Broadxent CB2455 BLUETOOTH HEADSET User Manual Wireless Bluetooth headset cutdown
Broadxent Pte Ltd. BLUETOOTH HEADSET Wireless Bluetooth headset cutdown
USERS MANUAL
1
Creative Headset CB2455 With
Bluetooth Technology
Microphone
Earpiece
Light Emitting
Diode (LED)
Power adapter jack
Multi-function
button
Volume
Increase
button
Volume Decrease button
When your headset is not in use, clip the earpiece to your headset as shown below.
Wireless Bluetooth headset_cutdown.fm Page 1 Wednesday, December 29, 2004 6:11 PM
2
Getting Started
1
1Charge your headset
Fully charge your headset before using it for the first time. This takes approximately five
hours. Consequently, charging your headset takes three hours.
Reading your headset’s LED
The table below shows you the various LED indications available.
LED Meaning
Red On (when charging) Battery is charging.
Blinks every five
seconds Battery low.
Blue
On (when charging) Fully charged.
Blinks once every five
seconds Headset is paired to your mobile phone and is in standby mode.
Blinks once every 15
seconds Call in progress.
Blue and
red Blinks alternately Headset is in pairing mode and is ready for pairing.
OR
Headset is paired, connected and the microphone is muted.
Wireless Bluetooth headset_cutdown.fm Page 2 Wednesday, December 29, 2004 6:11 PM
3
2
2Pair your headset and mobile phone
1. If your headset is turned on, turn it off by pressing and holding the Multi-function
button until the LED turns red.
2. Place your headset within one meter of your mobile phone.
3. Press and hold the Multi-function button and one of the Volume buttons
simultaneously, until the LED alternately blinks red and blue.
4. Turn on your mobile phone’s Bluetooth feature. For more information, see your
mobile phone’s documentation.
5. Set your mobile phone to detect Bluetooth devices.
6. From the list that appears, select CB2455Creative.
7. When prompted for a passkey, enter 0000 to complete pairing.
• If the pairing is not completed within two minutes, your headset turns itself off
automatically.
Wireless Bluetooth headset_cutdown.fm Page 3 Wednesday, December 29, 2004 6:11 PM
4
Using Your Headset
*Some features are available only for certain mobile phones. Refer to your mobile phone’s documentation.
Usage Action
Turning on
headset Press and hold the Multi-function button for three seconds. The LED turns
blue.
Turning off
headset Press and hold the Multi-function button until the LED turns red.
Making a call Make sure that your headset is turned on (it may be in standby mode when
inactive), dial the number, and then proceed with your call.
Answering a call If there is an incoming call, your earpiece and mobile phone rings, and your
headset beeps. Press the Multi-function button.
Ending a call Press the Multi-function button to end a call. You can also end a call using
your mobile phone.
Voice Dial* Press the Multi-function button and when you hear a beep, say the voice
tag.
Last Number
Redial* Press the Multi-function button twice within one second.
Adjusting volume Press the Volume Increase or Volume Decrease button to gradually
increase or decrease the volume.
Rejecting a call Press and hold the Multi-function button for three seconds.
Putting a call on
hold Press and hold the Volume Increase and Volume Decrease buttons
simultaneously, for one second.
Switching between
calls Press the Volume Increase and Volume Decrease buttons
simultaneously.
Mute Press and hold one of the Volume buttons until the LED alternately blinks
red and blue.
To unmute the microphone, press and hold one of the Volume buttons until
the LED blinks blue.
Clearing all
headset pairings
Make sure that your headset is turned off. Press and hold one of the Volume
buttons for 20 seconds. The LED alternately blinks red and blue. Press and
hold one of the Volume buttons again until you hear two beeps. Charge
your headset for a few seconds to reset your headset. All current pairings
are cleared.
Wireless Bluetooth headset_cutdown.fm Page 4 Wednesday, December 29, 2004 6:11 PM
5
Frequently Asked Questions
The headset fails to pair with my mobile phone.
• Check that your mobile phone’s Bluetooth feature is turned on.
• Make sure that your headset is turned on, fully charged and is within one meter of your
mobile phone.
• Recharge your headset and mobile phone, and try pairing both devices again.
What causes poor signal quality?
Keep your headset within 10 meters of your mobile phone and make sure that there are no
obstructions, such as walls or other electronic devices, between your headset and mobile
phone (for example, cordless phones and some wireless networking devices).
Will my headset interfere with my computer or car’s electronic devices?
You should not experience any interference when using your headset near standard
consumer-grade electronics equipment.
Can other Bluetooth-enabled mobile phone users accidentally tune in on my
conversation?
When you pair your headset to your mobile phone, you are creating a private link between
both devices. The wireless Bluetooth technology prevents monitoring by third parties.
Can I use my headset with other Bluetooth products?
Your headset will work with all Bluetooth version 1.1 or higher devices. These devices,
however, must have the Headset or Handsfree profile. For more information on
international Bluetooth standards, go to www.bluetooth.com.
How do I change my headset’s cover?
Wireless Bluetooth headset_cutdown.fm Page 5 Wednesday, December 29, 2004 6:11 PM
6
General Specifications
Bluetooth operation: • Bluetooth version1.2 compliance
• Bluetooth 2.4 GHz Class 2 radio, up to a radius of 10 meters
(32.8 feet) (varies depending on environment)
Supported Bluetooth profile: Headset and handsfree profiles
Frequency range: 2.4000 - 2.4835 GHz
Battery type: Built-in Lithium-ion battery (rechargeable)
Talk Time: Up to 6 hours *
Standby Time: Up to 200 hours *
* May vary depending on operation mode and mobile phone settings.
More Information
Register your product!
Enjoy a host of benefits by registering your product during installation, or at
www.creative.com/register.
Benefits include:
• Service and product support from Creative
• Exclusive updates on promotions and events.
Please note that your warranty rights are not dependent on product registration.
For more information on Creative Customer Support Services and Warranty, go to
www.europe.creative.com/support.
Creative Knowledge Base
Resolve and troubleshoot technical queries at Creative's 24-hour self-help
Knowledge Base. Go to www.creative.com and select your region.
Wireless Bluetooth headset_cutdown.fm Page 6 Wednesday, December 29, 2004 6:11 PM
7
Safety Advice
General Safety
Power Adapter Safety Notice
Power Source
This product is specially designed for operation within the electrical range(s) specified on
the provided power adapter. Any usage outside of these ranges is at your own risk.
If you are not sure of the type of power supply to your home, consult your product dealer
or local Power Company.
Cleaning
Unplug your headset from the power source and turn your headset off before cleaning. Do
not use liquid or aerosol cleaners. Use a damp cloth for cleaning.
Servicing
Do not attempt to service the product or change the battery on your own. Refer all
servicing to your local Customer Support Services center.
C
opyright © 2005 Creative Technology Ltd. All rights reserved. Bluetooth is a registered trademark of the Bluetooth SIG
,
I
nc., USA. All other products are trademarks or registered trademarks of their respective owners and are hereby recognize
d
a
s such. All specifications are subject to change without prior notice. Actual contents may differ slightly from those picture
d.
Wireless Bluetooth headset_cutdown.fm Page 7 Wednesday, December 29, 2004 6:11 PM
8
• Creative Product
• Produit Creative
• Prodotto Creative
• Creative-Produkt
• Producto Creative
• Creative Product
• Creative Produkt
• Creative tuote
• Creative Produkt
• Creative produkt
• Creative produkt
• Výrobek firmy Creative
• Produto Creative
• Creative продукт
• Dealer Stamp
• Cachet revendeur
• Timbro del rivenditore
• Händlerstempel
• Sello distribuidor
• Dealer stempel
• Forhandler stempel
• Jälleenmyyjä leima
• Återförsäljare stämpel
• Forhandler stempel
• Pieczątka dilera
• Razítko prodejce
• Carimbo do Agente
• Печать дилера
• Purchase Date
• Date d’achat
• Data di acquisto
• Kaufdatum
• Fecha de compra
• Aankoopdatum
• Kjøbsdato
• Ostopäivä
• Inköposdatum
• Købsdato
• Data zakupu
• Datum koupy
• Data de compra
• Покупное число
• Name and Address of Customer
• Nom et adrese du client
• Nome e indirizzo del cliente
• Name & Anschrift des Käufers
• Nombre & dirección del cliente
• Naam & adresvan de klant
• Kundens navn & adress
• Asiakkaan nimi & osoite
• Kundens namm & adress
• Kundens navn & adresse
• Imię i adres klienta
• Meno a adresa zákazníka
• Nome e morada do comprador
• Фамилия и адрес покупателя
Wireless Bluetooth headset_cutdown.fm Page 8 Wednesday, December 29, 2004 6:11 PM
8
• Creative Product
• Produit Creative
• Prodotto Creative
• Creative-Produkt
• Producto Creative
• Creative Product
• Creative Produkt
• Creative tuote
• Creative Produkt
• Creative produkt
• Creative produkt
• Výrobek firmy Creative
• Produto Creative
• Creative продукт
• Dealer Stamp
• Cachet revendeur
• Timbro del rivenditore
• Händlerstempel
• Sello distribuidor
• Dealer stempel
• Forhandler stempel
• Jälleenmyyjä leima
• Återförsäljare stämpel
• Forhandler stempel
• Pieczątka dilera
• Razítko prodejce
• Carimbo do Agente
• Печать дилера
• Purchase Date
• Date d’achat
• Data di acquisto
• Kaufdatum
• Fecha de compra
• Aankoopdatum
• Kjøbsdato
• Ostopäivä
• Inköposdatum
• Købsdato
• Data zakupu
• Datum koupy
• Data de compra
• Покупное число
• Name and Address of Customer
• Nom et adrese du client
• Nome e indirizzo del cliente
• Name & Anschrift des Käufers
• Nombre & dirección del cliente
• Naam & adresvan de klant
• Kundens navn & adress
• Asiakkaan nimi & osoite
• Kundens namm & adress
• Kundens navn & adresse
• Imię i adres klienta
• Meno a adresa zákazníka
• Nome e morada do comprador
• Фамилия и адрес покупателя
Wireless Bluetooth headset_cutdown.fm Page 8 Wednesday, December 29, 2004 6:11 PM
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation. See 47 CFR Sec.
15.19(3).
General Information
FCC Notice to Users
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment to an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
9
Note: The manufacturer is not responsible for any radio or TV
interference caused by unauthorized modifications made by the
user to this equipment. Such modifications could void the
user's authority to operate the equipment.
