Boompods AQUAPOD Waterproof Bluetooth Speaker User Manual
Boompods (HK) LTD. Waterproof Bluetooth Speaker
Boompods >
User Manual
Dongguan Linyar Tech Co., Ltd
Address: Xingye NO.6 Road, Xiabian Industrial Zone, Chang'an Town, Dongguan City, China
Tel: +86 769 81609935 Fax: +86 769 81609936 www.linyartech.com
Specification Sheet
Model #˖
˖
aquapod
Name
˖
Waterproof Bluetooth Speaker
Version
˖
V1.0
Made
˖
Wan.Z Check
˖
APRV
˖
Jay.Z
Date
˖
15/Apr/25 Date
˖
Date
˖
14/Apr/27
Pl
ease check this spec sheet carefully and confirm one of the below options:
This product is qualified , we approve this spec:
□ APPROVE
This product is un
-qualified, we reject this spec:
□ REJECT
Company name with seal
˖
Dongguan Linyar Tech Co., Ltd
Address: Xingye NO.6 Road, Xiabian Industrial Zone, Chang'an Town, Dongguan City, China
Tel: +86 769 81609935 Fax: +86 769 81609936 www.linyartech.com
Spec sheet of Waterproof Bluetooth Speaker aquapod
A. Brief Introduction
aquapod is a newly designed waterproof Bluetooth Speaker for almost everywhere( swiming, shower,
outdoor and biking.....), it is a waterproof, shakeproof, dropproof speaker.
aquapod has built-in CSR Bluetooth chipset, it integrates the Bluetooth 4.0 function for a ultrahigh data
transmission rate and distance (more than 10 meters); the built-in lithium polymer battery provides more
than 4 hours’ working time; the speaker uses ABS material as the main structure to make itself stable, and
with soft rubber finishing to assure comfortable feeling: all buttons designed in rubber with LED lights to
show an easy way while operating˗built-in high sensitive microphone for a clear talking.
aquapod brings a high quality music life, free your hands and let you enjoy the wireless communication
everywhere.
B. Outlook Structure
Main materials: ABS /silicon/ mess
Item size: 85*85*45mm˄L*W*H˅
Dongguan Linyar Tech Co., Ltd
Address: Xingye NO.6 Road, Xiabian Industrial Zone, Chang'an Town, Dongguan City, China
Tel: +86 769 81609935 Fax: +86 769 81609936 www.linyartech.com
C Electrical Features
Bluetooth Version Bluetooth 4.0
Bluetooth Name aquapod
Standby Current ≤ 200μA
Working Current ≤ 20mA (minimum volume)
Working Voltage DC 2.7-4.2 V
Charging Current DC 5V 300mA (red LED lights)
Speaker Unit IPX7 waterproof driver unit
φ45 4Ω 3.5W (max) 100-18000Hz
Microphone sensitivity: -48
f3dB;omni-directional; S.N.R≥60dB
Battery 550mAH 3.7V lithium polymer battery
Battery Life ≥ 500 times (then the capacity goes down non-linearly)
Charging Time 2H ˄fully charge˅
Standby Time ≥ 2000H
Working Time ≥ 4.5 H˄in iphone 70% volume˅
Working Distance ≥ 10M ˄in the open air˅
Working frequency *+=
Waterproof rank IPX 7 (no harmful effects by drop into the water)
S/N ≥70db
Distortion ≤1%
D Bluetoth spec
Bluetooth Profiles:
Bluetooth v4.0 specification support
HFP v1.6
HSP v1.2
A2DP v1.2
AVRCP v1.4
DI v1.3
D Operating
Button Definition˖
˖
Multi-button power on/ power off/ activate siri(IOS system) or voice
control(androd system).
Phone call button phone answer/ phone hung up/ re-dial last call
Next button/Volume up volume up /next music
Previous button/Volume down volume down/previous music
2.402-2.480 GHZ
Dongguan Linyar Tech Co., Ltd
Address: Xingye NO.6 Road, Xiabian Industrial Zone, Chang'an Town, Dongguan City, China
Tel: +86 769 81609935 Fax: +86 769 81609936 www.linyartech.com
Operation˖
First please activate your mobile phone Bluetooth function, and enter the searching mode.
Power on˖ press button for 2 seconds, the speaker will power on, you’ll hear the
“power on” voice prompt.
Activate Bluetooth pairing˖ The speaker will enter pairing mode automatically if there is no paired
device could connect. If there is a phone was connected you also could
enter pairing mode by press and hold for 2 seconds.
Power off: press button for 3 seconds, the speaker will power off, you’ll hear
the “aquadpod power off” voice prompt.
Select music˖ please press and hold button for 1second to select next music; please
press and hold button for 1second to select previous music.
Select volume: press on button to turn the volume up; and press button to turn
the volume down
Phone answer/hang up: when phone call comes, please press button to answer the call; when
phone call ended, please press button again to hang up the call;
please note when phone call comes, continuously press on button 3
seconds will reject the call.
Active siri or voice control: double press the button to active siri on IOS system or voice control
on androd system.
Last call re-dial: please double press the button to re-dial last phone call
Line in function: please us the attached cable to connect the music device and the speaker.
Charging˖ please use the attached USB cable to charge by computer USB port or
other output 5V chargers.
E Reliability Test and Certificates
Reliability testing:
Environmental
testing
Heat resisting
Put in +60
ć
environment for 2 hours, then check if the main body deform
or drop off, check if it can work normally
Cold resisting
Put in -20
ć
environment for 2 hours, then check if the main body deform
or drop off, check if it can work normally
Dongguan Linyar Tech Co., Ltd
Address: Xingye NO.6 Road, Xiabian Industrial Zone, Chang'an Town, Dongguan City, China
Tel: +86 769 81609935 Fax: +86 769 81609936 www.linyartech.com
IPX 7 waterproof test: PASS
CE certificate: PASS
ROHS Testing: PASS
F Notes
Please use the speaker in appropriate condition (-20ć to +50ć)
Please don’t drop the speaker from high .
Please charge the battery if:
˄1˅speaker power off automatically in many times
Please do not disassemble the headphone.
G Accessories, Packages, and Photos
Accessories:
Details:
Different colors
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-- Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
