ASKEY’s RT360W-D56 is 802.11g Wireless Access Point & USB Print Server
features and 1-port LAN . The 802.11g Access Point features allow PCs/Notebooks
with wireless card that adapts 802.11g technology to connect to the Ethernet. Through
the LAN connection to connect Local Area Network.
[Hardware Specifications]
Main Chip Sets
• Processor: Broadcom BCM4702 125MHz R3000 MIPS32 CPU
• 54g (draft IEEE802.11g) Broadcom Radio
− BCM4306 MAC and Baseband Processor
− BCM2050 Radio
• Memory
− 4MB Flash
− 16MB SDRAM
Interface
• One 2.4GHz 54g RF interface for Wireless LAN connection
• One 10/100 Mbps RJ-45 Ethernet LAN connection
• Two USB 1.1 Ports for printer connection
Radio Characteristics
• Standard: IEEE 802.11b (Wi-Fi) and 54g (draft IEEE802.11g)
• Frequency Band (ISM Band):
− 2.412 ~ 2.4835 GHz
• Spreading:
− Direct Sequence Spread Spectrum (11-chip Barker sequence)
• Modulation
− OFDM: 54, 48, 36, 24, 18, 12, 9, and 6 Mbps
− CCK: 11 , and 5.5 Mbps
− DQPSK: 2 Mbps
− DBPSK: 1 Mbps
• Number of Channels:
− 802.11b : 1 - 11 (FCC),
RT360W-D56 Wireless Broadband USB AP
www.askey.com.tw
June. 30, 2003 - 2 - Rev: 0.0
− 54g : 1 - 11 (FCC)
• Data Rate:
− 54g
54 Mbps
48 Mbps
36 Mbps
24 Mbps
18 Mbps
12 Mbps
9 Mbps
6 Mbps
− 802.11b
11 Mbps
5.5 Mbps
2 Mbps
1 Mbps
• Antenna:
− One external antenna
• RF Output Power:
− 15 dBm (typical)
• Range:
− 54 Mbps range in a typical office environment of up to 30 m and line-of-sight
(LOS) up to 150 m
− 11 Mbps range in a typical office environment of up to 60 m and line-of-sight (LOS)
up to 300 m
− 1 Mbps range in a typical office environment of up to 120 m and LOS up to 650 m
− Range differs by environment
• Power Consumption:
− TX: TDB mA
− RX: TDB mA
• Receiver Sensitivity: Per <8% @ length 1024 octets
− 54 Mbps: TDB dBm
− 11 Mbps: -80 dBm
− 5.5 Mbps: -88 dBm
− 2 Mbps: -91 dBm
− 1 Mbps: -93 dBm
• WEP Hardware Engine
− 64 Bits
www.askey.com.tw
June. 30, 2003 - 3 - Rev: 0.0
− 128 Bits
Power and Operation Environment
• Power Input:
− 5 Volts DC, 2 A
• Temperature
− Operating: 0°C to 40°C
− Storage: -10°C to 65°C
• Humidity:
− 5% to 80% (non-condensing)
LED Indicators
• POWER
• WLAN (two color)
• WAN (two color)
• HOST
• ERROR
Physical
• PCB Dimensions: 100 mm (L) × 90 mm (W)
[Software Specifications]
- Web Management Interface
- 11G wireless capability
- LPR/LPD protocol
• This standard LPR/LPD support makes the print server easily work with all different
Windows OSs and almost all different variations of Unix.
- Internet Printing Protocol (IPP/1.1)
• IPP is a relatively newer printing protocol; it gets widely supported recently. Microsoft has
built-in IPP support on Windows 2000/XP.
- Support Netbeui (Samba/Windows)
• This will enable a printer device showing up on Windows machine networking
neighborhood. By double-clicking the printer icon, windows guides user through the
process of installing the driver for the printer.
- AppleTalk (Mac)
• To work with MAC running AppleTalk protocol. Only support postscript printers.
- Unix Text File Support
• Can configure automatically to convert LF to CR+LF
www.askey.com.tw
June. 30, 2003 - 4 - Rev: 0.0
- IP Finder utility
• Find the IP address of print server and then link to print server's web management page.
- Test button
• A SW printing test button in print server's web management page.
