User Manual II
BlackBerry Curve 8520/8530 Smartphone
Safety and Product Information
To find the latest safety and product information, visit
www.blackberry.com/docs/smartphones.
MAT-32373-001 | PRINTSPEC-021
SWDT43156-696706-0416034819-001 | RCG41GW/RCL21CW/RCZ31CW
Contents
Important safety precautions.....................................................................................................................................3
Safety information........................................................................................................................................................7
Electrical safety .....................................................................................................................................................................7
Battery safety and disposal .................................................................................................................................................8
Device disposal......................................................................................................................................................................9
Safe use guidelines...............................................................................................................................................................9
Driving and walking safely.................................................................................................................................................10
Accessories............................................................................................................................................................................10
Antenna care........................................................................................................................................................................10
Operating and storage temperatures................................................................................................................................11
Interference with electronic equipment............................................................................................................................11
Dangerous areas...................................................................................................................................................................12
Service....................................................................................................................................................................................13
Additional safety guidelines ..............................................................................................................................................14
Compliance information.............................................................................................................................................17
Exposure to radio frequency signals..................................................................................................................................17
Specific absorption rate data ............................................................................................................................................18
FCC compliance statement (United States).....................................................................................................................21
US Information Concerning the Federal Communications Commission ("FCC") Requirements for Hearing Aid
Compatibility with Wireless Devices ................................................................................................................................22
Industry Canada certification ...........................................................................................................................................24
Class B compliance.............................................................................................................................................................24
EU regulatory conformance ..............................................................................................................................................24
Additional regulatory conformance .................................................................................................................................25
BlackBerry device product information..................................................................................................................27
Product information: BlackBerry Curve 8520 smartphone...........................................................................................27
Product information: BlackBerry Curve 8530 smartphone .........................................................................................28
Legal notice ..................................................................................................................................................................31
Important safety precautions
Tip Description
Before you use your BlackBerry® device, it is important that you read the compliance
information and the guidelines for the safe use of your BlackBerry device that are found in
this guide. To find the latest safety and product information, visit www.blackberry.com/docs/
smartphones.
Use only approved batteries with your BlackBerry device. Use of batteries that have not been
approved by Research In Motion might present a risk of fire or explosion, which could cause
serious harm, death, or property loss.
Use only RIM approved holsters. Use of holsters that have not been approved by RIM might,
in the long term, present a risk of serious harm.
Use only RIM approved chargers. Use of chargers that have not been approved by RIM might
present a risk of fire or explosion, which could cause serious harm, death, or property loss.
When you wear the BlackBerry device close to your body, use a RIM approved holster with
an integrated belt clip or maintain a distance of 0.98 in. (25 mm) between your
BlackBerry device and your body while the BlackBerry device is transmitting. Use of body-
worn accessories, other than RIM approved holsters with an integrated belt clip, might cause
your BlackBerry device to exceed radio frequency (RF) exposure standards if the accessories
are worn on your body while the BlackBerry device is transmitting. The long term effects of
exceeding RF exposure standards might present a risk of serious harm. For more information
about the compliance of this BlackBerry device with the FCC RF emission guidelines, visit
www.fcc.gov/oet/ea/fccid and search for the FCC ID for your device as listed below:
• BlackBerry® Curve™ 8520 smartphone: FCC ID L6ARCG40GW
3
Tip Description
• BlackBerry® Curve™ 8530 smartphone (model number RCL21CW): FCC ID
L6ARCL20CW
• BlackBerry Curve 8530 smartphone (model number RCZ31CW): FCC ID
L6ARCZ30CW
Do not rely on your BlackBerry device for emergency communications. The wireless networks
that are necessary to make emergency calls or send messages are not available in all areas,
and emergency numbers (such as 911, 112, or 999) might not connect you to emergency
services in all areas.
Do not disassemble your BlackBerry device. Your BlackBerry device contains small parts that
might be a choking hazard.
Keep your BlackBerry device away from medical devices, including pacemakers and hearing
aids, as they might malfunction causing serious harm or death to you or others.
Do not put your BlackBerry device in contact with liquids as this might cause a short circuit,
a fire, or an electric shock.
When you use your BlackBerry device speakerphone, never hold the BlackBerry device to
your ear. Serious and permanent hearing damage could occur.
Exposure to flashing lights on the BlackBerry device can cause epileptic seizures or blackouts
and might be dangerous to you or others. If you are susceptible to epileptic seizures or
blackouts, consult your physician before you use the BlackBerry device.
Do not use your BlackBerry device while driving unless you are permitted by law to use the
BlackBerry device in hands-free mode. Using your BlackBerry device while driving could put
you and others at greater risk of an accident causing serious injury, death, or property loss.
4
Tip Description
Do not use your BlackBerry device in the presence of gas fumes as it might present a risk of
fire or explosion.
Do not use or store your BlackBerry device in temperatures that exceed 104° F (40°C) as the
BlackBerry device might become hot.
Do not dispose of your BlackBerry device in a fire as this might cause an explosion resulting
in serious injury, death, or property loss.
Turn off your BlackBerry device in aircrafts. Using your BlackBerry device on an aircraft
might affect aircraft instrumentation, communication, and performance; might disrupt the
network; might otherwise be dangerous to the operation of the aircraft, its crew, and its
passengers; and might be illegal.
BlackBerry devices are not inherently safe and cannot be used in the presence of explosive
fumes, explosive dust, or other explosive chemicals. Sparks in such areas could cause an
explosion or fire resulting in serious injury, death, or damage to property.
5
6
Safety information
Please read these safety and operation instructions before using the BlackBerry® device or any accessories
provided with the device. Retain these instructions for future use.
In some countries there may be restrictions on using Bluetooth® enabled and wireless devices with encryption
software. Check with your local authorities.
Electrical safety
Charge the BlackBerry® device using only the charging accessories provided by or specifically approved by
Research In Motion for use with this BlackBerry device. Any approval from RIM under this document must be in
writing and must be from a person authorized to provide such approval. Use of any other accessory might
invalidate any warranty provided with the BlackBerry device and might be dangerous.
Approved charging accessory models for the BlackBerry® Curve™ 8520 smartphone
ASY-04195-002
ASY-18071-001
ASY-18072-002
ASY-18078-001
ASY-18078-003
ASY-18080-003
ASY-18080-007
ASY-18083-001
ASY-18683-001
ASY-18685-001
Approved charging accessory models for the BlackBerry® Curve™ 8530 smartphone
ASY-04195-002
ASY-18071-001
ASY-18072-002
ASY-18078-001
ASY-18078-003
ASY-18080-003
ASY-18080-007
ASY-18083-001
ASY-18683-001
ASY-18685-001
7
Use the charging accessories provided with the BlackBerry device or any other RIM approved charging
accessories only from the type of power source indicated on the marking label. Before you use any power supply,
verify that the mains voltage is in accordance with the voltage printed on the power supply. Connect the
BlackBerry device only to products that bear the USB-IF logo or have completed the USB-IF compliance program.
Do not overload power outlets, extension cords, or convenience receptacles as this might result in a risk of fire
or electric shock. To reduce the risk of damage to the cord or the plug, pull the plug rather than the cord when
you disconnect the charging accessory from the power outlet or convenience receptacle.
Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the
point where the power cord connects to the BlackBerry device. Unplug charging accessories during lightning
storms or when unused for long periods of time.
Do not use charging accessories outside or in any area exposed to the elements.
For more information about inserting the lithium-ion battery and connecting the power supply, see the
documentation that came with the BlackBerry device.
To buy accessories for your BlackBerry device, contact your wireless service provider or visit
www.shopblackberry.com.
Battery safety and disposal
The BlackBerry® device contains a removable lithium-ion battery. Do not dispose of either the BlackBerry device
or the lithium-ion battery in a fire. Dispose of the lithium-ion battery in accordance with the laws and regulations
in your area governing disposal of such cell types.
The lithium-ion battery might present a fire or chemical burn hazard if mistreated. Do not disassemble, crush,
or puncture the lithium-ion battery. Do not heat the lithium-ion battery above 140°F (60°C). Do not allow metal
objects to contact the battery terminals.
8
Use only the lithium-ion battery that Research In Motion specifies for use with your particular BlackBerry device
model. RIM specifies lithium-ion batteries for use in BlackBerry devices in compliance with IEEE® Std
1725™-200x. Using any other lithium-ion battery might invalidate any warranty provided with the BlackBerry
device and might present a risk of fire or explosion.
Children should not handle batteries unless they are supervised by an adult.
When this icon appears on your BlackBerry device, the lithium-ion battery is not inserted or an invalid
lithium-ion battery is inserted. If you have inserted an invalid lithium-ion battery, remove it immediately
and insert the lithium-ion battery that RIM specifies for use with your particular BlackBerry device
model. If you have inserted the lithium-ion battery that is specified for use with your particular BlackBerry device
model, remove and reinsert the lithium-ion battery. Verify that the battery connectors align with the connectors
on your BlackBerry device.
Device disposal
The BlackBerry® device should not be placed in household waste bins. Please check local regulations
for information about the disposal of electronic products in your area.
Safe use guidelines
• Do not place heavy objects on the BlackBerry® device.
• Do not attempt to modify or service the BlackBerry device.
•Do not attempt to cover or push objects into openings on the BlackBerry device unless instructed to do
so in the device documentation supplied by Research In Motion.
• Do not use sharp objects on the screen.
• Do not use excessive force on the screen.
9
Driving and walking safely
Give your full attention to driving; driving safely is your first responsibility. You are responsible for knowing and
obeying the laws and regulations regarding the use of wireless devices in the areas where you drive.
Research In Motion recommends that you do not use your BlackBerry® device while you drive. Instead, consider
having a passenger in the vehicle use your BlackBerry device for you, or find a safe location to stop your vehicle
before you use your BlackBerry device.
Store your BlackBerry device safely before driving your vehicle. Do not use any charging accessory as a means
of storing your BlackBerry device while you are in a vehicle. If your vehicle is equipped with an air bag, do not
place your BlackBerry device or other objects above the air bag, or in the air bag deployment area. If in-vehicle
wireless equipment is improperly stored or installed, and the air bag inflates, serious injury could result.
Radio frequency (RF) signals might affect improperly installed or inadequately shielded electronic systems in
motor vehicles. Check with the manufacturer or its representative regarding your vehicle. If any equipment has
been added to your vehicle, you should also consult the manufacturer of that equipment for information on RF
signals.
Do not use your BlackBerry device while walking or engaging in any activity that requires your full attention.
Inattention to vehicular traffic or other pedestrian hazards could result in serious injury, death, or property loss.
Accessories
Use only those accessories approved by Research In Motion (RIM). Using any accessories not approved by RIM
for use with this particular BlackBerry® device model might invalidate any approval or warranty applicable to
the device, might result in the non-operation of the device, and might be dangerous.
Antenna care
Use only the supplied integrated antenna. Unauthorized antenna modifications or attachments could damage
the BlackBerry® device and might violate U.S. Federal Communications Commission (FCC) regulations.
10
Operating and storage temperatures
Situate the BlackBerry® device or device accessories away from heat sources, such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
If you are not going to use the BlackBerry device for more than two weeks, turn off the device power, remove the
battery, and follow the operating and storage temperatures listed in the following table:
Device operating 32 to 104°F (0 to 40°C)
Device storage 50 to 86°F (10 to 30°C)
Travel charger operating 32 to 104°F (0 to 40°C)
Travel charger storage -22 to 167°F (-30 to 75°C)
Interference with electronic equipment
Most modern electronic equipment is shielded from radio frequency (RF) signals. However, certain electronic
equipment might not be shielded against the RF signals from the BlackBerry® device.
Pacemakers: Consult a physician or the manufacturer of your pacemaker if you have any questions regarding
the effect of RF signals on your pacemaker. If you have a pacemaker, verify that you are using the BlackBerry
device in accordance with the safety requirements associated with your particular pacemaker, which might
include the following requirements:
• Always keep the BlackBerry device more than 7.88 inches (20 cm) from the pacemaker when the
BlackBerry device is turned on.
• Do not carry the BlackBerry device in your breast pocket.
• When using the phone on the BlackBerry device, use the ear opposite the pacemaker for making and
receiving calls to minimize the potential interference.
• If you have any reason to suspect that interference is taking place, turn off all wireless connections on
the BlackBerry device immediately.
11
Hearing aids: Some digital wireless devices may interfere with some hearing aids. In the event of such
interference, consult your wireless service provider or contact the manufacturer of your hearing aid to discuss
alternatives.
Other medical devices: If you use any other personal medical device, consult the manufacturer of your device
to determine if the device is adequately shielded from external RF energy. Your physician may be able to assist
you in obtaining this information.
Health care facilities: Turn off all wireless connections on the BlackBerry device in health care facilities when
any regulations posted in these areas instruct you to do so. Hospitals or health care facilities may be using
equipment that could be sensitive to external RF energy.
Aircraft: Federal Aviation Administration (FAA) and Federal Communications Commission (FCC) regulations
prohibit using the radio of wireless devices while in the air. Turn off all wireless connections on the BlackBerry
device before boarding an aircraft. The effect of using the BlackBerry device with wireless connections turned
on in an aircraft is unknown. Such use might affect aircraft instrumentation, communication, and performance,
might disrupt the network, might otherwise be dangerous to the operation of the aircraft, and might be illegal.
With all wireless connections on the BlackBerry device turned off, use only non-radio based device applications
in accordance with airline regulations for electronic devices.
Dangerous areas
The BlackBerry device is not an intrinsically safe device and is not suitable for use in hazardous environments,
where such devices are required, including without limitation, in presence of gas fumes, explosive dust situations,
operation of nuclear facilities, aircraft navigation or communication services, air traffic control, and life support
or weapons systems.
Potentially explosive atmospheres: Turn off all wireless connections on the BlackBerry device when in any
area with a potentially explosive atmosphere, and obey all signs and instructions. Sparks in such areas could
cause an explosion or fire resulting in bodily injury or even death.
12
Areas with a potentially explosive atmosphere are often, but not always, clearly marked. They include fueling
areas such as gasoline or petrol stations; below deck on boats; fuel or chemical transfer or storage facilities;
vehicles using liquefied petroleum gas (such as propane or butane); areas where the air contains chemicals or
particles, such as grain, dust, or metal powders; and any other area where you would normally be advised to turn
off your vehicle engine.
Do not use the phone on the BlackBerry® device to report a gas leak in the vicinity of the leak. Leave the area
and, if the phone is available and active on the BlackBerry device, make the call from a safe location.
Blasting areas: To avoid interfering with blasting operations, turn off all wireless connections on the BlackBerry
device when in a “blasting area” or in areas posted: “Turn off two-way radio.” Obey all signs and instructions.
Service
Only qualified service personnel should perform repairs to the BlackBerry® device. Disconnect the power supply
cables from the computer or electrical outlet and refer the BlackBerry device or charging accessory for service
to qualified service personnel if any of the following situations occur:
• the power supply cord, plug, or connector is damaged
• liquid has been spilled or objects have fallen into the BlackBerry device or charging accessory
• the BlackBerry device or charging accessory has been exposed to rain or water
• the BlackBerry device or charging accessory becomes very hot to the touch
• the BlackBerry device or charging accessory has been dropped or damaged in any way
•the BlackBerry device or charging accessory does not operate normally by following the instructions in
the user documentation
• the BlackBerry device or charging accessory exhibits a distinct change in performance
Do not attempt to disassemble the BlackBerry device or any charging accessory.
To reduce the risk of fire or electric shock, adjust only those controls that are covered in the user documentation
for the BlackBerry device. An improper adjustment of other controls might cause damage and will often require
extensive work by a qualified technician to restore the BlackBerry device, charging accessory, or any other
accessory to normal operation.
13
Failure to observe all safety instructions contained in the user documentation for the BlackBerry device will void
the Limited Warranty and might lead to suspension or denial of services to the offender, legal action, or both.
Additional safety guidelines
Speakerphone: The BlackBerry® device is equipped with a speakerphone that can generate audio levels loud
enough for phone call operation while holding the BlackBerry device at an arm's length from your head. When
using your BlackBerry device speakerphone, never hold the BlackBerry device to your ear. Serious and permanent
hearing damage could occur.
Camera: Certain jurisdictions might prohibit or restrict your use of certain features on the BlackBerry device. If
your BlackBerry device model has a camera, the following statements are applicable to you:
When taking, processing, or using pictures, obey all laws, regulations, procedures, and policies, including, without
limitation, any copyright, personal privacy, trade secret, or security laws which might govern or restrict you while
using the BlackBerry device. Honor the personal rights of others. Copyright protections might prevent you from
copying, modifying, transferring, or forwarding some pictures, music (including ring tones), or other content. Do
not aim the camera directly at the sun or any other bright light. This action could cause serious damage to your
eyes or damage the BlackBerry device.
Flashing lights: Exposure to flashing lights on the BlackBerry device can cause epileptic seizures or blackouts
and might be dangerous to you or others. In the event that you experience, or your use of the BlackBerry device
causes in others, any disorientation, loss of awareness, twitching, convulsions, or any involuntary movements,
stop using the BlackBerry device immediately and consult a physician. If you are susceptible to epileptic seizures
or blackouts, consult your physician before using the BlackBerry device. The LED notification light is located on
the front of your BlackBerry device, in the top right corner. Caution: Use of controls or adjustments or
performance of procedures other than those specified herein may result in hazardous radiation exposure.
Audio files: The BlackBerry device has the capability to play audio files. When listening to audio files using
headphones, permanent hearing loss might occur if headphones are used at a high volume. Avoid increasing
the volume of your headphones to block out noisy surroundings. If you experience ringing in your ears or muffled
speech, consult a physician to have your hearing checked.
14
Liquids and foreign objects: Never push objects of any kind into the BlackBerry device or device accessories
through openings as this action might cause a short circuit, a fire, or electric shock. Do not use the BlackBerry
device or device accessories near water (for example, near a bathtub or a sink, in a wet basement, or near a
swimming pool). Never spill liquid of any kind on the BlackBerry device or device accessories.
Stability: Do not place the BlackBerry device or device accessory on any unstable surface. It could fall, thereby
potentially causing serious injury to a person and serious damage to the BlackBerry device or device accessory.
Take care when using the BlackBerry device with any charging accessories to route the power cord in a way that
reduces the risk of injury to others, such as by tripping or choking.
Cleaning: Do not use liquid, aerosol cleaners, or solvents on or near the BlackBerry device or device accessory.
Clean only with a soft dry cloth. Disconnect any cables from the computer and unplug any charging accessories
from the electrical outlet before cleaning either the BlackBerry device or the charging accessory.
Cleaning the battery cover: If it is necessary to clean the battery cover on your BlackBerry device, remove the
battery cover carefully and keep your BlackBerry device away from all liquids. Clean the battery cover with a
soft cloth that is dampened with water and mild liquid detergent. Verify that the battery cover is completely dry
before you put it back on your BlackBerry device. For more information about handling the battery cover, see
the printed documentation that came with your BlackBerry device.
Repetitive strain: When using the BlackBerry device, take frequent breaks. If you experience any discomfort in
your neck, shoulders, arms, wrists, hands (including thumbs and fingers), or other parts of the body when using
the BlackBerry device, cease use immediately. If discomfort persists, consult a physician.
Holster: The BlackBerry device might not come with a holster (body-worn accessory). If you wear the
BlackBerry device on your body, always put the BlackBerry device in a BlackBerry device holster equipped with
an integrated belt clip supplied or approved by Research In Motion. If you do not use a holster equipped with
an integrated belt clip supplied or approved by RIM when you carry the BlackBerry device, keep the
BlackBerry device at least 0.98 in. (25 mm) from your body when the BlackBerry device is transmitting. When
using any data feature of the BlackBerry device, with or without a USB cable, hold the BlackBerry device at least
0.98 in. (25 mm) from your body. Using accessories that are not supplied or approved by RIM might cause your
BlackBerry device to exceed radio frequency (RF) exposure guidelines. For more information about radio
frequency exposure, see the "Compliance information" section of this document.
15
Carrying solutions: Most BlackBerry carrying solutions for BlackBerry devices, for example holsters, totes, and
pouches, incorporate a magnet into the physical structure of the carrying solution. Do not place items containing
magnetic strip components such as debit cards, credit cards, hotel key cards, phone cards, or similar items near
BlackBerry carrying solutions which incorporate a magnet into the physical structure of the carrying solution as
the magnet might damage or erase the data stored on the magnetic strip.
16
Compliance information
Exposure to radio frequency signals
The BlackBerry® device radio is a low power radio transmitter and receiver. When the BlackBerry device radio
is turned on, it receives and also sends out radio frequency (RF) signals. The BlackBerry device is designed to
comply with Federal Communications Commission (FCC), Ministry of Internal Affairs and Communications (MIC),
and Industry Canada (IC) guidelines respecting safety levels of RF exposure for wireless devices, which in turn
are consistent with the following safety standards previously set by Canadian, U.S., and international standards
bodies:
• ANSI®/IEEE® C95.1, 1999, American National Standards Institute/Institute of Electrical and Electronics
Engineers Standard for Safety Levels with Respect to Human Exposure to Radio Frequency
Electromagnetic Fields, 3 kHz to 300 GHz
•National Council on Radiation Protection and Measurements (NCRP) Report 86, 1986, Biological Effects
and Exposure Criteria for Radiofrequency Electromagnetic Fields
• Health Canada, Safety Code 6, 1999, Limits of Human Exposure to Radiofrequency Electromagnetic
Fields in the Frequency Range from 3 kHz to 300 GHz
• EN 50360, 2001, Product standard to demonstrate the compliance of mobile phones with the basic
restrictions related to human exposure to electromagnetic fields (300 MHz to 3 GHz)
•International Commission on Non-Ionizing Radiation Protection (ICNIRP), 1998, Guidelines for Limiting
Exposure to Time-Varying Electric, Magnetic, and Electromagnetic fields (up to 300 GHz)
• Official Journal of the European Union (OJEU), 1999, Council Recommendation of 12 July 1999 on the
limitation of exposure of the general public to electromagnetic fields (0 Hz to 300 GHz)
• MIC, 2001, Article 14-2 of the Ordinance for Regulating Radio Equipment
To maintain compliance with FCC, IC, MIC, and EU RF exposure guidelines when you carry the BlackBerry device
on your body, use only accessories equipped with an integrated belt clip that are supplied or approved by Research
In Motion (RIM). Use of accessories that are not expressly approved by RIM might violate FCC, IC, and EU RF
exposure guidelines and might void any warranty applicable to the BlackBerry device. If you do not use a body-
worn accessory equipped with an integrated belt clip supplied or approved by RIM when you carry the
17
BlackBerry device, keep the BlackBerry device at least 0.98 in. (25 mm) from your body when the BlackBerry
device is transmitting. When using any data feature of the BlackBerry device, with or without a USB cable, hold
the BlackBerry device at least 0.98 in. (25 mm) from your body. If you use a body-worn accessory not supplied
by RIM when you carry the BlackBerry device, verify that the accessory does not contain metal and keep the
BlackBerry device at least 0.98 in. (25 mm) from your body when the BlackBerry device is transmitting.
To reduce radio frequency (RF) exposure consider these safety guidelines:
• Use the BlackBerry device in areas where there is a strong wireless signal. The indicator that provides
information about the strength of the wireless signal is located in the upper-right corner of the Home
screen and displays five ascending bars. Three or more bars indicate a strong signal. A reduced signal
display, which might occur in areas such as an underground parking structure or if you are traveling by
train or car, might indicate increased power output from your BlackBerry device as it attempts to connect
to a weak signal.
•Use hands-free operation if it is available and keep the BlackBerry device at least 0.98 in. (25 mm) from
your body (including the abdomen of pregnant women and the lower abdomen of teenagers) when the
BlackBerry device is turned on and connected to the wireless network. For more information about
carrying your BlackBerry device, see the holster information in the "Additional safety guidelines" section
of this document.
• Reduce the amount of time spent on calls.
Specific absorption rate data
THIS WIRELESS DEVICE MODEL MEETS GOVERNMENT REQUIREMENTS FOR EXPOSURE TO RADIO WAVES
WHEN USED AS DIRECTED IN THIS SECTION.
The BlackBerry® device is a radio transmitter and receiver. It is designed and manufactured not to exceed the
emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission
(FCC) of the U.S. Government, Industry Canada of the Canadian Government (IC), and recommended by The
Council of the European Union when used as directed in the previous section. These limits are part of
18
comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines
are based on standards that were developed by independent scientific organizations through periodic and
thorough evaluation of scientific studies.
The exposure standard for wireless devices employs a unit of measurement known as the Specific Absorption
Rate, or SAR. The SAR limit set by the FCC/IC is 1.6W/kg*. The SAR limit recommended by The Council of the
European Union is 2.0W/kg**. Tests for SAR are conducted using standard operating positions specified by the
FCC/IC with the device transmitting at its highest certified power level in all tested frequency bands. Although
the SAR is determined at the highest certified power level, the actual SAR level of the device while operating
can be well below the maximum value. This is because the device is designed to operate at multiple power levels
so as to use only the power required to reach the network. In general, the closer you are to a wireless base station
antenna, the lower the power output.
Before a wireless device model is available for sale to the public, it must be tested and certified to the FCC, IC,
and The Council of the European Union that it does not exceed the limit established by the government-adopted
requirement for safe exposure under the recommendations of the International Commission on Non-Ionizing
Radiation Protection (ICNIRP). The tests are performed in positions and locations (for example, at the ear and
worn on the body) as required by the FCC, IC, and The Council of the European Union for each model.
The highest SAR value for each device model when tested for use at the ear is outlined below:
Device SAR (W/kg) for 1g SAR (W/kg) for 10g
BlackBerry® Curve™ 8520 smartphone 1.22 1.02
BlackBerry® Curve™ 8530 smartphone (model
number RCL21CW)
1.31 -----
19
Device SAR (W/kg) for 1g SAR (W/kg) for 10g
BlackBerry Curve 8530 smartphone (model
number RCZ31CW)
1.24 -----
The highest reported SAR value for this BlackBerry device when clipped on a belt, in a Research In Motion
approved holster equipped with an integrated belt clip, is outlined below. Carrying solutions, including RIM
approved carrying solutions and carrying solutions not approved by RIM, that do not come equipped with an
integrated belt clip SHOULD NOT be worn or carried on the body. For more information regarding the wearing
or carrying of this BlackBerry device without using a RIM approved carrying solution equipped with an integrated
belt clip, see the holster information in the "Additional safety guidelines" section of this document.
Device SAR (W/kg) for 1g SAR (W/kg) for 10g
BlackBerry Curve 8520 smartphone 0.83 0.78
BlackBerry Curve 8530 smartphone (model
number RCL21CW)
0.66 -----
BlackBerry Curve 8530 smartphone (model
number RCZ31CW)
0.66 -----
Body-worn measurements differ among wireless device and phone models, depending upon available accessories
and FCC, IC, and The Council of the European Union requirements.
The FCC has granted an Equipment Authorization for this wireless device model with all reported SAR levels
evaluated as in compliance with the FCC RF emission guidelines when the BlackBerry device is used as directed
in this section. SAR information on this wireless device model is on file with the FCC and can be found under the
Display Grant section of www.fcc.gov/oet/ea after searching for the FCC ID for your device listed below.
Additional information on SAR can be found on the CTIA - The Wireless Association® web site at www.ctia.org.
20
In Japan, additional information on SAR can be found on the Association of Radio Industries and Businesses
(ARIB) web site at www.arib-emf.org/index.html, or on the Telecommunications Bureau of the Ministry of Internal
Affairs and Communications (MIC) web site at www.tele.soumu.go.jp/e/index.htm.
Device FCC ID
BlackBerry Curve 8520 smartphone L6ARCG40GW
BlackBerry Curve 8530 smartphone (model number
RCL21CW)
L6ARCL20CW
BlackBerry Curve 8530 smartphone (model number
RCZ31CW
L6ARCZ30CW
___________________________________
* In the United States and Canada, the SAR limit for mobile devices used by the public is 1.6 watts/kg (W/kg)
averaged over 1 gram of tissue for the body or head (4.0 W/kg averaged over 10 grams of tissue for the extremities
- hands, wrists, ankles and feet).
** In Europe, the SAR limit for mobile devices used by the public is 2.0 watts/kg (W/kg) averaged over 10 grams
of tissue for the body or head (4.0 W/kg averaged over 10 grams of tissue for the extremities - hands, wrists,
ankles and feet). Studies suggest that the standard incorporates a substantial margin of safety to give additional
protection for the public and to account for any variations in measurements.
The long-term characteristics or the possible physiological effects of Radio Frequency Electromagnetic fields
have not been evaluated by Underwriters Laboratories Inc. (UL).
FCC compliance statement (United States)
FCC Class B Part 15
21
This device complies with Part 15 of the Federal Communications Commission (FCC) Rules. Operation is subject
to the following two conditions:
• This device may not cause harmful interference.
• This device must accept any interference received, including interference that may cause undesired
operation.
CAUTION: Changes or modifications to this unit not expressly approved by the party responsible for compliance
could void the user’s authority to operate this equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the manufacturer’s instructions, may cause interference harmful to radio
communications.
There is no guarantee, however, that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio or TV technician for help.
US Information Concerning the Federal Communications Commission
("FCC") Requirements for Hearing Aid Compatibility with Wireless
Devices
When wireless devices are used near hearing devices (such as hearing aids and cochlear implants), users may
detect a buzzing, humming, or whining noise. Some hearing devices are more immune than others to this
interference, and wireless devices also vary in the amount of interference that they generate.
22
The wireless telephone industry has developed ratings to assist hearing device users in finding wireless devices
that may be compatible with their hearing devices. Not all wireless devices have been rated. Wireless devices
that are rated will have the rating displayed on the box together with other relevant approval markings.
The ratings are not guarantees. Results will vary depending on the user's hearing device and hearing loss. If your
hearing device is vulnerable to interference, you may not be able to use a rated wireless device successfully.
Consulting with your hearing health professional and testing the wireless device with your hearing device is the
best way to evaluate it for your personal needs.
This BlackBerry® device has been tested and rated for use with hearing aids for some of the wireless technologies
that the BlackBerry device uses. However, other wireless technologies may be used in this BlackBerry device
that have not been tested for use with hearing aids. It is important to try the different features of your
BlackBerry device thoroughly and in different locations to determine if you hear any interfering noise when using
this BlackBerry device with your hearing aid or cochlear implant. Consult your wireless service provider about
its return and exchange policies and for information about hearing aid compatibility.
How the ratings work
M-Ratings: Wireless devices rated M3 or M4 meet FCC requirements and are likely to generate less interference
to hearing devices than wireless devices that are not labeled. M4 is the better or higher of the two ratings.
T-Ratings: Wireless devices rated T3 or T4 meet FCC requirements and are likely to be more usable with a hearing
device's telecoil ("T Switch" or "Telephone Switch") than unrated wireless devices. T4 is the better or higher of
the two ratings. (Note that not all hearing devices have telecoils in them.)
Hearing devices may also be measured for immunity to this type of interference. Your hearing device
manufacturer or hearing health professional may help you find results for your hearing device. The more immune
your hearing aid is, the less likely you are to experience interference noise from wireless devices.
For more information about the actions that the FCC has taken with regard to hearing aid compatibility with
wireless devices and other steps that the FCC has taken to ensure that individuals with disabilities have access
to telecommunications services, visit www.fcc.gov/cgb/dro.
23
Industry Canada certification
The BlackBerry® Curve™ 8520 smartphone complies with Industry Canada RSS 102, RSS 132, RSS 133, RSS
210, under certification number 2503A-RCG40GW.
The BlackBerry® Curve™ 8530 smartphone (model number RCL21CW) complies with Industry Canada RSS 102,
RSS 132, RSS 133, and RSS 210 under certification number 2503A-RCL20CW.
The BlackBerry Curve 8530 smartphone (model number RCZ31CW) complies with Industry Canada RSS 102, RSS
132, RSS 133, RSS 139, and RSS 210 under certification number 2503A-RCZ30CW.
Class B compliance
This BlackBerry® device complies with the Class B limits for radio noise emissions as set out in the interference-
causing equipment standard entitled “Digital Apparatus,” ICES-003 of Industry Canada.
EU regulatory conformance
Research In Motion hereby declares that this BlackBerry® device is in compliance with the essential requirements
and other relevant provisions of Directive 1999/5/EC.
Device Applicable CE marking
BlackBerry® Curve™ 8520 smartphone
The Declaration of Conformity made under Directive 1999/5/EC (HG nr.88/2003) is available for viewing at
the following location in the EU community: www.blackberry.com/go/declarationofconformity.
24
Research In Motion UK Limited
200 Bath Road
Slough, Berkshire SL1 3XE
United Kingdom
If you have a Wi-Fi® enabled BlackBerry device, your BlackBerry device may be operated on Wi-Fi networks in
all European Union member countries. When operated in France, this equipment uses non harmonized frequency
bands. This equipment may be operated in Turkey.
If you have a Wi-Fi enabled BlackBerry device, in France, outdoor operation of a wireless device is only permitted
using the 2.4 to 2.454 GHz frequency band. The BlackBerry device only operates in infrastructure mode and as
a result, will not transmit in the 2.4 to 2.45 GHz frequency band other than to communicate with a wireless
access point.
Additional regulatory conformance
Specific details about compliance to the following standards and regulatory bodies for your BlackBerry® device
may be obtained from Research In Motion:
Device Applicable conformance information
BlackBerry® Curve™ 8520
smartphone • PCS Type Certification Review Board (PTCRB)
• Underwriters Laboratories (UL) 60950-1 requirements for
Canada and the United States
• Radio and Telecommunications Terminal Equipment (R&TTE)
Directive 1999/5/EC
• Global Certification Forum Certification Criteria (GCF CC)
requirements
BlackBerry® Curve™ 8530
smartphone • Underwriters Laboratories (UL) 60950-1 requirements for
Canada and the United States
25
This BlackBerry device supports the Turkish SMS characters as outlined in ETSI TS 123.038 V8.0.0 (or newer
version code) and ETSI TS 123.040 V8.1.0 (or newer version code).
This BlackBerry device is in conformity with Turkey’s EEE Directive.
26
BlackBerry device product information
Product information: BlackBerry Curve 8520 smartphone
Mechanical properties:
• weight: approximately 3.7 oz (106 g) including lithium-ion battery
• size (L x W x H): 4.29 x 2.36 x 0.54 in. (109 x 60 x 13.88 mm)
• 256 MB flash memory
Power specifications:
• removable, rechargeable lithium-ion cell battery
• supports 1.8V, 3V SIM cards
• micro-USB-compatible port for data synchronization and charging
Mobile network radio specifications:
• quad-band support: GSM® 850, GSM 900, DCS 1800, PCS 1900 MHz
• power class: Class 1 (DCS 1800, PCS 1900), Class 4 (GSM 850) as defined in GSM 5.05, Class 4
(GSM 900) as defined in GSM 02.06, Class E2 (GSM 850, GSM 900, DCS 1800, PCS 1900)
• transmitting frequency: GSM 824 to 849 MHz, GSM 880 to 915 MHz, DCS 1710 to 1785 MHz, PCS
1850 to 1910 MHz
•receiving frequency: GSM 869 to 894 MHz, GSM 925 to 960 MHz, DCS 1805 to 1880 MHz, PCS 1930
to 1990 MHz
Wi-Fi® network radio specifications:
27
• wireless LAN standard: IEEE® 802.11b™, IEEE® 802.11g™
• transmitting and receiving frequency: 2412 to 2472 MHz
Bluetooth® radio specifications:
• single-band support: ISM 2.4 GHz
• transmitting and receiving frequency: 2402 to 2480 MHz
• Bluetooth Class 1
Product information: BlackBerry Curve 8530 smartphone
Mechanical properties:
• weight: approximately 3.7 oz (105 g) including lithium-ion battery
• size (L x W x H): 4.29 x 2.36 x 0.54 in. (109 x 60 x 13.88 mm)
• 256 MB flash memory, 256 MB RAM
Power specifications:
• removable, rechargeable lithium-ion cell battery
• supports 1.8V, 3V SIM cards
• micro-USB-compatible port for data synchronization and charging
Mobile network radio specifications for model number RCL21CW:
• dual-band support: CDMA 800 and CDMA 1900 MHz
• networks: CDMA2000®, 1xEV-DO Release 0
28
• power class: Class 3 (CDMA 800), Class 2 (CDMA 1900)
• transmitting frequency: Cell 824.70 to 848.31 MHz, PCS 1851.25 to 1908.75 MHz
•receiving frequency: Cell 869.70 to 893.31 MHz, PCS 1931.25 to 1988.75 MHz, A-GPS E911: 1575 MHz
Mobile network radio specifications for model number RCZ31CW:
• tri-band support: CDMA 800, CDMA 1900 MHz and AWS CDMA 1700 MHz
• networks: CDMA2000®, 1xEV-DO Release 0
• power class: Class 3 (CDMA 800), Class 2 (CDMA 1900) and Class 2 (CDMA 1700)
• transmitting frequency: Cell 824.70 to 848.31 MHz, PCS 1851.25 to 1908.75 MHz, AWS 1711.25 to
1753.75 MHz
•receiving frequency: Cell 869.70 to 893.31 MHz, PCS 1931.25 to 1988.75 MHz, AWS 2111.25 to
2153.75 MHz, A-GPS E911: 1575 MHz
Wi-Fi® network radio specifications:
• wireless LAN standard: IEEE® 802.11b™, IEEE® 802.11g™
• transmitting and receiving frequency: 2412 to 2472 MHz
Bluetooth® radio specifications:
• single-band support: ISM 2.4 GHz
• transmitting and receiving frequency: 2402 to 2480 MHz
• Bluetooth Class 1
29
30
Legal notice
©2010 Research In Motion Limited. All rights reserved. BlackBerry®, RIM®, Research In Motion®, SureType®,
SurePress™ and related trademarks, names, and logos are the property of Research In Motion Limited and are
registered and/or used in the U.S. and countries around the world.
ANSI is a trademark of the American National Standards Institute. Bluetooth is a trademark of Bluetooth SIG.
CDMA2000 is a trademark of the Telecommunications Industry Association. CTIA - The Wireless Association is
a trademark of CTIA - The Wireless Association. GSM is a trademark of the GSM MOU Association. IEEE,
802.11b, 802.11g, and IEEE Std 1725 are trademarks of the Institute of Electrical and Electronics Engineers, Inc.
All other trademarks are the property of their respective owners.
Portions of the BlackBerry® Device Software are copyright © 2007-2008 The FreeType Project
(www.freetype.org). All rights reserved.
This documentation including all documentation incorporated by reference herein such as documentation
provided or made available at www.blackberry.com/go/docs is provided or made accessible "AS IS" and "AS
AVAILABLE" and without condition, endorsement, guarantee, representation, or warranty of any kind by Research
In Motion Limited and its affiliated companies ("RIM") and RIM assumes no responsibility for any typographical,
technical, or other inaccuracies, errors, or omissions in this documentation. In order to protect RIM proprietary
and confidential information and/or trade secrets, this documentation may describe some aspects of RIM
technology in generalized terms. RIM reserves the right to periodically change information that is contained in
this documentation; however, RIM makes no commitment to provide any such changes, updates, enhancements,
or other additions to this documentation to you in a timely manner or at all.
This documentation might contain references to third-party sources of information, hardware or software,
products or services including components and content such as content protected by copyright and/or third-
party web sites (collectively the "Third Party Products and Services"). RIM does not control, and is not responsible
for, any Third Party Products and Services including, without limitation the content, accuracy, copyright
compliance, compatibility, performance, trustworthiness, legality, decency, links, or any other aspect of Third
Party Products and Services. The inclusion of a reference to Third Party Products and Services in this
documentation does not imply endorsement by RIM of the Third Party Products and Services or the third party
in any way.
31
EXCEPT TO THE EXTENT SPECIFICALLY PROHIBITED BY APPLICABLE LAW IN YOUR JURISDICTION, ALL
CONDITIONS, ENDORSEMENTS, GUARANTEES, REPRESENTATIONS, OR WARRANTIES OF ANY KIND,
EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION, ANY CONDITIONS, ENDORSEMENTS,
GUARANTEES, REPRESENTATIONS OR WARRANTIES OF DURABILITY, FITNESS FOR A PARTICULAR PURPOSE
OR USE, MERCHANTABILITY, MERCHANTABLE QUALITY, NON-INFRINGEMENT, SATISFACTORY QUALITY,
OR TITLE, OR ARISING FROM A STATUTE OR CUSTOM OR A COURSE OF DEALING OR USAGE OF TRADE, OR
RELATED TO THE DOCUMENTATION OR ITS USE, OR PERFORMANCE OR NON-PERFORMANCE OF ANY
SOFTWARE, HARDWARE, SERVICE, OR ANY THIRD PARTY PRODUCTS AND SERVICES REFERENCED HEREIN,
ARE HEREBY EXCLUDED. YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY BY STATE OR PROVINCE. SOME
JURISDICTIONS MAY NOT ALLOW THE EXCLUSION OR LIMITATION OF IMPLIED WARRANTIES AND
CONDITIONS. TO THE EXTENT PERMITTED BY LAW, ANY IMPLIED WARRANTIES OR CONDITIONS RELATING
TO THE DOCUMENTATION TO THE EXTENT THEY CANNOT BE EXCLUDED AS SET OUT ABOVE, BUT CAN BE
LIMITED, ARE HEREBY LIMITED TO NINETY (90) DAYS FROM THE DATE YOU FIRST ACQUIRED THE
DOCUMENTATION OR THE ITEM THAT IS THE SUBJECT OF THE CLAIM.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW IN YOUR JURISDICTION, IN NO EVENT SHALL
RIM BE LIABLE FOR ANY TYPE OF DAMAGES RELATED TO THIS DOCUMENTATION OR ITS USE, OR
PERFORMANCE OR NON-PERFORMANCE OF ANY SOFTWARE, HARDWARE, SERVICE, OR ANY THIRD PARTY
PRODUCTS AND SERVICES REFERENCED HEREIN INCLUDING WITHOUT LIMITATION ANY OF THE
FOLLOWING DAMAGES: DIRECT, CONSEQUENTIAL, EXEMPLARY, INCIDENTAL, INDIRECT, SPECIAL,
PUNITIVE, OR AGGRAVATED DAMAGES, DAMAGES FOR LOSS OF PROFITS OR REVENUES, FAILURE TO
REALIZE ANY EXPECTED SAVINGS, BUSINESS INTERRUPTION, LOSS OF BUSINESS INFORMATION, LOSS OF
BUSINESS OPPORTUNITY, OR CORRUPTION OR LOSS OF DATA, FAILURES TO TRANSMIT OR RECEIVE ANY
DATA, PROBLEMS ASSOCIATED WITH ANY APPLICATIONS USED IN CONJUNCTION WITH RIM PRODUCTS
OR SERVICES, DOWNTIME COSTS, LOSS OF THE USE OF RIM PRODUCTS OR SERVICES OR ANY PORTION
THEREOF OR OF ANY AIRTIME SERVICES, COST OF SUBSTITUTE GOODS, COSTS OF COVER, FACILITIES OR
SERVICES, COST OF CAPITAL, OR OTHER SIMILAR PECUNIARY LOSSES, WHETHER OR NOT SUCH DAMAGES
WERE FORESEEN OR UNFORESEEN, AND EVEN IF RIM HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES.
32
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW IN YOUR JURISDICTION, RIM SHALL HAVE NO
OTHER OBLIGATION, DUTY, OR LIABILITY WHATSOEVER IN CONTRACT, TORT, OR OTHERWISE TO YOU
INCLUDING ANY LIABILITY FOR NEGLIGENCE OR STRICT LIABILITY.
THE LIMITATIONS, EXCLUSIONS, AND DISCLAIMERS HEREIN SHALL APPLY: (A) IRRESPECTIVE OF THE
NATURE OF THE CAUSE OF ACTION, DEMAND, OR ACTION BY YOU INCLUDING BUT NOT LIMITED TO
BREACH OF CONTRACT, NEGLIGENCE, TORT, STRICT LIABILITY OR ANY OTHER LEGAL THEORY AND SHALL
SURVIVE A FUNDAMENTAL BREACH OR BREACHES OR THE FAILURE OF THE ESSENTIAL PURPOSE OF THIS
AGREEMENT OR OF ANY REMEDY CONTAINED HEREIN; AND (B) TO RIM AND ITS AFFILIATED COMPANIES,
THEIR SUCCESSORS, ASSIGNS, AGENTS, SUPPLIERS (INCLUDING AIRTIME SERVICE PROVIDERS),
AUTHORIZED RIM DISTRIBUTORS (ALSO INCLUDING AIRTIME SERVICE PROVIDERS) AND THEIR
RESPECTIVE DIRECTORS, EMPLOYEES, AND INDEPENDENT CONTRACTORS.
IN ADDITION TO THE LIMITATIONS AND EXCLUSIONS SET OUT ABOVE, IN NO EVENT SHALL ANY DIRECTOR,
EMPLOYEE, AGENT, DISTRIBUTOR, SUPPLIER, INDEPENDENT CONTRACTOR OF RIM OR ANY AFFILIATES OF
RIM HAVE ANY LIABILITY ARISING FROM OR RELATED TO THE DOCUMENTATION.
Prior to subscribing for, installing, or using any Third Party Products and Services, it is your responsibility to
ensure that your airtime service provider has agreed to support all of their features. Some airtime service providers
might not offer Internet browsing functionality with a subscription to the BlackBerry® Internet Service. Check
with your service provider for availability, roaming arrangements, service plans and features. Installation or use
of Third Party Products and Services with RIM's products and services may require one or more patent, trademark,
copyright, or other licenses in order to avoid infringement or violation of third party rights. You are solely
responsible for determining whether to use Third Party Products and Services and if any third party licenses are
required to do so. If required you are responsible for acquiring them. You should not install or use Third Party
Products and Services until all necessary licenses have been acquired. Any Third Party Products and Services
that are provided with RIM's products and services are provided as a convenience to you and are provided "AS
IS" with no express or implied conditions, endorsements, guarantees, representations, or warranties of any kind
by RIM and RIM assumes no liability whatsoever, in relation thereto. Your use of Third Party Products and Services
33
shall be governed by and subject to you agreeing to the terms of separate licenses and other agreements
applicable thereto with third parties, except to the extent expressly covered by a license or other agreement with
RIM.
Certain features outlined in this documentation require a minimum version of BlackBerry® Enterprise Server,
BlackBerry® Desktop Software, and/or BlackBerry® Device Software.
The terms of use of any RIM product or service are set out in a separate license or other agreement with RIM
applicable thereto. NOTHING IN THIS DOCUMENTATION IS INTENDED TO SUPERSEDE ANY EXPRESS
WRITTEN AGREEMENTS OR WARRANTIES PROVIDED BY RIM FOR PORTIONS OF ANY RIM PRODUCT OR
SERVICE OTHER THAN THIS DOCUMENTATION.
Licensed by QUALCOMM Incorporated under one or more of the following United States Patents and/or their
counterparts in other nations:
5,490,165 5,504,773 5,506,865 5,511,073
5,228,054 5,535,239 5,267,261 5,544,196
5,568,483 5,337,338 5,600,754 5,414,796
5,657,420 5,416,797 5,659,569 5,710,784
5,778,338
BlackBerry® Curve™ 8520 smartphone model number: RCG41GW
BlackBerry® Curve™ 8530 smartphone model number: RCL21CW or RCZ31CW
Research In Motion Limited
295 Phillip Street
Waterloo, ON N2L 3W8
34
Canada
Research In Motion UK Limited
Centrum House
36 Station Road
Egham, Surrey TW20 9LF
United Kingdom
Published in Canada
35
