Technical Bulletin

Bulletin No: Effective Date: Cancels: Page: 1 of

Subject:

This bulletin identies the Bendix

®

BA-921

®

and BA-922

®

compressor maintenance kits available from Bendix. The attached

matrix includes the Bendix

®

OE, service, and remanufactured assembly piece numbers and customer piece numbers,

where applicable. Reference items noted are not available as service parts from Bendix Commercial Vehicle Systems.

For additional information please visit www.bendix.com or contact the Bendix TechTeam by calling 1-800-AIR-BRAKE

(1-800-247-2725). Representatives are available to assist you Monday - Friday, 8:00a.m. - 6:00p.m. EST.

© 2014 Bendix Commercial Vehicle Systems LLC, a member of the Knorr-Bremse Group • 3/2014 • All Rights Reserved.

TCH-001-063 3-24-2014 Same dated 10-4-2011 8

BENDIX® BA-921® AND BA-922® COMPRESSOR MAINTENANCE KITS - UPDATED MATRIX

Caterpillar Engines

Engine

Platform:

ACERT Engines (Pre-2007)

3126, C7 & C9 C11 & C13

Bendix® BA-921® Compressors

Compressor Piece Numbers

Bendix OE for Caterpillar (Reference) 5010803 K048932 K066809 5015207 K048935 K066810 5011441 5014177 5014401 K048938 K066811

Caterpillar OE (Reference) 191-6521 353-7135 385-0935 246-7095 353-7134 385-0933 223-3636 253-1736 255-4160 353-7136 385-0936

Bendix Service for Caterpillar

(Reference) 5010804 K048933 K066829 5015208 K048936 K066830 5012510 5014180 5014402 K048939 K066831

Bendix Reman for Caterpillar

(Reference) 5010805 K048934 K066836 5016858 K048937 K068004 5012459 5014235 5014427 K048940 K066837

Bendix Service 801285 801285 801285 801955 801955 801955 801465 801798 801826 K056649 K056649

Bendix Reman 5010806 5010806 5010806 5016859 5016859 5016859 5012464 5014236 5014428 K056647 K056647

Service Kit Piece Numbers

Cylinder Head Gasket Kit 5008558 5008558 5008558 5008558 5008558 5008558 5008558 5008558 5008558 5008558 5008558

Cylinder Assembly

Replacement Kit K023601 K023601 K023601 K023601 K023601 K023601 K023600 K023600 K023600 K023600 K023600

Unloader Kit -

Reference (See note 1) 335-6328 335-6328 335-6328 335-6328 335-6328 335-6328 335-6328 335-6328 335-6328 335-6328 335-6328

Compressor Seal Kit

(w/ engine seal) 5012367 5012367 5012367 5012367 5012367 5012367 5012369 5012369 5012369 5012369 5012369

Compressor Seal Kit

(w/out engine seal) 5008559 5008559 5008559 5008559 5008559 5008559 5008559 5008559 5008559 5008559 5008559

Governor Adapter Kit 5014183 5014183 5014183 5014183 5014183 5014183 5014183 5014183 5014183 5014183 5014183

Governor Hardware Kit K032046 K032046 K032046 K032046 K032046 K032046 K032046 K032046 K032046 K032046 K032046

Inlet Check Valve 801580 801580 801580 801580 801580 801580 801592 801592 801592 801592 801592

Bendix® Safety Valve Kit 801116 K105720 K105720 801116 K105720 K105720 801116 801116 801116 K105720 K105720

Numbers shown in blue and italics are for reference only and are not available from Bendix as an aftermarket part.

1. Unloader kit must be purchased through Caterpillar.

Caterpillar Engines

Engine

Platform:

ACERT Engines (Pre-2007) Tier 4 Industrial Apps

C15 & C18

C7 & C9

(BM Gear) C13 C15 & C18

C18

(2.8 BM Gear)

Bendix® BA-921® Compressors Bendix® BA-921® Closed Room Compressors

Compressor Piece Numbers

Bendix OE for Caterpillar (Reference) 5011427 K020283 K048941 K066812 K046449 K066808 K045107 K066806 K045108 K066807 K055770 K066813

Caterpillar OE (Reference) 223-3637 304-9991 353-7137 385-0937 351-7083 385-0938 351-7089 385-0939 351-7086 385-0940 360-4138 385-0944

Bendix Service for Caterpillar

(Reference) 5012531 K020285 K048942 K066832 K058843 K066828 K058841 K066826 K058842 K066827 K058844 K066833

Bendix Reman for Caterpillar

(Reference) 5012532 K020284 K048943 K066838 — — — — — — — —

Bendix Service 801463 801463 801463 801463 — — — — — — — —

Bendix Reman 5012533 5012533 5012533 5012533 — — — — — — — —

Service Kit Piece Numbers

Cylinder Head Gasket Kit 5008558 5008558 5008558 5008558 K023764 K023764 K023764 K023764 K023764 K023764 K023764 K023764

Cylinder Assembly

Replacement Kit K023600 K023600 K023600 K023600 K045143 K045143 K045143 K045143 K045143 K045143 K045143 K045143

Unloader Kit -

(Reference) (See note 1) 335-6328 335-6328 335-6328 335-6328 335-6328 335-6328 335-6328 335-6328 335-6328 335-6328 335-6328 335-6328

Compressor Seal Kit

(w/ engine seal) 5012369 5012369 5012369 5012369 5012367 5012367 5012369 5012369 5012369 5012369 5012369 5012369

Compressor Seal Kit

(w/out engine seal) 5008559 5008559 5008559 5008559 5008559 5008559 5008559 5008559 5008559 5008559 5008559 5008559

Governor Adapter Kit 5014183 5014183 5014183 5014183 5014183 5014183 5014183 5014183 5014183 5014183 5014183 5014183

Governor Hardware Kit K032046 K032046 K032046 K032046 K032046 K032046 K032046 K032046 K032046 K032046 K032046 K032046

Inlet Check Valve 801592 801592 801592 801592 — — — — — — — —

Bendix® Safety Valve Kit 801116 801116 K105720 K105720 K105705 K105705 K105705 K105705 K105705 K105705 K105705 K105705

Numbers shown in blue and italics are for reference only and are not available from Bendix as an aftermarket part.

1. Unloader kit must be purchased through Caterpillar.

Caterpillar® Engines

Engine Platform:

ACERT Engines

CAT C11 & C13 CAT C15 & C18

Bendix® BA-922® Compressor

Compressor Piece Numbers

Bendix OE for Caterpillar (Reference) 5011624 5011625

Caterpillar OE (Reference) 257-9346 226-9580

Bendix Service for Caterpillar

(Reference) 5013063 5013070

Bendix Reman for Caterpillar

(Reference) 5013064 5013071

Bendix Service 801594 801595

Bendix Reman 5013058 5013059

Service Kit Piece Numbers

Cylinder Head Assembly Kit K033300 K033300

Cylinder Head Gasket Kit 5014472 5014472

Unloader Kit (See note 1) 335-6328 335-6328

Compressor Seal Kit

(w/ engine seal) 5012369 5012369

Compressor Seal Kit

(w/out engine seal) 5008559 5008559

Governor Adapter Kit 5014183 5014183

Governor Mounting Hardware Kit K032046 K032046

Bendix® ST-4™ Safety Valve 801116 801116

1. Unloader kit must be purchased through Caterpillar.

Numbers shown in blue and italics are for reference only and are not available from Bendix as an aftermarket part.

John Deere Engines

Engine Platform: JD 6.8 JD 9.0 JD 13.5

Bendix® BA-922® Compressors

Compressor Piece Number

Bendix OE for

John Deere (Reference) 5016044 5016380 5016381

Bendix Service for

John Deere (Reference) 5019611 5019611 5019611

Bendix Identied Service Assembly 802158 802158 802158

Bendix Identied Reman Assembly 5016389 5016389 5016389

Service Kits

Cylinder Head Gasket Kit 5014472 5014472 5014472

Unloader Kit 5014473 5014473 5014473

Governor Adapter Kit 5014183 5014183 5014183

Governor Hardware Kit K032046 K032046 K032046

Compressor & Engine Interface Seal Kit 5018827 5018827 5018827

Compressor Seal Kit 5008559 5008559 5008559

Bendix® ST-4™ Safety Valve 800534 800534 800534

Numbers shown in blue and italics are for reference only and are not available from Bendix as an aftermarket part.

Detroit™ Diesel Engines

Engine Platform:

DDC Low Emissions S60

(Pre-2007) DDC 2007 S60 DDC 2007 HDEP DDC 2010 HDEP

Bendix® BA-921® Compressors

Comments

Cast Iron Cylinder

Head

Rear Oil

Drain Back

Aluminum

Cylinder Head

Closed Room

Head

Closed Room

Head

Closed Room

Head

Compressor Piece Number

Bendix OE for DDC (Reference) 5012794 5016612 5018514 5018652 K020801 K034111

Bendix Service for DDC

(Reference) 5010822 5016613 5018522 5018654 K031986 K035911

Bendix Reman for DDC (Reference) 5010823 5016614 5018523 5018655 K031987 K035912

DDC Identied Reman Kit

(Reference) 5014382 5016799 5018516 5018653 — —

Bendix Identied Service 801287 802767 802767 802789 K095740 —

Bendix Identied Reman 5010824 5018485 5018485 5018653 K095124 —

Service Kit Piece Numbers

Cylinder Head Gasket Kit 5008558 5008558 5008558 K023764 K023764 K023764

Unloader Kit K109119 K109119 K109119 K109119 K109119 K109119

Governor Adapter Kit 5014183 5014183 5014183 5014183 5014183 —

Governor Mounting Hardware Kit K032046 K032046 K032046 K032046 K032046 —

Compressor Seal Kit

(w/ engine seal) 5012371 5012371 5012371 5012371 — —

Compressor Seal Kit

(w/out engine seal) 5008559 5008559 5008559 5008559 — —

Service Inlet Check Valve 802192 802192 802192 — — —

Bendix® ST-4™ Safety Valve 800534 800534 800534 K105705 K105705 K105705

Numbers shown in blue and italics are for reference only and are not available from Bendix as an aftermarket part.

Detroit™ Diesel Engines

Engine Platform:

DDC S50

(Pre-EGR)

DDC S60

(EGR)

Bendix® BA-922® Compressors

Compressor Piece Number

Bendix OE for DDC (Reference) 5011616 5013262

DDC OE Number (Reference) —23533382

Bendix Service for DDC (Reference) 5013693 5012893

DDC Service Number Kit (Reference) —23533382

Bendix Reman for DDC (Reference) 5013694 5012894

DDC Reman Number Kit (Reference) — R23533382

Bendix Identied Service 801732 801535

Bendix Identied Reman 5013695 5012895

Service Kit Piece Numbers

Cylinder Head Gasket Kit 5014472 5014472

Unloader Kit 5014473 5014473

Governor Adapter Kit 5014183 5014183

Governor Hardware Kit K032046 K032046

Compressor Seal Kit 5008559 5008559

Engine Interface Seal Kit 5012370 5012371

Bendix® ST-4™ Safety Valve 800534 800534

Numbers shown in blue and italics are for reference only and are not available from Bendix as an aftermarket part.

Navistar® Engines

Engine Platform Pre-2010 MaxxForce™ Engines (G11/G13) 2010 MaxxForce™ 11/13L International® 15L Engine

Compressor Model

Bendix® 360cc

DLU

Water Cooled

Crankcase

Bendix® 720cc

DLU

Water Cooled

Crankcase

Bendix® 360cc

DLU

Water Cooled

Crankcase

Bendix®

BA-921® SMC

(Head Unld)

Bendix® 720cc

DLU

Water Cooled

Crankcase

Bendix®

BA-921® CR

Thru-drive

Bendix®

BA-922®

Thru-drive

Compressor Piece Numbers

Bendix OE for International®

(Reference) K015948 K015965 K028383 K042162 K048297 K041109 K041741

International (Reference) 51.54100-7121 51.54100-7114 3624499C91 3709920C92 3624500C92 3861777C91 3861778C91

Bendix Service K025822N00 — K025822N00 K044642 K048595 K055513 K055603

Bendix Reman — — — K075155 — K055514 K055604

Service Kit Piece Numbers

Complete Gasket Kit K026807 K026808 K026807 — K026808 — —

Safety Valve Kit — K026809 K026809 K105705 K026809 800534 800534

Cylinder Head Gasket Kit — — — K023764 — K023764 5014472

Unloader Kit — — — K109119 — K109119 5014473

Governor Adapter Kit — — — — — 5014183 5014183

Governor Mounting

Hardware Kit — — — K032046 — K032046 K032046

Compressor Seal Kit

(w/ engine seal) — — — — — 5012369 5012369

Compressor Seal Kit

(w/o engine seal) K051352 K051352 K051352 K051352 K051352 5008559 5008559

Numbers shown in blue and italics are for reference only and are not available from Bendix as an aftermarket part.
