Version 1.1 March 2003

Technical Specifications

ENGLISH

V-AMP PRO

2

V-AMP PRO

V-AMP PRO

V-AMP PRO

Professional Guitar Amp Modeling and Multi-Effects Processor with Additional 24-Bit/96 kHz Digital

Output and ULTRA-G Cabinet Simulation

s32 authentic virtual amp models can be combined with any of the 15 speaker cabinet simulations, noise

gate, compressor, wah-wah, modulation effects, delay and reverb

s125 memory locations, divided into 25 banks of 5 presets each

sFacilitates direct recording without an amp for professional guitar tones

sEasy, intuitive operation with self-explanatory controls

sComprehensive LEDs show all current settings

s15 rear panel connectors allow comprehensive routing and suit virtually every conceivable application

sAdditional unparalleled authentic cabinet simulation with sound designed by Juergen Rath

sStereo headphones output with adjustable volume

sAdjustable auto-chromatic tuner

sInternal power supply unit

sExtremely low-noise instrument input ensures maximum guitar signal integrity

sPre DSP send/return for dry recording and wet monitoring

sStereo 1/4" line outputs controlled by master volume for live use as guitar preamp

sBalanced stereo XLR DI out with ground lift and switchable ULTRA-G cabinet simulation

sPost DSP stereo inserts for connection of external effects

sPhones output on front panel for easy access

sBNC wordclock input for external sample rate synchronization up to 96 kHz

sAES/EBU and S/PDIF connectors allow usage as an all-purpose A/D converter with 24-bit/96 kHz digital

output

sMIDI In, Out/Thru

sManufactured under ISO9000 certified management system

3

V-AMP PRO

SPECIFICATIONS

AUDIO INPUTS

INSTRUMENT INPUT 1/4" TRS connector, unbalanced

Input impedance 1 MΩ

Max. input level +9 dBu

PRE DSP RETURN LINE IN 1/4" TRS connector, unbalanced

Input impedance 20 kΩ

Max. input level +15 dBu

POST DSP INSERT RETURN L/R 1/4" TRS connectors,

unbalanced

Input impedance 40 kΩ

Max. input level +8 dBu

AUDIO OUTPUTS

ANALOG LINE OUTPUTS L/R 1/4" TRS connectors, unbalanced

Output impedance approx. 680 Ω

Max. output level +20 dBu

PRE DSP SEND/LINE OUT 1/4" TRS connector, unbalanced

Output impedance <1 kΩ

Max. output level +9 dBu

POST DSP INSERT SEND L/R 1/4" TRS connectors, unbalanced

Output impedance 1 kΩ

Max. output level +8 dBu

BALANCED LINE OUT XLR connector, balanced

Output impedance 100 Ω

Max. output level +14 dBu (Studio); -10 dBu (Live)

HEADPHONES CONNECTOR 1/4" TRS stereo connector,

unbalanced

Max. output level +15 dBu/100 Ω (+23 dBm)

DIGITAL OUTPUTS

Format AES/EBU and S/PDIF, switchable

Sample frequency 44.1 / 48 / 96 kHz internal,

32 - 96 kHz wordclock,

sample rate converter

Type XLR (transformer-balanced)

Output impedance 110 Ω

Nominal output level 3.5 V peak-to-peak

Type RCA (not grounded, unbalanced)

Output impedance 75 Ω

Nominal output level 0.5 V peak-to-peak

(not grounded, unbalanced)

WORDCLOCK INPUT

Type BNC, coax-type

Input impedance 50 kΩ

Nom. input level 2 - 6 V peak-to-peak

MIDI

Type 5-pole DIN jacks IN, OUT / THRU

DIGITAL SIGNAL PROCESSING

Converter 24-bit Delta-Sigma,

64/128 times oversampling

Dynamics A/D 104 dB @ preamp bypass

Dynamics D/A 92 dB

Sample rate 31.250 kHz

DSP 100 Mips

Delay time max. 1,933 msec. stereo

Runtime (line in -> line out) approx. 5 msec.

DISPLAY

Type 7-digit LED

POWER SUPPLY

Mains voltage

U.S.A./Canada 120 V~, 60 Hz

Europe/U.K./Australia 230 V~, 50 Hz

Japan 100 V~, 50 - 60 Hz

General export model 120/230 V~, 50 - 60 Hz

Power consumption 15 W

Fuse 100 - 120 V ~: T 400 mA H

200 - 240 V ~: T 200 mA H

Mains connection standard IEC receptacle

DIMENSIONS/WEIGHT

Dimensions (H x W x D) approx. 3 1/2" x 19" x 5 1/4"

(89 mm x 482.6 mm x 135 mm)

Weight approx. 2.6 kg (5 3/4 lbs)

BEHRINGER constantly strives to maintain the highest quality standards. Modifi-

cations may be made, if necessary, without prior notice. The specifications and appearance

of the equipment may therefore differ from those listed or illustrated.
