User Manual
Pocket Kick
SFQ-10
User Manual
2
Safety Information
IMPORTANT SAFETY
INSTRUCTIONS
1. Read these instructions.
2. Keep these Instructions.
3. Heed all Warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings.
Install in accordance with the
manufacturer's instructions.
8. Do not install near any heat sources such
as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that
produce heat.
9. Do not defeat the safety purpose of the
polarized or grounding - type plug. A
polarized plug has two blades with one
wider than the other. A grounding type plug
has two blades and a third grounding prong.
The wide blade or the third prong is
provided for your safety. If the provided plug
does not fit into your outlet, consult an
electrician for replacement of the obsolete
outlet.
10. Protect the power cord from being walked
on or pinched particularly at plugs,
convenience receptacles, and the point
where they exit from the apparatus.
11. Only use attachments/accessories
specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket
or table specified by the manufacturer, or
sold with the apparatus. When a cart is
used, use caution when moving the
cart/apparatus combination to avoid injury
from tip-over.
PORTABLE CART WARNING
(Symbol provided by RETAC)
13. Unplug this apparatus during lightning
storms or when unused for long periods of
time.
14. Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way,
such as power-supply cord or plug is
damaged, liquid has been spilled or objects
have fallen into the apparatus, the
apparatus has been exposed to rain or
moisture, does not operate normally, or has
been dropped.
15. Apparatus shall not be exposed to dripping
or splashing and no objects filled with
liquids, such as vase,shall not be placed on
the apparatus.
16. The mains plug is used as disconnect
device and it shall remain readily operable
during intended use. In order to disconnect
the mains plug from the mains completely,
the mains plug should be disconnected
from the mains socket outlet completely.
17. The batteries (battery pack & batteries
installed) shall not be exposed to excessive
heat such as sunshine, fire or the like.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
WARNINGS:
The lightning flash with arrowhead symbol,
within an equilateral triangle is intended to
alert the user to the presence of uninsulated
"dangerous voltage" within the product's
enclosure that may be of sufficient
magnitude to constitute a risk of electric
shock to persons.
TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS APPLIANCE TO
RAIN OR MOISTURE.
DO NOT REMOVE COVER or OPEN THE CABINET.
Dangerous high voltages are present inside the
enclosure. No user serviceable parts inside. Leave all
servicing to qualified service personnel.
3
18. Do not place any naked flame sources,
such as lighted candles, on the apparatus.
19. The battery used in this product must be
properly recycled or disposed of. Please
contact your local recycling center for
proper battery handling and disposal
instructions.
FCC Information:
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two
conditions: (1) This device may not cause
harmful interference, and (2) this device must
accept any interference received, including
interference that may cause undesired
operation.
Canada IC statements
This device complies with Industry Canada
licence-exempt RSS standard(s).Operation is
subject to the following two conditions: (1) this
device may not cause interference, and (2) this
device must accept any interference, including
interference that may cause undesired
operation of the device.
Le présent appareil est conforme aux CNR
d'Industrie Canada applicables aux appareils
radio exempts de licence. L'exploitation est
autorisée aux deux conditions suivantes: (1)
l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout
brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le
fonctionnement.
CAN ICES-3 (B)/NMB-3 (B)
Warning: Changes or modifications to this unit
not expressly approved by the party responsible
for compliance could void the user's authority to
operate the equipment.
Note: This equipment has been tested and
found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC
Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment
generates, uses, and can radiate radio
frequency energy and, if not installed and used
in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does cause
harmful interference to radio or television
reception, which can be determined by turning
the equipment off and on, the user is
encouraged to try to correct the interference by
one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the
equipment and receiver.
Connect the equipment into an outlet on a
circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio
TV technician for help.
Warnings: The device meets the exemption
from the routine evaluation limits in section 2.5
of RSS 102 and users can obtain Canadian
information on RF exposure and compliance
from the Canadian Representative Burnport
Holdings Ltd. 72MT Belcher Pls, East, Calgary,
Alberta, T2Z 2G1, CANADA. Tel: 403-257-4961
FCC&IC Radiation Exposure
Statement
This equipment complies with FCC radiation
exposure limits set forth for an uncontrolled
environment and meets the exemption from the
routine evaluation limits in section 2.5 of RSS
102.
1. This Transmitter must not be co-located or
operating in conjunction with any other
antenna or transmitter.
2. This equipment complies with FCC RF
radiation exposure limits set forth for an
uncontrolled environment. This equipment
should be installed and operated with a
minimum distance of 20 centimeters from
user and bystanders.
Le dispositif rencontre l'exemption des limites
courantes d'évaluation dans la section 2.5 de
RSS 102 et la conformité à l'exposition de
RSS-102 rf, utilisateurs peut obtenir
l'information canadienne sur l'exposition et la
conformité de rf.
4
For compatibility between the system and
another device with Bluetooth technology,
consult the device's documentation and dealer.
In some countries, there may be restrictions on
using Bluetooth devices. Check with your local
authorities.
is a registered trademark of Bluetooth
SIG, Inc
Please read rating label at the bottom of system
for power input and other safety information.
CAUTION - Proper Installation
Install the system in a place which is level,
dry and neither too hot nor too cold. The
appropriate temperature is between 5oC
and 35 oC.
Install the system in a location with
adequate ventilation to prevent internal heat
from building up inside the unit.
Leave sufficient distance between the
system and TV.
Keep the system away from TV to avoid
interference with TV.
CAUTION - Proper Ventilation
To avoid risk of electric shock and fire, and to
prevent damage, locate the apparatus as
follows:
Front: No obstructions and open spacing.
Sides / Top / Back: No obstructions should be
placed in the areas shown by the dimensions
below.
Bottom: Place on the level surface. Maintain an
adequate air path for ventilation by placing on a
stand with a height of 10cm (3-15/16") or more.
Front View:
Side View:
Information for Users on
Disposal of Old Equipment
[European Union]
This symbol indicates that
the electrical and electronic
equipment should not be
disposed as general
household waste at its
end-of-life. Instead, the
product should be handed
over to the applicable
collection point for the
recycling in accordance with
your national legislation.
Attention:
This symbol
is only valid in
the European
Union.
By disposing of this product correctly, you will
help to conserve natural resources and will help
prevent potential negative effects on the
environment and human health that could
otherwise be caused by inappropriate waste
handling of this product. For more information
about collection point and recycling of this
product, please contact your local municipal
office, your household waste disposal service or
the shop where you purchased the product.
Penalties may be applicable for incorrect
disposal of this waste, in accordance with
national legislation.
[Other Countries outside the European
Union]
If you wish to dispose of this product, please do
so in accordance with applicable national
legislation or other rules in your country for the
treatment of old electrical and electronic
equipment.
QDID: xxxxxxx
15 cm
(5-
15
/
16
")
15 cm
(5-
15
/
16
")
15 cm
(5-
15
/
16
")
10 cm
(3-
15
/
16
")
15 cm
(5-
15
/
16
")
Front side
Back si d e
15 cm
(5-
15
/
16
")
5
Contents
Getting Started ............................................................................................ 6
Package Contents ............................................................................................................................ 6
Charging the Built-in Battery ........................................................................................................... 6
Checking Battery Power .................................................................................................................. 7
System Overview ........................................................................................ 8
Left View ........................................................................................................................................... 8
Right View ........................................................................................................................................ 8
Basic Operation .......................................................................................... 9
Turning on/off the System ................................................................................................................ 9
Adjusting the Volume ....................................................................................................................... 9
Activating the Power Saving Mode ................................................................................................. 9
Selecting the Sound Source .................................................................... 10
Playing back via Bluetooth ...................................................................... 11
Establishing a Bluetooth Connection ............................................................................................. 11
Using Multiple Bluetooth Devices ................................................................................................... 11
Playing back from Macbook or Macbook Pro ............................................................................... 12
Playing back from PC/Notebook ................................................................................................... 12
Playing back from External Source ......................................................... 13
Using Hands-free Calling ......................................................................... 14
Making a Call ................................................................................................................................. 14
Receiving a Call ............................................................................................................................. 14
Ending a Call .................................................................................................................................. 14
Rejecting a Call .............................................................................................................................. 14
Troubleshooting .......... .................. ................... ................... ................... ... 15
Technical Specifications .......................................................................... 16
6
Getting Started
Package Contents
Examine whether the following package contents are all included:
Main Unit USB Power Cable Audio Cable
Quick Start Guide Safety Card Warranty Card
Charging the Built-in Battery
To charge the built-in battery of the system, connect the micro plug of the USB power cable to
the USB power port of the system and the standard plug to USB power outlet such as PC USB
port, USB power adapter. For optimal performance, use only the supplied USB power cable.
Quick Start Guide
Safety Card
Warranty Card
To USB power
outlet, such as
computer, phone
or tablet charger.
7
During charging, the charging LED indicator combination with Power Switch will indicate the
charging status as follows:
System Mode During Charging Charging Complete
Standby Blinks in green at a slow rate. Blinks in white at a slow rate.
Power on but in idle mode Blinks in green. Blinks in white.
Bluetooth mode or AUX IN
mode
Remains on in green. Remains on in white.
Notes:
The battery cannot be replaced by the user.
It takes about 3 hours to charge the battery from empty to full when the system is in standby
mode. Time may vary depending on the temperature or conditions of use.
The built-in battery will give you portable power for up to 10 hours playback time. The
playback time may vary depending on the temperature or conditions of use.
Do not dispose of system in fire; battery may explode or leak.
Type: Lithium-Polymer Rechargeable
Model No: MLP563450
Rated Voltage: 3.7V
Capacity: 1130mAh
WARNING！
There is a danger of explosion if the battery is incorrectly replaced. Replace it only with the same
or equivalent type. Do not expose it to excessive heat such as sunshine, fire, etc., where it would
be exposed to high temperatures above 60°C.
Checking Battery Power
When the system is powering on and in idle mode, press and hold the VOL + and VOL – buttons
together on the system to check the battery power by the LED indicator.
Status Color Battery Power
Fast blinking (4 times) Green 66%-100%
Fast blinking (3 times) Green 36%-65%
Fast blinking (2 times) Green 15%-35%
Notes:
If the LED indicator blinks alternately in white and green at a slow rate, it indicates the built-in
battery power is less than 15%. In this case, you need to turn off the system or decrease the
volume level, and connect the USB power cable to charge it in time.
If the LED indicator blinks simultaneously in white and green at a fast rate, it indicates the
built-in battery voltage is too low, then the system will power off automatically. Please charge
in time and turn the system on again.
8
System Overview
Left View
Right View
1. LED indicator
- Indicates the built-in battery charging
status.
- When powering on, indicates the
pairing state.
2. Power switch
Slide to turn on/off the system.
3. (Pair) button
Press to put the system into pairing
mode.
4. USB power port
Connect the supplied USB power cable.
5. AUX IN jack
Input audio signals from an external
device.
6. Microphone
Use to speak during a call.
7. VOL + button
Press to increase the volume level.
8. VOL – button
Press to increase the volume level.
9. ► (Play/pause/Call) button
- In Bluetooth mode, press to play/pause
a track. Double press to skip to the
next track; triple press to skip to the
previous track.
- Press to answer/end a call.
10. Wrist strap hole
1
6
2
3
4
5
7
8
9
10
9
Basic Operation
Turning on/off the System
Slide up the Power switch to turn on the
System.
Slide down the Power switch to turn on the
System
Adjusting the Volume
You can adjust the volume level when one of
sound sources is selected by pressing the
VOL +/– buttons.
Each time you press VOL + or VOL – button,
the LED indicator will blink once. If the
system is at minimum volume level (or at
maximum volume level), then press VOL –
button (or VOL + button), the LED indicator
will keep its status as before without any
action.
Activating the Power Saving
Mode
Press and hold the (Pair) button and the
► button together to disable or enable the
Power Saving mode:
The LED indicator blinks twice to indicate
Power Saving mode is off. The system
will keep on all the time even it is in idle
mode.
The LED indicator blinks once to indicate
the Power Saving mode is activated. The
system will power off automatically when
the system is in idle mode for 45
minutes.
Note:
If you turn off the system manually, the
system will activate the Power Saving
mode automatically next time even if you
disabled it before.
Power
switch
VOL +/–
buttons
Left Side Right Side
10
Selecting the Sound Source
This system enables you to access two sound sources – AUX IN and Bluetooth.
If AUX IN jack has been inserted, the sound source will switch to AUX IN mode automatically.
Remove the audio cable from the AUX IN jack, the sound source will switch to Bluetooth
mode automatically.
When a Bluetooth connection has been established and the system is in Bluetooth mode,
once you insert audio cable, the system will suspend the Bluetooth playback and switch to
AUX IN mode.
To resume the Bluetooth playback, you need to remove the audio cable from the AUX IN
jack, and press the ► button.
11
Playing back via Bluetooth
Establishing a Bluetooth
Connection
Notes:
If your mobile phone supports A2DP,
AVRCP profiles, its music will play
through the system.
You can make a Bluetooth connection
with a mobile phone, an
iPhone/iPad/iPod touch or any other
Bluetooth-enabled devices.
1. Slide up the Power switch to turn on the
System.
The LED indicator illuminates and blinks
in white.
2. Press the (Pair) button to put the
system in pairing mode.
The indicator starts blinking at a fast rate.
If you press and hold the (Pair) button
for more than 2 seconds during the
process of pairing, the operation will be
canceled.
3. During this period, you can operate the
mobile phone, iPad or Bluetooth-enabled
device to pair with the system within a 33
feet (10m) range.
Please check the user manual of the
iPad or Bluetooth-enabled device with
which you are initiating pair to learn
about Bluetooth connection with any
other devices.
4. Once the system is detected and its
name Pocket Kick appears on the
display of your Bluetooth-enabled device,
then select the system on the display.
Key in the default password 1234 if a
prompt requests it.
The LED indicator starts blinking quickly
to indicate that the system and your
device have entered into the connection
mode.
After a Bluetooth connection is
established successfully, the LED
indicator will remain on in white.
5. Select the desired music and press Play
button on your device. The system
automatically starts playing back the
music.
Before starting playback via Bluetooth,
make sure the AUX IN jack is not
inserted using audio cable.
Try again above steps 2 to 4 if the LED
indicator blinks slowly after blinking
quickly for 3 minutes, the pair was
unsuccessful.
Using Multiple Bluetooth Devices
Only one device can be used at a time, but
you can switch between different Bluetooth
devices.
Make sure each device you want to use has
already been paired, to switch devices:
1. On Pocket Kick, press and hold the
(Pair) button for 2 second.
2. On Bluetooth device, select the
connection to Pocket Kick.
This device is now the connected device to
Pocket Kick, (the previous connected device
is now disconnected). Repeat those steps to
switch the connected device again.
Notes:
If the system has no sound output,
please check if the volume level of your
Bluetooth device connected to the
system is set to the minimum, or the
Bluetooth device is muted.
Ensure that the audio cable has been
removed from the AUX IN jack.
12
Playing back from Macbook or
Macbook Pro
1. In the desktop screen, select the Open
Bluetooth Preference.
2. If there are any old Pocket Kick records,
remove them. Click the Continue button
to continue pairing process.
3. Once completed, the pairing success
screen will come out.
Note:
Don’t quit the page immediately. You
may notice that the previous dialog
screen still shows the device not
connected. Just ignore it. It’s confusing
to the user. In fact, it’s connected
already.
4. Open iTune, play a song. Then use the
mouse to click the Bluetooth icon at the
top right hand corner of the desktop
screen, select the Pocket Kick option
and then select the Use as Audio
Device (Stereo). After a while (a few
seconds), the music will come out from
the system. If not, select the Use as
Audio Device (Stereo) once again. The
Sound Quality should be good.
Playing back from PC/Notebook
1. Press the Start button to open the
Device and Printers dialog box.
2. Turn on the system, then press the
(Pair) button to put into the pairing mode.
3. Select the Add a device in the Device
and Printer dialog box. The Pocket
Kick icon will appear on the display.
4. Double click the Pocket Kick icon and
wait until the device has been added
successfully.
5. Click the Close button to close the
Device and Printer dialog box. A
Pocket Kick icon appears in the dialog
box.
6. Double click the Pocket Kick icon and
the device connection screen will be
shown.
7. Click the Connect button in the Music
and Audio option.
8. Once connected, the LED indicator on
the system will be solid on in white and
the connection success screen will be
shown.
13
Playing back from External Source
You can enjoy the sound from an optional component such as a digital music player through the
speakers of this system. Be sure to turn off the power of each component before making any
connections. For details, refer to the instruction manual of the component to be connected.
Connect an external device to the AUX IN jack on the back panel of the system using a stereo
audio cable (supplied).
Notes:
When the audio cable is connected to the AUX IN jack, the system will switch to the AUX IN
mode automatically.
In order to save the energy, please plug off the AUX-IN cable when do not use.
1. Slide up the Power switch to turn on the System.
2. Set the volume to the minimum position.
3. Start playback on the external device.
4. Adjust the volume to meet your listening requirement.
AUX IN
jack
To audio output such as
CD/MD/digital music
player, etc.
14
Using Hands-free Calling
You can enjoy hands-free calling via Bluetooth connection with a Bluetooth mobile phone that
has a music function and supports the Bluetooth profile A2DP, and HFP or HSP. If your
Bluetooth mobile phone supports both HFP and HSP, set to HFP.
1. Slide up the Power switch to turn on the System.
2. Establish the Bluetooth connection between the system and your mobile phone.
Making a Call
You can use the mobile phone to make a call, and the dialing tone is heard on the system while
the music playback is muted. After the call has been connected, you can speak using the
microphone of the system.
Receiving a Call
When an incoming call arrives, the music playback is muted and a ringtone is heard from the
system, whether the system is in AUX IN mode or Bluetooth mode. Then press Call button on
the system and speak using the microphone.
Ending a Call
During a call, you can press Call button of the system to end the call.
Rejecting a Call
When an incoming call arrives, you can press and hold Call button of the system for 2 seconds
to reject the call.
Notes:
During the call, press VOL +/– buttons of the system to adjust the volume.
The music playback will be resumed when the call has finished.
Microphone
Call
button
15
Troubleshooting
Check this list for a possible troubleshooting solution before calling for service.
In These Cases Check the Following Points
Power does not come on When using the battery pack, the battery power is too low.
Charge the battery.
No sound output Check if the volume level of the system is set to the
minimum.
When in Bluetooth mode, check if the volume level of your
Bluetooth device is set to the minimum or muted; check if
your audio cable is connected to the AUX IN jack of the
system. Unplug the cable.
When in AUX IN mode, check if your external device is set
to the minimum or muted.
The system is powered off
automatically
The system enters the saving energy mode. The system
does not connect with any audio source for more than 45
minutes. Turn on the system again and play back an audio
source.
Check if the built-in battery is exhausted. Connect USB
power cable to USB power outlet for charging the built-in
battery.
Bluetooth connection
cannot be restored
automatically
The system may be powered off and powered on when
playing back a track over Bluetooth connection. You need
to make the connection again.
No voice/Low voice from
caller while using
Hands-free calling
Check if this system is powered on.
Increase the volume of the connected mobile phone and
the system.
Bluetooth connection
cannot be established
When making a Bluetooth connection between the system
and your device for the first time, if the connection is fail,
you need to power off your device and power on again to
clear the device name, and make the connection again.
16
Technical Specifications
Model SFQ-10
Type Pocket Kick
Support Bluetooth Bluetooth 1.2, 2.0, 2.1 and 4.0 compliant
Support Profile A2DP, AVRCP, HFP, HSP
Input Sensitivity AUX Input 700mV
Input Terminal Micro USB power port, AUX IN
Power Source DC 5V (External USB IN)
Dimensions (Approx.) 150mm (L) x 30mm (D) x 65mm (H)
Weight 266g
Design and specifications are subject to change without notice.
Save this manual
