Quick Start Guide
Dell™ Bluetooth®/SD Reader USB Adapter
Thank you for purchasing a Dell Bluetooth/SD Reader USB Adapter. Before you
begin to use the Dell Bluetooth/SD Reader USB Adapter, you will require the
following items:
A computer with a USB port and one of the following operating systems:
Microsoft® Windows® XP or Windows 2000.
The Software Installation Compact Disc included with your Dell
Bluetooth/SD Reader USB Adapter.
Getting Started with your Dell Bluetooth/SD Reader USB
Adapter
NOTE: If you did not purchase this device with a new Dell computer, please
start at Step 1: Installing the Software. If you did purchase this device with a
new Dell computer, please skip to Step 2: Inserting the Adapter.
Step 1: Installing the Software
NOTE: This installation is required before you insert the adapter into the USB
port of your computer.
1. Insert the Dell Bluetooth/SD Reader USB Adapter installation compact
disc (CD) into the CD-ROM or DVD drive of your computer.
2. If the Main Menu screen appears automatically, select Install
software and click OK. If the Main Menu screen does not appear
automatically, click Start, click Run, type x:\setup.exe (where x is the
CD-ROM or DVD drive letter of your computer), and click OK.
3. Click Next, click Finish, and then restart your computer.
4. Right-click the Bluetooth icon in the taskbar notification area (system
tray) and click Start Using Bluetooth. Follow the instructions provided
by the Initial Bluetooth Configuration Wizard.
1.
ENGLISH
Review Copy
2
Step 2: Inserting the Adapter
Insert the Dell Bluetooth/SD Reader USB Adapter into the USB port of your
computer.
If you started at Step 1: Installing the Software
The Found New Hardware Wizard detects and installs the device. When the
installation is finished, you are ready to begin using the SD Reader and the
Bluetooth features of this computer.
If you skipped Step 1: Installing the Software, you are ready to begin using the
SD Reader and the Bluetooth features of this computer.
NOTE: Before you begin, however, please review the Dell Bluetooth/SD
Reader USB Adapter User’s Guide. This document provides important
information and instructions that will help you do the things you want to do with
your SD Reader and your Bluetooth enabled computer.
Glossary
Authentication A Bluetooth security feature that is used to verify identity; it requires a
Bluetooth PIN Code from the remote device.
Authorization A Yes-or-No Bluetooth security feature that requires operator intervention to
avoid having the connection time out and fail.
Bluetooth
device
Bluetooth enabled hardware such as a computer, printer, fax, mouse,
keyboard, cell phone, headset, or PDA.
Bluetooth PIN
Code
The alphanumeric string (up to 16 characters) that is typed to respond to a
Bluetooth PIN Code Request. Also referred to as a Passkey.
Bluetooth® A short-range (9.14 meters/30 feet) networking protocol that allows enabled
devices to automatically recognize each other. Bluetooth wireless
technology allows quick and easy connectivity of Bluetooth enabled devices.
Client
Applications
Software applications on this computer that allow this computer to use the
Bluetooth services provided by remote Bluetooth devices.
Link Key An internally generated unique security key (based on a Passkey, the
Bluetooth Device Address, and an internally generated random number) that
is exchanged by paired devices as proof of identity before a connection is
established.
Local Services Services that this computer provides to other Bluetooth devices.
Paired Devices Bluetooth devices must be paired before they can connect. Paired devices
share a unique Link Key, which they exchange each time they connect.
Secure
Connection
A setting that requires a Passkey or Link Key each time you attempt to make
a connection. All data exchanged over the Bluetooth connection is
encrypted. Depending on other configuration options, authorization may also
be required.
ENGLISH
Review Copy
3
Support
For Technical Support for your Dell Bluetooth/SD Reader USB Adapter, contact
your local Dell technical support center at www.support.dell.com. The local
contact details are referred to in the user’s guide or owner’s manual that came
with your computer.
Information in this document is subject to change with notice.
© 2003 Dell Inc. All rights reserved.
Reproduction of this document in any manner whatsoever without the
written permission of Dell Inc. is strictly forbidden.
Trademarks used in this text: Dell is a trademark of Dell Inc. Microsoft and
Windows are registered trademarks of Microsoft Corporation. Other
trademarks and trade names may be used in this document to refer to
either the entities claiming the marks and names or their products. Dell Inc.
disclaims any proprietary interest in trademarks and trade names other
than its own.
August 2003
Dell P/N:
Rev. A02
3.
ENGLISH
Review Copy
Regulatory Statements for BCM92035BTSD
USA
FCC Part 15 Notice
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Warning: This device has been tested and found to comply with the limits for a
Class B digital device pursuant to Part 15 of the Federal Communications
Commissions Rules and Regulations. These limits are designed to provide
reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try and correct the interference by one or more of the following
measures:
. Relocate this device
. Increase the separation between the device and the receiver
. Connect the device into an outlet on a circuit different from that of other
electronics
. Consult the dealer or an experienced radio technician for help.
FCC Radiation Exposure Statement
Important Note: To comply with FCC RF exposure compliance requirement, the
antenna used for this transmitter must not be co-located or operating in
conjunction with any other transmitter.
Caution: This product does not contain any user serviceable components.
Changes or modifications not expressly approved by Broadcom Corporation
could void regulatory certifications and approvals and the user’s authority to
operate the equipment.
Canada
Industry Canada Notice
This device complies with Canadian RSS-210.
To prevent radio interference to the licensed services , this device is intended to
be operated indoors aand away from windows to provide maximum shielding.
Equipment (or the transmit antenna) that is installed outside is subject to
licensing.
The installer of this radio equipment must ensure that the antenna is located or
pointed such that is does not emit RF field in excess of Health Canada limits for
the general population; consult safety code 6, obtainable from Health Canada’s
website www.hc-sc.gc.ca/rpb
Avis de conformité à la réglementation d’Industrie Canada
Cet appareil est conform a la norme CNR-210 du Canada.
Pour empêcher que cet appareil cause du brouillage au service faisant l’objet
d’une licence, cet appareil doit être utilisé à l’intérieur seulement et devrait êtra
placé loin des fenêtres afin de fournir un écran de blindage maximal.
L’installateur du présent matériel radio doit s’assurer que l’antenne est située ou
pointée de maniere a ce que cette derniére n’émette pas de champs
radioélectriques supérieurs aux limites spécifées par Santé Canada pour le
grand public; condulter le code de sécurité 6, disponible sur le site Web de
Santé Canada, a l’address suivante: www.hc-sc.gc.ca/rpb.
European Community (EC) Directives Conformity and
Restrictions
This equipment is marked with the symbol and can be used throughout
the European community.
This indicates compliance to the R&TTE Directive 1999/5/EC and meets the
following technical specifcations:
EN 300 328 – Electromagnetic compatibility and Radio spectrum Matters (ERM);
Wideband Transmission Systems; Data transmission equipment operating in the
2,4GHz ISM band and using spread spectrum modulation techniques;
Harmonized EN covering essential requirements under article 3.2 of the R&TTE
directive.
EN 301 489-17 – Electromagnetic compatibility and Radio spectrum
Matters(ERM); Electromagnetic Compatibility (EMC) standard for radio
equipment and services; Part 17 Specific conditions for Wideband data and
HIPERLAN equipment.
EN 60950 – Information technology equipment, Safety.
Safety
This device has been been certified to the following safety standards for
Information technology equipment. It is intended for use in IT equipment which is
certified to these or equivalent standards:
UL 60950:2000
CAN/CSA-C22.2 No. 60950-00
IEC 60950
EN 60950
