DC 5330
User’s Manual
Copyright
Copyright (c) 2003 by BenQ Corporation. All rights reserved. No part of this publica-
tion may be reproduced, transmitted, transcribed, stored in a retrieval system or trans-
lated into any language or computer language, in any form or by any means, electronic,
mechanical, magnetic, optical, chemical, manual or otherwise, without prior written per-
mission from BenQ Corporation.
Brands and product names are trademarks or registered trademarks of their respective
companies.
Disclaimer
BenQ makes no warranty of any kind with regard to this material, including, but not lim-
ited to, the implied warranties of merchantability and fitness for a particular purpose.
BenQ assumes no responsibility for any error that may appear in this document. BenQ
makes no commitment to update nor to keep current the information contained in this
document.
Taking care of your camera
• Do not use your camera over the following environmental range: temperature: O
C
to 40
C, relative humidity: 45% ~ 85%.
• Do not use or store your camera in environments listed below:
Direct sunlight.
High humidity and dusty places.
Next to the air conditioner, electric heater or the other heat sources.
In a closed car that is directly under the sun.
Avoid shaky places.
• If your camera becomes wet, wipe it with dry cloth as soon as possible.
• Salt of seawater may cause severe camera damage.
• Do not use organic solvents, such as alcohol, etc., to clean your camera.
• If the lens or viewfinder is dirty, please use the lens brush or soft cloth to clean the
lens. Do not touch the lens with your fingers.
• To prevent electrical shock, do not attempt to disassemble or repair your camera by
yourself.
• Water may cause a fire or electric shock. Therefore, please store your camera in a dry
place.
• Do not use your camera outdoors when it is raining or snowing.
• Do not use your camera in the water.
• If the foreign substance or water gets in your camera, please tum the power off imme-
diately and disconnect the batteries and the transformer. Remove the foreign sub-
stance or water, and send it to the maintenance center.
• Transfer the data to the computer as soon as possible to avoid losing your image data.
BenQ DC 5330 Table of Contents
I
1. Touring your DC 5330 .................................1
1.1. Checking package contents ...............................1
1.2. Parts of the DC 5330 and their names ...........1
1.2.1. Front View ......................................................................1
1.2.2. Rear View ........................................................................2
1.2.3. Top View .........................................................................2
1.2.4. Bottom View ..................................................................2
1.2.5. Mode Dial and Focus Range .......................................2
2. Preparing your DC 5330 for using .............3
2.1. How to Switch On or Off The Camera .........3
2.2. Loading the battery and SD Card: ..................3
2.3. Basic Settings: ......................................................4
3. Using the DC 5330 ........................................5
Working Mode .............................................................6
3.1.Video Mode ...........................................................6
3.2. Capture Mode ......................................................7
3.2.1. Shooting images .............................................................7
3.2.2. FLASH Setting ................................................................9
3.2.3. Self Timer ........................................................................9
3.2.4. Shooting Continuously Setting ...................................9
3.2.5. Capture Mode Setup ....................................................10
3.3. Playback Mode ......................................................12
3.4. Macro Mode ..........................................................14
3.5. Dsc Setup Mode ...................................................15
4. PC dependent features .................................17
4.1. Installing digital camera software .....................17
4.2. The Software of this Installation CD ..............18
4.3. Downloading the Image(s) .................................19
BenQ DC 5330 User’s Manual
1
1. TOURING YOUR DC 5330
1.1. Checking package contents
The package should include the following items:
1.2. Parts of the DC 5330 and their names
1.2.1. Front View
DC 5330 digital camera Camera pouch USB cable
Battery DC 5330 software CD-ROM
Hand Strap
Battery Charger
Shutter Button Viewfinder
Auto-Focus Led
DC-In & USB
Connector
Microphone
Mode Dial
Flash
Self-timer Indicator LED
Handstrap Hook Zoom Lens
Hand Stop
BenQ DC 5330 User’s Manual
2
1.2.2. Rear View
1.2.3. Top View
1.2.4. Bottom View
1.2.5. Mode Dial and Focus Range
Note
Use only the specified battery or AC power adapter specified (5V 2A) for use with
this camera. Other power sources may cause fire.
TFT LCD Monitor
Menu Slection Button
Five-way Switch
Power/Flash LED
Display Button
Zoom Button
Viewfinder
Shutter Button
Mode Dial
Power Button
Speaker
Battery & SD Card
Compartment
Tripod mount
Docking Connector
Mode Dial Video Mode ( )
Capture Mode ( )
Playback Mode ( )
Macro Mode ( )
Setup Mode ( )
BenQ DC 5330 User’s Manual
3
2. PREPARING YOUR DC 5330 FOR USING
2.1. How to Switch On or Switch Off The Camera
2.2. Loading the battery and SD Card:
Note
The backside LED indicator will remain green while the power is turned ON.
1. Locate the power button on top of the camera.
2. Press the power button down to turn the
camera ON or OFF.
Power ON/OFF Button
This camera uses a Li-ion battery. The battery and SD card share the same compartment
and cover.
1. Slide the battery/SD Card cover in the direction
of the arrow, then lift to open.
2. Load the included battery in the compartment.
3. Insert the SD card into the slot.
4. Close the cover.
Battery Power Status
Full
Middle
Low
Empty
CAUTION!
1. Fully charge the battery before its first use.
2. To improve battery performance, replace installed battery at the same time and keep
away from heat.
3. To discard battery, refer to the index of the battery manufacturer.
4. Battery should be inserted in the battery compartment with the "+" and "-" sides
facing correctly.
BenQ DC 5330 User’s Manual
4
2.3. Basic Settings:
Upon turning the camera ON, a "BenQ logo" will appear on the LCD display. Turn the
mode dial to the DSC Setup Mode. Please proceed with the following settings:
Language Preference Setting
There are a total of nine languages to choose from to interact with this camera. English will
be the default language. Please refer to DSC Setup Mode. (page 15)
Date and Time Setting
Please refer to the Date and Time setting under DSC Setup Mode. (page 15)
Formatting the SD Card
To format the internal memory, withdraw the SD Card from the camera. To format, please
refer to “Erase Pictures” on page 13.
Note
This camera is equipped with a built-in flash memory. The image(s) can be stored in the
built-in memory or in a memory card if used. Please note that if a memory card is not
inserted, all operations will affect only the built-in flash memory. If the memory card is
inserted, all operations will affect only the memory card but not the built-in flash memory.
Note
1. Upon loading new battery, users will need to reset their Basic Settings.
2. Do not open the battery/SD card cover or remove the battery when the camera is in its
ON status. Only remove the battery and SD card when the camera is not in use, or in
its OFF status.
3. If you do not plan on using the camera for a long period of time, please remove the
battery and SD card.
4. Battery charges through the charger.
5. Camera will draw power from DC-in when used with the AC-Adapter.
Upon turning the camera ON, a "BenQ
logo" will appear on the LCD display.
BenQ DC 5330 User’s Manual
5
3. USING THE DC 5330
This section describes the five modes included in this camera. An in-depth coverage of these
modes will be further described. Here are the five main functions of this camera:
Camera Mode Function Setting Page
Video Mode Record Movies page 6
Capture Mode 1. Resolution
2. Image Quality
3. Color Effect
4. White Balance
5. Scene
6. Metering
7. Sharpness
8. EV Adjust
9. ISO
page 7
Playback Mode 1. Erase Picture
2. Protect Picture
3. DPOF
4. Slide Show
5. Voice Memo
page 12
Macro Mode 1. Resolution
2. Image Quality
3. Color Effect
4. White Balance
5. Scene
6. Metering
7. Sharpness
8. EV Adjust
9. ISO
page 14
DSC Setup Mode 1. Date and Time
2. Auto Power Off
3. DPOF
4. Slide Show
5. Sound Effect
6. Languages
7. TV-out
8. Restoring
page 15
Note
Press the display button once to delete the icons from the LCD display. To turn the LCD
display simply press the display button a second time. To save your battery power, it is best
to not leave your display ON for a long period of time.
BenQ DC 5330 User’s Manual
6
Working Mode
3.1.Video
Mode
Video Mode allows you to use the camera as a movie recorder, and set the self-timer
for recording purpose.
1. Turn the Mode Dial to the Video Mode
2. To start recording a movie, press the shutter button. The camera will start
checking whether the memory is sufficient to record a movie. If the memory is full,
a warning sign will display on the LCD, and will automatically exit the movie
recording state.
3. If there are no warning messages with memory problems, the camera will start
recording itself. To stop recording, press the shutter button again.
self timer: To set the self timer under the video mode, press the right button
once to activate the self timer. You will have ten seconds to get ready.
The countdown will be displayed on the LCD and followed by a beep
sound.
Note
The length is based on the capacity of your SD card and internal memory.
Note
Users can still zoom in and out while searching for a subject, but when the actual
recording is being made, zooming in and out will not be possible.
* The icons can be removed from the display by pressing
the menu button once.
Battery Status
Date or Time
Remaining Time
Video Mode
Zoom Bar
BenQ DC 5330 User’s Manual
7
3.2. Capture Mode
Capture mode will allow you to shoot single and continuous images, set your flash
and self-timer. Depending on the environment and setting, the camera’s settings will
work accordingly. To exit the setting menu, simply press the menu button.
3.2.1. Shooting images
1. Under Capture Mode, press the shutter button. The camera will start checking
whether the memory is sufficient to store the image. If it is full, a warning “Memory
Full” icon will display on the LCD.
2. Once the picture is taken, you can erase the image under instant review. user can
protect image when in playback mode
3. If you decide to erase this image, press down. An erase icon will appear on the
LCD, press OK to achieve this function.
Basic Shooting
1. Turn the mode dial to the capture mode
2. Look into the viewfinder/LCD and try to align your
subject in the crop mark.
3. When you are set, press the shutter button once.
Auto-Focus Function
Under Auto-Focus, the camera lens focuses automatically when the shutter release is
pressed halway. To activate Auto-Focus, please follow these steps:
1. Crop mark is white in normal situation. Press half shutter
to activate auto focus. Crop mark turns green when
focused. If fail, crop mark is red.
2. Then, fully press the shutter button to take the picture.
BenQ DC 5330 User’s Manual
8
Zooming In/Out
This camera has 4 x digital zoom. The zoom bar located on the left side of the LCD
display, informs users of the zoom status while the zoom in or out button is pressed.
The zoom lens can automatically protrude and retract.
1. Once you have aligned your subject in the LCD display, press the zoom in or out
button to select your preferred distance.
2. The picture can be zoomed in up to four times the original size.
Note
4 x digital zoom are all supported in PLAYBACK Mode.
Resolution
Image Quality
EV Icon
Continuous
Shot
Self Timer
Date or Time
Battery Status
Remaining Number
of Pictures
Zoom Bar
Flash
White Balance
* The icons can be removed from the display by pressing
the display button once.
Metering
ISO (100/200)
Capture Mode
BenQ DC 5330 User’s Manual
9
3.2.2. FLASH Setting
To set the Flash, press the Five-Way Switch to the Left to select the desired Flash
setting. You will have the four types of Flash settings: Flash Off, Auto Red-eye
reduction, Flash Force On, and Night. Once you’ve set your Flash setting, proceed
with your picture taking.
3.2.3. Self Timer
To set the self timer under the capture mode, please press Five-Way Switch to the
Right button once to activate the self timer. You will have ten seconds to get ready
for your pose. The countdown number will be displayed on the LCD as well
followed by a beep sound.
3.2.4. Shooting Continuously Setting
Pictures can be shoot in successive orders.
1. Keep pressing the right button twice until Shooting Continuously icon appears on
the LCD Display.
2. Keep pressing the shutter button to activate Shooting Continuously. Then
release the shutter after the three sequences have been taken.
Flash Off The Flash will not fire.
Auto Red-eye
reduction
The Flash will fire depending on the
light source. Red eye deduction will
also be active when needed. (Flash
will blink twice, picture will be shot
when the second flash is fired.)
Flash Force On The Flash always fire with every shot.
Night (Slow) The camera extends the mechanical
shutter action, and allow flash delay.
Note
Shooting Continuously function will not be available under resolution 5.5M setting.
BenQ DC 5330 User’s Manual
10
3.2.5. Capture Mode Setup
1. Turn the mode dial to Capture Mode.
2. To enter/exit Capture Mode Setup, press the menu button.
3. Once you are in the Capture Mode Setup, you will be able to adjust the following
settings.
4. To select each individual function settings, press the UP or DOWN arrow.
Function Selection Definition
Resolution Users can select from the
following resolution:
VGA
1.3M
3.0M
5.5M
The size of the
picture. The default
size is 3.0 M, but users
will have the option of
choosing VGA 1.3 M,
3.0 M, or 5.5 M
Image Quality Users can select from the
following quality:
Best (Default)
Better
Basic.
The quality of the
picture. The default is
Best.
Color Effect User can select from the
following color tones:
Normal (default)
Sepia
Black and white
It is the tone that will
be applied in the
picture. The default is
Normal.
Metering
Users can select from the
following metering:
Center
Spot
Matrix
It calculates the best
overall exposure
value. The default is
Center.
BenQ DC 5330 User’s Manual
11
White Balance Users can select the
following white balance:
Auto
Shade
Sun
Tungsten
Fluorescent
It adjusts the relative
brightness under
different condition.
The default is Auto.
Sharpness
Users can select the
following sharpness:
Normal
High
Low
Enhance of edge detail.
The default is Normal.
EV Adjust Users can select the
following EV adjust:
from EV+2.0~ toEV -2.0, in
EV 0.5 step increase
This function allows
users to control the
exposure value, to
either lighten or
darken images the
camera is trying to
focus. The default is 0.
Scene Users can select the
following scene:
Night
Portrait
Landscape
Night Portrait
Off
This pre-defined
settings make it even
more convient for
users to take pictures.
Users will not need to
make any further
adjustment to the
camera. The scenes
are already pre-
defined.
ISO Users can select the
following ISO setting:
100
200
Auto
It adjusts the
sensitivity of the
camera. The higher
the number, the more
sensitive it is to light.
The default is Auto.
BenQ DC 5330 User’s Manual
12
3.3. Playback Mode
This mode will allow you to replay/view your images or video. It can also protect
your desired images, set DPOF, slide show and voice memo.
Note
The Memory Capacity will be changed according to the resolution and image quality you
set, please refer to below table for the relative numbers, which will be changed a little in
different photo backgrounds.
Resolution
(based on 16 MB memory)
Image Quality
(Best)
Image Quality
(Better)
Image Quality
(Basic)
2720 x 2040 (5.5M) 8 12 16
2048 x 1536 (3.0M) 14 21 28
1280 x 960 (1.3M) 36 55 73
640 x 480 (VGA ) 146 218 291
Resolution
Image Quality
EV Adjust
Date or Time
Battery Status
Remaining
Number of
Pictures
Zoom Bar
Strobe
Status
White Balance ISO
BenQ DC 5330 User’s Manual
13
Displaying Thumbnails
1. Turn the Mode Dial to Playback Mode.
2. Press the display button two times to thumbnails in sets of nine.
3. Use the Five-Way Switch to change the image selection.
4. Press OK button to magnify images to standard size.
5. Press the left or right button to view other images.
Display with Digital Zoom
The camera has 4x digital zoom.The picture can be zoomed up to four times the
original size. The five-way switch controls left, right, up, and down of the image. Press
the OK button to quit Digital Zoom Display.
1. Turn the MODE DIAL to Playback Mode.
2. To enter/exit Playback Mode Setup, press the Menu button.
3. While you are in the Playback Mode menu setting, use the Five-Way Switch to select.
Note
1. The icon information can be removed by pressing the menu button once.
2. Thumbnail can be viewed after the display button twice.
3. To turn off the LCD, press the display button three times.
Function Setting Selection Definition
Protect Picture Users can select the fol-
lowing:
Protect all
Uprotect current
Unprotect all
Protect current
Protection setting for your
pictures against accidental
erasure. Once you are set,
press OK to confirm.
Slide Show Users can select from:
From current (picture)
From first (picture)
From last (picture)
Pictures will be displayed in
an orderly way. While you
are in the Slide Show set-
ting, press OK to start/exit
slide show.
Erase Pictures Users can select from:
Current
All
Format
Erasing options for your
pictures. When formatting,
a warning message will
appear. Press the OK but-
ton to confirm. Format will
permanently remove all
data such as internal mem-
ory/ SD card.
BenQ DC 5330 User’s Manual
14
3.4. Macro Mode
Macro mode is best used for taking close-up images with franges from 15-50 cm.
Digital Print Order
Format or DPOF
Users can select from:
Frame Set
Reset all
It is a standard for printing
the pictures directly from
the SD card. Pictures can
be printed on printers
compatible with the DPOF
standard.
frame set --> set for one
reset all --> set for all
Voice Memo You are allowed 20 sec-
onds to record voice
memo. Users can select
from:
Record
Erase
Play
1. Select the picture you
wish you add voice memo.
2. Press menu button.
3. Choose Voice Memo.
4. Select record
4. Press the shutter to start
or end recording.
Resolution
Picture Quality
EV Icon
Continuous
Shot
Date or Tim
e
Battery Status
Remaining Number
of Pictures
Flash
White Balance
* The icons can be removed from the display by pressing
the display button once.
Metering
ISO (100/200)
Scene
Macro Mode
BenQ DC 5330 User’s Manual
15
3.5. Dsc Setup Mode
Under this mode, you will be able to set your desired settings. There are a total of
eight different settings.
1. Turn the mode dial to enter the DSC Setup Mode.
2. Select the type of setup you want to perform by pushing the left or right button.
Press the UP or Down arrow to select the function setting.
Function Setting Selection Definition
Date and Time Users can select to set:
Time (hh:mm:ss)
Date (yy/mm/dd)
Reset date and time when
change battery.
Auto Power Off Users can select the fol-
lowing minutes to Auto
Power Off the camera.
This setting automatically
turns off the camera. (Prior
to shutting off, the LCD
will shut itself automati-
cally)
DPOF Users can select the num-
ber of copies of
images they want to print,
and whether turn the date
and the no. of files on or
off in the picture.
It is a standard for printing
the pictures directly from
the SD card. Pictures can
be printed on printers
compatible with the SD
card. Users can set certain
pictures to DPOF.
Sound Effect
TV-out
Slide Show Order
Date and Time Restoring
Auto Power Off
Languages
DPOF
BenQ DC 5330 User’s Manual
16
Slide Show Users can select the:
Interval
Repeat
Direction
Under this setting, users
can set the number of sec-
onds they want the slide
show to proceed per slide,
repeat the show or not,
and the direction where
these slides should pro-
ceed.
Sound Effect Users can select either
on or off
This function allows users
to turn the sound ON or
OFF.
Languages Users can select from the
following languages:
Deutsch
English
French
Italian
Japanese
Korean
Spanish
Simplified Chinese
Traditional Chinese
There are a total of nine
languages you can choose
to navigate this camera.
Camera will keep your lan-
guage setting but users will
need to reset when change
battery. Press the Up or
Down button to select.
Press OK to confirm.
TV-Out Users can select from:
NTSC
PAL
Depending on where your
location, different region
requires different system
for TV-out function. Please
use the docking station
(Optional) to set the TV-
Out. Press the Up or
Down button to select.
Press OK to confirm.
Restoring Reset back to default. To revert the setting back
to the default setting.
Press the OK if you want
to, if not, press the “right”
or “left” button to continue
next setting. When restor-
ing is completed, "done"
will appear on the LCD.
BenQ DC 5330 User’s Manual
17
4. PC DEPENDENT FEATURES
Preparations
To use the PC dependent functions, you need to install your digital camera software
and connect the camera to your PC.
4.1. Installing digital camera software
• If your operation system is Windows 98, please setup the DC 5330 driver first, if
the operation system is Windows ME/2000/XP, then it's not necessary for you to
setup driver in advance.
• It's recommended that you setup driver and software before connecting digital still
camera to your PC for smooth installation. Normally, a software installation menu
appears automatically after this installation CD is inserted into your CD-ROM
drive.
• Click on each item to start installing the software program of your choice. If the
menu did not appear, please browse the CD and find a program file named
"setup.exe" in the root directory and double-click on it. The menu will appear. If
you want to know the content of this CD and install software manually, please
refer to the descriptions of the CD content below.
BenQ DC 5330 User’s Manual
18
4.2. The Software of this Installation CD
Software Description
1. PhotoBase Arcsoft PhotoBase, for you to find and
organize your media-files efficiently. You can use it
to creat a slide show, a web album, or a video
postcard, then sharing these media-files with your
friends through internet.
2. PhotoImpression ArcSoft PhotoImpression, it is an easy-to-use
photo editing and creative design program. You
can edit and retouch your photos, then add
special effects or place them in cards, calendars,
frames and fantasy templates. PhotoImpression
also includes a wide variety of printing options.
3. VideoImpression Arcsoft Video Impression, for you to edit
and combine the video files. New videos can be
created by existing video, animation, and image
files,quickly and easily create desktop video
presentations for use at home, business or on
the internet.
4. PhotoPrinter Pro. Arcsoft Photo Printer this versatile
printing utility lets you print out casually, it can be
several different images on a single sheet of
paper. It's as simple as opening your image,
selecting from an assortment of templates and
clicking Print.
5. Microsoft DirectX Microsoft DirectX, an all-in-one and closs-
platform media tool.
6. Acrobat reader Adobe Acrobat Reader, it's a "must have" utility
to read files in the popular cross-platform file
format "PDF".
7.BenQ Q-link BenQ Q-link, for your smart photo downloads,
printout , edit function and share via email with
others,for photos folders management and
could also slide show photos on screen.
BenQ DC 5330 User’s Manual
19
4.3. Downloading the Image(s)
Under Windows Operating System (Windows 98/98SE/2000/ME/XP)
Downloading Image(s) From Removable Disk
1. Turn on the PC.
2. Switch on the camera.
3. Connect the camera to the PC with USB cable under any working mode.
Please make sure the USB cable is well connected to the PC and camera.
4. When the USB cable is connected to the PC, it will create a new hard disk named
Removable Disk .
5. The stored image(s) can be found in Removable Disk\300_CAMERA.
6. View the image with double-clicks.
BenQ DC 5330 User’s Manual
20
5. TROUBLESHOOTING (ERROR MESSAGE TABLE)
Symptoms Causes Solutions
The power won’t turn on. • The battery is out of power.
• The AC power adapter is not
well connected or damaged.
• Use the battery charger to
charge the battery.
• Make sure the AC power is
connected and it's not damaged.
The power turns off during
use.
• The battery is out of power.
• Auto power off.
• The battery/SD card cover is
opened when in process.
• The adapter has not been
connected properly.
• Use the battery charger to
charge the battery.
• Switch on the Power .
• Do not opened the battery/SD
card cover when camera is
under operating.
• Connect the adapter correctly.
The battery power is draining
quickly.
• The extemal temperature is too
cold.
• The battery is not used for a
long time.
• Keep the camera away from
extreme temperatures.
• Recharge the battery with
battery charger.
The camera does not take pic-
tures when the shutter button
is pressed .
• The camera is not set at
Recording Mode.
• The battery is weak.
• The power has not been
switched on.
• Set the Mode Dial at Recording
Mode.
• Replace the battery with a new
one.
• Switch on the power.
The close-up image is blurred. • You should select the correct
focus range.
• If the subject is within 15 cm,
select macro mode from mode
dial.
The flash does not fire. • The camera flash is turned off.
•The light source is sufficient.
• Set the flash mode to Auto Flash
or Fill-in Flash mode.
Incorrect date/time is
displayed.
• Reset Date/Time.
Camera fails to work by any
button or switch.
• Removed the battery and reload
again.
There is something wrong
with the color of the captured
image.
• White Balance is not set
properly.
• Set white balance to Auto mode
or other suitable mode.
The picture is too bright or
too dark.
• There is excessive or inadequate
exposure.
• Reset exposure compensation.
The TFT LCD monitor is not
clear.
• The LCD monitor plastic cover
is dirty.
• You should clean the LCD cover.
BenQ DC 5330 User’s Manual
21
6. SPECIFICATIONS
The camera cannot download
images to the PC.
• Cable is not connected properly.
• Camera is off.
• There are no battery or the
adapter is not well connected.
• OS is not Window 98/98SE /
2000/ME/XP or PC is not
equipped with USB port.
• USB driver is not installed.
• Check the cable connection.
• Turn on the power.
• Load new battery or check the
AC power adapter connection.
• Install Windows 98/98SE/2000/
ME/XP and USB Port.
• Install USB Driver.
Image Sensor 1/2.5” CCD with 3.23 Mega pixels
Lens
f=35-104 mm (film equivalent)
F2.8 / F4.8
Digital Zoom Capture Mode:4x (continuous)& Play Mode:4x (continuous)
Viewfinder Optical real image viewfinder
LCD Monitor 1.6" color TFT LCD (240 x 354 pixels)
Focusing TTL Auto Focus
Focusing Range Macro: 15cm, Normal: 0.5m-infinity
Shutter Mechanical shutter and Electrical shutter
Shutter Speed 1/30~ 1/1000 sec. Mechanical shutter
1/1000 sec. Electrical shutter
Exposure Center weighted TTL AE / Exposure compensation +2 EV
(0.5 EV / step)
ISO Equivalent 100,200 (Automatic)
White Balance Auto / Shade / Sun / Tungsten / Fluorescent
Flash Auto / Fill-in flash / Red - eye reduction / Flash off
BenQ DC 5330 User’s Manual
22
Flash Range 0.5 ~ 2.5m
Self-timer 10 seconds with LED indicator
Movie Clips Size : 320x240 with sound
Recording time : Manual (unlimited length)
Storage Internal memory: 16MB flash memory;
External memory: support SD Card
File Format Still Image: JPEG , EXIF2.1, DCF, DPOF;
Movie Clip: AVI format with wave sound
Image size Extra-Large: 2720 x 2040 (by interpolated),
Large: 2048 x 1536 pixels,
Medium: 1280 x 960 pixels,
Image Play Single image / AVI play / Thumbnails / Slide show
Interface Digital output connector: USB 2.0
DC power input connector: 5V
Power Source
Lithium-ion battery,
DC adaptor (optional)
Dimensions
(WxHxD)
96 x 61 x 38 mm
Weight 185g (without batteries and card)
System Requirments
FOR WINDOWS * Pentium MMX-class CPU
* 64MB RAM
* CD-ROM drive
* 100MB free hard disk space
* Available USB port
* Windows XP/ME/2000/98SE/98
Small : 640 x 480 pixels
BenQ DC 5330 User’s Manual
23
7. SERVICE INFORMATION
Technical support
If you encountered problems using DC 5330 and the camera driver program, please send an E-
mail (containing detailed descriptions of the problem you came upon, the hardware and software
environment of your system) to the following addresses:
USA: support-sc@BenQ.com
Europe: service@BenQ-eu.com
Taiwan: service-tw@BenQ.com
China: service_china@BenQ.com
Asia and other countries: support@BenQ.com
For free driver program updates, product information and news release, please visit the
following web address:
http://www.BenQ.com.tw/global/
BenQ DC 5330 User’s Manual
24
<Memo>
