The AeroTherm® Series Heat Pump water heater

offers advanced technology and low cost operation.

Model

Number

Approx.

Shipping

Weight

lbs.

E

Floor to

Cold Water

Conn.

in.

B

Jacket

Dia.

in.

C

Floor

to

Water

Conn.

in.

A

Floor

to

Heater

Top

in.

U.S.

Gal.

Nominal

Capacity

Recovery

90°F Rise

RE2H50R10B

RE2H80R10B

50

80

Imp.

Gal.

42

67

U.S.

GPH*

21

21

Imp.

GPH*

18

18

Uniform

Energy

Factor

(UEF)

First

Hour

Rating

(Gal.)

3.24

3.25

DOE

Rated

Storage

Volume

(Gal.)

45

75

64

89

195

235

591/8

711/8

603/4

731/2

213/4

25

591/8

593/8

50

595/8

603/4

31/8

383/4

50 3/8

F

Floor

to

T&P

Conn.

in.

E

Floor to

Cold Water

Conn.

mm.

444

D

Distance

Between

Water

Conn.

in.

8

8

E

Floor

to

Condensate

Conn.

in.

463/4

58 3/4

79

F

Floor to

Anode

Rod

in.

161/2

F

Floor to

Anode

Rod

mm.

G

Floor to

Electrical

Access

in.

161/2

G

Floor to

Electrical

Access

mm.

419

*Energy Factor and First Hour Rating are based on latest AHRI Directory listings.

A

C

D

B

E

F

A

C

D

B

E

F

Specs at a Glance

Dimensions and specifi cations subject to change without notice in

accordance with our policy of continuous product improvement.

QUIET OPERATION

Operating Sound Level 55 DBA Average

POWER / RATINGS

Electrical Circuit Required 208V/240V 60 Hz Dedicated 30 Amp Min.

Electrical Consumption - Lower Element 4,000 Watts

Electrical Consumption - Upper Element 4,500 Watts

Electrical Consumption Heat Pump 4,500 Watts Maximum Heating;

550 Watts Minimum Heating

Uniform Energy Factor (hybrid mode) Up to 3.25

First Hour Rating (FHR) Up to 94 gallons

Operating Air Temperature Range Heat Pump 35° F to 120° F (Unit operates in

Standard/Electric Mode outside of this range)

Operating Water Pressure 150 PSI Maximum Working Pressure

(30-80 PSI recommended)

©2017, Bradford White Corporation. All rights reserved.

ATHRMB-1017

AeroTherm® Series

Heat Pump Water Heater

Committed to the Professional.

1

2

5

4

2

3

6

Get The AeroTherm

®

Series Heat Pump Water Heater.

Smart for You and Smart for Your Customers.

The Bradford White AeroTherm® Series water heaters combine

the installation and servicing features valued by plumbing

professionals with the energy and cost saving benefi ts important

to today’s energy conscious consumer.

Smart for You

For plumbing professionals, the AeroTherm® Series features top water connections and

convenient height and weight for quick and easy replacements and installations. The product

can also be laid on its side for greater transportation fl exibility. And AeroTherm’s integrated

smart control panel includes detailed diagnostic information for ease of serviceability and

quick and accurate diagnostics. Just as important, the AeroTherm® Series adds another

great line of Bradford White products you can offer your customers.

Smart for Customers

ENERGY STAR® certifi ed, AeroTherm® Series water heaters are eligible for most rebate

programs throughout the country resulting in initial savings to the consumer. Effi ciencies

up to 3.25 UEF (Uniform Energy Factor) result in signifi cant energy and money savings

throughout product lifetime. First hour delivery ratings up to 89-gallons and ultra-quiet

operation ensure consumers get exceptional performance to meet their demands for

hot water. And with four user-selectable operation modes (Heat Pump, Hybrid, Electric,

Vacation), the new AeoTherm® Series gives consumers greater control over their water

heater’s energy consumption. The AeroTherm® Series also comes standard with a 10-year

limited warranty.

• 50- and 80-gallon capacities - comparable

replacements for 40-, 50-, or 80-gallon standard

electric water heaters

• Provide the same amount of hot water as standard

electric 50- or 80-gallon water heaters

• Same water and electrical connections as a

standard electric water heater

• Top water connections and a convenient height

and weight for quick and easy replacements and

installations

• Designed for indoor installation such as: basement,

garage, closet, utility room, attic, etc.

• Four operating modes: Heat Pump, Hybrid, Electric,

and Vacation

• Electronic controls make it simple to change the

temperature or operating mode

• Northern climate tier 3 capable (RE2H50R10B and

RE2H80R10B)

• Quiet operation

• 10-year limited warranty

Highlights

The AeroTherm® utilizes both heat-pump technology (1) and back-up electric heating

elements (2) to heat water. This integrated system helps to drive the AeroTherm’s

economical and effi cient operation. During heat pump operation, a fan (3) draws heat

from the air into a compressor (4) and evaporator (5) to heat refrigerant. Once heated,

the refrigerant travels through a coil (6) that fully surrounds the water storage tank.

The AeroTherm® Series heat pump water heater provides considerable energy

effi ciency while greatly reducing the cost of water heating.

What Makes It Smart

The AeroTherm® Series control panel provides detailed

diagnostic information including water heater fault codes,

tank codes, need to assess codes, and heat pump codes.

Additional functions allow you to monitor the status of

temperature-sensing thermistors and heating components.

• User friendly, easy to read display

• LED’s clearly indicate the current operating mode

• Easy to change the temperature or operating mode

• Adjustments of one degree increments from 100 to

140 degrees Fahrenheit

• Display communicates current status, mode and set point,

and displays error messages when applicable

The AeroTherm® Series

Smart Control Panel

Heat Pump (only) Mode – Maximizes consumer savings. The most energy

effi cient mode as it only utilizes the heat pump.

Hybrid Mode – Saves while experiencing fast recovery. Hybrid mode is the

factory setting combining heat pump effi ciency and savings with recovery rates

of standard electric when needed.

Electric (only) Mode – Operates like a standard electric water heater, and

eliminates the air fl ow and sound from the heat pump system when preferred

(fastest recovery time, but least energy effi cient).

Vacation Mode – Adjusts the temperature set point down to 50°F for extended

periods of time.

Operational Modes

• Save $400 per year

in estimated annual

operating cost*

• Qualifi es for

state and

local utility

rebates and

tax credits

• Exceeds ENERGY

STAR® standards and

provides year-round

energy and money

savings

ENERGY STAR®

QUALIFIED:

*Information provided by the Air Conditioning,

Heating and Refrigeration Institute (AHRI) and

Bradford White. Savings based on the estimated

annual operating cost of a standard 50-gallon

electric tank water heater using 4721 kWh per

year vs. the 50-gallon, 3.24 UEF AeroTherm® heat

pump water heater using 1355 kWh per year

and national average electricity rate of 12 cents

per kWh. For FTC guide information, please visit

www.ahrinet.org.
