Washing Machine

WNF 8441 AE20

User‘s Manual

2820523538/ 04-06-13.(14:43)Document Number

2 / EN Washing Machine /User’s Manual

Please read this user manual first!

Dear Customer,

Thank you for prefering an Blomberg product. We hope that you get the best results from your product

which has been manufactured with high quality and state-of-the-art technology. Therefore, please read

this entire user manual and all other accompanying documents carefully before using the product and

keep it as a reference for future use. If you handover the product to someone else, give the user manual

as well. Follow all warnings and information in the user manual.

Remember that this user manual is also applicable for several other models. Differences between

models will be identified in the manual.

Explanation of symbols

Throughout this user manual the following symbols are used:

CImportant information or useful hints

about usage.

AWarning for hazardous situations with

regard to life and property.

BWarning for electric shock.

Packaging materials of the product

are manufactured from recyclable

materials in accordance with our

National Environment Regulations.

Do not dispose of the packaging materials together with the domestic or other wastes. Take them to the

packaging material collection points designated by the local authorities.

3 / EN

1 Important instructions for safety and

environment 4

1.1 General safety . . . . . . . . . . . . . . . . . . . . . . .4

1.2 Intended use . . . . . . . . . . . . . . . . . . . . . . . . 4

1.3 Children's safety. . . . . . . . . . . . . . . . . . . . . .5

1.4 Package information. . . . . . . . . . . . . . . . . . .5

1.5 Disposing of the waste product . . . . . . . . . . .5

1.6 Compliance with WEEE Directive . . . . . . . . . .5

2 Your washing machine 6

2.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . .6

2.2 Package Contents . . . . . . . . . . . . . . . . . . . .7

2.3 Technical specifications . . . . . . . . . . . . . . . .8

3 Installation 9

3.1 Appropriate installation location. . . . . . . . . . .9

3.2 Removing packaging reinforcement . . . . . . .9

3.3 Removing the transportation locks. . . . . . . . .9

3.4 Connecting water supply. . . . . . . . . . . . . . .10

3.5 Connecting to the drain. . . . . . . . . . . . . . . .10

3.6 Adjusting the feet . . . . . . . . . . . . . . . . . . . .11

3.7 Electrical connection. . . . . . . . . . . . . . . . . .12

4 Preparation 14

4.1 Sorting the laundry . . . . . . . . . . . . . . . . . . .14

4.2 Preparing laundry for washing. . . . . . . . . . .15

4.3 Things to be done for energy saving . . . . . .15

4.4 Initial use . . . . . . . . . . . . . . . . . . . . . . . . . .15

4.5 Correct load capacity . . . . . . . . . . . . . . . . .16

4.6 Loading the laundry . . . . . . . . . . . . . . . . . .16

4.7 Using detergent and softener . . . . . . . . . . .16

4.8 Tips for efficient washing . . . . . . . . . . . . . .19

5 Operating the product 20

5.1 Control panel . . . . . . . . . . . . . . . . . . . . . . .20

5.2 Display symbols . . . . . . . . . . . . . . . . . . . . .20

5.3 Preparing the machine . . . . . . . . . . . . . . . .21

5.4 Programme selection . . . . . . . . . . . . . . . . .21

5.5 Main programmes . . . . . . . . . . . . . . . . . . .21

5.6 Additional programmes . . . . . . . . . . . . . . .22

5.7 Special programmes. . . . . . . . . . . . . . . . . .23

5.8 Temperature selection. . . . . . . . . . . . . . . . .23

5.9 Spin speed selection. . . . . . . . . . . . . . . . . .23

5.10 Programme and consumption table. . . . . .24

5.11 Auxiliary function selection . . . . . . . . . . . .26

5.12 Time display. . . . . . . . . . . . . . . . . . . . . . .27

5.13 Starting the programme . . . . . . . . . . . . . .28

5.14 Progress of programme . . . . . . . . . . . . . .28

5.15 Loading door lock. . . . . . . . . . . . . . . . . . .28

5.16 Changing the selections after programme

has started . . . . . . . . . . . . . . . . . . . . . . .28

5.17 Child Lock . . . . . . . . . . . . . . . . . . . . . . . .29

5.18 Cancelling the programme . . . . . . . . . . . .29

5.19 Machine is in Rinse Hold mode . . . . . . . . .29

5.20 End of programme . . . . . . . . . . . . . . . . . .29

5.21 Your machine is equipped with a “Standby

Mode”. . . . . . . . . . . . . . . . . . . . . . . . . . .30

6 Quick User Guide 31

6.1 Preparing the machine . . . . . . . . . . . . . . . .31

6.2 Programme selection . . . . . . . . . . . . . . . . .31

6.3 Auxiliary function selection . . . . . . . . . . . . .31

6.4 Starting the programme . . . . . . . . . . . . . . .31

6.5 End of programme . . . . . . . . . . . . . . . . . . .31

6.6 Cancelling the programme . . . . . . . . . . . . .31

6.7 Child Lock . . . . . . . . . . . . . . . . . . . . . . . . .31

7 Maintenance and cleaning 32

7.1 Cleaning the detergent drawer . . . . . . . . . .32

7.2 Cleaning the loading door and the drum . . .32

7.3 Cleaning the body and control panel . . . . . .33

7.4 Cleaning the water intake filters . . . . . . . . .33

7.5 Draining remaining water and cleaning the

pump filter. . . . . . . . . . . . . . . . . . . . . . . .33

8 Troubleshooting 35

TABLE OF CONTENTS

4 / EN Washing Machine /User’s Manual

1 Important instructions for safety and environment

This section contains safety instructions that

will help protect from risk of personal injury

or property damage. Failure to follow these

instructions shall void any warranty.

1.1 General safety

•Thisproductcanbeusedbychildrenatand

above 8 years old and by persons whose

physical, sensory or mental capabilities were

not fully developed or who lack experience and

knowledge provided that they are supervised

or trained on the safe usage of the product and

the risks it brings out. Children must not play

with the product. Cleaning and maintenance

works should not be performed by children

unless they are supervised by someone.

•Neverplacetheproductonacarpet-covered

floor. Otherwise, lack of airflow beneath the

machine will cause electrical parts to overheat.

This will cause problems with your product.

•Iftheproducthasafailure,itshouldnotbe

operated unless it is repaired by the Authorized

Service Agent. There is the risk of electric

shock!

•Thisproductisdesignedtoresumeoperating

in the event of powering on after a power

interruption. If you wish to cancel the

programme, see "Cancelling the programme"

section.

•Connecttheproducttoagroundedoutlet

protected by a 13 A fuse. Do not neglect to

have the grounding installation made by a

qualified electrician. Our company shall not

be liable for any damages that will arise when

the product is used without grounding in

accordance with the local regulations.

•Thewatersupplyanddraininghosesmustbe

securely fastened and remain undamaged.

Otherwise, there is the risk of water leakage.

•Neveropentheloadingdoororremovethefilter

while there is still water in the drum. Otherwise,

risk of flooding and injury from hot water will

occur.

•Donotforceopenthelockedloadingdoor.The

loading door will be ready to open just a few

minutes after the washing cycle comes to an

end. In case of forcing the loading door to open,

the door and the lock mechanism may get

damaged.

•Unplugtheproductwhennotinuse.

•Neverwashtheproductbyspreadingorpouring

water onto it! There is the risk of electric shock!

•Nevertouchtheplugwithwethands!Never

unplug by pulling on the cable, always pull out

by grabbing the plug.

•Usedetergents,softenersandsupplements

suitable for automatic washing machines only.

•Followtheinstructionsonthetextiletagsand

on the detergent package.

•Theproductmustbeunpluggedduring

installation, maintenance, cleaning and

repairing procedures.

•Alwayshavetheinstallationandrepairing

procedures carried out by the Authorized

Service Agent. Manufacturer shall not be

held liable for damages that may arise from

procedures carried out by unauthorized

persons.

•Ifthesupplycordisdamaged,itmustbe

replaced by the manufacturer, its service agent

or similary qualified persons in order to avoid a

hazard.

•Ifthepowercableisdamaged,itmustbe

replaced by the manufacturer, after sales

service or a similarly qualified person

(preferably an electrician) or someone

designated by the importer in order to avoid

possible risks.

1.2 Intended use

•Thisproducthasbeendesignedfordomestic

use. It is not suitable for commercial use and it

must not be used out of its intended use.

•Theproductmustonlybeusedforwashingand

rinsing of laundry that are marked accordingly.

•Themanufacturerwaivesanyresponsibility

arisen from incorrect usage or transportation.

•Theservicelifeofyourproductis10years.

During this period, original spare parts will be

available to operate the appliance properly.

Washing Machine /User’s Manual 5 / EN

Important instructions for safety and environment

1.3 Children's safety

•Packagingmaterialsaredangeroustochildren.

Keep packaging materials in a safe place away

from reach of the children.

•Electricalproductsaredangerousforthe

children. Keep children away from the product

when it is in use. Do not let them to tamper with

the product. Use child lock to prevent children

from intervening with the product.

•Donotforgettoclosetheloadingdoorwhen

leaving the room where the product is located.

•Storealldetergentsandadditivesinasafe

place away from the reach of the children by

closing the cover of the detergent container or

sealing the detergent package.

1.4 Package information

•Packagingmaterialsoftheproductare

manufactured from recyclable materials in

accordance with our National Environment

Regulations. Do not dispose of the packaging

materials together with the domestic or other

wastes. Take them to the packaging material

collection points designated by the local

authorities.

1.5 Disposing of the waste product

•Thisproducthasbeenmanufacturedwithhigh

quality parts and materials which can be reused

and are suitable for recycling. Therefore, do

not dispose the product with normal domestic

waste at the end of its service life. Take it to a

collection point for the recycling of electrical

and electronic equipment. Please consult your

local authorities to learn the nearest collection

point. Help protect the environment and natural

resources by recycling used products. For

children's safety, cut the power cable and break

the locking mechanism of the loading door so

that it will be non-functional before disposing of

the product.

1.6 Compliance with WEEE Directive

This product complies with EU WEEE

Directive (2012/19/EU). This product

bears a classification symbol for waste

electrical and electronic equipment

(WEEE).

This product has been manufactured with high

quality parts and materials which can be reused

and are suitable for recycling. Do not dispose of

the waste product with normal domestic and other

wastes at the end of its service life. Take it to the

collection center for the recycling of electrical and

electronic equipment. Please consult your local

authorities to learn about these collection centers.

6 / EN Washing Machine /User’s Manual

2 Your washing machine

2.1 Overview

7

3

4

6

5

2

1

8

1- Power cable

2- Top panel

3- Control panel

4- Filter cap

5- Adjustable feet

6- Loading door

7- Detergent drawer

8- Drain hose

Washing Machine /User’s Manual 7 / EN

Your washing machine

2.2 Package Contents

1

2

3 4

a b c

5

6

7

8

1- Power cable

2- Drain hose

3- Transportation safety bolts *

4- Mains water inlet hose (One of the following filter types is used for the mains hose connection.)

a- Electronical water shut-off

a- Mechanical water shut-off

c- Standard

5- Liquid detergent container**

6- User Manual

7- Blind plug***

8- Plastic plug group

* Number of transportation safety bolts may change depending on the model of your machine.

** This may be supplied with the machine depending on the model of your machine.

*** This is supplied if your machine is equipped with double water inlet.

8 / EN Washing Machine /User’s Manual

Your washing machine

WNF8441AE20

8

84

60

55

72

230 V / 50Hz

10

2200

1400

1.00

0.20

8811

•/-

2.3 Technical specifications

Models (EN)

Maximum dry laundry capacity (kg)

Height (cm)

Width (cm)

Depth (cm)

Net weight (±4 kg.)

Electrical input (V/Hz)

Total current (A)

Total power (W)

Spin speed (rpm/ min., max.)

Stand-by mode power (W)

Off-mode power (W)

Main model code

Single Water inlet / Double Water inlet

CTechnical specifications may be changed without prior notice to improve the quality of the product.

CFigures in this manual are schematic and may not match the product exactly.

CValues stated on the product labels or in the documentation accompanying it are obtained in laboratory

conditions in accordance with the relevant standards. Depending on operational and environmental

conditions of the product, these values may vary.

•Available

Washing Machine /User’s Manual 9 / EN

3 Installation

Refer to the nearest Authorised Service Agent for

installation of the product. To make the product

ready for use, review the information in the user

manual and make sure that the electricity, tap

water supply and water drainage systems are

appropriate before calling the Authorized Service

Agent. If they are not, call a qualified technician

and plumber to have any necessary arrangements

carried out.

CPreparation of the location and electrical,

tap water and waste water installations

at the place of installation is under

customer's responsibility.

BWARNING: Installation and electrical

connections of the product must be

carried out by the Authorized Service

Agent. Manufacturer shall not be held

liable for damages that may arise from

procedures carried out by unauthorized

persons.

AWARNING: Prior to installation, visually

check if the product has any defects on

it. If so, do not have it installed. Damaged

products cause risks for your safety.

CMake sure that the water inlet and

discharge hoses as well as the power

cable are not folded, pinched or crushed

while pushing the product into its place

after installation or cleaning procedures.

3.1 Appropriate installation location

•Placethemachineonarigidfloor.Donotplace

it on a long pile rug or similar surfaces.

•Totalweightofthewashingmachineandthe

dryer -with full load- when they are placed

on top of each other reaches to approx. 180

kilograms. Place the product on a solid and flat

floor that has sufficient load carrying capacity!

•Donotplacetheproductonthepowercable.

•Donotinstalltheproductatplaceswhere

temperature may fall below 0ºC.

•Placetheproductatleast1cmawayfromthe

edges of other furniture.

3.2 Removing packaging

reinforcement

Tilt the machine backwards to remove the

packaging reinforcement. Remove the packaging

reinforcement by pulling the ribbon.

3.3 Removing the

transportation locks

AWARNING: Do not remove the

transportation locks before taking out the

packaging reinforcement.

AWARNING: Remove the transportation

safety bolts before operating the washing

machine! Otherwise, the product will be

damaged.

1. Loosen all the bolts with a suitable spanner until

they rotate freely (C).

2. Remove transportation safety bolts by turning

them gently.

3. Attach the plastic covers supplied in the User

Manual bag into the holes on the rear panel. (P)

10 / EN Washing Machine /User’s Manual

Installation

CKeep the transportation safety bolts in

a safe place to reuse when the washing

machine needs to be moved again in the

future.

CNever move the product without the

transportation safety bolts properly fixed

in place!

3.4 Connecting water supply

CThe water supply pressure required to run

the product is between 1 to 10 bars (0.1

– 1 MPa). It is necessary to have 10 – 80

liters of water flowing from the fully open

tap in one minute to have your machine run

smoothly. Attach a pressure reducing valve

if water pressure is higher.

CIf you are going to use the double water-

inlet product as a single (cold) water-inlet

unit, you must install the supplied stopper

to the hot water valve before operating the

product. (Applies for the products supplied

with a blind stopper group.)

AWARNING: Models with a single water

inlet should not be connected to the hot

water tap. In such a case the laundry will

get damaged or the product will switch to

protection mode and will not operate.

AWARNING: Do not use old or used water

inlet hoses on the new product. It may

cause stains on your laundry.

1. Connect the special hoses supplied with the

product to the water inlets on the product. Red

hose (left) (max. 90 ºC) is for hot water inlet,

blue hose (right) (max. 25 ºC) is for cold water

inlet.

AWARNING: Ensure that the cold and hot

water connections are made correctly when

installing the product. Otherwise, your

laundry will come out hot at the end of the

washing process and wear out.

2. Tighten all hose nuts by hand. Never use a tool

when tightening the nuts.

3. Open the taps completely after making the

hose connection to check for water leaks at

the connection points. If any leaks occur, turn

off the tap and remove the nut. Retighten the

nut carefully after checking the seal. To prevent

water leakages and damages caused by them,

keep the taps closed when the machine is not

in use.

3.5 Connecting to the drain

•Theendofthedrainhosemustbedirectly

connected to the wastewater drain or to the

washbasin.

•Drainhoseshallbeattachedtoawalldrain,

stand pipe or sink siphon connected to the foul

water drain, do not connect to surface water

drains.

AWARNING: Your house will be flooded

if the hose comes out of its housing

during water discharge. Moreover, there

is risk of scalding due to high washing

temperatures! To prevent such situations

and to ensure smooth water intake and

discharge of the machine, fix the end

of the discharge hose tightly so that it

cannot come out.

Washing Machine /User’s Manual 11 / EN

Installation

•Thehoseshouldbeattachedtoaheightofat

least 40 cm, and 100 cm at most.

•Incasethehoseiselevatedafterlayingiton

the floor level or close to the ground (less than

40 cm above the ground), water discharge

becomes more difficult and the laundry may

come out excessively wet. Therefore, follow the

heights described in the figure.

•Topreventflowingofdirtywaterbackintothe

machine and to allow for easy discharge, do not

immerse the hose end into the dirty water or do

not drive it in the drain more than 15 cm. If it is

too long, cut it short.

•Theendofthehoseshouldnotbebent,it

should not be stepped on and the hose must

not be pinched between the drain and the

machine.

•Ifthelengthofthehoseistooshort,useitby

adding an original extension hose. Length of the

hose may not be longer than 3.2 m. To avoid

water leak failures, the connection between

the extension hose and the drain hose of the

product must be fitted well with an appropriate

clamp as not to come off and leak.

3.6 Adjusting the feet

AWARNING: In order to ensure that

the product operates more silently and

vibration-free, it must stand level and

balanced on its feet. Balance the machine

by adjusting the feet. Otherwise, the

product may move from its place and

cause crushing and vibration problems.

1. Loosen the lock nuts on the feet by hand.

2. Adjust the feet until the product stands level

and balanced.

3. Tighten all lock nuts again by hand.

12 / EN Washing Machine /User’s Manual

Installation

AWARNING: Do not use any tools to

loosen the lock nuts. Otherwise, they will

get damaged.

3.7 Electrical connection

Connect the product to a grounded outlet

protected by a 13 A fuse. Our company shall not

be liable for any damages that will arise when the

product is used without grounding in accordance

with the local regulations.

•Connectionmustcomplywithnational

regulations.

•Powercableplugmustbewithineasyreach

after installation.

•Ifthecurrentvalueofthefuseorbreakerinthe

house is less than 13 Amps, have a qualified

electrician install a 13 Amp fuse.

•Thevoltagespecifiedinthe"Technical

specifications" section must be equal to your

mains voltage.

•Donotmakeconnectionsviaextensioncables

or multi-plugs.

BWARNING: Damaged power cables

must be replaced by the Authorized

Service Agents.

Electrical requirements

Before you insert the plug into the wall socket

make sure that the voltage and the frequency

shown in the rating label corresponds to your

electricity supply.

We recommend that this appliance be connected

to the mains supply via a suitable switched and

fused socket in a readily accessible position.

Should the mains lead of the appliance become

damaged or need replacing at any time, it must be

replaced by a special purpose made mains lead

which can only be obtained from a Authorised

Service Agent.

BWARNING: This appliance must be

earthed

If the fitted moulded plug is not suitable for your

socket, then the plug should be cut off and an

appropriate plug fitted.

Destroy the old plug, which is cut off as a plug

with a bared cord could cause a shock hazard if

inserted into a socket elsewhere in the house.

The moulded plug on this appliance incorporates a

13A fuse. Should the fuse need to be replaced an

ASTA approved BS1362 fuse of the same rating

must be used. Do not forget to refit the fuse cover.

In the event of losing the fuse cover, the plug must

not be used until a replacement fuse cover has

been fitted. Colour of the replacement fuse cover

must be the same colour as that visible on the pin

face of the plug. Fuse covers are available from

any good electrical store.

Important

Fitting a different plug

As the colours of the wires in the mains lead

of this appliance may not correspond with the

coloured markings identifying the terminals on

your plug, proceed as follows:

1 Connect the green - yellow or green (earth) wire

to the terminal in the plug marked ‘E’ or with

the symbol f or coloured green and yellow or

green.

2 Connect the blue (neutral) wire to the terminal

in the plug marked ‘N’ or coloured black.

3 Connect the brown (live) wire to the terminal in

the plug marked ‘L’ or coloured red.

With the alternative plugs a 13A fuse must be fitted

either in the plug or adaptor or in the main fuse box. If

in doubt contact a qualified electrician.

Washing Machine /User’s Manual 13 / EN

Installation

Transportation of the product

1. Unplug the product before transporting it.

2. Remove water drain and water supply

connections.

3. Drain all water that has remained in the

product. See 7.5

4. Install transportation safety bolts in the reverse

order of removal procedure; see 3.3.

CNever move the product without the

transportation safety bolts properly fixed

in place!

AWARNING: Packaging materials are

dangerous to children. Keep packaging

materials in a safe place away from

reach of the children.

14 / EN Washing Machine /User’s Manual

4 Preparation

4.1 Sorting the laundry

•Sortlaundryaccordingtotypeoffabric,colour,

and degree of soiling and allowable water

temperature.

•Alwaysobeytheinstructionsgivenonthe

garment tags.

LAUNDRY WASH SYMBOLS

Machine

Wash

Symbols

Normal wash

No Iron

Sensitive-

Delicate

wash

Hand wash

Not washable

No Spin

WASH Water

Temperatures

Maximum 950C700C600C500C400C300C

Symbol(s) lll

lll

lll

l l

ll

ll

lll l l l

Drying

Symbols Suitable for

dryer No Iron Sensitive /

Delicate dry

Do not dry

with dryer

Do not dry Do not dry-

clean

DRYING

Drying

Settings

At any temperature

At high temperature

At medium

temperature

At low temperature

Without heating

Hang to dry

Lay to dry

Hang wet to dry

Lay in shadow

to dry

Dry-cleanable

Iron -

IRON Dry or Steam

Iron at high

temperature

Iron at medium

temperature

Iron at low

temperature

Do not iron

Iron without

steam

Maximum temperature 200 0C150 0C110 0C

All bleaches are allowed

Bleach (sodium

hypochlorite)

can be used

Bleach is not

allowed

Only bleaches without

chlorine are allowed

BLEACH

Washing Machine /User’s Manual 15 / EN

Preparation

4.2 Preparing laundry for washing

•Laundryitemswithmetalattachmentssuchas,

underwired bras, belt buckles or metal buttons

will damage the machine. Remove the metal

pieces or wash the clothes by putting them in a

laundry bag or pillow case.

•Takeoutallsubstancesinthepocketssuchas

coins, pens and paper clips, and turn pockets

inside out and brush. Such objects may damage

the product or cause noise problem.

•Putsmallsizeclothessuchasinfant'ssocks

and nylon stockings in a laundry bag or pillow

case.

•Placecurtainsinwithoutcompressingthem.

Remove curtain attachment items.

•Fastenzippers,sewloosebuttonsandmend

rips and tears.

•Wash“machinewashable”or“handwashable”

labeled products only with an appropriate

programme.

•Donotwashcoloursandwhitestogether.New,

dark coloured cottons release a lot of dye. Wash

them separately.

•Toughstainsmustbetreatedproperlybefore

washing. If unsure, check with a dry cleaner.

•Useonlydyes/colourchangersandlimescale

removers suitable for machine wash. Always

follow the instructions on the package.

•Washtrousersanddelicatelaundryturned

inside out.

•KeeplaundryitemsmadeofAngorawoolinthe

freezer for a few hours before washing. This will

reduce pilling.

•Laundrythataresubjectedtomaterialssuchas

flour, lime dust, milk powder, etc. intensely must

be shaken off before placing into the machine.

Such dusts and powders on the laundry may

build up on the inner parts of the machine in

time and can cause damage.

4.3 Things to be done

for energy saving

Following information will help you use the

product in an ecological and energy-efficient

manner.

•Operatetheproductinthehighestcapacity

allowed by the programme you have selected,

but do not overload; see, "Programme and

consumption table".

•Alwaysfollowtheinstructionsonthedetergent

packaging.

•Washslightlysoiledlaundryatlow

temperatures.

•Usefasterprogrammesforsmallquantitiesof

lightly soiled laundry.

•Donotuseprewashandhightemperaturesfor

laundry that is not heavily soiled or stained.

•Ifyouplantodryyourlaundryinadryer,select

the highest spin speed recommended during

washing process.

•Donotusedetergentinexcessoftheamount

recommended on the detergent package.

4.4 Initial use

Before starting to use the product, make sure

that all preparations are made in accordance

with the instructions in sections “Important safety

instructions” and “Installation”.

To prepare the product for washing laundry,

perform first operation in Drum Cleaning

programme. If your product is not equipped with

Drum Cleaning programme, perform the Initial

Use procedure in accordance with the methods

described under “7.2 Cleaning the loading door

and the drum” section of the user manual.

CUse an anti-limescale suitable for the

washing machines.

CSome water might have remained in

the product due to the quality control

processes in the production. It is not

harmful for the product.

16 / EN Washing Machine /User’s Manual

Preparation

4.5 Correct load capacity

The maximum load capacity depends on the type

of laundry, the degree of soiling and the washing

programme desired.

The machine automatically adjusts the amount

of water according to the weight of the loaded

laundry.

AWARNING: Follow the information in the

“Programme and consumption table”.

When overloaded, machine's washing

performance will drop. Moreover, noise

and vibration problems may occur.

Laundry type Weight (g)

Bathrobe 1200

Napkin 100

Duvet cover 700

Bed Sheet 500

Pillowcase 200

Tablecloth 250

Towel 200

Hand towel 100

Evening gown 200

Underclothing 100

Men’s overalls 600

Men’s shirt 200

Men’s pajamas 500

Blouses 100

4.6 Loading the laundry

1. Open the loading door.

2. Place laundry items loosely into the machine.

3. Push the loading door to close until you hear a

locking sound. Ensure that no items are caught

in the door.

CThe loading door is locked while a

programme is running. The door can only

be opened a while after the programme

comes to an end.

AWARNING: In case of misplacing the

laundry, noise and vibration problems may

occur in the machine.

4.7 Using detergent and softener

CWhen using detergent, softener, starch,

fabric dye, bleach or limescale remover

read the manufacturer's instructions

on the package carefully and follow the

suggested dosage values. Use measuring

cup if available.

Detergent Drawer

The detergent drawer is composed of three

compartments:

– (1) for prewash

– (2) for main wash

– (3) for softener

– (*) in addition, there is siphon piece in the

softener compartment.

1

23

Detergent, softener and other cleaning agents

•Adddetergentandsoftenerbeforestartingthe

washing programme.

•Neverleavethedetergentdraweropenwhile

the washing programme is running!

•Whenusingaprogrammewithoutprewash,

do not put any detergent into the prewash

compartment (compartment nr. "1").

•Inaprogrammewithprewash,donotput

liquid detergent into the prewash compartment

(compartment nr. "1").

•Donotselectaprogrammewithprewashifyou

are using a detergent bag or dispensing ball.

Place the detergent bag or the dispensing ball

directly among the laundry in the machine.

•Ifyouareusingliquiddetergent,donotforget

to place the liquid detergent cup into the main

wash compartment (compartment nr. "2").

Choosing the detergent type

The type of detergent to be used depends on the

type and colour of the fabric.

Washing Machine /User’s Manual 17 / EN

Preparation

•Usedifferentdetergentsforcolouredandwhite

laundry.

•Washyourdelicateclothesonlywithspecial

detergents (liquid detergent, wool shampoo,

etc.) used solely for delicate clothes.

•Whenwashingdarkcolouredclothesandquilts,

it is recommended to use liquid detergent.

•Washwoolenswithspecialdetergentmade

specifically for woolens.

AWARNING: Use only detergents

manufactured specifically for washing

machines.

AWARNING: Do not use soap powder.

Adjusting detergent amount

The amount of washing detergent to be used

depends on the amount of laundry, the degree of

soiling and water hardness.

•Donotuseamountsexceedingthedosage

quantities recommended on the detergent

package to avoid problems of excessive foam,

poor rinsing, financial savings and finally,

environmental protection.

•Uselesserdetergentforsmallamountsor

lightly soiled clothes.

Using softeners

Pour the softener into the softener compartment

of the detergent drawer.

•Donotexceedthe(>max<)levelmarkinginthe

softener compartment.

•Ifthesoftenerhaslostitsfluidity,diluteitwith

water before putting it in the detergent drawer.

Using liquid detergents

If the product contains a liquid detergent cup:

•Makesurethatyouhaveplacedtheliquid

detergent cup in compartment nr. "2".

•Iftheliquiddetergenthaslostitsfluidity,dilute

it with water before putting in the detergent

cup.

If the product does not contain a liquid

detergent cup:

•Donotuseliquiddetergentfortheprewashina

programme with prewash.

•Liquiddetergentstainsyourclotheswhenused

with Delayed Start function. If you are going to

use the Delayed Start function, do not use liquid

detergent.

Using gel and tablet detergent

Apply the following instructions when using tablet,

gel and similar detergents.

•Ifthegeldetergentthicknessisfluidaland

your machine does not contain a special liquid

detergent cup, put the gel detergent into the

main wash detergent compartment during first

water intake. If your machine contains a liquid

detergent cup, fill the detergent into this cup

before starting the programme.

•Ifthegeldetergentthicknessisnotfluidalorin

the shape of capsule liquid tablet, put it directly

into the drum before washing.

•Puttabletdetergentsintothemainwash

compartment (compartment nr. "2") or directly

into the drum before washing.

18 / EN Washing Machine /User’s Manual

Preparation

CTablet detergents may leave residues

in the detergent compartment. If you

encounter such a case, place the tablet

detergent between the laundry, close

to the lower part of the drum in future

washings.

CUse the tablet or gel detergent without

selecting the prewash function.

Using starch

•Addliquidstarch,powderstarchorthefabric

dye into the softener compartment.

•Donotusesoftenerandstarchtogetherina

washing cycle.

•Wipetheinsideofthemachinewithadamp

and clean cloth after using starch.

Using bleaches

•Selectaprogrammewithprewashandadd

the bleaching agent at the beginning of the

prewash. Do not put detergent in the prewash

compartment. As an alternative application,

select a programme with extra rinse and add

the bleaching agent while the machine is taking

water from the detergent compartment during

first rinsing step.

•Donotusebleachingagentanddetergentby

mixing them.

•Usejustalittleamount(approx.50ml)of

bleaching agent and rinse the clothes very

well as it causes skin irritation. Do not pour the

bleaching agent onto the clothes and do not

use it for coloured clothes.

•Whenusingoxygenbasedbleaches,select

a programme that washes at a lower

temperature.

•Oxygenbasedbleachescanbeusedtogether

with detergents; however, if its thickness

is not the same with the detergent, put the

detergent first into the compartment nr. "2"

in the detergent drawer and wait until the

detergent flows while the machine is taking in

water. Add the bleaching agent from the same

compartment while the machine is still taking in

water.

Using limescale remover

•Whenrequired,uselimescaleremovers

manufactured specifically for washing machines

only.

Washing Machine /User’s Manual 19 / EN

Preparation

4.8 Tips for efficient washing

Clothes

Light colours and

whites Colours Dark colours Delicates/Woolens/

Silks

(Recommended

temperature range

based on soiling level:

40-90ºC)

(Recommended

temperature range

based on soiling level:

cold-40ºC)

(Recommended

temperature range

based on soiling

level: cold-40ºC)

(Recommended

temperature range

based on soiling

level: cold-30ºC)

Soiling Level

Heavily Soiled

(difficult stains

such as grass,

coffee, fruits and

blood.)

It may be necessary

to pre-treat the

stains or perform

prewash. Powder

and liquid detergents

recommended

for whites can be

used at dosages

recommended for

heavily soiled clothes.

It is recommended to

use powder detergents

to clean clay and soil

stains and the stains

that are sensitive to

bleaches.

Powder and

liquid detergents

recommended for

colours can be used at

dosages recommended

for heavily soiled clothes.

It is recommended to

use powder detergents

to clean clay and soil

stains and the stains

that are sensitive to

bleaches. Use detergents

without bleach.

Liquid detergents

suitable for

colours and dark

colours can be

used at dosages

recommended

for heavily soiled

clothes.

Prefer liquid

detergents produced

for delicate clothes.

Woolen and silk

clothes must be

washed with special

woolen detergents.

Normally Soiled

(For example,

stains caused by

body on collars

and cuffs)

Powder and

liquid detergents

recommended for

whites can be used at

dosages recommended

for normally soiled

clothes.

Powder and

liquid detergents

recommended for

colours can be used at

dosages recommended

for normally soiled

clothes. Use detergents

without bleach.

Liquid detergents

suitable for

colours and dark

colours can be

used at dosages

recommended for

normally soiled

clothes.

Prefer liquid

detergents produced

for delicate clothes.

Woolen and silk

clothes must be

washed with special

woolen detergents.

Lightly Soiled

(No visible stains

exist.)

Powder and

liquid detergents

recommended for

whites can be used at

dosages recommended

for lightly soiled

clothes.

Powder and

liquid detergents

recommended for

colours can be used at

dosages recommended

for lightly soiled clothes.

Use detergents without

bleach.

Liquid detergents

suitable for

colours and dark

colours can be

used at dosages

recommended

for lightly soiled

clothes.

Prefer liquid

detergents produced

for delicate clothes.

Woolen and silk

clothes must be

washed with special

woolen detergents.

20 / EN Washing Machine /User’s Manual

5 Operating the product

1

6 7 8

2345

5.1 Control panel

1 - Spin Speed Adjustment button

2 - Display

3 - Temperature Adjustment button

4 - Programme Selection knob

5 - On / Off button

6 - Delayed Start buttons (+ / -)

7 - Auxiliary Function buttons

8 - Start / Pause / Cancel button

5.2 Display symbols

F1 F2 F3 F4

a - Spin Speed indicator

b - Temperature indicator

c - Spin symbol

d - Temperature symbol

e - Remaining Time and Delayed Start

indicator

f - Programme Indicator symbols

(Prewash / Main Wash / Rinse /

Softener / Spin)

g - Economy symbol

h - Delayed Start symbol

i - Door Locked symbol

j - Start symbol

k - Pause symbol

l - Auxiliary Function symbols

m - No Water symbol

Washing Machine /User’s Manual 21 / EN

Operating the product

5.3 Preparing the machine

1. Make sure that the hoses are connected

tightly.

2. Plug in your machine.

3. Turn the tap on completely.

4. Place the laundry in the machine.

5. Add detergent and fabric softener.

5.4 Programme selection

1. Select the programme suitable for the type,

quantity and soiling degree of the laundry

in accordance with the "Programme and

consumption table" and the temperature table

below.

90˚C

Heavily soiled white cottons and linens.

(coffee table covers, tableclothes, towels,

bed sheets, etc.)

60˚C

Normally soiled, coloured, fade proof

linens, cottons or synthetic clothes (shirt,

nightgown, pajamas, etc.) and lightly soiled

white linens (underwear, etc.)

40˚C-

30˚C-

Cold

Blended laundry including delicate textile

(veil curtains, etc.), synthetics and woolens.

2. Select the desired programme with the

Programme Selection button.

CProgrammes are limited with the highest

spin speed appropriate for that particular

type of fabric.

CWhen selecting a programme, always

consider the type of fabric, colour,

degree of soiling and permissible water

temperature.

CAlways select the lowest required

temperature. Higher temperature means

higher power consumption.

CFor further programme details, see

"Programme and consumption table"

5.5 Main programmes

Depending on the type of fabric, use the following

main programmes.

• Cottons

Use this programme for your cotton laundry (such

as bed sheets, duvet and pillowcase sets, towels,

bathrobes, underwear, etc.). Your laundry will be

washed with vigorous washing action for a longer

washing cycle.

• Synthetics

Use this programme to wash your synthetic

clothes (shirts, blouses, synthetic/cotton blends,

etc.). It washes with a gentle action and has a

shorter washing cycle compared to the Cottons

programme.

For curtains and tulle, use the Synthetic 40˚C

programme with prewash and anti-creasing

functions selected. As their meshed texture

causes excessive foaming, wash the veils/tulle by

putting little amount of detergent into the main

wash compartment. Do not put detergent in the

prewash compartment.

• Woollens

Use this programme to wash your woolen clothes.

Select the appropriate temperature complying

with the tags of your clothes. Use appropriate

detergents for woolens.

22 / EN Washing Machine /User’s Manual

Operating the product

5.6 Additional programmes

For special cases, additional programmes are

available in the machine.

CAdditional programmes may differ

according to the model of the machine.

• Cottons Eco

You may wash your normally soiled durable cotton

and linen laundry in this programme with the

highest energy and water saving compared to

all other wash programmes suitable for cottons.

Actual water temperature may differ from the

declared cycle temperature. Programme duration

may automatically be shortened during later

stages of the programme if you wash less amount

(e.g. ½ capacity or less) of laundry. In this case

energy and water consumption will be further

decreased giving you the opportunity for a more

economical wash. This feature is available for

certain models having remaining time display.

• Hygiene

Use this programme to wash baby laundry, and

the laundry that belongs to allergic persons.

Longer heating time and an additional rinsing step

provide a higher level of hygiene.

• Hand Wash

Use this programme to wash your woolen/delicate

clothes that bear “not machine- washable” tags

and for which hand wash is recommended. It

washes laundry with a very gentle washing action

to not to damage clothes.

• Fast Full Load

Use this programme to wash your lightly soiled

cotton clothes in a short time.

• Mini 14

Use this programme to wash your little amount of

lightly soiled cotton clothes in a short time.

• Dark Wash

Use this programme to wash your dark coloured

laundry, or the coloured laundry that you do not

want them get faded. Washing is performed with

less mechanical movements at low temperature.

It is recommended to use liquid detergent or wool

shampoo for dark coloured laundry.

• Intensive

You can use this programme for your durable

clothes that you wish to be rinsed gently. In this

programme an extra rinse cycle will be made

compared to the “Cottons” program.

• Lingerie

Use this programme to wash delicates such as

underwears. If there is little amount of laundry,

use a laundry net.

• Refresh

Use this programme to remove the odour on the

laundry that are worn only for once and do not

contain any stains or dirt.

• Cotton 20

Use this programme, which is much more

sensitive to environment and natural resources,

to wash your lightly soiled and unstained cotton

laundry (max. 3.5 kg) in a short time and

economically.

CIt is recommended to use liquid detergent

or gel washing detergent.

• Machine Care

Use this programme regularly (once in every

1-2 months) to clean the drum and provide the

required hygiene. Run the programme without

any laundry in the machine. To obtain better

results, put powder limescale remover for washing

machines into the detergent compartment II.

When the programme is over, leave the loading

door ajar so that the inside of the machine gets

dry.

CThis is not a washing programme. It is a

maintenance programme.

CDo not run the programme when there

is something in the machine. If you try to

do so, the machine detects that there is a

load inside and aborts the programme

Washing Machine /User’s Manual 23 / EN

Operating the product

5.7 Special programmes

For specific applications, select any of the

following programmes.

• Rinse

Use this programme when you want to rinse or

starch separately.

• Spin+Drain

Use this programme to apply an additional spin

cycle for your laundry or to drain the water in the

machine.

Before selecting this programme, select the

desired spin speed and press Start / Pause /

Cancel button. The machine will spin the laundry

with the set spin speed and drain the water

coming out of them.

If you wish to drain only the water without

spinning your laundry, select the Pump+Spin

programme and then select the No Spin function

with the help of Spin Speed Adjustment button.

Press Start / Pause / Cancel button.

CUse a lower spin speed for delicate

laundries.

5.8 Temperature selection

Whenever a new programme is selected,

the maximum temperature for the selected

programme appears on the temperature indicator.

To decrease the temperature, press the

Temperature Adjustment button. Temperature

decreases with increments of 10° and finally, “-”

symbol indicating the cold wash option appears

on the display.

CIf you scroll to cold wash option and

press Temperature Adjustment button

again, the recommended temperature

for the selected programme appears

on the display. Press the Temperature

Adjustment button again to decrease the

temperature.

Economy symbol

Indicates the programmes and temperatures that

provide energy savings.

CEconomy symbol can not be selected in

Intensive and Hygiene programmes since

washing is performed in long times and

at high temperatures in order to provide

hygiene. Similarly, Economy symbol can

not be selected in Baby, Refresh, Drum

Cleaning, Spin and Rinse programmes

as well.

5.9 Spin speed selection

Whenever a new programme is selected, the

recommended spin speed of the selected

programme is displayed on the spin speed

indicator.

To decrease the spin speed, press the Spin

Speed Adjustment button. Spin speed decreases

gradually. Then, depending on the model of the

product, "Rinse Hold" and "No Spin" options

appear on the display. See "Auxiliary function

selection" section for explanations of these

options.

CRinse Hold option is indicated with “

” symbol and No Spin option is indicated

with “ ” symbol.

F2 F4

F1 F3

24 / EN Washing Machine /User’s Manual

Operating the product

5.10 Programme and consumption table

EN 2Auxiliary functions

Programme (°C)

Max. Load (kg)

Water Consumption (l)

Energy Consumption (kWh)

Max. Speed***

Prewash

Shorter Wash

Rinse Plus

Anti-creasing

Rinse Hold

Pet hair removal

Selectable

temperature

range °C

Cottons 90 8 74 2.40 1600 •••••• 90-Cold

Cottons 60 8 72 1.70 1600 •••••• 90-Cold

Cottons 40 8 72 0.95 1600 •••••• 90-Cold

Hygiene 90 8 72 2.10 1600 * •90-30

Cottons Eco 60** 8 54 1.17 1600 •60-Cold

Cottons Eco 60** 4 47 0.84 1600 •60-Cold

Cottons Eco 40** 4 47 0.76 1600 •60-Cold

Cottons Eco 40 8 72 0.77 1600 •60-Cold

Synthetics 60 3 45 1.00 1200 •••••• 60-Cold

Synthetics 40 3 45 0.45 1200 •••••• 60-Cold

Cotton 20 20 3.5 39 0.16 1600 •20

Lingerie 30 1 54 0.24 1200 •30-Cold

Intensive 60 8 72 1.60 1600 * • • 60-40

Mini 14 30 2 35 0.10 1400 • • 30-Cold

Fast Full Load 90 8 55 1.95 1400 • • 90-Cold

Fast Full Load 60 8 55 1.10 1400 • • 90-Cold

Fast Full Load 30 8 65 0.22 1400 • • 90-Cold

Woollens 40 1.5 45 0.30 1200 • • 40-Cold

Hand Wash 30 1 35 0.20 1200 30-Cold

Dark Wash 40 3 82 0.55 1200 * •40-Cold

Machine Care 70 - 95 2.15 800 * 70

Refresh - 2 30 0.03 1200 •-

Washing Machine /User’s Manual 25 / EN

Operating the product

•:Selectable

* : Automatically selected, no cancelling.

** : Energy Label programme (EN 60456 Ed.3)

*** If maximum spin speed of the machine is lower then this value, you can only select up to the maximum spin

speed.

- : See the programme description for maximum load.

** “Cotton eco 40°C and Cotton eco 60°C are standard cycles.” These cycles are known as ‘40°C

cotton standard cycle’ and ‘60°C cotton standard cycle’ and indicated with the symbols

on the panel.

CThe auxiliary functions in the table may vary according to the model of your machine.

CWater and power consumption may vary subject to the changes in water pressure, water hardness

and temperature, ambient temperature, type and amount of laundry, selection of auxiliary functions

and spin speed, and changes in electric voltage.

CYou can see the washing time of the programme you have selected on the display of the machine. It is

normal that small differences may occur between the time shown on the display and the real washing

time.

“Selectability of auxiliary functions might be changed by the manufacturer. New selectabilities might

be added or existing ones might be removed.”

“The spin speed of your machine may vary among the programmes, however this speed cannot

exceed the max. spin speed of your machine.”

26 / EN Washing Machine /User’s Manual

Operating the product

5.11 Auxiliary function selection

Select the desired auxiliary functions before

starting the programme. Furthermore, you may

also select or cancel auxiliary functions that are

suitable to the running programme by pressing

the Start / Pause / Cancel button when the

machine is operating. For this, the machine must

be in a step before the auxiliary function you are

going to select or cancel.

Depending on the programme, press a, b, c or d

buttons to select the desired auxiliary function.

Symbol of the selected auxiliary function appears

on the display.

a b c d

CSome functions cannot be selected

together. If a second auxiliary function

conflicting with the first one is selected

before starting the machine, the function

selected first will be canceled and the

second auxiliary function selection will

remain active. For example, if you want

to select Quick Wash after you have

selected the Prewash, Prewash will be

canceled and Quick Wash will remain

active.

CAn auxiliary function that is not

compatible with the programme cannot

be selected. (See “Programme and

consumption table”)

CAuxiliary Function buttons may vary

according to the model of the machine.

• Prewash

A Prewash is only worthwhile for heavily soiled

laundry. Not using the Prewash will save energy,

water, detergent and time.

F1 appears on the display when you select this

function (a).

• Shorter Wash

This function can be used in Cottons and

Synthetics programmes. It decreases the washing

times and also the number of rinsing steps for

lightly soiled laundry.

F2 appears on the display when you select this

function (b).

CWhen you select this function, load

your machine with half of the maximum

laundry specified in the programme

table.

• Rinse Plus

This function enables the machine to make

another rinsing in addition to the one already

made after the main wash. Thus, the risk for

sensitive skins (babies, allergic skins, etc.) to be

effected by the minimal detergent remnants on

the laundry can be reduced.

F3 appears on the display when you select this

function (c).

• Anti-creasing

This function creases the clothes lesser when they

are being washed. Drum movement is reduced

and spinning speed is limited to prevent creasing.

In addition, washing is done with a higher water

level.

F4 appears on the display when you select this

function (d).

• Rinse Hold

If you are not going to unload your clothes

immediately after the programme completes, you

may use rinse hold function to keep your laundry

in the final rinsing water in order to prevent them

from getting wrinkled when there is no water in

the machine. Press Start / Pause /Cancel button

after this process if you want to drain the water

without spinning your laundry. Programme will

resume and complete after draining the water.

If you want to spin the laundry held in water,

adjust the Spin Speed and press Start / Pause /

Cancel button.

The programme resumes. Water is drained,

laundry is spun and the programme is completed.

Washing Machine /User’s Manual 27 / EN

Operating the product

• Pet hair removal

This function helps to remove pet hair that remain

on your garments more effectively.

When you select this function, Prewash and Extra

Rinse steps are added to the normal programme.

Thus, washing is performed with more water

(30%) and the pet hair is removed more

effectively.

AWARNING: Never wash your pets in the

washing machine.

5.12 Time display

Remaining time to complete the programme

appears on the display while the programme is

running. Tim is displayed as “01:30” in hours and

minutes format.

CProgramme time may differ from

the values in the “Programme and

consumption table” depending on the

water pressure, water hardness and

temperature, ambient temperature,

amount and the type of laundry, auxiliary

functions selected and the changes at the

mains voltage.

Delayed start

With the Delayed Start function the startup

of the programme may be delayed up to 24

hours. Delayed start time can be increased by

increments of 30 minutes.

CDo not use liquid detergents when you

set Delayed Start! There is the risk of

staining of the clothes.

1. Open the loading door, place the laundry and

put detergent, etc.

2. Select the washing programme, temperature,

spin speed and, if required, the auxiliary

functions.

3. Set the desired delayed start time by pressing

the Delayed Start + or - buttons. Delayed Start

symbol flashes.

4. Press Start / Pause / Cancel button. Delayed

start countdown starts. Delayed Start symbol

illuminates steadily. Start symbol appears. “:”

sign in the middle of the delayed start time on

the display starts flashing.

CAdditional laundry may be loaded during

the delayed start period. At the end of

the countdown, Delayed Start symbol

disappears, washing cycle starts and the

time of the selected programme appears

on the display.

Changing the delayed start period

If you want to change the time during countdown:

1. Press Start / Pause / Cancel button. “:” sign

in the middle of the delayed start time on the

display stops flashing. Pause symbol appears.

Delayed Start symbol flashes. Start symbol

disappears.

2. Set the desired delayed start time by pressing

the Delayed Start + or - buttons.

3. Press Start / Pause / Cancel button. Delayed

Start symbol illuminates steadily. Pause symbol

disappears. Start symbol appears.

4. “:” sign in the middle of the delayed start time

on the display starts flashing.

Cancelling the Delayed Start function

If you want to cancel the delayed start countdown

and start the programme immediately:

1. Press Start / Pause / Cancel button. “:” sign

in the middle of the delayed start time on the

display stops flashing.

2. Start symbol disappears. Pause symbol and

Delayed Start symbol flashes.

3. Decrease the delayed start time by pressing

the Delayed Start - button. Programme duration

appears after 30 minutes.

4. Press Start / Pause / Cancel button to start the

programme.

28 / EN Washing Machine /User’s Manual

Operating the product

5.13 Starting the programme

1. Press Start / Pause / Cancel button to start the

programme.

2. Start symbol showing the startup of the

programme will turn on.

3. Loading door is locked and Door Locked symbol

appears on the display.

4. The symbol of the step from which the

programme has started appears on the display

(Prewash, Main Wash, Rinse, Softener and

Spin).

5.14 Progress of programme

Progress of a running programme is indicated on

the display with a set of symbols.

Relevant symbol appears on the display at the

beginning of each programme step and all

symbols remain lit at the end of the programme.

The farthermost right symbol indicates the current

programme step.

Prewash

If the Prewash auxiliary function is selected,

Prewash symbol appears on the display indicating

that the prewash step has started.

Main Wash

Main Wash symbol indicating that the main wash

step has started appears on the display.

Rinse

Rinse symbol indicating that the rinsing step has

started appears on the display.

Softener

Softener symbol indicating that the softener step

has started appears on the display.

Spin

Appears at the beginning of the final spin step

and remains lit during Spin and Pump special

programmes.

CIf the machine does not pass to the

spinning step, Rinse Hold function might

be active or the automatic unbalanced

load detection system might be activated

due to the unbalanced distribution of the

laundry in the machine.

5.15 Loading door lock

There is a locking system on the loading door of

the machine that prevents opening of the door in

cases when the water level is unsuitable.

Door Locked symbol appears when the loading

door is locked. This symbol will flash until the

loading door becomes ready to open when

programme completes or the machine is paused.

Do not force to open the loading door in this step.

Symbol disappears when the door is ready to

open. You can open the door when the symbol

disappears.

5.16 Changing the selections

after programme has started

Switching the machine to pause mode

Press the Start / Pause / Cancel button to switch

the machine to pause mode. Pause symbol

appears on the display indicating that the machine

is paused. Start symbol disappears.

F2 F4

F1 F3

Changing the speed and temperature settings

for auxiliary functions

Depending on the step the programme has

reached, you may cancel or activate the auxiliary

functions; see, "Auxiliary function selection".

You may also change the speed and temperature

settings; see, "Spin speed selection" and

"Temperature selection".

Adding or taking out laundry

1. Press the Start / Pause / Cancel button to

switch the machine to pause mode. The

programme follow-up light of the relevant step

during which the machine was switched into

the pause mode will flash.

2. Wait until the Loading Door can be opened.

3. Open the Loading Door and add or take out the

laundry.

4. Close the Loading Door.

5. Make changes in auxiliary functions,

temperature and speed settings if necessary.

Washing Machine /User’s Manual 29 / EN

Operating the product

6. Press Start / Pause / Cancel button to start the

machine.

CThe loading door will not open if the

water temperature in the machine is

high or the water level is above the door

opening.

5.17 Child Lock

Use Child Lock function to prevent children from

tampering with the machine. Thus you can avoid

any changes in a running programme.

CYou can switch on and off the machine

with On / Off button when the Child

Lock is active. When you switch on the

machine again, programme will resume

from where it has stopped.

To activate the Child Lock:

Press and hold 2nd and 4th Auxiliary Function

buttons for 3 seconds. “Con” appears on the

display.

CSame phrase will appear on the display

if you press any button when Child Lock

is enabled.

To deactivate the Child Lock:

Press and hold 2nd and 4th Auxiliary Function

buttons for 3 seconds. “COFF” appears on the

display.

CDo not forget to disable the child lock

at the end of the programme if it was

enabled before. Otherwise, machine will

not allow to select a new programme.

5.18 Cancelling the programme

Press and hold Start / Pause / Cancel button

for 3 seconds. Start symbol flashes. Symbol of

the step at which the programme was cancelled

remains lit. "End" appears on the display and the

programme is cancelled.

CIf you want to open the loading door after

you have cancelled the programme but it

is not possible to open the loading door

since the water level in the machine is

above the loading door opening, then

turn the Programme Selection knob to

Pump+Spin programme and discharge

the water in the machine.

5.19 Machine is in Rinse Hold mode

Spin symbol flashes and Pause symbol illuminates

when the machine is in Rinse Hold mode.

If you want to spin your laundry when the machine

is in this mode:

Adjust the spin speed and press Start / Pause /

Cancel button. Pause symbol disappears and Start

symbol appears. Programme resumes, discharges

the water and spins the laundry.

If you only want to drain the water without

spinning:

Just press Start / Pause / Cancel button. Pause

symbol disappears. Start symbol appears.

Programme resumes and discharges the water

only.

5.20 End of programme

“End” appears on the display at the end of the

programme. Symbols of the programme steps

remain lit. Auxiliary function, spin speed and

temperature that were selected at the beginning

of the programme remain selected.

30 / EN Washing Machine /User’s Manual

Operating the product

5.21 Your machine is equipped

with a “Standby Mode”

In case of not starting any programme or waiting

without making any other operation when the

machine is turned on by On/Off button and while

it is in selection step or if no other operation is

performed approximately 2 minutes after the

programme you selected has come to an end,

your machine will automatically switch to energy

saving mode. Brightness of indicator lights will

decrease. Also, if your product is equipped with

a display showing the programme duration, this

display will completely turn off. In case of rotating

the Programme Selection knob or pressing any

button, lights and display will restore to their

previous condition. Your selections made while

exiting the energy saving mode may change.

Check the appropriateness of your selections

before starting the programme. Readjust if

necessary. This is not a fault.

Washing Machine /User’s Manual 31 / EN

6 Quick User Guide

6.1 Preparing the machine

1. Make sure that the hoses are connected tightly.

2. Plug in your machine.

3. Turn the tap on completely.

4. Place the laundry in the machine.

5. Add detergent and fabric softener.

6.2 Programme selection

Select the programme suitable for the type,

quantity and soiling degree of the laundry

in accordance with the "Programme and

consumption table" and the temperature table

below.

6.3 Auxiliary function selection

Select the desired auxiliary functions before

starting the programme. Furthermore, you may

also select or cancel auxiliary functions that are

suitable to the running programme by pressing

the Start / Pause / Cancel button when the

machine is operating. For this, the machine must

be in a step before the auxiliary function you are

going to select or cancel.

6.4 Starting the programme

1. Press Start / Pause / Cancel button to start the

programme.

2. Start symbol showing the startup of the

programme will turn on.

3. Loading door is locked and Door Locked symbol

appears on the display.

4. The symbol of the step from which the

programme has started appears on the display

(Prewash, Main Wash, Rinse, Softener and

Spin).

6.5 End of programme

“End” appears on the display at the end of the

programme. Symbols of the programme steps

remain lit. Auxiliary function, spin speed and

temperature that were selected at the beginning

of the programme remain selected.

6.6 Cancelling the programme

Press and hold Start / Pause / Cancel button

for 3 seconds. Start symbol flashes. Symbol of

the step at which the programme was cancelled

remains lit. “End” appears on the display and the

programme is cancelled.

6.7 Child Lock

Use Child Lock function to prevent children from

tampering with the machine. Thus you can avoid

any changes in a running programme.

CYou can switch on and off the machine

with On / Off button when the Child

Lock is active. When you switch on the

machine again, programme will resume

from where it has stopped.

To activate the Child Lock:

Press and hold 2nd and 4th Auxiliary Function

buttons for 3 seconds. “Con” appears on the

display.

CSame phrase will appear on the display

if you press any button when Child Lock

is enabled.

To deactivate the Child Lock:

Press and hold 2nd and 4th Auxiliary Function

buttons for 3 seconds. “COFF” appears on the

display.

CDo not forget to disable the child lock

at the end of the programme if it was

enabled before. Otherwise, machine will

not allow to select a new programme.

32 / EN Washing Machine /User’s Manual

7 Maintenance and cleaning

Service life of the product extends and frequently

faced problems decrease if cleaned at regular

intervals.

7.1 Cleaning the detergent drawer

Clean the detergent drawer at regular intervals

(every 4-5 washing cycles) as shown below

in order to prevent accumulation of powder

detergent in time.

1. Press the dotted point on the siphon in the

softener compartment and pull towards you

until the compartment is removed from the

machine.

CIf more than normal amount of water and

softener mixture starts to gather in the

softener compartment, the siphon must

be cleaned.

2. Wash the detergent drawer and the siphon with

plenty of lukewarm water in a washbasin. Wear

protective gloves or use an appropriate brush

to avoid touching of the residues in the drawer

with your skin when cleaning.

3. Insert the drawer back into its place after

cleaning and make sure that it is seated well.

If your detergent drawer is the one indicated in the

following figure:

CLift the rear part of the siphon to remove

it as illustrated. After performing the

above mentioned cleaning procedures,

replace the siphon back to its seating

and push its front section downwards to

make sure that the locking tab engages.

7.2 Cleaning the loading

door and the drum

Residues of softener, detergent and dirt may

accumulate in your machine in time and may

cause unpleasant odours and washing complaints.

To avoid this, use the Drum Cleaning programme.

If your machine is not featured with Drum

Cleaning programme, use Cottons-90 programme

and select Additional Water or Extra Rinse

auxiliary functions as well. Run theBefore starting

the programme, put max. 100 g of powder

anti-limescale into the main wash detergent

compartment (compartment nr. 2). If the anti-

limescale is in tablet form, put only one tablet into

compartment nr. 2. Dry the inside of the bellow

with a clean piece of cloth after the programme

has come to an end.

CRepeat Drum Cleaning process in every

2 months.

CUse an anti-limescale suitable for the

washing machines.

After every washing make sure that no foreign

substance is left in the drum.

Washing Machine /User’s Manual 33 / EN

Maintenance and cleaning

If the holes on the bellow shown in the figure is

blocked, open the holes using a toothpick.

CForeign metal substances will cause

rust stains in the drum. Clean the stains

on the drum surface by using cleaning

agents for stainless steel. Never use steel

wool or wire wool.

AWARNING: Never use sponge or scrub

materials. These will damage the painted

and plastic surfaces.

7.3 Cleaning the body

and control panel

Wipe the body of the machine with soapy water or

non-corrosive mild gel detergents as necessary,

and dry with a soft cloth.

Use only a soft and damp cloth to clean the

control panel.

7.4 Cleaning the water intake filters

There is a filter at the end of each water intake

valve at the rear of the machine and also at the

end of each water intake hose where they are

connected to the tap. These filters prevent foreign

substances and dirt in the water to enter the

washing machine. Filters should be cleaned as

they do get dirty.

1. Close the taps.

2. Remove the nuts of the water intake hoses to

access the filters on the water intake valves.

Clean them with an appropriate brush. If the

filters are too dirty, take them out by means of

pliers and clean them.

3. Take out the filters on the flat ends of the water

intake hoses together with the gaskets and

clean thoroughly under running water.

4. Replace the gaskets and filters carefully in their

places and tighten the hose nuts by hand.

7.5 Draining remaining water

and cleaning the pump filter

The filter system in your machine prevents solid

items such as buttons, coins and fabric fibers

clogging the pump impeller during discharge of

washing water. Thus, the water will be discharged

without any problem and the service life of the

pump will extend.

If the machine fails to drain water, the pump filter

is clogged. Filter must be cleaned whenever it

is clogged or in every 3 months. Water must be

drained off first to clean the pump filter.

In addition, prior to transporting the machine

(e.g., when moving to another house) and in case

of freezing of the water, water may have to be

drained completely.

AWARNING: Foreign substances left

in the pump filter may damage your

machine or may cause noise problem.

In order to clean the dirty filter and discharge the

water:

1. Unplug the machine to cut off the supply power.

AWARNING: Temperature of the water

inside the machine may rise up to 90 ºC.

To avoid burning risk, filter must be

cleaned after the water in the machine

cools down.

2. Open the filter cap.

If the filter cap is composed of two pieces,

press the tab on the filter cap downwards and

pull the piece out towards yourself.

34 / EN Washing Machine /User’s Manual

Maintenance and cleaning

If the filter cap is one piece, pull the cap from both

sides at the top to open.

CYou can remove the filter cover by slightly

pushing downwards with a thin plastic

tipped tool, through the gap above the

filter cover. Do not use metal tipped tools

to remove the cover.

3. Some of our products have emergency draining

hose and some does not have. Follow the steps

below to discharge the water.

Discharging the water when the product has an

emergency draining hose:

a. Pull the emergency draining hose out from its

seat

b. Place a large container at the end of the hose.

Drain the water into the container by pulling

out the plug at the end of the hose. When the

container is full, block the inlet of the hose

by replacing the plug. After the container is

emptied, repeat the above procedure to drain

the water in the machine completely.

c. When draining of water is finished, close the

end by the plug again and fix the hose in its

place.

d. Turn the pump filter to take it out.

Discharging the water when the product does not

have an emergency draining hose:

a. Place a large container in front of the filter to

catch water from the filter.

b. Loosen pump filter (anticlockwise) until water

starts to flow. Fill the flowing water into the

container you have placed in front of the filter.

Always keep a piece of cloth handy to absorb

any spilled water.

c. When the water inside the machine is finished,

take out the filter completely by turning it.

4. Clean any residues inside the filter as well as

fibers, if any, around the pump impeller region.

5. Install the filter.

6. If the filter cap is composed of two pieces, close

the filter cap by pressing on the tab. If it is one

piece, seat the tabs in the lower part into their

places first, and then press the upper part to

close.

Washing Machine /User’s Manual 35 / EN

8 Troubleshooting

Programme cannot be started or selected.

• Washingmachinehasswitchedtoselfprotectionmodeduetoasupplyproblem(linevoltage,waterpressure,

etc.).>>>Press and hold Start / Pause / Cancel button for 3 seconds to reset the machine to factory settings.

Water in the machine.

• Somewatermighthaveremainedintheproductduetothequalitycontrolprocessesintheproduction.>>>This

is not a failure; water is not harmful to the machine.

There is water leaking from the bottom of the washing machine.

• Likelyproblemswithhosesorthepumpfilter.>>>Be sure the seals of the water inlet hoses are securely fitted.

Attach the hose to the tap tightly.

• Pumpfiltermightnotbeclosedfully.>>>Make sure that the pump filter is completely closed.

Machine does not fill with water.

• Tapisturnedoff.>>>Open the inlet water taps fully.

• Waterinlethoseisbent.>>>Flatten the water inlet hose.

• Waterinletfilterisclogged.>>>Clean the water inlet filter.

• Theloadingdoorisajar.>>>Close the Loading Door.

Machine does not drain water.

• Waterdrainhosemightbecloggedortwisted.>>>Clean or flatten the hose.

• Pumpfilterisclogged.>>>Clean the pump filter.

Machine vibrates or makes noise.

• Machinemightbestandingunbalanced.>>>Adjust the feet to level the machine.

• Ahardsubstancemighthaveenteredintothepumpfilter.>>>Clean the pump filter.

• Transportationsafetyboltsarenotremoved.>>>Remove the transportation safety bolts.

• Laundryquantityinthemachinemightbetoolittle.>>>Add more laundry to the machine.

• Machinemightbeoverloadedwithlaundry.>>>Take out some of the laundry from the machine or distribute the

load by hand to balance it homogenously in the machine.

• Machinemightbeleaningonarigiditem.>>>Make sure that the machine is not leaning on anything.

Machine stopped shortly after the programme started.

• Machinemighthavestoppedtemporarilyduetolowvoltage.>>>It will resume running when the voltage

restores to the normal level.

Machine directly discharges the water it takes in.

• Draininghosemightnotbeatadequateheight.>>>Connect the water draining hose as described in the

operation manual.

No water can be seen in the machine during washing.

• Thewaterlevelisnotvisiblefromoutsideofthewashingmachine.Thisisnotafailure.

Loading door cannot be opened.

• Doorlockisactivatedbecauseofthewaterlevelinthemachine.>>>Drain the water by running the Pump or

Spin programme.

• Machineisheatingupthewateroritisatthespinningcycle.>>>Wait until the programme completes.

• Childlockisengaged.Doorlockwillbedeactivatedacoupleofminutesaftertheprogrammehascometoan

end.>>>Wait for a couple of minutes for deactivation of the door lock.

36 / EN Washing Machine /User’s Manual

Troubleshooting

Washing takes longer time than specified in the manual.(*)

• Waterpressureislow.>>>Machine waits until taking in adequate amount of water to prevent poor washing

quality due to the decreased amount of water. Therefore, the washing time extends.

• Voltagemightbelow.>>>Washing time is prolonged to avoid poor washing results when the supply voltage is

low.

• Inputtemperatureofwatermightbelow.>>>Required time to heat up the water extends in cold seasons. Also,

washing time can be lengthened to avoid poor washing results.

• Numberofrinsesand/oramountofrinsewatermighthaveincreased.>>>Machine increases the amount of

rinse water when good rinsing is needed and adds an extra rinsing step if necessary.

• Excessivefoammighthaveoccurredandautomaticfoamabsorptionsystemmighthavebeenactivateddueto

toomuchdetergentusage.>>>Use recommended amount of detergent.

Programme time does not countdown. (On models with display)(*)

• Timermaystopduringwaterintake.>>>Timer indicator will not countdown until the machine takes in adequate

amount of water. The machine will wait until there is sufficient amount of water to avoid poor washing results due

to lack of water. Timer indicator will resume countdown after this.

• Timermaystopduringheatingstep.>>>Timer indicator will not countdown until the machine reaches the

selected temperature.

• Timermaystopduringspinningstep.>>>Automatic unbalanced load detection system might be activated due

to the unbalanced distribution of the laundry in the drum.

Programme time does not countdown.(*)

• Theremightbeanimbalanceoflaundryinthemachine.>>>Automatic unbalanced load detection system

might be activated due to the unbalanced distribution of the laundry in the drum.

Machine does not switch to spinning step.(*)

• Theremightbeanimbalanceoflaundryinthemachine.>>>Automatic unbalanced load detection system

might be activated due to the unbalanced distribution of the laundry in the drum.

• Themachinewillnotspinifwaterisnotdrainedcompletely.>>>Check the filter and the draining hose.

• Excessivefoammighthaveoccurredandautomaticfoamabsorptionsystemmighthavebeenactivateddueto

toomuchdetergentusage.>>>Use recommended amount of detergent.

Washing performance is poor: Laundry turns gray.(**)

• Insufficientamountofdetergentwasusedoveralongperiodoftime.>>>Use the recommended amount of

detergent appropriate for water hardness and the laundry.

• Washingwasmadeatlowtemperaturesforalongtimeoveralongperiodoftime.>>>Select the proper

temperature for the laundry to be washed.

• Insufficientamountofdetergentisusedwithhardwaters.>>>Using insufficient amount of detergent with

hard water causes the soil to stick on the cloth and this turns the cloth into gray in time. It is difficult to eliminate

graying once it happens. Use the recommended amount of detergent appropriate for water hardness and the

laundry.

• Toomuchdetergentisused.>>>Use the recommended amount of detergent appropriate for water hardness

and the laundry.

Washing Machine /User’s Manual 37 / EN

Troubleshooting

Washing performance is poor: Stains persist or the laundry is not whitened.(**)

• Insufficientamountofdetergentisused.>>>Use recommended amount of detergent appropriate for the

laundry.

• Excessivelaundrywasloadedin.>>>Do not load the machine in excess. Load with amounts recommended in

the "Programme and consumption table".

• Wrongprogrammeandtemperaturewereselected.>>>Select the proper programme and temperature for the

laundry to be washed.

• Wrongtypeofdetergentisused.>>>Use original detergent appropriate for the machine.

• Detergentisputinthewrongcompartment.>>>Put the detergent in the correct compartment. Do not mix the

bleaching agent and the detergent with each other.

Washing performance is poor: Oily stains appeared on the laundry.

• Regulardrumcleaningisnotapplied.>>>Clean the drum regularly. For this, please see 7.2.

Washing performance is poor: Clothes smell unpleasantly.(**)

• Odoursandbacterialayersareformedonthedrumasaresultofcontinuouswashingatlowertemperaturesand/

orinshortprogrammes.>>>Leave the detergent drawer as well as the loading door of the machine ajar after

each washing. Thus, a humid environment favorable for bacteria cannot occur in the machine.

Colour of the clothes faded.(**)

• Excessivelaundrywasloadedin.>>>Do not load the machine in excess.

• Detergentinuseisdamp.>>>Keep detergents closed in an environment free of humidity and do not expose

them to excessive temperatures.

• Ahighertemperatureisselected.>>>Select the proper programme and temperature according to the type and

soiling degree of the laundry.

It does not rinse well.

• Theamount,brandandstorageconditionsofthedetergentusedareinappropriate.>>>Use a detergent

appropriate for the washing machine and your laundry. Keep detergents closed in an environment free of

humidity and do not expose them to excessive temperatures.

• Detergentisputinthewrongcompartment.>>>If detergent is put in the prewash compartment although

prewash cycle is not selected, machine can take this detergent during rinsing or softener step. Put the detergent

in the correct compartment.

• Pumpfilterisclogged.>>>Check the filter.

• Drainhoseisfolded.>>>Check the drain hose.

Laundry became stiff after washing.(**)

• Insufficientamountofdetergentisused.>>>Using insufficient amount of detergent for the water hardness can

cause the laundry to become stiff in time. Use appropriate amount of detergent according to the water hardness.

• Detergentisputinthewrongcompartment.>>>If detergent is put in the prewash compartment although

prewash cycle is not selected, machine can take this detergent during rinsing or softener step. Put the detergent

in the correct compartment.

• Detergentmightbemixedwiththesoftener.>>>Do not mix the softener with detergent. Wash and clean the

dispenser with hot water.

Laundry does not smell like the softener.(**)

• Detergentisputinthewrongcompartment.>>>If detergent is put in the prewash compartment although

prewash cycle is not selected, machine can take this detergent during rinsing or softener step. Wash and clean

the dispenser with hot water. Put the detergent in the correct compartment.

• Detergentmightbemixedwiththesoftener.>>>Do not mix the softener with detergent. Wash and clean the

dispenser with hot water.

38 / EN Washing Machine /User’s Manual

Troubleshooting

Detergent residue in the detergent drawer.(**)

• Detergentisputinwetdrawer.>>>Dry the detergent drawer before putting in detergent.

• Detergenthasgottendamp.>>>Keep detergents closed in an environment free of humidity and do not expose

them to excessive temperatures.

• Waterpressureislow.>>>Check the water pressure.

• Thedetergentinthemainwashcompartmentgotwetwhiletakingintheprewashwater.Holesofthedetergent

compartmentareblocked.>>>Check the holes and clean if they are clogged.

• Thereisaproblemwiththedetergentdrawervalves.>>>Call the Authorized Service Agent.

• Detergentmightbemixedwiththesoftener.>>>Do not mix the softener with detergent. Wash and clean the

dispenser with hot water.

There is detergent left on the laundry. (**)

• Excessivelaundrywasloadedin.>>>Do not load the machine in excess.

• Wrongprogrammeandtemperaturewereselected.>>>Select the proper programme and temperature for the

laundry to be washed.

• Wrongdetergentwasused.>>>Select the proper detergent for the laundry to be washed.

Too much foam forms in the machine.(**)

• Improperdetergentsforthewashingmachinearebeingused.>>>Use detergents appropriate for the washing

machine.

• Excessiveamountofdetergentisused.>>>Use only sufficient amount of detergent.

• Detergentwasstoredunderimproperconditions.>>>Store detergent in a closed and dry location. Do not store

in excessively hot places.

• Somemeshedlaundrysuchastullemayfoamtoomuchbecauseoftheirtexture.>>>Use smaller amounts of

detergent for this type of item.

• Detergentisputinthewrongcompartment.>>>Put the detergent in the correct compartment.

• Softenerisbeingtakenearly.>>>There may be problem in the valves or in the detergent dispenser. Call the

Authorized Service Agent.

Foam is overflowing from the detergent drawer.

• Toomuchdetergentisused.>>>Mix 1 tablespoonful softener and ½ l water and pour into the main wash

compartment of the detergent drawer.

• Putdetergentintothemachinesuitablefortheprogrammesandmaximumloadsindicatedinthe“Programme

and consumption table”. When you use additional chemicals (stain removers, bleachs and etc), reduce the

amount of detergent.

Laundry remains wet at the end of the programme (*)

• Excessivefoammighthaveoccurredandautomaticfoamabsorptionsystemmighthavebeenactivateddueto

toomuchdetergentusage.>>>Use recommended amount of detergent.

* Machine does not switch to spinning step when the laundry is not evenly distributed in the drum

to prevent any damage to the machine and to its surrounding environment. Laundry should be

rearranged and re-spun.

** Regulardrumcleaningisnotapplied.>>>Cleanthedrumregularly.Forthis,pleasesee7.2.

Washing Machine /User’s Manual 39 / EN

Troubleshooting

AWARNING: If you cannot eliminate the problem although you follow the instructions in this section,

consult your dealer or the Authorized Service Agent. Never try to repair a nonfunctional product

yourself.

Machine does not start. Nothing appears on the display.

Machinemaybeunplugged.>>>Check the plug and attach it to the socket.

Fusemaybedefective.>>>Check the fuse and have it replaced by a qualified electrician if necessary.

Powermaybeout.>>>Check if there is any power outage.

On/Offbuttonmightnotbepressed.>>>Press On / Off button.

Machine does not start when Start / Pause / Cancel button is pressed after selecting the programme.

Loadingdoormaybeopen.>>>Close the loading door.

Rinse symbol flashes in the display. (No Water symbol may also be lit depending on the model of your

machine).

Watermaybecutoff.>>>Make sure that the water is not cut off and press Start / Pause / Cancel button

again to start your machine.

40 / EN Washing Machine /User’s Manual

PRODUCT FICHE

Complying Commission Delegated Regulation (EU) No 1061/201

Supplier name or trademark Blomberg

Model name WNF8441AE20

Rated capacity (kg) 8

Energy efficiency class (1) A++

Annual Energy Consumption (kWh) (2) 218

Energy consumption of the standard 60°C cotton programme at full load (kWh) 1.170

Energy consumption of the standard 60°C cotton programme at partial load (kWh) 0.844

Energy consumption of the standard 40°C cotton programme at partial load (kWh) 0.763

Power consumption in ‘off-mode’ (W) 0.200

Power consumption in ‘left-on mode’ (W) 1.000

Annual Water Consumption (l) (3) 11000

Spin-drying efficiency class (4) B

Maximum spin speed (rpm) 1400

Remaining moisture Content (%) 53

Standard cotton programme (5) Cotton Eco 60°C and 40°C

Programme time of the standard 60°C cotton programme at full load (min) 184

Programme time of the standard 60°C cotton programme at partial load (min) 145

Programme time of the standard 40°C cotton programme at partial load (min) 133

Duration of the left-on mode (min) N/A

Built-in No

(1) Scale from A+++ (Highest Efficiency) to D (Lowest Efficiency)

(2) Energy Consumption based on 220 standard washing cycles for cotton programmes at 60°C and 40°C at full and partial

load, and the consumption of the low-power modes. Actual energy consumption will depend on how the appliance is used.

(3) Water consumption based on 220 standard washing cycles for cotton programmes at 60°C and 40°C at full and partial load.

Actual water consumption will depend on how the appliance is used.

(4)Scale from A (Highest Efficiency) to G (Lowest Efficiency)

(5) “Standard 60°C cotton programme” and the “standard 40°C cotton programme” are the standard washing programmes

to which the information in the label and the fiche relates and these programmes are suitable to clean normally soiled cotton

laundry and that they are the most efficient programmes in terms of combined energy and water consumption.
