Learn about Mi Router HD
Introduction
Manage your network using the mobile app
Anti-hijacking, sharing media files.
4-antennae design. Stronger signal, better coverage
4 omni-directional antennae allow higher speed and better wall
penetration.
Dual-band AC network with MU-MIMO support
Seamless connectivity with multiple devices, speed up to
2533Mbps.
5G
New and faster USB 3.0
Connect external storage via USB and share files wirelessly.
Regular updates
Equipped with the smart system Mi Wi-Fi, which is constantly
optimized and updated to improve stability and security.
Compatible with Gigabit Ethernet broadband interface
1 WAN port and 3 LAN ports.
* Use Gigabit-compatible network cables for best effect.
Connect Mi Router to the InternetGigabit WAN Ethernet ports
Press to reset the routerReset buttonReset
Connect USB devices (supports USB 3.0)USB port
Connect Mi Router power adapterPower adapter outlet12V 3A
Ports and buttons
Turn the router on and offPower button
Connect devices using network cableGigabit LAN Ethernet ports
FAQ
I connected the network cable and completed the setup process. Why can't I connect to the Internet ?
Check if the cable is connected properly. Make sure you've entered the username and password provided by your network provider correctly.Test network using Mi Wi-Fi app, or try to open a
website in your browser. Follow the instructions provided in the results of the network diagnostics. These are the possible problems and their solutions:
Error 678: Your network provider doesn't allow using the same account to login twice.
Solution: Re-connect the network cable, turn off and reboot your Fiber Modem/ADSL modem/network switch, wait for 10 minutes, and try again.
Error 691: Your password is incorrect, or the account you're using has expired.
Solution: Make sure your login and password are correct, confirm the information about your account with the network provider.
What is the default address and password of the admin platform ?
Mi Wi-Fi admin platform can be found at miwifi.com or 192.168.31.1. The default password is the same password you set during the initial setup.
Why is the LED light red after a reboot ?
If the LED light is blinking red, it means that the router can't finish the reboot due to an error and has entered safe mode.
In such case, your files are protected. You can connect the router to the computer via network cable, and then re-flash and restore your router.
If the red light is steady, it means that the router can't finish the reboot and can't enter safe mode.
Please contact your local Mi Home or customer support to solve the problem.
LED light
Here's what the colors of the
LED light mean:
* See FAQ when the LED light is red
The router works normally (steady)Blue
Yellow
The router is in safe mode (flashing),
or a system error occurred (steady)
The router is being updated (flashing)
or rebooted (steady)
The router is off or disconnected from
the power outlet
Off/Grey
Red
Back up photos from your phone
Connect to Wi-Fi and back up photos automatically
(setup in the Mi Wi-Fi app).
Digital camera backups
Connect your camera to Mi Router via USB to back up
new photos automatically.
Access files anywhere
View and open files stored on Mi Router directly from the app on your mobile devices.
Huge storage for media files
Save media files on Mi Router's hard drive and stream them on your mobile devices.
Quality of Service
PowerWAN（lnternet)
Connect AC power and network cable
Connect AC power adapter to the router by attaching power
cables. Connect the network cable to the WAN port.
* The other end of network cable should be connected to Fiber
Modem/ADSL modem/network switch, or contact your ISP for
assistance.
Thank you for choosing Mi Router HD
3 Steps to get online.
Download Mi Wi-Fi app
Scan the QR code to download
and install the Mi Wi-Fi app.
Setup
Assign priority to each device and service operating on your network.
Control the amount of bandwidth each is allowed to consume based on its
mission.
Parental Controls
Block inappropriate and potentially harmful sites.
Restrict Internet access during specific time.
Product: Mi Router HD
Model: R3D
Manufacturer: Beijing Xiaomi Electronics Co., Ltd.
Address: No.58 Yard, Fifth Jinghai Road, Beijing
Economic-Technological Development Area, Beijing, China.
Connect to Wi-Fi and open the app
Connect your mobile device or computer to the Wi-Fi
network (network name: Xiaomi_XXXX), open the Mi
Wi-Fi app, and follow instructions.
* XXXX are the 4 last digits of the router's MAC address
(see the bottom of the device).
Xiaomi_XXXX
Xiaomi_XXXX_5G
Public
MIOffice
Connect
Connect
FCC statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
・If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
RF exposure warning
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This equipment must be installed and operated in accordance with provided instructions and the
antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm
from all persons and must not be co-located or operating in conjunction with any other antenna or
transmitter.
NOTE: Any changes or modifications not expressly approved by the grantee of this device could void
the user's authority to operate the equipment.
FCC ID: 2AIMRMIWIFIR3D Beijing Xiaomi Electronics Co., Ltd.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Mi Router HD
