BenQ Mobile and OHG MC60 GSM1900 Mobile Phone User Manual A31008 H5760 A40 1 4A19 SUG for
BenQ Mobile GmbH & Co. OHG GSM1900 Mobile Phone A31008 H5760 A40 1 4A19 SUG for
Users Manual
right page (1) of MC60 Maguro, kurz, am A31008-H5760-A40-1-4A19 (08.08.2003, 12:39)
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60KIVZ.fm
Contents 1
VAR Language: English; VAR issue date: 11-Juni-2003
This is a summarised version of the operating instructions.
The detailed version is available on the Internet at:
www.my-siemens.com/mc60
Safety precautions ..................... 3
SAR (Cell Phone Designation) .... 5
Phone overview ......................... 7
Display symbols ......................... 9
Getting started ......................... 10
Switch on, off / PIN entry ......... 13
Emergency number (SOS) ...... 13
Switching on your phone
for the first time ..................... 13
General instructions ................ 14
Standard functions .................. 15
Security .................................... 16
Codes .................................... 16
Calling ...................................... 17
Text entry ................................. 21
Text modules ......................... 24
Phonebook ............................... 25
<New entry> .......................... 25
Assign picture ........................ 26
Voicedialling .......................... 27
Groups ................................... 28
Records, Durat/charges ............ 29
Camera ..................................... 30
Voicemail/CB services .............. 32
SMS .......................................... 33
MMS ......................................... 35
Message lists/settings .............. 37
Surf & fun ................................. 38
Internet browser (WAP) ..........38
Games & more .......................39
Setup ........................................ 40
Organiser .................................. 48
Calendar ................................48
Alarm .....................................48
Notes .....................................49
Missed appointments .............49
Time zones .............................49
Extras ........................................ 50
Alarm clock ............................ 50
Calculator ...............................50
Currency conv ........................50
Stopwatch ..............................51
Countdown ............................51
Voice command .....................51
New ringtone ......................... 52
SIM services (optional) ...........52
Fast access key/My menu ......... 53
Filesystem ................................54
Questions & Answers ............... 55
Customer Care .......................... 58
Specifications ........................... 60
Exposure to radiofrequency
signals .................................... 60
Technical data ....................... 60
Trademarks ............................ 60
Contents
This is a
summarised
version of the
operating
instructions.
The detailed
version is
available on
the Internet at:
www.my-
siemens.com/
mc60
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60KIVZ.fm
left page (2) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:39)
2Contents
VAR Language: English; VAR issue date: 11-Juni-2003
This is a summarised version of the operating instructions.
The detailed version is available on the Internet at:
www.my-siemens.com/mc60
Care and maintenance ............. 61
Battery quality statement ........ 62
U.S. FDA ................................... 63
FCC/Industry Canada Notice .... 69
Ten Driving Safety Tips ............ 70
Intellectual Property ................ 72
Menu tree ................................ 73
Index ........................................ 79
right page (3) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Security.fm
3Safety precautions
VAR Language: English; VAR issue date: 11-Juni-2003
Safety precautions
Information for parents
Please read the operating instructions and safety precautions carefully before use.
Explain the content and the hazards associated with using the phone to your children.
Remember to comply with legal
requirements and local
restrictions when using the
phone. For example, in
aeroplanes, petrol stations,
hospitals or while driving.
Mobile phones can interfere
with the functioning of medical
devices such as hearing aids or
pacemakers. Keep at least
20cm between phone and
pacemaker. When using the
mobile phone hold it to the ear
which is further away from the
pacemaker. For more
information consult your doctor.
The SIM card may be removed.
Caution! Small parts like this
could be swallowed by young
children.
The mains voltage specified on
the power supply unit (V) must
not be exceeded. Otherwise the
charging device may be
destroyed.
The ringtone (p. 42), info tones
(p. 42) and handsfree talking
are reproduced through the
loudspeaker. Do not hold the
phone to your ear when it rings
or when you have switched on
the handsfree function(p. 18) .
Otherwise you risk serious
permanent damage to your
hearing.
Only use original Siemens
batteries (100% mercury-free)
and -charging devices.
Otherwise you risk serious
damage to health and property:
The battery could explode, for
instance.
Do not open the phone. Only the
battery (100% mercury-free),
front and back covers, keypad
or SIM card may be replaced.
You must not open the battery
under any circumstances. Any
other changes to this device are
strictly prohibited, as they will
invalidate the type approval
required for operation of the
unit.
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Security.fm
left page (4) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
Safety precautions
4
VAR Language: English; VAR issue date: 11-Juni-2003
Important:
Please dispose ofunwanted
batteries and phones as
permitted by the laws in your
country.
The phone may cause
interference in the vicinity of TV
sets, radios and PCs.
Use only Siemens original
accessories. This will avoid
potential risks to health or
property and ensure compliance
with all relevant regulations.
Improper use will invalidate the guarantee!
right page (5) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60_SAR.fm
5SAR (Cell Phone Designation)
VAR Language: English; VAR issue date: 11-Juni-2003
SAR (Cell Phone
Designation)
RF EXPOSURE /SPECIFIC
ABSORPTION RATE (SAR)
INFORMATION
THIS SIEMENS MC60 PHONE MEETS
THE GOVERNMENT'S
REQUIREMENTS FOR EXPOSURE TO
ELECTROMAGNETIC FIELDS.
Your cell phone is a radio transmitter
and receiver. It is designed and
manufactured not to exceed the
emission limits for exposure to radio
frequency (RF) energy established by
the Federal Communications
Commission (FCC) of the U.S.
Government and by Health Canada.
These limits are part of
comprehensive guidelines and
establish permitted levels of RF
energy for the general population.
The guidelines were developed and
confirmed by independent scientific
organizations through periodic and
thorough evaluation of scientific
studies*. The standards include a
substantial safety margin designed
to assure the safety of all persons,
regardless of age and health.
The exposure standard for cell
phones employs a unit of
measurement known as the Specific
Absorption Rate, or SAR. The SAR
limit established by the FCC and by
Health Canada is 1.6 W/kg**. Tests
for SAR are conducted using
standard operating positions
accepted by the FCC and by Industry
Canada with the phone transmitting
at its highest certified power level in
all tested frequency bands. Although
the SAR is determined at the highest
certified power level, the actual SAR
level of the phone while operating
can be well below the maximum
value. This is because the phone is
designed to operate at multiple
power levels so as to use only the
power required to reach the
network. In general, the closer you
are to a wireless base station, the
lower the power output.
Before a phone model is available for
sale to the public, it must be tested
and the manufacturer must certify to
the FCC and Industry Canada that it
does not exceed the limit
established by each government for
safe exposure. The tests are
performed in positions and locations
(e.g., at the ear and worn on the
body), reported to the FCC and
available for review by Industry
Canada. The highest SAR value for
this model phone when testest for
use at the ear is
0.65 W/kg***
and when worn on the body+ is
0.30 W/kg***
Additional information on Specific
Absorption Rates (SAR) can be found
on the Cellular Telecommunications
Internet Association (CTIA) web-site
at www.phonefacts.net or the
Canadian Wireless
Telecommunications Association
(CWTA) website www.cwta.ca.
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60_SAR.fm
left page (6) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
SAR (Cell Phone Designation)
6
VAR Language: English; VAR issue date: 11-Juni-2003
SAR information on this Siemens
MC60 phone is on file with the FCC
and can be found under the Display
Grant section of
http://www.fcc.gov/oet/fccid
after searching on FCC ID PWX-MC60.
While there may be differences
between the SAR levels of various
phones and at various positions, all
Siemens products meet the
governmental requirements for safe
RF exposure.
+ For body worn operation, this
mobile phone has been tested
and meets FCC RF exposure
guidelines when used with a
carry accessory that contains no
metal and that positions the
handset at least 1.5 cm/0.59in from
the body. Use of other carry
accessories may not ensure
compliance with FCC RF
exposure guidelines.
*The World Health Organization
(WHO, CH-1211 Geneva 27,
Switzerland), on the basis of the
actual knowledge, does not see
any necessity for special
precautionary measures when
using cell phones.
Further information:
www.who.int/peh-emf,
www.mmfai.org,
www.my-siemens.com.
** averaged over 1 g of tissue.
***SAR values may vary depending
on national requirements and
network bands. SAR information
for different regions can be
found at www.my-siemens.com
right page (7) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Overview.fm
7Phone overview
VAR Language: English; VAR issue date: 11-Juni-2003
Phone overview
Call key
Displayed/selected phone number /name
displayed, take calls. Show last phone
numbers dialled in standby mode.
On/Off/End key
• Switched off: hold down to switch on.
• During a conversation or in an application:
press briefly to finish.
• In menus: press briefly to go back a level.
Hold down to return to standby mode.
• In standby mode: hold down to switch off
phone.
Control key top/bottom
In lists, messages and menus:
scroll up and down.
During a call:
Start adjusting the volume.
Open Addressbook/Phonebook.
In standby mode:
Voice control (hold down).
Open Phonebook.
Control key left/right
The current functions of this key are shown in
the bottom line of the display as §Text§/symbol
( e.g., " ).
0u8
Service provider
01.10.2003 10:10
NewMMS Menu
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Overview.fm
left page (8) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
Phone overview
8
VAR Language: English; VAR issue date: 11-Juni-2003
Integrated antenna
Do not obstruct the phone above the battery
cover unnecessarily. This reduces the signal
quality.
Loudspeaker
Display
Input keys
Camera
Hold down in standby mode:
Start camera function (p. 30).
Ringtone
•Hold down in standby mode:
switch all audible signals on/off (except
alarm).
•Hold down on incoming call: switch off
ringtone for this call only.
Key lock
Hold down in standby mode: switch key lock
on/off.
Plug socket
For charger, headset etc.
Socket for external antenna
Camera lens
0u8
Service provider
01.10.2003 10:10
NewMMS Menu
right page (9) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Displaysymbols.fm
9Display symbols
VAR Language: English; VAR issue date: 11-Juni-2003
Display symbols
Display symbols (selection)
0Signal strength.
9Charging.
5Battery charge level, e.g. 50%.
°Phonebook
+Records
Surf & Fun/Service provider
portal
¯Organiser
.Messages
aCamera
JExtras
File system
>Settings
?All calls are diverted.
;Ringtone off.
<Short ring (beep) only.
=Ringtone only, if the caller is
stored in the Phonebook.
Alarm set.
Alarm clock activated.
Keypad locked.
%Message memory full.
}No network access.
ABC/
Abc/abc Indicates whether upper or lower-
case letters are active.
T9Abc Text input with T9.
vActivated and available.
uRegistered.
sTemporarily interrupted.
tGPRS download.
WAP online.
WAP via GPRS online.
WAP no network.
|Auto answer feature on.
Organiser symbols (selection)
FMemo
GCall
HMeeting
LBirthday
Anniversary
Access with left control key (selection)
TMessage received.
µMMS received.
£MMS notification received.
- Voice message received.
PUnanswered call.
Depending on the service provider, some of
the symbols shown here may vary from
those in the phone,
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Startup.fm
left page (10) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
Getting started
10
VAR Language: English; VAR issue date: 11-Juni-2003
Getting started
The front and back covers of the casing as well as the keypad can be changed in a
matter of seconds - no tools required. Please switch the phone off first:
Assembling
Dismantling
Note
Your phone is supplied with a protective file applied to the display and
the display cover of the front shell. Remove this film before getting
started.
In rare cases the static discharge may cause discoloration at the edges of the display.
However this will disappear within 10 minutes.
To avoid damage to the display, the phone should not be used without the top shell.
right page (11) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Startup.fm
11Getting started
VAR Language: English; VAR issue date: 11-Juni-2003
Insert SIM card/battery
The service provider supplies you
with a SIM card on which all the
important data for your line is
stored. If the SIM card has been
delivered in credit-card size, snap the
smaller segment out and remove
any rough edges.
Press grooved area , then remove
the cover forwards/upwards in the
direction of the arrow .
• Place the SIM card into the slot
with the contact surface facing
downwards. Gently push the holder
tab over the SIM card 3 (ensure
the bevelled corner is correctly
positioned).
• Insert the battery sideways into
the phone , then press
downwards until it engages.
• To remove, press the retaining tab
on the side of the battery, then lift
the battery out.
• Place cover on phone and then
push to the lower edge , until it
clicks into place.
Additional information
Please switch off your phone before
removing the battery!
Only 3V SIM cards are supported. Please
contact your service provider if you have an
older card.
SIM card problems ............................p. 55
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Startup.fm
left page (12) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
Getting started
12
VAR Language: English; VAR issue date: 11-Juni-2003
Charge battery
The battery is not fully charged
when delivered. Plug charger cable
into the bottom of the phone, plug
power supply unit into a mains
power socket and charge for at least
two hours.
Display when charging is in progress
9During charging.
Charging time
An empty battery is fully charged
after about 2 hours. Charging is only
possible within a temperature range
of +5 °C to +40 °C. If the
temperature rises/falls 5 °C
above/below this, the charge symbol
flashes a warning. The mains voltage
specified on the power supply unit
must not be exceeded.
Charge icon not visible
If the battery has been discharged
fully the charge icon is not
immediately visible when the power
supply unit is plugged in. It will
appear after up to two hours. In this
case the battery is fully charged after
3-4 hours.
Only use the power supply unit supplied!
Display while in service
Charge level display during
operation (empty-full):
258
A beep sounds when the battery is
nearly empty. The charge level of the
battery is only displayed correctly
after an uninterrupted
charging/discharging cycle. You
should therefore not remove the
battery unnecessarily and where
possible not terminate the charging
process before completion.
Additional information
The power supply unit heats up when used
for long periods. This is normal and not
dangerous.
If the battery is removed for longer than 30
seconds, the clock must be reset.
right page (13) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Startup.fm
13Switch on, off / PIN entry
VAR Language: English; VAR issue date: 11-Juni-2003
Switch on, off / PIN entry
Switch on/off
Hold down On/Off/End key.
Enter PIN
The SIM card can be protected with a
4- to 8-digit PIN.
Enter the PIN using the
number keys. The
characters **** appear to
ensure nobody can read
your PIN on the display.
Correct errors with §Clear§.
§OK§ To confirm, press the
right of the control key.
Logging on to the
network will take a few
seconds.
Emergency number
(SOS)
Only to be used in real emergencies!
By pressing the left side of the
control key §SOS§ you can make an
emergency call on any network
without a SIM card and without
entering a PIN (not possible in all
countries)
Switching on your phone
for the first time
Time/date
Set the clock to the right time once
at start-up.
§Yes§ Press.
First enter the date
(day/month/year), then
the time (24 hours,
including seconds).
§OK§ Press. The time and date
are updated.
Time zones
Set the time zone for your area.
Select the required time
zone from list ...
§Set§ … and set it.
Signal strength
0Strong reception signal.
/A weak signal reduces the
call quality and may lead
to loss of the connection.
Change your location.
Additional information
Change PIN...................................... S. 35
Clear SIM card barring ......................p. 46
Clock settings....................................p. 44
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Startup.fm
left page (14) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
General instructions
14
VAR Language: English; VAR issue date: 11-Juni-2003
General instructions
User guide
The following symbols are used to
explain operation:
Without SIM card
If you switch on the phone without a
SIM card you can still use some
phone functions.
§Menu§ The functions are
displayed.
§SOS§ Emergency, SOS.
Menu controls
The steps needed to reach a function
are shown in a condensed form in this
user guide.
For example,
To display call list for missed calls in
condensed form:
§Menu§ ¢+¢Calls missed
This comprises the following steps:
§Menu§ Open main menu.
¢Select +, then select the
Calls missed function.
§Select§ Confirm.
Standby mode
Very often function descriptions
begin in standby mode.
The phone is in standby mode and is
ready for use when the name of the
service provider appears on the
display.
Hold down the On/Off/End
key to return to standby
mode from any situation.
Enter numbers or letters.
On/Off/End key.
Call key.
Press control key (left/right).
Press control key
(top/bottom).
§Menu§ Displays a function.
Function dependent on
service provider, may require
special registration.
right page (15) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Startup.fm
15Standard functions
VAR Language: English; VAR issue date: 11-Juni-2003
Standard functions
Option menus
Menu functions are made available
in options menus. A selection of
functions that occur frequently is
shown here.
§Options§ Open menu.
Highlighting mode
With some applications (e.g.
Phonebook) one or more entries in a
list can be highlighted to perform
multiple functions at once.
§Options§ Open menu.
Mark text Activate highlighting
mode.
If an unmarked entry is selected, this
can be highlighted:
§Mark text§ The current entry is
highlighted.
If a highlighted entry is selected, the
highlighting can be deleted:
§Unmark§ Unmark the current entry.
Additional highlighting functions:
Edit Open the entry to edit.
Capacity Display available capacity.
View Display entry.
Delete/
Delete all Delete entry/delete all
entries after confirmation.
New entry Create new entry.
Send MMS Send entry as MMS
message.
Send Dial number or select from
the Phonebook, then send.
Save Store entry.
Sort Set sort criteria
(alphabetical, type, time).
Text input
(p. 21)
T9 preferred:
Activate/deactivate T9 input.
Input language: Select
language for text.
Rename Rename selected entry.
Mark all Highlight all entries.
Unmark all Delete highlighting on all
marked entries.
Delete
marked All selected entries are
deleted.
Phonebook ¢
@Anne
@Barbara
ACarol
Options Mark text
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Startup.fm
left page (16) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
Security
16
VAR Language: English; VAR issue date: 11-Juni-2003
Security
§Menu§ ¢>¢Security ¢Select a
function
The phone and SIM card are
protected against misuse by several
security codes.
Codes
PIN control
You can stop the PIN prompt being
activated when the phone is
switched on, but you then risk
unauthorised use of the phone.
§Select§ Press, then enter PIN and
confirm with §OK§.
§Change§ Press and confirm with
§OK§ .
Change PIN
You can change the PIN to any 4- to
8-digit number you find easier to
remember.
Enter current PIN and
confirm with §OK§ .
,§OK§ Enter new PIN.
,§OK§ Renter new PIN.
Change PIN2
(Display only if PIN2 is available).
Proceed as with Change PIN.
Chg.phonecode
(Change phone code)
You define the phone code
(4-8 digits) the first time you call up
a protected function. It is then valid
for all phone-code protected
functions.
Clear SIM card barring
If the PIN is entered incorrectly three
times, the SIM card is barred. Enter
the PUK (MASTER PIN), provided by
your service provider with the SIM
card, according to instructions. If the
PUK (MASTER PIN) has been lost,
please contact your service provider.
Preventing accidental
activation
Even if PIN control is deactivated
confirmation is required to switch on
the phone. This prevents the phone
from being switched on accidentally,
e. g. when carried in a pocket or
whilst you are on an aircraft.
Hold down, then confirm with
§OK§ . The phone switches
on.
Keep these confidential numbers in a
safe place where you can access them
again if required.
right page (17) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Phone.fm
17Calling
VAR Language: English; VAR issue date: 11-Juni-2003
Calling
Dialling with number keys
The phone must be switched on
(standby mode).
Enter number (always
with area
code/international
dialling code).
§Clear§ A short press clears
the last digit, a long press
clears the entire phone
number.
Press the Call key. The
displayed phone number
is dialled.
End call
Press the End key briefly.
Press this key even if the
person on the other end
of the line has hung up
first.
Set volume
Use the top of the control
key to start adjusting the
volume. Then press
top/bottom to adjust the
volume as required (only
possible during a
conversation).
If a Car Kit is used, its volume setting
will not affect the usual setting on
the phone.
Redial
To redial numbers that were dialled
previously:
Press the Call key once.
Pick out the required
phone number from the
list, then to dial ...
Press ...
If the number is busy
Auto. redial
§Auto dial§ Press. The phone number
is automatically dialled
ten times at increasing
time intervals.
Or
Call back b
§Call back§ Press. Your phone rings
when the busy number is
free.
Reminder
§Prompt§ Press. A beep reminds you
to redial the displayed
phone number after
15 minutes.
International dialling codes
Hold down until a “+”-is displayed.
§+List§ Press and select country.
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Phone.fm
left page (18) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
Calling
18
VAR Language: English; VAR issue date: 11-Juni-2003
Accept call
The phone must be switched on
(standby mode). An incoming call
will interrupt any other use of the
phone.
§Answer§ Press.
Or
Press.
A phone number transmitted by the
network is displayed or the
corresponding name if it is
contained in the Phonebook (p. 25).
A picture may also appear (settings
p. 26).
Reject call
§Reject§ Press. To divert call, see
p. 43.
Or
Press briefly.
Handsfree
You can put the phone down during
a call. You can then hear the caller
via the loudspeaker.
§Handsfr.§ Activate handsfree
talking.
§Yes§ Switch on.
Use the control key to
adjust the volume.
§Handsfr.§ Switch off.
Warning!
Please make sure you have accepted the
call before holding the phone to your ear.
This will avoid damage to your hearing from
loud ringtones.
Additional information
P Missed calls.................................p. 29
Accept call using any key ..................p. 43
Switch off ringtone.............................p. 42
Warning!
Always switch off "handsfree talking"
before holding the phone to your ear! This
will avoid damage to your hearing.
y menu§ Call menu ......................... S. 32
08
GG
Carol
Handsfr. Menu
08
Handsfr. Menu
right page (19) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Phone.fm
19Calling
VAR Language: English; VAR issue date: 11-Juni-2003
Swapping calls b
• You can call another number
during a call.
§y menu§ Open call menu
Hold Put current call on hold.
Now dial the new phone number.
When the new connection is
established:
§y menu§ Open call menu
Swap Swap back and forth
between both calls.
• You are advised during a call that
there is another call waiting by a
special "call waiting" tone (p. 43).
§Swap§ Accept the waiting call
and put the current call on
hold. To swap between
the two calls, see above.
Or
End the current call.
§Answer§ Accept new call.
Conference b
• Call up to 5 parties and link them
together in a conference call.
When a call is established:
§y menu§ Open menu and select
Hold. The current call is
put on hold.
Now dial a new number.
When the new connec-
tion is established ...
§y menu§ …open menu and select
Conference. The held call is
joined.
Repeat procedure until all
participants are linked together (up
to 5 participants).
End
All calls in the conference
are ended simultaneously
when the End key is
pressed.
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Phone.fm
left page (20) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
Calling
20
VAR Language: English; VAR issue date: 11-Juni-2003
Call menu
The following functions are only
available during a call:
y menu§ Open menu.
Babysitter
If this is active, only one number can
be dialled.
Switch on
§Menu§¢>¢Security
¢Babysitter
§Select§ Press.
Enter phone code.
The phone code (4- to 8-digits) is set
by you and entered at the first
security setting.
Please note this code down (see also
p. 16).
§OK§ Confirm input.
§Change§ Press.
/Select phone number
from Phonebook (p. 25)
or enter new number.
§OK§ Confirm "On".
Apply
To dial, hold down the right of the
control key.
Switch off
Press down.
Enter phone code.
§OK§ Confirm input.
§Change§ Press.
§OK§ Confirm "Off".
Hold (S. 31)
Microphone on If the microphone is
switched off the person
on the other end of the
line cannot hear you
(muting).
Also: Hold down.
Handsfree (S. 30)
Volume Adjust handset volume.
Conference (S. 31)
Durat/charges Display call duration and
(if set, p. 29) costs
accruing during the call.
Send DTMF Enter numbers, e.g., for
remote access to an
automatic answering
machine.
Call
transferThe original call is joined
to the second one. For
you, both calls are now
ended.
Main menu Access to main menu.
Call status List all held and active
calls (e .g. conference
call participants).
right page (21) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Text.fm
21Text entry
VAR Language: English; VAR issue date: 11-Juni-2003
Text entry
Text entry without T9
Press number key repeatedly until
the required letter appears. After a
brief interval the cursor will advance.
Example:
Press once briefly to type
the letter a, twice to type
b etc.
Hold down to write the
number.
Ä,ä,1-9 Umlauts and numbers are
displayed after the
relevant letters.
§Clear§ Press briefly to delete the
letter before the cursor,
hold down to erase the
whole word.
Move the cursor
(forwards/back).
Press briefly: Swap
between abc, Abc, T9abc,
T9Abc, T9ABC, 123. Status
shown in top line of
display.
Hold down: All input modes
are displayed.
Press briefly: Special
characters are shown.
Hold down: Open input
menu.
Press once/repeatedly:
. , ? ! ’ " 0 - ( ) @ / : _
Hold down: Writes 0.
Writes blank. Press twice
= jumps a line.
Special characters
Press briefly. The symbols
chart is displayed:
1) Line break
,
Navigate to characters.
§Select§ Press.
Input menu
With text input:
Press down. The input
menu is displayed:
Text format (SMS only)
Input language
Mark text
Copy/Add
1)¿¡_;!?,.
+-"’:()/*
¤¥$£€&#\ @
[ ] { } %~<=>
|^§īǻĬȁȄȆ
ȈĭȌȍ
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Text.fm
left page (22) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
Text entry
22
VAR Language: English; VAR issue date: 11-Juni-2003
Text entry with T9
"T9" deduces the correct word from
the individual key entries by making
comparisons with an extensive
dictionary.
Activate, deactivate T9
§Options§ Open text menu.
Text input
Select.
T9 preferred
Select.
§Change§ Activate T9.
Select Input language
Select the language in which you
want to compose your message.
§Options§ Open text menu.
Text input
Select.
Input language
Select.
§Select§ Confirm, the new
language is set.
Languages with T9
support are marked with
the T9 symbol.
Write a word using T9
Since the display changes as you
proceed,
it is best if you finish a word without
looking at the display.
Simply press the keys once only
where the relevant letter is located.
For "hotel", for example:
press briefly for T9Abc then type
Press. A blank ends a
word.
Do not use special characters such as
Ä but rather use the standard
characters, e.g. A; T9 will do the rest
for you.
right page (23) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Text.fm
23Text entry
VAR Language: English; VAR issue date: 11-Juni-2003
T9 word suggestions
If several options are found in the
dictionary for a key sequence (a
word), the most probable is
displayed first. If the word you want
has not been recognised, the next
suggestion from T9 may be correct.
The word must be highlighted
§markiert§ . Then press
again. The displayed word
is replaced with a
different word. If this
word is also incorrect,
press
again. Repeat until the
correct word is displayed.
If the word you want is not in the
dictionary, it can also be written
without T9.
To add a word to the dictionary:
§Spell§ Select.
The last suggestion is deleted and
the word may now be entered
without T9 support. Press §Save§ to
add it automatically to the
dictionary.
Additional information
Set a full stop. A word is
concluded if it is followed by a
space. Within a word, a full
stop represents an
apostrophe or hyphen:
e.g. §provider.s§= provider’s.
Go to the right. Ends a word.
Press briefly: Swap
between: abc, Abc, T9abc,
T9Abc, 123. Status shown in
top line of display.
Hold down: All input modes
are displayed.
Press briefly: Select special
characters (S. 29).
Hold down: Open input menu
(S. 29).
e SMS 1 748
At 8 pm we are ___
Spell
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Text.fm
left page (24) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
Text entry
24
VAR Language: English; VAR issue date: 11-Juni-2003
Correct a word
Words written with T9:
Move left or right, word
by word, until the
required word is
highlighted §highlighted§.
Scroll through the T9
word suggestions again.
§Clear§ Deletes the character to
the left of the cursor and
displays a new possible
word!
Words not written with T9:
Move letter by letter to
the left/right.
§Clear§ Deletes the letter to the
left of the cursor.
Letters are inserted at the
cursor position.
Text modules
Text modules can be stored in the
phone for adding to your messages
(SMS, MMS).
Write text modules
§Menu§¢.¢Text modules
§Options§ Select New text.
Write text module.
§Options§ Select Save.
Accept the default name
or give it a new name,
then save with §OK§.
Use text modules
Write message (SMS,
MMS).
§Options§ Open text menu.
Select Text modules.
Select text module from
the list.
§Select§ Confirm. The text module
is displayed.
§OK§ Confirm. The text module
is inserted in the message
to the right of the cursor.
Additional information
Within a "T9-word", individual letters may
not be edited without first removing the
T9-status. In most cases it is better to
rewrite the complete word.
T9®Text Input is licensed under one or more of
the following: U.S. Pat. Nos. 5,818,437,
5,953,541, 5,187,480, 5,945 928 and 6,011,554;
Canadian Pat. No. 1,331,057; United Kingdom
Pat. No. 2238414B; Hong Kong Standard Pat. No.
HK0940329; Republic of Singapore Pat. No.
51383; Euro.Pat. No. 0 842 463 (96927260.8)
DE/DK, FI, FR, IT, NL, PT, ES, SE, GB; and
additional patents are pending worldwide.
right page (25) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Phonebook.fm
25Phonebook
VAR Language: English; VAR issue date: 11-Juni-2003
Phonebook
Enter frequently used phone
numbers in the Phonebook with a
special name. If a phone number is
stored with a name, it appears on
the display when you are called. You
can assign important phone
numbers to different groups.
<New entry>
Open Phonebook (in
standby mode).
§Select§ Display input fields.
Select input fields.
Fill in input fields. The
maximum number of
characters available is
shown at the top of the
display.
Number:
Always enter phone number with
dialling code. An entry is not saved
without a phone number.
Name:
Enter first and/or last names.
E-Mail:
Enter e-mail address for MMS (up to
50 addresses).
Group:
Default: No group
§Change§ Entries can be organised
by groups (S. 32) e.g.:
Family, Friends, Office, VIP...
Location:
Default: SIM
Specify where to save the
group: Mobile,SIM,
Protected SIM (S. 31).
Record no.:
Each entry is automatically assigned
a record number. You can also dial
using the record number (S. 30).
Change the record
number.
§Save§ Press to store the new
entry.
Phonebook ¢
<New entry>
<Special books>
<Groups>
Select
Additional information
Entries are not saved without phone
numbers.
§+List§ International dialling code......p. 17
Text entry ..........................................p. 21
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Phonebook.fm
left page (26) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
Phonebook
26
VAR Language: English; VAR issue date: 11-Juni-2003
Call (search for an entry)
Open Phonebook.
/Select a name with the
first letter and/or scroll.
Number is dialled.
Call using record no.
A record number is automatically
assigned to every new entry in
Phonebook.
Enter record number.
Press.
Press.
Change entry
Select entry in
Phonebook.
§Options§ Press and select Edit.
Select input field
required.
Make change.
§Save§ Press.
Phonebook options
The following functions are
available, depending on the current
situation. Special functions:
§Options§ Open menu.
Assign picture
Assign a specific picture or photo to
Phonebook entries. This picture will
appear in the display when there is a
call from this number.
Open Phonebook and
select an entry.
§Options§ Open menu and select
Picture. Select a picture.
§Open§ The picture is displayed.
§Select§ The picture is assigned to
the phone number. It
appears with a g symbol
in the Phonebook.
Voicedialling Record or change voice
dialling for an entry.
(S. 31).
Picture Assign a picture to a
Phonebook entry.
Send SMS... Send as a Phonebook
entry or text.
(For standard functions see p. 15)
right page (27) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Phonebook.fm
27Phonebook
VAR Language: English; VAR issue date: 11-Juni-2003
<Special books>
Open Phonebook (in
standby mode).
<Special books>
Select
<Own numbers>
Enter “own” phone numbers in
Phonebook (e.g., fax) for
information.
<Service numb.>/ <Info
numbers>
There might be phone numbers
saved in your Phonebook that have
been provided by your service
provider.
<SIM phonebook>
Entries stored in the Phonebook on
the SIM card can also be used on
other GSM phones.
<Protected SIM> b
On special SIM cards, phone
numbers can be stored in a
protected location. PIN2 is required
for editing (p. 16).
See also function Only ‚.(p. 46).
<Mobile>
Phonebook entries are stored in the
phone memory when the SIM card
memory is full.
Voicedialling
You can dial numbers by voice
command. Up to 20 voice
recordings can be saved in the
phone for voice dialling or voice
commands (not on SIM card).
Make a recording
Open Phonebook.
/Select entry.
§Options§ Open menu.
Voicedialling
Select.
§Starten§ Start recording.
A short signal sounds. Now say the
name and repeat it when prompted
by a beep. A further beep confirms
the recording, which is saved
automatically.
{Identification of entries in
the Phonebook that have
voice dialling.
Apply voice dialling
Press down (in standby
mode).
Now state the name; the number is
dialled.
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Phonebook.fm
left page (28) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
Phonebook
28
VAR Language: English; VAR issue date: 11-Juni-2003
Groups
Eight groups are specified in your
phone to enable you to arrange your
Phonebook entries clearly. You can
rename these.
Open Phonebook (in
standby mode).
<Groups> Select (the number of
entries is listed behind the
group name).
Select group.
§Select§ Open group.
<New entry>
• Insert an entry from the
Phonebook.
Open Phonebook.
Select entry.
§Select§ Copy entry to the group.
• Create new entry.
§Select§ Create a new Phonebook
entry (the selected group
is the default).
Change group name
§Rename§ Select and enter a new
name.
Ringtone for group
Assign a ringtone to a group that
plays when one of its members calls
you.
§Menu§¢>¢Audio¢Ringtones
¢Incoming calls¢Group
calls
Select group.
§Select§ Confirm.
Select ringtone.
§Select§ Confirm.
Groups
E Leisure (5)
Private (23)
Business (11)
Rename Select
Additional information
No group: Contains all Phonebook entries
that do not belong to a group (name cannot
be changed).
SMS to group.....................................p. 34
right page (29) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Records_Charge.fm
29Records, Durat/charges
VAR Language: English; VAR issue date: 11-Juni-2003
Records, Durat/charges
Records
Your phone stores the phone
numbers of calls for convenient
redialling.
§Menu§¢+
§Select§ Press.
Select call list and press
§Select§ .
Select phone number.
Dial phone number.
Calls missed b
The phone numbers of calls that you
have received but not answered are
stored for call back purposes.
PSymbol for a missed call.
Calls received b
Accepted calls are listed.
Calls dialled
Access to the last numbers dialled.
Fast access in standby
mode.
Erase records
The records are deleted.
Call list menu
§Options§ Edit entries.
Durat/charges
You can display the charges and the
duration of calls and set a unit limit
for outgoing calls.
§Menu§¢+¢Durat/charges
Select a function:
Last call,All outg. calls,All incoming,
Remain. units
§Select§ Display data.
§Reset§ Clear display.
§OK§ End display.
Charge settings
§Menu§¢+¢Durat/charges
¢Charge sett.
Conv. (PIN2 prompt). b
Currency for charge display.
Personal rate (PIN2 prompt). b
Charges per unit/period.
A/c limit (PIN2 prompt). b
Fix a credit/usage period on a special
SIM card.
Auto display
Display duration and charge
automatically at end of each call.
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Camera.fm
left page (30) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
Camera
30
VAR Language: English; VAR issue date: 11-Juni-2003
Camera
Photos you have taken with the
integrated camera may be viewed,
saved,
• used as wallpaper, startup and
shutdown animation and
screensaver, and
• sent as an MMS message.
Switch on
§Menu§¢a
Or
Hold down (in standby
mode).
Shot
The current (preview) image is
displayed.
At the top left of the display,
information on the brightness
setting for the shot is shown, and on
the right the number of shots
possible at the selected resolution.
The number of possible shots also
depends on the size of the image
(required memory space).
A shot (especially at high resolution)
requires a few seconds to be
processed and saved.
Setting the brightness.
Press to take a photo.
Or
§Photo§ As the shot is taken, you
will hear an advisory tone.
The photo is saved
automatically with a time
stamp as its name (to
change the name, S. 30).
After taking the photo:
§View pic.§ View shot.
§Delete§ Delete shot.
Shot options
§Options§ Open menu.
View
pictures The saved photos are
displayed on the phone at a
resolution of 101 x 80 pixels.
To display them at a higher
picture quality (See Picture
quality below), you must
transfer them to PC.
quality Setting the picture quality
(pixel resolution).
Prem. 352x288 (CIF).
High 320x240 (QVGA).
Med. 176x144 (QCIF).
Low 160x120 (QQVGA).
Brightness Set with:
right page (31) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Camera.fm
31Camera
VAR Language: English; VAR issue date: 11-Juni-2003
Photo album
§Options§ Open menu.
View pictures
Select.
Scroll through photos
taken.
Photo options
You can
• use the displayed photo as
wallpaper, startup and shutdown
animation and screensaver, and
• send it as an MMS message.
§Options§ Open menu.
White
Balance Automatic, Indoor,
Outdoor
Set with:
Info Displays help text
Send MMS Send photo as MMS
(p. 35).
MMS an
Album Save the photo in the
personal album your
service provider makes
available for you on the
Internet.
The provision and
description of this facility
depends on your service
provider.
Full screen Switch to full screen mode.
Also with
Zoom Enlarge image section.
Navigation using
and .
Set as... Use current photo as
wallpaper, startup or
shutdown animation or
screensaver.
Attributes Information about picture
quality.
Filesystem Open to select saved
photos.
Rename Give the photo a new
name.
(For standard functions see p. 15)
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Mailbox_CB.fm
left page (32) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
Voicemail/CB services
32
VAR Language: English; VAR issue date: 11-Juni-2003
Voicemail/CB services
§Menu§¢.¢Setup¢Voice
message
Most service providers offer you an
external answering service. A caller
may leave a voice message for you in
this mailbox
• if your phone is switched off or
not ready to receive,
• if you do not want to answer,
• if you are making a phone call
(and Call waiting is not activated,
p. 43).
You may have to register for this
service with the service provider and
enter the settings manually.
Settings b
The service provider supplies you
with two phone numbers:
Save mailbox number
Call this phone number to listen to
the voice messages left for you.
§Menu§¢.¢Setup¢Voice
message
Enter mailbox number and confirm
with §OK§.
Save call divert number
Calls are diverted to this phone
number (see also p. 43).
§Menu§¢>¢Phone setup
¢Divert
¢e. g., Unanswered¢Set
Dial divert number and register it at
the network with §OK§. Divert will be
confirmed after a few seconds (see
also p. 43).
Listening to message b
A new voice message can be
announced as follows:
An - icon with beep or . a text
message announces a new voice
mail or you receive a call with an
automatic announcement. Dial into
your mailbox and listen to your
message(s).
Hold down (if necessary enter
mailbox number once
only). Confirm with §OK§
and §Mailbox§ depending
on your service provider.
CB services
§Menu§¢.¢Setup¢CB
services
Some service providers offer
information services (info channels).
If reception is activated, your “Topic
list” will supply you with messages
on the activated topics.
right page (33) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Messages.fm
33SMS
VAR Language: English; VAR issue date: 11-Juni-2003
SMS
You can transmit and receive very
long messages (up to 760 characters)
on your phone. They are
automatically composed of several
"normal" SMS messages (note higher
charges).
Additionally you can insert pictures
and sounds in an SMS.
Depending on the service provider,
e-mails and faxes can also be sent
and e-mails received via SMS
(change setting if necessary, S. 33).
Writing and sending text
messages (SMS)
§Menu§¢.¢New SMS
Write text (Text entry with
T9, p. 22).
§Clear§ Press briefly to
delete letter by letter,
hold down to delete an
entire word.
Press.
/Dial number or select
from the Phonebook.
§OK§ Confirm. The SMS is sent
to the service centre for
transmission.
Text options
§Options§ Open text menu
.Save Save composed text in
draft list.
Picture&sound Add pictures,
animations and sounds
into message (see
following text).
Text modules Insert text module
(p. 24).
Format Line feed
Small font, Medium
font, Large font
Underline
Def. alignment, Left,
Right, Centre
Mark text (highlight text
using control key)
Clear text Delete the whole text.
Insert from... Insert entry from
Phonebook.
Send via ... Select an SMS profile
for transmission (S. 33).
(For standard functions see p. 15)
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Messages.fm
left page (34) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
SMS
34
VAR Language: English; VAR issue date: 11-Juni-2003
Special functions
§Options§ Open menu.
SMS to group
You can send an SMS message as a
"circular" to a recipient group.
Send Select.
§Group§ The list of groups is
displayed. Select and
open group, select group
members and send SMS.
Picture&sound
Insert pictures and sounds into
message.
Picture&soundSelect.
The menu contains:
Fix animations, Fix sounds,
Own anim.,Own pictures,
Own sounds
Select area, then select
the required entry and
confirm.
Receive/read SMS
TArrival of new SMS
announced on display. To
read the SMS press the
left control key.
Scroll through message
line by line.
§Reply§ Function for replying
directly.
SMS archive
§Menu§¢.¢SMS archive
The list of SMS messages stored in
the phone is displayed.
Additional information
Insert special characters ...................p. 21
SMS profile....................................... S. 33
Other functions for editing SMS can be
found under §Options§.
right page (35) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Messages.fm
35MMS
VAR Language: English; VAR issue date: 11-Juni-2003
MMS
The Multimedia Messaging Service
enables you to send texts, pictures
(also photos) and sounds in a
combined message to another
mobile phone or to an e-mail
address. All elements of an MMS
message are merged to form a "slide
show".
Depending on your phone's settings,
you will receive either the complete
message automatically or
notification that an MMS has been
saved in the network, giving sender
and size details. You may then
download it to your phone to read it.
Ask your service provider whether
this service is available. You may
need to register for this service
separately.
Writing/sending MMS
messages
An MMS consists of the address
header and the content.
§Menu§¢.¢New MMS
Input fields:
To: / Phone
number/e-mail address of
recipient(s).
Subject: Enter MMS heading (up to
40 characters).
Picture: Press §Insert§ again. The
picture list is opened for
selection.
Text: Press §Edit§ again. Write
text with the help of T9.
Sound: Press §Insert§ again.
Filesystem You can now
select a stored melody
(see also p. 54).
New sound: Record new
tones, for sending by
MMS only (see below).
Slide duration:
Enter length of display for
individual pages
(minimum 0.1 seconds).
New recording
The phone records via its
microphone.
§Record§ Start recording. The
current recording
duration and available
time remaining are
displayed.
§Stop§ End recording.
§Play§ Replay recording.
§Save§ Save. To give the
recording its own name,
the description §Clear§.
§OK§ Save.
Additional information
You can also easily send an image by MMS
immediately after taking it with the camera
(p. 30)
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Messages.fm
left page (36) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
MMS
36
VAR Language: English; VAR issue date: 11-Juni-2003
Attach extra pages
§Options§ Open menu.
New slide Select.
Attach business card
§Options§ Open menu.
Extras Select.
Scroll to Businesscard.
Attach business card.
Attach appointment
§Options§ Open menu.
Extras Select.
Scroll to Appointment.
oImport appointment from
calendar.
Send MMS.
§Options§ Open menu.
Send Select.
Receive/read MMS
µ/£Indicates
Recept/notification of an
MMS. Press the left
control key to read the
MMS or notification.
Depending on the setting, (S. 33)
the
• complete MMS is received
• or the notification is opened. Press
§Receiving§ to receive the complete
MMS, with §Play§ automatic
presentation of the MMS. Cancel
using any key.
• Open attachments using §Options§
and Attachments .
• Open images and tones using
§Options§ and Content.
Other functions for editing MMS can be
found under §Options§.
right page (37) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Messages.fm
37Message lists/settings
VAR Language: English; VAR issue date: 11-Juni-2003
Message lists/settings
All SMS and MMS messages are
saved in four different lists:
Inbox
§Menu§¢.¢Inbox¢MMS/SMS
The list of SMS and MMS messages
and notifications received is
displayed. To receive an MMS
subsequently, open notification and
press §Receiving§.
Draft
§Menu§¢.¢Draft¢MMS/SMS
The list of stored drafts is displayed.
Unsent
§Menu§¢.¢Unsent
¢MMS/SMS
The list of MMS messages not yet
successfully sent or not yet
completely sent concatenated SMS
messages is displayed.
Sent
§Menu§¢.¢Sent¢MMS/SMS
The list of sent SMS or MMS
messages is displayed.
SMS profiles, MMS
profiles
§Menu§¢.¢Setup¢SMS/MMS
Profiles have to be created for SMS
and MMS. The transmission
characteristics are defined in these.
The data for these may already have
been entered. If not, you can obtain
this from your service provider.
Additional information is available in
the comprehensive operating
instructions on the Internet at:
www.my-siemens.com/mc60
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Surf&Fun.fm
left page (38) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
Surf & fun
38
VAR Language: English; VAR issue date: 11-Juni-2003
Surf & fun
Internet browser (WAP)
Get the latest information from the
Internet that is specifically adapted
to the display options of your phone.
In addition, you can download
games and applications to your
phone.
Internet access b
§Menu§¢¢Internet
The browser is activated as soon as
you call up the function. If
necessary, configure how WAP
access should be established (see
browser menu ,Setup,Start with...).
Select the function from
the start menu.
§Select§ Confirm.
End connection
Hold down to terminate
the connection and close
the browser.
WAP profiles
§Menu§¢¢Internet¢Profiles
Activate WAP profile
You can change the current profile
each time you access the Internet.
Select profile.
§Select§ Activate. The current
profile is selected.
Set WAP profile
Up to 5 WAP profiles can be
configured (may be barred by your
provider). The entries may vary
depending on the service provider:
Select profile.
§Edit§ Open to configure, then
fill in the data fields.
To select the connection profile, see
Data services,p. 45.
Note
Depending on your service provider, you
may have direct access to its portal instead
of the Surf&Fun menu option. Contact your
service provider for details of the services
offered on the portal. In this case, you will
find the Internet and Games & more menu
options in the JExtras, p. 50 menu.
Additional information
Browser menu.
/ Offline / Online.
GPRS Online.
No network.
Select special characters,
such as @,~, \ , see p. 21.
Press repeatedly for:
. , ? ! ’ " 0 - ( ) @ / : _
right page (39) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Surf&Fun.fm
39Surf & fun
VAR Language: English; VAR issue date: 11-Juni-2003
Games & more
Download games and other
applications. Once you have selected
a game or application you can start
to download it. Then you can use the
application. Applications and games
can be found at: wap.my-siemens.com
or on the Internet under www.my-
siemens.com/city
Games and applications
Stored applications and links are
found in the folder:
§Menu§¢¢Games & more
Different functions are available
depending on which entry is
highlighted:
r Use game/application offline
§Select§ Application ready to run
immediately.
q Load game/application online
§Select§ Just descriptive file;
application yet to be
loaded.
Load link (optional)
§Internet§ The selected Internet
page is loaded.
Useful for many games (Virtual Joystick):
You can use WAP to download applications (e.g.
ringtones, games, images, animations) from the
Internet. Downloading or running applications will
not affect or change the software already
installed on your Java™-enabled mobile phone.
Siemens excludes all warranty and liability claims
in respect of or in connection with any
applications subsequently installed by the
customer and any software not included in the
original delivery package. This also applies to
functions enabled subsequently at the customer's
instigation. The purchaser bears sole risk for the
loss of, damage to, and any defects arising in, this
device or the applications and for any direct
damage or consequential damage of whatever
nature resulting from the use of this application.
For technical reasons, such applications and
subsequent enabling of certain functions are lost
in the event of the device being replaced/re-
supplied and may be lost if it is repaired.
In such cases, the buyer is required to download
or release the application again. Please ensure
that your phone has Digital Rights Management
(DRM) so that individual applications downloaded
via WAP are protected from unauthorised
reproduction. These applications are then
exclusively intended for your phone and cannot
be transferred from this even to create a backup.
Siemens does not warranty, guarantee or accept
any liability for the customer's ability to download
or enable applications again or to do so free of
charge. Where technically possible, back up your
applications to PC using the Siemens Data
Exchange Software (to download from the
Internet:
www.my-siemens.com/mc60).
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Setup.fm
left page (40) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
Setup
40
VAR Language: English; VAR issue date: 11-Juni-2003
Setup
Profiles
Several settings can be stored in a
phone profile in order, for example,
to adapt the phone to the
surrounding level of noise.
• Five standard profiles are provided
with default settings. They can be
changed however:
Normal envi., Quiet environ., Noisy
environ., Car Kit, Headset
• You can set two personal profiles
(<Name>).
• The special profile Aircraft mode
cannot be changed.
§Menu§¢>¢Profiles
Switch on
Select default profile or
personal profile.
§Select§ Switch on profile.
Setup
Select profile.
§Options§ Open menu, then select
Change sett. . The list of
available functions is
displayed.
Car Kit
If a Siemens original Car Kit is used
the profile is activated automatically
as soon as the phone is inserted into
the cradle (S. 36).
Headset
If an original Siemens headset is
used the profile is activated
automatically as soon as the headset
is in operation.
Aircraft mode
All alarms (appointments, alarm
clock) are deactivated. This profile
cannot be modified. The phone will
switch off automatically if you select
this profile.
Switch on
Scroll to Aircraft mode .
§Select§ Switch on profile. A
security prompt must be
confirmed. The phone
switches itself off
automatically.
Normal mode
When you switch on your phone
again, the previously set profile will
be reactivated automatically.
right page (41) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Setup.fm
41Setup
VAR Language: English; VAR issue date: 11-Juni-2003
Display
§Menu§¢>¢Display¢Select
function.
Language
Set the language of the display text.
‘Automatic’ will set the language of
your home service provider. To
return to this language in standby
mode:
* # 0 0 0 0 #
Text input
See also p. 22.
T9 preferred
Activate/deactivate intelligent text
entry.
Input language
Select language for text entry.
Languages with T9 support are
marked with the T9 symbol.
Wallpaper
Set wallpaper graphic for display.
Logo
Choose picture to be displayed
instead of the provider logo.
Colour scheme
Select colour scheme for the entire
user interface
Screensaver
The screensaver shows a picture in
the display when a period set by you
has elapsed. The function is ended
by an incoming call or by pressing
any key. Other screensavers:
www.my-siemens.com/screensaver
Start up anim.
Shown when the phone is switched
on. Additional animations:
www.my-siemens.com/animations
Shutdn anim.
Shown when the phone is switched
off.
Own greeting
Enter greeting to be displayed when
phone is switched on.
Big letters
You can choose between two font
sizes for the display.
Illumination
Set display light brighter/darker.
Contrast
Set display contrast.
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Setup.fm
left page (42) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
Setup
42
VAR Language: English; VAR issue date: 11-Juni-2003
Audio
§Menu§¢>¢Audio ¢Select
function.
You can set the tones to suit your
needs.
Ringer setting
Activate/deactivate the ringtone or
reduce it to a short beep.
Silent alert
Activate/deactivate the silent alert
(functions in addition to ringtone).
The silent alert is activated if the
highest volume is set for the
ringtone. This is to remind you not to
hold the phone to your ear when ringing
in order to avoid damaging your
hearing.
Volume
Set different volumes for types of
call/functions.
Ring tones
Set the ringtones for call
types/functions separately or record
a new ringtone. Additional
ringtones:
www.my-siemens.com/ringtones
Call screening b
Only calls from numbers that are in
the Phonebook or in a predefined
group are signalled. Other calls are
only displayed. If you do not accept
these calls, they are diverted to your
mailbox (if set, S. 32).
= Screen display in standby
mode:
call screening is activated.
Key tones
You can set the type of acoustic key
tone:
Click or Tone or Still
Minute beep
During the call, you will hear a beep
once a minute as a reminder.
Info tones
Set service and alarm tones.
Warning!
Please make sure you have accepted the
call before holding the phone to your ear.
This will avoid damage to your hearing from
loud ringtones.
right page (43) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Setup.fm
43Setup
VAR Language: English; VAR issue date: 11-Juni-2003
Keys
§Menu§¢>¢Keys ¢Select
function.
Any to answer
Incoming calls can be accepted by
pressing any key
(except for).
Auto key lock
If activated, the keypad is locked
automatically if no key has been
pressed for one minute in standby
mode. This prevents the phone from
being used accidentally. However,
you can still be called and you can
still make an emergency call.
Key tones
You can set the type of acoustic key
tone:
Click or Tone or Still
Phone setup
§Menu§¢>¢Phone setup
¢Select function.
Call waiting b
If you are registered for this service,
you can check whether it is set and
you can activate/deactivate it (see
also p. 19).
Hide ID b
If activated, your phone number will
not appear on the other party’s
display (depending on tyour service
providers).
Divert
You can specify when calls should be
diverted to your mailbox or other
numbers.
Set up call divert (example):
The most common condition for call
divert is, for example:
Unanswered b
Select Unanswered.
(Includes the conditions
Not reachable,No reply,
Busy, see below)
§Select§ Press and select Set .
Additional information
The keypad can also be directly locked and
unlocked in idle state.
In each case:
Hold down .
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Setup.fm
left page (44) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
Setup
44
VAR Language: English; VAR issue date: 11-Juni-2003
Enter the phone number
to which the caller will be
diverted (if not already
entered).
§OK§ Confirm. After a short
pause, the setting is
confirmed by the
network.
All calls b
All calls are diverted.
?Symbol in the top line of
the display in standby
mode.
Other possibilities for divert:
Not reachable,No reply,Busy,Receiving
fax,Receiving data
Status check
You can check the current divert
status for all conditions.
After a short pause, the current
situation is transmitted by the
network and displayed.
ACondition set.
@Not set.
DDisplay if status is
unknown (e.g. with a new
SIM card).
Clear all b
All set diverts are cleared.
Fact. settings
Reset phone to default values
(factory setting).
Filesystem
Format the file system (p. 54)
(Format) and delete (not Phonebook)
or defragment all stored data (Clean
up).
Phone identity
Display the phone identity number
(IMEI) and software version.
Auto off
The phone switches off each day at
the set time.
Clock
§Menu§¢>¢Clock¢Select
function.
Time/date
The clock must be set to the right
time once at start-up.
§Change§ First enter the date, then
the time.
Time zones
Set the time zone for where you
currently are .
Additional information
If the battery is removed for longer than 30
seconds, the clock must be reset.
right page (45) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Setup.fm
45Setup
VAR Language: English; VAR issue date: 11-Juni-2003
Date format
DD.MM.YYYY or MM/DD/YYYY
Time format
Select 24h or 12h.
Show clock
Activate/deactivate time display in
standby mode.
Buddhist year
Switch to the Buddhist year (not on
all phone models).
Connectivity
§Menu§¢>¢Connectivity
¢Select a function.
GPRS b
§Yes§ / §No§ Switch GPRS function
on/off.
GPRS info
Display information on the
connectivity status.
Authentication
§Change§ Activate or deactivate
encrypted WAP dial-up
(CSD connections only).
Data services
For the MMS, WAP and HTTP
applications at least one connection
profile must be set up and activated.
Preparation of the phone depends
on each service provider:
• The settings have already been
implemented by the provider. You
can start immediately.
• Access profiles have already been
created by your provider. Then
select and activate profile.
• The access profiles must be
configured manually.
If necessary, check with your service
provider for details. Current settings
for each service provider may be
found in the Internet under
www.my-siemens.com/
customercare in the FAQ section.
Select profile.
§Options§ Open menu, then select
Change sett.
If necessary enter CSD settings and
GPRS settings (your service provider
will supply you with information on
this if necessary):
§Options§ Open, select Change sett.
¢§Edit§ and enter data.
§Save§ Save settings.
HTTP profile
Select profile.
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Setup.fm
left page (46) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
Setup
46
VAR Language: English; VAR issue date: 11-Juni-2003
Fax/data mod.
Rec fax/data b
The call will be signalled by a special
ringtone (fax or data). Now start the
communication program in your PC
to receive the fax/data.
Send vce/fax b
To switch from voice mode to fax
mode, set the function on the phone
before transmission.
Voice/fax rec
After starting the PC communication
program, activate the function during
a call.
End transmission
End transmission with PC software
and/or press .
Security
§Menu§¢>¢Security ¢Select
function.
Codes
PIN control,Change PIN,Change PIN2,
Chg.phonecode, (p. 16).
Babysitter
(Phone-code protected)
Only one phone number can be
dialled(p. 20).
Only ‚b
Restrict calls to SIM-protected
numbers in the Phonebook.
Last 10 only b
Restrict calls to the list of ‘dialled
numbers’(p. 29).
This SIM only b
Your phone is prevented from being
used with a different SIM card.
Barrings b
Network barring restricts the use of
your SIM card.
All outgoing: Outgoing calls, except
emergency numbers, are barred.
Outgo internat: Only national calls can
be made.
Out.int.x home: International calls are
not permitted apart from calls to
your home country.
All incoming: The phone is barred for
all incoming calls.
When roaming: You will not receive
calls when outside your home
network.
Status check: Status check for
network barring
Clear all: Clear all barrings.
right page (47) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Setup.fm
47Setup
VAR Language: English; VAR issue date: 11-Juni-2003
Network
§Menu§¢>¢Network¢Select
function
Line b
To select/bar a telephone number,
two independent telephone numbers
have to be registered.
Network info
The list of GSM networks currently
available is displayed.
Choose network
Network search is restarted.
Auto network
If activated, the next network is
dialled in the order of your
"preferred networks".
Pref. network
Set the service providers you prefer
when you leave your home network.
Band selection b
Select either GSM 900, GSM 1800 or
GSM 1900.
Fast search
Network reconnection is speeded
up.
User group b
Depending on service provider, you
can create groups with this service.
These can have access to internal
(company) information, for
example, or special tariffs apply.
Please check with your service
provider for details.
Accessories
§Menu§¢>¢Accessories
¢Select function.
Car Kit
Auto answer
Calls are accepted automatically
after a few seconds.
Auto off
You can adjust the time between
switching off the ignition and
switching off the phone.
Car loudspk.
Improves playback in certain
circumstances.
Headset
Accept call with Call key or PTT key
(Push To Talk), even when the auto
key lock is activated.
Auto answer
Calls are accepted automatically
after a few seconds.
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Organizer.fm
left page (48) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
Organiser
48
VAR Language: English; VAR issue date: 11-Juni-2003
Organiser
Calendar
§Menu§¢¯¢Calendar
You can enter appointments in the
calendar. Time and date must be set
for the calendar to work correctly
(p. 44).
Press briefly to page
between days, hold down
to page between months.
Appointments exist on
calendar days displayed in
bold.
Agenda
§Agenda§ Call up from the monthly
overview.
Appointments for each individual
day are shown in the agenda in
chronological order.
Alarm
§Menu§¢¯¢Alarm
All appointment entries are
displayed in chronological order.
Enter new appointment
§Select§ Press.
Type:
§Change§ Press repeatedly to select
the required type:
FMemo.
Text input for description
GCall.
Enter phone number.
Shown with alarm.
HMeeting.
Text input for description
LBirthday
or
Anniversary
Enter name and date.
Then make further entries
field by field.
Description:
Description of appointment.
Date:
Date of appointment.
Time:
Time of appointment.
Alarm:
§ON§ Activate alarm.
Enter start time of the
alarm before the
appointment, then select
with
§Change§ Minutes,Hours,Days.
right page (49) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Organizer.fm
49Organiser
VAR Language: English; VAR issue date: 11-Juni-2003
Reoccurrence:
Select a timeframe for repeating the
appointment: No,Daily,Weekly,
Monthly,Annual.
Enter a parameter for repeating:
Forever,Until,Occurrences (number)
If Weekly is selected, certain
weekdays can be highlighted.
Alarm
When the set date and time are
reached there is an audio and a
visual alarm.
Alarm type Memo/Meeting: the text is
shown in the display.
Alarm type Call: The phone number
is displayed and can be dialled
immediately.
Alarm type Birthday and Anniversary:
you will be notified one day before
the event and on the
birthday/anniversary itself.
§Pause§ The alarm stops for 5
minutes.
§Off§ The alarm is stopped.
Notes
T9 support (p. 21) makes writing
short notes such as shopping lists
easier. Save confidential notes with
the phone code (p. 16). Please note
that with the aid of suitable
programs it is possible for
confidential notes to be read from
the phone when connected to a PC.
Missed appointments
Events with an alarm to which you
have not reacted are listed for
reading.
Time zones
Set the time zone for your area.
Calend. setup
§Menu§¢¯¢Calend. setup
Begin of week
You can set which weekday is listed
first on the left in the monthly and
weekly overviews.
Additional information
Alarms set are shown in the display as
follows:
Alarm clock, Appointments.
An alarm sounds even when the phone is
switched off. To deactivate it press any key.
Set alarm tone...................................p. 42
Clock .................................................p. 44
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Extras.fm
left page (50) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
Extras
50
VAR Language: English; VAR issue date: 11-Juni-2003
Extras
§Menu§¢J¢Select function.
Alarm clock
§Menu§¢J¢Alarm clock
The alarm will ring at the time set by
you, even when the phone is
switched off.
§On§ / §Off§ Switch on/off.
Setting
§Change§ Display options: alarm
time and days.
Navigate to the days.
§Change§ Set days for alarm calls,
then §OK§.
Calculator
§Menu§¢J¢Calculator
Enter number
(up to 8 digits).
§.§=§+§-§*§/§ Select calculator function.
Result is displayed.
Currency conv
§Menu§¢J¢Currency conv
Calculate the exchange rates. You
can enter three ccurrencies. If no
currency has yet been entered, press
§OK§ for first input.
§Options§ Open menu.
New entry
Select.
Enter names for the
currencies and confirm
with §OK§ .
Enter exchange rate. Save
with §Options§ and §OK§.
Select a combination of currencies to
convert.
§Select§ Confirm and enter
amount.
Result is displayed.
§Repeat§ Another
conversion using
different data.
Note
Depending on your service provider, the
Extras menu may also include Internet
and Games & more. See the Surf & fun
(p. 38) column for further functions.
Calculator functions
§.§=§+§-§*§/§ Press right control key
repeatedly.
Toggle between "+" and "-".
%Convert to percentage.
,Save/retrieve number.
eExponent (max. two digits).
Special key:
Set decimal point.
right page (51) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Extras.fm
51Extras
VAR Language: English; VAR issue date: 11-Juni-2003
Stopwatch
§Menu§¢J¢Stopwatch
Two intermediate times can be
recorded and saved.
Start/stop.
Intermediate time.
§Start§ Start stopwatch.
§Reset§ Reset.
Countdown
§Menu§¢J¢Countdown
A set time elapses. The last
3 seconds are indicated by a beep. At
the end a special beep sounds.
§Set§ Set period of time.
§Start§ Start counter.
§Stop§ Interrupt counter.
§Change§ Change period of time.
§Reset§ Set to start time.
Voice command
§Menu§¢J¢Voice command
Functions can be started by a voice
command. Up to 20 voice recordings
can be saved in the phone for voice
dialling or voice commands (not on
SIM card!).
Record
A list of the available functions is
displayed.
Select a function.
§Record§ Press.
§Yes§ Confirm selected
function.
§Start§ Start recording.
A short signal sounds. Now say the
command corresponding to the
function and repeat it when
prompted.
Apply
Press down (in standby
mode).
A short signal (beep) sounds and a
prompt appears in the display. Now
say the function.
Noisy environments may affect voice
recognition.
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Extras.fm
left page (52) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
Extras
52
VAR Language: English; VAR issue date: 11-Juni-2003
New ringtone
§Menu§¢J¢New ringtone
You can use the phone’s microphone
to record tones and sounds and then
use these as ringtones (see also
p. 42).
§Record§ Start recording. The
current recording
duration and available
time remaining are
displayed.
§Stop§ End recording.
§Save§ Enter the name of the
new ringtone.
§Save§ Save.
After that, you can replay the
recording or assign it to an event
using §Options§.
SIM services (optional)
§Menu§¢J¢SIM services
Your service provider may offer
special applications such as mobile
banking, share prices, etc. via the
SIM card.
If you have such a SIM card, the SIM
services will appear in the main
menu under "Extras" or directly
above the control key (on the left).
NSymbol for SIM services.
Where there are several applications,
these are displayed in a SIM services
menu.
With the SIM services menu, your
phone is ready to support future
additions in your service provider's
user package. For further
information, please contact your
service provider.
Note
If a call is accepted during recording, the
recording is aborted.
right page (53) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_FastDial_mymenu.fm
53Fast access key/My menu
VAR Language: English; VAR issue date: 11-Juni-2003
Fast access key/My menu
Control key (left)
Assign a function/phone number to
this key. With some service
providers, this key takes you directly
to their Internet portal.
Change (example)
§New SMS§ Press briefly .
§Change§ Pick out the application,
e.g., §Internet§.
Phone number: Select from
Phonebook.
§Select§ Confirm setting.
Apply (example)
Key with a phone number/name
assigned.
§Carola§ Press down.
Speed dialling keys
Only possible on keys 2 to 9. Number
key 1 is reserved for the mailbox.
Change (example)
Press an unassigned
number key (2- 9):
§Set§ Select the application.
Phone number: Pick out
from Phonebook.
Bookmarks: Scroll to a URL
in your bookmarks list
§Select§ Confirm setting.
Apply (example)
Hold key down.
My menu
§Menu§ Press.
§My menu§ Press.
Set up your own menu. The list of
10 entries is preset, but can be
changed.
Change menu
Select the entry to be
changed.
§Options§ Open menu.
Change sett.
Select. The selection list is
opened. Select the new
entry.
For a function such as Calendar:
§Set§ Confirm.
For Phonebook also select the phone
number or for Internet the bookmark.
§Select§ Confirm.
If you have selected a phone number
as a new entry, this can be called
directly from the My menu. When
selecting a bookmark, the link to
that Internet address is established.
Reset all
§Options§ Press and select Reset all.
The default entries are reset.
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Explorer.fm
left page (54) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
Filesystem
54
VAR Language: English; VAR issue date: 11-Juni-2003
Filesystem
To organise your files, you can use
the file system like a PC file manager.
The file system assigns special
folders to different data types.
§Menu§
A list of the folders and files is
displayed.
Navigate through this list using the
control key:
scroll up and down.
Go back from folder.
§Open§ Open folder or execute
file with related
application
or
for unknown file types:
§Mark§ Mark file.
Index structure
The file system assigns special
folders to different data types.
Colour
scheme Colour schemes *.col
Data in-
box Inbox *.*
Internet Internet files *.dat
Java Applications.
Data.
*.jad
*.jar
Misc Other files *.*
Pictures Pictures and
animations
Sub-folder:
Camera
Own photos
*.bmx
(anim)
SMS
Archive Sub-folders:
Inbox: Incoming
mail
Draft: Drafts
Unsent: Unsent
SMS
Sent: Sent SMS
*.smo
*.smi
Sounds Ringtones, tones *.mid
*.srt
*.amr
*.wav
(Intel
DVI)
Text
modules Text modules *.tmo
Depending on the service provider the file
system’s structure, content and
functionality may vary.
right page (55) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:13)
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_faq.fm
55Questions & Answers
VAR Language: English; VAR issue date: 11-Juni-2003
Questions & Answers
If you have any questions on the use of your phone, you can contact us at
www.my-siemens.com/customercare around the clock. As further help we have listed
below some frequently asked questions and answers.
Problem Possible causes Possible solution
Phone cannot
be switched on.
On/Off key not pressed long
enough.
Press On/Off key for at least two seconds.
Flat battery. Charge battery. Check charging indicator in the
display.
Battery contacts dirty. Clean contacts.
See also below under “Charging
error”
Too little
standby time.
Frequent use of organiser and
games.
Restrict use if necessary.
Fast search activated. Deactivate fast search .
Display illumination on. Switch off display illumination (p. 41).
Unintentional keystrokes
(illumination!).
Activate key lock (p. 43).
Charging error
(charge icon not
displayed).
Battery totally discharged. 1) Plug in charger cable, battery is on charge.
2) Charge icon appears after approx. 2 hours.
3) Charge battery.
Temperature out of range:
+5 °C to +40 °C.
Make sure the ambient temperature is right, wait for a
while, then recharge.
Contact problem. Check power supply and connection to the phone.
Check battery contacts and plug socket, clean them if
necessary, then insert battery again.
No mains voltage. Use different mains power socket, check mains
voltage.
Wrong charger. Only use original Siemens accessories.
Battery faulty. Replace battery.
SIM error. SIM card not inserted correctly. Check that the SIM card is inserted correctly (p. 11).
Dirty SIM card contacts. Clean SIM card with a dry cloth.
SIM card with wrong voltage. Use 3V SIM cards only.
SIM card damaged (e.g. broken). Carry out a visual check. Change SIM card at service
provider.
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_faq.fm
left page (56) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:13)
Questions & Answers
56
VAR Language: English; VAR issue date: 11-Juni-2003
No network
connection.
Weak signal. Move higher, to a window or an open space.
Outside GSM range. Check service provider's coverage area.
Invalid SIM card. Complain to the service provider.
New network not authorised. Try manual selection or select a different network
(p. 47).
Network call barring is set. Check network barrings (p. 46).
Network overloaded. Try again later.
Phone loses
network.
Signal too weak. Reconnection to another service provider is
automatic (p. 47). Switching phone off and on again
can speed this up.
Calls not
possible.
Second line set. Set first line 1 (p. 47).
New SIM card inserted. Check for new barrings.
Charge limit reached. Reset limit with PIN 2 (p. 29).
Credit used up. Load credit.
Certain uses of
phone not
possible.
Call restrictions are in place. Barrings can be set by service provider. Check
barrings (p. 46).
Impossible to
make entries in
Phonebook.
Phonebook is full. Delete entries in Phonebook (p. 25).
Voice message
not functioning.
Call divert to mailbox not set. Set call divert to mailbox (p. 43).
SMS (text
message) %
flashing.
SMS memory is full. To free up capacity, delete or file (p. 34) messages
(SMS).
Function cannot
be set.
Not supported by service provider
or registration required.
Contact your service provider.
Capacity
problems with,
for example,
Games & More,
ringtones,
pictures, SMS
archive.
Phone memory full. Delete files in the relevant areas.
No WAP access,
downloading not
possible.
Profile not activated, profile
settings wrong/incomplete.
Activate (p. 38), set (p. 38) WAP profile or set HTTP
profile (p. 45). If necessary ask your service provider.
Problem Possible causes Possible solution
right page (57) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:13)
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_faq.fm
57Questions & Answers
VAR Language: English; VAR issue date: 11-Juni-2003
Text message
cannot be sent.
Service provider does not support
this service.
Contact your service provider.
Phone number for service centre
not set or incorrect.
Set service centre (p. 37).
SIM card contract does not
support this service.
Contact your service provider.
Service centre too busy. Repeat message.
Recipient does not have a
compatible phone.
Check.
EMS pictures &
sounds are not
displayed at the
destination
phone
Destination phone does not
support the EMS standard.
No Internet
access possible.
Incorrect WAP profile set, or
wrong or incomplete settings.
Check settings or contact your service provider.
PIN error/
PIN2 error.
Three wrong entries. Enter the PUK (MASTER PIN) supplied with the SIM
card according to the instructions. If the PUK
(MASTER PIN) has been lost, please contact your
service provider.
Phone code
error.
Three wrong entries. Contact Siemens Service (p. 58).
Service provider
Code error.
No authorisation for this service. Contact your service provider.
Too few/too
many menu
entries.
Functions may have been added
or deleted by the service provider
via the SIM card.
Check with your service provider.
No fax possible. Wrong settings in the PC. Check settings .
No authorisation for this service. Contact your service provider.
Charge meter
does not work.
Charge pulse is not transmitted. Contact your service provider.
Damage
Severe shock. Remove battery and SIM and re-insert them. Do not dismantle the phone!
Phone became
wet.
Remove battery and SIM. Dry immediately with a cloth, but do not apply heat. Dry
connector contacts thoroughly. Stand mobile upright in an air current. Do not dismantle
the phone!
Problem Possible causes Possible solution
Reset all settings to factory default (p. 44): * # 9 9 9 9 #
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Hotline.fm
left page (58) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
Customer Care
58
VAR Language: English; VAR issue date: 11-Juni-2003
Customer Care
You can also get personal advice about our
range of products on our Premium Hotline:
United Kingdom...................0906 9597500
(£0.75 per minute)
Qualified Siemens employees are waiting to
offer you expert information about our
products and installation.
In some countries repair and replace
services are impossible where the products
are not sold through our authorised dealers.
When calling customer service, please have
ready your receipt and the phone identity
number (IMEI, to display press *# 0 6 #), the
software version (to display, press *# 0 6 #,
then info) and if available, your Siemens
Service customer number.
If repair work is necessary, please contact
one of our service centres:
Abu Dhabi .........................................0 26 42 38 00
Argentina .....................................0 80 08 88 98 78
Australia..........................................13 00 66 53 66
Austria.............................................05 17 07 50 04
Bahrain .................................................... 40 42 34
Bangladesh.......................................0 17 52 74 47
Belgium.............................................0 78 15 22 21
Bolivia ...............................................0 21 21 41 14
Bosnia Herzegovina..........................0 33 27 66 49
Brazil............................................0 80 07 07 12 48
Brunei ................................................. 02 43 08 01
Bulgaria............................................... 02 73 94 88
Cambodia ........................................... 12 80 05 00
Canada ........................................1 88 87 77 02 11
China ...........................................0 21 50 31 81 49
Croatia ..............................................0 16 10 53 81
Czech Republic...............................02 33 03 27 27
Denmark ............................................. 35 25 86 00
Dubai ................................................0 43 96 64 33
Egypt.................................................0 23 33 41 11
Estonia................................................ 06 30 47 97
Finland ............................................09 22 94 37 00
France.............................................01 56 38 42 00
Germany ......................................0 18 05 33 32 26
Greece .........................................0 80 11 11 11 16
Hong Kong.......................................... 28 61 11 18
Hungary ..........................................06 14 71 24 44
Iceland .................................................. 5 11 30 00
India.........................................01 13 73 85 89 - 98
Indonesia .....................................0 21 46 82 60 81
Ireland.............................................18 50 77 72 77
Italy .................................................02 24 36 44 00
Ivory Coast.......................................... 21 35 02 35
Jordan...............................................0 64 39 86 42
Kenya.................................................... 2 72 37 17
Kuwait ................................................... 2 45 41 78
Latvia .................................................... 7 50 11 18
Lebanon.............................................. 01 44 30 43
Libya ...............................................02 13 50 28 82
Lithuania ...........................................8 52 74 20 10
Luxembourg........................................ 43 84 33 99
Macedonia .......................................... 02 13 14 84
Malaysia..........................................03 21 63 11 18
Malta .....................................00 35 32 14 94 06 32
Mauritius ............................................... 2 11 62 13
We offer fast, individual advice! You have
several options:
Our online support on the Internet:
www.my-siemens.com/customercare
We can be reached any time, any place.
You are given 24 hour support on all
aspects of our products. Here you will find
an interactive fault-finding system, a
compilation of the most frequently asked
questions and answers, plus user guides
and current software updates to
download.
You will also find the most frequently
asked questions and answers in the
section entitled xxx in this user guide.
right page (59) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Hotline.fm
59Customer Care
VAR Language: English; VAR issue date: 11-Juni-2003
Mexico .......................................01 80 07 11 00 03
Morocco...............................................22 66 92 09
Netherlands .................................0 90 03 33 31 00
New Zealand...................................08 00 27 43 63
Nigeria ..............................................0 14 50 05 00
Norway.................................................22 70 84 00
Oman....................................................... 79 10 12
Pakistan..........................................02 15 66 22 00
Paraguay ..........................................8 00 10 20 04
Philippines ........................................0 27 57 11 18
Poland.............................................08 01 30 00 30
Portugal ............................................8 08 20 15 21
Qatar....................................................04 32 20 10
Romania .........................................02 12 04 60 00
Russia..........................................8 80 02 00 10 10
Saudi Arabia .....................................0 22 26 00 43
Serbia .............................................01 13 22 84 85
Singapore ............................................62 27 11 18
Slovak Republic ..............................02 59 68 22 66
Slovenia............................................0 14 74 63 36
South Africa ....................................08 60 10 11 57
Spain.................................................9 02 11 50 61
Sweden.............................................0 87 50 99 11
Switzerland .....................................08 48 21 20 00
Taiwan ............................................02 23 96 10 06
Thailand............................................0 22 68 11 18
Tunisia .................................................71 86 19 02
Turkey..........................................0 21 65 79 71 00
Ukraine ........................................8 80 05 01 00 00
United Arab Emirates........................0 43 31 95 78
United Kingdom ...........................0 87 05 33 44 11
USA .............................................1 88 87 77 02 11
Vietnam................................................45 63 22 44
Zimbabwe ............................................04 36 94 24
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60_Specification.fm
left page (60) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:14)
Specifications
60
VAR Language: English; VAR issue date: 11-Juni-2003
Specifications
Exposure to
radiofrequency signals
Your wireless handheld portable tel-
ephone is a low power radio trans-
mitter and receiver. When it is ON, it
receives and also sends out radiofre-
quency (RF) signals.
In August 1996, The Federal Com-
munications Commission (FCC)
adopted RF exposure guidelines with
safety levels for hand-held wireless
phones. Those guidelines are con-
sistent with the safety standards pre-
viously set by both U.S. and interna-
tional standards bodies:
• American National Standards In-
stitute (ANSI) C95.1 (1992)
• National Council of Radiation Pro-
tection and Measurement (NCRP)
Report 86 (1986)
• International Commission of Non-
Ionizing Radiation Protection (IC-
NIRP) 1996
• Ministry of Health (Canada) Safety
Code 6
Those standards were based on com-
prehensive and periodic evaluations
of the relevant scientific literature.
For example, over 120 scientists, en-
gineers, and physicians from univer-
sities, government health agencies,
and industry reviewed the available
body of research to develop the ANSI
standard (C95.1).
The design of your phone complies
with the FCC guidelines (and those
standards). For additional informa-
tion concerning exposure to radio
frequency signal, see the statement
by the FDA at the end of this user
guide.
Technical data
GSM class: 4 (2 Watt)
Frequency range: 880… 960 MHz
GSM class: 1 (1 Watt)
Frequency range: 1,710… 1,880 MHz
GSM class: 1 (1 Watt)
Frequency range: 1,850… 1,990 MHz
Weight: 86 g
Size 109x46x21 mm
(88 ccm)
Li-Ion Battery: 700 mAh
Operating temper-
ature: 14 ° F to 131 °F
SIM card: 3.0 V
right page (61) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_Maintenance.fm
61Care and maintenance
VAR Language: English; VAR issue date: 11-Juni-2003
Care and
maintenance
Your phone has been designed and
crafted with great care and attention
and should also be treated with care.
The suggestions below will help you
to enjoy your phone for many years.
• Protect your phone from moisture
and humidity! Precipitation,
humidity and liquids contain
minerals that will corrode
electronic circuits. Nevertheless,
should your phone become wet,
disconnect it immediately from
the power supply and remove the
battery!
• Do not use or store the phone in
dusty, dirty areas. Its moving parts
may become damaged.
• Do not store your phone in hot
areas. High temperatures can
shorten the life of electronic
devices, damage batteries and
warp or melt certain plastics.
• Do not store your phone in cold
areas. When the phone warms up
again (to its normal ambient
temperature), moisture can form
inside the phone, which may
damage electronic circuit boards.
• Do not drop, knock or shake your
phone. Rough handling can
damage internal circuit boards!
• Do not use harsh chemicals,
cleaning solvents, or strong
detergents to clean the phone!
The suggestions given above apply
equally to your phone, battery,
charger and all accessories. If any of
these parts are not working properly,
take them to your nearest qualified
service outlet. The personnel there
will assist you and, if necessary,
repair the device.
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\Akku_Quali.fm
left page (62) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
Battery quality statement
62
VAR Language: English; VAR issue date: 11-Juni-2003
Battery quality
statement
The capacity of your mobile phone
battery will reduce each time it is
charged/emptied. Storage at too
high or low temperatures will also
result in a gradual capacity loss. As a
result the operating time of your
mobile phone may be considerably
reduced, even after a full recharge of
the battery.
Regardless of this, the battery has
been designed and manufactured so
that it can be recharged and used for
six months after the purchase of
your mobile phone. After six
months, if the battery is clearly
suffering from loss of performance,
we recommend that you replace it.
Please buy only Siemens original
batteries.
right page (63) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\am_FDA.FM
63U.S. FDA
VAR Language: English; VAR issue date: 11-Juni-2003
U.S. FDA
The U.S. Food and Drug
Administration's (FDA) Center
for Devices and Radiological
Health Consumer Update on
Mobile Phones
FDA has been receiving inquiries
about the safety of mobile phones,
including cellular phones and PCS
phones. The following summarizes
what is know – and what remains
unknown – about whether these
products can pose a hazard to
health, and what can be done to
minimize any potential risk. This
information may be used to respond
to questions.
Why the concern?
Mobile phones emit low levels of
radio frequency energy (i.e., radio
frequency radiation) in the
microwave range while being used.
They also emit very low levels of
radio frequency energy (RF),
considered non-significant, when in
the stand-by mode. It is well known
that high levels of RF can produce
biological damage through heating
effects (this is how your microwave
oven is able to cook food). However,
it is not known whether, to what
extent, or through what mechanism,
lower levels of RF might cause
adverse health effects as well.
Although some research has been
done to address these questions, no
clear picture of the biological effects
of this type of radiation has emerged
to date. Thus, the available science
does not allow us to conclude that
mobile phones are absolutely safe,
or that they are unsafe. However,
the available scientific evidence does
not demonstrate adverse health
effects associated with the use of
mobile phones.
What kinds of phones are in question?
Questions have been raised about
hand-held mobile phones, the kind
that have a built-in antenna that is
positioned close to the user's head
during normal telephone
conversation. These types of mobile
phones are of concern because of
the short distance between the
phone's antenna – the primary
source of the RF – and the person's
head. The exposure to RF from
mobile phones in which the antenna
is located at greater distances from
the user (on the outside of a car, for
example) is drastically lower than
that from hand-held phones,
because a person's RF exposure
decreases rapidly with distance from
the source. The safety of so-called
"cordless phones", which have a
base unit connected to the
telephone wiring in a house and
which operate at far lower power
levels and frequencies, has not been
questioned.
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\am_FDA.FM
left page (64) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
U.S. FDA
64
VAR Language: English; VAR issue date: 11-Juni-2003
How much evidence is there that hand-
held mobile phones might be harmful?
Briefly, there is not enough evidence
to know for sure, either way; howev-
er, research efforts are on-going.
The existing scientific evidence is
conflicting and many of the studies
that have been done to date have
suffered from flaws in their research
methods. Animal experiments inves-
tigating the effects of RF exposures
characteristic of mobile phones have
yielded conflicting results. A few ani-
mal studies, however, have suggest-
ed that low levels of RF could accel-
erate the development of cancer in
laboratory animals. In one study,
mice genetically altered to be predis-
posed to developing one type of can-
cer developed more than twice as
many such cancers when they were
exposed to RF energy compared to
controls. There is much uncertainty
among scientists about whether re-
sults obtained from animal studies
apply to the use of mobile phones.
First, it is uncertain how to apply the
results obtained in rats and mice to
humans. Second, many of the stud-
ies showed increased tumor devel-
opment used animals that had al-
ready been treated with cancer-
causing chemicals, and other studies
exposed the animals to the RF virtu-
ally continuously – up to 22 hours
per day.
For the past five years in the United
States, the mobile phone industry
has supported research into the safe-
ty of mobile phones. This research
has resulted in two findings in partic-
ular that merit additional study:
1. In a hospital-based, case-control
study, researchers looked for an as-
sociation between mobile phone use
and either glioma (a type of brain
cancer) or acoustic neuroma (a be-
nign tumor of the nerve sheath). No
statistically significant association
was found between mobile phone
use and acoustic neuroma. There
was also no association between
mobile phone use and gliomas when
all types of gliomas were considered
together. It should be noted that the
average length of mobile phone ex-
posure in this study was less than
three years.
When 20 types of glioma were con-
sidered separately, however, an as-
sociation was found between mobile
phone use and one rare type of glio-
ma, neuroepithelliomatous tumors.
It is possible with multiple compari-
sons of the same sample that this as-
sociation occurred by chance. More-
over, the risk did not increase with
how often the mobile phone was
used, or the length of the calls. In
fact, the risk actually decreased with
cumulative hours of mobile phone
use. Most cancer causing agents in-
crease risk with increased exposure.
An ongoing study of brain cancers by
the National Cancer Institute is ex-
pected to bear on the accuracy and
repeatability of these results.1
right page (65) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\am_FDA.FM
65U.S. FDA
VAR Language: English; VAR issue date: 11-Juni-2003
2. Researchers conducted a large
battery of laboratory tests to assess
the effects of exposure to mobile
phone RF on genetic material. These
included tests for several kinds of
abnormalities, including mutations,
chromosomal aberrations, DNA
strand breaks, and structural
changes in the genetic material of
blood cells called lymphocytes. None
of the tests showed any effect of the
RF except for the micronucleus
assay, which detects structural
effects on the genetic material. The
cells in this assay showed changes
after exposure to simulated cell
phone radiation, but only after 24
hours of exposure. It is possible that
exposing the test cells to radiation
for this long resulted in heating.
Since this assay is known to be
sensitive to heating, heat alone
could have caused the abnormalities
to occur. The data already in the
literature on the response of the
micronucleus assay to RF are
conflicting. Thus follow-up research
is necessary. 2
FDA is currently working with
government, industry, and academic
groups to ensure the proper follow-
up to these industry-funded research
findings. Collaboration with the
Cellular Telecommunications
Internet Association (CTIA) in
particular is expected to lead to FDA
providing research
recommendations and scientific
oversight of new CTIA-funded
research based on such
recommendations.
Two other studies of interest have
been reported recently in the
literature:
• Two groups of 18 people were
exposed to simulated mobile
phone signals under laboratory
conditions while they performed
cognitive function tests. There
were no changes in the subjects'
ability to recall words, numbers,
or pictures, or in their spatial
memory, but they were able to
make choices more quickly in one
visual test when they were
exposed to simulated mobile
phone signals. This was the only
change noted among more than
20 variables compared.3
• In a study of 209 brain tumor
cases and 425 matched controls,
there was no increased risk of
brain tumors associated with
mobile phone use. When tumors
did exist in certain locations,
however, they were more likely to
be on the side of the head where
the mobile phone was used.
Because this occurred in only a
small number of cases, the
increased likelihood was too small
to be statistically significant.4
In summary, we do not have enough
information at this point to assure
the public that there are, or are not,
any low incident health problems
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\am_FDA.FM
left page (66) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
U.S. FDA
66
VAR Language: English; VAR issue date: 11-Juni-2003
associated with use of mobile
phones. FDA continues to work with
all parties, including other federal
agencies and industry, to assure that
research is undertaken to provide
the necessary answers to the
outstanding questions about the
safety of mobile phones.
What is known about cases of human
cancer that have been reported in users
of hand-held mobile phones?
Some people who have used mobile
phones have been diagnosed with
brain cancer. But it is important to
understand that this type of cancer
also occurs among people who have
not used mobile phones. In fact,
brain cancer occurs in the U.S.
population at a rate of about 6 new
cases per 100,000 people each year.
At that rate, assuming 80 million
users of mobile phones (a number
increasing at a rate of about 1
million per month), about 4800
cases of brain cancer would be
expected each year among those 80
million people, whether or not they
used their phones. Thus it is not
possible to tell whether any
individual's cancer arose because of
the phone, or whether it would have
happened anyway. A key question is
whether the risk of getting a
particular form of cancer is greater
among people who use mobile
phones than among the rest of the
population. One way to answer that
question is to compare the usage of
mobile phones among people with
brain cancer with the use of mobile
phones among appropriately
matched people without brain
cancer. This is called a case-control
study. The current case-control
study of brain cancers by the
National Cancer Institute, as well as
the follow-up research to be
sponsored by industry, will begin to
generate this type of information.
What is FDA's role concerning the safety
of mobile phones?
Under the law, FDA does not review
the safety of radiation emitting
consumer products such as mobile
phones before marketing, as it does
with new drugs or medical devices.
However, the agency has authority
to take action if mobile phones are
shown to emit radiation at a level
that is hazardous to the user. In such
a case, FDA could require the
manufacturers of mobile phones to
notify users of the health hazard and
to repair, replace or recall the
phones so that the hazard no longer
exists.
Although the existing scientific data
do not justify FDA regulatory actions
at this time, FDA has urged the
mobile phone industry to take a
number of steps to assure public
safety. The agency has
recommended that the industry:
right page (67) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\am_FDA.FM
67U.S. FDA
VAR Language: English; VAR issue date: 11-Juni-2003
• Support needed research into
possible biological effects of RF of
the type emitted by mobile
phones;
• Design mobile phones in a way
that minimizes any RF exposure to
the user that is not necessary for
device function; and
• Cooperate in providing mobile
phone users with the best possible
information on what is known
about possible effects of mobile
phone use on human health.
At the same time, FDA belongs to an
interagency working group of the
federal agencies that have
responsibility for different aspects of
mobile phone safety to ensure a
coordinated effort at the federal
level. These agencies are:
• National Institute for
Occupational Safety and Health
• Environmental Protection Agency
• Federal Communications
Commission
• Occupational Health and Safety
Administration
• National Telecommunications and
Information Administration
The National Institutes of Health also
participates in this group.
In the absence of conclusive information
about any possible risk, what can
concerned individuals do?
If there is a risk from these products
– and at this point we do not know
that there is – it is probably very
small. But if people are concerned
about avoiding even potential risks,
there are simple steps they can take
to do so. For example, time is a key
factor in how much exposure a
person receives. Those persons who
spend long periods of time on their
hand-held mobile phones could
consider holding lengthy
conversations on conventional
phones and reserving the hand-held
models for shorter conversations or
for situations when other types of
phones are not available.
People who must conduct extended
conversations in their cars every day
could switch to a type of mobile
phone that places more distance
between their bodies and the source
of the RF, since the exposure level
drops off dramatically with distance.
For example, they could switch to:
• a mobile phone in which the
antenna is located outside the
vehicle,
• a hand-held phone with a built-in
antenna connected to a different
antenna mounted on the outside
of the car or built into a separate
package, or
• a headset with a remote antenna
to a mobile phone carried at the
waist.
Where can I find additional information?
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\am_FDA.FM
left page (68) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
U.S. FDA
68
VAR Language: English; VAR issue date: 11-Juni-2003
For additional information, see the
following websites:
• Federal Communications
Commission (FCC) RF Safety
Program (select "Information on
Human Exposure to RF Fields from
Cellular and PCS Radio
Transmitters"):
http://www.fcc.gov/oet/rfsafety.
• World Health Organization (WHO)
International Commission on
Non-Ionizing Radiation Protection
(select Qs & As):
http://www.who.int/emf
• United Kingdom, National
Radiological Protection Board:
http://www.nrpb.org.uk
• Cellular Telecommunications
Internet Association (CTIA):
http://www.wow-com.com
• U.S. Food and Drug
Administration (FDA) Center for
devices and Radiological Health:
http://www.fda.gov/cdhr/
consumer/
1 Muscat et al. Epidemiological Study of
Cellular Telephone Use and Malignant Brain
Tumors. In: State of the Science
Symposium; 1999 June 20; Long Beach,
California.
2 Tice et al. Tests of mobile phone signals for
activity in genotoxicity and other laboratory
assays. In: Annual Meeting of the
Environmental Mutagen Society; March 29,
1999, Washington, DC; and personal
communication, unpublished results.
3 Preece, AW, Iwi, G, Davies-Smith, A,
Wesnes, K, Butler, S, Lim, E, and Varey, A.
Effect of a 915- MHz simulated mobile
phone signal on cognitive function in man.
Int. J. Radiat. Biol., April 8, 1999.
4 Hardell, L, Nasman, A, Pahlson, A,
Hallquist, A and Mild, KH. Use of cellular
telephones and the risk for brain tumors; a
case-control study. Int. J. Oncol, 15: 113-
116, 1999.
right page (69) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\am_FDA.FM
69FCC/Industry Canada Notice
VAR Language: English; VAR issue date: 11-Juni-2003
FCC/Industry
Canada Notice
Your phone may cause TV or radio
interference (for example, when
using a telephone in close proximity
to receiving equipment). The FCC or
Industry Canada can require you to
stop using your telephone if such
interference cannot be eliminated. If
you require assistance, please
contact your local service facility.
right page (71) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:23)
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\am_Driving_Tips.fm
71Ten Driving Safety Tips
VAR Language: English; VAR issue date: 11-Juni-2003
Ten Driving Safety
Tips
Your Siemens wireless phone gives
you the power to communicate by
voice – almost anywhere, anytime.
But an important responsibility
accompanies the benefits of wireless
phones, one that every user must
uphold.
When driving a car, driving is your
first responsibility. When using your
wireless phone behind the wheel of
a car, practice good common sense
and remember the following tips:
Get to know your phone and its features
such as speed dial and redial.
Carefully read your instruction
manual and learn to take advantage
of valuable features most phones
offer including, automatic redial and
memory dial – most phones can
store up to 99 numbers in memory
dial. Also, work to memorize the
phone keypad so you can use the
speed dial function without taking
your attention off the road.
When available, use a hands-free device.
A number of hands-free wireless
phone accessories are readily
available today. Whether you choose
an installed mounted device for your
phone or a speaker phone accessory,
take advantage of these devices if
they are available to you.
Position your phone within easy reach.
Make sure you place your wireless
phone within easy reach and where
you can grab it without removing
your eyes from the road. If you get
an incoming call at an inconvenient
time, let your voicemail answer it for
you.
Suspend conversations during
hazardous driving conditions or
situations.
Let the person you are speaking to
know you are driving; if necessary,
suspend the call in heavy traffic or
hazardous weather conditions. Rain,
sleet, snow and ice can be
hazardous, but so is heavy traffic. As
a driver, your first responsibility is to
pay attention to the road.
Do not take notes or look up phone
numbers while driving.
If you are reading an address book or
business card while driving a car, or
writing a "to do" list, then you are not
watching where you are going. It’s
common sense. Don’t get caught in a
dangerous situation because you are
reading or writing and not paying
attention to the road or nearby
vehicles.
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\am_Driving_Tips.fm
left page (72) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:23)
Ten Driving Safety Tips
72
VAR Language: English; VAR issue date: 11-Juni-2003
Dial sensibly and assess the traffic.
If possible, place calls when you are
not moving or before pulling into
traffic. Try to plan your calls before
you begin your trip, or attempt to
coincide your calls with times you
may be stopped at a stop sign, red
light or otherwise stationary. But if
you need to dial while driving, follow
this simple tip – dial only a few
numbers, check the road and your
mirrors, then continue.
Do not engage in stressful or emotional
conversations that may be distracting.
Stressful or emotional conversations
and driving do not mix – they are
distracting and even dangerous
when you are behind the wheel.
Make people you are talking with
aware you are driving and if
necessary, suspend phone
conversations that have the
potential to divert your attention
from the road.
Use your phone to call for help.
Your wireless phone is one of the
greatest tools you can own to
protect yourself and your family in
dangerous situations – with your
phone at your side, help is only three
numbers away. Dial 9-1-1 in the case
of fire, traffic accident, road hazard,
or medical emergency. Remember, it
is a free call on your wireless phone.
Use your phone to help others in
emergencies.
Your wireless phone provides you a
perfect opportunity to be a "good
Samaritan" in your community. If
you see an auto accident, crime in
progress or other serious
emergencies where lives are in
danger, call 9-1-1, as you would
want others to do for you.
Call roadside assistance or a special
wireless non-emergency assistance
number when necessary.
Certain situations you encounter
while driving may require attention,
but are not urgent enough to merit a
call to 9-1-1. But you can still use
your wireless phone to lend a hand.
If you see a broken-down vehicle
posing no serious hazard, a broken
traffic signal, a minor traffic accident
where no one appears injured, or a
vehicle you know to be stolen, call
roadside assistance or other special
non-emergency wireless numbers.
Provided by the Cellular
Telecommunications Internet Association
(CTIA)
"The wireless industry reminds you to
use your phone safely when driving"”
For more information, please call
1 (888) 901-SAFE, or visit our Web site
at: www.wow-com.com
right page (73) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\am_intellectual_property.fm
73Intellectual Property
VAR Language: English; VAR issue date: 11-Juni-2003
Intellectual Property
Intellectual Property Restrictions
All Intellectual Property, as defined
below, which is owned by or
otherwise the property of Siemens
Information and Communications
Mobile, LLC ("Siemens"), its
affiliates, partners or suppliers,
relating to the Phone, including but
not limited to accessories, parts or
software relating thereto (the
"Phone System"), is proprietary
under federal laws, state laws and
International treaty provisions.
Intellectual Property includes, but is
not limited to, inventions
(patentable or unpatentable),
patents, trade secrets, copyrights,
software, computer programs, and
related documentation and other
works of authorship. You may not
infringe or otherwise violate the
rights secured by the Intellectual
Property. Moreover, you agree that
you will not (and will not attempt to)
disassemble, decompile, reverse
engineer, prepare derivative works
from, modify or make any other
effort to create source code from the
software. No title to ownership in
the Intellectual Property is
transferred to you through purchase
or possession of the Phone or its
components. All applicable rights of
the Intellectual Property shall remain
with Siemens, its affiliates, partners
or suppliers.
Siemens will have no liability with
respect to any claim of patent
infringement which is based upon
the combination of the Product or
parts furnished hereunder with
software, apparatus or devices not
furnished by Siemens, nor will
Siemens have any liability for the use
of ancillary equipment or software
not furnished by Siemens which is
attached to or used in connection
with the Product, The foregoing
states the entire liability of Siemens
with respect to infringement of
patents by the Product or any parts
thereof.
Laws in the United States and other
countries preserve for Siemens
certain exclusive rights for
copyrighted Siemens software, such
as the exclusive rights to reproduce
and distribute copies of such
Siemens software. Siemens software
may be used only in the Product in
which the software was originally
embodied when purchased, and
such software in such Product may
not be replaced, copied, distributed.
modified in any way, or used to
produce any derivative thereof. No
other use including, without
limitation, alteration, modification,
reproduction, distribution. or
reverse engineering of such Siemens
software or exercise of rights in such
Siemens software is permitted. No
license is granted by implication,
estoppel or otherwise under
Siemens patent rights or copyrights.
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_MenuTree.fm
left page (74) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
Menu tree
74
VAR Language: English; VAR issue date: 11-Juni-2003
Menu tree
°Phonebook ><New entry>
<Special books> ><OwnNumbers>
<Service numb.>
<Info numbers>
<SIM phonebook>
<Protected SIM>
Groups <Mobile>
Surf & fun >Internet (siehe auch S. 34)
Games & more
Filesystem
¯ Organiser >Calendar
Alarm
Notes
Missed alarms
Time zones
Calend. setup
. Messages >New SMS
New MMS
Inbox >SMS
MMS
Data objects
CB messages
Draft >SMS
MMS
right page (75) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_MenuTree.fm
75Menu tree
VAR Language: English; VAR issue date: 11-Juni-2003
. Messages >Unsent >SMS
MMS
Sent >SMS
MMS
SMS archive
Text modules
Setup >SMS
MMS
Voice message
CB services >Receive CB
Read new CB
Topic list
Auto display
Topic index
+ Records >Calls missed CB languages
Calls received
Calls dialled
Erase records
Durat/charges >Last call
All outgoing
All incoming
Remain. units
Charge sett. >Conv.
Personal rate
A/c limit
J Extras >SIM services Auto display
Alarm clock
Calculator
Currency conv
Stopwatch
Countdown
New ringtone
>Voice command
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_MenuTree.fm
left page (76) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
Menu tree
76
VAR Language: English; VAR issue date: 11-Juni-2003
a Camera
> Setup >Profiles
Display >Language
Text input >T9 preferred
Wallpaper Input language
Logo
Colour scheme
Screensaver >Enable
Start up anim. Style
Shutdn anim. Bitmap
Own greeting Preview
Big letters Timeout
Illumination Security
Contrast Auto key lock
Audio >Ringer setting
Silent alert
Volume >Incoming calls
Alarm
Alarm clock
Messages
Cell broadcast
Start melody
End melody
Applications
Ring tones >New ringtone
Incoming calls
Alarm
Alarm clock
Messages
Cell broadcast
Start melody
right page (77) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_MenuTree.fm
77Menu tree
VAR Language: English; VAR issue date: 11-Juni-2003
> Setup >Audio >Ring tones >End melody
Call screening
Key tones
Minute beep
Info tones
Keys >Any to answer
Auto key lock
Key tones
Phone setup >Call waiting
Hide ID
Divert >All calls
Unanswered
Not reachable
No reply
Busy
Receiving fax
Receiving data
Status check
Clear all
Fact. settings
Filesystem >Format
Phone identity Clean up
Auto off
Clock >Time/date
Time zones
Date format
Time format
Buddhist year
Show clock
Connectivity >GPRS
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_MenuTree.fm
left page (78) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
Menu tree
78
VAR Language: English; VAR issue date: 11-Juni-2003
> Setup >Connectivity >GPRS info
Authentication
Data services >MMS, WAP
HTTP
HTTP profile
Fax/data mod. >Send vce/fax
Voice/fax rec
Rec fax/data
Security >Codes >PIN control
Babysitter Change PIN
Only ‚Change PIN2
Last 10 only Chg.phonecode
This SIM only
Barrings >All outgoing
Outgo internat
Out.int.x home
All incoming
When roaming
Status check
Clear all
Network >Line >Select line
Network info Block line
Choose network
Auto network
Pref. network
Band selection
Fast search
User group >Active
Select group
Outgo. access
Preferred grp
right page (79) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:31)
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60K_MenuTree.fm
79Menu tree
VAR Language: English; VAR issue date: 11-Juni-2003
> Setup >Accessories >Car Kit >Auto answer
Auto off
Car loudspk.
Headset >Auto answer
Note on Surf & fun
Depending on your service provider, you may have direct access to its portal instead of the
Surf & fun menu option. Contact your service provider for details of the services offered on
the portal. In this case, you will find the Internet and Games & more menu options in the
Extras J menu.
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60KSIX.fm
left page (80) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:28)
Index
80
VAR Language: English; VAR issue date: 11-Juni-2003
Index
A
Agenda ...................................... 48
Alarm
Alarm clock............................. 50
Appointment .......................... 48
Switch off ............................... 49
Type ....................................... 49
Alarm clock ................................ 50
All calls (diversion) ..................... 44
Answering service (external)....... 32
Any key answer (answer call)...... 43
Application, download................ 39
Appointments ............................ 48
Archive (SMS)............................. 34
Audio ......................................... 42
Auto key lock.............................. 43
Auto phone off........................... 44
Auto. redial ................................ 17
B
Babysitter................................... 20
Barrings...................................... 46
Battery
Charge.................................... 12
Insert...................................... 11
quality declaration .................. 62
Big letters
(message on display).................. 41
Busy number .............................. 17
C
Calculator................................... 50
Calendar..................................... 48
Call
Accept/end ............................. 18
Barring ................................... 46
Charges .................................. 29
Conference............................. 19
Divert ............................... 43, 76
End......................................... 17
Reject ..................................... 18
Swap (change)........................ 19
Call back ..................................... 17
Call divert ............................. 43, 76
Call transfer ................................20
Call waiting................................. 19
Calls dialled (call list)...................29
Calls received (call list) ................ 29
Camera....................................... 51
Car Kit......................................... 47
Care of phone .............................61
Cell Broadcast (CB)......................32
Charging the battery ...................12
Clock ..........................................44
Codes ......................................... 16
Colour schemes .......................... 41
Command (voice command) .......51
Conference ................................. 19
Connection profile ......................45
Contrast (message on display)..... 41
Countdown.................................51
Currency converter .....................50
Customer care ............................ 58
D
Data exchange (settings).............45
Date format ................................45
Dialling code............................... 17
Dialling with number keys...........17
Dial-up access (connection).........45
Display
Big letters................................41
Colour schemes.......................41
Contrast.................................. 41
Illumination ............................ 41
Symbols ....................................9
Display (settings) ........................41
Divert ................................... 43, 76
Driving safety..............................70
Duration/charges ........................29
right page (81) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:28)
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60KSIX.fm
81Index
VAR Language: English; VAR issue date: 11-Juni-2003
E
Emergency number .................... 13
Entry no. (phonebook)................ 25
Extras................................... 50, 61
F
Factory settings .......................... 44
Fast access ................................. 53
File system ................................. 54
Filter .......................................... 42
Forwarding (call) ........................ 20
Frequency (band) ....................... 47
G
Games & More............................ 39
Games (download) ..................... 39
Getting started ........................... 10
GPRS .......................................... 45
Group......................................... 28
H
Handset volume ......................... 17
Handsfree talking ....................... 18
Headset...................................... 47
Hide ID ....................................... 43
Highlighting mode...................... 15
Hold call..................................... 19
Hotline ....................................... 58
I
Identity number (IMEI)................ 44
Illumination (display).................. 41
IMEI number............................... 44
Index (file system) ........................ 9
Info tones................................... 42
Input language (T9).................... 22
International dialling code .......... 17
Internet...................................... 38
K
Key tones ................................... 43
Keypad (settings) ....................... 43
L
Last 10 only................................ 46
Logo, provider logo .................... 41
M
Mailbox ......................................32
Maintenance of phone ................61
Menu speed dialling....................16
Menu tree...................................73
Message
MMS .......................................35
SMS .................................. 33, 34
Minute beep ...............................42
Missed appointments..................49
Missed calls (call list)...................29
MMS
Lists ........................................37
Profile .....................................37
Receive ...................................36
Write.......................................35
Muting (microphone).................. 20
My menu ....................................53
N
Network functions ......................47
Notes.......................................... 49
O
Only ‚..................................... 77
Only this SIM ..............................46
Organiser.................................... 48
Own greeting..............................41
P
Phone (settings).......................... 43
Phone identity number (IMEI)......44
Phone number transmission
on/off ......................................... 43
Phonebook ................................. 25
Photo album ............................... 31
PIN
Change ...................................16
Control.................................... 16
Enter.......................................13
Error .......................................57
Preventing accidental
activation.................................... 16
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60KSIX.fm
left page (82) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:28)
Index
82
VAR Language: English; VAR issue date: 11-Juni-2003
Profiles
HTTP....................................... 45
Phone..................................... 40
SMS/MMS ............................... 37
WAP ....................................... 38
Prompt....................................... 17
Provider logo.............................. 41
Q
Questions & Answers.................. 55
R
Records ...................................... 29
redial.......................................... 17
Reminder ................................... 17
Ring tones .................................. 42
Ringer setting............................. 42
S
Safety precautions........................ 3
Screensaver................................ 41
Second phone number
(connection) .............................. 47
Security................................ 16, 46
Service tones.............................. 42
Set time/date.............................. 44
Settings
Accessories............................. 47
Audio ..................................... 42
Clock ...................................... 44
Data connection ..................... 45
Display ................................... 41
Divert ............................... 43, 76
Keys ....................................... 43
Network ................................. 47
Phone..................................... 43
Profiles ................................... 40
Security .................................. 46
Short message (SMS).................. 33
Shown in the display .................... 9
Shut down animation ................. 41
Signal strength ........................... 13
Silent alert.................................. 42
SIM card
Clear barring ...........................16
Insert ......................................11
Problems.................................55
SIM services (optional) ................52
SMS
Archive ...................................34
Profile .....................................37
Read ....................................... 34
T9 input .................................. 22
To group ................................. 34
Write.......................................33
SMS to group ..............................34
SMS/MMS Inbox..........................37
SOS ............................................13
Special characters ....................... 21
Speed dialling keys......................53
Standard values ..........................44
Standby mode ............................14
Start animation ...........................41
Start up animation ......................41
Stopwatch ..................................51
Surf & fun ...................................38
Swap ..........................................19
Switch on ...................................13
Symbols........................................9
T
T9Text entry ...............................22
Word suggestions....................23
Technical data............................. 60
Text entry with T9....................... 22
Text entry without T9..................21
Text module ............................... 24
Time zones ........................... 13, 44
U
Unanswered ...............................43
Upper and lowercase letters ........21
right page (83) of MC60 Maguro, kurz, am, A31008-H5760-A40-1-4A19 (08.08.2003, 12:28)
©
Siemens AG 2003, G:\Mobil\L55\MC60_Maguro\am\MC60KSIX.fm
83Index
VAR Language: English; VAR issue date: 11-Juni-2003
V
Voice command.......................... 51
Voice dialling.............................. 27
Voice message (mailbox) ............ 32
Volume
Handset volume...................... 17
Profiles ................................... 40
Ringer..................................... 42
W
Wallpaper................................... 41
WAP ........................................... 38
