Brookstone Purchasing AR117A2BLA WATCH SPEAKER BLACK User Manual 324308 Wrist Speaker IB indd

Brookstone Purchasing, Inc. WATCH SPEAKER BLACK 324308 Wrist Speaker IB indd

User manual

324308_INS_Wrist Speaker
Instructions Doc. Size: 350mm W x 130mm H Folded Size: 75mmW x 130mmH
Output at 100% Prints 1/1 Black Finishing: Trim to Crops; Accordian Fold: 4 folds
Fold
Fold
Fold
Fold
Wrist Speaker
BLUETOOTH® AUDIO
HANDSFREE CALLING
CAUTION
Do not drop, crush, bend or apply excessive force
to the device.
Do not expose the device to moisture, extreme or
prolonged heat, cold, humidity, or other adverse
conditions. Avoid storage in damp, humid or wet
locations. Do not submerge in water.
Do not attempt to open the Wrist Speaker. There
are no serviceable parts inside. The unit can only
be opened by qualified personnel.
LI-ION BATTERY WARNING
This device contains a Lithium-Ion battery. The battery
must be recycled or disposed of properly. Contact
your local waste management office for information
on battery recycling or disposal.
Use only the supplied cable to recharge the battery.
Improper charging may damage the battery and the
device.
Do not attempt to open the rechargeable battery or
battery pack. There are no serviceable parts inside.
Keep the battery out of reach of children. If
swallowed, consult a physician immediately.
Do not dispose of battery in a fire as it may explode.
The battery may also explode if damaged. BC
FCC INFORMATION
Caution: Changes or modifications not expressly
approved by the party responsible for compliance
could void the user's authority to operate the
equipment.
This equipment has been tested and found to
comply with the limits for a Class B Digital Device,
pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful interference to
radio or television reception, which can be determined
by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or
more of the following measures:
Reorient or relocate the receiving antenna.
Increase the distance between the equipment and
receiver.
Connect the equipment to an outlet on a circuit dif-
ferent from that
to which the receiver is connected.
Consult the dealer or an experienced radio/TV tech-
nician for help.
This equipment complies with part 15 of the FCC
Rules. Operation is subject to the following two
conditions:
1. This equipment may not cause harmful interference.
2. This equipment must accept any interference
received, including interference
that may cause undesired operation.
WARNING: To comply with FCC's RF radiation
exposure limits for general population/uncontrolled
exposure, the antenna(s) used for this transmitter
must be installed to provide a separation distance
of at least 20 cm from all persons and must not be
collocated or operating in conjunction with any other
antenna or transmitter.
FCC ID: AFVN-AR117A2BLA
CHARGING THE BATTERY
The Wrist Speaker includes a rechargeable Lithium-
Ion battery, which must be charged before first use.
To charge the battery:
1. Plug the charging cable's USB connector into a
USB port on an active device or a USB Adapter.
2. Plug the charging cable's Micro USB connector
into the Micro USB port on the Wrist Speaker. The
LED Indicator turns red during charging. It flashes
blue and red when the speaker is fully charged. A
full charge takes approximately 2 hours.
PAIRING WITH BLUETOOTH®
You use Bluetooth® to stream audio from your device
to the speaker, and to answer telephone calls through
the speaker. Using a MicroSD card or the FM Radio
feature does not require Bluetooth®.
Note: If you are using a MicroSD card, remove the
card before beginning the pairing procedure. If a
MicroSD card is present, the speaker will not enter
pairing mode.
LOCATION OF PARTS AND CONTROLS 1. Prepare your device (e.g., smartphone) to pair
using Bluetooth®, making sure that the device is
within 33 feet of the Wrist Speaker. Refer to your
device's owner’s manual for information on using
the Bluetooth® function.
2. Press and hold the POWER/PLAY/PAUSE
Button until the LED Indicator flashes blue quickly
and the voice prompt indicates that the speaker is
in pairing mode.
3. On your device, search the list of available devices
and select Wrist Speaker. Note that it may take
a few seconds for the speaker to be listed as an
available device. Depending on your device, you
may have to tap SCAN to update the device list.
Consult your device's owner's manual.
4. If prompted, type the password or PIN 0000.
When paired, the speaker's LED Indicator will flash
blue slowly and the voice prompt will advise you that
the device is paired.
The devices will remain paired, even after being
turned off, until you cancel pairing. Consult your
device's owner's manual for information on cancelling
pairing.
If no music is streaming for more than 30 seconds,
the speaker enters standby mode. The LED Indicator
flashes blue slowly. The devices remain paired in
standby mode for up to 48 hours.
USING A MICRO SD CARD
To play MP3/WAV music from a MicroSD card on
your Wrist Speaker, insert a MicroSD card into the
MicroSD slot. Press and hold the Volume + and
Volume — buttons to control volume; short press
Volume +/— to select the next/last song.
The Bluetooth® word mark and logos are registered trademarks
owned by Bluetooth SIG, Inc. and any use of such marks by
Brookstone is under license.
Mode Button
Volume +
Volume -
Power/Play/Pause
LED Indicator
MicroSD Slot
Under Protective Cover:
Micro-USB Port
Fold
Fold
Fold
Fold
324308
© Brookstone 2017
Brookstone.com | 1-800-846-3000
1 Innovation Way, Merrimack, NH 03054
Find thousands more
great ideas online
ONE (1) YEAR LIMITED WARRANTY
Brookstone® warrants this product against
defects in materials and/or workmanship under
normal use for a period of ONE (1) YEAR from
the date of purchase by the original purchaser
(“Warranty Period”). If a defect arises and a valid claim
is received within the Warranty Period, at its option,
Brookstone will either 1) repair the defect at no
charge, using new or refurbished replacement parts, or
2) replace the product with a new product that is at
least functionally equivalent to the original product, or
3) provide a store credit in the amount of the purchase
price of the original product. A replacement product
or part, including a user-installable part installed in
accordance with instructions provided by Brookstone,
assumes the remaining warranty of the original product.
When a product or part is exchanged, any replacement
item becomes your property and the replaced item
becomes Brookstone’s property. When a store credit
is given, the original product must be returned to
Brookstone and becomes Brookstone’s property.
Obtaining Service: To obtain warranty service,
call Brookstone Limited Warranty Service at
1-800-292-9819. Please be prepared to describe
the product that needs service and the nature of the
problem. A purchase receipt is required. All repairs and
replacements must be authorized in advance. Service
options, parts availability and response times will vary.
You are responsible for delivery and the cost of delivery
of the product or any parts to the authorized service
center for replacement, per our instructions.
Limits and Exclusions: Coverage under this Limited
Warranty is limited to the United States of America,
including the District of Columbia and the U.S.
Territories of Guam, Puerto Rico, and the U.S. Virgin
Islands. This Limited Warranty applies only to products
manufactured for Brookstone that can be identified by
the “Brookstone” trademark, trade name, or logo affixed
to them or their packaging. The Limited Warranty
does not apply to any non-Brookstone products.
Manufacturers or suppliers other than Brookstone
may provide their own warranties to the purchaser,
but Brookstone, in so far as permitted by law, provides
these products “as is.” This warranty does not apply
to: a) damage caused by failure to follow instructions
relating to product’s use or the installation of
components; b) damage caused by accident, abuse,
misuse, fire, floods, earthquake or other external causes;
c) damage caused by service performed by anyone who
is not a representative of Brookstone; d) accessories
used in conjunction with a covered product; e) a product
or part that has been modified to alter functionality or
capability; f) items intended to be periodically replaced
by the purchaser during the normal life of the product
including, without limitation, batteries or light bulbs; g)
any product sold “as is” including, without limitation,
floor demonstration models and refurbished items;
or h) a product that is used commercially or for a
commercial purpose.
BROOKSTONE SHALL NOT BE LIABLE FOR
INCIDENTAL OR CONSEQUENTIAL DAMAGES
RESULTING FROM THE USE OF THIS PRODUCT,
OR ARISING OUT OF ANY BREACH OF THIS
WARRANTY. TO THE EXTENT PERMITTED BY
APPLICABLE LAW, BROOKSTONE DISCLAIMS
ANY AND ALL STATUTORY OR IMPLIED
WARRANTIES, INCLUDING, WITHOUT
LIMITATION, WARRANTIES OF MERCHANTABILITY,
FITNESS FOR A PARTICULAR PURPOSE AND
WARRANTIES AGAINST HIDDEN OR LATENT
DEFECTS. IF BROOKSTONE CANNOT LAWFULLY
DISCLAIM STATUTORY OR IMPLIED WARRANTIES,
THEN TO THE EXTENT PERMITTED BY LAW,
ALL SUCH WARRANTIES SHALL BE LIMITED
IN DURATION TO THE DURATION OF THIS
EXPRESS WARRANTY.
Some states disallow the exclusion or limitation of
incidental or consequential damages or how long an
implied warranty lasts, so the above exclusions or
limitations may not apply to you. This warranty gives you
specific legal rights and you may also have other rights,
which vary from state to state.
VOLUME — Button
Press and hold to reduce volume.
Short press for last song/station.
MODE Button
Press and hold to change between
Bluetooth® mode and FM radio
mode. A voice prompt will confirm the
change. The LED Indicator is solid
blue when in radio mode; it flashes
blue when in Bluetooth® mode.
When in radio mode, short press to
search for radio stations. When the
search completes, the first station
found will play.
When in Bluetooth® mode and the
paired device's camera is open, short
press to trigger the camera's shutter,
allowing you to take a selfie or other
picture.
CARE AND MAINTENANCE
Clean the Wrist Speaker with a clean, soft cloth. Never
use harsh cleaning products or solvents.
SPECIFICATIONS
Output Power ..............................................................................................................3W
Input Power Supply ....................................................................DC5V/500mA
Sensitivity Ratio................................................................................................360mv
Frequency .......................................................................................120HZ-20KHZ
Bluetooth® Version Compatibility .........................................V2.1 + EDR
SNR ............................................................................................................................... 80db
Weight................................................................................... Approx. 2.5 oz (70 g)
Dimensions ...................................................... Approx. 2.76 x 1.58 x .95 in.
(Approx. 70 x 40 x 24 mm)
OUT-OF-RANGE ALERT
While in Bluetooth® mode, if your Wrist Speaker
leaves your device's broadcast range you will be
alerted and an alarm will sound. To cancel the
alarm, press any button on the Speaker or re-enter
the device's broadcast range. If the Wrist Speaker
re-enters the broadcast range, it will automatically
reconnect to your device.
The alarm will stop automatically after 3 minutes.
OPERATION
POWER/PLAY/
PAUSE Button
Press and hold to turn Wrist Speaker
on/off. A voice prompt will confirm
on/off status. The speaker will enter
pairing mode, or will pair with a
previously paired device and enter
Bluetooth® mode. (Depending on your
device, you may have to tap Wrist
Speaker in your Bluetooth® list to
reestablish the connection.)
If a MicroSD card is present, the
speaker will access the card instead
of entering Bluetooth® mode.
Short press for play/pause.
While in Bluetooth® mode with an
incoming call, short press to answer/
hang up phone.
VOLUME + Button
Press and hold to increase volume.
Short press for next song/station.
FCC Statement
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for
help.
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to
operate the equipment.

Navigation menu
