Becker Avionics BXT6513 BTX6513 User Manual BXT6513 0XX
Becker Avionics GmbH BTX6513 BXT6513 0XX
use manual
Becker Avionics GmbH • Baden-Airpark B108 • 77836 Rheinmünster • Germany
+49 (0) 7229 / 305-0 • Fax +49 (0) 7229 / 305-217
http://www.becker-avionics.com • E-mail: info@becker-avionics.com
Mode S Transponder
with ADS-B
BXT6513-(0XX)
Installation and Operation
Manual DV15104.03
Issue 03 November 2016
Article-No. 0647.225-071
Installation and Operation
2 BXT6513-(0XX) DV15104.03 Issue 03 November 2016
Preface
Dear Customer,
Thank you for purchasing a Becker Avionics product. We are pleased that you have chosen our
product and we are confident that it will meet your expectations.
For development and manufacturing of our product, the guidelines for highest quality and reliability
have been borne in mind, supplemented by selection of high quality material, responsible production
and testing in accordance to the ISO 9001 and DIN EN 9100 standards.
Our competent customer support department will respond on any technical question you may have.
Please do not hesitate to contact us at any time.
Transponder Design
BXT6513
with EM module
BXT6513
with mounting tray and backshell
Installation and Operation
DV15104.03 Issue 03 November 2016 BXT6513-(0XX) 3
List of Effective Pages and Changes
Only technical relevant modifications are described in this table.
Document: DV15104.03 / issue 03 Article Number 0647.225-071
Cover Page 11/2016
Introduction 11/2016
Chapter 1 – 4 11/2016
Issue Page No.: Section /
Chapter Description
03 1-64 all Updated: Descriptions aligned about technical capability.
-- all Added: New variant.
-- 1.4 Added: Descriptions about functionalities.
--
1.7
Added: Technical details.
Updated: Environmental Conditions, Certification
statements.
-- 1.8
Added: Equipment details for configuration and
documentation.
--
2.5
2.6
Added: Details about configuration and interfaces.
--
2.8
2.9
Updated: More details for configuration tasks.
Added: Description Software Update.
--
--
--
--
--
--
--
© 2016 by Becker Avionics GmbH / all rights reserved
Installation and Operation
4 BXT6513-(0XX) DV15104.03 Issue 03 November 2016
Table of Contents
1. General Description ..................................................................................................................... 11
1.1. Introduction .................................................................................................................................. 12
1.2. Purpose of Equipment ................................................................................................................. 13
1.3. Variants Overview ....................................................................................................................... 14
1.3.1. Software Status ................................................................................................................. 14
1.4. Scope of Functionality ................................................................................................................. 14
1.4.1. Fixed and Non-Volatile Data ............................................................................................. 14
1.4.2. Diversity ............................................................................................................................. 15
1.4.3. Mode S .............................................................................................................................. 15
1.4.4. ADS-B (Automatic Dependent Surveillance-Broadcast) ................................................... 16
1.4.5. Supported Transponder Messages ................................................................................... 17
1.4.6. Interfaces ........................................................................................................................... 18
1.4.7. Built-In Test ....................................................................................................................... 18
1.5. Safety-Conscious Utilization ........................................................................................................ 19
1.6. Restriction for Use ....................................................................................................................... 19
1.7. Technical Data ............................................................................................................................. 20
1.7.1. General Characteristics ..................................................................................................... 20
1.7.2. Dimensions & Weight ........................................................................................................ 21
1.7.3. Software ............................................................................................................................ 22
1.7.4. Hardware ........................................................................................................................... 22
1.7.5. Continued Airworthiness ................................................................................................... 22
1.7.6. Environmental Conditions ................................................................................................. 23
1.7.7. Certifications...................................................................................................................... 24
1.8. Order Code .................................................................................................................................. 26
1.8.1. BXT6513-(0XX) ................................................................................................................. 26
1.8.2. Accessories ....................................................................................................................... 26
1.8.3. Spare Parts ....................................................................................................................... 27
2. Installation .................................................................................................................................... 29
2.1. Packaging, Transport, Storage .................................................................................................... 29
2.1.1. Packaging Material and Transport .................................................................................... 29
2.2. Device Assignment ...................................................................................................................... 30
2.2.1. Scope of Delivery .............................................................................................................. 30
2.2.2. Additional Required Equipment......................................................................................... 30
2.2.3. Type Plate ......................................................................................................................... 31
2.2.4. Software Data Plate .......................................................................................................... 32
2.2.5. Meaning of Status LEDs ................................................................................................... 32
2.3. Mounting Requirements .............................................................................................................. 33
2.3.1. Mounting Distance ............................................................................................................ 33
2.3.2. Grounding .......................................................................................................................... 34
2.3.3. Cable Installation ............................................................................................................... 34
2.3.4. Recommended Crimp Tools ............................................................................................. 34
2.3.5. Antenna Cables ................................................................................................................. 35
2.3.6. Antenna Installation ........................................................................................................... 36
2.4. Dimensions .................................................................................................................................. 37
2.4.1. Transponder BXT6513-(0XX) ........................................................................................... 37
2.4.2. BXT6513-(0XX) with Mounting MT6533 ........................................................................... 38
2.4.3. BXT6513-(0XX) with Mounting MT6533 and Backshell BS6533 ...................................... 39
2.5. Electrical Installation .................................................................................................................... 40
2.5.1. Connector P1 .................................................................................................................... 40
2.5.2. Connector P2 .................................................................................................................... 42
2.5.3. Connector TOP, BOT (Antenna) ....................................................................................... 44
2.5.4. Connector USB ................................................................................................................. 44
2.5.5. Connector EM ................................................................................................................... 44
2.5.6. Service Connector (optional) ............................................................................................. 44
2.6. Interfaces ..................................................................................................................................... 45
2.6.1. ARINC 429 Input Labels ................................................................................................... 45
2.6.2. ARINC 429 Output Labels ................................................................................................. 46
2.7. Unit Configuration ........................................................................................................................ 46
2.7.1. General Architecture (example) ........................................................................................ 47
Installation and Operation
DV15104.03 Issue 03 November 2016 BXT6513-(0XX) 5
2.7.2. Single Unit Installation ...................................................................................................... 48
2.7.3. Dual Unit Installation ......................................................................................................... 48
2.7.4. Unit Installation Number.................................................................................................... 48
2.7.5. Data Source Configuration ............................................................................................... 48
2.7.6. Single Unit Installation - Antenna Diversity ....................................................................... 50
2.7.7. Dual Unit Installation - Antenna Diversity ......................................................................... 51
2.7.8. Single Unit Installation – Single Controller........................................................................ 52
2.7.9. Single Unit Installation – Dual Controller .......................................................................... 52
2.7.10. Burst Mode - Single Unit Installation ................................................................................. 53
2.7.11. Transmitter Disable ........................................................................................................... 53
2.8. Configuration Data ...................................................................................................................... 54
2.8.1. Configuration of BXT6513-(0XX) with EM module ........................................................... 54
2.8.2. Configuration of BXT6513-(0XX) with internal memory .................................................... 54
2.9. Software Update ......................................................................................................................... 55
2.9.1. PC Requirements .............................................................................................................. 55
2.9.2. Software Update Installation ............................................................................................. 55
2.10. Aircraft Wiring .............................................................................................................................. 56
2.11. Post Installation Check ................................................................................................................ 57
2.11.1. Mechanical Installation and Wiring Check ........................................................................ 57
2.11.2. Power Supply .................................................................................................................... 57
2.11.3. Antenna Check ................................................................................................................. 57
2.11.4. Interference Check ............................................................................................................ 58
2.11.5. Mode S Ground Test......................................................................................................... 58
2.11.6. Error / Failure Indication.................................................................................................... 58
3. Operating Instructions ................................................................................................................ 59
3.1. Device Description ...................................................................................................................... 59
3.1.1. Device Assignment ........................................................................................................... 59
3.1.2. Packing, Transport, Storage ............................................................................................. 59
3.1.3. Scope of Delivery .............................................................................................................. 59
3.1.4. Type Plate ......................................................................................................................... 59
3.2. Start-up ........................................................................................................................................ 60
3.2.1. Built In Tests (BIT) ............................................................................................................ 60
3.3. Operating..................................................................................................................................... 60
3.3.1. Operating with OEM Controller ......................................................................................... 60
3.4. Read Out and Reset Error Flags ................................................................................................ 60
4. Index ............................................................................................................................................. 64
Figure 1: Block Diagram – Mode S Transponder Concept ..................................................................................... 15
Figure 2: Type plate (example) .............................................................................................................................. 31
Figure 3: Software data plate (example) ................................................................................................................ 32
Figure 4: BXT6513-(0XX) mounting area ............................................................................................................... 33
Figure 5: Antenna Installation (Diversity) ............................................................................................................... 36
Figure 6: BXT6513-(0XX) ...................................................................................................................................... 37
Figure 7: BXT6513-(0XX) with Mounting Tray MT6533 ......................................................................................... 38
Figure 8: BXT6513-(0XX) with Mounting Tray MT6533 and Backshell BS6533 .................................................... 39
Figure 9: BXT6513-(0XX) connector layout ........................................................................................................... 40
Figure 10: BS6533 connector layout (backshell).................................................................................................... 40
Figure 11: Service Connector inside the Aircraft .................................................................................................... 44
Figure 12: Wiring Diagram (example) .................................................................................................................... 47
Figure 13: Single Unit Installation .......................................................................................................................... 48
Figure 14: Dual Unit Installation ............................................................................................................................. 48
Figure 15: Dual Unit Installation, Data Source = External Memory Module ........................................................... 49
Figure 16: External Memory Module via Backshell ................................................................................................ 49
Figure 17: Single Unit Installation, Data Source = Internal Memory ....................................................................... 50
Figure 18: Single Unit Installation - Antenna Diversity ........................................................................................... 50
Figure 19: Dual Unit Installation - Antenna Diversity .............................................................................................. 51
Figure 20: Single Unit Installation - Single Controller ............................................................................................. 52
Figure 21: Single Unit Installation – Dual Controller ............................................................................................... 52
Figure 22: Single Unit Installation – Dual Controller ............................................................................................... 53
Figure 23: Software update – Aircraft Installation .................................................................................................. 55
Figure 24: Software update – Laboratory Installation ............................................................................................. 56
Installation and Operation
6 BXT6513-(0XX) DV15104.03 Issue 03 November 2016
List of Abbreviations
List of Abbreviations
AA
Aircraft Address (24-bit ICAO)
AC
Alternating Current
Altitude Code
ACAS
Airborne Collision Avoidance System
ADLP
Airborne Data Link Processor
ADC
Air Data Computer
ADS-B
Automatic Dependent Surveillance-Broadcast
ARINC
Aeronautical Radio Inc.
ATCRBS
Air Traffic Control Radar Beacon System
AWG
American Wire Gauge
CAN
Controller Area Network
CBIT
Continuous Built-In Test
DC
Direct Current
DF
Downlink Format
DME
Distance Measurement Equipment
EM
External Memory
ES
Extended Squitter
EUROCAE
European Organisation for Civil Aviation Equipment
FAA
Federal Aviation Administration
FCC
Flight Control Computer
FMC
Flight Management Computer
FLS
Field Loadable Software
GND
Ground (electrical)
GNSS
Global Navigation Satellite System
GPS
Global Positioning System
IBIT
Initiated Built-In Test
ICAO
International Civil Aviation Organization
ID
Identifier
I/O
Inputs/Outputs
IP
Internet Protocol
IRS
Inertial Reference System
LED
Light Emitting Diode
MCP
Mode Control Panel
MSL
Mean Sea Level
NAV
Navigation
PBIT
Power-On Built-In Test
PC
Personal Computer
RF
Radio Frequency
RTCA
Radio Technical Commission for Aeronautics Inc.
RX
Receiver, Receive
SI
Surveillance Identifier
SW
Software
Installation and Operation
DV15104.03 Issue 03 November 2016 BXT6513-(0XX) 7
List of Abbreviations
TCAS
Traffic Alert and Collision Avoidance System
TX
Transmitter
USB
Universal Serial Bus
VHF
Very High Frequency
XPDR
Transponder
Units
Units
A
Ampere
mA
Milliampere
°C
Degree Celsius
cm
Centimeter
dBm
Power Ratio In Decibel
dB
Decibel
ft
Foot, feet
g
Gram
kg
Kilogram
kHz
Kilohertz
km/h
Kilometer Per Hour
kt
Knots
MHz
Megahertz
Mbps
Mega Bits Per Second
mm
Millimeter
Nm
Newton Meter
Ohm (Ω)
Resistance
s
Second
V
Volt
mV
Millivolt
W
Watt
mW
Milliwatt
"
Inch
Installation and Operation
8 BXT6513-(0XX) DV15104.03 Issue 03 November 2016
General Safety Definitions
Indicates a hazardous situation which, if not avoided, will result in death or
serious injury.
Indicates a hazardous situation which, if not avoided, could result in death or
serious injury.
Indicates a hazardous situation which, if not avoided, could result in minor or
moderate injury.
Is used to address practices not related to physical injury.
Safety instructions (or equivalent) signs indicate specific safety-related
instructions or procedures.
Installation and Operation
DV15104.03 Issue 03 November 2016 BXT6513-(0XX) 9
Disposal
The packaging material is inflammable, if it is disposed of improperly by burning,
toxic fumes may develop.
This product contains materials that fall under the special disposal regulation, which corresponds to
the EC directive for dangerous disposal material. We recommend disposing of the respective materials
in accordance with the respectively valid environmental laws. The following table states the materials
suitable for recycling and the materials which have to be disposed of separately.
Material
Suitable for recycling
Disposal
Metal
yes
no
Plastics
yes
no
Circuit boards
no
yes
Dispose of the circuit boards:
• Disposal via a technical waste dump which is allowed to take on e.g. electrolytic
aluminium capacitors. Do under no circumstances dump the circuit boards with
normal waste dump.
Warranty Conditions
User Conversions and Changes are Not Permitted.
Any change made by the user excludes any liability on our part (excluding the work described in this
manual).
• The device must not be opened.
• Do not make any modifications to the device, except for those described in the
manual.
• Make connections to the inputs, outputs and interfaces only in the manner described
in the manual.
• Fix the devices according to the mounting instructions.
We cannot provide any guarantee for other mounting methods.
Conditions of Utilization
General Introductory Notes
With this device you bought a product which was manufactured and tested before delivery with the
utmost care.
Please take your time to read the following notes which you ought to follow closely during installation
and operation.
Unless, all claims under the warranty will become void and a reduced service life or even damages
must be expected.
The user is responsible for protective covers and/or additional safety measures
in order to prevent damages to persons and electric accidents.
Additional Conditions of Utilization
Please refer to "Safety-Conscious Utilization", page 19.
Non Warranty Clause
We checked the contents of this publication for compliance with the associated hard and software. We
can, however, not exclude discrepancies and do therefore not accept any liability for the exact
compliance. The information in this publication is regularly checked, necessary corrections will be part
of the subsequent publications.
Installation and Operation
10 BXT6513-(0XX) DV15104.03 Issue 03 November 2016
Blank Page
General Description
Introduction
DV15104.03 Issue 03 November 2016 BXT6513-(0XX) 11
1. General Description
In this chapter you can read about:
1.1. Introduction.................................................................................................................................. 12
1.2. Purpose of Equipment ................................................................................................................. 13
1.3. Variants Overview ....................................................................................................................... 14
1.3.1. Software Status ................................................................................................................. 14
1.4. Scope of Functionality ................................................................................................................. 14
1.4.1. Fixed and Non-Volatile Data ............................................................................................. 14
1.4.2. Diversity ............................................................................................................................ 15
1.4.3. Mode S .............................................................................................................................. 15
1.4.4. ADS-B (Automatic Dependent Surveillance-Broadcast) ................................................... 16
1.4.5. Supported Transponder Messages .................................................................................. 17
1.4.6. Interfaces .......................................................................................................................... 18
1.4.6.1. ARINC 429 ............................................................................................................ 18
1.4.6.2. Logical Inputs/Outputs ........................................................................................... 18
1.4.6.3. Status and Control Ports ....................................................................................... 18
1.4.6.4. Internal and External Memory ............................................................................... 18
1.4.7. Built-In Test ....................................................................................................................... 18
1.5. Safety-Conscious Utilization ....................................................................................................... 19
1.6. Restriction for Use ....................................................................................................................... 19
1.7. Technical Data ............................................................................................................................ 20
1.7.1. General Characteristics .................................................................................................... 20
1.7.2. Dimensions & Weight........................................................................................................ 21
1.7.3. Software ............................................................................................................................ 22
1.7.4. Hardware .......................................................................................................................... 22
1.7.5. Continued Airworthiness ................................................................................................... 22
1.7.6. Environmental Conditions ................................................................................................. 23
1.7.7. Certifications ..................................................................................................................... 24
1.7.7.1. FCC Approval ........................................................................................................ 25
1.8. Order Code.................................................................................................................................. 26
1.8.1. BXT6513-(0XX) ................................................................................................................. 26
1.8.2. Accessories ....................................................................................................................... 26
1.8.3. Spare Parts ....................................................................................................................... 27
This manual describes the operation and installation of the remote controlled BXT6513-(0XX) Mode S
Transponder. The ID label on your device shows the part number for identification purposes (see
"Type Plate", page 31).
Before starting operation of the unit(s) please read this manual carefully, with particular attention to the
description referring to your device(s).
General Description
Introduction
12 BXT6513-(0XX) DV15104.03 Issue 03 November 2016
1.1. Introduction
The technical information in this document apply to the described product BXT6513-(0XX).
The manuals “Maintenance and Repair” (M&R), “Installation and Operation (I&O) contain the following
sections:
Section
DV15104.04
M&R
DV15104.03
I&O
General
X
X
Installation
X
X
Operation
X
X
Theory of Operation
X
N/A
Maintenance and Repair
X
N/A
Illustrated Parts List
X
N/A
Modification and Changes
X
N/A
Circuit Diagrams
X
N/A
Certifications
X
N/A
Attachments
X
N/A
General Description
Purpose of Equipment
DV15104.03 Issue 03 November 2016 BXT6513-(0XX) 13
1.2. Purpose of Equipment
The BXT6513-(0XX) transponder is designed as a remote controlled single block unit and is intended
for installation in aircraft avionics bay.
BXT6513-(0XX) is a transponder which provides to other stations Mode A/C/S messages as well
ADS-B Extended Squitter functionality (ES).
BXT6513-(0XX) is a remote controlled unit, which does not include a control panel. It can receive
commands and provides data through a set of standard interfaces.
Features:
• Control Interface ARINC 429.
• Mode A - in this mode, the 4096 character code is sent as a reply to interrogation from
a ground station.
• Mode C - in this mode, the encoded altitude is sent in addition to the mode A reply.
o Data range for 25 ft resolution: -1000… 50187 ft.
o Data range for 100 ft resolution: -1000… 126750 ft.
o The altitude information must be delivered from an external device.
• Mode S - interrogations are selective and Mode S transponders will respond to a
single directed interrogation from ground stations or another aircraft with ICAO 24-bit
address.
• ADS-B Broadcast-Only System, transmit:
o Airborne Position Message,
o Surface Position Message,
o Airborne Velocity Message,
o Aircraft Identification and Category Message,
o Aircraft Operational Status Message,
o Extended Squitter Aircraft Status Message.
• Diversity - operation with two antennas (top and bottom), required for installation in
aircrafts with gross mass in excess of 5700 kg or a maximum cruising true airspeed
in excess of 175 kt (324 km/h).
• Support of the SI code (Surveillance Identifier).
• Register capability for elementary surveillance (ELS) and enhanced surveillance (EHS).
• Data link capability.
• GPS receiver connection capability.
• Selftests (BITs) are integrated in the transponder.
Actual generation of each ADS-B message type and data within each message
depends on availability of navigation data and GPS capabilities.
General Description
Variants Overview
14 BXT6513-(0XX) DV15104.03 Issue 03 November 2016
1.3. Variants Overview
Within the part number, the meaning of "BXT6513-(0XX)" is:
B
XT
65
13
-
(0XX)
Identifier
000 – Diversity
010 – Single antenna
Model
1.3.1. Software Status
Details please see "Software Data Plate", page 32.
1.4. Scope of Functionality
BXT6513-(0XX) is a transponder providing downlink of aircraft information and single antenna and
diversity antenna installations. For single antenna one shall be installed on the bottom side. For
diversity one antenna is installed on the top side, and the other on the bottom side of the aircraft
fuselage (detailed type description see "Type Plate", page 31).
The BXT6513-(0XX) operates on radar frequencies; receiving ground radar and ACAS interrogations
and replies via its transmitter with coded pulse packages on 1090 MHz. A
special position identification pulse (SPI) can be added for a period of 18 seconds to each pulse
package after activation of the dedicated discrete signal input on the unit.
The BXT6513-(0XX) meets Mode S Enhanced Surveillance (EHS) requirements.EHS parameters
require additional interface with other aircraft systems and the BXT6513-(0XX). Aircraft that can
provide the list of eight Downlink Aircraft Parameters (DAPs) listed in BDS registers 4.0, 5.0 and 6.0
are considered to be Mode S EHS capable. Aircraft that cannot provide these parameters will be
considered as, not EHS capable.
1.4.1. Fixed and Non-Volatile Data
The BXT6513-(0XX) configuration is stored in a non-volatile memory. There are two possibilities
where to store configuration data:
• Use the internal memory
• Use the external memory module EM6100.
The selection of equipment configuration source is done by hardware configuration (see “Unit
Configuration", page 46).
General Description
Scope of Functionality
DV15104.03 Issue 03 November 2016 BXT6513-(0XX) 15
1.4.2. Diversity
Antenna diversity reduce the potential for antenna "shading", and helps to prevent target drop out in
each situation.
BXT6513-(000) is capable to operate with two antennas (top and bottom), required for installation in
aircrafts with gross mass in excess of 5700 kg or a maximum cruising true airspeed in excess of
175 kt (324 km/h).
1.4.3. Mode S
BXT6513-(0XX) as Mode S transponder is an airborne part of Mode S
Secondary Surveillance Radar system which detects ground interrogations arriving at 1030 MHz
signal frequency, processes them and generates responses at 1090 MHz signal frequency.
XPDR Receiver
bottom
Interrogation/
Reply
Processing
XPDR Receiver
top
XPDR
Transmitter
Antenna Switch
ADS-B Out message
ADLP
Control&Status
Configuration
Suppression Line
Figure 1: Block Diagram – Mode S Transponder Concept
General Description
Scope of Functionality
16 BXT6513-(0XX) DV15104.03 Issue 03 November 2016
1.4.4. ADS-B (Automatic Dependent Surveillance-Broadcast)
ADS-B is a GPS based technology to define and provide aircraft relevant data. To support ADS-B Out,
the aircraft needs a certified GPS receiver as the position source, and this device to send the ADS-B
data. This data can be received by other air- and ground stations.
The Automatic Dependent Surveillance-Broadcast Out (ADS-B Out) function provides position,
velocity and status data on the transponder for broadcasting as extended squitters (ES). When data is
available, it is transmitted at specific periods and enable other participants to determine current
position, velocity and status of the aircraft without interrogation.
BXT6513-(0XX) is an ADS-B class B1 or B1S (aircraft broadcast only) Mode S transponder capable
for automatically sending out ADS-B data like:
• (BDS 0,5) Airborne Position Message.
o SPI.
o Emergency Indicator.
o Barometric Altitude.
o Quality Indicator (NIC).
o Latitude (Airborne Position).
o Longitude (Airborne Position).
• (BDS 0,6) Surface Position Message.
o Quality Indicator (NIC).
o Latitude (Surface Position).
o Longitude (Surface Position).
o Surface Ground Speed.
o Surface Ground Track.
• (BDS 0,8) Aircraft ID and Category Message.
o Aircraft Identification & Categorie.
• (BDS 0,9) Airborne Velocity.
o Airborne Ground Velocity.
o Geometric to Barometric Altitude Difference.
o Geometric Vertical Speed.
• (BDS 6,1) Emergency/Priority Status.
o Squawk Code.
o Emergency Status.
• (BDS 6,5) Aircraft Operational Status Message, Airborne and Surface.
o Quality Indicator (NACp, NACv and GVA).
o Quality Indicator (SIL and SDA).
o Version Indicator.
o Surface Length/Width.
o Surface Antenna Offset.
General Description
Scope of Functionality
DV15104.03 Issue 03 November 2016 BXT6513-(0XX) 17
1.4.5. Supported Transponder Messages
BXT6513 supports the following Binary Data Selector (BDS) registers.
General Mode S Registers:
• (BDS 1,0) Data Link Capability Report.
• (BDS 1,7) Common Usage GICB Capability Report.
• (BDS 1,8 to 1,C) Mode S Specific Services GICB Capability Report.
Elementary Surveillance Registers:
• (BDS 2,0) Flight ID.
• (BDS 2,1) Aircraft Registration.
Enhanced Surveillance Registers:
• (BDS 4,0) Selected Vertical Intention Report (except Vertical Mode).
• (BDS 5,0) Track and Turn Report.
• (BDS 6,0) Heading and Speed Report.
Extended Squitter/ADS-B Registers:
• (BDS 0,5) Airborne Position Message.
• (BDS 0,6) Surface Position Message.
• (BDS 0,8) Aircraft ID and Category Message.
• (BDS 0,9) Airborne Velocity.
• (BDS 6,1) Emergency/Priority Status.
• (BDS 6,5) Aircraft Operational Status Message, Airborne.
• (BDS 6,5) Aircraft Operational Status Message, Surface.
General Description
Scope of Functionality
18 BXT6513-(0XX) DV15104.03 Issue 03 November 2016
1.4.6. Interfaces
1.4.6.1. ARINC 429
The ARINC 429 specification is a standard how avionics equipment and systems communicate on
aircraft. The specification defines:
• Electrical characteristics,
• Word structures,
• Protocol for bus communication.
Electrical and data format characteristics are defined for a two-wire serial bus with one transmitter and
up to 20 receivers. This simple architecture provides a highly reliable transfer of data. The bus is
capable of operating at a speed of 100 kbit/s.
For detailed information about ARINC 429 specifications please refer to: www.arinc.com.
Copyright Note ARINC: ARINC429 is a privately copy written specification developed to provide interchange ability and
interoperability of line replaceable units (LRUs) in commercial aircraft. ARINC stands for Aeronautical Radio, Inc.
1.4.6.2. Logical Inputs/Outputs
The hardware design of BXT6513-(0XX) provides a subset of inputs and outputs required for
transponder operation.
1.4.6.3. Status and Control Ports
The hardware design of BXT6513-(0XX) provides a subset of ports for provide information about
transponder status and for controlling.
1.4.6.4. Internal and External Memory
An internal or external memory is used as configuration data source, saving aircraft data installation
and configuration data.
On start-up BXT6513-(0XX) reads from this non-volatile memory configuration data which include
parameters specific to the actual aircraft and installation. Typically, an external memory (EM) is used.
If BXT6513-(0XX) is replaced e.g. for maintenance, so the new BXT6513-(0XX) can be assembled
with the external memory module in this way it is guaranteed that all relevant data is available for fast
& easy exchange.
We recommend the usage of the External Memory module EM6100 as data
source.
1.4.7. Built-In Test
BXT6513-(0XX) has advanced Built-In-Test. It monitors most of internal circuits against failures.
General Description
Safety-Conscious Utilization
DV15104.03 Issue 03 November 2016 BXT6513-(0XX) 19
1.5. Safety-Conscious Utilization
For safe operation of the product the following notes have to be observed:
• The installation of the BXT6513-(0XX) into an aircraft may be carried out
only by an authorized installation company. The country regulations always
have to be observed.
• Use the product only within the specified conditions, see "Technical Data"
page 20.
• Circuit breaker:
o Use the recommended fuses in the power line to protect the application,
see "Technical Data", page 20.
Excessive pulses on the DC bus of the aircraft may cause damage on electrical
circuits of any installed instrument.
It is the responsibility of the installer to ensure the ADS-B Out system is
compliant with current national regulations e.g. AC 20-165B and to ensure
compatibility between the BXT6513 and the ADS-B Out position source
equipment.
1.6. Restriction for Use
• Installation of BXT6513-(0XX) is limited to configurations where the aircraft
is equipped with an ARINC-743A compliant GNSS receiver having an time
mark output, the transponder is configured to use the time mark signal and
time mark output of the GNSS receiver is connected to the corresponding
input of the transponder.
• Installation of BXT6513-(0XX) is limited to configurations where the aircraft
has Weight-On-Wheels/Ground Sensor, the transponder is configured to
use Weight-On-Wheels/Ground Sensor input and Weight-On-
Wheels/Ground Sensor is connected to the corresponding input of the
transponder.
General Description
Technical Data
20 BXT6513-(0XX) DV15104.03 Issue 03 November 2016
1.7. Technical Data
1.7.1. General Characteristics
BXT6513-(0XX)
Specifications
Supply voltage
28 VDC (18.0...32.2 VDC)
Emergency voltage
18 VDC min.
Power consumption
27 W max.
Recommended external fuse protection
3 A
RF port
Impedance
50 Ω
Transmitter frequency
1090 ± 1 MHz
Transmitter power
min. 125 W at antenna terminal
Receiver frequency
1030 MHz
Mode A/C sensitivity
-73 ± 4 dBm at antenna terminal
Mode S sensitivity
-74 ± 3 dBm at antenna terminal
Interrogations - Mode
Mode A, C, A/S All Call, C/S All Call,
Mode S (DF=0, 4, 5, 11, 16, 20, 21)
Replay rate capability
Mode A/C
Continuous: 500 replies per second
Peak (100 ms): 1200 replies per second
Mode S
60 long replies per second
12 short and 6 long replies in 100 ms
4 short and 4 long replies in 25 ms
2 short and 2 long replies in 1.6 ms
Squitter
Short (56 bits): Acquisition
Long (112 bits): Identification
Airborne Position
Airborne Velocity
Surface Position
Aircraft Operational Status
Extended Squitter Aircraft Status
Custom messages (TYPE=23)
Interface
Control Interface
ARINC 718A, 3x ARINC 429 In
Air Data Computer
ARINC 706, 2x ARINC 429 In
ADLP
ARINC 718A, 1x ARINC 429 In, 1x ARINC 429 Out
FCC
ARINC 701, 1x ARINC 429 In
FMC
ARINC 702, 1x ARINC 429 In
General Description
Technical Data
DV15104.03 Issue 03 November 2016 BXT6513-(0XX) 21
BXT6513-(0XX)
Specifications
IRS
ARINC 704, 1x ARINC 429 In
GNSS
ARINC 743A, 1x ARINC 429, 1x Time Mark (differential)
Radio Altimeter
ARINC 707, 1x ARINC 429 In
Data concentrator
2x ARINC 429 In
Data output
ARINC 718A, 2x ARINC 429 Out
Field Loadable Software
ARINC 826, 1x CANbus, 1x Discrete In
Mutual Suppression
ARINC 718A
IDENT
1x Discrete In
Standby
1x Discrete In
Control Port select
1x Discrete In
ADC select
1x Discrete In
Weight on Wheels
1x Discrete In
Ext. Squitter disable
1x Discrete In
Burst Mode
1x Discrete In
Reply indication
1x Discrete Out
Status
3x Discrete Out
Maintenance
1x USB (front panel)
1.7.2. Dimensions & Weight
Specifications
BXT6513-(0XX) only (HxWxD)
171 x 47.4 x 276 mm (6.73 x 1.87 x 10.87 in)
BXT6513-(0XX) depth with EM module
310 mm (12.21 in)
BXT6513-(0XX) with mounting + backshell
(HxWxD)
172.5 x 52.4 x 331 mm (6.79 x 2.06 x 13.03 in)
Weight
Transponder BXT6513-(0XX)
≤ 1.6 kg (3.53 lb)
Mounting tray MT6533-(000)
≤ 0.50 kg (1.10 lb)
Backshell BS6533-(100)
≤ 0.3 kg (0.66 lb)
External memory module EM6100
≤ 0.018 kg (0.04 lb)
General Description
Technical Data
22 BXT6513-(0XX) DV15104.03 Issue 03 November 2016
1.7.3. Software
As a result of the safety assessment process the failure condition of the BXT6513-(0XX) was
determined to be Category MAJOR.
As the failure condition of the software used in the BXT6513-(0XX) was categorized MAJOR, the
Design Assurance Level (DAL) of the unit is determine to be Level C according DO-178C.
1.7.4. Hardware
The Complex Electronic Hardware (CEH) included into BXT6513-(0XX) has been designed in
accordance with EUROCAE/RTCA Document ED-80/DO-254; “Design Assurance Guidance for
Airborne Electronic Hardware”. And satisfy criteria of:
Hardware Assurance Level (HAL) C
1.7.5. Continued Airworthiness
• The BXT6513-(0XX) maintenance is defined as "on condition" only.
• No scheduled or regular maintenance of this product is required.
General Description
Technical Data
DV15104.03 Issue 03 November 2016 BXT6513-(0XX) 23
1.7.6. Environmental Conditions
BXT6513-(0XX) was tested in accordance with ED-14G/DO-160G under consideration of listed
environmental categories and conditions:
Characteristics
Section
Cat.
Condition
Temperature 4 B2
Intended for installation in non-pressurized
and non-controlled temperature location of
an aircraft that is operated at altitudes up
to 25 000 ft (7620 m) MSL.
-45…70 °C.
Altitude 4 F1
Intended for installation in non-pressurized
but controlled temperature location of an
aircraft that is operated at altitudes up to
55 000 ft (16 800 m) MSL
In-flight Loss of Cooling
4
X
No test
Temperature Variation 5 B
Non-temperature controlled or partially
temperature controlled internal sections of
the aircraft
Humidity
6
B
Severe humidity environment
Operational Shocks and Crash Safety 7 B
Tested for standard operational shock and
crash safety
Vibration 8 SMB2
Standard vibrations test:
• sine vibration curve M
• random vibration curve B2
8 U2FF1
Robust vibrations test: Helicopters with
unknown frequencies, Zone 1a and 2:
fuselage, instrument panel, console and
equipment rack
Explosion Proofness
9
X
No test
Water Proofness
10
X
No test
Fluids Susceptibility
11
X
No test
Sand and Dust
12
X
No test
Fungus Resistance 13 F
Fungus Resistance Compliance performed
by Analysis
Salt Spray
14
X
No test
Magnetic Effect 15 Z
Deflection for magnetic compass is ≤ 1°, if
unit is installed with a distance of ≤0.3 m.
Power Input 16 B
28 VDC equipment installed in aircrafts
supplied with engine-driven
alternator/rectifiers or DC generators
where a battery of significant capacity is
floating on DC bus all the time.
DC current ripple
16
X
No test
Inrush current
16
X
No test
Voltage Spike 17 A
High degree of protection against damage
by voltage spikes
Audio Freq. Conducted Susceptibility 18 Z
28 VDC equipment with no battery or
battery small compared with the capacity
of the DC generator
General Description
Technical Data
24 BXT6513-(0XX) DV15104.03 Issue 03 November 2016
Characteristics
Section
Cat.
Condition
Induced Signal Susceptibility 19 CCX
Equipment for which interference-free
operation is required; installed on aircraft
where severe coupling occurs due to long
wire runs
Radio Frequency Susceptibility 20 RR
Compliant to high intensity radiated fields
associated with the normal environment.
Emission of Radio Frequency Energy 21 M
Located in areas where apertures are
significant and not directly in view of radio
receiver’s antenna.
Lightning Induced Transients
Susceptibility 22 A3E3XX
Pin test waveform set A, level 3. Cable
bundle test waveform set E, level 3
Lightning Direct Effects
23
X
No test
Icing
24
X
No test
Electrostatic Discharge 25 A
Installed, repaired or operated in an
aerospace environment
Fire, Flammability
26
X
No test
BXT6513-(0XX) is fulfilling the related requirements of AC20-158A and AC20-136B.
1.7.7. Certifications
The Remote Controlled Mode S Transponder BXT6513 is certified.
Part Number
EASA Approval
BXT6513-(0XX)
EASA.21O.10058306
BXT6513-(0XX) meets the requirements of:
Specifications
ETSO
C112d – Level 2 dens, Class 1
(single antenna: Level 2 ens)
C166b Class B1
(single antenna: Class B1S)
ED12C / DO178C
DAL C
ED80 / DO-254
DAL C
ICAO
Annex 10, Vol IV
MOPS
RTCA/DO-160G, EUROCAE ED-73E,
EUROCAE ED-102A
General Description
Technical Data
DV15104.03 Issue 03 November 2016 BXT6513-(0XX) 25
1.7.7.1. FCC Approval
Radiofrequency radiation exposure information:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with minimum distance of 50 cm between the
radiator and your body.
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
NOTE:
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his own expense.
NOTE:
This device complies with Part 15 of the FCC Rules [and with Industry Canada licence-exempt
RSS standard(s)].
Operation is subject to the following two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received, including interference that may cause
undesired operation.
NOTE:
Changes or modifications made to this equipment not expressly approved by Becker Avionics may
void the FCC authorization to operate this equipment.
General Description
Order Code
26 BXT6513-(0XX) DV15104.03 Issue 03 November 2016
1.8. Order Code
1.8.1. BXT6513-(0XX)
Qty
Transponder
1
BXT6513-(000): XPDR (class1, Level 2 dens) /ADS-B Out (B1)
Article No. 0645.141-915
1
BXT6513-(010): XPDR (class1, Level 2 ens) /ADS-B Out (B1S)
Article No. 0649.732-915
1.8.2. Accessories
Qty
External Memory
1
EM6100-(000) External memory
Article-No. 0608.270-921
Qty
Configuration Equipment
1
EMP Kit, Configuration Set External Memory
• Programming module
• EM Programmer (software on USB stick)
• USB cable
Article-No. 0649.961-954
1
CANbus Kit, Configuration Set
• CAN USB-adapter
• EM Programmer & ARINC Data Loader on USB stick
on request
Qty
Mounting Equipment
1
Mounting tray MT6533-(000)
Article-No. 0635.952-264
1
Backshell BS6533-(100) for MT6533
Article-No.0645.168-284
1
Backshell BS6533-(110) single antenna for MT6533
Article-No.0649.767-284
Qty
Antenna
-
BXT6513-(0XX) accept all types of transponder antennas.
Please use only antennas which are certified to one of the
following TSOs:
(E)TSO-C66()
(E)TSO-C74()
(E)TSO-C112()
--
Qty
Connector Kit
1
CK6513-(100):
90°TNC connector kit for 311201 ECS coax cable
Article-No. 0647.551-954
Qty
Available Documentation
1
BXT6513-(0XX) Installation and Operation, English
Article-No. 0647.225-071
1
BXT6513-(0XX) Maintenance and Repair, English
Article-No. 0647.233-071
1
EMP Extended Memory Programmer User Manual, English
Article-No. 0648.655-071
1
ARINC 826 Data Loader Manual
Article-No.0649.562 071
1
ICD Manual (Interface Control Document), English
on request
1
FLS Manual, English
on request
General Description
Order Code
DV15104.03 Issue 03 November 2016 BXT6513-(0XX) 27
1.8.3. Spare Parts
Qty
Repair Kit
1
RK6533-(100): Repair Kit for the BS6533-(100)
Article-No. 0647.195-954
General Description
Order Code
28 BXT6513-(0XX) DV15104.03 Issue 03 November 2016
Blank Page
Installation
Packaging, Transport, Storage
DV15104.03 Issue 03 November 2016 BXT6513-(0XX) 29
2. Installation
This manual must be available close to the device during the performance of all tasks.
Careful planning should be applied to achieve the desired performance and reliability from the product.
Any deviations from the installation instructions prescribed in this document are under own
responsibility.
In this chapter you can read about:
2.1. Packaging, Transport, Storage ................................................................................................... 29
2.2. Device Assignment ..................................................................................................................... 30
2.3. Mounting Requirements .............................................................................................................. 33
2.4. Dimensions.................................................................................................................................. 37
2.5. Electrical Installation ................................................................................................................... 40
2.6. Interfaces..................................................................................................................................... 45
2.7. Unit Configuration ....................................................................................................................... 46
2.8. Configuration Data ...................................................................................................................... 54
2.9. Software Update ......................................................................................................................... 55
2.10. Aircraft Wiring .............................................................................................................................. 56
2.11. Post Installation Check ................................................................................................................ 57
2.1. Packaging, Transport, Storage
Visually inspect the package contents for signs of transport damage.
2.1.1. Packaging Material and Transport
The packaging material is inflammable, if it is disposed of improperly by
burning, toxic fumes may develop.
The packaging material can be kept and reused in the case of a return shipment. Improper or faulty
packaging may lead to transport damages.
Make sure to transport the device always in a safe manner and with the aid of suitable lifting
equipment if necessary. Do never use the electric connections for lifting. Before the transport, a clean,
level surface should be prepared to place the device on. The electric connections may not be
damaged when placing the device.
First Device Checkup
• Check the device for signs of transport damages.
• Please verify if the indications on the type plate correspond to your purchase order.
• Check if the equipment is complete ("Scope of Delivery", page 30).
Storage
If you do not wish to mount and install the device immediately, make sure to store it in a dry and clean
environment. Make sure that the device is not stored near strong heat sources and that no metal
chippings can get into the device.
Installation
Device Assignment
30 BXT6513-(0XX) DV15104.03 Issue 03 November 2016
2.2. Device Assignment
This manual is valid for the following devices:
• BXT6513-(0XX) + supplement
2.2.1. Scope of Delivery
• Manuals
o Installation and Operation manual
• Transponder
o BXT6513-(0XX)
• EASA Form One
2.2.2. Additional Required Equipment
• Mounting kit MT6533, mandatory to meet the conditions for certification
• Backshell BS6533, mandatory to meet the conditions for certification
• Connectors + cables
• Antennas + antenna cables
• External Memory module (depends on configuration)
• Configuration set
• Control unit (controlling and operating BXT6513-(0XX))
Details see "Accessories", page 26.
Installation
Device Assignment
DV15104.03 Issue 03 November 2016 BXT6513-(0XX) 31
2.2.3. Type Plate
The device type is defined by the type plate (on the housing):
Example:
Figure 2: Type plate (example)
Explanation:
PN:
Example Type designation:
BXT = Remote Controlled Transponder with ADS-B out
6513 = Model number
Options:
-(000): Diversity
-(010): Single antenna
Functionality:
XPDR class 1: Output power at antenna ≥125 W
Level 2: Surveillance and Comm-A/B
d: Diversity
e: Extended squitter
n: Enhanced surveillance
s: Surveillance identifier code (SI)
ADS-B class
B1: Aircraft broadcast only
B1S: Aircraft broadcast only, single antenna
SN:
Unique number of the particular device
AN:
Article number (=order number)
DoM:
Date of Manufacturing
MS
Mode state
Compliance and Certifications
Corresponding to the displayed text and logos
Installation
Device Assignment
32 BXT6513-(0XX) DV15104.03 Issue 03 November 2016
2.2.4. Software Data Plate
The software state is defined by the software data plate (on the housing):
Example:
Figure 3: Software data plate (example)
Explanation:
X
Example description:
The labelling on this data plate example shows:
Software status of the device = software package version 2.
2.2.5. Meaning of Status LEDs
The two front panel LEDs indicate basic information about overall equipment status.
Device Status
ERR
(LED yellow)
OK
(LED green)
Off
off
off
Initializing
off
off
Failure of any of basic function(s)
on
off
Operating, minor failures reported
on
on
Operating, no error
off
on
Installation
Mounting Requirements
DV15104.03 Issue 03 November 2016 BXT6513-(0XX) 33
2.3. Mounting Requirements
The installation of the BXT6513-(0XX) into an aircraft may be carried out only by
an authorized installation company. The country regulations always have to be
observed.
Antenna and cable installations on pressurized cabin aircraft require FAA/EASA
approved installation design and engineering substantiation data whenever such
installations incorporate alteration (penetration) of the cabin pressure vessel by
connector holes and/or mounting arrangements. Use of existing bulkhead
connectors previously approved by other means is permissible without additional
approval.
The device must not be opened.
When installing the device, make sure the heat dissipators of the device receive
sufficient air. Ensure air circulation gaps as specified, see “Mounting Distance”,
page 33.
The mounting place shall be at least 30 cm from the magnetic aircraft compass,
to avoid any interference to the magnetic compass.
Make sure that the mounting plate is not exposed to external temperature
influences.
BXT6513-(0XX) is mounted to the airframe using the dedicated mounting which consists of a
mounting tray MT6533) and a backshell (BS6533). The mounting tray provides fixing the
BXT6513-(0XX) to the aircraft structure. The backshell provides fixing for cable harness. Details see
"Dimensions", page 37.
Fixing the mounting tray MT6533 to the airframe:
• Use six M5 (metric) or size 10 (imperial) screws with countersunk head.
o Minimum torque for fixing screws should be 2.5 Nm.
• Torque for ground stud nut should be normally 1.5 Nm (max. 1.7 Nm).
2.3.1. Mounting Distance
Dimensions mm (inch)
37.8 (1.48)
min 30
(1.18)
cabling area
air circulation min 15 (0.59)
air circulation min 15 (0.59)
RF cable bending radius
min R20
6x Ø5.3 (Ø0.21)
Figure 4: BXT6513-(0XX) mounting area
Installation
Mounting Requirements
34 BXT6513-(0XX) DV15104.03 Issue 03 November 2016
2.3.2. Grounding
Make sure that the grounding contact area is adequate and that the connection has
low resistance and low inductance. Never use a grounding point on paint-coated
surfaces!
The mounting tray (MT6533) must be connected to the aircraft electrical frame. Use the dedicated
grounding stud at the rear part of the mounting.
The grounding stud is marked on the mounting tray.
• Wire cross section: min. 4 mm2.
• Length: max.150 mm (6 in).
2.3.3. Cable Installation
• General requirements (except power wires)
o Use only shielded cables.
o Connect each shield to the ground individually (no series connections).
o Connect all cable shields at both ends, ensuring large contact areas!
o Cable routing should be kept as short and as direct as practical.
o Avoid sharp bends to prevent cable break and defects of insulation.
o Avoid routing close to sharp edges to prevent cable break and defects of
insulation due to vibration handling the cable.
o Avoid routing cables near power sources
o Avoid routing cables near aircraft control cables.
o Avoid routing antenna cables near DME, TCAS, radar altimeter, and ADF
antenna cables (allow min. 12 inch separation)
• Shielded cables
o Wire cross section (cable shield – ground): min. AWG 24 (0.25 mm2).
o Shield connection length: max. 75 mm (3 in).
• Signal cables for configuration inputs
o Wire cross section (signal cables – ground): AWG 24 (0.25 mm2).
o Length: max. 150 mm (6 in).
2.3.4. Recommended Crimp Tools
Cable cross section – Crimp tool
Please always verify the use of the suited positioner (insert) in the crimping pliers
to guarantee a reliable wired connection.
Connector / cable cross section
Crimp tool category
(for the D-Sub connectors)
Crimps
CONEC part number: 360X10329X
Positioner
for CONEC pins – part number 360X20069X
Insertion/Removal tool
CONEC part number: 360X12009X
Installation
Mounting Requirements
DV15104.03 Issue 03 November 2016 BXT6513-(0XX) 35
2.3.5. Antenna Cables
The antenna installation needs to comply with following limitations:
• The total attenuation of a connection between any antenna and the equipment,
including cables, connectors, microwave switch (if used), etc. shall not be more than
3 dB.
• The connection attenuation difference between antennas shall not be greater than
0.5 dB.
• The signal delay of a connection between any antenna and the equipment shall not be
greater than 75 ns.
• The signal delay difference between antennas shall not be greater than 20 ns.
It is recommended that "Top" & "Bottom" antenna cables are of the same type
and have similar length.
2.3.5.1. Attenuation: Cable length vs coax cable type
Data below shall be used as guideline only.
cable type
max. loss
max. cable length
RG400
0.5 dB/m
6 m
RG142
0.42 dB/m
7.14 m
RG393
0.29 dB/m
10.3 m
ECS310801
0.11 dB/m
27 m
ECS310701
0.10 dB/m
30 m
Installation
Mounting Requirements
36 BXT6513-(0XX) DV15104.03 Issue 03 November 2016
2.3.6. Antenna Installation
For antenna installation, refer always to the manufacturer´s maintenance documentation for the
aircraft. Carry out the antenna installation in accordance with AC 43.12-2A Chapter 3.
Penetration of the pressurised cabin on a pressurised aircraft requires additional
data, which are not contained in this installation manual.
Radiation risk:
A safe distance to the installed antenna must be ensured by corresponding
installation measures around human body damage (e.g. at the eyes) and/or
avoid the inflammation of combustible materials by radiated energy.
The picture shows a typical location for top and bottom antenna installation for Diversity Mode S
transponder.
Figure 5: Antenna Installation (Diversity)
Transponder antennas should be installed as far away as practical from:
• Other antennas,
• Shadowing produced by other installations on the surface of the aircraft body,
• Exhaust path of the engine(s),
• Landing gear doors or other openings.
• Check the skin panels for sufficient bonding before the antenna installation.
• Separate the transponder antennas from DME and TCAS as much as possible
(approx. 1.8 m or 6 feet as guideline).
• Generally, transponder antennas should not be closer to the XPDR transceiver
installed as 3 ft. Otherwise RF interference may occur.
• Mount the main antenna on the bottom of the aircraft fuselage in a vertical position,
same as the top antenna. Horizontal separation of both antennas should not exceed
7.6 meters (25 ft).
• Follow the manufacturer´s installation instruction for the antenna to ensure achieving
maximum performance of the BXT6513-(0XX).
• If existing antennas on the aircraft will be used an inspection of the area between
antenna and the aircraft skin is highly recommended to avoid negative effects of
possible corrosion in this area.
• On composite aircraft, add sufficient ground plane material.
Installation
Dimensions
DV15104.03 Issue 03 November 2016 BXT6513-(0XX) 37
2.4. Dimensions
2.4.1. Transponder BXT6513-(0XX)
Dimensions mm (inch)
USB
OK ERR
TOPBOTEM
P2 P1
173350
11834
173350
11834
CENTER OF GRAVITY
120 (4.72)
276 (10.87)
310 (12.21)
47.4
(1.87) 22
(0.87)
74 (2.91)
154.5 (6.08)
171 (6.73)
28.8
(1.13)
235.4 (9.27)
Figure 6: BXT6513-(0XX)
"Center of Gravity" for BXT6513-(0XX) with EM module.
Allowable deviation for dimensions without tolerances: DIN ISO 2768 T1 C
xx...6 (±0.3)
>30...120 (±0.8)
>400...1000 (±2.0)
>6...30 (±0.5)
>120...400 (±1.2)
>1000...2000 (±3.0)
Installation
Dimensions
38 BXT6513-(0XX) DV15104.03 Issue 03 November 2016
2.4.2. BXT6513-(0XX) with Mounting MT6533
Dimensions mm (inch)
USB
OK ERR
CENTER OF GRAVITY
263 (10.36)
64 (2.52)
172.5 (6.79)
157.5 (6.20)
277 (10.91)
319 (12.56)
148 (5.95)
165 (6.5)
30
(1.18)
60 (2.36)6x Ø5.3 (Ø0.21)
52.4
(2.06) 24
(0.94)
Figure 7: BXT6513-(0XX) with Mounting Tray MT6533
"Center of Gravity" for BXT6513-(0XX) with EM module and mounting.
Allowable deviation for dimensions without tolerances: DIN ISO 2768 T1 C
xx...6 (±0.3)
>30...120 (±0.8)
>400...1000 (±2.0)
>6...30 (±0.5)
>120...400 (±1.2)
>1000...2000 (±3.0)
Installation
Dimensions
DV15104.03 Issue 03 November 2016 BXT6513-(0XX) 39
2.4.3. BXT6513-(0XX) with Mounting MT6533 and Backshell BS6533
Dimensions mm (inch)
USB
OK ERR
CENTER OF GRAVITY
263 (10.36)
67 (2.64)
172.5 (6.79)
157.5 (6.20)
292.8 (11.53)
331 (13.03)
144 (5.67) 11.3
(0.45)
165 (6.5)
30
(1.18)
60 (2.36)6x Ø5.3 (Ø0.21)
52.4
(2.06) 27
(1.06) Backshell without cable clamps
17
33
50
1
18
34
17
33
50
1
18
34
Figure 8: BXT6513-(0XX) with Mounting Tray MT6533 and Backshell BS6533
"Center of Gravity" for BXT6513-(0XX) with EM module, mounting and backshell.
Allowable deviation for dimensions without tolerances: DIN ISO 2768 T1 C
xx...6 (±0.3)
>30...120 (±0.8)
>400...1000 (±2.0)
>6...30 (±0.5)
>120...400 (±1.2)
>1000...2000 (±3.0)
Installation
Electrical Installation
40 BXT6513-(0XX) DV15104.03 Issue 03 November 2016
2.5. Electrical Installation
For installations in a more severe electromagnetically environment use shielded
cable connectors and a common shielding for the transponder interwiring.
Detailed information according electrical signals and wiring are available in
ICD manual; please see “Order Code”, “Available Documentation” page 26.
TOPBOTEM
P2 P1
17
33
50
1
18
34
17
33
50
1
18
34
173350
11834
173350
11834
17
33
50
1
18
34
17
33
50
1
18
34
Backshell without cable clamps
Figure 9: BXT6513-(0XX) connector layout
Figure 10: BS6533 connector layout (backshell)
Reserved Pins shall not be connected.
2.5.1. Connector P1
P1
Pin
Signal
name
Pin Name
Function
I/O
Remarks
1
CAX0B
Reserved
-
factory only
2
C4XXIB0
XPDR Control, Port A, Line B
ARINC 429
I
3
C4XXIB1
GNSS Data, Line B
ARINC 429/RS422
I
configurable,
4
C4XXIB2
ADC/Altitude Encoder, Port A,
Line B
ARINC 429/RS422
I
configurable
5
CIX2
Reserved
-
factory only
6
CIX3
XPDR Standby
Discrete
I
7
CIX0
XPDR Reply
Discrete
O
Low active, ≈ 200 ms
after every generated
reply.
8
CIX1
Ident Activation
Discrete
I
Low active, < 3.5 V
9
C429IA0
FMC, Line A
ARINC 429
I
10
C429IB0
FMC, Line B
ARINC 429
I
11
C429IA1
Reserved
-
factory only
12
C422IN0
Time Mark, inverting
RS422
I
Line B
13
C422IP0
Time Mark, non-inverting
RS422
I
Line A
14
CSI1
Configuration Source Select
Discrete
I
data source
configuration
Installation
Electrical Installation
DV15104.03 Issue 03 November 2016 BXT6513-(0XX) 41
P1
Pin
Signal
name
Pin Name
Function
I/O
Remarks
15
CRDY
System Status
Discrete
O
Low active, < 1.0 V
16
PGND
Ground
Supply Return
-
17
PGND
Ground
Supply Return
-
18
CAX0A
Reserved
-
factory only
19
C4XXIA0
XPDR Control, Port A, Line A
ARINC 429
I
20
C4XXIA1
GNSS Data, Line A
ARINC 429/RS422
I
configurable
21
C4XXIA2
ADC/Altitude Encoder, Port A,
Line A
ARINC 429/RS422
I
configurable
22
C429XB0
XPDR Data, Port A, Line B
ARINC 429
O
23
C429XA0
XPDR Data, Port A, Line A
ARINC 429
O
24
GND
Ground
Signal Return
-
25
C429XB1
Reserved
-
factory only
26
C429XA1
Reserved
-
factory only
27
C429XB2
Reserved
-
factory only
28
C429XA2
Reserved
-
factory only
29
GND
Ground
Signal Return
-
30
CSI0
Configuration Source Selection
Discrete
I
data source
configuration
31
CSI2
XPDR Source/Destination select
Discrete
I
unit number (No.1,
No.2) in dual
installations
32
SUPP
DC Power Supply
28 VDC aircraft
power
I
33
SUPP
DC Power Supply
28 VDC aircraft
power
I
34
C3V3
External Memory Module supply
Supply
I
35
CSDA
External Memory Module data
Data
I/O
36
CSCL
External Memory Module clock
Clock
O
37
GND
Ground
Signal Return
-
38
CCANN0
CAN Bus, Port 0
CAN
I/O
39
CCANP0
CAN Bus, Port 0
CAN
I/O
40
C4XXIA3
ADC/Altitude Encoder, Port B,
Line A
ARINC 429/RS422
I
configurable
41
C4XXIB3
ADC/Altitude Encoder, Port B,
Line B
ARINC 429/RS422
I
configurable
42
GND
Ground
Signal Return
-
43
CSIX
Mutual Suppression
ARINC 718A
I/O
44
CIHL0
Weight on Wheel Sensor
Discrete
I
active State
configurable, (High or
Low active)
45
C429IB1
Reserved
-
factory only
Installation
Electrical Installation
42 BXT6513-(0XX) DV15104.03 Issue 03 November 2016
P1
Pin
Signal
name
Pin Name
Function
I/O
Remarks
46
GND
Ground
Signal Return
-
47
CSI3
Transmitter Test Inhibit
Discrete
I
active if strapped to
GND.
48
CI10
ADC/Altitude Encoder Port Select
Discrete
I
Source selection
Low = Port B
High= Port A
49
CI11
Reserved
-
factory only
50
CILLI
Reserved
-
factory only
2.5.2. Connector P2
P2
Pin
Signal
name
Pin Name
Function
I/O
Remarks
1
CAX1B
Reserved
-
factory only
2
CI9
Reserved
-
factory only
3
CIX7
Reserved
-
factory only
4
CIX6
ADS-B Function Status
Discrete
I/O
Closed = ADS-B
position data receiving,
(max. drain = 100 mA)
Open = No valid
position data available.
5
CIX4
Reserved
-
factory only
6
CIX5
Burst mode enable
Discrete
I
Low = Enabled
High = Disabled
7
C429XB7
XPDR Data, Port B, Line B
ARINC 429
O
8
C429XA7
XPDR Data, Port B, Line A
ARINC 429
O
9
C429XB6
Reserved
-
factory only
10
C429XA6
Reserved
-
factory only
11
C429XB5
ADLP Output, Line B
ARINC 429
O
12
C429XA5
ADLP Output, Line A
ARINC 429
O
13
C232X
Reserved
-
factory only
14
C429XB4
Reserved
-
factory only
15
C429XA4
Reserved
-
factory only
16
C429XB3
Reserved
-
factory only
17
C429XA3
Reserved
-
factory only
18
C4XXIA4
XPDR Control, Port B, Line A
ARINC 429
I
19
C4XXIB4
XPDR Control, Port B, Line B
ARINC 429
I
20
C4XXIB5
XPDR Control, Port C, Line B
ARINC 429
I
21
C4XXIB6
Reserved
-
factory only
22
CI8
XPDR Control Port Select
I
23
C4XXIB7
Reserved
-
factory only
Installation
Electrical Installation
DV15104.03 Issue 03 November 2016 BXT6513-(0XX) 43
P2
Pin
Signal
name
Pin Name
Function
I/O
Remarks
24
GND
Ground
Signal Return
-
25
CLRXN
Ethernet Receive
10/100BASE-TX
I/O
26
CLTXN
Ethernet Transmit
10/100BASE-TX
I/O
27
C429IA7
Data Concentrator, Port A,
Line A
ARINC 429
I/O
28
C429IA6
Radio Altimeter/Data
Concentrator, Port B, Line A
ARINC 429
I/O
configurable
29
GND
Ground
Signal Return
-
30
C429IA5
IRS, Port A
ARINC 429
I
31
C429IA4
Reserved
-
factory only
32
C429IA3
FCC/MCP Data, Port A
ARINC 429
I
33
C429IA2
ADLP, Port A
ARINC 429
I
Data from ADLP
34
CAX1A
Reserved
-
factory only
35
GND
Ground
Signal Return
-
36
C4XXIA5
XPDR Control, Port C, Line A
ARINC 429
I
37
C4XXIA6
Reserved
-
factory only
38
CIX13
Extended Squitter Disable
Discrete
I
Low = Disabled
High = Enabled
39
C4XXIA7
Reserved
-
factory only
40
CIX14
Software Update Enable
Discrete
I
High = Normal operation
Low = Update enabled.
41
CLRXP
Ethernet Receive
10/100BASE-TX
I
42
GND
Ground
Signal Return
-
43
CLTXP
Ethernet Transmit
10/100BASE-TX
O
44
C429IB7
Data Concentrator, Port A,
Line B
ARINC 429
I/O
45
C429IB6
Radio Altimeter/Data
Concentrator, Port B, Line B
ARINC 429
I/O
configurable
46
GND
Ground
Signal Return
-
47
C429IB5
IRS, Port B
ARINC 429
I
48
C429IB4
Reserved
-
factory only
49
C429IB3
FCC/MCP Data, Port A
ARINC 429
I
Data from FCC/MCP
50
C429IB2
ADLP, Port B
ARINC 429
I
Data from ADLP
Installation
Electrical Installation
44 BXT6513-(0XX) DV15104.03 Issue 03 November 2016
2.5.3. Connector TOP, BOT (Antenna)
• Type: BMA female at the rear side of the unit (transformed into TNC by the backshell
BS6533).
• Antenna cable: low-loss cable.
• Signal: bi-directional
2.5.4. Connector USB
• Only for service operation
• Type: USB 2.0 Micro B
• Cable: Max. cable length: 5 m (15 ft)
• Data transfer: Bidirectional data exchange
2.5.5. Connector EM
Connection for external memory, if installed.
• Please mount a dust cup on EM connector (BXT rear side) if this connector is
not used.
For example:
• Internal memory is used.
• External memory module EM6100 connection is done via backshell.
2.5.6. Service Connector (optional)
Becker Avionics recommend the installation of a service connector. This allows the configuration of
the BXT6513-(0XX) after installation inside the aircraft.
2.5.6.1. Service connector inside the aircraft
Pinout service connector (Dsub, 9pol.) see "Figure 12: Wiring Diagram (example)" page 47.
Software + Adapter
CAN-BusAdapter
(USB)
CANbus Kit Installation
Service Connector
CAN-Bus
Figure 11: Service Connector inside the Aircraft
Installation
Interfaces
DV15104.03 Issue 03 November 2016 BXT6513-(0XX) 45
2.6. Interfaces
2.6.1. ARINC 429 Input Labels
Parameter
Label
XPDR control
016 or 031
Selected altitude
102
GNSS track angle
103
GNSS latitude
110
GNSS longitude
111
GNSS ground speed
112
GNSS latitude fine
120
GNSS longitude fine
121
GNSS horizontal integrity limit
130
GNSS vertical figure of merit
136
UTC fine
140
UTC
150
Radio altitude
164
GNSS vertical velocity
165
North-south velocity
166
East-west velocity
174
Altitude
203
Mach number
205
Indicated airspeed
206
True airspeed
210
Altitude rate
212
Flight ID
233…237 or 360
Baro correction
234
GNSS horizontal figure of merit
247
Ground speed
312
True track angle
313
True heading
314
Magnetic heading
320
Roll angle
325
Track angle rate
335
Inertial vertical velocity
365
GNSS altitude, HAE
370
Installation
Unit Configuration
46 BXT6513-(0XX) DV15104.03 Issue 03 November 2016
2.6.2. ARINC 429 Output Labels
Parameter
Label
XPDR control
016 or 031
Flight ID
233…237
Mode S address
275, 276
Maintenance
350, 353, 354
GA equipment identification
371
Equipment identification
377
2.7. Unit Configuration
The figure "General Architecture (example)", page 47 shows an example of a single unit installation
including:
• Power supply without separate switch,
• Configuration from internal memory,
• Single ADC conformant to ARINC 706,
• FMC,
• ADLP,
• GNSS sensor conformant to ARINC 743A,
• Weight-on-wheels switch, active low,
• Indicators for system status and transponder reply,
• Standby switch,
• Dual antenna (Diversity).
• Service Connector (optional).
Relevant configuration settings:
Configuration
Set to
Air Data Source Configuration
Single
Air Data Format and Resolution
ARINC 429
Air Data Port A Selection
Dedicated port
Ground Sensor Enable
Enable, active low
XPDR Control Port A Selection
Dedicated port
TCAS Interface Enable
Disable
ADLP Interface Enable
Enable
FMC Input Selection
Dedicated port
GNSS Receiver Input Selection
Dedicated port
GNSS Data Format
ARINC 743A
Installation
Unit Configuration
DV15104.03 Issue 03 November 2016 BXT6513-(0XX) 47
2.7.1. General Architecture (example)
OUT-A
OUT-B
TMARK-P
TMARK-N
OUT-A
OUT-B
OUT-A
OUT-B
OUT-A
OUT-B
OUT-A
OUT-B
IN-A
IN-B
TOP-IN
GND
BOT-IN
GND
C4XXIA1
C4XXIB1
C422IP0
C422IP1
C429IA2
C429IB2
C429IA0
C429IB0
C4XXIA2
C4XXIB2
C4XXIA0
C4XXIB0
SUPP
SUPP
PGND
PGND
CIX3
CIX4
CIX5
CSI3
CSI2
CSI1
CSI0
C429XA5
C429XB5
CRDY
CIX0
CIHLO
TOP-IN
TOP-OUT
BOT-IN
BOT-OUT
P1-20
P1-3
P1-13
P1-12
P2-33
P2-50
P1-9
P1-10
P1-21
P1-4
P1-19
P1-2
P1-32
P1-33
P1-16
P1-17
P1-6
P2-5
P2-6
P1-47
P1-31
P1-14
P1-30
P2-12
P2-11
P1-15
P1-7
P1-44
OK
REPLY
WoW switch, (closed on ground)
Operating
Standby
Do not connect
Do not connect
Do not connect
Do not connect
3 A
+28 VDC
+28 VDC Power
Supply Ground
Top Antenna Bottom Antenna
GNSS Sensor
ADLP
Flight Management
Computer
ADC
Control Panel
BXT6513-(XXX)
CCANP0
CCANN0 P1-39
P1-38
Service Connector (optional)
Dsub,
9pol,
female
2
7
Figure 12: Wiring Diagram (example)
Detailed information about wiring is available in ICD manual; please see “Order
Code”, “Available Documentation” page 26.
Installation
Unit Configuration
48 BXT6513-(0XX) DV15104.03 Issue 03 November 2016
2.7.2. Single Unit Installation
Electrical connections:
SUPP
SUPP
PGND
PGND
P1-32
P1-33
P1-16
P1-17
Avionic Master Switch
+28 VDC
Supply Ground
other
equipment
3 A
BXT6513-(XXX)
Figure 13: Single Unit Installation
2.7.3. Dual Unit Installation
Electrical connections:
SUPP
SUPP
PGND
PGND
P1-32
P1-33
P1-16
P1-17
Avionic Master Switch
+28 VDC
Supply Ground
other
equipment
3 A
BXT6513-(XXX) 2
SUPP
SUPP
PGND
PGND
P1-32
P1-33
P1-16
P1-17
Supply Ground
3 A
BXT6513-(XXX) 1
Figure 14: Dual Unit Installation
2.7.4. Unit Installation Number
In a single unit installation set the installation number to 1.
In a dual unit installation set the installation number for one unit to 1 and for the other unit to 2.
Unit installation number
unit 1
unit 2
P1 pin31
do not connect
GND
2.7.5. Data Source Configuration
Select the data source:
Data source
Internal memory
External memory
P1 pin14
do not connect
GND
P1 pin30
GND
do not connect
Installation
Unit Configuration
DV15104.03 Issue 03 November 2016 BXT6513-(0XX) 49
2.7.5.1. External Memory Module
External memory interface signals are available at P1 connector and EM connector.
If the External Memory module EM6100 is used as configuration data source the mechanical
installation is as per description:
• Backshell installation
(fix the EM6100 module to the pre-assembled connector at the back shell. Please
note, use a cable connection as short as practical but not longer than 150 mm).
Do not install two External Memory modules at same unit. The External Memory
module must always be installed when it is defined as configuration data source
(see "Data Source Configuration", page 48.
In dual unit installations with External Memory module as a configuration data
source, each unit needs its own External Memory module.
In case of dual unit installation, it is the responsibility of the installer to provide
correlated data to each unit.
Please make sure that configuration data of both units match to the aircraft and
installation. Aircraft properties include:
• Mode S address
• Maximum airspeed
• Aircraft registration
• Aircraft category
• Length and width code
Electrical connections:
CSI3
CSI2
CSI1
CSI0
P1-47
P1-31
P1-14
P1-30
Do not connect
Do not connect
Do not connect
BXT6513-(XXX) 1
CSI3
CSI2
CSI1
CSI0
P1-47
P1-31
P1-14
P1-30
Do not connect
Do not connect
BXT6513-(XXX) 2
Figure 15: Dual Unit Installation, Data Source = External Memory Module
C3V3
CSCL
CSDA
GND P1-35
P1-37
P1-34
P1-36
CSDA
GND
C3V3
CSCL
green
black
red
yellow
BXT6513-(XXX) EM FIX CPL
(with EM6100)
CSI1
CSI0 P1-14
P1-30
Do not connect
Figure 16: External Memory Module via Backshell
Installation
Unit Configuration
50 BXT6513-(0XX) DV15104.03 Issue 03 November 2016
2.7.5.2. Internal Memory
Electrical connections:
CSI3
CSI2
CSI1
CSI0
P1-47
P1-31
P1-14
P1-30
Do not connect
Do not connect
Do not connect
Signal ground
BXT6513-(XXX)
Figure 17: Single Unit Installation, Data Source = Internal Memory
2.7.6. Single Unit Installation - Antenna Diversity
Electrical connections:
TOP
GND
BOT
GND
TOP-IN
TOP-OUT
BOT-IN
BOT-OUT
Top Antenna Bottom Antenna
BXT6513-(XXX)
Figure 18: Single Unit Installation - Antenna Diversity
Installation
Unit Configuration
DV15104.03 Issue 03 November 2016 BXT6513-(0XX) 51
2.7.7. Dual Unit Installation - Antenna Diversity
Electrical connections:
TOP
GND
BOT
GND
TOP-IN
TOP-OUT
BOT-IN
BOT-OUT
CIX4
CIX3
P2-5
P1-6
Top Antenna
Microwave switch
Microwave switch
Unit 1 ON Unit 2 ON
Bottom Antenna
+28 VDC
BXT6513-(XXX) 1
TOP
GND
BOT
GND
TOP-IN
TOP-OUT
BOT-IN
BOT-OUT
CIX4
CIX3
P2-5
P1-6
BXT6513-(XXX) 2
Figure 19: Dual Unit Installation - Antenna Diversity
Installation
Unit Configuration
52 BXT6513-(0XX) DV15104.03 Issue 03 November 2016
2.7.8. Single Unit Installation – Single Controller
Relevant configuration settings:
Option
Set to
XPDR Control Port A Selection
Dedicated Port
Electrical connections:
CI8
CIX5
C4XXIA0
C4XXIB0 P1-19
P1-2
P1-22
P2-6
OUT-A
OUT-B
BXT6513-(XXX)
Controller
Do not connect
Do not connect
Figure 20: Single Unit Installation - Single Controller
2.7.9. Single Unit Installation – Dual Controller
Relevant configuration settings:
Option
Set to
XPDR Control Port A Selection
Dedicated Port
XPDR Control Port B Selection
Dedicated Port
Electrical connections:
With open switch, Controller 1 controls the transponder function.
With closed switch, Controller 2 controls the transponder function.
CIX5
CI8
P2-6
P2-22
C4XXIA0
C4XXIB0
P1-19
P1-2
C4XXIA4
C4XXIB4
P2-18
P2-19
BXT6513-(XXX)
Do not connect Controller 1
Controller 2
OUT-A
OUT-B
Controller1
Controller2
OUT-A
OUT-B
Figure 21: Single Unit Installation – Dual Controller
Installation
Unit Configuration
DV15104.03 Issue 03 November 2016 BXT6513-(0XX) 53
2.7.10. Burst Mode - Single Unit Installation
The burst mode allows for up to three sources to control the transponder operation. The selection of
the active source is dynamic. The operation in burst mode depends on “XPDR Burst Mode Control”
option.
Relevant configuration settings:
Option
Set to
XPDR Control Port A Selection
Dedicated Port
XPDR Control Port B Selection
Dedicated Port
CIX5
CIX3
CI8
CSI2
P2-6
P1-6
P2-22
P1-31
C4XXIA0
C4XXIB0
P1-19
P1-2
C4XXIA4
C4XXIB4
P2-18
P2-19
BXT6513-(XXX)
OUT-A
OUT-B
Controller1
Controller2
OUT-A
OUT-B
C4XXIA5
C4XXIB5
P2-36
P2-20
other Controller
OUT-A
OUT-B
Do not connect
Do not connect On
Standby
Figure 22: Single Unit Installation – Dual Controller
2.7.11. Transmitter Disable
This input is relevant for several tests during shop maintenance.
Leave this input open in all installations.
Relevant configuration settings:
Operation
Remarks
P1 pin47
enable
do not connect
Normal configuration
P1 pin47
disabled
GND
No transmissions from equipment – for
tests only
Installation
Configuration Data
54 BXT6513-(0XX) DV15104.03 Issue 03 November 2016
2.8. Configuration Data
The BXT6513-(0XX) must be configured with the characteristic aircraft data.
The BXT6513-(0XX) configuration is stored in a non-volatile memory.
There are two possibilities where to store or load configuration data (see "Data Source Configuration"
page 48):
• Usage of the internal memory or
• Usage of an external memory module.
• We recommend the usage of the External Memory module EM6100 as data
source.
• The usage of the internal memory as configuration data storage can only be
approved when customers have and maintain an own data base memory.
• It is a condition to store the current configuration data in the customer data
base memory.
2.8.1. Configuration of BXT6513-(0XX) with EM module
The configuration parameters of the BXT6513-(0XX) with EM module can be set via two ways:
• CANbus interface at BXT6513-(0XX) to program EM6100 which is connected to
BXT6513-(0XX) via "CANbus Kit".
• Program EM6100 by PC directly via "EMP Kit".
Detailed information are available in "EMP Extended Memory Programmer User Manual" and "ARINC 826 Data Loader
Manual", please see “Order Code”, “Available Documentation” page 26.
2.8.2. Configuration of BXT6513-(0XX) with internal memory
• The usage of the internal memory as configuration data storage can only be
approved when customers have and maintain an own data base memory.
• It is a condition to store the current configuration data in the customer data
base memory.
• In case the internal memory is used a service connector needs to be placed at a
suitable place inside the aircraft to be able to configure the device without
removing it.
Detailed information are available in "EMP Extended Memory Programmer User Manual" and "ARINC 826 Data Loader
Manual", please see “Order Code”, “Available Documentation” page 26.
For wiring example - service connection - see also "Figure 23: Software update – Aircraft Installation" page 55.
Installation
Software Update
DV15104.03 Issue 03 November 2016 BXT6513-(0XX) 55
2.9. Software Update
The BXT6513-(0XX) provides an interface for Field Loadable Software (FLS). This interface enables
in-field loading of equipment software and unit configuration.
Details in "FLS Manual" (Field Loadable Software); please see “Order Code”, “Available Documentation” page 26.
• A software update may be carried out only by authorized aircraft maintenance
personnel.
• Aircraft maintenance personnel are responsible for proper marking of performed
changes.
• After update procedure the ID plates on the BXT6513-(100) have to be
changed.
Information about software and configurable hardware versions are available via
maintenance USB connector (for details refer ICD manual chapter "Configurable
items identification”).
2.9.1. PC Requirements
• MS Vista SP2 or newer with installed .NET Framework 4.5.
• ARINC 665 Data Loader application
(recommended ARINC 826 Data Loader version 3.6.34.0 or higher available on
request).
• CAN interface - PCAN USB
(details how to install PCAN USB interface see http://www.peak-system.com).
Windows Vista, Windows .NET Framework are trademarks of Microsoft Corporation.
2.9.2. Software Update Installation
2.9.2.1. Software Update – Aircraft Installation
The BXT6513-(0XX) software update can be done without removing equipment from installation.
CCANP0
CCANN0
CIX14 P2-40 Update Control
closed=enable
P1-39
P1-38
CAN-H
120 Ω
120 Ω
other CAN device
CAN-L
BXT6513-(XXX)
CAN-bus adapter
CIHL0 P1-44 weight on wheel switch
Service Connector
(optional)
Dsub,
9pol,
female
2
7
Figure 23: Software update – Aircraft Installation
Note: If only one BXT6513 +one PC with cable length < 2 m is used, the topology without 120 Ω resistor may be used, see
"Figure 24: Software update – Laboratory Installation" page 56.
Installation
Aircraft Wiring
56 BXT6513-(0XX) DV15104.03 Issue 03 November 2016
2.9.2.2. Software Update – Laboratory Installation
CCANP0
CCANN0
CIX14 P2-40
CIHL0 P1-44
Update Control
closed=enable
weight on wheel switch
Length ≤ 2 m
P1-39
P1-38 CAN-H
CAN-L
BXT6513-(XXX) Software Data Loader
(ARINC 826)
Figure 24: Software update – Laboratory Installation
• Detailed information about required equipment, wiring, FLS interface and update
procedure in "ICD Manual (Interface Control Document)".
• It is recommended as a minimum to perform “Mode S ground test (for details see
"Mode S Ground Test", page 58).
Details in "FLS Manual" (Field Loadable Software); please see “Order Code”, “Available Documentation” page 26.
The equipment enables Field Loadable Software (FLS) only at power-on when following conditions are
provided:
• FLS function enable input is active.
• If "weight-on-wheels" input is enabled in equipment configuration and it reports "on-
the-ground" state.
When in-field loading of software is enabled, the equipment does not perform
normal operations.
Details in "FLS Manual" (Field Loadable Software); please see “Order Code”, “Available Documentation” page 26.
2.10. Aircraft Wiring
Installation of the unit varies according to aircraft and equipment design. It is
therefore only possible to provide general guidelines in this section.
See "General Architecture (example)", page 47.
Installation
Post Installation Check
DV15104.03 Issue 03 November 2016 BXT6513-(0XX) 57
2.11. Post Installation Check
It is assumed that the installation and configuration has been done before the
"Post Installation Check" will be carried out.
Once the unit is installed completely a test procedure to verify system functionality. Ensure compliance
with authority required procedures. Refer to the installation order of the minor change document or
use an own approved test protocol. The following text provides guidance for such tests.
2.11.1. Mechanical Installation and Wiring Check
• Verify all cables are securely fixed and shields connected properly to signal ground.
• Check the movement of aircraft controls to verify there is no interference.
• Verify all screws are tight, check if all connections are mechanically secured.
2.11.2. Power Supply
• Check the power supply lines and confirm correct polarity. Don´t apply reverse
voltage!
• Confirm that the aircraft power supply is within the specified limits, with and without a
running engine.
2.11.3. Antenna Check
• Applying portable reflectometer or network analyzer measure the voltage standing
wave ratio (VSWR) at the transponder end of antenna aircraft installation.
• The measured VSWR at frequencies 1030MHz and 1090MHz shall not exceed 1.5:1.
Installation
Post Installation Check
58 BXT6513-(0XX) DV15104.03 Issue 03 November 2016
2.11.4. Interference Check
• Check the unit while engine is running and powered on all other avionics/ electrical
systems on the aircraft, to verify that no significant interference exists.
• Check also that the unit does not cause significant interference with other systems.
The installer´s standard test procedure may use for the interference check and the following table can
be taken as a reference. Depending on the individual avionic systems installed in the aircraft, it might
be necessary to extend the following checklist accordingly.
Aircraft System
Function
OK
NOT OK
DME
Audio
Generators / Inverters
GPS System
Compass 1
ADF
VHF / NAV 1 all channels
VHF / NAV 2 all channels
Marker Beacon
Motor(s)
Engine Instruments
Storm scope
Transponder
Air Data Computer
Autopilot and Servos
For the remaining avionic equipment repeat all interference checks during a flight and include all
equipment not previously checked out on ground.
2.11.5. Mode S Ground Test
After successful completion of the previously described post installation checks perform a Mode S
ground test. (Refer to FAR 43 Appendix F or EASA CS-ACNS). The part 145 company approved test
protocol shall finally be used.
An experienced test setup configuration shall also be arranged, otherwise refer to the user instruction
of your specific test equipment.
2.11.6. Error / Failure Indication
It is possible to read out and reset error flags for details contact Becker Avionics Customer Service.
Error / Failure List for details contact Becker Avionics Customer Service.
Operating Instructions
Device Description
DV15104.03 Issue 03 November 2016 BXT6513-(0XX) 59
3. Operating Instructions
In this chapter you can read about:
3.1. Device Description ...................................................................................................................... 59
3.1.1. Device Assignment ........................................................................................................... 59
3.1.2. Packing, Transport, Storage ............................................................................................. 59
3.1.3. Scope of Delivery .............................................................................................................. 59
3.1.4. Type Plate ......................................................................................................................... 59
3.2. Start-up ........................................................................................................................................ 60
3.2.1. Built In Tests (BIT) ............................................................................................................ 60
3.3. Operating..................................................................................................................................... 60
3.3.1. Operating with OEM Controller ......................................................................................... 60
3.4. Read Out and Reset Error Flags ................................................................................................ 60
3.1. Device Description
BXT6513-(0XX) is a remote controlled unit, which does not include a control panel. It can receive
commands and provides data through a set of interfaces.
3.1.1. Device Assignment
This manual is valid for the following devices:
• See page 30
3.1.2. Packing, Transport, Storage
• See page 29
3.1.3. Scope of Delivery
• See page 30
3.1.4. Type Plate
• See page 31
Operating Instructions
Start-up
60 BXT6513-(0XX) DV15104.03 Issue 03 November 2016
3.2. Start-up
3.2.1. Built In Tests (BIT)
BXT6513-(0XX) has advanced Built-In-Test. It monitors most of internal circuits against failures. In
addition BIT monitors some external (installation) conditions to increase reliability. There are three
types of BIT implemented:
• PBIT (performed after Power ON the unit).
The test routine PBIT checks:
o System integrity,
o Software integrity,
• IBIT (initiated by special command via serial protocol).
The test routine IBIT checks:
o Transmitter operation
• CBIT (which continuously check operation).
The test routine CBIT checks:
o Reply transmissions,
o Squitter transmissions,
o Transponder receivers operation,
o Interfaces operation,
o System integrity,
o Equipment temperature,
o Internal voltages.
3.3. Operating
3.3.1. Operating with OEM Controller
For detailed information please refer to the manual of the connected respective OEM product.
3.4. Read Out and Reset Error Flags
It is possible to read out and reset error flags.
Read out with:
• Connected OEM product,
for detailed information please refer to the manual of the respective connected
OEM product.
Operating Instructions
Read Out and Reset Error Flags
DV15104.03 Issue 03 November 2016 BXT6513-(0XX) 61
Blank Page
Operating Instructions
Read Out and Reset Error Flags
62 BXT6513-(0XX) DV15104.03 Issue 03 November 2016
Blank Page
Operating Instructions
Read Out and Reset Error Flags
DV15104.03 Issue 03 November 2016 BXT6513-(0XX) 63
Blank Page
Index
64 BXT6513-(0XX) DV15104.03 Issue 03 November 2016
4. Index
Abbreviations .................................................. 6
Accessories ............................................ 26, 27
Additional Conditions of Utilization ................. 9
Additional Required Equipment .................... 30
ADS-B ........................................................... 16
Aircraft Wiring ............................................... 56
Antenna Installation ...................................... 36
ARINC 429 .................................................... 18
BIT ................................................................ 60
Built In Tests ................................................. 60
Certification ................................................... 24
Conditions of Utilization .................................. 9
Configuration with EM module ...................... 54
Connector 1 .................................................. 44
Connector P1 ................................................ 40
Connector P2 ................................................ 42
Connector TOP, BOT (Antenna) .................. 44
Connector USB ............................................. 44
Device Assignment ................................. 30, 59
Dimensions ................................................... 37
Diversity ........................................................ 15
Environmental Condition............................... 23
General Description ...................................... 11
Grounding ..................................................... 34
Hardware Configuration ................................ 46
In-field loading functionality ........................... 55
Installation ..................................................... 29
Installation Check .......................................... 57
List of Abbreviations ........................................ 6
Mode S .......................................................... 15
Mounting ....................................................... 33
Non Warranty Clause ...................................... 9
Operation Instructions ................................... 59
Order Code ................................................... 26
Packaging, transport, storage ....................... 29
PC Requirements .......................................... 55
Pressurised cabin.......................................... 36
Purpose of Equipment .................................. 13
Radiation risk ................................................ 36
Reset Error Flags .......................................... 60
Safety Definitions ............................................ 8
Software Configuration ................................. 54
Software Data Plate ...................................... 32
Software Update ........................................... 55
Type Plate ..................................................... 31
Units ................................................................ 7
Usage of the internal memory ....................... 54
Variants Overview ......................................... 14
Warranty Conditions ....................................... 9
We reserve the right to make technical changes.
The data correspond to the current status at the time of printing.
© 2016 by Becker Avionics GmbH / all rights reserved
*** End of the Document ***
