Belkin F5D6051 Wireless USB Adapter User Manual belkinusb

Belkin International, Inc. Wireless USB Adapter belkinusb

User Manual

Wireless USB Adapter F5D6050
Users manual
TABLE OF CONTENTS
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Knowing Your Wireless USB Network Adapter . . . . . . . . . . . . . . . . . . 3
Placing the Wireless USB Network Adapter . . . . . . . . . . . . . . . . . . . . 4
Connecting to Your Wireless Network . . . . . . . . . . . . . . . . . . . . . . . 8
Uninstalling the Software and Drivers . . . . . . . . . . . . . . . . . . . . . . . 9
Using the Belkin Wireless LAN Monitor Utility . . . . . . . . . . . . . . . . 10
The Status Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
The Statistics Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
The Site Survey Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
The Encryption Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
The Advanced Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Using Profile Manager Mode . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Operating in Ad-Hoc Mode . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
1
INTRODUCTION
Thank you for purchasing the Belkin Wireless USB Network Adapter
(the
Adapter). Now you can take advantage of this great new technology and
gain
the freedom you need around the home or office without using cables.
The
Wireless USB Network Adapter works like a conventional network
adapter, but
without the wires. The easy installation and setup will have you
networking
wirelessly in minutes. Please be sure to read through this manual
completely to
be sure that you are getting the most out of your Wireless USB Network
Adapter.
Features:
The Adapter complies with the IEEE 802.11b standard in order to
communicate
with other 802.11b-compliant wireless devices.
• 2.4GHz ISM (Industrial, Science, and Medical) band operation
• Integrated, easy-to-use profile manager for storing multiple wireless
network settings for work, school, home, or any other setup
• Wireless interface compliance with the IEEE 802.11b standard
• USB interface, for Plug-and-Play installation and convenience
• 64- or 128-bit Wireless (WEP) Encryption
• Wireless access to networked resources
• Support for both infrastructure and ad-hoc (peer-to-peer) networking
modes
• Data rate of up to 11Mbps
• Supports 11, 5.5, 2 or 1Mbps rates (auto-rollback)
• Easy installation and use
• External antennas
• LED link indicator
Applications and Advantages
Wireless roaming with a laptop around the home or office
Offers the freedom of networking—without cables.
• Difficult-to-wire environments
Enables networking in buildings with solid or finished walls, or open
areas
where wiring is difficult to install.
• Frequently changing environments
Adapts easily in offices or environments that frequently rearrange or
change locations.
INTRODUCTION
2
• Temporary LANs for special projects or peak time
Sets up temporary networks such as at trade shows, exhibitions, and
constructions sites, which need networks on a short-term basis; also
companies who need additional workstations for a peak activity period.
• SOHO (Small Office/Home Office) networking needs
Provides the easy and quick small network installation SOHO users
need.
Product Specifications
Host Interface: USB 1.1
Power Consumption: 300mA (max)
Certification: FCC Class B, CE Mark, C-Tick
Operating Temperature: 32–131° F (0–55° C)
Storage Temperature: -13–158° F (-25–70° C)
Typical Operating Range: Indoor: 160' (50m) @ 11Mbps, 260' (80m)
@ 5.5Mbps or lower
Outdoor: 490' (150m) @ 11Mbps, up to 1800'
(550m) @ 5.5Mbps or lower
System Requirements
• PC with one available USB port
• Windows® 98, 2000, Me, or XP
Package Contents
• Belkin Wireless USB Network Adapter
• Quick Installation Guide
• Installation Software CD
• User Manual
KNOWING YOUR WIRELESS USB NETWORK
ADAPTER
3
Status Light
Indicates network
activity and power
Adjustable
Antenna
PLACING THE WIRELESS USB NETWORK
ADAPTER
4
The best location for your adapter is on top of your computer’s monitor.
Placing
the Adapter on your desktop is acceptable, however, avoid placing the
Adapter
near metal objects such as a computer case or speakers. Any object
that is metal
has the ability to block the radio signals from the Adapter.
Installing and Setting Up the Adapter
Installing your Adapter is done in three easy steps:
1. Install the software FIRST. If you connect your Adapter to your PC
before
you install the software, it will not work until you install the software.
2. Connect the Adapter to your PC.
3. Let Windows finish installing the Adapter.
NOTE: INSTALL THE SOFTWARE FIRST BEFORE YOU CONNECT
THE ADAPTER TO
YOUR COMPUTER
Software and Driver Installation
1. Insert the CD into your CD-ROM drive.
2. The Belkin Wireless USB Network Adapter Setup Utility screen will
automatically appear. If it does not appear within 15–20 seconds, then
select your CD-ROM drive and double-click on the folder named “Files”.
Next
double-click on the icon named “USB_UTILITY.exe”.
3. In the menu window,
drag your mouse over
the “Install” button
then select “Click here
to start the software
installation program.
PLACING THE WIRELESS USB NETWORK
ADAPTER
5
4. The installer will start. Click on or select “Easy” to continue to the next
step.
If you are using Windows XP, it is recommended that you use the Belkin
Wireless USB Network Adapter Utility to manage the Adapter’s wireless
settings. If you want to
use Windows XP to manage
the Adapter, check “Use
the Windows XP Wireless
Network Connection
Utility”. Instructions on
how to use the Windows
XP Connection Utility are
available from Microsoft.
Click “Next” to continue.
5. After the software installation is
finished, the message “You can
plug in your WLAN adapter now”
will appear. Plug the Adapter to
an available USB port on your PC
or USB hub.
6. After connecting your Adapter,
Windows will detect that new
hardware has been installed.
Depending on your version of
Windows, a window similar to
the one pictured here will
appear. Select the option
“Install the software
automatically (Recommended)”.
PLACING THE WIRELESS USB NETWORK
ADAPTER
6
7. If you are using Windows 2000 or
Windows XP, you may see a screen
similar to this one. This does not
mean there is a problem. Select
“Continue Anyway”.
8. If you are using Windows 98
or Me, you will be asked to
restart your computer. Select
“Restart”. If you are using
Windows 2000 or XP, you will
see a window similar to this
one. Click “Finish”.
PLACING THE WIRELESS USB NETWORK
ADAPTER
7
9. When the installation is complete, the Belkin WLAN Monitor icon will
be on
your desktop. To open the Monitor Utility, double-click on this icon.
10. A small icon in your system tray (bottom right corner of most
screens) will
appear. This is your shortcut to the Belkin WLAN Monitor. It also
indicates
the status of your connection:
Red: No connection to a wireless network
Blue: Connected to a wireless network.
If you already have a wireless router or an access point in your home or
office, the Adapter will automatically attempt to connect to your wireless
network. In most cases, the Adapter will be able to connect to your
network
automatically. If you are using encryption, you will have to set the
encryption settings on your wireless router or access point before the
Adapter can successfully connect to your wireless network. For
information
about configuring your Adapter, see the next section in this manual.
CONNECTING TO YOUR WIRELESS NETWORK
8
If you already have a wireless router or an access point in your home or
office,
the Adapter will automatically attempt to connect to your wireless
network. In
most cases, the Adapter will be able to connect to your network
automatically. If
your wireless network is using encryption, you will need to set the
encryption
settings of your Adapter to match that of your wireless network. For
information
about configuring your Adapter, see the next section in this manual.
UNINSTALLING THE SOFTWARE AND DRIVERS
9
If you need to remove the software and drivers for any reason, you can
easily
accomplish this in one of two ways. You can insert the software CD and
click on
the “Uninstall” option in the menu, or you can go to the Windows Control
Panel
and select the “Add/Remove Programs” option. The Belkin wizard will
walk you
through the removal process.
When you launch the Wireless LAN Monitor Utility (the Utility), you will
be
presented with the screen below. The following small icon will also be
present in
your system tray.
The Utility can be set to always be on top of everything else
on your desktop when it is open. This setting can be changed
if you right-click on the icon in your system tray.
Place a check mark next to “Always on top” to keep the
utility on top all of the time. Remove the check mark to set
the window to move to the back when you select another window. You
can close
the Utility screen without shutting the Utility down by clicking Exit (l).
Double-clicking on the icon in the system tray will open the window.
The Status Tab
USING THE BELKIN WIRELESS LAN MONITOR
UTILITY
10
a
b
c
d
e
f
g
h
i
j
k
l
USING THE BELKIN WIRELESS LAN MONITOR
UTILITY
11
(a) Profile Name
The first thing you will notice is the “Profile Name”. Initially this will say
“default” and be grayed out until you have set up a profile. Also, the
Profile
Manager Mode (k) will be “OFF”. Using Profiles allows you to save
configurations
for different wireless networks. For instance, if you use your Adapter at
your
place of work and also at your home, your wireless network settings
may be
different for each location. Profiles let you store settings for each
location and
name them for easy identification. The “default” profile will contain the
initial
configuration setting when you install the Adapter. To learn how to use
Profiles,
see the section of this manual called “Using Profile Manager Mode”.
(b) Operating Mode
Shows the current wireless mode the Adapter is operating in. There are
two
operating modes: “Infrastructure” and “802.11 Ad-Hoc”. Infrastructure is
the
most common mode to operate in and is the factory default setting. Use
Infrastructure mode when connecting your PC to a wireless access
point or to a
wireless router. Ad-Hoc mode is used to connect two or more
computers together
without the use of an access point or wireless router. To change the
mode, click
the down-facing arrow next to the Operating Mode field. Select the
mode you
wish to use, then click “Apply”.
(c) Channel
Shows the current channel the Adapter is operating on. When operating
in
Infrastructure mode, the channel is set automatically by the access point
or
wireless router that the Adapter is connected to. You cannot change the
channels in Infrastructure mode. In Ad-Hoc mode, the channel can be
set
manually. For more information about operating in Ad-Hoc mode, see
“Operating
in Ad-Hoc Mode”.
(d) SSID
The SSID is the wireless network name. This field shows the current
SSID with
which the Adapter is associated. The default (factory) setting is “ANY”,
which
will cause the Adapter to automatically look for any wireless network in
the area.
To connect to a specific wireless network, you can manually enter the
SSID of
the known wireless network. Note that the SSID is case-sensitive, so,
capital
letters do make a difference. To change the SSID, click in the SSID field,
type the
SSID you want, then click “Apply”.
USING THE BELKIN WIRELESS LAN MONITOR
UTILITY
12
(e) Tx Rate
Displays the current rate of data transmission. There are five Tx rates
possible:
Fixed 11Mbps—Always transmit and receive at 11Mbps data rate
regardless of
signal quality.
Fixed 5.5Mbps—Always transmit and receive at 5.5Mbps data rate
regardless of
signal quality.
Fixed 2Mbps—Always transmit and receive at 2Mbps data rate
regardless of
signal quality.
Fixed 1Mbps—Always transmit and receive at 1Mbps data rate
regardless of
signal quality.
AutoAdjust speed according to signal strength. This mode is the
recommended
setting. It will decrease the amount of transmit and receive errors by
reducing
the speed of transmission in favor of receiving error-free data. Note that
data
being sent at Fixed 11Mbps with low signal quality will not necessarily
get the
data to the computer faster. This is because when errors occur, the data
must be
resent. When the signal quality is low, the chances for errors to occur at
high
speeds are greatly increased. Sending the data at lower speeds when
the signal
quality is poor will reduce the chances of errors, and thus data will get to
the
computer in the shortest possible time.
(f) MAC Address
Shows the MAC address of the Wireless USB Network Adapter.
(g) Status
Displays the BSSID (in hexadecimal) of the access point with which the
Adapter
is associated. If you are connected to a network, the word “Associated”
followed
by a series of numbers (the MAC address of the access point) will be
displayed. If
the Adapter is scanning for a network, you will see the word “Scanning”.
(h) Signal Strength
Displays the strength of the wireless signal from 0 to 100%. The closer
to 100%,
the better the signal strength is. The closer you are to a wireless router
or access
point, the stronger the signal should be.
USING THE BELKIN WIRELESS LAN MONITOR
UTILITY
13
(i) Link Quality
Displays the quality of the wireless signal from 0 to 100%. The closer to
100%,
the better the link quality is. Link quality differs from signal strength by
measuring the actual quality of the signal. It is possible to have low
signal
strength and high link quality.
(j) Activate Profile Manager Mode
See the section called “Using Profile Manager Mode”.
(l) Exit Button
Click “Exit” to close the Wireless LAN Monitor Utility. To access the
utility again,
double-click on the “ “ icon in the bottom right corner of your screen.
USING THE BELKIN WIRELESS LAN MONITOR
UTILITY
14
The Statistics Tab
The “Statistics” tab shows you how much data has been sent and
received and if
any errors occurred. Click “Reset” (a) to start at zero. This screen is
mostly for
diagnostics. Note that the number of unsuccessful data and
management frames
is recorded. A large number of unsuccessful frames may indicate that
there is a
problem or interference in your area.
a
USING THE BELKIN WIRELESS LAN MONITOR
UTILITY
15
The Site Survey Tab
Clicking on the “Site Survey” tab will display a list of all available access
points
in your area. The following information about each is displayed:
(a) BSSID
The MAC address of the access point.
(b) SSID
The Service Set Identifier (wireless network name) of the access point.
c b e d a f
g
USING THE BELKIN WIRELESS LAN MONITOR
UTILITY
16
(c) Signal
The signal strength of the related access point. This is a “snapshot” of
the signal
strength at the time of the site survey. Pressing the “Re-Scan” (g) button
may
get a different result.
(d) Channel
The current operating channel of the access point.
(e) Encryption
Will display “No” when encryption is disabled, “64-bit” when 64-bit
encryption is
enabled, and “128-bit” when 128-bit encryption is enabled.
(f) BSS
Displays the mode that the access point is operating in: Infrastructure
or AD-Hoc.
TIP: Double-clicking on the BSSID of an access point will make the
Adapter
join that particular network. To check the area for more access points,
click “Re-Scan”.
USING THE BELKIN WIRELESS LAN MONITOR
UTILITY
17
The Encryption Tab
The “Encryption” tab is used to set up the wireless encryption settings.
There are two ways to set up the encryption settings of your Adapter:
“Create
with Passphrase” or “Manual Entry”. Select “64-bit” from the drop-down
menu.
You will notice when using 64-bit encryption that there are four keys
labeled
“Key 1” through “Key 4”. Only one key can be used at a time. For ease
of use,
the software can generate keys using a passphrase that you enter. This
passphrase can be easily distributed to other wireless-equipped
computer users
in your network. For instance, creating a key using the passphrase
“Passphrase”
generates four keys in 64-bit encryption mode and one key in 128-bit
encryption
mode. In this scenario, a user of a laptop needs only to enter the
passphrase
and the key number into the computer’s wireless management software
to be
able to communicate while using encryption. All computers on the
network must
use the same encryption rate, passphrase, and key. The passphrase
can be
changed as often as desired.
USING THE BELKIN WIRELESS LAN MONITOR
UTILITY
18
Setting 64-Bit or 128-Bit Encryption Using a Passphrase
(Easiest)
1. Select “64-bit” or “128-bit” from
the drop-down menu (a).
2. Select “Create with Passphrase” (b).
3. Enter a passphrase and click
“Generate” (c). Clicking “Generate”
will generate four keys (d) if you
choose “64-bit” or one key if you
choose “128-bit”. The keys are
obscured for security reasons so they
cannot be read by another person.
4. You can now select which 64-bit key you want to use from the
“Default
Key ID” drop-down menu. Leave this set to “1” unless you have a
specific
reason to use another key. Click “Apply” for the changes to be saved.
Encryption is now enabled. Each wireless-equipped computer (client)
that needs
to communicate on the wireless network must be set to the same
encryption
settings (rate, passphrase, and key).
a
b
d
c
USING THE BELKIN WIRELESS LAN MONITOR
UTILITY
19
Setting 64-Bit or 128-Bit Manually Using an Alphanumeric
Keyword (Advanced)
1. Select “64-bit” or “128-bit” encryption from the drop-down menu.
2. Select “Manual Entry” then
“Alphanumeric: 5 characters” if
using 64-bit or “Alphanumeric: 12
characters” if using 128-bit. Enter
up to four keys.
3. Select the key that you want to use.
4. Click “Apply”.
Encryption is now enabled. Each wireless-equipped computer (client)
that needs
to communicate on the wireless network must be set to the same
encryption
settings (rate, passphrase, and key).
USING THE BELKIN WIRELESS LAN MONITOR
UTILITY
Setting 64-Bit or 128-Bit Manually Using a Hexadecimal Key
(Advanced)
1. Select “64-bit” or “128-bit” from the drop-down menu.
2. Select “Manual Entry” then
“Hexadecimal: 10 characters (0-9,A-F)”
if using 64-bit or “Hexadecimal: 26
characters (0-9,A-F)” if using 128-bit.
Enter up to four keys.
3. Select the key that you want to use.
4. Click “Apply”.
Encryption is now enabled. Each wireless-equipped computer (client)
that
needs to communicate on the wireless network must be set to the same
encryption settings (rate, passphrase, and key).
20
USING THE BELKIN WIRELESS LAN MONITOR
UTILITY
21
The Advanced Tab
The settings on the “Advanced” tab
should be left as is unless there is a
specific reason to change them.
(a) Preamble Type
The preamble is a signal used to synchronize the timing between the
Adapter
and the access point. Some older wireless equipment may not be able
to work if
this setting is too short. Leaving this setting to “Auto” is the most
effective way
to ensure the Adapter will connect to any wireless network available.
(b) Fragmentation Threshold and RTS/CTS Threshold
These settings should be left at their default settings. If you are
experiencing
many data errors, you can change these settings, however, network
performance
will likely decrease.
(c) Power Save
Enabling “Power Save” will help reduce battery consumption on a laptop
by
turning the Adapter OFF after each data set is sent or received to or
from the
network. Enabling this mode will decrease performance of the Adapter,
but may
greatly enhance your battery life. Use this feature only if necessary.
a
b
c
USING THE BELKIN WIRELESS LAN MONITOR
UTILITY
22
Using Profile Manager Mode
Using Profiles allows you to save configurations for different wireless
networks. For instance, if you use your Adapter at your place of work
and also
at your home, your wireless network settings may be different for each
location. Profiles let you store settings for each location and name them
for
easy identification. You can quickly change from one profile to another
profile
without having to remember the particular settings of a certain network.
After you first install the Adapter, the Profile Manager mode will be
turned
OFF. If you want to use the Profile Manager, you will need to turn it on
and
set up a profile.
a
b
c
e
d
USING THE BELKIN WIRELESS LAN MONITOR
UTILITY
23
Creating a Profile
Before you can use the Profile Manager, you need to create a profile.
Follow
these steps to create a profile.
1. If not already, turn ON the Profile Manager mode by pressing the
“Activate
Profile Manager Mode” button (c).
2. The “Profile Name” field (a) will become active. Click inside of the
Profile Name field and type in the name you want to call the profile,
such as “Home” (e).
3. At this point, you now need to set the rest of the parameters for the
network that you will be connecting to. Set the Operating Mode,
Encryption settings, Network Type, SSID, etc. When you have finished
making these settings, click “Apply” (b).
A profile with the name you chose now exists in the Profile Manager.
You can
select this profile quickly and easily any time you need to use it
Choosing a Profile
You can quickly and easily choose a profile any time you need it. There
are two
methods to do so.
Quick Pick
1. Right-click the Utility icon in the task bar.
2. Place your cursor over “Profile”. A list of the
profiles you have created will appear. Move the
cursor over the profile that you want to use and
left-click on the name. The profile you just
selected will become active.
Choosing from the Utility
1. Make sure Profile Manager mode is on.
2. Click the down-facing arrow next to “Profile Name”. A list of all of the
profiles you have created will appear. Click on the name of the profile
you
want to use.
3. Click “Apply”. The profile you just selected will become active.
USING THE BELKIN WIRELESS LAN MONITOR
UTILITY
24
Operating in Ad-Hoc Mode
Ad-Hoc mode is a peer-to-peer mode (computer-to-computer). To set
two or
more computers to communicate directly with each other, follow these
steps.
1. Select “Ad-Hoc” from the Operating Mode box (a).
2. Enter the channel you want to use in the “Channel” box (b). You can
choose any one of the available channels you wish.
3. In the SSID field (c), type in the name you want to use to identify the
Ad-Hoc network. You can name this anything you want.
a
b
c
USING THE BELKIN WIRELESS LAN MONITOR
UTILITY
25
4. Click “Apply” to save the changes. When the Adapter is in Ad-Hoc
mode,
the “Status” box (d) will say “Ready”.
Note: The Signal Strength and Link Quality indicators do not work in
Ad-Hoc mode.
5. Using these same settings, set the rest of the computers on your
Ad-Hoc
network to the same settings. When you have completed setup of the
Ad-Hoc network, computers will network together normally as if wired
together through a hub or switch.
d
TROUBLESHOOTING
26
You can find technical support information at networking.belkin.com
or
www.belkin.com through the tech support area. If you want to contact
technical support by phone, please call 800-223-5546. Technical
support is
available 24 hours a day, 7 days a week.
27
INFORMATION
Belkin Corporation Limited Lifetime Product Warranty
Belkin Corporation warrants this product against defects in materials and workmanship for its
lifetime. If a defect is discovered, Belkin will, at its option, repair or replace the product at no
charge provided it is returned during the warranty period, with transportation charges prepaid,
to
the authorized Belkin dealer from whom you purchased the product. Proof of purchase may
be
required.
This warranty does not apply if the product has been damaged by accident, abuse, misuse,
or
misapplication; if the product has been modified without the written permission of Belkin; or if
any Belkin serial number has been removed or defaced.
THE WARRANTY AND REMEDIES SET FORTH ABOVE ARE EXCLUSIVE IN LIEU OF
ALL OTHERS,
WHETHER ORAL OR WRITTEN, EXPRESSED OR IMPLIED. BELKIN SPECIFICALLY
DISCLAIMS ANY AND
ALL IMPLIED WARRANTIES, INCLUDING, WITHOUT LIMITATION, WARRANTIES OF
MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE.
No Belkin dealer, agent, or employee is authorized to make any modification, extension, or
addition to this warranty.
BELKIN IS NOT RESPONSIBLE FOR SPECIAL, INCIDENTAL, OR CONSEQUENTIAL
DAMAGES RESULTING
FROM ANY BREACH OF WARRANTY, OR UNDER ANY OTHER LEGAL THEORY,
INCLUDING BUT NOT
LIMITED TO, LOST PROFITS, DOWNTIME, GOODWILL, DAMAGE TO OR
REPROGRAMMING, OR
REPRODUCING ANY PROGRAM OR DATA STORED IN, OR USED WITH, BELKIN
PRODUCTS.
Some states do not allow the exclusion or limitation of incidental or consequential damages
or
exclusions of implied warranties, so the above limitations of exclusions may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights that vary
from
state to state.
28
INFORMATION
FCC Statement
DECLARATION OF CONFORMITY WITH FCC RULES FOR
ELECTROMAGNETIC COMPATIBILITY
We, Belkin Corporation, of 501 West Walnut Street, Compton, CA 90220, declare under our
sole
responsibility that the product,
F5D6050
to which this declaration relates,
complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this
device may not cause harmful interference, and (2) this device must accept any interference
received,
including interference that may cause undesired operation.
Caution: Exposure to Radio Frequency Radiation.
The radiated output power of this device is far below the FCC radio frequency exposure
limits.
Nevertheless, the device shall be used in such manner that the potential for human contact
normal operation is minimized.
When connecting an external antenna to the device, the antenna shall be placed in such a
manner to minimize the potential for human contact during normal operation. In order to
avoid
the possibility of exceeding the FCC radio frequency exposure limits, human proximity to the
antenna shall not be less than 20cm (8 inches) during normal operation.
Federal Communications Commission Notice
This equipment has been tested and found to comply with the limits for a Class B digital
device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection
against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy. If not installed and
used
in accordance with the instructions, it may cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged
to try and correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the distance between the equipment and the receiver.
• Connect the equipment to an outlet on a circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Modifications
The FCC requires the user to be notified that any changes or modifications to this device that
are not expressly approved by Belkin Components may void the users authority to operate
the equipment.
29
Canada- Industry Canada (IC)
The wireless radio of this device complies with RSS 139 & RSS 210 Industry Canada. This
Class B
digital complies with Canadian ICES-003.
Cet appareil numérique de la classe B conforme á la norme NMB-003 du Canada.
Europe-European Union Notice
Radio products with the CE 0560 or CE alert marking comply
with the R&TTE Directive (1995/5/EC) issued by the Commission of the
European Community.
Compliance with this directive implies conformity to the following European Norms (in
brackets
are the equivalent international standards).
• EN 60950 (IEC60950) – Product Safety
• EN 300 328 Technical requirement for radio equipment
• ETS 300 826 General EMC requirements for radio equipment.
To determine the type of transmitter, check the identification label on your Belkin product.
Products with the CE marking comply with the EMC Directive (89/336/EEC) and the Low
Voltage
Directive (72/23/EEC) issued by the Commission of the European Community. Compliance
with
these directives implies
conformity to the following European Norms (in brackets are the
equivalent international standards).
• EN 55022 (CISPR 22) – Electromagnetic Interference
• EN 55024 (IEC61000-4-2,3,4,5,6,8,11)- Electromagnetic Immunity
• EN 61000-3-2 (IEC610000-3-2) - Power Line Harmonics
• EN 61000-3-3 (IEC610000) – Power Line Flicker
• EN 60950 (IEC60950) – Product Safety
Products that contain the radio transmitter are labeled with CE 0560 or CE alert marking and
may
also carry the CE logo.
INFORMATION
編號:F5D6050F00000 SP01 版次:A
產品規格書
適用機種:F5D6050
Wireless USB Adapter F5D6050
Specifications
1. General specification
2. Standard test condition
3. Electrical specification
4. Frequency channel plan
核准: 審查: 製表:
莊繐瑄
修訂日期:
制定日期:
2002 11 08
Page : 1/3
Specification
No. Item Condition Min. Typ. Max.
Test Method/Condition
1. General specification
1-1. Standard IEEE 802.11b
1-2. Frequency Band(MHz) 2400 2483.5
1-3. No. of Selectable
Channels
11 Channels (US, Canada)
13 Channels (Europe)
14 Channels (Japan)
1-4. Channel Spacing (MHz) 5
1-5. Modulation Technique DSSS (CCK, DQPSK, DBPSK)
1-6. Spreading 11-chip Barker Sequence
1-7. Media Access Protocol CSMA/CA(collision Avoidance) with
ACK
1-8. Interface USB V 1.1
1-9. Dimensions 102 x 77 x 30 mm
1-10. LED Indicators Power/Link Status
1-11. Antenna One External Dipole antenna
2. Standard Test Condition
2-1. Supply voltage(V)
5.0
3. Electrical
Specification
Temperature Range0 ~ 55
Humidity95 % (Non-condensing)
260 Receiver Mode
3-1. Power Consumption
(mA)
@+5V
540 Transmit Mode
-80 -81 @ 11 Msps
-84 @ 5.5 Msps
-86 @ 2 Msps
3-2 Receive Sensitivity
(dBm)[FER < 8%]
-89 @ 1 Msps
35 @ 11 Msps Indoor
100 180 @ 1 Msps
150 @ 11 Msps
3-3. Range(Meters)
Outdoor
300 @ 1 Msps
3-4. Average Output Power
(dBm)
CH1~CH13
CH14
15
15
17.5
16
21
19
@29.5dB difference between the signal
level at center frequency and higher
first side lobe
3-5 Frequency Accuracy(ppm) - 25 + 25
Page : 2/3
4. Frequency channel plan
Regulation Domains
Channel_ID Frequency
(Mhz)
FCC
(X ’10’ )
IC
(X ‘20’ )
ETSI
(X ’30‘ )
Spain
(X ’31‘ )
France
(X ‘32’ )
MKK
(X ‘40’ )
1 2412 X X X
2 2417 X X X
3 2422 X X X
4 2427 X X X
5 2432 X X X
6 2437 X X X
7 2442 X X X
8 2447 X X X
9 2452 X X X
10 2457 X X X X X
11 2462 X X X X X
12 2467
X X
13 2472
X X
14 2484
X
Page : 3/3

Navigation menu
