Quick Installation Guide
Congratulations on your purchase of this keyboard! This unique keyboard
combines the Microsoft Office applications, including Microsoft Word, Excel,
PowerPoint. All functions you use in Office applications show on the keyboard
for your fingertips. Besides Multimedia and Internet keys are included. It
contains health concept of minimal mouse movement and the ergonomics
design. This keyboard helps you take less time to do the work you do all the
time.
System Requirement
w Microsoft Windows NT 4.0, Windows 95, Windows 98,
Windows ME, Windows 2000 or Windows XP operating system
w CD-ROM or DVD drive (for CD or Video operation)
w Standard sound card (for CD or Video operation)
w PS/2 port
w Microsoft Office 97 or later version (for Office Application keys and
Enhanced Function keys)
w Microsoft Internet Explorer 5.0 or later version (for the Internet keys)
w The system supporting ACPI or APM II (for power management buttons)
w ATX mother board and ATX power supply (for power management
buttons)
Hardware Installation
1. Make sure your PC is switched off.
2. Plug the keyboard connector into the keyboard PS/2 port of your PC.
3. Start your PC, your computer will auto-detect your keyboard.
Software Installation
1. Check if there is any keyboard driver existed. If yes, please remove it
before installing this keyboard driver.
2. Insert the driver disc in your computer CD-ROM drive, and run the
“Autorun.exe”.
3. Select driver for “Minimum Installation” or “Typical Installation”
according to your operating system.
4. Follow the on screen instructions to finish the installation procedure. The
driver will be installed at C:\program files\keymaestro.
5. After installation, restart your computer to enable the keyboard software.
Hot Keys Block
w Office Application Keys Block : Word, Excel, PowerPoint and Calendar.
w Enhanced Function Keys Block: Office Wizard Key and Embedded Office
Keys.
w Internet Keys Block : WWW, E-mail, Back, Forward, Refresh,
Search and My favorite.
w Application Keys Block : My computer, Calculator and Power.
w Multimedia Keys Block : Volume up, Volume down, Mute.
w Clipboard Key Block : Application Switch.
Connector – Pin Assignment
PS/2 Compatible Cable
(6-pin Miniatures Din Connector)
Pin# Signal Name Voltage
1Keyboard Clock +5VDC Signal
2Ground 0
3Keyboard Data +5VDC Signal
4Reserved 0
5+5VDC +5VDC
6Reserved 0
FCC GUIDELINES
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
♦ Reorient or relocate the receiving antenna.
♦ Increase the separation between the equipment and receiver.
♦ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
♦ Consult the dealer or an experienced radio/TV technician for help.
♦ Use only shielded cables to connect I/O devices to this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, (2) this device must accept any interference received, including interference
that may cause undesired operation.
Information to User:
F Any changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate this equipment. Shielded interface cable, if any, must be used in
order to comply with emission limits.
IBM AT and PS/2 are registered trademarks of International Business Machines Corporation.
Microsoft and Windows are registered trademarks of Microsoft Corporation in the United States and/or other
countries.
All other trademarks are trademarks of their respective holders.
