Security Systems
From Nuremberg
ST-VS/MKP1 Product Management 20.10.2016
1
BOSCH and the symbol are registered trademarks of Robert Bosch GmbH, Germany
Release Letter
Products:
H.264 Firmware for
CPP3 cameras and encoders
Version: 5.73.0052
This letter contains latest information about the above mentioned firmware version.
1 General
This firmware is a maintenance release based on former release 5.73.0046.
Changes since last release are marked blue.
The platforms have been renamed for a more generic recognition to “Common Product Platform”,
short CPP, followed by the architecture-related number or suffix.
The filenames are adapted accordingly.
Please note:
This firmware is not applicable to wireless cameras.
Security Systems
From Nuremberg
ST-VS/MKP1 Product Management 20.10.2016
2
BOSCH and the symbol are registered trademarks of Robert Bosch GmbH, Germany
2 Applicable products:
AUTODOME Easy II IP series
AUTODOME Junior HD, Jr HD fix
VG4 AUTODOME IP series
AUTODOME 700 IP IVA
AUTODOME 800 IP IVA series
DINION XF 720p+, NBN-921-P
DINION XF, NBC-455-P
DINION 2X, NBN-498-P
FLEXIDOME XF 720p+, NDN-921-P
FLEXIDOME XF, NDC-455-P
FLEXIDOME 2X, NDN-498-P
Economy Box Cameras, NBC-225 series, NBC-255 series, NTC-255-PI
Economy Dome Cameras, NDC-225 series, NDC-255 series
Economy HD Box Cameras, NBC-265 series
Economy HD Dome Cameras, NDC-265 series
Extreme series EX30 IR, NEI-30 IR Imager
Far Infra-Red camera, VOT-320
VIP X1 XF Single-Channel H.264 Encoder
WLAN cameras NBC-255-W and NBC-265-W
Economic version VIP-X1XF-E
Video Conference Dome IVA
MIC IP PSU
3 Changes
An issue with encoders under certain conditions not detecting the correct video standard has
been fixed.
An issue with mp4 export of interlaced video has been fixed.
An issue with sporadic failing of camera front-end start-up has been fixed.
HTTP port 80 is now really closed if set to ‘Off’ instead of being redirected to HTTPS port 443.
FTP port is now configurable and can be closed.
An issue with ONVIF GetPreset command has been fixed.
Security Systems
From Nuremberg
ST-VS/MKP1 Product Management 20.10.2016
3
BOSCH and the symbol are registered trademarks of Robert Bosch GmbH, Germany
4 Restrictions; Known Issues
The camera date/time will be set to default (Year 2000) after power loss exceeding the buffer
period. It is important to ensure that the date/time is correct for recording. An incorrect
date/time setting could prevent from correct recording.
After firmware upload while daylight saving time checkbox is activated the time zone must be
adjusted.
After reboot, the system time re-synchronisation may be delayed up to 9 seconds for SNTP
respectively up to 14 seconds for time server protocol.
LUN size for local recording via “Direct iSCSI” is limited to 2 TB.
VRM version 2.10 or higher is required.
In some cases formatting errors on external iSCSI drives may occur, which might need
multiple tries to overcome.
In rare cases it may happen that the owner of an iSCSI LUN is not displayed correctly.
Recording is not affected, just previous owner remains displayed.
If a device had primary and secondary recording running on SD card and is then added to a
VRM system, the blocks used for primary recording will not be re-used, reducing the available
recording space for the ANR recording. This can be solved by re-formatting the SD card.
Throughput limit for simultaneous recording and local replay at 100% playback speed is:
o maximum total recording bit rate of 7 Mbps for external iSCSI recording
o maximum total recording bit rate of 10 Mbps for SD card recording, depending on
SD card performance
SD card recording performance is highly dependent on the speed (class) and performance of
the SD card.
FTP exported files which include audio in a format other than AAC must be renamed from
.mp4 to .m4a to allow correct playback in QuickTime.
With streaming set to 1080p or 720p50/60, AES encryption is not possible.
For HD cameras the encoder property setting “H.264 BP+ (bitrate limited)” can only be
selected for the downscaled second stream.
For standard definition devices the encoder property setting “H.264 BP+ (HW Decoder)” can
only be selected for one stream. If the second H.264 stream is configured for this property, the
selection of the other stream will be changed to “H.264 MP Low Latency”.
Encoding bit rate for Baseline Profile plus (BP+) is limited to maximum 1.2 Mbps, regardless
of any other setting in the encoder profile, without the special Global License Key applied.
Additional delay will also be applied; maximum end-to-end delay might be up to 400 ms.
Privacy Masks with colors black or white may cause tamper alarms "Picture too dark" or
"Picture too bright" to trigger. Use gray color for Privacy Masks when these tamper alarms
shall be activated to avoid false alarms.
Privacy Masks on AUTODOME Junior HD can only be colored gray.
Privacy masking is not supported for VG4 AUTODOME, AUTODOME Easy II, Economy Box
cameras NBC-2x5, Economy Dome cameras NDC-2x5 as well as for VIP X1 XF.
Security Systems
From Nuremberg
ST-VS/MKP1 Product Management 20.10.2016
4
BOSCH and the symbol are registered trademarks of Robert Bosch GmbH, Germany
Access to the BVIP products’ browser interface with secure connection (HTTPS) using
Microsoft Internet Explorer 8 is only possible with AES Encryption license enabled.
IE8 does not support 56-bit key DES encryption any more which requires the BVIP products to
provide a 128-bit key encryption algorithm. This can only be realised by using AES.
If the memory protection inside the Internet Explorer is enabled (default setting), the automatic
installation of Autoload Decoder will fail without producing an error message.
Consequently, the replay page will not show video.
As a work-around, two options are available:
o Disable memory protection in Internet Explorer and re-connect to the device.
o Manually download the Autoload Decoder installer from the device.
The installer can be downloaded via http://<ipaddress>/setup.exe and started manually.
With I-frame-only recording and audio also enabled for recording, audio will be fragmented or
not audible during replay. Please disable audio recording in case of I-frame-only recording.
With JPEG Posting active when device is booting, the first posted JPEG image may be a no-
cam logo.
M-JPEG HD resolution always follows HD resolution of stream1, respectively the stream with
the higher resolution.
Numbering of the recorded files on the replay page is not always contiguous.
If snippets across block borders belong together, like pre-alarm and alarm recording, the
snippets become logically united and only the lower file number is presented in the list.
Video and audio may be asynchronous during replay via Web page.
FTP posting with resolution 1080p delivers JPEG with size of 1920x1072 pixels due to 16
pixel macroblock boundary of the JPEG encoder.
JPEGs from HD cameras in downscaled formats 480p and 240p are not scaled to 16:9 aspect
ratio but to aspect ratio of 4CIF respectively CIF.
When DHCP is switched on, Web browser has to be restarted and reconnected to the newly
assigned correct IP address.
Video loss might occur when the I-frame quality is set to a low value (e.g. 9) in a complex
scene with a high video resolution. With these settings I-frames may become too big, which
might cause a buffer-overflow.
When configuring a secondary VRM recording while a primary recording is active, a gap of a
few seconds will occur in the primary recording until all recordings are restarted.
Pre-alarm time might become less accurate with extreme values, e.g. hours.
For VOT-320, the tasks removed object, idle object and crowd detection are not supported.
Frame rates in low light mode might vary and cause bit rate control to produce higher bit rates
than set as maximum.
Autopan starts outside of defined range if orientation is set to “Inverted”.
Tilt up limit is treated as lower tilt limit if orientation is set to “Inverted”.
A printout was added to telnet when sending an e-mail failed.
A more detailed printout was added for the three error cases 'could not connect to server',
'authentication failed' and 'recipient not accepted'.
Security Systems
From Nuremberg
ST-VS/MKP1 Product Management 20.10.2016
5
BOSCH and the symbol are registered trademarks of Robert Bosch GmbH, Germany
SDXC cards are formatted to FAT32 file system and not using the exFAT file system as being
mandatory for SDXC standard compliance but fully recognized and accessible.
The maximum size of 2TB is also supported with FAT32, once SD cards of that size might
become available.
FAT32 also increases portability to other than Windows platforms.
Aspect ratios 16:9 and 4:3 are not combinable. Aspect ratio from stream 1 will lead.
With GOP structure set to IBP and IBBP the I-frame distance may not exactly correspond with
the set value.
Installation of Autoload Decoder fails if more than one NIC is installed in a PC.
For VG5, when Fast Address was changed a reboot is required to activate it.
Replay using Autoload Decoder may be jerky when a device is close to or in an overload
situation.
IVA and flow need at least 12.5 frames per second video input frame rate. If IVA or Flow is
configured, minimum frame rate of 12.5 must be set in ALC mode.
In Firefox, no audio is audible on the Audio Settings page.
Opera mini for mobile devices can not work in Intranets because it gets all pages through an
opera proxy in the Internet. If there is no Internet connection no content is provided.
When changing GUI language, the browser cache may have to be deleted and the web
browser be reloaded before the language will be selected correctly.
QoS values are set according to group Video/Audio/Control for UDP packets, but for TCP
packets, only the QoS value for Video is inserted.
In camera menu of VG5 700, “High sensitivity” setting is not functional.
Blanked sectors in dome cameras may cause “too dark” alarm or global change alarm when
activated.
In AUTODOMEs blanked sector may trigger a “too dark” alarm.
In AUTODOMEs, if placed too close to the edge of a scene, privacy masking does not cover
the complete configured area. Center the target part of the scene before creating a privacy
mask.
Intelligent Tracking bounding box and trajectories are visible behind a blanked sector.
Intelligent Tracking requires decent lighting to reliably track objects and will not show optimal
performance during night mode.
For proper function of Intelligent Tracking digital zoom should be disabled,
If a local media is exchanged, existing former recordings are only discovered after rebooting
the device.
AAC audio timestamps are 90 kHz instead of 16 kHz to ensure compatibility with VideoSDK.
If LIVEPAGE is refreshed during recording of Tour A/B on AUTODOMEs the button “Stop
display” will falsely display “Start recording” but still continue tour recording.
There is only one configuration for IVA. When analysis type is changed, e.g. from IVA to IVA
Flow, the former configuration is lost. Due to this, it is not possible to change the analysis type
in a VCA profile switch.
Security Systems
From Nuremberg
ST-VS/MKP1 Product Management 20.10.2016
6
BOSCH and the symbol are registered trademarks of Robert Bosch GmbH, Germany
If FTP export files contain only a few frames some players might not correctly replay such a
file, or the replay is too quick to recognize something. The exported file is not corrupt though it
might seem so.
Wit VG5 AUTODOMEs and Privacy Masks defined in 'Normal' orientation, then orientation set
to 'Inverted', existing Privacy Masks will not be disabled, thus the Privacy Masks do not cover
the previously defined areas anymore. Make sure to adjust the Privacy Masks to the correct
position.
Due to a limitation of the script language that is used in the background, the delay timer for
event-triggered VCA starts immediately when the configuration is set. A trigger event during
this period does not restart the timer. Once the timer has elapsed, operation is as desired. On
devices with VCA FPGA an outgoing IPv6 connection fails when device is initiator, e.g. trying
to resolve a time server domain name,
Files exported using continuous FTP backup for Rec. 2 where stream 2 is set to I-frames only
mode contain wrong timing information and play back too fast.
With AUTODOMEs, after a soft reset or cycling power, if the user does not pan at all, the
second attempt to autopivot will not be successful.
SSL requires a certain amount of computational performance, depending on the encryption
algorithm in use, e.g. 3DES as the most requiring. Encoding bit rate might need to be reduced
to avoid overload conditions.
IP addresses 172.20.1.0/30 which include 172.20.1.0 to 172.20.1.3 are reserved for internal
communication and must not be used as device addresses. Products without internal
communication ignore this restriction and allow the use of this range.
After changing the selectable camera mode via alarm input the switch back to a previous
mode doesn't work anymore.
Firmware upload stops recording when it fails or is terminated.
FTP export file size is always 100 MB if resolution change occurred in exported time span.
After downgrade configuration integrity cannot be ensured and settings need to be checked or
re-configured.
Google Chrome requires a plug-in for displaying TIFF images to properly show the reference
image.
When a configuration file is loaded to an incompatible camera, e.g. a configuration file from a
HD camera loaded onto a VGA camera, encoder settings might become invalid and need to
be re-configured.
IE10 by default does not allow snapshots or recording from the LIVEPAGE on local hard disk
until one of the following actions is performed:
o - uncheck the box "Enable Protected Mode" in internet options/security
o - add the device’s IP range to "Local intranet" zone
o - add the device’s IP address to the trusted sites
o - start IE as administrator
If an intranet site is opened, IE10 automatically runs in compatibility mode.
This leads to a misbehaviour that no timeline is shown on the PLAYBACK page.
Therefore the function "Display intranet sites in Compatibility View" must be disabled.
Security Systems
From Nuremberg
ST-VS/MKP1 Product Management 20.10.2016
7
BOSCH and the symbol are registered trademarks of Robert Bosch GmbH, Germany
Changing audio format while audio is being recorded may cause unknown behaviour of the
device and must be avoided.
With some switches, when a port is set to 100 Mbps FD and the connected device also not set
to Auto Negotiation but to 100 Mbps FD, it may happen that after a network interrupt the
connection may not be re-established automatically.
When an encoder profile with GOP using B-frames is assigned to at least one of the encoders,
Encoding Interval settings for all encoder streams are no more valid and frame rates will thus
be at the maximum.
Using HTTPS together with Image Optimized encoder settings may cause overloading the
CPU with unpredictable effects, typically frame drops.
When combining CPU-intensive functions like e.g. encryption, watermarking, or dual
recording, with high quality and high frame rate encoder settings, tuning of encoder profile
settings might be required to avoid overload situations.
When setting a device to factory default the reference image should also be reset or re-
initiated. Otherwise it could produce false alarms.
Using B-frames with RTSP connections may cause video to flicker every 20 to30 seconds. It is
recommended to not use B-frames in RTSP or ONVIF profiles.
Physically removing the local storage media while recording causes the device to reboot.
Recording must be stopped before removal.
When combining CPU-intensive functions like e.g. encryption, watermarking, or dual
recording, with high quality and high frame rate encoder settings, tuning of encoder profile
settings might be required to avoid overload situations.
When using ONVIF GetPresets command preset names are not set for scene1 to scene6.
Please check the respective release letter of a camera or encoder for further device-specific
restrictions.
Security Systems
From Nuremberg
ST-VS/MKP1 Product Management 20.10.2016
8
BOSCH and the symbol are registered trademarks of Robert Bosch GmbH, Germany
5 System Requirements
Web Browsers:
o Microsoft Internet Explorer 9.0 or higher
o Mozilla Firefox
Oracle Java Virtual Machine 1.6.0_35
DirectX 9.0c
MPEG-ActiveX 5.60 or newer
Configuration Manager 4.45 or newer
6 Previous Revisions
6.1 Changes with 5.73.0046
An issue of terminating a RTSP connection when a client sends a SET_PARAMETER keep-
alive while streaming with RTP over RTSP over TCP has been fixed.
An issue with Daylight Saving Table being off by 1 or 2 hours in time zones with more than 9
hours away from GMT has been fixed.
6.2 New Features with 5.73.0045
This firmware is available as a global standard package and as a separate firmware package
with a special Chinese graphical character table with Unicode support.
Note:
Camera name stamping will not be converted automatically when changing to special Chinese
firmware and must be redone.
6.3 Changes with 5.73.0045
An issue with wrong RTSP sequence numbers has been fixed.
The ONVIF PTZ stop command handling has been improved.
Security Systems
From Nuremberg
ST-VS/MKP1 Product Management 20.10.2016
9
BOSCH and the symbol are registered trademarks of Robert Bosch GmbH, Germany
6.4 New Features with 5.73.0040
Platform type (CPP) is now displayed in System Overview page.
With a Bilinx dome connected to a VIP-X1XF, PTZ control is now available via the Video
Security app.
Tamper detection is now also possible on VOT-320.
ONVIF: a timeout range for continuous move has been added.
ONVIF GetDigitalInputs is now implemented.
Enhanced Chinese character set with Unicode support.
6.5 Changes with 5.73.0040
Night Mode can now be used in Alarm Task Scripting for AUTODOME 700 and 800.
On AUTODOME 700/800 when pan, tilt and zoom were performed simultaneously, zooming
might have still continued for a short time. This has been fixed.
Using NTCIP, camera no longer refuses new connection when already connected but instead
now releases old one and accepts new one.
DHCP default value is now correctly set to “On” after firmware upgrade even when an IP
address was already assigned by DHCP.
On a VOT-320 camera signal loss alarm no longer occurs in conjunction with FFC.
Idle objects do not disappear any more after 120 sec regardless if the global idle debounce
time is set higher.
However, it should be noted, that there are other issues that can preclude keeping an idle
object for a long time, so high idle time settings are not recommended.
ONVIF
GetSnapshotUri now delivers correct URL even when HTTP port was changed.
GotoHomePosition now works correctly.
The initial state transmitted after subscription now indicates the correct actual state.
The PTZ command "Stop Zoom" does not affect Pan/Tilt movement of the PTZ device
anymore.
Security Systems
From Nuremberg
ST-VS/MKP1 Product Management 20.10.2016
10
BOSCH and the symbol are registered trademarks of Robert Bosch GmbH, Germany
6.6 Changes with 5.72.0028
Retention time for recording has been changed to maximum due to legal requirements.
By this change, the overwrite checkboxes became obsolete and were discarded.
6.7 New Features with 5.72.0028
Enhanced support of MIC 550, MIC 550 IR and MIC 612.
Virtual Masking in Intelligent Tracking for AUTODOME 700 and 800 Series has been added.
A dropdown list for PTZ presets can be enabled on the LIVEPAGE to select from textual list.
The list is configurable for display in the LIVEPAGE settings.
6.8 Changes with FW 5.70.0039
Audio back-channel is now supported via SSL connections.
Audio and SD card support has been activated for MIC-VIP.
Bug fix for exports over NAT/PAT networks using relative paths.
6.9 New Features with FW 5.70.0039
Device capabilities are included in XML response of network scan
Security Systems
From Nuremberg
ST-VS/MKP1 Product Management 20.10.2016
11
BOSCH and the symbol are registered trademarks of Robert Bosch GmbH, Germany
6.10 Changes with FW 5.60.0063
RECORDINGS page renamed to PLAYBACK
Tamper alarms like too noisy, too dark, reference check could have forced alarm recording for
very long periods though no relevant material is captured. Tamper alarm recording has been
changed to edge-trigger but tamper alarms are presented as long as they persist.
FTP name scheme changed to allow sorting by date, new scheme like
Due to legal requirements, minimum retention time has been changed to maximum retention
time for local recordings.
To fully comply with the RFC '_' characters are replaced by '-' in the MIB file.
Bugfix for: Junior HD Fixed doesn't always return to saved fixed position
Bugfix for: Preset Manual Focus incorrectly returns 1 for Auto/OnePush and 2 for Manual
Bugfix for: Sector blanking not clearing after some operations
Bugfix for: Upgrading firmware with sector 1 blanked causes all sectors to be blanked
Bugfix for: Change behavior of Aux 86 and 87
Bugfix for: 66-On removes Install Mode title in Junior HD Fixed
Bugfix for: Functional OSD feedback displays replace 'Display Blanked' in blanked sector
Bugfix for: Position loss issue for AutoDome 700 & 800
Bugfix for: "Display Blanked" message is not always on the screen when sector is blanked
Bugfix for: "Install Mode" overlay is removed while Junior HD Fixed is still in Install Mode
Bugfix for: SET-898 while zoomed does not reset the pan/tilt speed
Bugfix for: Position loss issue for Junior HD
Bugfix for: AutoDome 800 series moves in the wrong direction after receiving the NTCIP Delta
command
Bugfix for: Junior HD Cogging at full zoom is not acceptable for casino project
Security Systems
From Nuremberg
ST-VS/MKP1 Product Management 20.10.2016
12
BOSCH and the symbol are registered trademarks of Robert Bosch GmbH, Germany
6.11 New Features with FW 5.60.0063
Support of MIC 612 via MIC IP PSU box
Zoom Threshold for Privacy Masks in AutoDomes
Out-of-the-box support for Bosch Cloud-based Security & Services(CbS)
Dynamic DNS extension to alternative providers no-ip.com and selfhost.de
A JPEG thumbnail image is returned in auto-detect reply after network scan.
Central URL http://downloadstore.boschsecurity.com where devices automatically check for
new FW when Internet access is provided.
ONVIF conformance to Profile S, validated with recent ONVIF test tool 12.06, with additional
beta features of Profile G, like search service and replay service.
6.12 Changes with FW 5.52.0015
AutoTracker has been renamed to Intelligent Tracking.
NTCIP support has been moved under license and is not available anymore for free.
6.13 New Features with FW 5.52.0015
Support of new DSA E-series iSCSI storage arrays.
Intelligent Tracking (formerly AutoTracker) for HD resolution PTZ dome cameras
Intelligent Tracking can be controlled by video analysis via an IVA task, e.g. when an object
crosses a line Intelligent Tracking starts tracking this object.
A user can manually start Intelligent Tracking by clicking on an object.
In auto mode Intelligent Tracking will follow the biggest object.
The compass function for AutoDome 700 and 800 series allows calibration for geographic
OSD within the video.
The compass function interferes with Intelligent Tracking and therefore is automatically turned
off when Intelligent Tracking is activated.
6.14 Changes with FW 5.51.0045
Mp4 files have been internally restructured to allow almost immediate replay access.
Security Systems
From Nuremberg
ST-VS/MKP1 Product Management 20.10.2016
13
BOSCH and the symbol are registered trademarks of Robert Bosch GmbH, Germany
6.15 New Features with FW 5.51.0045
AutoTracker for SD resolution PTZ dome cameras
AutoTracker can be controlled by video analysis via an IVA task, e.g. when an object crosses
a line AutoTracker starts tracking this object.
A user can manually start the AutoTracker by clicking on an object.
In auto mode AutoTracker will follow the biggest object.
Support of new device:
o MIC IP PSU
6.16 Changes with FW 5.50.0059
DHCP is enabled by default with new devices to achieve ONVIF Plug&Play compatibility.
Settings remain untouched during firmware upgrade.
NTCIP support is now a licensable option for dome cameras.
Class D IP addresses are denied for standard address fields in Web browser.
Unused pre-alarm buffer is released when changing the recording block.
RTSP multicast connections need a retrigger to keep alive, initiated by the CGI parameter
"mcRetrigger", which is set by default.
It can be disabled by setting mcRetrigger=0 in the RTSP URL for environments where no
keep-alive messages are sent. Otherwise the connection will time out after 1 minute.
6.17 New Features with FW 5.50.0059
Encoder
Predictable rate control for long term recording ensures that maximum bit rate is not exceeded
by peaks due to high motion. This makes storage calculation more reliable.
Downscaled images from HD cameras can use resolutions with undistorted 16:9 aspect ratio.
JPEGs are also possible with downscaled resolutions.
Adaptive Bit Rate encoding is available in TCP mode for replay and live. This is activated as
long as there is only a single client connected to the stream. With the second connection, the
profile settings become active.
Quality settings (QP settings) are harmonized over all products.
Security Systems
From Nuremberg
ST-VS/MKP1 Product Management 20.10.2016
14
BOSCH and the symbol are registered trademarks of Robert Bosch GmbH, Germany
Network
IPv6 support for Web browser access to product pages, including live view, control and replay,
has been introduced.
Quality of Service (QoS) allows setting different priorities for video, audio and control
connections.
IP Filtering allows defining two IP address ranges allowed to communicate with a device.
Flexible path for FTP can be defined, using a built-in FTP explorer.
HTTPS encryption using AES and 3DES ensures compatibility with latest Web browser
generations like IE9.
SNMP community names can be defined.
HTTP streaming (server push) allows mobile clients to access video.
MTU can be configured to adapt to network conditions.
Recording
Continuous recording files can be exported to a FTP server.
Pre-alarm recording for short time spans can be done in RAM.
FTP login data can be verified during setup.
Recording ID can be delivered with triggering a virtual alarm and stored within metadata.
Filenames for FTP export can be defined more meaningful by using pre-defined variables in
an Alarm Task Script. Please refer to the Alarm Task Scripting Language manual.
Alarm
Alarm images, JPEGs attached to alarm emails, can be defined more meaningful by using
pre-defined variables in an Alarm Task Script.
Quality of Service (QoS) level for video can be set higher on alarm.
True HTTP request is now possible in the Alarm Task Editor as an additional
SendHTTPCommand().
VCA
IVA 5.5 has been incorporated in firmware 5.50.
Please refer to the respective release letter for details.
Security Systems
From Nuremberg
ST-VS/MKP1 Product Management 20.10.2016
15
BOSCH and the symbol are registered trademarks of Robert Bosch GmbH, Germany
Web browser interface
Mobile device can access the devices via browsers and are forwarded to specific pages,
optimized for viewing on mobile devices. These pages use HTML5 technology with HTTP
streaming for the live stream and HTTP download of recording files in .mp4 format.
Apple devices support live view and playback of recordings.
Android and Windows Phone support live view only.
Pixel Counter allows counting of pixels in respect to stream resolution, e.g. to check if number
of pixels of object in view is sufficient for identification.
I-Frame only stream can be configured to be shown on the LIVEPAGE.
The expected frame rate for I-Frame only is indicated on recording page.
Display of V-SDK overlay icons can be configured on the LIVEPAGE settings
Preview images in settings pages can be expanded for more details, including 1:1 view.
Buttons to reboot a camera remotely and to set all camera and encoder parameters to factory
defaults have been added.
ONVIF
ONVIF Profile S is supported.
Miscellaneous
Debug logging has been enhanced to ease investigation during support cases.
Holidays (Special Days) are updateable without stop/start recording.
AAC is supported in addition to G.711 and L16 audio codecs and is selectable for recording.
It provides higher audio quality than G.711 with 16 kHz sampling rate at significantly lower bit
rate of approx. 48 kbps.
Firmware files of all three platforms are combined into a common file that can be uploaded to
any applicable product, regardless of the platform.
Camera specific features
Enhanced tone mapping for VOT cameras
Lens installation aid for motorized lens devices
6.18 Changes with FW 4.54.0026
For wireless cameras, protocol for connection handling to access point has been improved:
For VOT-320, no alarm was signalled when VCA was reconfigured. This has been fixed.
Security Systems
From Nuremberg
ST-VS/MKP1 Product Management 20.10.2016
16
BOSCH and the symbol are registered trademarks of Robert Bosch GmbH, Germany
6.19 Changes with FW 4.54.0024
Support of new devices:
o Wireless LAN cameras NBC-255-W and NBC-265-W
o Economic version VIP-X1XF-E
o AutoDome 700 IP IVA
o Video Conference Dome IVA
False Color tables for VOT-320 for better visualization of content of IR image.
JPEG stream on HD devices now always delivers HD resolution JPEG.
6.20 Changes with FW 4.53.0014
In former firmware releases I-frame distance in H.264 BP+ was fixed at 15, which in
combination with low frame rates set by Divar XF/700 caused intermittent video.
This has been fixed, and I-frame distance is configurable also for H.264 BP+.
For keep-alive reasons, the RTSP parameter GET_PARAMETER is now supported.
6.21 Changes with FW 4.53.0009
Support of AutoDome Junior HD Fixed and VG5 AutoDome IP series.
Stream 1 Stream 2 Stream 3 Stream 4
Quadruple
streaming HD 720p25/30 Downscaled stream I frame only
(from stream 1) JPEG (HD 720p,
limited frame rate)
Alternative
streaming HD 1080p25/30 HD 1080p25/30
(copy of stream 1) I frame only
(from stream 1) JPEG (HD 1080p,
limited frame rate)
Alternative
streaming HD 720p50/60 HD 720p50/60
(copy of stream 1) I frame only
(from stream 1) JPEG (HD 720p,
limited frame rate)
Alternative
streaming HD 720p25/30 HD 720p25/30
(copy of stream 1) I frame only
(from stream 1) JPEG (4CIF 480p,
full frame rate)
JPEG (HD 720p,
limited frame rate)
Security Systems
From Nuremberg
ST-VS/MKP1 Product Management 20.10.2016
17
BOSCH and the symbol are registered trademarks of Robert Bosch GmbH, Germany
6.22 Features with FW 4.53.0009
ONVIF 1.02 conformance
PTZ, event and imaging services are supported.
Firmware is fully conformant to the official ONVIF Test Tool 1.02.
Support SD Card recording in DINION XF and 2X and FLEXIDOME XF and 2X.
New Quadruple Streaming capabilities for HD cameras.
All video, also the downscaled stream, is provided in 16:9 aspect ratio.
Recording of I-frames only is possible from both, stream 1 and stream 2.
Recordings can be exported as *.mp4 files to a FTP server, either manually or after an alarm.
The resulting file can be replayed with standard players.
Replay from local recording via Web interface has been re-introduced. This allows replay over
bandwidth-limited connections and connections using NAT.
An “early warning” message is created when the device is in danger to run out of recording
blocks. This message can also be sent as SNMP trap.
In alarm e-mails with JPEGs attached, JPEG name includes camera name, date and time
information for easier differentiation and archiving.
Privacy masks are automatically excluded from alarm creation in MOTION+ and IVA.
Intelligent Video Analysis (IVA) is enhanced to cover HD resolution.
IVA allows Crowd Level Detection in a field.
New IVA software framework for more reliable detection. This allows reduction of false alarms
caused by shadows or windy elements, more stable object ID, pre-estimation of trajectory of
an object, and improvement of the detection of small and slow objects.
New IVA versions can be tested during a 30-day trial period, beginning with upgrading to a
firmware including a new IVA version.
This special activation key can only be applied once per new IVA version.
To start the 30-day trial period a special Global License Activation Key must be entered via
the License page in the Web browser or the Configuration Manager:
02-08.20.2D0-C3C6D6F8-0FF05DE6-C9983538-45DB6B3F-F2A5AF58
This Global License Key is valid for all applicable and IVA-capable products.
To avoid typing errors it is recommended to copy & paste the key from this release letter.
MOTION+ alarms can be applied with a debounce time of 1 second to reduce event load to
management systems.
Multiple MOTION+ or IVA alarms can be aggregated over a configurable time period.
Recording of transparent (e.g. ATM or POS) data via plain TCP channel is possible.
Data is stored as metadata and can be searched later on.
The time limit for tamper detection with reference image has been extended to 9999 seconds.
Security Systems
From Nuremberg
ST-VS/MKP1 Product Management 20.10.2016
18
BOSCH and the symbol are registered trademarks of Robert Bosch GmbH, Germany
RTSP audio connections use 8 kHz timestamps to allow audio with standard media players
like QuickTime or VLC.
NTCIP is supported for all AutoDome series.
Audio is possible in 16 kHz quality for live connections.
This mode requires approx. 500 kbps for such an audio stream.
Recording of 16 kHz audio is also possible.
UPnP discovery support can be enabled or disabled.
Extended multi-connectivity by increasing RCP+ connections to 100 minimum.
Temperature values (current and maximum) included in system overview for applicable
products with temperature sensor.
Decentralized event pre-processing is possible via Alarm Task scripting.
Devices can register for RCP messages and payload as input for script actions.
Implementation of a licensable function to increase the bandwidth limitation for H.264 BP+
encoded video from 1.2 Mbps up to 2 Mbps.
H.264 BP+ requires CAVLC entropy encoding which is handled by the built-in CPU.
The required computational power for CAVLC at 2 Mbps does not allow for more additional
functions than MOTION+ on the CPU.
Using this mode needs special care for the setup of a camera or encoder to ensure full
functionality.
Please consider the following restrictions to avoid erroneous behaviour:
Do not enable
o JPEG encoding in any way, including JPEG Posting or JPEGs in alarm emails
o iSCSI or SD card recording, neither local nor remote
o FTP export of recordings
o AES encryption
Do not allow
o Access to the second stream (H.264 MP)
o Access to the JPEG stream
o Access to RTSP streams
If necessary, access-protect the devices with passwords or disable the relevant ports.
In case of less than the 2 Mbps being required there may be sufficient computational power
left for an additional function. The needed performance is dependent on various settings and
must be very carefully evaluated using the real environment.
CPU load must be ensured to be continuously below 90% to keep the system functional.
Exceeding the available computational power will cause undeterminable behaviour,
including the risk of loosing video recording of multiple GOP lengths.
Security Systems
From Nuremberg
ST-VS/MKP1 Product Management 20.10.2016
19
BOSCH and the symbol are registered trademarks of Robert Bosch GmbH, Germany
To allow the bit rate increase a special Global License Activation Key must be entered via the
License page in the Web browser or the Configuration Manager:
02-01.1D.01-E7F59A39-5247CA08-C8FFE9F3-F4D1CEB1-F5DB22B3
To limit the bit rate to 1.2 Mbps again, a Global License Deactivation Key can be applied:
02-01.1D.00-DF14DC1D-0FFCFA4C-0FB214D8-6C231CD1-6585AD46
These Global License Keys are valid for all applicable products.
To avoid typing errors it is recommended to copy & paste the keys from this release letter.

Navigation menu
