6301URF Ⅲ Quick Installation Guide
Hardware Installation
Front View of Back View of
USB Connector USB Connector
(--)
(+)
(+)
(--)
1. Plug in the receiver connector into your available USB port on PC.
2. Make sure the batteries of the keyboard and mouse are installed
correctly. Please follow the polarity signs in the battery compartment.
3. Please make sure the slide switch on the back of the mouse is
switched to “on” before using the mouse. When not in use, please turn
the slide switch to “off” for power saving.
Pairing Procedure
The wireless kit can operate out of the box immediately after you plug the
receiver USB connector into your PC USB port. If it can’t work, please follow
the steps below to process ID setting of the Wireless Kit.
The pairing/connect button is the LED light on top of the receiver. The LED
shows the pairing or data reception status.
The ID-recognition function helps to protect against interference from other
RF products in the same environment. Remember to pair ID when other RF
products affect your keyboard kit.
w Mouse pairing procedure:
1. Press the pairing/connect button on top of the receiver first. Receiver
LED indicator will blink slowly indicating it’s ready to receive
keyboard/mouse pairing information.
2. Next, press the pairing/connect button on the bottom of the mouse
once.
w Keyboard pairing procedure:
1. Then press the pairing/connect button on top of the receiver again.
2. Press the pairing/connect button on the bottom of the keyboard.
Receiver LED indicator flashes 3 times rapidly as indication it’s paired with
this keyboard and mouse.
Note:
- Each procedure should be completed within 60 seconds.
Connect Button
Power Switch
- Make sure your PC is on and running when doing the pairing procedure.
- You don’t have to pair ID again after changing batteries.
Driver Installation
n USB Device Driver
The USB device driver is included in Windows operating system.
During initial installation of the USB device, the system will automatically detect a new hardware being added, and then bring up
"Add New Hardware Wizard" dialogue box. For Windows® ME, Windows® 2000 and Windows® XP operating system, the system
will run automatically and finish the installation steps. But for Windows® 98SE operating system, please follow the Wizard's USB
driver installation steps to install USB Device Driver. Once this installation step is completed the basic functions of the USB device
will work under the operating system. The additional functions are provided only after the KeyMaestro application is installed.
n KeyMaestro Input Device Driver
1. After you download the driver, please find the “SetupKey.exe” in the directory and double-click this file.
2. Follow the on-screen instruction to install the driver.
3. The driver icon will show at the right-bottom of the Windows system tray when the driver is loaded.
Important Information
- For Windows® 98SE operating system, please go to http://www.btc.com/ website to download and install the “KeyMaestro Input
Device Driver” to have the Internet Keys Block and Multimedia Keys Block functions.
- For Windows® ME, Windows® 2000 and Windows® XP operating system, you can use the keyboard immediately after plugging
the receiver connector into PC. If you want to enjoy the full potentiality function of the keyboard, please visit our website at
http://www.btc.com/ to download and install the “KeyMaestro Input Device Driver”. Once the driver has been installed, these hot
keys are reprogrammable, except Volume Up / down and Mute. They can be configured as a string, a combination key, a web site,
an existing file, or a function that the driver pre-defines for you.
Pairing/connect button on the bottom
of the keyboard
Pairing/connect button
on top of the receiver
(With a LED indicator
under the
pairing/connect button)
Pairing/connect
button on the bottom
of the mouse
English
6301URF Ⅲ BTC QIG 3100507040 Version 1.0-Preliminary English
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's
authority to operate this equipment.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End users must follow the
specific operating instructions for satisfying RF exposure compliance.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
