Behavior Tech Computer MS5187URF49 Wireless Optical Mouse User Manual
Behavior Tech Computer Corporation Wireless Optical Mouse Users Manual
Users Manual
BEHAVIOR TECH COMPUTER CORP. 5187URF+ (49MHz) Manual Ver.1.0
C
Co
on
nf
fi
id
de
en
nt
ti
ia
al
l
January 3, 2005 BTC property, do not copy or distribute outside of your department. Page 1
A. GENERAL SPECIFICATION
1 SPECIFICATIONS
One channel, 4095ID
Cordless Technology: Radio frequency
Frequency: Keyboard 49.865MHz
Mouse 49.845MHz
Cable: USB connecter
Cable Length: 1800mm
2 KEYBOARD
Effective distance: 49MHz: 3M ± 0.2M
Battery life: ≒ 7.5 months (4hrs/day)
Input power: 3Vdc (2 x AA alkaline)
Rated output power level (Max): -16dbm
Switch activation mechanism: membrane
Travel distance: 3.85 ± 0.5mm
Peak load before make (normal key): 55 ± 20g
Dimension: 464 (L) x 187 (W) x 43 (H) mm
Weight (including batteries): 0.82kg
3 MOUSE
Effective distance: 49MHz: 3M ± 0.2M
Battery life: 1.3 months (4hrs/day)
Input power: 3Vdc (2 x AA alkaline)
Rated output power level (Max): -16dbm
Buttons: 2 buttons, scroll button (3-button Type)
Tracking: Optical sensor
Resolution: 800 DPI
Tracking speed: 5 inch/sec
Accuracy: 10%
Dimension: 119.64 (L) x 64.08 (W) x 40.29 (H) mm
Weight (including batteries): 0.09kg
4 SYSTEM REQUIREMENTS
IBM PC or compatible
Available USB port.
CD-ROM drive or DVD drive
Microsoft Windows 98, Windows ME, Windows 2000 or Windows XP operating
system
BEHAVIOR TECH COMPUTER CORP. 5187URF+ (49MHz) Manual Ver.1.0
C
Co
on
nf
fi
id
de
en
nt
ti
ia
al
l
January 3, 2005 BTC property, do not copy or distribute outside of your department. Page 2
BEHAVIOR TECH COMPUTER CORP. 5187URF+ (49MHz) Manual Ver.1.0
C
Co
on
nf
fi
id
de
en
nt
ti
ia
al
l
January 3, 2005 BTC property, do not copy or distribute outside of your department. Page 3
BEHAVIOR TECH COMPUTER CORP. 5187URF+ (49MHz) Manual Ver.1.0
C
Co
on
nf
fi
id
de
en
nt
ti
ia
al
l
January 3, 2005 BTC property, do not copy or distribute outside of your department. Page 4
Federal Communication Commission
Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
INFORMATION TO USER:
The users manual or instruction manual for an intentional or unintentional radiator shall
caution the user that changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
