User manual
User’s Guide
Video Baby Monitor with Touchless
Thermometer
Models: MBP27T, MBP27T/2, MBP27T/3, MBP27T/4
The features described in this User's Guide are subject to modifications without prior notice.
Welcome...
to your new Motorola Baby Monitor!
Thank you for purchasing the MBP27T, MBP27T/2, MBP27T/3, MBP27T/4.
Now you can see and hear your baby sleeping in another room or you can
monitor your older children in their playroom.
Please retain your original dated sales receipt for your records.
For warranty service of your Motorola product, you will need to provide a
copy of your dated sales receipt to confirm warranty status. Registration is
not required for warranty coverage.
For product related questions, please call:
This User's Guide provides you with all the information you need to get the
most from your product.
Before you can use the Baby Monitor, we recommend you insert and fully
charge the battery in the Parent Unit, so that it continues to work if you
disconnect it from the power supply to carry it to another location. Please
read the Safety Instructions on page 6 before you install the units.
Got everything?
• 1 x Parent unit
• 1 x Baby unit (camera)
• 1 x Rechargeable Ni-MH battery pack for the Parent Unit
• 1 x Power adapter for the Parent Unit
• 1 x Power adapter for the Baby Unit
• 1 x Belt Clip
In multi-camera packs, you will find one or more additional Camera Units
with power adapter units.
US and Canada 1-888-331-3383
Email: motorola@encompass.com
Overview of the Parent Unit
1. Display (LCD screen)
2. Object temperature mode
Press and hold to measure the liquid
temperature
3. Forehead temperature mode
Press and hold to measure the body
temperature at forehead
4. Scroll Up/Volume+ Button
5. Scroll Down/Volume- Button
6. Return/Switch Camera Button
Press to return to previous menu level.
Press to switch camera units (if paired with
more than one camera).
Press to pan left in digital pan/tilt mode.
7. Menu/OK Button
Press to open the menu options.
Press to confirm a selection.
Press to pan right in digital pan/tilt mode.
8. Digital Pan/Tilt
Press to enter/exit digital pan/tilt mode
9. Talk Key
Press and hold to talk back through the
camera.
10. Power Indicator LED turns BLUE when
the unit is on and the power adapter is
plugged in.
11. Unit ON/OFF LED (Green)
12. Audio Level LED (Green, Orange, Red,
Red)
13. Power / Video On-Off Button P
Press and hold to turn the Unit
ON or OFF.
In monitor mode, press to turn the
display ON/OFF
14. Battery cover
15. Stand
16. Speaker
17. Power Adapter Socket
18. Belt Clip
19. Probe tip
POWER
17
13
18
15
14
19
1
3
9
4
7
5
10
8
2
6
16
11
12
Parent unit menu icons
Signal Level Indication (5 Levels)
Night Vision Mode (Video also changes to Black/White)
Battery Level Indication (4 Levels)
Volume Level Control (8 Levels)
Brightness Level Control (8 Levels)
Alarm Setting (6h, 4h, 2h, OFF)
Camera setting
Add Camera
Delete Camera
Select Camera
Digital Pan/Tilt mode On
Camera scan mode set
Forehead Temperature Record
Select C/F
1
N
*
Overview of Your Baby Unit
Important guidelines for installing your Baby Monitor
• To use your Video Monitor Baby and Parent Units together, you must be able
to establish a radio link between them, and the range may be effected by
environmental conditions.
• Any large metal object, like a refrigerator, a mirror, a filing cabinet, metallic
doors or reinforced concrete between the Baby and Parent Unit may block
the radio signal.
• The signal strength may also be reduced by other solid structures, like walls,
or by radio or electrical equipment, such as TVs, computers, cordless or
mobile phones, fluorescent lights or dimmer switches.
• Use of other 2.4 GHz products, such as wireless networks (Wi-Fi® routers),
Bluetooth® systems, or microwave ovens, may cause interference with this
product, so keep the Baby Monitor away at least 3 to 4.5 feet (1 to 1.5 meters)
from these types of products, or turn them off if they appear to be causing
interference.
• If the signal is weak, try moving the Parent and/or the Baby Unit to different
positions in the rooms.
1. Photo Sensor (Night Vision Mode) 6. Power Adapter Socket
2. Camera Lens 7. Pair Key
3. Infrared LEDs 8. Microphone
4. Power LED 9. Speaker
5. ON/OFF Switch
9
1
5
7
8
2
4
36
Table of contents 5
ENGLISH
Table of contents
1. Safety Instructions..................................................................................... 6
2. Getting Started.......................................................................................... 8
2.1 Baby Unit Power Supply..............................................................................8
2.2 Parent Unit Battery Installation ....................................................................8
2.3 Parent Unit Power Supply ...........................................................................9
2.4 Registration (Pairing).................................................................................11
3. Using the Baby Monitor...........................................................................12
3.1 Setting up...................................................................................................12
3.2 Night Vision Mode.....................................................................................12
3.3 Video ON/OFF..........................................................................................12
3.4 Talk Mode.................................................................................................. 12
3.5 Touchless Thermometer ...........................................................................12
3.5.1 Forehead Temperature Mode .................................................. 13
3.5.2 Object Temperature Mode ......................................................13
4. Parent Unit Menu Options....................................................................... 14
4.1 Volume.......................................................................................................14
4.2 Brightness ..................................................................................................14
4.3 Digital Pan and Tilt..................................................................................... 14
4.4 Alarm..........................................................................................................14
4.5 Camera Control ........................................................................................15
4.5.1 Add (pair) a camera ..................................................................15
4.5.2 View a camera ...........................................................................15
4.5.3 Delete a camera ........................................................................16
4.5.4 Scan the cameras ......................................................................16
4.6 Body Temperature Measurement Review ...............................................17
4.7 Change of Measurement Scale ................................................................17
5. Disposal of The Device (environment) ................................................... 18
6. Cleaning .................................................................................................. 19
7. Help.......................................................................................................... 20
8. General Information ................................................................................ 22
6Safety Instructions
1. Safety Instructions
WARNING
This Digital Video Baby Monitor is compliant with all relevant standards
regarding electromagnetic fields and is, when handled as described in the
User's Guide, safe to use. Therefore, always read the instructions in this User's
Guide carefully before using the device.
• Adult assembly is required. Keep small parts away from children when
assembling.
• This product is not a toy. Do not allow children to play with it.
• This baby monitor is not a substitute for responsible adult supervision.
• Keep this user's guide for future reference.
• Do not place the baby unit or cords in the crib or within the reach of the baby.
• Keep the cords out of reach of children.
• Do not cover the baby monitor with a towel or blanket.
• Test this monitor and all its functions so that you are familiar with it prior to
actual use.
• Do not use the baby monitor in moist places or close to water.
WARNING:
STRANGULATION HAZARD - Keep the unit and adapter cords more than
3 feet from the crib and out of baby’s reach. NEVER place camera or cords
within the crib. SECURE the cord. Never use extension cords with AC
Adapters. Only use the AC Adapters provided.
CAMERA SET UP & USE:
●Determine a location for the BABY UNIT that will provide the best view
of your baby in his/her crib.
●Place the BABY UNIT on a flat surface, such as a dresser, bureau, or
shelf, or wall mount it securely using the keyhole slots under the stand.
●NEVER place the Baby Unit or cords within the crib.
Safety Instructions 7
ENGLISH
• Do not install the baby monitor in extreme cold or heat, direct sunlight, or
close to a heat source.
• Only use the chargers and power adapters provided. Do not use other
chargers or power adapters as this may damage the device and battery pack.
• Only insert a battery pack of the same type.
• Do not touch the plug contacts with sharp or metal objects.
• Connect the power adapters to easily accessible mains sockets.
CAUTION
Risk of explosion if battery is replaced by an incorrect type.
Dispose of used batteries according to their instructions.
8Getting Started
2. Getting Started
2.1 Baby Unit Power Supply
1. Connect the small plug of the power adapter to the Baby Unit (camera) and
the other end to the electrical outlet.
NOTE
Only use the enclosed power adapter (6V DC / 500mA) with the slightly larger
DC plug.
2. Slide the ON/OFF switch to the ON position. The power LED will light up
in orange.
3. Slide the ON/OFF switch to the OFF position to turn the Baby Unit off.
2.2 Parent Unit Battery Installation
The supplied rechargeable battery pack should be fitted so the Parent Unit can
be moved without losing the link with the camera. Charge the battery in Parent
Unit before first time use or when the Parent Unit indicates the battery is low.
1. Insert the plug of the rechargeable battery pack into the small socket inside
the battery compartment as shown above and fit the battery pack into the
compartment.
Black
Red
Getting Started 9
ENGLISH
2. Place the battery cover over the compartment and gently tighten the
screw in a clockwise direction using a Small cross head or Flat end
screwdriver.
2.3 Parent Unit Power Supply
IMPORTANT
Installing the rechargeable battery pack and charge it fully before use is
recommended. This will allow the unit to operate on battery in the event of a
power failure, or when moving to a different room.
1. Connect the small plug of the power adapter to the Parent Unit and the
other end to the electrical outlet. Only use the enclosed power adapter
(6V DC/500mA) with the slightly smaller DC plug.
2. Press and hold the P POWER ON/OFF button for 1 second to turn ON
the Parent Unit.
3. Once the Baby and Parent Units are switched on, the display on the Parent
Unit will show the video captured by the Baby Unit.
Small cross head or
Flat end screwdriver.
POWER
10 Getting Started
4. If there is no connection or you are out of range, the video display will go
off and the symbol will flash on the LCD display, and the unit will beep
every 9 seconds. (If the unit is on scan the
1 ?
symbol displays.)
Move the Parent Unit closer to the Baby Unit the link is re-established.
5. Press and hold the P POWER ON/OFF button, until the progress bar
scrolls fully across, to turn OFF the Parent Unit.
NOTE
The battery icon will turn RED and flash to indicate that the battery is low,
and it will beep approximately every 5 seconds. The battery needs to be
recharged. The battery pack will take approximately 16 hours to charge.
When charging
1. If the Parent Unit is turned OFF, when the adapter is plugged in, it displays
a "mains plug" icon briefly, then a large battery icon with internal segments
cycling for 60 seconds, before the display goes blank, but the unit will
continue to charge. The Blue LED at top left corner will light up to indicate
the adapter is plugged in.
2. If the Parent Unit is turned ON, when the adapter is plugged in, the battery
icon in the screen's top right corner will show that the battery is charging by
cycling the internal segments. The segments stop cycling when the battery
is fully charged. The Blue LED at top left corner will light up to indicate the
adapter is plugged in.
0
Getting Started 11
ENGLISH
2.4 Registration (Pairing)
The Baby Monitor Camera is pre-registered to your Parent Unit. You do not
need to register it again unless the Baby Unit loses its link with the Parent Unit.
To re-register your Baby Unit, or register a new Baby Unit, follow the procedure
below:
1. Press the button of the Parent Unit and then press the - DOWN button
to select the Camera setting icon , and press the button to enter.
Press the - DOWN button to select ADD CAMERA icon , and press
the button to confirm.
2.
1
/
2
/
3
/
4
will pop up, press the + UP button or - DOWN button to
select the desired Camera identification number and press the button to
start searching for a Camera Unit. The Green Audio Level LED turns on will
appear while searching.
3. Press and hold the PAIR button under the bottom left edge of the Camera
Unit until the Parent Unit finds the Camera, beeps and the video from the
Camera appears.
NOTE
If a particular Baby Unit was registered previously, registering this current Baby
Unit again will overwrite the old registration.
If a Camera Unit is not found within about 30 seconds, the search will end and
the Parent Unit will return to its previous mode.
12 Using the Baby Monitor
3. Using the Baby Monitor
3.1 Setting up
• Place the Baby Unit in a convenient location (e.g. on a table) and point the
camera lens towards the area you want to monitor.
• Adjust the Baby Unit's head angle by rotating the camera up, down, left and
right until you are satisfied with the image in the Parent Unit.
NOTE
Do not place the Baby Unit within reach of a child or baby(s)! If there is
interference with the picture or sound, try moving the units to different locations,
and ensure they are not close to other electrical equipment.
3.2 Night Vision Mode
The Baby Unit has 8 high-intensity infrared LEDs for picking up clear images in
the dark. When the built-in photo sensor on the top of the unit detects a low level
of ambient light, the LEDs will automatically activate and the screen on the
Parent Unit will display in black and white. The N icon will be displayed at the top
of the screen.
3.3 Video ON/OFF
Press the VIDEO ON/OFF button V on the Parent Unit to turn the LCD display
on or off, but still leave the audio monitor on.
3.4 Talk Mode
Press and hold the T TALK button on the Parent Unit to talk to your baby through
the Baby Unit's loudspeaker. The T icon will be displayed at the top of the LCD
screen.
3.5 Touchless Thermometer
The thermometer is designed to precisely measure the temperature of the
forehead between the eye socket and the hairline. Due to the unique body
physiology of each person, it is recommended that you take a person's
temperature at the same temple location to compare measurements. High,
prolonged fever requires medical attention especially for young children.
Please contact your physician.
Using the Baby Monitor 13
ENGLISH
3.5.1 Forehead Temperature Mode
• Always make sure the probe lens is clean without any, damage
free and the forehead is clean.
• Place the probe tip about 1 cm away from the central forehead
of the baby (Fig. 1)
• Press and hold the Forehead Temperature button until you hear the beep and
the reading displays on the LCD screen.
Note:
a. Temperature Measurement Range: Forehead temperature
mode: 32~42.2°C (89.6~108°F)
b. Forehead temperature is displayed in oral mode. This mode converts the
forehead temperature to display its "oral-equivalent" value.
c. Before the measurement, please stay in a stable environment for
approximately 5 minutes. Avoid bathing or strenuous movement for at
least 30 minutes prior to taking the measurement. “Normal” body
temperature can vary from person to person and changes according to
time of day and body location. Drinking hot or cold drinks may change
body temperature by one degree or more.
d. Remember to keep the forehead area clean and dry while taking
temperature.
3.5.2 Object Temperature Mode
Point the probe tip at about 1 cm away from the liquid surface. Press and hold
the liquid temperature button to the liquid surface temperature like milk or bath
tub temperature. The reading will be displayed at the LCD screen.
Note:
a. Temperature Measurement Range: Object temperature mode:
-20~80°C (-7.6~176°F)
b. Application include temperature measurements for water, milk, cloth, skin
or other objects.
c. This mode shows the actual and unadjusted surface temperature which is
different from the body temperature.
Figure 1
14 Parent Unit Menu Options
4. Parent Unit Menu Options
4.1 Volume
1. While in monitor mode, press the + UP button or - DOWN button to
select the desired volume level from level 1 ~ 8. (The default volume level
setting is level 4.)
4.2 Brightness
1. Press the button and the first menu option will appear.
2. To select the BRIGHTNESS icon press the button.
3. Press the + UP button or - DOWN button to select the desired brightness
level from level 1 ~ 8. (The default brightness level setting is level 4.)
4. Press the button to return to the monitor mode or the device will
automatic return to the monitor mode after 30 seconds.
4.3 Digital Pan and Tilt
1. Press the Pan & Tilt button.
2. Press the + UP button or - DOWN button to move the display view up or
down, or press the and buttons to pan the display view left and right.
4.4 Alarm
1. Press the button and the first menu option will appear.
2. Press the - DOWN button to show the ALARM icon and press
button to confirm.
3. Press the + UP button or - DOWN button to select the alarm time
(
6h
,
4h
,
2h
). (The default setting is Alarm OFF (X).)
If an alarm time is selected, the Parent Unit will beep at the end of the
selected 2, 4 or 6 hour period, and the alarm icon will flash red. The alarm
is cancelled after 60 seconds or by pressing any button on the Parent
Unit.
Parent Unit Menu Options 15
ENGLISH
4.5 Camera Control
4.5.1 Add (pair) a camera
1. Press the button and the first menu option will appear.
2. Press the - DOWN button to select the Camera setting icon , and
press the button to enter. Press the - DOWN button to select ADD
CAMERA icon and press the button to confirm.
3.
1
/
2
/
3
/
4
will pop up, press the + UP button or - DOWN button to
select the desired Camera identification number, and press the button
to start searching for a camera unit. The Green Audio Level LED turns on
while searching.
4. Press and hold the PAIR button underneath the Baby Unit until the Parent
Unit finds the camera, beeps and the picture from the camera appears.
NOTE
A camera can only be registered to one Parent Unit at any one time.
4.5.2 View a camera
1. Press the button and the first menu option will appear.
2. Press the - DOWN button to select the Camera setting icon , and
press the button to enter. Press the - DOWN button to select VIEW
CAMERA icon and press the button to confirm.
3.
1
/
2
/
3
/
4
will pop up, press the + UP button or - DOWN button to
select the desired Camera unit, and press the button to view the picture
from that camera.
TIP
Quick Method to View Cameras instead of using the menu.
Directly press repeatedly to select
1
/
2
/
3
/
4
or .
16 Parent Unit Menu Options
4.5.3 Delete a camera
1. Press the button and the first menu option will appear.
2. Press the - DOWN button to select the Camera setting icon , and
press the button to enter. Press the - DOWN button to select DELETE
CAMERA icon and press the button to confirm.
3.
1
/
2
/
3
/
4
will pop up, press the + UP button or - DOWN button to
select the desired Camera unit, press the button then press the -
DOWN button to select the DELETE CAM icon .
4. Press the button to confirm the deletion or RETURN button to exit.
NOTE
You cannot delete the camera if it is the only camera paired in the system.
4.5.4 Scan the cameras
1. Press the button and the first menu option will appear.
2. Press the - DOWN button to select the Camera setting icon , and
press the button to enter. Press the - DOWN button to select and
choose the symbol for scan selection.
3. The screen will then display images from each registered cameras in a
loop, changing about every 10 seconds.
TIP
Quick Method to View Cameras instead of using the menu.
Directly press repeatedly to select
1
/
2
/
3
/
4
or .
NOTE
If the Parent Unit is in scan mode and one of the registered cameras is turned off
or out of range, the scan will stop at the missing camera
(e.g. camera) and display the
3 ?
icon while emitting a warning beep every
8 seconds.
WARNING
Check the camera and correct the fault immediately if you are using that
camera to monitor your baby.
If you want to continue in camera scan mode without that camera, delete the
camera (see 4.5.3 Delete a camera) and start the scan again.
Parent Unit Menu Options 17
ENGLISH
4.6 Body Temperature Measurement Review
1. Press the button and the first menu option will appear.
2. Press the - DOWN button to show the record icon and press
button to confirm.
3. Press - button to review previous measurement record (body
temperature only).
4.7 Change of Measurement Scale
1. Press the button and the first menu option will appear.
2. Press the - DOWN button to show the Thermometer icon and press
button to confirm.
3. Press the button to show the C/F selection icon
°C and °F
.
4. Press the + UP button or - DOWN button to select.
18 Disposal of The Device (environment)
5. Disposal of The Device (environment)
At the end of the product lifecycle, you should not dispose of
this product with normal household waste. Take this product to
a collection point for the recycling of electrical and electronic
equipment. The symbol on the product, user's guide and/or
box indicates this.
Some of the product materials can be reused if you take them to
a recycling point. By reusing some parts or raw materials from used products
you make an important contribution to the protection of the environment.
Please contact your local authorities in case you need more information on the
collection points in your area.
Dispose of the battery pack in an environmentally-friendly manner according to
your local regulations.
Cleaning 19
ENGLISH
6. Cleaning
Clean the MBP27T, MBP27T/2, MBP27T/3, MBP27T/4 with a slightly damp cloth
or with an anti-static cloth.
Never use cleaning agents or abrasive solvents.
Cleaning and care
• Do not clean any part of the product with thinners or other solvents and
chemicals – this may cause permanent damage to the product which is not
covered by the warranty.
• Please make sure the probe is clean to ensure an accurate reading.
• The probe tip is the most delicate part of the thermometer. Use with care
when cleaning the probe tip to avoid damage.
• Use a 70% alcohol swab or a soft cotton moistened with 70% alcohol solution
to clean the probe lens.
• Allow the probe to fully dry for at least 1 minute.
• Keep the unit dry and away from any liquids and direct sunlight.
• The device should not be submerged into liquids.
• Keep your MBP27T, MBP27T/2, MBP27T/3, MBP27T/4 away from hot, humid
areas or conditions, strong sunlight and avoid moisture.
• Every effort has been made to ensure high standards of reliability for your
MBP27T, MBP27T/2, MBP27T/3, MBP27T/4. However, if something does go
wrong, please do not try to repair it yourself – contact Customer Service for
assistance.
20 Help
7. Help
Display
No display
• Try recharging or replacing the battery pack.
• Reset the units. Disconnect the battery pack of the Parent Unit and unplug
both the units' electrical power, then plug them back in.
• Is the unit turned on?
Press and hold the ON/OFF button P on the Parent Unit to turn it ON.
• Is the correct camera selected?
Change the camera number, if necessary.
• Is the video display turned on?
Press the VIDEO ON/OFF button V to turn it on.
• When operating using batteries only, the Display will go blank after
4 minutes to save power. The unit is still active and will give you audio alerts.
You can reactivate the screen by pressing any button.
Registration
If the Baby Unit has lost its link with the Parent Unit
• Try recharging or replacing the battery pack.
• If the Baby Unit is too far away it may be going out of range, move the Baby
Unit closer to the Parent Unit.
• Reset the units by disconnecting them from the battery and electrical power.
Wait about 15 seconds before reconnecting. Allow up to one minute for the
Baby Unit and the Parent Unit to synchronise.
• See 2.4 Registration (Pairing), if there is a need to re-register the units.
Help 21
ENGLISH
Interference
Noise interference on your Parent Unit
• Your Baby and Parent Units may be too close. Move them farther apart.
• Make sure there is at least 3 to 4.5 feet (1 to 1.5 meters) between the
2 units to avoid audio feedback.
• lf the Baby Unit is too far away it may be out of range, try moving the Baby
Unit closer to the Parent Unit.
• Make sure the Baby and Parent Units are not near other electrical equipment,
such as a television, computer or cordless/mobile telephone.
• Use of other 2.4 GHz products, such as wireless networks (Wi-Fi® routers),
Bluetooth® systems, or microwave ovens, may cause interference with this
product, so keep the Baby Monitor away at least 3 to 4.5 feet (1 to 1.5 meters)
from these types of products, or turn them off if they appear to be causing
interference.
• If the signal is weak, try moving the Parent and/or Baby Unit to different
positions in the rooms.
Reasons of Measurement Error
• Dirty probe tip
Please refer to the cleaning process in the manual to make sure the cleanness
of probe tip.
• Unstable human status, such as: hot or cold baths, physical exercise,
smoking and drinking hot or cold drinks ... etc.
Please avoid exercise, bathing for 30mins, and keep the forehead clean & dry
before measurement.
• Unstable environment, such as: the vent of air conditioning or fan.
Make sure the thermometer has been at room temperature for 15 minutes
before use..
• Wrong measurement area
Users should measure the correct position as Fig. 1 shown on page 13.
• Wrong measurement way
When scanning, the probe should face the Middle of Forehead area & the
measurement distance should be as close as possible.
22 General Information
8. General Information
lf your product is not working properly....
1. Read this User's Guide or the Quick Start Guide.
2. Contact Customer Service:
To order a replacement battery pack, contact customer service.
Consumer Products and Accessories Limited Warranty
("Warranty")
Thank you for purchasing this Motorola branded product manufactured under
license by Binatone Electronics International LTD ("BINATONE").
What Does this Warranty Cover?
Subject to the exclusions contained below, BINATONE warrants that this
Motorola branded product ("Product") or certified accessory ("Accessory") sold
for use with this product that it manufactured to be free from defects in materials
and workmanship under normal consumer usage for the period outlined below.
This Warranty is your exclusive warranty and is not transferable.
Who is covered?
This Warranty extends only to the first consumer purchaser, and is not transferable.
What will BINATONE do?
BINATONE or its authorised distributor at its option and within a commercially
reasonable time, will at no charge repair or replace any Products or Accessories
that does not conform to this Warranty. We may use functionally equivalent
reconditioned/ refurbished/ pre-owned or new Products, Accessories or parts.
US and Canada 1-888-331-3383
Email: motorola@encompass.com
General Information 23
ENGLISH
What Other Limitations Are There?
ANY IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, SHALL BE LIMITED TO THE DURATION OF THIS
LIMITED WARRANTY, OTHERWISE THE REPAIR OR REPLACEMENT
PROVIDED UNDER THIS EXPRESS LIMITED WARRANTY IS THE EXCLUSIVE
REMEDY OF THE CONSUMER, AND IS PROVIDED IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED. IN NO EVENT SHALL MOTOROLA OR
BINATONE BE LIABLE, WHETHER IN CONTRACT OR TORT (INCLUDING
NEGLIGENCE) FOR DAMAGES IN EXCESS OF THE PURCHASE PRICE OF
THE PRODUCT OR ACCESSORY, OR FOR ANY INDIRECT, INCIDENTAL,
SPECIAL OR CONSEQUENTIAL DAMAGES OF ANY KIND, OR LOSS OF
REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF INFORMATION OR
OTHER FINANCIAL LOSS ARISING OUT OF OR IN CONNECTION WITH THE
ABILITY OR INABILITY TO USE THE PRODUCTS OR ACCESSORIES TO THE
FULL EXTENT THESE DAMAGES MAY BE DISCLAIMED BY LAW.
Some jurisdictions do not allow the limitation or exclusion of incidental or
consequential damages, or limitation on the length of an implied warranty, so
the above limitations or exclusions may not apply to you. This Warranty gives
you specific legal rights, and you may also have other rights that vary from one
jurisdiction to another.
24 General Information
Exclusions
Normal Wear and Tear. Periodic maintenance, repair and replacement of parts
due to normal wear and tear are excluded from coverage.
Batteries. Only batteries whose fully charged capacity falls below 80% of their
rated capacity and batteries that leak are covered by this Warranty.
Abuse & Misuse. Defects or damage that result from: (a) improper operation,
storage, misuse or abuse, accident or neglect, such as physical damage (cracks,
scratches, etc.) to the surface of the product resulting from misuse; (b) contact
with liquid, water, rain, extreme humidity or heavy perspiration, sand, dirt or the
like, extreme heat, or food; (c) use of the Products or Accessories for
commercial purposes or subjecting the Product or Accessory to abnormal
usage or conditions; or (d) other acts which are not the fault of MOTOROLA or
BINATONE, are excluded from coverage.
Use of Non-Motorola branded Products and Accessories. Defects or damage
that result from the use of Non-Motorola branded or certified Products or
Accessories or other peripheral equipment are excluded from coverage.
Unauthorised Service or Modification. Defects or damages resulting from
service, testing, adjustment, installation, maintenance, alteration, or
modification in any way by someone other than MOTOROLA, BINATONE or its
authorised service centers, are excluded from coverage.
Products Covered Length of Coverage
Consumer Products One (1) year from the date of the
products original purchase by the first
consumer purchaser of the product.
Consumer Accessories Ninety (90) days from the date of the
accessories original purchase by the
first consumer purchaser of the
product.
Consumer Products and Accessories
that are Repaired or Replaced
The balance of the original warranty or
for Ninety (90) days from the date
returned to the consumer, whichever is
longer.
General Information 25
ENGLISH
Altered Products. Products or Accessories with (a) serial numbers or date
tags that have been removed, altered or obliterated; (b) broken seals or
that show evidence of tampering; (c) mismatched board serial numbers;
or (d) nonconforming or non-Motorola branded housings, or parts, are excluded
from coverage.
Communication Services. Defects, damages, or the failure of Products or
Accessories due to any communication service or signal you may subscribe to
or use with the Products or Accessories is excluded from coverage.
How to Obtain Warranty Service or Other Information?
To obtain service or information, please call:
You will receive instructions on how to ship the Products or Accessories at your
expense and risk, to a BINATONE Authorised Repair Center.
To obtain service, you must include: (a) the Product or Accessory; (b) the
original proof of purchase (receipt) which includes the date, place and seller of
the Product; (c) if a warranty card was included in your box, a completed
warranty card showing the serial number of the Product; (d) a written
description of the problem; and, most importantly; (e) your address and
telephone number.
These terms and conditions constitute the complete warranty agreement
between you and BINATONE regarding the Products or Accessories purchased
by you, and supersede any prior agreement or representations, including
representations made in any literature publications or promotional materials
issued by BINATONE or representations made by any agent employee or staff
of BINATONE, that may have been made in connection with the said purchase.
US and Canada 1-888-331-3383
Email: motorola@encompass.com
26 General Information
FCC and IC regulations
FCC Part l5
NOTE: This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the Federal Communications
Commission (FCC) rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications to this equipment not expressly approved by the
party responsible for compliance could void the user's authority to operate the
equipment.
This device complies with Part 15 of the FCC rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation. Privacy of communications
may not be ensured when using this device.
To ensure safety of users, the FCC has established criteria for the amount of radio
frequency energy that can be safely absorbed by a user or bystander according to
the intended usage of the product. This product has been tested and found to
comply with the FCC criteria. The Baby Unit shall be installed and used such that
parts of the user's body other than the hands are maintained at a distance of
approximately 8 inches (20 cm) or more.
This Class B digital apparatus complies with Canadian ICES-003.
CAN ICES-3(B)/NMB-3(B)
General Information 27
ENGLISH
WARNING
Changes or modifications, to this equipment not expressively approved by the
party responsible for compliance could void the user's authority to operate the
equipment.
The socket-outlet shall be installed neat the equipment and shall be easily
accessible.
Industry Canada
This device complies with Industry Canada licence-exempt RSS standard(s):
Operation is subject to the following Two conditions:(1) this device may not
cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.
The term "IC: " before the certification/registration number only signifies that
the Industry Canada technical specifications were met. This product meets the
applicable Industry Canada technical specifications.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux
appareils radio exempts de licence. L’exploitation est autorisée aux deux
conditions suivantes : (1) l’appareil ne doit pas produire de brouillage, et (2)
l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d’en compromettre le fonctionnement.
28 General Information
Technical Specifications
Baby unit
Frequency 2.4 GHz to 2.48 GHz
Image sensor color CMOS 0.3M Pixels
Lens f 2.5mm, F 2.4
IR LED 8 pcs
Power Adapter: 5E-AD 060050-U; Input: 100-240V,
50/60Hz 300mA; Output: 6V, 500mA
OR
Adapter: BLJ5W060050P; Input: 100-240V,
50/60Hz 150mA; Output: 6V, 500mA
WARNING
Use only with provided power supply.
General Information 29
ENGLISH
Parent unit
Frequency 2.4 GHz to 2.48 GHz
Display 2.4" diagonal
Display colors 16M color LCD
Brightness control 8 steps
Volume control 8 steps
Power Adapter: 5E-AD 060050-U; Input: 100-240V,
50/60Hz 150mA; Output: 6V, 500mA
OR
Adapter: BLJ5W060050P; Input: 100-240V,
50/60Hz 150mA; Output: 6V, 500mA
WARNING
Use only with provided power supply.
OR
Battery: Model - JUSTHIGH Ni-MH AAA 3 x 1.2V
900mAh rechargeable battery pack
WARNING
Do not use non-rechargeable batteries for the Parent
Unit. Risk of explosion if battery is replaced by an
incorrect type. Dispose of used batteries according to
the instructions.
Temperature
measurement range of
the touchless
thermometer
Forehead mode: 89.6~108°F (32~42.2°C)
Surface mode: -4~176°F (-22~80°C)
30 General Information
Accuracy Forehead mode: ±0.5°F (0.3°C). This thermometer
converts the forehead temperature to display its "oral
equivalent."
Surface mode: ±0.5°F (0.3°C) within 71.6~108°F
(22~42.2°C), others ±4% or ±4°F (2°C) whichever is
greater
Enclosure rating IP22
Compliance Comply with ASTM E1965-98, IEC/EN60601-1-
2(EMC), IEC/EN60601-1(Safety) standards.
Note Keep the device away from hot or boiling water and
chemicals.
There is no gender and age limitation for using the
infrared thermometer.
Manufactured, distributed or sold by
Binatone Electronics International LTD.,
official licensee for this product.
MOTOROLA and the Stylized M Logo,
are trademarks or registered trademarks
of Motorola Trademark Holdings, LLC.
and are used under license. All other
trademarks are the property of their
respective owners.
© 2013 Motorola Mobility LLC. All rights
reserved.
Version 5.0
Printed in China
