Lenovo regulatory notice for wireless adapters - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
This manual contains regulatory information for the following Lenovo products.
• Lenovo Yoga 2 Pro (13")
The following wireless modules are supported on Lenovo Yoga 2 Pro (13"):
• 7260NGW BN
• 7260NGW
• BCM94352Z
Read first — regulatory information
Please read this document before you use the Lenovo computer. Lenovo computer complies
with the radio frequency and safety standards of any country or region in which it has been
approved for wireless use. You must install and use your computer in strict accordance with
the instructions as described hereafter.
Veuillez lire ce document avant d’utiliser l’ordinateur Lenovo. L’ordinateur Lenovo est
conforme aux normes de sécurité et de radiofréquence du pays ou de la région où son
utilisation sans fil est agréée. Vous devez installer et utiliser votre ordinateur en respectant
scrupuleusement les instructions décrites ci-après.
USA — Federal Communications Commission (FCC)
I. Factory preinstalled Wireless LAN/WiMAX module
• FCC ID: PD97260NGU (Model: 7260NGW BN)
• FCC ID: PD97260NGU (Model: 7260NGW)
• FCC ID: QDS-BRCM1076 (Model: BCM94352Z)
Wireless LAN Mini PCI Express Cards marketed in the USA and Canada do not support nor
function in the extended channels (12ch, 13ch).
i) The FCC RF Exposure compliance:
The radiated output power of the Wireless LAN/WiMAX Mini PCI Express Card authorized
to use for the your Lenovo computer is far below the FCC radio frequency exposure limits.
Nevertheless, it shall be used in such a manner that the potential for human contact during
normal operation is minimized as follows:
ii) FCC ID of wireless module:
On the bottom side of your Lenovo computer, you will find an indicator label of the format
“Contains Transmitter Module: FCC ID XXXX”, where XXXX represents the FCC ID that
corresponds to your preinstalled Wireless LAN/WiMax module.
Note: The transmission diversity function is implemented for this product. For WLAN cards (Model:
7260NGW BN, 7260NGW, BCM94352Z) using Main and Auxiliary antennas for transmission in
the IEEE 802.11 b/g transmission mode, radio frequency energy is not emitted simultaneously
from both Main and Auxiliary antennas. One of the antennas is selected automatically or
manually (by users) to have good quality of radiocommunication (transmission diversity
function). For WLAN card 7260NGW BN, 7260NGW and BCM94352Zin the IEEE 802.11 a/b/g,
or MIMO (Multiple In Multiple Out ) transmission mode, the radio frequency energy is emitted
from Main antenna.
2
iii) Radio Frequency interference requirement:
The devices have been tested and found to comply with the limits for a Class B digital
device pursuant to FCC Part 15 Subpart B. Refer to “Electronic emission notices” on page 4.
The model 7260NGW BN, 7260NGW and BCM94352Z underwent the certification process
with each respective FCC ID number listed in “I. Factory preinstalled Wireless LAN/
WiMAX module” on page 1.
When you use a wireless LAN module in the 802.11 a/n transmission mode:
• Each device is restricted to indoor use due to its operation in the 5150 to 5250 MHz
frequency range. FCC requires these products to be used indoors for the frequency range
5150 to 5250 MHz to reduce the potential for harmful interference to co-channel Mobile
Satellite systems.
• High power radars are allocated as primary users of the 5250 to 5350 MHz and 5650 to
5850 MHz bands. These radar stations can cause interference with and/or damage this
device.
II. Simultaneous use of RF transmitters
Please make sure of the following conditions on use of wireless features:
1. When you use any other RF option device, all wireless features in your Lenovo computer
are required to be turned off.
2. Users must follow the RF Safety instructions on wireless option devices that are included
in the RF option device's user's manual.
Canada — Industry Canada (IC)
IC Certification number
I) Factory preinstalled Wireless LAN modules:
• IC: 1000M-7260NG (Model: 7260NGW BN)
• IC: 1000M-7260NG (Model: 7260NGW)
• IC: 4324A-BRCM1076 (Model: BCM94352Z)
Wireless LAN Mini PCI Express Cards marketed in the USA and Canada do not support nor
function in the extended channels (12ch, 13ch).
There is no certification number of Industry Canada for Mini PCI Express Card shown on the
enclosure of your Lenovo computer. Instead you will find an indicator label pointing to the
location of the IC Certification number on the bottom side of your Lenovo computer. This label
will be of the format “Contains Transmitter Module: Canada IC: XXXX”, where XXXX
represents the IC ID that corresponds to your preinstalled WLAN module.
II) Low power license-exempt radiocommunication devices (RSS-210):
Operation is subject to the following two conditions:
1. This device may not cause interference, and
2. this device must accept any interference, including interference that may cause undesired
operation of the device.
The transmitter devices have been designed to operate with the antennas integrated in
Lenovo computer, and having a maximum gain of within 3 dBi.
III) Exposure of humans to RF fields (RSS-102):
Lenovo computers employ low gain integral antennas that do not emit RF field in excess of
Health Canada limits for the general population; consult Safety Code 6, obtainable from
Health Canada’s Web site at www.hc-sc.gc.ca/rpb
3
The radiated energy from the antennas connected to the wireless adapters conforms to the IC
limit of the RF exposure requirement regarding IC RSS-102, Issue 2 clause 4.2. The maximum
antenna gain permitted for devices in the 5250-5350 MHz, 5470-5725 MHz, and 5725-5825
MHz bands complies with the e.i.r.p. limit in section A9.2 of RSS-210. When you use a
Wireless LAN and Bluetooth Combo module adapter in the 802.11 a/n transmission mode:
harmful interference to co-channel Mobile Satellite systems. 5350 MHz and 5650-5850 MHz
bands and these radars could cause interference and/or damage to LELAN (Licence-Exempt
Local Area Network) devices.
Numéro d’homologation IC
I) Modules de réseaux local sans fil pré-installé à l’usine:
• IC: 1000M-7260NG (Model: 7260NGW BN)
• IC: 1000M-7260NG(Model: 7260NGW)
• IC: 4324A-BRCM1076 (Model: BCM94352Z)
Les cartes de réseau local sans fil Express mini-PCI commercialisées aux Etats-Unis et au
Canada ne prennent pas en charge les canaux étendus (12ch, 13ch) et ne fonctionnent donc
pas sur de tels canaux.
Le boîtier de votre ordinateur Lenovo ne comporte pas de numéro d’homologation IC (Industry
Canada) pour la carte mini-PCI Express ; mais sous votre Lenovo, vous trouverez une étiquette
indicatrice pointant vers l’emplacement du numéro d’homologation IC. L’étiquette se présente
sous la forme “Contains Transmitter Module: Canada IC: XXXX” où XXXX représente l’ID IC qui
correspond au module WLAN préinstallé.
II) Remarque relative aux appareils de communication radio de faible puissance sans
licence (CNR-210):
Le fonctionnement de ce type d’appareil est soumis aux deux conditions suivantes:
1. Cet appareil ne doit pas perturber les communications radio, et
2. cet appareil doit supporter toute perturbation, y compris les perturbations qui pourraient
provoquer son dysfonctionnement.
Les périphériques d’émission sont conçus pour fonctionner avec des antennes intégrées aux
Lenovo et ayant un gain maximal de moins de 3 dBi.
III) Exposition des êtres humains aux champs radioélectriques (RF) (CNR-102):
L’ordinateur Lenovo utilise des antennes intégrales à faible gain qui n’émettent pas un
champ électromagnétique supérieur aux normes imposées par le Ministére de la santé
canadien pour la population. Consultez le Safety Code 6 sur le site Web du Ministére de la
santé canadien à l’adresse “www.hc-sc.gc.ca/rpb”.
L’énergie émise par les antennes reliées aux adaptateurs sans fil respecte la limite d’exposition
aux radiofréquences telle que définie par Industrie Canada dans la clause 4.2 du document CNR-
102. Le gain d'antenne maximal autorisépour les appareils dans les bandes de fréquence 5250-
5350 MHz, 5470-5725 MHz et 5725-5825 MHz est conforme àla limite p.i.r.e (puissance isotrope
rayonnée équivalente) définie dans la section A9.2 du CNR-210. Lorsque vous utilisez un
adaptateur de module combiné Bluetooth et LAN sans fil dans le mode de transmission 802.11
a/n: intérieur afin de réduire les risques de perturbations électromagnétiques gênantes sur les
systèmes de satellite mobile dans un même canal. qu'ils sont prioritaires) des bandes 5250-5350
MHz et. 5650-5850 MHz. lls peuvent provoquer des perturbations électromagnétiques sur les
appareils de type LELAN (réseau de communication local sans licence) ou les endommager.
4
Electronic emission notices
Federal Communications Commission (FCC) Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
• Consult an authorized dealer or service representative for help.
Lenovo is not responsible for any radio or television interference caused by unauthorized
changes or modifications to this equipment. Unauthorized changes or modifications could
void the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Responsible Party:
Lenovo (United States) Incorporated
1009 Think Place - Building One
Morrisville, NC 27560
Telephone: 1-919-294-5900
Industry Canada Class B Emission Compliance Statement
This Class B digital apparatus complies with Canadian ICES-003.
Avis de conformité à la réglementation d’Industrie Canada
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
Trademarks
Lenovo and the Lenovo logo are trademarks of Lenovo in the United States, other countries,
or both.
Other company, product, or service names may be trademarks or service marks of others.
Note: The compliance of the FCC Part 15 Subpart B for Models: 7260NGW BN, 7260NGW and
BCM94352Z, was proceeded by certification, thus the FCC ID: PD97260NGU, QDS-BRCM1076,
respectively include both compliances of Part 15 Subpart B and C/E.
