Manual
5187URF2
Page 1
GENERAL MANUAL
1 SPECIFICATIONS
w One channel, 4095ID
w Cordless Technology: Radio frequency
w Frequency: Keyboard 27.145MHz
Mouse 27.045MHz
w Unmodulation: Keyboard take out R16
Mouse take out L8
w Keyboard output power: 0.125mV@3m
w Mouse output power: 0.026mV@3m
w Cable: USB connecter
w Cable Length: 1850mm
2 KEYBOARD
w Effective distance: 27MHz: 2M ± 0.2M
w Battery life: 7.5 months (4hrs/day)≒
w Input power: 3Vdc (2 x AA alkaline)
w Rated output power level (Max): -16dbm
w Switch activation mechanism: membrane
w Travel distance: 3.85 ± 0.5mm
w Peak load before make (normal key): 55 ± 20g
w Dimension: 464 (L) x 187 (W) x 43 (H) mm
w Weight (including batteries): 0.82kg
3 MOUSE
w Effective distance: 27MHz: 1.5M ± 0.2M
w Battery life: 1.3 months (4hrs/day)
w Input power: 3Vdc (2 x AA alkaline)
w Rated output power level (Max): -16dbm
w Buttons: 2 buttons, scroll button (3-button Type)
w Tracking: Optical sensor
w Resolution: 800 DPI
w Tracking speed: 5 inch/sec
w Accuracy: 10%
w Dimension: 119.64 (L) x 64.08 (W) x 40.29 (H) mm
w Weight (including batteries): 0.09kg
4 SYSTEM REQUIREMENTS
w IBM PC or compatible
w Available USB port.
w CD-ROM drive or DVD drive
w Microsoftâ Windowsâ 98, Windowsâ ME, Windowsâ 2000 or Windowsâ XP
operating system
5187URF2
Page 2
5187URF2
C
C
o
o
n
n
f
f
i
i
d
d
e
e
n
n
t
t
i
i
a
a
l
l
Page 3
5187URF2
C
C
o
o
n
n
f
f
i
i
d
d
e
e
n
n
t
t
i
i
a
a
l
l
Page 4
FCC GUIDELINES
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
s Reorient or relocate the receiving antenna
s Increase the separation between the equipment and receiver
s Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
s Consult the dealer or an experienced radio/TV technician for help.
The Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulation.
Cet appareil numerique de la class B respecte toutes les exigences du Règlement sur le materiel brouilleur du Canada.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired
operation.
This equipment is intended for use in the following countries EU 15 countries:
Austria, Belgium, Denmark, Finland, France, Germany, Ireland, Italy, Luxembourg, Netherlands, Spain, Sweden, United Kingdom,
Portugal, Greece. And other non-EU countries: Switzerland, Norway, and Iceland.
低功率電波輻射性電機管理辦法：
第十二條：經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、加大功率或變更原設計之特性及
功能。
第十四條：低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停用，並改善至無干擾時方得繼續
使用。
前項合法通信，指依電信法規定作業之無線電信。
低功率射頻電機需忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。
Caution:
Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to
operate this equipment. Shielded interface cable, if any, must be used in order to comply with emission limits.
The information in this document is subject to change without notice and does not represent a commitment on the part of the vendor.
No warranty of representation, either expressed or implied, is made with respect to the quality, accuracy or fitness for any particular
purpose of this document. The manufacturer reserves the right to make changes to the content of this document and/or the products
associated with it at any time without obligation to notify any person or organisation of such changes.
In no event will the manufacturer be liable for direct, indirect, special, incidental or consequential damages arising out of the use or
inability to use this product or documentation, even if advised of the possibility of such damages.
Copyright © 2003. All rights reserved
IBM, PC/AT and PS/2 are registered trademarks of International Business Machines Corporation.
Microsoft, Windows, and Windows NT are registered trademarks of Microsoft Corporation in the United States of America and/or other
countries.
All other trademarks are trademarks of their respective holders.
