Belkin >
Users Manual
System Requirements
Monitor
Flip supports any monitor with a VGA connection. You can also use
your DVI-I monitor with Flip by connecting a VGA adapter to the DVI
cable. Flip does not support direct DVI connections from monitors.
Keyboard/Mouse
Flip supports any keyboard and mouse with a USB connection.
Computers
Flip can be used with any PC or Mac® desktop or notebook computer
that supports USB keyboard and mouse connections, and that runs on
one of these operating systems:
• Windows® 98 SE, 2000, XP, 2003
• Mac OS® X v10.0 and above
• Linux®
Package Contents
• Wireless Remote
• Base with Cables
• Audio Extension Cable
• Fastener Strip
• Battery
Introduction
Congratulations and thank you for purchasing Flip Wireless. Flip is
easy to set up and use, and comes with everything you need to share
one monitor, keyboard, mouse, and one set of speakers between your
two computers. No additional cables or software are required.
The diagram below shows a typical Flip Wireless setup. The wireless
remote sits on your desk. Your monitor, keyboard, mouse, and
speakers plug into the base, and the base connects to your two
computers through the attached cables.
Installing your Flip
Before you begin, make sure that your USB keyboard and mouse work
properly with both computers.
1. Power on your computers.
2. Connect your monitor, keyboard, mouse, and speakers to the
base. Insert the battery into the wireless remote (positive side
facing out), and place the remote anywhere on your desk within
10 feet of the base.
3. Connect one set of cables to the monitor, USB, and speaker ports
on your first computer. Wait for your computer to recognize the
new USB device (Flip). Then connect the other set of cables to the
monitor, USB, and speaker ports on your second computer. If the
cable is not long enough to connect to your speaker port, use the
included audio extension cable.
You are now ready to use your Flip.
Flip Tip:
Use the included fastener strip to attach
the remote to your monitor, keyboard,
desk, or other item.
Flip Tip:
Keep the base behind your computers to
keep your desk free of cable clutter.
Package Contents/Introduction 1 System Requirements 2 Installing your Flip 3 Installing your Flip 4
Using your Flip
When you power up your computers, your first computer’s desktop
will appear on your monitor. You are now ready to use that computer
as if it were directly connected to your monitor, keyboard, mouse,
and speakers.
To switch access to your other computer, simply press the remote.
Your other computer’s desktop will appear on your monitor. You are
now ready to use your other computer as if it were directly connected
to your monitor, keyboard, mouse, and speakers. Press the remote
each time you want to switch access from one computer to the other.
Optional Software
You can install software onto your computers that will allow you to
flip between computers using a desktop icon or keyboard hot-key
sequence. The software will also allow you to listen to music files
on one computer while you work on the other. To download the free
software, please visit our website at www.belkin.com/flip.
Note: For a list of frequently asked questions and troubleshooting
tips, please visit our website at www.belkin.com/flip.
Using your Flip 5
USB connection
VGA connection
User Guide F1DG102W
Information
FCC Statement
DECLARATION OF CONFORMITY WITH FCC RULES FOR
ELECTROMAGNETIC COMPATIBILITY
We, Belkin Corporation, of 501 West Walnut Street, Compton CA 90220, declare
under our sole responsibility that the product F1DG102W, to which this
declaration relates:
Complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
CE Declaration of Conformity
We, Belkin Corporation, declare under our sole responsibility that the F1DG102W, to
which this declaration relates, is in conformity with Emissions Standard EN55022 and
with Immunity Standard EN55024, LVP EN61000-3-2, and EN61000-3-3.
ICES
This Class B digital apparatus complies with Canadian ICES-003. Cet appareil
numérique de la classe B est conforme á la norme NMB-003 du Canada.
Belkin Corporation Limited 3-Year Product Warranty
What this warranty covers.
Belkin Corporation warrants to the original purchaser of this Belkin product that the
product shall be free of defects in design, assembly, material, or workmanship.
What the period of coverage is.
Belkin Corporation warrants the Belkin product for three years.
What will we do to correct problems?
Product Warranty.
Belkin will repair or replace, at its option, any defective product free of charge (except
for shipping charges for the product).
Belkin Corporation
501 West Walnut Street
Los Angeles, CA 90220-5221, USA
310-898-1100
310-898-1111 fax
Belkin Ltd.
Express Business Park, Shipton Way
Rushden, NN10 6GL, United Kingdom
+44 (0) 1933 35 2000
+44 (0) 1933 31 2000 fax
Belkin Ltd.
7 Bowen Crescent, West Gosford
NSW 2250, Australia
+61 (0) 2 4372 8600
+61 (0) 2 4372 8603 fax
Belkin B.V.
Boeing Avenue 333
1119 PH Schiphol-Rijk, The Netherlands
+31 (0) 20 654 7300
+31 (0) 20 654 7349 fax
Belkin Tech Support
US: 800-223-5546 ext. 2263
310-898-1100 ext. 2263
Europe: 00 800 223 55 460
Australia: 1800 235 546
New Zealand: 0800 235 546
Singapore: 800 616 1790
© 2006 Belkin Corporation. All rights reserved. All trade names are registered trademarks
of respective manufacturers listed. Mac and Mac OS are trademarks of Apple Computer,
Inc., registered in the U.S. and other countries. Windows is either a registered trademark or
trademark of Microsoft Corporation in the United States and/or other countries.
Information 7
What is not covered by this warranty?
All above warranties are null and void if the Belkin product is not provided to
Belkin Corporation for inspection upon Belkin’s request at the sole expense of the
purchaser, or if Belkin Corporation determines that the Belkin product has been
improperly installed, altered in any way, or tampered with. The Belkin Product
Warranty does not protect
against acts of God (other than lightning) such as flood, earthquake, war, vandalism,
theft, normal-use wear and tear, erosion, depletion, obsolescence, abuse, damage
due to low voltage disturbances (i.e. brownouts or sags), non-authorized program, or
system equipment modification or alteration.
How to get service.
To get service for your Belkin product you must take the following steps:
1. Contact Belkin Corporation at 501 W. Walnut St., Compton CA 90220, Attn:
Customer Service, or call (800)-223-5546, within 15 days of the Occurrence. Be
prepared to provide the following information:
a. The part number of the Belkin product.
b. Where you purchased the product.
c. When you purchased the product.
d. Copy of original receipt.
2. Your Belkin Customer Service Representative will then instruct you on how to
forward your receipt and Belkin product and how to proceed with your claim.
Belkin Corporation reserves the right to review the damaged Belkin product. All
costs of shipping the Belkin product to Belkin Corporation for inspection shall be
borne solely by the purchaser. If Belkin determines, in its sole discretion, that it
is impractical to ship the damaged equipment to Belkin Corporation, Belkin may
designate, in its sole discretion, an equipment repair facility to inspect and estimate
the cost to repair such equipment. The cost, if any, of shipping the equipment to and
from such repair facility and of such estimate shall be borne solely by the purchaser.
Damaged equipment must remain available for inspection until the claim is finalized.
Whenever claims are settled, Belkin Corporation reserves the right to be subrogated
under any existing insurance policies the purchaser may have.
Information 6
P75115
Flip
Wireless
Flip
Wireless
How state law relates to the warranty.
THIS WARRANTY CONTAINS THE SOLE WARRANTY OF BELKIN CORPORATION,
THERE ARE NO OTHER WARRANTIES, EXPRESSED OR, EXCEPT AS REQUIRED
BY LAW, IMPLIED, INCLUDING THE IMPLIED WARRANTY OR CONDITION OF
QUALITY, MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, AND
SUCH IMPLIED WARRANTIES, IF ANY, ARE LIMITED IN DURATION TO THE TERM
OF THIS WARRANTY.
Some states do not allow limitations on how long an implied warranty lasts, so the
above limitations may not apply to you.
IN NO EVENT SHALL BELKIN CORPORATION BE LIABLE FOR INCIDENTAL,
SPECIAL, DIRECT, INDIRECT, CONSEQUENTIAL OR MULTIPLE DAMAGES SUCH
AS, BUT NOT LIMITED TO, LOST BUSINESS OR PROFITS ARISING OUT OF THE
SALE OR USE OF ANY BELKIN PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY
OF SUCH DAMAGES.
This warranty gives you specific legal rights, and you may also have other rights,
which may vary from state to state. Some states do not allow the exclusion or
limitation of incidental, consequential, or other damages, so the above limitations
may not apply to you.
