Billion Electric BIL-5200WTR2 Wireless-N ADSL2+ Firewall Router User Manual Manual
Billion Electric Co., Ltd. Wireless-N ADSL2+ Firewall Router Manual
User manual
%LOOLRQ
%L3$&:75
:LUHOHVV1$'6/
)LUHZDOO5RXWHU
Quick Start Billion 4 PORT Wi-Fi Router
Thank you for purchasing Billion 4 PORT Wi-Fi Router (here in after referred to as the Billion 4 PORT Wi-Fi
Router).
With the Billion 4 PORT Wi-Fi Router you can access the Internet at a high speed while making a phone
call.
If there is a need to configure the device in your application, please ask for
necessary information and guidance from your ISP.
Packing List
Open the package with care and make sure that you have the following items:
Billion 4 PORT Wi-Fi Router
Splitter
dedicated power adapter
RJ-11 telephone cables
straight-through Ethernet cable
Quick Guide
Overview
Billion 4 PORT Wi-Fi Router gives full consideration to the household arrangements, as well as hanging
on the wall. Picture below shows how it stands on your table.
2
