Bose 774092 Rcb Sound Touch 300 Ml

User Manual: Bose SoundTouch 300 Soundbar

Open the PDF directly: View PDF .
Page Count: 24

Setup Guide
Guía de configuración
Guide d’installation

SETUP GUIDE • GUÍA DE CONFIGURACIÓN • GUIDE D’INSTALLATION

SOUNDTOUCH 300

universal remote control

2 - ENGLISH

CONTENTS

Programming the Universal Remote Control ..... 3

Using the Remote Control

Universal remote control buttons ................................................ 4

Source selection ................................................................................... 4

Bluetooth® Technology

Pairing a mobile device ..................................................................... 5

Pairing a mobile device with NFC ................................................. 5

Universal Remote Control Device Codes

TV ............................................................................................................... 6

Cable ......................................................................................................... 8

Satellite .................................................................................................... 10

DVD ........................................................................................................... 11

CD .............................................................................................................. 13

VCR ............................................................................................................ 13

Audio Accessory .................................................................................. 14

Video Accessory ................................................................................... 14

ENGLISH - 3

The universal remote control has four programmable source buttons

(, AUX, and ). You can program these buttons to control

your TV, cable/satellite box, DVD or Blu-ray Disc™ player, game system,

DVR or other auxiliary source by entering the code for your source’s

brand. There may be several codes for your source. You may need to

perform this procedure multiple times to locate the correct code.

Locate the code

1. Power on your source.

2. Locate the code for your source’s brand in the appropriate section

of the Universal Remote Control Device Codes list (located in the

back of the guide).

Enter the code

1. On the remote control, press and hold the appropriate source

button ( , AUX, or ) until all six source buttons glow,

then release. For example, to program your TV, press and hold

until all six source buttons glow, then release.

The appropriate source button continues to glow.

2. On the number keypad, enter the code for your source’s brand and

press .

Test the code

1. Test the source for basic functions by following the instructions for

your source:

• TV: press the channel buttons. Press MENU. The settings menu

appears. Press and to navigate.

• Cable/satellite box: press GUIDE. The programming guide

appears. Press and to navigate.

• DVD or Blu-ray Disc™ player: press GUIDE. The settings menu

appears. Press and to navigate.

• Game system: press and to navigate through the menu.

2. Based on your source’s response to basic functions:

• Remote responds accurately: press EXIT to exit programming

and save your settings.

• Remote does not respond or does not respond accurately:

– If your source button glows: press to move to the next

code. Repeat steps 1 and 2 in “Test the code.” You may need to

repeat this procedure 30 or more times. If all six buttons blink

three times, you have cycled through all codes for your source.

– If your source button is off: your remote exited programming

mode. Repeat steps 1 and 2 in “Enter the code” and steps 1 and

2 in “Test the code.”

Note: Your source may not be compatible with universal remote

controls or may not accept IR (infrared) signals. Refer to your

source owner’s guide for more information.

PROGRAMMING THE UNIVERSAL REMOTE CONTROL

4 - ENGLISH

USING THE REMOTE CONTROL

Universal remote control buttons Source selection

After programming the remote control, you can switch between

sources by selecting different inputs on your TV using the

remote control.

Notes:

• To use the Bluetooth® source, you must pair a mobile device to

the soundbar (see page 5).

• Pressing , AUX, or on the remote control does not

switch the source. It turns on the soundbar and changes the

mode of the remote so that the remote can control your

source’s functions.

1. Press the button for the source you want to control.

The source button glows.

2. Press .

The source powers on.

3. If the source is connected to your TV, press and select the

correct input on your TV.

Source selection

Powers on/off

the soundbar

Powers on/off a

selected source

Selects a source

connected to

your TV

Function buttons

Lists recorded

DVR programs

Navigation pad

Playback controls

Previous channel,

chapter or track

Numeric keypad.

Numbers 1 – 6 can

play SoundTouch®

Presets

Displays the Internet

TV home page or

the current source’s

home menu

Press to like/dislike

currently playing

selection (for use

with participating

music services)

Adjusts bass setting

Dialogue mode Closed captioning

Teletext mode

ENGLISH - 5

BLUETOOTH® TECHNOLOGY

To stream music from your Bluetooth® phone or other mobile device,

you must pair your mobile device with the soundbar.

Note: For more information on using Bluetooth® functions, refer to

the owner’s guide at global.Bose.com/Support/ST300

Pairing a mobile device

1. On the remote control, press and hold the Bluetooth® button

until the Bluetooth® indicator on the soundbar blinks blue.

2. On your mobile device, turn on the Bluetooth® feature.

3. Select your SoundTouch® 300 soundbar from the device list.

Once paired, the soundbar emits a tone.

Pairing a mobile device with NFC

1. With the soundbar powered on, unlock your mobile device and

turn on the Bluetooth® and NFC features.

2. Gently tap the NFC touchpoint on your mobile device to the top of

the soundbar behind the Bose® logo.

Your mobile device may prompt you to accept pairing.

Once paired, the soundbar emits a tone.
