Booyue Daily Necessities M7 alilo programming toys for children early education User Manual rev01
Shenzhen Booyue Daily Necessities Company Limited alilo programming toys for children early education rev01
User Manual-rev01
Click into the “Voice Control”
Press and hold the recorder key then say your command to your device
The content box on the right of the interface will show your command in text.
The alilo Explorer will follow your command.
Click to back to home page
Click for instruction of current mode
Click into the “Remote Control”
Drag the on the right of the interface to adjust the relative position
between robot and user
Drag the on the left of the interface to control the walking path of alilo Explorer
Click to back to home page
Click for instruction of current mode
Click to adjust speed
Click for different voice prompts and face expression
14.Advanced-1
12.Intermediate-4 13.Intermediate-5
15.Advanced-2
16.Advanced-3 17.Advanced-4
01.Beginner-1
09.Intermediate-1
02.Beginner-2
03.Beginner-3 04.Beginner-4
05.Beginner-5 06.Beginner-6
07.Beginner-7
08.Beginner-8
10.Intermediate-2 11.Intermediate-3
User Notice
1
FAQ
There may be out of battery, you can recharge it and start it up
When charging , check and see if the indicator on work,otherwise please
try to replace the line or adapter
Check and if the charging interface is abnormal, if any damage,it needed
to be repaired
2
User Manual
M7
USB Charge Cable
25*Programming Puzzles
The alilo programming robot is a high-tech product based on the concept
of STEAM education. Through research education and entertainment,
we cultivate children's scientific literacy centered on “solving problems,
logical thinking, critical thinking and creativity”.
3 4
Product Specification
Charging
Switch button(holding)
Game mode(short press)
Delete step
(short press )
Timing Switch
button(holding)
Volume up
(short press)
Forward
(short press)
Previous(short press)
Left turn(short press)
FM switch(short press)
Child lock(holding)
Next(short press)
Right turn(short press)
Play/pause(short press)
Start/pause(short press)
Volume down(short press)
Backward(short press)
1.Can’t power on
2.Can’t be recharged
Click into the “Path”
Drag the on the right of the interface to adjust the relative position
between robot and user
The indicate the walking direction of alilo Explorer. Just draw the path!
Click to make alilo Explorer execute the path. Click to delete the
route and start over.
Click to back to home page
Click for instruction of current mode
Click to adjust speed
Click for different voice prompts and face expression
3.Path
90x130mm(装订本）
Card Card Name Card Explanation
Start
Finish
Forward
Right Turn
Left Turn
River
Boat
Candy
Ice Cream
Direction Choice
Music
The route begins and the alilo
Explorer goes one step forward.
*Note: ①Please place the alilo
Explorer according to the
corresponding direction of the
graphic
②This start card is the start point of
all the route, please make sure every
programmed routes begin from it
Stop move, route ends
Go one step forward along
current direction
Turn 90 degrees in a clockwise
direction, then move one step
forward after turning.
Turn 90 degrees in
a counter-clockwise direction, then
move one step forward after turning.
This product can only be used under the adults guardian.
If the shell of this product damaged , please stop using it immediately.
This product is strictly prohibited from exposure to direct sunlight or in
extreme high temperatures.
This product and its accessories can not be soaked in water or other liquid
Please check the USB line regularly. If there is any damaged, please
replace it in time.
The toy can't connect with the charger over 5V (recommended power
adapter specification: 5V 1A).
Rechargeable battery can not be disassembled and replaced.
Warm Tips
*Please read this instruction carefully before using,
so that it can be installed and used quickly.
*If anything change of the configuration,
please take physical product as prevail
Product
Introduction
Packing list
Product
Structure
Button Description
The switch button light would be red when charging and then
turn green once it full
It takes 2.5 hours for full charged and can be used continuously
for 4 hours at medium volume after fully charged
Charging tips: It is recommended to charge in the off state
Operation
Instruction
Button Programming
1.Long press the power button to boot
2.Automatically enter the game mode
3.Press the 4 arrow keys for personalized path programming
4.Press to perform the path
APP Programming
Activate the Bluetooth on your device (Apple or Android smart phone
or tablet). Open the app and turn on the alilo Explorer. Put you device
close to alilo Explorer and click to connect it to the alilo Explorer.
*The suggested distance for control alilo Explorer is within 10 meters
There 4 programming modes include “Remote Control”, “Voice
Control”, “Path” and “Blockly”
1.Remote Control
2.Voice Control
Click into the “Blockly”
Select instructions from“Motion”, ”Expression”, “Sound ”, “Logic” and
“Loop”. Put these instruction pieces in your own order and get your
personalized path and program
Click to perform the path and program
For deleting instructions, just press and drag instructions into
Click to save the path and program to .Easy to view next time
Click to check/copy/delete the saved program
Click to create new program
4.Blockly
Scene Programming Card Introduction
*NOTE: To run alilo Explorer on scene programming,
please keep alilo Explorer stay on the cards
Voice prompt "Get a boat; it can be
used to cross a river!" and go one
step further.
When alilo Explorer walk on the
river card,
A. has alresdy gotten the boat - go
one step forward and voice prompt:
"Let's paddle to across the river"
B. hasn't gotten the boat yet - stop
move and voice prompt:"There is
a river in front,you must get a boat to
cross the river,please reedit the route
for turesure or get a boat first"
Voice prompt "get candy" and
go one step further.
Voice prompt "get ice cream"
and go one step further.
When alilo Explorer walk on the
direction choice card, if it
A. got the candy - voice prompt:"get
candy and turning left" and turn 90
degrees in a counter-clockwise
direction, then move one step
forward after turning.
B. got the ice cream - voice prompt:
"get ice cream and turning right" and
turn 90 degrees in a clockwise
direction, then move one step
forward after turning.
C. got both candy and ice
cream - voice prompt:"get candy ice
cream and go straight"
D. got neither of candy and ice
cream - stop move and voice
prompt: "Wrong!Wrong!try it again!"
Sing and dance on the card. Go one
step forward after singing and
dancing
*Note: Different cards come with
different songs and dances
Reference
Sweetie, try to add your inspiration to the puzzle cards placement.
You'll have more fun! Come on and create your world!
Local Audio Playback
1.Long press the power button to boot
2.Short press for audio mode and switch audio
VE-1.1
⸺ alilo Explorer ⸺
Alilo
Intelligent Programming Robot
Item No.M7
Manual
FCC ID User
Manual Warning
5 2
Product Size: 135*125*75mm
Battery: 1200mAh polymer battery
Speaker: 4R 3W Φ31mm
USB Port: Micro
Operation Environment: -5°C~40°C
Edutainment for Children
How to get the APP:
1.Search “alilo explorer” on App Store or Google play
2.Find , download and install it
Warning: Changes or modifications to this unit not
expressly approved by the party responsible for
compliance could void the user’s authority to operate the
equipment.
NOTE: This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception,
which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
receiver.
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician
for help.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions :
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
The device must not be co-located or operating in
conjunction with any other antenna or transmitter.
This appliance should not be put into the domestic garbage at the end of its useful life, but must be
disposed of at a centralpoint for recycling of electric and electronic domestic appliances. This symbol
on appliance, instruction manual and packaging puts your attention to this important issue. The
materials used in this appliance can be recycled. By recycling used domestic appliances you
contribute an important push to the protection of our environment. Ask your local authorities for
information regarding the point of recollection.
Guidelines for protection of the environment
The symbol indicates DC voltage .
WARING
HAZARDOUS MOVING PAPTS
KEEP FIMGERS AND OTHER BODY PARTS AWAY
To maintain compliance with the FCC’s RF exposure
guidelines, place the product at least 20cm from
nearby persons
FCC RF Radiation Exposure Statement Caution:
