1
Avvio
User’s Manual
For
Avvio 821S
2
CONTENTS
4 SAFETY INFORMATION
12 DESCRIPTION OF KEYS
16 Getting started
18 CALL FUNCTIONS
22 FUNCTION MENU
22 Messaging
25 Portal Movil
26 TELCEL
29 Fun
39 Ideas Box
29 Phonebook
32 Call center
35 Multimedia
35 Organizer
3
35 File manager
37 Settings
38 Services
43 MP3 AND MP4 INSTRUCTION
44 TROUBLESHOOTING
50 LIMITED WARRANTY
STATEMENT
4
SAFETY INFORMATION
PERSONAL USE
Operation of any radio equipment including mobile
phones may interfere with the function of inadequately
shielded medical devices such as hearing aids and
pacemakers. Please consult the manufacturer of these
devices or your physician before use.
In oil depots and chemical factories where explosive gas
or other products are stored, the user should pay close
attention to the restriction on the use of mobile phone.
Even if your phone is in the idle mode, it will still transmit
radio frequency signals. Therefore, you must switch off
when requested to do so.
Note traffic safety. When you are driving, please do no
use your mobile phone. Stop on the side of the road
when you do need to use it. Avoid making calls with your
cellular phone in stormy weather.
Safety Information related with children:
■ Be cautious of children swallowing the small parts
such as the SIM card.
■ Prevent children from playing with your cell phone
as toys. For example, behaviors like throwing,
biting the phone, or immersing it into water should
be avoided.
■ Do not let children less than 14 years old hang the
phone around the neck.
MOBILE PHONE USE
Please use only the accessories or parts offered by the
manufacturer or those authorized by the manufacturer.
Use of unauthorized accessories might influence the
performance of the phone. What’s worse, your phone
5
might get damaged and harm will be caused to your
body. It might even violate the national regulations on
the telecommunication terminal products.
Do not use chemical products like cleaning solvents or
detergents to clean your phone. It is recommended that
you use slightly damp and static electricity proof cloth
instead of cloth that is dry and easy to catch static
electricity. Before cleaning, you should switch off your
phone.
Your mobile phone produces magnetic fields. Do not
place it next to magnetic storage media such as
computer diskettes. Operating your mobile phone close
to other electrical equipment such as televisions,
phones, radios and personal computers may cause
interference and therefore influence the performance of
your phone.
Please do not link it to other unnecessary equipments.
Note! Non-professionals must not try to dissemble the
phone.
Phone Precautions!
■ Use your phone battery only for its intended
purpose, and never use any battery charger which
is damaged or worn out.
■ When you unplug your phone from its charger,
grasp and pull the plug, not the power cord.
■ Do not use harsh chemicals, cleaning solvents, or
strong detergents to clean your phone. Wipe it with
a soft cloth slightly dampened in a mild soap-and-
water solution.
6
■ Do not attempt to open the casing on your phone
or its battery.
■ Always keep SIM card out of children’s reach.
BATTERY USE
Do not short-circuit the battery terminals. This is
dangerous and will damage the battery, produce heat
and may cause a fire.
Never dispose of batteries in a fire as it can cause
explosion. Return waste batteries to your supplier or an
approved recycling center. Do not dispose along with
household wastes.
Warning! If the battery case is broken, avoid contact
with the contents. Wash contaminated skin with lots of
water and seek medical attention.
Battery Precautions!
■ Avoid dropping the cell phone. Dropping it,
especially on a hard surface, can potentially cause
damage to the phone and battery. If you suspect
damage to the phone or battery, take it to a service
center for inspection.
■ Never use any charger or battery that is damaged
in any way.
■ Use the battery only for its intended purpose.
■ If you use the phone near the network’s base
station, it uses less power; talk and standby time
are greatly affected by the signal strength on the
cellular network and the parameters set by the
network operator.
■ Battery charging time depends on the remaining
battery charge and the type of battery and charger
used. The battery can be charged and discharged
7
hundreds of times, but it will gradually wear out.
When the operation time (talk time and standby
time) is noticeably shorter than normal, consider
purchasing a new battery.
■ If left unused, a fully charged battery will fully
discharge itself over time.
■ Extreme temperatures will affect the charging
capacity of your battery: it may require cooling or
warming first.
■ Do not leave the battery in hot or cold places, such
as in a car in summer or winter conditions, as it will
reduce the capacity and life of the battery. Always
try to keep the battery at room temperature. A
phone with a hot or cold battery may temporarily
not work, even when the battery is fully charged.
Batteries are particularly affected by temperatures
below 32°F.
■ Do not place the phone in areas that may get very
hot, such as on or near a cooking surface, cooking
appliance, iron, or radiator.
■ Prevent your phone or battery from getting wet.
Even though they will dry and appear to operate
normally, the circuitry could slowly corrode and
pose a safety hazard.
■ Avoid a battery out of the phone in coming contact
with metal objects, such as coins, keys or jewelry.
8
DESCRIPTION OF KEYS
Left Soft Key
■ Performs the functions indicated by the text in the
left bottom line of the display screen above it.
Right Soft Key
■ Performs the functions indicated by the text in the
right bottom line of the display screen above it.
■ Go to Calls in idle screen.
Send Key
■ Access call log from idle.
■ Press to dial a Number.
■ Press to answer an incoming Call.
End Key
■ Press to end a call or reject an incoming call.
■ The phone will switch ON or OFF if it is pressed
and held.
■ Also in the menu mode, enables you to return to
the idle mode (screen) .
Central(OK) Key
■ Open main Menu in idle.
■ Confirm/ok/select in other state.
Extra Key
In the idle mode, each key has the following function.
■ Left Extra Key: go to Camera preview mode.
■ Right Extra Key: go to Media player mode.
0~9 Numeric Keys
■ By pressing the keys, you can edit numbers and
characters.
Volume Key
■ When the phone is in the idle mode, you can
adjust the volume of the key tone.
■ During a call, when the MP3 player is working, you
9
can adjust the volume of the voice or music.
Hook Button on the headset
■ If you insert the headset, you can use it as below
■ You can answer or end a call by pressing the hook
button on the headset.
Backlight
A backlight illuminates the display and the keypad.
When you press digit key, the backlight comes on. It
goes off when no keys are pressed within a given period
of time.
BATTERY
The phone comes with Li-ion battery which is only half
charged but can be put into use immediately after the
package is opened. However, the battery should be
thoroughly discharged and fully recharged for at least 3
recycling times successively to achieve optimum
performance.
How to Charge the Battery
○ Plug your charger into the main socket first.
○ Connect the lead from the charger to the upper
side of the phone.
○ When the battery is charging, the icon on the
upper right corner which indicates the battery
charge level will flash in cycle. If the phone has
powered off, a charging screen will show that the
battery is charging now.
○ When the bars in the icon are fully filled and has
stopped flashing, it tells you that the battery has
been fully charged. If the phone has powered off,
the screen will tell you verbally that the charging
has finished. Generally, it takes 2~3 hours to fully
charge the battery. Normally, the battery, the
10
phone and the charger might get heated in the
process.
○ Release the charger from the power socket and
the phone.
○ Warning! You must only use the supplied charger.
Unauthorized charger might result in danger and
any malfunction or damage caused by the use of
unapproved charger will void the product warranty
and it will not be acknowledged by the
manufacturer.
Getting started.
Insert the SIM Card
○ Insert the SIM card under the SIM card holder.
○ When you need to remove the SIM card, you
should first switch off the phone, remove the
battery and take it away from under the SIM card
holder.
○ Always handle the SIM card with care and insert
with the gold contacts facing down.
Insert & Remove the Micro SD Card
○ Insert the Micro SD card under the Micro SD card
holder.
Power ON/OFF
○ Make sure that the battery is attached. You can
switch your phone On/Off by long pressing the
[End] key.
○ If you switch the phone on without a SIM card :
○ The phone will promote “Insert SIM” ― In this case,
you can make emergency call.
○ The phone will promote “Network Emergency”―
which means it is searching for network but has
11
failed to link.
12
CALL FUNCTIONS
Making a call
○ In the idle mode, you will enter the dialing mode by
pressing any numeric key. By pressing the [Send]
key, you can make a call.
○ Key operation: You can end a call by pressing, [End]
key or the hook button on the headset.
Adjusting the Call Volume
○ During a call, if you want to adjust volume, use the
Up/Down-volume key. Press Volume up key to
increase the volume level, press the Volume down
key decrease the volume level.
International Call
○ You should press [+/O] key , the symbol “+” appear
on the screen. By doing so, you can make an
international call in whatever country without having
to input the international dialing code. When you
are dialing an international call, you should omit the
digit “0” before the city code.
○ To dial a fixed number: “＋”Country code +
complete number + [Send] key
Call from the List
○ Your phone automatically stores each number
dialed or answered in its memory. You can view the
Dialed Call numbers by pressing [Send] key. You
can also dial the numbers in the list by pressing
[Send] key.
Emergency Call
13
○ In whichever countries covered by the digital GSM
network, you can make an emergency call if you
are within the coverage of the network. The
network signal strength indictor will tell you whether
you can make it or not. If no service is available,
you can make an emergency call even without the
SIM card in place.
○ ! Note: Some network may not allow the
emergency call and may request to insert SIM card.
Receiving a call
○ When you receive an incoming call , press the
[Send] key to talk and hang up using [End] key.
○ Press the [Send] key to answer a call as a default
setting. To change the answering mode, press
Menu> Setting >Call center > Call settings >
Advanced settings > Answer Mode.
Available functions during the call
○ These options are visible only when you are during
the process of a call. The multi-part call function
should get support by the network. Please contact
you network service provider for further information.
○ The following options are available:
“Hold”, “End single call”, “New call”, “Phonebook”,
“Call history”, “Messaging”, “Sound recorder”,
“DTMF (You can set it ON or OFF)” and etc.
14
FUNCTION MENU
Messages
Write message
Text message
You can also create your own text messages. You can
add the message module to the new message you are
editing.
▪ Multimedia message
A multimedia message can contain text, images, and
sound clips.
When a message is readily finished, you can choose to
send it at once or save it for later use.
Inbox
With this menu, you can view the new messages or the
read messages. Sender number or name(if stored in the
Contact) are displayed on the list.
Drafts
▪ With this menu, you can view a list of any draft
messages that have been created in the ‘write
message mode’ and you can save the draft
messages here.
Outbox
▪ If you send a message, it will be saved to the
“Outbox” after the message isn’t successfully send.
The unsent messages are saved to the “Drafts”
and “No Number” is displayed, which indicates that
there is no destination.
▪ If you send a message, it will be saved to the
“Sent” after the message is successfully send.
15
Sent messages
▪ With this menu, you can view a list of the sent
message.
Broadcast Message
○ Receive mode: You can set activation “ON” or
“OFF”.
○ Channel settings
Select: You can select the channel you want.
Add: You can add the channel you want. Type
“Channel title” and “Channel ID”.
Edit: You can edit the existing channel.
Delete: You can delete the channel you want.
○ Languages: You can set the language type you
want.
○ Read messages: You can read the message.
! Note: The Voice mail service may not be available on
all networks. For more detail, please contact your
network service provider.
Templates
▪ Users can insert a preset phrase into a text
message which is being composed.
▪ When you are sending a message, you can
quickly use a preset phrase.
Message settings
▪ Text message
SIM/Memory status/Save sent message/Preferred
storage
▪ Multimedia message
Data account : You can activate or edit MMS
Profile.
Common settings: Compose/Sending/Retrieval/
16
Preferred storage/Memory status
▪ Service message
Enable push
Enable service loading
Portal Movil
Direct access to the Portal WAP / UMTS.
TELCEL
You can enjoy SIM Card Menu.
17
Fun
There are games for your enjoyment.
You can download the game which you want.
○ You can configure of game setting with “Java
Setting” menu
Ideas Box
Access to Applications section in America Movil which
may be, for example, Radio Ideas, Ideas Code, etc..
Phonebook
! Note: If the SIM card is changed, Phone show the
message “Copy all from SIM to Phone?”
The SIM card memory and phone memory is physically
separated but they are searched as a single entity.
○
View：
You can go through the list of telephone numbers stored
in the contact.
Send Text Message：
Send SMS to a number selected from the contact.
Send Multimedia Message：
Send MMS to a number selected from the contact.
Call：
Call to this contact.
Edit：Edit names, Number and etc.
Delete:
Delete the selected information/record.
Copy：
You can copy the selected information either from
18
Phone memory to SIM card memory or vice versa.
Move：
You can move the selected information either from
Phone memory to SIM card memory or vice versa.
Add to Blacklist :
add this contact to Blacklist
Caller groups
○ You can set different alert Associate ringtone,
Associate picture and Member list to each of the
groups. Navigation key is for you to choose specific
objects.
■ Phonebook settings
○ Preferred storage: You can select
“SIM/Phone/Both” to save the contact.
○ Speed dial : You can set a speed dial.
○ My number : You can edit or send your vCard.
○ Extra numbers : you can set Owner numbers,
Fixed dial and SOS numbers.
○ Memory status: You can see the memory status
of the contact list.
○ Copy contacts : Copy the records stored in the
memory of SIM card and the phone memory
respectively.
○ Move contacts : Move the records stored in the
memory of SIM card and the phone memory
respectively.
○ Delete all contacts : Delete all the records stored
in SIM card and Phone memory respectively.
! Note Options of Phonebook
If you press option soft key after locating the menu
19
cursor to the name you wish to do an action, the
following options are available.
Call center
Call history
In the call records menu screen, you can see the
number of Missed Calls, Dialed Calls, and Received
Calls.
Following options are available in the sub-menu of Call
History:
View : View the call history.
Call : Call back the caller.
Send text message : You can send SMS to the
selected number.
Send multimedia message : You can send MMS to the
selected number.
Save to Phonebook : Save the selected number to the
Phonebook.
Delete : Delete the selected record.
Delete all : Delete all records.
Advanced : Call timers/Call cost/Text msg.
counter/GPRS counter
All calls
○ This menu lets you view all calls. you can view the
details of the record by pressing the left soft key.
Then select view option. In the view screen you
can make a call to the number by pressing the
[Send] key.
Dialed calls
○ This menu lets you view the last some dialed calls.
Missed calls
○ This menu lets you view the latest missed calls.
20
Received calls
○ This menu lets you view the received calls.
Call settings
SIM1/SIM2 call settings
○ Call waiting : call waiting
○ Call divert : divert call
○ Call barring : call barring
○ Line switching : network line switch
○ Group List :
Advance Settings
○ Blacklist / Whitelist
○ Auto redial
○ IP dial
○ Call time display / Call time reminder
○ Auto quick end
○ Reject by SMS / Connect notice
○ Answer mode
Multimedia
Camera
○ In the camera main screen, you can take photos,
set camera options or view the saved pictures.
○ To take a photo, press “OK” key
○ If there is not enough memory to save a new
photo, you need to create free space by deleting
old pictures or other files.
Image viewer
21
○ You can view the saved photos in this menu.
○ The same as the option of Photos.
Video recorder
○ In the video main screen, you can take video.
○ To take a video, press “OK” key
○ If there is not enough memory to save a new video,
you need to create free space by deleting old
pictures or other files in the menu.
Media player
○ In the video/audio player, you can play the saved
video/audio clip.
○ You can set the corresponding options and enter
the video/audio player menu to see the saved
video/audio clip.
Photo editor
○ You can edit photos with color, size, effect.
Sound recorder
○ In the sound recorder, you can record the sound.
○ You can set the corresponding options and enter
the media player menu to see the saved audio clip.
22
FM radio
Press the left soft key for “Option” to bring the follow
menus:
▪ Channel list: You can define 1~30 channel shortcut.
▪ Manual input: You can input the frequency
manually. [./M] key is assigned to point “.”
▪ Auto search: FM Tuner search all available
channels for preset list.
▪ Setting :
You can select the following setting value:
Background play / Audio quality / Record storage
option
Tip! Press [navi up] key, turn on/off search
algorism
Press [navi down ]key, turn on/off power
▪ Record : you can record FM radio.
▪ File list : you can check file manager.
23
Organizer
Calendar
Press left soft key “Option” and the following are
available:
▪ Check way : You can view today schedules all. In
the menu, you can edit Date/Time, Description,
Alarm, Repeat, Repeat until, Location and Priority.
You can choose the due date by pressing Numeric
key. You can Delete the Schedule and Add a New
Schedule.
▪ View all : You can view all schedules recorded.
▪ Add event: You can add a new schedule.
▪ Delete event: You can delete a schedule.
▪ Jump to date: View the designated date.
▪ Go to today /Go to weekly view
24
Tasks
You can check the schedule arranged
on the current date. To edit schedule
Alarm
This menu allows you to set the alarm to ring at a
specific time. Five options are available. The
default mode is OFF. You may set one or all ON if
necessary. The time, Repeat, Snooze and Alert
type of each alarm can be set separately.
Notes
You can use to memo
■ Calculator
○ Enter numbers by pressing [0]—[9]. Press [.] for a
decimal point. Press the [Del] key to clear your
input.
○ You can press the Up, Down, Left, Right
navigation keys to enter the symbols of addition,
subtraction, multiplication and division.
○ Clear the latest input digit or result by pressing the
[Del] key. Long press the [Del] key to clear all the
input or the result.
○ Press the left soft key to calculate and the result
will appear on the screen.
Currency converter
You can use to memo
Stopwatch
Ebook reader
You can read electronic book
25
Bluetooth
You can turn on/off Bluetooth.
You can search new device for pairing.
○ Note! The precision of the calculator is limited for
the round off error.
File Manager
You can realize the management of images, video clips,
sounds, MP3, folder, etc. through this function menu.
It is to manage your files of audio, eBook, photos,
images, my music, received and video as default. It
works as “My Document” in Window O/S.
Select drive between phone and memory card (only in
case that you are using Micro SD). You can have the
following options:
○ Open: Open the folder. If you create a folder, it will
be generated in here.
○ New Folder: Create a folder as you want.
○ Format: Format all folders and its properties.
26
Settings
Many different features of your phone can be
customized to suit your preferences. All of these
features are accessed via the Setting menu.
User profiles
You can use the sound setting features to customize
various settings such as ring type, vibrator, and volume
depending on environments: General, Silent, Meeting.
Outdoor, Power Saving, My style.
Phone settings : Time and date, Schedule power on/off,
Language, Preferred writing language, Encoding,
Display, Dedicated key, Auto update time, Flight mode
Display
This menu is to set about display for idle screen,
wallpaper, power ON/OFF screen, screen saver.
You can set LCD backlight
Network settings
SIM1/SIM2 secrity, Phne security, Auto keypad lock,
certificate manager
Security settings
SIM1/SIM2 secrity, Phne security, Auto keypad lock,
certificate manager
Connectivity : Bluetooth, Data account, Data service
Restore factory settings
27
Service
WAP is a standard application protocol specially created
for mobile devices and gives fast and easy access to
Internet information and service. You can obtain rich
information by the WAP browser instead of a PC. Multi-
services are available such as Reservation, News,
Sports and Weather Broadcast.
○ Homepage: Once the connection is built, you will
link to the home page defined by yourself.
○ Bookmarks: Once you choose the menu
Bookmarks, you can connect to your favorite site
much more conveniently.
Recent pages: The phone keeps track of the recent
pages you log in. When you choose ‘Recent pages’,
your WAP browser will open the latest page at any time
MP3 AND MP4 INSTRUCTION
Connect your phone to the computer using the Shielded
USB cable.
If the phone is connected, the computer will show a sign
that an external memory device is connected. Select an
mp3 file of your choice from the computer and copy it to
the My Music folder in the USB memory. For mp4 files,
you can copy it to the Video Folder.
After canceling the connection of the external memory
device through the computer, disconnect the USB Cable
from the computer.
Use the follow the sequence “Menu > Multimedia >
Audio Player/Video Player” to activate the player.
In case play music with headset: To play music, short
28
press ear button of headset.
If you long press the ear button, the phone will dial the
last call made
29
TROUBLESHOOTING
If you meet a trouble on your phone operation, please
check the followings. These checks enable you to save
time and expense due to unnecessary after-service.
When Enter PIN appears at the power-up…
The PIN check is currently enabled. You must enter
the PIN supplied together with your SIM card. You can
disable the PIN check if you want, please see Security
Setting menu.
When Enter PUK appears at the power-up…
PUK (Personal Unblocking Key) is used to unblock
the blocked SIM card due to incorrectly entered PIN.
PUK code is composed of 8 digits, and usually provided
with your SIM card. If the PUK code is entered
incorrectly several times in succession, PUK will be
blocked and your SIM card will be automatically lock-up
and the SIM Blocked message will be displayed. Once
you see the message, you need to contact your network
service provider for a new SIM card.
When Insert SIM screen appears at the power-up…
Please, check that your SIM card is inserted properly.
When Enter Lock Code appears at the power-up…
Your phone is phone locked. You must enter the Lock
Code supplied together with your phone.
When No Service appears…
You probably are in the area out of the coverage of a
GSM/ GPRS network.
When Emergency Only appears even though a number
30
of the signal bar are indicated…
You probably are in the area out of the coverage of
your home GSM, GPRS network. You probably are in
the coverage of another GSM, GPRS network but you
are not allowed to be registered to the network.
If any tone is not generated when you press a keypad…
You need to check the quick silence mode setting. If
you can find icon on the top of the main display
screen it is the quick silence mode. By pressing and
holding [Space] key on the idle screen, you can switch it
off. You need to check the Key Tone Type of Sound
Setting menu. You need to check Key Tone Volume of
the profile option that you have set on Profiles menu.
If an audible alert is not made when a call is received…
You need to check the quick silence mode setting. If
you can find icon on top of the main display screen
it is the quick silence mode. By pressing and holding
[Space] key on the idle screen, you can switch it off. You
need to check Ring Type and Ring Volume of the profile
option that you have set on Profiles menu.
If an audible alert is not made when an alarm is
expired…
You need to check the quick silence mode setting. If
you can find icon on top of the main display screen
it is quick silence mode. By pressing and holding [Space]
key on the idle screen, you can switch it off.
If an outgoing call is not made…
You have probably set an outgoing calls barring
option. You need to check Call Barring menu. Otherwise,
you have probably set to Hide Number in Caller Number
31
menu of Call Setting menu. In some network, when you
make a call with hiding the telephone number, the
network does not allow to make the call.
If an incoming call is not made…
You have probably set an incoming calls barring
option. You need to check Call Barring menu.
If an outgoing SMS message is not sent…
You need to check the Message Center option in SMS
Setting menu.
If all audible key tones are muted and all audible alerts
are changed to vibrator alert…
You need to check the quick silence mode setting. If
you can find icon on top of the main display screen
it is the quick silence mode. By pressing and holding
[Space] key on the idle screen, you can switch it off.
If some audible action is not prompted on a menu of
Sound Setting menu…
You need to check the quick silence mode setting. If
you can find icon on top of the main display screen
it is the quick silence mode. By pressing and holding
[Space] key on the idle screen, you can switch it off.
If the image on the screen is blurred when you try to
take a picture…
You need to check that the protection film is detached
or the lens is clean. To remove fingerprints or other
stains, wipe the lens with soft cloth.
32
LIMITED WARRANTY STATEMENT
1. WHAT THIS WARRANTY COVERS:
IDENTITY offers you a limited warranty that the
enclosed subscriber unit will be free from defects in
material and workmanship, according to the following
terms and conditions:
The limited warranty extends only to the original
purchaser of the product and is not assignable or
transferable to any subsequent purchaser/end user.
This warranty is good only to the original purchaser of
the product during the warranty period as long as it is in
the purchased local area.
The external housing and cosmetic parts shall be free of
defects at the same time of shipment and, therefore,
shall not be covered under these limited warranty terms.
Upon request from IDENTITY, the customer must
provide information reasonably prove the date of
purchasing.
The customer shall bear the cost of shipping the product
to the Customer Service Center of IDENTITY. IDENTITY
shall bear the cost of shipping the product back to the
customer after the completion of service under this
limited warranty.
2. WHAT THIS WARRANTY DOES NOT COVER:
Defects or damages resulting from use of the product in
other than its normal and customary manner.
Defects or damages from abnormal use, abnormal
conditions, improper storage, exposure to moisture or
dampness, unauthorized modifications, unauthorized
connections, unauthorized repair, misuse, neglect,
abuse, accident, alteration, improper installation, or
other acts which are not the fault of IDENTITY, including
damage caused by shipping, blown fuses, spills of food
33
or liquid.
Breakage or damage to antennas unless caused directly
by defects in material or workmanship.
That the Customer Service Department at IDENTITY
was not notified by consumer of the alleged defect or
malfunction of the product during the applicable limited
warranty period.
Products which have had the serial no. removed or
made illegible.
This limited warranty is in lieu of all other warranties,
express or implied either in fact or by operations of law,
statutory or fitness for a particular use.
Damage resulting from use of non-IDENTITY approved
accessories.
All plastic surfaces and all other externally exposed
parts that are scratched or damaged due to normal
customer use.
Products operated outside published maximum ratings.
Products used or obtained in a rental program.
Consumables (such as fuses).
34
3. STATE LAW RIGHT:
No other express warranty is applicable to this product.
THE DURATION OF ANY IMPLIED WARRANTIES,
INCLUDING THE IMPLIED WARRANTY OF
MARKETABILITY, IS LIMITED TO THE DURATION OF
THE EXPRESS WARRANTY HEREIN. IDENTITY
SHALL NOT BE LIABLE FOR THE LOSS OF THE USE
OF THE PRODUCT, INCONVENIENCE, LOSS OR ANY
OTHER DAMAGES, DIRECT OR CONSEQUENTIAL,
ARISING OUT OF THE USE OF, OR INABILITY TO
USE, THIS PRODUCT OR FOR ANY BREACH OF ANY
EXPRESS OR IMPLIED WARRANTY, INCLUDING THE
IMPLIED WARRANTY OF MARKETABILITY
APPLICABLE TO THIS PRODUCT.
Some states do not allow the exclusive of limitation of
incidental or consequential damages or limitations on
how long an implied warranty lasts: so these limitations
or exclusives may not apply to you. This warranty gives
you specific legal rights and you may also have other
rights which vary from state to state.
4. HOW TO GET WARRANTY SERVICE:
To obtain warranty service, please contact the retailer
where you purchased this handset.
FCC Regulations:
This mobile phone complies with part 15 of the FCC
Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference that may
cause undesired operation.
This mobile phone has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
35
provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses and can radiated radio frequency
energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation If
this equipment does cause harmful interference to radio
or television reception, which can be determined by
turning the equipment off and on, the user is
encouraged to try to correct the interference by one or
more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and
receiver.
-Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV
technician for help.
Caution: Changes or modifications not expressly
approved by the party responsible for compliance could
void the user‘s authority to operate the equipment.
RF Exposure Information (SAR)
This phone is designed and manufactured not to exceed
the emission limits for exposure to radio frequency (RF)
energy set by the Federal Communications Commission
of the United States, Industry Canada of Canada.
During SAR testing, this device was set to transmit at its
highest certified power level in all tested frequency
bands, and placed in positions that simulate RF
36
exposure in usage against the head with no separation,
and near the body with the separation of 15 mm.
Although the SAR is determined at the highest certified
power level, the actual SAR level of the device while
operating can be well below the maximum value. This
is because the phone is designed to operate at multiple
power levels so as to use only the power required to
reach the network. In general, the closer you are to a
wireless base station antenna, the lower the power
output.
The exposure standard for wireless devices employing a
unit of measurement is known as the Specific
Absorption Rate, or SAR. The SAR limit set by the
FCC is 1.6W/kg, and 1.6W/kg by Industry Canada.
This device is complied with SAR for general population
/uncontrolled exposure limits in ANSI/IEEE C95.1-1992
and Canada RSS 102, and had been tested in
accordance with the measurement methods and
procedures specified in OET Bulletin 65 Supplement C,
and Canada RSS 102. This device has been tested, and
meets the FCC, IC RF exposure guidelines when tested
with the device directly contacted to the body.
The FCC has granted an Equipment Authorization for
this model phone with all reported SAR levels evaluated
as in compliance with the FCC RF exposure
guidelines. SAR information on this model phone is on
file with the FCC and can be found under the Display
Grant section of www.fcc.gov/oet/ea/fccid after
searching on FCC ID: WVBA821X.
For this device, the highest reported SAR value for
usage against the head is 0.77 W/kg, for usage near
37
the body
is 1.13 W/kg.
While there may be differences between the SAR levels
of various phones and at various positions, they all meet
the government requirements.
SAR compliance for body-worn operation is based on a
separation distance of 15 mm between the unit and the
human body. Carry this device at least 15 mm away
from your body to ensure RF exposure level compliant
or lower to the reported level. To support body-worn
operation, choose the belt clips or holsters, which do
not contain metallic components, to maintain a
separation of 15 mm between this device and your body.
RF exposure compliance with any body-worn accessory,
which contains metal, was not tested and certified, and
use such body-worn accessory should be avoided.
