User manual

Lifestyle

28/35 Home Entertainment Systems

Operating Guide

Safety Information

WARNING:

To reduce the risk of ﬁre or electric shock, do not expose the system to rain or moisture.

These important safety-related markings and instructions may be located on the enclosure bottoms of your Life-

style

media center and Acoustimass

module:

The lightning ﬂash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the

presence of uninsulated dangerous voltage within the system enclosure that may be of sufﬁcient magni-

tude to constitute a risk of electric shock.

The exclamation point within an equilateral triangle, as marked on the system, is intended to alert the user

to the presence of important operating and maintenance instructions in this owner’s guide.

CAUTION:

To prevent electric shock, match wide blade of plug to wide slot, insert fully.

Class 1 laser product

This compact disc player is classiﬁed as a CLASS 1 LASER PRODUCT.

The CLASS 1 LASER PRODUCT label is located on the bottom of the unit.

CAUTION:

Use of controls or adjustments or performance of procedures other than those speciﬁed herein may

result in hazardous radiation exposure. The compact disc player should not be adjusted or repaired by anyone

except properly qualiﬁed service personnel.

Class B emissions limits

This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment

Regulations.

Batteries

Please dispose of used batteries properly, following any local regulations. Do not incinerate.

Additional safety information

See the additional instructions on the Important Safety Information page enclosed with this owner’s guide.

Please read this owner’s guide

Please take the time to follow this owner’s guide carefully. It will help you set up and operate your system properly,

and enjoy all of its advanced features. Save your owner’s guide for future reference.

CAUTIONCAUTION

RISK OF ELECTRICAL SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED PERSONNEL.

AAVIS

RISQUE DE CHOC ÉLECTRIQUE

NE PAS OUVRIR

AFIN DE PRÉVENIR UN CHOC ÉLECTRIQUE NE PAS ENLEVER

LE COUVERCLE ARRIÈRE. IL NE SE TROUVE À L’INTÉRIEUR

AUCUNE PIÈCE POUVANT ÊTRE RÉPARÉE PAR

L’USAGER. S’ADRESSER À UN RÉPARATEUR COMPÉTENT.

CLASS 1 LASER PRODUCT

KLASSE 1 LASER PRODUKT

LUOKAN 1 LASER LAITE

KLASS 1 LASER APPARAT

Manufactured under license from Dolby Laboratories, Inc. “Dolby” and the double-D symbol are trademarks of Dolby Laboratories, Inc.

This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual

property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized

by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision

Corporation. Reverse engineering or disassembly is prohibited.

"DTS" is a trademark of Digital Theater Systems, Inc.

MPEG Layer-3 audio compression technology licensed by Fraunhofer IIS and THOMSON multimedia

Contents

Where to ﬁnd …

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Welcome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Region numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Types of discs you can play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Conventions used in this owner’s guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Glossary of terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Controls and Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

The remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Media center control buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Media center display window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

General System Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Treble and bass compensation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Too much or too little treble . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Too much or too little bass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Selecting the number of speakers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Adjusting surround sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Using the SLEEP function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

System settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Playing a Video DVD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Before you play your first DVD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Loading and playing a DVD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Basic DVD operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Using parental controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Playing an Audio CD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Loading and playing an audio CD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Basic CD operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Listening to AM/FM Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Turning the radio on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Tuning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Setting a station preset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Erasing a station preset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Playing External Sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

In general . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Programming your remote for other components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Turning the system on and selecting the source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Using the VCR sound source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Using a tape deck . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Changing System Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Using the settings menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Changing DVD play options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Making audio adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Changing the system setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

System setup items . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Remote control setup submenu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

DVD setup submenu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Parental control submenu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Changing the house code settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Setting up a second listening zone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Taking care of your Lifestyle

system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Replacing the remote control batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Technical information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Warranty period . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Contacting customer service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32

Contents

Introduction

Welcome

Thank you for purchasing a Bose

Lifestyle

DVD-based home entertainment system.

Through proprietary Bose technologoes and innovative Lifestyle

systems design, it delivers

superior performance for both music and video programming from an elegant and easy-to-

use system.

Note:

Because DVD is a new technology, please take the time to read through this manual

and familiarize yourself with the features of your new system.

Region numbers

Region numbers are allocated to DVD players according to where they are sold. Look for the

region number marked on the carton or on the bottom of the media center. Your system can

play DVD discs marked with the same region number.

Types of discs you can play

The DVD player in your system can play the following types of discs having the

corresponding logos:

•DVDs

•Audio CDs

•CD-R

Conventions used in this owner’s guide

Operating instructions include names of buttons on the remote control and on the Media

Center front panel, and menu items appearing on your TV screen and on the Media Center

display.

Button names

appear in boldface type. If a button has only a symbol, that will be used.

On-Screen Display messages

appear in boldface with a line above and below.

MEDIA CENTER DISPLAY

items are represented by a narrow boldface upper case type.

Glossary of terms

TBD

Controls and Indicators

The remote control

The advanced radio-frequency remote control works from anywhere within most types of

home construction. Simply press the desired button. You do not need to aim the remote at

the media center.

Note:

Some types of buildings create “dead spots” where the remote will not operate. Move

the remote a foot or two and try again. You can also move the media center a few feet to a

location with better remote response.

Power on/off and mute controls

SOURCE/INPUT controls

AUDIO

SurroundSpeakers

SOURCE / INPUT

MENU / NAVIGATION

Seek

Volume

PLAYBACK

Pause PlayStop

Channel

Chapter

Preset

Track

Tune

Guide Exit

PowerPowerPower

TV Input

DVD

Repeat

FM/AM

Tape

2-3-5

Mute

All

Enter

456

789

Shuffle

Settings

CD/DVD

AUXVCRTV

Off

Turns the system on and off.

Mutes the volume in both zones.

Mutes/unmutes the volume in the current zone.

Selects the built-in CD/DVD player and turns the system on.

Selects the built-in FM/AM tuner and turns the system on to the previously-

selected station. Switches between FM and AM when the tuner is on.

Selects the TAPE AUDIO INPUT and turns the system on.

Switches between the multiple video inputs (such as between the antenna/

cable input and one or more external source inputs) of your TV.

- Turns the system on and selects your TV as the sound source. Unmutes

the volume in the current zone.

POWER

– Turns TV power on and off.

VCR

– Turns the system on and selects your VCR as the sound source.

Unmutes the volume in the current zone. Toggles the input of your VCR

between TV and VCR.

POWER

– Turns VCR power on and off.

AUX

– Turns the system on and selects your AUX equipment (such as cable

box or satellite receiver) as the sound source. Unmutes the volume in the

current zone. Toggles the input of your auxiliary equipment.

POWER

– Turns AUX equipment power on and off.

Off

Mute

All

Mute

CD/DVD

FM/AM

Tape

TV Input

Power

VCR

Power

AUX

Controls and Indicators

The remote control – continued

System MENU/NAVIGATION controls

Displays the context-sensitive menu for the current source.

Displays or exits the current title’s menu from the DVD disc.

For DVD:

Displays the menu of all titles on a DVD disc.

For TV:

Displays the electronic program guide of TV listings.

Exits the electronic program guide of TV listings, the menu from a DVD

disc, or the context-sensitive menu for the current source.

In the Settings menu:

Selects the next item, up or down, in the menu.

Moves forward/backward to the next/previous variable in a menu list.

For FM/AM:

Tunes the FM/AM radio up/down to the next higher/lower

frequency.

In the Settings menu:

Selects menu item to the left or right. Moves

backward/forward to the previous/next variable in a menu list.

For FM/AM:

Seeks backward/forward to the next strong radio station.

In the Settings menu:

Enters the current option in a menu list. Enters

the value of a variable in a menu.

For FM/AM:

Enters a radio station preset number from the keypad.

For TV/CD/DVD:

Enters the number of a TV channel, CD track, or DVD

chapter from the keypad.

Skips to the next/previous TV/VCR/AUX channel, DVD chapter, radio

station preset, or CD track.

Raises or lowers the volume of the current source.

Unmutes the current source in the current zone.

By a numerical input, allows you to access a DVD chapter, CD track,

TV channel, VCR channel, AUX channel, or a radio station preset.

Skips to the previous DVD chapter, CD track, TV channel, VCR chan-

nel, AUX channel, or radio station preset.

AUDIO

SurroundSpeakers

SOURCE / INPUT

MENU / NAVIGATION

Seek

Volume

PLAYBACK

Pause PlayStop

Channel

Chapter

Preset

Track

Tune

Guide Exit

PowerPowerPower

TV Input

DVD

Repeat

FM/AM

Tape

2-3-5

Mute

All

Enter

456

789

Shuffle

Settings

CD/DVD

AUXVCRTV

Off

Settings

DVD

Guide

Exit

Seek

Tune

Enter

Seek

Tune

Enter

Seek

Tune

Enter

Channel

Chapter

Preset

Track

Volume

456

789

Controls and Indicators

The remote control – continued

PLAYBACK controls

AUDIO controls

Stops the disc player. If left unchanged for more than 20 minutes, the system

automatically switches itself to the “Stop” state.

Pauses the disc player. If left unchanged for more than 20 minutes, the disc

player automatically stops.

Starts the disc player.

Scans backward through the disc currently playing. Press and hold for fast

backward motion.

Scans forward through the disc currently playing. Press and hold for fast for-

ward motion.

Plays audio CD tracks in a random fashion. Pressed again cancels this mode.

Repeats a CD, CD track, DVD chapter, or DVD title

Selects 2, 3, or 5 speaker sound.

In surround (5-speaker) mode, raises (+) or lowers (–) volume of the surround

speakers.

In 3-speaker mode, raises (+) or lowers (–) volume of the center speaker.

In 2-speaker mode,

Surround +

selects the surround mode.

AUDIO

SurroundSpeakers

SOURCE / INPUT

MENU / NAVIGATION

Seek

Volume

PLAYBACK

Pause PlayStop

Channel

Chapter

Preset

Track

Tune

Guide Exit

PowerPowerPower

TV Input

DVD

Repeat

FM/AM

Tape

2-3-5

Mute

All

Enter

456

789

Shuffle

Settings

CD/DVD

AUXVCRTV

Off

Shuffle

Repeat

Speakers

2-3-5

Surround

Controls and Indicators

Media center control buttons

The Media Center has eight control buttons located under the front cover of the media center.

Media center display window

The media center display window shows you information about your system. The upper area

of the display is used to show you system messages and source-related information. The

lower area of the display has icons which light up to present system status information.

Figure 1

Elements of the media

center display

On/Off Source Volume

Enter

Erase Store

All Off

Open/Close

Turns the system on or off in zone 1.

Turns the system off in all zones.

Steps through the seven available source selections.

For FM/AM:

Enters a radio station preset number from the

keypad.

For TV/CD/DVD:

Enters the number of a TV channel, CD track,

or DVD chapter from the keypad.

In the Settings menu:

Enters the current option in a menu list.

Enters the value of a variable in a menu.

Raises/lowers the volume of the system. Unmutes the current

source if muted.

Opens/closes the disc tray.

Removes a radio station preset from the system.

Stores a radio station preset.

On/Off

All Off

Source

Enter

Volume

Open/Close

Erase

Store

General System Operation

Treble and bass compensation

The acoustics (sound qualities) of your room can affect the overall sound quality of any

speaker system. In general, you can reduce many problems with acoustics by the cautious

use of the treble and bass adjustments in the audio settings menu.

Too much or too little treble

Rooms with too few sound-absorbing furnishings, especially those with bare ﬂoors and walls,

may sound overly shrill or “bright.” Lowering the Treble Compensation setting to a negative

value from –1 to –15 decreases the treble sound.

Rooms with a lot of sound-absorbing furnishings, such as upholstered furniture, wall-to-wall

carpet, or heavy drapes, may reduce the treble sound of your system. Moving speakers far-

ther away from soft furnishings increases treble. You can increase the treble sound by raising

the Treble Compensation setting to a positive value from +1 to +14.

Too much or too little bass

Placement of the Acoustimass module affects the amount of bass you hear. Placing the mod-

ule closer to the corner of the room will increase the bass. Moving the module away from the

corner will decrease the bass.

You can decrease the bass sound by lowering the Bass Compensation setting to a negative

value from –1 to –15. To increase the bass, raise the bass compensation setting to a positive

value from +1 to +14.

Selecting the number of speakers

TBD

Adjusting surround sound

TBD

Using the SLEEP function

TBD

System settings

TBD

Playing a Video DVD

Before you play your ﬁrst DVD

This section tells you how to use the DVD player in your system to play video DVDs. Before

you play your ﬁrst DVD, make note of the following:

•Make sure that you are familiar with the functions of the remote control buttons (see “The

remote control” on page 6). Although some remote control buttons look the same as those

found on a VCR or CD player remote, their functions are different.

•In order for some system features to work, the DVDs that you play must be encoded with

the information for that feature. For example, in order to display subtitles while watching a

movie, the disc must contain subtitle information.

•Both the DVD player in your system and the discs you play are coded by region. In order for

a disc to play, these regional codes must match. Check the label on the media center or on

the shipping carton for your player’s region code.

Loading and playing a DVD

1. Turn your television and Lifestyle® system on.

2. Press the CD/DVD button on the remote to select the DVD player. If the system is off, this

will also turn it on.

3. Lift the media center front cover and press the Open/Close button.

4. Insert the DVD disc into the tray.

5. Press the Open/Close button to close the disc tray. The DVD disc will start to play auto-

matically. If not, press Play.

Note: Automatic play can be turned off. Press the Settings button, select System Setup,

select DVD Setup and press Enter.

Basic DVD operations

If you want to: Do this:

Pause a DVD movie …Press Pause . If left unchanged for more than 20

minutes, the system automatically switches itself to the

stop state.

Resume play …Press Pause or Play .

Stop a DVD movie …Press Stop once. Pressing Play continues the

movie from the point you stopped it.

Press Stop twice. Pressing Play starts the movie

from the beginning.

Skip to the next chapter …Press Chapter up.

Skip to the previous chapter …Press Chapter down twice.

Advance one frame at a time …Press Pause . Then press or momentarily.

Repeat a chapter …While playing the chapter you want to repeat, press

Repeat .

Search backward or forward …Press and hold or .

Channel

Chapter

Preset

Track

Channel

Chapter

Preset

Track

Repeat

Playing a Video DVD

Using parental controls

TBD

Playing an Audio CD

Loading and playing an audio CD

1. Press the CD/DVD button on the remote to select the CD player. If the system is off, this

will also turn it on.

2. Lift the media center front cover and press the Open/Close button.

3. Insert the audio CD into the tray.

4. Press the Open/Close button to close the disc tray. The CD will start to play automati-

cally. If not, press Play .

While playing a CD, the media center display window will show you the album name, track

number, track time, and repeat or shufﬂe mode

Basic CD operations

If you want to: Do this:

Pause a CD …Press Pause .

Resume play of paused CD …Press Pause again or Play .

Stop a CD …Press Stop .

Go to next track …Press Track up.

Go to beginning of current track …After track has played for several seconds,

press Track down.

Go to a previous track …If track has played for several seconds, press

Track down twice. If not, press once.

Scan a CD backward/forward …Press and hold or .

Randomly play CD tracks …Press after loading CD.

Cancel random play …Press while in Shufﬂe mode.

Channel

Chapter

Preset

Track

Channel

Chapter

Preset

Track

Channel

Chapter

Preset

Track

Shuffle

Listening to AM/FM Radio

Turning the radio on

Press on the remote to select the radio tuner. If the system is off, this will also turn it on.

When it turns on, the radio will be playing the most recently selected FM or AM station.

Tuning

You can tune to a radio station in the following ways:

Setting a station preset

1. Take your remote and stand in front of the media center.

2. Lift up the media center door.

3. Using the remote, tune to a radio station you want to store as a preset.

4. Press on the media center front panel.

Erasing a station preset

1. Take your remote and stand in front of the media center.

2. Lift up the media center door.

3. Using the remote, select the reset you want to erase.

4. Press on the media center front panel.

FM/AM

If you want to: Do this:

Switch between FM and AM Press on the remote.

Seek the strongest stations Press and hold Seek or on the remote until the

radio begins seeking. Release to stop at the next strongest

station.

To stop sooner, brieﬂy press or , or stop .

To begin seeking again without holding down the skip but-

ton, brieﬂy press or again as soon as the ﬁrst

seek operation stops.

Manually tune to a station Press Tune or on the remote.

Select a preset station Press Preset .

Key in a preset number on the keypad and press .

FM/AM

Channel

Chapter

Preset

Track

Enter

Store

Erase

Playing External Sources

In general

Follow the instructions in your Lifestyle® system Installation Guide for connecting external

components.

Turn on your component directly or by using its remote control. If you like, you can program

your new Lifestyle® remote to control most brands of TVs, VCRs, and other audio equipment.

Use the Volume ▲ or ▼ button on the Lifestyle® remote control or music center to raise or

lower the volume. Control all other functions at the source, referring to its owner’s manual, if

necessary. To begin, make sure the component is turned on and a tape, CD, DVD, etc. is

loaded.

Programming your remote for other components

TBD

Turning the system on and selecting the source

Press the Tape, VCR, or AUX button on the remote or press Source on the media center until

the desired component is selected. This turns your system on and selects the component

connected to that input. If the system is already on, this button selects the component.

Note: Selecting a source turns the system on in surround (5-speaker) mode.

Press the Speakers button to change the mode.

The appropriate indicators light up on the media center when the system is on and the com-

ponent is selected.

Using the VCR sound source

Press VCR on the remote or Source on the media center until VCR appears on the display.

This turns your system on in surround (5-speaker) mode and selects the VCR sound source

connected to the VCR jacks.

Using a tape deck

To record to a connected tape deck, play the source (AM/FM, CD, or AUX) you want to tape.

In a 2-zone system, play the source in zone 1. Set the tape deck to record.

16 C

Changing System Settings

Using the settings menus

Use the remote MENU/NAVIGATION buttons to move within the on-screen menus. Figure 2

shows you the elements of the on-screen menu displays.

Figure 2

Elements of the on-screen

menu displays

To display the settings menu on your TV screen

Press the Settings button. The displayed menu will contain items related to the currently

selected source. For example, if you press the Settings button while watching a DVD, you

will see a menu similar to the one in Figure 2.

To exit the settings menu and clear it from your TV screen

Press the Settings button again.

To select a menu item

Selected items are highlighted with a lighter color. Use the up/down arrow buttons ( )

to scroll up or down the list and highlight the item you want.

To enter a submenu

When you see the Enter button symbol to the right of the selected item, then that item has

a submenu of additional items. With the item selected, press Enter to go to the submenu.

Settings (DVD)

DVD Play Options

Sleep (minutes): Off

DVD Status:

Audio Settings

System Setup

Enter

Lists options for how to play and view the current DVD.

select item

Title bar – shows the name of the menu

or submenu you are using (the currently

selected source is in parentheses).

Menu items – a list of source-related

settings and submenus is shown in

this space.

Selected menu item – menu items are selected

(highlighted) with the up/down arrow keys.

Menu item description – Describes the

selected menu item.

Navigation controls – Identifies which remote

control buttons to use within this menu.

Submenu – This symbol indicates that there

is a submenu of items for this selection.

Press the Enter button go to this submenu.

Status display area – this area is

used to display status information

when a status item is selected.

Changing System Settings

To change a setting

Select the item you want to change using the up/down arrow buttons. Press the left or right

arrow button to step through the available choices. Find the setting you want and press the

Settings button to leave the menu. Your selected setting is stored in the system.

Figure 3

Example of changing

a setting

To view the system status

The settings menu provides a selection for displaying the status of the currently selected

source. Press the Settings button and step down to the status selection. The system status

is shown on the right-hand side of the menu display.

Figure 4

A DVD status example

DVD Play Options (1 of 2)

Title: Off

Chapter: 23 of 30

Title Time: 0:23:02

Time Display: Elapsed

Motion Control: Play 1x

Chooses an audio track for the current DVD.

select item

Subtitles: Auto

More…

Audio Track: English 22

22 3/2.1

change setting

Settings (DVD)

DVD Play Options

Sleep (minutes): Off

DVD Status:

Audio Settings

System Setup

Enter

Displays information about the current source.

selects item

DVD

Playing

The Movie Title

Title 1 of 13

Chapter 1 of 5

0:01:45 of 1:20:35

Audio English 22

22 3/2.1

Subtitle Off

Ratings Limit: 8

Repeat Chapter

Region Code:1

Changing System Settings

Changing DVD play options

While playing a DVD movie, there are several play options that can be changed. Figure 5

shows you a map to the DVD Play Options menu.

Figure 5

The DVD Play options menu

DVD movies are identiﬁed by title. If you have a DVD disc with more than one movie, this

function lets you select the movie you want to see.

A DVD video is divided into chapters. This function lets you select an individual chapter.

Chooses a time into the movie.

Selects either time elapsed or time remaining in the current DVD title.

Chooses direction and speed of DVD playback.

Some DVD discs are recorded with more than one soundtrack. Other soundtracks may pro-

vide another language or PCM.

To change soundtracks during play:

1. Press the Settings button.

2. Select DVD Play Options and press Enter.

3. Select Audio Track.

4. Choose another soundtrack. Press Settings when done.

DVD Play Options

Title

Chapter

Title Time

Audio Track

Time Display

Motion Control

Subtitle Language

Camera Angle

Subtitles

Settings

Enter

AUDIO

SurroundSpeakers

SOURCE / INPUT

MENU / NAVIGATION

Seek

Volu me

PLAYBACK

Pause PlayStop

Channel

Chapter

Preset

Track

Tune

Guide Exit

PowerPowerPower

TV Input

DVD

Repeat

FM/AM

Tape

2-3-5

Mute

All

Enter

456

789

Shuffle

Settings

CD/DVD

AUXVCRTV

Off

DVD Play Options

Settings (DVD)

AB Repeat

Title: 1 of n

Chapter: 1 of n

Title Time: h:mm:ss

Time Display: Elapsed / Remaining

Motion Control: <<Scan, <<4x, <<2x, <<1x, Pause, 1/4x >>, 1/2x >>, Play 1x, 2x >>, 4x >>, Scan >>

Audio Track: English Dolby Digital 3/2.1, French, Etc.

Changing System Settings

Turns the subtitles on or off. “Auto” turns subtitles on automatically if audio is not available.

Chooses a subtitle language for the current DVD.

Chooses a camera angle from those available on the current DVD title.

Repeats a speciﬁed section of the DVD movie. To specify a section to repeat:

1. Move to point “A” in the movie and press Enter.

2. Move to point “B” in the movie and press Enter.

The movie scene is repeated until you press Stop. To resume normal play, press Play.

Making audio adjustments

You can adjust the audio of each source individually. Figure 6 shows you a map to the DVD

Play Options menu:

1. Press the Settings button. A menu of the available settings for the current source

will be displayed on your TV screen.

2. Using the down navigation button ( ), scroll down the list and select (highlight)

Audio Settings.

3. Press the Enter button and the audio settings will be displayed for the current source.

Figure 6

The audio settings

submenu

Subtitles: On / Off

Subtitle Language: Lang1 / Lang2 / Etc.

Camera Angle: 1 of maximum on title

AB Repeat

Audio Settings

Movie EQ

Range Compression

Dolby Digital 1+1

Audio Status

Mono Decoding

Center Channel

Treble Compensation

Bass Compensation

Not available for

FM, AM, or CD.

Available only when Dolby 1+1

is not available.

Available only when Movie EQ

is not available.

Settings

Enter

AUDIO

SurroundSpeakers

SOURCE / INPUT

MENU / NAVIGATION

Seek

Volu me

PLAYBACK

Pause PlayStop

Channel

Chapter

Preset

Track

Tune

Guide Exit

PowerPowerPower

TV Input

DVD

Repeat

FM/AM

Tape

2-3-5

Mute

All

Enter

456

789

Shuffle

Settings

CD/DVD

AUXVCRTV

Off

Audio Settings

Settings (source)

Changing System Settings

Selecting DVD, TV, VCR, AUX, or TAPE turns the system on in an enhanced mode called

“Movie EQ.” In this mode, the bass and treble compensation are automatically set (more bass

and less treble) for the proper playback of movie soundtracks. Any additional adjustments

can be made by changing the Treble Compensation and Bass Compensation settings.

Digital Dynamic Range® compression automatically adjusts the volume to allow you to hear

soft sounds (particularly dialogue) and to prevent you from being overwhelmed by a loud spe-

cial effect, such as an explosion. This feature is normally engaged when you turn the system

on to DVD, TV, VCR, AUX, or TAPE. You can turn this feature off by setting Range Compres-

sion: Off.

Selects Track 1, Track 2, or both of the currently available audio tracks.

Displays system audio information. The following example shows you a DVD audio status.

Figure 7

Status example: DVD audio

settings

Bose® Videostage® decoding can process a one-channel program into ﬁve-speaker sound –

directing the signals so that dialogue remains locked on-screen, while music and ambient

effects ﬁll the room. You experience a surround sensation, providing extra enjoyment when

you watch older (that is, pre-stereo) movies. This feature can be used for mono TV, FM, and

AM programs. This feature is automatically engaged when a Dolby Digital bitstream indicates

that it contains a mono program. This feature can be turned off by setting Mono Decoding :

Off.

Movie EQ: On / Off

Range Compression: On / Off

Dolby Digital 1+1: 1 / 1 / Both

Audio Status:

Audio Settings (DVD)

Movie EQ: Normal

Range Compression: Off

Audio Status:

Mono Decoding: Normal

Center Channel: 0

Displays information about volume and other

adjustments.

select item

Audio

Volume: 55

Mute: Off

Zone: 1

Room: A

Speakers: 5

Surround

Setting: +3

Treble Compensation: --

Bass Compensation: 0

Mono Decoding: On / Off

Changing System Settings

Focuses or softens the presentation of center-channel sound.

Rooms with too few sound-absorbing furnishings, especially those with bare ﬂoors and walls,

may sound overly shrill or “bright.” Lowering the Treble Compensation setting to a negative

value from –1 to –15 decreases the treble sound.

Rooms with a lot of sound-absorbing furnishings, such as upholstered furniture, wall-to-wall

carpet, or heavy drapes, may reduce the treble sound of your system. Moving speakers far-

ther away from soft furnishings increases treble. You can increase the treble sound by raising

the Treble Compensation setting to a positive value from +1 to +14.

Placement of the Acoustimass module affects the amount of bass you hear. Placing the mod-

ule closer to the corner of the room will increase the bass. Moving the module away from the

corner will decrease the bass.

You can decrease the bass sound by lowering the Bass Compensation setting to a negative

value from –1 to –15. To increase the bass, raise the bass compensation setting to a positive

value from +1 to +14.

Center Channel: -- [2 speakers] / –8 to 8 [3 or 5 speakers]

Treble Compensation: –15 to +14

Bass Compensation: –15 to +14

Changing System Settings

Changing the system setup

Press the Settings button to open the Settings menu on your TV screen. Using the down

arrow button ( ), scroll down the list and select (highlight) System Setup. Press the Enter

button to display the System Setup menu.

Figure 8

Map of the System Setup

Menus

Settings

Enter

AUDIO

SurroundSpeakers

SOURCE / INPUT

MENU / NAVIGATION

Seek

Volu me

PLAYBACK

Pause PlayStop

Channel

Chapter

Preset

Track

Tune

Guide Exit

PowerPowerPower

TV Input

DVD

Repeat

FM/AM

Tape

2-3-5

Mute

All

Enter

456

789

Shuffle

Settings

CD/DVD

AUXVCRTV

Off

Display Brightness

Display Language

DVD Setup

Record Out Processing

Optical Source

Optical Input

Remote Control Setup

Send IR Commands

TV Power

Receive IR Commands

Channel Spacing

Video Format

Aspect Ratio

Component Video

Video Black Level

Zone 1 Protocol

DVD Autoplay

Auto Select Audio Track

Auto Subtitle

Parental Control

Image Format

TV Brand

TV Device Code

AUX Device

VCR Brand

VCR Device Code

AUX Device Code

AUX Brand

Enter Password

Restrict Unrated Titles

Create Password

Create/Change Password

Set Ratings Limit

Confirm Password

Enter

System Setup DVD Setup

System Setup

Settings (source)

Enter

Parental Control

Enter

Create/Change Password

Remote Control Setup

Enter Password: _ _ _ _

DVD Access

Changing System Settings

System setup items

Chooses the brightness level of the media center display.

Chooses a language for the system’s displays.

Lists options for how the DVD player should operate, including Parental Control.

Assigns the optical digital input to a speciﬁed source.

Adjusts the Optical audio level to match other sources.

Chooses the digital output format for recording.

Sends system commands to learning IR remote controls.

Allows IR remote controls to operate this system.

Chooses the channel spacing for the AM and FM tuners.

Chooses the video format for your region.

Selects the black level for DVD playback. Most TVs require a Normal setting.

Chooses the type of video output. Normal is COMPOSITE and S-VIDEO.

Selects a data protocol for speakers in zone 1. Most speakers require a Normal setting.

Selects a data protocol for speakers in zone 2. Most speakers require a Normal setting.

Display Brightness: n of 7

Display Language: English/French/Spanish, German, Italian/Dutch

DVD Setup

Optical Source: TV / AUX / VCR / TAPE

Optical Input: –6 / –3 / 0 / 3 / 6

Record Out Processing: None / PCM

Send IR Commands: Normal / On

Receive Commands: Normal / On

Channel Spacing: USA / European

Video Format 1+1: NTSC / PAL

Video Black Level: Normal / Extended

Component Video: Normal / YPrPb / RGB

Zone 1 Protocol: Normal / Legacy

Zone 2 Protocol: Normal / Legacy

Changing System Settings

Remote control setup submenu

Chooses the TV brand. Press TV Power to test.

Chooses the IR code that the TV remote control uses.

Chooses the VCR brand. Press VCR Power to test.

Chooses the IR code that the VCR remote control uses.

Chooses the type of device connected to the AUX input.

Chooses the AUX component brand. Press AUX Power to test.

Chooses the IR code that the remote control of the AUX component uses.

DVD setup submenu

Automatically plays the 5.1 channel audio track when available on a DVD.

Automatically displays DVD subtitles when the audio is muted.

Automatically plays the DVD when it is loaded into the DVD player.

Provides the DVD aspect ratio for standard (4:3) or widescreen (16:9) TVs.

Pan and Scan images are resized to ﬁt a standard TV. Letterbox images are wider.

If Aspect Ratio is 16:9, Image Format is --.

If Aspect Ratio is 4:3, Image Format is Pan & Scan / Letterbox

TV Brand: Brand 1/ Brand 2 / Etc.

TV Device Code: Code 1/ Code 2 / Etc.

VCR Brand: Brand 1/ Brand 2 / Etc.

VCR Device Code: Code 1/ Code 2 / Etc.

AUX Device: Satellite / Cable

AUX Brand: Brand 1/ Brand 2 / Etc.

AUX Device Code: Code 1/ Code 2 / Etc.

Auto Select Audio Track: On / Off

Auto Subtitle: On / Off

DVD Autoplay: On / Off

Aspect Ratio: 4:3 / 16:9

Image Format: Pan & Scan / Letterbox / --

Changing System Settings

Parental control submenu

Chooses a password to restrict access to DVDs above a speciﬁed rating limit.

Prevents viewing of unrated titles when password is set.

Lists options for how to create a new password or to change a current password.

Chooses the IR code that the VCR remote control uses.

Enter Password: * * * *

Restrict Unrated Titles: On / Off

Create/Change Password

Enter

Set Ratings Limit: 1 to 8

26 C

Reference

Changing the house code settings

Each Lifestyle® remote control uses a system of matching house codes to communicate with

its corresponding media center. If commands given from your remote ever conﬂict with those

of another nearby Lifestyle® system, you can easily set a new house code for your system and

its remote control(s) by following these steps.

1. Open the remote control battery cover and locate the miniature switches (Figure 9).

2. Change the position of switches 1, 2, 3, or 4 by moving them in the opposite direction

from their current settings. Use a paper clip, ball point pen, or similar object.

3. Replace the battery cover.

4. Lift the media center door and press the All Off button.

5. Press and hold the Store key. The media center display will begin to ﬂash PROGRAM.

6. While holding the Store key, press any key on the remote control. The display stops

ﬂashing and momentarily shows PROGRAM to conﬁrm recognition of a new house code.

The display veriﬁes the house code by showing four rectangles corresponding to the four

switch positions (up or down). See the example in Figure 10.

7. Release the STORE key. The system remains off.

8. If you have additional remote controls, change the switches to match those of the ﬁrst

remote control. It is not necessary to repeat steps 4-8.

Note: To verify your system’s house code, press Store while the system is off. The display

conﬁrms the settings of switches 1-4.

Figure 9

Miniature house code

switches

Figure 10

Media center display

window showing switch

positions

House code switches (1-4)

Shown as set at the

factory: all switches

down.

Reference

Setting up a second listening zone

Your Lifestyle® home entertainment system can direct sound from one or two sound sources

(such as CD, AM/FM tuner, TAPE, or AUX) to two different listening zones at the same time.

What is a zone?

Each listening area, whether a room or a group of rooms (including outdoor areas), is called a

zone. Your primary listening area is set up as zone 1.

What do I need for setting up a second zone?

•A Bose® powered speaker system that is compatible with your home entertainment system.

An existing stereo system can also be connected (special adapter required).

•The appropriate Lifestyle® system cable to connect the zone 2 speaker system to the

SPEAKER ZONES 2 connector on the rear panel of the media center.

•A second Lifestyle® system remote control to operate the zone 2 sound.

See your dealer or contact Bose for information on obtaining additional powered speakers,

remote controls, cables, and adapters for connecting additional equipment.

How do I set up a second remote to control zone 2?

1. Remove the battery compartment cover from the back side of the zone 2 remote.

2. Locate miniature switches 5 and 6 (Figure 11) and set them according to the table.

3. Make sure the house code switches (1, 2, 3, and 4) match those on your ﬁrst remote.

4. Re-install the battery compartment cover back.

Figure 11

Miniature zone code

switches

Zone code switches (5 & 6)

Controlled Zone 5 6

Zone 1 Down Up

Zone 2 Up Down

Both zone 1& 2 Up Up

Reference

Taking care of your Lifestyle® system

Caring for your system may include:

•Cleaning the system’s enclosures

•Cleaning your compact discs

•Replacing the remote control batteries

Cleaning the media center

•Use only a soft, dry cloth to clean the outside of the music center.

•Do not use any solvents, chemicals, or cleaning solutions containing alcohol, ammonia, or

abrasives.

•Do not allow liquids to spill into any openings.

•Do not use any sprays near the system.

Cleaning the speakers

•Clean the surface of your speakers with a soft, damp cloth. You can use an ammonia-free

window cleaner on a soft cloth to maintain the ﬁnish.

•Do not use any sprays near the system. Do not use any solvents, chemicals, or cleaning

solutions containing alcohol, ammonia, or abrasives.

•Do not allow liquids to spill into any openings.

•The speaker grille panels require no special care, although you may vacuum them carefully,

if necessary.

Cleaning compact discs

•Handle discs by their edges to prevent ﬁngerprints and scratches (Figure 12).

•To remove stains or ﬁngerprints from the surface of a disc, use a soft, lint-free, dry cloth.

Wipe in straight movements from the center of the disc to the outside. Do not use any

chemical products; they can damage the disc.

•Do not write on or attach labels to the surface of the disc.

•To minimize exposure to dust and dirt, replace discs in their cases after use. Store each

disc in its case, out of direct sunlight, high temperatures, and humidity.

Figure 12

Handling and cleaning a

compact disc

Reference

Replacing the remote control batteries

Slide the battery compartment door off of the back of the remote. Find the polarity markings

(+ and –) inside the compartment and install the batteries accordingly. Slide the cover back on

the remote and snap it closed.

Figure 13

Opening the remote con-

trol battery compartment

Troubleshooting

–

––+–

Battery

compartment

door

Battery

compartment

AA batteries (4)

Problem What to do

System doesn’t do any-

thing •Make sure the power connector is inserted securely into the music center, the power

cord is inserted securely into the Acoustimass® module, and the power pack and power

cord are plugged fully into operating AC wall outlets.

•Be sure to select a source (CD/DVD, AM/FM, etc.).

•Unplug the media center power supply for a minute, then reconnect it. This allows the

unit to reset itself after a power surge or power interruption.

•If the system is not responding, press Store, Erase, and On/Off (on the music center) at

the same time, to reset the system.

No sound •Increase the volume.

•Check to see if MUTE is lit on the display. If it is, press the Mute button on the remote

control to unmute the sound.

•Make sure the audio input cable is ﬁrmly seated in the media center SPEAKER ZONE 1

jack and the multi-pin connector on the other end is ﬁrmly seated in the Acoustimass

module AUDIO INPUT jack.

•Check speaker connections.

•Turn the media center off for 10 seconds, then on again, to restore communication

between the music center and the speakers.

•Check the connections for any external components. Make sure to select the correct

source for the desired input.

•Be sure the disc is placed correctly, label-side up, in the CD tray.

•Connect the FM and AM antennas.

No sound from center

speaker •Make sure the center speaker cable is connected at both ends.

•Select 3- or 5-speaker mode.

Too much sound from

center speaker •In 3-speaker mode, press Surround – to decrease center speaker volume.

Reference

No sound from surround

speakers •Select 5-speaker mode.

•Press Surround +

•Make sure the video sound source is stereo and surround-encoded, and the component

used (TV, VCR, etc.) is stereo.

Surround speakers are too

loud •In 5-speaker mode, press Surround – .

•Make sure that the left and right front speakers are connected to the front speaker jacks

(blue) and the left and right surround speakers are connected to the surround speaker

jacks (orange).

Remote control is incon-

sistent or does not work •Check batteries and their polarity (+ and –). See “Replacing the remote control batteries”

on page 29.

•Operate the remote control closer to the media center.

•Move the remote (or the media center) a few feet to avoid an area of “dead spots.” See

note under “The remote control” on page 6.

•Make sure the audio input cable is ﬁrmly seated, uncoiled, and extended as much as

possible.

•Make sure the remote control and media center house codes match. See “Changing the

house code settings” on page 26.

System turns on by itself,

or behaves erratically •Change the house code setting to prevent signals from conﬂicting with another nearby

Lifestyle® system.

•See “Changing the house code settings” on page 26.

Radio does not work •Make sure antennas are connected properly.

•Move AM antenna at least 20 inches (50 cm) from the media center.

•Adjust antenna position to improve reception.

•AM antenna must be upright.

•Move antennas farther from TV or other electronic equipment.

•You may be in an area of weak signal coverage.

The disc does not play •Check to see if the play symbol in the display is lit.

•After pressing the CD/DVD button, wait a few seconds before pressing Play.

•Make sure the disc is properly inserted (label side up).

•Eject the disc and try loading it again.

•There may be dirt or dust on the CD. Clean the CD. See “Cleaning compact discs” on

page 28

•The CD may be defective. Try another CD.

FM sound is distorted •Adjust antenna position to reduce interference.

FM sound is noisy in sur-

round mode •Weak FM stations will produce static in the surround speakers. Select the 2-speaker

mode to minimize noise.

Sound is distorted •Make sure speaker cables are not damaged and the connections are secure.

•Reduce the output level from any external components connected to the music center.

No tape, CD, VCR, or TV

sound. •Check the connections.

•Make sure the component is turned on.

•Refer to the component owner’s manual.

Problem What to do

Reference

Technical information

Media center power pack rating

USA/Canada: 120V, 60 Hz, 25VA

Speaker system power rating

USA/Canada: 120V, 50/60 Hz, 350W

Media center inputs

TAPE: 2Vrms, maximum

AUX: 2Vrms, maximum

VCR: 2Vrms, maximum

TV: 2Vrms, maximum

DIGITAL:

COMPOSITE VIDEO:

S-VIDEO:

OPTICAL:

FM antenna: 75 Ω

AM antenna:

TV SENSOR:

Media center outputs

SPEAKER ZONES 1 and 2: Variable audio

RECORD L and R: Fixed audio

RECORD DIGITAL:

RECORD OPTICAL:

COMPOSITE VIDEO:

S-VIDEO:

Remote control range

65 ft (20m)

Dimensions/Weights

Finish

Media center: Aluminum

Cube speakers: Polymer painted

Acoustimass module: Vinyl veneer, Polymer

Media Center: 15.5" W x 8.0" D x 2.6" H

(39.4 cm x 20.3 cm x 6.6 cm) 5.9 lb (2.7 kg)

Cube speakers:

(2-wire conn.)

3.1" W x 4.0" D x 6.2" H

(7.8 cm x 10.2 cm x 15.7 cm) 2.4 lb (1.1 kg)

Cube speakers:

(plug-in conn.)

2.2" W x 3.2" D x 4.4" H

(5.6 cm x 8.1 cm x 11.2 cm) 1.0 lb (0.5 kg)

Acoustimass module: 23.3" W x 7.5" D x 14.0" H

(59.0 cm x 19.0 cm x 35.5 cm) 33 lb (15.0 kg)

Reference

Accessories

For information on speaker mounting brackets and stands, additional remote controls, and

connecting additional Bose® powered loudspeakers, contact your Bose dealer or call Bose

customer service.

Warranty period

Your Lifestyle home entertainment system is covered by a one-year transferable warranty.

See your warranty card for details. Please be sure to ﬁll out the information section on the

card and mail it to Bose.

Contacting customer service

For additional help in solving problems, contact Bose Customer Service. See the address and

phone number list included with your system.

The Mountain, Framingham, MA 01701-9168 USA

259776 AM Rev.00 JN10719

Bose RC48T1-27 Remote Control RC48T1-27 User Manual LS28 35 OpGuideRev0

Bose Corporation Remote Control RC48T1-27 LS28 35 OpGuideRev0

User manual

Navigation menu

Namespaces

Views

Navigation
