MBP18 - Quick Start Guide
For a full explanation of all features and instructions, please refer to the User's Guide.
1 Setting up your digital baby monitor
Connecting power supply for the Baby unit
A
• Connect the small plug
of the power adapter to
the baby unit and the
other end to the
electrical outlet.
• Only use the enclosed
adapter (6V DC /
500mA).
Installing the battery pack for the Parent unit
B
Red
Black
• Insert the wire tab of
the rechargeable
battery pack into the
contact slot as shown
above and fit the
battery pack into the
compartment.
Connecting power supply for the Parent unit
D
• Connect the small plug
of the power adapter to
the parent unit and the
other end to the
electrical outlet.
• Only use the enclosed
adapter (6V DC /
500mA).
Fastening the cover for the Parent unit
C
Small cross head or Flat
end screw driver.
MBP18_QSG_EN_US.fm Page 1 Friday, November 9, 2012 12:04 PM
2 Basic operation of the keys
3 General Information
If your product is not working properly...
1. Read this Quick Start Guide or the User’s Guide.
2. Visit our website: www.motorola.com
3. Contact Customer Service:
Parent unit
PON/OFF button Press and hold to turn the unit ON/OFF.
UP/VOL+ buttons Press to increase sound volume. Press to adjust menu up setting.
DOWN/VOL- buttons Press to decrease sound volume. Press to adjust menu down setting.
MENU/OK button Press to open menu options or exit.
Press to confirm a selection.
Press to pan right in 2x zoom level.
Return/Switch Camera
button
Press to return to previous menu level.
Press to switch camera units. (if paired with more than one camera)
Press to pan left in 2x zoom mode.
VVIDEO button Press to turn the LCD display ON/OFF.
ZZOOM button Press once to switch to 2x zoom level.
Toggle again to return to normal view (1x).
Baby unit
ON/OFF switch Push power switch to the right to switch on the unit. Push power switch to the left to switch off the unit.
