User Manual

Table of Contents 1

See also Index at the end of this User Guide

t page

(1)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Legal notices ...............................3

Safety precautions ......................5

Antenna care ............................7

Phone operation .......................7

Overview of phone ...................12

Display symbols ........................14

Getting started .........................16

Insert SIM card/battery ............16

Charge battery ........................17

Switch on/off, PIN entry ............19

Entering the PIN .....................19

Emergency number (SOS) .......19

General instructions .................20

Standby mode ........................20

Signal strength .......................20

Digital Rights Mgmt. (DRM) .....20

Main menu .............................20

Standard functions ...................22

Highlighting mode ..................23

Menu speed dialling ...............23

Security .....................................24

Codes .....................................24

Preventing accidental

activation ...............................25

Text entry .................................26

My phone ..................................31

Calling .......................................32

Default book .............................38

Address book ............................ 39

New entry .............................. 39

Change entry ......................... 41

Call entry ............................... 41

Groups ................................... 42

Phonebook ............................... 43

New entry .............................. 43

Call (search for an entry) ........ 44

Change entry ......................... 44

<Special books> ..................... 45

Camera ..................................... 46

Call records .............................. 48

Time/charges ............................ 49

Main Inbox ............................... 50

SMS .......................................... 51

Write/send ............................. 51

Read ...................................... 53

Setting ................................... 55

MMS ......................................... 57

Create .................................... 57

Templates .............................. 59

Send ...................................... 60

Receive .................................. 61

Read ...................................... 62

Setting ................................... 63

E-mail ....................................... 65

Write ...................................... 65

Receive/read .......................... 66

Setting ................................... 67

Table of Con-

tents

See also

Index at the

end of this

User Guide

2 Table of Contents

See also Index at the end of this User Guide

t page

(2)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Voice message/mailbox ........... 68

Chat room ................................ 69

Start menu ............................. 69

Contact lists ........................... 70

Start chat ............................... 73

Msg. history ........................... 74

Setting ................................... 74

CB services ............................... 76

Surf & fun ................................. 77

Internet ................................ 77

Bookmarks ............................. 79

Games and Applications ......... 80

Download wiz. ....................... 81

Setup ........................................ 83

Profiles .................................. 83

Topics .................................... 85

Display ................................... 86

Ring tones ............................. 88

Call setup ............................... 90

Phone setup ........................... 92

Clock ..................................... 94

Connectivity .......................... 95

Security ................................. 97

Network ................................ 99

Accessories .......................... 101

My menu ................................ 102

Fast access ............................. 103

Organizer ............................... 105

Calendar .............................. 105

Appointments ...................... 106

Tasks ................................... 108

Notes ................................... 108

Missed appts. .......................108

Dictat.machine .....................109

Time zones ........................... 110

Media player ...........................111

Extras ......................................112

SIM services (optional) ......... 112

Alarm clock ..........................112

Sound recorder .....................113

Calc. .....................................114

Unit converter ......................114

Stopwatch ............................115

Countdown ..........................116

Remote synchronisation .......116

My stuff .................................. 118

Mobile Phone Manager ..........120

Questions & Answers ............. 123

Customer Care ........................ 126

Care and maintenance ...........128

Battery quality statement ......128

Display quality declaration ....128

Product data ...........................129

Accessories .............................130

SAR .........................................132

U.S. FDA .................................. 133

FCC/Industry Canada Notice ...139

Intellectual Property ...............140

Ten Driving Safety Tips ...........141

End user license agreement ... 143

Menu tree ...............................147

Index .......................................153

3Legal notices

t page

(3)

C72

ormorant

FUG

105

143

, us-en,

A31008

H6090

A40

4A19

(30

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Legal notices

The mobile phone described in this guide is approved for use on the GSM and GPRS net-

works operating on the GSM 900, 1800 (DCS/PCN) and 1900 (PCS) bands. It is approved

for use in the country where it was originally sold and may be approved for use in other

countries.

Siemens and the C72 model phone

are trademarks or registered trade-

marks of Siemens AG and/or its affili-

ates in the United States and/or

other countries.

T9® is a registered trademark of

America Online, Inc. in the United

States. Java and all Java-based trade-

marks and logos are trademarks or

registered trademarks of Sun

Microsystems, Inc. in the U.S and

other countries. The names of actual

companies and products mentioned

herein may be the trademarks of their

respective owners.

Disclaimer

THE INFORMATION CONTAINED IN

THE USER GUIDE IS WRITTEN FOR

THE C72 PHONE. SIEMENS RESERVES

THE RIGHT TO MAKE CHANGES AND

IMPROVEMENTS TO THE PRODUCTS

AND ANY OF THE FEATURES OF THE

PRODUCTS DESCRIBED IN THIS DOC-

UMENT WITHOUT PRIOR NOTICE.

THE CONTENTS OF THE USER GUIDE

ARE PROVIDED "AS IS". EXCEPT AS

REQUIRED BY APPLICABLE LAW, NO

WARRANTIES OF ANY KIND, EITHER

EXPRESS OR IMPLIED, INCLUDING,

BUT NOT LIMITED TO, THE IMPLIED

WARRANTIES OF MERCHANTABILITY

AND FITNESS FOR A PARTICULAR

PURPOSE, ARE MADE IN RELATION

TO THE ACCURACY, RELIABILITY OR

CONTENTS OF THIS DOCUMENT.

SIEMENS RESERVES THE RIGHT TO

REVISE THE USER GUIDE OR WITH-

DRAW IT AT ANY TIME WITHOUT

PRIOR NOTICE. UNDER NO CIRCUM-

STANCES SHALL SIEMENS BE

RESPONSIBLE FOR ANY LOSS OF

DATA OR INCOME OR ANY SPECIAL,

INCIDENTAL, CONSEQUENTIAL OR

INDIRECT DAMAGES HOWSOEVER

CAUSED.

Export Information

The mobile phone may be subject to

export regulation of the United

States and other countries. Diversion

contrary to law is prohibited. You

must comply with all applicable

export laws, restrictions and regula-

tions of the United States foreign

agencies or authorities, and may not

export, or transfer for the purpose of

re-export, the mobile phone or any

part of the phone in violation of any

Legal notices4

t page

(4)

C72

ormorant

FUG

105

143

, us-en,

A31008

H6090

A40

4A19

(30

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

applicable restrictions, laws or regu-

lations, or without all necessary

approvals.

Network Services

A number of features included in this

guide are called Network Services.

They are special services provided by

wireless service providers. In order

to use any of these Network Serv-

ices, you must subscribe to these

service(s) from your service provider

and obtain instructions for their use.

Some of these Network Services may

not be available when roaming on a

network other than your home net-

work.

Standby and

Talk Time Information

The mobile phone incorporates fea-

tures that are new to the mobile

phone world. These may include

color displays and lighting, graphic

games, music reproduction and

browsing the Internet. The way you

use the display and the features will

affect the performance of the bat-

tery and how long it lasts between

charge cycles. The quoted standby

times and talk times show the mini-

mum and maximum performance

that can be expected from the bat-

tery under normal network condi-

tions and with the default settings as

set by the factory. However, playing

games (particularly with the back-

light continuously switched on) and

listening to music will shorten the

time available for standby and to

make and receive telephone calls.

Operation times also vary depending

on network conditions, SIM settings,

charging and battery condition, how

you use your phone and other fac-

tors.

Memory

The mobile phone contains an inter-

nal memory device that stores the

software required to operate the

mobile phone, communicate with

the GSM/GPRS network and provide

the user interface. Some features in

the internal memory run additional

devices and some additional games

and utilities. The amount of memory

available in the mobile phone is

finite and may be insufficient to

store large numbers of applications

and files.

Warning!

Remember to back up your data and to do

so frequently. Always back up all data and

programs before sending the mobile phone

in for repair.

5Safety precautions

t page

(

)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Safety precautions

Information for parents

Please read the operating instructions and safety precautions carefully before use.

Explain the content and the hazards associated with using the phone to your children.

Remember to comply with legal

requirements and local restric-

tions when using the phone.

For example in aeroplanes,

petrol stations, hospitals or

while driving.

Cellular phones can interfere

with the functioning of medical

devices such as hearing aids or

pacemakers. Keep at least

9 inches (20 cm) between

phone and pacemaker. When

using the cell phone hold it to

the ear which is farthest from

the pacemaker. For more infor-

mation consult your doctor.

The ringtone (page 88), info

tones (page 92) and speaker-

phone talking are reproduced

through the loudspeaker. Do

not hold the phone to your ear

when it rings or when you have

switched on the speakerphone

function (page 34). Otherwise

you risk serious, permanent

damage to your hearing.

Only use original Siemens bat-

teries (100% mercury-free) and

– charging devices. Otherwise

you risk serious damage to

health and property. The bat-

tery could explode, for instance.

Small parts such as the SIM

card, sealing stop, lens ring

and lens cap can be disman-

tled and swallowed by small

children. The phone must

therefore be stored out of the

reach of small children.

The mains voltage specified on

the power supply unit (V) must

not be exceeded. Otherwise

the charging device may be

destroyed.

The power supply must be

plugged into an easily accessi-

ble AC mains power socket

when charging the battery. The

only way to turn off the charg-

ing device after charging the

battery is to unplug it.

Do not use a handheld while

driving.

Do not look at the LED (e.g. ac-

tivated infrared port, flash LED)

with optical magnifiers because

of the risk of radiation.

This product complies with

IEC/EN 60825-1 2 2Safety of

Laser Products2 for LED

Class 1M products; such prod-

ucts are safe under reasonably

foresee-able operating condi-

tions.

Safety precautions6

t page

(6)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Do not place the phone near to

electromagnetic data carriers

such as credit cards and floppy

disks. Information stored on

them could be lost.

You may only open the phone

to replace the battery (100%

mercury-free) or SIM card. You

must not open the battery

under any circumstances. All

other changes to this device

are strictly prohibited and will

invalidate the guarantee.

Important

Please dispose of unwanted

batteries and phones as per-

mitted by the laws in your

country.

The phone may cause interfer-

ence in the vicinity of TV sets,

radios and PCs.

Use only Siemens original

accessories. This will avoid

potential risks to health or prop-

erty and ensure compliance

with all relevant regulations.

Improper use will invalidate the guarantee!

These safety instructions also apply to

Siemens original accessories.

Product attributes are subject to changes in

technology, design and availability.

Siemens reserves the right to modify prod-

ucts without prior notice.

This cellular phone offers a range of func-

tions, it can be used in positions other than

the head, such as on the body. In this case,

separation distance of 2cm is required.

When a carry case, belt clip or holder is

used for body-worn operation, it should not

contain metal and should position the

device the above-stated distance from your

body.

7Safety precautions

t page

(

)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Antenna care

Use only the supplied or an approved

replacement antenna. Unauthorized

antennas, modifications, or attach-

ments could damage the phone and

may violate FCC regulations.

Phone operation

Normal position

Hold the phone as you would any

other telephone with the antenna

pointed up and over your shoulder.

Tips on efficient operation

For your phone to operate most

efficiently:

• Extend your antenna fully

(if applicable).

• Do not touch the antenna unnec-

essarily when the phone is in use.

Contact with the antenna affects

call quality and may cause the

phone to operate at a higher

power level than otherwise

needed.

Driving

Laws pertaining to the use of mobile

phones while driving vary signifi-

cantly from state to state and some-

times even from locality to locality

within states. For example, some

areas may allow persons to use their

mobile phones only if they employ a

hands-free device, and some areas

may prohibit the use of cell phones

entirely. Accordingly, Siemens rec-

ommends that persons check the

laws for the areas in which they drive

or will be driving. For areas where

the use of mobile phones while driv-

ing is permitted, Siemens encour-

ages persons to use their phones

responsibly and to employ hands-

free devices. Also, if using your

phone while driving, please:

• Give full attention to driving –

driving safely is your first

responsibility;

• Use hands-free operation, if

available;

• Pull off the road and park before

making or answering a call, if

driving conditions so require.

Important

Read this information before using

your wireless handheld phone.

As this mobile phone is equipped

with a fixed (non-retractable)

antenna, some paragraphs in the

text below may not be applicable.

Safety precautions8

t page

(8)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

For vehicles equipped with

air bags

An air bag inflates with great force.

DO NOT place objects, including

either installed or portable wireless

equipment, in the area over the air

bag or in the air bag deployment

area. If in-vehicle wireless equip-

ment is improperly installed and

the air bag inflates, serious injury

could result.

Electronic devices

Most modern electronic equipment

is shielded from radio frequency (RF)

signals. However, certain electronic

equipment may not be shielded

against the RF signals from your

wireless phone.

Pacemakers

The Health Industry Manufacturers'

Association recommends that a min-

imum separation of six inches (6")

be maintained between a handheld

wireless phone and a pacemaker to

avoid potential interference with the

pacemaker. These recommenda-

tions are consistent with the inde-

pendent research by and recommen-

dations of Wireless Technology

Research.

Persons with pacemakers

• should ALWAYS keep the phone

more than six inches from their

pacemaker when the phone is

turned ON;

• should not carry the phone in a

breast pocket;

• should use the ear opposite the

pacemaker to minimize the poten-

tial for interference;

• should turn the phone OFF imme-

diately if there is any reason to

suspect that interference is taking

place.

Hearing aids

Some digital wireless phones may

interfere with some hearing aids. In

the event of such interference, you

may want to consult your service

provider or your hearing aid manu-

facturer to discuss alternatives.

Other medical devices

If you use any other personal medi-

cal devices, consult the manufactur-

ers of your devices to determine if

they are adequately shielded from

external RF energy. Your physician

may be able to assist you in obtain-

ing this information.

Turn your phone OFF in health care

facilities when any regulations posted

in these areas instruct you to do so.

Hospitals or health care facilities may

be using equipment that could be

sensitive to external RF energy.

9Safety precautions

t page

(9)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Vehicles

RF signals may affect improperly

installed or inadequately shielded

electronic systems in motor vehicles.

Check with the manufacturer or its

representative regarding your vehi-

cle. You should also consult the

manufacturer of any equipment that

has been added to your vehicle.

Posted facilities

Turn your phone OFF in any facility

where posted notices so require.

Airplanes

FCC and Airline Regulations prohibit

using your phone while in the air.

Turn your phone OFF when

requested by the airline.

Check and comply with the policy of

your airline regarding the use of your

phone while the airplane is on the

ground.

Blasting areas

To avoid interfering with blasting

operations, turn your phone OFF

when in a “blasting area” or in areas

posted: “Turn off two-way radio.”

Obey all signs and instructions.

Potentially explosive

atmospheres

Turn your phone OFF when in any

area with a potentially explosive

atmosphere and obey all signs and

instructions. Sparks in such areas

could cause an explosion or fire

resulting in bodily injury or even

death.

Areas with a potentially explosive

atmosphere are often but not always

clearly marked. They include: fueling

areas such as gasoline stations;

below deck on boats; fuel or chemi-

cal transfer or storage facilities; vehi-

cles using liquefied petroleum gas

(such as propane or butane); areas

where the air contains chemicals or

particles, such as grain, dust or metal

powders; and any other area where

you would normally be advised to

turn off your vehicle engine.

Safety precautions10

t page

(10)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Emergency calls (SOS)

Your wireless phone can be used

to make emergency calls. You can

make an emergency call from the

main display screen. Enter the local

emergency number such as 911 and

then press the A key.

This phone, like any wireless phone,

operates using radio signals, wire-

less and landline networks, and user-

programmed functions. Because of

this, connections in all conditions

cannot be guaranteed. Therefore,

you should never rely solely on any

wireless phone for essential commu-

nications (for example, medical

emergencies). Remember – to make

or receive any calls, the phone must

be switched on and be used in a serv-

ice area that has adequate signal

strength. Emergency calls might not

be possible on all wireless phone

networks or when certain network

services or phone features are in use.

Check with local service providers

regarding their network features.

Always make certain that your

phone is properly charged before

attempting any emergency calls. If

you allow your battery to discharge,

you will be unable to receive or make

calls, including emergency calls. You

must then wait a few minutes after

the charging begins to place any

emergency calls.

When making an emergency call,

remember to give all of the neces-

sary information as accurately as

possible. Remember that your wire-

less phone might be the only means

of communication at the scene of an

accident, therefore you should not

terminate the call until given permis-

sion to do so.

11Safety precautions

t page

(11)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Batteries and Chargers

Only use original Siemens batteries

(100% mercury-free) and charging

devices. Use of non-Siemens batter-

ies and/or charging devices may

cause explosion resulting in serious

injury and/or property damage. Use

original Siemens accessories in order

to avoid possible injury and property

damage and to ensure compliance

with applicable laws and regula-

tions. Improper use invalidates the

warranty.

Battery safety precautions

To reduce the risk of fire, injury or

electric shock, and to properly dis-

pose of batteries, please read and

understand the following instruc-

tions. CONTAINS LITHIUM-ION OR

NICKEL-METAL HYDRIDE BATTERY.

BATTERY MUST BE RECYCLED OR DIS-

POSED OF PROPERLY. DO NOT DIS-

POSE IN MUNICIPAL WASTE.

1. Only use the batteries specified

for use with this mobile phone.

2. Do not use batteries of different

sizes or from different manufac-

turers in this mobile phone.

3. Do not dispose of the battery in a

fire; it may explode. Dispose of

used batteries and phones in

accordance with applicable laws

and safety regulations. Do not

expose battery to water. Check

with local codes for special dis-

posal instructions.

4. Do not open or mutilate the bat-

tery. Doing so may cause damage

to the eyes or skin.

5. Exercise care in handling the bat-

tery in order not to short the bat-

tery with conducting materials

such as rings, bracelets, and keys.

The battery or conducting mate-

rial may overheat and cause burns

or fire.

6. Charge the battery provided with,

or identified for use with, this

product only in accordance with

the instructions and limitations

specified in the User's Guide. Do

not attempt to charge the battery

by any means other than those

specified in the User's Guide.

Overview of phone12

t page

(12)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(30

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Overview of phone

1 ACall key

Dial displayed/highlighted phone num-

bers/names, take calls. Show last

phone numbers dialled in standby

mode.

2 BOn/Off/End key

• Switched off: press and hold to

switch on.

• During a conversation or in an appli-

cation: press briefly to finish.

• In menus: press briefly to go back a

level.

Press and hold to go back to standby

mode.

• In standby mode: press and hold to

switch off phone.

3 Joystick

C Press the joystick down verti-

cally to start an application or

function.

In standby mode

C Open main menu.

G Open user profiles.

H Open Phonebook/Addressbook.

E Open Main Inbox.

D Start the camera.

In lists, messages and menus

I Scroll up and down.

D Back a level.

E Function as for right soft key.

During a call

I Set volume.

E Call options.

4 Soft keys

The current functions of this key are

shown in the bottom line of the display

as §Text§/symbol (e.g. p).

5 Function when pressing the joystick

(see p. 15).

Z X

01.10.2005 10:10

Service provider

NewMMS íMenu

13Overview of phone

t page

(13)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(30

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

1 Integrated antenna

Do not obstruct the phone above the

battery cover unnecessarily. This

reduces the signal quality.

2 Loudspeaker

3 Display

4 Infrared interface (IrDA)

5 Access to the Internet portal

6 Input keys

7 *Ringtone

• Press and hold in standby mode:

Switch all audible signals on/off

(except alarm).

• Press and hold on incoming call:

Switch off ringtone for this call only.

8 #Key lock

Press and hold in standby mode:

Switch key lock on/off.

9 Connection socket

For charger, headset, flash etc.

: Connection for external antenna

* Camera lens

Z X

01.10.2005 10:10

Service provider

NewMMS íMenu

Display symbols14

t page

(14)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Display symbols

Display symbols (selection)

Z Signal strength

Y Charging

W Battery charge level, e.g. 50%

L Phonebook

P Call records

O Surf & fun/

Service provider portal

Q Organizer

M Messages

R Camera

S Extras

N My stuff

T Setup

Ç All calls are diverted

¿ Ringer off

¾ Short ring (beep) only

¼ Ringer only if the caller is stored

in the Phonebook.

¹ Alarm set

Ä Keypad locked

Å Auto answer feature on

T9Abc Text input with T9.

£ Activated and available

¢ Registered

¤ Temporarily interrupted

± Browser offline

² Browser is being connected

³ Browser via GPRS online

´ Browser no network

¯ IrDA activated

® IrDA transmission

Events (selection)

ã SMS memory full

ä MMS memory full

å Phone memory full

Æ No network access

Â Missed call

Ê Delete assistant

Message symbols (selection)

p Unread

q Read

r Draft

s Delivered

t MMS not sent

w MMS received

x MMS read

y MMS with DRM contents (p. 20)

À Voice mail received

15Display symbols

t page

)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Camera symbols

Ù Brightness

Ú Zoom factor

Û White balance

× Flash connected

Joystick symbols

î Camera

ð Make call/accept call

í Menu

ï Zoom

ì OK

Getting started16

t page

(16)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(30

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Getting started

Insert SIM card/battery

The service provider supplies you

with a SIM card on which all the

important data for your line is

stored. If the SIM card has been

delivered in credit-card size, snap the

smaller segment out and remove

any rough edges.

Press the grooved area 1, then push

the battery cover towards the front

in the direction indicated by the

arrow 2.

• Place the SIM card flat in front of

the slot with the contact surface

facing downwards. Then push the

SIM card in using gentle pressure

3 (ensure that the chamfered

corner is in the correct position).

• Insert the battery sideways into

the phone 4, then press it down-

wards 5 until it clicks into posi-

tion.

• To remove, press the hook on the

right side 6 outwards, turn the

phone over, and then shake out

the battery.

17Getting started

t page

)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(30

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

• Push the battery cover onto the

side hooks 7, until it clicks into

position.

Charge battery

Charging procedure

The battery is not fully charged

when delivered. Plug charger cable

into the bottom of the phone, plug

power supply unit into a mains

power socket and charge for at least

two hours.

YDisplay during charging.

Charging time

An empty battery is fully charged

after about 2.5 hours. Charging is

only possible within a temperature

range of +5 °C to 45 °C (41 °F to

113 °F). If the temperature rises/falls

5 °C (9 °F) above/below this, the

charge symbol flashes a warning.

The mains voltage specified on the

power supply unit must not be

exceeded.

Additional information

Please switch off your phone before

removing the battery!

Only 3-V SIM cards are supported. Please

contact your service provider if you have an

older card.

Getting started18

t page

(18)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(30

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Operating times

The operating time depends upon

the respective conditions of use.

Extreme temperatures considerably

reduce the phone’s standby time.

Avoid placing the phone in the sun

or on a heater.

Talktime: 100 to 300 minutes

Standby time: 60 to 300 hours

Charge icon not visible

If the battery has been discharged

fully, the charge icon is not immedi-

ately visible when the power supply

is plugged in. It will appear after up

to two hours. In this case the battery

is fully charged after 3 to 4 hours.

Only use the plug-in power supply unit

supplied!

Display while in service

Charge level display during opera-

tion (empty–full):

V W X

A beep sounds when the battery is

nearly empty. The charge level of the

battery is only displayed correctly

after an uninterrupted charging/dis-

charging cycle. You should therefore

not remove the battery unnecessarily

and where possible not finish the

charging procedure early.

Additional information

The power supply unit heats up when used

for long periods. This is normal and not

dangerous.

If the battery is removed for longer than

30 seconds, the clock must be reset.

19Switch on/off, PIN entry

t page

(19)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(30

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Switch on/off, PIN entry

Switching phone on/off

BPress and hold the On/Off/

End key.

Entering the PIN

The SIM card can be protected with a

4to 8-digit PIN.

JEnter the PIN using the

number keys. The charac-

ters **** appear to

ensure nobody can read

your PIN on the display.

Correct with ].

CConfirm by pressing the

joystick. Logging on to

the network will take a

few seconds.

Emergency number

(SOS)

Only to be used in real emergencies!

By pressing the §SOS§ soft key you can

make an emergency call on any net-

work without a SIM card and without

entering a PIN (not available in all

countries).

Switching on your phone

for the first time

Time/date

Set the clock correctly on a one-off

basis when getting started.

CPress this key, then select

§Change§.

JFirst enter the date (day/

month/year), then the

time (24 hours, including

seconds).

CPress. The time and date

are updated.

Time zones

Set the time zone for your area.

ISelect the city in the

desired time zone from

the list ...

§Set§ ... and set it.

Copy SIM addresses

The first time the SIM card is

inserted, the entries on it can be cop-

ied to the Addressbook. Please do not

interrupt this procedure. During this

time do not accept incoming calls.

Follow instructions in the display.

You can also copy data from the

SIM card at a later time (p. 44).

Additional information

Change PIN.......................................p. 24

Clear SIM card barring ......................p. 25

General instructions20

t page

(20)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(30

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

General instructions

Standby mode

The phone is in standby mode and is

ready for use when the name of the

service provider appears on the dis-

play.

BPress and hold the On/Off/

End key to return to

standby mode from any

situation.

Signal strength

ZStrong receiving signal.

[A weak signal reduces the

call quality and may lead

to loss of the connection.

Change your location.

Digital Rights Mgmt.

(DRM)

Remember that your phone has Dig-

ital Rights Management. The use of

downloaded pictures, sounds or

applications can be restricted by the

suppliers, e.g. copy protection, use

for a limited period of time only,

number of times it can be used etc.

(see also p. 81).

Main menu

The main menu is displayed graphi-

cally with symbols:

CCall up from standby

mode.

F ISelect the application

symbols.

CStart an application.

Main menu options

§Options§ Open menu.

Different functions are available

depending on the context.

Large letters Select between two font

sizes.

Illumination Set display illumination to

brighter/darker.

Help Display a help text.

21General instructions

t page

(21)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(30

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Operating instructions

Menu controls

The steps needed to reach a function

are shown in a condensed form in this

user guide, e. g., to display record of

missed calls in condensed form:

C¢P¢Missed calls

This comprises the following steps:

COpen main menu.

¢ Select (highlight) P by

moving the joystick

upwards, then press verti-

cally down on the joystick

before using the joystick

to highlight Missed calls.

CConfirm. The record is

opened.

Symbols

The following symbols are used to

explain operation:

J Enter numbers or letters.

B On/Off/End key

A Call key

<> Soft keys

§Menu§ Displays a soft-key func-

tion.

The joystick can be moved

in 5 directions.

C Press the joystick vertically,

e.g., to call up the menu.

D F E

H I G

Press the joystick in the

direction indicated.

= Function dependent on

service provider, may

require special registration.

Standard functions22

t page

(22)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(30

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Standard functions

Option menus

Functions which appear repeatedly

in the options menu are listed here.

§Options§ Open menu.

Edit Open the entry to edit.

View Display entry.

Delete/

Delete all Delete entry / delete all

entries after confirmation.

New entry Create new entry.

Send... Select transmission service

and medium for sending.

Reply/

Reply to all The sender becomes the

recipient. The received text

is transferred into the new

message.

Save Store entry.

Save to 9Save recipients in the cur-

rent address directory.

Sort Set sort criteria

(according to alphabetical

order, type, time).

Text input

(p. 26)

T9 preferred: Activate/

deactivate T9 input.

Input language: Select

language for text.

Rename Rename selected entry.

Capacity Display memory capacity.

Attributes Display properties of the

highlighted object.

Help Display help text.

23Standard functions

t page

(23)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(30

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Highlighting mode

With some applications (e.g. Phone-

book/Addressbook) one or more

entries in a list can be highlighted to

carry out a function jointly.

§Options§ Open menu.

Mark Activate highlighting

mode.

If a non-highlighted entry is selected,

this can be highlighted:

§Mark§ The current entry is high-

lighted.

If a highlighted entry is selected, the

highlighting can be deleted:

§Unmark§ Dehighlight the current

entry.

Additional highlighting functions:

Menu speed dialling

All menu functions are numbered

internally. A function may be

selected directly by entering these

numbers in sequence. These num-

bers are shown in the top right of the

display.

E.g., write new SMS

(from standby mode):

CPress to display the main

menu. Then press

5for Messages, then

1for Create new, then

1for SMS.

Mark all Highlight all entries.

Deselect all Delete highlighting on all

marked entries.

Delete

marked All selected entries are

deleted.

Security24

t page

(24)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(30

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Security

The phone and SIM card are pro-

tected against misuse by several

security codes.

Codes

C¢T¢Security

¢Codes

¢Select function.

PIN control

The PIN is usually requested each

time the phone is switched on. You

can deactivate this feature but you

risk unauthorised use of the phone

together with your SIM card. Some

service providers do not permit deac-

tivating the control.

§Selection§ Press.

JEnter PIN.

CConfirm input.

§Change§ Press.

CConfirm.

Change PIN

You can change the PIN to any

4 to 8-digit number you find easier

to remember.

JEnter current PIN.

CPress.

J,CEnter new PIN.

J,CRepeat new PIN.

Keep these security codes in a safe

place where you can access them again

if required.

PIN Protects your SIM card

(personal identification

number).

PIN2 This is needed to set the charge

detail display and to access

additional functions on special

SIM cards.

PUK

PUK2 Key code. Used to unlock

SIM cards after the wrong PIN

has been entered repeatedly.

Phone

code Protects your phone. Must be

entered at the first security

setting.

25Security

t page

)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(30

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

C¢T¢Security

¢Codes

¢Select function.

Change PIN2

(Display only if PIN2 is available)

Proceed as for Change PIN.

Chg.phonecode

(Change phone code)

You define the phone code

(4 to 8 digits) when you call up a

phone-code protected function for

the first time (e.g. Direct call, p. 37).

It is then valid for all phone code-

protected functions.

Following the third unsuccessful

attempt, access to the phone code

and the functions that use it is

denied. If this occurs, contact the

Siemens Service (p. 126).

Clear SIM card barring

If the PIN is entered incorrectly three

times, the SIM card is barred. Enter

the PUK (MASTER PIN) provided by

your service provider with the

SIM card in accordance with the

instructions. If the PUK (MASTER PIN)

has been lost, please contact your

service provider.

Preventing accidental

activation

Even if PIN control is deactivated

(p. 24) confirmation is required to

switch on the phone.

This prevents accidental activation

of the phone, e.g. when you are car-

rying it in a bag or when you are trav-

elling in an aircraft.

BPress and hold.

CPress. The phone

switches on.

§Cancel§ Press this key or take no

action. The phone does

not switch on.

Text entry26

t page

(26)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Text entry

Text entry without T9

Press number key repeatedly until

the required letter appears. After a

brief interval the cursor will advance.

Example:

2Press once briefly to write

the letter a, twice to write

b etc.

Press and hold to write the

number.

Ä, ä, 1–9 Umlauts and numbers are

displayed after the rele-

vant letters.

]Press briefly to delete the

letter before the cursor;

press and hold to erase the

whole word.

FMove the cursor (for-

wards/back).

#Press briefly: Swap

between abc, Abc, T9abc,

T9Abc, T9ABC, 123. Status

shown in top line of dis-

play.

Press and hold: All input-

variants are displayed.

*Press briefly: Special char-

acters are shown.

Press and hold: Open input

menu.

0Press once/repeatedly:

. , ? ! ’ " 0 + - ( ) @ / : _

Press and hold: Writes 0.

1Writes blank. Press twice =

line break.

Special characters

*Press briefly. The symbols

chart is displayed

1) Line break

I,FNavigate to characters.

§Selection§ Confirm.

)

¿¡_; . ,?!

+-"’:*/()

¤¥$£€@\&#

[ ] { }%~<=>

| ^`§ Γ ∆ Θ Λ Ξ

Π Σ Φ Ψ Ω

27Text entry

t page

)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Input menu

With text input:

*Press and hold. The input

menu is displayed:

Text format (SMS only)

Input language

Mark

Copy/Insert

Text entry with T9

"T9" deduces the correct word from

the individual key entries by making

comparisons with an extensive

dictionary.

Activate, deactivate T9

§Options§ Open text menu.

Text input Select.

T9 preferred

Select.

§Change§ Activate T9.

Select input language

Select the language in which you

want to compose your message.

§Options§ Open text menu.

Text input Select.

Input language

Select.

§Selection§ Confirm. The new lang is

set. Languages with T9

support are marked with

the T9 symbol.

Writing with T9

The display changes as you proceed.

It is therefore best if you finish a word

without looking at the display.

Simply press the keys once only

where the relevant letter is located.

For "hotel", for example:

#Press briefly for T9Abc then

4 6 8 3 5

1/ EA blank space or moving

to the right ends the

word.

Do not use special characters such

as Ä. Use the standard characters

instead, e.g. A; T9 will do the rest for

you.

Text entry28

t page

(28)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

T9 word suggestions

If several options are found in the

dictionary for a key sequence

(a word), the most probable is dis-

played first. If the word you want has

not been recognised, the next sug-

gestion from T9 may be correct.

The word must be shown §highlighted§.

Then press

^The displayed word is

replaced with a different

word. If this word is also

incorrect, press

^Press until the correct

word is displayed.

If the word you want is not in the dic-

tionary, it can also be written with-

out T9.

To add a word to the dictionary:

§Learn§ Select.

The last suggestion is deleted and

the word may now be entered with-

out T9 support. Press §Save§ to add it

automatically to the dictionary.

Correct a word

FMove left or right, word by

word, until the required

word is §highlighted§.

^Scroll through the T9

word suggestions again.

]Deletes the last character

in a word and displays a

new possible word.

T9® Text Input is licensed under one or more

of the following: U.S. Pat. Nos. 5,187,480,

5,818,437, 5,945,928, 5,953,541, 6,011,554,

6,286,064, 6,307,548, 6,307,549, and 6,636,162,

6,646,573; Australian Pat. Nos. 727539, 746674,

and 747901; Canadian Pat. Nos. 1,331,057,

2,302,595, and 2,227,904;

Japan Pat. No. 3532780, 3492981;

United Kingdom Pat. No. 2238414B;

Hong Kong Standard Pat. No. HK1010924;

Republic of Singapore Pat. No. 51383, 66959,

and 71979; European Pat. Nos. 0 842 463

(96927260.8), 1 010 057 (98903671.0),

1 018 069 (98950708.2); Republic of Korea Pat.

Nos. KR201211B1 and KR226206B1.

People’s Republic of China Pat. Application

Nos. 98802801.8, 98809472.X and 96196739.0;

Mexico Pat. No. 208141; Russian Federation

Pat. No. 2206118; and additional patents are

pending worldwide.

29Text entry

t page

(29)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Text modules

Text modules can be stored in the

phone for adding to your messages

(SMS, MMS, e-mail).

Write Text modules

C¢M¢Text modules

§Options§ Select New text.

JWrite Text modules.

§Options§ Open menu and select

Save. Accept the specified

name or allocate a new

one.

CSave.

Additional information

Within a "T9 word", individual letters may

not be edited without first removing the T9

status. In most cases it is better to rewrite

the complete word.

0Set a full stop. The word is

concluded if it is followed by

a space. Within a word, a full

stop represents an apostro-

phe or hyphen:

e.g. §Provider.s§ = provider’s.

EMoving the cursor to the right

ends the word.

#Press briefly: Swap between

abc, Abc, T9abc, T9Abc, 123.

Status shown in top line

of display.

Press and hold: All input

modes are displayed.

*Press briefly: Select special

characters (p. 26).

Press and hold: Opens input

menu (p. 27).

Text entry30

t page

(30)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Use Text modules

JWrite message

(SMS, MMS).

§Options§ Open text menu.

§Insert§ Select.

ISelect Text modules.

ISelect text module from

the list.

§Selection§ Confirm. The text module

is displayed.

CConfirm. The text module

is inserted in the message

to the right of the cursor.

31My phone

t page

(31)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

My phone

Adjust your phone according to your

own wishes in the following ways to

give it a personal touch:

Ringtones (p. 88)

Assign individual ringtones to caller

groups or special dates.

Pictures (p. 118)

Assign individual pictures or photos

to your Addressbook entries.

Animations (p. 87)

Choose a start-up and closing anima-

tion as well as a personal greeting.

Screensaver (p. 86)

Choose an analogue or digital clock,

or a personal picture.

(Operator) Logo (p. 86)

Choose an individual picture (to be

displayed in standby mode).

Wallpaper (p. 86)

Choose your own permanent back-

ground image.

Colour scheme (p. 86)

Select a colour scheme for the user

interface.

Applications (p. 80)

Download your own applications

from the Internet.

Where do I get what?

You can purchase additional ring-

tones, logos, animations and Java

applications from your service pro-

vider or directly from Siemens.

Service provider portal

Depending on your service provider,

you will find direct access to his por-

tal on your telephone via menu

items or bookmarks. Please contact

your service provider for more infor-

mation on these services.

Siemens City Portal

You will find additional ringtones,

logos, animations and screensavers

as well as more application, games

and services on the Internet at this

address:

www.siemens.com/mobilephones

Or you can download them directly

via Browser:

wap.siemens.com

You will also find a service for saving

data here as well as a list of the coun-

tries in which these services are

available.

My menu

Create your own menu (p. 102) with

frequently used functions, phone

numbers or Browser pages.

Calling32

t page

(32)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Calling

Dialling with number

keys

The phone must be switched on

(standby mode).

JEnter the number (always

with dialling code/inter-

national dialling code).

] A short press clears

the last digit, a long press

clears the entire phone

number.

APress the Call key.

The displayed phone

number is dialled.

End call

BPress the End key briefly.

Press this key even if the

person on the other end

of the line has hung up

first.

Set volume

IRegulate the volume

(only possible during

a call).

If a Car Kit is used, its volume setting

will not affect the usual setting on

the phone.

Redial previous numbers

To redial the phone number last

called:

APress the Call key twice.

To redial other numbers that were

dialled previously:

APress the Call key once.

IPick out the phone

number from the list,

then to dial press the …

A... key.

33Calling

t page

(33)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

If the number is busy

If the called number is busy or can-

not be reached because of network

problems several options are availa-

ble (depending on the service pro-

vider). An incoming call or any other

use of the phone interrupts these

functions.

Either

Auto. redial

§Auto dial§ The phone number is

dialled automatically up

to ten times at increasing

time intervals. End with:

B End key.

Call back b

§Call back§ Your phone rings when

the busy number is free.

Press the Call key to dial

the number.

Reminder

§Prompt§ A beep reminds you to

redial the displayed

phone number after

15 minutes.

Additional information

ÐStore phone number in the

Addressbook/Phonebook.

§Handsfr.§ Switch on Handsfree (play-

back through loudspeaker).

Always switch off "handsfree

talking" before holding the

phone to your ear. This will

avoid damage to your hearing.

*Press and hold to switch

microphone off.

International dialling codes

0 Press and hold until a "+" is

displayed.

§Country§ Press and select country.

Phone number memo

You can enter a phone number during the

call. The person to whom you are speaking

can hear these entries. When the connec-

tion has ended you can save or dial the

phone number.

Calling34

t page

(34)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Accept call

The phone must be switched on. An

incoming call will interrupt any other

use of the phone.

CPress.

APress.

A phone number transmitted by the

network is displayed, along with the

associated name (where applicable

with picture) if this is stored in the

Phonebook/Addressbook (p. 40).

Reject call

§Reject§ Press.

B Press briefly.

Handsfree

You can put the phone down during

a call. You can then use the loud-

speaker to hear the caller.

§Handsfr.§ Activate handsfree talking.

CSwitch on.

IUse the joystick to adjust

the volume.

§Handsfr.§ Deactivate.

Swap between

two calls b

Establish a second connection

You can call another number during

a call.

§Options§ Open call menu.

Hold The current call is put on

hold.

JNow dial the new phone

number or select

§Options§, Phonebook/

Addressbook, and select

phone number.

When the new connection

is established:

§Toggle§ Swapping between calls.

Warning!

Please make sure you have accepted the

call before holding the phone to your ear.

This will avoid damage to your hearing from

loud ringtones.

Additional information

*Press and hold to switch off

the ringing tone and vibration.

ÂMissed call display.

Warning!

Always switch off "handsfree talking"

before holding the phone to your ear!

Otherwise, you will damage your hearing!

35Calling

t page

)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Incoming calls during a call

You may need to register for this

service with your service provider

and set your phone accordingly

(p. 90). During a call, you may be

advised that there is another call

waiting. You will hear a special tone

during the call. You have the follow-

ing options:

•Accept the waiting call in addition to

the first

§Toggle§ Accept the waiting call,

putting the current call on

hold to do so.

Always proceed as above to swap

between the two calls.

•Reject the waiting call

§Reject§ Press.

§Forward§ The waiting call is

diverted, for example, to

the mailbox.

• Accept the waiting call and end the

current call

BEnd the current call.

CAccept new call.

End call(s)

BPress the End key.

After the Return to held call? display,

you have the following selection:

§Yes§ You accept the call on

hold.

§No§ You end the second call.

Calling36

t page

(36)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Conference b

Call up to 5 parties one by one and

link them together in a multiparty

call. Some of the functions described

may not be supported by your serv-

ice provider or may have to be ena-

bled specially.

A connection has already been

established:

§Options§ Open menu and select

Hold. The current connec-

tion is maintained.

JNow dial a new number.

When the new connec-

tion is established ...

§Options§ ... open menu and select

Conference. The held call is

joined.

Repeat procedure until all partici-

pants are linked together

(up to 5 participants).

End

BAll calls in the multiparty

conversation are ended

when the End key is

pressed.

Call options

The following functions are only

available during a call:

§Options§ Open menu.

Hold Hold current call.

Microphone

on If switched off, the person

on the other end of the line

cannot hear you (muting).

Also: * Press and hold.

Handsfree Call via the loudspeaker.

Volume Adjust handset volume.

Default book Display Phonebook/

Addressbook.

Conference (See p. 36)

Time/

charges Display talktime that has

elapsed so far and (if set)

cost incurred during the

call.

Send DTMF Enter control codes (num-

bers) for remote inquiries

to an answering machine.

Call

transfer= Connect the original call

with a second call. For you,

both calls are now ended.

Main menu Access to the main menu.

Call status List all held and active calls

(e.g. participants in a con-

ference).

37Calling

t page

)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Direct call

If this is active, only one number can

be dialled.

Switch on

C¢T¢Security

¢Direct call

CConfirm selection.

JEnter phone code.

When first prompted you define and

enter the phone code (4–8 digits).

CConfirm selection.

Please do not forget this code (p. 24)!

Ï/JSelect phone number

from the Phonebook/

Addressbook or enter it.

CConfirm.

Apply

§Carol§ To dial the phone number

(e.g. Carol’s phone

number), press and hold

the right soft key.

Switch off

# Press and hold.

JEnter phone code.

CConfirm input.

Control codes (DTMF)

You can, for example, enter control

codes (numbers) for remote access

to an automatic answering machine

while another connection exists. These

entries are transmitted directly as

DTMFcodes (control codes).

§Options§ Open menu.

Send DTMF

Select.

Using the Phonebook/

Addressbook

Store phone numbers and control

codes (DTMF codes) in the Phone-

book/Addressbook in the same way

as a normal entry, see p. 38.

JEnter phone number.

0Press and hold until a "+"

appears in the display

(wait for the connection

to be established).

JEnter DTMF codes

(numbers).

0If necessary, wait again

for three seconds at a

time for the receiver to

process the entries safely.

JEnter a name.

§Save§ Store entry.

You may also store just the

DTMFcodes (numbers) and then

send them during the call.

Default book38

t page

(38)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Default book

C¢L¢Select function.

Show entries

The entries in the default book

(Addressbook or Phonebook) are

shown.

J/ISelect a name with the

first letter and/or scroll.

New entry

Create new entry.

Address book (see also p. 39)

Phonebook (see also p. 43)

Default book

You can set which directory you pre-

fer to use.

The selected default book is opened

in standby mode with the joystick.

HOpen Phonebook or

Addressbook

Address book

A lot of data can be recorded in the

Addressbook for each entry, and

additional functions (e.g., pictures,

birthdays) can be used.

Phonebook

The Phonebook is located on the SIM

card. Only one phone number can be

entered per entry. The Phonebook

on the SIM card can easily be trans-

ferred into a different phone.

Business card

Create your own business card to

send to a different GSM-phone. If no

business card has been created yet,

you will be asked for your input.

HMove from field to field to

enter your details.

§Save Press.

Groups

See p. 42.

See p. 45.

Additional information

The content of the business card and the

Addressbook entries correspond to inter-

national standards (vCard).

ÏCopy numbers from

Addressbook/Phonebook.

39Address book

t page

(39)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Address book

The Addressbook can store up to

1000 entries, each with a variety of

phone numbers and additional

address details. These entries are

managed separately from those in

the Phonebook in the phone mem-

ory. However, you can exchange

data between the Addressbook and

the Phonebook on the SIM card.

New entry

The Addressbook is set as standard:

HOpen Addressbook

(in standby mode)

CDisplay input fields.

ISelect required input

fields.

JFill in input fields. The

maximum number of

characters available is

shown at the top of the

display.

At least one name must

be entered. Always enter

phone number with

dialling code.

Possible input fields

Additional information

Group: Assignment to a group

(p. 42).

Address: Extension to enter the

complete address:

Street:, ZIP:, City:, Country:

Chat room Information if the entry is

being used as a chat room

contact (p. 69):

Nickname:, WV user ID:,

ICQ number:, AIM screen

name:

Last name: URL:

First name: Chat room >>

Phone number: Group:

Phone no./office: Company:

Phone no./cell: Address: >>

Fax: Birthday: >>

Fax #2: Picture:

E-mail address:

Email #2: All fields

Address book40

t page

(40)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Birthday: After activation, the date

of birth is entered.

Reminder: The phone

reminds you at the time

entered one day before

the birthday.

Picture: Assign a picture to the

entry. It is displayed if you

are called by one of the

corresponding phone

numbers.

All fields/Reduced fields

Displays the required

input fields.

§Save§ Save the entry.

Display/find entry

HOpen Addressbook

(in standby mode).

J/ISelect required entry.

CDisplay.

Display options

§Options§ The options menu only

offers the functions for

the currently selected

input field.

Additional information

ÎTemporary switch to Phone-

book.

Synchronisation

You can use the mobile phone manager

(p. 120) to synchronise your Addressbook

with Outlook® and other Siemens

telephones.

Using Remote sync. you can synchronise

your mobile with an organiser stored on the

Internet (see also p. 116).

Completing phone numbers

see p. 45

Move to ... Assign current entry or

highlighted entries to a

group.

View Display an assigned

picture.

Copy to SIM Copies name and one

phone number to the

SIM card (Phonebook).

New SMS,

New MMS,

New e-mail

Create a message with

the selected entry.

Browser Start Browser and visit

URL.

Com. services Begin dialogue, p. 69.

(For standard functions see p. 22)

41Address book

t page

(41)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Change entry

HOpen Addressbook

(in standby mode).

J/ISelect required entry.

§Edit§ Press.

ISelect input field.

§Edit§ Open entry if necessary.

JMake changes.

§Save§ Save.

Call entry

HOpen Addressbook

(in standby mode).

J/ISelect a name with the

first letter and/or scroll.

AThe number is dialled.

If there are several numbers in the

address book entry, these are

offered for selection.

ISelect phone number.

AThe number is dialled.

Addressbook options

Depending on the actual situation,

different functions will be offered.

These functions can be applied to

the entry currently selected as well

as to multiple selected entries:

§Options§ Open menu.

Move to ... Copy current entry or high-

lighted entries to a group.

Copy to SIM Copies name and number to

the SIM card (Phonebook).

Filter Only those entries which

match the filter criteria are

displayed.

Import Set up readiness to receive

for a Phonebook entry via

IrDA (p. 95) or SMS (p. 51).

Sort Specify sorting criteria for

output of the Addressbook

entries.

Search Enter search term.

(For standard functions, see p. 22)

Address book42

t page

(42)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Groups

Nine groups are specified in your

phone to enable you to arrange your

Addressbook entries clearly. You can

rename seven groups.

HOpen Addressbook

(in standby mode).

<Groups> Select (the number of

entries is listed behind the

group name).

ISelect group.

Groups menu

§Options§ Open menu.

Ringtone for group

Assign a ringtone to a group that

plays when one of its members calls

you.

C¢T¢Ring tones

¢Group calls

ISelect group.

CConfirm. If a ringtone has

already been set, it will be

played. Otherwise, the

ringtone list will be dis-

played and you can select

one.

I If necessary, select a

ringtone.

CConfirm.

Rename

group Change name of group.

Group

symbol Assign a symbol to a group.

The symbol must then appear

in the display when one of the

group members calls.

Additional information

No group: Contains all Addressbook

entries that do not belong to a group (name

cannot be changed).

Received: Contains Addressbook entries

received by IrDA (p. 95) or SMS (p. 51)

(name cannot be changed).

43Phonebook

t page

(43)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Phonebook

Entries in the Phonebook (on the

SIM card) are managed separately

from the Addressbook. You can, how-

ever, exchange data between the

Phonebook and the Addressbook.

New entry

If the Phonebook has been selected

as standard:

HOpen Phonebook

(in standby mode).

HSelect <New entry>.

CDisplay input fields.

ISelect input field.

JFill in input fields.

The maximum number of

characters available is

shown at the top of the

display.

Phone number:

Always enter phone number with

dialling code. An entry is not saved

without a phone number.

Name:

Enter first and/or last names.

Group:

Default No group

Important phone numbers may be

combined in a group (VIP).

Location:

Default SIM

Special SIM cards can save phone

numbers in a protected area

(SIM protected) (PIN2 required).

Record #:

Each entry is automatically assigned

a record number. You can also dial

using the record number.

§Save§ Press to store the new

entry.

Additional information

ÎTemporary switch to Address-

book.

§Country§

International dialling code...................p. 33

Functions related to Text entry ..........p. 26

Phonebook44

t page

(44)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Call (search for an entry)

HOpen Phonebook.

J/ISelect a name with the

first letter and/or scroll.

APhone number is dialled.

Call using record no.

A record number is automatically

assigned to every new entry in the

Phonebook.

JEnter record number.

#Press.

APress.

Change entry

ISelect entry in

Phonebook.

§Edit§ Press.

J/ISelect input field

required.

JMake changes.

§Save§ Press.

Phonebook options

The following functions are availa-

ble, depending on the current situa-

tion.

§Options§ Open menu.

Copy to 9Copy all highlighted

entries to the

Addressbook.

Copy all to 9Copy all entries to the

Addressbook.

Delete all The whole Phonebook

is deleted.

PIN-protected.

Import Set up readiness to

receive for a Phone-

book entry via IrDA

(p. 95) or SMS (p. 51).

(For standard functions, see p. 22)

45Phonebook

t page

)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

HOpen Addressbook

(in standby mode).

Select.

Enter "own" phone numbers in

Phonebook (e.g., fax) for informa-

tion. These numbers can be

changed, deleted and also sent as an

SMS message.

Display the phone numbers saved in

the VIP group.

Entries stored in the Phonebook on

the SIM card can also be used on

other GSM phones.

<Protected SIM> b

On special SIM cards, phone num-

bers can be stored in a protected

location. PIN2 is required for editing.

There might be phone numbers

saved in your Phonebook that have

been provided by your service pro-

vider. They may be used to call local

or national information services or to

use services offered by your service

provider.

Completing phone numbers in the

Phonebook

Digits may be replaced by a "?" when

phone numbers are entered in the

Phonebook:

*Press and hold.

These wildcards must be replaced with

numbers before dialling (e.g., with the

extension numbers in a phone system).

To make a call, select the phone number

from the Phonebook/Addressbook.

APress.

JReplace "?" with numbers.

ANumber is dialled.

Camera46

t page

(46)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(29

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Camera

You can view photos recorded on

the integrated camera immediately

and

• use the photo as a background

image, logo, a switch on/off

animation or a screensaver.

• send the photo via MMS or e-mail.

Switch on

C¢R

DStart camera in standby

mode.

The current (preview) image is dis-

played. You will see the following in

the first line from left to right:

ÙBrightness

ÚZoom factor

ÛWhite balance

×Flash connected.

The number of photos that can still

be taken in the selected resolution is

displayed in the top right-hand cor-

ner of the preview image. As the

memory requirement depends

essentially on the subject photo-

graphed and the resolution, the

number of photos that are still possi-

ble can sometimes change unex-

pectedly. Information about the

selected resolution is located under

the preview image.

Record

CTakes a photo.

CDisplays the preview

image of the next photo.

The photo is saved with a name, the

date and the time. To enter the

name see Setup in the options menu.

Settings prior to taking a photo:

FSets the brightness.

ISets the zoom factor.

ÙÚ ×

Photo î Options

47Camera

t page

)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(29

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Image resolution

It is possible to set the quality of the

image regardless of the preview

image resolution, e.g.:

The resolution may decrease

depending on the selected digital

zoom.

Flash (accessories)

If the flash is active, this is shown by

a symbol in the display. The flash is

charged constantly while it is con-

nected to the phone and the camera

is activated. This reduces the stand-

by time.

×This symbol appears

when the flash is being

charged.

For settings, see options menu.

Camera options

The following functions are available,

depending on the current situation.

§Options§ Open menu.

Premium

Medium

Background

Setup • Name for recordings

• Image resolution

Pictures The last picture taken is

displayed.

Use flash Choose between:

Automatic, Off,

Red-eye

Auto-timer The photo is taken approx.

15 seconds after trigger-

ing. For the last 5 seconds,

you will hear a beep each

second.

White

balance Choose between:

Automatic, Indoor,

Outdoor

(For standard functions see p. 22)

Additional information

ÊInsufficient memory available.

Start the delete assistant to

delete data (p. 93).

A mirror can be attached to the back of the

phone depending on the phone variant.

This makes it easier to take self portraits.

Call records48

t page

(48)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Call records

The phone number of a caller is dis-

played if

• the caller has switched off the

Incognito function and

• the network supports the

"Caller Identity" function.

Alternatively, a caller’s name is dis-

played if it is stored in the Phone-

book/Addressbook.

Your phone stores the phone num-

bers of calls for convenient redial-

ling.

C¢P

ISelect record.

COpen record.

ISelect phone number.

ADial phone number.

§View§ Display information on

the phone number.

Up to 500 entries are stored in

the records:

Missed calls b

The phone numbers of calls that you

have received but not answered are

stored for callback purposes.

ÂIcon for missed call

(in standby mode).

Press the display key

beneath the symbol to

call up the Main Inbox

(p. 50).

Calls received

Accepted calls are listed.

Calls dialed

Access to the last numbers dialled by

you.

AFast access in standby

mode.

Delete records

The records are deleted.

Call list menu

The records menu can be called up if

an entry is highlighted.

§Options§ Open menu.

Copy to 9 /

Copy to SIM Copy the currently

selected phone number

into the preferred direc-

tory.

(For standard functions see p. 22)

Time/charges44

t page

(44)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Time/charges

You can display the charges and

duration during a call. You can set a

unit limitation for outgoing calls.

C¢P¢Time/charges

Select:

Last call:

Incoming calls:

Outgoing calls:

All calls:

Remaining units:

IScroll through the display.

COpen menu.

§Reset§ Reset the selected setting.

Charge setting

COpen menu.

Currency

Enter currency.

Charge/Unit

(PIN2 prompt)

Enter the currency as well as the

charge per unit and time.

Account limit

(PIN2 prompt)

Special SIM cards allow you or the

service provider to define a credit

limit or a period after which the

phone is barred for outgoing calls.

§Edit§ Press.

JEnter PIN2.

Account limit

Switch on.

JEnter number of units.

§OK§ Confirm.

Then confirm the credit or reset the

counter. The status display for pre-

paid cards may vary, depending on

the service provider.

Auto display

Call duration and charges are

displayed automatically.

Main Inbox50

t page

(

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Main Inbox

The inbox folder offers immediate

access to the messages just received.

This means that you no longer have

to look through all inbox folders for

the various message types. The

entries are marked with a symbol to

indicate their type and status. You

will find a list of the symbols on

p. 14.

To call up the inbox folder, e.g. if a

new SMS has been received:

çPress the soft key beneath

the symbol.

EIn standby mode:

You will find the following message

types in the inbox folder:

SMS, MMS, E-mail

System messages

Message about MMS, Missed alarm,

Missed appts., Missed calls, WAP push,

Voice message

Data objects

Ring tones, Pictures, Calendar entries,

Notes and Business card

CWhen you open an entry,

the relevant application

also starts.

After a set period of time, entries

which have already been read and

opened are only displayed in the

message-related inbox lists (see

Setup in the optionsmenu).

Main Inbox options

§Options§ Open menu.

Receive e-mail Connect to set account

and send all e-mails.

Setup If entries have been

read, remove them from

the Main Inbox:

Daily, Never,

Immediately

If Daily has been

selected, specify the

time.

(For standard functions see p. 22)

51SMS

t page

(

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

SMS

You can transmit and receive very

long messages (up to 760 charac-

ters) on your phone. They are auto-

matically composed of several "nor-

mal" SMS messages (note higher

charges). The maximum possible

length of an SMS is reduced if you

use special letters from some lan-

guages. If you do not wish to use

these letters then change the input

language in the options menu.

You can also insert simple pictures

and sounds in an SMS.

Write/send

C¢M¢Create new

¢SMS

JInput text.

You will find information

on writing texts with and

without T9 in the chapter

"Text entry" (p. 26).

The following is displayed

in the top display line:

Text entry status, number

of SMS messages

required, number of char-

acters still available.

AStart sending procedure.

Ï/JSelect phone number

from the Phonebook/

Addressbook or enter it.

§Group§ If necessary, select

a group.

CConfirm. The SMS is trans-

mitted to the service cen-

tre to be sent and saved in

the Sent items list.

Text options

§Options§ Open menu.

.Save Save composed text in draft

list.

Picture&

sound Add pictures, animations and

sounds into message (see fol-

lowing text).

Text

modules Insert Text modules (p. 29).

Format Font size: Small font,

Medium font, Large font

Underline

Alignment: Default alignm.,

Left, Center, Right

Mark (highlight text with the

joystick)

Delete

text Delete the whole text.

Send

with... Select SMS profile so the SMS

can be sent.

(For standard functions see p. 22)

SMS52

t page

(

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Picture&sound

Send simple pictures and tones with

or without accompanying text.

Remember that these may be pro-

tected (DRM, p. 20).

With the text input field open:

§Options§ Open menu.

ISelect Picture&sound.

The menu contains:

Def animations

Def. sounds

My anim.

My pictures

My sounds

ISelect list.

CConfirm. The first entry of

the selected section is dis-

played.

IScroll to entry required.

For Def animations/Def. sounds:

CThe selection is added to

the SMS.

For My anim./My pictures/

My sounds:

CThe selection is displayed/

played back.

CThe selection is added to

the SMS.

The pictures which have been added

are displayed. Sounds are displayed

in the form of "wildcards".

SMS to group

You can send an SMS message as a

"circular" to a recipient group.

§Options§ Open menu.

Send Select.

§Group§ The list of groups is dis-

played.

ISelect group.

COpen group and highlight

all/individual entries.

CTransmission is started

after a security prompt.

53SMS

t page

(

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Read

pArrival of a new SMS

announced in the display.

Open Main Inbox (p. 50)

using the soft key posi-

tioned beneath it.

CReading the SMS.

IScroll through message

line by line.

You can answer the currently open

SMS immediately. The newly added

text is placed above the received

text.

Reply options

§Reply§ Open reply menu.

Read options

§Options§ Open options menu.

çSMS

10.05.2004 19:42

+ 12398765431

SMS text . . .

Reply í Options

Create new Create a new reply

text.

Edit Edit received SMS or

add new text.

Answer is YES Add Answer is YES to

the SMS.

Answer is NO Add Answer is NO to

the SMS.

Call back, Delay,

Thanks Add a standard text as

a reply to an SMS.

Reply See "Reply options"

above.

Picture&sound Save picture/sound

contained in the SMS.

Zoom in Enlarge or reduce text

display.

Archive Move SMS message

to archive.

(For standard functions see p. 22).

SMS54

t page

(

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Lists

All SMS messages are archived in dif-

ferent lists, according to their status.

(For overview of message symbols,

see p. 14):

Inbox

C¢M¢Inbox¢SMS

The list of received SMS messages is

displayed.

Draft

C¢M¢Draft¢SMS

The list of not yet transmitted SMS

messages is displayed.

Unsent

C¢M¢Unsent¢SMS

The list of concatenated SMS mes-

sages not yet completely sent is

displayed. Transmission can be

restarted.

Sent items

C¢M¢Sent¢SMS

The list of sent SMS messages is

displayed.

SMS archive

C¢M¢SMS archive

The list of SMS messages stored in

the phone is displayed.

List options

Different functions are offered

depending on the list.

§Options§ Open menu.

Send Send or forward entry.

Send with... Select an SMS profile for

transmission.

Archive Move SMS message to

archive.

(For standard functions, see p. 22)

55SMS

t page

(

)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Setting

SMS signature

C¢M¢Msg settings

¢SMS¢SMS signature

You can enter a "signature" with a

maximum of 16 characters. This sig-

nature will then be attached to each

SMS except for a §Reply§ and when

changes are made to an existing

SMS.

SMS profiles

C¢M¢Msg settings

¢SMS¢SMS profiles

Up to 5 SMS profiles can be set. The

transmission characteristics of an

SMS are defined in these. The pre-

setting depends on the SIM card

inserted.

Activate profile

ISelect profile.

CActivate.

Set profile

ISelect profile.

§Edit§ Open to edit the profile.

Service

center Enter the phone numbers for

the service centre as provided

by the service provider.

Recipient Enter a standard recipient for

the profile.

Message

type •Manual: Inquiry for all mes-

sages.

•Standard text: Normal SMS

message.

•Fax: Transmission via SMS.

•E-mail: Transmission via

SMS.

•New: You may need to

obtain the required code

number from your service

provider.

Validity

period Period within which the service

centre is to try to deliver the

message:

Manual, 1 hour, 3 hours,

6 hours, 1 day, 1 week,

Maximum*

* Maximum period that the

service provider permits.

Status

report

Receive confirmation of suc-

cessful/failed transmission of a

message. This service may be

subject to a charge.

Direct

reply = If activated, the reply to your

SMS message is handled via

your service centre (for infor-

mation, please contact your

service provider).

SMS via

GPRS

Send SMS automatically via

GPRS (p. 95).

Save aft.

send Sent SMS messages are

saved in the Sent items list.

SMS56

t page

(

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

More information on SMS

SMS status report

If the message cannot be transmit-

ted to the service centre you are

offered the chance to repeat the

transmission. If this also fails, con-

tact your service provider.

The Message sent. message only indi-

cates transmission to the service

centre. This will then attempt to

relay the message within a certain

period.

see also Add contact.

Find member Search for group member.

Invite Invitation to the contacts

in your own group to Inst.

Message.

Delete

member Delete contact from the

group member list.

Add group Add new group.

Find group Search for group on the

server (no longer in the

"administered groups"

list).

Create group Group ID:

Enter a non-ambiguous

group name.

Name:

Name of group.

Topic:

Topic of group.

Searchable:

Other people can look for

the group.

Welcome msg.:

Enter welcome text.

Create group Delete group.

Chat room72

t page

(

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Creating a new contact list

The current contact list is displayed.

§Options§ Open menu.

Contact lists

Available contact lists are

displayed.

§Options§ Open menu.

Create Select.

Contact list ID:

Give the contact list its

own, specific name.

Name: Allocate self-explanatory

names.

CConfirm.

Contact list options

§Options§ Open menu.

Details =Additional information

about the contact or the

group.

My settings Information on your cur-

rent personal status

(p. 75).

Set Functions for managing

a contact or a group.

Contact lists Display contact lists for

selection.

Block list Display all blocked con-

tacts. Can be unblocked.

App. settings Set the application

(p. 75).

Exclude Terminate the applica-

tion, the server remains

connected.

Logout Log off from the server

and return to start menu.

Help Display help text.

73Chat room

t page

(

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Start chat

A contact list must be displayed.

ISelect a contact or a

group.

CStart communication with

the contact.

The page is displayed.

During Inst. Message with

a group, the name of the

sender is placed in front

of each contribution.

COpen editor.

JWrite text

CSend text. The text

appears in the chat soon

afterwards.

Naturally, you can also receive mes-

sages from contacts whom you do

not know. This will be pointed out to

you in the display, and you can

either switch to Inst. Message or

ignore/block the contact.

Options (individual contact)

§Options§ Open menu.

Send sound

=Select and send a melody/

tone from the list

(DRM p. 20).

Send

picture =Select and send a picture

from the list (DRM p. 20).

Send other

=Send any file.

Details Information about the con-

tact (if this is authorised by

him).

Clear all Delete all texts in the cur-

rent Inst. Message.

Block

contact No more messages are

received from the contact

and the contact receives

no status information from

you. This function works

for all your lists.

Chat room74

t page

(

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Options (group contact) b

§Options§ Open menu.

Receiving objects b

You will be informed in the display if

sounds or pictures are sent to you

during a dialogue.

§Accept§ Accept object.

§Reject§ Reject object.

Msg. history

C¢M¢Chat room

¢Msg. history

The messages from the last meeting

are displayed. You can read and

delete the contributions.

Requirement: The server must be

disconnected, see Exclude (p. 72)

and Automatic login: (p. 75).

Setting

C¢M¢Chat room

¢Setup¢Select function.

Account

The list of available accesses is

displayed.

I/CSelect an access to estab-

lish a connection.

<New entry>/Account sett. b

Set up an access or

change the settings as

specified by the service

provider. Depending on

the service provider, the

settings may not be

changeable.

Subscribers List group participants cur-

rently online.

Leave group Exit group.

Details Information about the

group:

Group ID:, Name:, Topic:,

Owner:

Clear all Delete all texts in the cur-

rent Inst. Message.

Name: Name of the access.

URL: Enter URL, e.g.

http://www.abc.com

User ID: Enter a non-ambiguous

user (login) name.

Password: Enter password (shown

as a series of asterisks).

75Chat room

t page

(

)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

My settings

Information on your current per-

sonal status:

§Options§ For each setting, specify

who is allowed to view

your personal infor-

mation:

Public

All contacts.

Private

Contacts designated as

Friend: (p. 70).

Hide

Nobody.

App. settings

Settings for the application used:

Alias: Your own alias by which

you can be found on the

server.

AIM screen

name: Name to be displayed in

the group.

Mood: Information about your own

mood, e.g.

Happy, Sad, Tired, etc.

Status text: Random text information,

e.g. "Am at home".

Availability: Status display

Cellphone: Enter the phone number

with internal extension

code.

Automatic

last access to be used.

Timeout: Time without action after

which the application is

terminated. However, the

server remains con-

nected.

Message info:/

Online info: Signal the receipt of mes-

sages: Yes/No

Signal given as:

•Sound

•Silent alert

•Pop-up

Popup windows

authorised: Yes/No

CB services76

t page

(

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

CB services

C¢M¢Setup

¢CB services

Some service providers offer infor-

mation services (info channels, Cell

Broadcast). If reception is activated,

you will receive messages on the

activated topics in your Topic list.

CB messages are displayed in

standby mode; longer messages are

scrolled automatically.

Receive CB

You can activate and deactivate the

CB service. If the CB service is acti-

vated, standby time for the phone

will be reduced.

Topic list

You can add any topics to this per-

sonal list from the topic index. You

can preset 10 entries with their

channel numbers (ID) and, if applica-

ble, with their names.

New topic Select.

• If no topic index is available, enter

a topic with its channel number

and confirm with §OK§.

• If the topic index has already been

transmitted, select a topic and

activate it with §Options§.

Topic Select

§Options§ Open list menu.

If a topic is selected in the list you

can view it, activate/ deactivate it,

edit it or delete it.

CB languages

Receive Cell Broadcast messages in

one specific language only or in all

languages.

Displays

Ö,ÕTopic activated/deactivated.

pNew messages received on

the topic.

qMessages already read.

77Surf & fun

t page

(

)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(30

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Surf & fun

Get the latest information from the

Internet that is specifically adapted

to the display options of your phone.

In addition, you can download

games and applications to your

phone. Internet access may require

registration with the service pro-

vider.

Access to the service

provider

Direct call-up of the browser with

the URL from your service provider.

Internet

C¢O¢Internet

The browser is activated with the

pre-set option as soon as you call up

the function (Browser settings, p. 78;

may be specified/pre-assigned by

service provider).

Browser menu

§Options§ Open menu.

Homepage Call up the pre-set

homepage for the current

profile.

Bookmarks •List bookmarks

Display list of book-

marks stored in the

phone.

•Bookmark site

The current page is

saved as a bookmark.

Go to... Enter URL for direct dial to

an Internet address, e.g.

wap.siemens.com

Reload Reload current page.

Show URL Display the URL of the

page currently loaded for

sending via SMS/MME/

e-mail.

History Display last Internet sites

to be visited.

Disconnect Disconnect the Internet.

File Save object on the current

page or save the complete

page; display saved

pages.

Settings Set or reset browser

(p. 78).

Exit browser Close the browser.

Surf & fun78

t page

(

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(30

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

End connection

B Press and hold to clear

down the connection and

close the browser.

Navigation in the browser

Display symbols in the browser

(selection)

Enter special characters

*, 0Select important special

characters.

Browser settings

C¢O¢Internet

§Options§ Open menu.

Settings Select.

C • Select a link.

• Settings, status on/off.

B •Press briefly: back a page.

I • One input field/link forward/back.

• Scroll one line.

Connect ´ No network

±Network ³ GPRS online

Browser Set start option as well as

handling of pictures and

sounds plus send options.

Profiles The list of profiles is dis-

played for activation/setting.

For more information, con-

tact your service provider.

Protocol

parameters Set protocol parameters,

push messages and abort

time as well as handling of

cookies.

Security Set encryption.

Context Reset session; delete

cache, history and cookies.

Your Internet browser is licensed by:

79Surf & fun

t page

(

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(30

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Profiles

Preparation of the phone for Internet

access depends on the service pro-

vider concerned:

Profile pre-set

In most cases, access profiles have

already been created for one or more

service provider(s).

ISelect profile.

CActivate profile.

Set profile manually

If necessary, contact your service

provider.

§Options§ Open menu.

Bookmarks

C¢O¢Bookmarks

Display URL/call up page

List bookmarks

Display list of bookmarks

stored in the phone.

ISelect bookmark.

CCall up URL.

Save

Bookmark site

The current page is saved

in the phone as a book-

mark.

Bookmark options

§Options§ Open menu.

Here you will find functions for

changing and managing bookmarks

and their folders. This includes edit-

ing individual entries with the corre-

sponding URLs as well as deleting

and moving them to other folders.

Edit Start processing. For the

Internet-specific settings

below, please contact your

service provider.

Delete Delete selected profile.

Surf & fun80

t page

(80)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Surf & fun Games and Applications

Games and applications are offered

on the Internet. Once downloaded

these are available to you on your

phone. Most applications include

instructions. Some applications and

games are already pre-installed on

your phone. You will find these listed

here:

www.siemens.com/c72

Requirements

Browser profile (p. 79) and the

access (p. 95) must be configured.

Download

Select the correct access depending

on whether you are loading games

or applications:

C¢O¢Games

C¢O¢Applications

In addition to URLs and service pro-

viders for the download, any availa-

ble applications/games and folders

will be displayed.

Download new

ISelect a service provider

or URL.

CStart Browser and visit

URL.

Only description file

ÌThe description file is

loaded for information

purposes only. The appli-

cation/game itself must

be loaded separately.

or complete download

ËThe application/game is

completely loaded.

Apply

Remember that applications/games

may be protected (DRM, p. 20).

ÍThe executable applica-

tion is saved on the phone

and can be started

immediately.

81Surf & fun

t page

(81)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Download wiz.

C¢O¢Download wiz.

You will not be left on your own dur-

ing the download!

Games and applications –

options

Processing and managing your appli-

cations and folders:

Additional information

You can control games with the joystick or

by using the following keypad controls:

864

Move Move applications between

folders.

New folder Create and name new folder.

Reinstall Reinstall an application

(update).

Security Select a safety level.

Reinstall Repeat after transmission

error.

Attributes Show details of the applica-

tion/folder (name, version,

size, path, producer, date).

HTTP

profile Display profile list for

activation/setting

(For standard functions see p. 22)

Surf & fun82

t page

(82)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Additional information

You can use the browser to download applica-

tions (e.g. ringtones, games, pictures, anima-

tions) from the Internet.

Siemens excludes all warranty and liability claims

in respect of or in connection with any applica-

tions subsequently installed by the customer and

any software not included in the original delivery

package. This also applies to functions enabled

subsequently at the customer's instigation. The

purchaser bears sole risk for the loss of, damage

to, and any defects arising in this device or the

applications and for any direct damage or conse-

quential damage of whatever nature resulting

from the use of this application. For technical rea-

sons, such applications and subsequent enabling

of certain functions are lost in the event of the de-

vice being replaced/re-supplied and may be lost if

it is repaired. In such cases, the buyer is required

to download or release the application again.

Please ensure that your phone has Digital Rights

Management (DRM) so that downloaded applica-

tions are protected from unauthorised reproduc-

tion. These applications are then exclusively

intended for your phone and cannot be trans-

ferred from this even to create a backup. Sie-

mens does not warrant, guarantee or accept any

liability for the customer's ability to download or

enable applications again or to do so free of

charge. We recommend that you carry out a back

from time to time of the applications on your PC

using the "Mobile Phone Manager" (MPM,

p. 120) .You can download the relevant latest

version of the MPM from the Internet at:

www.siemens.com/c72.

83Setup

t page

(83)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Setup

Profiles

C¢T¢Profiles

Several settings can be stored in a

phone profile in order, for example,

to adapt the phone to the surround-

ing level of noise.

• Five standard profiles are provided

with default settings. They can be

changed however:

Normal environment

Quiet environment

Noisy environment

Car Kit

Headset

• You can set two personal profiles

(<Name>).

• The special profile Airplane mode is

fixed and cannot be changed.

Switch on

ISelect default profile or

personal profile.

CSwitch on profile.

Profile settings

Edit a default profile or create a new

personal profile:

ISelect profile.

§Options§ Open menu.

Change sett.

Select.

The list of available functions is dis-

played.

When you have finished setting a

function, you return to the profile

menu where you can change a fur-

ther setting.

Additional information

• Call up the list in standby mode:

GProfile list is displayed.

• The active profile is identified with ·.

Setup84

t page

(84)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Profile options

§Options§ Open menu.

Car Kit

If an original Siemens Car Kit is used,

the profile is switched on automati-

cally when the phone is inserted into

the cradle (also see accessories).

Headset

The profile is only switched on auto-

matically if an original Siemens

headset is used (see accessories

also).

Airplane mode

The acoustic signals and vibration

for the alarms (appointments, alarm

clock) are switched off. The alarms

continue to be shown in the display

only.

Switch on

HScroll to Airplane mode.

CConfirm selection.

CConfirm safety prompt

again to activate the pro-

file. The phone switches

itself off automatically.

Normal mode

When you switch on your phone

again, the previously set profile will

be reactivated automatically.

Activate Activate selected profile.

Change sett. Change profile settings.

Copy from Copy settings from

another profile.

Rename Change personal profile

(except default profiles).

85Setup

t page

)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Setup Topics

C¢T¢Topics

Load a completely new visual pres-

entation onto your phone. At the

press of a key, various functions are

re-organised on a theme basis, e. g.

switch on/off animation, back-

ground image, screensaver, switch

on/off melody, additional anima-

tions.

theme files are compressed to save

memory space. After being down-

loaded (p. 80) or called up from

My stuff, these are automatically

unzipped when activated.

Activate new theme

ISelect theme.

CDisplay theme preview.

CActivate new theme.

Setup86

t page

(86)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Setup Display

C¢T¢Display

¢Select function.

Language

Set the language for the display text.

When "automatic" is set, the lan-

guage of your home service provider

is used.

If a language that you do not under-

stand happens to be set, the phone

can be reset to the language of your

home service provider with the fol-

lowing input (in standby mode):

* # 0 0 0 0 # A

Text input

T9 preferred

Activate/deactivate intelligent text

entry.

Input language

Select language for text entry.

Languages with T9 support are

marked with the T9 symbol.

Wallpaper

Set wallpaper graphic for the display.

Logo

Choose graphic to be displayed

instead of the provider logo.

Color scheme

Select colour scheme, incl. back-

ground image for the entire user

interface

Screensaver

The screensaver shows a picture in

the display when a period set by you

has elapsed. An incoming call and/or

pressing any key will end the func-

tion except if the safety function is

activated.

Preview

Display the screensaver.

Style

Select Analog clock, Digital clock,

Bitmap, Energy saving.

Bitmap

Select image in My stuff.

87Setup

t page

)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Timeout

Set period after which the screen-

saver starts.

Security

The phone code is requested to stop

the screensaver.

Auto key lock

Automatic keypad locking if no key

has been pressed for one minute in

standby mode.

Unlocking:

#Press and hold.

Start up anim.

Select animation to be shown when

the phone is switched on.

Shutdn anim.

Select animation to be shown when

phone is switched off.

Greeting

Enter greeting to be displayed

instead of animation when phone is

switched on.

Large letters

You can choose between two font

sizes for the display.

Illumination

Set display illumination to brighter/

darker. The darker the setting the

longer the standby time.

IPress the joystick repeat-

edly at the top/bottom to

adjust up or down.

Contrast

Set display contrast.

IPress the joystick repeat-

edly at the top/bottom to

adjust up or down.

Note

The "picture" (animated) and

"digital clock" screensavers significantly

reduce the phone’s standby time.

Setup88

t page

(88)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Setup Ring tones

C¢T¢Ring tones

¢Select function.

Set the signal tones on the phone to

suit your requirements.

Ringer setting

On/off Activate/deactivate all

tones.

Beep Reduce ringtone to a

short signal (beep).

Silent alert

To avoid the disturbance caused by a

ringing phone, you can activate the

silent alert function as an alterna-

tive. The silent alert can also be acti-

vated in addition to the ringtone

(e.g. in noisy environments). This

function is deactivated when the

battery is being loaded and accesso-

ries are connected (except the head-

set).

ISelect from several silent

alert versions.

Volume

Set different volumes for types of

call/functions.

ISelect

Incoming call

Messages

Alarm clock

Organizer

System

Applications

CThe ringtone is repeated.

ISet volume.

CConfirm setting.

Additional information

Please make sure you have accepted the

call before holding the phone to your ear.

This will avoid damage to your hearing from

loud ringtones.

89Setup

t page

(89)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Assign ringtone

A ringtone which has already been

selected will be played or the list of

possible ringtones will be displayed

for selection.

d Calls

Assign a single ringtone to all phone

numbers in the Addressbook.

Group calls

Assign a different ringtone to each

group.

Other calls

Assign one ringtone to the remain-

ing callers.

More melodies

Assign further ringtones for:

Messages

Alarm clock

Organizer

Startup melody

Shutdown mel.

or record new ones with:

Sound recorder (p. 113)

Setup90

t page

(90)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Setup Call setup

C¢T¢Call setup

¢Select function.

Hide ID b

When you make a call, your phone

number can be displayed on the

recipient's display (depending on the

service providers).

To suppress this display, you can

enable the "Hide ID" mode for all sub-

sequent calls or just for the next call.

You may need to register separately

with your service provider for these

functions.

Call waiting b

If you are registered for this service,

you can check whether it is set and

you can activate/deactivate it.

Divert

You can specify the conditions under

which calls should be diverted to

your mailbox or other numbers.

Status check

You can check the current divert sta-

tus for all conditions. After a short

pause, the current situation is trans-

mitted by the network and dis-

played.

ÖCondition set.

ÕNot set.

ÔDisplay if status is

unknown (e.g. with a new

SIM card).

Clear all b

All set diversions are cleared.

Set up call divert (example)

The most common condition for call

divert is, for example:

Unanswered b

ISelect Unanswered.

(Includes the conditions

Not reachable, No reply,

Busy, see below)

CConfirm.

Set Select.

CConfirm.

Ï/JSelect or enter the phone

number to which the calls

are to be diverted.

§Mailbox§ Use existing mail-

box phone numbers, or

enter them if necessary.

CConfirm. After a short

pause, the setting is con-

firmed by the network.

91Setup

t page

(91)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

All calls b

All calls are diverted.

ÇIcon in the top line of the

display in standby mode.

Not reachable

Divert occurs if the phone is

switched off or is out of range.

No reply

A call is only diverted after a delay

that is determined by the network.

The period can be set to a maximum

of 30 seconds in 5 second intervals.

Busy

Divert occurs if a call is in progress. If

Call waiting is activated (p. 33) you

will hear the call waiting tone during

a call (p. 35).

Receiving data b

Data calls are diverted to a phone

number with a PC connection.

Call screening b

Only calls from phone numbers that

are in the Phonebook/Addressbook

or assigned to a group are signalled.

Other calls are only displayed.

Any key

Incoming calls can be accepted by

pressing any key (except for B).

Minute beep

During a call you have initiated you,

and only you, will hear a beep

every minute so you can check the

call’s duration. The recipient does

not hear this beep.

Additional information

Note that the divert is stored in the network

and not in the phone (e.g., when the

SIM card is changed).

Reactivate divert

The last divert has been stored. Proceed as

with "Set divert". The stored phone number

is displayed. Confirm number.

Setup92

t page

(92)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Setup Phone setup

C¢T¢Phone setup

¢Select function.

Key tones

Set the type of acoustic key

acknowledgement.

Info tones

Set service and alarm tones:

On/off Activate/deactivate tones.

Extended If switched on, a wider

range of service tones is

available, e.g.: end of

menu reached, network

connection interrupted.

Automatic switch off

The phone switches off each day at

the set time.

Activate

§Time§ Press.

JEnter time

(24-hour clock).

CConfirm.

Deactivate

§Manual§ Press.

CConfirm.

Phone identity

The phone identity number (IMEI) is

displayed. This information may be

useful for customer service.

Alternatively enter in standby mode:

* # 0 6 #

§Info§ Display further informa-

tion about the appliance.

Device check

A self-test and an individual test are

offered after the last information

page. If you select Self test, all indi-

vidual tests are carried out.

Software version

Display the software version for your phone

in standby mode:

* # 0 6 #, then press §More§.

93Setup

t page

(93)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Memory assis.

The delete assistant will help you if

there is insufficient phone memory.

It is also started automatically from

applications if necessary.

After capacity has been checked, all

files and folders are displayed along

with their size and may be opened/

viewed and deleted if applicable.

File system

Format

(Phone-code protected)

The phone memory is formatted and

all saved data such as ringtones,

pictures, games etc. are deleted.

Formatting may take longer than

1minute.

Clean up

Creating more memory by deleting

temporary files that are no longer

required.

Fact. settings

Reset phone to default values (fac-

tory setting). This does not affect the

SIM card or the network settings.

Alternatively enter in standby mode:

* # 9 9 9 9 # A

Setup94

t page

(94)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Setup Clock

C¢T¢Clock

¢Select function.

Time/date

The clock must be set correctly once

at start-up.

§Change§ Press.

JFirst enter the date (day/

month/year), then the

time (hours/minutes/sec-

onds).

Time zones

The time zone can be selected in the

world map or a city list:

World map

FSelect the desired record-

ing.

City list

ISelect a city in the

selected time zone.

§Options§ Open menu.

Date format

Select the display format for the

date.

Time format

Select 24h or 12h.

Buddhist date

Switch to the Buddhist year (not on

all phone models).

Show clock

Activate/deactivate time display in

standby mode.

Auto time zone b

The time is set automatically via the

GSM network.

Additional information

If the battery is removed for longer than

30 seconds, the clock must be reset.

Set Set time zone.

Auto time

zone= Have the time zone set auto-

matically by the network.

Search city Search for a city.

Help Operating instructions.

95Setup

t page

)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Setup Connectivity

C¢T¢Connectivity

¢Select function.

GPRS b

(General Packet Radio Service)

CSwitch GPRS on/off

GPRS is a method for transmitting

data faster in the mobile network.

Use GPRS and, if the network has suf-

ficient capacity, you can be con-

nected to the Internet permanently.

Only the actual transmission time is

charged by the network operator.

Some service providers do not yet

support this service.

Shown in the display:

GPRS info

Displays information on connection

status.

IrDA

Your phone has an infrared inter-

face. With this interface, you can

exchange data such as pictures, ring-

tones, Addressbook entries, busi-

ness cards or organiser data with

other devices which also have an

infrared interface.

The infrared interface is on the left

side of the phone. The distance

between the two devices must not

exceed 30 cm. The infrared windows

in both appliances must be aligned

as accurately as possible with each

other.

Shown on the display:

¯IrDA activated.

®During transmission.

Data services

Basic setting and activation of the

connection profiles for data trans-

mission such as MMS, WAP.

The phone default setting varies

from service provider to service pro-

vider.

• The settings have already been

implemented by the provider. You

can start immediately.

• Access profiles have already been

created by your provider. Then

select profile and activate.

• The access profiles must be con-

figured manually.

£ Activated and available.

¢ Registered.

¤ Temporarily interrupted.

Setup96

t page

(96)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

If necessary, check with your service

provider for details. You will also find

the current settings for the service

provider on the Internet at this

address:

www.siemens.com/

mobilephonescustomercare

in the FAQ section.

Select profile

ISelect the profile.

CConfirm selection.

Set profile

ISelect the profile.

§Options§ Open menu.

§Edit§ Open the selection.

ISelect CSD settings, and/or

GPRS settings.

§Edit§ Make the settings as

specified by your service

provider.

HTTP profile

The phone default setting varies

from service provider to service pro-

vider.

• The settings have already been

implemented by the provider. You

can start immediately.

• Access profiles have already been

created by your provider. Then

select and activate profile.

• The access profiles must be con-

figured manually.

If necessary, check with your service

provider for details. You will also find

the current settings for the service

provider on the Internet at this

address:

www.siemens.com/

mobilephonescustomercare

in the FAQ section.

IMake the settings.

Authentication

Activate or deactivate encrypted

Internet dial-up (CSD connections

only).

97Setup

t page

)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Setup Security

C¢T¢Security

¢Select function.

Auto key lock

The keypad is locked automatically if

no key has been pressed for one

minute in standby mode. This pre-

vents the phone from being used

accidentally. However, you can still

be called and you can still make an

emergency call.

Direct call

(Phone-code protected)

Only one phone number can be

dialled (see also p. 37).

Only ‚b

(PIN2 or phone-code protected)

Dialling options are restricted to

SIM-protected phone numbers in the

Phonebook. If only area codes are

entered, relevant phone numbers

can be added to these manually

before dialling.

If the SIM card does not support PIN2

input, the whole Phonebook can be

protected with the phone code.

This SIM only b

(Phone-code protected)

The phone can be connected to a

SIM card when the phone code is

entered. Unless the phone code is

known the phone will not operate

with a different SIM card.

If the phone is to be used with a dif-

ferent SIM card, enter the phone

code when requested.

Codes

For description see p. 24:

PIN control, Change PIN, Change PIN2,

Chg.phonecode

Additional information

The keypad can also be directly locked and

unlocked in idle state.

In each case:

# Press and hold.

Setup98

t page

(98)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Barring b

Barring restricts the use of your

SIM card (not supported by all serv-

ice providers). You need a 4-digit

network password for network bar-

ring. Your service provider will give

you this password. You may need to

be registered separately for each

barring.

All outgoing

All outgoing calls except emergency

numbers are barred.

Outgoing intl.

(International outgoing)

Only national calls can be made.

Out.int.x home

(International outgoing without

home country)

International calls are not permitted.

However you can make calls to your

home country when abroad.

All incoming

The phone is barred for all incoming

calls (forwarding all calls to mailbox

provides a similar effect).

When roaming

You do not receive calls when you

are outside your home network. This

means that no charges are incurred

for incoming calls.

Status check

The following information can be

displayed after a status check:

ÖBarring set.

ÕBarring not set.

ÔStatus unknown

(e.g.new SIM card).

Clear all

All barrings are deleted. A password

which the service provider will give

you is necessary for this function.

99Setup

t page

(99)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Setup Network

C¢T¢Network

¢Select function.

Line b

This function is only displayed if it is

supported by the service provider.

Two separate phone numbers must be

registered on the phone.

Select line

Select the currently used phone

number.

\Display current phone

number in standby mode.

Protected

(Phone-code protected)

You may limit usage to one phone

number.

Network info

The list of GSM networks currently

available is displayed.

ÆIndicates non-authorised

service providers

(depending on SIM card).

Choose netwrk

Network search is restarted. This is

useful if you are not on your home

network or want to register on a dif-

ferent network. The network list is

rebuilt when Auto network is set.

Auto network

Activate/deactivate, see also Choose

netwrk above. If "Automatic network"

is activated, the next network on the

list is dialled in ranking order of your

"preferred networks". Otherwise a

different network can be selected

manually from the list of the availa-

ble GSM networks.

Preferred net

Enter your preferred service provid-

ers here for when you leave your

home network (e.g. if there are dif-

ferences in price).

Additional information

Special settings may be made for each

phone number (e.g., melody, call divert etc.)

To do this, first switch to the required phone

number.

Switch from phone number / connection in

standby mode:

0Press.

§Line 1§ Press.

Setup100

t page

(100)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Your service provider is displayed:

§List§ Display list of preferred

networks.

Create/change entry:

<Empty> or select an existing entry,

then select a new service

provider in the list and

confirm.

Record new service provider

(last entry in the list):

Furth.network

Select, enter the provider data and

save it.

Band selection b

Select either GSM 900, GSM 1800 or

GSM 1900.

Fast search

When this function is active, net-

work reconnection is speeded up

(standby time is reduced).

User group b

Depending on the service provider,

you can create groups with this serv-

ice. These can have access to inter-

nal (company) information, for

example, or special tariffs apply. The

details can be clarified with your

service provider.

Active

Activate/deactivate function. "User

group" must be deactivated for nor-

mal phone use.

Select group

You can select or add groups other

than preferred groups (see below).

Code numbers for the groups are

obtained from your service provider.

All outgoing

In addition to network control for a

user group, it is possible to set

whether outgoing calls outside the

group are permitted. If the function

is deactivated, only calls within the

group are permitted.

Pref. group

If activated, calls may only be made

within this standard user group

(depending on the network configu-

ration).

Additional information

If you are outside your home network, your

phone automatically dials another GSM

network.

If the signal strength of the preferred net-

work is inadequate when you switch on the

phone, the phone may register in a different

network. This can change when the tele-

phone is next switched on or if another net-

work is selected manually.

101Setup

t page

(101)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Setup Accessories

C¢T¢Accessories

¢Select function.

Car Kit

Only in combination with an original

Siemens handsfree car kit (see

accessories). The car kit profile is

activated automatically when the

phone is inserted into the cradle.

Auto answer

(factory default: off)

Calls are accepted automatically

after a few seconds. Eavesdropping

is possible!

ÅShown on the display.

Automatic switch off

(factory default: 2 hours)

The phone is powered by the car's

power supply. You can adjust the

time between switching off the igni-

tion and the phone switching off

automatically.

Car loudspk.

Improves playback in certain circum-

stances.

Automatic settings

• Permanent illumination:

switched on.

• Key lock: switched off.

• Charging the phone battery.

• Auto. activation of car kit profile

when the phone is inserted.

Headset

Only in conjunction with an original

Siemens headset (see accessories). If

an original Siemens headset is used

the profile is activated automatically

when the headset is plugged in.

Auto answer

(factory default: off)

Calls are accepted automatically

after a few seconds (except where

the ringer is switched off or set to

beep). You should therefore be

wearing the headset.

Automatic setting

Accept call with Call key or ptt key

(push to talk), even when the auto

key lock is activated.

Auto answer

If you do not notice that your phone has

accepted a call, there is the danger that the

caller may eavesdrop.

My menu102

t page

(102)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

My menu

CPress.

§My menu§ Press.

Create your own menu

with frequently used functions,

phone numbers or Browser pages.

The list of 10 entries is preset. You

can, however, change it as you wish.

Use

ISelect the required entry.

CConfirm.

AIf the entry selected is a

phone number, you can

also call it with the Call

key.

Change menu

You can replace each entry (1–10)

with another entry from the selec-

tion list.

ISelect the required entry.

§Change§ The function list is opened

for selection.

ISelect the new entry from

the list.

CConfirm. The entry is

saved.

If Phonebook is selected,

the phone number must

also be selected; if Internet

is selected, the bookmark

must also be selected.

Reset all

(Telephone code required)

§Reset all§ Select. Following confir-

mation, the pre-assign-

ment is reset.

103Fast access

t page

(103)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Fast access

You can assign one important phone

number or a function to each one of

the two soft keys and number keys

2 to 9 (speed-dial numbers). The

phone number can then be dialled or

the function started at the touch of a

button.

Soft keys

Change

For example, the Internet function is

assigned to the soft key. To change

this (in standby mode):

§Internet§ Press briefly.

§Change§ Scroll to new assignment

in the list.

CConfirm.

•Special case Phone number. Pick

out a name from the Phonebook/

Addressbook for assignment to

the key.

•Special case Bookmark. Scroll to a

URL in the bookmark list for

assignment to the key.

Apply

In standby mode:

Application

The "Internet" is just used as an

example here.

§Internet§ Press and hold; the appli-

cation is started.

Phone number

The setting "Carol" is used here only

as an example.

§Carol§ Press and hold, the phone

number is dialled.

Additional information

The service provider may have already

assigned functions to a soft key (e.g.,

access to "SIM services" or direct call-up of

the Internet portal). It may not be possible

to modify this key assignment.

The left soft key may sometimes be

replaced automatically by p/À to

access a new message, for example.

Z £ X

Service provider

01.03.2004 10:10

Internet í Help

Fast access104

t page

(104)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Speed dialling keys

Number keys 2 to 9 can be used as

speed dialling numbers for fast

access. Number key 1 is reserved for

the mailbox phone number (p. 68)

and number key 0 is reserved for

switching over two connections dur-

ing use (p. 99).

Change

In standby mode:

3Press number key briefly

(e.g. the 3).

This number is still free:

§Set§ Press.

Select a new function

from the list and confirm

with §OK§.

Or An assignment has

already been made to this

key (assignment dis-

played above the right

soft key):

CPress briefly.

§Change§ Scroll to application in the

list.

CConfirm.

• Special case Phone number. Pick

out a name from the Phonebook/

Addressbook for assignment to

the key.

• Special case Bookmark. Scroll to a

URL in the bookmark list for

assignment to the key.

Apply

Select a stored phone number or

start a stored application

(e.g. Internet).

In standby mode:

3Press briefly.

The assignment of the number key 3

is displayed above the right soft key

e.g.:

§Internet§ Press and hold.

Or simply

3Press and hold.

105Organizer

t page

(10

)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Organizer

Calendar

C¢Q¢Calendar

You can enter appointments in the

calendar. Time and date must be set

for the calendar to work correctly.

The calendar offers you three views:

Monthly view

Special colour coding:

Day with entries for appointments,

day of the week, weekend.

Navigation:

FOne day forward/back.

IOne week forward/back.

C Open daily view.

Weekly view

Special displays:

Appointments are shown as a verti-

cal colour bar on the horizontal hour

division.

Navigation:

FOne day forward/back.

IForward/backward by the

hour through the day.

Daily view

Special displays:

Description of appointment.

Navigation:

FOne day forward/back.

ITo the start/end of the day

or next/last entry.

Calend. setup

C¢Q¢Calend. setup

Start of day:

Time when the working day begins.

Start of week:

Weekday on which the monthly and

weekly view on the left starts.

Weekend

Set the days for the weekend.

Show birthdays:

Shown in the display.

Organizer106

t page

(106)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Appointments

C¢Q¢Appointments

Appointments are displayed in

chronological order in a list.

Enter new appointment

Select.

Types:

cMemo

Text input for description.

dVoice memo

Enter voice memo.

Shown with alarm.

eCall

Enter phone number to

be displayed with the

alarm.

fMeeting

Text input for description.

gVacation

Enter start and end date.

hBirthday

Enter name and date.

Different input/selection fields are

displayed depending on the type.

The number of fields can be

restricted, see Default at the end of

the list.

Description:

Description of appointment.

Phone number:

Enter a phone number or select one

from the address directory.

Voice memo:

Enter a voice recording, see

Dictat.machine, p. 109.

Location:

Location of appointment.

Whole day:

All-day appointment: Yes/No

Start date:

Date when appointment starts.

Start time:

Time when appointment starts.

End date:

Date when appointment ends.

End time:

Time when appointment ends.

107Organizer

t page

(10

)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Alarm time:

On/off or Silent alert.

JEnter the period of time

before the appointment

and select the time unit:

Minutes, Hours, Days

Recurrence:

Select a timeframe for repeating the

appointment:

No, Daily, Weekly, Monthly, Yearly.

Enter a parameter for repeating:

Forever, Until, Events (number).

If Weekly is selected, certain week-

days can be highlighted.

Default

In the list, select those fields which

are to be offered for future entries.

Information on the alarm

When the set date and time are

reached there is an audio and a vis-

ual alarm. If an alarm is missed it

appears in the list of missed appoint-

ments (p. 108).

Alarm type Memo

Meeting: The text is shown in the dis-

play.

Alarm type Call: The phone number

is displayed and can be dialled

immediately.

Alarm type Birthday: You can send

special birthday greetings by SMS,

MMS or a call via §Options§.

With Pause you can set the alarm to

repeat.

Additional information

Display above set alarms:

¹Alarm clock

»Appointment

An alarm sounds even when the phone is

switched off (except in Airplane mode,

p. 84). The phone does not go to standby

mode. Pressing any key will lead to Pause

(see below).

Organizer108

t page

(108)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Tasks

C¢Q¢Tasks

A task is displayed like an appoint-

ment in the agenda of the selected

day. However, unlike an appoint-

ment it does not require a time.

When no time is entered the task

appears at the top of the list every

day until it is marked as completed.

The entries are made in the same

way as Appointments (see "Appoint-

ments"). Then press

Status:

Select Done or Outstanding.

Priority:

Selection in 5 levels from Lowest to

Highest.

Use date:

If activated with Yes, the following

time-input option is offered.

Due date:/Expiry time:

Enter the date and time by which the

task is to be completed.

Alarm: and Default as for Appointments.

Notes

C¢Q¢Notes

Write and administer brief text

memos.

Enter a new memo

Select.

JInput text. The first line is

displayed as a "title" in the

memo list. Total length:

max. 160 characters.

§Options§ Open menu.

Save Save memo. When Confi-

dential is selected, a memo

is protected with the

phone code.

Missed appts.

C¢Q¢Missed appts.

Events with an alarm (Appointments,

Tasks) to which you have not reacted

are listed for reading.

109Organizer

t page

(109)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Organiser options

Depending on the application used

(Calendar, Appointments, Tasks, Notes)

and the current situation, different

functions are offered.

§Options§ Open menu.

Dictat.machine

C¢Q¢Dictat.machine

Use the dictating machine to record

short voice memos.

• Use your phone as a dictating

machine when on the move.

• Record a memo as a reminder or

as a note for others.

• Add a voice memo to an appoint-

ment in the calendar.

Delete Delete entry.

Delete by Delete all entries prior to a

certain date.

Delete all Delete all entries after

confirmation.

Delete done Delete all completed tasks.

Activate/

Deactivate Switch alarm on/off.

Filter Display all entries with the

selected feature.

Confidential Protect note with phone

code. We recommend that

you do not store any pass-

words (PIN, TAN etc.) as

notes.

(For standard functions see p. 22)

Organizer110

t page

(110)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

New recording

Select.

The remaining time avail-

able, as well as the record-

ing time, are shown in the

display.

CA brief tone sounds when

the recording starts. Now

say the text.

CAlternate between pause/

record.

DEnd recording.

The recording is automat-

ically saved with a time

stamp. Rename with

§Options§.

Playback

ISelect the desired

recording.

CAlternate between

playback/pause.

D/EPress and hold for rapid

rewind and fast forward.

Dictating machine options

§Options§ Open menu.

Time zones

C¢Q¢Time zones

The time zone can be selected in the

world map or a city list:

World map

FSelect the desired

recording.

City list

ISelect a city in the

selected time zone.

Time zone options

§Options§ Open menu.

Loudspeaker Playback through the

built-in loudspeaker.

(For standard functions, see p. 22)

Set Specify the time zone.

Auto time

zone= The time zone is switched

automatically to local time

by the network.

Search city Search for a city.

Help Operating instructions.

111Media player

t page

(111)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Media player

When you are viewing a picture or

listening to a melody, the applica-

tion starts a media playback.

FBrowse to the next media

file.

0–9Switch on display illumi-

nation.

Pictures

The following functions can be

applied to a displayed picture:

CZoom function if the dis-

played picture has a

higher resolution than the

display. The two soft keys

(+/–) enlarge/reduce the

picture. The joystick

moves the picture detail.

5 Centre the picture.

#Switch to full screen

mode and back again.

§Send§ Send via MMS or e-mail

for example.

Melodies

The media playback offers the fol-

lowing functions for melody play-

back:

CPlay or stop, depending

on the situation.

ISet volume.

*Switch to mute.

§Stop§ Pause function.

BEnd playback.

Options

§Options§ Open menu.

Different functions are offered

depending on the starting situation

and the object.

Volume Set the volume with the

joystick.

Set as... Set picture as Wallpaper,

Logo for example, and

sounds for Incoming call,

Startup melody, for

example.

Slideshow Automatic run-through in

full-picture mode. Individ-

ual picture connection with

joystick.

Edit Access to picture editing.

(For standard functions see p. 22)

Extras112

t page

(112)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Extras

SIM services (optional)

C¢S¢SIM services

Your service provider may offer spe-

cial applications such as mobile

banking, share prices, etc. via the

SIM card.

If you have such a SIM card, the SIM

services will appear in the main

menu under "Extras" or directly

above the soft key (on the left).

USymbol for SIM services.

Where there are several applications,

these are displayed in a SIM services

menu. With the SIM services menu,

your phone is ready to support

future additions in your service pro-

vider's user package. For further

information, please contact your

service provider.

Alarm clock

C¢S¢Alarm clock

The alarm will ring at the time set by

you, even when the phone is

switched off.

FActivate/deactivate the

alarm.

HSwitch to time setting.

JSet alarm call time

(hh:mm).

HSwitch to the week days.

FNavigate to the various

days.

CDisplay options: alarm call

time and days.

CSet days for alarm calls.

Press again to delete the

highlighting.

Press and hold to high-

light/unhighlight all the

days.

§OK§ Confirm setting.

Additional information

¹ Screen display in standby

mode: alarm clock activated.

With Pause you can set the alarm to

repeat.

éAlarm clock

§On§

07:30

Mo Tu We Th Fr Sa Su

Edit OK

113Extras

t page

(113)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Sound recorder

Use the Sound recorder to record

noises or sounds for use as ring-

tones. The Sound recorder is usually

started from other applications/func-

tions such as assigning a ringtone.

New recording

Start from main menu

C¢S¢Sound recorder

Select.

The remaining time avail-

able, as well as the record-

ing time, are shown in the

display.

Start it from another application as

follows

The recording display appears:

CA brief tone sounds when

the recording starts.

CAlternate between pause/

record.

DEnd recording.

The recording is saved

with a timestamp in the

Sounds folder. Rename

with §Options§.

§Insert§ Transfer the recording

into the application.

Playback

ISelect the desired

recording.

CAlternate between

playback/pause.

D/EPress and hold for rapid

rewind and fast forward.

§Options§ Open menu.

Loudspeaker Playback via the built-in

loudspeaker.

Set as... Set the recording as a

ringtone.

(For standard functions see p. 22)

Extras114

t page

(114)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Calc.

C¢S¢Calc.

The calculator can be used in a basic

version and with an advanced range

of functions. The input line and two

calculation lines (including the

matrix with the calculation func-

tions) are located in the top half of

the display.

JEnter digit(s).

F/INavigate functions.

CUse function. The result is

calculated and displayed

immediately.

Calculator options

§Options§ Open menu.

Unit converter

C¢S¢Unit converter

You can convert various measure-

ment units into other measurement

units.

The following types are offered with

various units:

Velocity

Energy

Mass

Pressure

Time

Volume

Area

Length

Power

Temperature

Currency

Basic functions

+, -, *, / Basic calculation types

=Result

1/x Reversion

%Convert to percentage

.Decimal point.

±Sign change "+"/"–"

§Options§ Expansion of the range of

functions:

Square root

Square

eExponent

MS Save displayed number

MR Call up saved number

M+ Insert number from memory

Convert Call up the unit con-

verter with the current

result.

Clear all Delete all units.

Extended mode/

Basic mode Convert calculation

functions.

(For standard functions see p. 22)

115Extras

t page

(11

)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Example using Velocity units:

Converting the units/currency

FSelect the source unit/

currency.

HSwitch to the input field.

JEnter the quantity to be

converted.

HSwitch to the selection

field.

FSelect the target meas-

urement unit/currency.

The result is displayed.

You can use both input fields alter-

nately.

Special key functions:

*Enter decimal point.

#Change sign.

Currency

When you call up the function, you

must enter a basic currency into

which the conversions are to be

made.

JEnter currency

(e.g. euro).

§Save§ Store entry.

Now enter the name and exchange

rate of the currency to be converted.

§Options§ Open menu.

Stopwatch

C¢S¢Stopwatch

Two intermediate times can be

recorded and saved.

CStart/stop.

*Save intermediate time.

After a stop:

CReset to zero.

Type Units

Velocity Kilometers/h, Meters/sec,

Miles/h, Miles/sec, Knots,

Mach

Add currency Enter new currency and

exchange rate.

Set as base Use entered currency as

basic currency.

Edit rate Change the exchange

rate of the basic currency.

Calc. Start calculator.

(For standard functions see p. 22)

Extras116

t page

(116)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Stopwatch options

§Options§ Open menu.

Countdown

C¢S¢Countdown

A set time elapses. The last

3 seconds are indicated by a beep.

At the end a special beep sounds.

If no time has been entered:

COpen input window.

JSet period of time.

CConfirm.

If a countdown time is specified:

CStart countdown.

While the time is elapsing:

CInterrupt counter.

CLet counter continue

running.

§Reset§ Reset counter to starting

time.

Remote synchronisation

C¢S¢Remote sync.

You can use this function remotely

to access externally filed data

(addresses, calendar, etc.) and syn-

chronise these with the data on your

phone. The data can, for example,

be saved on a company computer or

the Internet, e. g.:

www.siemens-mobile.com/syncml

Synchronise

§Sync§ The computer is selected

and synchronisation

started. When completed,

the actions which have

been performed are dis-

played.

§Next§ Scroll through the various

displays.

Sync. setting

The following settings can be made

prior to synchronisation:

Sync. profile

You can choose between 5 profiles.

ISelect profile.

CActivate profile.

Stopwatch list Display saved entries.

(For standard functions see p. 22)

117Extras

t page

(11

)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

§Edit§ Set profile

Server sett.

Last sync:

Time of the last synchronisation.

Sync. mode

•Sync data: Modified data or All data

•Sync instruction: Two-way,

Device update or Server update

Sync items:

Highlight database areas to be

synchronised:

Calendar

Address book

Notes

Tasks

CSave settings.

Providers Display the current serv-

ice provider.

Homepage: Set the homepage

Port: Enter port number.

e.g. 80.

(login name).

Password: Enter password (shown

as a series of asterisks).

Calendar path

Contacts path

Notes path

Task path

e.g., events

e.g., contacts

e.g., notes

e.g., tasks

HTTP authen-

tication. Confirmation required;

Yes/No (if No, the input

fields are not visible).

HTTP name: Enter name.

HTTP

password: Enter password.

My stuff118

t page

(118)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

My stuff

To organise your files, you can use

the file system like a PC file manager.

There are some folders for the

various data types in My stuff for this

purpose.

C¢N

The list of the folders and files is dis-

played.

Navigation

ISelect file/folder in lists.

F/IThe cursor can be moved

as required in the pre-

view.

COpen folder or start file

with related application.

The application for the folder cur-

rently selected is loaded.

The Browser is started and the URLs

for downloading displayed.

My stuff options

§Options§ Open menu.

Move Place highlighted file(s) or

folder in temporary memory.

Copy Place highlighted file(s) or

folder in temporary memory.

Paste Transfer content of temporary

memory into current folder.

New folder Create a new folder and

name it.

Preview Switch over to miniature

view.

Attributes Display information on file or

folder selected.

(For standard functions see p. 22)

119My stuff

t page

(119)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Index structure

Some folders have already been cre-

ated for different data types in

My stuff. These folders cannot be

changed.

Folder Description Format

Pictures Pictures bmp

bmx

jpg/

jpeg

png

gif

Anima-

tions Switch on/off

animations

bmx

gif

Sounds Melodies mid

amr

wav

Themes Loaded theme

(zipped)

sdt

Theme configura-

tion (unzipped)

stc

Skins Loaded user inter-

faces

scs

Games Java archive jar

Download info jad

Applica-

tions Applications *

Misc Text modules tmo

Voice recordings vmo

Depending on the service provider, the

structure, content and functionality of

My stuff may vary.

Mobile Phone Manager120

t page

(120)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(30

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Mobile Phone Manager

The MPM (Mobile Phone Manager)

enables you to use extended phone

functions from your PC. The phone

and PC communicate via a data cable

(see Accessories, p. 130) or IrDA.

You can download the latest version

of the MPM software from the Inter-

net at:

www.siemens.com/c72

Organiser

You can use the organiser to manage

the contacts and appointments you

have stored in your phone and syn-

chronise them between your phone,

Outlook® and other Siemens phones

(including Gigaset). You can use all

Call Control functions from the

organiser.

Call Control

You can dial straight from the organ-

iser at the click of a mouse. It also

makes establishing and managing

conference calls extremely easy –

the parties to the call are displayed

on-screen in a virtual conference

room, allowing you to swap effort-

lessly between the conference call

and a private call and to call and add

new subscribers at the click of a

mouse.

SMS and MMS management

Write EMS and SMS messages from

the convenience of your PC. Use all

the options your PC offers you and

use your sounds and pictures to cre-

ate SMS and EMS messages. You can

read, forward, print, delete and

archive your messages.

121Mobile Phone Manager

t page

(121)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(30

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Backup and restore

With the back-up function, you can

regularly make a back-up copy of

your phone data on the PC. If you

ever lose the data on your phone, or

replace the phone, you can quickly

re-instate all data with the restore

function. Please observe any possi-

ble restrictions for DRM-protected

data.

Bookmark Management

Use your PC to browse on the Inter-

net and define your preferred Inter-

net sites. Save the Internet addresses

as bookmarks on your phone so that

you can quickly call them up at a

later time when you are on the

move.

Phone explorer

You can access the data in your

phone quickly and easily with the

Phone Explorer. The phone is simply

integrated in the data structure of

your PC and handled exactly as if it

was another folder in your PC.

Mobile Modem Assistant

The Mobile Modem Assistant quickly

and easily establishes an Internet

connection via your mobile phone

enabling you to use your PC at home

or when travelling to surf the Inter-

net.

Mobile Phone Manager122

t page

(122)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(30

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Picture and photo processing

Picture/photo processing offers you

the opportunity to conveniently cre-

ate, edit and manage pictures and

photos. Filters and effects are

offered to help you create colourful,

attractive graphics. The user-friendly

interface makes child’s play of trans-

ferring pictures/photos from or to

the mobile phone, and of changing

the graphic settings.

My stuff

My stuff offers you a convenient

option for managing ringtones,

music, playlists and videos. You can

store your music files in your phone

automatically converting them into

a suitable format.

Plug & Sync

Plug & Sync carries out your routine

tasks for you as you wish. With

"Music > phone" you can always copy

your latest tracks and playlists auto-

matically to your phone. With "Pho-

tos > PC" you can transfer your newly

taken photos to your PC.

SmartSync

With SmartSync you can always syn-

chronise your data with Outlook®,

OutlookExpress® or Lotus Notes™ as

soon as the phone is connected to a

PC. New and changed contacts are

synchronised in just the same way as

messages and appointments.

Notifier

If your phone is connected to a PC

you will always be notified on the PC

screen, if required, about incoming

calls or messages – even when the

phone is switched to mute.

123Questions & Answers

t page

(123)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Questions & Answers

If you have any questions on the use of your phone, you can contact us at

www.siemens.com/mobilephonescustomercare around the clock. As further help we

have listed below some frequently asked questions and answers.

Problem Possible causes Possible solution

Phone cannot be

switched on.

On/Off key not pressed long

enough.

Press On/Off key for at least 2 seconds.

Flat battery. Charge battery. Check charging indicator in

the display.

Battery contacts dirty. Clean contacts.

See also below under

"Charging error".

Too little standby

time.

Frequent use of applications such

as organiser, games, camera.

Restrict use if applicable.

Fast search activated. Deactivate fast search(p. 100).

Display illumination switched on. Switch off display illumination (p. 87).

Unintentional keystrokes

(illumination!).

Activate key lock (p. 97).

Charging error

(charge icon not

displayed).

Battery totally discharged. 1) Plug in charger cable, battery is on charge.

2) Charge icon appears after approx. 2 hours.

3) Charge battery.

Temperature out of range:

+5 °C to +40 °C.

Make sure the ambient temperature is right, wait for

a while, then recharge.

Contact problem Check power supply and connection to the phone.

Check battery contacts and telephone connection

socket, clean them if necessary, then insert battery

again.

No mains voltage. Use different mains power socket; check mains

voltage.

Wrong charger. Only use original Siemens accessories.

Battery faulty. Replace battery.

SIM error. SIM card not inserted correctly. Check that the SIM card is inserted correctly

(p. 16).

Dirty SIM card contacts. Clean SIM card with a dry cloth.

SIM card with wrong voltage. Use 3V SIM cards only.

SIM card damaged

(e.g., broken).

Carry out a visual check. Ask service provider to

change SIM card.

Questions & Answers124

t page

(124)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

No network

connection.

Weak signal. Move higher, to a window or an open space.

Outside GSM range. Check service provider’s coverage area.

Invalid SIM card. Complain to the service provider.

New network not authorised. Try manual selection or select a different network

(p. 99).

Network call barring is set. Check network barrings (p. 98).

Network overloaded. Try again later.

Phone loses

network.

Signal too weak. Reconnection to another service provider is auto-

matic (p. 99). Switching phone off and on again can

speed this up.

Calls not possible. Second line set. Set first line \ (p. 100).

New SIM card inserted. Check for new barrings.

Charge limit reached. Reset limit with PIN2 (p. 49)

Credit used up. Load credit.

Certain uses of

phone not possible.

Call restrictions are in place. Barrings can be set by service provider.

Check barrings (p. 98).

Impossible to make

entries in Phone-

book/Addressbook.

Phonebook/Addressbook is full. Delete entries in the Addressbook (p. 39)/Phone-

book (p. 41).

Voice message not

functioning.

Call divert to mailbox not set. Set call divert to mailbox (p. 68).

ã flashes to indi-

cate an SMS.

SMS memory is full. Delete SMS or archive (p. 54).

ä flashes to indi-

cate an MMS.

MMS memory is full. Delete MMS.

å flashes to indi-

cate an MMS.

Phone memory full. Delete messages, pictures, games or applications.

Function cannot

be set.

Not supported by service pro-

vider or registration required.

Contact your service provider.

Capacity problems

with, for example,

Games & More, ring-

tones, pictures, SMS

archive.

Phone memory full. Delete files in the relevant areas. You can use the

memory assistant to delete specific files (p. 93).

No Browser access,

downloading not

possible.

Profile not activated, profile set-

tings wrong/incomplete.

Activate or set Browser profile (p. 79). If necessary

ask your service provider.

Problem Possible causes Possible solution

125Questions & Answers

t page

(12

)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Text message can-

not be sent.

Service provider does not sup-

port this service.

Contact your service provider.

Phone number for service

centre not set or incorrectly set.

Set service centre (p. 55).

SIM card contract does not sup-

port this service.

Contact your service provider.

Service centre too busy. Repeat message.

Recipient does not have a com-

patible phone.

Check.

EMS pictures &

sounds are not dis-

played on the desti-

nation phone.

Destination phone does not sup-

port the EMS standard.

No Internet access

possible.

Incorrect Browser profile set, or

wrong or incomplete settings.

Check Browser settings (p. 79); contact your serv-

ice provider if necessary.

PIN error/

PIN2 error.

Three wrong entries. Enter the PUK (MASTER PIN) supplied with the

SIM card according to the instructions. If the PUK

(MASTER PIN) has been lost, contact your service

provider.

Phone code error. Three wrong entries. Contact Siemens Service (p. 126).

Service provider

code error.

No authorisation for this service. Contact your service provider.

Missing/too many

menu entries

Functions may have been

added or deleted by the service

provider via the SIM card.

Check with your service provider.

Charge meter does

not work

Charge pulse is not being trans-

mitted.

Contact your service provider.

Damage

Severe shock Remove battery and SIM and re-insert them. Do not dismantle the phone!

Phone became wet. Remove battery and SIM. Dry immediately with a cloth, but do not apply heat.

Dry connector contacts thoroughly. Stand mobile upright in an air current. Do not dis-

mantle the phone!

Problem Possible causes Possible solution

Reset settings to the factory default, p. 93: * # 9 9 9 9 # A

Customer Care126

t page

(126)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050920

Customer Care

In some countries repair and replace serv-

ices are impossible where the products are

not sold through our authorised dealers.

If repair work is necessary, please contact

one of our service centres:

Abu Dhabi .........................................0 26 42 38 00

Argentina .....................................0 80 08 88 98 78

Australia..........................................13 00 66 53 66

Austria.............................................05 17 07 50 04

Bahrain .................................................... 40 42 34

Bangladesh.......................................0 17 52 74 47

Belgium.............................................0 78 15 22 21

Bolivia ...............................................0 21 21 41 14

Bosnia Herzegovina..........................0 33 27 66 49

Brunei ..................................................02 43 08 01

Bulgaria................................................02 73 94 88

Cambodia ............................................12 80 05 00

Canada ........................................1 88 87 77 02 11

Chile..................................................8 00 53 06 62

China ...........................................0 21 23 01 71 88

Colombia....................................01 80 07 00 66 24

Croatia ..............................................0 16 10 53 81

Czech Republic.................................2 33 03 27 27

Denmark ............................................. 35 25 86 00

Dubai ................................................0 43 96 64 33

Ecuador ..........................................18 00 10 10 00

Egypt.................................................0 23 33 41 11

Estonia.................................................. 6 30 47 97

Finland ............................................09 22 94 37 00

France.............................................01 56 38 42 00

Germany ......................................0 18 05 33 32 26

Greece ............................................80 11 11 11 16

Hong Kong.......................................... 28 61 11 18

Hungary ..........................................06 14 71 24 44

Iceland .................................................. 5 11 30 00

India .............................22 24 98 70 00 Extn: 70 40

Indonesia .....................................0 21 46 82 60 81

Ireland.............................................18 50 77 72 77

Italy .................................................02 24 36 44 00

Ivory Coast.......................................... 05 02 02 59

Jordan...............................................0 64 39 86 42

Kenya.................................................... 2 72 37 17

Kuwait ................................................... 2 45 41 78

Latvia .................................................... 7 50 11 18

Lebanon.............................................. 01 44 30 43

Libya ...............................................02 13 50 28 82

Lithuania ...........................................8 70 07 07 00

Luxembourg........................................ 43 84 33 99

Macedonia ........................................0 23 13 14 84

Malaysia....................................+ 6 03 77 12 43 04

Malta .......................................+ 35 32 14 94 06 32

Mauritius ............................................... 2 11 62 13

Mexico .......................................01 80 07 11 00 03

Morocco .............................................. 22 66 92 09

Netherlands .................................0 90 03 33 31 00

New Zealand...................................08 00 27 43 63

Nigeria ..............................................0 14 50 05 00

Norway................................................ 22 70 84 00

Oman ....................................................... 79 10 12

Pakistan ..........................................02 15 66 22 00

Paraguay ..........................................8 00 10 20 04

Peru ..................................................0 80 05 24 00

Philippines ........................................0 27 57 11 18

Poland.............................................08 01 30 00 30

Portugal ............................................8 08 20 15 21

Qatar................................................... 04 32 20 10

Romania .........................................02 12 09 99 66

We offer fast, individual advice! You have

several options:

Our online support on the Internet:

www.siemens.com/

mobilephonescustomercare

We can be reached any time, any place.

You are given 24 hour support on all

aspects of our products. Here you will find

an interactive fault-finding system, a com-

pilation of the most frequently asked ques-

tions and answers, plus user guides and

current software updates to download.

When calling customer service, please

have ready your receipt and the phone

identity number (IMEI, to display press

*#06#), the software version (to display,

press *#06#, then §More§) and if available,

your Siemens Service customer number.

127Customer Care

t page

(12

)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050920

Russia..........................................8 80 02 00 10 10

Saudi Arabia .....................................0 22 26 00 43

Serbia .............................................01 13 07 00 80

Singapore ............................................62 27 11 18

Slovak Republic ..............................02 59 68 22 66

Slovenia............................................0 14 74 63 36

South Africa ....................................08 60 10 11 57

Spain.................................................9 02 11 50 61

Sweden.............................................0 87 50 99 11

Switzerland .....................................08 48 21 20 00

Taiwan ............................................02 23 96 10 06

Thailand............................................0 27 22 11 18

Tunisia .................................................71 86 19 02

Turkey..........................................0 21 64 59 98 98

Ukraine ........................................8 80 05 01 00 00

United Arab Emirates........................0 43 66 03 86

United Kingdom ...........................0 87 05 33 44 11

USA .............................................1 88 87 77 02 11

Venezuela....................................0 80 01 00 56 66

Vietnam...........................................84 89 20 24 64

Zimbabwe ............................................04 36 94 24

Care and maintenance128

t page

(128)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Care and maintenance

Your phone has been designed and manu-

factured to the highest of standards and

should be treated with great care. The sug-

gestions below will help you to enjoy your

phone for many years.

• Protect your phone from moisture and

humidity. Precipitation, humidity and liq-

uids contain minerals that will corrode

electronic circuits. Nevertheless, should

your phone become wet, disconnect it

immediately from the power supply to

avoid electric shock. Do not place your

phone (even to dry it) on/in a source of

heat such as a microwave oven, oven or

radiator. The phone may become over-

heated and possibly explode.

• Do not use or store the phone in dusty,

dirty areas. Its moving parts may be

damaged and the casing may become

deformed and discoloured.

• Do not store your phone in hot environ-

ments (e.g. vehicle instrument panel in the

summer). High temperatures can shorten

the life of electronic devices, damage bat-

teries and warp or melt certain plastics.

• Do not store your phone in cold environ-

ments. When the phone warms up again

(to its normal ambient temperature), mois-

ture can form inside the phone, which may

damage electronic circuit boards.

• Do not drop, knock or shake your phone.

Rough handling can damage internal cir-

cuit boards!

• Do not use harsh chemicals, cleaning

solvents, or strong detergents to clean the

phone!

The suggestions given above apply equally

to your phone, battery, charger and all

accessories. If any of these parts is not work-

ing properly, obtain fast and reliable help at

our service centres.

Battery quality statement

The capacity of your mobile phone battery

will reduce each time it is charged/emptied.

Storage at too high or low temperatures will

also result in a graduly capacity loss. As

a result the operating time of your mobile

phone may be considerably reduced, evan

after a rull recharge of the battery.

Regardless of this, the battery has been

designed and manufactured so that it can be

recharged and used for six months after the

purchase of your mobile phone. After six

months, if the battery is clearly suffering from

loss of performance, we recommend that

your replace it. Please buy only Siemens

original batteries.

Display quality

declaration

For technological reasons, a few small dots

with different colours may appear in the dis-

play in exceptional cases.

Just remember that the appearance of

brighter or darker dots generally does not

mean that a fault has occurred.

129Product data

t page

(129)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(30

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Product data

Declaration of conformity

BenQ Mobile hereby declares that the phone

described in this user guide is in compliance

with the essential requirements and other

relevant provisions of European Directive

1999/5/EC (R&TTE). The relevant declara-

tion of conformity (DoC) has been signed.

Please call the company hotline if you

require a copy of the original:

www.siemens.com/mobiledocs

Technical data

Operating times

The operating time depends upon the

respective conditions of use. Extreme tem-

peratures considerably reduce the phone’s

standby time. Avoid placing the phone in the

sun or on a heater.

Talktime: 100 to 300 minutes.

Standby time: 60 to 300 hours

GSM class: 4 (2 watt)

Frequency range: 880–960 MHz

GSM class: 1 (1 watt)

Frequency range: 1,710–1,880 MHz

GSM class: 1 (1 watt)

Frequency range: 1,850–1,990 MHz

Weight: 86 g (3 oz)

Size: 105 × 47 × 18 mm

(75.6 ccm)

Li-Ion battery: 750 mAh

Operating

temperature:

–10 °C to 55 °C

(15 °F to 130 °F)

SIM card: 3.0 V

Phone ID

You will need the following details if you

lose your phone or SIM card:

the number of the SIM card (on the card):

...................................................................

15-digit serial number of the phone

(under the battery):

...................................................................

the customer service number of the service

provider:

...................................................................

Lost phone

If you lose your phone or SIM card contact

your service provider immediately to pre-

vent misuse.

Action taken Time

(min)

Reduction of stand-

by time by

Calling 1 30–90 minutes

Light * 1 40 minutes

Network

search 1 5–10 minutes

* Keypad input, games, organiser etc.

Accessories130

t page

(130)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(30

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Accessories

Fashion & Carry

Carrying Cases

Tour Case FCT-650

Belt Case FCL-600

Energy

Li-Ion battery EBA-660 (750 mAh)

Spare battery.

Desk Top Stand EDS-600

Desk top charging station for your phone.

Travel Charger

Travel Charger EU ETC-500

Travel Charger UK ETC-510

Travel charger with an extended input volt-

age range of 100–240 V.

Car Charger Plus ECC-600

Charger for the cigarette lighter socket in the

car. It is possible to make phone calls during

charging.

Handsfree Portable

Headset Basic HHS-500

Headset PTT HHS-510

Headset with ptt key (push to talk) to accept

and end calls.

Headset Purestyle HHS-610

High quality headset with detachable ear-

phones and ptt key (push to talk) to accept

and end calls.

Office

Data Cable DCA-500

For connecting the phone to the serial

RS232 port of the PC.

Data Cable USB DCA-540

For connecting the phone to the USB port of

the PC. With charging function.

SyncStation DSC-600

Table support for the phone to facilitate sim-

ultaneous data exchange and telephone

charging. Includes a desktop stand and a

USB data cable.

Siemens Original Accessories

www.siemens.com/shop

131Accessories

t page

(131)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(30

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Car Solutions

Mobile Holder HMH-660

Cradle without antenna port.

Mobile Holder Antenna HMH-665

The cradle for connecting an external

antenna. Ideal for use with Headset PTT or

Car Kit Portable.

Can also be used as cradle for retrofitting

your handsfree car kit

(series 55).

Car Kit Comfort Basic HKC-700

Handsfree car kit with first-class digital call

quality and supreme ease of use. Includes

all components needed for installation. The

individual antenna solution is available in

specialist shops.

Car Kit Easy HKP-700

Facilitates convenient handsfree talking with

high call quality. With the integrated, rotating

cradle and the flexible microphone position-

ing, the phone can be optimally adjusted to

suit any vehicle interior. The power is sup-

plied via the cigarette lighter socket.

Car Kit Portable HKP-500

The portable handsfree car kit can easily be

moved from one car to another. Simply plug

into the cigarette lighter socket, connect, and

talk.

Siemens Original Accessories

www.siemens.com/shop

SAR132

t page

(132)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

SAR

INFORMATION ON RF EXPOSURE/

SPECIFIC ABSORPTION RATE (SAR)

THIS MODEL MEETS THE GOVERN-

MENT’S REQUIREMENTS FOR EXPO-

SURE TO RADIO WAVES

Your cellular phone is a radio trans-

mitter and receiver. It is designed to

meet the requirements for exposure

to radio waves established by the

Federal Communications Commis-

sion (FCC, USA) and by Health Can-

ada. These requirements include

safety margins designed to assure

the protection of all persons, regard-

less of age and health. They use a

unit of measurement known as the

Specific Absorption Rate (SAR). The

SAR limit is 1.6 W/kg averaged over

one gram of tissue.

The highest SAR value for this

device when tested at the ear was

0.56 W/kg. In positions other than

the head, such as on the body, a sep-

aration distance of 2 cm is required.

The highest SAR value in this case

was 0.98 W/kg.

Information about this device model

can be found at

http://www.fcc.gov/oet/fccid

by searching the equipment authori-

zation system using FCC ID: PWX-C72.

As SAR is measured utilizing the

device’s highest transmitting power,

the actual SAR of this device while

operating is typically below that indi-

cated above. This is due to automatic

changes to the power level of the

device to ensure it only uses the min-

imum level required to reach the

network.

Additional Information can be found

on the websites of the World Health

Organization

http://www.who.int/emf

the Cellular Telecommunications

Industry Association (CTIA) web-site

www.phonefacts.net

the Canadian Wireless Telecommuni-

cations Association (CWTA) website

www.cwta.ca

or Siemens

www.siemens.com/mobilephones

133U.S. FDA

t page

(133)

C72

ormorant

FUG

105

143

, us-en,

A31008

H6090

A40

4A19

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

U.S. FDA

The U.S. Food and Drug Admin-

istration's (FDA) Center for

Devices and Radiological Health

Consumer Update on Mobile

Phones

FDA has been receiving inquiries

about the safety of mobile phones,

including cellular phones and PCS

phones. The following summarizes

what is know – and what remains

unknown – about whether these

products can pose a hazard to

health, and what can be done to

minimize any potential risk. This

information may be used to respond

to questions.

Why the concern?

Mobile phones emit low levels of

radio frequency energy (i.e., radio

frequency radiation) in the micro-

wave range while being used. They

also emit very low levels of radio fre-

quency energy (RF), considered non-

significant, when in the stand-by

mode. It is well known that high lev-

els of RF can produce biological dam-

age through heating effects (this is

how your microwave oven is able to

cook food). However, it is not known

whether, to what extent, or through

what mechanism, lower levels of RF

might cause adverse health effects

as well. Although some research has

been done to address these ques-

tions, no clear picture of the biologi-

cal effects of this type of radiation

has emerged to date. Thus, the avail-

able science does not allow us to

conclude that mobile phones are

absolutely safe, or that they are

unsafe. However, the available sci-

entific evidence does not demon-

strate adverse health effects associ-

ated with the use of mobile phones.

What kinds of phones are in question?

Questions have been raised about

hand-held mobile phones, the kind

that have a built-in antenna that is

positioned close to the user's head

during normal telephone conversa-

tion. These types of mobile phones

are of concern because of the short

distance between the phone's

antenna – the primary source of the

RF – and the person's head. The

exposure to RF from mobile phones

in which the antenna is located at

greater distances from the user (on

the outside of a car, for example) is

drastically lower than that from

hand-held phones, because a per-

son's RF exposure decreases rapidly

with distance from the source. The

safety of so-called “cordless phones,”

which have a base unit connected to

the telephone wiring in a house and

which operate at far lower power

levels and frequencies, has not been

questioned.

U.S. FDA134

t page

(134)

C72

ormorant

FUG

105

143

, us-en,

A31008

H6090

A40

4A19

(30

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

How much evidence is there that hand-

held mobile phones might be harmful?

Briefly, there is not enough evidence

to know for sure, either way; how-

ever, research efforts are on-going.

The existing scientific evidence is

conflicting and many of the studies

that have been done to date have

suffered from flaws in their research

methods. Animal experiments inves-

tigating the effects of RF exposures

characteristic of mobile phones have

yielded conflicting results. A few ani-

mal studies, however, have sug-

gested that low levels of RF could

accelerate the development of can-

cer in laboratory animals. In one

study, mice genetically altered to be

predisposed to developing one type

of cancer developed more than

twice as many such cancers when

they were exposed to RF energy

compared to controls. There is much

uncertainty among scientists about

whether results obtained from ani-

mal studies apply to the use of

mobile phones. First, it is uncertain

how to apply the results obtained in

rats and mice to humans. Second,

many of the studies showed

increased tumor development used

animals that had already been

treated with cancer-causing chemi-

cals, and other studies exposed the

animals to the RF virtually continu-

ously – up to 22 hours per day.

For the past five years in the United

States, the mobile phone industry

has supported research into the

safety of mobile phones. This

research has resulted in two findings

in particular that merit additional

study:

1. In a hospital-based, case-control

study, researchers looked for an

association between mobile phone

use and either glioma (a type of

brain cancer) or acoustic neuroma (a

benign tumor of the nerve sheath).

No statistically significant associa-

tion was found between mobile

phone use and acoustic neuroma.

There was also no association

between mobile phone use and glio-

mas when all types of gliomas were

considered together. It should be

noted that the average length of

mobile phone exposure in this study

was less than three years.

When 20 types of glioma were con-

sidered separately, however, an asso-

ciation was found between mobile

phone use and one rare type of gli-

oma, neuroepithelliomatous tumors.

It is possible with multiple compari-

sons of the same sample that this

association occurred by chance.

Moreover, the risk did not increase

with how often the mobile phone

was used, or the length of the calls. In

fact, the risk actually decreased with

cumulative hours of mobile phone

use. Most cancer causing agents

increase risk with increased expo-

sure. An ongoing study of brain can-

cers by the National Cancer Institute

is expected to bear on the accuracy

and repeatability of these results.1

135U.S. FDA

t page

(13

)

C72

ormorant

FUG

105

143

, us-en,

A31008

H6090

A40

4A19

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

2. Researchers conducted a large

battery of laboratory tests to assess

the effects of exposure to mobile

phone RF on genetic material. These

included tests for several kinds of

abnormalities, including mutations,

chromosomal aberrations, DNA

strand breaks, and structural

changes in the genetic material of

blood cells called lymphocytes. None

of the tests showed any effect of the

RF except for the micronucleus

assay, which detects structural

effects on the genetic material. The

cells in this assay showed changes

after exposure to simulated cell

phone radiation, but only after 24

hours of exposure. It is possible that

exposing the test cells to radiation

for this long resulted in heating.

Since this assay is known to be sensi-

tive to heating, heat alone could

have caused the abnormalities to

occur. The data already in the litera-

ture on the response of the micronu-

cleus assay to RF are conflicting.

Thus follow-up research is neces-

sary. 2

FDA is currently working with gov-

ernment, industry, and academic

groups to ensure the proper follow-

up to these industry-funded research

findings. Collaboration with the Cel-

lular Telecommunications Industry

Association (CTIA) in particular is

expected to lead to FDA providing

research recommendations and sci-

entific oversight of new CTIA-funded

research based on such recommen-

dations.

Two other studies of interest have

been reported recently in the litera-

ture:

• Two groups of 18 people were

exposed to simulated mobile

phone signals under laboratory

conditions while they performed

cognitive function tests. There

were no changes in the subjects'

ability to recall words, numbers,

or pictures, or in their spatial

memory, but they were able to

make choices more quickly in one

visual test when they were

exposed to simulated mobile

phone signals. This was the only

change noted among more than

20 variables compared.3

• In a study of 209 brain tumor

cases and 425 matched controls,

there was no increased risk of

brain tumors associated with

mobile phone use. When tumors

did exist in certain locations, how-

ever, they were more likely to be

on the side of the head where the

mobile phone was used. Because

this occurred in only a small

number of cases, the increased

likelihood was too small to be sta-

tistically significant.4

In summary, we do not have enough

information at this point to assure

the public that there are, or are not,

any low incident health problems

U.S. FDA136

t page

(136)

C72

ormorant

FUG

105

143

, us-en,

A31008

H6090

A40

4A19

(30

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

associated with use of mobile

phones. FDA continues to work with

all parties, including other federal

agencies and industry, to assure that

research is undertaken to provide

the necessary answers to the out-

standing questions about the safety

of mobile phones.

What is known about cases of human

cancer that have been reported in users

of hand-held mobile phones?

Some people who have used mobile

phones have been diagnosed with

brain cancer. But it is important to

understand that this type of cancer

also occurs among people who have

not used mobile phones. In fact,

brain cancer occurs in the U.S. popu-

lation at a rate of about 6 new cases

per 100,000 people each year. At

that rate, assuming 80 million users

of mobile phones (a number increas-

ing at a rate of about 1 million per

month), about 4800 cases of brain

cancer would be expected each year

among those 80 million people,

whether or not they used their

phones. Thus it is not possible to tell

whether any individual's cancer

arose because of the phone, or

whether it would have happened

anyway. A key question is whether

the risk of getting a particular form

of cancer is greater among people

who use mobile phones than among

the rest of the population. One way

to answer that question is to com-

pare the usage of mobile phones

among people with brain cancer

with the use of mobile phones

among appropriately matched peo-

ple without brain cancer. This is

called a case-control study. The cur-

rent case-control study of brain can-

cers by the National Cancer Institute,

as well as the follow-up research to

be sponsored by industry, will begin

to generate this type of information.

What is FDA's role concerning the safety

of mobile phones?

Under the law, FDA does not review

the safety of radiation emitting con-

sumer products such as mobile

phones before marketing, as it does

with new drugs or medical devices.

However, the agency has authority

to take action if mobile phones are

shown to emit radiation at a level

that is hazardous to the user. In such

a case, FDA could require the manu-

facturers of mobile phones to notify

users of the health hazard and to

repair, replace or recall the phones

so that the hazard no longer exists.

Although the existing scientific data

do not justify FDA regulatory actions

at this time, FDA has urged the

mobile phone industry to take a

number of steps to assure public

safety. The agency has recom-

mended that the industry:

• Support needed research into pos-

sible biological effects of RF of the

type emitted by mobile phones;

137U.S. FDA

t page

(13

)

C72

ormorant

FUG

105

143

, us-en,

A31008

H6090

A40

4A19

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

• Design mobile phones in a way

that minimizes any RF exposure to

the user that is not necessary for

device function; and

• Cooperate in providing mobile

phone users with the best possible

information on what is known

about possible effects of mobile

phone use on human health.

At the same time, FDA belongs to an

interagency working group of the

federal agencies that have responsi-

bility for different aspects of mobile

phone safety to ensure a coordi-

nated effort at the federal level.

These agencies are:

• National Institute for Occupa-

tional Safety and Health

• Environmental Protection Agency

• Federal Communications Com-

mission

• Occupational Health and Safety

Administration

• National Telecommunications and

Information Administration

The National Institutes of Health also

participates in this group.

In the absence of conclusive information

about any possible risk, what can con-

cerned individuals do?

If there is a risk from these products

– and at this point we do not know

that there is – it is probably very

small. But if people are concerned

about avoiding even potential risks,

there are simple steps they can take

to do so. For example, time is a key

factor in how much exposure a per-

son receives. Those persons who

spend long periods of time on their

hand-held mobile phones could con-

sider holding lengthy conversations

on conventional phones and reserv-

ing the hand-held models for shorter

conversations or for situations when

other types of phones are not availa-

ble.

People who must conduct extended

conversations in their cars every day

could switch to a type of mobile

phone that places more distance

between their bodies and the source

of the RF, since the exposure level

drops off dramatically with distance.

For example, they could switch to:

• a mobile phone in which the

antenna is located outside the

vehicle,

• a hand-held phone with a built-in

antenna connected to a different

antenna mounted on the outside

of the car or built into a separate

package, or

• a headset with a remote antenna

to a mobile phone carried at the

waist.

U.S. FDA138

t page

(138)

C72

ormorant

FUG

105

143

, us-en,

A31008

H6090

A40

4A19

(30

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Where can I find additional information?

For additional information, see the

following websites:

• Federal Communications Com-

mission (FCC) RF Safety Program

(select “Information on Human

Exposure to RF Fields from Cellular

and PCS Radio Transmitters”):

http://www.fcc.gov/oet/rfsafety

• World Health Organization (WHO)

International Commission on

Non-Ionizing Radiation Protection

(select Qs & As):

http://www.who.int/emf

• United Kingdom, National Radio-

logical Protection Board:

http://www.nrpb.org.uk

• Cellular Telecommunications

Industry Association (CTIA):

http://www.wow-com.com

• U.S. Food and Drug Administra-

tion (FDA) Center for devices and

Radiological Health:

http://www.fda.gov/cdhr/consumer/

1 Muscat et al. Epidemiological Study of Cel-

lular Telephone Use and Malignant Brain

Tumors. In: State of the Science Sympo-

sium; 1999 June 20; Long Beach, California.

2 Tice et al. Tests of mobile phone signals for

activity in genotoxicity and other laboratory

assays. In: Annual Meeting of the Environ-

mental Mutagen Society; March 29, 1999,

Washington, DC; and personal communica-

tion, unpublished results.

3 Preece, AW, Iwi, G, Davies-Smith, A,

Wesnes, K, Butler, S, Lim, E, and Varey, A.

Effect of a 915- MHz simulated mobile

phone signal on cognitive function in man.

Int. J. Radiat. Biol., April 8, 1999.

4 Hardell, L, Nasman, A, Pahlson, A, Hal-

lquist, A and Mild, KH. Use of cellular tele-

phones and the risk for brain tumors; a case-

control study. Int. J. Oncol, 15: 113-116,

1999.

139FCC/Industry Canada Notice

t page

(139)

C72

ormorant

FUG

105

143

, us-en,

A31008

H6090

A40

4A19

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

FCC/Industry Canada Notice

Your phone may cause TV or radio

interference (for example, when

using a telephone in close proximity

to receiving equipment). The FCC or

Industry Canada can require you to

stop using your telephone if such

interference cannot be eliminated. If

you require assistance, please con-

tact your local service facility.

This device complies with part 15 of

the FCC rules. Operation is subject to

the condition that this device does

not cause harmful interference.

Intellectual Property140

t page

(140)

C72

ormorant

FUG

105

143

, us-en,

A31008

H6090

A40

4A19

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Intellectual Property

Intellectual Property Restrictions

All Intellectual Property, as defined

below, which is owned by or other-

wise the property of Siemens Infor-

mation and Communications

Mobile, LLC (“Siemens”), its affili-

ates, partners or suppliers, relating

to the Phone, including but not lim-

ited to accessories, parts or software

relating thereto (the “Phone Sys-

tem”), is proprietary under federal

laws, state laws and International

treaty provisions. Intellectual Prop-

erty includes, but is not limited to,

inventions (patentable or unpatent-

able), patents, trade secrets, copy-

rights, software, computer pro-

grams, and related documentation

and other works of authorship. You

may not infringe or otherwise violate

the rights secured by the Intellectual

Property. Moreover, you agree that

you will not (and will not attempt to)

disassemble, decompile, reverse

engineer, prepare derivative works

from, modify or make any other

effort to create source code from the

software. No title to ownership in

the Intellectual Property is trans-

ferred to you through purchase or

possession of the Phone or its com-

ponents. All applicable rights of the

Intellectual Property shall remain

with Siemens, its affiliates, partners

or suppliers.

Siemens will have no liability with

respect to any claim of patent

infringement which is based upon

the combination of the Product or

parts furnished hereunder with soft-

ware, apparatus or devices not fur-

nished by Siemens, nor will Siemens

have any liability for the use of ancil-

lary equipment or software not fur-

nished by Siemens which is attached

to or used in connection with the

Product, The foregoing states the

entire liability of Siemens with

respect to infringement of patents

by the Product or any parts thereof.

Laws in the United States and other

countries preserve for Siemens cer-

tain exclusive rights for copyrighted

Siemens software, such as the exclu-

sive rights to reproduce and distrib-

ute copies of such Siemens software.

Siemens software may be used only

in the Product in which the software

was originally embodied when pur-

chased, and such software in such

Product may not be replaced, copied,

distributed. modified in any way, or

used to produce any derivative

thereof. No other use including, with-

out limitation, alteration, modifica-

tion, reproduction, distribution. or

reverse engineering of such Siemens

software or exercise of rights in such

Siemens software is permitted. No

license is granted by implication,

estoppel or otherwise under Siemens

patent rights or copyrights.

141Ten Driving Safety Tips

t page

(141)

C72

ormorant

FUG

105

143

, us-en,

A31008

H6090

A40

4A19

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Ten Driving Safety

Tips

Your Siemens wireless phone gives

you the power to communicate by

voice – almost anywhere, anytime.

But an important responsibility

accompanies the benefits of wireless

phones, one that every user must

uphold.

When driving a car, driving is your

first responsibility. When using your

wireless phone behind the wheel of

a car, practice good common sense

and remember the following tips:

Get to know your phone and its features

such as speed dial and redial.

Carefully read your instruction man-

ual and learn to take advantage of

valuable features most phones offer

including, automatic redial and

memory dial – most phones can

store up to 99 numbers in memory

dial. Also, work to memorize the

phone keypad so you can use the

speed dial function without taking

your attention off the road.

When available, use a

hands-free device. b

A number of hands-free wireless

phone accessories are readily availa-

ble today. Whether you choose an

installed mounted device for your

phone or a speaker phone accessory,

take advantage of these devices if

they are available to you.

Position your phone within easy reach.

Make sure you place your wireless

phone within easy reach and where

you can grab it without removing

your eyes from the road. If you get

an incoming call at an inconvenient

time, let your voicemail answer it for

you.

Suspend conversations during hazard-

ous driving conditions or situations.

Let the person you are speaking to

know you are driving; if necessary,

suspend the call in heavy traffic or

hazardous weather conditions. Rain,

sleet, snow and ice can be hazard-

ous, but so is heavy traffic. As a

driver, your first responsibility is to

pay attention to the road.

Do not take notes or look up

phone numbers while driving.

If you are reading an address book or

business card while driving a car, or

writing a “to do” list, then you are not

watching where you are going. It’s

common sense. Don’t get caught in a

dangerous situation because you are

reading or writing and not paying

attention to the road or nearby

vehicles.

Ten Driving Safety Tips142

t page

(142)

C72

ormorant

FUG

105

143

, us-en,

A31008

H6090

A40

4A19

(30

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Dial sensibly and assess the traffic.

If possible, place calls when you are

not moving or before pulling into

traffic. Try to plan your calls before

you begin your trip, or attempt to

coincide your calls with times you

may be stopped at a stop sign, red

light or otherwise stationary. But if

you need to dial while driving, follow

this simple tip – dial only a few num-

bers, check the road and your mirrors,

then continue.

Do not engage in stressful or emotional

conversations that may be distracting.

Stressful or emotional conversations

and driving do not mix – they are dis-

tracting and even dangerous when

you are behind the wheel. Make peo-

ple you are talking with aware you

are driving and if necessary, suspend

phone conversations that have the

potential to divert your attention

from the road.

Use your phone to call for help.

Your wireless phone is one of the

greatest tools you can own to pro-

tect yourself and your family in dan-

gerous situations – with your phone

at your side, help is only three num-

bers away. Dial 9-1-1 in the case of

fire, traffic accident, road hazard, or

medical emergency. Remember, it is

a free call on your wireless phone.

Use your phone to help others in

emergencies.

Your wireless phone provides you a

perfect opportunity to be a “good

Samaritan” in your community. If

you see an auto accident, crime in

progress or other serious emergen-

cies where lives are in danger, call

9-1-1, as you would want others to

do for you.

Call roadside assistance or a special

wireless non-emergency assistance

number when necessary.

Certain situations you encounter

while driving may require attention,

but are not urgent enough to merit a

call to 9-1-1. But you can still use

your wireless phone to lend a hand.

If you see a broken-down vehicle

posing no serious hazard, a broken

traffic signal, a minor traffic accident

where no one appears injured, or a

vehicle you know to be stolen, call

roadside assistance or other special

non-emergency wireless numbers.

Provided by the Cellular Telecommunica-

tions Industry Association (CTIA)

“The wireless industry reminds you to

use your phone safely when driving.”

For more information, please call

1 (888) 901-SAFE, or visit our Web site

at: www.wow-com.com

143End user license agreement

t page

(143)

C72

ormorant

FUG

105

143

, us-en,

A31008

H6090

A40

4A19

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

End user license agreement

This Software License Agreement

("Agreement") is between You and

Siemens Information and Communi-

cation Mobile, LLC and/or one of its

affiliates ("Licensor"). The Agree-

ment authorizes You to use the Soft-

ware specified in Clause 1 below,

which may be included on Your

phone, stored on a CD-ROM, sent to

You by electronic mail, downloaded

from Licensor's Web pages or servers

or from other sources under the

terms and conditions set forth

below. This is an agreement on end

user rights and not an agreement for

sale. Licensor continues to own the

copy of the Software and any other

copy that You are authorized to

make pursuant to this Agreement.

Read this Agreement carefully

before installing, downloading or

using the Software. Further, by

installing, downloading and/or using

the Software, You agree to the terms

and conditions of this Agreement.

1. Software.

As used in this Agreement, the term

"Software" means, collectively: (i) all

the software in Your phone, all of the

contents of the disk(s), CD-ROM(s),

electronic mail and its file attach-

ments, or other media with which

this Agreement is provided; (ii)

related Licensor or third party soft-

ware; (iii) digital images, stock pho-

tographs, clip art or other artistic

works ("Stock Files") (iv) related

explanatory written materials

("Documentation"); (v) fonts

(vi) upgrades, modified versions,

updates, additions and copies of the

Software, if any, licensed to You by

Licensor (collectively "Updates") and

(vii) any other possible documenta-

tion related thereto.

2. End user rights and use.

Licensor grants to You a non-exclu-

sive, non-transferable end user right

to install the Software or use the

Software installed on the phone. The

Software is licensed with the phone

as a single integrated product and

may be used with the phone only as

set forth in these licensing terms.

3. Limitations on end user rights.

(a) You may not copy, distribute, or

make derivative works of the Soft-

ware.

(b) You may not use, modify, trans-

late, reproduce or transfer the right

to use the Software or copy the Soft-

ware except as expressly provided in

this Agreement.

rent, lease or lend the Software;

except You may permanently trans-

fer all of Your rights as set forth in

the Agreement only as part of a per-

manent sale or transfer of the

phone, provided the recipient agrees

to the terms of this Agreement.

End user license agreement144

t page

(144)

C72

ormorant

FUG

105

143

, us-en,

A31008

H6090

A40

4A19

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

(d) You may not reverse engineer,

reverse compile, disassemble or oth-

erwise attempt to discover the

source code of the Software (except

to the extent that this restriction is

expressly prohibited by law) or cre-

ate derivative works based on the

Software.

(e) You shall not display, modify,

reproduce or distribute any of the

Stock Files included with the

Software.

(f) You shall not display, modify,

reproduce or distribute any of the

pre-loaded content included with

the software unless permitted as

stated in the User Guide or in the

prompts in the Software. In the

event that You are allowed to dis-

play, modify, reproduce or distribute

certain parts of the pre-loaded con-

tent, You shall review the "Readme"

files associated with the pre-loaded

content (contained on the CD) to

ascertain what rights You have with

respect to such materials. Pre-loaded

content may not be used in the pro-

duction of libelous, defamatory,

fraudulent, infringing, lewd,

obscene or pornographic material or

in any otherwise illegal manner. You

agree that You shall only use the pre-

loaded content in a manner that

complies with all applicable laws,

including, but not limited to, applica-

ble restrictions concerning copyright

and other intellectual property

rights. You may not register or claim

any rights in the pre-loaded content

or derivative works thereof.

(g) You agree that You shall only use

the Software in a manner that com-

plies with all applicable laws in the

jurisdiction in which You use the

Software, including, but not limited

to, applicable restrictions concern-

ing copyright and other intellectual

property rights.

4. Copyright.

Licensor and/or its software suppli-

ers and their respective affiliates

own the Software and all rights,

including without limitation includ-

ing proprietary rights therein, are

protected by international treaty

provisions and other applicable

national laws of the country in which

it is being used. The structure,

organization and code of the Soft-

ware are the valuable trade secrets

and confidential information.

5. Multiple copies/updates.

If the Software supports multiple

platforms or languages, if You

receive the Software on multiple

media, of if You otherwise receive

multiple copies of the Software, the

number of phones on which all ver-

sions of the Software are installed

shall be one phone. If the Software is

an Update to a previous version of

the Software, You must possess a

valid end user right to such previous

version in order to use the Update

and You may use the previous ver-

145End user license agreement

t page

(14

)

C72

ormorant

FUG

105

143

, us-en,

A31008

H6090

A40

4A19

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

sion for ninety (90) days after You

receive the Update in order to assist

You in the transition to the Update.

After such time You no longer have a

right to use the previous version,

except for the sole purpose of ena-

bling You to install the Update.

6. Commencement & termination.

This Agreement is effective from the

first date You use or install the Soft-

ware. Your end user rights automati-

cally and immediately terminate

without notice from Licensor if You

fail to comply with any provision of

this Agreement. In such event, You

must immediately delete, destroy or

return at Your own cost and

expense, and without entitlement to

any refund of the purchase price, the

phone and the Software, and all

related material to Licensor.

7. Except as expressly provided in the

limited warranty for the phone, you

acknowledge the Software is pro-

vided "as is" without warranty of any

kind express or implied. To the maxi-

mum extent permitted by applicable

law neither Licensor, Licensor's Soft-

ware suppliers or their respective

affiliates, nor the copyright holders

make any representations or warran-

ties, express or implied, including

but not limited to the warranties of

merchantability or fitness for a par-

ticular purpose or that the Software

will not infringe any third party pat-

ents, copyrights, trademarks or

other rights. There is no warranty by

Licensor or by any other party that

the functions contained in the Soft-

ware will meet your requirements or

that the operation of the Software

will be uninterrupted or error free.

8. Not fault tolerant. The Software

may contain technoloy that is not

fault tolerant and is not designed,

manufactured, or intended for use in

environments or applications in

which the failure of the licensed

Software could lead direclty to

death, personal injury, or severe

physical or environmental damage

or financial loss.

9. Limitation of liability.

To the maximum extent permitted

by applicable law, in no event shall

Licensor or Licensor's Software sup-

pliers or their respecitve affiliates

and employees be liable for any lost

profits, revenue, sales, data or costs

of procurement of substitute goods

or services, property damage, per-

sonal injury, interruption of busi-

ness, loss of business information or

for any special, direct, indirect, inci-

dental, economic, cover, punitive,

special or consequential damages,

however caused and whether arising

under contract, tort, negligence, or

other theory of liability arising out of

the use of or inability to use the Soft-

ware, even if Licensor or its Software

suppliers are advised of the possibil-

ity of such damages. Because some

countries/states/jurisdictions do not

allow the exclusion or limitation of

End user license agreement146

t page

(146)

C72

ormorant

FUG

105

143

, us-en,

A31008

H6090

A40

4A19

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

liability, but may allow liability to be

limited, in such cases, the liability of

Licensor, its Software suppliers and

their respective affiliates and

employees shall be limited to, at

Licensor's option, either (a) return of

the price paid less a reasonable

amount for usage, or (b) repair or

replacment of the Software that

does not meet the limited warranty

provided with the phone and which

is returned in accordance with the

requirements of the limited war-

ranty.

Nothing contained in this Agree-

ment shall prejudice the statutory

rights of any party dealing as a con-

sumer. Nothing contained in this

Agreement limits Licensor's liability

to You in the event of death or per-

sonal injury resulting from Licensor's

negligence if law prohibits such a

limitation. Licensor is acting on

behalf of its software suppliers and

their respective employees and affili-

ates for the purpose of disclaiming,

excluding and/or restricting obliga-

tions, warranties and liability as pro-

vided in this clause 9, but in no other

respects and for no other purpose.

10. Technical support.

Licensor has no obligation to furnish

You with technical support except as

agreed in writing between You and

Licensor in the Limited Warranty pro-

vided with the phone.

11. Export control.

The Software may be subject to

export regulations of the United

States and other countries. You

agree that You shall comply with all

applicable export laws, restrictions

and regulations of the United States

or foreign agencies or authorities,

and shall not export, or transfer for

the purpose of re-export, any Soft-

ware, product or technical data

received under this Agreement or

any Software or product produced

by use of such technical data, includ-

ing processes and services, in viola-

tion of any applicable restrictions,

laws or regulations, or without all

necessary approvals.

12. Applicable law & general provisions.

This Agreement shall be governed by

and construed in accordance with

the laws of the State of California

without regard to its conflicts of laws

rules. This is the entire agreement

between Licensor and You relating

to the Software and it supersedes

any prior representations, discus-

sions, undertakings, end user agree-

ments, communications or advertis-

ing relating to the Software.

147Menu tree

t page

(14

)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Menu tree

Default book >Show entries

Business card

Groups

Default book

Call records >Missed calls

Calls received

Calls dialed

Delete records

Time/charges >Last call

All outgoing

All incom.calls

Remain. units

Charge setting >Currency

Charge/Unit

Surf & fun >URL/Serv. provider Account limit

Games Auto display

Applications

Download wiz.

Bookmarks

Internet

Camera

Messages >Create new >SMS

MMS

E-mail

Chat room

Menu tree148

t page

(148)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Messages >Inbox >SMS

MMS

E-mail

WAP push

Retrieve email

Send/receive

CB services

Draft >SMS

MMS

E-mail

Unsent >SMS

MMS

E-mail

Retrieve email

Send/receive

Sent items >SMS

MMS templates MMS

E-mail

SMS archive

Text modules

Msg settings >Text zoom

SMS setup >SMS Profile

MMS settings SMS Signature

E-mail >Accounts

General sett.

Help

WAP push set. >Security sett.

Voice message Help

149Menu tree

t page

(149)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Messages CB services >Receive CB

Read new CB

Topic list

Auto display

Topic index

CB languages

Organizer >Calendar

Appointments

Tasks

Notes

Missed appts.

Organizer >Dictat.machine

Time zones

Calend. setup

Extras >SIM services

Alarm clock

Sound recorder

Calc.

Unit converter

Stopwatch

Countdown

Remote sync.

My stuff

Settings >Profiles

Topics

Display >Language

Text input >T9 preferred

Wallpaper Input language

Logo

Menu tree150

t page

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Color scheme

Screensaver

Start up anim.

Shutdn anim.

Greeting

Large letters

Illumination

Ring tones >Ringer setting

Silent alert

Settings >Ring tones >Volume >Calls

d Calls Messages

Group calls CB services

Other calls Alarm clock

Organizer

System

Applications

More melodies >Messages

Alarm clock

Organizer

Startup melody

Shutdown mel.

Sound recorder

Call setup >Hide ID

Call waiting

Divert >All calls

Call screening Unansw. calls

Any key Not reachable

Minute beep No reply

Busy

151Menu tree

t page

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Status check

Clear all

Phone setup >Key tones

Info tones

Automatic switch off

Phone identity

Memory assis.

File system >Format

Fact. settings Clean up

Settings >Clock >Time/date

Time zones

Date format

Time format

Buddhist date

Show clock

Auto time zone

Connectivity >GPRS

GPRS info

IrDA

Data services

HTTP profile

Authentication

Security >Auto key lock

Direct call

Only ‚

Codes >PIN control

Change PIN

Change PIN2

Chg.phonecode

Menu tree152

t page

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

This SIM only

Barring >All outgoing

Outgoing intl.

Out.int.x home

All incoming

When roaming

Status check

Clear all

Settings >Network >Line >Select line

Network info Protected

Choose netwrk

Auto network

Preferred net

Band selection

Fast search

User group >Active

Select group

All outgoing

Pref. group

Accessories >Car Kit >Auto answer

Automatic switch off

Car loudspk.

Headset >Auto answer

153Index

t page

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Index

Accessories ....................................... 130

Addressbook

Dial entry........................................ 41

Groups ........................................... 42

New entry ...................................... 39

Read entry......................................41

Aircraft mode...................................... 84

Alarm

Alarm clock................................... 112

Type ............................................. 107

Alarm clock....................................... 112

All calls (call time/charge) ................... 49

All calls (diversion).............................. 91

All incoming (barrings) ....................... 98

Answering service (external)............... 68

Any to answer..................................... 91

Appointments................................... 106

Auto display

Clock .............................................. 94

Duration/charges ............................ 49

Auto key lock................................ 13, 97

Auto time zone ........................... 94, 110

Auto. network selection ...................... 99

Auto. redial......................................... 33

Automobile accessories..................... 131

Band selection .................................. 100

Battery

Charge ........................................... 17

Insert.............................................. 16

Operating times...................... 18, 129

quality declaration........................ 128

Big letters ........................................... 87

Bookmarks.................................... 77, 79

Browser .............................................. 78

Buddh. year ........................................ 94

Business card...................................... 38

Busy number ...................................... 33

Calculator......................................... 114

Calendar .......................................... 105

Call

Accept/end..................................... 34

Barring........................................... 98

Charges ......................................... 49

Conference .................................... 36

Divert............................................. 90

End................................................ 32

Hold............................................... 34

Menu............................................. 36

Reject............................................. 34

Swap (change)............................... 34

Call back............................................. 33

Call divert........................................... 90

Call screening..................................... 91

Call transfer........................................ 36

Call waiting ...................................35, 90

Calling................................................ 32

Calls dialled (call record)..................... 48

Calls received (call record) .................. 48

Camera .............................................. 46

Car accessories ................................. 131

Car Kit

Accessories .................................. 131

Setting......................................... 101

Care and maintenance...................... 128

Cell Broadcast (CB) ............................. 76

Charge rate ........................................ 49

Charges.............................................. 49

Charging the battery .......................... 17

Clock.................................................. 94

Colour skin ......................................... 86

Conference ........................................ 36

Connection profiles ............................ 95

Connectivity....................................... 95

Contact list......................................... 70

Control code (DTMF) .......................... 37

Countdown ...................................... 116

Credit limit ......................................... 49

CSD settings ....................................... 96

Currency .......................................... 115

Customer Care.................................. 126

Index154

t page

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Date format ........................................94

Default book....................................... 38

Delete assistant .................................. 93

Dialling code....................................... 32

Dialling with number keys................... 32

Dictating machine............................. 109

Digital rights management.................. 20

Direct reply (SMS) ............................... 55

Display

Illumination.................................... 87

Language ....................................... 86

Symbols ......................................... 14

Wallpaper ....................................... 86

Divert ................................................. 90

Download........................................... 80

Driving safety ................................... 141

DTMF codes (control codes) ................ 37

Duration/charges ................................ 49

E-Mail

Lists................................................ 66

E-mail ................................................. 65

Receiving/reading ........................... 66

Writing ........................................... 65

Settings.......................................... 67

Emergency number ............................ 19

End user license agreement ..............143

Extras ............................................... 112

Fast access........................................ 103

Fast search ....................................... 100

Formatting (phone memory)............... 93

Formatting (SMS text)......................... 51

Forwarding (call) ................................ 36

Frequency range............................... 100

Games and applications ...................... 80

GPRS................................................... 95

Groups ............................................... 42

Handset volume ................................. 32

Handsfree talking ............................... 34

Headset

Accessories .................................. 130

Setting......................................... 101

Hide ID............................................... 90

Highlighting mode ............................. 23

Hold call........................................34, 36

Home network ................................... 99

Hotline............................................. 126

HTTP .................................................. 96

Identity number (IMEI) ....................... 92

IMEI number ...................................... 92

Inbox ................................................. 50

Info tones........................................... 92

Information services (CB).................... 76

Infrared.............................................. 95

Infrared (IrDA).................................... 95

Input language (T9)............................ 27

Inst. Message ..................................... 69

International dialling code .................. 33

Internet.............................................. 77

Joystick .............................................. 12

Key tones ........................................... 92

Language ........................................... 86

Legal notices ........................................ 3

Limit (call time/charge)....................... 49

Logo .................................................. 86

Loss of phone, SIM card.................... 129

Mailbox.............................................. 68

Maintenance of phone ..................... 128

Master reset ....................................... 93

Media player .................................... 111

155Index

t page

)

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Controls ......................................... 21

My menu...................................... 102

Speed dialling................................. 24

Menu speed dialling............................ 23

Menu tree......................................... 147

Message

CB .................................................. 76

E-mail............................................. 65

MMS .............................................. 57

SMS.......................................... 51, 53

Message memory full.......................... 56

Message type...................................... 55

Microphone on/off.............................. 36

Minute beep .......................................91

Missed appointments........................ 108

Missed calls (call record) .....................48

MMS

Lists................................................ 62

Receive........................................... 61

Send............................................... 60

Write .............................................. 57

Mobile Phone Manager .....................120

Muting (microphone).......................... 36

My menu .......................................... 102

My phone ........................................... 31

My stuff............................................ 118

Network

Barring ........................................... 98

Connection..................................... 99

Settings.......................................... 99

Notes................................................ 108

One number only................................ 37

Only ‚............................................. 97

Operating times (battery)............ 18, 129

Organiser.......................................... 105

Own (phone) numbers........................ 45

Own greeting ..................................... 87

Phone

Maintainance ............................... 128

Phone (settings) ................................. 92

Phone code ........................................ 24

Phone data....................................... 129

Phone identity number (IMEI) ............. 92

Phone number memo......................... 33

Phone number transmission

on/off................................................. 90

Phonebook

Call an entry................................... 44

New entry...................................... 43

Protected SIM................................. 45

Special books ................................. 45

VIP numbers................................... 45

Photo ................................................. 46

Pictures & sounds (SMS) ..................... 52

Change .......................................... 24

Control .......................................... 24

Enter.............................................. 19

Error ............................................ 125

PIN2................................................... 24

Preferred network .............................. 99

Preventing accidental

activation ........................................... 25

Product data..................................... 129

Profiles

Browser ......................................... 79

MMS .............................................. 63

Phone ............................................ 83

SMS ............................................... 55

Prompt............................................... 33

Provider logo...................................... 86

PUK, PUK2.......................................... 24

Questions & Answers........................ 123

Records .............................................. 48

Redial................................................. 32

Reminder ........................................... 33

Remote synchronisation ................... 116

Ringer setting..................................... 88

Ringtones......................................42, 88

Index156

t page

C72

ormorant

FUG

105

143

, us-en,

A31008

H7850

7619

(28

2005

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050718

Safety precautions ................................ 5

Screensaver ........................................ 86

Second phone number........................ 99

Security .............................................. 24

Security codes..................................... 24

Service centre (SMS) ........................... 55

Service supplier portal......................... 31

Service tones ...................................... 92

Set time/date ...................................... 94

Settings .............................................. 83

Short message (SMS) .......................... 51

Shown in the display........................... 14

Shut down animation ......................... 87

Siemens City Portal ............................. 31

Signal strength ...................................20

Silent alert .......................................... 88

SIM card

Clear barring................................... 25

Insert.............................................. 16

Phonebook ..................................... 45

Problems ...................................... 123

SIM services (optional)......................112

SMS

Archive........................................... 54

Lists................................................ 54

Profiles ........................................... 55

Read............................................... 53

Settings.......................................... 55

Signature ....................................... 55

T9 input ......................................... 27

To group ........................................ 52

Write .............................................. 51

SMS push............................................ 50

Software version................................. 92

SOS .............................................. 10, 19

Sound recorder................................. 113

Special books...................................... 45

Special characters ............................... 26

Speech time (battery) ....................... 129

Speed dialling keys ........................... 104

Standard functions.............................. 22

Standby mode .................................... 20

Standby time .............................. 18, 129

Start up animation .............................. 87

Stopwatch........................................ 115

Storage location (Phonebook)............. 43

Surf & fun........................................... 77

Swap.................................................. 34

Switch off phone

Automatic...................................... 92

Manually........................................ 19

Switch on phone ................................ 19

Symbols ............................................. 14

Synchronisation ............................... 116

T9 text input ...................................... 27

Tasks................................................ 108

Technical data .................................. 129

Text entry

With T9 .......................................... 27

Without T9..................................... 26

Text modules ..................................... 29

Themes .............................................. 85

This SIM only...................................... 97

Time zones............................19, 94, 110

Unanswered....................................... 90

Unit converter .................................. 114

Upper and lowercase

letters (T9) ......................................... 26

User group ....................................... 100

Validity, SMS ...................................... 55

Voice message (mailbox).................... 68

Volume

Handset volume............................. 32

Profiles........................................... 83

Ringtone ........................................ 88

Wallpaper (display)............................. 86

WAP ................................................... 77

BenQ Mobile and OHG C72 GSM 900/1800/1900 Mobile Phone User Manual C72

BenQ Mobile GmbH & Co. OHG GSM 900/1800/1900 Mobile Phone C72

User Manual

Navigation menu

Namespaces

Views

Navigation
