WICED Sense Kit
Quick Start
Broadcom Corporation
5300 California Avenue
Irvine, CA 92617
© 2014 by Broadcom Corporation
All rights reserved
Printed in the U.S.A.
Broadcom®, the pulse logo, Connecting everything®, and the Connecting everything
logo are among the trademarks of Broadcom Corporation and/or its affiliates in the
United States, certain other countries and/or the EU. Any other trademarks or trade
names mentioned are the property of their respective owners.
Broadcom® Corporation reserves the right to make changes without further
notice to any products or data herein to improve reliability, function, or design.
Information furnished by Broadcom Corporation is believed to be accurate
and reliable. However, Broadcom Corporation does not assume any liability
arising out of the application or use of this information, nor the application or
use of any product or circuit described herein, neither does it convey any
license under its patent rights nor the rights of others.
Broadcom® August 6, 2014 • MMPWICED-Smart-DQSG100-R
Introduction
The WICED Sense TAG is made up of the BCM20737S
Bluetooth Low Energy SoC and five ST Microelectronics
sensors: gyroscope, accelerometer, eCompass, pressure,
and humidity/temperature. The BCM20737S connects directly
to the sensors without the need for an external micro-
processor. The WICED Sense smartphone application
receives and displays real-time data from the sensors.
Kit Contents
1. One WICED Sense TAG
2. One USB to Micro USB cable
3. This document, which contains information about how to
download all required software, including the:
• WICED Sense sample application for iOS.
• WICED Smart Software Development Kit 2.X
Setup
Pair the WICED Sense TAG and an iPhone
1. From the iPhone 4S (or greater):
• Go to the iTunes App Store.
• Search for and download the WICED Sense app.
2. When the download is complete, start the WICED Sense
app.
3. On the WICED Sense TAG:
• Remove the plastic shipping strip in the battery
compartment (pull the tab).
• Press the Wake button. See the WICED Sense TAG
illustration for the location of the Wake button.
4. On the phone, the app will display the WICED Sense kits
that are ready to pair. Tap the desired kit to complete
pairing.
Tap the information icon ("i") in the lower-left corner of the
iPhone screen for application information.
Kit Components
Humidity
Sensor
USB Port
(Not Visible)
Wake
Button
App
Button
USB Cable
Sense Tag iPhone App UI
Buzzer On
the Back
For additional information and/or to download the WICED
Smart SDK visit:
http://www.broadcom.com/wicedsense
For additional support and/or to download the WICED Sense
reference design package, visit:
http://community.broadcom.com/community/wiced-smart
Note
ST Microelectronics Devices used in the WICED Smart Kit
(http://www.st.com/web/en/catalog/sense_power/...):
• Gyroscope (L3GD20) – ...FM89/SC1288/PF252443
• Accelerometer (LIS3DSH) – ...FM89/FM89/SC444/PF252716
• eCompass (LSM303D) – ...FM89/SC1449/PF253884
• Pressure sensor (LPS25H) – ...FM89/SC1316/PF255230
• Humidity Temperature sensor (HTS221) – ...FM89/SC1718/PF260067
