Car Multimedia

2005/2006

www.blaupunkt.com

The advantage in your car.

It’s not whether you win

or lose, it’s how you play

the game. As long as

you’re one of the winners.

Each new win raises

the bar: for you as well as for

us. We are well aware of this, not only

because we have come out winning the

tests conducted by trade magazines time and

again, but because we are also an official spon-

sor of the German Touring Car Masters. And we

always use the experience we gain in our pioneer-

ing technological advances to make you a winner,

too. Take radio reception in CD quality, for example.

Traffic congestion avoidance thanks to proactive

navigation. Travel entertainment and sound

experience customised to meet your specific

needs. Our drive for perfection is reflec-

ted in all Blaupunkt’s products.

And that makes everyone

a winner.

2/3

Introduction

1932 – the first

car radio. 1957 – the first tran-

sistor radio. 1969 – the first stereo radio.

1974 – ARI. 1982 – the first turn-by-turn route

guidance system. 1983 – the first CD player. 1988 –

the first RDS radio. 1989 – the first European naviga-

tion system. 1991 – TIM: Traffic Information Memory.

1994 – DSA: Digital Signal Adaptation. 1996 – the first

fully digital radio. 1997 – the first TMC radio. Digital

Radio/DMB. 1998 – traffic telematics. 1999 – the first pro-

active, dynamic navigation system. 2001 – the first digital

radio with MP3 and MMC. The first MP3 unit with 1 GB. The

first WAP-enabled off-board navigation system incl.

sound and telephone. 2002 – the TwinCeiver. 2003 –

digital recording function. 2004 – the first dynamic,

proactive navigation system with “optimal

route” and CD sound at the same time.

Ultra-flat speakers with front

neodymium magnets.

You’ll find

out what your advantage in

the car is when you take a look

towards the bottom of this page. From

the very first car radio to the first radio-

based navigation system with the “optimal

route” function, we can look back proudly on a

long list of innovative accomplishments. And

if you now take a look to the right, you’ll see

the innovations you have to look forward to.

Whether it’s sound or entertainment, radio

or a navigation system, mobile com-

munications or information: with

Blaupunkt, you’ll always be

right out in front.

Product Guide

Navigation

24|86 TravelPilot DX-V

16|86 TravelPilot E

17|86 TravelPilot E

25|32|87 Chicago IVDN-7003

25|33|87 Aspen IVDN-7003

In Car Entertainment

32|87 Chicago IVDM-7003

33|87 Aspen IVDM-7003

34|86 DVD ME4

35|88 TV Tuner and Signal Controller

36|88 Monitors

MP3 Tuners

08|18|82 Bremen MP74

09|29|82 Seattle MP74

28|82 Los Angeles MP74

09|19|82 Acapulco MP54

10|82 Calgary MP35

10|83 Barcelona MP35

11|83 London MP35

11|83 Kingston MP35

12|83 Madrid MP35

12|83 San Diego MP35

44|84 Essen MP35

44|84 Brighton MP35

CD Tuners

13|84 Vancouver CD35

13|84 Bristol CD35

45|84 Kiel CD35

45|85 Malaga CD35

Cassette Tuners

45|85 Ravenna C32

Digital Radios

20|26|85 Woodstock DAB 54

Sound

48|56|62|89 Velocity-Series

50|89 Amplifiers

58|89 Subwoofers

64|90 Speakers

57|62 OD-Series

59|90 Subwoofers

66|90 Speakers

49|57|63 TH-Series

52|89 Amplifiers

60|90 Subwoofers

68|91 Speakers

49|53|57|63 GT-Series

53|89 Amplifiers

61|90 Subwoofers

69|91 Speakers

70– 71 Antennas and Accessories

72– 81 Technology

82– 91 Product Overview

User Guide

Fun | 6 – 13

More fun with mobile entertainment

MP3 and CD Tuners

Bremen MP74

Seattle MP74

Acapulco MP54

Calgary MP35

Barcelona MP35

London MP35

Kingston MP35

Madrid MP35

San Diego MP35

Vancouver CD35

Bristol CD35

In Car Entertainment | 30 – 41

More enjoyment with multimedia

Navigation

Chicago IVDN-7003

Aspen IVDN-7003

Multimedia

Chicago IVDM-7003

Aspen IVDM-7003

DVD

DVD ME4

TV Tuner and Signal Controller

IVTV-03, IVSC-5502, IVSC-3302,

IVSC-1102

Monitors

IVMS-5802, IVMS-6502, IVMR-7002,

IVMR-9002, IVMR-1042, IVMR-1542

Performance | 14 – 21

More fascination with technology and design

Navigation

TravelPilot E

MP3 Tuners, Digital Radios

Bremen MP74

Acapulco MP54

Woodstock DAB 54

Basic | 42 – 45

More features at the entry level

MP3, CD and Cassette Tuners

Essen MP35

Brighton MP35

Kiel CD35

Malaga CD35

Ravenna C32

Business | 22 – 29

More convenience with mobile communications

Navigation

TravelPilot DX-V

Chicago IVDN-7003

Aspen IVDN-7003

Digital Radios, MP3 Tuners

Woodstock DAB 54

Los Angeles MP74

Seattle MP74

Sound | 46 – 69

More enthusiasm for great sound

Amplifiers | Subwoofers | Speakers

Velocity-Series

OD-Series

TH-Series

GT-Series

4/5

Contents

6/7

Fun

Fun – Are you in the

market for an attrac-

tive, new passenger

in your vehicle?

Good music

demands good sound. And

that always goes hand-in-hand

with the best possible reception.

Brilliant sound and rich volume.

Perfectly matched components. And

that means technology that is – and

stays – state-of-the-art. And then

there’s individual sound con-

figuration. And it’s all

Blaupunkt.

8Fun

MP3 and CD Tuners.

Bremen MP74

The TwinCeiver Bremen MP74, a digital twin receiver with

a Digital Directional Antenna (DDA), is clearly the top choice

for individualists with the most exacting demands on sound

and tuner performance. It is equipped with a four-channel,

self-adjusting equalizer with a total of 108 bands and delivers

richly detailed, differentiated, well-balanced sound. It is also

possible to adjust all 108 bands on your PC – to reflect your

own personal tastes and to accommodate the conditions in

your specific vehicle interior. Experience listening pleasure in

a new dimension.

connectivity

Vario

Colour

Fun

Seattle MP74

The Seattle MP74 with the Digital DigiCeiver is equipped with

a DEQmaxEX equalizer with a self-adjusting function that

enables it to determine perfect sound all on its own. Thanks to

the digital, self-adjusting parametric 5-band equalizer, you’ll

enjoy differentiated range of sound that can be individually

adjusted to accommodate the vehicle acoustics. You can also

choose from three key variocolor illuminations; green, red and

amber, which make the Seattle look perfect in your dashboard.

Acapulco MP54

The Acapulco MP54 with an MP3-enabled CD drive and

DEQmaxEX, a digital, fully parametric, self-adjusting 5-band

equalizer, is state-of-the-art in terms of technology as well as

looks. Real sound freaks can now use the PC connection to

adjust all the sound parameters on their PCs and the

VarioColour display is a delight to the eyes. You can select

exactly the display colour you want from more than 4,000

shades.

connectivity

Vario

Colour

10 Fun

MP3 and CD Tuners.

Nowadays, it’s hard to imagine in-vehicle sound without MP3

sound files. The advantages are obvious: not only is there a

diverse range of storage media, you’ve got a choice of different

playback devices as well. The most important argument in

favour of this technology, however, is the compression stand-

ard used for music files, based on the MPEG1 standard –

which gives you hours of music listening enjoyment. And a new

interface also makes it possible to connect an iPod, the mobile

MP3 player from Apple®. The unique VarioColour feature also

offers a great deal of flexibility in looks: 4,096 different shades

of colour enable you to match up the radio perfectly to virtu-

ally any vehicle dashboard.

Calgary MP35

Barcelona MP35

Aux- in

4-Channel

Preamp-out

4 x45 W

4-Channel

Preamp-out

Equalizer

Fun

London MP35

Kingston MP35

4-Channel

Preamp-out

4-Channel

Preamp-out

Vario

Colour

Speech

output

Vario

Colour

Sub out

12 Fun

Madrid MP35

Equalizer

Remote

Control

4 x45 W

Aux- in

4-Channel

Preamp-out

San Diego MP35

4-Channel

Preamp-out

MP3 Tuners.

Fun

Vancouver CD35

Aux- in

Sound

Presets

Bristol CD35

CD tuners from Blaupunkt exhibit convincing technology

with their high-quality, shock and shake-proof CD drives, easy

operation and high functionality. The Sound Preset feature, for

example, lets you set the ideal frequency response for different

types of music (rock, pop and classical) at the touch of a

button. The convenient 4-channel preamp out provides reli-

able control for external amplifiers and different connection

options make it possible to add to your music system.

4-Channel

Preamp-out

Aux- in

Sound

Presets

4-Channel

Preamp-out

CD Tuners.

We just keep raising

the bar, for sound as well as

for navigation. And our claim to the

technical sophistication of our pro-

ducts is also reflected in their modern,

ergonomic design. Advances that we

prove time and again with Digital Radio,

MP3 playback or the TwinCeiver. With

Blaupunkt, you experience the best

ever Car Multimedia. With all

your senses.

Performance –

See it with your

own two ears.

14/15

Performance

16 Performance

Get to your destination quicker and more conveniently

than ever before.

Precise, reliable route guidance with traffic congestion ahead

avoidance is good. Individual navigation – with a setting option

to combine the quickest and the shortest route – is better.

And being able to listen to music at the same time – CD or

MP3 – means technology of the finest.

The TravelPilot E , the TravelPilot E ’s big

brother, is equipped to perfection in terms of technology as

well as looks. Enjoy MP3 sound or your favourite CD, while

you take advantage of the dynamic corridor function to get

wherever you’re going on the optimal route without a traffic

jam in sight. Thanks to house number interpolation, the

TravelPilot E not only finds the best way to the street

you’re looking for, it takes you directly to the front door. Just

insert the Europe navi CD to get you to virtually any desti-

nation in Europe. Precise navigation with optional speed signal

hook-up (easy to install). Easy installation in just three steps:

remove the old system – connect the new one and attach

the GPS antenna – slide the Travel-Pilot E right in.

You’re done!

Display illumination in

white

Key pad illumination in

white

Display illumination in

blue

Key pad illumination in

red

Display illumination in

white

Key pad illumination in

red

Start/Finish corridor

Shortest route

Quickest route

Optimal route

Performance

The TravelPilot E has been making it easy to go into the

navigation mode since 2004. Thanks to a new chip concept,

this navigation system is excellent value for money. The

TravelPilot E started off as the first radio-based naviga-

tion system with optimal route guidance (combination of quick-

est and shortest route) and a dynamic corridor function.

And while you are listening to your favourite CD, the Travel-

Pilot E gets you to your destination, quickly and reliably.

The TravelPilot E is also able to boast easy installation

in just three steps thanks to the optional speed signal hook-up.

Other CDs including Major Roads:

Benelux E 2005, Germany E 2005, France E 2005 (incl. Monaco), Great

Britain/Ireland E 2005, Italy E 2005 (incl. San Marino and Vatican City),

Austria/Switzerland E 2005 (incl. Liechtenstein), Poland (from summer 2005),

Czech Republic E 2005, Portugal/Spain E 2005 (incl. Andorra), Scandinavia E 2005

(incl. Denmark, Sweden, Norway and Finland)

Features based on the Germany CD:

• Detailed road network in Germany

• Major connecting roads in: France, Belgium, the Netherlands, Luxembourg, Italy,

Great Britain, Ireland, Austria, Switzerland, Portugal, Spain, Norway, Sweden,

Denmark, Finland, Andorra, Liechtenstein, San Marino, Vatican City and Monaco

• Dynamic navigation in Germany, Austria, Belgium, Denmark, France, Italy, the

Netherlands, Sweden, Switzerland and Spain

• Destination input in Germany via postal codes (complete coverage in Germany)

• More than 260,000 Points of Interest, such as airports, motorways, border cross-

ings, city centres and petrol stations right on up to fast-food restaurants and much

• Compatible with the TravelPilot E , TravelPilot E

18 Performance

The Blaupunkt Bremen MP74 is the first car radio to have made

it to “autohifi” magazine’s reference class, a prestigious award

given by Europe’s well respected Car hifi magazine. Thanks to

a self-adjusting equalizer (DSA Max) with 108 bands, which

can also be adjusted individually, you’ll experience optimal

sound at the touch of a button. And we even added an interface

(PC connection) to connect the car radio with a PC so that you

can display all the sound settings conveniently on a large screen

while you adjust them in real time. A TwinCeiver equipped with

two DSP-based receivers puts the finishing touch on perfect

radio reception. The TIM speech memory makes it possible to

store traffic messages lasting a total of four minutes, and, last

but not least, the high-resolution full-graphic display with

VarioColour makes for a fantastic all-round package.

Two of a kind.

Bremen MP74

connectivity

Vario

Colour

Performance

The automatic DEQmaxEX self-adjusting equalizer is the heart

of the Acapulco MP54 DigiCeiver. It can optimize the system’s

sound at the touch of a button. Or use the PC connection to

fine-tune the system’s sound performance on your computer

yourself. This car radio sports a very elegant look, featuring

a VarioColour display. Select your favourites from among

4,096 colours and 16 coloured night design shades.

Acapulco MP54

connectivity

Vario

Colour

20 Performance

Digital Radio – the future on board.

Woodstock DAB 54

The Woodstock DAB 54 digital radio features a professional

design with a high-resolution full-graphic display and sophisti-

cated technology. Interference-free listening pleasure in CD

quality is guaranteed by digital reception on the DigiCeiver. A

one-of-a-kind digital recorder lets you record your favourite

song on an SD/MMC card even when you’re already on the road.

And don’t fret if you missed the first few seconds – thanks to

Blaupunkt technology, your recording will be complete from

start to finish every time.

Performance

Services

With Digital Radio, you can now display additional information

visually. Information on the radio programme that is automati-

cally broadcast with the radio signal, for example, can be

shown in a display. This service can be specifically related to

the current programme (e. g. song title, artist and CD cover for

title currently played) or completely independent of it (e. g.

news, weather, traffic, timetables, stock market information,

tips).

PDA

Use your Personal Digital Assistant (PDA) in combination with

Digital Radio to take advantage of a wide variety of services.

Bluetooth technology and an optional interface connect your

PDA with the digital radio. And you can download the DAB

browser from the Blaupunkt website free of charge.

For more information, go to www.digitalradio.de

Business –

Even leaders sometimes

need a little guidance.

You’ll always know

where you are going with navi-

gation systems from Blaupunkt.

Proactive. Dynamic. Quick and precise.

Simply bypass any traffic congestion ahead

as easily as you insert a CD. And if you like,

you can let your feelings be your guide. As far

as the music is concerned, that is. After all,

this is where you’re in complete control –

with top class sound, easy handling and

future proof technology. In short:

Blaupunkt keeps you heading in

the right direction.

22/23

Business

24 Business

In full view: Navigation.

TravelPilot DX-V

The TravelPilot DX-V high-end navigation system with an infra-

red remote control system and wide screen monitor puts on a

convincing show in its clear-cut design and 16 :9 format.

Proactive navigation with dynamic route guidance and traffic

congestion avoidance via TMC keeps you fully informed all

the time. Detailed map displays with different views and a split

screen show you everything you need to know at a glance.

Perfect input with the help of the Operating

Assistant.

The on-board computer shows you such details

as average speed or driving time any time you

want.

Select between the arrow or map display or use

both at once.

You’ll always know exactly where to find the

next hotel, restaurant or petrol station.

Traffic congestion is automatically taken into

consideration in route guidance.

Decide for yourself whether or not to avoid

motorways, toll roads or ferries.

Steering wheel

remote control

optional

Hand-held

remote control

included

Business

Chicago IVDN-7003

In combination with the TravelPilot DX-V navigation computer,

the Aspen IVDM-7003 also turns out as a full-fledged multi-

media navigation system with an easy-to-follow route and map

display.

The addition of the TravelPilot DX-V navigation computer trans-

forms the Chicago IVDM-7003 into a convenient navigation

package. The different displays on the easy-to-read 7” monitor

help you to get where you’re going, quickly and directly.

DX-TravelGuide CDs with travel-guide function:

Michelin

• Benelux

• France

• Germany

• Great Britain

• Spain/Portugal

De Agostini

•Italy

MERIAN scout

• Alps

• France

• Germany

• Germany Executive

• Germany

Sport & Leisure Time

•Italy

TravelGuide information on:

• Hotels

• Restaurants

• Petrol stations

• Points of interest

• Car parks

• Banks

• Hospitals

• Distance indicator

• Credit cards accepted

• Operas

• Museums

• Bars

• Post offices

• Police

• Airports

• Concert halls

• Tennis courts

• Adventure/

amusement parks

• Trade shows

Aspen IVDN-7003

26 Business

For Business as Usual.

Blaupunkt sets new standards in terms of speed and precision

in the business segment. Anyone travelling on business needs

information, up-to-date and easy-to-access. And the same high

demands are made of entertainment quality. Much of our

equipment meets the highest business standards: with its

revolutionary DigiCeiver concept, Blaupunkt offers unparallel-

ed FM reception quality in your car. And the Woodstock DAB 54

is already equipped with the reception standard of the future –

Digital Radio. Thanks to the digital recorder, you can even

record music on a SD/MMC card from DAB while you’re on the

Woodstock DAB 54

4 x50 W

Bluetooth technology makes it possible to connect your PDA

(Personal Digital Assistant) to the Woodstock DAB 54. A DAB

browser for the PDA can be downloaded from the Blaupunkt

website free of charge.

Business

road. From start to finish – even if you missed the first few

seconds. As another extra feature, you can also connect

a Personal Digital Assistant (PDA) with a touch screen and

Windows CE operating system. With Bluetooth technology

and an optional interface, it can be connected with your

Woodstock DAB 54 to keep you right up to date wherever and

whenever. A DAB browser for your PDA can be downloaded

from the Blaupunkt website free of charge.

28 Business

A Perfect Combination of Style and Technology.

With its high-resolution full-graphic display, the Los Angeles

MP74 offers you all the information you need at a glance. The

tuner with an MP3-enabled CD drive exhibits outstanding

sound characteristics and enhanced reception thanks to

unique DigiCeiver technology. The digital, self-adjusting, fully

parametric DEQmaxEX 5-band equalizer determines the

optimal sound for your vehicle on its own. The flip-release panel

is motorised. And thanks to VarioColour, you have more than

4,000 colours to choose from to match your display background

colour to the dashboard in your vehicle. The steering-wheel

remote control comes as standard, it’s easy to use without

distracting you from the traffic situation.

VarioColour

You decide what colour the display of your Los Angeles MP74

should have. Car radios equipped with VarioColour offer you a

selection of 4,096 different shades and a colour scan function

at the touch of a button for a wide variety of design options –

either matching your instrument cluster or just for fun.

Los Angeles MP74

connectivity

Vario

Colour

Business

With the digital DEQmaxEX equalizer, the Seattle MP74 featu-

res an automatic self-adjusting function to optimize the sound

in your vehicle at the touch of a button. The steering-wheel

remote control unit is easy to use without distracting you from

the traffic situation. The Seattle MP74 DigiCeiver with an MP3-

enabled CD drive and ergonomic design with a classic black

front panel combines technical sophistication with elegant

looks.

Seattle MP74

4 x50 W

In Car Entertainment –

Your car key is your

admission ticket to the

movies.

Blaupunkt Car Multi-

media opens up a new world of

information and entertainment – one

that you can customise to your own per-

sonal tastes. Put together your own indivi-

dual package by selecting from the different

products: music and navigation for the dri-

ver and front-seat passenger, for example,

and DVD or TV systems for the back seats.

With In Car Entertainment, you have

so many options to choose from.

But the name is always the

same: Blaupunkt.

30/31

In Car Entertainment

32 In Car Entertainment

A Perfect Combination of Style and Technology.

This DVD player with a power 7”TFT touch panel for particular-

ly easy operation forms the basis of a complete entertainment

and information system, featuring an RDS tuner, two additional

AV outputs to connect such auxiliary sources as a navigation

computer, back-up camera, etc. and two AV output jacks to

connect additional monitors. And there’s also an integrated

surround decoder to provide for the best in listening pleasure

on the road.

Chicago IVDM-7003

The TravelPilot DX-V navigation computer transforms the

Chicago IVDM-7003 into a convenient navigation package. The

different displays available on the easy-to-read 7” monitor help

you to get where you’re going quickly and directly.

Chicago IVDN-7003

5x45 W

In Car Entertainment

The aspen IVDM-7003 opens the door for you into the world of

automotive multimedia. It is equipped with convenient system

operation via a 7” TFT touch-panel monitor, a DVD player, an

RDS tuner and the option of connecting two auxiliary sources

and monitors.

In combination with the TravelPilot DX-V navigation computer,

the Aspen IVDM-7003 also becomes a full-fledged multimedia

navigation system with easy-to-understand route and map

displays.

Aspen IVDM-7003

Aspen IVDN-7003

4 x45 W

34 In Car Entertainment

We offer the best in entertainment.

Whether it’s your favourite film or just music: the DVD ME4

makes both possible. It plays not only your DVDs and CDs,

it can also handle MP3 or DivX files. The connection of a

Blaupunkt monitor provides rear-seat passengers in particular

with relaxing entertainment options on the road. And cinch

input jacks make it possible to connect a digital camera or a

gaming console.

DVD ME4

Remote

Control

In Car Entertainment

You and your passengers all have different ideas about what

good entertainment really is: your son wants to play a video

game, while your daughter wants to watch her favourite DVD,

and you want to listen to a CD. The switching control centre

in the Blaupunkt In Car Entertainment program, the signal

controllers, allow you to use up to four different sources at the

same time. And if your partner wants to watch TV as well, all

you need is the IVTV-03 TV tuner.

IVTV-03 IVSC-5502

IVSC-3302 IVSC-1102

36 In Car Entertainment

Perfect cinema feeling.

They offer unlimited viewing enjoyment and transform your

vehicle into a cinema on wheels to provide you with exactly

the entertainment you want. This makes every trip, no matter

how long it may be, a pleasure. The outstanding picture quality

of the TFT-Matrix LCD completes that perfect cinema feeling.

The monitors can be operated either directly on the sets or

conveniently by remote control.

IVMS-5802

In Car Entertainment

IVMS-6502

38 In Car Entertainment

It’s all in how you look at it.

IVMR-7002

Suspended conveniently from the roof

interior, Blaupunkt roof monitors in diffe-

rent screen sizes offer the best in view-

ing pleasure. And when the film is over,

they simply fold back up out of the way.

IVMR-9002

In Car Entertainment

IVMR-1042

IVMR-1542

40 In Car Entertainment

Customised Car Entertainment.

Blaupunkt In Car Entertainment products make it possible to

put together the best combinations to satisfy a wide variety

of different requirements. From simply extending an existing

navigation system right on up to creating a complex multimedia

system: the components on offer leave nothing more to be

desired.

Stand-alone navigation and source (e.g. here with DVD)

Woodstock DAB 54

DVD-ME4

Flip-out monitor, navigation and TV tuner

Chicago IVDN-7003

or Aspen IVDN-7003

Optional

DX-V navigation computer

One source, e.g. TV tuner

IVTV-03 TV tuner

Optional

DX-V wide screen Monitor

DX-V navigation computer

IVSC-1102

signal converter

Audio

In Car Entertainment

Rear-seat entertainment system Dolby Digital

A/V multimedia high-end system

IVMS-6502

IVSC-3302

signal controller

DVD-ME4

IVMS-5802

IVSC-5502

signal controller

IVMR-9002

Chicago IVDM-7003

IVTV-03 TV tuner

e.g. Game Station

or back-up camera

DX-V

navigation computer

DVD-ME4

IVMS-6502IVMS-6502

Chicago IVDM-7003

Velocity

VD Six

Vw 300

subwoofer

Vc 172

front right

Vc 172

rear right

Vc 172

rear left

ODce 20

centre

Vc 172

front left

Get in, switch on,

drive off. With the right sound

all the way. With a modern design.

And with a system that’s even easier to

operate than it is to install. Whether you

choose a cassette, CD or MP3 player – you’ll

enjoy life with all its highs and lows. Our

powerful equalizers will make sure of that.

Hear the difference for yourself. And you can

see it as well: just take a look at the test

winners in one of the trade magazi-

nes. Entry-level systems that satisfy

exacting demands. No more

than child’s play for us.

Basic –

Child’s play to operate.

For a very grown-up

kind of sound.

42/43

Basic

44 Basic

Listen to the music.

If you like to concentrate on what is most important, Blaupunkt

offers you this series of uncomplicated, easy-to-use car radios.

Choose your favourite from radios equipped with MP3 sound,

a CD player or a cassette deck. With their elegant black front-

panel design, these car radios make a stylish addition to any

vehicle and you can always depend on outstanding Blaupunkt

quality.

Essen MP35

Brighton MP35

4-Channel

Preamp-out

Aux- in

4 x45 W

4-Channel

Preamp-out

Aux- in

4 x45 W

Basic

Kiel CD35

Malaga CD35

Ravenna C32

4-Channel

Preamp-out

Aux- in

Sound

Presets

4-Channel

Preamp-out

Aux- in

Sound

Presets

Maximum

sound and the most

powerful bass ever. That’s

what our amplifiers deliver. High-

quality materials and innovative

technology guarantee richly detailed

high-performance sound in every

frequency range. And this will ampli-

fy not only the sound, but your

enjoyment of it as well. Were

you expecting anything

less?

Sound –

Amplify your feelings.

46/47

Sound

48 Sound

Sound in New Dimensions.

Four different Blaupunkt amplifier series deliver a new genera-

tion of sound designed to electrify your senses. Blaupunkt sets

new standards with extraordinary reliability, outstanding sound

quality, even greater power-handling capacity and an excel-

lent range of features: there’s something for every taste, every

space and every budget.

The Velocity Pro Series amplifiers impres-

sively demonstrate state-of-the-art ampli-

fier engineering. The VPA amplifiers really

kick it up a notch, with sensational perfor-

mance values and sound charactistics as

well as a practical, comprehensive range

of outstanding features.

Velocity Pro –“The Ultimate Series”

With its flexible, exclusive looks, this new VA

amplifier line is able to satisfy even the most

exacting tastes. Thanks to the innovative

Velocity Pro –“The Competition Series”

Amplifier

channel 3

Amplifier

channel 1 Overload pro-

tection circuits

DC-DC converter

for channel 1/3

Solid

speaker

terminals

Fuses

Amplifier

channel 2

Amplifier

channel 4

Power supply

unit filter

capacitors

Double-sided

circuit board

impregnated

with epoxy resin

DC-DC converter

for channel 2/4

Solid terminals

for + 12 volts

Audio

output

Temperature

Typical amplifier

Time

Audio output in comparison

Audio

output

Temperature

Blaupunkt Thermal Throttle

Time

Thermal Throttle circuit, the amplifiers are

able to operate continuously at maximum

power levels without the risk of shut-down.

Sound

The GTA amplifiers are a prime example of what Blaupunkt

understands as optimal “value for money”. Maximum reliability,

high power reserves and a rich range of features are combined

here with great workmanship – it’s no wonder then that this

amplifier series is incredibly successful.

THA –“The Easy Installation Series”

GTA –“The Best Value Series”

Thanks to the flat installation depth of its heat sink profile

(just 43 mm), the THA amplifiers can be easily installed

anywhere where conventional amplifiers usually have to give

up. The elegant surface finish, high reliability and protection

of all the connections with the removable end caps complete

this amplifier series.

50 Sound

Top Equipment for Excellent Sound.

Velocity Pro –“The Competition Series”

• Uncompromising design for highest sound quality and maximum performance

• Exclusive use of only the highest-quality materials and components

• Oversized heat sink for optimal reliability under the most extreme conditions

• Enormous adaptability thanks to a multitude of setting options for the integrated filters

VPA 11500

Variable low pass

Variable

bass boost/subsonic filter

Phase control 0/180

1x 3000 W

VPA 2120

Variable low pass /high pass

Variable

bass boost/subsonic filter

Phase control 0/180

2x 250 W

1x 750 W

VPA 4120

Variable low pass /high pass

Variable

bass boost/subsonic filter

Phase control 0/180

4 x 250 W

2 x750 W

Sound

VA 4100

Thermal Throttle

Variable low pass /high pass

Remote control

4 x 250 W

2 x700 W

VA 2100

Thermal Throttle

Variable low pass /high pass

Remote control

2x 250 W

1x 700 W

Velocity –“The Power Series”

• The Thermal Throttle circuit reliably prevents the risk of

audio output shut-down under all operating conditions

• Flexible system of removable end caps and side rails made

of solid aluminium

• Visually seamless installation to integrate multiple ampli-

fiers into a single unit

• All amplifiers come complete with cable remote control

VA 1400

Thermal Throttle

Variable low pass

Remote control

1x1200 W

52 Sound

Good Looks and Technical Sound Highlights.

THA 1400

Variable low pass

Variable

bass boost/subsonic filter

1x1000 W

THA 480

Variable low pass /high pass

Variable bass boost

4 x 200 W

2 x 600 W

THA 280

Variable low pass /high pass

Variable bass boost

2x 200 W

1x600 W

THA –“The Easy Installation Series”

• Easiest installation thanks to particularly flat design with a

depth of just 43 mm

• Flexible design with removable end caps that reliably protect

all wiring and setting controls

• Visually seamless installation to integrate multiple

amplifiers into a single unit

• THA 1400 and THA 280 include cable remote control

Sound

GTA –“The Best Value Series”

• Solid, oversized heat sink for optimal performance and

reliability

• High adaptability thanks to comprehensive setting options

for the integrated filters

• Very high audio output and 2-ohm stability

GTA 1300

Variable low pass

Variable

bass boost/subsonic filter

1x 750 W

GTA 470

Variable low pass /

high pass

Variable

bass boost

4 x 150 W

2 x 400 W

GTA 270

Variable low pass /

high pass

Variable

bass boost

2 x150 W

1x400 W

GTA 400 Flash

Variable low pass

Switchable high pass

Switchable

bass boost

4 x 90 W

2x300 W

GTA 200 Flash

Variable low pass

Switchable high pass

Switchable

bass boost

2 x 90 W

1x350 W

Impressive pressure:

speakers from Blaupunkt. And

that’s no coincidence – it’s all based

on a well-thought-out combination of

high-quality materials. As well as on tests,

tests and more tests. That is the only way to

find out whether the speakers are able to stand

up to extreme conditions and to the extreme

bandwidths our amps have to offer. Not to men-

tion the bandwidth of your own musical tastes.

After all, we don’t know whether you listen

to hip-hop or heavy metal. But we can be

sure of one thing: any kind of music

sounds better when it’s true to

life and free of distor-

tion. Right?

Sound –

Easy listening.

Even when it gets

hard and heavy.

Sound 54/55

56 Sound

Subwoofers.

The newest subwoofer generation from Blaupunkt will really

make your car rock and reproduces even the lowest octaves

with power and precision. Sound pressure and deep bass be-

come an intensive, sensual experience. With clearly structured,

cleanly defined bass in combination with exclusive design,

these subwoofers significantly enhance your music listening

pleasure. Blaupunkt delivers long-term quality and highest

performance to satisfy a wide variety of different demands.

Velocity Pro –“The Competition Series”

The extreme VPw subwoofers in the

Velocity Pro Series were built to satisfy

the most exacting demands for superior

sound. The sophisticated technology will

have even the most hard-core deep-bass

and sound-pressure fan convinced.

Unrivalled power handling and maximum

sound pressure give new meaning to the

expression “deep bass”.

The new Velocity subwoofers are equip-

ped with many of the virtues sported by

their ‘Velocity Pro series’ counterparts.

The solid diecast baskets, the stiff, stable

fibreglass cones and the powerful drivers

provide the right pressure, even under

rigorous competitive conditions.

Velocity –“The Power Series”

VPw 300 sound-level profile

50-mm wide BUTYL RUBBER

SURROUND

Joined to the cone with a reinforced

seam to reduce bell-node resonance,

increase service life even under

extreme conditions and maximum

excursion.

Double SPIDER

Provides for a smooth cone ride

for even extreme cone excursion

Solid DIECAST BASKET

Non-magnetic, resonance-free

basket for optimal drive unit

mounting.

Double-stacked STRONTIUM-

FERRITE MAGNET SYSTEM

Oversized, for high drive energy

and maximum cone excursion

Extremely stiff, stable CONE

made of carbon and fibreglass

(CFG) for 30 % more inner attenua-

tion, resulting in distortion-free

reproduction at high power levels

LITZ WIRE woven into the spider

prevents noise and increases

service life, even for extremely

high cone excursion

75-mm VOICE COIL

on an aluminium carrier, wound

for maximum thermal power

handling

VPw subwoofer

Sound

GT –“The Best Value Series”

The elegant design of the shiny

blue cones underscores the solid

technology of the three subwoo-

fer boxes in the GT Series. Up to

1,500 watts of impressive maxi-

mum power handling rounds out

this exception to the rule in this

segment.

Linear spectrum

EXP

design

subwoofer

THb

subwoofer

Other linear bandwidth for enhanced

performance

Compare the installation depth of the THb

vs. the Vb

The THb subwoofer takes up much less room

in the boot than a normal subwoofer.

The new THb systems are considerably

flatter than conventional enclosures, thus

reducing the space they require in the

boot to a minimum. With absolutely no

adverse effects on the deep bass quality.

The powerful drivers with generously

proportioned force factors provide for the

right sound pressure.

TH –“The Easy Installation Series”

OD –“The Compact Series”

There’s always room for a subwoofer, even in the smallest boot – as long as it’s a

subwoofer from the Blaupunkt OD Series. And thanks to the integrated amplifier,

this subwoofer is particularly easy to add to factory-installed sound systems. All

it takes is a few connections (even without a preamp out) to transform a system

that’s short on bass into a rich sound experience.

58 Sound

Optimal Variety.

Velocity Pro –

“The Competition Series”

• Optimized for highest power handling and

maximum sound pressure

• Ultra-stable carbon/fibreglass cone (CFG)

• Solid aluminium diecast basket with an

“integrated magnet system”

• Design covers included

Velocity –“The Power Series”

• Stable, particularly hard fibreglass cone

• Large dual voice coils for highest power handling

• Solid aluminium diecast basket

VPw 460

2 x 2 ohms

CFG cone

Diameter: 460 mm

5400 W

VPw 380 VPw 300

Vw 380 Vw 300 Vw 250

2 x 2 ohms

Fibreglass cone

Diameter: 380 mm

3000 W

2 x 2 ohms

Fibreglass cone

Diameter: 300 mm

2250 W

2 x 2 ohms

Fibreglass cone

Diameter: 250 mm

1500 W

2 x 2 ohms

Diameter: 380 mm

4500 W

CFG cone

2 x 2 ohms

CFG cone

Diameter: 300 mm

3600 W

Sound

Vb 300

ODsb 8000A

Active subwoofer box

Diameter: 200 mm

with passive radiator

140 W

OD –

“The Compact Series”

• Integrated amplifier for easiest

installation

• Ultra-compact

• Easy connection to factory-installed

sound systems

• High-level inputs

Highlights in the Vb series

• Stable, particularly hard fibreglass cone

• Large dual voice coils for highest power handling

• Solid, compact enclosures made of MDF with design covers

2 x 2 ohms

Diameter: 300 mm

bass-reflex

1200 W

Vb 250

2 x 2 ohms

Diameter: 250 mm

bass-reflex

600 W

60 Sound

The bassest of the bass!

THb 300

THb 250

4 ohms

Diameter: 250 mm

bass-reflex

600 W

THb –

“The Easy Installation Series”

• Particularly flat installation depth – requires

significantly less room in the boot than a

conventional subwoofer

• High-power-handling drivers with a stable

PP cone and integrated magnet system

• Solid, compact enclosures made of MDF

with design covers

4 ohms

Diameter: 300 mm

bass-reflex

750 W

Sound

GT –“The Best Value Series”

• High-power-handling drivers with a stable

“spun paper” cone and EXP technology

• Solid, compact enclosures made of MDF

with design covers

GTb 300 Dual

2 x 4 ohms

Diameter: 2 x 300 mm

1500 W

GTb 300

4 ohms

Diameter: 300 mm

750 W

GTt 300

4 ohms

Diameter: 300 mm

600 W

62 Sound

Speakers.

Great in-car sound is difficult to recreate without good

speakers. Thanks to high-quality workmanship, Blaupunkt

speakers always deliver even at constant high power levels.

Installation is no problem as Blaupunkt offers practical

solutions for virtually any vehicle on the market.

The target definition in the development

of this high-end speaker was “simply

the best”. With top-rate sound, these

speakers master the reproduction of any

type of music and tease out even the

finest details with ease. Friends of high-

end performance will be delighted to

find first-class material workmanship

combined with the finest components.

Velocity –“The Competition Series”

Speakers at the absolute top of the class

that are as easy to install as conventional

speakers, but come very close to the

technology and sound of the ultimate VPc

Series. That translates as the music of

your dreams and highest power handling

capability, combined with easy installa-

tion.

Velocity –“The Power Series”

The OD Series, which received the

Innovation Award in the USA, stands out

by virtue of its very flat design and most

modern materials. Maximum sound with

minimum installation depth, among other

things, is guaranteed by the innovative

front neodymium magnet.

OD –“The Compact Series”

Sound

TH –“The Easy Installation Series”

GT –“The Best Value Series”

With its innovative drive concept, the new

TH Series shows how compact high-qua-

lity speakers can be. Installation depth as

a limiting factor is virtually eliminated –

without making any compromises in

sound quality.

Perfection at ground level – with the new GT Series. Perfect

sound quality and reliability at outstanding value for money make

these speakers particularly interesting. And the shiny blue cones,

the chrome-plated tweeter systems and the elegant design

covers make them so successful.

Linear spectrum

EXP

design

Other linear bandwidth for enhanced

performance

64 Sound

Velocity – Ultimate Power.

VPc 172

VPc 132

Velocity Pro –

“The Competition Series”

• Ultra-stable carbon/fibreglass cones

(CFG)

• Solid aluminium diecast baskets

with an “integrated magnet system”

• Separate steep crossovers with

selected components

• Design covers included

28-mm tetron dome tweeter

CFG cone

Diameter: 165 mm

360 W

28-mm tetron dome tweeter

CFG cone

Diameter: 130 mm

300 W

Sound

Vc 172

25-mm silk dome tweeter

Fibreglass cone

Diameter: 165 mm

300 W

Vc 132

25-mm silk dome tweeter

Fibreglass cone

Diameter: 130 mm

240 W

Velocity –“The Power Series”

• Stable fibreglass cones

• Removable magnet covered for cramped installation spaces

• Separate steep crossovers

• Design covers included

66 Sound

Maximum Power – Minimum Space.

OD –“The Compact Series”

• Particularly flat and ultra-light for easiest installation

• Highly efficient neodymium magnets for tweeters and woofers

• Low-resonance PWF cones

• Design covers included (except for ODx 92)

ODc 172 ODx 172

Neodymium drive

Diameter: 165 mm

210 W

Neodymium drive

Component system

Diameter: 165 mm

240 W

ODc 162 ODx 162

ODc 132 ODx 132

Neodymium drive

Diameter: 130 mm

180 W

Neodymium drive

Component system

Diameter: 130 mm

180 W

Neodymium drive

Component system

Diameter: 160 mm

210 W

Neodymium drive

Diameter: 160 mm

210 W

Sound

ODx 693 ODx 102

Neodymium drive

Diameter: 100 mm

120 W

Neodymium drive

3-way triax system

Diameter: 6’’ x 9’’ mm

300 W

ODx 573 ODx 92

Neodymium drive

Diameter: 87 mm

90 W

Neodymium drive

3-way triax system

Diameter: 5’’ x 7’’ mm

270 W

ODx 462 ODc 25

Silk dome tweeter

Diameter: 25 mm

300 W

Neodymium drive

Diameter: 4’’ x 6’’ mm

120 W

68 Sound

Great Sound – Easy to Install!

THc 172 THx 172

Injected PP cone

Diameter: 165 mm

150 W

Injected PP cone

Component system

Diameter: 165 mm

180 W

THc 132 THx 132

Injected PP cone

Component system

Diameter: 130 mm

150 W

Injected PP cone

Diameter: 130 mm

120 W

THx 693 THx 102

Injected PP cone

Diameter: 100 mm

120 W

3-way triax system

Diameter: 6’’ x 9’’

210 W

TH – “The Easy

Installation Series”

• Ultra flat for easy installation

• Rear-ventilated voice coils

for high thermal power

handling

• Neodymium magnets as

drives for the tweeters

• Design covers included

Sound

GT –“The Best Value Series”

• Low-resonance injected PP cones

• Design covers included

GTc 172 GTx 203

Injected PP cone

3-way triax system

Diameter: 200 mm

150 W

Injected PP cone

Component system

Diameter: 165 mm

140 W

GTx 693 GTx 173 GTx 172

Injected PP cone

Diameter: 165 mm

120 W

Injected PP cone

3-way triax system

Diameter: 6’’ x 9’’ mm

150 W

Injected PP cone

3-way triax system

Diameter: 165 mm

140 W

GTx 132 GTx 462 GTx 102

Injected PP cone

Diameter: 100 mm

90 W

Injected PP cone

Diameter: 130 mm

110 W

Injected PP cone

Diameter: 4’’ x 6’’ mm

110 W

70 Antennas

The perfect fit.

Blaupunkt delivers not only high-quality car radios, navigation

and multimedia systems. We also offer a finely-tuned pro-

gramme of accessories for the optimal integration of the

systems in any vehicle. With customized installation kits for

easy installation, adapter cables to reduce installation time

and interfaces that allow you to add new devices to your in-car

audio system, system supplier Blaupunkt offers everything you

need to ensure that you have a comfortable ride.

Get the best reception

In addition to conventional car radio

antennas and combined radio, telephone

and navigation antennas, Blaupunkt also

sells high-tech products for digital radio.

A-PG01-E

Telephone-window antenna

The new window antenna is the future-

proof solution for your car phone.

• Easiest installation

• No drilling required

• UMTS-enabled

• GSM 900/800

Antennas

Autofun antenna

The most frequently sold window antenna

in the world with a new look and excellent

reception

• Easy to install

• Integrated amplifier

• AM/FM

Digital Radio Autofun

The active on-glass antenna guarantees

outstanding reception and easy installa-

tion.

• Band III (174 – 240 MHz)

• L band (1452 –1492 MHz)

• No drilling required

• Plug&play, i. e. no adapter required

A-DR-T 01-M Digital-radio

combined roof antenna

The active antenna is the perfect

replacement solution for existing roof

antennas.

• AM, FM

• L band (1452 – 1492 MHz)

• Band III (174 – 240 MHz)

• 2 services in one antenna

• Fits into existing drill holes when

replacing old antenna

• Retrofit solution for AM/FM and DAB

• Easy installation thanks to integrated

crossover and amplifier in antenna base

• Optimal reception throughout Europe

Design rod

The attractive rod antenna is a delight to

Your eyes and your ears

• Top-class design

• Great reception despite reduced length

• Easily replaces existing antenna

• Fits all popular vehicles models with

M5 screw threads

• AM/FM

Accessories

CD changers

Installed in the standard DIN compartment, this 5-disc

CD changer is controlled by Blaupunkt DMS radios and allows

unlimited music enjoyment for longer periods of time.

IDC-A 09

CDC-A 03

Just hook up the iPod to the changer interface of your car radio

and you have

• play lists that you can see and select from in the radio display

• song folders, songs played and performing artists on the display

• a battery that get recharged by the interface so that it’s always

fully charged in the car.

• Compatible to all car radios and navigation systems with CD

Changer control ability

Apple®iPod Interface

Remote Control Units

The RC 13H cable remote control was specially designed for

back-seat passengers. It is compatible with the Bremen MP74

and makes it possible to play a CD while the driver is listening

to his/her own programme, for example. Blaupunkt offers the

RC 10 infrared remote control for the steering wheel – design-

ed to save the driver from any distraction, even in the dark. And

of course, it controls all the most important functions of your

in-car hi-fi system (tuner, cassette recorder, CD CDC).

RC 10

The 10-disc CDC-A 03 CD changer can play even more music

without interruption.

Can Basic Interface/Remote Control Interfaces

Blaupunkt now offers the high-quality Can Basic interface

for vehicle in the VW Group (Audi, VW, Seat, Skoda) as well as

for Daimler-Chrysler vehicles with a CAN bus solution without

steering wheel remote control. For all popular Can Bus network-

ed vehicles with steering wheel remote control, Blaupunkt

delivers interface solutions to retain the remote control func-

tions after the unit has been replaced. The installation time is

reduced to a maximum of 2 hours, all the wiring is included and

long cable simplify installation considerably.

RC 13H

72/73

Technology

Technology –

There are many different reasons

for perfect sound. But only one

manufacturer.

DDA, SHARX,

neodymium tweeters,NTSC.

We know what makes perfect

Car Multimedia. And so that you

know it too, you’ll find the Blaupunkt

Technical Terminology on the following

pages – describing all the technical

terms and product features. After all,

anyone who tunes into innovative

technology will be interested in

the perfect fine-tuning for

In Car Entertainment

as well.

DAB – Digital Audio Broadcasting

➞Digital-Radio

DAB Antennas

In contrast to the familiar analogue radio

(AM/FM 0.145–108 MHz), digital radio is

broadcast with its 2 bands (Band III 174–240

MHz, L-Band 1452–1492 MHz) in a higher

frequency range. That is why it is necessary

to add an antenna or replace the existing

AM/FM antenna before it is possible to enjoy

uninterrupted digital radio listening pleasure

and the reception of extensive data services

(news, traffic messages, traffic congestion

maps, car park information, stock-market

reports, display of artist and song title, etc.).

In this department, Blaupunkt offers 5 diffe-

rent antennas to cover the digital radio fre-

quency range. These include single antennas

to simply add to your existing system or com-

bination antennas to replace the old antenna.

Depending on the model, the combination

antennas also offer AM/FM and/or GSM in

addition to DAB.

DDA – Digital Directional Antenna

74 Technology

Angle (horizontal/vertical)

This describes the range within which the

picture displayed on an LCD monitor can be

easily identified. The values indicated are for

the viewing angle from the side (horizontal)

and a vertical (from above/from below)

position (e.g. horizontal +45 degrees/

–45 degrees).

Angle

Depending on where the car radio is install-

ed, the reading angle of the display can be

adjusted to best suit the driver.

Audio output

The audio output power of a car radio or

an external output stage measured according

to different measurement standards.

RMS power:

Continuous power with a sine wave, measur-

ed at 10 % THD (DIN 45.324) for car radios

or at 1 % THD (DIN 45.500) for amplifiers or

another THD as indicated.

Music power:

Continuous power with a complex signal

(music signal), measured at 10 % THD

(DIN 45.324) for car radios or at 1% THD

(DIN 45.500) for amplifiers or another

THD as indicated.

Max. Power:

Maximum short-term output power possible,

important for extreme level peaks.

AutomaticSound

AutomaticSound, also known as GALA,

controls the volume in relation to the driving

speed. Important: the speedometer signal

must be connected to the car radio.

Aux-In

Stereo preamp in-line to which an external CD

changer is usually hooked up. An adapter can

also be used to connect other external signal

sources such as portable CD or MP3 players.

Aux naming

External sources, such as an MD-Walkman,

can be given any user-defined name (max.

of 16 characters). This name will then appear

in the display of the car radio when the

corresponding source is selected.

Bass-Boost

The Bass-Boost control is used to adjust

the bass reproduction of the amplifier. The

settings normally range from 0 dB to +12 dB

or +18 dB and boosts the deep bass sound.

Bass-Boost creates a full, rich, powerful

bass sound from relatively small subwoofer

enclosure volumes.

Bass-Tube

A subwoofer usually built into a round,

acoustically matched enclosure. Particularly

well suited for vehicles in which the boot is

not physically separated from the passenger

cabin. If maximum loading capacity is requir-

ed in the boot, just remove the bass tube

from the car.

Brightness

A menu is used to adjust the brightness of

the display and night design to the cockpit

illumination. Separate settings can be select-

ed for “headlights on” and “headlights off”.

Calibration microphone

Special microphone required for the automa-

tic self-adjustment of the equalizer (DSA Max,

DEQmaxEX). This microphone is already

included with the Bremen MP74 and the Los

Angeles MP74; it is available as an accessory

for other car radios.

CD-Text

Many CDs now already include additional

information on the artist, the name of the

album and the names of the individual tracks.

The CD-Text function can be used to show

this information on the car radio display.

Centre-Out

Centre channel generated from the two front

channels. It requires an additional external

amplifier and a speaker in the centre of the

dashboard.

CFG

CFG stands for Carbon FibreGlass Cone – the

optimal cone material for woofers. CFG com-

bines extreme stability and minimum weight

with particularly pleasing resonance characte-

ristics. CFG cones deliver practically perfect

frequency response even without a crossover.

Clock

Time display. The exact time is synchronized

via the RDS-CT signal.

Coaxial speaker

2-way speaker in which the tweeter is posi-

tioned in the centre of the woofer on one axis.

CODEM®

A reception concept developed by Blaupunkt

that makes virtually interference-free

reception possible even for weaker reception

signals without lowering the treble.

Combination antenna

Combination of different types of antennas

in one enclosure/rod. There are duplex

(e.g. radio/GSM) and triplex antennas (e.g.

radio/GSM/GPS). This means that only one

antenna is required on your car to ensure

optimal reception for different applications.

Component system

2- or 3-way system, in which the chassis

(tweeter, woofer, perhaps subwoofer) can be

installed separately to optimise the sound/

installation situation.

Crossover

➞High pass, low pass

Cursor up/down

Pressing one of these keys on the Blaupunkt

monitors triggers two different functions:

when the on-screen display (OSD) is switched

off, the volume will increase (up) or decrease.

If the OSD is active, the two keys can be used

to navigate within the menu.

Customisable Power-On Message

Any text (max. of 35 characters) that briefly

appears in the display when the unit is

switched on.

High-end reception concept with TwinCeiver

and DDA

Wanted

signal

Reflected

signal with

interference

Crackling

Usual situation when reception

is poor

Transmitting antenna

Reception with TwinCeiver and

DDA – interference-free reception

Interference

signal is eliminated

electronically by the

DDA directional antenna

Wanted

signal

Transmitting antenna

Comparatively circular reception range of a normal car

antenna: both the transmitter signal and the reflected

signal are received.

Conventional reception

Direct signal Reflection

Vehicle-specific frequency response without DSA+correction

Amplitude

in dB

–10

–20

–30

102103104

Frequency

in Hz

Annoying frequency

response peaks

Lack of

deep bass sound

Lack of

brilliant trebles

125 350

1400

Correction using DSA+(13 EQ bands)

Amplitude

in dB

–10

–20

–30

102103104

Frequency

in Hz

Filter 1 Filter 2 Filter 3

Filter 4

Filter 5

Vehicle-specific frequency response with DSA+correction

Amplitude

in dB

–10

–20

–30

102103104

Frequency

in Hz

Technology

DigiCeiver

Technology, whereby the car radio is based

on signal/computer processors. The signal

is digitally processed from the receiver to

the Preamp Out. This affords considerable

advantages in terms of reception properties

and sound adaptation.

➞SHARX®

Digital radio/DAB –

Digital Audio Broadcasting

Digital radio standard that, in contrast to

analogue radio signals, makes it possible

to transmit a great deal of data. In addition to

audio signals and texts, it is also possible

to transmit programme information in the

form of images and HTML pages. Even moving

images are possible. With digital radio, many

familiar programmes are now available in

CD quality, along with an entire spectrum of

completely new stations.

Interference

Should there ever be any problem in the

transmission of a digital signal, it is usually

only a small part of the information that gets

lost. And the listener won’t even notice: the

digital correction process simply recreates

the original signals. This guarantees inter-

ference-free listening enjoyment every time.

Reception convenience

Digital radio programmes are transmitted

over just one frequency. This means that,

once you have tuned into a programme, you

will be able to listen to it anywhere within

reception range without having to adjust your

set.

Versatility

Even though digital radio is bound to replace

FM as the radio standard sooner or later,

the Blaupunkt digital radios all still include an

FM receiver as well.

Additional reception

In the future, digital radio will also be able

to receive such additional multimedia infor-

mation as telematics services, information on

song titles, weather reports and MP3 files.

Sound quality

Digital radio provides the same excellent

sound quality as a music CD, even at top

speed on the motorway.

Future standard

It is already possible to pick up digital radio

almost everywhere in Germany. Full coverage

is expected to be achieved by 2004. And since

digital radio is a European standard, it will

be available in all European countries in the

future as well.

Programme diversity

Digital radio doesn’t mean you have to make

do with fewer programmes. In Germany,

there are already more than 150 digital radio

programmes on air – and that number is

growing.

Disc-Naming

This function makes it possible to enter a

name for any CD currently playing. This name

will then appear in the display each time

the CD is played as long as the corresponding

display function has been activated.

Display-Out

Connection option for existing external

displays in the car via an optional interface.

DMB – Digital Multimedia

Broadcasting

➞Digital-Radio

Equalizers that do the thinking for you! The

intelligent Blaupunkt equalizers are equipped

with a self-adjusting function to automatically

optimise sound reproduction. The new DSA+

equalizer is a complete high-performance

24-bit DSP system. The computer has enough

power to handle the 4-channel self-adjust-

ment of 27 graphic equalizer bands (= 108

bands in total). This creates a sound quality

that remains unparalleled to date and can

also be adjusted to your personal taste.

Signal time alignment for the audio signal

guarantees a true-to-life, concert-like pano-

rama. Dynamic Noise Covering (DNC) auto-

matically adjusts the volume, the equalizer

and music dynamics to the current noise

background in the vehicle. And this feature

not only regulates the level, it also adjusts

the sound to the frequency spectrum of the

driving noise.

A spectrum analyser, fascinating effect sound

options for Club, Stadium, Cathedral, Theatre

and Concert as well as sound presets round

out the virtually unlimited opportunities to

individualize your sound!

Parametric bands in DEQ Max/DEQ Max EX:

For particularly easy operation and the out-

standing adjustment of the complicated

acoustic conditions in modern vehicles, the

DEQ Max EX equalizer uses five fully para-

metric bands (adjustable mid frequency,

quality and level) with an automatic self-

adjusting function (in systems with the DEQ

Max, the parametric 5-band equalizer requires

manual adjustment). In addition, you can

also choose individually from five pre-defined

sound curves for different music styles.

Automatic equalizer adjustment with the

DSA Max and DEQ Max EX:

To keep things simple and ensure that the

best possible sound is what you get in the

end, Blaupunkt has developed an automatic

self-adjusting function that measures the pro-

blematic frequency response individually in

every vehicle. All you have to do is to connect

the calibration microphone (comes included

with the Bremen MP74 and the Los Angeles

MP74) with the ISO connection box and

press the AUTO key in the equalizer menu.

After just a few seconds, the sound will be

noticeably more harmonious, richer in detail

with greater differentiation, as the annoying

frequency peaks are reliably balanced out.

To satisfy personal tastes, all the settings can

also be adjusted manually afterwards. Alter-

natively, the sound-related or voice-optimised

sound preset curves can also be selected.

In principle, the DDA process mimics the

reactions of an extremely quick, automatic

directional antenna – similar to TV “rabbit

ears” that deliver just “snow” or perfect

reception depending on just a small adjust-

ment. When used in car radios, the DDA pro-

cess works with two independent antennas

and receivers, whose signals are digitised

using intermediate frequency analogue-digital

converters. The digitised data is then fed

to an adaptive algorithm with extremely low

settling times. Thus, the two intermediate

frequency signals are combined so that the

antenna can gain up to 3 dB of antenna

power even for weak reception field strengths.

In areas with strong reception, the second

regular receiver, the so-called RDS back-

ground receiver, is then freely available. The

switch between DDA operation and RDS

background reception is quick and inaudible,

controlled by a logic that evaluates the cur-

rent reception conditions. This guarantees

the radio listeners the best possible recepti-

on and rapid frequency switching at all times,

without annoying station searches.

DEQ/DEQ+/DSA+

Digital Sound Adjustment

Direct signal Reflection

Reception with DDA

Reception range of the automatic DDA directional

antenna: the wanted transmitter signal is received,

the reflected interference signal is faded out.

Linear spektrum

EXP

design

Other linear bandwidth for enhanced

performance

76 Technology

Fader

Regulates the volume between the front and

rear stereo channels.

Fibreglass Cone

The cones used in woofers and mid-range

speakers must combine stiffness and minimal

weight for the best linear behaviour. The

Blaupunkt fibreglass cone offers particularly

pleasing resonance characteristics for a very

even frequency response.

FM Modulator

Functions in the same way as a small radio

transmitter. It converts the incoming signals

of such equipment as CD changers into radio

waves in a selected frequency, which are fed

into the car radio tuner through an adapter

connected between the antenna input and

the antenna plug. This makes it possible to

connect a CD changer to any type of car

radio.

FNM (Front Neodymium Magnet)

Technology

Neodymium magnets are known for their

compact, lightweight design. Thanks to neo-

dymium magnets, it is now possible to build

far lighter, flatter speakers with the same per-

formance capabilities. The ultra-flat design

is achieved through the use of FNM technolo-

gy. With the neodymium magnet, which is

installed in the front deep in the voice coil,

the installation depth of the speaker is redu-

ced by more than 30% and the mounting

height for coaxial system set to close to 0 mm.

FNM technology is used in all coaxial (ODx)

and component systems (ODc) in the OD

series.

GALA

➞AutomaticSound

GPS – Global Positioning System

25 satellites orbit the Earth. On the basis of

the location data they transmit constantly,

it is possible to use a trigonometric formula

to determine the location of a vehicle, for

example, anywhere on the Earth’s surface.

Gyroscope

Magnetically independent, electronic gyros-

copic compass for the exact measurement of

angles. Standard in airplane, ship and car

navigation systems.

Hands-free operation

You can use the microphone and speakers

in the car to place telephone calls without

taking your hands off the wheel.

HDD – Hard Disk Drive

Head Unit

A term commonly used in the car hi-fi industry

for a car radio in complex systems.

High pass

Active frequency crossover to control sub-

woofer/satellite speaker systems, whereby

the music signal is faded out below a

selected frequency.

High-power output stage

Car radio output stage with 22–26 watts

RMS (acc. to DIN 45 324) or 45–50 watts per

channel of max. power, created by special

high-power transistors.

ID 3 Tags

Information on artist, album, song, genre, etc.

that can be stored with every MP3 file.

This information can be shown in the car

radio display (comparable to CD-Text).

Installation kit

Mechanical adaptation of DIN car radios or

speakers to different-sized, vehicle-specific

installation locations. Blaupunkt offers a

comprehensive programme with the perfect

solution for each fitting problem.

Integrated Magnet System

To provide for greater stability, the speaker’s

driver magnet is not screwed onto the back of

the basket as usual, but rather integrated into

the basket. This affords advantages not only

for high-power-handling subwoofers, it also

increases overall reliability.

IPP (Injected Polypropylene) cone

The IPP cone developed by Blaupunkt is

a mechanically very stiff cone. With the

addition of a synthetic material to the conven-

tional PP cone, the injected IPP cone become

noticeably stiffer and produces a louder,

more linear and precise sound in the entire

frequency response range. The IPP cone

is used in all coaxial, triaxial and component

systems in the GT series and Th series.

IR remote control

A handheld or steering-wheel mounted remote

control unit whose signal is transmitted in

the invisible infrared range. Products that are

mounted on the steering wheel have been

certified by the German Technical Inspection

Agency (TÜV).

DMS – Disc Management System

The Disc Management System makes it

possible to connect a Blaupunkt CD changer

and operate it using the car radio keypad.

DNC – Dynamic Noise Covering

➞DSA Max

DSA Max – Digital Sound

Adjustment

➞DEQ Max / DEQmaxEx / DSA Max

Dual voice coil

In a dual voice coil, the two lengths of wire

wound around the same former can be driven

separately. This provides you with greater

flexibility in the configuration of your system.

In a parallel hook-up (= half the impedance),

the amplifier connected is able to deliver

double the performance at best. For sub-

woofers that require a lot of power, each

voice coil can be wired to a separate ampli-

fier channel.

DualZone Audio

Devices equipped with dual zone audio

have preamp outs on the back that lets you

connect a second signal source (e.g. tuner

from the front, CD playback from the back).

A separate adapter is required for the connec-

tion of headphones and remote control for

the second source.

DVD

Abbreviation of Digital Versatile Disc.

Universal storage medium offered in a diverse

range of formats (e.g. DVD-video, DVD-audio,

DVD+R/RW, DVD-R/RW)

EON

Enhanced Other Networks.

➞RDS

Equalizer

Sound control, which adapts the frequency

response on several frequency bands to

accommodate less-than-perfect acoustic

conditions and personal preferences.

➞DEQ Max / DEQ Max EX / DSA Max

EXP technology

EXP stands for “Extended Pole Piece”, i.e. the

pole piece of the speaker magnets is extend-

ed to allow greater linear excursion for the

cone/voice coil while simultaneously reducing

distortion.

DNC Module

Audio signal,

e.g. from a CD

Driving noise,

wind, reflections,

etc.

Microphone

to analyse the

noise in the

vehicle interior

Audio signal with

driving noise

Extracted

driving noise signal

Correction

of the driving

noise using

the 9-band-

EQ and

2-band

dynamic

compression

Adaptive

filter

Driving noise

extraction

Technology

ISO connection technology

Mechanical connection standard commonly

used in the car hi-fi industry in which all of

the electrical connections are combined into

several blocks. The contact allocation can

vary electrically depending on the radio or car

manufacturer so that specific adapter cables

are required even though the plugs look

identical.

KeyCard

A particularly convenient theft protection

system developed by Blaupunkt. The car radio

cannot be operated until the corresponding

card has been inserted.

Loudness

➞X-Bass

Low pass

Active frequency crossover to control sub-

woofer systems, whereby the music signal is

faded out above a selected frequency.

Sub-X-Over, Sub-Out

Map Matching

Vehicle position determined by comparing

GPS locating and all sensor data with the

digital navigation CD.

The “menu” can be used to adjust the basic

settings of the car radio to vehicle-specific

conditions, individual preferences and

perhaps to an existing car hi-fi system.

MMC – MultimediaCard/

SD – Secure Digital Card

Storage cards for multimedia data, such as

MP3 music files.

MosFet transistors

Metal oxide semiconductor field effect tran-

sistors. Particularly effective in power con-

sumption (less heat generation) and switch

quickly, but not necessarily better than nor-

mal bipolar transistors as far as the sound is

concerned. Ideal for use in the switch-mode

power supplies of high-power amplifiers to

guarantee a constantly stable and high power

supply.

MP3

Compression standard for music data based

on the MPEG1 standard.

MP3 browsing

Convenient option that lets you scroll through

a list of all the MP3 titles on a CD-R/CD-RW

or MMC/SD card without having to interrupt

the song currently playing.

MP3 music on a CD-R/RW

A CD-ROM can accommodate up to approxi-

mately 10 conventional CDs, providing that

you burn the music in MP3 format.

MP3 music on a Microdrive

The MP3 Compact Drive from Blaupunkt is

a virtual CD changer. Simply compile a selec-

tion of your own favourite CDs by loading

music from your PC onto the Microdrive.

MP3 music on a MultimediaCard/SD card

Up to eight hours of MP3 music can be stored

on the MultimediaCard/SD card. It’s not

much bigger than a postage stamp, easy to

transport and versatile to use.

MP3 music on a PC

You need the right software to play MP3

music on your PC. At www.blaupunkt.com

you can simply download a WinAmp MP3

player – in the Blaupunkt look.

MP3 park

At www.blaupunkt.com you will find out

everything worth knowing about the topic of

MP3. In addition to basic technical principles

and legal background information, there are

also a lot of useful tips, tricks and links.

MultiColour display

Display in different colours for the different

display segments to differentiate visually

between the various functions displayed and

to improve the appeal of the equipment

design. The headline is usually highlighted to

make it easier to read.

Multipath interference

The radio waves emitted directly by the radio

station are overlaid with reflected signals

(e.g. from apartment buildings, mountains,

etc.) that are received with a slight time

delay. The Blaupunkt reception concepts

effectively minimise or even eliminate multi-

path interference.

➞DDA

Music/Speech

➞RDS

Navigation (dynamic)

Blaupunkt was the first manufacturer to

combine TMC and TIM® to create complete

traffic management. The Traffic Message

Channel – TMC is a free service provided by

radio stations; its traffic information is used

permanently in route calculation. TIM® is

a Blaupunkt process for recording traffic

messages. This combination of technologies

allows proactive, dynamic traffic congestion

avoidance on all motorways.

Navigation TravelPilot

Active route guidance system for motorists

using spoken recommendations and direc-

tional arrows on a monitor/display. Route

guidance is based on a navigation CD and

computer, locating via satellite receiver

(GPS), speedometer sensors, a gyroscope

and data comparison with the digital map.

1. The GPS system makes the initial rough

estimate of the vehicle location.

2. After just a few metres, the road the vehicle

is travelling on can be identified. Any turns

are recorded by the gyroscope.

3. Now the vehicle position has been determined

accurately and is updated constantly, whereby

the system compares all the sensor data with

the information on the digital map.

Operating Assistant

Of course, a navigation system is packed full

of highly complicated technology, but thanks

to the operating assistant, every Blaupunkt

stand-alone navigation system is still easy to

use. Developed during the course of many

practical tests, the operating assistant makes

it easier for you to enter address information.

The QuickInfo explains the different options

in easy-to-understand language. And entering

your destination is also incredibly easy – the

intelligent speller offers you only the letters

that could form a logical combination. And if

you should happen to make a typing error,

simply press the backspace key to delete the

last letter and correct your entry.

Navigation, Off-board

A new kind of navigation system; the route is

no longer calculated by the navigation unit

in the vehicle, but rather by a stationary com-

puter operated by a service provider. You no

longer need a navigation CD. The destination

address is entered into the in-vehicle unit

as usual. After that, this address and your

current vehicle position are transmitted to

the service provider via GSM or GPRS. This is

where the route is then calculated, taking all

current traffic information into account. The

data that describes the route to be driven are

then transmitted back to the vehicle. The

off-board navigation unit guides the driver

to the selected destination just like a conven-

tional radio navigation system would. In other

words, every turn along the way is indicated

by a spoken recommendation and an arrow

symbol.

Spoken street names

The special thing about Blaupunkt off-board

navigation is that you also hear the name of

the street or road you are supposed to turn

onto. And that is something that conventional

navigation systems just can’t do. In conven-

tional systems, the spoken recommendations

are recorded by a speaker in advance and all

the spoken recordings for the many thousands

of streets simply exceed the storage capacity

of any navigation CD or DVD. In Blaupunkt

off-board navigation, the street names are

transmitted as text and read out aloud by a

natural-sounding computer voice. Listen to

CD music even while you are using route

guidance. Because Blaupunkt off-board navi-

gation does not require a navigation CD,

the CD drive is always available to play back

a music CD.

Navigation functions, radio-based

78 Technology

Navigation functions, screen format

Dynamic navigation systems from Blaupunkt

automatically take traffic congestion into

consideration in route calculation.

So you would like to avoid motorways, ferries

or toll routes? No problem – simply select the

corresponding route option.

Mix mode allows you to display the directional

arrows and the map at the same time. You can

also simply choose between the two modes.

The on-board computer gives you such

information as your driving time, the route or

your average speed.

TMC and TIM® provide the TravelPilot DX-R70

with proactive, dynamic navigation. TMC

makes it possible to detect traffic congestion

on the route up ahead and uses this infor-

mation in route calculation. TIM® stores all

traffic messages, even when the unit is not

switched on.

Spoken and visual driving recommendations

show you the way. The distance bar in the

display tells you how far it is to your next

driving manoeuvre.

Entering your destination is easier and more

convenient than ever before. The intelligent

speller offers you only those combinations

of letters that are logically possible.

The TravelPilot DX-R70’s travel-guide

function allows you to enter such destinati-

ons as hotels, restaurants, tourist attracti-

ons, etc. directly and to read information

on these destinations in the display.

Like its big brother, the TravelPilot DX-R70,

the TravelPilot DX-R52 also offers highly

precise, proactive, dynamic route guidance.

Easy-to-understand arrow symbols and

a friendly voice let you know which exit to

take in the roundabout plenty of time in

advance.

The Operating Assistant makes your work

easier by using colour coding to mark the input

options.

Practical information such as petrol stations,

hotels and restaurants are indicated by symbols

on the map.

Technology

PDA – Personal Digital Assistant

Small, pocket-sized computer, usually equip-

ped with a touch screen and the Windows CE

or Palm OS operating system.

PP (Polypropylene) cone

The PP cone developed by Blaupunkt is a

solid, reliable cone. Acoustically, it creates a

perfect frequency response and an extremely

pleasant sound in the upper mid-range.

The PP cone is used in all the speakers in the

In Car series as well as the ODsb 5000.

Preamp-Out

Preamp output to control external amplifiers,

available in either 2-channel or 4-channel

versions. A maximum of 3 volts output is

standard. To improve sound quality and the

control of external amplifiers, the top-of-the-

line car radios have a maximum output of

up to 5 volts.

Preset equalizer

Equalizer settings that provide ideal frequency

curves at the touch of a button for different

types of music (rock, pop, jazz, techno,

speech and classical).

PTY – Program Type

➞RDS

PWF (Platinum Woven Fiber) cone

The PWF cone is made of a very durable,

woven fibreglass material. Thanks to the cone

fibre, which was specially developed by

Blaupunkt, the PWF cone delivers an optimal

frequency response with first-class resolution

(particularly in the upper mid-range), con-

trolled bass and excellent inner attenuation.

The PWF cone is used for all coaxial (ODx)

and component systems (ODc) in the OD

series.

Radio-based navigation

➞Navigation functions, radio-based

RDS – Radio Data System

RDS is a service provided by radio stations.

In addition to the usual music and speech

programs, other information is transmitted in

the form of coded digital signals that can be

evaluated by the car radio. The following RDS

services are currently available:

AF – Alternative frequency:

The car radio automatically selects the

frequency with the best reception for the

program you are currently listening to.

EON:

When a traffic announcement (TA) is broad-

cast, the radio will automatically switch from

a station that does not transmit traffic infor-

mation to one that does in the same broad-

casting network.

M/S – Music/Speech:

In future, a number of radio stations will

differentiate between music and speech pro-

grams. A separate tone setting (lowering bass

and treble) can be selected (via DSC) for

speech programs.

PI Code:

The car radio uses the PI code to identify the

radio station.

PS – Program Service:

Allows the display of the station name.

The TravelPilot DX-R52’s precise locating

makes sure you arrive safe and sound –

like all Blaupunkt navigation systems, it is

accurate right down to within three

metres.

Entering your destination is incredibly

quick and easy. The intelligent speller

offers you only those letter combinations

that make sense for your input.

And of course there are also a number of

different route options available. You can

select your options so that the system will

calculate your route either with or without

ferry connections, for example.

The TravelPilot navigation system is integrated

into the car radio and controlled using the car

radio keypad. The voice providing the spoken

driving recommendations is emitted via the

hi-fi speakers; symbols appear in the radio

display. The navigation CD is inserted into the

integrated CD/CD-ROM drive.

Neodymium tweeter

Tweeter equipped with neodymium magnets.

Neodymium has much greater magnetic field

strength than conventional materials and

drives speakers very powerfully despite the

relatively small magnets. This makes it

possible to design very small tweeters, which

nonetheless produce outstanding sound.

NTSC (National Television

System Committee)

US-American colour television system. The

colour picture is optically divided into the

three primary colours of red, green and blue

in the TV camera and fed into three TV picture

tubes.

➞PAL

OSD On-screen display

The settings menu shown on the screen. To

adjust Blaupunkt products, it is possible to

use either the remote control and/or the but-

tons directly on the unit to select the desired

menu item and to alter the corresponding

value or perform the corresponding function.

PTY – Program Type:

A function that is supported by an increasing

number of radio stations, whereby the car

radio can search for stations broadcasting

specific program contents (e.g. news, rock,

pop, sport, etc.).

RT – Radiotext:

Additional information supplied by the radio

station on the programme (e.g. title of the

programme, name of the artist, etc.).

Reinforced Seam Surround

Subwoofer with a max. power >1000 watts

are subjected to enormous mechanical pres-

sure. The joint between the surround and the

cone in particular can tear under the strain

of continuously high cone excursion. An extra

seam sewn to join these two components

reliably prevents damage to the speaker.

RP – Release Panel

Effective system of theft protection for car

radios whereby you take part of or the entire

front panel of the radio with you when you

leave the vehicle. The radio will not function

without the RP.

Scan

Scans all radio stations within reception

range (Radio Scan), preset station buttons

(Preset Scan) or music titles (CD Scan, CC

Scan).

Sender list (dynamic)

Listing and automatic updating of all the

radio stations within reception range. The

advantage: you no longer need station keys

and have access to all the available stations.

Sensitivity

Measurement for the volume of a speaker

at 1 watt of input, measured at 1 metre’s

distance. Sensitivity is measured in dB.

SHARX®

Digital adaptive filter designed to optimise

channel separation in the receiver. Even stati-

on signals that are extremely close to one

another are separated cleanly. SHARX® is part

of the DigiCeiver and TwinCeiver concepts.

TA – Traffic Announcement

➞RDS

Telematics

Functions that a service provider makes

available via telecommunications, e.g. infor-

mation services with position transmission,

emergency call, breakdown call and off-board

navigation.

Telephone line-in

Separate aux-in to which a mobile telephone

can be connected for hands-free operation.

The caller’s voice is heard on the car hi-fi

speakers.

Telephone mute

The car radio automatically switches to mute

as soon as an incoming telephone call is

detected. Prerequisite: the corresponding pin

in the connection box must be connected

with the car phone or the hands-free system

of the mobile phone.

Thermal Throttle

Circuit that reliably prevents amplifier shut-

down due to overload. It subtly varies the

voltage at the power supply to reduce heat

production without discernibly changing the

audio output volume, thus guaranteeing

reliable performance even when operated

continuously at maximum power levels.

TIM®

A system developed by Blaupunkt with a digi-

tal voice memory that can record up to 4 traf-

fic messages with a total length of 4 minutes.

The TIM® memory updates itself continually.

A function that even works when the car

radio is switched off in a freely selectable

time frame.

80 Technology

Sub-Out

Separate preamp output with preceding low

pass.

Subsonic filter

The subsonic filter can be used with an ampli-

fier when a subwoofer is connected. It can be

set to protect the subwoofer from mechanical

overload due to low frequencies that cannot

be heard by the human ear. Thus, the subsonic

filter is able to increase the power handling

and the subjective maximum sound pressure

of the subwoofer.

The subsonic filter is used in all output stages

of the TS series and Velocity. A corresponding

adjustable filter can be switched on in the

Bremen MP74.

Subwoofer

Additional low bass speaker, which is driven

by an integrated or separate amplifier with a

low pass.

Subwoofer phase

Lets you switch the phase of the subwoofer

output to adjust it perfectly to the other

speakers.

Sub X-Over

Subwoofer crossover.

➞Low pass

➞High pass

Signal time alignment

Electronically corrects the asymmetrical

seating position in the vehicle by delaying the

music channels so that the sound waves emitt-

ed by all the speakers reach the listener at the

same time. The signal time for the Bremen

MP74 can be adjusted right down to the last

centimetre. It is possible to select different

seating positions.

Silk dome tweeter

Silk dome tweeters use impregnated silk as

the cone material. Silk works with virtually no

annoying resonance of its own and delivers

a perfectly balanced frequency response. The

impregnation process gives the cone material

the stability it requires to handle high power

levels.

S/N – Signal/noise ratio

Maximum possible ratio of the music signal

to the basic noise, measured in decibels. The

higher the value, the better the quality of the

equipment.

Softkeys

Keys at the side of the car radio display that

are allocated different functions on the display

depending on the sound source or the operat-

ing menu, e.g. tuner station keys, CD Mix, Mag

Mix, Scan, AUD Bass, Treble, Balance, Fader,

Equaliser etc.

Sound presets

➞Preset equalizer

Source tone memory

The settings for bass/treble can be adjusted

separately for each sound source to compen-

sate for differences in sound quality.

SPC (Spun Paper Cone)

The SPC, a development by Blaupunkt, is a very

stable, reliable paper cone. Thanks to a unique

polishing process and the mixture of 9 mineral

materials, the mechanical SPC exhibits a high

degree of stiffness. In terms of sound, it pro-

duces an extremely homogenous frequency

response without any noticeable cone resonan-

ce. The SPC is used for the ODce 20, ODce

20A, ODsb 8000A, GTb 300, GTx300 and GTb

300 Dual.

Speedometer signal

Impulses from the electronic speedometer

that are used to measure distances travelled

and for GALA.

Current traffic information

on the way to destination 1

Current traffic information

on the way to destination 2

7:30 am 9:30 am 4:00 pm 6:00 pm

2 h 2 h 2 h

Timer 1: 8.00 am

Programmed recording

Automatic recording every time the unit is switched off

Timer 2: 4.30 am

Recording period for traffic messages with TIM®

Start Destina-

tion 1

Destina-

tion 2

Start

Destina-

tion 1 Destina-

tion 2 Destina-

tion 3

Asymmetrical sound

impression at the

driver’s position

without signal time

alignment

Differentiated live-

concert sound impres-

sion at the driver’s

position with signal

time alignment

Video input: Composite

Video 1. OV p-p, 75 ohms

Describes the standard and the electrical

value of the signal to be connected.

Composite Video corresponds to the normal

TV signal, like the one emitted by DVD play-

ers, game stations or TV tuners.

Watts

➞Output power

X-Bass

Psycho-acoustic boost of the low frequencies

at low volume. For almost all the car radios –

an exclusive feature for Blaupunkt car radios

– there is a menu which can be used to adjust

the effect of X-Bass feature to the existing

car-audio system in 6 stages.

Y adapter

Distribution of a 2-channel stereo signal to

several different amplifiers using a Y-shaped

adapter to link the cables. Using Y adapters

can have an adverse effect on the fader

function.

TwinCeiver – digital twin tuner

Advanced development of the DigiCeiver with

two receivers in one car radio.

The TwinCeiver, which boasts two DSP-based

receivers, underscores Blaupunkt’s outstand-

ing position in perfect radio reception: crackl-

ing and noise due to multi-path reception

caused by apartment blocks in cities or

mountains in the countryside now virtually

belong to the past.

More distant stations, which were once well

outside of the usual reception range, are now

within reach as well: the TwinCeiver continu-

ously evaluates the digitised signals from

two antennas and combines them to create a

strong, clear signal that is free of interfe-

rence. This process, which was developed by

Blaupunkt engineers, is called DDA (Digital

Directional Antenna) and it mimics the reac-

tions of an extremely quick, automatic direc-

tional antenna – similar to TV “rabbit ears”

that deliver just “snow” or perfect reception

depending on just a small adjustment.

If the reception is currently so good that the

second antenna is not required, or if only

one antenna is connected, the radio can be

switched to “dynamic station lists”. This

means that the display will only show those

stations that are actually within reception

range – which saves you a lot of searching.

Tint (for NTSC only)

Regulates the colour and affects only the

NTSC mode, which is used in the USA. In

Europe, PAL is the corresponding signal, in

parts of France and Switzerland the SECAM

signal is the standard used.

Titanium tweeter

The titanium tweeters developed by

Blaupunkt are manufactured from an

extremely stiff titanium. The rigidity of the

titanium dome guarantees a seamless, lively

reproduction of the trebles and superb sound

definition. The titanium tweeter is used in all

the coaxial systems (ODx) of the OD series.

TMC-Out FM

Car radios with this output are able to for-

ward TMC data to any Blaupunkt navigation

system connected (e.g. TravelPilot DX-V) for

dynamic route guidance (separate connection

cable required). Prerequisite: the radio must

be set to an RDS station that transmits TMC

data.

TMC – Traffic Message Channel

A digital traffic information data channel with

constantly updated data on traffic conditions.

TMC receivers allow the user to select data

by entering such information as travelling

direction, area and road class. The latest

information, selected to suit the user’s indivi-

dual needs, is then available at the touch of a

button.

Total harmonic distortion (THD)

Measurement for distortion that indicates

the ratio of the sum of the powers of all the

harmonic frequencies above the fundamental

frequency to the power of the fundamental

frequency. Rule of thumb: lower values for

the same performance are usually a sign of

better sound quality.

TP – Traffic Program

➞RDS

Traffic telematics

➞Telematics

Travelstore

Search function that stores the six radio

stations with the strongest reception signals

sorted according to signal strength in a speci-

al memory bank at the touch of a button.

Triaxial speakers

Three-way speakers whereby the mid-range

tweeter is positioned in the centre of the

bass speaker on one axis and the tweeter is

on another axis on the side.

Triplex antenna

➞Combination antenna

Technology

Antenna

Tuner 1

Imperfect

antenna signal

Signal

processing

Reception concept without the TwinCeiver

Tuner 1

AntennaAntenna

Imperfect

antenna signal

Optimal

antenna signal

Tuner 2

DDA Signal

processing

Imperfect

antenna signal

Reception concept with the TwinCeiver

82 Car Radios

Page

Radio

FM/MW/LW/SW (band)

Codem concept

2-tuner RDS

DDA (DigitalDirectionalAntenna)

RDS

Radiotext

TIM® (Traffic Memo)

Traffic Announcement (TA)

Digital selectivity enhancement (SHARX®)

Station presets

Updated station list

FM frequency response (Hz) –3 dB

AM interference suppression

Connection option for 2nd FM antenna

Digital Radio

Reception range

DAB modes

Frequency response (Hz) –1 dB

Dynamic label (Radiotext)

Ensemble/Service seek tuning

Station presets

Reception of primary and secondary services

Program Type display (PTY)

Preselection options

Service Following (DAB/FM, Ensemble)

Cassette

Autoreverse

Frequency response (Hz)

Tape equalization

Signal/noise ratio

CD-R/RW-compatible

Frequency response (Hz) –1 dB

CD Mix/Disc Naming/CD List/CD-Text

DMS (CD changer control)

MMC/SD

Card reader for MMC/SD

Formatting

MP3 player

MP3 playback on CD-R, CD-RW and DVD

MP2 (Digital Radio) playback from

Digital recorder for Digital Radio

Display of directories/file names

Display of ID3 tags

Bit rate

Support of variable bit rates

Amplifier

DSA Max (DigitalSoundAdjustment)

DNC (Dynamic Noise Covering)

Digital parametric equalizer

Self-adjusting equalizer

Number of bands

Variable EQ quality

Sound/echo effects

Signal delay compensation (adjustable)

AutomaticSound (GALA)

High pass filter

Source tone memory

Sound presets

X-Bass

Preamp-out

Aux-in

Sub-out

Centre-out

Dual zone audio

RMS power (DIN 45324) at 14.4 V

Max. power

Miscellaneous

Display technology

Flip release panel

Softkey operating concept

Display colour

Keypad illumination

Display brightness

Angle

Display out (via opt. interface)

Theft protection

Clock

Connections: dimmer/telephone-mute

Calibration microphone included

IR remote control included

TMC out FM/DAB

Pre-equipped for telephone/navigation voice output

Window antenna included

Dimensions (W x H x D) mm

Product

+/+/+/+

–

TwinCeiver

RDS-EON-PTY

20 –16,000

–

-/-

–

15 –20,000

+/ / /+

–

CD-ROM/CD-RW

–

Up to 127/+

Up to 30 characters (V1)

8 – 320 Kbit

–

108

–

Separate front/rear

4-channel (5V), gold-plated

Adjustable

4 x 26

4 x 50

Full-graphic DOT

VarioColour (4,096 colours)

VarioColour (16 colours)

Removable release panel

(RDS)

+/+

–

+/-

179/52/160

Bremen MP74

+/+/+/-

DigiCeiver

–

RDS-EON-PTY

–

20 –16,000

–

-/-

–

15 –20,000

+/ / /+

–

CD-ROM/CD-RW

–

Up to 127/+

Up to 30 characters (V1)

8 – 320 Kbit

–

DEQmaxEx

–

4-channel (4V), gold-plated

–

4 x 26

4 x 50

Full-graphic DOT

White

Switch between red/orange/green

Removable release panel

(RDS)

+/+

–

+/-

–

179/52/160

Seattle MP74

+/+/+/-

DigiCeiver

–

RDS-EON-PTY

–

20 –16,000

–

-/-

–

15 –20,000

+/+/-/+

–

CD-ROM/CD-RW

–

Up to 127/+

Up to 30 characters (V1)

8 – 320 Kbit

–

DEQmaxEx

–

4-channel (4V)

–

4 x 26

4 x 50

DOT matrix graphic-enabled

–

VarioColour (4,096 colours)

VarioColour (16 colours)

–

Removable release panel

(RDS)

+/+

–

+/-

–

179/50/160

+/+/+/-

III+

–

RDS-EON-PTY

–

35 – 16,000

> 30 dB

–

-/-

–

20 Hz – 20 kHz

+/-/-/+

–

CD-R, CD-RW

–

Up to 64/+

Up to 30 characters

32 kbit/sec to 320 kbit/sec

–

4-channel, 2 V

–

4 x 18 W

4 x 45 W

13 segments, 1-line

–

White

Red

–

Removable release panel

RDS

-/+

–

179/50/150

Acapulco MP54 Calgary MP35

= in combination with CD changer

+/+/+/-

DigiCeiver

–

RDS-EON-PTY

–

20 –16,000

–

-/-

–

15 – 20,000

+/ / /+

–

CD-ROM/CD-RW

–

Up to 127/+

Up to 30 characters (V1)

8 – 320 Kbit

–

DEQmaxEx

–

4-channel (4V), gold-plated

–

4 x 26

4 x 50

Full-graphic DOT

VarioColour (4,096 colours)

VarioColour (16 colours)

Removable release panel

(RDS)

+/+

+/-

–

179/52/160

Los Angeles MP74

Car Radios

Page

Radio

FM/MW/LW/SW (band)

Codem concept

2-tuner RDS

DDA (DigitalDirectionalAntenna)

RDS

Radiotext

TIM® (Traffic Memo)

Traffic Announcement (TA)

Digital selectivity enhancement (SHARX®)

Station presets

Updated station list

FM frequency response (Hz) –3 dB

AM interference suppression

Connection option for 2nd FM antenna

Digital Radio

Reception range

DAB modes

Frequency response (Hz) –1 dB

Dynamic label (Radiotext)

Ensemble/Service seek tuning

Station presets

Reception of primary and secondary services

Program Type display (PTY)

Preselection options

Service Following (DAB/FM, Ensemble)

Cassette

Autoreverse

Frequency response (Hz)

Tape equalization

Signal/noise ratio

CD-R/RW-compatible

Frequency response (Hz) –1 dB

CD Mix/Disc Naming/CD List/CD-Text

DMS (CD changer control)

MMC/SD

Card reader for MMC/SD

Formatting

MP3 player

MP3 playback on CD-R, CD-RW and DVD

MP2 (Digital Radio) playback from

Digital recorder for Digital Radio

Display of directories/file names

Display of ID3 tags

Bit rate

Support of variable bit rates

Amplifier

DSA Max (DigitalSoundAdjustment)

DNC (Dynamic Noise Covering)

Digital parametric equalizer

Self-adjusting equalizer

Number of bands

Variable EQ quality

Sound/echo effects

Signal delay compensation (adjustable)

AutomaticSound (GALA)

High pass filter

Source tone memory

Sound presets

X-Bass

Preamp-out

Aux-in

Sub-out

Centre-out

Dual zone audio

RMS power (DIN 45324) at 14.4 V

Max. power

Miscellaneous

Display technology

Flip release panel

Softkey operating concept

Display colour

Keypad illumination

Display brightness

Angle

Display out (via opt. interface)

Theft protection

Clock

Connections: dimmer/telephone-mute

Calibration microphone included

IR remote control included

TMC out FM/DAB

Pre-equipped for telephone/navigation voice output

Window antenna included

Dimensions (W x H x D) mm

Product

+/+/+/-

III+

–

RDS-EON-PTY

–

35 – 16,000

> 30 dB

–

-/-

–

20 Hz – 20 kHz

+/-/-/+

–

CD-R, CD-RW

–

Up to 64/+

Up to 128 characters

32 kbit/sec to 320 kbit/sec

–

4-channel, 2 V

–

4 x 18 W

4 x 45 W

DOT, 1-line

–

White, blue

Red

–

Removable release panel

RDS

+/+

–

179/50/150

Barcelona MP35

+/+/+/-

III+

–

RDS-EON-PTY

–

35 – 16,000

> 30 dB

–

-/-

–

20 Hz – 20 kHz

+/-/-/+

–

CD-R, CD-RW

–

Up to 64/+

Up to 128 characters

32 kbit/sec to 320 kbit/sec

–

4-channel, 2 V

–

4 x 18 W

4 x 45 W

DOT, 1-line

–

White

Red

–

Removable release panel

RDS

+/+

–

179/50/150

Madrid MP35

+/+/+/-

III+

–

RDS-EON-PTY

–

35 – 16,000

> 30 dB

–

-/-

–

20 Hz – 20 kHz

+/-/-/+

–

CD-R, CD-RW

–

Up to 64/+

Up to 128 characters

32 kbit/sec to 320 kbit/sec

–

4-channel, 2 V

–

4 x 18 W

4 x 45 W

DOT, 1-line

–

VarioColour (4,096 colours)

Red

–

Removable release panel

RDS

+/+

–

179/50/150

London MP35

+/+/+/-

III+

–

RDS-EON-PTY

–

35 – 16,000

> 30 dB

–

-/-

–

20 Hz – 20 kHz

+/-/-/+

–

CD-R, CD-RW

–

Up to 64/+

Up to 128 characters

32 kbit/sec to 320 kbit/sec

–

4-channel, 2 V

–

4 x 18 W

4 x 45 W

DOT, 1-line

–

VarioColour (4,096 colours)

Red

–

Removable release panel

RDS

+/+

–

179/50/150

+/+/+/-

III+

–

RDS-EON-PTY

–

35 – 16,000

> 30 dB

–

-/-

–

20 Hz – 20 kHz

+/-/-/+

–

CD-R, CD-RW

–

Up to 64/+

Up to 128 characters

32 kbit/sec to 320 kbit/sec

–

4-channel, 2 V

–

4 x 18 W

4 x 45 W

13 segments, 1-line

–

Blue

Red

–

Removable release panel

RDS

-/+

–

179/50/150

Kingston MP35 San Diego MP35

84 Car Radios

= in combination with CD changer

Product

+/+/+/-

III+

–

RDS-EON-PTY

–

35 – 16,000

> 30 dB

–

-/-

–

20 Hz – 20 kHz

+/-/-/-

–

4-channel, 2 V

–

4 x 15 W

4 x 40 W

13 segments, 1-line

–

Positive white

Red

–

Removable release panel

RDS

-/+

–

179/50/150

Bristol CD35

+/-/-/-

III+

–

RDS-EON-PTY

–

35 –16,000

> 30 dB

–

-/-

–

20 Hz – 20 kHz

+/-/-/+

–

CD-R, CD-RW

–

Up to 64/+

Up to 128 characters

32 kbit/sec to 320 kbit/sec

–

4-channel, 2 V

–

4 x 18 W

4 x 45 W

13 segments, 1-line

–

Negative white

Red

–

RDS

-/+

–

179/50/150

Essen MP35

+/+/+/-

III+

–

RDS-EON-PTY

–

35 –16,000

> 30 dB

–

-/-

–

20 Hz – 20 kHz

+/-/-/+

–

CD-R, CD-RW

–

Up to 64/+

Up to 128 characters

32 kbit/sec to 320 kbit/sec

–

4-channel, 2 V

–

4 x 18 W

4 x 45 W

13 segments, 1-line

–

Blue

Red

–

RDS

-/+

–

179/50/150

Brighton MP35

+/-/-/-

III+

–

RDS-EON-PTY

–

35 –16,000

> 30 dB

–

-/-

–

20 Hz – 20 kHz

+/-/-/-

–

4-channel, 2 V

–

4 x 15 W

4 x 40 W

13 segments, 1-line

–

Orange

–

RDS

-/+

–

179/50/150

Kiel CD35

+/+/+/-

III+

–

RDS-EON-PTY

–

35 – 16,000

> 30 dB

–

-/-

–

20 Hz – 20 kHz

+/-/-/-

–

4-channel, 2 V

–

4 x 15 W

4 x 40 W

13 segments, 1-line

–

Negative white

Red

–

Removable release panel

RDS

-/+

–

179/50/150

Vancouver CD35

Page

Radio

FM/MW/LW/SW (band)

Codem concept

2-tuner RDS

DDA (DigitalDirectionalAntenna)

RDS

Radiotext

TIM® (Traffic Memo)

Traffic Announcement (TA)

Digital selectivity enhancement (SHARX®)

Station presets

Updated station list

FM frequency response (Hz) –3 dB

AM interference suppression

Connection option for 2nd FM antenna

Digital Radio

Reception range

DAB modes

Frequency response (Hz) –1 dB

Dynamic label (Radiotext)

Ensemble/Service seek tuning

Station presets

Reception of primary and secondary services

Program Type display (PTY)

Preselection options

Service Following (DAB/FM, Ensemble)

Cassette

Autoreverse

Frequency response (Hz)

Tape equalization

Signal/noise ratio

CD-R/RW-compatible

Frequency response (Hz) –1 dB

CD Mix/Disc Naming/CD List/CD-Text

DMS (CD changer control)

MMC/SD

Card reader for MMC/SD

Formatting

MP3 player

MP3 playback on CD-R, CD-RW and DVD

MP2 (Digital Radio) playback from

Digital recorder for Digital Radio

Display of directories/file names

Display of ID3 tags

Bit rate

Support of variable bit rates

Amplifier

DSA Max (DigitalSoundAdjustment)

DNC (Dynamic Noise Covering)

Digital parametric equalizer

Self-adjusting equalizer

Number of bands

Variable EQ quality

Sound/echo effects

Signal delay compensation (adjustable)

AutomaticSound (GALA)

High pass filter

Source tone memory

Sound presets

X-Bass

Preamp-out

Aux-in

Sub-out

Centre-out

Dual zone audio

RMS power (DIN 45324) at 14.4 V

Max. power

Miscellaneous

Display technology

Flip release panel

Softkey operating concept

Display colour

Keypad illumination

Display brightness

Angle

Display out (via opt. interface)

Theft protection

Clock

Connections: dimmer/telephone-mute

Calibration microphone included

IR remote control included

TMC out FM/DAB

Pre-equipped for telephone/navigation voice output

Window antenna included

Dimensions (W x H x D) mm

Car Radios

Product

+/+/+/-

DigiCeiver

–

RDS-EON-PTY

–

20 –16,000

–

Band III, L band

I, II, III, IV

20 – 20,000

+/+

Weather, news, traffic news

–

20 – 20,000

+/+/-/+

FAT 16

CD-ROM/CD-RWMMC/SD

Up to 127/+

Up to 30 characters (V1)

8 – 320 Kbit

–

DEQmaxEx

–

4-channel (4V)

–

4 x 26

4 x 50

DOT matrix graphic-enabled

–

VarioColour (4,096 colours)

VarioColour (16 colours)

–

KeyCard & Removable release panel

(RDS)

+/+

–

-/+

–

179/50/150

Woodstock DAB 54

+/+/+/-

III+

–

RDS-EON-PTY

–

35 –16,000

> 30 dB

–

-/-

–

20 Hz – 20 kHz

+/-/-/-

–

4-channel, 2 V

–

4 x 15 W

4 x 40 W

13 segments, 1-line

–

Green

–

RDS

-/+

–

179/50/150

Malaga CD35

+/+/+/-

III+

–

RDS-EON-PTY

–

35 –16,000

–

30 –18,000

0,20 %

–

/-/-/-

–

-/-

–

4-channel (3 V)

–

4 x 22

4 x 45

13 segments

–

Yellow + orange

Red

–

Release Panel

–

-/+

–

179/50/150

Ravenna C32

Page

Radio

FM/MW/LW/SW (band)

Codem concept

2-tuner RDS

DDA (DigitalDirectionalAntenna)

RDS

Radiotext

TIM® (Traffic Memo)

Traffic Announcement (TA)

Digital selectivity enhancement (SHARX®)

Station presets

Updated station list

FM frequency response (Hz) –3 dB

AM interference suppression

Connection option for 2nd FM antenna

Digital Radio

Reception range

DAB modes

Frequency response (Hz) –1 dB

Dynamic label (Radiotext)

Ensemble/Service seek tuning

Station presets

Reception of primary and secondary services

Program Type display (PTY)

Preselection options

Service Following (DAB/FM, Ensemble)

Cassette

Autoreverse

Frequency response (Hz)

Tape equalization

Signal/noise ratio

CD-R/RW-compatible

Frequency response (Hz) –1 dB

CD Mix/Disc Naming/CD List/CD-Text

DMS (CD changer control)

MMC/SD

Card reader for MMC/SD

Formatting

MP3 player

MP3 playback on CD-R, CD-RW and DVD

MP2 (Digital Radio) playback from

Digital recorder for Digital Radio

Display of directories/file names

Display of ID3 tags

Bit rate

Support of variable bit rates

Amplifier

DSA Max (DigitalSoundAdjustment)

DNC (Dynamic Noise Covering)

Digital parametric equalizer

Self-adjusting equalizer

Number of bands

Variable EQ quality

Sound/echo effects

Signal delay compensation (adjustable)

AutomaticSound (GALA)

High pass filter

Source tone memory

Sound presets

X-Bass

Preamp-out

Aux-in

Sub-out

Centre-out

Dual zone audio

RMS power (DIN 45324) at 14.4 V

Max. power

Miscellaneous

Display technology

Flip release panel

Softkey operating concept

Display colour

Keypad illumination

Display brightness

Angle

Display out (via opt. interface)

Theft protection

Clock

Connections: dimmer/telephone-mute

Calibration microphone included

IR remote control included

TMC out FM/DAB

Pre-equipped for telephone/navigation voice output

Window antenna included

Dimensions (W x H x D) mm

86 Navigation

Page

Navigation

Optimal route configuration

Traffic congestion avoidance with dynamic, proactive navigation

New destination input in corridor with no CD change

Clear route guidance with natural speech and symbols

Postal code input

Listen to CD during dynamic, proactive navigation

Traffic congestion ahead function

Display of special destinations

Navigation CD included

Last 20 City history

House number exact route guidance

Dynamic navigation also in corridor mode

Display of traffic messages on map (symbols)

On-board computer functions

On-board navigation

Gyroscope

Speedometer signal

Automatic length calibration via GPS

Voice output

Spoken traffic messages

Display of street travelled

Display of next street

Remaining km

Arrival time

TMC module

Additional information retrieved on display

Spoken message output in German abroad

Audio CD playback

Listen to favourite CDs with optimum route to destination

MP3

MP3 playback from CD-R/RW

Display of directories

Display of file names

Convenient MP3 browsing

without interruption

Display of ID3 tags (V1)

Bit rate

Mix

Scan

Amplifier

4 x 26 W RMS

4 x 50 W max. power

Digital parametric 5-band equalizer

Automatic volume adjustment

Source-specific tone control

Loudness (adjustable)

4-channel preamp out (4V)

Radio

FM, MW, LW

DigiCeiver for best reception

AM noise suppression

RDS EON PTY

Optimized digital channel separation (SHARX)

30 station presets

Miscellaneous

Flip-release panel

Clock display

Telephone mute

TCM out

Steering wheel remote control (extra)

High-end navigation system with infrared remote control

Large format: modern design in 16:9 format

Extensible: connections for different components (for dynamic route guidance, steering wheel remote control, video, etc.)

Memory: memory for last 12 destinations, storage in alphabetical order

Informative: on-board computer functions (display of arrival time and remaining km, current speed, km travelled,

total driving time, average speed), 46 forms of additional information such as petrol stations, tourist attractions and

covered parking can be added

Flexible: adjustable height, contrast and brightness

Theft protection: monitor is easy to remove

Traffic congestion avoidance: fully automatic route guidance via RDS/TMC (important: suitable TMC source required)

Optional speed signal hook-up

–

Product

DVD ME 4

Page

DVD video

Video CD

Audio CD

MP3

Disc/display size

Colour of the operating display (LED)

Infrared receiver

On/off switch/eject

Loading mechanism

Password function/angle function

Picture format

PAL/NTSC switch

On-screen display (OSD)

TV screen

TV type

Language selection

On-screen display on/off

DVD/AV switch

Operating voltage

Dimensions (W x H x D)

Weight/installation

Region code

single + double layer

VCD/SVCD

CD, CD-R, CD-RW

CDs with MP3 files

12/8 cm / VFD

blue

built-in

+/+

inload

+/ Multi

16:9/4:3 adjustable

auto

4:3/16:9 letterbox/wide

PAL/NTSC

10 – 23 V

178 mm x 50 mm x 187 mm

1700 g/horizontal + vertical

–

Product

TravelPilot

ETravelPilot DX-V

In Car Entertainment

Aspen IVDM-7003

–

single + double layer

DVD-R, -RW, +R, +RW

VCD/SVCD

CD/CD-R/CD-RW

CDs/DVDs with MP3 files

inload

Multi

16:9/4:3 adjustable

automatic/manual

4:3/4:3 letterbox/wide

PAL / NTSC

auto/high/flicker-free

on/off

2x, 4x, 6x, 8x

+/+/+

7’’

17,5 cm

1440 x 234

+/-60 degrees

+60/-30 degrees

PAL/NTSC

automatic

–

180 x 50 x 26,7 mm

175 x 50 x 235 mm

Aspen IVDN-7003

–

single + double layer

DVD-R, -RW, +R, +RW

VCD/SVCD

CD/CD-R/CD-RW

CDs/DVDs with MP3 files

inload

Multi

16:9/4:3 adjustable

automatic/manual

4:3/4:3 letterbox/wide

PAL / NTSC

auto/high/flicker-free

on/off

2x, 4x, 6x, 8x

+/+/+

7’’

17,5 cm

1440 x 234

+/-60 degrees

+60/-30 degrees

PAL/NTSC

automatic

–

180 x 50 x 26,7 mm

175 x 50 x 235 mm

Chicago IVDM-7003

–

SPDIF (5.1)

single + double layer

DVD-R, -RW, +R, +RW

VCD/SVCD

CD/CD-R/CD-RW

CDs/DVDs with MP3 files

inload

Multi

16:9/4:3 adjustable

automatic/manual

4:3/4:3 letterbox/wide

PAL / NTSC

auto/high/flicker-free

on/off

2x, 4x, 6x, 8x

+/+/+

7’’

17,5 cm

1440 x 234

+/-60 degrees

+60/-30 degrees

PAL/NTSC

automatic

–

180 x 50 x 26,7 mm

175 x 50 x 235 mm

Chicago IVDN-7003

–

SPDIF (5.1)

single + double layer

DVD-R, -RW, +R, +RW

VCD/SVCD

CD/CD-R/CD-RW

CDs/DVDs with MP3 files

inload

Multi

16:9/4:3 adjustable

automatic/manual

4:3/4:3 letterbox/wide

PAL / NTSC

auto/high/flicker-free

on/off

2x, 4x, 6x, 8x

+/+/+

7’’

17,5 cm

1440 x 234

+/-60 degrees

+60/-30 degrees

PAL/NTSC

automatic

–

180 x 50 x 26,7 mm

175 x 50 x 235 mm

Page

Navigation

Optimal route configuration

Traffic congestion avoidance with dynamic, proactive navigation

New destination input in corridor with no CD change

Clear route guidance with natural speech and symbols

Postal code input

Listen to CD during dynamic, proactive navigation

Traffic congestion ahead function

Display of special destinations

Navigation CD included

Last 20 City history

House number exact route guidance

Dynamic navigation also in corridor mode

Display of traffic messages on map (symbols)

On-board computer functions

On-board navigation

Gyroscope

Speedometer signal

Automatic length calibration via GPS

Voice output

Spoken traffic messages

Display of street travelled

Display of next street

Remaining km

Arrival time

TMC module

Additional information retrieved on display

Spoken message output in German abroad

Radio

FM,

RDS

Station naming

Audio CD playback

CD-ROM playback

CD-RW compatible

Disc up/down

Disc Scan

Track up/down

Track scan

Cue/review

Audio features

Digital output

DVD/Compatibility

DVD video

DVD media

Video CD

Audio CD

MP3

DVD features

Loading mechanism

Password function

Angle function

Picture format

PAL/NTSC switch

Dolby Digital support

DTS support

On-screen display (OSD)

Selection of menu, title, chapter

Language selection

Subtitles

Setup features

TV screen

TV type

Picture resolution

Angle adjustment

Remote control

Power on/off

Menu selection

Brightness

Language selection

Subtitle selection

Fast cue/review

Search cue/review

Play/stop/pause

Next/previous chapter/title

On-screen display on/off

Angle selection

Audio selection

DVD/AV switch

Monitor

Monitor size

Visible picture/diagonal

Resolution (horizontal x vertical)

Horizontal viewing angle

Vertical viewing angle

System

Switch

Connections

Remote control input

Telephone mute connection

RGB input

External IR receiver

Integrated IR receiver

Miscellaneous

Flip panel

Flip-release panel

TMC out FM

TMC out DAB

Display colour, numbers

Display brightness

Angle

Theft protection; flip-release panel

Clock display

Navigation control

IR remote control included

IR remote control as optional accessory

Steering wheel remote control included

Steering wheel remote control as optional accessory

Dimensions (W x H x D) mm Operating panel

Dimensions (W x H x D) mm Control box

Black front panel

Product

IVMS-5802

14.4 cm

1200 x 234

+/-60°

+/-30°

400 cd/m2

PAL/NTSC

automatisch

Composite Video

1.0 Vpp, 75 Ohm

0–0.3 Vmrs

20 Hz – 20 kHz

•

-/blue

•

optional

–

•

3 options

•

13-pin plug combined

with power, ground

and system control

12 volts

< 600 mA

< 1 mA

0 to +60° C

-20 to +80° C

150 x 107 x 24

165 x 122 x 27

400 g

IVMS-6502

16.1 cm

1200 x 234

+/-60°

+30°/-60°

350 cd/m2

PAL/NTSC

automatisch

Composite Video

1.0 Vpp, 75 Ohm

0–0.3 Vmrs

20 Hz – 20 kHz

•

-/blue

•

optional

–

•

3 options

•

13-pin plug combined

with power, ground

and system control

13 volts

< 700 mA

< 1 mA

0 to +60° C

-20 to +80° C

161 x 107 x 24

176 x 121 x 27

400 g

IVMR-7002

17.6 cm

1200 x 234

+/-60°

+/-50°

320 cd/m2

PAL/NTSC

automatisch

Composite Video

0.7 Vpp – 2.0 Vpp, 75 Ohm

0–0.3 Vmrs

1 Watt, 280 Hz – 20 kHz

•

blue LED on/off

•

optional

•

full color

•

3 options

•

13-pin plug combined

with power, ground

and system control

10 – 16 volts

n/a

0 to +60° C

-30 to +80°C

233 x 219 x 54 mm

n/a

1.100 g

IVMR-9002

22.7 cm

1920 x 480

+/-65

50/65

300 cd/m2

PAL/NTSC

automatisch

Composite Video

0.7 Vpp – 2.0 Vpp, 75 Ohm

0–0.3 Vmrs

1 Watt, 280 Hz – 20 kHz

•

blue LED on/off

•

optional

•

built-in

•

full color

•

3 options

•

13-pin plug combined

with power, ground

and system control

10 – 16 volts

n/a

0 to +60° C

-30 to +80° C

165 x 122 x 26.7 mm

n/a

IVMR-1042

26.4 cm

1920 x 480

+/-45

40/15

290 cd/m2

PAL/NTSC

automatisch

Composite Video

0.7 Vpp – 2.0 Vpp, 75 Ohm

0–0.3 Vmrs

1 Watt, 280 Hz – 20 kHz

•

blue LED on/off

•

optional

•

built-in

•

full color

•

3 options

•

13-pin plug combined

with power, ground

and system control

10 – 16 volts

n/a

0 to +60° C

-30 to +80° C

176 x 122 x 26.7 mm

n/a

IVMR-1542

39.1 cm

1280 x 480

+/-70°

+/-60°

220 cd/m2

PAL/NTSC

atomatisch

Composite Video

0.7 Vpp – 2.0 Vpp, 75 Ohm

0–0.3 Vmrs

1 Watt, 280 Hz – 20 kHz

•

blue LED on/off

•

optional

•

full color

•

3 options

•

13-pin plug combined

with power, ground

and system control

10 – 16 volts

n/a

0 to +50° C

344 x 222 x 6.5 mm

n/a

88 In Car Entertainment

IVSC-5502 IVSC-3302 IVSC-1102

Page

Connectable A/V sources

A/V outputs

witch-in for monitors

Integrated power supply

for monitors

Connections

Dimensions (W x D x H)

Included

Product

4 (composite video)

4 signal inputs

(50 Hz/60 Hz composite video/audio)

1 navigation input (RGB)

4 signal outputs

(50 Hz/60 Hz composite video/audio)

1 navigation output (RGB)

Line out to radio or amp,

switchable (0 dB, +10 dB)

12 V input

205 x 45 x 146 mm

IR remote control

Cable for 12 V/ground

IVTV-03

Seite

Tuner type

No. of A/V inputs

No. of A/V outputs

Antenna inputs

(Diversity)

Signal system

Dimensions

Weight

Included

Product

3 (composite video)

3 signal inputs

(50 Hz/60 Hz composite video/audio)

3 signal outputs

(50 Hz/60 Hz composite video/audio)

Line out to radio or amp,

switchable (0 dB, +10 dB)

12 V input

205 x 45 x 146 mm

IR remote control

Cable for 12 V/ground

1 (RGB)

–

1 signal input

(50 Hz/60 Hz composite video/audio)

1 signal output

(50 Hz/60 Hz composite video/audio)

12 V input

123 x 29 x 98 mm

Cable for 12 V/ground

Product

Page

Visible picture/diagonal

Resolution (horizontal x vertical)

Horizontal viewing angle

Vertical viewing angle

Brightness

System

Switch

Video input

Audio input

Audio frequency range

Operating elements

Power on/off

On-screen display (OCD)

Cursor up

Cursor down

CH (source channel)

LED operating display (on/off)

Infrared remote control

Earphones

Infrared earphones

Additional illumination

Integrated speaker

OSD features

Volume

Brightness

Contrast

Colour strength

Tint (for NTSC only)

Picture settings

Picture inversion (left-right/top-bottom)

Reset picture

Connections

AV input

Voltage supply

Operating voltage

Maximum consumption

Stand-by consumption

Miscellaneous

Operating temperature range

Storage temperature range

Mechanical data

Monitor dimensions (W x H x D in mm)

Installation bracket dimensions (W x H x D in mm)

Weight

analogue

2 (cinch)

1 (cinch)

PAL B/G, B/H, I,

D/K, AUS,

SECAM L/L´,

BG, DKK1

182 x 27,4 x 134 mm

640 g

Passive,

4-fold diversity antenna

IR remote control

VA 4100VA 1400

7607 792 108

1,800 Watts

1 x 450 Watts

1 x 1,200 Watts

Cinch, gold-plated

15 – 250 Hz

2 Ohms

> 100 dBA

0.3 – 8 Volts

50 – 250 Hz

–

Cable remote control

Variable Flanken-

Variable slope, low pass

490 x 60 x 300

VA 2100

7607 792 109

800 Watts (2-channel mode)

2 x 100 Watts / 1 x 350 Watts

2 x 250 / 1 x 900 Watts

2/1

Cinch, gold-plated

15 – 50,000 Hz

2 Ohms

> 100 dBA

0.3 – 8 Volts

50 – 250 Hz

Cable remote control

361 x 60 x 300 mm

7607 792 110

1,400 Watts (2-channel mode)

4 x 100 Watts / 2 x 300 Watts

4 x 250 / 2 x 700 Watts

4/3/2

Cinch, gold-plated

15 – 50,000 Hz

2 Ohms

> 100 dBA

0.3 – 8 Volts

50 – 250 Hz

Cable remote control

491 x 60 x 300 mm

Sound

Page

Part number

Total output power (2 ohms)

RMS power (4 ohms)

Max power (4 ohms)

Number of channels

Speaker outputs

Preamp-in

Frequency range Hz

Stability

Signal/noise ratio

Gain adjust

Low pass

High pass

Special features

Dimensions W x H x D (mm)

Product

VPA 11500

7607 792 072

4,500 Watts

1 x 1,500 Watts

1 x 3,000 Watts

Cinch, chrome-plated

10 – 500 Hz

2 Ohms

> 100 dBA

0.2 – 5 Volts

50 – 250 Hz

–

Subsonic filter

Bass boost 0 – 12 dB

Phase switch

Cable remote control

700 x 90 x 280 mm

VPA 4120

7607 792 074

1,400 Watts (4-channel mode)

4 x 120 Watts / 2 x 350 Watts

4 x 250 / 2 x 750 Watts

4/3/2

Cinch, chrome-plated

10 – 50,000 Hz

2 Ohms

> 100 dBA

0.3 – 8 Volts

50 – 250 Hz

Subsonic filter

Bass boost 0 – 12 dB

Phase switch

Cable remote control

465 x 90 x 280 mm

VPA 2120

7607 792 073

700 Watts (2-channel mode)

2 x 120 Watts / 1 x 350 Watts

2 x 250 / 1 x 750 Watts

2/1

Cinch, chrome-plated

10 – 50,000 Hz

2 Ohms

> 100 dBA

0.2 – 5 Volts

50 – 250 Hz

Subsonic filter

Bass boost 0 – 12 dB

Phase switch

Cable remote control

345 x 90 x 280 mm

THA 1400

7607 792 104

1,300 Watts

1 x 400 Watts

1 x 1,000 Watts

Cinch, gold-plated

10 – 30,000 Hz

2 Ohms

> 100 dBA

0.3 – 8 Volts

20 – 250 Hz

–

Cable remote control

Subsonic filter

502 x 43 x 251

Product

THA 280

7607 792 105

600 Watts (2-channel mode)

2 x 80 Watts / 1 x 240 Watts

2 x 200 / 1 x 600 Watts

2/1

Cinch, gold-plated

10 – 30,000 Hz

2 Ohms

> 100 dBA

0,3 – 8 Volts

50 – 250 Hz

Bass boost 0 – 12 dB

Cable remote control

352 x 43 x 251 mm

THA 480

7607 792 106

1,200 Watts (4-channel mode)

4 x 80 Watts / 2 x 240 Watts

4 x 200 / 2 x 600 Watts

4/3/2

Cinch, gold-plated

10 – 30,000 Hz

2 Ohms

> 100 dBA

0,3 – 8 Volts

50 – 250 Hz

–

482 x 43 x 250 mm

GTA 200 Flash

7607 792 102

350 Watts (2-channel mode)

2 x 45 Watts / 1 x 140 Watts

2 x 90 / 1 x 350 Watts

2/1

Cinch, gold-plated

10 – 55,000 Hz

2 Ohms

> 85 dBA

0,1 – 8 Volts

40 – 160 Hz

100 Hz

Bass boost 0/9 dB

218 x 60 x 246 mm

GTA 400 Flash

7607 792 103

600 Watts (4-channel mode)

4 x 45 Watts / 2 x 140 Watts

4 x 90 / 2 x 300 Watts

4/3/2

Cinch, gold-plated

10 – 55,000 Hz

2 Ohms

> 85 dBA

0,1 – 8 Volts

50 – 250 Hz

Bass boost 0/9 dB

328 x 60 x 246 mm

GTA 1300

7607 792 079

900 Watts

1 x 300 Watts

1 x 750 Watts

Cinch, gold-plated

10 – 300 Hz

2 Ohms

> 90 dBA

0,3 – 8 Volts

50 – 250 Hz

–

Bass boost 0 – 12 dB

Subsonic filter

340 x 49 x 254

GTA 270

7607 792 075

400 Watts (2-channel mode)

2 x 70 Watts / 1 x 200 Watts

2 x 150 / 1 x 400 Watts

2/1

Cinch, gold-plated

10 – 26,000 Hz

2 Ohms

> 90 dBA

0,3 – 8 Volts

50 – 250 Hz

Bass boost 0 – 12 dB

200 x 49 x 254 mm

GTA 470

7607 792 077

800 Watts (4-channel mode)

4 x 70 Watts / 2 x 200 Watts

4 x 150 / 2 x 400 Watts

4/3/2

Cinch, gold-plated

10 – 26,000 Hz

2 Ohms

> 90 dBA

0,3 – 8 Volts

50 – 250 Hz

Bass boost 0 – 12 dB

290 x 49 x 254 mm

Page

Part number

System

Diameter (mm)

Rated power

Peak-power handling

Sensitivity 2.83 V/m

Frequency range Hz

Impedance

Cone material

Installation depth (mm)

Product

VPw 300

7 606 291 000

Subwoofer

300

1,200 Watts

3,600 Watts

93 dB

35 – 2,500 Hz

2 x 2 Ohms

Carbon/fibreglass

182 mm

VPw 380

7 606 281 002

Subwoofer

380

1,500 Watts

4,500 Watts

93 dB

35 – 2,500 Hz

2 x 2 Ohms

Carbon/fibreglass

206 mm

VPw 460

7 606 293 000

Subwoofer

460

1,800 Watts

5,400 Watts

93 dB

35 – 2,500 Hz

2 x 2 Ohms

Carbon/fibreglass

245 mm

Vw 250

7 606 344 000

Subwoofer

250

500 Watts

1,500 Watts

92 dB

35 – 1,000 Hz

2 x 2 Ohms

Fibreglass

121 mm

Vw 300

7 606 345 000

Subwoofer

300

750 Watts

2,250 Watts

93 dB

30 – 1,000 Hz

2 x 2 Ohms

Fibreglass

142 mm

Vw 380

7 606 349 000

Subwoofer

380

1,000 Watts

3,000 Watts

94 dB

25 – 1,000 Hz

2 x 2 Ohms

Fibreglass

179 mm

Page

Part number

Total output power (2 ohms)

RMS power (4 ohms)

Max power (4 ohms)

Number of channels

Speaker outputs

Preamp-in

Frequency range Hz

Stability

Signal/noise ratio

Gain adjust

Low pass

High pass

Special features

Dimensions W x H x D (mm)

90 Sound

Vb 250

7 606 346 000

Subwoofer box

250

200 Watts

600 Watts

93 dB

40 – 1,000 Hz

2 x 2 Ohms

Fibreglass

390 x 330 x 350 mm

Vb 300

7 606 347 000

Subwoofer box

300

400 Watts

1,200 Watts

94 dB

35 – 1,000 Hz

2 x 2 Ohms

Fibreglass

435 x 390 x 400 mm

Page

Part number

System

Diameter (mm)

Rated power

Peak-power handling

Sensitivity 2.83 V/m

Frequency range Hz

Impedance

Cone material

Installation depth (mm)

Product

VPc 132

7 606 274 003

2-way component

130

100 Watts

300 Watts

91 dB

Open

4 Ohms

CFG/Tetron

63.5

VPc 172

7 606 273 003

2-way component

165

120 Watts

360 Watts

92 dB

Open

4 Ohms

CFG/Tetron

Vc 132

7 606 342 000

2-way component

130

80 Watts

240 Watts

91 dB

Open

4 Ohms

Fibreglass/silk

Vc 172

7 606 343 000

2-way component

165

100 Watts

300 Watts

92 dB

Open

4 Ohms

Fibreglass/silk

58.5

ODx 92

7 606 320 001

2-way coaxial

30 Watts

90 Watts

89 dB

80 – 22,000 Hz

4 Ohms

Fibreglass/titanium

Page

Part number

System

Diameter (mm)

Rated power

Peak-power handling

Sensitivity 2.83 V/m

Frequency range Hz

Impedance

Cone material

Installation depth (mm)

Product

ODx 102

7 606 321 001

2-way coaxial

100

40 Watts

120 Watts

90 dB

70 – 22,000 Hz

4 Ohms

Fibreglass/titanium

34.5

ODx 462

7 606 322 001

2-way coaxial

4“ x 6“

40 Watts

120 Watts

90 dB

70 – 22,000 Hz

4 Ohms

Fibreglass/titanium

ODx 132

7 606 301 001

2-way coaxial

130

60 Watts

180 Watts

90 dB

60 – 22,000 Hz

4 Ohms

Fibreglass/titanium

41.5

ODx 162

7 606 323 001

2-way coaxial

160

70 Watts

210 Watts

91 dB

50 – 22,000 Hz

4 Ohms

Fibreglass/titanium

37.5

ODx 172

7 606 302 001

2-way coaxial

165

70 Watts

210 Watts

91 dB

50 – 22,000 Hz

4 Ohms

Fibreglass/titanium

45.5

ODx 573

7 606 324 001

3-way triaxial

5“ x 7“

90 Watts

270 Watts

92 dB

45 – 22,000 Hz

4 Ohms

Fibreglass/titanium

42.5

ODx 693

7 606 325 001

3-way triaxial

6“ x 9“

100 Watts

300 Watts

92 dB

40 – 22,000 Hz

4 Ohms

Fibreglass/titanium

Page

Part number

System

Diameter (mm)

Rated power

Peak-power handling

Sensitivity 2.83 V/m

Frequency range Hz

Impedance

Cone material

Installation depth (mm)

Product

ODsb 8000A

7 606 318 000

active subwoofer box

200

70 Watts

140 Watts

active system

30 – 120 Hz

–

Spun Paper

288 x 274 x 238 mm

THb 250

7 606 338 000

Subwoofer box

250

200 Watts

600 Watts

92 dB

40 – 1,000 Hz

4 Ohms

Injected PP

450 x 310 x 220 mm

THb 300

7 606 339 000

Subwoofer box

300

250 Watts

750 Watts

93 dB

35 – 1,000 Hz

4 Ohms

Injected PP

500 x 365 x 240 mm

GTt 300

7 606 439 000

Subwoofer tube

300

200 Watts

600 Watts

91 dB

35 – 500 Hz

4 Ohms

Spun Paper

484 mm x 328 mm

GTb 300

7 606 450 000

Subwoofer box

300

250 Watts

750 Watts

91 dB

35 – 500 Hz

4 Ohms

Spun Paper

432 x 387 x 378 mm

GTb 300 Dual

7 606 451 000

Subwoofer box

2 x 300

2 x 250 Watts

2 x 750 Watts

96 dB

25 – 500 Hz

2 x 4 Ohms

Spun Paper

864 x 378 x 387

Sound

Page

Part number

System

Diameter (mm)

Rated power

Peak-power handling

Sensitivity 2.83 V/m

Frequency range Hz

Impedance

Cone material

Installation depth (mm)

Product

THx 172

7 606 334 000

2-way coaxial

165

50 Watts

150 Watts

92 dB

60 – 22,000 Hz

4 Ohms

Injected PP/PEI

THx 693

7 606 335 000

3-way triaxial

6“ x 9“

70 Watts

210 Watts

93 dB

50 – 22,000 Hz

4 Ohms

Injected PP/PEI

THc 132

7 606 336 000

2-way component

130

50 Watts

150 Watts

92 dB

70 – 22,000 Hz

4 Ohms

Injected PP/PEI

THc 172

7 606 337 000

2-way component

165

60 Watts

180 Watts

92 dB

60 – 22,000 Hz

4 Ohms

Injected PP/PEI

GTx 102

7 606 431 001

2-way coaxial

100

30 Watts

90 Watts

90 dB

90 – 20,000 Hz

4 Ohms

Injected PP/PEI

39.4

GTx 462

7 606 434 001

2-way coaxial

4“ x 6“

35 Watts

110 Watts

91 dB

80 – 20,000 Hz

4 Ohms

Injected PP/PEI

Page

Part number

System

Diameter (mm)

Rated power

Peak-power handling

Sensitivity 2.83 V/m

Frequency range Hz

Impedance

Cone material

Installation depth (mm)

Product

GTx 132

7 606 430 001

2-way coaxial

130

35 Watts

110 Watts

91 dB

70 – 20,000 Hz

4 Ohms

Injected PP/PEI

GTx 172

7 606 428 001

2-way coaxial

165

40 Watts

120 Watts

92 dB

60 – 20,000 Hz

4 Ohms

Injected PP/PEI

GTx 173

7 606 425 001

3-way triaxial

165

45 Watts

140 Watts

93 dB

40 – 22,000 Hz

4 Ohms

Injected PP/PEI

GTx 693

7 606 427 001

3-way triaxial

6“ x 9“

50 Watts

150 Watts

92 dB

40 – 22,000 Hz

4 Ohms

Injected PP/PEI

72.4

GTx 203

7 606 426 001

3-way triaxial

200

50 Watts

150 Watts

92 dB

40 – 22,000 Hz

4 Ohms

Injected PP/PEI

GTc 172

7 606 429 001

2-way component

165

45 Watts

140 Watts

91 dB

60 – 20,000 Hz

4 Ohms

Injected PP/PEI

Page

Part number

System

Diameter (mm)

Rated power

Peak-power handling

Sensitivity 2.83 V/m

Frequency range Hz

Impedance

Cone material

Installation depth (mm)

Product

ODc 25

7 606 326 001

Tweeter

100 Watts

300 Watts

91 dB

2,500 – 23,000 Hz

4 Ohms

Silk

ODc 132

7 606 303 001

2-way component

130

60 Watts

180 Watts

90 dB

70 – 23,000 Hz

4 Ohms

Fibreglass/silk

ODc 162

7 606 327 001

2-way component

160

70 Watts

210 Watts

91 dB

65 – 23,000 Hz

4 Ohms

Fibreglass/silk

37,5

ODc 172

7 606 304 001

2-way component

160

80 Watts

240 Watts

91 dB

65 – 23,000 Hz

4 Ohms

Fibreglass/silk

THx 102

7 606 332 000

2-way coaxial

100

40 Watts

120 Watts

91 dB

80 – 22,000 Hz

4 Ohms

Injected PP/PEI

THx 132

7 606 333 000

2-way coaxial

130

40 Watts

120 Watts

91 dB

70 – 22,000 Hz

4 Ohms

Injected PP/PEI

www.blaupunkt.com

The advantage in your car.

Blaupunkt GmbH

P.O. Box

D-31132 Hildesheim

Germany

Hotline +49-180/5 00 02 25

Telefax +49-5121/49 4154

Service numbers /Numéros du service après-vente/

Números de servicio/Número de serviço

Germany (D) Phone 0180-5000225 Fax 0 5121-49 40 02

Austria (A) Phone 01-610 39 0 Fax 01-610 39 391

Belgium (B) Phone 02-525 5444 Fax 02-525 5263

Denmark (DK) Phone 44-898 360 Fax 44-898 644

Finland (FIN) Phone 09-435 991 Fax 09-435 99236

France (F) Phone 01-4010 7007 Fax 01-4010 7320

Great Britain (GB) Phone 01-89583 8880 Fax 01-89583 8394

Greece (GR) Phone 210 94 27 337 Fax 210 94 12 711

Ireland (IRL) Phone 01-46 66 700 Fax 01-46 66 706

Italy (I) Phone 02-369 62331 Fax 02-369 62464

Luxembourg (L) Phone 40 4078 Fax 40 2085

Netherlands (NL) Phone 0800 400 1010 Fax 0800 400 1040

Norway (N) Phone 66-817 000 Fax 66-817 157

Portugal (P) Phone 2185 00144 Fax 2185 00165

Spain (E) Phone 902 52 77 70 Fax 91 410 4078

Sweden (S) Phone 08-7501850 Fax 08-7501810

Switzerland (CH) Phone 01-8471644 Fax 01-8471650

Czech. Rep. (CZ) Phone 02-6130 0446 Fax 02-6130 0514

Hungary (H) Phone 76 511 803 Fax 76 511 809

Poland (PL) Phone 0800-118922 Fax 022-8771260

Turkey (TR) Phone 0212-335 06 71 Fax 0212-346 00 40

USA (USA) Phone 800-2662528 Fax 708-6817188

Brasil (Mercosur) (BR) Phone 0800 7045446 Fax +55-19 3745 2773

Malaysia (Asia Pacific) (MAL) Phone +604-6382 474 Fax +604-6413 640

Subject to availability and technical modification · CM/SMC · 8671210100 · Printed in Germany

Blaupunkt Car Multimedia Users Manual

Car Multimedia to the manual 48af2601-e8be-406e-a291-410f758d6482

Navigation menu

Versions of this User Manual:

Views

Navigation
