Users Manual

right page (1) of AX75_Pegasus, fcc, us-en (31.05.2005, 08:47)

Contents 1

VAR Language: am; VAR issue date: 050309

Legal notices ...................................... 2

Safety precautions ............................. 4

Antenna care ...................................5

Phone operation ..............................5

Electronic devices ............................ 6

Overview of the phone ...................... 9

Display symbols ................................ 10

Getting started .................................11

Switch on/off, PIN .............................12

Emergency number (SOS) ..............12

General instructions .........................12

Security ............................................13

Codes ............................................13

Calling ..............................................14

Text entry .........................................14

Default book .....................................16

Phonebook .......................................16

<New entry> ..................................16

Call (search for an entry) ................16

Address book ....................................16

<New entry> ..................................16

Change entry .................................17

Voice dialing ..................................17

Records ............................................. 17

Duration/charges .............................. 17

Voice message/ mailbox .................. 17

SMS ................................................... 18

MMS ................................................. 19

Message setup ................................. 20

Ring tones ........................................ 20

Surf & fun .........................................20

Internet browser ............................20

Games & more ...............................21

Setup ................................................ 21

Organizer ......................................... 24

Alarm clock ................................... 24

Calendar ....................................... 24

Appointments ............................... 24

Notes ............................................ 24

Missed alarms ............................... 25

Time zones .................................... 25

Calend. setup ................................ 25

Extras ............................................... 25

SIM services (optional) .................. 25

Calculator ...................................... 25

Currency conv ............................... 25

Stopwatch ..................................... 25

Countdown ................................... 25

Voice command ............................ 25

Fast access key ................................. 26

Own stuff ......................................... 26

Customer Care ................................. 27

Care and maintenance ..................... 28

Product data ..................................... 29

Accessories ...................................... 30

SAR (AX75) ....................................... 31

U.S. FDA ........................................... 33

FCC/Industry Canada Notice ............ 37

Ten Driving Safety Tips .................... 38

Intellectual property ........................ 40

End user license agreement ............ 41

Contents

left page (2) of AX75_Pegasus, fcc, us-en, (31.05.2005, 08:47)

Legal notices

VAR Language: am; VAR issue date: 050309

Legal notices

The mobile phone described in this guide is approved for use on the GSM and GPRS net-

works operating on the GSM 900, 1800 (DCS/PCN) and 1900 (PCS) bands. It is approved

for use in the country where it was originally sold and may be approved for use in other

countries.

Siemens and the AX75 model phone are

trademarks or registered trademarks of

Siemens AG and/or its affiliates in the

United States and/or other countries.

T9® is a registered trademark of America

Online, Inc. in the United States. Java and

all Java-based trademarks and logos are

trademarks or registered trademarks of Sun

Microsystems, Inc. in the U.S and other

countries. The names of actual companies

and products mentioned herein may be the

trademarks of their respective owners.

Disclaimer

The information contained in the User

Guide is written for the AX75 phone.

Siemens reserves the right to make changes

and improvements to the products and any

of the features of the products described in

this document without prior notice. The

contents of the user guide are provided "AS

IS". Except as required by applicable law, no

warranties of any kind, either express or im-

plied, including, but not limited to, the im-

plied warranties of merchantability and fit-

ness for a particular purpose, are made in

relation to the accuracy, reliability or con-

tents of this document. Siemens reserves

the right to revise the user guide or with-

draw it at any time without prior notice. Un-

der no circumstances shall Siemens be re-

sponsible for any loss of data or income or

any special, incidental, consequential or in-

direct damages howsoever caused.

Export Information

The mobile phone may be subject to export

regulation of the United States and other

countries. Diversion contrary to law is pro-

hibited. You must comply with all applica-

ble export laws, restrictions and regulations

of the United States foreign agencies or au-

thorities, and may not export, or transfer

for the purpose of re-export, the mobile

phone or any part of the phone in violation

of any applicable restrictions, laws or regu-

lations, or without all necessary approvals.

Network Services

A number of features included in this

guide are called Network Services. They

are special services provided by wireless

service providers. In order to use any of

these Network Services, you must sub-

scribe to these service(s) from your ser-

vice provider and obtain instructions for

their use. Some of these Network Servic-

es may not be available when roaming on

a network other than your home network.

Standby and

Talk Time Information

The mobile phone incorporates features

that are new to the mobile phone world.

These may include color displays and

lighting, graphic games, music reproduc-

tion and browsing the Internet. The way

you use the display and the features will

affect the performance of the battery and

how long it lasts between charge cycles.

The quoted standby times and talk times

show the minimum and maximum per-

formance that can be expected from the

right page (3) of AX75_Pegasus, fcc, us-en, (31.05.2005, 08:47)

Legal notices

VAR Language: am; VAR issue date: 050309

battery under normal network conditions

and with the default settings as set by the

factory. However, playing games (particu-

larly with the backlight continuously

switched on) and listening to music will

shorten the time available for standby

and to make and receive telephone calls.

Operation times also vary depending on

network conditions, SIM settings, charg-

ing and battery condition, how you use

your phone and other factors.

Memory

The mobile phone contains an internal

memory device that stores the software

required to operate the mobile phone,

communicate with the GSM/GPRS net-

work and provide the user interface.

Some features in the internal memory

run additional devices and some addition-

al games and utilities. The amount of

memory available in the mobile phone is

finite and may be insufficient to store

large numbers of applications and files.

Warning!

Remember to back up your data and to do so fre-

quently. Always back up all data and programs

before sending the mobile phone in for repair.

left page (4) of AX75_Pegasus, fcc, us-en, (31.05.2005, 08:46)

Safety precautions

VAR Language: am; VAR issue date: 050309

Safety precautions

Information for parents

Please read the operating instructions and safety precautions carefully before use.

Explain the content and the hazards associated with using the phone to your children.

Remember to comply with legal re-

quirements and local restrictions

when using the phone. For example

in aeroplanes, petrol stations, hos-

pitals or while driving.

Mobile phones can interfere with

the functioning of medical devices

such as hearing aids or pacemak-

ers. Keep at least 20 cm/9 inches

between phone and pacemaker.

When using the mobile phone hold

it to the ear which is further away

from the pacemaker. For more

information consult your doctor.

The ringtones, message tones and

handsfree (p. 14) talking are repro-

duced through the loudspeaker. Do

not hold the phone to your ear when

it rings or when you have switched

on the handsfree function (p. 14).

Otherwise you risk serious perma-

nent damage to your hearing.

Only use original Siemens batteries

(100 % mercury-free) and – charg-

ing devices. Otherwise you risk seri-

ous damage to health and property.

The battery could explode, for in-

stance.

Small parts such as the SIM card,

sealing stop, lens ring and lens cap

can be dismantled and swallowed

by small children. The phone must

therefore be stored out of the reach

of small children.

The mains voltage specified on the

power supply unit (V) must not be

exceeded. Otherwise the charging

device may be destroyed.

The power supply must be plugged

into an easily accessible AC mains

power socket when charging the

battery. The only way to turn off the

charging device after charging the

battery is to unplug it.

Do not use a handheld while

driving.

Do not use an optical magnifier to

look at the activated infrared inter-

face [Class 1 LED product (classifi-

cation as per IEC 60825-1)].

Do not place the phone near to

electromagnetic data carriers such

as credit cards and floppy disks. In-

formation stored on them could be

lost.

You may only open the phone to re-

place the battery (100 % mercury-

free) or SIM card. You must not

open the battery under any circum-

stances. All other changes to this

device are strictly prohibited and will

invalidate the guarantee.

right page (5) of AX75_Pegasus, fcc, us-en, (31.05.2005, 08:46)

Safety precautions

VAR Language: am; VAR issue date: 050309

Antenna care

Use only the supplied or an approved re-

placement antenna. Unauthorized anten-

nas, modifications, or attachments could

damage the phone and may violate FCC

regulations.

Phone operation

Normal position

Hold the phone as you would any other

telephone with the antenna pointed up

and over your shoulder.

Tips on efficient operation

For your phone to operate most

efficiently:

• Extend your antenna fully

(if applicable).

• Do not touch the antenna unnecessari-

ly when the phone is in use. Contact

with the antenna affects call quality

and may cause the phone to operate at

a higher power level than otherwise

needed.

Driving

Laws pertaining to the use of mobile

phones while driving vary significantly from

state to state and sometimes even from lo-

cality to locality within states. For example,

some areas may allow persons to use their

mobile phones only if they employ a hands-

free device, and some areas may prohibit

the use of cell phones entirely. Accordingly,

Siemens recommends that persons check

the laws for the areas in which they drive or

will be driving. For areas where the use of

mobile phones while driving is permitted,

Siemens encourages persons to use their

Important:

Please dispose of unwanted batter-

ies and phones as permitted by the

laws in your country.

The phone may cause interference

in the vicinity of TV sets, radios and

PCs.

Use only Siemens original accesso-

ries. This will avoid potential risks to

health or property and ensure com-

pliance with all relevant regulations.

Improper use will invalidate the guarantee!

These safety instructions also apply to Siemens

original accessories.

Product attributes are subject to changes in tech-

nology, design and availability. Siemens reserves

the right to modify products without prior notice.

Important

Read this information before using your

wireless handheld phone.

As this mobile phone is equipped with a

fixed (non-retractable) antenna, some

paragraphs in the text below may not be

applicable.

left page (6) of AX75_Pegasus, fcc, us-en, (31.05.2005, 08:46)

Safety precautions

VAR Language: am; VAR issue date: 050309

phones responsibly and to employ hands-

free devices. Also, if using your phone while

driving, please:

• Give full attention to driving – driving

safely is your first responsibility;

• Use hands-free operation, if available;

• Pull off the road and park before mak-

ing or answering a call, if driving condi-

tions so require.

For vehicles equipped with air bags

An air bag inflates with great force. DO NOT

place objects, including either installed or

portable wireless equipment, in the area

over the air bag or in the air bag deploy-

ment area. If in-vehicle wireless equipment

is improperly installed and the air bag in-

flates, serious injury could result.

Electronic devices

Most modern electronic equipment is

shielded from radio frequency (RF) sig-

nals. However, certain electronic equip-

ment may not be shielded against the RF

signals from your wireless phone.

Pacemakers

The Health Industry Manufacturers' Associ-

ation recommends that a minimum separa-

tion of six inches (6") be maintained be-

tween a handheld wireless phone and a

pacemaker to avoid potential interference

with the pacemaker. These recommenda-

tions are consistent with the independent

research by and recommendations of Wire-

less Technology Research.

Persons with pacemakers

• should ALWAYS keep the phone more

than six inches from their pacemaker

when the phone is turned ON;

• should not carry the phone in a breast

pocket;

• should use the ear opposite the pace-

maker to minimize the potential for in-

terference;

• should turn the phone OFF immediate-

ly if there is any reason to suspect that

interference is taking place.

Hearing aids

Some digital wireless phones may

interfere with some hearing aids. In the

event of such interference, you may want

to consult your service provider or your

hearing aid manufacturer to discuss alter-

natives.

Other medical devices

If you use any other personal medical de-

vices, consult the manufacturers of your

devices to determine if they are ade-

quately shielded from external RF energy.

Your physician may be able to assist you

in obtaining this information.

Turn your phone OFF in health care facili-

ties when any regulations posted in these

areas instruct you to do so. Hospitals or

health care facilities may be using equip-

ment that could be sensitive to external

RF energy.

Vehicles

RF signals may affect improperly installed

or inadequately shielded electronic sys-

tems in motor vehicles. Check with the

manufacturer or its representative regard-

ing your vehicle. You should also consult

the manufacturer of any equipment that

has been added to your vehicle.

Posted facilities

Turn your phone OFF in any facility where

posted notices so require.

Airplanes

FCC and Airline Regulations prohibit using

your phone while in the air. Turn your

phone OFF when requested by the airline.

Check and comply with the policy of your

airline regarding the use of your phone

while the airplane is on the ground.

right page (7) of AX75_Pegasus, fcc, us-en, (31.05.2005, 08:46)

Safety precautions

VAR Language: am; VAR issue date: 050309

Blasting areas

To avoid interfering with blasting opera-

tions, turn your phone OFF when in a

“blasting area” or in areas posted: “Turn

off two-way radio.” Obey all signs and in-

structions.

Potentially explosive atmospheres

Turn your phone OFF when in any area with

a potentially explosive atmosphere and

obey all signs and instructions. Sparks in

such areas could cause an explosion or fire

resulting in bodily injury or even death.

Areas with a potentially explosive atmo-

sphere are often but not always clearly

marked. They include: fueling areas such

as gasoline stations; below deck on boats;

fuel or chemical transfer or storage facili-

ties; vehicles using liquefied petroleum

gas (such as propane or butane); areas

where the air contains chemicals or parti-

cles, such as grain, dust or metal pow-

ders; and any other area where you

would normally be advised to turn off

your vehicle engine.

Emergency calls (SOS)

Your wireless phone can be used to make

emergency calls. You can make an emer-

gency call from the main display screen.

Enter the local emergency number such

as 911 and then press the A key.

This phone, like any wireless phone, oper-

ates using radio signals, wireless and

landline networks, and user-pro-

grammed functions. Because of this, con-

nections in all conditions cannot be guar-

anteed. Therefore, you should never rely

solely on any wireless phone for essential

communications (for example, medical

emergencies). Remember – to make or

receive any calls, the phone must be

switched on and be used in a service area

that has adequate signal strength. Emer-

gency calls might not be possible on all

wireless phone networks or when certain

network services or phone features are in

use. Check with local service providers re-

garding their network features.

Always make certain that your phone is

properly charged before attempting any

emergency calls. If you allow your battery

to discharge, you will be unable to receive

or make calls, including emergency calls.

You must then wait a few minutes after

the charging begins to place any

emergency calls.

When making an emergency call,

remember to give all of the necessary in-

formation as accurately as possible. Re-

member that your wireless phone might

be the only means of communication at

the scene of an accident, therefore you

should not terminate the call until given

permission to do so.

Batteries and Chargers

Only use original Siemens batteries

(100% mercury-free) and charging

devices. Use of non-Siemens batteries

and/or charging devices may cause explo-

sion resulting in serious injury and/or

property damage. Use original Siemens

accessories in order to avoid possible

injury and property damage and to

ensure compliance with applicable laws

and regulations. Improper use invalidates

the warranty.

Battery safety precautions

To reduce the risk of fire, injury or electric

shock, and to properly dispose of batter-

ies, please read and understand the fol-

lowing instructions. CONTAINS LITHIUM-

ION OR NICKEL-METAL HYDRIDE BATTERY.

BATTERY MUST BE RECYCLED OR DIS-

POSED OF PROPERLY. DO NOT DISPOSE IN

MUNICIPAL WASTE.

1. Only use the batteries specified for use

with this mobile phone.

2. Do not use batteries of different sizes

or from different manufacturers in this

mobile phone.

left page (8) of AX75_Pegasus, fcc, us-en, (31.05.2005, 08:46)

Safety precautions

VAR Language: am; VAR issue date: 050309

3. Do not dispose of the battery in a fire; it

may explode. Dispose of used batteries

and phones in accordance with applica-

ble laws and safety regulations. Do not

expose battery to water. Check with

local codes for special disposal

instructions.

4. Do not open or mutilate the battery.

Doing so may cause damage to the

eyes or skin.

5. Exercise care in handling the battery in

order not to short the battery with con-

ducting materials such as rings, brace-

lets, and keys. The battery or conduct-

ing material may overheat and cause

burns or fire.

6. Charge the battery provided with, or

identified for use with, this product

only in accordance with the instruc-

tions and limitations specified in the

User's Guide. Do not attempt to charge

the battery by any means other than

those specified in the User's Guide.

right page (9) of AX75_Pegasus, fcc, us-en, (31.05.2005, 08:47)

Overview of the phone

VAR Language: am; VAR issue date: 050309

Overview of the phone

1Display indicators

Signal strength/GPRS/battery level.

2Soft keys

Press the soft key to call up the function

that is displayed as §Text§ or icon on the

grey fields above the key.

3ACall key

Dial displayed phone number or name,

accept calls. In standby mode: Display the

last calls.

4BOn/Off/End key

• Switched off: press and hold to

switch on.

• During a conversation or in an

application: press briefly to finish.

• In menus: press briefly to go back a

level. Press and hold to return to

standby mode.

• In standby mode: press and hold to

switch off phone.

5Navi-key

In lists and menus:

GScroll up and down.

DFunction call.

CBack a menu level.

During a call:

DOpen call menu.

EStart adjusting the volume then set

volume withG.

FOpen Addressbook/Phonebook.

In standby mode:

EVoice control (press and hold).

FOpen Addressbook/Phonebook.

DOpen menu.

CGPRS info.

6*Press and hold

• In standby mode: switch on/off all

signal tones (except alarm).

• For incoming calls: only switch off ring

tones.

7Press and hold

In standby mode: switch key lock on/off.

8 Plug socket

For charger, headset, camera etc.

9 Infrared interface (IrDA)

_ ªg

Service provider

17.04.2005 09:15

NewMMS Menu

left page (10) of AX75_Pegasus, fcc, us-en, (31.05.2005, 08:47)

Display symbols

VAR Language: am; VAR issue date: 050309

Display symbols

Display symbols (selection)

_ Signal strength

h Charging

d Battery charge level, e.g. 50%

è Addressbook/Phonebook

Z Call records

É Surf & fun/Service provider portal

ç Organizer

] Messages

 Ring tones

 Extras

Ñ Own stuff

m Setup

n Call(s) is/are diverted

j Ringer off

k Short ring (beep) only

l Ringtone only, if the caller is stored in

the Addressbook/Phonebook

Ø Alarm set

Ö Alarm clock activated

µ Keypad locked

T Message memory full

² No network access

ABC/

Abc/abc

Indicates whether upper or lower-

case letters are active

T9Abc Text input with T9

« Activated and available

ª Registered

 Temporarily interrupted

Ê Internet online

Ë Internet via GPRS online

Ì Internet no network

± Auto answer feature on

Organiser symbols (selection)

u Memo

v Call

w Meeting

{ Birthday

È Anniversary

Access with left soft key (selection)

… Message received

Û MMS notification received

\ Voice message received

 Unanswered call

Depending on the service provider, some of the

symbols shown here may vary from those in the

phone.

right page (11) of AX75_Pegasus, fcc, us-en, (31.05.2005, 09:05)

Getting started

VAR Language: am; VAR issue date: 050309

Getting started

Using the SIM card/battery

Your phone's display is delivered with a

protective film. Remove this film before get-

ting started. The service provider supplies

you with a SIM card on which all the im-

portant data for your account is stored. If

the SIM card is credit card-sized, snap out

the smaller segment and trim any rough

edges.

Press depression 1 to remove the

cover downwards in the direction of the

arrow 2.

Insert SIM card 3 and push it fully into

the locating slot (make sure the angled

corner is in the correct position 4).

To remove the SIM card push the card

here 5.

Insert the battery sideways into the phone

6, then press downwards 7 until it

engages.

To remove, press the retaining tab 8

then lift the battery out.

Place cover on phone and push to the up-

per edge, until it clicks into place 9.

Always switch off phone before removing

the battery!

Only 3V and 1.8V SIM cards are support-

ed. Please contact your service provider if

you have an older card.

Charge battery

The battery is not fully charged when de-

livered. Plug charger cable into the bot-

tom of the phone, plug power supply unit

into a mains power socket and charge for

at least two hours. The power supply unit

heats up when used for long periods. This

is normal and not dangerous.

left page (12) of AX75_Pegasus, fcc, us-en, (31.05.2005, 09:05)

Switch on/off, PIN

VAR Language: am; VAR issue date: 050309

When charging is in progress h is

displayed.

Charging time

An empty battery is fully charged after

about 2 hours. Charging is only possible

within a temperature range of +5°C to

+40°C (+41°F to +104°F) If the tempera-

ture rises/falls 5°C above/below this, i.e

drops to 32°F or rises to 113°F, the charge

symbol flashes a warning. The mains volt-

age specified on the power supply unit

must not be exceeded (Operating time,

p. 30).

Charge icon not visible

If the battery has been discharged fully

the charge icon is not immediately visible

when the power supply unit is plugged

in. It will appear after up to two hours. In

this case the battery is fully charged after

3-4 hours.

Only use the power supply unit provided!

Display while in service

Charge level display during operation

(empty - full): adg.

A beep sounds when the battery is nearly

empty. The charge level of the battery is

only displayed correctly after an uninter-

rupted charging/discharging cycle. You

should therefore not remove the battery un-

necessarily and where possible not termi-

nate the charging process early.

Switch on/off, PIN

Switch on/off

Press and hold the On/Off/End key B to

switch on or off.

Enter PIN

The SIM card can be protected with a

4- to 8-digit PIN.

Enter the PIN using the number keys. The

characters **** appear to ensure no-

body can read your PIN on the display.

Correct errors with §Clear§.

Confirm your input with §OK§. Logging on

to the network will take a few seconds.

Emergency number (SOS)

Only to be used in real emergencies!

By pressing the soft key §SOS§ you can

make an emergency call on any network

without a SIM card and without entering a

PIN (not available in all countries).

Signal strength

_Strong reception signal.

^A weak signal reduces the call

quality and may lead to loss

of the connection. Change your

location.

General instructions

User guide

The following symbols are used to explain

operation:

JEnter numbers or letters.

BOn/Off/End key.

ACall key.

DPress navigation key on the side

indicated

§Menu§ Displays a soft-key function.

LFunction depends on the service

provider, special registration

may be necessary.

right page (13) of AX75_Pegasus, fcc, us-en, (31.05.2005, 09:05)

Security

VAR Language: am; VAR issue date: 050309

Menu control

The steps needed to reach a function are

shown in a condensed form in this user

guide.

E.g. to display call list for missed calls:

Press §Menu§ ¢Z ¢Missed calls

¢§Selection§.

This comprises the following steps:

Open main menu, select Z, then select

the function Missed calls. You have to con-

firm with §Selection§.

Standby mode

Very often function descriptions begin in

standby mode.

The phone is in standby mode and is ready

for use when the name of the service pro-

vider appears on the display.

Press and hold the On/Off/End key B

to return to standby mode from any

situation.

Security

§Menu§ ¢m ¢Security

¢Select function.

The phone and SIM card are protected

against misuse by several security codes.

Keep these confidential numbers in a safe

place where you can access them again if

required.

Codes

PIN control

You can stop the PIN prompt being

activated when the phone is switched on,

but you then risk unauthorised use of the

phone.

Press §Change§. Enter PIN and confirm

with §OK§.

Change PIN

You can change the PIN to any 4- to 8-dig-

it number you find easier to remember.

Enter current PIN and confirm with §OK§.

Enter new PIN twice and confirm each

time with §OK§.

Change PIN2

(Display only if PIN2 is available). Proceed

as with Change PIN.

Change phonecode

You define the phone code (4-8 digits)

when you call up a protected function for

the first time. It is then valid for all phone-

code protected functions.

Clear SIM card barring

If the PIN is entered incorrectly three

times, the SIM card is barred. Enter the

PUK (MASTER PIN), provided by your ser-

vice provider with the SIM card, according

to instructions. If the PUK (MASTER PIN)

has been lost, please contact your service

provider.

Preventing accidental activation

Even if PIN control is deactivated confir-

mation is required to switch on the

phone.

This prevents the phone from being

switched on accidentally, e. g. when car-

ried in a pocket or whilst you are on an

aircraft.

Press and hold the On/Off/End key B

and confirm with §OK§. The phone switch-

es on.

left page (14) of AX75_Pegasus, fcc, us-en, (31.05.2005, 09:05)

Calling

VAR Language: am; VAR issue date: 050309

Calling

Dialling with number keys

The phone must be switched on (standby

mode). Dial number (always with area

code, if necessary with international dial-

ling code). To dial international dialling

code press and hold 0 until a "+" is dis-

played. Press §Country§ and select country.

Short press §Clear§ to clear the last digit, a

long press clears the entire phone num-

ber. To dial press the Call key A.

Accept call

The phone must be switched on (standby

mode). An incoming call will interrupt

any other use of the phone. Press §Answer§

or A.

Please make sure you have accepted the call

before holding the phone to your ear. This will

avoid damage to your hearing from loud ring

tones!

Handsfree

You can put the phone aside during a call.

You can then hear the caller via the

loudspeaker.

Activate handsfree function with §Handsfr.§

and switch on with §Yes§.

Adjust the volume with E. Pressing

§Handsfr.§ switches off "handsfree talking".

Always switch off "handsfree talking" before

holding the phone to your ear! This will avoid

damage to your hearing!

Swapping between 2 calls b

Make a new connection during a call

with y Menu§ ¢Hold ¢J(dial

a new phone number). With y Menu§

¢Toggle you can swap back and forth

between both calls.

If you are called during a phone call and

you can hear the "call waiting tone"

(p. 22), you can accept the waiting call

with §Toggle§,putting the current call on

hold to do so.

Swap back and forth between the calls

see above or end the current call with B

and accept the new call with §Answer§.

Babysitter

If this is active, only one number can be

dialled.

§Menu§ ¢m ¢Security ¢Babysitter

Press D and enter phone code. The

phone code (4- to 8-digits) is set by you

and entered at the first security setting.

Please note this code down (see also p. 13)!

Confirm code input with §OK§.

Press §Change§ and enter number (press

· to select phone number from the

Adressbook p. 17 or Phonebook p. 16).

Confirm "On" with §OK§.

To dial, press and hold the right soft key.

To switch direct call off, press and hold .

Enter phone code and confirm with §OK§.

Press §Change§ and Confirm Off with §OK§.

Text entry

Text entry without T9

Press number key repeatedly until the re-

quired letter appears. After a brief interval

the cursor will advance. Example:

2Press once briefly to type the let-

ter a, twice to type b, etc. Press

and hold to write the number.

Ä,ä,1-9 Umlauts and numbers are dis-

played after the relevant letters.

§Clear§ Press briefly to delete the letter

before the cursor, press and hold

to erase the whole word.

H/GMove the cursor

(forwards/back).

Press briefly: Swap between abc,

Abc, T9abc, T9Abc, T9ABC, 123.

Status shown in top line of

display.

Press and hold: All inputvariants

are displayed.

right page (15) of AX75_Pegasus, fcc, us-en, (31.05.2005, 09:05)

Text entry

VAR Language: am; VAR issue date: 050309

*Press briefly: Special characters

are shown.

Press and hold: Open input

menu.

0Press once/repeatedly:

. , ? ! ’ " 0 - ( ) @ / : _

Press and hold: Writes 0.

1Writes blank. Press twice =

jumps a line.

Special characters

Press * briefly. The character map is

displayed:

1) Line break

Navigate to characters with G,H and

press §Selection§.

Input menu

Press and hold* with text input. The input

menu ist displayed:

Text format (SMS only), Input language, Mark

text, Copy/Add

Text entry with T9

"T9" deduces the correct word from the

individual key entries by making compari-

sons with an extensive dictionary.

Activate, deactivate T9

§Menu§ ¢] ¢Message setup ¢T9

preferred ¢§Change§

(activate/deactivate T9).

Select Input language

Select the language in which you want to

compose your message.

§Menu§ ¢] ¢Message setup ¢Input

language ¢§Selection§ (the new language

is set)

Write a word using T9

Since the display changes as you proceed,

it is best if you finish a word without look-

ing at the display.

Simply press the keys once only where the

relevant letter is located. For "hotel", for

example:

Press briefly  for T9Abc then 46835and

1 (the blank ends a word).

Do not use special characters such as Ä

but rather use the standard characters,

e.g. A; T9 will do the rest for you.

Additional information

0Set a full stop. A word is conclud-

ed if it is followed by a space.

Within a word, a full stop repre-

sents an apostrophe or hyphen:

e.g. §provider.s§ = provider’s.

DGo to the right. Ends a word.

Press briefly: Swap between: abc,

Abc, T9abc, T9Abc, 123. Status

shown in top line of display.

Press and hold: All input modes

are displayed.

*Press briefly: Select special char-

acters (p. 15).

Press and hold: Open input menu

T9 word suggestions

If the word you want has not been

recognised, the next suggestion from T9

may be correct.

The word must be §highlighted§. Then press

». The displayed word is replaced

with a different word. If this word is also

incorrect, repeat until the correct word is

displayed.

To add a word to the dictionary, select

§Learn§. Now write the word without T9-

support and accept with §Save§ into the

dictionary.

1) ¿¡_;.,?!+

-"’:*/()¤¥

$£€@\ &#[ ] {

} %~<=>| ^§ Γ

∆ Θ Λ Ξ Π Σ Φ Ψ Ω

left page (16) of AX75_Pegasus, fcc, us-en, (31.05.2005, 09:05)

Default book

VAR Language: am; VAR issue date: 050309

Correct a word

Words written with T9:

With H move left or right, word by

word, until the required word is

§highlighted§.

With » scroll through the T9 word

suggestions again. §Clear§ deletes the char-

acter to the left of the cursor and displays

a new possible word!

Default book

§Menu§ ¢è ¢Select function.

Show entries

Entries in the standard directory (Address-

book or Phonebook) are shown for

selection.

Select a name by entering the first letter

J and/or scroll G. To dial press the

Call key A.

Create new entry in standard directory.

Phonebook, Address book (see below).

Default book

Select the Phonebook (only one phone

number possible per entry) or the Ad-

dressbook as your standard directory

(default book).

F ¢Phonebook / Address book ¢D

(set as standard)

Phonebook

Entries in the Phonebook (on the SIM

card) are managed separately from those

in the Addressbook. You can, however,

exchange data between the Phonebook

and the Addressbook.

If the Phonebook is set as standard

(Addressbook as standard):

Open Phonebook (in standby mode)

F ¢<New entry> ¢Select entry field

(The maximum number of characters

available is displayed at the top of the

screen)

Press §Save§ to store the new entry.

Call (search for an entry)

Open phonebook F, select name and

and press the Call key A.

<Own numbrs>: enter personal phone

numbers, <VIP numbers>: assign important

numbers to group, <SIM phonebook>,

<Protected SIM>, <Info numbers>.

Address book

The Addressbook can store up to

500 entries that are managed in the

phone memory.

If the Addressbook has been selected as

standard:

Open Addressbook (in standby mode)

F ¢D ¢J (enter first and/or

last name) ¢Select entry field ¢Make

further entries ¢§Save§.

Group

Entries can be organized by groups.

Select with §Change§.

T9® Text Input is licensed under one or more of

the following:

U.S. Pat. Nos. 5,818,437, 5,953,541, 5,187,480,

5,945,928 and 6,011,554;

Canadian Pat. No. 1,331,057;

United Kingdom Pat. No. 2238414B;

Hong Kong Standard Pat. No. HK0940329;

Republic of Singapore Pat. No. 51383;

Euro.Pat. No. 0 842 463 (96927260.8)

DE/DK, FI, FR, IT, NL, PT, ES, SE, GB;

and additional patents are pending worldwide.

right page (17) of AX75_Pegasus, fcc, us-en, (31.05.2005, 09:05)

Records

VAR Language: am; VAR issue date: 050309


Press §Selection§. Assign a picture to an Ad-

dressbook entry. It is displayed if you are

called by the corresponding phone

number.

Birthday

After entering the date of birth, the "re-

minder box" can be activated. You can

now enter the time for the reminder.

The phone will then remind you with

an accoustic tone and also with a display

one day before the birthday and on the

birthday.

All fields

Press §Selection§. Show all input fields if the

display was previously reduced (§Options§,

Field setup).

Change entry

F ¢Select entry ¢§View§ ¢§Edit§

¢Make changes ¢§Save§.

Voice dialing

Dial numbers by voice command. Up to

20 recorded names for voice dialling or

voice commands (p. 25) can be saved on

the mobile (not on the SIM card).

Record

Open Addressbook (in standby mode).

F ¢Select entry (first letter and/or

scroll) ¢§Options§ ¢Voice dialing

¢(Select phone numbers if there are

more than one ¢§Record§ ¢§Start§.

A short signal sounds. Now speak the

name. After a second beep and message

in the display, repeat the name. A beep

now confirms the recording, which is

saved automatically.

Apply voice dialling

Press and hold E (in standby mode).

Now speak the name. The number is

dialled.

Records

Your phone stores the phone numbers of

calls for convenient redialling.

§Menu§ ¢Z ¢§Selection§ ¢Select call list

and confirm ¢Select phone number

¢A.

Here you will find Missed calls,

Calls received, Calls dialed, Delete records.

Duration/charges b

Display charge details and the duration of

different types of calls while you speak, as

well as setting a unit limit for outgoing

calls. These Functions are dependent on

your service provider. Please check with

your service provider for more

information.

§Menu§ ¢Z ¢Duration/charges

Select function: Last call, All outg. calls,

All incoming calls, Remain. units,

Charge setting.

Voice message/

mailbox

§Menu§ ¢] ¢Message setup

¢Voice message

Most service providers offer a mailbox, in

which a caller may leave a voice message

for you

• if your phone is switched off or not

ready to receive,

• if you do not want to answer,

• if you are making a phone call (and Call

waiting is not activated, p. 22).

You may have to register for this service

with the service provider and enter the

settings manually.

left page (18) of AX75_Pegasus, fcc, us-en, (31.05.2005, 09:05)

SMS

VAR Language: am; VAR issue date: 050309

Settings b

The service provider supplies you with

two phone numbers:

Save mailbox number

Call this phone number to listen to the

voice messages left for you.

§Menu§ ¢] ¢Message setup ¢Voice

message ¢J (enter mailbox number)

¢§OK§.

Save call divert number

Calls are diverted to this phone number

(see also p. 22).

§Menu§ ¢m ¢Phone setup ¢Forward

¢e.g., Unanswered ¢Set ¢J (dial

divert number) ¢§OK§ (register number

at the network). Divert will be confirmed

after a few seconds (see also p. 22).

Listening to message b

A new voice message can be announced

as follows: An \ icon with beep or …

a text message announces a new voice

mail or you receive a call with an

automatic announcement. Dial into your

mailbox and listen to your message(s).

Press and hold 1 (if necessary enter mail-

box number once only). Confirm with §OK§

and §Mailbox§ depending on your service

provider.

CB services b

§Menu§ ¢] ¢Message setup

¢CB services

Some service providers offer information

services (info channels). If reception is ac-

tivated, your "Topic list" will supply you

with messages on the activated topics.

SMS

You can transmit and receive very long

messages (up to 760 characters) on your

phone. They are automatically composed

of several "normal" SMS messages (note

higher charges).

Additionally you can insert pictures and

sounds in an SMS.

Writing and sending

§Menu§ ¢] ¢New SMS ¢J

(write text) ¢A ¢·/J(enter

phone number or select from Address-

book/Phonebook) ¢§OK§.

The SMS is sent to the service centre for

transmission.

For Text input using "T9", p. 15. Press

§Clear§ briefly to delete letter by letter, press

and hold to delete an entire word.

Special functions

SMS to group

You can send an SMS message as a

"circular" to a recipient group.

§Options§ ¢Send ¢§Group§ ¢Select

group ¢Select group members and

send SMS.

Picture&sound

Insert pictures and sounds into message.

§Options§ ¢Picture&sound ¢select sec-

tion and entry.

The menu contains:

Def animations, Def. sounds, Own anim.,

Own pictures, Own sounds

Receive/read SMS

An arrival of a new SMS is announced on

display with …. To read the SMS, press

left soft key.

With G you scroll through message line

by line. Select §Reply§ for a direct reply.

SMS archive

§Menu§ ¢] ¢SMS archive

The list of SMS messages stored in the

phone is displayed.

right page (19) of AX75_Pegasus, fcc, us-en, (31.05.2005, 09:05)

MMS

VAR Language: am; VAR issue date: 050309

MMS

The Multimedia Messaging Service en-

ables you to send texts, pictures (also

photos) and sounds in a combined mes-

sage to another mobile phone or to an

e-mail address. All elements of an MMS

message are merged to form a "slide

show".

Depending on your phone's settings, you

will receive either the complete message

automatically or notification that an MMS

has been saved in the network, giving

sender and size details. You may then

download it to your phone to read it.

Ask your service provider whether this

service is available. You may need to reg-

ister for this service separately.

Writing/sending MMS messages

An MMS consists of the address header

and the content.

§Menu§ ¢] ¢New MMS

Input fields:

To: ·/J Phone number /

e-mail address of recipient(s).

Subject: Enter MMS heading (up to

40 characters).

Picture: §Insert§. The picture list is opened

for selection.

Text: §Edit§. Write text with the help

of T9.

Sound: §Insert§. Select a melodie (p. 26)

or record a new melody (see

below).

Slide duration:

Enter length of display

for individual pages (minimum

0.1 seconds).

New recording

The phone records via its microphone.

Press §Insert§ in the Sound: field when com-

pleting the input fields. Select New ring

tone. Press §Record§. The current recording

duration and available time remaining are

displayed. To end recording press §Stop§.

Press §Play§ to replay recording. Press §Save§.

To give the recording its own name, the

description §Clear§. Confirm with §OK§.

Attach extra pages

§Options§ ¢New slide

Attach business card

§Options§ ¢Extras ¢G Scroll to

Business card ¢·.

Attach appointment

§Options§ ¢Extras ¢G Scroll to

Appointment ¢·.

Send MMS

§Options§ ¢Send

Sending a photo by MMS

You can easily send a photo as an MMS

immediately after taking it with the

"QuickPic" camera.

§Menu§ ¢ ¢Camera ¢§Options§

¢Send via MMS ¢§Selection§ (select the

desired resolution) ¢§Skip§ (skip record-

ing a melody p. 19).

The MMS Editor starts. Simply complete

the following input fields:

To: · /J Telephone number /

e-mail address of the recipient/s.

Subject: Title of the MMS (maximum of

40 characters).

The MMS is now ready to send:

§Options§ ¢Send

Receive/read MMS

An arrival of a new MMS/notification of

an MMS is announced on display with

… / Û. Press the left soft key to read

the MMS or notification.

Depending on the setting, the

• complete MMS is received

• or the notification is opened. Press

§Receiving§ to receive the complete

MMS, with §Play§ automatic presenta-

tion of the MMS. Cancel using any key.

left page (20) of AX75_Pegasus, fcc, us-en, (31.05.2005, 09:05)

Message setup

VAR Language: am; VAR issue date: 050309

• Open attachments using §Options§ and

Attachments.

• Open images and tones using §Options§

and Content.

Message setup

§Menu§ ¢] ¢Message setup ¢SMS

profiles/MMS profiles

Profiles have to be created for SMS and

MMS. The transmission characteristics are

defined in these. The data for these may

already have been entered. If not, you can

obtain this from your service provider. Ad-

ditional information is available in the

comprehensive operating instructions on

the Internet: www.siemens.com/ax75

Ring tones

§Menu§ ¢ ¢Select function.

You can set the ring tone separately for

call types/functions. You can download

new ringtones from the internet via

Download new.

Volume

Set different volumes for types of

call/functions.

Please make sure you have accepted the call

before holding the phone to your ear. This will

avoid damage to your hearing from loud ring

tones.

Surf & fun

Internet browser

§Menu§ ¢É ¢Select function.

Get the latest information from the Inter-

net that is specifically adapted to the

display options of your phone. In addi-

tion, you can download games and appli-

cations to your phone. Internet access

may require registration with the service

provider.

End connection

Press and hold B to close the browser.

After GPRS/CSD lingertime (WAP param)

the connection will also be ended.

Additional information

ÍBrowser menu.

ÉOffline.

ÊOnline.

ËGPRS Online.

ÌNo network.

*Select special characters, such as

@, ~, \, see p. 15.

0Press repeatedly for:

. , ? ! ’ " 0 - ( ) @ / : _

Profiles

§Menu§ ¢É ¢Internet ¢Profiles

Activate profile

You can change the current profile each

time you access the Internet. For this, se-

lect profile, then §Selection§. The current

profile is selected.

right page (21) of AX75_Pegasus, fcc, us-en, (31.05.2005, 09:05)

Setup

VAR Language: am; VAR issue date: 050309

Games & more

Applications and games can be found at

wap.siemens.com or on the Internet at

www.siemens.com/ax75

Setup

Profiles

§Menu§ ¢m ¢Profiles

Several settings can be stored in a phone

profile in order, for example, to adapt the

phone to the surrounding level of noise.

Airplane mode

Sound for all alarms (appointments,

alarm clock) are deactivated. Alarms are

only indicated on the display. This profile

cannot be modified. The phone will switch

off if you select the profile Airplane mode.

Confirm a security prompt.

Normal mode

When you switch on your phone again,

the previously set profile will be reactivat-

ed automatically.

Display

§Menu§ ¢m ¢Display

¢Select function.

Language

Set the language of the display text.

When "automatic" is set, the language of

your service provider is used. Reset to this

language in standby mode:

*  0 0 0 0  A

More settings...

Wallpaper, Logo, Color scheme, Screensaver,

Start up animation, Shut down animation,

Greeting, Large letters, Illumination, Contrast.

Call setup

§Menu§ ¢m ¢Call setup

¢Select function.

Hide ID b

When you make a call, your phone num-

ber can be displayed on the recipient's dis-

play (depending on the service providers).

Additional information

You can use the browser to download applica-

tions (e.g. ringtones, games, pictures, anima-

tions) from the Internet.

Siemens excludes all warranty and liability claims

in respect of or in connection with any applica-

tions subsequently installed by the customer and

any software not included in the original delivery

package. This also applies to functions enabled

subsequently at the customer's instigation. The

purchaser bears sole risk for the loss of, damage

to, and any defects arising in, this device or the

applications and for any direct damage or conse-

quential damage of whatever nature resulting

from the use of this application. For technical rea-

sons, such applications and subsequent enabling

of certain functions are lost in the event of the de-

vice being replaced/re-supplied and may be lost if

it is repaired. In such cases, the buyer is required

to download or enable the application again.

Please ensure that your phone has Digital Rights

Management (DRM) so that downloaded applica-

tions are protected from unauthorised reproduc-

tion. These applications are then exclusively

intended for your phone and cannot be trans-

ferred from this even to create a backup. Siemens

offers no warranty or guarantee nor does it accept

any liability for the customer's ability to download

or enable applications again or to do so free of

charge. We recommend that you carry out a

backup from time to time of the applications on

your Windows® PC using the Siemens Data

Exchange Software (to download from the

Internet: www.siemens.com/ax75

left page (22) of AX75_Pegasus, fcc, us-en, (31.05.2005, 09:05)

Setup

VAR Language: am; VAR issue date: 050309

Call waiting b

If you are registered for this service, you

can check whether it is set and you can

activate/deactivate it.

Forward b

You can specify when calls should

be diverted to your mailbox or other

numbers.

•Unanswered

•All calls

• Status check

• Clear all

Minute beep

During a call, you will hear a beep after

each minute as a reminder of the time

elapsed. The recipient does not hear this

beep.

Clock

§Menu§ ¢m ¢Clock ¢Select function.

Time/date

The clock must be set to the right time

once at start-up.

§Change§ ¢Enter the date first, then the

time.

Time zones

Set the time zone for your area.

Time format

Select 24h or 12h.

Date format

DD.MM.YYYY or MM/DD/YYYY

Buddhist year

Switch to the Buddhist year (not on all

phone models).

Show clock

Activate/deactivate time display in stand-

by mode.

Automatic switch off

The phone switches off each day at the

set time.

Connectivity

§Menu§ ¢m ¢Connectivity

¢Select function.

GPRS b

§Yes§ / §No§ Switch GPRS function on/off.

GPRS info

Display of information on connection

status.

IrDA

Your phone has an infrared interface.

With this interface, you can exchange

data such as pictures, ringtones and

phonebook entries with other appliances

which also have an infrared interface. The

distance between two devices must not

exceed 30 cm/12 inches. The infrared

windows in both devices must be aligned

as accurately as possible with each other.

Authentication

D Activate or deactivate encrypted In-

ternet dial-up (CSD connections only).

Data services

§Menu§ ¢m ¢Connectivity

¢Select function.

For the MMS, WAP and HTTP applications

at least one connection profile must be

set up and activated.

The default for the phone depends on

each service provider.

If necessary, check with your service pro-

vider for details. If necessary enter CSD

settings and GPRS settings (your service

provider will supply you with information

on this if necessary or

www.siemens.com/

mobilephonescustomercare in the

FAQ section).

Select profile ¢D ¢Change sett.

¢§Options§ ¢§Edit§ ¢(Enter data)

¢§Save§.

right page (23) of AX75_Pegasus, fcc, us-en, (31.05.2005, 09:05)

Setup

VAR Language: am; VAR issue date: 050309

HTTP profile

Select profile with G. Enter or modify

settings. If necessary, check with your ser-

vice provider for details.

Security

§Menu§ ¢m ¢Security

¢Select function.

Auto key lock

The keypad is locked automatically if no

key has been pressed for one minute in

standby mode. This prevents the phone

from being used accidentally. However,

you can still be called and you can still

make an emergency call.

Babysitter

(Phone-code protected)

Only one phone number can be dialled.

Only ‚ b

(PIN2 protected)

Restrict calls to SIM-protected numbers in

the Phonebook.

Last 10 only

(Phone-code protected)

Restrict calls to the list of "dialled

numbers" (p. 17).

Codes

PIN control, Change PIN, Change PIN2,

Change phonecode, (p. 13).

This SIM only b

(Phone-code protected)

Your phone is prevented from being used

with a different SIM card.

Barring b

Network barring restricts the use of your

SIM card.

Phone identity

The phone identity number (IMEI)

is displayed. This information may be use-

ful for customer service.

Alternative input in standby mode:

*  0 6 

File system

Format

The file system memory (p. 26) is format-

ted and all data that has been saved is

deleted, including e.g. ringtones, images,

games etc.

Clean up

The file system is defragmented.

Master reset

The phone is reset to the default values

(factory setting) (does not apply to SIM

card or network settings).

Alternative input in standby mode:

*  9 9 9 9  A

Network

§Menu§ ¢m ¢Network

¢Select function.

Line b

Choose between two independent

telephone numbers.

Network info

A list of GSM networksis displayed.

Auto network selection

Choose network

Network search is restarted.

Preferred network

Set the service providers you prefer when

you leave your home network.

Band selection

Fast search

User group b

Depending on service provider, you can

create groups with this service.

left page (24) of AX75_Pegasus, fcc, us-en, (31.05.2005, 09:05)

Organizer

VAR Language: am; VAR issue date: 050309

Accessories

§Menu§ ¢m ¢Accessories

¢Select function.

Car Kit

Auto answer

Calls are accepted automatically after a

few seconds.

Headset

Accept call with Call key or PTTkey

(Push to Talk), even when the keylock

is activated.

Auto answer

Calls are accepted automatically after a

few seconds.

Organizer

§Menu§ ¢ç ¢Select function.

Alarm clock

The alarm will ring at the time set by you,

even when the phone is switched off. If

the phone has been switched off in Air-

plane mode the alarm is only shown on

the display and is not indicated by sound.

Setting

Set the time for the alarm call (hh:mm).

Confirm with §OK§.

Press §On/off§ to activate/deactivate the alarm.

Calendar

You can enter appointments in the calen-

dar. Time and date must be set for the cal-

endar to work correctly (p. 22).

Page between days with H. Press G

briefly to page between weeks, press and

hold G to page between months. Calen-

dar days in bold face indicate appoint-

ments on this day.

Agenda

Press §Agenda§ to call up from the monthly

overview. Appointments for each individ-

ual day are shown in the agenda in chro-

nological order.

Appointments

§Menu§ ¢ç ¢Appointments

All appointment entries are displayed in

chronological order. If an alarm is missed

it appears in the list of missed

appointments (p. 25).

Enter new appointment

PressD.

Select the Type of your appointment. Add

Description, Date and Time.

Alarm:

Activate alarm with §ON§ ¢J (enter start

time of the alarm before the appointment)

¢§Change§ (select Minutes, Hours, Days).

Recurrence:

Select a timeframe for repeating the

appointment: No, Daily, Weekly, Monthly,

Annual.

Enter a parameter for repeating: Forever,

Until, Events (number).

If Weekly is selected, certain weekdays can

be highlighted.

Alarm

When the set date and time are reached

there is an audible and a visual alarm.

Alarm type Memo/Meeting: the text is

shown in the display.

Alarm type Call: The phone number is dis-

played and can be dialled immediately.

Alarm type Birthday and Anniversary: you

will be notified one day before the event

and on the birthday/ anniversary itself.

Press §Pause§. The alarm stops for

5 minutes. Press §Off§ to stop the alarm.

Notes

§Menu§ ¢ç ¢Notes

T9 support (p. 15) makes writing short

notes such as shopping lists easier.

right page (25) of AX75_Pegasus, fcc, us-en, (31.05.2005, 09:05)

Extras

VAR Language: am; VAR issue date: 050309

Missed alarms

§Menu§ ¢ç ¢Missed alarms

Events with an alarm to which you have

not reacted are listed for reading.

Time zones

§Menu§ ¢ç ¢Time zones

Set the time zone for your area.

Calend. setup

§Menu§ ¢ç ¢Calend. setup

Start of week

You can set which weekday is listed first

on the left in the monthly and weekly

overviews.

Extras

SIM services (optional)

§Menu§ ¢ ¢SIM services

Your service provider may offer special

applications such as mobile banking,

share prices, etc. via the SIM card.

If you have such a SIM card, the SIM ser-

vices will appear in the main menu under

"Extras" or directly above the left soft key

with symbol }.

For further information, please contact

your service provider.

Calculator

§Menu§ ¢ ¢Calculator ¢Enter num-

ber (up to 8 digits) ¢§.§=§+§-§*§/§ Select cal-

culator function.

Repeat procedure with other numbers.

Press  to display result.

Calculator functions

§.§=§+§-§*§/§ Press right soft key repeatedly.

±Toggle between "+" and "-".

%Convert to percentage.

Ï,,/ÐSave /Retrieve number.

eExponent (max. two digits).

Special keys:

*Set decimal point.

0Add (press and hold).

Currency conv

§Menu§ ¢ ¢Currency conv

Calculate the exchange rates. You can en-

ter three currencies.

If no currency has yet been entered, press

§OK§ for the first input.

Otherwise:

§Options§ ¢New entry ¢Enter symbols for

the currencies ¢§OK§ ¢Enter exchange

rate ¢Save with §Options§ and §OK§.

Stopwatch

§Menu§ ¢ ¢Stopwatch

Two intermediate times can be recorded

and saved.

Press  for Start/stop. Press * for Interme-

diate time. Press §Start§ to start stopwatch.

Press §Reset§ to reset stopwatch.

Countdown

§Menu§ ¢ ¢Countdown

A set time elapses. The last 3 seconds are

indicated by a beep. At the end a special

beep sounds.

Voice command

§Menu§ ¢ ¢Voice command

Functions can be started by a voice com-

mand. Up to 20 voice recordings can be

saved in the phone for voice dialling or

voice commands (not on SIM card!).

Record

§Menu§ ¢ ¢Voice command

A list with the functions available is dis-

played. G Select function. Press §Record§.

Confirm selected function with §Yes§.

Press §Start§ to start recording.

left page (26) of AX75_Pegasus, fcc, us-en, (31.05.2005, 09:05)

Fast access key

VAR Language: am; VAR issue date: 050309

A short signal sounds. Now say the com-

mand corresponding to the function and

repeat it when prompted.

Apply

Press and hold E (in standby mode).

A short signal (beep) sounds and a

prompt appears in the display.

Now say the function. Noisy environ-

ments may affect voice recognition.

Fast access key

The left soft key and the number keys 2 to

9 (speed dialling numbers) can each be

assigned an important phone number or

a function. The phone number can then

be dialled or the function started at the

touch of a button.

Left soft key

Assign a function/phone number to the

left soft key for fast access.

Change (example)

§New SMS§ ¢§Change§ ¢Search for appli-

cation (e.g., Internet, Phone number)

¢§Selection§.

Apply (example)

Key assigned with Phone number/name.

Press and hold §Carol§.

Speed dialling keys

Only possible for keys 2 to 9. Key 1 is

reserved for the mailbox.

Change

J Press an unassigned numberkey

(2- 9) ¢§Set§ Select application (e.g. New

SMS, Phone number, Bookmarks).

Apply

Press and hold assigned numberkey,

e.g. 3.

Menu speed dialling

All menu functions are numbered inter-

nally. A function may be selected directly

by entering these numbers in sequence.

Example:

Press §Menu§. Press e.g. 2 for Records or 1

for Missed calls.

Own stuff

§Menu§ ¢Ñ

Files and folders are displayed. The fol-

lowing folders are provided for organising

your files: Pictures, Sounds, Colour

scheme, Data inbox.

Sending files

Press A to send a highlighted picture,

sound, animation etc.

right page (27) of AX75_Pegasus, fcc, us-en, (31.05.2005, 09:05)

Customer Care

VAR Language: am; VAR issue date: 050309

Customer Care

In some countries repair and replace services are

impossible where the products are not sold through

our authorised dealers.

If repair work is necessary, please contact one of

our service centres:

Abu Dhabi .........................................0 26 42 38 00

Argentina .....................................0 80 08 88 98 78

Australia..........................................13 00 66 53 66

Austria.............................................05 17 07 50 04

Bahrain .................................................... 40 42 34

Bangladesh.......................................0 17 52 74 47

Belgium.............................................0 78 15 22 21

Bolivia ...............................................0 21 21 41 14

Bosnia Herzegovina..........................0 33 27 66 49

Brunei ..................................................02 43 08 01

Bulgaria................................................02 73 94 88

Cambodia ............................................12 80 05 00

Canada ........................................1 88 87 77 02 11

Chile..................................................8 00 53 06 62

China ...........................................0 21 23 01 71 88

Colombia....................................01 80 07 00 66 24

Croatia ..............................................0 16 10 53 81

Czech Republic.................................2 33 03 27 27

Denmark ..............................................35 25 86 00

Dubai ................................................0 43 96 64 33

Ecuador ..........................................18 00 10 10 00

Egypt.................................................0 23 33 41 11

Estonia.................................................. 6 30 47 97

Finland............................................09 22 94 37 00

France.............................................01 56 38 42 00

Germany ......................................0 90 01 00 77 00

Greece ............................................80 11 11 11 16

Hong Kong.......................................... 28 61 11 18

Hungary ..........................................06 14 71 24 44

Iceland .................................................. 5 11 30 00

India.............................22 24 98 70 00 Extn: 70 40

Indonesia .....................................0 21 46 82 60 81

Ireland.............................................18 50 77 72 77

Italy .................................................02 24 36 44 00

Ivory Coast.......................................... 05 02 02 59

Jordan...............................................0 64 39 86 42

Kenya.................................................... 2 72 37 17

Kuwait ................................................... 2 45 41 78

Latvia .................................................... 7 50 11 18

Lebanon.............................................. 01 44 30 43

Libya ...............................................02 13 50 28 82

Lithuania ...........................................8 70 07 07 00

Luxembourg........................................ 43 84 33 99

Macedonia .......................................... 02 13 14 84

Malaysia....................................+ 6 03 77 12 43 04

Malta.......................................+ 35 32 14 94 06 32

Mauritius ............................................... 2 11 62 13

Mexico .......................................01 80 07 11 00 03

Morocco .............................................. 22 66 92 09

Netherlands .................................0 90 03 33 31 00

New Zealand...................................08 00 27 43 63

Nigeria ..............................................0 14 50 05 00

Norway................................................ 22 70 84 00

Oman ....................................................... 79 10 12

Pakistan ..........................................02 15 66 22 00

Paraguay ..........................................8 00 10 20 04

Peru ..................................................0 80 05 24 00

Philippines ........................................0 27 57 11 18

Poland.............................................08 01 30 00 30

Portugal ............................................8 08 20 15 21

Qatar................................................... 04 32 20 10

Romania .........................................02 12 09 99 66

Russia..........................................8 80 02 00 10 10

Saudi Arabia .....................................0 22 26 00 43

We offer fast, individual advice! You have

several options:

Our online support on the Internet:

www.siemens.com/

mobilephonescustomercare

We can be reached any time, any place. You are

given 24 hour support on all aspects of our prod-

ucts. Here you will find an interactive fault-finding

system, a compilation of the most frequently

asked questions and answers, plus user guides

and current software updates to download.

When calling customer service, please have

ready your receipt and the phone identity num-

ber (IMEI, to display press *#06#), the software

version (to display, press *#06#, then §Info§) and

if available, your Siemens Service customer

number.

left page (28) of AX75_Pegasus, fcc, us-en, (31.05.2005, 09:05)

Care and maintenance

VAR Language: am; VAR issue date: 050309

Serbia .............................................01 13 07 00 80

Singapore ............................................62 27 11 18

Slovak Republic ..............................02 59 68 22 66

Slovenia............................................0 14 74 63 36

South Africa ....................................08 60 10 11 57

Spain.................................................9 02 11 50 61

Sweden.............................................0 87 50 99 11

Switzerland .....................................08 48 21 20 00

Taiwan ............................................02 23 96 10 06

Thailand............................................0 27 22 11 18

Tunisia .................................................71 86 19 02

Turkey..........................................0 21 64 59 98 98

Ukraine ........................................8 80 05 01 00 00

United Arab Emirates........................0 43 66 03 86

United Kingdom ...........................0 87 05 33 44 11

USA .............................................1 88 87 77 02 11

Venezuela....................................0 80 01 00 56 66

Vietnam...........................................84 89 20 24 64

Zimbabwe ............................................04 36 94 24

Care and maintenance

Your phone has been designed and manufactured

to the highest of standards and should be treated

with great care. The suggestions below will help

you to enjoy your phone for many years.

• Protect your phone from moisture and humidity!

Precipitation, humidity and liquids contain min-

erals that will corrode electronic circuits. Should

your phone nonetheless become wet, discon-

nect it immediately from any power supply, re-

move the battery and leave the open phone to

dry at room temperature!

• Do not use or store the phone in dusty, dirty ar-

eas. Its moving parts may become damaged.

• Do not store your phone in hot areas. High tem-

peratures can shorten the life of electronic de-

vices, damage batteries and warp or melt

certain plastics.

• Do not store your phone in cold areas. When

the phone warms up again (to its normal ambi-

ent temperature), moisture can form inside the

phone, which may damage electronic circuit

boards.

• Do not drop, knock or shake your phone. Rough

handling can damage internal circuit boards!

• Do not use harsh chemicals, cleaning solvents,

or strong detergents to clean the phone!

The suggestions given above apply equally to your

phone, battery, charger and all accessories. If any

of these parts are not working properly, take them

to your nearest qualified service outlet. The per-

sonnel there will assist you and, if necessary, re-

pair the device.

right page (29) of AX75_Pegasus, fcc, us-en, (31.05.2005, 09:05)

Product data

VAR Language: am; VAR issue date: 050309

Battery quality declaration

The capacity of your mobile phone battery is re-

duced each time you charge/discharge it. Storing

the battery at temperatures that are too high or too

low also causes a gradual loss of capacity. This

can significantly reduce the operating times of your

mobile phone, even after it has been fully charged.

The battery is, however, designed to be capable of

being charged and discharged for a period of six

months from when the mobile phone was pur-

chased. Following this six-month period, we rec-

ommend replacing your battery if you experience a

significant drop in performance. Only purchase

original Siemens batteries.

Display quality declaration

For technological reasons, a few small dots with

different colours may appear in the display in ex-

ceptional cases.

Please note that the appearance of brighter or

darker dots generally does not mean that a fault

has occurred.

Product data

Declaration of conformity

Siemens Information and Communication mobile

hereby declares that the phone described in this

user guide is in compliance with the essential re-

quirements and other relevant provisions of Euro-

pean Directive 1999/5/EC (R&TTE). The

declaration of conformity (DoC) concerned has

been signed. Please call the company hotline if you

require a copy of the original or:

www.siemens.com/mobiledocs

Technical data

GSM class: 4 (2 watt)

Frequency range: 880-960 MHz

GSM class: 1 (1 watt)

Frequency range: 1,710-1,880 MHz

GSM class: 1 (1 watt)

Frequency range: 1,850-1,990 MHz

Weight: 76 g

Size: 105.6x 46.8x 17.5 mm

(75 cm3)

Li-ion battery: 600 mAh

Operating temperature: -10 °C… +55 °C

SIM card: 3.0 V or 1.8 V

left page (30) of AX75_Pegasus, fcc, us-en, (31.05.2005, 09:05)

Accessories

VAR Language: am; VAR issue date: 050309

Operating time

The operating time depends upon usage: Extreme

temperatures considerably reduce the phone’s

standby time. You should therefore avoid the leav-

ing the phone in the sun or on a radiator.

Talk time: 90 to 300 minutes.

Standby time: 50 to 220 hours.

Accessories

Available Accessories are:

Fashion & Carry

Tour Case FCT-650

Belt Case FCL-600

Energy

Li-Ion Battery 600 mAh EBA-670

Travel Charger EU ETC-500

Travel Charger UK ETC-510

Car Charger Plus ECC-600

Car Charger ECC-500

Desk Top Stand EDS-600

Handsfree portable

Headset Basic HHS-500

Headset HHS-510

Headset Purestyle HHS-610

Office

Data Cable DCA-500

Data Cable USB DCA-510

Multitainment

Quick Pic Camera IQP-500

Car Solutions

Car Kit Portable HKP-500

Car Kit Easy HKP-700

Car Kit Easy Upgrade HK0-700

Products can be obtained in specialist

shops or you can visit the Siemens Mobile

Store online:

Phone ID

You will need the following details if you lose your

phone or SIM card:

the number of the SIM card (on the card):

..............................................................

15-digit serial number of the phone

(under the battery):

..............................................................

the customer service number of the service

provider:

..............................................................

Lost phone

If you lose your phone or SIM card contact your

service provider immediately to prevent misuse.

Action taken Time

(min)

Reduces standby

time by

Calling 1 30 - 90 minutes

Light * 1 60 minutes

Network search 1 5 -10 minutes

* Keypad input, dynamic light games, organiser,

etc.

Siemens Original Accessories

www.siemens.com/shop

right page (31) of AX75_Pegasus, fcc, us-en, (31.05.2005, 08:54)

SAR (AX75)

VAR Language: am; VAR issue date: 050309

SAR (AX75)

RF EXPOSURE/SPECIFIC ABSORPTION RATE

(SAR) INFORMATION

THIS SIEMENS AX75 PHONE MEETS THE

GOVERNMENT'S REQUIREMENTS FOR

EXPOSURE TO ELECTROMAGNETIC FIELDS.

Your cell phone is a radio transmitter and

receiver. It is designed and manufactured

not to exceed the emission limits for ex-

posure to radio frequency (RF) energy es-

tablished by the Federal Communications

Commission (FCC) of the U.S. Govern-

ment and by Health Canada. These limits

are part of comprehensive guidelines and

establish permitted levels of RF energy for

the general population. The guidelines

were developed and confirmed by inde-

pendent scientific organizations through

periodic and thorough evaluation of sci-

entific studies*. The limits include a sub-

stantial safety margin designed to assure

the safety of all persons, regardless of age

and health.

The exposure standard for cell phones

employs a unit of measurement known as

the Specific Absorption Rate, or SAR. The

SAR limit established by the FCC and by

Health Canada is 1.6 W/kg**. Tests for

SAR are conducted using standard operat-

ing positions accepted by the FCC and by

Industry Canada with the phone transmit-

ting at its highest certified power level in

all tested frequency bands. Although the

SAR is determined at the highest certified

power level, the actual SAR level of the

phone while operating can be well below

the maximum value. This is because the

phone is designed to operate at multiple

power levels so as to use only the power

required to reach the network. In general,

the closer you are to a wireless base sta-

tion, the lower the power output.

Before a phone model is available for sale

to the public, it must be tested and the

manufacturer must certify to the FCC and

Industry Canada that it does not exceed

the limit established by each government

for safe exposure. The tests are performed

in positions and locations (e.g., at the ear

and worn on the body), reported to the

FCC and available for review by Industry

Canada. The highest SAR value for this

Siemens AX75 when tested for use at

the ear is

0.42 W/kg***

and when worn on the body+ is

0.28 W/kg***

Additional information on Specific Ab-

sorption Rates (SAR) can be found on the

Cellular Telecommunications Internet As-

sociation (CTIA) web-site at

www.phonefacts.net or the Canadian Wire-

less Telecommunications Association

(CWTA) website www.cwta.ca

SAR information on this Siemens AX75

phone is on file with the FCC and can be

found under the Display Grant section of

www.fcc.gov/oet/fccid.

While there may be differences between

the SAR levels of various phones and at

various positions, all Siemens products

meet the governmental requirements for

safe RF exposure.

+ For body worn operation, this mobile phone has

been tested and meets FCC RF exposure

guidelines when used with a Siemens accesso-

ry designated for this product, where available,

or when used with a carry accessory that con-

tains no metal and that positions the handset at

least 1.50 cm/0.59 inch is the correct testing

distance from the body. Use of other carry ac-

cessories may not ensure compliance with FCC

RF exposure guidelines.

left page (32) of AX75_Pegasus, fcc, us-en, (31.05.2005, 08:54)

SAR (AX75)

VAR Language: am; VAR issue date: 050309

* The World Health Organization (WHO,

CH-1211 Geneva 27, Switzerland), on the basis

of the actual knowledge, does not see any ne-

cessity for special precautionary measures

when using cell phones.

Further information:

www.who.int/peh-emf

www.mmfai.org

www.siemens.com/mobilephones

** averaged over 1 g of tissue.

*** SAR values may vary depending on national re-

quirements and network bands. SAR informa-

tion for different regions can be found at

www.siemens.com/mobilephones

right page (33) of AX75_Pegasus, fcc, us-en, (31.05.2005, 08:47)

U.S. FDA

VAR Language: am; VAR issue date: 050309

U.S. FDA

The U.S. Food and Drug Administration's

(FDA) Center for Devices and Radiologi-

cal Health Consumer Update on Mobile

Phones

FDA has been receiving inquiries about

the safety of mobile phones, including

cellular phones and PCS phones. The fol-

lowing summarizes what is know – and

what remains unknown – about whether

these products can pose a hazard to

health, and what can be done to mini-

mize any potential risk. This information

may be used to respond to questions.

Why the concern?

Mobile phones emit low levels of radio

frequency energy (i.e., radio frequency

radiation) in the microwave range while

being used. They also emit very low levels

of radio frequency energy (RF), consid-

ered non-significant, when in the stand-

by mode. It is well known that high levels

of RF can produce biological damage

through heating effects (this is how your

microwave oven is able to cook food).

However, it is not known whether, to

what extent, or through what mecha-

nism, lower levels of RF might cause ad-

verse health effects as well. Although

some research has been done to address

these questions, no clear picture of the bi-

ological effects of this type of radiation

has emerged to date. Thus, the available

science does not allow us to conclude

that mobile phones are absolutely safe, or

that they are unsafe. However, the avail-

able scientific evidence does not demon-

strate adverse health effects associated

with the use of mobile phones.

What kinds of phones are in question?

Questions have been raised about hand-

held mobile phones, the kind that have a

built-in antenna that is positioned close

to the user's head during normal tele-

phone conversation. These types of mo-

bile phones are of concern because of the

short distance between the phone's an-

tenna – the primary source of the RF –

and the person's head. The exposure to

RF from mobile phones in which the an-

tenna is located at greater distances from

the user (on the outside of a car, for ex-

ample) is drastically lower than that from

hand-held phones, because a person's RF

exposure decreases rapidly with distance

from the source. The safety of so-called

“cordless phones,” which have a base unit

connected to the telephone wiring in a

house and which operate at far lower

power levels and frequencies, has not

been questioned.

How much evidence is there that hand-held mo-

bile phones might be harmful?

Briefly, there is not enough evidence to

know for sure, either way; however, re-

search efforts are on-going. The existing

scientific evidence is conflicting and

many of the studies that have been done

to date have suffered from flaws in their

research methods. Animal experiments

investigating the effects of RF exposures

characteristic of mobile phones have

yielded conflicting results. A few animal

studies, however, have suggested that

low levels of RF could accelerate the de-

velopment of cancer in laboratory ani-

mals. In one study, mice genetically al-

tered to be predisposed to developing

one type of cancer developed more than

twice as many such cancers when they

were exposed to RF energy compared to

controls. There is much uncertainty

among scientists about whether results

obtained from animal studies apply to the

use of mobile phones. First, it is uncertain

how to apply the results obtained in rats

and mice to humans. Second, many of

the studies showed increased tumor de-

left page (34) of AX75_Pegasus, fcc, us-en, (31.05.2005, 08:47)

U.S. FDA

VAR Language: am; VAR issue date: 050309

velopment used animals that had already

been treated with cancer-causing chemi-

cals, and other studies exposed the ani-

mals to the RF virtually continuously – up

to 22 hours per day.

For the past five years in the United

States, the mobile phone industry has

supported research into the safety of mo-

bile phones. This research has resulted in

two findings in particular that merit addi-

tional study:

1. In a hospital-based, case-control study,

researchers looked for an association be-

tween mobile phone use and either glio-

ma (a type of brain cancer) or acoustic

neuroma (a benign tumor of the nerve

sheath). No statistically significant associ-

ation was found between mobile phone

use and acoustic neuroma. There was

also no association between mobile

phone use and gliomas when all types of

gliomas were considered together. It

should be noted that the average length

of mobile phone exposure in this study

was less than three years.

When 20 types of glioma were considered

separately, however, an association was

found between mobile phone use and

one rare type of glioma, neuroepithel-

liomatous tumors. It is possible with mul-

tiple comparisons of the same sample

that this association occurred by chance.

Moreover, the risk did not increase with

how often the mobile phone was used, or

the length of the calls. In fact, the risk ac-

tually decreased with cumulative hours of

mobile phone use. Most cancer causing

agents increase risk with increased expo-

sure. An ongoing study of brain cancers

by the National Cancer Institute is expect-

ed to bear on the accuracy and repeat-

ability of these results.1

2. Researchers conducted a large battery

of laboratory tests to assess the effects of

exposure to mobile phone RF on genetic

material. These included tests for several

kinds of abnormalities, including muta-

tions, chromosomal aberrations, DNA

strand breaks, and structural changes in

the genetic material of blood cells called

lymphocytes. None of the tests showed

any effect of the RF except for the micro-

nucleus assay, which detects structural ef-

fects on the genetic material. The cells in

this assay showed changes after exposure

to simulated cell phone radiation, but

only after 24 hours of exposure. It is pos-

sible that exposing the test cells to radia-

tion for this long resulted in heating.

Since this assay is known to be sensitive

to heating, heat alone could have caused

the abnormalities to occur. The data al-

ready in the literature on the response of

the micronucleus assay to RF are conflict-

ing. Thus follow-up research is

necessary.2

FDA is currently working with govern-

ment, industry, and academic groups to

ensure the proper follow-up to these in-

dustry-funded research findings. Collabo-

ration with the Cellular Telecommunica-

tions Industry Association (CTIA) in

particular is expected to lead to FDA pro-

viding research recommendations and sci-

entific oversight of new CTIA-funded re-

search based on such recommendations.

Two other studies of interest have been

reported recently in the literature:

• Two groups of 18 people were exposed

to simulated mobile phone signals un-

der laboratory conditions while they

performed cognitive function tests.

There were no changes in the subjects'

ability to recall words, numbers, or pic-

tures, or in their spatial memory, but

they were able to make choices more

quickly in one visual test when they

were exposed to simulated mobile

phone signals. This was the only

change noted among more than

20 variables compared.3

• In a study of 209 brain tumor cases and

425 matched controls, there was no in-

creased risk of brain tumors associated

with mobile phone use. When tumors

did exist in certain locations, however,

right page (35) of AX75_Pegasus, fcc, us-en, (31.05.2005, 08:47)

U.S. FDA

VAR Language: am; VAR issue date: 050309

they were more likely to be on the side

of the head where the mobile phone

was used. Because this occurred in only

a small number of cases, the increased

likelihood was too small to be statisti-

cally significant.4

In summary, we do not have enough in-

formation at this point to assure the pub-

lic that there are, or are not, any low inci-

dent health problems associated with use

of mobile phones. FDA continues to work

with all parties, including other federal

agencies and industry, to assure that re-

search is undertaken to provide the nec-

essary answers to the outstanding ques-

tions about the safety of mobile phones.

What is known about cases of human cancer

that have been reported in users of hand-held

mobile phones?

Some people who have used mobile

phones have been diagnosed with brain

cancer. But it is important to understand

that this type of cancer also occurs

among people who have not used mobile

phones. In fact, brain cancer occurs in the

U.S. population at a rate of about 6 new

cases per 100,000 people each year. At

that rate, assuming 80 million users of

mobile phones (a number increasing at a

rate of about 1 million per month), about

4800 cases of brain cancer would be ex-

pected each year among those 80 million

people, whether or not they used their

phones. Thus it is not possible to tell

whether any individual's cancer arose be-

cause of the phone, or whether it would

have happened anyway. A key question is

whether the risk of getting a particular

form of cancer is greater among people

who use mobile phones than among the

rest of the population. One way to an-

swer that question is to compare the us-

age of mobile phones among people with

brain cancer with the use of mobile

phones among appropriately matched

people without brain cancer. This is called

a case-control study. The current case-

control study of brain cancers by the Na-

tional Cancer Institute, as well as the fol-

low-up research to be sponsored by in-

dustry, will begin to generate this type of

information.

What is FDA's role concerning the safety of

mobile phones?

Under the law, FDA does not review the

safety of radiation emitting consumer

products such as mobile phones before

marketing, as it does with new drugs or

medical devices. However, the agency

has authority to take action if mobile

phones are shown to emit radiation at a

level that is hazardous to the user. In such

a case, FDA could require the manufactur-

ers of mobile phones to notify users of

the health hazard and to repair, replace or

recall the phones so that the hazard no

longer exists.

Although the existing scientific data do

not justify FDA regulatory actions at this

time, FDA has urged the mobile phone in-

dustry to take a number of steps to assure

public safety. The agency has recom-

mended that the industry:

• Support needed research into possible

biological effects of RF of the type emit-

ted by mobile phones;

• Design mobile phones in a way that

minimizes any RF exposure to the user

that is not necessary for device func-

tion; and

• Cooperate in providing mobile phone

users with the best possible informa-

tion on what is known about possible

effects of mobile phone use on human

health.

• At the same time, FDA belongs to an in-

teragency working group of the federal

agencies that have responsibility for

different aspects of mobile phone safe-

ty to ensure a coordinated effort at the

federal level. These agencies are:

• National Institute for Occupational

Safety and Health

• Environmental Protection Agency

• Federal Communications Commission

left page (36) of AX75_Pegasus, fcc, us-en, (31.05.2005, 08:47)

U.S. FDA

VAR Language: am; VAR issue date: 050309

• Occupational Health and Safety

Administration

• National Telecommunications and In-

formation Administration

The National Institutes of Health also par-

ticipates in this group.

In the absence of conclusive information about

any possible risk, what can concerned individ-

uals do?

If there is a risk from these products – and

at this point we do not know that there is

– it is probably very small. But if people

are concerned about avoiding even po-

tential risks, there are simple steps they

can take to do so. For example, time is a

key factor in how much exposure a per-

son receives. Those persons who spend

long periods of time on their hand-held

mobile phones could consider holding

lengthy conversations on conventional

phones and reserving the hand-held

models for shorter conversations or for

situations when other types of phones

are not available.

People who must conduct extended con-

versations in their cars every day could

switch to a type of mobile phone that plac-

es more distance between their bodies

and the source of the RF, since the expo-

sure level drops off dramatically with dis-

tance. For example, they could switch to:

• a mobile phone in which the antenna is

located outside the vehicle,

• a hand-held phone with a built-in an-

tenna connected to a different antenna

mounted on the outside of the car or

built into a separate package, or

• a headset with a remote antenna to a

mobile phone carried at the waist.

Where can I find additional information?

For additional information, see the fol-

lowing websites:

• Federal Communications Commission

(FCC) RF Safety Program (select “Infor-

mation on Human Exposure to RF

Fields from Cellular and PCS Radio

Transmitters”):

www.fcc.gov/oet/rfsafety

• World Health Organization (WHO) In-

ternational Commission on Non-Ioniz-

ing Radiation Protection (select Qs &

As):

www.who.int/emf

• United Kingdom, National Radiological

Protection Board:

www.nrpb.org.uk

• Cellular Telecommunications Industry

Association (CTIA):

www.wow-com.com

• U.S. Food and Drug Administration

(FDA) Center for devices and Radiolog-

ical Health:

www.fda.gov/cdhr/consumer/

1 Muscat et al. Epidemiological Study of Cellular

Telephone Use and Malignant Brain Tumors. In:

State of the Science Symposium; 1999 June 20;

Long Beach, California.

2 Tice et al. Tests of mobile phone signals for activ-

ity in genotoxicity and other laboratory assays. In:

Annual Meeting of the Environmental Mutagen So-

ciety; March 29, 1999, Washington, DC; and per-

sonal communication, unpublished results.

3 Preece, AW, Iwi, G, Davies-Smith, A, Wesnes, K,

Butler, S, Lim, E, and Varey, A. Effect of a 915-

MHz simulated mobile phone signal on cognitive

function in man. Int. J. Radiat. Biol., April 8, 1999.

4 Hardell, L, Nasman, A, Pahlson, A, Hallquist, A

and Mild, KH. Use of cellular telephones and the

risk for brain tumors; a case-control study. Int. J.

Oncol, 15: 113-116, 1999.

right page (37) of AX75_Pegasus, fcc, us-en, (31.05.2005, 08:47)

FCC/Industry Canada Notice

VAR Language: am; VAR issue date: 050309

FCC/Industry Canada

Notice

Your phone may cause TV or radio inter-

ference (for example, when using a tele-

phone in close proximity to receiving

equipment). The FCC or Industry Canada

can require you to stop using your tele-

phone if such interference cannot be

eliminated. If you require assistance,

please contact your local service facility.

This device complies with part 15 of the

FCC rules. Operation is subject to the con-

dition that this device does not cause

harmful interference.

left page (38) of AX75_Pegasus, fcc, us-en, (31.05.2005, 08:47)

Ten Driving Safety Tips

VAR Language: am; VAR issue date: 050309

Ten Driving Safety Tips

Your Siemens wireless phone gives you

the power to communicate by voice – al-

most anywhere, anytime. But an impor-

tant responsibility accompanies the bene-

fits of wireless phones, one that every

user must uphold.

When driving a car, driving is your first re-

sponsibility. When using your wireless

phone behind the wheel of a car, practice

good common sense and remember the

following tips:

Get to know your phone and its features such

as speed dial and redial.

Carefully read your instruction manual

and learn to take advantage of valuable

features most phones offer including, au-

tomatic redial and memory dial – most

phones can store up to 99 numbers in

memory dial. Also, work to memorize the

phone keypad so you can use the speed

dial function without taking your atten-

tion off the road.

When available, use a hands-free device.

A number of hands-free wireless phone

accessories are readily available today.

Whether you choose an installed mount-

ed device for your phone or a speaker

phone accessory, take advantage of these

devices if they are available to you.

Position your phone within easy reach.

Make sure you place your wireless phone

within easy reach and where you can

grab it without removing your eyes from

the road. If you get an incoming call at an

inconvenient time, let your voicemail an-

swer it for you.

Suspend conversations during hazardous driv-

ing conditions or situations.

Let the person you are speaking to know

you are driving; if necessary, suspend the

call in heavy traffic or hazardous weather

conditions. Rain, sleet, snow and ice can

be hazardous, but so is heavy traffic. As a

driver, your first responsibility is to pay at-

tention to the road.

Do not take notes or look up phone numbers

while driving.

If you are reading an address book or

business card while driving a car, or writ-

ing a “to do” list, then you are not watch-

ing where you are going. It’s common

sense. Don’t get caught in a dangerous

situation because you are reading or writ-

ing and not paying attention to the road

or nearby vehicles.

Dial sensibly and assess the traffic.

If possible, place calls when you are not

moving or before pulling into traffic. Try to

plan your calls before you begin your trip,

or attempt to coincide your calls with

times you may be stopped at a stop sign,

red light or otherwise stationary. But if you

need to dial while driving, follow this sim-

ple tip – dial only a few numbers, check

the road and your mirrors, then continue.

Do not engage in stressful or emotional conver-

sations that may be distracting.

Stressful or emotional conversations and

driving do not mix – they are distracting

and even dangerous when you are be-

hind the wheel. Make people you are talk-

ing with aware you are driving and if nec-

essary, suspend phone conversations that

have the potential to divert your attention

from the road.

Use your phone to call for help.

Your wireless phone is one of the greatest

tools you can own to protect yourself and

your family in dangerous situations –

with your phone at your side, help is only

three numbers away. Dial 9-1-1 in the

case of fire, traffic accident, road hazard,

or medical emergency. Remember, it is a

free call on your wireless phone.

right page (39) of AX75_Pegasus, fcc, us-en, (31.05.2005, 08:47)

Ten Driving Safety Tips

VAR Language: am; VAR issue date: 050309

Use your phone to help others in emergencies.

Your wireless phone provides you a per-

fect opportunity to be a “good Samaritan”

in your community. If you see an auto ac-

cident, crime in progress or other serious

emergencies where lives are in danger,

call 9-1-1, as you would want others to do

for you.

Call roadside assistance or a special wireless

non-emergency assistance number when nec-

essary.

Certain situations you encounter while

driving may require attention, but are not

urgent enough to merit a call to 9-1-1.

But you can still use your wireless phone

to lend a hand. If you see a broken-down

vehicle posing no serious hazard, a bro-

ken traffic signal, a minor traffic accident

where no one appears injured, or a vehi-

cle you know to be stolen, call roadside

assistance or other special non-emergen-

cy wireless numbers.

Provided by the Cellular Telecommunications In-

dustry Association (CTIA)

“The wireless industry reminds you to use

your phone safely when driving.”

For more information, please call

1 (888) 901-SAFE, or visit our Web site at:

www.wow-com.com

left page (40) of AX75_Pegasus, fcc, us-en, (31.05.2005, 08:47)

Intellectual property

VAR Language: am; VAR issue date: 050309

Intellectual property

Intellectual Property Restrictions

All Intellectual Property, as defined below,

which is owned by or otherwise the prop-

erty of Siemens Information and Commu-

nications Mobile, LLC ("Siemens"), its af-

filiates, partners or suppliers, relating to

the Phone, including but not limited to

accessories, parts or software relating

thereto (the “Phone System”), is propri-

etary under federal laws, state laws and

International treaty provisions. Intellectu-

al Property includes, but is not limited to,

inventions (patentable or unpatentable),

patents, trade secrets, copyrights, soft-

ware, computer programs, and related

documentation and other works of au-

thorship. You may not infringe or other-

wise violate the rights secured by the In-

tellectual Property. Moreover, you agree

that you will not (and will not attempt to)

disassemble, decompile, reverse engi-

neer, prepare derivative works from,

modify or make any other effort to create

source code from the software. No title to

ownership in the Intellectual Property is

transferred to you through purchase or

possession of the Phone or its compo-

nents. All applicable rights of the Intellec-

tual Property shall remain with Siemens,

its affiliates, partners or suppliers.

Siemens will have no liability with respect

to any claim of patent infringement

which is based upon the combination of

the Product or parts furnished hereunder

with software, apparatus or devices not

furnished by Siemens, nor will Siemens

have any liability for the use of ancillary

equipment or software not furnished by

Siemens which is attached to or used in

connection with the Product, The forego-

ing states the entire liability of Siemens

with respect to infringement of patents

by the Product or any parts thereof.

Laws in the United States and other coun-

tries preserve for Siemens certain exclu-

sive rights for copyrighted Siemens soft-

ware, such as the exclusive rights to

reproduce and distribute copies of such

Siemens software. Siemens software may

be used only in the Product in which the

software was originally embodied when

purchased, and such software in such

Product may not be replaced, copied, dis-

tributed. modified in any way, or used to

produce any derivative thereof. No other

use including, without limitation, alter-

ation, modification, reproduction, distri-

bution. or reverse engineering of such

Siemens software or exercise of rights in

such Siemens software is permitted. No

license is granted by implication, estoppel

or otherwise under Siemens patent rights

or copyrights.

right page (41) of AX75_Pegasus, fcc, us-en, (31.05.2005, 08:47)

End user license agreement

VAR Language: am; VAR issue date: 050309

End user license agreement

This Software License Agreement

("Agreement") is between You and

Siemens Information and Communication

Mobile, LLC and/or one of its affiliates

("Licensor"). The Agreement authorizes

You to use the Software specified in

Clause 1 below, which may be included

on Your phone, stored on a CD-ROM, sent

to You by electronic mail, downloaded

from Licensor's Web pages or servers or

from other sources under the terms and

conditions set forth below. This is an

agreement on end user rights and not an

agreement for sale. Licensor continues to

own the copy of the Software and any

other copy that You are authorized to

make pursuant to this Agreement. Read

this Agreement carefully before installing,

downloading or using the Software. Fur-

ther, by installing, downloading and/or

using the Software, You agree to the

terms and conditions of this Agreement.

1. Software.

As used in this Agreement, the term "Soft-

ware" means, collectively:

(i) all the software in Your phone, all of

the contents of the disk(s), CD-ROM(s),

electronic mail and its file attachments, or

other media with which this Agreement is

provided;

(ii) related Licensor or third party software;

(iii) digital images, stock photographs, clip

art or other artistic works ("Stock Files");

(iv) related explanatory written materials

("Documentation");

(v) fonts;

(vi) upgrades, modified versions, up-

dates, additions and copies of the Soft-

ware, if any, licensed to You by Licensor

(collectively "Updates") and

(vii) any other possible documentation re-

lated thereto.

2. End user rights and use.

Licensor grants to You a non-exclusive,

non-transferable end user right to install

the Software or use the Software installed

on the phone. The Software is licensed

with the phone as a single integrated

product and may be used with the phone

only as set forth in these licensing terms.

3. Limitations on end user rights.

(a) You may not copy, distribute, or make

derivative works of the Software.

(b) You may not use, modify, translate, re-

produce or transfer the right to use the

Software or copy the Software except as

expressly provided in this Agreement.

lease or lend the Software; except You

may permanently transfer all of Your

rights as set forth in the Agreement only

as part of a permanent sale or transfer of

the phone, provided the recipient agrees

to the terms of this Agreement.

(d) You may not reverse engineer, reverse

compile, disassemble or otherwise attempt

to discover the source code of the Software

(except to the extent that this restriction is

expressly prohibited by law) or create deriv-

ative works based on the Software.

(e) You shall not display, modify,

reproduce or distribute any of the Stock

Files included with the Software.

(f) You shall not display, modify, repro-

duce or distribute any of the pre-loaded

content included with the software unless

permitted as stated in the User Guide or in

the prompts in the Software. In the event

that You are allowed to display, modify, re-

produce or distribute certain parts of the

pre-loaded content, You shall review the

"Readme" files associated with the pre-

loaded content (contained on the CD) to

ascertain what rights You have with re-

spect to such materials. Pre-loaded con-

tent may not be used in the production of

libelous, defamatory, fraudulent, infring-

left page (42) of AX75_Pegasus, fcc, us-en, (31.05.2005, 08:47)

End user license agreement

VAR Language: am; VAR issue date: 050309

ing, lewd, obscene or pornographic mate-

rial or in any otherwise illegal manner.

You agree that You shall only use the pre-

loaded content in a manner that complies

with all applicable laws, including, but not

limited to, applicable restrictions concern-

ing copyright and other intellectual prop-

erty rights. You may not register or claim

any rights in the pre-loaded content or de-

rivative works there of.

(g) You agree that You shall only use the

Software in a manner that complies with

all applicable laws in the jurisdiction in

which You use the Software, including,

but not limited to, applicable restrictions

concerning copyright and other intellec-

tual property rights.

4. Copyright.

Licensor and/or its software suppliers and

their respective affiliates own the Soft-

ware and all rights, including without limi-

tation including proprietary rights therein,

are protected by international treaty provi-

sions and other applicable national laws

of the country in which it is being used.

The structure, organization and code of

the Software are the valuable trade se-

crets and confidential information.

5. Multiple copies/updates.

If the Software supports multiple plat-

forms or languages, if You receive the

Software on multiple media, of if You oth-

erwise receive multiple copies of the Soft-

ware, the number of phones on which all

versions of the Software are installed

shall be one phone. If the Software is an

Update to a previous version of the Soft-

ware, You must possess a valid end user

right to such previous version in order to

use the Update and You may use the pre-

vious version for ninety (90) days after

You receive the Update in order to assist

You in the transition to the Update. After

such time You no longer have a right to

use the previous version, except for the

sole purpose of enabling You to install the

Update.

6. Commencement & termination.

This Agreement is effective from the first

date You use or install the Software. Your

end user rights automatically and imme-

diately terminate without notice from Li-

censor if You fail to comply with any pro-

vision of this Agreement. In such event,

You must immediately delete, destroy or

return at Your own cost and expense, and

without entitlement to any refund of the

purchase price, the phone and the Soft-

ware, and all related material to Licensor.

7. Except as expressly provided

in the limited warranty for the phone, you

acknowledge the Software is provided "as

is" without warranty of any kind express

or implied. To the maximum extent per-

mitted by applicable law neither Licensor,

Licensor's Software suppliers or their re-

spective affiliates, nor the copyright hold-

ers make any representations or warran-

ties, express or implied, including but not

limited to the warranties of merchantabil-

ity or fitness for a particular purpose or

that the Software will not infringe any

third party patents, copyrights, trade-

marks or other rights. There is no warran-

ty by Licensor or by any other party that

the functions contained in the Software

will meet your requirements or that the

operation of the Software will be uninter-

rupted or error free.

8. Not fault tolerant.

The Software may contain technoloy that

is not fault tolerant and is not designed,

manufactured, or intended for use in en-

vironments or applications in which the

failure of the licensed Software could

lead direclty to death, personal injury, or

severe physical or environmental damage

or financial loss.

right page (43) of AX75_Pegasus, fcc, us-en, (31.05.2005, 08:47)

End user license agreement

VAR Language: am; VAR issue date: 050309

9. Limitation of liability.

To the maximum extent permitted by ap-

plicable law, in no event shall Licensor or

Licensor's Software suppliers or their re-

specitve affiliates and employees be liable

for any lost profits, revenue, sales, data or

costs of procurement of substitute goods

or services, property damage, personal

injury, interruption of business, loss of

business information or for any special,

direct, indirect, incidental, economic, cov-

er, punitive, special or consequential

damages, however caused and whether

arising under contract, tort, negligence,

or other theory of liability arising out of

the use of or inability to use the Software,

even if Licensor or its Software suppliers

are advised of the possibility of such dam-

ages. Because some countries/states/ju-

risdictions do not allow the exclusion or

limitation of liability, but may allow liabili-

ty to be limited, in such cases, the liability

of Licensor, its Software suppliers and

their respective affiliates and employees

shall be limited to, at Licensor's option, ei-

ther (a) return of the price paid less a rea-

sonable amount for usage, or (b) repair or

replacment of the Software that does not

meet the limited warranty provided with

the phone and which is returned in accor-

dance with the requirements of the limit-

ed warranty.

Nothing contained in this Agreement

shall prejudice the statutory rights of any

party dealing as a consumer. Nothing

contained in this Agreement limits Licen-

sor's liability to You in the event of death

or personal injury resulting from Licen-

sor's negligence if law prohibits such a

limitation. Licensor is acting on behalf of

its software suppliers and their respective

employees and affiliates for the purpose

of disclaiming, excluding and/or restrict-

ing obligations, warranties and liability as

provided in this clause 9, but in no other

respects and for no other purpose.

10. Technical support.

Licensor has no obligation to furnish You

with technical support except as agreed

in writing between You and Licensor in

the Limited Warranty provided with the

phone.

11. Export control.

The Software may be subject to export

regulations of the United States and other

countries. You agree that You shall com-

ply with all applicable export laws, restric-

tions and regulations of the United States

or foreign agencies or authorities, and

shall not export, or transfer for the pur-

pose of re-export, any Software, product

or technical data received under this

Agreement or any Software or product

produced by use of such technical data,

including processes and services, in viola-

tion of any applicable restrictions, laws or

regulations, or without all necessary

approvals.

12. Applicable law & general provisions.

This Agreement shall be governed by and

construed in accordance with the laws of

the State of California without regard to

its conflicts of laws rules. This is the entire

agreement between Licensor and You re-

lating to the Software and it supersedes

any prior representations, discussions,

undertakings, end user agreements, com-

munications or advertising relating to the

Software.

BenQ Mobile and OHG AX75 GSM 900/1800/1900 Mobile Phone User Manual S Pegasus

BenQ Mobile GmbH & Co. OHG GSM 900/1800/1900 Mobile Phone S Pegasus

Users Manual

Navigation menu

Namespaces

Views

Navigation
