OWNER’S GUIDE
Save this guide for after your headphones are complete!
BOSEbuild™ Headphones
Using your headphones without the app
The BOSEbuild Listen app includes step-by-step
assembly instructions, as well as activities and tools
that help you get the most out of your BOSEbuild
headphones. Once you’ve finished building your
headphones, refer to this guide for information about
using the headphones without the Listen app.
Headphone controls and connections
Powering on
Slide the Power/Bluetooth switch forward.
A voice prompt announces the battery level and any
connected devices. The battery indicator glows
according to the current charge level.
Powering o
Slide the Power/Bluetooth switch back.
Music controls
Call controls
Connecting to a mobile device
1. Slide the Power/Bluetooth button forward to the
symbol and hold it for two seconds. You hear
“Ready to connect” and the Bluetooth light blinks
blue.
2. On your mobile device, make sure Bluetooth is on.
(The Bluetooth menu is usually found in the Settings
menu.)
3. Select your BOSEbuild headphones from your
mobile device’s Bluetooth list.
The Bluetooth indicator glows solid white, and the
voice prompt says, “Connected to <device name>.”
Note: When powered on, the headphones try to
reconnect with the two most recently-connected
devices. The devices must be powered on and within
range (30 ft. or 9 m).
Using your headphones with multiple devices
Your BOSEbuild headphones can remember up to
eight paired devices and can be actively connected to
two devices at a time. If you pair a ninth device, the
least recently used device will be deleted from the
headphone’s memory.
Managing multiple connections
When two devices are actively connected, you can play
music from either device. To switch between
connected devices, pause the first device and play
music from the second.
Scrolling through other paired devices
To play music from a paired device that is not currently
connected:
1. Slide the Power/Bluetooth button forward to the
symbol and release to hear which device(s) are
currently connected.
2. Slide the Power/Bluetooth button forward again
within three seconds to connect to the next paired
device.
3. Repeat step 2 until you hear the correct device
name.
Note: To use this feature, voice prompts must be on.
Changing the headphone’s color
You can use the Color button on the left earcup to
change the color of your headphones. Use the
BOSEbuild Listen app to create your own color
presets.
1. Press the Color button to switch between
color presets.
2. Press and hold the Color button for three
seconds to turn the LEDs o.
Charging your headphones
1. Plug the small end of the USB cable into the
micro-USB connector on the right earcup.
2. Plug the other end into a USB wall charger or
computer that is powered on.
Note: During charging, the battery light blinks amber.
When the battery is fully charged, the battery light
glows green.
Charging time
Allow up to two hours to fully charge the headphones.
Notes:
Using the colored LED lights draws battery power
more quickly than music listening alone.
A full charge powers the headphones for up to 15
hours of music listening, or up to 8 hours of music
listening with LED lights.
Listening to music at high volume levels or using the
LEDs at full brightness draws battery power more
quickly.
Battery level
Each time you power on the headphones, a voice
prompt announces the battery level. When the battery
is nearly depleted, you hear “Battery low, please
charge now.”
Indicator Lights
The Bluetooth and battery indicators are located on
the right earcup.
Once the headphones are connected, the Bluetooth
light turns o after 10 seconds. When the headphones
are powered on, press any button to view the
Bluetooth status.
When not charging, the battery light turns o after 10
seconds. When the headphones are powered on, press
any button to view the battery status.
Note: If the headphones are connected to an Apple
device, the device displays the headphone battery
level near the upper right corner of the screen and in
the notification center.
Voice prompts
Voice prompts guide you through the Bluetooth
connection process, announce the battery level and
identify connected devices. You can enable or disable
voice prompts using the buttons on your headphones.
Tip: You can also manage voice prompt settings using
the BOSEbuild Listen app.
Disable voice prompts
To disable voice prompts, press and hold + and –
simultaneously until you hear, “voice prompts o.”
Press and hold + and – again to re-enable voice
prompts.
Note: Disabling voice prompts does not disable iOS or
Android voice control.
Accessing voice control
When connected to an Apple or Android device, press
and hold for one second.
You hear a tone that indicates voice control is active.
Press again to dismiss voice control.
Clearing the headphone’s memory
To clear the headphone’s memory of all paired
devices:
1. Slide the Power/Bluetooth button forward to the
symbol and hold it for 10 seconds, until you hear
“Bluetooth device list cleared.”
2. Delete the BOSEbuild headphones from your
mobile device’s Bluetooth list. All Bluetooth devices
are cleared, and the headphones are ready to pair.
Factory reset
To restore your headphones to factory default
settings:
1. Make sure the headphones are powered on.
2. Press and hold the Color and Volume down buttons
for 10 seconds until the LEDs flash green.
The headphones reset, the Bluetooth indicator light
blinks blue, and you hear “Ready to pair.”
Bluetooth light What it means
Blinking blue Ready to connect
Blinking white Connecting
Solid white Connected
Battery light What it means
Solid green Medium to full charge
Blinking amber Charging
Solid amber Low charge
Blinking red Need to charge
Solid red Charging error - contact
BOSEbuild customer service
Function What to do
Play/Pause Press
Skip Forward Double-press
Skip Back Triple-press
Fast Forward Double-press and hold the second press
Rewind Triple-press and hold the third press
Volume Up Press
Volume Down Press
Volume up button
Color button
Volume down button
Multi-function button
Power/Bluetooth switch
Aux connector
Micro USB connector
Indicator lights
Volume up ( )
Multi-function ( )
Volume down ( )
Function What to do
Answer or end a call Press
Decline an incoming call Press and hold for one
second
Answer a second incoming call
and put the current call on hold
While on a call,
press once
Decline a second incoming call
and stay on current call
While on a call, press and
hold for one second
Switch between two calls With two active calls,
double-press
Create a conference call With two active calls, press
and hold for one second
Mute or unmute a call While on a call, press +
and – simultaneously
Important Safety Instructions
Please read and keep all safety and use instructions.
WARNINGS/CAUTIONS
Do NOT use the headphones at a high volume for any extended period.
• To avoid hearing damage, use your headphones at a comfortable, moderate volume level.
• Turn the volume down on your device before placing the headphones in/on your ears, then turn the
volume up gradually until you reach a comfortable listening level.
Do NOT use your headphones while driving or at any time the inability to hear surrounding sounds may
present a danger to yourself or others.
Focus on your safety and that of others if you use the headphones while engaging in any activity requiring
your attention, e.g., while riding a bicycle or walking in or near trac, a construction site or railroad, etc., and
follow applicable laws regarding headphone use. Remove the headphones or adjust your volume to ensure
you can hear surrounding sounds, including alarms and warning signals.
This product is intended for ages 8 and up.
Contains small parts which may be a choking hazard.
Not suitable for children under age 3.
This product contains magnetic material.
Consult your physician on whether this might aect your implantable medical device.
To reduce the risk of fire or electrical shock, do NOT expose this product to rain, liquids or moisture.
Do NOT expose this product to dripping or splashing, and do not place objects filled with liquids, such as
vases, on or near the product.
Keep the product away from fire and heat sources. Do NOT place naked flame sources, such as lighted
candles, on or near the product.
Do NOT make unauthorized alterations to this product.
Use this product only with an agency-approved power supplythat meets local regulatory requirements
(e.g., UL, CSA, VDE, CCC).
If the battery leaks, do not allow the liquid to come in contact with the skin or eyes. If contact is made, seek
medical advice.
Do not expose products containing batteries to excessive heat (e.g. from storage in direct sunlight,
fire or the like).
REGULATORY INFORMATION
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment o and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by Bose Corporation could void the user's authority to
operate this equipment.
This device complies with part 15 of the FCC Rules and with Industry Canada license-exempt RSS
standard(s). Operation is subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
This device complies with FCC and Industry Canada radiation exposure limits set forth for general population.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
CAN ICES-3 (B)/NMB-3(B)
Rated voltage: 5 Vdc
Rated current: 0.5 A
Charging temperature range: 0˚C to 45˚C
Discharging temperature range: -20˚C to 60˚C
BOSEbuild Headphones
Serial number:
Model number: 423376
BOSE CORPORATION
THE MOUNTAIN
FRAMINGHAM, MA 01701-9168
USA
This product is covered by a limited, one year warranty from Bose.
For terms, please visit http://build.bose.com/docs or write to:
BOSEbuild Support
c/o Bose Corporation
100 The Mountain Road, Framingham, MA 01701
The Bluetooth® word mark is a registered trademark owned by Bluetooth SIG, Inc. and any use of such mark
by Bose Corporation is under license. Apple, the Apple logo, iPad, iPhone, and iPod are trademarks of Apple
Inc., registered in the U.S. and other countries. App Store is a service mark of Apple Inc. Android is a
trademark of Google, Inc. “Made for iPod,” “Made for iPhone,” and “Made for iPad” mean that an electronic
accessory has been designed to connect specifically to iPod, iPhone, or iPad, respectively, and has been
certified by the developer to meet Apple performance standards. Apple is not responsible for the operation
of this device or its compliance with safety and regulatory standards. Please note that the use of this
accessory with iPod, iPhone, or iPad may aect wireless performance.
Copyright 2018, Bose Corporation. All rights reserved.
805496-0010
