
stuck along the ribs on the back of Sound
Rise.
• Always set volume to the minimum when
connecting or disconnecting the other
equipment.
• When you connect your iPod to unit, make
sure you insert it all the way.
• When placing or removing the iPod, hold the
iPod at the same angle as that of the
connector on this unit, and do not twist or
bend the iPod as connector damage may
result.
• Before disconnecting the iPod, pause
playback.
• If the battery of your iPod is extremely low,
charge it for a while before operation.
Listening to an iPod
1. Press the “Power” button to turn on the
System.
• The indicator on the button is solid on when
the unit is powered on.
2. Tap the button repeatedly to select the
iPod mode.
3. The music starts playing back automatically.
Charging an iPod
The battery of the iPod is always charged
through the unit when it is connecting to a wall
outlet.
• Charging begins when the iPod is set on the
dock.
• The charging status appears in the display on
iPod.
• The iPod is charged regardless of the sound
source selected on the unit.
• See the iPod instruction manual about the
details of iPod charging.
SOURCE Button
iPod Connector
Back of System
Top
Bottom
Stick
Dock Cover
Spacer Pad
Dock Cover
.12.
Notes for Caring Your iPod:
• The connector plug is protected with a cover
when it is first purchased. Please remove the
cover before operating the unit.
• Do not carry the unit with iPod connected.
You might drop it down or it might cause
damages to the connector part.
• Do not touch or hit the iPod terminal pins or
the connector pins directly. It might cause
damages to the connector part.
• If the iPod does not play correctly, please
update your iPod software to the latest
version. - For details about updating your
iPod, check on the Apple web site
<http://www.apple.com>.
• iPod is a trademark of Apple Inc., registered in
the U.S. and other countries.
• iPhone is a trademark of Apple Inc.
• iPad is a trademark of Apple Inc.
• We are not responsible for any loss of or
damage to iPod that might result from the
use of this product.
• Sound distortion may occur when playing back
audio sources with high recording levels.
When distortion occurs, it is recommended
to turn off the equalizer of the iPod. For
information on operating the iPod, see the
iPod instruction manual.
• "Made for iPod" and "Made for iPhone" and
"Made for iPad" mean that an electronic
accessory has been designed to connect
specifically to iPod/iPhone/iPad and has
been certified by the developer to meet
Apple performance standards.
• Apple is not responsible for the operation of
this device or its compliance with safety and
regulatory standards.
.13.
FM
1. Tap the “Power” button to turn on the
System.
• The indicator on the button is solid on when
the unit is powered on.
2. Tap the button repeatedly to select the
FM tuner mode.
3. Select a desired radio station for listening.
For details, see “Presetting a Station”)
4. Adjust the FM antenna’s length and angle
and direction until the best reception is
obtained.
5. If necessary, adjust the volume level.
Listening to a Station
Note: Position the antenna as far away as
possible from the AC adaptor, a TV, or other
radiation source.
1. Plug the supplied FM antenna into the
FM.ANT jack located on the back of unit.
Press the Button Functions
Unit
• Hold this button to enter saving mode. Press to save a channel.
(see "Presetting a station”)
• Switch between the frequency display and channel number display.
Tune the desired frequency or channel number based on the different display.
• Select a channel (from 01 to 20).
Change frequency from 87.5MHz to 108.0MHz in the FM mode.
• Hold for more than one second to activate the Auto Scan function, and then
release the button. The frequency will be scanned automatically until a radio
station is found. Or press again to quit search while searching.
Frequency display Channel number display
FM Antenna
2. Set the volume to the minimum.
3. Tap the button repeatedly to select the
AUX IN mode.
4. Start playback on the external device.
.14.
1. Select FM tuner mode with the button.
2. Switch to the frequency display if the display
is channel number.
3. Tune a desired frequency. You can use either
of the below methods to tune the frequency.
Presetting a Station
System Display
System Display
System Display
System Display
System Display
4. Hold the SET button to start storing a
station.
• The channel number starts blinking.
5. Use the / buttons on the System to
select the channel number (from 01 to 20) to
be set.
6. Press the SET button again to store the
frequency. The selected frequency will then
be stored with the preset channel number.
• The display will be switched automatically to
clock show display after a few seconds.
A. Manual Tuning - Briefly tap " "/ " "
button repeatedly to move frequency to
frequency (from 87.5 MHz to 108.0 MHz) until
you find the desired station.
B. Auto Scanning - Hold " "/ " " button
until the frequency display starts blinking.
The frequency will be scanned automatically
until a station is found.
External Device
You can enjoy the sound from an optional
component such as a digital music player
through the speakers of this unit. Be sure to
turn off the power of each component before
making any connections. For details, refer to the
instruction manual of the component to be
connected.
Connect an external device to the AUX IN jack
on the back panel of the System using a stereo
audio cable.
1. Tap the “Power” button to turn on the
System.
• The indicator on the button is solid on when
the unit is powered on.
To audio output such as
CD/MD/digital music
player, etc.
Charging an External Device
Using the Timer
.15.
The USB power jack can be used to charge most
devices that allow for USB charging (including
many mobile phones, smart phones and
wireless headsets).
Note: Please use the USB power cord that came
with your device to connect to Sound Rise to
charge.
1. Tap the “Power” button to turn on the
System.
• The indicator on the button is solid on when
the unit is powered on.
USB power jack
Setting the Sleep Timer
1. Tap the button on the front of the
System. The time on the display will blink.
Each time you tap the button, the shutoff
time (in minute) changes as follows:
15 30 60 90 120 OFF
To check the remaining time before the System
shuts off, press the button once.
To cancel the sleep timer, press the button
repeatedly until the “SLEEP” indicator on the
display is disppear.
Display Window
Display Window
Setting the Daily Timer
Using the daily timer (Playback timer), you can
wake up with your favorite music.
Notes:
• Set the clock before setting the daily timer.
• Connect a Bluetooth device, dock an iPod,
tune into a station and connect an external
device to the System, and make sure that the
source works properly beforehand.
• Perform each setting within 10 seconds.
Otherwise, setting will be cleared and the
procedure must be repeated from the
beginning.
1. Tap the / button.
• The / indicator appears on the
display window.
2. Tap the SET button to enter to alarm setting
mode.
3. Tap the or to adjust the hour of the
starting time.
• When you hold the button, the hour digit
changes continuously.
4. Tap the SET button to confirm the setting.
5. Repeat 3 and 4 to adjust the minute of the
starting time, the hour and minute of the
finish time, and select the AM/PM, day of the
week, sound source and the volume.
6. Press the “Power” button to turn off the
System, if necessary.
.16.
Cancelling the Daily Timer
1. Tap the / button. The alarm time will
show on the display.
2. Tap the button again to cancel the timer.
• The / indicator on the display goes
out.
.17.
• Remove and reconnect the AC power plug and turn on the system again.
The system does not react
when the buttons are
pressed.
• The system enters the saving energy mode. The unit does not connect with
any audio source for more than 20 minutes. Turn on the system again and
play back an audio source.
The system is suddenly
powered off.
• The unit may be powered off and powered on when playing back a track via
Bluetooth connection. You need to make the connection again.
No sound output is via Bluetooth
or Bluetooth connection cannot
be restored automatically.
Troubleshooting
In These Cases Check the following points
Check this list for a possible troubleshooting solution before calling for service.
• AC adaptor is not inserted securely. Plug in securely.
• Is the connector plug of the unit firmly inserted into the connector port of
the iPad/iPhone/iPod?
• Is the iPad/iPhone/iPod properly functioning? Test the iPad/iPhone/iPod
functions in stand-alone condition.
• Is the connector plug of the unit firmly inserted into the connector port
of the iPad/iPhone/iPod?
• Is the AC adaptor plug firmly inserted into DC IN jack of the unit?
• The path between the remote control and the sensor on the unit is
blocked.
• The battery of remote control is exhausted.
Hard to listen to broadcasts
because of noise.
• The antenna is not properly extended or positioned.
• Tune to the correct radio channel/frequency.
• Making sure the antenna is further away from any equipment that may be
causing the noise or interference.
Power does not come on.
Cannot operate
iPad/iPhone/iPod.
iPad/iPhone/iPod cannot be
charged.
Unable to operate the
System from the remote
control.
No sound output.
• Check if the volume level is set to the minimum.
• Check if the volume level of your Bluetooth device connected to the system is
set to the minimum.
• Check to make sure your Bluetooth device is not muted.
• Maybe your USB cable is not supported by the system, please try to use
another USB cable.
If you find USB charging
cannot perform after
connecting your device to the
USB jack on the unit.
Bluetooth connection cannot
be established.
• When making a Bluetooth connection between the unit and your device for
the first time, if the connection is fail, you need to power off your device and
power on again to clear the device name, and make the connection again.
.18.
External DC IN (for AC adaptor), AUX IN
DC 12 V 2.5 A (External DC IN)
Input: AC 100-240V, 50/60Hz
Output: DC 12 V 2.5 A
148 mm (W) * 220 mm (H) * 143mm (D)
1.48Kg
Model
Type
Support Bluetooth
Support Profile
Bluetooth 1.2, 2.0 and 2.1 compliant
Sound Rise
A2DP
Input Sensitivity AUX Input ? mV
Tuner
Band
Tuning Range
Frequency Step
Preset Stations
Input Terminal
Power Source
AC Adaptor
Dimensions (Approx.)
Weight
Technical Specifications
SFQ-05
FM
87.5 ~ 108.0 MHz
100 KHz
20
Save this manual
