Contents
UserMan_Host1
Aspire Notebook Series
Quick Guide
Product registration
When using your product for the first time, it is recommended that you immediately
register it. This will give you access to some useful benefits, such as:
•Faster service from our trained representatives.
•Membership in the Acer community: receive promotions and participate in customer
surveys.
•The latest news from Acer.
Hurry and register, as other advantages await you!
How to register
To register your Acer product, please visit www.acer.com. Select your country, click
PRODUCT REGISTRATION and follow the simple instructions.
You will also be asked to register your product during the setup process, or you can
double-click the Registration icon on the desktop.
After we receive your product registration, you will be sent a confirmation email with
important data that you should keep in a safe place.
Obtaining Acer accessories
We are happy to inform you that Acer's warranty extension program and Notebook
accessories are available online. Come and visit our online shop and find what you need
at store.acer.com.
The Acer store is being progressively rolled out, and, unfortunately may not be available
in some regions. Please check back regularly to see when it will be available in your
country.
Model number: __________________________________
Serial number: ___________________________________
Date of purchase: ________________________________
Place of purchase: ________________________________
© 2011. All Rights Reserved.
Aspire Notebook Series Quick Guide
Original Issue: 07/2011
Acer recommends...
Productivity Software
Work Great with Microsoft® Office 2010 - Express your ideas, solve problems and simplify everyday projects
with Office 2010.
Photo editing - Easily edit and print your photos with Windows Live Photo Gallery. Then share them on Facebook,
YouTube or Windows Live.
Search & Decide with Bing - Find and organize the answers you need using Bing™, so you can make faster, more
informed decisions.
3
English
First things first
We would like to thank you for making an Acer notebook your choice for
meeting your mobile computing needs.
Your guides
To help you use your Acer notebook, we have designed a set of guides:
First off, the setup poster helps you get started with setting up your
computer.
The Aspire User’s Manual contains useful information applying to your
new computer. It covers basic topics such as using the keyboard and
audio, etc.
The Quick Guide introduces you to the basic features and functions of
your new computer. For more on how your computer can help you to be
more productive, please refer to the Aspire User’s Manual. This guide
contains detailed information on such subjects as system utilities, data
recovery, expansion options and troubleshooting. In addition it contains
warranty information and the general regulations and safety notices for
your notebook. It is available from your computer desktop; simply double-
click the Acer User’s Manual icon.
4
English
Your Acer notebook tour
After setting up your computer as illustrated in the setup poster, let us
show you around your new Acer notebook.
Top view
#Icon Item Description
1 Display screen Also called Liquid-Crystal Display (LCD),
displays computer output.
2Power button /
indicator
Turns the computer on and off. Indicates the
computer's power status.
3 Microphone Internal microphone for sound recording.
4 Keyboard For entering data into your computer.
5Touchpad
Touch-sensitive pointing device.
The lower left and right of the touchpad
react like left and right selection buttons;
press down on either area to perform a left
or right click.
5
English
Rear view
Left view
6
Power indicator Indicates the computer’s power status.
Battery indicator
Indicates the computer’s battery status.
Charging: The light shows amber when the
battery is charging.
Fully charged: The light shows blue when in
AC mode.
7 Integrated webcam Web camera for video communication.
#Icon Item Description
1 DC-in jack Connects to an AC adapter.
2HDMI portSupports high-definition digital video
connections.
3 USB 2.0 ports Connect to USB 2.0 devices (e.g., USB
mouse, USB camera).
#Icon Item Description
1 Headset/speaker jack Connects to audio devices (e.g., speakers,
headphones) or a headset with microphone.
#Icon Item Description
6
English
Right view
Base view
Environment
#Icon Item Description
1 2-in-1 card reader
Accepts one Secure Digital (SD or
SDHC) card or one MultiMediaCard
(MMC).
Note: To remove the card, simply pull it
from the slot.
#Icon Item Description
1 Battery reset pinhole
Insert a paperclip into the hole to reset the
computer (simulates removing and
reinstalling the battery).
2 Speakers Deliver stereo audio output.
•Temperature:
•Operating: 5 °C to 35 °C
•Non-operating: -20 °C to 65 °C
•Humidity (non-condensing):
•Operating: 20% to 80%
•Non-operating: 20% to 80%
