Behavior Tech Computer KB5187URF492 Wireless Keyboard User Manual 5187URF2 49MHz manual

Behavior Tech Computer Corporation Wireless Keyboard 5187URF2 49MHz manual

Users Manual

C
C
o
o
n
n
f
f
i
i
d
d
e
e
n
n
t
t
i
i
a
a
l
l
5187URF2+ MANUAL
1 SPECIFICATIONS
w One channel, 4095ID
w Cordless Technology: Radio frequency
w Frequency: Keyboard 49.865MHz
Mouse 49.845MHz
w Cable: USB connecter
w Cable Length: 1800mm
2 KEYBOARD
w Effective distance: 49MHz: 3M ± 0.2M
w Battery life: 7.5≒ months (4hrs/day)
w Input power: 3Vdc (2 x AA alkaline)
w Rated output power level (Max): -16dbm
w Switch activation mechanism: membrane
w Travel distance: 3.85 ± 0.5mm
w Peak load before make (normal key): 55 ± 20g
w Dimension: 464 (L) x 187 (W) x 43 (H) mm
w Weight (including batteries): 0.82kg
3 MOUSE
w Effective distance: 49MHz: 3M ± 0.2M
w Battery life: 1.3 months (4hrs/day)
w Input power: 3Vdc (2 x AA alkaline)
w Rated output power level (Max): -16dbm
w Buttons: 2 buttons, scroll button (3-button Type)
w Tracking: Optical sensor
w Resolution: 800 DPI
w Tracking speed: 5 inch/sec
w Accuracy: 10%
w Dimension: 119.64 (L) x 64.08 (W) x 40.29 (H) mm
w Weight (including batteries): 0.09kg
4 SYSTEM REQUIREMENTS
w IBM PC or compatible
w Available USB port.
w CD-ROM drive or DVD drive
w Microsoftâ Windowsâ 98, Windowsâ ME, Windowsâ 2000 or Windowsâ XP operating
system
C
Co
on
nf
fi
id
de
en
nt
ti
ia
al
l
C
Co
on
nf
fi
id
de
en
nt
ti
ia
al
l
C
Co
on
nf
fi
id
de
en
nt
ti
ia
al
l
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
INFORMATION TO USER:
The users manual or instruction manual for an intentional or unintentional radiator shall
caution the user that changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
