© Copyright 2002, Bioscrypt Inc. All rights reserved.
V-Prox / V-Flex / V-PASS / V-Smart
OO PERATIONS PERATIONS MM ANUALANUAL
© 2000 Bioscrypt, Inc.
Trademark Disclosures
Bioscrypt has made every effort to provide disclosures when using
trademarks owned by other companies. Trademarked designations
appear throughout this publication. The publisher states that it is using the
designations only for editorial purposes, and to the benefit of the
trademark owner with no intent to infringe upon that trademark. The
following trademarks are found in this manual:
• Microsoft™, and Windows 95™, Windows 98™, Windows NT™, Windows
ME™, Windows 2000™, and Windows XP™ are trademarks of the Microsoft
Corporation.
• V-Prox ®, V-Flex ®, V-PASS ®, V-Smart ®, MV1100 ®, MV1200 ® are
registered trademarks of Bioscrypt, Inc.
• HID™ is a trademark of the HID Corporation.
• Motorola™ Indala™ are trademarks of the Motorola Corporation.
• MIFARE® is a registered trademark of Philips Electronics N.V.
• iCLASS™ is a trademark of HID Corporation.
© 2000 Bioscrypt, Inc.
Disclaimer
The instructions in this document have been carefully checked for
accuracy and are presumed to be reliable. Bioscrypt, Inc. and its writers
assume no responsibility for inaccuracies and reserve the right to modify
and revise this document without notice.
It is always our goal at Bioscrypt, Inc. to supply accurate and reliable
documentation. If you discover a discrepancy in this document, please e-
mail your comments to support@bioscrypt.com, or contact Bioscrypt
Technical Support at the telephone number listed below.
No part of this publication may be placed in a retrieval system,
transmitted, or reproduced in any way, including, but not limited to,
photograph, photocopy, computer disk or other record, without prior
agreement and written permission from:
Bioscrypt Inc.
5000 Van Nuys Blvd., Suite 300
Sherman Oaks, CA 91403
Phone 818.304.7150
Toll Free 888.982.4643
http://www.bioscrypt.com
© 2000 Bioscrypt, Inc.
Bioscrypt One Year Limited Warranty Policy
Bioscrypt warrants to the original consumer purchaser (“Customer”)
that new Bioscrypt products will be free from defects in material
and workmanship for one year from the date the product was
shipped from Bioscrypt. For replacement products the warranty on
the replacement unit is the remainder of the warranty on the
original product or ninety (90) days, whichever is longer. The
Customer is responsible for making any claims for shipment damage
(evident or concealed) with the freight carrier. Bioscrypt must be
notified within thirty days of shipment of incorrect materials.
If a defect is discovered, Bioscrypt's sole obligation shall be to repair
or replace the Bioscrypt product(s) at its sole discretion at no
charge, provided it is returned to Bioscrypt during the warranty
period and is shipped freight and insurance prepaid. Merchandise
must be properly packaged to prevent damage during shipping.
Before returning a Bioscrypt product, contact Bioscrypt Technical
Service to obtain a Return Material Authorization (RMA) number.
No product may be returned whether in warranty or out of warranty
without first obtaining approval from Bioscrypt. The model number,
invoice number, and serial number may be required for warranty
service.
This warranty shall not apply to any product or any part of a
product, which in the judgment of Bioscrypt, has been subjected to
misuse, negligence, alteration, accident, improper maintenance, or
damage by excessive physical or electrical stresses. Tampering,
such as opening the housing of a biometric reader or replacing
parts will void this warranty. The warranty is void if the serial number
of the Bioscrypt product has been defaced, altered, or removed or
if the product has been modified. Repair and replacement parts
will be furnished on an exchange basis and may be either
reconditioned or new. All replaced parts or products become the
property of Bioscrypt. This warranty may also be voided for failure
to comply with Bioscrypt’s return policy.
The warranty is not applicable to:
• Abnormal wear and tear
© 2000 Bioscrypt, Inc.
• Damage caused during installation
• Damage caused by the equipment or system with which the biometric
reader is used
• Damage caused by modification or repairs not made or authorized by
Bioscrypt
• Damage caused by improper packaging
• Damage caused by lack of ESD protection
• Merchandise that is determined to be stolen
The newest Bioscrypt Veri-Series products are designed to be
weather resistant but no sensor technology exists today that can
work in all weather environments. If a Bioscrypt Veri-Series product is
not used in a completely indoor environment, then a protective
cover is required to shield the sensor from moisture, dust, and other
contaminants that will degrade sensor operation and void the
product warranty.
This warranty is exclusive and in lieu of all others, whether oral or
written, expressed or implied. Bioscrypt specifically disclaims any
and all implied warranties, including without limitation, warranties of
merchantability and fitness for any particular purpose. No Bioscrypt
dealer, agent, or employee is authorized to make any modification,
extension or addition to this warranty.
© 2000 Bioscrypt, Inc.
Notices
The Veri-Series line of products has been tested for compliance with all
applicable international standards. The resulting approvals are listed
below, and are additionally printed on the labeling located on the rear
panel of the product.
The power supply offered by Bioscrypt is CE and CSA approved and UL
listed.
V-Flex FCC, UL, ULC, CE
V-Prox FCC, UL, ULC, CE
V-Pass FCC, UL, ULC, CE
V-Smart FCC, UL, ULC, CE
FCC Information to Users
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment
is operated in a commercial environment. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to correct the
interference at his own expense.
Warning to Users
Warning: Changes or modifications not expressly approved by Bioscrypt Inc.
could void the user’s authority to operate the equipment.
V-Smart, A Information for Users
The V-Smart, A includes a contact-less smart card reader (GemEasyLink680SL).
This is a radio-transceiver with the following characteristics:
Operating Frequency Range: 13.553-13.567 MHz
RF Power Rating: 0.0 Watts
RF Output Impedance: 50 Ohms
© 2000 Bioscrypt, Inc.
V-Smart, A, H Information for Users
The V-Smart, A, H includes a contact-less smart card reader (HID iCLASS™
model R10). This is a radio-transceiver with the following characteristics:
Operating Frequency Range: 13.553-13.567 MHz
RF Power Rating: 0.0 Watts
RF Output Impedance: 50 Ohms
V-Prox, A, H Information for Users
The V-Prox, A, H includes a HID contact-less proximity reader. This device has
the following characteristics:
Transmit Frequency: 125 KHz
Excite Frequency: 125 KHz
© 2000 Bioscrypt, Inc.
