Communications Systems | PRS‑16MCI Multichannel Interface
PRS‑16MCI Multichannel Interface
www.boschsecurity.com
uInterface to Praesideo basic amplifiers
uUp to 16 audio channels
uRedundant fiber optic network connection
uControl input and output connections
uComplete supervision
The PRS-16MCI is part of the Praesideo network and
acts as an interface to the Praesideo basic amplifiers
that do not provide network connectivity. The unit is
intended for public address and emergency sound
systems. The multichannel interface provides 16
configurable output channels (14 main outputs and
two spare outputs). It provides the audio signals to
the basic amplifiers and has full control over the
amplifiers. It supervises itself and the connected basic
amplifiers, and reports fault events to the Praesideo
network controller.
The unit should be mounted in a 19"-rack with the
included mounting brackets.
Functions
This unit is the interface between the Praesideo
network and the Praesideo basic amplifiers. It can get
its power from the amplifiers it is connected to, or
from the network. It has 16 audio channels for up to
14 main amplifiers (zones) and two spare amplifiers.
These can be assigned from a non-mixing matrix of 28
Praesideo channels. There are connections for 32
control inputs and 16 control outputs.
The interface provides supervision for the unit itself,
as well as all connected basic amplifiers. The interface
monitors the functions of the amplifiers, and can
activate a spare amplifier to replace one that reports a
fault. It has loop-through in and outputs, supporting
failsafe mode, which pass emergency calls through,
even if the unit itself fails. A controller for multiple-line
and loudspeaker supervision is a standard component.
The interface can be configured for redundant group
A/B switching, or for class-A loop wiring of the
connected basic amplifiers. All configuration is done
with software over the network.
Controls and indicators
• 16 two-color LEDs for amplifier channel status
• Two-color LED for network status
Interconnection
• Two system network connectors
• 32 RJ45 jacks for basic amplifiers
• Female XLR-3 connector for failsafe audio loop-
through input
• Male XLR-3 connector for failsafe audio loop-through
and supervision
• 32 control inputs on removable Euro-style screw
terminals
• 16 control outputs on removable Euro-style screw
terminals
Certifications and approvals
Safety acc. to IEC 60065 / EN 60065
Immunity acc. to EN 55103‑2 / EN 50130‑4 /
EN 50121‑4
Emissions acc. to EN 55103-1 / FCC-47 part 15B
Emergency acc. to EN 60849 / EN 54‑16 /
ISO 7240‑16
Maritime acc. to IEC 60945
Region Certification
Europe CPR EU_CPR
CE
CE DOP
GL
Poland CNBOP
Parts included
Quantit
y
Component
1PRS-16MCI Multichannel Interface
1 Set of mounting brackets for 19” rack
1 Set of connectors
Technical specifications
Electrical
Power consumption 12 W (DC)
Performance
Frequency response 20 Hz to 20 kHz (-3 dB)
Total harmonic
distortion
<0.1% (1 kHz)
Cross talk <-80 dB (1 kHz)
S/N >85 dB (without pilot tone)
Line input 1 x
Connector XLR bypass
Line output 1 x
Connector XLR loop-through
Line output 16 x
Connectors RJ45 jack (in pairs)
0 dBV (symmetrical)
Control inputs 32 x
Connectors Removable screw terminals
Operation Closing contact (with supervision)
Control outputs 16 x
Connectors Removable screw terminals
Operation Change over contact (SPDT)
voltage free relay
Rating 24 V, 1 A
Mechanical
Dimensions (H x W x D)
rack with brackets
88 x 483 x 400 mm
(3.5 x 19 x 15.7 in)
in front of brackets 40 mm (1.6 in)
behind brackets 360 mm (14.2 in)
Weight 7 kg (15.4 lb)
Mounting 19” rack
Color Charcoal with silver
Environmental
Operating temperature -5 ºC to +55 ºC (+23 ºF to +131 ºF)
Storage temperature -40 ºC to +70 ºC (-40 ºF to +158 ºF)
Humidity 15% to 90%
Air pressure 600 to 1100 hPa
Ordering information
PRS‑16MCI Multichannel Interface
Interface to Praesideo network, provides 16 audio
outputs with control and supervision to non-network
connected basic amplifiers, powered from the
Praesideo network or the connected amplifiers, rack
unit 2 RU.
Order number PRS-16MCI
