English

The Braun ThermoScan thermometer has been carefully developed for accurate,

safe and fast human body temperature measurements in the ear. The shape of

the thermometer prevents it from being inserted too far into the ear canal to damage

the eardrum.

However, as with any thermometer, proper technique is critical to obtaining

accurate temperatures. Therefore, please read all instructions carefully and

thoroughly before using this product and keep the manual handy for future

reference.

Important

• The operating ambient temperature range for this thermometer is 50 °F to 104 °F

(10 °C to 40 °C).

• Do not expose the thermometer to temperature extremes below - 4 °F or over 122 °F

( - 20 / 50 °C) or excessive humidity ( > 95 % RH non-condensing).

• This thermometer must only be used with genuine Braun ThermoScan Lens Filters

(LF 40). Never use this thermometer without a new, clean lens filter attached.

• If the thermometer is ever accidentally used without a lens filter attached, clean

the lens (see «Care and cleaning»).

• Always store thermometer in travel case, protective cover or plastic case.

• Basic safety precautions should always be observed, especially when using

the thermometer on or near children and disabled persons.

• Keep lens filters out of reach of children.

• This thermometer is intended for home use only.

• Use of this thermometer is not intended as a substitute for consultation with

your physician.

• Do not leave thermometer or lens filters with infants or children at any time.

How does Braun ThermoScan work?

The Braun ThermoScan thermometer measures the infrared heat

generated by the eardrum and surrounding tissue. To help ensure

accuracy, the thermometer «scans» by taking 8 measurements in

just one second and displaying the highest temperature.

The displayed ThermoScan temperature is the actual measured

ear canal temperature plus a mathematical adjustment to approximate

the familiar oral range. However, this is not necessarily the same as

an oral temperature measured at the same time.

Why measure in the ear?

The goal of thermometry is to measure core body temperature,

which is the temperature of the vital organs. Clinical studies have

shown that the ear is an excellent site to measure body temperature,

since ear temperatures reflect core body temperature. The eardrum

shares blood supply with the temperature control center in the brain,

the hypothalamus, allowing changes in body temperature to be

reflected sooner in the ear than at other sites.

4

6012136_IRT_3000_NA 28.10.2005 8:20 Uhr Seite 4

• Axillary temperatures reflect skin temperature which may not indicate core body

temperature.

• Oral temperatures are influenced by drinking, eating and breathing through the

mouth.

• Rectal temperatures often lag behind changes in core body temperature and there

is a risk of cross-contamination.

Body temperature

Normal body temperature is a range. The following table1shows that ranges of nor-

mal also vary by site. Therefore, readings from different sites, even if taken at the

same time, should not be directly compared.

• Also, a person’s normal temperature range tends to decrease with age. The follow-

ing table shows normal ThermoScan ranges by age.

Normal ThermoScan temperature ranges2

• However, the range of normal also varies from person to person and fluctuates

throughout the day. It is therefore important to determine your and your family

members’ normal temperature ranges. This is easily done using Braun ThermoScan.

Practice taking temperatures on yourself and healthy family members to determine

their normal temperature ranges.

Note: When consulting your physician, communicate that the ThermoScan tempera-

ture is a temperature measured in the ear and if possible, note the individual’s normal

ThermoScan temperature range as additional reference.

1. Chamberlain, J.M., Terndrup, T.E., New Light on Ear Thermometer Readings, Contemporary Pediatrics,

March 1994.

2. Chamberlain, J.M., et al., Determination of Normal Ear Temperature with an Infrared Emission Detection

Thermometer, Annals of Emergency Medicine, January 1995.

5

Axillary: 94.5 °F - 99.1 °F 34.7 °C - 37.3 °C

Oral: 95.9 °F - 99.5 °F 35.5 °C - 37.5 °C

Rectal: 97.9 °F - 100.4 °F 36.6 °C - 38.0 °C

ThermoScan2: 96.4 °F - 100.4 °F 35.8 °C - 38.0 °C

0 - 2 years 97.5 °F - 100.4 °F 36.4°C - 38.0 °C

3 - 10 years 97.0 °F - 100.0 °F 36.1°C - 37.8 °C

11 - 65 years 96.6 °F - 99.7 °F 35.9°C - 37.6 °C

> 65 years 96.4 °F - 99.5 °F 35.8°C - 37.5 °C

6012136_IRT_3000_NA 28.10.2005 8:20 Uhr Seite 5

Product description

1. Lens filter

2. Probe tip

3. Probe

4. Lens filter detector

5. Lens filter ejector

6. Display (LCD)

7. LCD light button (IRT 3520 only)

8. /mem button (On/memory function)

9. Battery door lock

10. Battery door

11. Activation button

12. Label

13. Travel case/protective cover/storage pouch

(depending on configuration)

Package components

• Braun ThermoScan thermometer

• Use and Care manual

• Quick Reference Guide

• Lens filters (20, plus one on the thermometer)

• Owner registration/warranty card

• Additional items may be included as noted on

outer packaging

• Label

The first time you use the thermometer, please

make sure to apply the special label included

in the package, in the language of your choice

(Item 12 on page 3).

How to use Braun ThermoScan

1. Always make sure a new, clean lens filter is

in place to help ensure an accurate reading.

The thermometer will not function without a

lens filter attached (see Changing the lens

filter).

2. Press the /mem button.

The LCD (liquid crystal display) is activated,

showing all segments.

When the ready symbol is displayed

the thermometer is ready for use.

6

6012136_IRT_3000_NA 28.10.2005 8:20 Uhr Seite 6

To help ensure an accurate temperature

reading, use the following technique: If you are

right handed, hold the thermometer in the

right hand and take the temperature in the right

ear. If you are left handed, hold it in the left

hand and use the left ear.

3. Perform an ear tug to straighten the ear canal.

This gives the thermometer a clear view of the

eardrum.

Children under 1 year:

Pull the ear straight back.

Children aged 1 year to adult:

Pull the ear up and back.

An ear tug is best performed by using your free

hand to grasp the outer edge of the top half of

the ear. To take your own temperature, wrap

your free hand around the back of your head

and grab your ear from behind.

4. While tugging the ear, fit the probe snugly into

the ear canal as far as possible and press the

activation button. Release it when you hear a

beep. This is the Temp Beep that confirms the

end of measurement.

5. Remove the thermometer from the ear canal.

The LCD displays the temperature measured.

6. Replace the lens filter after each measure-

ment: press the ejector button and put on a

new, clean lens filter.

7. A new measurement can be taken as long as

the ready symbol is shown. If no button

is pressed within 2 minutes, the thermometer

will turn off automatically.

7

6012136_IRT_3000_NA 28.10.2005 8:20 Uhr Seite 7

Temperature taking hints

• The right ear reading may differ from the reading taken at the left

ear. Therefore, always take the temperature in the same ear.

• The ear must be free from obstructions or excess earwax build-

up to take an accurate reading.

• External factors may influence ear temperatures, including when

an individual has:

- been lying on one ear or the other

- had their ears covered

- been exposed to very hot or very cold temperatures, or

- been recently swimming or bathing.

In these cases, remove the individual from the situation and wait

20 minutes prior to taking a temperature.

8

Note: In the following situations, it is recommended that you

take three temperatures in the same ear. If they differ, use the

highest reading.

• Infants in the first 90 days of life.

• Children under three years of age who have a condition

such as a compromised immune system and for whom the

presence or absence of fever is critical.

• When you are first learning to use the ear thermometer until

you are comfortable with the technique and are obtaining

consistent readings.

Important: As with any type of thermometer, slight temperature

variations ( ± 0.3 - 0.5 °F / ± 0.2 - 0.3 °C) can occur, if con-

secutive measurements are taken.

6012136_IRT_3000_NA 28.10.2005 8:20 Uhr Seite 8

Memory mode

The last temperature taken before the thermo-

meter powers down is stored in memory. To enter

the memory mode, press the /mem button.

Even in memory mode, a new temperature can be

taken provided that the ready symbol is

shown.

IRT 3020

The last stored temperature is displayed along

with the MEM symbol. To quit the memory mode,

press the /mem button again.

IRT 3520

This model allows you to store up to 8 temper-

atures.

When pressing the /mem button, the display

shows the memory cell number (e.g. MEM 1).

When releasing the /mem button, the stored

temperature is displayed.

Each time the /mem button is pressed, a new

memory cell is displayed (up to MEM 8).

An empty memory cell shows «- - - °F».

Only the first empty memory cell will be displayed.

To quit the memory mode, press the /mem

button again after reaching MEM 8 or «- - - °F».

Memory clear

Press the /mem button for 5 seconds to clear

the temperatures stored in memory. Release the

/mem button to return to the ready symbol

.

LCD light (model IRT 3520 only)

For easy nighttime reading.

9

6012136_IRT_3000_NA 28.10.2005 8:20 Uhr Seite 9

Changing the temperature scale

This thermometer is shipped with the Fahrenheit temperature

scale activated. If you wish to switch to Celsius (°C), proceed as

follows:

• Turn on the thermometer.

(If it is already turned on, make sure it is not in memory mode.)

• Press the /mem button and keep it pressed. Then press and

release the activation button to switch over to the «change

temperature scale» mode.

• By pressing the activation button again, the Celsius scale is

activated, «°C» is displayed on the LCD. Each further pressing

of the activation button toggles the scale between °C and °F.

• Release the /mem button to return to the ready symbol .

All temperatures stored in memory will automatically be converted

to the selected scale when displayed on the LCD.

Changing the lens filter

The thermometer is supplied with a lens filter in place. To assure

accuracy and sanitary practice, Braun recommends replacing the

lens filter after each use. To install a new lens filter, first remove

the one in place by pressing the lens filter ejector. Check the lens

for any damage. Then take a new lens filter from the box, and hold-

ing it by its edges, slide it onto the probe until it snaps in place.

Caution: Do not touch the tip of the probe or lens filters

when installing. Fingerprints, ear wax, dust and other soiling

compounds reduce the transparency, resulting in lower tem-

perature readings (see also Care and cleaning).

Should you run out of lens filters and need to take a temperature,

you may use the following lens filter cleaning procedure:

• Clean the lens filter without removing it from the thermometer

with a soft cloth or cotton swab moistened with alcohol.

Do not use hot or boiling water.

• Dry completely with a soft cloth before reusing.

• Replace lens filter as soon as possible with a new one (LF 40 ).

• Additional lens filters (LF 40 ) are available at most stores

10

IRT 3020

IRT 3520

6012136_IRT_3000_NA 28.10.2005 8:20 Uhr Seite 10

carrying Braun ThermoScan thermometers or at Braun Service

Centers.

• If you have accidentally placed the thermometer in your ear with-

out a lens filter in place, be sure and clean the probe (see

«Care and cleaning» and then apply a clean lens filter.

Care and cleaning

The probe tip is the most delicate part of the thermometer.

It has to be clean and intact to ensure accurate readings.

If the thermometer is ever accidentally used without a lens filter,

clean the lens as follows:

• Hold the appliance with the probe tip facing down to prevent

liquid from entering the probe tip area. Very gently wipe the sur-

face with a cotton swab or soft cloth moistened with alcohol.

• After cleaning, allow at least 45 minutes drying time before reat-

taching a new, clean lens filter and taking a temperature.

If the probe tip is damaged, contact Braun.

Use a soft, dry cloth to clean the thermometer display and exterior.

Do not use abrasive cleaners. Never submerge the thermometer in

water or any other liquid.

Store thermometer and lens filters in a dry location free from dust

and contamination and away from direct sunlight. The ambient

temperature at the storage location should remain fairly constant

and within the range of 50 °F to 104 °F (10 °C - 40 °C).

Always keep cleaning solutions and rubbing alcohol away

from children.

Replacing the batteries

The thermometer is supplied with two 3 V lithium batteries

(CR 2032/DL 2032). Insert new batteries when the battery symbol

appears on the display.

Using the tip of a ball-point pen, press the battery door lock to

open the battery compartment. Remove the batteries and replace

with new batteries, making sure the poles are in the right direction.

Slide battery door back in until it snaps in place.

11

6012136_IRT_3000_NA 28.10.2005 8:20 Uhr Seite 11

Troubleshooting

Error message Situation Solution

No lens filter is attached. Attach new, clean lens filter

No lens filter is attached Make sure probe tip is clean;

and activation button was refer to section «Care and cleaning»

pressed while probe was in if necessary.

the ear. Attach new, clean lens filter to stop

error beeps.

Ambient temperature is not Allow the thermometer to remain

within the allowed operating in a room for 30 minutes where

range 50 °F to 104 °F the temperature is between

(10 °C - 40 °C) or changing 50 °F to 104 °F (10 °C - 40 °C)

too rapidly.

Temperature taken is not Make sure new, clean lens filter is

within typical human attached and thermometer is properly

temperature range (93.2 °F - inserted.

108 °F / 34 °C - 42.2 °C). Then, take a new temperature.

HI = too high

LO = too low

Battery is low, but Insert new batteries

thermometer will still operate

correctly.

(No light function on

IRT 3020 models.)

Battery is too low to take Insert new batteries

correct temperature

readings.

System error Wait 2 minutes until thermometer

powers down, then turn on again.

• If error persists ... reset the thermometer by removing

the batteries and putting them back in.

• If error still persists ... call Braun ThermoScan Customer

Service at 1- 800 - 327-7226.

12

6012136_IRT_3000_NA 31.10.2005 16:07 Uhr Seite 12

Special situations

The Braun ThermoScan thermometer has been shown in clinical

studies to obtain accurate temperatures on persons of all ages.

However, there are certain situations when the ear thermometer

should not be used. These include but may not be limited to the

following situations.

• If there is blood or drainage in the external ear canal.

• For persons who have deformities of the face and ear canal

where the probe of the thermometer cannot be inserted fully into

the ear canal.

• For persons wearing hearing aids or ear plugs, remove the device

and wait 20 minutes prior to taking a temperature.

• Use the untreated ear if prescription ear drops or other ear medi-

cations have been placed in the ear canal.

Never attempt to clean inside ears. You could damage the ear drum

or surrounding tissues. You should remove excess ear wax only

when you can reach it with a wash cloth. If you suspect that you or

your child has excess ear wax, consult your physician.

Fever facts

Many persons may not have an elevated temperature even when

they are ill. These include, but are not limited to infants under

90 days of age, persons taking steroids, antibiotics or antipyretics

(acetaminophen, ibuprofen, aspirin), persons with compromised

immune systems, including the elderly or persons with some chro-

nic illnesses. Consult your physician if you feel an illness is present

even if there may not be an elevated temperature.

Fever is described as an elevation of body temperature over an

individual’s «normal» temperature.

An elevated temperature or fever is often viewed as a danger sign.

In fact, a fever can be very beneficial, and helps our immune

system work more effectively. A fever should be evaluated in the

light of other physical symptoms. With the exception of newborn

infants, the presence of fever, without any other symptoms of ill-

ness, or in a child who is behaving normally may not be cause for

concern. On the other hand, a physician should be consulted in the

following situations:

- vomiting

- diarrhea

- changes in appetite, activity or breathing, or

- with children who are irritable, lethargic or unusually sleepy.

13

6012136_IRT_3000_NA 28.10.2005 8:20 Uhr Seite 13

Some people, like the elderly, infants under 90 days of age, those

with compromised immune systems, or persons who take steroids,

for example are often unable to build a response to illness or

environmental conditions. These individuals may not have a fever

when they are ill, or their elevated temperature may be lower than

expected for the severity of their illness. Other medications such

as anti-inflammatories and some analgesics may also mask fever.

The presence or absence of fever should rarely be used as the only

measurement of the significance of illness. Your physician should

be contacted whenever there is a question about your family’s

health.

Antipyretics, like acetaminophen or ibuprofen, are usually recom-

mended to relieve the aches and associated symptoms of fever,

not the fever itself. Febrile seizures, or convulsions, which usually

occur in children six months to six years of age, are thought to

occur not because a fever is present, but because of the rate of

rise of the child’s temperature. Call your physician if your child has

a febrile seizure or you desire further information.

Use of the Braun ThermoScan thermometer is not intended

as a substitute for consultation with your physician.

14

6012136_IRT_3000_NA 28.10.2005 8:20 Uhr Seite 14

Product specifications

Displayed temperature range 93.2 °F -108 °F (34 °C - 42.2 °C)

Operating ambient

temperature range 50 °F -104 °F (10 °C - 40 °C)

Display resolution 0.1 °F or °C

Accuracy for patient temperature range

Maximum Laboratory Error

96.8 °F -102.2 °F (36 °C - 39 °C): ± 0.4 °F ± 0.2 °C

outside this range: ± 0.5 °F ± 0.3 °C

Long term storage ranges

Temperature: - 4 °F to 122 °F ( - 20 °C to 50 °C)

Humidity: 95 % non-condensing

Battery life: 2 years / 1000 measurements

This infrared thermometer meets requirements established in ASTM

Standard E 1965-98 (for the thermometer system [thermometer with

lens filter]). Full responsibility for the conformance of the product to the

standard is assumed by Braun GmbH, 61476 Kronberg, Germany.

ASTM laboratory accuracy requirements for the thermometer only (not

including a lens filter) in the display range of 98.8 °F to 102.2 °F

(36 °C to 39 °C) for infrared thermometers is ± 0.4 °F (± 0.2 °C), whereas

for mercury-in-glass and electronic thermometers, the requirement per

ASTM Standards E 667-86 and E 1112-86 is ± 0.2 °F ( ± 0.1 °C).

This appliance conforms to the following standards:

DIN EN 60601-1: 3/96 «Medical electrical equipment» –

Part 1: General requirements for safety

DIN EN 12470-5: 2003 «Clinical thermometers» –

Part 5: Performance of infrared ear thermometers

(with maximum device)

Internally Powered Equipment

Continuous Operation

Not Protected against Ingress of Water

U.S. Patent No. 5,088,834 Other Patents Pending

MEDICAL ELECTRICAL EQUIPMENT needs special precautions regarding EMC. For

detailed description of EMC requirements please contact the Braun ThermoScan Customer

Service at 1-800-327-7226.

Portable and mobile RF communications equipment can affect MEDICAL ELECTRICAL

EQUIPMENT.

In the unlikely event you experience any difficulty using the Braun ThermoScan thermometer,

simply call us toll free at 1-800-327-7226.

15

TYPE BF

EQUIPMENT

Attention, consult

ACCOMPANYING

DOCUMENTS

MEDICAL ELECTRICAL EQUIPMENT

CLASSIFIED BY UNDERWRITERS LABORATORIES INC.®

WITH RESPECT TO ELECTRIC SHOCK, FIRE AND

MECHANICAL HAZARDS ONLY

IN ACCORDANCE WITH UL 2601-1 / CAN CSA C22.2

No.601.1 10HK

6012136_IRT_3000_NA 28.10.2005 8:20 Uhr Seite 15

Service

The Braun ThermoScan thermometer has a limited three year

warranty. Should service be required during or after the warranty

period, you must call Braun ThermoScan’s Customer Service

Department at 1-800-327-7226 to obtain a return authorization

number and shipping address. Repackage the thermometer

carefully in its original packaging or securely packed to avoid

damage during shipping. Include the original sales slip indicating

the date of purchase, a note describing the problem, your

authorization number, and your return address. Send the Braun

ThermoScan thermometer prepaid and insured.

Note: Shipping address varies by country.

Answers to any question regarding operation of the Braun

ThermoScan thermometer may be obtained by calling us toll free at:

1-800-327-7226

Monday-Friday

6:30 AM to 5:00 PM Pacific Time

Limited three year warranty

Braun warrants this product against any defects that are due to

faulty material or workmanship for a period of three years from

the original date of consumer purchase or receipt as a gift. This

warranty applies when used for normal household use in accord-

ance with the Use and Care Manual and excludes the battery and

damage to the product resulting from accident or misuse. This

product is not warranted when used in a professional environment.

In no event shall Braun be liable for any special, incidental, indirect

or consequential damages in connection with the purchase or use

of this product or costs over the original cost of the product.

If the product should become defective within the warranty period,

contact Braun ThermoScan’s Customer Support Department at

1-800-327-7226 for repair or replacement at no charge.

Braun reserves the right to replace a defective product with the

most comparable product currently available. This product has a

five year minimum expected lifetime.

While this warranty gives you specific legal rights, you may also

have other rights which vary from state to state/province to

province.

16

6012136_IRT_3000_NA 28.10.2005 8:20 Uhr Seite 16
