User Manual

Table of Contents 1

See also Index at the end of this User Guide

right page (1) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:40)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Legal notices .............................. 3

Safety precautions ..................... 5

Antenna care ........................... 7

Phone operation ...................... 7

Phone overview ....................... 11

Display symbols ....................... 13

Getting started ......................... 15

Inserting SIM card/battery ...... 15

Charging the battery .............. 16

Switching on/off, PIN entry ...... 18

General instructions ................ 19

User guide ............................. 19

Slider ..................................... 19

Standby mode ....................... 20

Tabs ...................................... 20

Digital Rights Mgmt. (DRM) .... 20

Menu controls ........................ 21

Centre key ............................. 21

Standard functions ................. 22

Security .................................... 23

PIN code ................................ 23

Text input ................................. 25

Calling ...................................... 29

Ending a call .......................... 29

Setting the volume ................ 29

Accept call ............................. 30

Rejecting a call ....................... 31

Handsfree .............................. 31

Swapping between 2 calls ...... 31

Conference ............................ 32

Call options ............................ 33

Direct call ............................... 33

Tone sequences (DTMF) ......... 34

Contacts ....................................35

All contacts ............................35

Groups ...................................36

Online status .......................... 36

SIM ........................................37

Filter ......................................37

General options ......................38

Call records ...............................40

Dur./charges .............................41

Camera .....................................42

SMS/MMS ..................................45

Writing an SMS ....................... 45

Writing an MMS ......................46

Receive ..................................48

Reading ..................................48

Draft ......................................49

Outbox ...................................49

Sent .......................................49

Archive ...................................49

Templates ..............................49

General settings .....................50

SMS settings ...........................50

MMS settings .........................52

Save aft. send .........................52

Zoom in .................................52

Emoticons ..............................52

E-mail ........................................53

Writing/sending ......................53

Receiving/reading ...................54

Draft ......................................55

Archive ...................................55

Settings ..................................55

Table of

Contents

See also In-

dex at the end

of this User

Guide

3Legal notices

right page (3) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:38)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Legal notices

The mobile phone described in this guide is approved for use on the GSM and GPRS net-

works operating on the GSM 900, 1800 (DCS/PCN) and 1900 (PCS) bands. It is approved

for use in the country where it was originally sold and may be approved for use in other

countries.

Siemens and the SL75 model phone

are trademarks or registered trade-

marks of Siemens AG and/or its affili-

ates in the United States and/or oth-

er countries.

T9® is a registered trademark of Amer-

ica Online, Inc. in the United States.

Java and all Java-based trademarks

and logos are trademarks or registered

trademarks of Sun Microsystems, Inc.

in the U.S and other countries. The

names of actual companies and prod-

ucts mentioned herein may be the

trademarks of their respective owners.

Disclaimer

THE INFORMATION CONTAINED IN

THE USER GUIDE IS WRITTEN FOR

THE SL75 PHONE. SIEMENS RE-

SERVES THE RIGHT TO MAKE CHANG-

ES AND IMPROVEMENTS TO THE

PRODUCTS AND ANY OF THE FEA-

TURES OF THE PRODUCTS DE-

SCRIBED IN THIS DOCUMENT WITH-

OUT PRIOR NOTICE. THE CONTENTS

OF THE USER GUIDE ARE PROVIDED

"AS IS". EXCEPT AS REQUIRED BY AP-

PLICABLE LAW, NO WARRANTIES OF

ANY KIND, EITHER EXPRESS OR IM-

PLIED, INCLUDING, BUT NOT LIMITED

TO, THE IMPLIED WARRANTIES OF

MERCHANTABILITY AND FITNESS

FOR A PARTICULAR PURPOSE, ARE

MADE IN RELATION TO THE ACCURA-

CY, RELIABILITY OR CONTENTS OF

THIS DOCUMENT. SIEMENS RE-

SERVES THE RIGHT TO REVISE THE

USER GUIDE OR WITHDRAW IT AT

ANY TIME WITHOUT PRIOR NOTICE.

UNDER NO CIRCUMSTANCES SHALL

SIEMENS BE RESPONSIBLE FOR ANY

LOSS OF DATA OR INCOME OR ANY

SPECIAL, INCIDENTAL, CONSEQUEN-

TIAL OR INDIRECT DAMAGES HOW-

SOEVER CAUSED.

Export Information

The mobile phone may be subject to

export regulation of the United States

and other countries. Diversion con-

trary to law is prohibited. You must

comply with all applicable export

laws, restrictions and regulations of

the United States foreign agencies or

authorities, and may not export, or

transfer for the purpose of re-export,

the mobile phone or any part of the

phone in violation of any applicable

restrictions, laws or regulations, or

without all necessary approvals.

Legal notices4

left page (4) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:38)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Network Services

A number of features included in this

guide are called Network Services.

They are special services provided by

wireless service providers. In order

to use any of these Network Servic-

es, you must subscribe to these serv-

ice(s) from your service provider and

obtain instructions for their use.

Some of these Network Services may

not be available when roaming on a

network other than your home net-

work.

Standby and

Talk Time Information

The mobile phone incorporates fea-

tures that are new to the mobile

phone world. These may include

color displays and lighting, graphic

games, music reproduction and

browsing the Internet. The way you

use the display and the features will

affect the performance of the bat-

tery and how long it lasts between

charge cycles. The quoted standby

times and talk times show the mini-

mum and maximum performance

that can be expected from the bat-

tery under normal network condi-

tions and with the default settings as

set by the factory. However, playing

games (particularly with the back-

light continuously switched on) and

listening to music will shorten the

time available for standby and to

make and receive telephone calls.

Operation times also vary depending

on network conditions, SIM settings,

charging and battery condition, how

you use your phone and other fac-

tors.

Memory

The mobile phone contains an inter-

nal memory device that stores the

software required to operate the

mobile phone, communicate with

the GSM/GPRS network and provide

the user interface. Some features in

the internal memory run additional

devices and some additional games

and utilities. The amount of memory

available in the mobile phone is fi-

nite and may be insufficient to store

large numbers of applications and

files.

Warning!

Remember to back up your data and to do

so frequently. Always back up all data and

programs before sending the mobile phone

in for repair.

5Safety precautions

right page (5) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Safety precautions

Information for parents

Please read the operating instructions and safety precautions carefully before use.

Explain the content and the hazards associated with using the phone to your children.

Remember to comply with legal

requirements and local restric-

tions when using the phone.

For example in aeroplanes,

petrol stations, hospitals or

while driving.

Cellular phones can interfere

with the functioning of medical

devices such as hearing aids or

pacemakers. Keep at least

9 inches (20 cm) between

phone and pacemaker. When

using the cell phone hold it to

the ear which is farthest from

the pacemaker. For more infor-

mation consult your doctor.

The ringtone, info tones and

speakerphone talking are re-

produced through the loud-

speaker. Do not hold the phone

to your ear when it rings or

when you have switched on the

speakerphone function. Other-

wise you risk serious, perma-

nent damage to your hearing.

Only use original Siemens bat-

teries (100% mercury-free) and

– charging devices. Otherwise

you risk serious damage to

health and property. The bat-

tery could explode, for instance.

Small parts such as the SIM

card, sealing stop, lens ring

and lens cap can be disman-

tled and swallowed by small

children. The phone must

therefore be stored out of the

reach of small children.

The mains voltage specified on

the power supply unit (V) must

not be exceeded. Otherwise

the charging device may be de-

stroyed.

The power supply must be

plugged into an easily accessi-

ble AC mains power socket

when charging the battery. The

only way to turn off the charg-

ing device after charging the

battery is to unplug it.

Do not use a handheld while

driving.

Do not look at the LED (e.g. ac-

tivated infrared port, flash LED)

with optical magnifiers because

of the risk of radiation.

This product complies with

IEC/EN 60825-1 2 2Safety of

Laser Products2 for LED

Class 1M products; such prod-

ucts are safe under reasonably

foresee-able operating condi-

tions.

Safety precautions6

left page (6) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Bluetooth®

Your phone has a Bluetooth interface. This

makes it possible to establish a wireless

connection of your phone with a headset of

a car kit, or with other Bluetooth-enabled

devices.

In order to establish a secure link between

the devices and to prevent a third party from

having access to your phone, you should

observe the following points:

• The initial connection between two devic-

es, called "pairing", should take place in

familiar surroundings.

• Both devices must be able to identify

themselves once by using a password/

PIN. To ensure sufficient security, you

should choose a 16-digit number

combination for a password that would be

difficult to guess (if a PIN has not been

assigned).

• An automatic connection acceptance

("connection without confirmation") should

only be used in exceptional cases.

• In general, only trustworthy devices should

be linked in order to minimize security

risks.

• You should restrict the "visibility" of your

phone if possible. This will make it much

more difficult for unknown devices to es-

tablish a connection with your phone. To

do this, in the Bluetooth menu, set the op-

tion Visib.to others of Always visible to

Not visible (see page 77).

• The name of your phone is transmitted in

a Bluetooth connection. The factory de-

fault is the "Bluetooth ID". The first time

Bluetooth is activated, or later in the

Bluetooth menu, you can change this

name (My BT name, page 77).

• If Bluetooth is not needed, this function

should be deactivated.

Do not place the phone near to

electromagnetic data carriers

such as credit cards and floppy

disks. Information stored on

them could be lost.

You may only open the phone

to replace the battery (100%

mercury-free) or SIM card. You

must not open the battery un-

der any circumstances. All oth-

er changes to this device are

strictly prohibited and will inval-

idate the guarantee.

Important

Please dispose of unwanted

batteries and phones as permit-

ted by the laws in your country.

The phone may cause interfer-

ence in the vicinity of TV sets,

radios and PCs.

Use only Siemens original ac-

cessories. This will avoid po-

tential risks to health or proper-

ty and ensure compliance with

all relevant regulations.

Improper use will invalidate the guarantee!

These safety instructions also apply to

Siemens original accessories.

This cellular phone offers a range of func-

tions, it can be used in positions other than

the head, such as on the body. In this case,

separation distance of 2.0 cm is required.

When a carry case, belt clip or holder is

used for body-worn operation, it should not

contain metal and should position the de-

vice the above-stated distance from your

body.

7Safety precautions

right page (7) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Before using Bluetooth accessories, or a

mobile phone inside a vehicle, check the ve-

hicle user guide for any limitations on the use

of these products.

Antenna care

Use only the supplied or an approved

replacement antenna. Unauthorized

antennas, modifications, or attach-

ments could damage the phone and

may violate FCC regulations.

Phone operation

Normal position

Hold the phone as you would any

other telephone with the antenna

pointed up and over your shoulder.

Tips on efficient operation

For your phone to operate most

efficiently:

• Extend your antenna fully

(if applicable).

• Do not touch the antenna unnec-

essarily when the phone is in use.

Contact with the antenna affects

call quality and may cause the

phone to operate at a higher pow-

er level than otherwise needed.

Driving

Laws pertaining to the use of mobile

phones while driving vary signifi-

cantly from state to state and some-

times even from locality to locality

within states. For example, some ar-

eas may allow persons to use their

mobile phones only if they employ a

hands-free device, and some areas

may prohibit the use of cell phones

entirely. Accordingly, Siemens rec-

ommends that persons check the

laws for the areas in which they drive

or will be driving. For areas where

the use of mobile phones while driv-

ing is permitted, Siemens encourag-

es persons to use their phones re-

sponsibly and to employ hands-free

devices. Also, if using your phone

while driving, please:

• Give full attention to driving –

driving safely is your first

responsibility;

• Use hands-free operation, if

available;

• Pull off the road and park before

making or answering a call, if

driving conditions so require.

For vehicles equipped with

air bags

An air bag inflates with great force.

DO NOT place objects, including ei-

ther installed or portable wireless

equipment, in the area over the air

bag or in the air bag deployment ar-

ea. If in-vehicle wireless equipment is

Important

Read this information before using

your wireless handheld phone.

As this mobile phone is equipped

with a fixed (non-retractable) an-

tenna, some paragraphs in the text

below may not be applicable.

Safety precautions8

left page (8) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

improperly installed and the air bag

inflates, serious injury could result.

Electronic devices

Most modern electronic equipment

is shielded from radio frequency (RF)

signals. However, certain electronic

equipment may not be shielded

against the RF signals from your

wireless phone.

Pacemakers

The Health Industry Manufacturers'

Association recommends that a min-

imum separation of six inches (6")

be maintained between a handheld

wireless phone and a pacemaker to

avoid potential interference with the

pacemaker. These recommenda-

tions are consistent with the inde-

pendent research by and recommen-

dations of Wireless Technology

Research.

Persons with pacemakers

• should ALWAYS keep the phone

more than six inches from their

pacemaker when the phone is

turned ON;

• should not carry the phone in a

breast pocket;

• should use the ear opposite the

pacemaker to minimize the poten-

tial for interference;

• should turn the phone OFF imme-

diately if there is any reason to

suspect that interference is taking

place.

Hearing aids

Some digital wireless phones may in-

terfere with some hearing aids. In

the event of such interference, you

may want to consult your service

provider or your hearing aid manu-

facturer to discuss alternatives.

Other medical devices

If you use any other personal medi-

cal devices, consult the manufactur-

ers of your devices to determine if

they are adequately shielded from

external RF energy. Your physician

may be able to assist you in obtain-

ing this information.

Turn your phone OFF in health care

facilities when any regulations post-

ed in these areas instruct you to do

so. Hospitals or health care facilities

may be using equipment that could

be sensitive to external RF energy.

Vehicles

RF signals may affect improperly

installed or inadequately shielded

electronic systems in motor vehicles.

Check with the manufacturer or its

representative regarding your vehi-

cle. You should also consult the

manufacturer of any equipment that

has been added to your vehicle.

Posted facilities

Turn your phone OFF in any facility

where posted notices so require.

9Safety precautions

right page (9) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Airplanes

FCC and Airline Regulations prohibit

using your phone while in the air.

Turn your phone OFF when request-

ed by the airline.

Check and comply with the policy of

your airline regarding the use of your

phone while the airplane is on the

ground.

Blasting areas

To avoid interfering with blasting op-

erations, turn your phone OFF when

in a “blasting area” or in areas post-

ed: “Turn off two-way radio.” Obey

all signs and instructions.

Potentially explosive

atmospheres

Turn your phone OFF when in any

area with a potentially explosive

atmosphere and obey all signs and

instructions. Sparks in such areas

could cause an explosion or fire

resulting in bodily injury or even

death.

Areas with a potentially explosive at-

mosphere are often but not always

clearly marked. They include: fueling

areas such as gasoline stations; be-

low deck on boats; fuel or chemical

transfer or storage facilities; vehicles

using liquefied petroleum gas (such

as propane or butane); areas where

the air contains chemicals or parti-

cles, such as grain, dust or metal

powders; and any other area where

you would normally be advised to

turn off your vehicle engine.

Emergency calls (SOS)

Your wireless phone can be used

to make emergency calls. You can

make an emergency call from the

main display screen. Enter the local

emergency number such as 911 and

then press the A key.

This phone, like any wireless phone,

operates using radio signals, wire-

less and landline networks, and user-

programmed functions. Because of

this, connections in all conditions

cannot be guaranteed. Therefore,

you should never rely solely on any

wireless phone for essential commu-

nications (for example, medical

emergencies). Remember – to make

or receive any calls, the phone must

be switched on and be used in a serv-

ice area that has adequate signal

strength. Emergency calls might not

be possible on all wireless phone

networks or when certain network

services or phone features are in use.

Check with local service providers re-

garding their network features.

Always make certain that your

phone is properly charged before

attempting any emergency calls. If

you allow your battery to discharge,

you will be unable to receive or make

calls, including emergency calls. You

must then wait a few minutes after

Safety precautions10

left page (10) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

the charging begins to place any

emergency calls.

When making an emergency call, re-

member to give all of the necessary

information as accurately as possi-

ble. Remember that your wireless

phone might be the only means of

communication at the scene of an

accident, therefore you should not

terminate the call until given permis-

sion to do so.

Batteries and Chargers

Only use original Siemens batteries

(100% mercury-free) and charging

devices. Use of non-Siemens batter-

ies and/or charging devices may

cause explosion resulting in serious

injury and/or property damage. Use

original Siemens accessories in order

to avoid possible injury and property

damage and to ensure compliance

with applicable laws and regula-

tions. Improper use invalidates the

warranty.

Battery safety precautions

To reduce the risk of fire, injury or

electric shock, and to properly dis-

pose of batteries, please read and

understand the following instruc-

tions. CONTAINS LITHIUM-ION OR

NICKEL-METAL HYDRIDE BATTERY.

BATTERY MUST BE RECYCLED OR DIS-

POSED OF PROPERLY. DO NOT DIS-

POSE IN MUNICIPAL WASTE.

1. Only use the batteries specified

for use with this mobile phone.

2. Do not use batteries of different

sizes or from different manufac-

turers in this mobile phone.

3. Do not dispose of the battery in a

fire; it may explode. Dispose of

used batteries and phones in

accordance with applicable laws

and safety regulations. Do not

expose battery to water. Check

with local codes for special dis-

posal instructions.

4. Do not open or mutilate the bat-

tery. Doing so may cause damage

to the eyes or skin.

5. Exercise care in handling the bat-

tery in order not to short the bat-

tery with conducting materials

such as rings, bracelets, and keys.

The battery or conducting mate-

rial may overheat and cause burns

or fire.

6. Charge the battery provided with,

or identified for use with, this

product only in accordance with

the instructions and limitations

specified in the User's Guide. Do

not attempt to charge the battery

by any means other than those

specified in the User's Guide.

11Phone overview

right page (11) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Phone overview

1 A Call key

Dial displayed/highlighted phone

numbers/names, take calls. In standby

mode, show last phone numbers

dialled.

2 B On/Off/End key

• Switched off: press to switch on.

• During a conversation or in an appli-

cation: press briefly to end.

• In menus: return to standby mode.

• In standby mode, Slider closed:

• Press to lock keypad. Press and con-

firm with §OK§ to unlock the keypad.

3 Media player key

Direct number for the media player.

4 Wildcard key

Key for Internet access unless other-

wise preconfigured.

5 Soft keys

The current functions of these keys are

shown as §text§/symbol (e.g. p).

6 Centre key

í Press the centre key to open the

main menu and to start an appli-

cation or function (page 21).

7 Navigation keys

In standby mode:

G Open user profiles.

H Open contacts.

E Open inbox.

D Start the camera.

In lists, messages and menus:

I Scroll upwards/downwards.

During the conversation:

H Open contacts.

á £ ß

01.10.2005 10:10

Service provider

Inbox íNew SMS

Phone overview12

left page (12) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

1 Loudspeaker

2 X Camera key

3 Z Media Player active: Play/Pause.

Media Player not active: Start playing.

4 Display

5 [ / \ Volume control

6 * Ringtone

• Press and hold in standby mode:

switch all acoustic signals on/off

(except alarm clock).

• Press and hold on incoming call:

switch off ringtone for this call only.

7 #Key lock

Press and hold in standby mode:

activate/deactivate key lock.

8 Plug socket

9 Flash/torch

X Press and hold X key:

switch torch on/off.

= Camera lens

! Mirror

á £ ß

01.10.2005 10:10

Service provider

Inbox íNew SMS

13Display symbols

right page (13) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Display symbols

Display symbols (selection)

á Signal strength

à Charging

Þ Battery charge level, e.g. 50 %

L Contacts

P Call records

O Internet/Service provider portal

W Games

Q Organizer

M Messages

R Camera

S Extras

V Media player

N My stuff

U Alarm clock

T Settings

Ç All calls are diverted.

½ Ringer (beep) off

¹ Alarm set

Ä Keypad locked

T9Abc Text input with T9.

£ Activated and available

¢ Registered

¤ Temporarily interrupted

± Browser offline

² Browser is being connected

³ Browser online via GPRS

´ No network (Internet)

¨ Bluetooth activated.

« Bluetooth during data

transmission.

ª Call accepted on Bluetooth

device.

Display symbols14

left page (14) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Events (selection)

å SMS memory full

æ MMS memory full

ç Phone memory full

Æ No network access

¿ Inbox

Ê Memory assistant

Message symbols (selection)

m Unread

n Read

o Draft

p Sent

q MMS not sent

r MMS notification received

t MMS with DRM contents

(page 20)

u E-mail forwarded

v E-mail with attachment

l Voice mail received

Camera symbols

Ú Zoom factor

Û White balance

Ø Flash activated

15Getting started

right page (15) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Getting started

Your phone's display is covered with

a protective film. Remove this before

using the phone.

Inserting SIM card/

battery

The service provider supplies you

with a SIM card on which all the im-

portant data for your line is stored. If

the SIM card has been delivered in

credit-card size, snap the smaller

segment out and remove any rough

edges.

• Place the SIM card in front of the

slot with the contacts facing

downwards. Then push the SIM

card fully into the holder using

gentle pressure 1. Ensure that

the chamfered corner is in the

correct position.

• Insert the battery into the phone

with the retaining lugs beneath

the camera lens 2 and then press

down 3 until it clicks into place.

• To remove, press the catch

down 4 until the battery springs

out a little, and then remove 5.

In rare cases static

discharge can

cause temporary

discoloration in

the display.

However, this

will disappear

within approx.

10 minutes.

Getting started16

left page (16) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

• Position the battery cover on the

device, slightly offset at the

top 6, and then push in the direc-

tion of the arrow until it clicks into

place 7.

• To remove, press the locking but-

ton 8, push the battery cover

forwards slightly, and then lift it

up and out 9.

Charging the battery

Charging

The battery is not fully charged

when delivered. Plug the charger ca-

ble into the bottom of the phone,

plug the power supply unit into a

mains power socket and charge

for at least two hours (for charging

via USB, see page 92). Do not

interrupt the charging procedure

prematurely.

àDisplay when charging is

in progress.

Charging time

An empty battery is fully charged af-

ter about 2 hours. Charging is only

possible within a temperature range

of +5°C to +45°C (41°F to 113°F). If

the temperature rises/falls 5°C (9°F)

above/below this, the charge symbol

flashes a warning. The mains voltage

specified on the power supply unit

must not be exceeded.

Additional information

Please switch off your phone before remov-

ing the battery!

1.8 and 3 volt SIM cards are supported.

Please contact your service provider if you

have a different card.

17Getting started

right page (17) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Operating time

The operating time depends upon

the respective conditions of use. Ex-

treme temperatures considerably re-

duce the phone’s standby time. You

should therefore avoid leaving the

phone in the sun or on a radiator.

Talktime: up to 300 minutes

Stand-by time: up to 300 hours

Charge icon not visible

If the battery has been discharged

fully, the charge icon is not immedi-

ately visible when the power supply

is plugged in. It will appear after up

to two hours. In this case the battery

is fully charged after 3 to 4 hours.

Only use the plug-in power supply unit

included in delivery!

Display during operation

Charge level display during

operation (empty–full):

Ý Þ ß

A beep sounds when the battery is

nearly empty. The charge level of the

battery is only displayed correctly af-

ter an uninterrupted charging/dis-

charging cycle. You should therefore

not remove the battery unnecessarily

and where possible not terminate the

charging process before completion.

Additional information

The power supply unit heats up when used

for long periods. This is normal and not

dangerous.

If the battery is removed for longer than

30 seconds, the clock must be reset.

Switching on/off, PIN entry18

left page (18) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Switching on/off, PIN entry

Switching on/off

BPress and hold the On/ Off/

End key.

Entering PIN

The SIM card can be protected with

a 4 to 8-digit PIN.

JOpen Slider. Enter the PIN

using the number keys.

The characters **** ap-

pear in the display to en-

sure nobody can read

your PIN. Correct with].

§OK§ Press the left soft key to

confirm. Logging on to

the network will take a

few seconds.

Emergency number

(SOS)

Only to be used in real emergencies!

By pressing the left soft key §SOS§ you

can make an emergency call on any

network without a SIM card and with-

out entering a PIN (not available in

all countries).

Switching your phone on

for the first time

Time/date

Set the clock correctly once when

getting started (see also page 21).

ìConfirm.

ñStart entry.

JFirst enter the date (day/

month/year), then the

time (24 hours, including

seconds).

ìConfirm. The time and

date are updated.

Time zones

ISelect the city in the

desired time zone.

ìConfirm.

Additional information

Changing the PIN.........................page 23

Clearing SIM card barring ............page 24

19General instructions

right page (19) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

General instructions

User guide

The following symbols are used to

explain operation:

Slider

Open slider completely

•Light on.

• Keypad unlocked.

• Opening melody on (if set).

• The call is accepted.

• Alarm sound off (appointment,

alarm).

Close slider completely

• Prompt to decide whether applica-

tion should be continued or re-

turned to standby status.

• Keypad locked in standby mode if

no application except Media Play-

er is running (if set).

• Closing melody on (if set).

• The call is ended (only if headset is

not connected).

• The call is rejected.

• Alarm sound off (appointment,

alarm).

Receiving signal

áStrong receiving signal.

âA weak signal reduces the

call quality and may lead

to loss of the connection.

Change your location.

J Enter numbers, letters.

B On/Off/End key

A Call key

<> Soft keys

§Menu§ Displays a soft-key

function.

í Press the centre key, e.g.,

to call up the menu.

D F E

H I G

Press the navigation key

on the side marked with

a triangle.

= Function dependent on the

service provider.

General instructions20

left page (20) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Standby mode

The phone is in standby mode and

is ready for use when the name of

the service provider appears on the

display.

BPress the On/Off/End key

to return to standby mode

from any situation.

Tabs

The handy tabs offer you fast access

to information and functions.

FSwitch between the

individual tabs.

If an input field is activated on a tab,

it is only possible to navigate within

the field using the navigation key.

Digital Rights Mgmt.

(DRM)

Remember that your phone has Dig-

ital Rights Management. The use of

downloaded pictures, sounds or ap-

plications can be restricted by the

suppliers, e.g., copy protection, use

for a limited period of time only,

number of times it can be used etc.

Main menu

The applications are shown with

symbols in the main menu:

íCall up from standby

mode using the

centre key.

F/ISelect application with

the navigation key.

ìStart application.

Main menu options

§Options§ Open menu.

131 2Search List output of the menu.

You can use the search op-

tion to directly access any

menu item just by browsing

for the keyword.

Large font Select one of two font

sizes.

Lighting Set display light brighter/

darker.

21General instructions

right page (21) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Menu controls

The steps needed to reach a function

are shown in a condensed form in the

user guide, e.g. to display record of

missed calls in condensed form:

í¢P¢Calls dialed

This comprises the following steps:

íPressing the centre key

opens the main mmenu in

standby mode.

GSelect the record

application P.

ìConfirm with the

centre key.

HSelect the function Calls

dialed.

ìConfirm with the

centre key.

Centre key

The symbol in the centre of the low-

er line of the display shows the cur-

rent function when the centre key is

pressed.

í Main menu ý Send

ì OK, confirm ö View

ñ Change û Save

ð Call ò Play

ü Edit ô Record

÷ Insert ó Pause

ú Options õ Stop

ù Camera ø Zoom

General instructions22

left page (22) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Standard functions

Functions which appear repeatedly

in the options menu are listed here.

§Options§ Open menu.

Printing via USB

This Mobile Printing Ready product is

designed to provide easy printing

from mobile phones by connecting

the mobile phone with a USB data

cable to the printer.

This product follows the guidelines

Version 1.0 for PictBridge from Mo-

bile Imaging and Printing Consorti-

um (MIPC).

Mark mode

For some applications (e.g. deleting

several SMS messages) you can mark

several entries on the tab in order to

perform multiple functions at once.

§Options§ Open menu.

Mark Activate mark mode.

ISelect entry/entries.

ñMark or unmark.

Additional mark mode functions:

§Options§ Open menu.

Edit Open the entry to edit.

View Display entry.

Delete Delete entry.

New entry Create new entry.

SendöSelect transmission service

and medium for sending.

PrintöPrintout on a suitable termi-

nal via Bluetooth or USB.

Reply/

Reply to all The sender becomes the

recipient, "Re:" is placed

before the subject, and the

received text is transferred

into the new message.

Save Store entry.

Save to ªSave recipient in Contacts.

Sort Set sort criteria

(alphabetical, type, time).

Rename Rename selected entry.

Capacity Display memory capacity.

Import Device ready to receive da-

ta (vcard, vcal, vnotes) via

Bluetooth.

Attributes Display properties of the

highlighted object.

Help Display help text.

Mark all Mark all entries.

Deselect all Unmark all marked entries.

Delete

marked All merked entries are

deleted.

23Security

right page (23) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Security

The phone and SIM card are protect-

ed against misuse by several security

codes.

PIN code

í¢T¢Security

¢PIN code

¢Select function.

PIN control

The PIN is usually requested each

time the phone is switched on. You

can deactivate this feature but you

risk unauthorised use of the phone.

Some service providers do not per-

mit deactivating the control.

ñEdit.

JEnter PIN.

ìConfirm entry.

Change PIN

You can change the PIN to any

4 to 8-digit number you find easier

to remember.

ñEdit.

JEnter current PIN.

ìConfirm.

J,ìEnter new PIN.

J,ìRepeat new PIN.

Keep these security codes in a safe

place where you can access them again

if required.

PIN Protects your SIM card

(personal identification

number).

PIN2 This is needed to set the

charge detail display and to

access additional functions on

special SIM cards.

PUK

PUK2 Key code. Used to unlock SIM

cards after the wrong PIN has

been entered repeatedly.

Phone

code Protects your phone. Must be

entered at the first security

setting.

Security24

left page (24) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Change PIN2

Proceed as for Change PIN.

Chg.phonecode

(Change phone code)

You define the phone code (4–8 dig-

it number) the first time you call up a

phone-code protected function

(e.g. Direct call, page 87). It is then

valid for all phone-code protected

functions.

Following the third incorrect at-

tempt, access to the phone code and

the functions that use it is denied. If

this happens please contact Siemens

Service (page 122).

Clearing SIM card

barrings

If the PIN is entered incorrectly three

times, the SIM card is barred. Enter

the PUK (MASTER PIN) provided by

your service provider with the SIM

card in accordance with the instruc-

tions. If the PUK (MASTER PIN)

has been lost, please contact your

service provider.

Preventing accidental

activation

Even if PIN use is deactivated

(page 18) confirmation is required

to switch on the phone.

This prevents the phone from being

switched on accidentally, e.g. when

carried in a pocket or whilst you are

on an aircraft.

BPress and hold.

§OK§ Press. The phone

switches on.

§Cancel§ Press (or no further input)

to stop switch-on proce-

dure. The phone does not

switch on.

Connection with PCs

You can connect your phone to a PC

using Bluetooth or a data cable (ac-

cessories). The PC program MPM

(Mobile Phone Manager) enables

you to store data on your PC and, for

example, synchronise the Address-

book with Outlook®, Lotus Notes™

and other Siemens phones (includ-

ing Gigaset). You will find Mobile

Phone Manager on the CD-ROM sup-

plied or you can download it from

the Internet at:

www.siemens.com/sl75

25Text input

right page (25) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Text input

Text input without T9

Press the number key repeatedly un-

til the required character appears.

After a brief interval the cursor will

advance. Example:

2Press once briefly to write

the letter a, twice to write

b etc.

Press and hold to write the

number.

Ä, ä, 1–9 Umlauts and numbers are

displayed after the rele-

vant letters.

]Press briefly to delete the

letter before the cursor,

press and hold to erase the

whole word.

FMove the cursor (forward/

back).

#Press briefly: swap be-

tween abc, Abc, T9abc,

T9Abc, 123. Status shown

in top line of the display.

Press and hold: all input

variants are displayed.

*Press briefly: special char-

acters are displayed.

Press and hold: open text

input menu.

0Press once/repeatedly:

. , ? ! ’ " 0 + - ( ) @ / : _

Press and hold: write 0.

1Inserts a space. Press

twice = line break.

Special characters

*Press briefly. The symbols

chart is displayed:

1) Line break

I/FScroll to a character.

ìConfirm.

1)¿¡_;.,?!

+- "’ : */()

¤¥$£€@\ &#

[ ] { } %~<=>

|^` § Γ ∆ Θ Λ Ξ

Π Σ Φ Ψ Ω

Text input26

left page (26) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Text input menu

For text input:

*Press and hold. The text

input menu is displayed:

Input language

Mark text

Copy/Insert

Text input withT9

"T9" deduces the correct word from

the individual key entries by making

comparisons with an extensive

dictionary.

Writing with T9

The display changes as you proceed.

It is therefore best if you finish a word

without looking at the display.

Simply press the keys once only

where the relevant letter is located.

For "hotel", for example:

#Press briefly for T9Abc, then

4 6 8 3 5

1A blank ends a word.

Do not use special characters such as

Ä. Use the standard characters in-

stead, e.g. A; T9 will do the rest for

you.

T9 word suggestions

If several options are found in the

dictionary for a key sequence

(a word), the most probable is dis-

played first. If the word you want has

not been recognised, the next sug-

gestion from T9 may be correct.

The word must be §highlighted§. Then

press

^The displayed word is re-

placed with a different

word. If this word is also

incorrect, press again.

^Repeat until the correct

word is displayed.

If the word you want is not in the

dictionary, it can also be written

without T9.

T9®Text Input is licensed under one or more

of the following:

U.S. Pat. Nos. 5,187,480, 5,818,437, 5,945,928,

5,953,541, 6,011,554, 6,286,064, 6,307,548,

6,307,549, 6,636,162 and 6,646,573;

Australian Pat. Nos. 727539, 746674 and 747901;

Canadian Pat. Nos. 1,331,057, 2,302,595 and

2,227,904;

Japan Pat. No. 3532780, 3492981;

United Kingdom Pat. No. 2238414B;

Hong Kong Standard Pat. No. HK1010924;

Republic of Singapore Pat. No. 51383, 66959

and 71979;

European Pat. Nos. 0 842 463 (96927260.8), 1

010 057 (98903671.0), 1 018 069 (98950708.2);

Republic of Korea Pat. Nos. KR201211B1 and

KR226206B1.

People's Republic of China Pat. Application Nos.

98802801.8, 98809472.X and 96196739.0;

Mexico Pat. No. 208141;

Russian Federation Pat. No. 2206118;

and additional patents are pending worldwide

27Text input

right page (27) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

To add a word to the dictionary:

§Learn§ Select.

The last suggestion is deleted and

the word may now be entered with-

out T9 support. Press §Save§ to add it

automatically to the dictionary.

Correcting a word

FMove left or right, word

by word, until the

required word is

§highlighted§.

^Scroll through the T9

word suggestions again.

]Deletes the character to

the left of the cursor and

displays a new possible

word!

Additional information

Within a "T9 word", individual letters may

not be edited without first removing the T9

status. In most cases it is better to rewrite

the complete word.

0Set a full stop. The word is

concluded if it is followed by

a space. Within a word, a full

stop represents an apostro-

phe or hyphen:

e.g. §provider.s§ = provider’s.

EMoving the cursor to the right

ends the word.

#Press briefly: swap between:

abc, Abc, T9abc, T9Abc, 123.

Status shown in top line of the

display.

Press and hold: all input vari-

ants are displayed.

*Press briefly: select special

characters (page 25).

Press and hold: opens text

input menu (page 26).

Text input28

left page (28) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Text modules

Text modules can be stored in the

phone for adding to your messages

(SMS, MMS, e-mail).

í¢M¢Templates

¢Text modules

§New§ Select.

ìThe input field is opened.

JWrite text, select with

§Options§ or, if applicable,

select input language and

copy or insert texts.

ûSave text module.

Using text modules

From text modules

í¢M¢Templates

¢Text modules

ISelect text module from

the list

Create message

Select.

ISelect the type of mes-

sage in which the text

module is to be used.

ìConfirm. The text module

is added.

JComplete the message

and send.

From an application (SMS, MMS, e-mail)

JWrite the text for the mes-

sage in the application.

§Options§ Open the text menu.

Insert text Select, then Text modules.

ISelect text module from

the list.

ìConfirm. The text module

is added.

29Calling

right page (29) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Calling

Dialling with number

keys

The phone must be switched on

(standby mode) and the slider must

be open.

JEnter number (always

with area/international

dialling code).

]A short press clears the

last digit, a long press

clears the entire number.

APress the Call key. The dis-

played phone number is

dialled.

Ending a call

BPress briefly. Press this key

even if the person on the

other end of the line has

hung up first.

Or Close slider.

Setting the volume

[/\Adjust the volume with

the plus/minus keys (only

possible during a call).

If a Car Kit is used, its volume setting

will not affect the usual setting on

the phone.

Redialling

To redial the phone number last

called:

APress Call key the twice.

To redial other phone numbers that

were dialled previously:

APress the Call key once.

IPick out the phone

number from the list,

then press …

A… to dial.

International dialling codes

0Press and hold until a "+" is

displayed.

§Options§ Open call menu.

Country Press and select country.

Phone number memo

You can enter a phone number during the

call. The person to whom you are speaking

can hear these entries. When the connec-

tion has ended you can save or dial the

phone number.

Calling30

left page (30) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

If the number is busy

If the called number is busy or can-

not be reached because of network

problems several options are

available (depending on the service

provider). An incoming call or any

other use of the phone interrupts

these functions.

Either

Auto last number redial

§Options§ Open call menu.

Auto dial The phone number is au-

tomatically dialled ten

times at increasing time

intervals.

ìConfirm. End with:

B End key.

Call back b

§Options§ Open call menu.

Call back Your phone rings when

the busy number is free.

Press the Call key to dial

the number.

ìConfirm.

Reminder

§Options§ Open call menu.

Reminder A beep reminds you to re-

dial the displayed phone

number after 15 minutes.

Accept call

The phone must be switched on. An

incoming call will interrupt any other

use of the phone.

APress the Call key.

ðPress the centre key.

Or Open slider.

A phone number transmitted by the

network plus the corresponding

name are displayed if they are stored

in Contacts (page 37).

If the slider is closed, press the soft

key §Mute§ to disable the ringer for the

current call.

31Calling

right page (31) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Rejecting a call

§Reject§ Press.

BPress briefly.

Or Close slider.

Handsfree

You can put the phone down during

a call. You can then hear the caller

via the loudspeaker.

§Options§ Open call menu.

Handsfr. Activate/deactivate

handsfree talking.

ìConfirm.

Swapping between

2calls b

Establishing a second

connection

You can call another number during

a call.

§Options§ Open call menu.

Hold The current call is put on

hold.

ìConfirm.

JEnter new phone number

H call up Contacts or

A open call records and

select a phone number.

When the new connection is

established:

§Options§ Open call menu.

Toggle Swap between calls.

ìConfirm.

Incoming calls during a call

You may need to register for this

service with your service provider

and set your phone accordingly. Dur-

ing a call, you may be advised that

there is another call waiting. You will

hear a special tone during the call

(page 81). You have the following

options:

Warning!

Please make sure you have accepted the

call before holding the phone to your ear.

This will avoid damage to your hearing from

loud ringtones.

Warning!

Always switch off "handsfree talking" be-

fore holding the phone to your ear. Other-

wise you will damage your hearing!

Calling32

left page (32) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

•Accept the waiting call in addition to

the first

§Toggle§ Accept the waiting call

and place the current call

on hold.

Always proceed as above to swap

between the two calls.

•Reject the waiting call

§Reject§ Press.

§Forward§ The waiting call is divert-

ed, for example,

to mailbox (see page 81,

also Ring tones and silent

alert must be off).

•Accept the waiting call and end the

current call

BEnd the current call.

ðAccept the new call.

End call(s)

BPress briefly.

Or Close slider.

After the Return to held call? display,

you have the following choice:

§Yes§ You accept the call on

hold.

§No§ You end the second call

too.

Conference b

You can call up to 5 conference par-

ticipants one after the other and

then link them together in a confer-

ence call. Some of the functions de-

scribed may not be supported by

your service provider or may have to

be enabled specially.

A connection has already been

established:

§Options§ Open menu and select

Hold. The current connec-

tion is maintained.

H/JSelect phone number

from Contacts or enter it

manually.

When the new connec-

tion is established …

§Options§ … open the menu and se-

lect Conference. The held

call is joined.

Repeat procedure until all partici-

pants are linked together (up to

5participants).

Ending

BAll calls in the conference

finish simultaneously

when the End key is

pressed.

Or Close slider.

33Calling

right page (33) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Call options

The following functions are only

available during a call:

§Options§ Open menu.

Direct call

If this is active, only one number can

be dialled.

Switching on

C¢T¢Security

¢Direct call

ìConfirm selection.

JEnter phone code.

When first prompted you define and

enter the phone code (4–8 digits).

Please do not forget this code (page 24)!

ìConfirm selection.

H/JSelect phone number

from Contacts or enter it

manually.

ìConfirm.

Applying

§Carol§ To dial the phone number

(e.g. "Carol") press and

hold the right soft key.

Switching off

#Press and hold.

JEnter phone code.

ìConfirm entry.

Hold Hold current call.

Microphone

on If switched off, the person

on the other end of the line

cannot hear you (muting).

Also: press * and hold.

Handsfree Playback through the

loudspeaker.

Conference (p. 32)

Time/

charges Display talktime that has

elapsed so far and (if set)

cost incurred during the

call.

Send DTMF Enter tone sequences

(numbers) for remote in-

quiries to an answering

machine.

Main menu Access to main menu.

Call transfer

= Connect the original call to

a second call. For you,

both calls are now ended.

Call status List all held and active calls

(e.g. participants in a

conference).

Calling34

left page (34) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Tone sequences (DTMF)

You can, for example, enter tone se-

quences (digits) for remote access to

an answering machine during an ex-

isting connection. These entries are

transmitted directly as DTMF codes

(tone sequences).

§Options§ Open menu.

Send DTMF

Select.

JEnter phone number.

ìConfirm.

Using Contacts

Store phone numbers and tone se-

quences (DTMF tones) in Contacts in

the same way as a normal entry.

JEnter phone number.

0Press until a "+" appears

in the display (wait for

the connection to be

established).

JEnter DTMF tones (digits).

0If necessary, wait again

for three seconds at a

time for the receiver

to process the entries

correctly.

JEnter a name.

§Save§ Save entry.

You may also store just the

DTMFtones (digits) and then send

them during the call.

35Contacts

right page (35) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Contacts

C¢L

You can store up to 5000 entries in

this phone directory, with several

phone and fax numbers plus addi-

tional address details.

For fast access, the contacts and

functions are sorted and offered on

five tabs:

All contacts, Groups, Online status,

SIM,Filter

HOpen Contacts (fast ac-

cess in standby mode).

FSwitch between the

individual tabs.

Communication

ISelect contact.

ACall selected contact.

§Options§ Open menu, then Create

message, to start an In-

stant Message dialogue.

All contacts

Display all entries stored in the

phone or on the SIM card in

alphabetical order.

New entry

ìConfirm New entry. The

tabs for creating the entry

are displayed.

FSwitch between the

individual tabs.

The following tabs are offered:

General

sett. First name, surname and im-

portant phone numbers. A

ringtone, a picture, or video

with sound can be assigned

to each contact.

Private General address information

and additional communica-

tion numbers such as fax and

e-mail.

Business Company information, ad-

dress, communication

numbers.

Person Personal details such as date

of birth, group membership

and other notes.

Presence Contact information for

Instant Messaging (page 58).

Contacts36

left page (36) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

In the respective tabs:

ISelect required input

fields.

JFill in input fields. The

maximum number of

characters available is

shown at the top of the

display.

At least one name or one

company must be en-

tered. Always enter

phone number with

dialling code.

úOpen options menu and

select Save.

Viewing/editing entries

ISelect required entry.

FSwitch between the

individual tabs.

üOpen current tab to edit.

úOpen options menu.

Groups

You are offered 10 different groups

to enable you to arrange your con-

tacts clearly. You can edit the names

of groups as you wish.

Editing group attributes

ISelect group.

§Options§ Open menu and select

Attributes. You can make

the following changes:

Name:, Ringtone:, Picture:

Adding a contact

Contacts may be added to a group

via All contacts.

ISelect contact, open

§Options§ and select Add to

group.

A contact can only belong to one

group.

Online status

Display all contacts for whom

a Instant Messaging address

(WV address) is entered.

Synchronisation

The Siemens MPM (Mobile Phone

Manager, page 115) allows you to manage

contacts using PCs.

37Contacts

right page (37) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

SIM

Display all contacts stored on the

SIM card.

New entry

ìConfirm New entry,

enter name and phone

number, and select

the storage location (SIM/

protected SIM).

Viewing/editing entries

ISelect required entry.

üEdit entry.

Editing menu

§Options§ Open menu.

Filter

Those entries which match the se-

lected filter criteria are displayed,

e.g. those containing a picture.

Add more

fields Move SIM card entry to

the phone memory. Now

all tabs are offered for

further entries.

from

contacts Copy entry/entries from

the phone memory to

the SIM card (reduced

information).

Change Location: SIM/Protected

SIM.

On special SIM cards,

phone numbers can be

stored in a protected loca-

tion. PIN2 is required for

editing.

Record #:

Select an unassigned

number for the entry. It

can be used to dial the

phone number.

(For standard functions see page 22)

Most used (default)

URL Birthday

Pictures Ringtones

E-mail

Contacts38

left page (38) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

General options

§Options§ Different functions are

offered dpending on

the tab and the current

situation.

Location

Switch the storage location of en-

tries between the phone memory

and the SIM card.

Synchronizatn.

You can synchronise your mobile

with an organiser stored on the In-

ternet (Remote sync., page 99).

Capacity

Display memory capacity.

Settings

Filter Only those entries

which match the filter

criteria are displayed.

Create message Create a message for a

selected contact (SMS,

MMS, e-mail, Instant

Message).

Search IM ID Search for assigned In-

stant Message ID.

Internet The URL assigned to

the contact is visited via

the WAP browser.

Open Display phone num-

bers for information.

Add to †Store entry in Contacts.

Add to group Add entry to a group.

Take a photo,

Record video,

Record sounds,

etc.

Create picture, video

and sound information

for a contact from

scratch or add from

My stuff.

More See below.

(For standard functions see page 22)

Sort byöFirst name or surname

Spec.

numbers Display special phone

numbers, yes/no

Alarm time Period of time before

which you want to be re-

minded of an entry with a

birthday.

Display name First name or surname is

displayed.

Field setup Setup for fields on a tab.

Entry Tab: Tab that is to be shown

first.

39Contacts

right page (39) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

As business c.

Define a selected contact as a

business card.

Business card

Establish a contact as your own

business card to send to a different

GSM-phone.

Import

Set up readiness to receive via

Bluetooth.

Add more fields

Move SIM card entry to the phone

memory. Now all tabs are offered for

further entries.

Conference b

AStart a conference with

up to five particpants

highlighted in advance.

The contacts are dialled

one after another.

Call records40

left page (40) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:38)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Call records

A caller's phone number is

displayed if

• the caller has switched off the

Hide ID function and

• the network supports the "Caller

Identity" function.

Alternatively, a caller’s name is dis-

played if it is stored in Contacts.

Your phone stores the phone

numbers of calls for convenient

redialling.

C¢P

ISelect record.

COpen record.

ISelect phone number.

ADial phone number.

öDisplay information on

the phone number.

Up to 500 entries are stored in

the records:

Missed calls b

The phone numbers of calls that you

have received but not answered are

stored for call back purposes.

¿Symbol for missed call

(in standby mode).

Press the soft key beneath

the symbol to bring up

the inbox.

Calls received

Accepted calls are listed.

Calls dialed

Access to the last numbers you have

dialled.

AFast access in standby

mode.

Delete records

The records are deleted.

41Dur./charges

right page (41) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:38)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Dur./charges

You can display the charges and du-

ration during a call. You can set a

unit limit for outgoing calls.

C¢P¢Dur./charges

Last call

All outg. calls

All incom. calls

Remain. units

(Only shown if supported

by your service provider)

ISelect display.

COpen area.

Dur./charges options

úOpen menu.

Charge settings

Currency

(PIN2 prompt)

Enter desired currency.

Charge/Unit

(PIN2 prompt)

Enter the currency used as well as

the charge per unit or time.

Account limit

(PIN2 prompt)

Special SIM cards allow you or the

service provider to define a credit or

duration limit after which the phone

is barred for outgoing calls.

ñPress.

JEnter PIN2.

Account limit

Activate.

JEnter number of units.

§Options§ Open menu, then

select Save.

Auto display

Call duration and charges are

displayed during and after call if

personal rate is set.

Reset Reset the currently

selected setting.

Reset all Reset all settings.

Charge

settings Call up the menu

(see below).

Camera42

left page (42) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Camera

A camera with flash is integrated

in the phone. Take photos/record

videos and

• use photos as wallpaper, a logo,

screensaver or startup and

shutdown animation

• assign a photo/video to a contact

• send photos/videos via MMS

or e-mail

• save photos in My stuff (page 112).

Switching on

C¢R

Xwith the plus/minus key in

standby mode.

The current (preview) image is dis-

played. You will see the following in

the first line from left to right:

ÚZoom factor

ÙNight mode

ÛWhite balance

ØFlash active.

The number of photos that can still

be taken in the selected resolution is

displayed in the preview image. This

number varies considerably depend-

ing on the subject matter and how

much storage space is required. You

will also see an indication of the

selected resolution or, if video mode

has been selected, there is an indica-

tion as to how much recording time

has already been used and the maxi-

mum time still available.

FSwitch between the

Take a photo and

Record video tabs.

Take a photo

ùTake a photo. A beep

is heard as the photo

is taken (this cannot be

deactivated).

I If necessary, set the

zoom factor first.

The photo is saved with the user de-

fined name (see Settings in camera

options) and a consecutively

number in the Pictures (page 114)

folder in My stuff. To enter the name,

see Settings in the options menu.

43Camera

right page (43) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Image resolution

It is possible to set the quality of the

image regardless of the preview im-

age resolution. The best possible res-

olution is 1280 × 960 pixels.

To take individual wallpaper images

you need to set Background as the im-

age resolution in the options.

Record video

The video mode resolution is

the same as the preview image

resolution.

ôStart video recording.

A red dot appears in the top right of

the display while the video recording

is being made.

õEnd video recording.

The video is saved with a name, the

date and the time in the Videos folder

(page 114) in My stuff.

Video resolution

It is possible to set the quality of

the image for a video regardless

of the preview image resolution.

The best possible resolution is

176 × 144 pixels.

Flash

If the flash is active, a symbol ap-

pears in the display. The flash is

charged constantly when activated.

This reduces the stand-by time.

ØThis symbol flashes when

the flash is being charged.

For settings, see options menu. The

flash performance depends on the

outside temperature and the charge

status of the battery. If the tempera-

ture is low and the battery needs

charging the flash performance

deteriorates.

You can use also an external plug-

in flash module (see accessories

page 128).

Additional information

A mirror is integrated in the back of

the phone to make it easier to take self-

por-traits.

Camera44

left page (44) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Camera options

The following functions are availa-

ble, depending on the current

situation.

§Options§ Open menu.

Memory

assis. If there is insufficient mem-

ory available the memory

assistant is started.

Pictures Display list of photos.

Archive

C¢M¢Msg. archive¢E-mail

Messages are saved in the archive

according to their type and origin.

Select tab and read required

message(s).

You can move important messages

to the archive with §Options§, Move to

archiv.

Settings

C¢M¢Msg settings

¢E-mail setup

¢Select function.

General sett.

General settings for receiving and

sending.

Connectiv. set.

You will receive the necessary data

to set the server access and your

e-mail parameters from your service

provider or at:

www.siemens.com/

mobilephonescustomercare

Change active profile

ñPress.

FSelect the new profile.

ìActivate.

Download

option Receive complete e-mail

or only the message

header.

Size limit Limit size for a receiving

an e-mail in KB.

Delete option Delete e-mail on phone

only or also at the server.

E-mail56

left page (56) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Change profile settings

ISelect the fields to edit.

§Options§ Open, then select Save.

Name: Application name.

Application

profile: Select application

profile.

Preferences List of preferred

accesses.

User name: Your name.

E-mail address: Your e-mail address,

e.g.:

name@domain.abc

Reply address: Additional e-mail

address for replies.

User ID: Your user ID.

Password: Your password.

POP3 server: Enter Internet address if

the server type is POP3

and SMTP.

POP3 port: (Default: 110)

SMTP server: Enter Internet address.

SMTP port: (Default: 25)

SMTP

authentic.: Authentication: Yes/No

SMTP

password: A user password will be

required if "Authentica-

tion" is set to Yes.

57WAP push

right page (57) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

WAP push

WAP push messages are transmitted

from special service centres. If, for

example, you have requested con-

figuration data from your service

provider this will be transmitted via

WAP push.

Inbox

C¢M¢WAP push

ISelect the required

message.

öRead the message or

information about the

transmitted data/pro-

grams and, if applicable,

trigger a download.

Inbox options

Different functions are offered

depending on the situation.

§Options§ Open menu.

Msg settings

C¢M¢Msg settings

¢WAP push

§Options§ Open menu, then select

Settings.

Execute Execute program.

Install Start installation.

Accept/

Reject Accept/reject message.

Settings Call up settings.

Allow push Settings to receive WAP

push messages: Allow

specific, Allow none,

Allow all

If Allow specific has been

set, the following lists may

be edited.

Accept list All messages whose send-

ers are included in this

list are accepted

(max. 20 entries possible).

Reject list All messages whose send-

er is included in this list are

automatically deleted

(max. 20 entries possible).

Unk.

address Handling of messages

whose senders are neither

in the white nor the reject

list:

Reject, Delete

Chat room58

left page (58) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Chat room b

You can chat with dialogue partners

who are also registered for this serv-

ice on your phone or PC. Your part-

ners are entered in contact lists for

this and selected from them for a pri-

vate or group dialogue. Similarly,

you can be invited to a dialogue by

other subscribers.

GPRS must be switched on.

Start menu (offline)

If Autom. login is activated the main

overview is displayed immediately.

C¢M¢Chat room

connection.

Account The access settings are

normally preconfigured. If

necessary, enter User ID:

and Password: to activate

access.

Please contact your serv-

ice provider if you do not

have access data.

Online status

Call up the Online stat. mgr

to set your personal at-

tributes (page 103).

Saved convers.

Access to permanently

saved dialogues.

Conversa. hist.

Read all dialogues from

the last session offline

(deleted next time you

Settings Settings for applications

and servers.

Automatic login:

Select your preferred

manual or when the

phone is switched on.

Timeout:

Set the timeout in min-

utes after which Chat room

is put in the background if

no action is taken. The

session continues and can

be called up again via the

menu.

Pop-up info:

Activate/deactivate pop-

ups for new messages or

change the online status,

for Chat room only, if the

application is visible.

59Chat room

right page (59) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Main overview (online)

After you have logged in successful-

ly, depending on your service provid-

er you will see up to 5 tabs as de-

scribed below:

Conversations

IM contacts

IM groups

Info messages

Saved convers.

Conversations

The following are shown in the list:

• Online contacts with whom

a conversation is being held.

• Offline contacts to whom

a message has been sent.

• Groups you are registered with.

• Groups that are not connected

and have unread messages.

• Offline contacts with unread

messages.

Starting a dialogue

ISelect an entry (individual

contact or group) for

a dialogue.

ìStart dialogue.

Dialogues that have taken place

previously are displayed.

Navigation

IScroll in the dialogue.

FSwitch between different

dialogues.

Dialogue

ü / JWrite text.

ýSend text.

Naturally, you can also receive mes-

sages from contacts you do not

know. This will be pointed out to you

in the display, and you can either

switch to the dialogue or block the

contact.

Options

§Options§ Open menu.

Different functions are offered

depending on the selection and

situation:

Contact

details Additional information

about the contact.

Group details Additional information

about the group.

Online status Set your personal at-

tributes (page 103).

Add member Add a new member.

Find member Look for member.

Chat room60

left page (60) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

IM contacts

Display the contact list last used and,

if applicable, entries from Contacts

with Instant Message ID.

ISelect an entry in a con-

tact list for a dialogue.

ìStart dialogue.

At the end the offline

contacts are displayed,

visually separated and in

alphabetical order.

IM contacts options

§Options§ Open menu.

Different functions are offered

depending on the selection and

situation:

Invite Invitation to the contacts

in your own group to join

the dialogue.

Delete

member Delete contact from the

list of members.

IM contact Save contact in the cur-

rent contact list on the

server.

Settings Settings for auto login.

Block contact No more messages are

received from the contact

and the contact receives

no status information

from you.

Message to ID Enter ID manually.

Logout The session is ended

and the start menu

displayed.

Only the display is ended

with §Exit§; the session

continues in the back-

ground. New messages

are stored in the Inbox.

To continue the dia-

logue, open the applica-

tion again via the main

menu.

(For standard functions see page 22)

Add contact User ID:

Enter a unique user

(login) name.

Display name:

Enter your own nickname

for the contact.

Find contact Look for the contact in the

contact lists.

Block contact No more messages are

received from the contact

and the contact receives

no status information from

you.

61Chat room

right page (61) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

IM groups

Display all groups created by you or

in which you are yourself a member.

Hold dialogue as for IM contacts.

IM groups options

§Options§ Open menu.

Different functions are offered de-

pending on the selection and

situation:

Delete

contact Delete contact from the

list.

Contact lists Display your personal

contact lists.

Create new contact

list:select New entry and

assign an ID and a name.

Block list Display the list with

rejected contacts.

For further functions see page 59.

Invite Invitation to the contacts

in your own group to Inst.

Message.

Add member Add new group member.

Find member Search for group member.

Delete

member Delete contact from the

group member list.

Add group Add new group.

Find group Search for group on the

server (also groups no

longer managed in the

list).

Create group Group ID:

Enter an unambiguous

group name.

Name:

Name of group.

Topic:

Topic of group.

Searchable:

Other people can look for

the group.

Welcome message:

Enter own greeting.

Type:

Restricted or open.

Create group Delete group.

Screen name My name for group

dialogue.

For further functions see page 59.

Chat room62

left page (62) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Info messages

Display messages such as invitations

to a group, server messages or other

system messages.

öDisplay selected message.

öReply to invitation/

requests.

To reject, open §Options§ menu and

select Deny.

Saved convers.

Display permanently saved

dialogues.

öDisplay selected dialogue.

Saved dialogues can be renamed or

deleted via the §Options§ menu.

63Voice mailbox/Mailbox

right page (63) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Voice mailbox/Mailbox

C¢M¢Voice mailbox

Most service providers provide a

mailbox in which a caller can leave

voice mail for you

• if your phone is switched off or

not ready to receive,

• if you do not want to answer,

• if you are making a phone call

(and if Call waiting page 81 is not

activated).

If the voice mail service is not part of

your service provider's standard

package, you will need to register for

it, and possibly set it manually. The

following sequence may vary from

service provider to service provider.

Settings b

The service provider supplies you

with two phone numbers:

Save mailbox number

Call this phone number to listen

to the voice mailbox left for you.

C¢M¢Voice mailbox

L/JSelect phone number

from Contacts or enter/

change it manually.

§OK§ Confirm.

Save call divert number

Calls are diverted to this phone

number.

C¢T¢Call setup

¢Forward

ISelect condition,

e.g. Unanswered.

ñConfirm change, then

select Set.

JEnter phone number.

§Options§ Open, then select Save.

Listen b

A new voice mailbox can be an-

nounced as follows, depending on

the service provider:

lSymbol plus beep.

mNotification via SMS.

You receive a call with an automatic

announcement.

Call your mailbox and play the mes-

sage(s) back.

1Press and hold (if neces-

sary enter mailbox

number once only). Con-

firm with §OK§ and §Mailbox§

depending on your serv-

ice provider.

CB services64

left page (64) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

CB services b

C¢M¢CB services

Some service providers offer infor-

mation services (info channels, Cell

Broadcast). If reception is activated,

you will receive messages on the ac-

tivated topics in your Topic list.

CB messages are displayed in stand-

by mode; longer messages are

scrolled automatically.

Receive CB

ñActivate/deactivate CB-

service. If the CB service

is activated, standby

time for the phone will be

reduced.

Read new CB

ìAll new messages are

displayed in chronological

order.

Topic list

Add up to 10 topics to your personal

list from the topics index.

Requirements: Use Topic index is acti-

vated and the service provider sup-

ports the function.

ñActivate/deactivate topic.

öDisplay message on cur-

rent topic if any received.

New topic Add to topic list.

• If the topic index is available,

select a topic from it and confirm.

• Create a new topic. Enter topic

name and channel number. Open

§Options§ menu and select Save.

Auto display

ñChoose to display:

no messages, all messag-

es, or only all new

messages.

Use Topic index

ñActivate/deactivate use of

the topic index.

CB languages

Receive Cell Broadcast messages in

just one language, in several, or in all

languages.

Displays

Ö,ÕTopic activated/deactivated.

mNew messages received on

the topic.

nMessages already read.

65Internet

right page (65) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Internet

C¢O¢Internet

¢Select function.

Get the latest information from the

Internet that is specifically adapted

to the display options of your phone.

In addition, you can visit

wap.siemens.com ("Downloads")

where you can download or update

games, applications, sounds, graph-

ics and more for your phone. Inter-

net access may require registration

with the service provider.

Access to the service

provider

Direct call-up of the browser with

the URL from your service provider.

Download wiz.

You will not be left on your own

during the download!

Enter URL

On inputting a URL the browser

is started and the entered page

displayed.

Bookmarks

Display URL/call up page

List bookmarks

Display list of bookmarks

stored in the phone.

ISelect bookmark.

ìCall up URL.

Saving

Bookmark site

The current page is

saved in the phone as

a bookmark.

Bookmark options

§Options§ Open menu.

Here you will find functions for

changing and managing bookmarks

and their folders. This includes edit-

ing individual entries with the corre-

sponding URLs as well as deleting

and moving them to other folders.

Internet66

left page (66) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Internet

Calling the function opens the

browser with the preset option.

Browser menu

§Options§ Open menu.

End connection

BPress to clear down the

connection and close the

browser.

Navigation in the browser

Display symbols in the browser

(selection)

Enter special characters

*, 0Select important special

characters.

Homepage Call up the pre-set

homepage of the current

profile.

Bookmarks •List bookmarks

Display list of bookmarks

stored in the phone.

•Bookmark site

The current page is

saved as a bookmark.

Go toöEnter URL to dial an Inter-

net address directly, e.g.

wap.siemens.com

Reload Reload current page.

Show URL Display the URL of the

page currently loaded for

sending via SMS/MMS/

e-mail.

History Display most recently

visited Internet sites.

Disconnect Disconnect the Internet.

File Save the object on the cur-

rent page or the complete

page; display saved pages.

Settings Set or reset browser.

Exit browser Close the browser.

ì • Select a link.

• Settings, status on/off.

B • Press briefly: go back a level.

I • One input field/link forward/back.

• Scroll one line.

² Connect ´ No network

³ GPRS online ± Network

Your Internet browser is licensed by:

67Internet

right page (67) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Browser settings

C¢O¢Internet

§Options§ Open menu.

Settings Select.

Profiles

Processing depends on the service

provider (see page 78).

History

Display most recently visited

Internet sites.

Saved websites

Display list of pages stored in the

phone.

Browser Set start option as well as

handling of pictures and

sounds plus send options.

Protocol

parameters Set protocol parameters,

push messages and abort

time as well as handling of

cookies.

Security Set encryption.

Context Reset session; delete

cache, history and cookies.

Settings68

left page (68) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Settings

Profiles

C¢T¢Profiles

Several settings can be stored in a

phone profile in order, for example,

to adapt the phone to the surround-

ing level of noise.

• Six profiles are provided with

default settings. They can be

changed however:

General

Silent alert

Meeting

Outdoor

Car Kit

Headset

• You can name two personal

profiles (<Name>).

Switching on

ISelect default profile or

personal profile.

ìActivate the profile.

Changing profile settings

Edit a default profile or create a new

personal profile:

ISelect profile.

§Options§ Open menu.

Change sett.

Select.

The list of available functions is

displayed.

When you have finished setting a

function, you return to the profile

menu where you can change a

further setting.

Additional information

• To call up the list in standby mode:

G profile list is displayed.

• The active profile is identified with ·.

69Settings

right page (69) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Profile options

§Options§ Open menu.

Car Kit

If an original Siemens car kit is used,

the profile is switched on automati-

cally when the phone is inserted into

the cradle (also see Accessories,

page 127).

Headset

The profile is only switched

on automatically if an original

Siemens headset is used (also

see Accessories, page 127).

Activate Activate selected profile.

Change sett. Change profile settings.

Copy from Copy settings from

another profile.

Rename Change personal profile

(except default profiles).

Settings70

left page (70) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Settings Ringtones

C¢T¢Ringtones

¢Select function.

Volume

Set the volume for all tones.

ISet the volume.

ìConfirm setting.

Melody settings

You can also make individual set-

tings for the following functions:

•Calls

•Messages (SMS, MMS, CB services,

E-mail, Duration)

•Organizer

•Alarm clock

•Chat room

•Games

•Shutdown tune

•Startup tune

•Open ProSlide

•Close ProSlide

or record new ones with:

•Sound recorder (page 104)

Different options are available

depending on the function:

Tunes

ISelect a ringtone from

My stuff.

Ringer setting

Ring Play back the ringtone at

the set volume.

Ascend Set ringtone to a rising

volume.

Beep Reduce ringtone to

ashort beep.

Off Deactivate all tones for

the function concerned.

71Settings

right page (71) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Settings Topics

C¢T¢Topics

Load a completely new visual pres-

entation onto your phone. Various

functions are reorganised on a

theme basis at the press of a key,

e.g.

•Animations

•Sounds

•Color skins

•Background

Theme files are compressed to save

memory space. On activation,

Theme packages are extracted and

registered automatically. Anima-

tions, Sounds and Pictures are

placed in My stuff in their correspond-

ending folders.

Activating a new theme

ISelect theme.

ìActivate; if required, view

§Preview§.

Additional information

Existing display and ringtones settings

could be overwritten.

Settings72

left page (72) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Settings Display

C¢T¢Display

¢Select function.

Background

Set wallpaper graphic for the display.

Logo

Choose picture to be displayed

instead of the provider logo.

Screensaver

After a specifiable time, the screen-

saver shows a picture in the display.

An incoming call and/or pressing any

key will end the function except if

the code security with the telephone

code is activated.

Preview

Display the screensaver.

Style:

Choose between: Standard,

Digital clock, Analog clock, Picture,

Energy saving, Off.

Picture:

Select image in My stuff.

Timeout:

Set period after which the

screensaver starts.

Code protection:

The phone code is requested to close

the screensaver.

Start up anim.

Select animation to be shown when

the phone is switched on.

Shutdn anim.

Select animation to be shown when

phone is switched off.

Greeting

Enter greeting to be displayed in-

stead of animation when phone is

switched on.

Large font

You can choose between two font

sizes for the display.

Lighting

Set display light brighter/darker.

The darker the setting the longer

the standby time.

IPress the navigation key

repeatedly at the top/bot-

tom to adjust up or down.

Contrast

Set contrast.

IPress the navigation key

repeatedly at the top/bot-

tom to adjust up or down.

Note

The Digital clock/Animations screensav-

er reduce your phone's standby time.

73Settings

right page (73) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Settings Silent alert

C¢T¢Silent alert

To avoid the disturbance caused by

a ringing phone, you can activate

the silent alert function as an alter-

native. The silent alert can be

switched on in addition to the ring-

tone (e.g. in a noisy environment).

This function is deactivated when

the battery is being charged and ac-

cessories are connected (except the

headset).

Silent alert

ñActivate/deactivate silent

alert.

Play demo

The types of silent alert offered are

demonstrated.

Assigning types of silent alert

Each of the following applications

can be assigned their own type of

silent alert:

Calls, Messages, Alarm, Chat room

Settings74

left page (74) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Settings Phone Pilot

C¢T¢Phone Pilot

¢Select function.

Your Phone Pilot will provide you with

information for many actions that

you carry out with your phone. It will

also remind you about appointments

or birthdays.

A Phone Pilot is available on the

phone as standard and cannot be

deleted.

Activating, deactivating

Switch off You can deactivate the

Phone Pilot function.

Default Select the included

"standard figure".

If you have loaded additional figures,

you can also install, activate or

delete these:

ISelect entry.

CActivate.

Install

You can download additional figures

from the Internet.

ISelect entry from the list

or from the Inbox.

JWhen installing a new

Phone Pilot you can give

this its own name.

§Yes§ Activate.

75Settings

right page (75) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Settings Connectivity

C¢T¢Connectivity

¢Select function.

EGPRS (EDGE)

ìActivate/deactivate

EGPRS.

EGPRS is a method for transmitting

data in the mobile network faster

than with GPRS. Use EGPRS and if the

network has sufficient capacity, you

can be connected to the Internet

permanently. Only the actual trans-

mission time is charged by the net-

work operator. Some service provid-

ers do not yet support this service.

Shown in the display:

£ Activated and available.

¢ Registered.

¤ Temporarily interrupted.

EGPRS info

Display information on connection

status.

Bluetooth® (BT)

Bluetooth is a short-range radio con-

nection by means of which a headset

or car kit, for example, can be con-

nected without the need for wires.

Using the Send/print function in the

options menu for the application

concerned you can also use this

route to send data.

With SAP (SIM Access Profile) a car

phone GSM module can, for exam-

ple, use the access data from the SIM

card on your phone. There is no need

to swap the SIM card. It is possible

that SAP might not be supported by

your service provider.

Each Bluetooth device has its own

specific address and can be given a

self-explanatory name as an option.

Password protection ensures the se-

curity of a Bluetooth connection, as

does including the BT partner in a list

as a "trusted" device.

To establish a Bluetooth connection

between your phone and other Blue-

tooth devices you must activate

Bluetooth.

The Bluetooth® word mark and logos are

owned by Bluetooth SIG, Inc. and any use

of such marks by Siemens is under licence.

Other trademarks and trade names are

those of their respective owners. Bluetooth

QDID (Qualified Design ID): B02422

Settings76

left page (76) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

ìActivate/deactivate

Bluetooth.

If Bluetooth is activated, standby

time for the phone will be reduced.

B-tooth setup

CBluetooth activation.

My BT name: You can give

the phone a name when

you activate Bluetooth for

the first time.

The search can be global or just for

certain BT devices specified in the

options menu.

ìOpen selection.

Specify which BT devices are to be

searched for:

All All BT devices

Audio E.g. headset, Car Kit

Phone Other BT phones

PC Personal computer with

BT connection

ìStart search.

The number and name of the

most recently found BT device are

displayed.

ìThe search is ended and

the first 10 devices found

are shown in a list.

§Repeat§ Start new search.

IScroll to the required

entry.

ìDial the device and start

the procedure for accept-

ance as a "trusted" device

in the list of known devic-

es. To do this, enter the

password for the other

device. If the list is full

it is not possible to add

another device.

Device list

•Known devices

To make selection easier, frequent

BT partners can be recorded in the

known device list. If entries are

"trusted", no password query is

made.

• Last connected

List of most recently and/or still

connected devices.

•Reject list

Attempts to make connections to

devices in this list are rejected.

• Last srch result

List of the last devices found.

Shown in the display

¨Bluetooth activated.

©Bluetooth visible to others.

«Bluetooth during data

transmission.

ªCall accepted on

Bluetooth device.

77Settings

right page (77) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Lists options

Different functions are offered

depending on the list.

§Options§ Open menu.

My BT name

The phone is given a name (max.

20 characters) – this is the name the

partner sees. If no name is given,

the phone uses the non-changeable

device address.

Information about the BT hardware

also cannot be modified.

Visib.to others

Make settings to specify how your

phone should "act" when in contact

with other BT devices. This means (if

"visible"), for example, that the de-

vice address or the BT name of your

phone is shown to other BT devices if

they request this in order to receive

or send data.

• Not visible

Your phone is not "visible" to other

BT devices. Known devices such as

the Bluetooth Headset / Car Kit con-

tinue operating.

• Auto mode

Your phone is "visible" to other BT

devices for five minutes. You will

then be asked if "visibility" should

continue.

• Always visible

Your phone is always "visible" to oth-

er BT devices. These devices can cre-

ate a connection to your phone and

be added to the known device list if

necessary.

BT aud. stream

When a Bluetooth headset is used,

all audio signals are transmitted to

this exclusively.

Search/Retry Search for BT devices or

repeat search.

Use as audio If not possible automati-

cally, specify device as

an "audio" device.

Higher priority Move entry up the list so

that, for example, a spe-

cific audio device is used

first.

Lower priority Move entry down the list.

to reject list Move entry to the reject

list.

to known list Move entry to the list of

known devices.

(For standard functions see page 22)

Settings78

left page (78) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Online settings

Default setting and activation of

the connection profiles for data

transmission.

The phone default setting varies

from service provider to service

provider:

• The settings have already been

implemented by the service pro-

vider. You can start immediately.

• Access profiles have already been

created by your service provider.

Then select profile and activate.

• The access profiles must be con-

figured manually. In this case, you

will receive the necessary data

from the service provider or visit:

www.siemens.com/

mobilephonescustomercare

Selecting profile

FSelect the profile.

ìConfirm selection.

Fax/data

Send voice/fax b

Set this function on the phone before

transmission so that you can switch

from voice mode to fax mode.

Rcve fax/data b

Your service provider has given you

a number for telephoning and a fax/

data number.

The call is signalled by a special ring-

tone and the type of call (fax or data)

is displayed. Now start the commu-

nication program in your PC to

receive the fax/data.

79Settings

right page (79) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Settings Shortcuts

C¢T¢Shortcuts

Short. Softkeys

You can assign a function to the

right soft keys.

Editing

ISelect key.

ñCall up the edit function.

IScroll to new assignment

in the list.

ìConfirm.

Application

The "Internet" is just used as an

example here.

§Internet§ Press and hold; the

application is started.

Navigation keys

The navigation key can be assigned

a function for three directions (only

effective in standby mode). The

downwards movement is assigned

to opening contacts and cannot be

modified.

ISelect the desired

direction.

ñCall up the edit function.

IChoose application from

the list.

ìConfirm selection.

Number keys

Number keys 2 to 9 can be used

as speed dialling numbers for fast

access to functions.

Number key 1 is reserved for the

mailbox phone number (page 63).

Additional information

The service provider may have already as-

signed functions to all the keys (e.g. access

to "SIM services" or direct call-up of the In-

ternet portal). It may not be possible to

modify this key assignment.

Settings80

left page (80) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Assigning numbers or functions

ISelect the key.

ñCall up the edit function.

IChoose application from

the list.

ìConfirm selection.

Apply

Start a stored application

(e.g. Internet).

In standby mode:

3Press briefly.

The assignment of the number key 3

is displayed above the right soft key

e.g.:

§Internet§ Press and hold.

Or simply

3press and hold.

Show features

Show the functions set for the

number keys.

Key tones

Set the type of acoustic key

acknowledgement.

Tune, Tone, Silent

81Settings

right page (81) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Settings Call settings

C¢T¢Call settings

¢Select function.

Hide ID b

When you make a call, your phone

number can be displayed on the re-

cipient's display (depending on the

service providers).

To suppress this display, you can en-

able the "Hide ID" mode for all subse-

quent calls or just for the next call.

You may need to register separately

with your service provider for these

functions.

Call waiting b

If you are registered for this service,

you can check whether it is set and

you can activate/deactivate it.

Forward

Select the condition under which

calls should be diverted to your mail-

box or another phone number. To

set diversion:

ISelect condition,

e.g. Unanswered.

ñConfirm change, then

select Set.

JEnter phone number.

§Options§ Open, then select Save.

All calls

All calls are diverted.

ÇSymbol in the top line of

display in standby mode.

Unanswered b

Includes the conditions Not reachable,

No reply, Busy, see below.

Not reachable

Divert occurs if phone is switched off

or is out of range.

No reply

A call is only diverted after a delay

that is determined by the network.

The period can be set to a maximum

of 30 seconds in 5-second intervals.

Busy

Divert occurs if a call is in progress.

If Call waiting is activated, you will

hear the call waiting tone during a

call.

Receiving fax b

Fax calls are diverted to a number

with a fax connection.

Receiving data b

Data calls are diverted to a phone

number with a PC connection.

Status check

You can check the current divert

status for all conditions. After a

short pause, the current situation

is transmitted by the network and

displayed.

Settings82

left page (82) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Clear all b

All set diverts are cleared.

Alert calls from b

Only calls from phone numbers that

are in Contacts or on the SIM card or

assigned to a group are signalled au-

dibly. Other calls are only displayed.

Any key

Incoming calls can be accepted by

pressing any key (except for B).

Minute beep

During the call, you will hear a beep

after each minute as a reminder of

the time elapsed. The recipient nor-

mally does not hear this beep.

Additional information

Note that the divert is stored in the network

and not in the phone (e.g. when the SIM

card is changed).

Reactivating divert

The last divert has been stored. Proceed as

with "Set divert". The stored phone number

is displayed. Confirm number.

83Settings

right page (83) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Settings Phone setup

C¢T¢Phone setup

¢Select function.

Language

Display language

Set the language for the display text.

When Automatic is set, the language

of your service provider is used.

If a language that you do not under-

stand happens to be set, the phone

can be reset to the language of your

home service provider with the fol-

lowing input (in standby mode):

* # 0 0 0 0 # A

Input language

Select the language for text input.

Languages supported by T9 are

marked with the T9 symbol.

User dictionary

T9 import

Load database for T9 support for the

current language.

T9 export

Save database for T9 support for the

current language to My stuff.

Key tones

Set the type of acoustic key

acknowledgement.

Tune, Tone, Silent

Info tones

Set service and alarm tones:

On/off Activate/deactivate tones.

Extended If switched on, a wider

range of service tones

is available, e.g.: end

of menu, network

connection interrupted.

Automatic switch off

The phone switches off each day at

the set time.

Switching on

Set Select.

JEnter time

(24-hour-clock).

§Save§ Save.

Switching off

Switch off Select.

ìConfirm.

Settings84

left page (84) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

File system

Format

(Phone-code protected)

The phone memory is formatted

and all saved data such as ringtones,

pictures, games, etc. is deleted.

Formatting may take longer than

1minute.

License mgr.

The licensed data or applications can

be displayed and managed (see also

DRM, page 20).

Phone identity

ID no.

The phone identity number (IMEI) is

displayed. This information may be

useful for customer service.

About phone

Product name, production date,

software version.

CC Monitor

Call center monitor.

Device test

A self-test as well as individual tests

are offered. If you select Self test, all

individual tests are carried out.

Memory assis.

The memory assistant will help you

if there is insufficient phone memo-

ry. If required it can also be started

automatically from applications.

After their capacities have been

checked, all files and folders are dis-

played along with their size and may

be viewed/opened and, if necessary,

deleted.

Software version

Display the software version for your phone

in standby mode:

* # 0 6 # press, then E.

85Settings

right page (85) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Device manag.

The device manager can be used,

for example, to transfer configura-

tion data from the service provider

via WAP push (page 57).

The phone default setting varies

from service provider to service

provider:

• The settings have already been

implemented by the service pro-

vider. You can start immediately.

• Access profiles have already been

created by your service provider.

Then select profile and activate.

• The access profiles must be con-

figured manually. If necessary,

contact your service provider. You

will also find the current settings

for the service provider on the

Internet at

www.siemens.com/

mobilephonescustomercare

under "FAQ".

Active access

ISelect function.

§Start§ Establish a connection to

the active profile.

• Profile active

After the data has been transferred:

§OK§ Confirm.

• No profile active

The list of profiles is chosen for you

to choose from.

ISelect profile.

ìActivate the profile.

§Options§ Open menu, then select

§Edit§ and make entries.

Last connection

öThe data for the last

connection is displayed.

Fact. settings

The phone is reset to the default

values (factory setting). This does

not affect SIM card and network

settings or data saved during Instant

Messaging.

Alternatively, in standby mode

enter:

* # 9 9 9 9 # A

Settings86

left page (86) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Settings Clock

C¢T¢Clock

¢Select function.

Time/date

The clock must be set to the right

time once at start-up.

ìStart editing.

JFirst enter the date (day/

month/year), then the

time (hours/ minutes/sec-

onds).

Time zones

The time zone can be selected in the

world map or a city list:

World map

FSelect the desired time

zone.

City list

ISelect a city in the

selected time zone.

§Options§ Open menu and select

Search city.

Time format

Select 24h or 12h.

Date format

Select the display format for the

date.

Start of week

Select the weekday on which the

monthly and weekly view on the left

starts.

Buddhist date b

Switch to the Buddhist year (not on

all phone models).

Show clock

Activate/deactivate time display in

standby mode.

Auto time b

Time and tine zone are set automati-

cally. The time zone is detected

automatically.

Additional information

÷Display the calendar to select

the date.

If the battery is removed for longer than

30 seconds, the clock must be reset.

87Settings

right page (87) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Settings Security

C¢T¢Security

¢Select function.

Auto key lock

The keypad is locked automatically

if no key has been pressed for a

specific (pre-determinable) time.

This prevents the phone from being

used accidentally. However, you

can still receive calls and make an

emergency call.

HSelect Set.

JEnter time in minutes

and seconds after which

the keypad lock is to be

activated.

ProSlide lock

Enable/disable automatic keylock

when closing the slider. The keys are

always unlocked automatically when

opening the slider.

Direct call

(Phone-code protected)

Only one phone number can be

dialled (page 33).

Only ¡b

(PIN2 or phone-code protected)

Dialling options are restricted to SIM-

protected phone numbers in the

Phonebook. If only area codes are

entered, relevant phone numbers

can be added to these manually

before dialling.

If the SIM card does not support PIN2

input, the whole Phonebook can be

protected with the phone code.

This SIM only b

(PIN2 or phone-code protected)

The phone can be connected to a

SIM card once the phone code is en-

tered. Unless the phone code is

known the phone will not operate

with a different SIM card.

If the phone is to be used with a

different SIM card, enter the phone

code when requested.

Additional information

The keypad can also be locked and

unlocked directly in standby mode.

In each case:

#Press and hold.

Settings88

left page (88) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

PIN code

For description, see page 18:

PIN control, Change PIN, Change PIN2,

Chg.phonecode

Call blocking b

Barring restricts the use of your SIM

card (this is not supported by all serv-

ice providers). You need a 4-digit

network password for network bar-

ring which your service provider will

give you. You may need to be regis-

tered separately for each barring.

All outgoing

All outgoing calls except emergency

numbers are barred.

Outgoing intl. (Outgoing international)

Only national calls can be made.

Out.int.x home (International outgoing

without home country)

International calls are not permitted.

However you can make calls to your

home country when abroad.

All incoming

The phone is barred for all incoming

calls (forwarding all calls to mailbox

provides a similar effect).

When roaming

You do not receive calls when you

are outside your home network. This

means that no charges are incurred

for incoming calls.

Status check

Status check for network barrings.

Clear all

All barrings are deleted. A password

which the service provider will give

you is necessary for this function.

89Settings

right page (89) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Settings Network

C¢T¢Network

¢Select function.

Line b

This function is only displayed if it is

supported by the service provider.

Two separate phone numbers must be

registered on the phone.

Select line

ñChange the connection.

ãDisplay the current phone

number.

Protected

(Phone-code protected)

You may limit usage to one phone

number.

Network info

The list of GSM networks currently

available is displayed.

ÆIndicates forbidden serv-

ice providers (depending

on SIM card).

Choose netwrk

Network search takes place again if,

for example, you leave your home

network or want to register on a

different network. The search can

take place in Manual (see Network info)

or Automatic mode (see also Preferred

net).

Preferred net

Enter your preferred service provid-

ers here in order of preference for

when you leave your home network

(e.g. if there are differences in

price).

The current service provider is

displayed.

ìShow list of preferred

networks.

<Empty> Select.

Additional information

Special settings may be made for each

phone number (e.g. ringtones, call diver-

sion etc.). To do this, first switch to the

required phone number.

Settings90

left page (90) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

ñConfirm change, then

select a new service

provider from the list.

Record service provider

again (last entry in the

list):

Furth.network

Select, enter the provider

data and save it.

Band selection b

Let it set automatically or select ei-

ther GSM 900, GSM 1800, or

GSM 1900. Make sure that your

service provider also supports the

selected band.

Fast search

When this function is active, net-

work reconnection is speeded up

(standby time is reduced).

User group b

Depending on your service provider,

you can create groups with this serv-

ice. These have access, for example,

to internal (company) information,

or special tariffs apply to them. The

details can be clarified with your

service provider.

Active

Activate/deactivate function. "User

group" must be deactivated for nor-

mal phone use.

Select group

You can select or add groups other

than preferred groups (see below).

Code numbers for the groups are ob-

tained from your service provider.

All outgoing

In addition to network control for

a user group, it is possible to set

whether outgoing calls outside the

group are permitted. If the function

is deactivated, only calls within the

group are permitted.

Pref. group

If activated, calls may only be made

within this standard user group

(depending on the network

configuration).

Additional information

If you are outside your home network, your

phone automatically dials another GSM

network.

If the signal strength of the preferred net-

work is inadequate when you switch on the

phone, the phone may register in a different

network. This can change when the tele-

phone is next switched on or if another net-

work is selected manually.

91Settings

right page (91) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Settings Accessories

C¢T¢Accessories

¢Select function.

Car Kit

Only in combination with an original

Siemens handsfree car kit (see

Accessories). The car kit profile is

activated automatically when the

phone is inserted into the cradle.

Edit profile

See page 69.

Auto answer

(Factory default: off)

Calls are accepted automatically af-

ter a few seconds. Eavesdropping is

possible!

Answer by removing from the cradle

(do not use while driving).

Automatic switch off

(Factory default: 2 hours)

The phone is powered by the car's

power supply. You can adjust the

time between switching off the igni-

tion and the time at which the phone

switches off automatically.

Car loudspk.

Improves playback in certain

circumstances.

Automatic settings

• Permanent illumination:

activated.

• Auto key lock: deactivated.

• Charging the phone battery.

• Automatic activation of the Car Kit

profile when the phone is inserted

in the cradle.

Car Kit keys

Key assignment when working to-

gether with Car Kit Comfort Basic.

Auto answer

If you do not notice that your phone has ac-

cepted a call, there is the danger that the

caller may eavesdrop.

Settings92

left page (92) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Headset

Only in conjunction with an original

Siemens headset (see Accessories).

If an original Siemens headset is

used the profile is automatically

activated when the headset is

plugged in.

Edit profile

See page 69.

Auto answer

(Factory default: off)

Calls are accepted automatically af-

ter a few seconds (except where the

ringer is switched off or set to beep).

You should therefore be wearing the

headset.

Automatic setting

Accept call with Call key or Call ac-

ceptance key, even when the auto

key lock is activated.

Upload via USB

If the phone is connected with the

data cable to a PC, the battery can al-

so be charged in this way (only with

original Siemens accessories,

page 127).

93Organizer

right page (93) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Organizer

Calendar

C¢Q¢Calendar

You can enter appointments in the

calendar. Time and date must be set

for the calendar to work correctly.

The calendar offers you three views:

Monthly view

Special appointments are highlight-

ed in colour.

IPress briefly to go forward/

back a week.

Press and hold to go

forward/back a month.

FPress briefly to go forward/

back a day.

ìOpen daily view.

Weekly view

Appointments are shown as a colour

bar on the vertical hour division.

Conflicting appointments are high-

lighted in colour.

FPress briefly to go forward/

back a day.

Press and hold to go

forward/back a week.

IForward/backward by the

hour through the day.

ìOpen daily view.

Daily view

Description of appointment.

FOne day forward/back.

IScroll by the hour or to

next/last entry.

ìDisplay current entry.

Calend. setup

§Options§ Open menu, then select

Calend. setup.

Start of day:

Time when the working day begins.

Start of week:

Weekday on which the monthly and

weekly view on the left starts.

Weekend

Set the days for the weekend.

Show birthdays:

Yes/No.

Organizer94

left page (94) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Appointments

C¢Q¢Appointments

Appointments are displayed in

chronological order in a list.

Enter new appointment

Select.

Category:

cMemo

Text input for description.

dVoice memo

Create a voice memo.

Shown with alarm.

eCall

Enter phone number to

be displayed with the

alarm.

fMeeting

Text input for description.

gVacation

Enter start and end date.

hBirthday

Enter name and date.

Different input/selection fields are

displayed depending on the type.

The number of fields can be restrict-

ed, see Default at the end of the list.

Description:

Description of nature of

appointment.

Phone number:

Enter a phone number or select one

from Contacts.

Voice memo:

Enter a voice recording, see

Dictat.machine, page 97.

Location:

Location of appointment.

Whole day:

Day-long appointment: yes/no.

Start date:

Date when appointment begins.

Start time:

Time when appointment starts.

End date:

Date when appointment ends.

End time:

Time when appointment ends.

Additional information

÷Insert date

from calendar.

95Organizer

right page (95) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Alarm:

On/off or Silent alert.

JEnter the period of time

before the appointment

and select the time unit:

Minutes, Hours, Days

Recurrence:

Select a timeframe for repeating the

appointment:

No, Daily, Weekly, Monthly, Yearly

Enter a parameter for repeating:

Forever, Until, Events (number)

If Weekly is selected, certain

weekdays can be highlighted.

All fields/Fewer fields

In the list, select those fields which

are to be offered for future entries.

§Options§ Open menu.

Save Save appointment.

Information on the alarm

When the set date and time are

reached there is an audio and a

visual alarm.

Alarm type Birthday:

You can send special birthday greet-

ings by SMS, MMS, e-mail or a call via

§Options§. The alarm sounds one day

before the birthday.

Use Pause to set the alarm to repeat.

Additional information

Display above set alarms:

¹Alarm clock

»Appointment

An alarm sounds even when the phone

is switched off. The phone does not go to

standby mode. To deactivate it press any

key.

Organizer96

left page (96) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Tasks

C¢Q¢Tasks

A task is displayed like an appoint-

ment in the agenda for the selected

day. However, unlike an appoint-

ment it does not require a time.

When no time is entered the task ap-

pears at the top of the list every day

until it is marked as completed.

The entries are made in the same

way as Appointments (see "Appoint-

ments"). Then:

Status:

Select Done or Outstanding.

Priority:

Select 5 levels from

Lowest to Highest.

Date used:

If activated with Yes, the following

time input option is offered.

Date due:/Due time:

Enter the date and time by which the

task is to be completed.

Alarm:

As for Appointments.

Save Save task.

Notes

C¢Q¢Notes

Write and manage brief text notes.

Protect confidential information

with the phone code (do not save

any important data or the PIN for

credit cards etc. here).

Entering a new note

Write a normal note.

Write a protected note

(phone code).

JEnter text. The first line is

displayed later as a "title"

in the notes list.

ûSave.

97Organizer

right page (97) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Organiser options

Depending on the application used

(Calendar, Appointments, Tasks, Notes)

and the current situation, different

functions are offered.

§Options§ Open menu.

Dictat.machine

C¢Q¢Dictat.machine

Use the dictating machine to record

short voice memos.

• Use your phone as a dictating

machine when on the move.

• Record a memo as a reminder or

as a note for others.

• Add a voice memo to an appoint-

ment in the calendar.

•Record a call.

New recording

Record new

Select. The remaining

time available, as well as

the recording time, are

shown in the display.

ôA brief beep sounds when

the recording starts. Now

dictate the text.

Delete by Delete all entries prior to

a certain date.

Delete done Delete all completed tasks.

Activate/

Deactivate Switch alarm on/off.

Done Set task to completed/in

progress.

(For standard functions see page 22)

Warning!

The use of this feature may be subject to

restrictions under criminal law.

Please inform the other party to the conver-

sation in advance if you want to record the

conversation and please keep such record-

ings confidential.

You may only use this feature if the other

party to the conversation agrees.

Organizer98

left page (98) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

ó/ôSwitch between pause/

record.

§Stop§ End recording.

Recording is saved with

the prefix ’voice’ and a

consecutively number.

Rename with §Options§.

Playback (via Media player)

ISelect the desired

recording.

ò/óSwitch between playback/

pause.

D/EPress and hold for fast

forward and rewind.

Dictating machine options

§Options§ Open menu.

Time zones

C¢Q¢Time zones

The time zone can be selected in

the world map or a city list:

World map

FSelect the desired time

zone.

City list

ISelect a city in the

selected time zone.

§Options§ Open menu and select

Search city.

ìSet time zone.

Play Play back current

recording.

Loudspeaker Playback through the

built-in loudspeaker.

Settings Set recording quality:

Low, Medium, High

(For standard functions see page 22)

99Organizer

right page (99) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Remote synchronisation

C¢Q¢Remote sync.

You can use this function remotely

to synchronise the personal data on

your phone (contacts, notes, calen-

dar entries) with externally saved da-

ta. The external data can, for exam-

ple, be saved on a company

computer or the Internet e.g.:

www.siemens-mobile.com/syncml

A request to synchronise data can al-

so be sent via WAP push (page 57).

The user, however, must agree to

the start.

Settings and functions

ISelect the desired

function.

öDisplay.

Active account

Two profiles can be set for

synchronisation.

ISelect profile.

ìActivate the profile.

Set profile:

ñDisplay menu for

changing.

Server sett.

Last sync:

Display the time of the last

synchronisation.

Sync data:

Modified data or All data

Sync instruction:

Two-way, Device update or Server

update

Date range

Limit the time for the synchronisa-

tion of appointments in days/weeks.

Contacts, Appointments, Tasks, Notes

Highlight application(s) whose data

is to be synchronised.

Homepage: e.g. www.siemens-

mobile.com/syncml

Port: Enter port number, e.g. 80.

name).

Password: Enter password (shown as

a series of asterisks).

Server ID: Default ID/Enter server

address.

Contacts path:, Appointments path:,

Notes path:, Tasks path:

Organizer100

left page (100) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Synchronisation

Before synchronisation you must se-

lect a profile (Active account) and a

data area (Sync items:) and enter the

correct path to the data (Server sett.).

Confidential notes are not transferred.

§Sync§ The computer is selected

and synchronisation

started.

When synchronisation

has been carried out suc-

cessfully, the actions that

have been performed are

displayed on several tabs.

101Extras

right page (101) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005,

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Extras

SIM services (optional)

C¢S¢SIM services

Your service provider may offer spe-

cial applications such as mobile

banking, share prices, etc. via the

SIM card.

If you have such a SIM card, the SIM

services will appear in the main

menu under "Extras" or directly

above the soft key (on the left).

iSymbol for SIM services.

Where there are several applications,

these are displayed in a SIM services

menu. With the SIM services menu,

your phone is ready to support fu-

ture additions in your service provid-

er's user package. For further infor-

mation, please contact your service

provider.

My applications

To help you organise the applica-

tions you download from the Inter-

net you can use the My applications

folder in My stuff.

For further information, see

page 114.

Calculator

C¢S¢Calc.

The calculator is offered in a basic

version and with an advanced range

of functions.

The input line is in the middle of the

display with two calculation lines

above it.

Beneath it is the matrix with the

calculation functions.

JEnter digit(s).

F/INavigate to functions in

the matrix.

ìAccept function.

JEnter digit(s).

ìApply function. The result

is calculated and dis-

played immediately.

Extras102

left page (102) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Calculator options

§Options§ Open menu.

Unit converter

C¢S¢Unit converter

You can convert various measure-

ment units in the decimal system

into other measurement units.

Example for Velocity units:

Converting the units/currency

FSelect the source unit/

currency.

HSwitch to the input field.

JEnter the quantity to be

converted.

HSwitch to the selection

field.

FSelect the target meas-

urement unit/currency.

The result is displayed.

You can use both input fields

alternately.

Basic functions

+, -, *, / Basic calculation types

=Result

1/x Reversion

%Convert to percentage

.Decimal point

± Sign change "+" / "–"

§AC§ New calculation

Extended functions:

§Options§ Open menu, then select

Extended mode.

Square root

Square

eExponent

MS Save displayed number

MR Call up saved number

M+ Insert number from memory

Convert Call up the current

result in the unit

converter.

Clear all Delete all units.

Memory save,

Memory recall,

Memory clear

Save or recall result;

delete memory.

Extended mode/

Basic mode Switch calculator

functionality.

(For standard functions see page 22)

Velocity Energy

Mass Pressure

Time Volume

Area Length

Power Temperature

Currency

Type Units

Velocity Kilometers/h, Meters/sec,

Miles/h, Miles/sec, Knots,

Mach

103Extras

right page (103) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005,

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Special key functions:

*Set the decimal point.

#Change the preceding

sign.

Currency

When you call up the function for the

first time, you must enter currencies

into which the conversions are to be

made.

JEnter the name of the

currency (e.g. Euro).

§Options§ Open menu and

save the entry with Save.

Now enter the names and exchange

rates of up to three additional

currencies for conversion.

§Options§ Open menu.

Online status b

The application can be called up

from various other applications,

such as Chat room or from Contacts.

In Online status you can set such at-

tributes as "Availability" or "Mood",

which are visible to subscribers to

Chat room. You can also edit your sta-

tus lists for the respective service

here.

Depending on the service provider

and available services, five tabs are

offered.

Online status

For Instant message:

Available, Busy, Not available

Indicate whether you

can be reached in the

respective service.

§Options§ Select Private area. De-

pending on the choice be-

tween Public, Private or

Hide the following at-

tributes can be seen by all

subscribers, only by mem-

bers of the Private list or by

no-one.

My alias: Enter your personal

nickname.

My text: Enter your personal infor-

mation text (access to

saved texts via §Options§).

Sign change Change the preceding

sign.

Memory save,

Memory recall Save or recall result.

Edit rate Change the exchange

rate for the base

currency.

Add currency Enter new currency and

exchange rate.

Set as base Use current currency as

base currency.

Calculator Start calculator.

(For standard functions see page 22)

Extras104

left page (104) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

My logo: Select your personal logo

(start via §Options§ My stuff

or Camera).

My mood: Indicate your personal

mood.

MSG lists b

(Instant Messaging lists)

Access to the following lists:

Pend. requests

Display the current requests for your

personal attributes.

Watcher list

Display who is watching your

attributes.

Private list

Display subscribers who can see all

attributes set to Private.

IM block list

Display all subscribers who can see

no attributes and are blocked for

Chat room.

Info messages

List the messages sent by the service

provider.

Settings

The dependence of Online status

settings on those of the current

profile (page 68) can be activated/

deactivated.

Sound recorder

C¢S¢Sound recorder

Use the sound recorder to record

noises and tones for use as ring-

tones. The sound recorder is usually

started from other applications/func-

tions such as assigning a ringtone.

New recording

New entry Select.

The remaining time avail-

able, as well as the record-

ing time, are shown in the

display.

ôA brief beep sounds when

the recording starts.

ò/óSwitch between pause/

record.

§Stop§ The recording is ended

and saved with the

prefix ’sound’ and a

consecutively number in

My stuff/Sounds.

Start the recording from Sound

recorder:

òPlay back.

Rename the recording via

§Options§.

105Extras

right page (105) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005,

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Start the recording from another

application:

ìBack to application.

Playback (via Media player)

ISelect the desired

recording.

ò/óSwitch between playback/

pause.

D/EPress and hold for fast

forward and rewind.

§Options§ Open menu.

Stopwatch

C¢S¢Stopwatch

The stopwatch can work with lap

times and intermediate times.

With Lap timing, each time a time is

taken the stopwatch returns to zero.

With Split timing, the clock continues

to run and the respective intermedi-

ate time is stored (max. 99).

Display, also in standby mode.

ò/õStart, stop or continue,

depending on the

situation.

§Lap§/§Split§

Store the current

intermediate/lap time.

Stopwatch options

§Options§ Open menu.

Play Play back current

recording.

Set asöSet the recording as a

ringtone.

™ contact Assign recorded sounds

to a contact.

Settings Set recording quality:

Low, Medium, High

(For standard functions see page 22)

Start Start the stopwatch.

Next Continue to take an inter-

mediate time.

Reset Reset to zero.

Stopwatch

list Display saved entries.

Lap timing/

Split timing Switch mode.

(For standard functions see page 22)

Extras106

left page (106) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Countdown

C¢S¢Countdown

A set time elapses. The last 4 sec-

onds are indicated by a beep. At the

end a special beep sounds. Display,

also in standby mode.

JEnter period of time

Iselect standard timing.

òStart countdown.

Standard timings

It is possible to call up or set five

timings with different countdown

times.

ISelect standard timing.

§Change§ Open input field.

JEnter name, then period

of time.

§Save§ Save entries.

Date calculator

Calculate the period between two

specified dates.

JFrom: enter date, then

until: enter date.

§Calc.§ Start calculation.

ñEdit output units.

FSelect previous/next

value.

My menu

Create your own menu with fre-

quently used functions, phone

numbers or Internet pages.

The list of 20 entries is preset. You

can, however, change it as you wish.

Using

ISelect the required entry.

ìConfirm.

AIf the selected entry is a

phone number, you can

also call it with the Call

key.

Additional information

For Stopwatch and Countdown:

§Stop§ ends the function

prematurely.

§Exit§ or Bend only the display, not the

function.

107Extras

right page (107) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005,

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Change menu

You can replace each entry (1–10)

with another entry from the

selection list.

ISelect the required entry.

§Change§ The function list is opened

for selection.

ISelect the new entry from

the list.

ìConfirm. The entry

is saved.

If Phonebook

is selected, the phone

number must also be se-

lected; if Internet is select-

ed, the bookmark must

also be selected.

Conversa. hist.

Read all dialogues from

the last session offline

(deleted next time you

Alarm clock108

left page (108) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Alarm clock

C¢U¢Alarm clock

The alarm sounds at the set time

even when the ringtones or the

phone are switched off. The alarm

clock is activated automatically after

a change is made.

An alarm is ended by pressing any

number key.

ñSet the time for the alarm

call (hh:mm).

ñActivate/deactivate the

alarm clock.

Setting the days for an alarm

§Options§ Open the menu and select

Set days.

ISwitch between the days

of the week.

ñMark or unmark the days

for an alarm.

§Save§ Save the alarm call time.

Alarm clock options

§Options§ Open menu.

Alarm clock

18:45

07:30

Mon Tue Wed Thu Fri Sat Sun

Options ñ Exit

¹Change Set the alarm call time.

Switch between am and

pm if 12 hour mode set.

Set days Set the days for an alarm.

Ringtones Set ringtone.

Clock Set time (page 86).

Auto snooze If user does not react:

snooze only or deactivate

alarm.

(For standard functions see page 22)

Additional information

¹Screen display in standby

mode:

alarm clock activated.

Use Pause to set the current alarm to

repeat.

109Media player

right page (109) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005,

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Media player

Starting from an application

When you are viewing a picture/

video or listening to a melody, the

application starts a media playback.

Direct key for the media player

?Press key.

C¢V

Arranging files

After the media player starts the

following tabs are displayed:

Music

All AAC, AAC+, AAC++ and MP3 files

are displayed.

AAC and MP3 files stored in the

phone are automatically shown in a

list in the Music tab. This list can be

arranged according to the meta data

(ID3 tags) according to album, artist,

genre or title.

Play list

All playlists (file format: *.m3u) are

displayed.

Pictures

All supported picture formats are

displayed.

Videos

All supported video formats are

displayed.

Music/Videos

Functions for playing back songs or

videos.

ìPlay or pause, depending

on the situation.

FFast forward/rewind while

key is pressed.

ILoad next/previous

media file.

#Switch to full screen

mode and back again

(only for video).

[/\Set the volume with the

plus/minus keys.

*Switch to mute and

off mute.

§Stop§ End playback.

For further services, see §Options§

page 110.

Media player110

left page (110) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Play list

Several pieces of music are compiled

in a playlist (*.m3u).

§Options§ Open menu, select New

and then Play list.

Edit playlist options

§Options§ Open menu.

In the simplest case, the playlists are

created on a PC and transferred, to-

gether with the songs, via the Mo-

bile Phone Manager (see page 24

and page 115) into the Sounds

directory in My stuff.

Pictures

Zoom functions for a displayed

picture.

øZoom function if the dis-

played picture has a high-

er resolution than the

display. The two soft keys

(+/–) enlarge/reduce the

picture.

F/IThe enlarged picture de-

tail is moved using the

navigation key.

5 Centre picture.

For further services, see §Options§

page 110.

Media player options

§Options§ Open menu.

Different functions are offered

depending on the starting situation

and the object.

Add track Add a piece of music.

Remove track Remove a piece of music.

Move track Move piece of music up/

down with the navigation

key.

Centre key functions

òPlay, play back

óPause

õStop

Play/Pause Play back the current

media file or pause.

Open Select the media source

such as My stuff,

Bookmarks or URL.

New Select an application to

create a new object or a

new playlist for music.

Zoom Activate zoom mode.

111Media player

right page (111) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005,

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Set asöSet picture as Back-

ground, Logo, for exam-

ple, and sounds, for

example, for Incoming

call, Startup tune.

™ contact Assign a picture or melody

to a contact.

Edit playlist Edit a playlist (page 110).

Play mode • Single track (individual

piece of music)

• Repeat track

• Play all (tracks)

• Repeat all (tracks)

• Repeat playlist

• Intros ( the first

5 seconds of each

track are played).

Slideshow Automatic run-through in

full screen mode.

Change individual picture

with navigation key.

Edit Access to picture editing

(application must be

loaded).

To back-

ground Put Media player into the

background.

Full screen Full screen display of a

picture/video.

(For standard functions see page 22)

Incoming call

An incoming call pauses the playback and

puts the media player into the background.

After the call has ended the playback

continues automatically.

Playback in the background

You can put the media player in the back-

ground in order to work with other applica-

tions. Playback, e.g. of songs, continues.

?Press key repeatedly to

switch: foreground or back-

ground operation.

My stuff112

left page (112) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

My stuff

To organise your files, you can use

the file system like a PC file manager.

There are separate folders for the

various data types in My stuff.

C¢N

The list of the folders and files is

displayed.

ISelect file or folder.

ì/öOpen folder and select file

or link.

Depending on the selec-

tion, the file with the as-

sociated application is

opened or the download

started.

Download

Melodies, pictures, games and other

applications are offered on the Inter-

net. Once downloaded, you can ac-

cess these via the phone. Most appli-

cations include instructions. To

download e.g. new pictures, sounds,

the appropriate folders contain the

download function.

Remember that pictures and sounds

may be protected (DRM, page 20).

Some applications and games are al-

ready pre-installed on your phone.

Downloading can, if necessary, take

place in two stages:

Description file only

ÌThe description file is

loaded for information

purposes only. The appli-

cation/game itself must

be loaded separately.

or complete download

ËThe application/game is

completely loaded (the

asterisk icon may be re-

placed by an application/

game icon).

113My stuff

right page (113) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005,

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

My stuff options

Different functions are offered de-

pending on the starting situation

and the object.

§Options§ Open menu.

New folder Create a new folder and

name it.

Attributes Display information on file

or folder selected.

Move/Copy Select file(s) or folder,

then select destination

folder and insert with ì.

License mgr. Handling of DRM rights.

(For standard functions see page 22)

Additional information

You can use the browser to download applica-

tions (e.g. ringtones, games, pictures, anima-

tions) from the Internet.

Siemens excludes all warranty and liability claims

in respect of or in connection with any applica-

tions subsequently installed by the customer and

any software not included in the original delivery

package. This also applies to functions enabled

subsequently at the customer's instigation. The

buyer bears the sole risk for loss, damage or

faults to the phone or application as well as all

damage and implications arising from the applica-

tion. For technical reasons, such applications or

the retrospective release for certain functions

may be lost if the phone is exchanged/re-deliv-

ered or repaired. In such cases, the buyer is re-

quired to download or release the application

again. Please ensure that your phone has Digital

Rights Management (DRM) so that downloaded

applications are protected from unauthorised re-

production. These applications are then exclu-

sively intended for your phone and cannot be

transferred from this even to create a backup.

Siemens does not warrant, guarantee or accept

any liability for the customer's ability to download

or enable applications again or to do so free of

charge. We recommend that you carry out a

backup from time to time of the applications on

your PC using the "Mobile Phone Manager"

(MPM, page 115). You will find this on the sup-

plied CD-ROM. You can download the relevant

latest version of the MPM from the Internet at:

www.siemens.com/sl75.

My stuff114

left page (114) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Directory structure

Separate folders have already been

created for different data types in

My stuff. These folders cannot be

changed.

Folder Description

The structure, names

and contents can vary,

depending on the serv-

ice provider

Format

Sounds Music, ringtones mp3

aac

aac+

aac++

m3u

mid

amr

wav

Pictures Pictures bmp

bmx

jpg

jpeg

png

gif

Videos Videos 3gp

Topics Theme packages sdt

Phone

Pilot Selection of a

character

sda

Games Java archive jar

Download info jad

Applica-

tions Applications, such

as Photo Editor or

Download Assistant

Other Text modules tmo

Voice recordings vmo

Internet pages html

wml

Depending on the service provider, the

structure, folder names, content and range

of functions in My stuff may vary.

115Mobile Phone Manager

right page (115) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005,

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Mobile Phone Manager

The MPM (Mobile Phone Manager)

enables you to use extended phone

functions from your PC. The phone

and PC communicate via a data cable

(see Accessories, page 127) or

Bluetooth.

You can download the latest version

of the MPM software from the

Internet at:

www.siemens.com/sl75

Organizer

You can use the Organizer to man-

age the contacts and appointments

you have stored in your phone and

synchronize them between your

phone, Outlook® and other Siemens

phones (including Gigaset). You can

use all Call Control functions from

the Organizer.

Call Control

You can dial straight from the Organ-

izer on a mouse click. It also makes

establishing and managing confer-

ence calls extremely easy – the par-

ties to the call are displayed on-

screen in a virtual conference room,

allowing you to swap effortlessly be-

tween the conference call and a pri-

vate call and to call and add new

subscribers on a mouse click.

SMS and EMS management

Write EMS and SMS messages from

the convenience of your PC. Use all

the options your PC offers you and

use your sounds and pictures to cre-

ate SMS and EMS messages. You can

read, forward, print, delete and ar-

chive your messages.

Mobile Phone Manager116

left page (116) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Backup and Restore

With the back-up function, you can

regularly make a back-up copy of

your phone data on the PC. If you ev-

er lose the data on your phone, or re-

place the phone, you can quickly re-

instate all data with the restore func-

tion. Please observe any possible re-

strictions for DRM-protected data.

Bookmark Management

Use your PC to browse on the Inter-

net and define your preferred Inter-

net sites. Save the Internet addresses

as bookmarks on your phone so that

you can quickly call them up at a

later time when you are on the

move.

Phone explorer

You can access the data in your

phone quickly and easily with the

Phone Explorer. The phone is simply

integrated in the data structure of

your PC and handled exactly as if it

was another folder on your PC.

Mobile Modem Assistant

The Mobile Modem Assistant quickly

and easily establishes an Internet

connection via your mobile phone

enabling you to use your PC at

home or when travelling to surf the

Internet.

117Mobile Phone Manager

right page (117) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005,

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Picture and Photo Processing

Picture/photo processing offers you

the opportunity to conveniently cre-

ate, edit and manage pictures and

photos. Filters and effects are of-

fered to help you create colourful,

attractive graphics. The user-friendly

interface makes child’s play of trans-

ferring pictures/photos from or to

the mobile phone, and of changing

the graphic settings.

Media Pool

Media Pool offers you a convenient

option for managing ringtones, mu-

sic, playlists and videos. You can

store your music files in your phone

automatically converting them into

a suitable format.

Plug & Sync

Plug & Sync carries out your routine

tasks for you as you wish. With "Mu-

sic > phone" you can always copy

your latest tracks and playlists auto-

matically to your phone. With "Pho-

tos > PC" you can transfer your newly

taken photos to your PC.

SmartSync

With SmartSync you can always syn-

chronize your data with Outlook®,

OutlookExpress® or Lotus Notes™ as

soon as the phone is connected to a

PC. New and changed contacts are

synchronized in just the same way as

messages and appointments.

Notifier

If your phone is connected to a PC

you will always be notified on the PC

screen, if required, about incoming

calls or messages – even when the

phone is switched to mute.

Questions & Answers118

left page (118) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Questions & Answers

If you have any questions about using your phone, visit us anytime at

www.siemens.com/mobilephonescustomercare.For additional help, we have listed be-

low some frequently asked questions and answers.

Configuration service

To help you set up your mobile phone for the data service WAP, MMS, e-mail and Internet,

you can use a configuration service. This service is used to have the necessary settings for

your mobile phone sent to you by SMS. We recommend that you contact your network pro-

vider who will send you the configuration messages.

As an alternative you can also use the "Setting Configurator" at www.siemens.com/

mobilephonescustomercare. Siemens will then send you the configuration messages.

Please follow the instructions contained in those messages.

Problem Poss. causes Possible solution

Phone cannot be

switched on.

On/Off key not pressed long enough. Press On/Off key for at least 2 seconds.

Flat battery. Charge battery. Check charging indicator in the

display.

Battery contacts dirty. Clean contacts.

See also below under

"Charging error".

Standby time is too

short.

Frequent use of organiser and

games.

Restrict use if applicable.

Fast search activated. Deactivate speed search (page 90).

Display illumination switched on. Switch off display illumination (page 72).

Unintentional keystrokes

(illumination!).

Switch on Auto key lock (page 87).

119Questions & Answers

right page (119) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005,

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Charging error

(charge icon not

displayed).

Battery totally discharged. 1) Plug in charger cable, battery is on charge.

2) Charge icon appears after approx. 2 hours.

3) Charge battery.

Temperature out of range:

5°C to 45°C(41°F to 113°F).

Make sure the ambient temperature is right,

wait for a while, then recharge.

Contact problem Check power supply and connection to the

phone. Check battery contacts and telephone

connection socket, clean them if necessary,

then insert battery again.

No mains voltage. Use different mains power socket, check mains

voltage.

Wrong charger. Only use original Siemens accessories.

Battery faulty. Replace battery.

SIM error. SIM card not inserted correctly. Check that the SIM card is inserted correctly

(page 15).

Dirty SIM card contacts. Clean SIM card with a dry cloth.

SIM card with wrong voltage. Use 3V SIM cards only.

SIM card damaged (e.g. broken). Carry out a visual check. Have service provider

change the SIM card.

No network

connection.

Weak signal. Move higher, to a window or an open space.

Outside the GSM range. Check service provider’s coverage area.

Invalid SIM card. Complain to the service provider.

New network not authorised. Try manual selection or select a different net-

work (page 89).

Network call barring is set. Check network barrings (page 88).

Network overloaded. Try again later.

Phone loses

network.

Signal too weak. Reconnection to another service provider is au-

tomatic (page 89). Switching phone off and on

again can speed this up.

Calls not possible. Second line set. Set line 1 ã (page 90).

New SIM card inserted. Check for new barrings.

Charge limit reached. Reset limit with PIN2 (page 41).

Credit used up. Load credit.

Some calls not

possible.

Call restrictions are in place. Barrings can be set by service provider. Check

barrings (page 88).

Problem Poss. causes Possible solution

Questions & Answers120

left page (120) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Impossible to make

entries in Phone-

book/Addressbook.

Phonebook/Addressbook is full. Delete entries in the Addressbook/Phonebook

(see Standard functions, page 22).

Voice mailbox not

functioning.

Call divert to mailbox not set. Set call divert to mailbox (page 63).

å flashes. SMS memory is full. Delete SMS messages (see Standard func-

tions, page 22) or archive them (page 49).

æ flashes. MMS memory is full. Delete MMS messages (see standard func-

tions, page 22).

ç flashes. Phone memory full. Delete messages, pictures, videos, games or

applications.

Function cannot be

set.

Not supported by service provider or

registration required.

Contact your service provider.

Capacity problems

with, for example,

Games & More,

ringtones, pic-

tures, videos, SMS

archive.

Phone memory full. Delete files in the relevant areas. You can use

the memory assistant to delete specific files

(page 84).

No Internet access,

downloading not

possible.

Profile not activated, profile settings

wrong/incomplete.

Activate or set browser profile. If necessary

consult your service provider.

Message cannot

be sent.

Service provider does not support

this service.

Check with your service provider.

Phone number for service centre not

set or incorrectly set.

Set service centre (page 50).

SIM card contract does not support

this service.

Contact your service provider.

Service centre too busy. Repeat message.

Recipient does not have a compati-

ble phone.

Check.

EMS pictures are

not displayed on the

destination phone.

Destination phone does not support

the EMS standard.

No Internet access

possible.

Incorrect browser profile set, or

wrong or incomplete settings.

Check browser settings; contact your service

provider if necessary.

Problem Poss. causes Possible solution

121Questions & Answers

right page (121) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005,

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

PIN error/

PIN2 error

Three wrong entries. Enter the PUK (MASTER PIN) supplied with the

SIM card according to the instructions. If the

PUK (MASTER PIN) has been lost, contact

your service provider.

Phone code error. Three wrong entries. Contact Siemens Service (page 122).

Service provider

code error.

No authorisation for this service. Contact your service provider.

Too few/too many

menu entries.

Functions may have been added or

deleted by the service provider via

the SIM card.

Check with your service provider.

No fax possible. Wrong settings in the PC. Check settings.

No authorisation for this service. Contact your service provider.

Charge meter does

not work.

Charge pulse is not being

transmitted.

Contact your service provider.

Damage

Severe shock. Remove battery and SIM and re-insert them. Do not dismantle the phone!

Phone became

wet.

Remove battery and SIM. Dry immediately with a cloth, but do not apply heat.

Dry connector contacts thoroughly. Stand mobile upright in an air current. Do not

dismantle the phone!

Problem Poss. causes Possible solution

Reset settings to the factory default, page 85: * # 9 9 9 9 # A

Customer Care122

left page (122) of SL75 Hydra FUG, w/o ptt, en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050920

Customer Care

In some countries repair and replace servic-

es are impossible where the products are

not sold through our authorised dealers.

If repair work is necessary, please contact

one of our service centres:

Abu Dhabi .........................................0 26 42 38 00

Argentina .....................................0 80 08 88 98 78

Australia..........................................13 00 66 53 66

Austria.............................................05 17 07 50 04

Bahrain .................................................... 40 42 34

Bangladesh.......................................0 17 52 74 47

Belgium.............................................0 78 15 22 21

Bolivia ...............................................0 21 21 41 14

Bosnia Herzegovina..........................0 33 27 66 49

Brunei ..................................................02 43 08 01

Bulgaria................................................02 73 94 88

Cambodia ............................................12 80 05 00

Canada ........................................1 88 87 77 02 11

Chile..................................................8 00 53 06 62

China ...........................................0 21 23 01 71 88

Colombia....................................01 80 07 00 66 24

Croatia ..............................................0 16 10 53 81

Czech Republic.................................2 33 03 27 27

Denmark ............................................. 35 25 86 00

Dubai ................................................0 43 96 64 33

Ecuador ..........................................18 00 10 10 00

Egypt.................................................0 23 33 41 11

Estonia.................................................. 6 30 47 97

Finland ............................................09 22 94 37 00

France.............................................01 56 38 42 00

Germany ......................................0 18 05 33 32 26

Greece ............................................80 11 11 11 16

Hong Kong.......................................... 28 61 11 18

Hungary ..........................................06 14 71 24 44

Iceland .................................................. 5 11 30 00

India .............................22 24 98 70 00 Extn: 70 40

Indonesia .....................................0 21 46 82 60 81

Ireland.............................................18 50 77 72 77

Italy .................................................02 24 36 44 00

Ivory Coast.......................................... 05 02 02 59

Jordan...............................................0 64 39 86 42

Kenya.................................................... 2 72 37 17

Kuwait ................................................... 2 45 41 78

Latvia .................................................... 7 50 11 18

Lebanon.............................................. 01 44 30 43

Libya ...............................................02 13 50 28 82

Lithuania ...........................................8 70 07 07 00

Luxembourg........................................ 43 84 33 99

Macedonia ........................................0 23 13 14 84

Malaysia....................................+ 6 03 77 12 43 04

Malta .......................................+ 35 32 14 94 06 32

Mauritius ............................................... 2 11 62 13

Mexico .......................................01 80 07 11 00 03

Morocco .............................................. 22 66 92 09

Netherlands .................................0 90 03 33 31 00

New Zealand...................................08 00 27 43 63

Nigeria ..............................................0 14 50 05 00

Norway................................................ 22 70 84 00

Oman ....................................................... 79 10 12

Pakistan ..........................................02 15 66 22 00

Paraguay ..........................................8 00 10 20 04

Peru ..................................................0 80 05 24 00

We offer fast, individual advice! You have

several options:

Our online support on the Internet:

www.siemens.com/

mobilephonescustomercare

We can be reached any time, any place.

You are given 24 hour support on all as-

pects of our products. Here you will find an

interactive fault-finding system, a compila-

tion of the most frequently asked questions

and answers, plus user guides and current

software updates to download.

When calling customer service, please

have ready your receipt and the phone

identity number (IMEI, to display press

*#06#), the software version (to display,

press *#06#, then E) and if available,

your Siemens Service customer number.

You will also find the most frequently

asked questions and answers in the sec-

tion entitled "Questions & Answers" in this

user guide on page 118.

123Customer Care

right page (123) of SL75 Hydra FUG, w/o ptt, en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050920

Philippines ........................................0 27 57 11 18

Poland.............................................08 01 30 00 30

Portugal ............................................8 08 20 15 21

Qatar....................................................04 32 20 10

Romania .........................................02 12 09 99 66

Russia..........................................8 80 02 00 10 10

Saudi Arabia .....................................0 22 26 00 43

Serbia .............................................01 13 07 00 80

Singapore ............................................62 27 11 18

Slovak Republic ..............................02 59 68 22 66

Slovenia............................................0 14 74 63 36

South Africa ....................................08 60 10 11 57

Spain.................................................9 02 11 50 61

Sweden.............................................0 87 50 99 11

Switzerland .....................................08 48 21 20 00

Taiwan ............................................02 23 96 10 06

Thailand............................................0 27 22 11 18

Tunisia .................................................71 86 19 02

Turkey..........................................0 21 64 59 98 98

Ukraine ........................................8 80 05 01 00 00

United Arab Emirates........................0 43 66 03 86

United Kingdom ...........................0 87 05 33 44 11

USA .............................................1 88 87 77 02 11

Venezuela....................................0 80 01 00 56 66

Vietnam...........................................84 89 20 24 64

Zimbabwe ............................................04 36 94 24

Care and maintenance124

left page (124) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Care and maintenance

Your phone has been designed and manu-

factured to the highest of standards and

should be treated with great care. The sug-

gestions below will help you to enjoy your

phone for many years.

• Protect your phone from moisture and hu-

midity. Precipitation, humidity and liquids

contain minerals that will corrode electron-

ic circuits. Nevertheless, should your

phone become wet, disconnect it immedi-

ately from the power supply to avoid elec-

tric shock. Do not place your phone (even

to dry it) on/in a source of heat such as a

microwave oven, oven or radiator. The

phone may become overheated and

possibly explode.

• Do not use or store the phone in dusty,

dirty areas. Its moving parts may be

damaged and the casing may become

deformed and discoloured.

• Do not store your phone in hot environ-

ments (e.g. vehicle instrument panel in the

summer). High temperatures can shorten

the life of electronic devices, damage bat-

teries and warp or melt certain plastics.

• Do not store your phone in cold environ-

ments. When the phone warms up again

(to its normal ambient temperature), mois-

ture can form inside the phone, which may

damage electronic circuit boards.

• Do not drop, knock or shake your phone.

Rough handling can damage internal cir-

cuit boards!

• Do not use harsh chemicals, cleaning

solvents, or strong detergents to clean the

phone!

The suggestions given above apply equally

to your phone, battery, charger and all ac-

cessories. If any of these parts is not working

properly, obtain fast and reliable help at our

service centres.

Battery quality statement

The capacity of your mobile phone battery

will reduce each time it is charged/emptied.

Storage at too high or low temperatures will

also result in a graduly capacity loss. As

a result the operating time of your mobile

phone may be considerably reduced, evan

after a rull recharge of the battery.

Regardless of this, the battery has been de-

signed and manufactured so that it can be

recharged and used for six months after the

purchase of your mobile phone. After six

months, if the battery is clearly suffering from

loss of performance, we recommend that

your replace it. Please buy only Siemens

original batteries.

Display quality

declaration

For technological reasons, a few small dots

with different colours may appear in the dis-

play in exceptional cases.

Just remember that the appearance of

brighter or darker dots generally does not

mean that a fault has occurred.

125Product data

right page (125) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005,

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Product data

Declaration of conformity

BenQ Mobile hereby declares that the phone

described in this user guide is in compliance

with the essential requirements and other

relevant provisions of European Directive

1999/5/EC (R&TTE). The relevant declara-

tion of conformity (DoC) has been signed.

Please call the company hotline if you re-

quire a copy of the original:

www.siemens.com/mobiledocs

Technical data

Operating time

Talktime: up to 300 minutes

Standby time: up to 300 hours

The operating time depends upon the re-

spective conditions of use. Extreme temper-

atures considerably reduce the standby

time. You should therefore avoid the leaving

the phone in the sun or on a radiator.

The following applications reduce the stand-

by time and can be deactivated if required:

• Flash (page 43)

• CB services (page 64)

• Screensaver (page 72)

• Lighting (page 72)

• EGPRS (page 75)

• Bluetooth (page 75)

• Fast search (page 90)

GSM class: 4 (2 watt)

Frequency range: 880–960 MHz

GSM class: 1 (1 watt)

Frequency range: 1,710–1,880 MHz

GSM class: 1 (1 watt)

Frequency range: 1,850–1,990 MHz

Weight: 99 g (3.49 oz)

Size: 92 × 48 × 23 mm

(~ 78 ccm)

Li-Ion battery: 750 mAh

Operating

temperature:

–10°C to 55°C

(14°F to 131°F)

SIM card: 1.8 and 3.0 V

Phone ID

You will need the following information if

you lose your phone or SIM card:

the number of the SIM card (on the card):

..............................................................

15-digit serial number of the phone

(under the battery):

..............................................................

the customer service number of the service

provider:

..............................................................

Lost phone

If you lose your phone or SIM card, contact

your service provider immediately to pre-

vent misuse.

SAR126

left page (126) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

SAR

INFORMATION ON RF EXPOSURE /

SPECIFIC ABSORPTION RATE (SAR)

THIS MODEL MEETS THE GOVERN-

MENT’S REQUIREMENTS FOR EXPO-

SURE TO RADIO WAVES

Your cellular phone is a radio transmitter and

receiver. It is designed to meet the require-

ments for exposure to radio waves estab-

lished by the Federal Communications

Commission (FCC, USA) and by Health

Canada. These requirements include safety

margins designed to assure the protection of

all persons, regardless of age and health.

They use a unit of measurement known as

the Specific Absorption Rate (SAR). The

SAR limit is 1.6 W/kg averaged over one

gram of tissue.

The highest SAR value for this device when

tested at the ear was 0.23 W/kg. In positions

other than the head, such as on the body, a

separation distance of 2.0 cm is required.

The highest SAR value in this case was

0.80 W/kg.

Information about this device model can be

found at http://www.fcc.gov/oet/fccid

by searching the equipment authorization sys-

tem using FCC ID: PWX-SL75.

As SAR is measured utilizing the device’s

highest transmitting power, the actual SAR

of this device while operating is typically be-

low that indicated above. This is due to auto-

matic changes to the power level of the

device to ensure it only uses the minimum

level required to reach the network.

Additional Information can be found on the

websites of the World Health Organization

http://www.who.int/emf

the Cellular Telecommunications Industry

Association (CTIA) web-site at

www.phonefacts.net,

the Canadian Wireless Telecommunications

Association (CWTA) website

www.cwta.ca

or Siemens

www.siemens.com/mobilephones

127Accessories

right page (127) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005,

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Accessories

Fashion & Carry

Carrying Cases

Leather Case FCL-700

Tour Case FCT-650

Energy

Li-Ion battery EBA-730 (750 mAh)

Spare battery.

Travel Charger

Travel Charger EU ETC-500

Travel Charger UK ETC-510

Travel charger with an extended input

voltage range of 100–240 V.

Car Charger Plus ECC-600

Charger for the cigarette lighter socket in

the car. It is possible to make phone calls

during charging.

Desk Top Stand EDS-600

A smart and practical desk station for your

mobile phone.

Handsfree Portable

Headset Basic HHS-500

Headset HHS-510

Headset with key to accept and end calls.

Headset Purestyle HHS-610

High quality headset with detachable ear-

piece and key to accept and end calls.

Headset Stereo HHS-700

Stereo headset with function key for enjoy-

ing music and making phone calls.

Headset Bluetooth®

HHB-600 with EU battery charger

HHB-610 with battery charger for UK

HHB-620 with battery charger for Australia

Small Bluetooth® headset that is very

comfortable to wear.

Charger adapter ECA-500

Charger adapter for Headset Bluetooth

HHB-600.

Headset Bluetooth®

HHB-700 with EU battery charger

HHB-710 with battery charger for UK

HHB-720 with battery charger for Australia

Elegant, small Bluetooth® headset that is

very comfortable to wear.

Headset Bluetooth® Stereo HHB-750

Stereo Bluetooth® headset with integrated

display for high quality and convenient

handsfree talking and listening to music.

Office

Data Cable DCA-500

For connecting the phone to the serial

RS232 port of the PC.

Data Cable USB DCA-510

For connecting the phone to the USB port of

the PC. With charging function.

Data Cable USB DCA-540

For connecting the phone to the USB port of

the PC. With charging function.

Accessories128

left page (128) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

SyncStation DSC-600

Desk station for the phone to facilitate sim-

ultaneous data exchange and telephone

charging. Includes a desktop stand and

a USB data cable.

Multitainment

Flash IFL-600

Plug-in flash module for taking photos in are-

as with low ambient light.

Mobile Music Set IMS-700

The portable Mobile Music Set allows you to

listen to music on your mobile phone any-

where you go with excellent sound quality.

You can also play music over the active

loudspeaker so that others can share your

enjoyment.

Car Solutions

Car Kit Portable HKP-500

The portable handsfree car kit can easily be

moved from one car to another. Simply plug

into the cigarette lighter socket, connect, and

talk.

Car Kit Bluetooth® HKW-600

State-of-the-art Bluetooth® Car Kit with ex-

ternal display for safe and convenient

handsfree use of a mobile phone in the car.

Car Kit Bluetooth® Portable HKW-700

High-tech Bluetooth handsfree car kit with

no cable connection to the mobile phone.

Installation is easy - simply plug into the

cigarette lighter socket.

Car Kit Bluetooth® HKW-710

Innovative Bluetooth® handsfree kit with an

external display for making in-car calls safely

and conveniently.

Car Kit Bluetooth® SIM HKW-720

Innovative Bluetooth® handsfree kit with an

external display for making in-car calls

safely, conveniently, and with low power

consumption.

Products can be obtained in specialist shops

or you can visit the Siemens Mobile Store

online:

Siemens Original Accessories

www.siemens.com/shop

129U.S. FDA

right page (129) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005,

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

U.S. FDA

The U.S. Food and Drug

Administration's (FDA) Center

for Devices and Radiological

Health Consumer Update on

Mobile Phones

FDA has been receiving inquiries

about the safety of mobile phones,

including cellular phones and PCS

phones. The following summarizes

what is know – and what remains

unknown – about whether these

products can pose a hazard to

health, and what can be done to

minimize any potential risk. This in-

formation may be used to respond

to questions.

Why the concern?

Mobile phones emit low levels of ra-

dio frequency energy (i.e., radio fre-

quency radiation) in the microwave

range while being used. They also

emit very low levels of radio frequen-

cy energy (RF), considered non-sig-

nificant, when in the stand-by mode.

It is well known that high levels of RF

can produce biological damage

through heating effects (this is how

your microwave oven is able to cook

food). However, it is not known

whether, to what extent, or through

what mechanism, lower levels of RF

might cause adverse health effects

as well. Although some research has

been done to address these ques-

tions, no clear picture of the biologi-

cal effects of this type of radiation

has emerged to date. Thus, the avail-

able science does not allow us to

conclude that mobile phones are ab-

solutely safe, or that they are unsafe.

However, the available scientific evi-

dence does not demonstrate ad-

verse health effects associated with

the use of mobile phones.

What kinds of phones are in question?

Questions have been raised about

hand-held mobile phones, the kind

that have a built-in antenna that is

positioned close to the user's head

during normal telephone conversa-

tion. These types of mobile phones

are of concern because of the short

distance between the phone's an-

tenna – the primary source of the RF

– and the person's head. The expo-

sure to RF from mobile phones in

which the antenna is located at

greater distances from the user (on

the outside of a car, for example) is

drastically lower than that from

hand-held phones, because a per-

son's RF exposure decreases rapidly

with distance from the source. The

safety of so-called “cordless phones,”

which have a base unit connected to

the telephone wiring in a house and

which operate at far lower power

levels and frequencies, has not been

questioned.

U.S. FDA130

left page (130) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:10)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

How much evidence is there that hand-

held mobile phones might be harmful?

Briefly, there is not enough evidence

to know for sure, either way; howev-

er, research efforts are on-going.

The existing scientific evidence is

conflicting and many of the studies

that have been done to date have

suffered from flaws in their research

methods. Animal experiments inves-

tigating the effects of RF exposures

characteristic of mobile phones have

yielded conflicting results. A few ani-

mal studies, however, have suggest-

ed that low levels of RF could accel-

erate the development of cancer in

laboratory animals. In one study,

mice genetically altered to be predis-

posed to developing one type of can-

cer developed more than twice as

many such cancers when they were

exposed to RF energy compared to

controls. There is much uncertainty

among scientists about whether re-

sults obtained from animal studies

apply to the use of mobile phones.

First, it is uncertain how to apply the

results obtained in rats and mice to

humans. Second, many of the stud-

ies showed increased tumor

development used animals that had

already been treated with cancer-

causing chemicals, and other studies

exposed the animals to the RF virtu-

ally continuously – up to 22 hours

per day.

For the past five years in the United

States, the mobile phone industry

has supported research into the safe-

ty of mobile phones. This research

has resulted in two findings in partic-

ular that merit additional study:

1. In a hospital-based, case-control

study, researchers looked for an as-

sociation between mobile phone use

and either glioma (a type of brain

cancer) or acoustic neuroma (a be-

nign tumor of the nerve sheath). No

statistically significant association

was found between mobile phone

use and acoustic neuroma. There

was also no association between

mobile phone use and gliomas when

all types of gliomas were considered

together. It should be noted that the

average length of mobile phone ex-

posure in this study was less than

three years.

When 20 types of glioma were con-

sidered separately, however, an as-

sociation was found between mobile

phone use and one rare type of glio-

ma, neuroepithelliomatous tumors.

It is possible with multiple compari-

sons of the same sample that this as-

sociation occurred by chance. More-

over, the risk did not increase with

how often the mobile phone was

used, or the length of the calls. In

fact, the risk actually decreased with

cumulative hours of mobile phone

use. Most cancer causing agents in-

crease risk with increased exposure.

An ongoing study of brain cancers by

the National Cancer Institute is ex-

pected to bear on the accuracy and

repeatability of these results.1

131U.S. FDA

right page (131) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005,

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

2. Researchers conducted a large

battery of laboratory tests to assess

the effects of exposure to mobile

phone RF on genetic material. These

included tests for several kinds of ab-

normalities, including mutations,

chromosomal aberrations, DNA

strand breaks, and structural chang-

es in the genetic material of blood

cells called lymphocytes. None of

the tests showed any effect of the RF

except for the micronucleus assay,

which detects structural effects on

the genetic material. The cells in this

assay showed changes after expo-

sure to simulated cell phone radia-

tion, but only after 24 hours of expo-

sure. It is possible that exposing the

test cells to radiation for this long re-

sulted in heating. Since this assay is

known to be sensitive to heating,

heat alone could have caused the ab-

normalities to occur. The data al-

ready in the literature on the re-

sponse of the micronucleus assay to

RF are conflicting. Thus follow-up re-

search is necessary. 2

FDA is currently working with gov-

ernment, industry, and academic

groups to ensure the proper follow-

up to these industry-funded research

findings. Collaboration with the Cel-

lular Telecommunications Industry

Association (CTIA) in particular is ex-

pected to lead to FDA providing re-

search recommendations and scien-

tific oversight of new CTIA-funded

research based on such recommen-

dations.

Two other studies of interest have

been reported recently in the litera-

ture:

• Two groups of 18 people were ex-

posed to simulated mobile phone

signals under laboratory condi-

tions while they performed cogni-

tive function tests. There were no

changes in the subjects' ability to

recall words, numbers, or pic-

tures, or in their spatial memory,

but they were able to make choic-

es more quickly in one visual test

when they were exposed to simu-

lated mobile phone signals. This

was the only change noted among

more than 20 variables com-

pared.3

• In a study of 209 brain tumor cas-

es and 425 matched controls,

there was no increased risk of

brain tumors associated with mo-

bile phone use. When tumors did

exist in certain locations, howev-

er, they were more likely to be on

the side of the head where the

mobile phone was used. Because

this occurred in only a small

number of cases, the increased

likelihood was too small to be sta-

tistically significant.4

In summary, we do not have enough

information at this point to assure

the public that there are, or are not,

any low incident health problems as-

sociated with use of mobile phones.

FDA continues to work with all par-

ties, including other federal agencies

U.S. FDA132

left page (132) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:10)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

and industry, to assure that research

is undertaken to provide the neces-

sary answers to the outstanding

questions about the safety of mobile

phones.

What is known about cases of human

cancer that have been reported in users

of hand-held mobile phones?

Some people who have used mobile

phones have been diagnosed with

brain cancer. But it is important to

understand that this type of cancer

also occurs among people who have

not used mobile phones. In fact,

brain cancer occurs in the U.S. popu-

lation at a rate of about 6 new cases

per 100,000 people each year. At

that rate, assuming 80 million users

of mobile phones (a number increas-

ing at a rate of about 1 million per

month), about 4800 cases of brain

cancer would be expected each year

among those 80 million people,

whether or not they used their

phones. Thus it is not possible to tell

whether any individual's cancer

arose because of the phone, or

whether it would have happened an-

yway. A key question is whether the

risk of getting a particular form of

cancer is greater among people who

use mobile phones than among the

rest of the population. One way to

answer that question is to compare

the usage of mobile phones among

people with brain cancer with the

use of mobile phones among appro-

priately matched people without

brain cancer. This is called a case-

control study. The current case-con-

trol study of brain cancers by the Na-

tional Cancer Institute, as well as the

follow-up research to be sponsored

by industry, will begin to generate

this type of information.

What is FDA's role concerning the safety

of mobile phones?

Under the law, FDA does not review

the safety of radiation emitting con-

sumer products such as mobile

phones before marketing, as it does

with new drugs or medical devices.

However, the agency has authority

to take action if mobile phones are

shown to emit radiation at a level

that is hazardous to the user. In such

a case, FDA could require the manu-

facturers of mobile phones to notify

users of the health hazard and to re-

pair, replace or recall the phones so

that the hazard no longer exists.

Although the existing scientific data

do not justify FDA regulatory actions

at this time, FDA has urged the mo-

bile phone industry to take a number

of steps to assure public safety. The

agency has recommended that the

industry:

• Support needed research into pos-

sible biological effects of RF of the

type emitted by mobile phones;

• Design mobile phones in a way

that minimizes any RF exposure to

the user that is not necessary for

device function; and

133U.S. FDA

right page (133) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005,

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

• Cooperate in providing mobile

phone users with the best possible

information on what is known

about possible effects of mobile

phone use on human health.

At the same time, FDA belongs to an

interagency working group of the

federal agencies that have responsi-

bility for different aspects of mobile

phone safety to ensure a coordinat-

ed effort at the federal level. These

agencies are:

• National Institute for Occupation-

al Safety and Health

• Environmental Protection Agency

• Federal Communications Com-

mission

• Occupational Health and Safety

Administration

• National Telecommunications and

Information Administration

The National Institutes of Health also

participates in this group.

In the absence of conclusive information

about any possible risk, what can con-

cerned individuals do?

If there is a risk from these products

– and at this point we do not know

that there is – it is probably very

small. But if people are concerned

about avoiding even potential risks,

there are simple steps they can take

to do so. For example, time is a key

factor in how much exposure a per-

son receives. Those persons who

spend long periods of time on their

hand-held mobile phones could con-

sider holding lengthy conversations

on conventional phones and reserv-

ing the hand-held models for shorter

conversations or for situations when

other types of phones are not availa-

ble.

People who must conduct extended

conversations in their cars every day

could switch to a type of mobile

phone that places more distance be-

tween their bodies and the source of

the RF, since the exposure level

drops off dramatically with distance.

For example, they could switch to:

• a mobile phone in which the an-

tenna is located outside the vehi-

cle,

• a hand-held phone with a built-in

antenna connected to a different

antenna mounted on the outside

of the car or built into a separate

package, or

• a headset with a remote antenna

to a mobile phone carried at the

waist.

Where can I find additional information?

For additional information, see the

following websites:

• Federal Communications Com-

mission (FCC) RF Safety Program

(select “Information on Human Ex-

posure to RF Fields from Cellular

and PCS Radio Transmitters”):

http://www.fcc.gov/oet/rfsafety

U.S. FDA134

left page (134) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:10)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

• World Health Organization (WHO)

International Commission on

Non-Ionizing Radiation Protection

(select Qs & As):

http://www.who.int/emf

• United Kingdom, National Radio-

logical Protection Board:

http://www.nrpb.org.uk

• Cellular Telecommunications In-

dustry Association (CTIA):

http://www.wow-com.com

• U.S. Food and Drug Administra-

tion (FDA) Center for devices and

Radiological Health:

http://www.fda.gov/cdhr/consumer/

1 Muscat et al. Epidemiological Study of Cel-

lular Telephone Use and Malignant Brain

Tumors. In: State of the Science Symposi-

um; 1999 June 20; Long Beach, California.

2 Tice et al. Tests of mobile phone signals for

activity in genotoxicity and other laboratory

assays. In: Annual Meeting of the Environ-

mental Mutagen Society; March 29, 1999,

Washington, DC; and personal communica-

tion, unpublished results.

3 Preece, AW, Iwi, G, Davies-Smith, A,

Wesnes, K, Butler, S, Lim, E, and Varey, A.

Effect of a 915- MHz simulated mobile

phone signal on cognitive function in man.

Int. J. Radiat. Biol., April 8, 1999.

4 Hardell, L, Nasman, A, Pahlson, A, Hal-

lquist, A and Mild, KH. Use of cellular tele-

phones and the risk for brain tumors; a case-

control study. Int. J. Oncol, 15: 113-116,

1999.

135FCC/Industry Canada Notice

right page (135) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005,

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

FCC/Industry Canada Notice

Your phone may cause TV or radio in-

terference (for example, when using

a telephone in close proximity to re-

ceiving equipment). The FCC or In-

dustry Canada can require you to

stop using your telephone if such in-

terference cannot be eliminated. If

you require assistance, please con-

tact your local service facility.

This device complies with part 15 of

the FCC rules. Operation is subject to

the condition that this device does

not cause harmful interference.

Intellectual Property136

left page (136) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:37)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Intellectual Property

Intellectual Property Restrictions

All Intellectual Property, as defined

below, which is owned by or other-

wise the property of Siemens Infor-

mation and Communications Mo-

bile, LLC (“Siemens”), its affiliates,

partners or suppliers, relating to the

Phone, including but not limited to

accessories, parts or software relat-

ing thereto (the “Phone System”), is

proprietary under federal laws, state

laws and International treaty provi-

sions. Intellectual Property includes,

but is not limited to, inventions (pat-

entable or unpatentable), patents,

trade secrets, copyrights, software,

computer programs, and related

documentation and other works of

authorship. You may not infringe or

otherwise violate the rights secured

by the Intellectual Property. Moreo-

ver, you agree that you will not (and

will not attempt to) disassemble, de-

compile, reverse engineer, prepare

derivative works from, modify or

make any other effort to create

source code from the software. No

title to ownership in the Intellectual

Property is transferred to you

through purchase or possession of

the Phone or its components. All ap-

plicable rights of the Intellectual

Property shall remain with Siemens,

its affiliates, partners or suppliers.

Siemens will have no liability with re-

spect to any claim of patent infringe-

ment which is based upon the com-

bination of the Product or parts

furnished hereunder with software,

apparatus or devices not furnished

by Siemens, nor will Siemens have

any liability for the use of ancillary

equipment or software not fur-

nished by Siemens which is attached

to or used in connection with the

Product, The foregoing states the en-

tire liability of Siemens with respect

to infringement of patents by the

Product or any parts thereof.

Laws in the United States and other

countries preserve for Siemens cer-

tain exclusive rights for copyrighted

Siemens software, such as the exclu-

sive rights to reproduce and distrib-

ute copies of such Siemens software.

Siemens software may be used only

in the Product in which the software

was originally embodied when pur-

chased, and such software in such

Product may not be replaced, copied,

distributed. modified in any way, or

used to produce any derivative there-

of. No other use including, without

limitation, alteration, modification,

reproduction, distribution. or reverse

engineering of such Siemens soft-

ware or exercise of rights in such Sie-

mens software is permitted. No li-

cense is granted by implication,

estoppel or otherwise under Siemens

patent rights or copyrights.

137Ten Driving Safety Tips

right page (137) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005,

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Ten Driving Safety

Tips

Your Siemens wireless phone gives

you the power to communicate by

voice – almost anywhere, anytime.

But an important responsibility ac-

companies the benefits of wireless

phones, one that every user must

uphold.

When driving a car, driving is your

first responsibility. When using your

wireless phone behind the wheel of

a car, practice good common sense

and remember the following tips:

Get to know your phone and its features

such as speed dial and redial.

Carefully read your instruction man-

ual and learn to take advantage of

valuable features most phones offer

including, automatic redial and

memory dial – most phones can

store up to 99 numbers in memory

dial. Also, work to memorize the

phone keypad so you can use the

speed dial function without taking

your attention off the road.

When available, use a hands-free

device. b

A number of hands-free wireless

phone accessories are readily availa-

ble today. Whether you choose an

installed mounted device for your

phone or a speaker phone accessory,

take advantage of these devices if

they are available to you.

Position your phone within easy reach.

Make sure you place your wireless

phone within easy reach and where

you can grab it without removing

your eyes from the road. If you get

an incoming call at an inconvenient

time, let your voicemail answer it for

you.

Suspend conversations during hazard-

ous driving conditions or situations.

Let the person you are speaking to

know you are driving; if necessary,

suspend the call in heavy traffic or

hazardous weather conditions. Rain,

sleet, snow and ice can be hazard-

ous, but so is heavy traffic. As a driv-

er, your first responsibility is to pay

attention to the road.

Do not take notes or look up phone

numbers while driving.

If you are reading an address book or

business card while driving a car, or

writing a “to do” list, then you are not

watching where you are going. It’s

common sense. Don’t get caught in a

dangerous situation because you are

reading or writing and not paying

attention to the road or nearby

vehicles.

Ten Driving Safety Tips138

left page (138) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Dial sensibly and assess the traffic.

If possible, place calls when you are

not moving or before pulling into

traffic. Try to plan your calls before

you begin your trip, or attempt to co-

incide your calls with times you may

be stopped at a stop sign, red light or

otherwise stationary. But if you need

to dial while driving, follow this sim-

ple tip – dial only a few numbers,

check the road and your mirrors, then

continue.

Do not engage in stressful or emotional

conversations that may be distracting.

Stressful or emotional conversations

and driving do not mix – they are dis-

tracting and even dangerous when

you are behind the wheel. Make peo-

ple you are talking with aware you

are driving and if necessary, suspend

phone conversations that have the

potential to divert your attention

from the road.

Use your phone to call for help.

Your wireless phone is one of the

greatest tools you can own to pro-

tect yourself and your family in dan-

gerous situations – with your phone

at your side, help is only three num-

bers away. Dial 9-1-1 in the case of

fire, traffic accident, road hazard, or

medical emergency. Remember, it is

a free call on your wireless phone.

Use your phone to help others in

emergencies.

Your wireless phone provides you a

perfect opportunity to be a “good

Samaritan” in your community. If

you see an auto accident, crime in

progress or other serious emergen-

cies where lives are in danger, call

9-1-1, as you would want others to

do for you.

Call roadside assistance or a special

wireless non-emergency assistance

number when necessary.

Certain situations you encounter

while driving may require attention,

but are not urgent enough to merit a

call to 9-1-1. But you can still use

your wireless phone to lend a hand.

If you see a broken-down vehicle

posing no serious hazard, a broken

traffic signal, a minor traffic accident

where no one appears injured, or a

vehicle you know to be stolen, call

roadside assistance or other special

non-emergency wireless numbers.

Provided by the Cellular Telecommunica-

tions Industry Association (CTIA)

“The wireless industry reminds you to

use your phone safely when driving.”

For more information, please call

1 (888) 901-SAFE, or visit our Web site

at: www.wow-com.com

139End user license agreement

right page (139) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005,

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

End user license agreement

This Software License Agreement

("Agreement") is between You and

Siemens Information and Communi-

cation Mobile, LLC and/or one of its

affiliates ("Licensor"). The Agree-

ment authorizes You to use the Soft-

ware specified in Clause 1 below,

which may be included on Your

phone, stored on a CD-ROM, sent to

You by electronic mail, downloaded

from Licensor's Web pages or servers

or from other sources under the

terms and conditions set forth be-

low. This is an agreement on end us-

er rights and not an agreement for

sale. Licensor continues to own the

copy of the Software and any other

copy that You are authorized to

make pursuant to this Agreement.

Read this Agreement carefully be-

fore installing, downloading or using

the Software. Further, by installing,

downloading and/or using the Soft-

ware, You agree to the terms and

conditions of this Agreement.

1. Software.

As used in this Agreement, the term

"Software" means, collectively: (i) all

the software in Your phone, all of

the contents of the disk(s), CD-

ROM(s), electronic mail and its file

attachments, or other media with

which this Agreement is provided;

(ii) related Licensor or third party

software; (iii) digital images, stock

photographs, clip art or other artistic

works ("Stock Files") (iv) related ex-

planatory written materials

("Documentation"); (v) fonts (vi) up-

grades, modified versions, updates,

additions and copies of the Soft-

ware, if any, licensed to You by Li-

censor (collectively "Updates") and

(vii) any other possible documenta-

tion related thereto.

2. End user rights and use.

Licensor grants to You a non-exclu-

sive, non-transferable end user right

to install the Software or use the

Software installed on the phone. The

Software is licensed with the phone

as a single integrated product and

may be used with the phone only as

set forth in these licensing terms.

3. Limitations on end user rights.

(a) You may not copy, distribute, or

make derivative works of the Soft-

ware.

(b) You may not use, modify, trans-

late, reproduce or transfer the right

to use the Software or copy the Soft-

ware except as expressly provided in

this Agreement.

rent, lease or lend the Software; ex-

cept You may permanently transfer

all of Your rights as set forth in the

Agreement only as part of a perma-

nent sale or transfer of the phone,

provided the recipient agrees to the

terms of this Agreement.

End user license agreement140

left page (140) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

(d) You may not reverse engineer,

reverse compile, disassemble or oth-

erwise attempt to discover the

source code of the Software (except

to the extent that this restriction is

expressly prohibited by law) or cre-

ate derivative works based on the

Software.

(e) You shall not display, modify,

reproduce or distribute any of the

Stock Files included with the Software.

(f) You shall not display, modify, re-

produce or distribute any of the pre-

loaded content included with the

software unless permitted as stated

in the User Guide or in the prompts

in the Software. In the event that

You are allowed to display, modify,

reproduce or distribute certain parts

of the pre-loaded content, You shall

review the "Readme" files associated

with the pre-loaded content (con-

tained on the CD) to ascertain what

rights You have with respect to such

materials. Pre-loaded content may

not be used in the production of li-

belous, defamatory, fraudulent, in-

fringing, lewd, obscene or porno-

graphic material or in any otherwise

illegal manner. You agree that You

shall only use the pre-loaded content

in a manner that complies with all

applicable laws, including, but not

limited to, applicable restrictions

concerning copyright and other in-

tellectual property rights. You may

not register or claim any rights in the

pre-loaded content or derivative

works thereof.

(g) You agree that You shall only use

the Software in a manner that com-

plies with all applicable laws in the

jurisdiction in which You use the

Software, including, but not limited

to, applicable restrictions concern-

ing copyright and other intellectual

property rights.

4. Copyright.

Licensor and/or its software suppli-

ers and their respective affiliates

own the Software and all rights, in-

cluding without limitation including

proprietary rights therein, are pro-

tected by international treaty provi-

sions and other applicable national

laws of the country in which it is be-

ing used. The structure, organization

and code of the Software are the val-

uable trade secrets and confidential

information.

5. Multiple copies/updates.

If the Software supports multiple

platforms or languages, if You re-

ceive the Software on multiple me-

dia, of if You otherwise receive mul-

tiple copies of the Software, the

number of phones on which all ver-

sions of the Software are installed

shall be one phone. If the Software is

an Update to a previous version of

the Software, You must possess a

valid end user right to such previous

version in order to use the Update

and You may use the previous ver-

sion for ninety (90) days after You

receive the Update in order to assist

You in the transition to the Update.

141End user license agreement

right page (141) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005,

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

After such time You no longer have a

right to use the previous version, ex-

cept for the sole purpose of enabling

You to install the Update.

6. Commencement & termination.

This Agreement is effective from the

first date You use or install the Soft-

ware. Your end user rights automati-

cally and immediately terminate

without notice from Licensor if You

fail to comply with any provision of

this Agreement. In such event, You

must immediately delete, destroy or

return at Your own cost and ex-

pense, and without entitlement to

any refund of the purchase price, the

phone and the Software, and all re-

lated material to Licensor.

7. Except as expressly provided in the

limited warranty for the phone, you

acknowledge the Software is provid-

ed "as is" without warranty of any

kind express or implied. To the maxi-

mum extent permitted by applicable

law neither Licensor, Licensor's Soft-

ware suppliers or their respective af-

filiates, nor the copyright holders

make any representations or warran-

ties, express or implied, including

but not limited to the warranties of

merchantability or fitness for a par-

ticular purpose or that the Software

will not infringe any third party pat-

ents, copyrights, trademarks or oth-

er rights. There is no warranty by Li-

censor or by any other party that the

functions contained in the Software

will meet your requirements or that

the operation of the Software will be

uninterrupted or error free.

8. Not fault tolerant. The Software

may contain technoloy that is not

fault tolerant and is not designed,

manufactured, or intended for use in

environments or applications in

which the failure of the licensed

Software could lead direclty to

death, personal injury, or severe

physical or environmental damage

or financial loss.

9. Limitation of liability.

To the maximum extent permitted

by applicable law, in no event shall

Licensor or Licensor's Software sup-

pliers or their respecitve affiliates

and employees be liable for any lost

profits, revenue, sales, data or costs

of procurement of substitute goods

or services, property damage, per-

sonal injury, interruption of busi-

ness, loss of business information or

for any special, direct, indirect, inci-

dental, economic, cover, punitive,

special or consequential damages,

however caused and whether arising

under contract, tort, negligence, or

other theory of liability arising out of

the use of or inability to use the Soft-

ware, even if Licensor or its Software

suppliers are advised of the possibili-

ty of such damages. Because some

countries/states/jurisdictions do not

allow the exclusion or limitation of li-

ability, but may allow liability to be

limited, in such cases, the liability of

Licensor, its Software suppliers and

End user license agreement142

left page (142) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

their respective affiliates and em-

ployees shall be limited to, at Licen-

sor's option, either (a) return of the

price paid less a reasonable amount

for usage, or (b) repair or replacment

of the Software that does not meet

the limited warranty provided with

the phone and which is returned in

accordance with the requirements of

the limited warranty.

Nothing contained in this Agree-

ment shall prejudice the statutory

rights of any party dealing as a con-

sumer. Nothing contained in this

Agreement limits Licensor's liability

to You in the event of death or per-

sonal injury resulting from Licensor's

negligence if law prohibits such a

limitation. Licensor is acting on be-

half of its software suppliers and

their respective employees and affili-

ates for the purpose of disclaiming,

excluding and/or restricting obliga-

tions, warranties and liability as pro-

vided in this clause 9, but in no other

respects and for no other purpose.

10. Technical support.

Licensor has no obligation to furnish

You with technical support except as

agreed in writing between You and

Licensor in the Limited Warranty pro-

vided with the phone.

11. Export control.

The Software may be subject to ex-

port regulations of the United States

and other countries. You agree that

You shall comply with all applicable

export laws, restrictions and regula-

tions of the United States or foreign

agencies or authorities, and shall not

export, or transfer for the purpose of

re-export, any Software, product or

technical data received under this

Agreement or any Software or prod-

uct produced by use of such techni-

cal data, including processes and

services, in violation of any applica-

ble restrictions, laws or regulations,

or without all necessary approvals.

12. Applicable law & general provisions.

This Agreement shall be governed by

and construed in accordance with

the laws of the State of California

without regard to its conflicts of laws

rules. This is the entire agreement

between Licensor and You relating

to the Software and it supersedes

any prior representations, discus-

sions, undertakings, end user agree-

ments, communications or advertis-

ing relating to the Software.

143Menu tree

right page (143) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005,

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Menu tree

Contacts >All contacts

Groups

Online status

SIM

Filter

Call records >Missed calls

Calls received

Calls dialed

Delete records

Time/charges >Last call

All incom. calls

All outg. calls

Remain. units

Charge settings

Internet >URL/service provider

Download wiz.

Enter URL

Bookmarks

Internet

History

Saved websites

Camera >Take a photo

Record video

Messages >Create new >SMS

MMS

E-mail

Menu tree144

left page (144) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Messages >Inbox >SMS, MMS

E-mail

Draft >SMS,MMS

E-mail

Sent >SMS,MMS

E-mail

Outbox >SMS,MMS

Chat room E-mail

Voice mailbox

WAP push

CB services >Receive CB

Read new CB

Topic list

Auto display

Use Topic index

CB languages

Msg. archive >SMS,MMS

E-mail

Templates >Text modules

MMS templates

Msg settings >Zoom in

Emoticons

Save aft. send

General sett.

SMS setup

MMS settings

E-mail setup

WAP push set.

145Menu tree

right page (145) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005,

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Organizer >Calendar

Appointments

Tasks

Notes

Games Dictat.machine

Media player Time zones

Alarm clock Remote sync.

Extras >SIM services

My applications

Calc.

Unit converter

Online status

Sound recorder

Stopwatch

Countdown

Date calculator

My stuff My menu

Settings >Profiles

Ringtones >Volume

Calls

Messages

Organizer

Alarm clock

Chat room

Games

Startup tune

Shutdown tune

Pro Slide open

ProSlide close

Sound recorder

Menu tree146

left page (146) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Settings >Topics

Display setup >Background

Logo

Screensaver

Start up anim.

Shutdn anim.

Greeting

Large font

Lighting

Contrast

Silent alert

Phone Pilot

Connectivity >Bluetooth

EGPRS

EGPRS info

B-tooth setup

Online settings

Fax/data

Shortcuts >Short. Softkeys

Navigation keys

Number keys

Key tones

Call setup >Hide ID

Call waiting

Forward

Call screening

Any key

Minute beep

147Menu tree

right page (147) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005,

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Settings >Phone setup >Language

User dictionary

Key tones

Info tones

Auto off

Memory assis.

File system

License mgr.

Phone identity

Device manag.

Fact. settings

Clock >Time/date

Time zones

Time format

Date format

Start of week

Buddhist date

Show clock

Auto time

Security >Auto key lock

ProSlide lock

Direct call

Only ¡

PIN code

This SIM only

Call blocking

Menu tree148

left page (148) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:39)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Settings >Network >Line

Network info

Choose netwrk

Auto network

Preferred net

Band selection

Fast search

User group

Accessories >Car Kit

Headset

Upload via USB

149Index

right page (149) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005,

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Index

Accept list........................................... 57

Accessories....................................... 127

Addressbook

New entry ...................................... 35

Alarm ................................................. 95

Alarm clock....................................... 108

Alert calls from ................................... 82

All calls (diversion).............................. 81

All incoming (network barrings)..........88

Any key to answer .............................. 82

Appointments..................................... 94

Auto display

Clock .............................................. 86

Time/charges.................................. 41

Auto key lock ...................................... 87

Auto last number redial....................... 30

Band selection .................................... 90

Battery

Charging ........................................ 16

Inserting......................................... 15

Operating times......................17, 125

quality declaration........................ 124

Big letters ........................................... 72

Bluetooth ........................................... 75

Bookmarks (WAP) .........................65, 66

Browser .............................................. 66

Buddhist year...................................... 86

Calculator ......................................... 101

Calendar ............................................. 93

Call

Accepting/ending ........................... 30

Blocked .......................................... 88

Charges.......................................... 41

Conference..................................... 32

Diverting ........................................ 81

Ending............................................ 29

Menu ............................................. 33

Putting on hold............................... 31

Rejecting ........................................ 31

Toggling (swapping)....................... 31

Call back............................................. 30

Call divert ........................................... 81

Call settings........................................ 81

Call transfer ........................................ 33

Call waiting .................................. 31, 81

Calling................................................ 29

Calls received (call record) .................. 40

Camera .............................................. 42

Car kit

Setting........................................... 91

Care of phone .................................. 124

CB services ......................................... 64

Certificates......................................... 88

Charges.............................................. 41

Charges/units ..................................... 41

Charging the battery .......................... 16

Charging via USB ................................ 92

Clock.................................................. 86

Codes................................................. 23

Conference ........................................ 32

Connection profiles ............................ 78

Connectivity....................................... 75

Contrast ............................................. 72

Converter......................................... 102

Countdown ...................................... 106

Credit limit ......................................... 41

Currency converter........................... 103

Date format........................................ 86

Device manager ................................. 85

Dialling code ...................................... 29

Dialling with number keys .................. 29

Dictating machine .............................. 97

Digital Rights Management................. 20

Direct reply (SMS)............................... 50

Display

Illumination ................................... 72

Language....................................... 83

Symbols......................................... 13

Wallpaper....................................... 72

Divert................................................. 81

Driving safety ................................... 137

DTMF tones (tone sequences)............. 34

Duration/charges................................ 41

Earpiece volume................................. 29

EGPRS ................................................ 75

E-mail

Receiving/reading........................... 54

Settings ......................................... 55

Writing........................................... 53

Index150

left page (150) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005, 15:41)

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Emergency number ............................ 18

End user license agreement ..............139

Extras ............................................... 101

Factory settings ..................................85

Fast access.......................................... 79

Fast network search............................ 90

Flash .................................................. 43

Formatting (phone memory)............... 84

Forwarding (call) ................................ 33

Frequency range................................. 90

Handsfree talking................................ 31

Headset

Accessories................................... 127

Setting ........................................... 92

Hide ID ............................................... 81

Highlighting mode.............................. 22

Home network.................................... 89

Hotline ............................................. 122

Identity number (IMEI)........................ 84

IMEI number....................................... 84

Inbox.................................................. 48

Info tones ........................................... 83

Information services (CB) .................... 64

Inst. Message...................................... 58

International dialling code .................. 29

Internet .............................................. 66

Key tones......................................80, 83

Last number redial .............................. 29

Legal notices......................................... 3

Licence Manager................................. 84

Limit (duration/charges)...................... 41

Logo................................................... 72

Loss of phone, SIM card ....................125

Mailbox .............................................. 63

Maintenance of phone...................... 124

Media player..................................... 109

Memory assistant................................ 84

Menu tree......................................... 143

Message

CB.................................................. 64

E-mail ............................................ 53

MMS .............................................. 45

SMS ............................................... 45

Message memory full ......................... 51

Message type ..................................... 51

Microphone on/off.............................. 33

Minute beep....................................... 82

Missed calls (call record)..................... 40

Mobile Phone Manager..................... 115

Muting (microphone) ......................... 33

My menu.......................................... 106

My stuff ........................................... 112

Network

Barring........................................... 88

Connection .................................... 89

Settings ......................................... 89

Notes ................................................. 96

Number busy...................................... 30

Numbers dialled (call record) .............. 40

One number only ............................... 33

Only ¡............................................. 87

Operating times (battery) ........... 17, 125

Organiser ........................................... 93

PC connection .................................... 24

Personal greeting ............................... 72

Phone code ........................................ 23

Phone data....................................... 125

Phone ID (IMEI) .................................. 84

Phone number memo......................... 29

Phone number transmission on/off ..... 81

Phone Pilot......................................... 74

Phone setup ....................................... 83

Photo ................................................. 42

Changing ....................................... 23

Entering......................................... 18

Error ............................................ 121

Use ................................................ 23

PIN2................................................... 23

POP3 (e-mail) ..................................... 56

151Index

right page (151) of SL75 Hydra FUG, w/o ptt, us-en, A31008-H3300-A1-1-7619 (06.10.2005,

Template: X75, Version 2.2;VAR Language: am; VAR issue date: 050822

Preferred network............................... 89

Preventing accidental activation.......... 24

Product data ..................................... 125

Profiles

Phone............................................. 68

WAP ............................................... 67

Progress.............................................. 67

Prompt ............................................... 30

ProSlide lock ....................................... 87

Provider logo ......................................72

PUK, PUK2 ..........................................23

Putting a call on hold ....................31, 33

Questions & Answers ........................ 118

Receiving signal .................................. 19

Records .............................................. 40

Reject list............................................ 57

Reminder............................................ 30

Remote synchronisation...................... 99

Ringtone setting .................................70

Ringtones .....................................70, 74

Safety precautions ................................ 5

Screensaver ........................................ 72

Second phone number........................ 89

Security .............................................. 23

Service centre (SMS) ........................... 50

Service tones ...................................... 83

Setting time/date ................................ 86

Settings .............................................. 68

Short message (SMS) .......................... 45

Shortcuts............................................ 79

Shown in the display........................... 13

Shut down animation ......................... 72

Silent alert .......................................... 73

SIM card

Clearing barrings ............................24

Inserting......................................... 19

Problems ...................................... 119

SIM services (optional)...................... 101

Slider.................................................. 19

SMS

Lists................................................ 49

T9 input ......................................... 26

SMTP (e-mail) ..................................... 56

Software version................................. 84

SOS ................................................9, 18

Sound recorder......................... 104, 105

Sound recording............................... 104

Special characters............................... 25

Standard functions ............................. 22

Standby mode.................................... 20

Standby time.............................. 17, 125

Start up animation.............................. 72

Stopwatch........................................ 105

Switching microphone on/off.............. 44

Switching off the phone

Automatic...................................... 83

Manual .......................................... 18

Switching on (phone)......................... 18

Symbols ............................................. 13

Synchronisation ................................. 99

T9 text input ...................................... 26

Tasks.................................................. 96

Technical data .................................. 125

Text input

With T9 .......................................... 26

Without T9..................................... 25

Text module....................................... 28

Themes .............................................. 71

This SIM only...................................... 87

Time zones............................. 18, 86, 98

Toggling............................................. 31

Tone sequence (DTMF)....................... 34

Upper and lowercase letters (T9) ........ 25

User dictionary ................................... 83

User group ......................................... 90

Video playback ................................. 109

Voice mail (mailbox)........................... 63

Volume

Earpiece volume............................. 29

Profiles........................................... 68

Ringtone ........................................ 70

Wallpaper (display)............................. 72

WAP ................................................... 65

WAP push........................................... 57

BenQ Mobile and OHG SL75 Tri-Band GSM Mobile Phone with BT User Manual HYDRA FUG

BenQ Mobile GmbH & Co. OHG Tri-Band GSM Mobile Phone with BT HYDRA FUG

User Manual

Navigation menu

Namespaces

Views

Navigation
