Belter Health Measurement and Analysis Technology EIVSCK Kitchen scale User Manual IVSCK

Shenzhen Belter Health Measurement and Analysis Technology Co., Ltd. Kitchen scale IVSCK

IVSCK User manual

IVSCKmanual
For the purpose of proper using & maintaining the kitchen scale, please read this
instruction completely before operating.
SPECIFICATIONS
● Equipped with high precision “strain-guage” sensor
● Capacity: 5g-5000g/11LB
● Graduation: 1g/8oz
● LCD Display
● Sensor touch power on
● Automatic zero resetting
● Switch off or Auto off
● Overload indicator
● Tare function
POWER
Battery: 3xAAA batteries
OPERATION
1， When in the first use, please insert the batteries.
2， Place the scale on a hard and flat surface; Press the “ON/OFF”button, the scale will
be zero in 3 seconds.
3， Put the object on the plate, weight will display.
TARE
(TO WEIGHT DIFFERENT INGREDIENTS ON THE SAME KITCHEN SCALE)
Leave the first ingredient weighed on the plate, press “TARE” button to reset the display to
“0g”, add the next ingredient on the plate and the weight will appear on the display, and so
on.
UNIT EXCHANGE
When “0g” displaying or weighing, press the “Unit” button on the base, you can choose the
unit of “g” “oz/lb”.
SWITCH OFF OR AUTO OFF
1， After finish weighing, press “ON/OFF” button to switch off.
2， After finish weighing or if no any operation of the scale, the scale will automatically
switch off after approximate 30 seconds.
LOW BATTERY INDICATOR
When the battery power is low, scale will display "Lo", please replace the battery in time.
OVERLOAD INDICATOR
When the scale is overloaded (over 5000g), “oL” will display on the LCD. Please remove
the weight immediately to avoid the damage of the scale.
ATTENTION
1， Place the scale on a hard and flat surface to ensure the greatest accuracy and
reliability.
2， Do not use any chemical cleanser to clean the scale. Clean your scale with a damp
cloth, but do not immerge your scale into any liquid, as this can damage the inner
parts.
3， To ensure that the scales of life, please do not over-heat scale placed in the
environment.
4， Remove the batteries if the scale is not being used for a long time.
5， Treat your scale with care. It’s a precision instrument, do not drop it or jump on it.
Don’t put the object over 150% of the max capacity on the plate.
6， If the scale doesn’t work, check whether the battery contact well with the contactor. If
the scale has been used for a long time, check whether the batteries need to be
replaced. If necessary, please contact the distributor or call our company.
7， This scale is only used in household for body weight measurement, not for
commercial or other use
FCC STATEMENT
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
To assure continued compliance, any changes or modifications not expressly approved
by the party responsible for compliance could void the user’s authority to operate
this equipment.
Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment and it also complies with Part 15 of FCC RF Rules.
CAUTION
To comply with the limits of the Class B digital device, pursuant to Part 15 of the
FCC Rules, this device is comply with Class B limits. All peripherals must be shielded
and grounded. Operation with non-certified peripherals or non-shielded cables may
results in interference to radio or reception.
MODIFICATION
Any changes or modifications not expressly approved by the grantee of this device
could void the user’s authority to operate the device.
Annex of Report
Manufacturer’s Declaration of the EUT
(altogether 5 pages)
Guidance and manufacturer’s declaration – electromagnetic emission –
for all EQUIPMENT AND SYSTEMS
1
Guidance and manufacturer’s declaration – electromagnetic emission
2
The SF-371 body fat scale is intended for use in the electromagnetic environment specified below. The
customer or the user of SF-371 body fat scale should assure that it is used in such an environment.
3
Emissions test
Compliance
Electromagnetic environment - guidance
4
RF emissions
CISPR 11
Group 1
The SF-371 body fat scale uses RF energy only for its internal
function. Therefore, its RF emissions are very low and are not
likely to cause any interference in nearby electronic equipment.
5
RF emissions
CISPR 11
Class B
The SF-371 body fat scale is suitable for use in all
establishments, including domestic establishments and those
directly connected to the public low-voltage power supply netw
ork
that supplies buildings used for domestic purposes.
6
Harmonic emissions
IEC 61000-3-2
N/A
7
Voltage fluctuations /
flicker emissions
IEC 61000-3-3
N/A
Guidance and manufacturer's declaration – electromagnetic immunity –
for all EQUIPMENT and SYSTEMS
Guidance and manufacturer’s declaration – electromagnetic immunity
The SF-371 body fat scale is intended for use in the electromagnetic environment specified below. The customer
or the user of the SF-371 body fat scale should assure that it is used in such an environment.
IEC 60601
test level
Compliance level
Electromagnetic environment -
guidance
± 6 kV contact
± 8 kV air
± 6 kV contact
± 8 kV air
Floors should be wood, concrete or
ceramic tile. If floors are covered with
synthetic material, the relative
humidity
should be at least 30 %.
± 2 kV for power
supply lines
± 1 kV for input/output
lines
N/A
Mains power quality should be that of
a
typical commercial or hospital
environment.
± 1 kV differential
mode
± 2 kV common mode
N/A
Mains power quality should be that of
a
typical commercial or hospital
environment.
< 5 % UT
(>95 % dip in UT )
for 0.5 cycle
40 % UT
(60 % dip in UT )
for 5 cycles
70 % UT
(30 % dip in UT )
for 25 cycles
< 5 % UT
(>95 % dip in UT )
for 5 sec
N/A
Mains power quality should be that of
a
typical commercial or hospital
environment. If the user of the
SF-371 body fat scale requires
continued operation during power
mains interruptions, it is
recommended that the SF-371 body
fat scale be powered from an
uninterruptible power supply or a
battery.
3 A/m
3 A/m
Power frequency magnetic fields
should be at levels characteristic of a
typical location in a typical
commercial or hospital environment.
NOTE UT is the a. c. mains voltage prior to application of the test level.
Guidance and manufacturer’s declaration – electromagnetic immunity –
for EQUIPMENT and SYSTEM that are not LIFE-SUPPORTING
Guidance and manufacturer’s declaration – electromagnetic immunity
The SF-371 body fat scale is intended for use in the electromagnetic environment specified below. The customer or
the user of the SF-371 body fat scale should assure that it is used in such an environment.
Immunity test
IEC 60601 test
level
Compliance level
Electromagnetic environment - guidance
Conducted RF
IEC 61000-4-6
Radiated RF
IEC 61000-4-3
3 Vrms
150 kHz to 80 MHz
3 V/m
80 MHz to 2.5 GHz
N/A
3 V/m
Portable and mobile RF communications equipment
should be used no closer to any part of the SF-371 body
fat scale , including cables, than the recommended
separation distance calculated from the equation
applicable to the frequency of the transmitter.
Recommended separation distance
P
V
d]
5.3
[1
P
E
d]
5.3
[1
80 MHz to 800 MHz
P
E
d]
7
[1
800 MHz to 2.5 GHz
where p is the maximum output power rating of the
transmitter in watts (W) according to the transmitter
manufacturer and d is the recommended separation
distance in metres (m).b
Field strengths from fixed RF transmitters, as determined
by an electromagnetic site survey,a should be less than the
compliance level in each frequency range.b
Interference may occur in the vicinity of equipment
marked with the following symbol:
NOTE 1 At 80 MHz and 800 MHz, the higher frequency range applies.
NOTE 2 These guidelines may not apply in all situations. Electromagnetic is affected by absorption and reflection from structures,
objects and people.
a Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios,
amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted theoretically with accuracy. To assess the
electromagnetic environment due to fixed RF transmitters, an electromagnetic site survey should be considered. If the measured field
strength in the location in which the SF-371 body fat scale is used exceeds the applicable RF compliance level above, the
SF-371 body fat scale should be observed to verify normal operation. If abnormal performance is observed, additional measures
may be necessary, such as reorienting or relocating the SF-371 body fat scale .
b Over the frequency range 150 kHz to 80 MHz, field strengths should be less than 3V/m.
Recommended separation distances between portable and mobile
RF communications equipment and the EQUIPMENT or SYSTEM -
for EQUIPMENT and SYSTEMS that are not LIFE-SUPPORTING
Recommended separation distances between
portable and mobile RF communications equipment and the SF-371 body fat scale
The SF-371 body fat scale is intended for use in an electromagnetic environment in which radiated RF disturbances are
controlled. The customer or the user of the SF-371 body fat scale can help prevent electromagnetic interference by
maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the SF-371 body
fat scale as recommended below, according to the maximum output power of the communications equipment
Separation distance according to frequency of transmitter
m
Rated maximum
output of
transmitter
W
150 kHz to 80 MHz
P
V
d]
5.3
[1
80 MHz to 800 MHz
P
E
d]
5.3
[1
800 MHz to 2.5 GHz
P
E
d]
7
[1
0.01
/
0.12
0.23
0.1
/
0.38
0.73
1
/
1.2
2.3
10
/
3.8
7.3
100
/
12
23
For transmitters rated at a maximum output power not listed above the recommended separation distance d in metres
(m) can be estimated using the equation applicable to the frequency of the transmitter, where P is the maximum output
power rating of the transmitter in watts (W) according to the transmitter manufacturer.
NOTE 1 At 80 MHz and 800 MHz, the separation distance for the higher frequency range applies.
NOTE 2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and
reflection from structures, objects and people.
