Bosch Plena Public Address Easy Line
Application Note: Retail
Superb sound & speech reproduction
Straight-out-of-box functionality
Future-ready expandability
Easy-to-use: no training required
Stylish European design
Retail environments
Retail locations differ from place to place. Some are
extremely busy. Others offer a special atmosphere.
Whichever way, the Bosch Plena Public Address Easy
Line provides quality background music and clear voice
announcements for all types of retail environments like
chain stores, boutiques or supermarkets.
Plena Public Address Easy Line features 10 flexible
inputs and multi-zone control for different music options
and professional-level amplification. It is easy to install
and equally easy to customize and expand. With smart
equalizing, clear source labels and recommended setting
indicators, staff members are certain to use the system
correctly.
2
Smart sound solutions
For one-zone locations, retailers want a simple solution:
a Plena Mixer Amplifier. It provides quality background
music as well as occasional voice announcements.
With 3 music inputs, sales staff will be able to choose
from several sound sources such as a classic CD player,
an MP3 player or even a PC with a digital music library.
Besides the ‘smart’ equalizer, the recommended setting
indicators prevent the volume and sound balance to be
set too high or too low. Clear source labeling helps staff
easily select the preferred source.
Typical retail requirements
1 or 2 zones
High quality music reproduction
Clear voice announcements
Simple operation for staff
Ready for audio-visual solutions
1
2
2
3
5
6
4
3
3
Easy announcements with priority functionality
With automatic volume override, the Plena Mixer
Amplifier can handle various public address
requirements. A Plena call station can be placed next
to the check-out counter for in-store announcements.
Another Plena call station could be placed in the
warehouse or storage area for better staff
communication. With this set-up, the two call stations
would be connected directly to the Plena mixer
amplifier. Bosch Ceiling Loudspeakers or cabinets are
connected to the 100 V (70 V US version) outputs of
the Plena Mixer Amplifier to distribute quality sound
throughout the retail location.
Video capabilities
The Plena Public Address range lets retailers install a
permanent or temporary LCD screen to play the latest
commercials while corresponding music is played on
the sound system.
Easy Automation
Standard announcements such as closing times can
be automated by connecting a Bosch Message Manager
to the mixer amplifier with a loop-through connection.
A Bosch Weekly Timer can be connected to trigger
scheduled events, and complete energy-saving actions,
such as turning off lights.
1 Entrance
2 Counters
Plena 1-zone callstations
3 Shop
4 Plena system
Mixer Amplifier PLE 1MA60
BGM source
5 Video Screen
6 Storage
other Bosch Public Address
products
Modular ceiling loudspeakers
4
Bosch Security Systems
To learn more about our
product offering, please visit
www.boschsecurity.com
or send an e-mail to
emea.securitysystems@bosch.com
© Bosch Security Systems, 2008
Printed in The Netherlands
Modifications reserved
PA-EH-en-06_F01U519331_01
Future-ready expandability
The Bosch Plena Public Address Easy Line can be easily
expanded with additional two-zone mixer amplifiers,
amplifiers, two-zone mixers, call stations, loudspeakers,
and other additional equipment, such as Plena wall
panels for remote control.
Practical. Versatile. Flexible.
Bosch designed this system as a multi-functional
concept with clean-cut European design. Good looks
aside, Plena Easy Line is built to last without overlooking
user-friendly functionality, sound quality and excellent
speech intelligibility.
For more information about the Plena Easy Line Range,
Plena Public Address Solutions and Plena Voice Alarm
products, please feel free to contact your nearest
Bosch representative or visit our website:
www.boschsecurity.com.
