Beautiful Enterprise SFQ09 Double Spot User Manual SFQ 09 0109 x
Beautiful Enterprise Co., Ltd. Double Spot SFQ 09 0109 x
User Manual
Double Spot
SFQ-09
User Manual
2
Safety Information
IMPORTANT SAFETY
INSTRUCTIONS
1. Read these instructions.
2. Keep these Instructions.
3. Heed all Warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings.
Install in accordance with the
manufacturer's instructions.
8. Do not install near any heat sources such
as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that
produce heat.
9. Do not defeat the safety purpose of the
polarized or grounding - type plug. A
polarized plug has two blades with one
wider than the other. A grounding type plug
has two blades and a third grounding prong.
The wide blade or the third prong is
provided for your safety. If the provided plug
does not fit into your outlet, consult an
electrician for replacement of the obsolete
outlet.
10. Protect the power cord from being walked
on or pinched particularly at plugs,
convenience receptacles, and the point
where they exit from the apparatus.
11. Only use attachments/accessories
specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket
or table specified by the manufacturer, or
sold with the apparatus. When a cart is
used, use caution when moving the
cart/apparatus combination to avoid injury
from tip-over.
PORTABLE CART WARNING
(Symbol provided by RETAC)
13. Unplug this apparatus during lightning
storms or when unused for long periods of
time.
14. Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way,
such as power-supply cord or plug is
damaged, liquid has been spilled or objects
have fallen into the apparatus, the
apparatus has been exposed to rain or
moisture, does not operate normally, or has
been dropped.
15. Apparatus shall not be exposed to dripping
or splashing and no objects filled with
liquids, such as vase,shall not be placed on
the apparatus.
16. The mains plug is used as disconnect
device and it shall remain readily operable
during intended use. In order to disconnect
the mains plug from the mains completely,
the mains plug should be disconnected
from the mains socket outlet completely.
17. The batteries (battery pack & batteries
installed) shall not be exposed to excessive
heat such as sunshine, fire or the like.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
WARNINGS:
The lightning flash with arrowhead symbol,
within an equilateral triangle is intended to
alert the user to the presence of uninsulated
"dangerous voltage" within the product's
enclosure that may be of sufficient
magnitude to constitute a risk of electric
shock to persons.
TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS APPLIANCE TO
RAIN OR MOISTURE.
DO NOT REMOVE COVER or OPEN THE CABINET.
Dangerous high voltages are present inside the
enclosure. No user serviceable parts inside. Leave all
servicing to qualified service personnel.
3
18. Do not place any naked flame sources,
such as lighted candles, on the apparatus.
19. The battery used in this product must be
properly recycled or disposed of. Please
contact your local recycling center for
proper battery handling and disposal
instructions.
FCC and IC Information:
This device complies with Part 15 of the FCC
Rules and RSS-210 of the IC Rules. Operation
is subject to the following two conditions: (1)
This device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
Canada IC statments
Le présent appareil est conforme aux CNR
d'Industrie Canada applicables aux appareils
radio exempts de licence. L'exploitation est
autorisée aux deux conditions suivantes: (1)
l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout
brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le
fonctionnement.
Warning: Changes or modifications to this unit
not expressly approved by the party responsible
for compliance could void the user's authority to
operate the equipment.
Note: This equipment has been tested and
found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC
Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment
generates, uses, and can radiate radio
frequency energy and, if not installed and used
in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does cause
harmful interference to radio or television
reception, which can be determined by turning
the equipment off and on, the user is
encouraged to try to correct the interference by
one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the
equipment and receiver.
Connect the equipment into an outlet on a
circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio
TV technician for help.
Warnings: The device meets the exemption
from the routine evaluation limits in section 2.5
of RSS 102 and users can obtain Canadian
information on RF exposure and compliance
from the Canadian Representative Burnport
Holdings Ltd. 72MT Belcher Pls, East, Calgary,
Alberta, T2Z 2G1, CANADA. Tel: 403-257-4961
FCC&IC Radiation Exposure
Statement
This equipment complies with FCC radiation
exposure limits set forth for an uncontrolled
environment and meets the exemption from the
routine evaluation limits in section 2.5 of RSS
102.
1. This Transmitter must not be co-located or
operating in conjunction with any other
antenna or transmitter.
2. This equipment complies with FCC RF
radiation exposure limits set forth for an
uncontrolled environment. This equipment
should be installed and operated with a
minimum distance of 20 centimeters from
user and bystanders.
Le dispositif rencontre l'exemption des limites
courantes d'évaluation dans la section 2.5 de
RSS 102 et la conformité à l'exposition de
RSS-102 rf, utilisateurs peut obtenir
l'information canadienne sur l'exposition et la
conformité de rf.
For compatibility between the system and
another device with Bluetooth technology,
consult the device's documentation and dealer.
In some countries, there may be restrictions on
using Bluetooth devices. Check with your local
authorities.
is a registered trademark of Bluetooth
SIG, Inc
Please read rating label at the bottom of system
for power input and other safety information.
4
CAUTION - Proper Installation
Install the system in a place which is level,
dry and neither too hot nor too cold. The
appropriate temperature is between 5
o
C
and 35
o
C.
Install the system in a location with
adequate ventilation to prevent internal heat
from building up inside the unit.
Leave sufficient distance between the
system and TV.
Keep the system away from TV to avoid
interference with TV.
CAUTION - Proper Ventilation
To avoid risk of electric shock and fire, and to
prevent damage, locate the apparatus as
follows:
Front: No obstructions and open spacing.
Sides / Top / Back: No obstructions should be
placed in the areas shown by the dimensions
below.
Bottom: Place on the level surface. Maintain an
adequate air path for ventilation by placing on a
stand with a height of 10cm (3-15/16") or more.
Front View:
Side View:
Information for Users on
Disposal of Old Equipment
[European Union]
This symbol indicates that the
electrical and electronic
equipment should not be
disposed as general household
waste at its end-of-life. Instead,
the product should be handed
over to the applicable collection
point for the recycling in
accordance with your national
legislation.
By disposing of this product correctly, you will
help to conserve natural resources and will help
prevent potential negative effects on the
environment and human health that could
otherwise be caused by inappropriate waste
handling of this product. For more information
about collection point and recycling of this
product, please contact your local municipal
office, your household waste disposal service or
the shop where you purchased the product.
Penalties may be applicable for incorrect
disposal of this waste, in accordance with
national legislation.
[Other Countries outside the European
Union]
If you wish to dispose of this product, please do
so in accordance with applicable national
legislation or other rules in your country for the
treatment of old electrical and electronic
equipment.
QDID: B022149
15 cm
(5-
15
/
16
")
15 cm
(5-
15
/
16
")
15 cm
(5-
15
/
16
")
10 cm
(3-
15/16
")
15 cm
(5-
15/
16
")
Fr on t si de Back si d e
Attention:
This symbol
is only valid
in the
European
Union.
5
Contents
Getting Started ............................................................................................ 6
Package Contents ............................................................................................................................ 6
Connecting to the AC Power Adapter ............................................................................................. 6
Using the Battery Pack (Optional) ............................................................. 7
Installing the Battery Pack ............................................................................................................... 7
Charging the Battery Pack ............................................................................................................... 7
Checking Battery Power .................................................................................................................. 8
System Overview ........................................................................................ 9
Top View ........................................................................................................................................... 9
Rear View ....................................................................................................................................... 10
Bottom View ................................................................................................................................... 10
Basic Operation ........................................................................................ 11
Turning on/off the System ............................................................................................................... 11
Adjusting the Volume .............................................................................................................. ........ 11
Selecting a Sound Mode ................................................................................................................ 11
Activating the Power Saving Mode ................................................................................................ 11
Selecting the Sound Source .................................................................... 12
Playing back via Bluetooth ...................................................................... 13
Establishing a Bluetooth Connection ............................................................................................ 13
Using Multiple Bluetooth Devices .................................................................................................. 13
Playing back from Macbook or Macbook Pro ............................................................................... 14
Playing back from PC/Notebook ................................................................................................... 14
Playing back from External Source ......................................................... 15
Charging an External Device ................................................................... 16
Optimizing Sound Quality ........................................................................ 17
Troubleshooting .................... ................... ................... ................... ........... 18
Technical Specifications .......................................................................... 19
6
Getting Started
Package Contents
Examine whether the following package contents are all included:
Main Unit AC Power Adapter Audio Cable
Quick Start Guide Safety Card Warranty Card
Connecting to the AC Power Adapter
WARNING! For optimal performance, use only the supplied AC power adapter.
Ensure that power supply outlet matches with the unit AC's input 100V~240V, 50/60Hz before
connection.
Connect one end of the AC power adapter to DC IN jack, and the other end to an electrical outlet
only after all other connections are completed.
Quick Start Guide
Safety Card
Warranty Card
Power outlet
7
Using the Battery Pack (Optional)
The system has been designed to equip with a separate battery pack (purchased separately) to
give you portable power without using the AC power adapter.
Installing the Battery Pack
1. Twist the screw clockwise from CLOSE to OPEN ( ), and push down to remove the battery
cover ( ).
2. Insert the Battery Pack and press it gently to lock in place.
3. Reverse Step 1 above to close the battery cover.
Charging the Battery Pack
After installing successfully, plug the AC power adapter to start charge the battery Pack.
During charging, the charging LED indicator combination with the button will indicate the
charging status as follows:
System Mode During Charging Charging Complete
Standby Blinks in green at a slow rate. Off
Power on but in idle mode Blinks in green. Blinks in white.
Bluetooth mode or AUX IN
mode
Remains on in green. Remains on in white.
Notes:
It takes about 3 hours to charge the battery from empty to full when the system is in standby
mode. Time may vary depending on the temperature or conditions of use.
The battery will give you portable power for up to 6 hours playback time. The playback time
may vary depending on the temperature or conditions of use.
Do not dispose of system in fire; battery may explode or leak.
B
B B
A
8
Type: Li-Ion Battery
Model No: LC18650
Rated Voltage: 7.4V
Capacity: 1800mAh
WARNING！
There is a danger of explosion if the battery is incorrectly replaced. Replace it only with the same
or equivalent type. Do not expose it to excessive heat such as sunshine, fire, etc., where it would
be exposed to high temperatures above 60°C.
Checking Battery Power
When the system is on using the battery power and in idle mode, press and hold the VOL+ and
VOL– buttons simultaneously on the system to check the battery power by the LED indicator.
Status Color Battery Power
Fast blinking (4 times) Green 66%-100%
Fast blinking (3 times) Green 36%-65%
Fast blinking (2 times) Green 15%-35%
Note:
During operations in battery mode, if the LED indicator blinks alternately in white and green
at a slow rate, it indicates the battery power is less than 15%; then you need to connect the
AC power adapter to charge it in time.
9
System Overview
Top View
1. VOL– button
Press to decrease the volume level.
2. VOL+ button
Press to increase the volume level.
3. << (Previous/Rewind) button
In Bluetooth mode, press to skip to the
start of the current track or skip to
previous track. Hold to rewind a track
fast.
4. ►(Play/Pause) button
In Bluetooth mode, tap to play or pause a
track.
5. >> (Next/fast forward) button
In Bluetooth mode, tap to skip to next
track. Hold to fast-forward a track.
6. PAIR button
Press to put the system into pairing
mode.
7. (On/Standby) button
Press to switch between standby and
power-on modes.
LED Indicator
- Illuminates and indicates the battery
pack charging status. (See Charging
the Battery Pack section)
- When powering on, illuminates and
blinks in white, and blinks once when
any button is pressed.
- When powering on, indicates the
pairing state.
- When powering on in battery mode
without Bluetooth and AUX connection,
indicates the battery pack power by
holding VOL+ and VOL– buttons at the
same time. (See Checking Battery
Power section)
- When powering on, indicates the state
of power saving mode by holding PAIR
and the ► buttons at the same time.
1234567
10
Rear View
Bottom View
8. DC IN jack
Connect to AC power Adapter.
9. POWER OUT jack
Charges your external USB devices.
10. AUX IN jack
Inputs audio signals from an external
device.
11. switch
Slide to activate or deactivate the UQ3
(High Definition Wide Stereo) sound
effect.
12. TONE switch
Slide to switch EQ settings among
WARM, FLAT, and BRIGHT.
13. Battery Pack compartment
8 9 10 11 12
13
11
Basic Operation
Turning on/off the System
Press the button on the top to turn on the
System.
Press the button again to turn off the
System.
Adjusting the Volume
You can adjust the volume level when one of
sound sources is selected by pressing the
VOL+/– buttons.
Each time you press VOL+ or VOL– button,
the LED indicator will blink once in white. If
the system is at minimum volume level (or at
maximum volume level), then press VOL–
button (or VOL+ button), the LED indicator
will keep its status as before without any
action.
Selecting a Sound Mode
Sound modes can be selected to enhance
the type of music being played. You can
select one sound mode of WARM, FLAT,
and BRIGHT by sliding the TONE switch on
the back of the system.
Activating the Power Saving
Mode
Press and hold PAIR button and the ►
button together to disable or enable the
Power Saving mode:
The LED indicator blinks twice in green
to indicate Power Saving mode is off.
The system will keep on all the time.
The LED indicator blinks once in green to
indicate the Power Saving mode is
activated. The system will power off
automatically when the system is in idle
mode for 45 minutes.
Note:
If you turn off the system manually, the
system will activate the Power Saving
mode automatically next time even if you
disabled it before.
12
Selecting the Sound Source
This system enables you to access two sound sources – AUX IN and Bluetooth.
If AUX IN jack has been inserted, the sound source will switch to AUX IN mode automatically.
Remove the audio cable from the AUX IN jack, the sound source will switch to Bluetooth
mode automatically.
When a Bluetooth connection has been established and the system is in Bluetooth mode,
once you insert audio cable, the system will suspend the Bluetooth playback and switch to
AUX IN mode.
To resume the Bluetooth playback, you need to remove the audio cable from the AUX IN
jack, and press the ► button.
13
Playing back via Bluetooth
Establishing a Bluetooth
Connection
Notes:
If your mobile phone supports A2DP,
AVRCP profiles, its music will play
through the system.
You can make a Bluetooth connection
with a mobile phone, an
iPhone/iPad/iPod touch or any other
Bluetooth-enabled devices.
1. Press the button to turn on the
system.
The LED indicator on top panel
illuminates and blinks in white.
2. Press PAIR button on top of system to
put it in pairing mode.
The indicator starts blinking at a fast rate.
If you press and hold the PAIR button for
more than 2 seconds during the process
of pairing, the operation will be canceled.
3. During this period, you can operate the
mobile phone, iPad or Bluetooth-enabled
device to pair with the system within a 33
feet (10m) range.
Please check the user manual of the
iPad or Bluetooth-enabled device with
which you are initiating pair to learn
about Bluetooth connection with any
other devices.
4. Once the system is detected and its
name Double Spot appears on the
display of your Bluetooth-enabled device,
then select the system on the display.
Key in the default password 1234 if a
prompt requests it.
The LED indicator on top panel starts
blinking quickly to indicate that the
system and your device have entered
into the connection mode.
After a Bluetooth connection is
established successfully, the LED
indicator will remain on in white.
5. Select the desired music and press Play
button on your device. The system
automatically starts playing back the
music.
Before starting playback via Bluetooth,
make sure the AUX IN jack is not
inserted using audio cable.
Try again above steps 2 to 4 if the LED
indicator blinks slowly after blinking
quickly for 3 minutes, the pair was
unsuccessful.
Using Multiple Bluetooth Devices
Only one device can be used at a time, but
you can switch between different Bluetooth
devices.
Make sure each device you want to use has
already been paired, to switch devices:
1. On Double Spot, press and hold PAIR
button for 2 second.
2. On Bluetooth device, select the
connection to Double Spot.
This device is now the connected device to
Double Spot, (the previous connected device
is now disconnected). Repeat those steps to
switch the connected device again.
Notes:
If the system has no sound output,
please check if the volume level of your
Bluetooth device connected to the
system is set to the minimum, or the
Bluetooth device is muted.
Ensure that the audio cable has been
removed from the AUX IN jack.
14
Playing back from Macbook or
Macbook Pro
1. In the desktop screen, select the Open
Bluetooth Preference.
2. If there are any old Double Spot records,
remove them. Click the Continue button
to continue pairing process.
3. Once completed, the pairing success
screen will come out.
Note:
Don’t quit the page immediately. You
may notice that the previous dialog
screen still shows the device not
connected. Just ignore it. It’s confusing
to the user. In fact, it’s connected
already.
4. Open iTune, play a song. Then use the
mouse to click the Bluetooth icon at the
top right hand corner of the desktop
screen, select the Double Spot option
and then select the Use as Audio
Device (Stereo). After a while (a few
seconds), the music will come out from
the system. If not, select the Use as
Audio Device (Stereo) once again. The
Sound Quality should be good.
Playing back from PC/Notebook
1. Press the Start button to open the
Device and Printers dialog box.
2. Turn on the system, then press PAIR
button to put into the pairing mode.
3. Select the Add a device in the Device
and Printer dialog box. The Double
Spot icon will appear on the display.
4. Double click the Double Spot icon and
wait until the device has been added
successfully.
5. Click the Close button to close the
Device and Printer dialog box. A
Double Spot icon appears in the dialog
box.
6. Double click the Double Spot icon and
the device connection screen will be
shown.
7. Click the Connect button in the Music
and Audio option.
8. Once connected, the LED indicator on
the system will be solid on in white and
the connection success screen will be
shown.
15
Playing back from External Source
You can enjoy the sound from an optional component such as a digital music player through the
speakers of this system. Be sure to turn off the power of each component before making any
connections. For details, refer to the instruction manual of the component to be connected.
Connect an external device to the AUX IN jack on the back panel of the system using a stereo
audio cable (supplied).
Notes:
When the audio cable is connected to the AUX IN jack, the system will switch to the AUX IN
mode automatically.
In order to save the energy, please plug off the AUX-IN cable when do not use.
1. Press the button to turn on the system.
2. Set the volume to the minimum position.
3. Start playback on the external device.
4. Adjust the volume to meet your listening requirement.
To audio output such
as CD/MD/digital
music player, etc.
16
Charging an External Device
The POWER OUT jack can be used to charge most devices that allow for USB charging
(including many mobile phones, smart phones and wireless headsets).
Connect one end of USB power cord to POWER OUT jack of the system, and the other end to
your USB device.
When Double Spot is using the power supply, simply connect your device to Double Spot to
begin charging.
When Double Spot is using the power of Battery Pack (purchased separately), connect your
device to Double Spot, and turn on the system to begin charging.
Notes:
Please use the USB power cord that came with your device to connect to Double Spot to
charge.
When using the Battery Pack power, if the battery power is less than 15%, the charging
function will be unavailable.
When the system is operating by Battery Pack only and charging external device at the same
time, when the Battery Pack power level is low, it is suggested to keep playback volume to
low/medium level to avoid sudden turn off of the system when the Battery Pack is drained off
by the external device
To external USB devices,
such as mobile, smart-
phone, etc.
17
Optimizing Sound Quality
TM is proprietary technology that enhances stereo separation.
To turn UQ3 on/off, slide the switch.
Slide Tone switch to select a WARM, FLAT or BRIGHT tone for your listening preference.
TIP: Sound Spot Stereo has been tuned to a balanced acoustic profile. You can use the EQ
settings on your playback device to further customize the EQ balance to suit your personal
preference. Note: Some custom EQ settings when combined with UQ3 enhancement may
cause distortion.
TIP: For playback in Bluetooth or Aux mode, the output volume is set by both the volume control
on Sound Spot Stereo and the source device. Both may be adjusted to set your preferred
listening volume. Typically, sound quality is best when the volume of the source device is
between 70~90%. Note: As with any speaker system, if the volume on both your source device
and the speaker are at maximum output, it is possible to overdrive the speakers and cause
distortion. When using an iOS device or other device that offers a “volume limit” feature, turn this
setting off for higher volume listening in Bluetooth or Aux mode.
18
Troubleshooting
Check this list for a possible troubleshooting solution before calling for service.
In These Cases Check the Following Points
Power does not come on AC power adaptor is not inserted securely. Plug in
securely.
When using the battery pack, the battery power is too low.
Charge the battery.
No sound output Check if the volume level of the system is set to the
minimum.
When in Bluetooth mode, check if the volume level of your
Bluetooth device is set to the minimum or muted; check if
your audio cable is connected to the AUX IN jack of the
system. Unplug the cable.
When in AUX IN mode, check if your external device is set
to the minimum or muted.
The system is powered off
automatically
The system enters the saving energy mode. The system
does not connect with any audio source for more than 45
minutes. Turn on the system again and play back an audio
source.
If using the battery pack, check if the battery pack is
exhausted. Connect AC power adapter and turn on the
system again.
Bluetooth connection
cannot be restored
automatically
The system may be powered off and powered on when
playing back a track over Bluetooth connection. You need
to make the connection again.
If you find USB charging
cannot perform after
connecting your device to
the POWER OUT jack on
the system
Maybe your USB cable is not supported by the system,
please try to use another USB cable.
The battery power of the system is less than 15%.
Bluetooth connection
cannot be established
When making a Bluetooth connection between the system
and your device for the first time, if the connection is fail,
you need to power off your device and power on again to
clear the device name, and make the connection again.
19
Technical Specifications
Model SFQ-09
Type Double Spot
Support Bluetooth Bluetooth 1.2, 2.0 and 2.1 compliant
Support Profile A2DP, AVRCP
Input Sensitivity AUX Input 1000mV
Input Terminal External DC IN, AUX IN
Power Source DC IN 12V/2.5A
Dimensions (Approx.) 280mm (L) x 80mm (D) x 112mm (H)
Weight 845g (without Battery pack)
Design and specifications are subject to change without notice.
Save this manual
