Quick Setup Guide MFC-8690DW/MFC-8890DW

Start Here MFC-8690DW

MFC-8890DW

Quick Setup Guide

USA/CAN Version 0

Before you can use the machine, read this Quick Setup Guide for the correct setup and installation.

To view the Quick Setup Guide in other languages, please visit http://solutions.brother.com/.

Unpack the machine and check the components

WARNING

Plastic bags are used in the packaging of your machine. Plastic bags are not toys. To avoid danger of

suffocation, please keep these bags away from babies and children and dispose of them properly.

IMPORTANT

DO NOT connect the interface cable yet.

Drum Unit Assembly

(including High-Yield Toner Cartridge for MFC-8690DW,

Standard Toner Cartridge for MFC-8890DW)

AC Power Cord

Quick Setup Guide User’s Guide CD-ROMs

Accessory Order Form Product Registration Sheet

(USA only)

USB Interface Cable

(MFC-8690DW only)

Telephone Line Cord

Symbols used in this guide

Note

• The components included in the box may differ depending on your country.

• Save all packing materials and the box in case for any reason you must ship your machine.

• The interface cable is not a standard accessory. Buy the appropriate interface cable for the interface you

want to use (USB, Parallel or Network). The MFC-8690DW includes a USB 2.0 interface cable as a standard

accessory.

USB cable

• Please make sure you use a USB 2.0 cable (Type A/B) that is no longer than 6 feet (2 meters).

• DO NOT connect the interface cable at this time. Connecting the interface cable is done during MFL-Pro

installation process.

• When you use a USB cable, make sure you connect it to the USB port of your computer and not to a USB

port on a keyboard or non-powered USB hub.

Parallel cable

DO NOT use a parallel interface cable that is longer than 6 feet (2 meters). Use a shielded interface cable that

is IEEE 1284-compliant.

Network cable

Use a straight-through Category5 (or greater) twisted-pair cable for 10BASE-T or 100BASE-TX Fast Ethernet

Network.

WARNINGS tell you what to do to prevent possible personal injury.

CAUTIONS specify procedures you must follow or avoid to prevent possible

minor injuries.

IMPORTANT describe procedures you must follow or avoid to prevent possible

machine problems or machine damage, or damage to other objects.

Electrical Hazard icons alert you to a possible electrical shock.

Hot Surface icons warn you not to touch machine parts that are hot.

Note Notes tell you how you should respond to a situation that may arise or give tips

about how the current operation works with other features.

User’s Guide

Software User’s Guide

Network User’s Guide

Indicates reference to the printed User’s Guide, the Software User’s Guide or

the Network User’s Guide. The Software User’s Guide and Network User’s

Guide are located on the supplied CD-ROM.

WARNING

CAUTION

IMPORTANT

CAUTION

When you move the machine, grasp the side handholds that are under the scanner. DO NOT carry the machine

by holding it at the bottom.

Note

Keep a minimum gap around the machine as shown in the illustration.

11.8 in. (300 mm)

19.68 in.

(500 mm)

7.87 in.

(200 mm)

5.12 in.

(130 mm)

Install the drum unit and

toner cartridge assembly

aRemove the protective tape and film covering

the scanner glass.

bPress the front cover release button and open

the front cover a.

cUnpack the drum unit and toner cartridge

assembly.

dGently shake it from side to side several times

to distribute the toner evenly inside the

assembly.

ePut the drum unit assembly into the machine

until it clicks into place.

fClose the front cover of the machine.

IMPORTANT

DO NOT connect the interface cable yet.

Load paper in the paper

tray

aPull the paper tray completely out of the

machine.

bWhile pressing the blue paper-guide release

lever a, slide the paper guides to fit the paper

size you are loading in the tray. Make sure that

the guides are firmly in the slots.

cFan the stack of paper well to avoid paper jams

and misfeeds.

dPut paper in the tray, and make sure that the

paper is below the maximum paper mark a.

The side to be printed on must be face down.

ePut the paper tray firmly back in the machine.

Make sure that it is completely inserted into the

machine.

fUnfold the support flap a to prevent paper

from sliding off the face-down output tray.

Note

For Legal or Folio size paper, press the release

button a in the bottom of the paper tray and then

pull out the back of the paper tray.

(Legal or Folio size paper are not available in

some regions.)

IMPORTANT

Make sure the paper guides touch the sides of

the paper so it will feed properly.

Release the scanner lock

aPush the lever a in the direction shown to

unlock the scanner.

(The gray scanner lock lever is located at the

back left side, under the document cover b.)

Connect the power cord

and telephone line

aMake sure that the machine power switch is off.

Connect the AC power cord to the machine.

bPlug the AC power cord into an AC outlet. Turn

the power switch on.

cConnect the telephone line cord. Connect one

end of the telephone line cord to the jack on the

machine marked LINE and the other end to a

modular wall jack.

WARNING

The machine must be grounded using a

3-prong plug.

Since the machine is grounded through the

power outlet, you can protect yourself from

potentially hazardous electrical conditions on

the telephone network by keeping the power

cord connected to your machine when you

connect it to a telephone line. Similarly, you

can protect yourself when you want to move

your machine by disconnecting the telephone

line first and then the power cord.

IMPORTANT

DO NOT connect the interface cable yet.

Note

If Scanner Locked appears on the LCD,

immediately release the scanner lock and press

Stop/Exit. (See Release the scanner

lock on page 6.)

IMPORTANT

The telephone line cord MUST be connected

to the jack on the machine marked LINE.

Choose your language

(If needed)

aPress Menu.

bPress 0.

cPress 0.

dPress or to choose your language.

Press OK.

ePress Stop/Exit.

Note

If you are sharing one telephone line with an

external telephone, connect it as shown below.

Before you connect the external telephone,

remove the protective cap a from the EXT. jack

on the machine.

1Extension telephone

2External telephone

Note

If you are sharing one telephone line with an

external telephone answering machine, connect it

as shown below.

Before you connect the external telephone

answering machine, remove the protective cap a

from the EXT. jack on the machine.

Set the receive mode to External TAD if

you have an external answering machine.

See Choose the correct Receive

Mode on page 8. For additional details, see

Connecting an external TAD (telephone

answering device) in Chapter 7 of the User’s

Guide.

Choose the correct Receive Mode

The correct Receive Mode is determined by the external devices and telephone subscriber services (Voice Mail,

Distinctive Ring, etc.) you have (or will be using) on the same line as the Brother machine.

aPress Menu.

bPress 0.

cPress 1.

dPress or to choose the receive mode.

Press OK.

ePress Stop/Exit.

Will you be using a Distinctive Ring number for receiving faxes?

Brother uses the term “Distinctive Ring” but telephone companies may have other names for this service such

as Custom Ringing, RingMaster, Personalized Ring, Teen Ring, Ident-A-Call, and Smart Ring. See Distinctive

Ring in Chapter 7 of the User’s Guide for instruction on setting up your machine using this feature.

Will you be using Voice Mail on the same telephone line as your Brother machine?

If you have Voice Mail on the same telephone line as your Brother machine, there is a strong possibility that

Voice Mail and the Brother machine will conflict with each other when receiving incoming calls. See Voice Mail

in Chapter 7 of the User’s Guide for instructions on setting up your machine using this service.

Will you be using a Telephone Answering Device on the same telephone line as your Brother machine?

Your external telephone answering device (TAD) will automatically answer every call. Voice messages are

stored on the external TAD and fax messages are printed. Choose External TAD as your receive mode. See

the instructions below.

Will you be using your Brother machine on a dedicated fax line?

Your machine automatically answers every call as a fax. Choose Fax Only as your receive mode. See the

instructions below.

Will you be using your Brother machine on the same line as your telephone?

Do you want to receive voice calls and faxes automatically?

The Fax/Tel receive mode is used when sharing the Brother machine and your telephone on the same line.

Choose Fax/Tel as your receive mode. See the instructions below.

Important Note: You cannot receive voice messages on either Voice Mail or an answering machine when

choosing the Fax/Tel mode.

Do you expect to receive very few faxes?

Choose Manual as your receive mode. You control the phone line and must answer every call yourself. See

the instructions below.

For details, see Using receive modes in Chapter 6 of the User’s Guide.

Set the LCD contrast

(If needed)

If you are having difficulty reading the LCD, try

changing the contrast setting.

aPress Menu.

bPress 1.

cPress 7.

dPress to increase the contrast.

—OR—

Press to decrease the contrast.

Press OK.

ePress Stop/Exit.

Set the date and time

The machine displays the time, and if you set up the

station ID the date and time will be added to each fax

you send.

aPress Menu.

bPress 0.

cPress 2.

dEnter the last two digits of the year on the dial

pad, and then press OK.

02.Date&Time

Year:2009

Enter & OK Key

(e.g. Enter 0, 9 for 2009.)

eEnter the two digits for the month on the dial

pad, and then press OK.

02.Date&Time

XX/XX/2009

Month:03

Enter & OK Key

(e.g. Enter 0, 3 for March.)

fEnter the two digits for the day on the dial pad,

and then press OK.

02.Date&Time

03/XX/2009

Day:25

Enter & OK Key

(e.g. Enter 2, 5.)

gEnter the time in 24-hour format on the dial

pad, and then press OK.

02.Date&Time

03/25/2009

Time:15:25

Enter & OK Key

(e.g. Enter 1 5, 2 5 for 3:25 P.M.)

hPress Stop/Exit.

Set your Station ID

You should store your name and fax number to be

printed on all fax pages that you send.

aPress Menu.

bPress 0.

cPress 3.

dEnter your fax number (up to 20 digits) on the

dial pad, and then press OK.

03.Station ID

Fax:_

Enter & OK Key

eEnter your telephone number (up to 20 digits)

on the dial pad, and then press OK. (If your

telephone number and fax number are the

same, enter the same number again.)

03.Station ID

Fax:XXXXXXXXXXX

Tel:_

Enter & OK Key

fUse the dial pad to enter your name (up to 20

characters), and then press OK.

03.Station ID

Fax:XXXXXXXXXXX

Tel:XXXXXXXXXXX

Name:_

Enter & OK Key

gPress Stop/Exit.

Note

• See the following chart for entering your name.

• If you need to enter a character that is on the

same key as the last character, press to

move the cursor to the right.

• If you entered a letter incorrectly and want to

change it, press or to move the

cursor to the incorrect character, press

Clear/Back.

Press

key

One

time

Two

times

Three

times

Four

times

Five

times

2ABC2A

3DEF3D

4GH I 4G

5JKL5J

6MNO6M

7PQRS 7

8TUV8T

9WX Y Z 9

For more details, see Entering Text in the

User’s Guide.

Note

If you make a mistake and want to start again,

press Stop/Exit and go back to step a.

(USA only) The Telephone Consumer Protection

Act of 1991 makes it unlawful for any person to

use a computer or electronic device to send any

message via a telephone fax machine unless

such messages clearly contain, in a margin at the

top or bottom of each transmitted page, or on the

first page of the transmission, the date and time it

is sent and an identification of the business or

other entity or other individual sending the

message and the telephone number of the

sending machines or such business, other entity

or individual. To program this information into

your machine, see Set the date and

time on page 9 and Set your Station

ID on page 10.

Fax Transmission Report

Your Brother machine is equipped with a

Transmission Verification Report that can be used as

confirmation that you sent a fax. This report lists the

name or fax number of the receiving party, the date,

time, and duration of the transmission, the number of

pages transmitted, and whether or not the

transmission was successful. If you want to use the

Fax Transmission Report feature see Chapter 11

Printing Reports in the User’s Guide.

Set tone or pulse dialing

mode (Canada only)

Your machine comes set for Tone dialing service. If

you have Pulse dialing service (rotary), you need to

change the dialing mode.

aPress Menu.

bPress 0.

cPress 4.

dPress or to choose Pulse (or

Tone).

Press OK.

ePress Stop/Exit.

Dial Prefix

The dial prefix setting will automatically dial a

predefined number before every fax number you dial.

For example: If your phone system requires a 9 to dial

an outside number this setting will automatically dial 9

for every fax you send.

aPress Menu.

bPress 0.

cPress 5 (For Canada, press 6).

dEnter the prefix number (up to 5 digits) on the

dial pad, and then press OK.

ePress Stop/Exit.

Automatic Daylight

Savings Time

You can set the machine to change automatically for

daylight savings time. It will reset itself forward one

hour in the Spring and backward one hour in the Fall.

aPress Menu.

bPress 1.

cPress 4.

dPress or to choose On (or Off).

Press OK.

ePress Stop/Exit.

Note

• You can use the number 0 to 9, #,

and !.

(Press Hook to display “!”.)

You cannot use ! with any other numbers or

characters.

If your telephone system requires a timed

break recall (hookflash), press Hook to enter

the break.

• If the pulse dialing mode is on, # and

are not

available to use. (Canada only)

Send in the Product

Registration and Test

Sheet (USA only)

You can also register your product online using the

On-Line Registration link from the installation

CD-ROM or visit

http://www.brother.com/registration/.

aFill out the Product Registration and Test

Sheet.

bPut the sheet face up in the ADF (Automatic

Document Feeder) or face down on the

scanner glass.

cMake sure (Fax) is illuminated in Blue.

dEnter the toll-free fax number: 1-877-268-9575.

ePress Start.

Note

You will receive a confirmation fax of your Product

Registration.

Windows®

USB

Macintosh Windows®

Parallel

Windows®Macintosh

Wired Network Wireless Network

Windows®Macintosh

Choose your connection type

For USB Interface Users

Windows

, go to page 14

Macintosh, go to page 18

For Parallel interface cable

Windows

, go to page 20

For Wired Network

Windows

, go to page 24

Macintosh, go to page 28

For Windows Server® 2003/ 2008, see the Network User’s Guide on the CD-ROM.

For Wireless Network

Windows

and Macintosh,

go to page 30

Windows®

USB

For USB Interface Users

(Windows

2000 Professional/XP/XP Professional x64 Edition/

Windows Vista

)

Before you install

aMake sure that your computer is ON and you

are logged on with Administrator rights.

bTurn off and unplug the machine from the AC

outlet and disconnect it from your computer, if

you already connected an interface cable.

Install MFL-Pro Suite

aPut the supplied CD-ROM into your CD-ROM

drive. If the model name screen appears,

choose your machine. If the language screen

appears, choose your language.

bThe CD-ROM main menu will appear. Click

Initial Installation.

cClick Install MFL-Pro Suite.

IMPORTANT

• DO NOT connect the USB cable yet.

• If there are any programs running, close

them.

• Make sure a USB Flash memory device is

not inserted into the machine.

• The screen may differ depending on the

operating system.

• The supplied CD-ROM includes ScanSoft™

PaperPort™ 11SE. This software supports

Windows® 2000 (SP4 or greater), XP (SP2 or

greater), XP Professional x64 Edition and

Windows Vista®. Update to the latest

Windows® Service Pack before installing

MFL-Pro Suite.

Note

If the Brother screen does not appear

automatically, go to My Computer (Computer),

double-click the CD-ROM icon, and then

double-click Start.exe.

Windows®

USB

Windows®

USB

Macintosh

dChoose Local Connection, and then click

Next. The installation continues.

eWhen the ScanSoft™ PaperPort™ 11SE

License Agreement window appears, click

Yes if you agree to the Software

License Agreement.

fThe installation of ScanSoft™ PaperPort™

11SE will automatically start and is followed by

the installation of MFL-Pro Suite.

gWhen the Brother MFL-Pro Suite Software

License Agreement window appears, click

Yes if you agree to the Software

License Agreement.

hIf you do not want to monitor the machine

status and error notification from your

computer, uncheck Enable Status Monitor

and then click Next.

iWhen this screen appears, go to the next step.

Note

• If the installation does not continue

automatically, open the main menu again by

ejecting and then reinserting the CD-ROM or

double-click the Start.exe program from the

root folder, and continue from step c to install

MFL-Pro Suite.

• For Windows Vista®, when the

User Account Control screen appears, click

Allow.

Note

If you want to install the PS driver (Brother’s

BR-Script Driver), choose Custom Install and

then follow the on-screen instructions. When the

Select Features screen appears, check

PS Printer Driver, and then continue following

the on-screen instructions.

Note

For Windows Vista®, when this screen appears,

click the check box and click Install to complete

the installation correctly.

Windows®

USB

Connect the USB cable

aRemove the label covering the USB interface

connector.

bConnect the USB cable to the USB connector

on the machine marked with the symbol.

Then connect the cable to your computer.

Connect the power cord

aPlug the AC power cord into an AC outlet. Turn

the power switch on.

The installation will continue automatically.

The installation screens appear one after

another.

bWhen the On-Line Registration screen is

displayed, make your selection and follow the

on-screen instructions. Once you have

completed the registration process, close your

web browser to return to this window.

Then click Next.

IMPORTANT

• DO NOT connect the machine to a USB port

on a keyboard or a non-powered USB hub.

• Connect the machine directly to your

computer.

IMPORTANT

DO NOT cancel any of the screens during the

installation. It may take a few seconds for all

screens to appear.

Windows®

USB

Windows®

USB

Macintosh

Finish and restart

aClick Finish to restart your computer.

After restarting the computer, you must be

logged on with Administrator rights.

bIf this screen appears, choose the firmware

update setting and click OK.

Note

If an error message appears during the software

installation, run the Installation Diagnostics

located in Start/All Programs/Brother

/MFC-XXXX (where MFC-XXXX is your model

name).

Note

Internet access is required for the firmware

upgrade.

Finish The installation is now

complete.

Note

XML Paper Specification Printer Driver

The XML Paper Specification Printer Driver is the

most suitable driver when printing from the

applications that use the XML Paper Specification

documents. Please download the latest driver by

accessing the Brother Solutions Center at

http://solutions.brother.com/.

Macintosh

USB

For USB Interface Users

(Mac OS X 10.3.9 or greater)

Before you install

aMake sure your machine is connected to the

power and your Macintosh is ON. You must be

logged on with Administrator rights.

Connect the USB cable

aRemove the label covering the USB interface

connector.

bConnect the USB cable to the USB connector

on the machine marked with the symbol.

Then connect the cable to your computer.

Install MFL-Pro Suite

aPut the supplied CD-ROM into your CD-ROM

drive.

bDouble-click Start Here OSX to install.

IMPORTANT

Make sure a USB Flash memory device is not

inserted into the machine.

IMPORTANT

• DO NOT connect the machine to a USB port

on a keyboard or a non-powered USB hub.

• Connect the machine directly to your

Macintosh.

Note

Please see the Software User’s Guide on the

CD-ROM if you want to install the PS driver.

(Brother’s BR-Script Driver)

Macintosh

USB

Windows®

USB

Macintosh

cChoose Local Connection, and then click

Next. Follow the on-screen instructions.

dThe Brother software will search for the Brother

device. During this time the following screen

will appear.

eChoose the machine from the list, and then

click OK.

fWhen this screen appears, click OK.

Install

Presto! PageManager

When Presto! PageManager is installed OCR

capability is added to Brother ControlCenter2. You

can easily scan, share and organize photos and

documents using Presto! PageManager.

aDouble-click Presto! PageManager and follow

the on-screen instructions.

Note

Please wait, it will take a few seconds for the

software to install. After the installation, click

Restart to finish installing the software.

The installation of MFL-Pro Suite is now

complete.

Go to step 20 on page 19.

Finish The installation is now

complete.

Windows®

Parallel

For Parallel Interface Users

(Windows

2000 Professional/XP/XP Professional x64 Edition)

Before you install

aMake sure that your computer is ON and you

are logged on with Administrator rights.

bTurn off and unplug the machine from the AC

outlet and disconnect it from your computer, if

you already connected an interface cable.

Install MFL-Pro Suite

aPut the supplied CD-ROM into your CD-ROM

drive. If the model name screen appears,

choose your machine. If the language screen

appears, choose your language.

bThe CD-ROM main menu will appear. Click

Initial Installation.

cClick Install MFL-Pro Suite.

IMPORTANT

• DO NOT connect the Parallel cable yet.

• If there are any programs running, close

them.

• Make sure a USB Flash memory device is

not inserted into the machine.

• The screen may differ depending on the

operating system.

• The supplied CD-ROM includes ScanSoft™

PaperPort™ 11SE. This software supports

Windows® 2000 (SP4 or greater), XP (SP2 or

greater) and XP Professional x64 Edition.

Update to the latest Windows® Service Pack

before installing MFL-Pro Suite.

Note

If the Brother screen does not appear

automatically, go to My Computer (Computer),

double-click the CD-ROM icon, and then

double-click Start.exe.

Windows®

Parallel

Windows®

Parallel

dChoose Local Connection, and then click

Next. The installation continues.

eWhen the ScanSoft™ PaperPort™ 11SE

License Agreement window appears, click

Yes if you agree to the Software

License Agreement.

fThe installation of ScanSoft™ PaperPort™

11SE will automatically start and is followed by

the installation of MFL-Pro Suite.

gWhen the Brother MFL-Pro Suite Software

License Agreement window appears, click

Yes if you agree to the Software

License Agreement.

hIf you do not want to monitor the machine

status and error notification from your

computer, uncheck Enable Status Monitor

and then click Next.

iWhen this screen appears, go to the next step.

Note

If the installation does not continue automatically,

open the main menu again by ejecting and then

reinserting the CD-ROM or double-click the

Start.exe program from the root folder, and

continue from c to install MFL-Pro Suite.

Note

If you want to install the PS driver (Brother’s

BR-Script Driver), choose Custom Install and

then follow the on-screen instructions. When the

Select Features screen appears, check

PS Printer Driver, and then continue following

the on-screen instructions.

Windows®

Parallel

Connect the Parallel

cable

aConnect the Parallel interface cable to your

computer, and then connect it to the machine.

Connect the power cord

aPlug the AC power cord into an AC outlet. Turn

the power switch on.

The installation will continue automatically.

The installation screens appear one after

another.

bDo one of the following:

For Windows® 2000 Professional users,

click Next.

For Windows® XP/XP Professional x64

Edition users, wait for a while since the

installation of the Brother drivers will

automatically start. The screens appear one

after another.

cWhen the On-Line Registration screen is

displayed, make your selection and follow the

on-screen instructions. Once you have

completed the registration process, close your

web browser to return to this window.

Then click Next.

IMPORTANT

Connect the machine directly to your

computer.

Note

If this screen appears, click OK.

IMPORTANT

DO NOT cancel any of the screens during the

installation. It may take a few seconds for all

screens to appear.

Windows®

Parallel

Windows®

Parallel

Finish and restart

aClick Finish to restart your computer.

After restarting the computer, you must be

logged on with Administrator rights.

bIf this screen appears, choose the firmware

update setting and click OK.

Note

If an error message appears during the software

installation, run the Installation Diagnostics

located in Start/All Programs/Brother

/MFC-XXXX LPT (where MFC-XXXX is your

model name).

Note

Internet access is required for the firmware

upgrade.

Finish The installation is now

complete.

Note

XML Paper Specification Printer Driver

The XML Paper Specification Printer Driver is the

most suitable driver when printing from the

applications that use the XML Paper Specification

documents. Please download the latest driver by

accessing the Brother Solutions Center at

http://solutions.brother.com/.

Windows®

Wired Network

For Wired Network Interface Users

(Windows

2000 Professional/XP/XP Professional x64 Edition/

Windows Vista

)

Before you install

aMake sure that your computer is ON and you

are logged on with Administrator rights.

bUnplug the machine from the AC outlet.

Connect the network

cable

aConnect the network interface cable to the LAN

connector marked with a symbol and then

connect it to a free port on your hub.

Connect the power cord

aPlug the AC power cord into an AC outlet. Turn

the power switch on.

IMPORTANT

• If there are any programs running, close

them.

• Make sure a USB Flash memory device is

not inserted into the machine.

• The screens may differ depending on the

operating system.

• The supplied CD-ROM includes ScanSoft™

PaperPort™ 11SE. This software supports

Windows® 2000 (SP4 or greater), XP (SP2 or

greater), XP Professional x64 Edition and

Windows Vista®. Update to the latest

Windows® Service Pack before installing

MFL-Pro Suite.

IMPORTANT

Disable all personal firewall

software (other than Windows®

Firewall), anti-spyware or

antivirus applications for the

duration of the installation.

Windows®

Wired Network

Windows®Macintosh

Wired Network

Install MFL-Pro Suite

aPut the supplied CD-ROM into your CD-ROM

drive. If the model name screen appears,

choose your machine. If the language screen

appears, choose your language.

bThe CD-ROM main menu will appear. Click

Initial Installation.

cClick Install MFL-Pro Suite.

dChoose Wired Network Connection, and

then click Next.

eWhen the ScanSoft™ PaperPort™ 11SE

License Agreement window appears, click

Yes if you agree to the Software

License Agreement.

fThe installation of ScanSoft™ PaperPort™

11SE will automatically start and is followed by

the installation of MFL-Pro Suite.

Note

If the Brother screen does not appear

automatically, go to My Computer (Computer),

double-click the CD-ROM icon, and then

double-click Start.exe.

Note

• If the installation does not continue

automatically, open the main menu again by

ejecting and then reinserting the CD-ROM or

double-click the Start.exe program from the

root folder, and continue from c to install

MFL-Pro Suite.

• For Windows Vista®, when the

User Account Control screen appears, click

Allow.

Note

If you want to install the PS driver (Brother’s

BR-Script Driver), choose Custom Install and

then follow the on-screen instructions. When the

Select Features screen appears, check

PS Printer Driver, and then continue following

the on-screen instructions.

Windows®

Wired Network

gWhen the Brother MFL-Pro Suite Software

License Agreement window appears, click

Yes if you agree to the Software

License Agreement.

hFor Windows® XP SP2/XP Professional x64

Edition/ Windows Vista® users, when this

screen appears, choose Change the Firewall

port settings to enable network connection

and continue with the installation.

(Recommended) and click Next.

If you are not using the Windows® Firewall, see

the User’s Guide for your software for

information on how to add the following

network ports.

For network scanning, add UDP port 54925.

For network PC-Fax receiving, add UDP port

54926.

If you still have trouble with your network

connection, add UDP port 137.

iIf the machine is configured for your network,

choose the machine from the list, and then click

Next.

jIf you do not want to monitor the machine

status and error notification from your

computer, uncheck Enable Status Monitor

and then click Next.

kThe installation of the Brother drivers will

automatically start. The installation screens

appear one after another.

Note

• You can find your machine’s IP address and

the node name by printing out the Network

Configuration List. See Print the Network

Configuration List on page 45.

• If your machine is not found over the network,

following screen will appear.

Confirm your network setting by following the

on-screen instructions.

• If the machine is not yet configured for use on

your network, the following screen appears.

Click OK and then Configure IP Address.

Enter an IP address for your machine that is

suitable for your network by following the on-

screen instructions.

IMPORTANT

DO NOT cancel any of the screens during the

installation. It may take a few seconds for all

screens to appear.

Windows®

Wired Network

Windows®Macintosh

Wired Network

lWhen the On-Line Registration screen is

displayed, make your selection and follow the

on-screen instructions. Once you have

completed the registration process, close your

web browser to return to this window.

Then click Next.

Finish and restart

aClick Finish to restart your computer. After

restarting the computer, you must be logged on

with Administrator rights.

bIf this screen appears, choose the firmware

update setting and click OK.

Install MFL-Pro Suite on

additional computers

(If needed)

If you want to use your machine with multiple

computers on the network, install MFL-Pro Suite on

each computer. Go to step 20 on page 25.

Note

For Windows Vista®, when this screen appears,

click the check box and click Install to complete

the installation correctly.

Note

If an error message appears during the software

installation, run the Installation Diagnostics

located in Start/All Programs/Brother/

MFC-XXXX LAN (where MFC-XXXX is your

model name).

Note

Internet access is required for the firmware

upgrade.

Note

The MFL-Pro Suite Software License permits

installation on up to 5 network computers. If you

want to install MFL-Pro Suite on additional

computers, you can purchase additional NL-5

(five user) license agreements from your

authorized Brother dealer or contact Brother

customer service.

Finish The installation is now

complete.

Note

XML Paper Specification Printer Driver

The XML Paper Specification Printer Driver is the

most suitable driver when printing from the

applications that use the XML Paper Specification

documents. Please download the latest driver by

accessing the Brother Solutions Center at

http://solutions.brother.com/.

Macintosh

Wired Network

For Wired Network Interface Users

(Mac OS X 10.3.9 or greater)

Before you install

aMake sure your machine is connected to the

power and your Macintosh is ON. You must be

logged on with Administrator rights.

Connect the network

cable

aConnect the network interface cable to the LAN

connector marked with a symbol and then

connect it to a free port on your hub.

Install MFL-Pro Suite

aPut the supplied CD-ROM into your CD-ROM

drive.

bDouble-click Start Here OSX to install.

cChoose Wired Network Connection, and

then click Next. Follow the on-screen

instructions.

IMPORTANT

Make sure a USB Flash memory device is not

inserted into the machine.

Note

Please see the Network User’s Guide on the

CD-ROM if you want to install the PS driver.

(Brother’s BR-Script Driver)

Note

Please wait, it will take a few seconds for the

software to install. After the installation, click

Restart to finish installing the software.

Macintosh

Wired Network

Windows®Macintosh

Wired Network

dThe Brother software will search for the Brother

device. During this time the following screen

will appear.

eIf the machine is configured for your network,

choose the machine from the list, and then click

OK.

fWhen this screen appears, click OK.

Install

Presto! PageManager

When Presto! PageManager is installed OCR

capability is added to Brother ControlCenter2. You

can easily scan, share and organize photos and

documents using Presto! PageManager.

aDouble-click Presto! PageManager and follow

the on-screen instructions.

Install MFL-Pro Suite on

additional computers

(If needed)

If you want to use your machine with multiple

computers on the network, install MFL-Pro Suite on

each computer. Go to step 19 on page 28.

Note

• You can find your machine’s IP address and

the node name by printing out the Network

Configuration List. See Print the Network

Configuration List on page 45.

• If your machine is not found over the network,

confirm your network setting.

• If this screen appears click OK.

• Enter a name for your Macintosh in

Display Name up to 15 characters long and

click OK. Go to f.

• If you want to use the machine ’s Scan key to

scan over the network, you must check the

function on the machine box.

• The name you enter will appear on the

machine’s LCD when you press and

choose a scan option. (For more information,

see Network Scanning in the Software User’s

Guide on the CD-ROM.)

The installation of MFL-Pro Suite is now

complete.

Go to step 20 on page 29.

Finish The installation is now

complete.

For Wireless Network Users

For Wireless Network Interface Users

Before you begin

First you must configure the wireless network settings of your machine to communicate with your network access

point (router). After the machine is configured to communicate with your access point (router) computers on your

network will have access to the machine. To use the machine from these computers, you will need to install the

drivers and software. The following steps will guide you through the configuration and installation process.

Note

• To achieve optimum results with normal everyday document printing, place the Brother machine as close

to the network access point (router) as possible with minimal obstructions. Large objects and walls between

the two devices as well as interference from other electronic devices can affect the data transfer speed of

your documents.

• Due to these factors, wireless may not be the best method of connection for all types of documents and

applications. If you are printing large files, such as multi-page documents with mixed text and large graphics,

you may want to consider choosing wired Ethernet for a faster data transfer or USB for the fastest

throughput speed.

• Although the Brother MFC-8690DW and MFC-8890DW can be used in a both wired and wireless network,

only one of the connection methods can be used at a time.

• If you have previously configured the wireless settings of the machine you must reset the network (LAN)

settings before you can configure the wireless settings again.

On your machine, press Menu. Press 7.

Press 0 to choose Network Reset.

Press 1 twice for Yes to accept the change.

Note

The following instructions are for infrastructure mode.

To set up your machine in any other wireless environment you can find instructions in the Network User’s

Guide on the CD-ROM.

You can view the Network User’s Guide by following the instructions below.

1 Turn on your computer/Macintosh. Insert the Brother CD-ROM into your CD-ROM drive.

For Windows®:

2 Choose your model and the language. The CD-ROM main menu will appear.

3 Click Documentation, and then click HTML documents.

For Macintosh:

2 Double-click Documentation, and then double-click your language folder.

3 Double-click top.html.

For Wireless Network Users

Wireless Network

Windows®Macintosh

Infrastructure Mode

aAccess Point (router)

bWireless Network machine (your machine)

cWireless capable computer connected to the access point

dWired computer connected to the access point

For Wireless Network Users

Confirm your network environment (Infrastructure Mode)

The following instructions will offer two methods for installing your Brother machine in a wireless network

environment. Both methods are for infrastructure mode, using a wireless router or access point that uses DHCP

to assign IP addresses. Choose a configuration method and proceed to the page indicated.

aIf your wireless router/access point does not support SecureEasySetup™, Wi-Fi Protected Setup or

AOSS™, write down the wireless network settings of your wireless access point/router.

1WPA/WPA2-PSK is a Wi-Fi Protected Access Pre-Shared Key, which lets the Brother wireless machine associate with access points using TKIP or

AES encryption (WPA-Personal). WPA/WPA2-PSK (TKIP or AES) uses a Pre-Shared Key (PSK) that is 8 or more characters in length, up to a

maximum of 63 characters.

2The WEP key is for 64-bit encrypted networks or 128-bit encrypted networks and can contain both numbers and letters. If you do not know this

information you should see the documentation provided with your access point or wireless router. This key is a 64-bit or 128-bit value that must be

entered in an ASCII or HEXADECIMAL format.

Now go to page 33

IMPORTANT

If you do not know this information (Network Name, WEP key, WPA2-PSK (Pre-Shared Key), LEAP or EAP-

FAST) you cannot continue the wireless setup. You should see the documentation provided with your

access point or wireless router, consult the router manufacturer, or your system administrator.

Item Example Record the current wireless network settings

Communication mode: (infrastructure) Infrastructure

Network name: (SSID, ESSID) HELLO

Authentication method:

(Open system, Shared key, WPA-PSK 1,

WPA2-PSK 1, LEAP, EAP-FAST)

WPA2-PSK

Encryption mode:

(None, WEP,TKIP, AES, CKIP)

AES

Network key:

(Encryption key , WEP key 2, Passphrase)

12345678

For example:

64-bit ASCII: Uses 5 text characters

e.g. “Hello” (this is case sensitive)

64-bit Hexadecimal: Uses 10 digits of hexadecimal data

e.g. “71f2234aba”

128-bit ASCII: Uses 13 text characters

e.g. “Wirelesscomms” (this is case sensitive)

128-bit Hexadecimal: Uses 26 digits of hexadecimal data

e.g. “71f2234ab56cd709e5412aa3ba“

bIf your wireless router/access point supports automatic wireless (one-push) setup

(SecureEasySetup™, Wi-Fi Protected Setup or AOSS™)

Now go to page 35

For MFC-8890DW only

For Wireless Network Users

Wireless Network

Windows®Macintosh

Connecting the Brother machine to the wireless network

Configure the wireless

settings (Typical

Wireless Setup in

infrastructure mode)

aOn your machine, press Menu, 7 (Network), 2

(WLAN), 2 (Setup Wizard).

Press or to choose On, then press

OK.

bThe machine will search for available SSIDs. If

a list of SSIDs is displayed, use or

to choose the SSID you wrote down in step 18

on page 32, then press OK. Go to step f.

If your access point is set to not broadcast the

SSID you will have to manually add the SSID

name. Go to step c.

cPress or to choose <New SSID>

and press OK. Go to step d.

dEnter the SSID you wrote down in step 18 on

page 32 using the dial pad to choose each

letter or number.

You can use and to move the

cursor left and right. For example, to enter the

letter a, press the 2 key on the dial pad once.

To enter the number 3, press the 3 key on the

dial pad seven times.

The letters appear in this order: lower case,

upper case and then numbers.

(For more information, see Entering Text for

Wireless Settings on page 46.)

Press OK when you have entered all the

characters.

ePress or to choose

Infrastructure, then press OK.

fUse the , and OK keys to choose

one of the options below: If your network is

configured for Authentication and Encryption

you must match the settings used for your

network.

No Authentication or Encryption:

Choose Open System, press OK then use

or to choose None for

Encryption Type? and press OK. Then

press 1 for Yes to apply your settings. Go to

step k.

No Authentication with WEP Encryption:

Choose Open System, press OK then use

or to choose WEP for the

Encryption Type? and press OK.

Go to step g.

Authentication with WEP Encryption:

Choose Shared Key and press OK.

Go to step g.

Authentication with WPA/WPA2-PSK

(TKIP or AES) Encryption:

Choose WPA/WPA2-PSK and press OK.

Go to step h.

Authentication with LEAP:

Choose LEAP, press OK. Go to step i.

Authentication with EAP-FAST/NONE,

EAP-FAST/MS-CHAPv2, EAP-FAST/GTC

(TKIP or AES Encryption):

Choose EAP-FAST/NONE,

EAP-FAST/MSCHAP (EAP-FAST/MS-

CHAPv2) or EAP-FAST/GTC, press OK. Go

to step j.

gChoose the appropriate key number and press

OK. Enter the WEP key you wrote down in

step 18 on page 32 using the dial pad to

choose each letter or number.

For example, to enter the letter a, press the 2

key on the dial pad once. To enter the number

3, press the 3 key on the dial pad seven times.

The letters appear in this order: lower case,

upper case and then numbers.

(For more information, see Entering Text for

Wireless Settings on page 46.)

Press OK when you have entered all the

characters, then press 1 for Yes to apply your

settings. Go to step k.

Note

It will take several seconds to display a list of

available SSIDs.

For Wireless Network Users

hPress or to choose TKIP or AES

for Encryption Type? and press OK.

Enter the WPA/WPA2-PSK password you

wrote down in step 18 on page 32 using the

dial pad to choose each letter or number.

For example, to enter the letter a, press the 2

key on the dial pad once. To enter the number

3, press the 3 key on the dial pad seven times.

The letters appear in this order: lower case,

upper case and then numbers.

(For more information, see Entering Text for

Wireless Settings on page 46.)

Press OK when you have entered all the

characters, then press 1 for Yes to apply your

settings. Go to step k.

iEnter the user name and press OK. You can

use or to move the cursor. For

example, to enter the letter a, press the 2 key

on the dial pad once.

Enter the password and press OK, and then

press 1 to apply your settings. Go to step k.

(For more information, see Entering Text for

Wireless Settings on page 46.)

jPress or to choose TKIP or AES

for Encryption Type? and press OK.

Enter the user name and press OK. You can

use or to move the cursor. For

example, to enter the letter a, press the 2 key

on the dial pad once.

Enter the password and press OK, and then

press 1 to apply your settings. Go to step k.

(For more information, see Entering Text for

Wireless Settings on page 46.)

kYour machine will now try to connect to your

wireless network using the information you

have entered. If successful, Connected will

appear briefly on the LCD.

If your machine does not successfully connect

to your network, verify your network settings

collected in step 18 on page 32, then repeat

steps a to j to make sure you have entered the

correct information.

If your access point does not have DHCP

enabled you will need to manually configure

the IP address, subnet mask and gateway of

the machine to suit your network. See the

Network User’s Guide for details.

To install MFL-Pro Suite, continue to

step 20.

For Windows® Users:

Now go to

page 37

For Macintosh Users:

Now go to

page 41

Wireless setup is now complete. A four

level indicator at the top of your

machine’s LCD will show the wireless

signal strength of your access point or

router.

For Wireless Network Users

Wireless Network

Windows®Macintosh

Configure the wireless

settings using the

automatic wireless (one-

push) method

aConfirm your wireless router or access point

has the SecureEasySetup™, Wi-Fi Protected

Setup or AOSS™ symbol as shown below.

bPlace the Brother machine within range of a

SecureEasySetup™, Wi-Fi Protected Setup or

AOSS™ access point/router. The range may

differ depending on your environment. Refer to

the instructions provided with your access

point/router.

cPush the SecureEasySetup™, Wi-Fi Protected

Setup or AOSS™ button on your wireless

router or access point.

See the user’s guide for your wireless

router/access point for instructions.

dOn your machine, press Menu, 7 (Network), 2

(WLAN), 3 (SES/WPS/AOSS).

Press or to choose On, then press

OK.

This feature will automatically detect which

mode (SecureEasySetup™, Wi-Fi Protected

Setup or AOSS™) your access point uses to

configure your machine.

eIf the LCD shows Connected, the machine

has successfully connected to your

router/access point. You can now use your

machine with your wireless network.

If the LCD shows Setting WLAN,

Connecting SES (Connecting WPS or

Connecting AOSS), then

Connection Fail, the machine has not

successfully connected to your router/access

point. Try starting from step c again. If the

same message is indicated again, reset the

machine back to the default factory settings

and try again. For resetting, see Restore the

network settings to factory default on page 45.

If the LCD shows Setting WLAN, then

Connection Fail or Connection Error,

a session overlap or connection failure was

detected (see the table below). The machine

has detected 2 or more routers/access points

on your network that have the

SecureEasySetup™, Wi-Fi Protected Setup

mode or AOSS™ mode enabled. Make sure

that only one router/access point has the

SecureEasySetup™, Wi-Fi Protected Setup

mode or AOSS™ mode enabled and try

starting from step c again.

If the LCD shows Setting WLAN, then

No Access Point, the machine has not

detected your router/access point on your

network with the SecureEasySetup™ mode,

the Wi-Fi Protected Setup mode or AOSS™

mode enabled. Move your machine close to the

router/access point and try starting from step c

again.

Note

If your wireless access point supports the Wi-Fi

Protected Setup (PIN Method) and you want to

configure your machine using the PIN (Personal

Identification Number) Method, see Using the PIN

Method of Wi-Fi Protected Setup in the Network

User’s Guide on the CD-ROM.

For MFC-8890DW only

LCD messages when using

the SES/WPS/AOSS control panel menu

Setting WLAN Searching or accessing the

access point and

downloading settings from

the access point.

Connecting

SES/WPS/AOSS

Connecting to the access

point.

Connection Fail Connection failed.

Connection Error A session overlap was

detected.

Connected The machine has

successfully connected.

No Access Point The access point detection

failed.

Note

If you encounter a problem during setup,

temporarily place your machine closer to the

wireless access point, and go back to step c.

Wireless setup is now complete.

For Wireless Network Users

Wireless setup is now complete. To

install MFL-Pro Suite, continue to

step 20.

For Windows® Users:

Now go to

page 37

For Macintosh Users:

Now go to

page 41

Windows®

Wireless Network

Windows®Macintosh

Install the Drivers & Software

(Windows

2000 Professional/XP/XP Professional x64 Edition/

Windows Vista

)

Before you install

MFL-Pro Suite

aMake sure that your computer is ON and you

are logged on with Administrator rights.

Install MFL-Pro Suite

aPut the supplied CD-ROM into your CD-ROM

drive. If the model name screen appears,

choose your machine. If the language screen

appears, choose your language.

bThe CD-ROM main menu will appear. Click

Initial Installation.

cClick Install MFL-Pro Suite.

IMPORTANT

• If there are any programs running, close

them.

• Make sure a USB Flash memory device is

not inserted into the machine.

• The screens may differ depending on the

operating system.

• The supplied CD-ROM includes ScanSoft™

PaperPort™ 11SE. This software supports

Windows® 2000 (SP4 or greater), XP (SP2 or

greater), XP Professional x64 Edition and

Windows Vista®. Update to the latest

Windows® Service Pack before installing

MFL-Pro Suite.

IMPORTANT

Disable all personal firewall

software (other than Windows®

Firewall), anti-spyware or

antivirus applications for the

duration of the installation.

Note

If the Brother screen does not appear

automatically, go to My Computer (Computer),

double-click the CD-ROM icon, and then

double-click Start.exe.

Windows®

Wireless Network

dChoose Wireless Network Connection, and

then click Next.

eClick on Wireless settings checked and

confirmed check box, and then click Next.

fWhen the ScanSoft™ PaperPort™ 11SE

License Agreement window appears, click

Yes if you agree to the Software

License Agreement.

gThe installation of ScanSoft™ PaperPort™

11SE will automatically start and is followed by

the installation of MFL-Pro Suite.

hWhen the Brother MFL-Pro Suite Software

License Agreement window appears, click

Yes if you agree to the Software

License Agreement.

iFor Windows® XP SP2/XP Professional x64

Edition/ Windows Vista® users, when this

screen appears, choose Change the Firewall

port settings to enable network connection

and continue with the installation.

(Recommended) and click Next.

If you are not using the Windows® Firewall, see

the User’s Guide for your software for

information on how to add the following

network ports.

For network scanning, add UDP port 54925.

For network PC-Fax receiving, add UDP port

54926.

If you still have trouble with your network

connection, add UDP port 137.

Note

• If the installation does not continue

automatically, open the main menu again by

ejecting and then reinserting the CD-ROM or

double-click the Start.exe program from the

root folder, and continue from step c to install

MFL-Pro Suite.

• For Windows Vista®, when the

User Account Control screen appears, click

Allow.

Note

If you want to install the PS driver (Brother’s

BR-Script Driver), choose Custom Install and

then follow the on-screen instructions. When the

Select Features screen appears, check

PS Printer Driver, and then continue following

the on-screen instructions.

Windows®

Wireless Network

Windows®Macintosh

jIf the machine is configured for your network,

choose the machine from the list, and then click

Next.

kIf you do not want to monitor the machine

status and error notification from your

computer, uncheck Enable Status Monitor

and then click Next.

lThe installation of the Brother drivers will

automatically start. The installation screens

appear one after another.

mWhen the On-Line Registration screen is

displayed, make your selection and follow the

on-screen instructions. Once you have

completed the registration process, close your

web browser to return to this window.

Then click Next.

Note

• You can find your machine’s IP address and

the node name by printing out the Network

Configuration List. See Print the Network

Configuration List on page 45.

• If your wireless settings fail, an error message

will appear during the installation of MFL-Pro

Suite and the installation will be terminated.

Confirm your network setting by following the

on-screen instruction. If you encounter this

failure, please go to step 18 on page 32 and

setup the wireless connection again.

• If you are using WEP and the LCD displayed

‘Connected’ but your machine is not found,

make sure you entered the WEP key correctly.

The WEP key is case sensitive.

• If the machine is not yet configured for use on

your network, the following screen appears.

Click OK and then Configure IP Address.

Enter an IP address for your machine that is

suitable for your network by following the on-

screen instructions.

IMPORTANT

DO NOT cancel any of the screens during the

installation. It may take a few seconds for all

screens to appear.

Note

For Windows Vista®, when this screen appears,

click the check box and click Install to complete

the installation correctly.

Windows®

Wireless Network

Finish and restart

aClick Finish to restart your computer. After

restarting the computer, you must be logged on

with Administrator rights.

bIf this screen appears, choose the firmware

update setting and click OK.

Install MFL-Pro Suite on

additional computers

(If needed)

If you want to use your machine with multiple

computers on the network, install MFL-Pro Suite on

each computer. Go to step 20 on page 37.

Note

If an error message appears during the software

installation, run the Installation Diagnostics

located in Start/All Programs/Brother/

MFC-XXXX LAN (where MFC-XXXX is your

model name).

Note

Internet access is required for the firmware

upgrade.

Note

The MFL-Pro Suite Software License permits

installation on up to 5 network computers. If you

want to install MFL-Pro Suite on additional

computers, you can purchase additional NL-5

(five user) license agreements from your

authorized Brother dealer or contact Brother

customer service.

Finish The installation is now

complete.

Note

XML Paper Specification Printer Driver

The XML Paper Specification Printer Driver is the

most suitable driver when printing from the

applications that use the XML Paper Specification

documents. Please download the latest driver by

accessing the Brother Solutions Center at

http://solutions.brother.com/.

Macintosh

Wireless Network

Windows®Macintosh

Install the Drivers & Software

(Mac OS X 10.3.9 or greater)

Before you install

MFL-Pro Suite

aMake sure your machine is connected to the

power and your Macintosh is ON. You must be

logged on with Administrator rights.

Install MFL-Pro Suite

aPut the supplied CD-ROM into your CD-ROM

drive.

bDouble-click Start Here OSX to install.

cChoose Wireless Network Connection, and

then click Next.

dClick on the Wireless settings checked and

confirmed check box, and then click Next.

Follow the on-screen instructions.

eThe Brother software will search for the Brother

device. During this time the following screen

will appear.

fIf the machine is configured for your network,

choose the machine from the list, and then click

OK.

IMPORTANT

Make sure a USB Flash memory device is not

inserted into the machine.

Note

Please see the Network User’s Guide on the

CD-ROM if you want to install the PS driver.

(Brother’s BR-Script Driver)

Note

Please wait, it will take a few seconds for the

software to install. After the installation, click

Restart to finish installing the software.

Macintosh

Wireless Network

gWhen this screen appears, click OK.

Install

Presto! PageManager

When Presto! PageManager is installed OCR

capability is added to Brother ControlCenter2. You

can easily scan, share and organize photos and

documents using Presto! PageManager.

aDouble-click Presto! PageManager and follow

the on-screen instructions.

Install MFL-Pro Suite on

additional computers

(If needed)

If you want to use your machine with multiple

computers on the network, install MFL-Pro Suite on

each computer. Go to step 20 on page 41.

Note

• You can find your machine’s IP address and

the node name by printing out the Network

Configuration List. See Print the Network

Configuration List on page 45.

• If your wireless settings fail, the installation of

the MFL-Pro software will be terminated.

Confirm your network settings. If you encounter

this failure, go to step 18 on page 32 and setup

the wireless connection again.

• If this screen appears click OK.

• Enter a name for your Macintosh in

Display Name up to 15 characters long and

click OK. Go to step g.

• If you want to use the machine’s Scan key to

scan over the network, you must check the

function on the machine box.

• The name you enter will appear on the

machine’s LCD when you press and

choose a scan option. (For more information,

see Network Scanning in the Software User’s

Guide on the CD-ROM.)

The installation of MFL-Pro Suite is now

complete.

Go to step 22 on page 42.

Finish The installation is now

complete.

For Network Users

BRAdmin Light utility (For Windows

users)

BRAdmin Light is a utility for initial setup of Brother network connected devices. It also can search for Brother

products on your network, view the status and configure basic network settings, such as IP address.

For more information on BRAdmin Light, visit us at http://solutions.brother.com/.

Install the BRAdmin Light

configuration utility

aClick Network Utilities on the menu screen.

bClick BRAdmin Light and follow the on-screen

instructions.

Set your IP address, Subnet Mask

and Gateway using BRAdmin Light

aStart BRAdmin Light. It will search for new

devices automatically.

bDouble-click the unconfigured device.

cChoose STATIC for the Boot Method. Enter

the IP Address, Subnet Mask and Gateway,

and then click OK.

dThe address information will be saved to the

machine.

Note

If you require more advanced printer management, use the latest Brother BRAdmin Professional utility version

that is available as a download from http://solutions.brother.com/.

Note

If you have a DHCP/BOOTP/RARP server in your

network, you do not have to do the following

operation. The machine will automatically obtain

its own IP address.

Note

The default password for the machine is ‘access’.

You can use BRAdmin Light to change this

password.

For Network Users

BRAdmin Light utility (For Mac OS X users)

BRAdmin Light is a utility for initial setup of Brother network connected devices. It also can search for Brother

products on your network, view the status and configure basic network settings, such as IP address from a

computer running Mac OS X 10.3.9 or greater.

The BRAdmin Light software will be installed automatically when you install the printer driver. If you have already

installed the printer driver, you do not have to install BRAdmin Light again. For more information on BRAdmin

Light, visit us at http://solutions.brother.com/.

Set your IP address, Subnet Mask

and Gateway using BRAdmin Light

aDouble-click Macintosh HD on your desktop.

bChoose Library, Printers, Brother and then

Utilities.

cDouble-click the file BRAdmin Light.jar and

run the software. BRAdmin Light will then

search for new devices automatically.

dDouble-click the unconfigured device.

eChoose STATIC for Boot Method. Enter the

IP Address, Subnet Mask and Gateway, and

then click OK.

fThe address information will be saved to the

machine.

Note

• If you have a DHCP/BOOTP/RARP server in

your network, you do not have to do the

following operation. The machine will

automatically obtain its own IP address.

• Make sure that version 1.4.2 or greater of Java

client software is installed on your computer.

• The default password for the machine is

‘access’. You can use BRAdmin Light to

change this password.

For Network Users

Web Based Management

(web browser)

The Brother print server is equipped with a web server

that allows you to monitor its status or change some

of its configuration settings, using HTTP (Hyper Text

Transfer Protocol).

aOpen your browser.

bType http:// printer_ip_address /into your

browser (Where “printer_ip_address” is the IP

address of the printer or the print server name).

You can find the IP address of the machine on

the Network Configuration List. See Print the

Network Configuration List on page 45.

For example http://192.168.1.2/

Print the Network

Configuration List

You can print the Network Configuration List to

confirm the current network settings. To print the

Network Configuration List:

aMake sure that the front cover is closed and the

AC power cord is plugged in.

bTurn on the machine and wait until the machine

is in the Ready state.

cPress Menu, 6, 6.

dPress Start.

The machine will print the current network

settings.

Restore the network settings to

factory default

To restore all network settings of the internal

Print/Scan server to factory default, please follow the

steps below.

aMake sure the machine is not operating, then

disconnect all the cables from the machine

(except the power cord).

bPress Menu, 7, 0.

cPress 1 to choose Reset.

dPress 1 to choose Yes.

eThe machine will restart, re-connect cables

once this is complete.

Note

• The User Name is ‘admin’ and the default

password is ‘access’. You can use a web

browser to change this password.

• We recommend Microsoft® Internet Explorer

6.0® (or higher) or Firefox 1.0 (or higher) for

Windows® and Safari 1.3 for Macintosh.

Please also make sure that JavaScript and

cookies are always enabled in whichever

browser you use. To use a web browser, you

will need to know the IP address of the print

server. The IP address of the print server is

listed on the Network Configuration List.

See Chapter 11 of the Network User’s Guide.

For Network Users

Entering Text for Wireless Settings

Most number keys have three or four letters printed on them. The keys for 0, # and l do not have printed letters

because they are used for special characters.

By pressing the proper number key repeatedly, you can access the character you want.

For configuring wireless network settings

Putting spaces

To enter a space in a name, press twice between characters.

Making corrections

If you entered a letter incorrectly and want to change it, press or to move the cursor under the

incorrect character, press Clear/Back. Re-enter the correct character. You can also back up and insert letters.

Repeating letters

If you need to enter a letter that is on the same key as the letter before, press to move the cursor right before

you press the key again.

Special characters and symbols

Press l, # or 0 repeatedly until you see the special character or symbol you want. Press OK to choose it.

Press

Key

One time Two

times

Three

times

Four

times

Five

times

Six

times

Seven

times

Eight

times

2abcABC2a

3de fDEF3d

4gh iGHI 4g

5jklJKL5j

6mn oMNO6m

7pqr sPQRS

8tuvTUV8t

9wxyzWXYZ

Press lfor (space) ! ” # $ % & ’ ( ) + , - . /

Press #for : ; < = > ? @ [ ] ^ _ \ ˜ ‘ | { }

Press 0for 0 \ { | } ˜

Options and Consumables

Options

For more details about the optional Lower Tray Unit and compatible SO-DIMM Memory please see the User’s

Guide or visit http://solutions.brother.com/.

Replacement consumables

When the time comes to replace consumable items, an error message will be indicated on the LCD. For more

information about the consumables for your machine, visit http://www.brother.com/original/ or contact your local

Brother re-seller.

Lower Tray Unit SO-DIMM Memory

LT-5300

Second lower paper tray unit can hold up to 250

sheets of paper. When the tray is installed, the

machine expands total input capacity up to 550

sheets.

You can expand the memory by installing a (144-pin

SO-DIMM) memory module.

Toner cartridge Drum unit

TN-620/TN-650 DR-620

Trademarks

The Brother logo is a registered trademark of Brother Industries, Ltd.

Brother is a registered trademark of Brother Industries, Ltd.

Windows Vista is either a registered trademark or a trademark of Microsoft Corporation in the United States and other countries.

Microsoft, Windows and Windows Server, Outlook and Internet Explorer are registered trademarks of Microsoft Corporation in the United

States and/or other countries.

Apple, Macintosh, Safari and TrueType are trademarks of Apple Inc., registered in the United States and other countries.

Nuance, the Nuance logo, PaperPort and ScanSoft are trademarks or registered trademarks of Nuance Communications, Inc. or its affiliates

in the United States and/or other countries.

BROADCOM, SecureEasySetup and the SecureEasySetup logo are trademarks or registered trademarks of Broadcom Corporation in the

United States and/or other countries.

AOSS is a trademark of Buffalo Inc.

Wi-Fi, WPA, WPA2, Wi-Fi Protected Access and Wi-Fi Protected Setup are either trademarks or registered trademarks of Wi-Fi Alliance in the

United States and/or other countries.

Each company whose software title is mentioned in this manual has a Software License Agreement specific to its proprietary programs.

Any trade names and product names of companies appearing on Brother products, related documents and any other

materials are all trademarks or registered trademarks of those respective companies.

Compilation and Publication

Under the supervision of Brother Industries, Ltd., this manual has been compiled and published, covering the latest product descriptions and

specifications.

The contents of this manual and the specifications of this product are subject to change without notice.

Brother reserves the right to make changes without notice in the specifications and materials contained herein and shall not be responsible for

any damages (including consequential) caused by reliance on the materials presented, including but not limited to typographical and other

errors relating to the publication.

This product includes software developed by the following vendors:

This product includes the “KASAGO TCP/IP” software developed by ZUKEN ELMIC, Inc.

Brother Mfc 8890Dw Quick Start Guide

Brother-Mfc-8690Dw-Quick-Start-Guide brother-mfc-8690dw-quick-start-guide

MFC-8690DW QSG_MFC_8690DW_8890DW_EN_4863

Navigation menu

Versions of this User Manual:

Views

Navigation
