Using Your Phone 85
Voice Memo
1. When the phone is in the standby mode, long-press .
3. After you are finished recording, press (Save)
to save the voice memo. Enter the name of the
recording and then press .
4. After you save the voice memo, the display will
show the name of the voice memo. You can now:
a. Press (Option), and then select whether
you wish to record a new voice memo, rename
the current voice memo, delete the current
voice memo, or send the current voice memo
to others via MMS.
8For details on composing and sending an
MMS message, see page 66, "Editing and
sending MMS messages"
2. Press (Option) to bring up a pop-up menu.
Select Add and then press . The voice memo
screen will appear. Use to navigate to the
button icons on the screen and access Voice Memo
functions:
a. Press to record.
b. Press to stop recording.
c. Press to play the voice memo.
86 Using Your Phone
Input Modes
Changing the Text Input Mode
The input mode icons (names) that may appear in the upper right
corner of the screen represent the following input modes:
b. Press to play the voice memo. In the
voice memo screen, you can press to
play the previous or next memo.
Uppercase letters input mode.
Lowercase letters input mode.
iTap (predictive input mode) for uppercase letters.
iTap (predictive input mode) for lowercase letters.
Numeric input mode (123).
/You can set the default input mode to the one you most frequently
use. Go the menu Settings → Input Mode. See page 162.
When the display shows the editing screen, you
will be able to see the name of the current text
input mode in the upper right corner of the
screen. Press to change the input mode.
The text input mode
currently in use
Using Your Phone 87
Letter Input Mode (ABC)
In this mode, press the key containing the desired letter repeatedly to
scroll through the available characters in order until it is reached.
How to use the letter input mode
•You must press the key corresponding to the desired letter the correct
number of times in order to enter the letter you want. Display letters
for entry according to the order shown on each key. Pressing a key
once will display the first letter listed on the key, while pressing it twice
will display the second letter, and so on.
•When you have entered a letter and wish to enter the next letter, either
wait for two seconds until the cursor moves to the next text entry
position, or immediately press the key for the next letter.
•Press to enter a space before beginning a new word.
•While entering text, press to move the cursor left or right; press
to move the cursor up or down. Press once to delete a
character; long-press to delete all entered content.
Numeric Input Mode (123)
The numeric input mode allows you to use the alphanumeric keys
to to enter numbers.
Predictive Input Mode (iTap)
iTap analyzes letters as they being inputted, making intelligent
predictions about the words you are attempting to enter, and speeding
up text entry.
88 Using Your Phone
How to use iTap
•Press once the alphanumeric key corresponding to the first letter of
the word you wish to enter without considering where that letter falls
in the sequence of characters available through that key. Then press
the key corresponding to the second letter, and so forth. The phone
will predict which word you wish to enter based on the set of keys you
have pressed. The predicted word will be shown in the lower left
portion of the screen. This word may change as you continue to press
other keys; therefore, before you have entered a complete word, you
do not need to worry if the displayed word does not yet match the
word you intend to enter.
•After pressing keys for a complete word, if the displayed word does
not match the one you intended to enter, press to view other
candidate words and locate the desired word.
•Once the correct word is displayed on the screen, press to enter this
word. A space will automatically be inserted after the word.
•While entering text, press to move the cursor left or right; press
to move the cursor up or down. Press
once to delete a
character; long-press to delete all entered text.
Example of iTap in use
To enter "COME HOME" in the message editing screen using iTap, use
the following steps:
1. Press to switch to iTap for uppercase letters (ITAP).
2. Press to select C, O, M, E.
3. Press to enter "COME" as text. A space will automatically be
inserted after "COME".
4. Press to enter "HOME".
Using Your Phone 89
5. Since "GOOD" is not the word that you wish to enter, press to
display the next candidate word, "HOME".
6. Press to place "HOME" into the message.
Symbol Input Mode
When editing messages, press to open the symbols field along the
bottom of the screen. Use to move the selection box to the symbol
you wish to enter, and then press to place it in the message text.
90 Using Your Phone
Direct Connection to URLs
Your phone provides handy preset URL text hotkeys, enabling you to
enter a complete URL more quickly and conveniently, and making
Internet access more efficient and enjoyable.
From the standby screen, you can rapidly key in numerical URLs. If, for
example, you wish to enter "http://123.com" you need only key in "123"
and then press . The full URL will appear on the screen.
automatically adds the necessary "http://" prefix and the ".com" domain
suffix. To actually connect to this website, simply press to confirm
and the phone's browser will be started up so that you can get online.
When entering a URL, you can also use to access the following
functions:
•After pressing once, further presses of will switch to the URL
suffixes shown in the chart:
•You can convert (*) into the (.) that appears in URL addresses.
For example, if you enter 123*456 in the standby screen, and then
press , the URL "http://123.456.com" will appear on the screen.
Number of
times Output result
0 . com
1.com.tw
2.net
3 .net.tw
4.com.cn
5 .net.cn
Using Your Phone 91
•After you press to enter "http://" press to enter "/" and "-".
For example, if after you enter "123" and then press once-causing
"http://123.com" to appear on the screen-you press again, the
URL will change to "http://123.com/". Pressing again will
switch between "/" and "-".
•When the screen shows the desired URL, press to connect to the
Internet and access this URL address.
92 Menus
Menus
The phone's menus provide various features. The main menu consists
of 9 icons. Each icon represents a particular menu item, which is used to
access related sub-menus.
For information about navigating menus, see page 23, "Menu
Navigation".
Phone Book
This menu provides various functions for managing the Phone Book,
including the ability to add, locate, and copy contact data; add contacts
to a caller group; and so forth.
Find
Used to locate a contact in the Phone Book. You can enter the full name
of the desired contact, or if you are not sure about the spelling of the
contact's name, simply enter the first letter, and then press . The
phone will locate all contacts whose names begin with this letter, and
you can scroll to the field containing the contact you want. For details
on what to do after locating the desired contact, see page 43, "Finding
Contacts in the Phone Book".
Add
Used to add a new contact to the Phone Book. You can follow the
procedure described on page 38, "Adding Contacts to the Phone Book".
Edit
After selecting a particular contact, you can follow the procedure
described on page 38 for editing the data for this contact.
Menus 93
Copy
If you are using the phone book stored in the phone's memory, you can
copy contact data to the SIM card's phone book, and vice versa. You can
select a contact to copy from one phone book to the other, and copy all
contacts in one phone book to the other by choosing the option Copy
All Phone Book to SIM (Copy All SIM Phone Book to Phone).
Delete
Deletes a contact from the Phone Book. You can delete one contact at a
time, or delete all contacts at once. If you select the option to delete all
contacts, you will be asked for your phone password (the default
password is "1234").
Caller Groups
Caller groups are combinations of phone settings used to identify a
particular group of contacts, such as work colleagues, family members,
or friends. For example, you can associate a ring tone and animation
with one group, and when a member of that group calls, the phone will
use the group's ring tone and display its animation.
The phone provides 5 caller groups: Colleagues, Family, Friends, VIP,
Others.
After you scroll the caller group that you wish to configure, you can
perform the following tasks:
•Press (Option): Used to select the ring tone or animation/
image that will help you identify the caller group to which a
particular caller belongs, or to rename the caller group.
•Press : Allows you to view a list of all contacts that belong to
the caller group. Press to highlight the desired contact, and
then press (Option) to access the following options:
94 Menus
Add: Add a contact to the caller group. Press to select a
contact to add, and when finished press .
Delete: Deletes the selected contact from the contact group.
Privacy Manager
This option allows you to set your phone to reject certain calls, or
alternatively, specify which calls to accept, rejecting all others.
1. First, create a list of calls that you wish to accept (Accept List) or a list
of calls that you wish to reject (Reject List), by scrolling to the
corresponding item. Then press (Edit) and the names of the
contacts who are already on the selected list will be displayed. If the
list is empty, press (Option) and then select Add to choose
contacts to include in the list.
2. You can select all the members of a caller group to
be added to a list, or you can select contacts from
the Phone Book individually (the screen will first
display the caller group option). Press to scroll
to the caller group or contacts that you wish to add
to the list, and then press (Select) to make your
selections; press (Cancel) to clear the caller
group or contacts that you have selected.
Menus 95
3. When you are finished, press . The screen will display the names
of the contacts you have added to the list. If needed, you can press
(Option) to add or remove contacts. When you have confirmed the
list, press (Back) to return to the Privacy Manager menu.
If you choose to activate the Accept List, from now on your
phone will only be able to receive calls from contacts in the
Accept List. If, on the other hand, you choose to activate the
Reject List, your phone will not be able to receive calls from
contacts in the Reject List.
8The same contact cannot be included in both the Accept List and
the Reject List.
8If you are currently using the phone book on your SIM card, you
will not have access to the Privacy Manager feature.
4. Lastly, select whether to activate the Accept List or
the Reject List. Press to scroll to the list that
you wish to activate, and then press to
confirm your choice.
96 Menus
Business Card
You can use this option to enter your own business card information.
The data fields are as follows:
Press to scroll to the data field you wish to edit, and then
press (Edit), press , or begin entering text to edit the data in
this field. After you are finished entering the data you wish to, press
to save all the business card data.
Your name.
Your mobile phone number.
Your e-mail address.
Your company's address.
Your job title.
Menus 97
Activate
My Number
This option allows you to save your SIM card number and name to your
SIM card's memory.
Press (Option) and select Add. Now select whether you want to
enter your name or number and then press (Edit) or to begin
entering the information. When you are finished, pres , and the
screen will display the name you have stored in your SIM card's
memory. You can press (Option) to add more data, edit the
currently selected data, or delete the currently selected data.
SIM Status
Used to view how many additional entries can be stored in the SIM
card's phone book and the maximum number of entries that it can
store.
Used to activate the phone book stored in the phone's
memory or on your SIM card. Press to highlight
the desired phone book and then press .
98 Menus
Call Records
8Your network operator must support this feature in order for you to be
able to use it.
This menu includes a list of your missed calls, dialed calls, and received
calls. Call costs and time are also recorded.
Missed Calls
Shows your most recent missed calls.
Press to scroll to the missed call that you wish to select. You can
now choose to view, edit, or delete the number for the missed call. The
procedure is the same as that described on page 45, "Last Missed,
Dialed, and Received Calls".
Received Calls
Shows your most recent received calls.
The procedure for using this feature is the same as that described on
page 45, "Last Missed, Dialed, and Received Calls".
Dialed Calls
Shows your most recent dialed calls.
The procedure for using this feature is the same as that described on
page 45, "Last Missed, Dialed, and Received Calls".
Delete All
Deletes all call records.
Menus 99
Call Duration
8This feature is only accessible if supported by your network operator.
Last Call Time
Shows the duration of the last call.
All Calls Time
Shows the total time for all calls.
Received Calls Time
Shows the total time for all received calls.
Dialed Calls Time
Shows the total time for all dialed calls.
Clear
Clears all call time records.
8You must enter your PIN2 code in order to zero call times.
/What is a PIN2 code?
•The PIN2 is the second PIN code. Its main use is in controlling
restricted services-for example, call time limits and restricted phone
numbers.
•If the PIN2 code is incorrectly entered three times consecutively, the
PIN2 code will be locked. To unlock the PIN2 code, you will need to
enter the PUK2 code, which you obtain from your network operator.
100 Menus
Call Cost
Last Call Cost
Shows the cost of your last call.
8Requires the support of the network operator.
All Calls Cost
Shows the total cost of all calls.
8Requires the support of the network operator.
Clear
Clears all call cost records.
8Requires entry of the PIN2 code.
Call Cost Limit
Shows the current limit set for total call costs.
Set Cost Limit
Allows you to set a limit for total call costs. If call costs exceed this
limit, the phone will no longer be able to dial pay calls. When this
feature is activated, the remaining cost will be displayed in the
information box on the screen each time you end a call.
8Requires entry of the PIN2 code.
Set Units
Allows you to first enter the unit price and a currency for
calculating call costs.
8Requires entry of the PIN2 code.
Menus 101
Messages
For a description of the features available in the messages menu, see
page 61, "Messages Menu".
102 Menus
Organizer
Calendar
You can use the Calendar to set up memos for forthcoming events such
as a meeting, an appointment, or a friend's birthday. The Calendar will
also remind you about events you have previously scheduled.
3. In the memo editor screen, scroll to the data field you wish to edit,
and then press (Edit) or , or press alphanumeric keys to
1. When you open the Calendar, the phone will
show the calendar for the current date.
8If you have not set the current date on your
phone, go the menu Settings → Date & Time.
See page 144.
In the Calendar screen, press to move
the red box to the date where you wish
create a memo. You can also press
(Option) and select the Go to Date
option, then enter the desired date, pressing
to confirm your selection of that date.
When the Calendar i
s
opened, the current
date will be
highlighted by a red
box.
2. When the red box is highlighting the desired date,
press (Option) and select the Add option to
open the memo editor.
Menus 103
begin entering data. You can enter data in these fields:
4. After completing entry of data in each of the fields, you must press
to save the memo to that date. The phone will display this date's
memo list, including the event name and time for the memo you just
saved. If the Alarm Clock has been set to remind you about the event
associated with the memo, the icon will appear beside the event
name.
Change the memo's assigned date. In the Calendar screen, press
to scroll to the date where you wish to create the memo, and
then press .
Enter a time for the event associated with the memo by using the
appropriate number keys.
Enter a name for the event associated with the memo.
Enter the scheduled location for the event associated with the
memo.
Enter the names of the participants in the event associated with the
memo.
Record any notes about the event associated with the memo.
Scroll to this option to set up your phone to
remind you about an event. On the appointed
date, when the scheduled time arrives, the memo
will appear on the screen and the Alarm Clock
will ring.
First press to activate this feature. The time
field will appear beneath, and you can enter the time when you wish
to be reminded about the event.
104 Menus
5. You can now perform the following tasks:
a. Press (Option) to select whether to edit or delete the
memo, or send this memo to others through SMS.
b. Press to view the information in the memo. Then press
(Option) to edit or delete the memo
c. Press (Back) to return to the Calendar screen. You can
move the red box to other dates to create additional memos
(dates that already contain memos will be marked by a
yellow box); you can also create a second memo for the same
date. The procedure is identical to that described previously.
6. After creating all the event memos you wish, return to the Calendar
screen. You can now press (Option) and select:
•Delete All: Deletes all currently saved memos.
•Auto Delete: If this feature is activated, all event memos for dates prior
to the current date will be automatically deleted.
To D o List
You can use this feature to create a list of work tasks or personal
projects.
1. Press (Option) and then select Add to bring up the editor
window. After entering the name of the task, press to create this
to do item.
2. In the list screen, scroll to the desired to do item, and then press
(Option) to add a new to do item, or to edit or delete the
selected to do item. If there are two or more items in the list, you can
select Delete All to delete all of them.
Menus 105
3. In the list screen, if there are any to do items that have already been
completed, you can scroll to the item and then press to mark it to
remind yourself that the task has been done. If you
press (Option), you can activate the Auto Delete, which will
automatically clear any to do items that you have marked as
completed.
Note
You can use this feature to create a list of notes.
1. Press (Option) and select Add to bring up the editor screen.
Enter the desired text and press .
2. A message on the screen will ask whether you wish to add a password
for this note. If you press (Ye s), you will from then on need to
enter the phone password in order to view the contents of the note.
Press (No) to save the note without adding a password.
8The default phone password is 1234. To change the password, go to
the menu Settings → Security → Phone Lock. See page 160.
Tools
Camera
You can use the phone's digital camera here to shoot photos. For
information on using the camera, see page 52, "Camera Function".
106 Menus
Alarm Clock
Use the following steps to set an alarm:
/If you activate the Alarm Clock feature, when the specified date and
time arrive, the phone will sound the alarm, even if your phone is
turned off.
Day
Used to set the alarm to go off on
a particular day from Monday to
Sunday. Press (Edit) to display
the days of the week. Press
(Select) to make your selection.
When done, press to return
to the Alarm Ring screen. The
Day field will now indicate the
days on which the alarm will go
off.
Time
Allows you enter the time when an alarm will go off.
1. Select an alarm you wish to set and activate.
2. Press to select the feature for activation. The
configuration fields for the alarm will appear in the
lower part of the screen.
The days on which the
alarm will go off.
Menus 107
3. Lastly, you must press to save all your current Alarm Clock
settings. After completing Alarm Clock settings, will appear in
the external display's status bar; will appear in the main display's
status bar.
Shortcuts
For a description of the features accessible through the Shortcuts menu,
see page 57, "Shortcuts Menu".
Voice M em o
For a description of the features accessible through the Voice Memo
menu, see page 85, "Voice Memo".
Time Duration
Allows you to set the length of the alarm. Press (Edit) to select the
desired alarm duration and then press .
/When the alarm rings, there are two ways to turn it off:
•Press (Snooze) to stop the alarm. The alarm will ring again
five minutes later.
•Press to turn off the alarm. The alarm will not ring until the next
scheduled time.
108 Menus
Calculator
Currency Converter
Below is a description of the Currency Converter screen:
1. To set the currencies for conversion, press
(Option) and select either Currency 1 (to set
the currency at the top of the screen) or Currency
2 (to set the currency at the bottom of the screen),
then press to confirm. After selecting a
currency from the list, press .
Allows you to use the phone as a
calculator. Use to perform
the mathematical operations
shown on the screen.
8You can enter numbers up
to a maximum of 8 digits in
length.
Entered numbers
and calculation
results will appear
in this field.
Press to enter
a decimal point.
Currency 1:
EUR (euros)
The current exchange
rate setting
Currency 2: USD
(US dollars)
For entering the amount
for conversion
Once you enter the Currency Converter screen, the default currencies
will be displayed, as shown in this example:
Menus 109
2. Used to set the exchange rate.
Press (Option) and select Rate Setting, then
enter the rate for converting from Currency 1 to
Currency 2. The conversion calculation result will
be displayed in the same line as the bottom
currency on the screen. Use the to view the
calculation result. The calculation can provide
precision up to two decimal places.
8The exchange rate field can accommodate a
maximum of five digits (including decimal digits).
8Press to enter a decimal point.
3. After returning to the Currency Converter screen,
you can select one of the currencies and then enter
an amount that you wish to convert into the other
currency.
8You can enter amounts up to six digits long.
4. After pressing the converted amount will
appear in the field for the other currency.
110 Menus
Stopwatch
4. Once the stopwatch is halted, press (Reset) to zero the stopwatch.
Countdown Timer
1. Enter the amount of time to count down. You can set any time up to
23 hours, 59 minutes and 59 seconds.
2. When you press , the countdown timer will begin counting
down to zero. When the countdown is finished, the screen will
display the "Time's Up" message and an alert sound will be played.
Press (Exit) to leave the screen.
3. Press to stop the countdown timer.
4. After the countdown timer is stopped, you can press (Reset) and
enter a new time to count down.
1. Press to start the stopwatch.
2. While the stopwatch is running, you can press
(Split) to save up four elapsed times (such as in a
race). The display will show the saved times in the
lower part of the screen.
8Pressing (Back) while the stopwatch is running
will bring up the "Quit?" warning message (the
stopwatch will continue to run). Press (Yes) to
stop the stopwatch or (No) to return to the timer
screen.
3. Press to halt the stopwatch.
Menus 111
5. When the countdown timer is running, press (Back). The "Stop
Timer?" message will appear. If you press (Ye s), the countdown
timer will stop and return to the timer screen. If you press (No),
you will exit the countdown timer screen, but the countdown timer
will continue the countdown. You can then perform other tasks, and
when the countdown is finished, the "Time's Up" message will appear
and an alert sound will be played. Press (Exit) to exit the screen.
Memory Status
Shows the amount of memory, including space for storing pictures,
animations, and ring tones on the phone. The amount will be displayed
as "Remaining Usable Memory / Total Usable Memory".
Service Number
This option can be used to display the service number that the network
operator has stored on the SIM card.
8Requires network operator support.
SIM Toolkit Menu
Your network operator provided you with the mobile services in this
SIM Toolkit (STK, for short) menu. Depending on the particular
services provided by the network operator, this menu may contain a
number of extra options. However, if the network operator has not
provided any STK services, this menu will not appear on the screen. For
detailed information, contact your network operator.
8Requires network operator support.
112 Menus
Games
Your phone provides a number of exciting games that you can use to
entertain yourself when you have a spare moment.
Champion Soccer
1. After choosing this option, select Start to enter the
game's opening screen. Press and select
START to begin a new round of play.
2. Select World Cup Mode or Arcade Mode.
This game lets you manage one of the world's top eight
soccer teams in its quest to win the greatest prize in
world soccer.
Menus 113
3. In the World Cup Mode, you can select your own
team with the opposing team selected at random
by the phone. If your team wins, you face the next
team as you make a challenge for the World Cup
title. In the Arcade Mode, you can select your own
team and the opposing team to play a single game.
Press to select a flag representing a national
team, and then press to confirm.
4. After the message announcing the first half
appears, press to begin the game.
114 Menus
Game Controls
During the game, you need to control your three players on the
pitch, while your goalkeeper is controlled by the phone.
•When attacking, use to , and (the
alphanumeric keys, excepting ) to move the players.
Use to to pass the ball (you will see the player's
number on the screen), and when near the goal, press
to take a shot on goal.
•When on defense, use to , and (the
alphanumeric keys, excepting ) to move a player.
Use to to select a player to move (you will be able
to see the player's number on the screen). When a player on
the opposing team is near the goal, use to tackle.
•If you want to stop a game during play, press and .
•When on defense, use
these three keys to
select players to move.
•When attacking, use
these three keys to
select which player to
pass the ball to.
•When on defense,
press to
tackle.
•When attacking,
press to take
a shot on goal.
•Controls the direction
of the player's
movement.
•Controls the
direction of the
player's movement.
Menus 115
Game screen
Game options
•START: Begins a new game.
•Continue: Resumes an interrupted game. Usable only in the
World Cup Mode.
•Controls: Brings up an explanation of how to use keys during a
game.
•Ranking: Records the rankings of the teams after a tournament in
the World Cup Mode is completed.
•Option:
Sound: Press to adjust the volume, or to turn off
background music.
Mini Map: Shows/hides the full pitch view.
Time: Sets the duration of a half.
Full pitch view
White point: The position of the player you
are controlling
Black point: The ball's location
Blue points: Your teammates
Red points: Players on the opposing team.
The opposing
team
Your team
Your score The opposing
team's score
Timer
The number of
the player you are
controlling.
116 Menus
•Exit: Quits this game.
Menus 117
Dragon Fight
The flying dragon that you control must make
incursions into hostile territory and destroy enemies.
Select Start to enter the game's opening screen, and
then press to begin play. The more enemies you
destroy, the higher your score. If you collide into an
enemy, you lose one flying dragon.
Press
to control
the direction of the
dragon's flight
Pick up objects like
this to increase the
power of your
weapon
Enemy
Super Bombs
Number of remaining dragons
Score
Shield
Press to shoot the
laser gun or fireballs
Press to launch a
firestorm or bring up a
protective shield
Press to
increase the power
of your weapon.
118 Menus
Internet
Your phone includes a built-in WAP browser, allowing you to use the
phone for mobile Internet connectivity. You can browse the online
services offered by the network operator or ISP, such as information on
financial news, sports, travel, and entertainment. To use the phone to
get online, necessary WAP and GPRS settings must be made in this
menu.
8You must apply to a network operator for WAP services and complete
WAP and GPRS settings in this menu before you will be able to take
advantage of mobile Internet connectivity. In general, once the
service you have applied for has been activated, the network operator
will automatically transmit the needed settings to your phone. If this is
not the case, you must perform this configuration yourself. For
information about WAP and GPRS services and configuration details,
contact a network operator providing these services.
WAP S er v i ce
/Your phone provides the following methods for activating the browser
and getting online.
1. From the standby screen, activate the browser and get online by
using the feature that allows you to connect directly to URLs. For
details, see page 90, "Direct Connection to URLs".
2. Activate the browser from the three options in the menu Internet
→ WAP Service:
•Start Browser: Starts up the browser and connects to the
homepage.
•WAP Message: Starts up the browser and accesses the WAP
inbox for reading text messages.
•Enter Address: Starts up the browser and connects to the
URL that you enter.
Menus 119
Start Browser
Starts up the browser and connects to the homepage.
Browsing a webpage
Referring to the soft key commands at the bottom of the screen,
press and
to perform needed tasks while browsing a
webpage. Press to scroll up or down a webpage. For details on
browsing a webpage, inquire with the network operator providing
WAP services. Your Internet connectivity service will determine the
layout and content of the webpages you view. Depending on the
specifics of your service, they way you browse the Internet on your
phone will differ.
How to close the browser and end the online session
•While online, press or long-press .
•If you are already viewing a WAP webpage, long-press or
from the browser's menu select Exit.
How to display the browser's menu
While viewing a WAP webpage, press to display the browser's
menu. Referring to the soft key commands at the bottom of the
screen, press and to access the various options. Press the
corresponding alphanumeric keys to directly select an option. The
browser menu contains the following items:
Back
Selecting this option will take you to the page you viewed
previously.
120 Menus
Home
Returns to the home page. To designate a particular page to be
your home page, go to 9 Settings → 1 Homepage.
Exit
Closes the browser and returns you to the main menu screen.
Inbox
When your phone receives a message that can only be viewed
using a WAP browser, you enter this WAP inbox to read the
message.
Bookmarks
You can open the Bookmarks menu and select webpage
bookmarks.
View
Allows you to see the current bookmarks and bookmarks
folders. Scroll to the desired bookmark or bookmarks
folder, and you can:
•Press (Go) to link to the webpage that the bookmark
represents. If you have selected a bookmarks folder, select
the desired bookmark from within the folder, and then
press (Go).
•Press (Menu) to display the following options:
Details: Displays the bookmark's title and the URL it
represents.
Delete: Deletes the bookmark or bookmarks folder.
New Bookmark: Creates a new bookmark.
New Folder: Creates a new bookmarks folder.
Menus 121
Move to Folder: Moves a bookmark to the
designated folder.
Delete All: Deletes all bookmarks and book-marks
folders.
Hotkeys: Allows you set a numerical key as a hotkey
for a bookmark. After completing the setting, you
can press this numerical key to directly link to the
webpage represented by the bookmark.
Mark Site
Adds the current webpage to your bookmarks list.
GoTo URL
Press (Edit) and enter the URL of the webpage that you
wish to browse, and then scroll to the Go option and press
(Go) to link to that URL.
Save Items
When viewing a webpage, if you discover that it contains an
image that can be downloaded, you can access this option to
save the image to your phone. Subsequently, this image will be
available for use when you are composing messages or
choosing a standby screen wallpaper.
Reload
Reloads the current webpage.
Settings
You can enter this item to making the following settings:
8For detailed information about the following settings, contact
your ISP.
122 Menus
Homepage
Designates a homepage. When you start up the WAP
browser or if you select Home from the browser's menu,
the screen will display the homepage you designate.
a. Press (Edit) and then enter the URL of the webpage
that you wish to use as your homepage. (Some WAP
service providers do not allow users to set a homepage.)
b. Select the Save option to designate the URL you entered
as your homepage. Select Use Default to use the
homepage designated by your WAP service provider.
Scroll Mode
You can select two scrolling modes: Block or Smooth. In
the Block mode, as many words as will fit in a line are
shown for a few seconds, then the next line is shown, and
so on. In the Smooth mode, the content scrolls smoothly
on the screen. You can also adjust the scrolling speed: Fast,
Medium, Slow.
Send Referrer
This option allows you to determine whether the browser
will send an HTTP referrer header.
Key Press Timeout
This option sets the amount of time that the phone waits
during text entry before automatically advancing the
cursor to the next entry position. As long as the same key is
re-pressed within the interval of time set here, it will
continue to cycle through the characters available through
that key.
Menus 123
Set Proxy
Your phone can save the settings for six WAP proxy
servers. You can select one of these proxy settings for use as
a default so that your phone will connect to that proxy
server when you begin an Internet session.
You can also go to the menu Internet → Wap Service →
Wap Setting s to select the server that you wish to activate.
See page 125.
Circuit Prompt
The Circuit Prompt is a message displayed before each
circuit data call is made. It reads, "Circuit is down. Start a
data call?" You can choose to enable or disable this feature.
Security
Secure Prompt
The Secure Prompt message is displayed before you
leave a secure area. It reads, "Entering a non-secure
area. OK?" You can choose to enable or disable this
feature.
Current Certificate
Displays information on the certificate currently in
use.
CA Certificates
Displays information on the built-in certificate. A
certificate is a digital ID issued by a trusted third party
known as a certificate authority (CA). The phone uses
CA certificates to authenticate websites that send
information to the phone.
124 Menus
Authentication
You can decide whether your phone should store your
user name and passwords for websites that require
them. If you allow your phone to authenticate you
automatically, you will not need to re-enter your user
name and password each time you visit the same
website.
Advanced
Restart Browser
Restarts the browser, and automatically returns to the
designated homepage. This feature is provided for
your convenience if network errors occur, allowing
you to restart the browser and re-establish your
Internet connection.
Downloads
If this option is enabled, you will not be able to
download images, background audio, and objects.
View Title Region
You can choose whether or not to have the browser
display webpage titles. You can also set this option so
that titles exceeding a certain length will be split into
separate lines. (The first line of the browser displays a
"G" and a globe image, while the second is the "title
region". The actual webpage content begins on the
third line.)
About…
From here, you can view information about the
version of the browser that you are using.
Menus 125
WAP Message
Starts up the browser and displays the WAP inbox so you can read
WAP messages.
Enter Address
Starts up the browser and connects to the URL you enter.
Resume
Returns to the last webpage you viewed.
Clear Cache
Clears webpage content that the browser temporarily stores in
memory.
WAP S et ti ng s
In this menu, you can make settings for the WAP servers of six
different network operators, and select the server that you would
like to use when connecting to the Internet.
The first time that you start your phone after inserting a SIM card,
the ISP name of the network operator issuing the SIM card will
appear in this menu's first group of settings. This indicates that
your network operator's WAP server settings will be saved under
the name shown. The phone will activate this group of settings for
use in connecting to the Internet.
To activate another set of WAP server settings, scroll to the group of
settings you wish to use and then press . The phone will activate
these settings for use in connecting to the Internet.
126 Menus
By scrolling to a particular group of WAP server settings that you
wish to modify, and then pressing (Option), you can create a
new group of settings, edit the settings, or delete the settings.
WAP server settings include the fields listed below. Press (Edit)
to edit the setting in each field. When you are finished with the
settings for all fields, you must press in order for this group of
WAP server settings to be saved.
•Profile Name: Gives the WAP server settings a name.
•Homepage: Sets the webpage that the browser will link to when it
is started up. After you enter this item, key in the URL for the
webpage that you would like to use as the homepage —for
example, http://wap.yahoo.com.
•IP Address: Enter the IP address used for accessing the mobile
Internet.
•Port: Enter the connection port specified by the network operator
—for example, 9201.
•Bearer Mode: Before connecting to the Internet, you must set this
item according to whether your Internet connection bearer mode
is a GPRS network system or a GSM dialup network. Doing so
will allow you to properly link to the data network to browse WAP
pages, download Java programs, and so forth. If you are using a
GPRS network, you can use both the GPRS and dialup network to
connect to the Internet. If, however, you are using a dialup
network, you are restricted to using only the dialup network to
connect to the Internet.
GPRS/CSD: Use the GPRS network preferentially. Only if
there is no GPRS network present will the dialup network be
used.
GPRS: Use only the GPRS network.
Menus 127
CSD/GPRS: Use the dialup network preferentially. Only if
there is no dialup network will the GPRS network be used.
CSD: Use only the dialup network.
•GPRS: To modify settings for a GPRS account, press (Edit) to
edit the settings in each field. GPRS settings include the following
fields:
APN: Enter the APN (Access Point Name) assigned by your
network operator.
User Name: If needed, enter the user name provided by your
network operator.
Password: If needed, enter the account password provided by
your network operator.
•CSD: If you are using a GSM network, you must configure and
activate a CSD account. Press (Edit) to edit the settings in the
following fields:
Dial Number: When you start up the browser to connect to
the Internet, you phone will dial this number. Your telecoms
network operator or ISP will provide this number to you.
User Name: This is your user account name, and is provided
by your network operator.
Password: The account password provided by the network
provider.
/A dialup network is a GSM Circuit Switch Data Service (CSD
for short). Using a dialup network can be likened to using a
home computer's modem, in that before connecting to the
Internet a number must be dialed. As for GPRS, it like the
LANs used at company, where users do not need to dial a
number to access the network. Regular GSM users who are
not using a GPRS network system can only have a dialup
connection to the Internet.
128 Menus
Line Type: This is the type of dialup connection. Press
to select.
Baud Rate: The default value is 9600, which is the standard
speed for data connections with a GSM mobile phone.
Auth Type: This is information needed for
telecommunications protocol authentication.
Menus 129
JAVA
Your phone provides Java support, allowing you to download and
install Java applications that you like, such as various Java games, from
sites provided by your network operator. You can then run these Java
applications directly on your phone. If you do not need an application,
you can remove it from your phone at any time, replacing it with
another downloaded application.
The JAVA menu contains the following items:
JAVA Settings
Yo u can g o to t h e m e nu Internet → JAVA → Environment Settings →
Internet Setting, and then press (Edit) to complete the Java settings
below. When you are finished making all settings, you must press
to save them.
•Profile Name: Provides a name for this Internet setting.
•Network Access: Some types of Java games are only playable online
(for example, mahjong), and using the phone to go online entails an
extra cost. However, it may not be possible to determine from a
game's name alone whether or not it is an online game. Therefore, this
setting allows you to be presented a prompt asking if you wish to go
online to play a game before actually running the program.
Application
Browser
All Java applications will be listed in this menu.
The Application Browser menu serves as a file manager,
and includes the option to place Java applications into
groups, similar to folders, for convenient organization of
and access to the Java applications you download.
Environment
Settings
This sets a file size limit for downloads, allows you to
complete necessary Java online settings, and displays
memory usage within Java (space in use/space available).
130 Menus
Always Ask: Each time you attempt to launch an online game, you
will be asked if you want to connect to the Internet.
Ask Once per AP: You will only be asked if you want to go online
the first time you attempt to launch an online game. The next
time you attempt to launch the game, the same choice that you
made the first time will be applied.
Never Ask: Each time you launch an online game, the phone will
automatically connect to the Internet, and you will not be asked
to confirm.
•DNS: Here you can enter the IP address of the Domain Name Server
that you wish to use.
•Bearer Mode: Before you download a Java application from the
Internet, you must set the network system that you are using to either
GPRS or CSD (dialup).
•Based on the bearer mode that you have set, you will need to make
further settings for either the GPRS or dialup network. For details on
configuring GPRS and dialup network access, see page 127.
Downloading JAVA applications
Please use the WAP browser to download Java applications. The
browser screen will first display information about the applications.
After you have read this information, you can run the download
command shown on the screen to begin downloading the desired
application to the MyApps group on the phone.
Menus 131
Managing and running JAVA applications
To manage and run Java applications installed on the phone, go to the
menu JAVA → Applications Browser. All Java applications will be listed
in this menu. The Applications Browser menu serves as a file manager,
and the groups listed within it can be thought of as folders used to
organize different types of Java applications.
When you enter the Applications Browser menu, you will see the default
group MyApps, where all downloaded Java applications will initially be
installed. The name of this group cannot be changed, and the group
itself cannot be deleted. Press to enter MyApps, and then select the
name of the desired Java application. You can now:
•Press (Option) to access the following options:
Content: Displays information about the Java application.
Delete: Deletes the Java application.
Move: Removes the Java application from the MyApps group and
places it in another group in the Applications Browser. Scroll to
the group where you wish to move the application and then press
.
8To move a Java application to a group other than MyApps when
it is currently the only group, you must press (Option) in the
JAVA → Applications Browser menu and select New to create
a new group.
132 Menus
•Press to show the names of the executable files of the applications.
Scroll to the desired executable file and press to run the
corresponding Java application.
8After starting up a Java application, use the keys corresponding to
the commands shown in the soft key bar in the lower part of the
screen to control that application.
Use only BenQ-certified Java applications in order to ensure that they
will run properly on your phone.
/The default Java applications contained in MyApps may differ
according to localized configurations. Once you begin running an
application, simply follow the on-screen instructions. You can delete it
in order to install other application software.
Menus 133
Multimedia
This image library stores the phone's default pictures, as well as images
received in EMS/MMS messages, or downloaded through WAP services
or using multimedia communications tools.
Scroll to the desired picture to access the following options:
•Press to display this picture. Pressing will display the next or
previous picture; pressing will show the full-screen picture.
•Press (Option) to perform the following tasks with the picture:
Rename: Allows you to provide the picture with a new name.
8The phone's default picture cannot be renamed, so this option is
not present for it.
Delete: Deletes the picture.
8The phone's default picture cannot be deleted, so this option is
not present for it.
Send: Sends the picture in an EMS/MMS message.
8For information about messaging features, see page 61,
"Messages Menu".
Information: Displays the picture's name, file size, and whether
the file is a default picture, a picture you have saved or one you
downloaded yourself (noted as User Defined).
The file formats supported by the phone are BMP, PNG, GIF, JPEG
(progressive or marithmetic-encoded saves not supported), and EMS
picture.
134 Menus
Set Wallpaper: Use the picture as the wallpaper for the standby
screen.
Animation
This animation library stores the phone's default animations, as well as
animations received in EMS/MMS messages, or downloaded through
WAP services or using multimedia communications tools. The
procedure for using this menu is the same as that described above for
the Picture menu.
Melody
My Melodies
This ring tone library includes the phone's default ring tones, as
well as ring tones received in EMS/MMS messages, or downloaded
through WAP services or using multimedia communications tools,
or that you have created yourself with the Composer function.
Scroll to the desired ring tone, and press (Option) to perform
the following tasks with the ring tone:
•Set Ringtone: Makes the ring tone the alert sound for incoming
calls.
8Ring tones that support the EMS format (such as Chimes High)
cannot be set as the phone's alert sound for incoming calls, so
they do not offer this menu option.
The phone supports the following animation file formats: GIF, EMS
animation.
The phone supports the following music file formats: MIDI,
SMAF.
Menus 135
•Rename: Allows you to give a new name to the ring tone.
8The phone's default ring tones cannot be renamed, so they do
not present this option.
•Edit: Allows you to edit the ring tone.
8The phone's default ring tone cannot be edited, and only
Composer offers this option. For information on how to edit ring
tones, see page 136, "Composer".
•Delete: Deletes user-edited ring tones.
8The phone's default ring tones cannot be deleted. Only user-
created or downloaded ring tones provide this option.
•Send: Sends the ring tone in a message.
8For information about messaging features, see page 61,
"Messages Menu".
•Information: Displays the name of the ring tone, its file size, and
whether it is a default ring tone, or a file that you have saved or
downloaded yourself (noted as User Defined).
136 Menus
Composer
You can edit your own polyphonic ring tone melodies, and use
them as alert sounds for incoming calls.
A polyphonic ring tone consists of musical tones in multiple
channels. The Composer function allows you to create a maximum
of 8 channels, mixing them to create the final polyphonic ring tone.
Note format
Entering default notes
Press to to enter the eight pitches in an octave as
quarter notes: Do Re Mi Fa So La Ti. The screen will display:
4C5, 4D5, 4E5, 4F5, 4G5, 4A5 and 4B5.
Entering a default rest
Press to enter a quarter rest: 40.
/The "4" on the left shows that the represented note is a
quarter note; the "5" indicates that it is in the fifth octave.
Length Octave
Sharp
Pitch
Menus 137
Adjusting the length of a note
The default note length is a quarter note (the screen uses the
number 4 to represent a quarter note). Press to increase
the note's length (the number on the screen will increase);
press to reduce the note's length (the number on the
screen will decrease). Various note lengths are represented by
the numbers shown in the chart:
Adjusting a note's octave
The default notes just entered are in the middle octave
(represented on the screen by the number 5). Press to
adjust a note's octave. The octave of a note is represented by the
numbers shown in the chart:
Adding a sharp to a note
Press to add a sharp '#', which raises the note a semitone.
To remove a sharp from a note, press .
8A sharp cannot be added to an E or B note.
On-screen
number 12345678
Note length 1/16 1/8 3/16 1/4 3/8 1/2 3/4 1
On-screen number Represented octave
4 Lower octave
5 Middle octave
6 Higher one octave
7 Higher two octaves
138 Menus
Steps for creating a polyphonic ring tone
1. The first time you enter the Composer menu, you will see 8
channels that you can select for editing. Each channel can be
used to save one passage of music that you have created.
Scroll to the channel that you wish to edit, and then press
to enter the ring tone editing window to begin
composing the music for this channel.
2. Edit notes according to the procedures described above.
•To modify a note after you have entered several notes,
press to move the cursor to the right of the note that
you wish to change. You can then proceed with adjusting
the length, octave, sharp/unsharp, and so on.
•Press to delete a highlighted note.
3. When editing the music in a channel, press (Option) to
access the following options:
•Play: Plays the notes in the channel.
•Instrument: Allows you select the instrument that will
play the notes in the channel.
•Time Beat: Sets the tempo (tempo range: 40 to 200).
4. After you are finished editing the notes in the channel, press
to return to the channel list. You can now repeat the
above steps to create another channel of music.
5. When you are finished with all the channels that you wish to
fill with notes, press (Option) in the channel list screen to
access the following options:
Menus 139
•Play All: Plays the polyphonic ring tone that results from
mixing all channels.
•Play Channel: Plays the channel you have currently
scrolled to (if this channel does not contain any music
that you created, this option will not appear).
•Save: Select this option and your phone will
automatically mix the music you have created in the
channels into a polyphonic ring tone, and save this ring
tone to the menu Multimedia → Melody → My Melodies.
Press and enter a name for the ring tone and it will
be saved.
Help
Displays information on how to use the phone's keys in composing
ring tones.
Album
Photos taken using the phone's digital camera are stored in this menu.
After entering this menu, the two most recently saved photos will be
displayed on the left of the screen as thumbnails--small miniature
versions of photos, and the top of the screen will display the file name of
the currently highlighted photo thumbnail. On the right of each photo
thumbnail you will see the following information associated with the
photo:
•The date when the photo was taken: Shown as "yyyy.mm.dd".
•The photo's resolution: Shown as "width x height".
•The photo's file size: Shown as "xxx KB".
Steps for handling photos are as follows:
1. Press to scroll to the photo thumbnail you need.
140 Menus
2. Press to display the photo in full screen. Press to show the
next/previous photo.
3. When the display shows photo thumbnails, or after you press to
display a photo in full screen, you can press (Option) to perform
the following tasks with that photo:
•Send Photo: This option enables you to send the selected photo
to others through MMS. You can also do so by selecting the
menu: Messages →Create → MMS. For details on using the MMS
function, see page 66.
•Set to Wallpaper: Designates this photo as the wallpaper for the
main display's standby screen. You can also do so by using the
menu: Settings → Display → Wallpaper → Photo. See page 150.
•Set to Phonebook: You can use this photo as a Phone Book
contact's visual caller ID. When there is an incoming call from
that contact, the phone's display will show this photo.
New Entry: Enables you to create a new contact in the Phone
Book using this photo as the new contact's caller ID.
Exist Entry: Uses this photo as an existing contact's caller ID.
Select the contact you want and press to attach the photo
to that contact.
8This function is only available for contacts saved in the phone
memory's Phone Book. Please go to the menu: Phone Book →
Activate to select the Phone Book for use.
•Rename: Give this photo a new file name.
8A photo's name can't be left empty, nor can it share the same
name with another photo already stored in your phone.
•Details: Shows the photo's name, date, resolution, and file size.
•Delete: Deletes the selected photo.
Menus 141
•Delete all: Deletes all of the photos stored in the Album menu.
（this option is only available when the screen shows photo
thumbnails).
•Face Morph: You are able to change a person's facial expression
shown in the photo with this Face Morph function, and then save
photos showing different expressions of that person. Follw the
steps below to perform the Face Morph function:
a. The Face Morph function will generate various expression
effects for a person's face shown in the photo, according to
the four red spots you have manually positioned over the
photo. After you have entered the Face Morph option, the
selected photo will appear in full screen, along with the first
red spot displayed on it. Press to position this red spot
where you would like it to be over the person's face--press
to fine tune the position of the red spot; long press
to move the spot by a fixed space. When the first spot is in
the desired position, press to confirm. The next spot
will then show up automatically in order for you to adjust its
position.
b. You must first set the four spots' positions in order to
perform the Face Morph function. To generate the best
expression effects, it is recommended that the four spots be
placed over the corners of the eyes and the corners of the
mouth, which are normally used to make facial expressions.
Please follow the correct order below to set the positions
of the red spots: outer corner of the right eye (1) →outer
corner of the left eye (2) → right corner of the mouth (3)
→ left corner of the mouth (4).
142 Menus
c. To reset a red spot's position, press (Undo) to first
remove that spot, press to display it again in its default
position, and then press to adjust its position.
8The moment you finish setting the four spots' positions and
press , you can immediately press (Reset) to reset
all of the spots' positions.
d. When the spots are in desired positions, press . The
screen will show "Press number key to change," and then
will bring up the original photo with that person's face
remaining unchanged. At this point, you can press a
corresponding number key to generate the desired facial
expression effects for the person's face. The chart below
shows each number key and their matching expression
effects:
8Press (Normal) to display the original photo with no
expression effects made.
Key Expression Key Expression
Smile Angry
Young Funny
Slim Alien
Kiss Koala
Sleepy Monkey
Sad Fox
Menus 143
e. Press to intensify/reduce expression effects. Intensity
levels will be displayed at the top right corner of the screen
ranging from 1 to 5; the default value is 2.
f. When the photo shows desired expression effects, you can
press and save this new photo as a separate file. Enter
this new photo's file name, and then press to save it to
the Album menu.
g. After you have saved the photo showing the expression
effects you want, the original photo will reappear. You can
then again press corresponding number keys to create more
photos showing various facial expressions.
•The Face Morph function may not create desired outcomes
when used to change your pets or dolls' facial expressions.
•The Face Morph function cannot be applied to photos at the
resolution of 80 x 60.
144 Menus
Settings
Date & Time
Used to set the time and date, as well as the format in which the time
and date will be displayed on the startup screen.
Time
2. After selecting the Set mode, you can complete the date and time
fields.
Format
This option is used to decide the format in which the time and date
will appear in the standby screen.
1. Press to select either the Auto or Set mode
for this item:
Auto: Automatic time zone adjustment. If
during travel, you move between time zones,
the phone will automatically adjust the time
displayed on the screen based on the time zone
prompts provided by the local network operator
so that you always have access to accurate local
time.
Set: You phone will display the time you have
set, and when you travel to other time zones, the
phone will ignore time zone prompts issued by
the local network operator.
Menus 145
Secondary Time
Power On/Off
Allows you turn the phone on and off at specified times to conserve
power.
Power On
Designates a time for the phone to be automatically turned on. If
this option is activated, the phone will be automatically turned on
at the designated time each day.
Power Off
Designates a time for the phone to be automatically turned off. If
this option is activated, the phone will be automatically turned off
at the designated time each day.
When riding in an airplane or in any other situation where you cannot
use a mobile phone, remember to deactivate the Power On/Off
option.
Allows you to display the time in
another designated time zone. If you
choose to activate this option, the
standby screen will display the time in
that time zone along with your local
time.
Time in
secondary
time zone
146 Menus
Profiles
A profile is a group of settings that determine whether the phone will
alert you to incoming calls through a ring tone or a vibrating alert, and
how ring tones in general are used on the phone. These settings allow
the phone's operation to best suit the environment you are in.
1. Press to scroll to the desired profile and then press to
activate this profile. You can choose from among the following
profiles:
Normal
This is the default profile. Once this profile is activated, the
main display's status bar will show the icon; the external
display will show the .
Meeting
The options in this profile have been preset to suit a meeting
environment (for example, only a vibrating alert is used, with
no audible ring tone and no keypad tones). Once this profile is
activated, the main display's status bar will show the icon;
the external display will show the icon.
Outdoors
The options in this profile have been preset to suit an outdoor
activity (for example, use of the highest ring tone volume,
activation of both ring tone and vibrating alerts, and use of
keypad tones). Once this profile is activated, the main display's
status bar will show the ; the external display will show the
icon.
Menus 147
Handsfree
This profile is only active when a hands-free kit is attached to
the phone. Once this profile is activated, the main display's
status bar will show the icon; the external display will
show the icon.
Airplane
When you are on a plane, you can select this profile to turn off
the phone. Once this profile is activated, the phone will
automatically be powered off, and all alarms will be suspended.
If the phone is turned off by long-pressing , the alarms will
still turn the phone at the appointed times.
Personal
You can use this profile as a group of custom settings, and
rename the profile if desired. After activating this profile,
besides the appearance of the icon in the main display's
status bar and the icon on the external display, "Personal"
will appear as well. If however you have renamed this profile,
the name you chose will appear on the standby screens.
8The default profile name "Personal" or the name you give to
this profile will only appear on the external display when the
phone's flip is opened.
148 Menus
2. Press to scroll to the desired profile, and then press (Edit) to
modify the settings listed below and adjust the profile to suit a
particular environment.
8After entering the Edit menu, the setting for each option will be
displayed, providing a overview of the profile.
Vibrate
Includes the following setting options:
•Ring Only: When there is an incoming call, the phone will
use a ring tone but no vibrating alert.
•Vibrate Only: When there is an incoming call, the phone will
use a vibrating alert but no ring tone.
•Ring & Vibrate: When there is an incoming call, the phone
will use both a vibrating alert and a ring tone.
•Vibrate then Ring: When there is an incoming call, the phone
will first use a vibrating alert and then a ring tone.
Call Ring
Your phone includes various types of ring tone melodies. Scroll
to the desired ring tone, and after one second or so you will be
able to hear that ring tone. Press to confirm your selection.
Message Ring
The ring tone that your phone uses when a message is received.
Alarm Ring
The ring tone used by the Alarm Clock.
Calendar Ring
The ring tone used for Calendar events for which you have set
an alarm.
Menus 149
Keypad Tone
Determines whether keypad tones are played when keys are
pressed.
Ring Volume
Answer Mode
•Send Key: Allows incoming calls to be answered only by
pressing .
•Any Key: Allows any key except to be used to answer an
incoming call. In this mode, is used to reject an
incoming call, and not to answer.
•Automatic: If the Automatic answer mode is activated, the
phone will ring for five seconds, and then the incoming call
will be automatically answered (only the Handsfree profile
allows this setting).
Rename
Allows you to provide a new name for the profile (only
available for the Personal profile).
Restore
Returns the above settings for the profile to their factory
default values.
8Requires entry of the phone password, whose default value
is 1234.
Press to adjust the ring tone volume or
mute the ring tone.
150 Menus
Display
Theme
A display theme consists of a combination of display color and the
standby screen wallpaper. Different display colors are paired with
different preset wallpapers, so when you change the display color,
the standby screen wallpaper will also change. Scroll to the color
that you wish to use and then press (View) to preview the color
matched with the standby screen wallpaper. Press to confirm
the setting.
Wallpa per
Designates the wallpaper used for the main display's standby
screen.
Image: Here you can select an image/animation to use as the main
display's wallpaper. Scroll to the name of the image/animation that
you wish to use, and then press (View) to view this image/
animation. After you press (View) to enter the preview mode,
pressing will display the next or previous image/animation;
pressing will display it in full screen. Press to confirm
your selection.
/After you press (View) to enter the preview mode, pressing
will allow you to browse the wallpapers matched to the
colors.
Menus 151
Photo: Here you can select a photo saved in the phone memory as
the wallpaper.
Welcome Message
Used to select and configure the animation/picture/text that is
displayed when the phone is turned on, as well as the music that is
played.
•Animation: Only the animation selected in this option will be
displayed when the phone is turned on.
•Picture: Only the picture selected in this option will be displayed
when the phone is turned on. Images that have been saved from
messages can also be set for use in the welcome screen.
•Te x t : Only the welcome message entered in this option will be
displayed when the phone is turned on.
8Limit on length of entered text: 15 letters or numbers.
•Picture and Text: The picture and welcome message set in this
option will be displayed when the phone is turned on.
•Off: Returns the settings for startup music and animation to their
factory default values.
/You can also use this feature to change the wallpaper matched
with a color in the Theme option.
/Regardless of the settings you have made for the animation/
picture/text to be displayed when the phone is turned on, the
phone will play the music set in this option. Therefore, after
making settings for the animation/picture/text used for the
startup screen, the startup music must also be set.
152 Menus
Contrast
Brightness
Press to adjust the brightness of the phone's display
backlighting. Press to confirm the setting.
Backlight Setting
You can turn the phone's keypad backlighting and display
backlighting on or off, as well as set the length of time that
backlighting will remain activated after the flip is opened or a key is
pressed. After turning backlighting on, you can scroll to the Time
Duration option and then press (Edit) to set this length of time.
When done, press .
OLED Duration
•Default: After the external display cycles through displays of the
time and animations, it will power off, and will only power on
again when you press the upper or lower part of the volume key
on the left side of the phone, or open and then close the flip (if
a new message is received or there is an incoming call, the external
display will also power on and then, after cycling through the
programmed items, power off once more).
•Cycle: After the external display cycles through displays of the
time and animations, it will power off. After 15 seconds, the
external display will automatically power on and again cycle
through the programmed items.
Press to adjust the contrast of the screen's
display. Press to confirm the setting.
Menus 153
•Always On: The external display will remain on, cycling
continuously through displays of the time and animations.
OLED Animation Setting
You can set the animations to show on the external display. Press
(Select) to make your selections; press (Cancel) to clear the
animations that you have selected. When you are finished, press to
confirm your selections.
Audio
This menu allows you to set various sounds that the phone uses.
8Some of the options provided in this menu and the Profiles menu are
identical (for example, Call Ring). Therefore the particular setting that
the phone uses will depend on which menu you last used to make the
setting.
Power Saving Mode
After you activate the power saving mode, keypad and display
backlighting will be turned off, as will the status indicator lights on the
flip, in order to conserve power.
Because the phone's external display drains power from the
battery when it is on, selecting Cycle or Always On will reduce
battery life.
154 Menus
Call Settings
Call Divert
8 Requires the support of the network operator.
Forward All
Forwards all incoming calls to a designated phone number or
voicemail inbox. When you use this feature, you must enter a
phone number to which to forward incoming calls.
8After the Forward All mode is activated, the standby screen
will display the icon.
When Busy
The phone will divert incoming calls to another number when
you are in the middle of another call.
No Reply
Forwards incoming calls to another number when you do not
answer.
Not Reachable
Diverts incoming calls when your phone is turned off or
outside network coverage.
Cancel All
Cancels all call divert options.
Menus 155
Call Barring
You can request that your network operator block the dialing or
receiving of certain calls. The call barring services below require the
support of your network operator. To activate or cancel any of the
options below, you must enter the network password provided by
the network operator.
All Outgoing
Blocks dialing of any calls from the phone.
Intl. Out
If this option is activated, no international calls can be made
with your phone.
Intl. Except Home
If this option is activated, your phone can only be used to dial
local calls and calls to your home country from abroad. Other
international calls will be barred.
All Incoming
Rejects all incoming calls.
Incoming When Roaming
If you are in another country (using roaming), activating this
option will cause the phone to reject all incoming calls.
Cancel All
Cancels all call barring settings. You must enter the network
password in order to cancel these settings.
Change Password
You can change the network password, which can be obtained
from the network operator.
156 Menus
Call Waiting
If there is an incoming call when you are in the middle of another
call, the screen will display the number of the incoming call and call
waiting message to alert you. You can activate, cancel, or view the
status of this feature from this menu.
8You must apply to the network operator for the call waiting
service in order to use this feature.
Auto Redial
If there is no answer at a number you have dialed, the phone will
automatically redial.
Show Number
You can decide whether or not to display your phone number on
the recipient's phone when you make a call.
On: When you call someone, the recipient's phone will display your
phone number.
Off: Your phone number will not be shown on the recipient's
phone.
8If this feature is turned off, you may not be able to make phone
calls in certain countries, such as Singapore and China.
Preset: Whether your phone number will be displayed on a
recipient's phone will be determined by the default set by the
network operator.
Menus 157
Fixed Dial Number
After this feature is activated, the phone will only be able to dial
numbers on the Fixed Dial Number list. If a number is not on the
list, calls cannot be made to this number.
8When you activate or cancel this feature, you must enter the
PIN2 code.
Before activating the Fixed Dial Number feature, you must
press (View), then press (Option) and select Add to create a
Fixed Dial Number list. You must enter the PIN2 code, and then
add a new number to your Fixed Dial Number list.
After creating the list, you can view, edit and delete numbers in the
list.
Active Line
This feature allows you to use two different phone numbers on one
phone. You can designate one number for dialing calls, while
accepting incoming calls dialed to both numbers without needing
to use two phones. Select either Line 1 or Line 2. The number you
select ( or ) will appear on the standby screen.
8This feature requires the support of the network operator.
Connect Alert
This feature allows the phone to provide a ring tone or vibrating
alert, or flash the backlighting when the recipient of a call has
answered.
If the PIN2 code is entered incorrectly three consecutive times,
the PIN2 code will be locked down. You will need the PUK2 code
to unlock the PIN2 code. Contact your network operator to obtain
the PUK2 code.
158 Menus
Minute Beep
Once this option is activated, the phone will emit a beep once every
minute during a call.
Network
Generally speaking, the choice of the network that your phone uses is
configured automatically. When turned on, the phone will
automatically connect to the network provided by your network
operator, or will automatically connect to the roaming network when
you are outside the coverage of your regular network.
If you wish to change the connection network, this menu will allow you
to select the network you want to use. When outside the coverage of
your regular network in your home country or when abroad, you can
manually select the local network system.
8Your network operator must be able to support network selection in
order for you to use this feature.
Mode Selection
You can choose whether the network selection mode that the phone
will use when it is turned on is automatic or manual.
Automatic: If this option is selected, when outside the coverage of
your regular network, the phone will automatically search for
usable networks.
Manual: If this option is selected, when outside the coverage of
your regular network, the phone will list all the networks of telecom
vendors and allow you to choose.
Available List
Allows you to manually select a network. Your phone will list all the
networks of telecoms vendors so you can choose.
8Not all networks listed will necessarily be available for use. If you
require further information, contact your network operator.
Menus 159
Band Setting
According to your requirements, you can set an appropriate band
in the GSM network system.
Connection Mode
Used to set whether the phone will also search for a GPRS network
when it is turned on.
•GPRS & GSM: When it is turned on, the phone will search for
available GPRS and GSM networks.
•GSM Only: When it is turned on, the phone will search only for a
GSM network.
Security
You can use a PIN code, phone password, and SIM card lock
authentication to prevent unauthorized use of the phone.
PIN Code
A PIN (Personal Identification Number) code is a password
provided by a network operator. When PIN code authentication is
activated, it will prevent unauthorized use of the SIM card. Unless
the correct PIN code is entered when the phone is turned on, the
SIM card cannot be used, even if it is inserted in another phone.
PIN1 Code
Used to activate/deactivate or change the PIN1 code. Before
changing settings for the PIN1 code feature, the previously set
PIN1 code must be entered.
,
If the PIN code is entered incorrectly three consecutive times,
this will cause the SIM card to lock down, and a PUK1 code
provided by the network operator will be required to unlock it.
After unlocking, the PIN code will be automatically set to activate
once the phone is turned on.
160 Menus
If you wish to change the PIN1 code, you must press in
the Enable item to select On, so that you will be able to enter
and confirm the new password.
PIN2 Code
Used to change the PIN2 code. The procedure is the same as for
the PIN1 code.
Phone Lock
Activates/deactivates or changes the phone's startup password. The
startup password prevents unauthorized persons from using your
phone. Once the phone's password is activated, the phone will be
locked down when it is turned on unless this password is correctly
entered. If an incorrect password is entered, your phone will remain
locked down, and cannot be unlocked even if the SIM card is
replaced by another one. When the phone is locked, you will only
be able to make emergency calls.
Once the phone password is activated, you must enter the password
each time the phone is turned on in order to unlock the phone
(there is no limit on the number of attempts to enter the phone
password).
The procedure for setting the phone password is the same as for the
PIN1 code (the default phone password is 1234).
Menus 161
SIM Lock
Using this feature, you can prevent unauthorized persons from
using your phone with other SIM cards. After you activate the SIM
Lock feature, only the SIM card present when the feature was
activated will be accepted by the phone. If a new SIM card is
inserted in the phone, when the phone is turned on and a PIN code
is entered, the phone will request entry of a SIM Lock password
(there is no limit on the number of attempts to enter the SIM Lock
password.
If the password is entered correctly, the phone will be able to
recognize the new SIM card and use it normally. The next time the
phone is turned on with this SIM card inserted, the phone will not
ask again for you to enter the SIM Lock password.
8Your phone can recognize a maximum of three different SIM
cards.
Before setting the SIM Lock feature, you must enter the previously
set SIM Lock password (the default SIM Lock password is 1234).
The password must be between 4 and 8 digits in length.
Screen Lock
Used to create a security screensaver. When you
have not performed any tasks with the phone for a
set period of time, the phone will automatically
activate the screensaver shown on the left, the
purpose being to prevent personal information on
the phone from being viewed by others. To return
to the original screen, after pressing any key, you must enter the
password you set for this feature.
The steps for setting the Screen Lock feature are as follows:
1. You must first enter the Screen Lock password that was
previously set (the default password is 1234).
162 Menus
2. Press in the Enable option to select On, and then press
to scroll to the Timeout item.
3. In the Timeout item, press (Edit) or press to set the
period of inactivity before the phone will enter the Screen Lock
mode.
4. After completing settings, press . The phone will prompt you
to enter and confirm the Screen Lock password. You have two
choices:
a. If you do not wish to change the password, press to
activate the Screen Lock feature using the previously set
password.
b. If you wish to change the password, enter the new password
in the New Password and Confirm fields, then press to
use the new password and activate the Screen Lock feature.
Language
You can select the language that the phone will use to display
information.
Input Mode
You can set the default input mode that will be automatically activated
whenever you open the editing window for entering information into a
message, the Phone Book, and so forth.
Flip Activate
Activates/deactivates the active flip feature.
Menus 163
User Group
User Group
Used to create a closed group of callers based on a service provided
by the network operator. The members of a User Group can call
each other, but cannot conduct calls with anyone outside the group
unless special provisions are made. This option can be used to
select whether or not to activate this service.
Outside Access
When the User Group service is activated, enabling Outside Access
will allow users in the group to make calls to numbers outside the
group. However, incoming calls will still be restricted to calls from
within the group.
Restore
Restores all of the phone's settings to their factory defaults.
164 Care and Maintenance
Care and Maintenance
Take note of the points noted below to ensure that you are using the
phone properly and to extend the lifespan of the phone.
•Store the phone and its accessories out of the reach of children.
•Keep the phone and accessories dry, and use the phone in
environments where the temperature is between –20°C and 55°C.
High or low temperatures outside this range may damage the phone.
•If possible, do not use or store the phone in excessively dusty or dirty
environments.
•Do not remove the warranty seal on the phone yourself, nor allow an
unauthorized dealer to do so.
•Do not use strong detergents or organic solvents to wipe or clean the
phone.
•If your phone or its accessories are not operating normally, contact an
authorized dealer immediately.
•Use only genuine BenQ accessories such as batteries, battery charger
and hands-free kit to ensure the phone's normal operation and
preserve battery life, as well as protect the safety of your person and
belongings. Use of non-BenQ accessories will not allow your phone to
achieve optimal performance, and may cause the phone to
malfunction. Any malfunctions or damage caused by the use of third-
party accessories are not be covered by the terms of the product
warranty, and will void the product warranty.
•Avoid allowing objects that may discharge electricity to contact the
charging socket on the bottom of the phone or the metal contacts on
the battery, as this may cause short circuits and put you in danger.
Troubleshooting 165
Troubleshooting
If you encounter problems while using the phone, or if it performs
erratically, you can consult the information in the chart below. If your
particular problem cannot be resolved using the information in the
chart, contact the dealer where you purchased the phone.
Problem Possible cause Solution
Poor
reception
•The network signal is too
weak at your current
location —for example, in
a basement or near a tall
building-because wireless
transmissions can not
effectively reach it.
Move to a location where the
network signal can be
properly received.
•The network is busy at
the current time (for
example, during peak
times, there may be too
much network traffic to
handle additional calls).
Avoid using the phone at
such times, or try again after
waiting a short time.
•You are too far away from
a base station for your
network operator.
You can request a service
area map from your network
operator.
Echo or noise
•Poor network trunk quality
on the part of your
network operator.
Hang up the phone and dial
again. You may be switched
to a better-quality network
trunk or phone line.
•Poor local telephone line
quality.
166 Troubleshooting
Shortened
standby time
•The standby time is
related to your network
operator's system
configuration. The same
phone used with different
network operators'
systems will not provide
exactly the same length
of standby time.
If you are located in an area
where signaling is weak,
temporarily shut off the
phone.
•The battery is depleted. In
high-temperature
environments, battery life
will be shortened.
Use a new battery.
•If you are not able to
connect to the network,
the phone will continue to
send out signals as it
attempts to locate a base
station. Doing so
consumes battery power
and will consequently
shorten standby time.
Change your location to one
where the network is
accessible, or temporarily
turn off your phone.
You cannot
switch your
phone on.
•Battery power has been
depleted.
Recharge the phone's
battery.
SIM card
error
•SIM card malfunction or
damage.
Take the SIM card to your
network operator for testing.
•SIM card inserted
improperly.
Insert the SIM card properly.
•Debris on the SIM card
contacts.
Use a soft, dry cloth to clean
the SIM card contacts.
Problem Possible cause Solution
Troubleshooting 167
Unable to
connect to the
network.
•SIM card invalid. Contact your network
operator.
•You are not within the
network's service area.
Check the service area with
your network operator.
•Poor signal. Move to an open space, or if
you are inside a building,
move closer to a window.
You cannot
answer
incoming
calls.
•You have activated
Accept List or Reject
List in the Privacy
Manager option.
Go to the menu Phone
Book → Privacy Manager
and then select Off in order
to deactivate this option.
•You have activated the
Call Barring feature.
Go to the menu Settings →
Call Settings → Call
Barring, and then select
Cancel All.
You cannot
make
outgoing
calls.
•You have activated the
Call Barring feature.
Go to the menu Settings →
Call Settings → Call
Barring, and then select
Cancel All.
•You have activated the
Fixed Dial Number
feature.
Go to the menu Settings →
Call Settings → Fixed Dial
Number, and then select
Off to turn off this feature.
PIN Code is
blocked.
•You have entered an
incorrect PIN code three
consecutive times.
Contact your network
operator. If the network
operator provides the SIM
card's PUK code, use the
PUK code to unlock the SIM
card.
Problem Possible cause Solution
168 Troubleshooting
Battery will
not charge.
•The battery or battery
charger is damaged.
Contact the dealer.
•The phone's temperature
is below 0°C or higher
than 45°C.
Adjust the battery charging
environment to avoid
extremes of temperature.
•Poor contact between the
battery and charger.
Check all connectors to
make sure all connections
have been properly made.
Unable to
enter
information
into the
Phone Book.
•The Phone Book's
memory is already full.
Delete unnecessary data
from the Phone Book.
Unable to
select certain
features.
•Your network operator
does not support these
features, or you have not
applied for services that
provide these features.
Contact your network
operator.
Problem Possible cause Solution
