1. user manual
2. User Manual

User Manual

23528_8820-00380_F7D4302 v1_Play Router_Updated_0222-2010

PLAY WIRELESS ROUTER

USER MANUAL

F7D4302 v1

TABLE OF CONTENTS

Getting Started

What’s in the Box

Initial Setup

Advanced Tools & Settings

The Belkin Router Manager

Manual Setup Using Your Browser

Adding Computers to Your Network

Adding USB Devices

Bundled Software

Additional Capabilities

Getting to Know Your Router

Front Panel

Back Panel

Technical Details

Technical Features

System Requirements

Troubleshooting, Support, and Warranty

Troubleshooting

Technical Support

Belkin International, Inc., Limited 2-Year Product Warranty

Regulatory Information

FCC Statement

23528_8820-00380_F7D4302 v1_Play Router_Updated_0222-2010

Getting Started

What’s in the Box

PlayWirelessRouter

Ethernetcable(attachedtorouter)

Powersupply(attachedtorouter)

Networkinformationcard(attachedtorouter)

BelkinSetupCDwithUserManual

Initial Setup

WheretoPlaceYourRouter

Forthebestresults,placetheRouternexttoyourmodeminan

openlocationawayfromlargemetalobjectsandmagnetssuchas

thosefoundinspeakers.RaisingtheRouterabovefloorlevelcan

improvethestrengthofyourwirelesssignal.

HowtoSetItUp

[RSHARE/PLAYSETUPDIAGRAMrshareplaysetup.ai]

1) ConnectyourRouter’sEthernetcabletoyourmodem’s

Ethernetport(onthebackofyourmodem).Thisportmight

belabeleddifferentlyonyourparticularmodem.Ifyouare

addingaRouterforthefirsttime,thisportmaybeconnected

toyourcomputerbyanEthernetcable.ItisOKtodisconnect

yourcomputerandplugtheRouterintothemodeminstead.

2) PlugtheRouter’spowersupplyintoawalloutlet.

3) PuttheCDintoyourcomputer.IftheCDdoesn’topen

automatically,pleasebrowsetoyourCDdriveanddouble

clickontheBelkinSetupCDicon.

[SCREENSHOTOFSETUPMENUsetupmenu.png]

4) ClicktheSetupiconontheCDmenu.

23528_8820-00380_F7D4302 v1_Play Router_Updated_0222-2010

[SCREENSHOTOFNETWORKINFOCARDSCREENsetup

netinfocard.png]

5) Afterabriefinstallation,thesetupsoftwarewillaskyoufor

thenetworknameandpasswordfromthenetwork

informationcardthatisattachedtoyourRouter.Storethe

cardunderthebaseofyourRouterforfuturereference.

[SCREENSHOTOFSUCCESSsetupsuccess.png]

6) Aprogressscreenwillappearwhileadditionalsoftwareis

installed.Thismaytakeafewminutestocomplete.Once

finished,a“Success”messagewillappearindicatingthatyou

areconnectedtotheInternetviayournewBelkinRouter.

Duringsetupyoumaybeaskedforadditionalinformation.

YoumayneedtoenterausernameandpasswordprovidedbyyourISP.

Thisusernameandpasswordislikelytobefoundonmaterialsthatcame

fromyourISPwhenyousignedupforservice.Ifnecessary,youmayneed

tocontactyourISPtoretrieveyourusernameandpassword.

IfyouhaveastaticIPaddress,youmayneedtoenteradditional

informationalsoprovidedbyyourISP.

Ifyourcomputerdoesn’thaveawirelessadapter,orthesetupsoftwareis

unabletocontrolit,youmaybeaskedtoconnectyourcomputertothe

Routerwithanetworkcable.

Advanced Tools & Settings

[SCREENSHOTOFADVANCEDMENUsetupadvanced2.png]

Aftertheinitialsetupiscomplete,youhavetheoptiontochangesettingslike

yournetworkname,securitytype,andpassword.Tomakethesechangesand

others,clickontheAdvancedToolsiconattheCDSetupmenuandselectone

ofthefollowingsettingsthatyouwouldliketochange:

NetworkName&Security

Personalizeyournetworkname(SSID),password,andstrengthof

wirelesssecurity.

23528_8820-00380_F7D4302 v1_Play Router_Updated_0222-2010

InternetServiceProvider&LoginSettings

HaveyoumovedorchangedInternetServiceProviders?Ifyou’dliketo

changethesesettingswithoutrunningthroughthesetupprocessagain,

thisistheplace.

The Belkin Router Manager

[PLAYSCREENSHOTOFTRAYAPPMENU(TBD)]

TheBelkinRouterManagerappearsinyoursystemtray(Windows)ormenubar

(Mac).ItsiconindicatesthecurrentstatusofyourRouterandalsoallowsyouto

accessyourRouter’ssettingstomakechanges.Italsoprovidesquickaccessto

softwarethatcamebundledwithyourRouter.

ToaccesstheRoutersettings,clickontheiconandselectfromthemenuthat

appears.

ThestatusofyourRouterisshownbytheBelkinRouterManagericon,which

closelymimicsthelightonthefrontoftheRouter.

Green: You are connected to your Belkin Router and it is connected to the Internet.

Amber: You are connected to your Belkin Router, but it is not connected to the

Internet.

23528_8820-00380_F7D4302 v1_Play Router_Updated_0222-2010

Manual Setup Using Your Browser

[ZOOMEDSCREENSHOTOFADDRESSBARaddressbar.png]

Inyourbrowser,type“http://router”(youdonotneedtotypeinanythingelse

suchas“www”).ThenpresstheEnterkey.Ifyou’restillhavingtroublerunning

themanualsetupoption,type“192.168.2.1”inyourbrowser(youdonotneed

totypeinanythingelsesuchas“http://”or“www”).ThenpresstheEnterkey.

Adding Computers to Your Network

Wirelessdevicessuchascomputers,networkprinters,andgamingsystemscan

connecttoyourRouterwithafewsimplesteps.

UsingtheCD

1) PuttheSetupCDintoyourcomputer.IftheCDdoesn’topen

automatically,browsetoyourCDdriveandopentheBelkin

SetupCDicon.

2) ClicktheSetupiconontheCDmenu.

3) Afterabriefinstallation,thesetupsoftwarewillaskyoufor

thenetworknameandpasswordfromthenetwork

informationcardthatcamewithyourRouter.Thiscardis

mostlikelynowlocatedunderneaththefootofyourRouter

intheprovidedcardslot.

4) Aprogressscreenwillappearwhileadditionalsoftwareis

installed.Thismaytakeafewminutestocomplete.Once

finished,a“Success”messagewillappearindicatingthatyou

areconnectedtotheInternetviayournewBelkinRouter.

Note:ThesetupsoftwarerunsonlyonWindowsandMacOSX

systems.

Manually

IfyouchoosenottousetheincludedSetupCDforadding

additionalcomputersorwirelessdevices,youcanmanuallyadd

theseitemstoyournetwork.

1) Locatethewirelessnetworkconnectionsoptiononyour

computerorwirelessdevice.

23528_8820-00380_F7D4302 v1_Play Router_Updated_0222-2010

2) SelectyourBelkinRouterfromthelistofavailablenetworks.

YoucanidentifyyourBelkinRouterbylocatingthenetwork

name(SSID)fromthecardlocatedunderneaththefootof

yourRouter.

3) Enteryournetworkpassword(locatedonyournetwork

informationcard).

Yourwirelessdevicewilltakeafewmomentstoconnectto

yournetwork.Iftheconnectionisnotmadethefirsttime,try

thisprocessagain.Ifyoustillhavedifficultyconnectingto

yournetworkaftertryingthisprocessafewtimes,seethe

“Troubleshooting”sectioninthismanualforhelpwith

connectingtoyournetwork.

Note:Insomecasesyoumaybepromptedtoselectthe

securitytype.Itisprintedonthecardforyourconvenience.

UsingtheWPSButton

1) StartWPSPushButtonConnection(WPSPBC)onyour

computerorotherWiFidevicethatyouwouldliketo

connectwirelesslytoyourRouter.Oftentherewillbea

buttonforthispurposeinsoftwarethatcamewiththedevice,

oraphysical“WPS,”“PBC,”or“Security”buttononthedevice

itself.

2) Withintwominutes,presstheWPSbuttononyourRouter.

TheWPSlight(smalllightaboveWPSbutton)willblinkgreen

whileitlistensforyourWiFidevice.Onceaconnectionis

established,thelightwillturngreenandthengoout.Ifa

connectionisnotestablished,thelightwillblinkamber.You

mayrepeattheprocesstotryagain.

YoucanrepeatthisprocessforeachWPSenableddeviceyou’d

liketoaddtoyournetwork.

Adding USB Devices

[USBINVITATIONDIAGRAM(TBD)]

AddingaDrive

23528_8820-00380_F7D4302 v1_Play Router_Updated_0222-2010

YoucanshareaUSBharddriveorflashdrivetoyournetworkvia

yourRouter’sUSBport.Onceconnected,youcansharefilesand

musicwithothercomputersanddeviceswithinyournetwork.

PlugyourUSBharddriveintotheUSBportonthebackofyour

Router.WhenthelightabovetheUSBportislit,yourdriveis

availabletocomputersonyournetwork.

Youcanmanuallycheckthestatusofyourshareddriveby

visitingtheUSBPrintandStorageManager,foundunderthe

BelkinRouterManagericondisplayedinyoursystemtray

(Windows)ormenubar(Mac).Ifyouhavedifficultysharinga

driveonyournetwork,pleaseseethe“Troubleshooting”

sectionofthismanual.

AddingaPrinter

YoucanaddaprintertoyournetworkviayourRouter’sUSBport.

Onceconnected,youcanprintfromvariouscomputersand

wirelessdeviceswithinyournetwork.

Plugyourprinter’sUSBcableintotheUSBportlocatedontheback

ofyourRouter.WhenthelightabovetheUSBportislit,your

printerisavailabletocomputersonyournetwork.

Youcanmanuallycheckthestatusofyourprinterbyvisitingthe

USBPrintandStorageManager,foundundertheBelkinRouter

Managericondisplayedinyoursystemtray(Windows)ormenu

bar(Mac).Ifyouhavedifficultysharingaprinteronyournetwork,

pleaseseethe“Troubleshooting”sectionofthismanual.

Note:Eachcomputerthatwillusetheprintermusthaveboththe

Belkinsoftwareandtheprinter’sdriverinstalled.Iftheprint

driverisnotinstalled,youwillbeaskedtoinstallitbytheBelkin

USBPrintandStorageManager.

AddingOtherUSBDevices

OtherUSBdevicesmayalsobesharedviayourRouter.Plugyour

deviceintotheUSBportlocatedonthebackofyourRouter.When

23528_8820-00380_F7D4302 v1_Play Router_Updated_0222-2010

thelightabovetheUSBportislit,yourdeviceisavailableto

computersonyournetwork.

ComputersrunningtheBelkinUSBPrintandStorageManagerwill

beabletomakeuseoftheshareddevicebyvisitingtheUSBPrint

andStorageManager,foundundertheBelkinRouterManagericon

displayedinyoursystemtray(Windows)ormenubar(Mac).

Bundled Software

USBPrintandStorageManager

TheUSBPrintandStorageManagerhelpstomanageandmonitor

theuseofyourUSBprinters,scanners,harddrives,andother

devicesthatareconnectedtoyourRouter’sUSBportandshared

acrossyournetwork.USBPrintandStorageManagerisfoundin

theBelkinRouterManagericondisplayedinyoursystemtray

(Windows)ormenubar(Mac).

WhenyouhaveoneormoreUSBdevicesattachedtoyourRouter,

themainactionsforthosedevicesareavailabledirectlyfromthe

BelkinRouterMonitormenu.

MemorySafe

MemorySafeallowsyoutosetuparoutinebackupofyourfilestoa

harddriveorflashdriveattachedtoyourRouter.MemorySafeis

foundintheBelkinRouterManagericondisplayedinyoursystem

tray(Windows)ormenubar(Mac).

MusicLabeler

BelkinMusicLabelercorrectsmetadata(tracknames,artistnames,

tracknumbers,etc.)inyouriTunesandWindowsMedialibraries,

makingiteasytofindthemusicyouarelookingfor.MusicLabeler

isfoundundertheBelkinRouterManagericondisplayedinyour

systemtray(Windows)ormenubar(Mac).

DailyDJ

BelkinDailyDJdeliverspersonalizedplaylistsfromyourmusic

collection,automatically,everyday.It’slikehavingyourown

23528_8820-00380_F7D4302 v1_Play Router_Updated_0222-2010

personalDJplayingthesongsthatyouwanttohear.Itworksgreat

withiTunesandWindowsMediaPlayer.DailyDJisfoundunder

theBelkinRouterManagericondisplayedinyoursystemtray

(Windows)ormenubar(Mac).

Additional Capabilities

GuestAccess

YoucanallowgueststouseyourInternetconnectionwithout

joiningyourpersonalnetwork.Thenetworknameandpassword

fortheguestnetworkislocatedonthenetworkinformationcard

foundunderthefootofyourRouter.

Apersonusingyourguestnetworkwillbeabletojoinwithouta

password,butwillbeshownaloginpagewhentheyattempttosurf

theWeb.Theywillneedtoentertheguestpasswordintothispage

tocontinue.

VideoMax

VideoMaxautomaticallyprioritizesyournetworktraffictoensure

highqualitystreamingvideo,VoIPcalls,andgames.

MusicMover

MusicMoversendsmusicfromaUSBdriveattachedtoyourRouter

toanyUPnP(UniversalPlugandPlay)orDLNAcompatibledevice

onyournetwork.Thesedevicesincludecertaingamingsystems,

televisions,Blurayplayers,andcellphones.

Getting to Know Your Router

Front Panel

[DIAGRAMfront.ai]

A)RouterStatusLight

YourRouter’sstatusisshownbythelightonthefront.

23528_8820-00380_F7D4302 v1_Play Router_Updated_0222-2010

Off:TheRouterisnotpluggedintoapowersource.

BlinkingGreen:TheRouterisstartingup.

SolidGreen:TheRouterisconnectedtotheInternet.

BlinkingAmber:TheRoutercan’tdetectthemodem.Eitherthemodemis

off,isnotpluggedintotheRouter,orisunresponsive.

B)Wi‐FiProtectedSetup(WPS)LightandButton

TheWPSbuttononthefrontofyourRoutercanbeusedtohelp

establishasecureconnectionbetweenyourRouterandotherWPS

enabledWiFidevicessuchascomputers.TousetheWPSfeature

onyourRouter,see“GettingStarted>AddingComputerstoYour

Network>UsingtheWPSButton”.

ThesmalllightneartheWPSbuttonshowswhatishappening

whileyouareusingWPStoestablishaconnection.

Off:Idle

BlinkingGreen:TheRouterislisteningforaWPSenabledcomputeror

otherdevice.

SolidGreen:TheRouterhasmadeasecureconnectionwiththecomputer

orotherdevice.

Amber:Aconnectionwasnotcreated.

23528_8820-00380_F7D4302 v1_Play Router_Updated_0222-2010

Back Panel

[RDIAGRAMFORSHAREANDPLAYr_shareplay_back.ai]

A)Modem(WAN)Connector

ConnectyourmodemtothisportusinganEthernetcable.

B)Wired(LAN)Connectors

Connectcomputersandotherwirednetworkdevicestotheseports

usingEthernetcables.

C)USBPort

USBprinters,disks,andotherUSBdevicespluggedintothisport

willbesharedonyournetwork.EachUSBporthasalightthat

indicatesitsstatus.

Off:NoUSBdeviceisconnectedortheattachedUSBdeviceisnotinuse.

Blinking:Pleasewaittounplugthedeviceuntilthelightturnsoff.

On:TheUSBdeviceisconnectedandbeingsharedonyournetwork.

D)ResetButton

ThisbuttonisusedtorestartyourRouterinrarecaseswhenit

functionsincorrectly.ResettingtheRouterwillpreserveyour

settings.Thisbuttonmayalsobeusedtorestorethefactorydefault

settings.PleaseseetheTroubleshootingsectionformore

information.

E)PowerConnector

Connecttheincludedpowersupplytothisjack.

Technical Details

Technical Features

Integrated 802.11n Wireless Access Point

Utilizing Dual-Band Network technology, your Router creates two

separate networks (one at 2.4GHz band and the other at 5GHz band),

allowing increased bandwidth to all your connected wireless devices and

computers.

23528_8820-00380_F7D4302 v1_Play Router_Updated_0222-2010

NAT IP Address Sharing

To save you the cost of adding IP addresses per computer in your house,

your Belkin Router uses Network Address Translation (NAT) technology,

allowing you to share a single IP address across your network.

SPI Firewall

Your Router is equipped with a firewall that will protect your network

from a wide array of common attacks and viruses.

Universal Plug-and-Play (UPnP) Compatibility

The UPnP (Universal Plug-and-Play) feature in your Router offers

seamless operation of voice and video messaging, games, and other

applications that are UPnP-compliant.

Web-Based Advanced User Interface

You can easily make changes to your Router’s advanced settings through

your web browser. These changes can be made from any computer on your

network.

Belkin Router Monitor

The Belkin Router Monitor application helps you to monitor your

Router’s status and change network settings.

Integrated 4-Port 10/100 Switch

Your Router has a built-in, 4-port network switch to allow your wired

computers to share: printers, data, MP3 files, digital photos, and much

more.

USB Port

The USB port lets you plug in printers, hard drives, and other USB

devices to share across your network.

System Requirements

Router

Broadband Internet connection such as a cable or DSL modem with RJ45

(Ethernet) connection

At least one computer with an installed network interface adapter

TCP/IP networking protocol installed on each computer

RJ45 Ethernet networking cable

Internet browser

Setup Software

A computer running Windows® XP SP2 or higher, Windows Vista®, or

Windows 7; or Mac OS® X v10.x

Minimum 1GHz processor and 256MB RAM

600MB of free hard-drive space for installation

Memory Safe and USB Print and Storage Manager

Windows XP SP2 or higher or Windows Vista; or Mac OS X v10.4 or later

Minimum 1GHz processor and 256MB RAM

50MB of free hard-drive space for installation

Daily DJ and Music Labeler

Windows XP SP2 or higher, Windows Vista, or Windows 7

2GHz processor

1GB of RAM

23528_8820-00380_F7D4302 v1_Play Router_Updated_0222-2010

DirectX® 9.0-compliant video and sound

Internet Explorer® or Firefox®

Mac®

Mac OS X v10.4.8 or later

Intel® Core™ Duo 1.83GHz or higher processor

1GB of RAM

Safari® or Firefox

200MB of free hard-drive space for installation

23528_8820-00380_F7D4302 v1_Play Router_Updated_0222-2010

Troubleshooting, Support, and Warranty

Troubleshooting

TheSetupCDdoesnotautomaticallystart.

IfBelkinSetupdoesnotrunwhenyouinserttheCDROM,your

computermaynotbeconfiguredtoopenCDsautomatically.

IfBelkinSetupdoesnotappearwithin15seconds,browsetoyour

CDROMdriveandopenthe“BelkinSetup”icon.Alternatively,you

mayvisithttp://router/andperformthesetupmanually.Please

see“ManualSetupUsingYourBrowser”earlierinthismanualfor

moreinformation.

BelkinSetupcannotfindmyRouter.

IfBelkinSetupisnotabletocommunicatewithyourRouterduring

theinstallationprocess,pleasecheckthefollowingitems.

1) Makesurethatthewirelesshardwareonyourcomputeristurned

on,ifavailable.

2) Tryconnectingyourcomputertooneofthefour“wired”portson

theRouterwithanEthernetcable.

3) EnsurethattheRouterison.Thefrontpanellightshouldbeon.

4) UnplugtheRouter’spowersupplyfor10seconds,thenplugitback

in.

5) Theremaybefirewallsoftwareonyourcomputerpreventingan

outgoingconnection.Youmaychoosetotemporarilydisablethis

softwarebeforeattemptingsetup.

IfBelkinSetupstillcannotfindtheRouter,youmightchoosetodo

amanualsetup.Referto“ManuallyConfiguringNetworkSettings”

inthismanualfordetails.

BelkinSetupcannotconnectmyRoutertotheInternet.

IfBelkinSetupisnotabletoconnecttheRoutertotheInternet,

pleasecheckthefollowingitems:

1) Use the troubleshooting suggestions within Belkin Setup.

23528_8820-00380_F7D4302 v1_Play Router_Updated_0222-2010

2) If your ISP requires a user name and password, make sure that

you have typed in your user name and password correctly.

Some user names require that the ISP’s domain may be at the

end of the name. Example: “myname@myisp.com”. The

“@myisp.com” part of the user name may need to be typed as

well as your user name.

3) If you continue to have no Internet connection, refer to

“Manually Configuring Network Settings” in this manual for an

alternative setup method.

BelkinSetupcompletedinstallation,butIcannotbrowsetheWeb.Thelighton

thefrontofmyRouterisblinkingamber.

1) MakesuretheRouterisconnectedtoyourmodemwithan

EthernetcableviatheRouter’soneWAN(modem)port.

2) Unplugthemodemfromitspowersourceandmakesurethat

itgoesdark.Thenreapplypowertothemodem.

3) UnplugyourRouter’spowersupply,wait10seconds,and

plugitbackin.ThiswillcausetheRoutertotrytoreestablish

communicationwiththemodem.

BelkinSetupcompletedinstallation,butIcannotbrowsetheWeb.Thelighton

thefrontofmyRouterissolidamber.

1) Use the troubleshooting suggestions within Belkin Setup.

2) If your ISP requires a user name and password, make sure

that you have typed in your user name and password

correctly. Some user names require that the ISP’s domain

may be at the end of the name. Example:

“myname@myisp.com”. The “@myisp.com” part of the

user name may need to be typed as well as your user name.

3) If you have a static connection, your ISP will have assigned

you an IP address, subnet mask, and gateway address.

Please re-run Belkin Setup and enter this information when

a static connection is mentioned.

23528_8820-00380_F7D4302 v1_Play Router_Updated_0222-2010

4) You may need to configure your Router to meet the

specific requirements of your ISP. To search our

knowledge base for ISP-specific issues, go to:

http://www.belkin.com/support and type in “ISP”.

5) If you continue to have no Internet connection, refer to

“Manually Configuring Network Settings” in this manual for

an alternative setup method.

Ican’tconnecttotheInternetwirelessly.

IfthelightonthefrontoftheRouterissolidgreen,thenyour

RouterisconnectedtotheInternet.Youmaynotbeconnectedto

theRouter’swirelessnetwork.Pleasereferto“AddingComputers

toYourNetwork”inthismanualforinstructions.

Ican’tconnecttotheInternetwirelesslyandmynetworknameisnotlistedin

AvailableNetworks.

1) VerifythatyourRouterisonandthefrontpanellightshows

solidgreen.

2) IfyouarefarfromtheRouter,youmighttrymovingcloserto

seeifyoumighthavebeenoutofrange.

3) UsingacomputerattachedtotheRouterviaanetworkcable,

visithttp://router/andensurethat“BroadcastSSID”isON.

Thissettingisfoundonthe“ChannelandSSID”page.

Mywirelessnetworkperformanceisslow,inconsistent,suffersfromweak

signal,orI’mhavingdifficultymaintainingaVPNconnection.

Wireless technology is radio-based, which means connectivity

and the throughput performance between devices decreases

when the distance between devices increases. Other factors that

will cause signal degradation (metal is generally the worst

culprit) are obstructions such as walls and metal appliances.

Note also that connection speed may decrease as you move

farther away from the Router.

In order to determine if wireless issues are related to range, we

suggest temporarily moving the computer within 10 feet from

the Router if possible.

23528_8820-00380_F7D4302 v1_Play Router_Updated_0222-2010

Changing the wireless channel—Depending on local wireless traffic and

interference, switching the wireless channel of your network can

improve performance and reliability. See the section titled

“Changing the Wireless Channel” for instructions on how to

choose other channels.

Limiting the wireless transmit rate—Limiting the wireless transmit rate can

help improve range and connection stability. Most wireless

cards have the ability to limit the transmission rate. To change

this property in Windows, go to the Windows Control Panel,

open “Network Connections”, and double-click on your wireless

card’s connection. In the properties dialog, select the

“Configure” button on the “General” tab, then choose the

“Advanced” tab and select the rate property.

Wireless client cards are usually set to automatically adjust the

wireless transmit rate for you, but doing so can cause periodic

disconnects when the wireless signal is too weak; as a rule,

slower transmission rates are more stable. Experiment with

different connection rates until you find the best one for your

environment. Note that all available transmission rates should

be acceptable for browsing the Internet. For more assistance,

see your wireless card’s user manual.

I’veinstalledthisnewRouterandsomeofmynetworkclients(computers,

gameconsoles,etc.)arenowunabletoconnect.

YournewRoutercamepreconfiguredwithanetworknameand

password,foundprintedonanattachedcard.Allclientsmustuse

thisnetworknameandpasswordtoconnectwirelesslytoyour

Router.Youwillneedtofindthenetworksettingsonyourclient,

selectthenetworknameprintedonthecardfromthelistof

availablenetworks,andenterthepasswordwhenpromptedtojoin

thewirelessnetwork.

DoestheRoutersupportWirelessProtectedAccess(WPA)security?

TheRoutershipswithWPA/WPA2securityturnedon.WindowsXP

andsomeoldernetworkhardwaremayrequireasoftwareupdate

tosupportWPA/WPA2.

23528_8820-00380_F7D4302 v1_Play Router_Updated_0222-2010

IamhavingdifficultysettingupWPAsecurityonmyRouter.

1) LogintoyourRouterbyvisitinghttp://router/withyour

webbrowser.Click on the “Login” button in the top right-

hand corner of the screen. You will be asked to enter your

password. If you have never set a password, leave the

“Password” field blank and click “Submit”.

2) Click“Wireless”inthelefthandmenu.Thenclick“Security”

justbelowthat.

3) Selectthe“WPA/WPA2”option.

4) Enterapassword.Thiscanbefrom8–63charactersofyour

choice,includingspacesandpunctuation,ORa64digit

hexadecimalnumber(usingonlythenumbers0–9andletters

A–F).

5) Click“ApplyChanges”tofinish.Yourwirelessconnectionis

nowencrypted.Eachcomputerusingyourwirelessnetwork

willneedtousethenewkey.

Note:IfyouareconfiguringtheRouteroverawireless

connection,youwillhavetoreconnecttotheRouterafter

changinganysecuritysettings.

Note:SomeoldernetworkinghardwaresupportsonlyWEP

encryption.Ifyouroldercomputerscannotconnecttoyour

network,try128bitor64bitWEP,orseeksoftwareupdates

fromtheirmanufacturers.

IamhavingdifficultysettingupWiredEquivalentPrivacy(WEP)securityonmy

Router.

1) LogintoyourRouter.Visithttp://router/withyourweb

browser.Click on the “Login” button in the top right-hand

corner of the screen. You will be asked to enter your

password. If you have never set a password, leave the

“Password” field blank and click “Submit”.

2) Click“Wireless”inthelefthandmenu.Thenclick“Security”

justbelowthat.

23528_8820-00380_F7D4302 v1_Play Router_Updated_0222-2010

3) Selectthe“128bitWEP”option.

4) YoumaytypeinaWEPkeymanually,orgenerateonefroma

passphrase.Typeaphraseinthe“Passphrase”fieldandclick

the“Generate”button.AWEPkeyiscomposedof26

hexadecimaldigits(0–9,A–F).Forexample,C3030FAF4B

B2C3D44BC3D4EE74isavalid128bitWEPkey.

5) Click“ApplyChanges”tofinish.Yourwirelessactivityisnow

encrypted.Eachcomputerusingyourwirelessnetworkwill

needtousethenewkey.

Note:IfyouareconfiguringtheRouteroverawireless

connection,youwillhavetoreconnecttotheRouterafter

changinganysecuritysettings.

Note:Someoldernetworkinghardwaresupportsonly64bit

WEPencryption.Ifyouroldercomputerscannotconnectto

yournetwork,try64bitWEP.

AdiskIpluggedintotheUSBportisnotshowinguponmycomputerorin

MemorySafe.

1) IsthelightonovertheUSBportthatthediskispluggedinto?

Ifnot,tryunpluggingandrepluggingthedisk.Pleasecheck

thattheUSBconnectorisfirmlypluggedintotheRouter.

2) Ifyourdiskhasanoptionalpowersupply,pleaseuseitwhile

thediskisattachedtoyourRouter.

3) TheRoutersupportsFAT16,FAT32,orNTFSformatteddisks.

DisksinotherformatswillnotappearintheFinder(MacOS

X)orWindowsInternetExplorer.

AprinterIpluggedintotheUSBportisnotshowinguponmycomputer.

1) IsthelightonovertheUSBportthattheprinterisplugged

into?Ifnot,tryunpluggingandrepluggingtheprinter.

PleasecheckthattheUSBconnectorisfirmlypluggedinto

theRouter.

23528_8820-00380_F7D4302 v1_Play Router_Updated_0222-2010

2) ToprinttoaprinterattachedtotheRouter,yourcomputer

musthavethatprinter’sdriverinstalled.Pleasecheckthat

thedriverisinstalled.

3) Theprintermaynotbesettoautoconnect.ViatheBelkin

RouterManager,opentheUSBPrintandStorageCenter.

Checkthattheprinterappearsinthelistofavailabledevices.

Viewthepropertiesoftheprinter,andcheckthat“auto

connect”isselected.

AdifferentsortofUSBdevicethatIpluggedintotheUSBportisnotshowingup

onmycomputer.

MostUSBdevicesotherthandisksandprintersmustbe

accessedviatheUSBPrintandStorageCenter.

1) IsthelightonovertheUSBportthatthedeviceisplugged

into?Ifnot,tryunpluggingandrepluggingthedevice.Please

checkthattheUSBconnectorisfirmlypluggedintothe

Router.

2) ViatheBelkinRouterManager,opentheUSBPrintand

StorageCenter.Checkthatthedeviceappearsinthelistof

availabledevices.

3) Selectthedeviceandclickthe“Use”button.Thedevicewill

bevirtuallyconnectedtoyourcomputeruntilyouchooseto

“StopUsing”thedevice,oranotherpersonrequestsuseofthe

device.

Technical Support

US

http://www.belkin.com/support

UK

http://www.belkin.com/uk/support

Australia

http://www.belkin.com/au/support

23528_8820-00380_F7D4302 v1_Play Router_Updated_0222-2010

NewZealand

http://www.belkin.com/au/support

Singapore

6562218850

Europe

http://www.belkin.com/uk/support

Belkin International, Inc., Limited 2-Year Product Warranty

What this warranty covers.

Belkin International, Inc. (“Belkin”) warrants to the original purchaser of this

Belkin product that the product shall be free of defects in design, assembly,

material, or workmanship.

What the period of coverage is.

Belkin warrants the Belkin product for two years.

What will we do to correct problems?

Product Warranty.

Belkin will repair or replace, at its option, any defective product free of charge

(except for shipping charges for the product). Belkin reserves the right to

discontinue any of its products without notice, and disclaims any limited warranty

to repair or replace any such discontinued products. In the event that Belkin is

unable to repair or replace the product (for example, because it has been

discontinued), Belkin will offer either a refund or a credit toward the purchase of

another product from Belkin.com in an amount equal to the purchase price of the

product as evidenced on the original purchase receipt as discounted by its

natural use.

What is not covered by this warranty?

All above warranties are null and void if the Belkin product is not provided to

Belkin for inspection upon Belkin’s request at the sole expense of the purchaser,

or if Belkin determines that the Belkin product has been improperly installed,

altered in any way, or tampered with. The Belkin Product Warranty does not

protect against acts of God such as flood, lightning, earthquake, war, vandalism,

theft, normal-use wear and tear, erosion, depletion, obsolescence, abuse,

damage due to low voltage disturbances (i.e. brownouts or sags), non-authorized

program, or system equipment modification or alteration.

How to get service.

To get service for your Belkin product you must take the following steps:

23528_8820-00380_F7D4302 v1_Play Router_Updated_0222-2010

1. Contact Belkin International, Inc., at 12045 Waterfront Drive, Los Angeles,

CA 90094, Attn: Customer Service, or call (800)-223-5546, within 15 days of the

Occurrence. Be prepared to provide the following information:

a. The part number of the Belkin product.

b. Where you purchased the product.

c. When you purchased the product.

d. Copy of original receipt.

2. Your Belkin Customer Service Representative will then instruct you on

how to forward your receipt and Belkin product and how to proceed with your

claim.

Belkin reserves the right to review the damaged Belkin product. All costs of

shipping the Belkin product to Belkin for inspection shall be borne solely by the

purchaser. If Belkin determines, in its sole discretion, that it is impractical to ship

the damaged equipment to Belkin, Belkin may designate, in its sole discretion, an

equipment repair facility to inspect and estimate the cost to repair such

equipment. The cost, if any, of shipping the equipment to and from such repair

facility and of such estimate shall be borne solely by the purchaser. Damaged

equipment must remain available for inspection until the claim is finalized.

Whenever claims are settled, Belkin reserves the right to be subrogated under

any existing insurance policies the purchaser may have.

How state law relates to the warranty.

THIS WARRANTY CONTAINS THE SOLE WARRANTY OF BELKIN. THERE

ARE NO OTHER WARRANTIES, EXPRESSED OR, EXCEPT AS REQUIRED

BY LAW, IMPLIED, INCLUDING THE IMPLIED WARRANTY OR CONDITION

OF QUALITY, MERCHANTABILITY OR FITNESS FOR A PARTICULAR

PURPOSE, AND SUCH IMPLIED WARRANTIES, IF ANY, ARE LIMITED IN

DURATION TO THE TERM OF THIS WARRANTY.

Some states do not allow limitations on how long an implied warranty lasts, so

the above limitations may not apply to you.

IN NO EVENT SHALL BELKIN BE LIABLE FOR INCIDENTAL, SPECIAL,

DIRECT, INDIRECT, CONSEQUENTIAL OR MULTIPLE DAMAGES SUCH AS,

BUT NOT LIMITED TO, LOST BUSINESS OR PROFITS ARISING OUT OF THE

SALE OR USE OF ANY BELKIN PRODUCT, EVEN IF ADVISED OF THE

POSSIBILITY OF SUCH DAMAGES.

23528_8820-00380_F7D4302 v1_Play Router_Updated_0222-2010

This warranty gives you specific legal rights, and you may also have

other rights, which may vary from state to state. Some states do not

allow the exclusion or limitation of incidental, consequential, or other

damages, so the above limitations may not apply to you.

*Regulatory Information

FCC Statement

DECLARATION OF CONFORMITY WITH FCC RULES FOR

ELECTROMAGNETIC COMPATIBILITY

We, Belkin International, Inc., of 12045 Waterfront Drive, Los Angeles, CA 90094,

declare under our sole responsibility that the device, F7D4302 v1, complies with

Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)

this device may not cause harmful interference, and (2) this device must accept

any interference received, including interference that may cause undesired

operation.

23528_8820-00380_F7D4302 v1_Play Router_Updated_0222-2010

Caution: Exposure to Radio Frequency Radiation.

The device shall be used in such a manner that the potential for human contact

normal operation is minimized.

This equipment complies with FCC radiation exposure limits set forth for an

uncontrolled environment. This equipment should be installed and operated with

a minimum distance of 20cm between the radiator and your body.

Federal Communications Commission Notice

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential

installation.

This equipment generates, uses, and can radiate radio frequency energy, and if

not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try and correct the

interference by one or more of the following measures:

 Reorient or relocate the receiving antenna.

 Increase the distance between the equipment and the receiver.

 Connect the equipment to an outlet on a circuit different from that to which the

receiver is connected.

 Consult the dealer or an experienced radio/TV technician for help.

FCC Caution: Any changes or modifications not expressly approved by the party

responsible for compliance could void the user’s authority to operate this

equipment.

This device and its antenna(s) must not be co-located or operating in conjunction

with any other antenna or transmitter.

For product available in the USA/Canada market, only channel 1~11 can be

operated. Selection of other channels is not possible.

This device is going to be operated in 5.15~5.25GHz frequency range, it is

restricted in indoor environment only.

Canada-Industry Canada (IC)

The wireless radio of this device complies with RSS 210 Industry Canada. This

Class B digital apparatus complies with Canadian ICES-003.

23528_8820-00380_F7D4302 v1_Play Router_Updated_0222-2010

Operation is subject to the following two conditions: (1) this device may not cause

interference, and (2) this device must accept any interference, including

interference that may cause undesired operation of the device.

Cet appareil numérique de la classe B conforme á la norme NMB-003 du

Canada.

IMPORTANT NOTE:

IC Radiation Exposure Statement:

This equipment complies with IC RSS-102 radiation exposure limits set forth for

an uncontrolled environment. This equipment should be installed and operated

with minimum distance 20cm between the radiator & your body.

Europe

European Union Radio products with the CE or CE alert marking comply with the

R&TTE Directive (1999/5/EC) issued by the Commission of the European

Community.

Compliance with this directive implies conformity to the following European

Norms (in brackets are the equivalent international standards).

• EN 60950-1:2006 (IEC60950-1) – Product Safety

• EN 300 328 Technical requirement for radio equipment

• ETS 301 489 General EMC requirements for radio equipment.

Information

Products with the CE marking comply with the EMC Directive (2004/108/EC) and

the Low Voltage Directive (2006/95/EC) issued by the Commission of the

European Community. Compliance with these directives implies conformity to the

following European Product Family Standards.

• EN 55022 (CISPR 22) – Electromagnetic Interference

• EN 55024-1 – Electromagnetic Immunity

• EN 61000-3-2 (IEC610000-3-2) – Power Line Harmonics

• EN 61000-3-3 (IEC610000) – Power Line Flicker

• EN 60950-1 (IEC60950-1) – Product Safety

Products that contain the radio transmitter are sometimes labeled with the

Notified Body number (CE0560) or CE alert marking if the standard used in the

conformity is not harmonized across the European Community.

23528_8820-00380_F7D4302 v1_Play Router_Updated_0222-2010

*Back cover

registered trademarks of respective manufacturers listed. Mac, Mac OS, and

Safari are trademarks of Apple Inc., registered in the U.S. and other countries.

Windows, Windows Vista, Internet Explorer, and DirectX are either registered

trademarks or trademarks of Microsoft Corporation in the United States and/or

other countries.

8820-00380

F7D4302 v1

Ok mk 12/15/09

Belkin F7D4302V1 Belkin Router User Manual

Belkin International, Inc. Belkin Router

Contents

User Manual

Navigation menu

Namespaces

Views

Navigation
