AV Receiver

DTR-50.2

Instruction Manual

Introduction

Important Safety Instructions

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in

accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators,

heat registers, stoves, or other apparatus (including

amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or

grounding-type plug. A polarized plug has two blades

with one wider than the other. A grounding type plug

has two blades and a third grounding prong. The wide

blade or the third prong are provided for your safety. If

the provided plug does not fit into your outlet, consult

an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or

pinched particularly at plugs, convenience receptacles,

and the point where they exit from the apparatus.

11. Only use attachments/accessories specified by the

manufacturer.

12. Use only with the cart, stand,

tripod, bracket, or table speci-

fied by the manufacturer, or

sold with the apparatus. When

a cart is used, use caution

when moving the cart/appara-

tus combination to avoid

injury from tip-over.

13. Unplug this apparatus during lightning storms or when

unused for long periods of time.

14. Refer all servicing to qualified service personnel. Ser-

vicing is required when the apparatus has been dam-

aged in any way, such as power-supply cord or plug is

damaged, liquid has been spilled or objects have fallen

into the apparatus, the apparatus has been exposed to

rain or moisture, does not operate normally, or has

been dropped.

15. Damage Requiring Service

Unplug the apparatus from the wall outlet and refer

servicing to qualified service personnel under the fol-

lowing conditions:

A. When the power-supply cord or plug is damaged,

B. If liquid has been spilled, or objects have fallen

into the apparatus,

C. If the apparatus has been exposed to rain or water,

D. If the apparatus does not operate normally by fol-

lowing the operating instructions. Adjust only

those controls that are covered by the operating

instructions as an improper adjustment of other

controls may result in damage and will often

require extensive work by a qualified technician to

restore the apparatus to its normal operation,

E. If the apparatus has been dropped or damaged in

any way, and

F. When the apparatus exhibits a distinct change in

performance this indicates a need for service.

16. Object and Liquid Entry

Never push objects of any kind into the apparatus

through openings as they may touch dangerous volt-

age points or short-out parts that could result in a fire

or electric shock.

The apparatus shall not be exposed to dripping or

splashing and no objects filled with liquids, such as

vases shall be placed on the apparatus.

Don’t put candles or other burning objects on top of

this unit.

17. Batteries

Always consider the environmental issues and follow

local regulations when disposing of batteries.

18. If you install the apparatus in a built-in installation,

such as a bookcase or rack, ensure that there is ade-

quate ventilation.

Leave 20 cm (8") of free space at the top and sides and

10 cm (4") at the rear. The rear edge of the shelf or

board above the apparatus shall be set 10 cm (4")

away from the rear panel or wall, creating a flue-like

gap for warm air to escape.

WARNING:

TO REDUCE THE RISK OF FIRE OR ELECTRIC

SHOCK, DO NOT EXPOSE THIS APPARATUS TO

RAIN OR MOISTURE.

CAUTION:

TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK). NO

USER-SERVICEABLE PARTS INSIDE. REFER

SERVICING TO QUALIFIED SERVICE

PERSONNEL.

The lightning flash with arrowhead symbol, within an

equilateral triangle, is intended to alert the user to the

presence of uninsulated “dangerous voltage” within

the product’s enclosure that may be of sufficient

magnitude to constitute a risk of electric shock to

persons.

The exclamation point within an equilateral triangle is

intended to alert the user to the presence of important

operating and maintenance (servicing) instructions in

the literature accompanying the appliance.

WARNING

RISK OF ELECTRIC SHOCK

DO NOT OPEN

RISQUE DE CHOC ELECTRIQUE

NE PAS

OUVRIR

AVIS

PORTABLE CART WARNING

S3125A

Precautions

1. Recording Copyright—Unless it’s for personal use

only, recording copyrighted material is illegal without

the permission of the copyright holder.

2. AC Fuse—The AC fuse inside the unit is not user-ser-

viceable. If you cannot turn on the unit, contact the

dealer from whom you purchased this unit.

3. Care—Occasionally you should dust the unit all over

with a soft cloth. For stubborn stains, use a soft cloth

dampened with a weak solution of mild detergent and

water. Dry the unit immediately afterwards with a

clean cloth. Don’t use abrasive cloths, thinners, alco-

hol, or other chemical solvents, because they may

damage the finish or remove the panel lettering.

4. Power

WARNING

BEFORE PLUGGING IN THE UNIT FOR THE

FIRST TIME, READ THE FOLLOWING SECTION

CAREFULLY.

AC outlet voltages vary from country to country.

Make sure that the voltage in your area meets the volt-

age requirements printed on the unit’s rear panel (e.g.,

AC 230 V, 50 Hz or AC 120 V, 60 Hz).

The power cord plug is used to disconnect this unit

from the AC power source. Make sure that the plug is

readily operable (easily accessible) at all times.

Pressing On/Standby to select Standby mode does

not fully shutdown the unit. If you do not intend to use

the unit for an extended period, remove the power cord

from the AC outlet.

5. Preventing Hearing Loss

Caution

Excessive sound pressure from earphones and head-

phones can cause hearing loss.

6. Batteries and Heat Exposure

Warning

Batteries (battery pack or batteries installed) shall not

be exposed to excessive heat as sunshine, fire or the

like.

7. Never Touch this Unit with Wet Hands—Never han-

dle this unit or its power cord while your hands are

wet or damp. If water or any other liquid gets inside

this unit, have it checked by the dealer from whom

you purchased this unit.

8. Handling Notes

• If you need to transport this unit, use the original

packaging to pack it how it was when you originally

bought it.

• Do not leave rubber or plastic items on this unit for

a long time, because they may leave marks on the

case.

• This unit’s top and rear panels may get warm after

prolonged use. This is normal.

• If you do not use this unit for a long time, it may not

work properly the next time you turn it on, so be

sure to use it occasionally.

For U.S. models

FCC Information for User

CAUTION:

The user changes or modifications not expressly approved

by the party responsible for compliance could void the

user’s authority to operate the equipment.

NOTE:

This equipment has been tested and found to comply with

the limits for a Class B digital device, pursuant to Part 15

of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a

residential installation.

This equipment generates, uses and can radiate radio fre-

quency energy and, if not installed and used in accordance

with the instructions, may cause harmful interference to

radio communications. However, there is no guarantee

that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio

or television reception, which can be determined by turn-

ing the equipment off and on, the user is encouraged to try

to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and

receiver.

• Connect the equipment into an outlet on a circuit differ-

ent from that to which the receiver is connected.

• Consult the dealer from whom you purchased this unit or

an experienced radio/TV technician for help.

For Canadian Models

NOTE: THIS CLASS B DIGITAL APPARATUS COM-

PLIES WITH CANADIAN ICES-003.

For models having a power cord with a polarized plug:

CAUTION: TO PREVENT ELECTRIC SHOCK,

MATCH WIDE BLADE OF PLUG TO WIDE SLOT,

FULLY INSERT.

Modèle pour les Canadien

REMARQUE: CET APPAREIL NUMÉRIQUE DE

LA CLASSE B EST CONFORME À LA NORME NMB-

003 DU CANADA.

Sur les modèles dont la fiche est polarisée:

ATTENTION: POUR ÉVITER LES CHOCS ÉLEC-

TRIQUES, INTRODUIRE LA LAME LA PLUS LARGE

DE LA FICHE DANS LA BORNE CORRESPON-

DANTE DE LA PRISE ET POUSSER JUSQU’AU

FOND.

Thank you for purchasing an Integra AV receiver.

Please read this manual thoroughly before making con-

nections and plugging in the unit.

Following the instructions in this manual will enable you

to obtain optimum performance and listening enjoyment

from your new AV receiver.

Please retain this manual for future reference.

Supplied Accessories

Make sure you have the following accessories:

*In catalogs and on packaging, the letter at the end of the prod-

uct name indicates the color. Specifications and operations are

the same regardless of color.

Installing the Batteries

Note

• If the remote controller

doesn’t work reliably, try

replacing the batteries.

• Don’t mix new and old

batteries or different

types of batteries.

• If you intend not to use

the remote controller for

a long time, remove the

batteries to prevent dam-

age from leakage or corrosion.

• Remove expired batteries as soon as possible to prevent damage

from leakage or corrosion.

Aiming the Remote Controller

To use the remote controller, point it at the AV receiver’s

remote control sensor, as shown below.

Transmission

Received

Indoor FM antenna (➔21)

AM loop antenna (➔21)

Power cord (➔21)

Speaker cable labels (➔13)

Speaker setup microphone (➔29)

Remote controller and two batteries (AA/R6)

Using the Remote Controller

Batteries (AA/R6)

Remote control sensor

AV receiver

Approx. 16 ft. (5 m)

Transmitter

AV receiver

Approx. 16 ft. (5 m)

Incoming sensor

Contents

Introduction

Important Safety Instructions ......................................... 2

Precautions....................................................................... 3

Supplied Accessories...................................................... 4

Using the Remote Controller .......................................... 4

Features ............................................................................ 6

Front & Rear Panels......................................................... 8

Front Panel..................................................................... 8

Display............................................................................ 9

Rear Panel ................................................................... 10

Remote Controller.......................................................... 11

Controlling the AV Receiver ......................................... 11

About Home Theater...................................................... 12

Enjoying Home Theater................................................ 12

Connections

Connecting the AV Receiver ......................................... 13

Connecting Your Speakers .......................................... 13

Connecting a Power Amplifier ...................................... 16

About AV Connections ................................................. 17

Connecting Your Components with HDMI.................... 18

Connecting Your Components ..................................... 19

Connecting Integra/Onkyo u Components ................ 20

Connecting Antenna..................................................... 21

Connecting the Power Cord ......................................... 21

Which Connections Should I Use?............................... 22

Turning On & Basic Operations

Turning On/Off the AV Receiver ................................... 24

Turning On ................................................................... 24

Turning Off ................................................................... 24

Basic Operations............................................................ 25

Selecting the Language Used for

the Onscreen Setup Menus ....................................... 25

Playing the Connected Component.............................. 25

Displaying Source Information ..................................... 25

Setting the Display Brightness ..................................... 25

Muting the AV Receiver................................................ 26

Using the Sleep Timer.................................................. 26

Selecting Speaker Layout ............................................ 26

Using the Home Menu.................................................. 26

Changing the Input Display .......................................... 27

Using Headphones....................................................... 27

Using Activities to Start Easy Macros........................... 27

Audyssey MultEQ® Room Correction and

Speaker Setup ........................................................... 28

Listening to the Radio ................................................... 31

Using the Tuner............................................................ 31

Presetting FM/AM Stations........................................... 32

Listening to SIRIUS Satellite Radio®

(North American models)........................................... 32

Using RDS (Australian models).................................... 38

Recording ....................................................................... 40

Using the Listening Modes ........................................... 41

Selecting Listening Modes ........................................... 41

About Listening Modes................................................. 42

Advanced Operations

Advanced Setup ............................................................. 47

On-screen Setup Menus............................................... 47

Common Procedures in Setup Menu ........................... 47

Input/Output Assign ...................................................... 48

Speaker Setup..............................................................51

Audio Adjust .................................................................54

Source Setup................................................................56

Listening Mode Preset..................................................60

Miscellaneous ............................................................... 61

Hardware Setup............................................................ 61

Lock Setup.................................................................... 64

Using the Audio Settings .............................................. 64

NET/USB..........................................................................67

About NET .................................................................... 67

Connecting the AV Receiver ........................................67

Listening to Internet Radio............................................ 68

Playing Music Files on a Server ...................................69

Remote Playback from

Media Server/Personal Computer.............................. 72

Network Settings .......................................................... 73

About USB....................................................................75

Multi Zone .......................................................................77

Connecting Zone 2 .......................................................77

Connecting Zone 3 .......................................................78

Setting the Powered Zone 2 ......................................... 79

Setting the Multi Zone................................................... 79

Using Zone 2/3 .............................................................80

Using the 12V Triggers................................................. 82

Using the Remote Controller in

Zone 2/3 and Multiroom Control Kits ......................... 83

Controlling iPod & Other Components

Controlling iPod .............................................................84

Connecting the iPod Directly to the USB Port ..............84

Connecting an Onkyo Dock..........................................85

Using the Onkyo Dock..................................................86

Controlling Your iPod.................................................... 87

Controlling Other Components..................................... 89

Preprogrammed Remote Control Codes ...................... 89

Looking up for Remote Control Code ........................... 89

Entering Remote Control Codes................................... 91

Remote Control Codes for

Integra/Onkyo Components Connected via u......... 91

Resetting Remote Mode Buttons.................................. 92

Resetting the Remote Controller ..................................92

Controlling Other Components ..................................... 92

Activities Setup ............................................................. 94

Learning Commands ....................................................95

Using Normal Macros ................................................... 96

Others

Troubleshooting .............................................................97

Specifications ............................................................... 102

About HDMI................................................................... 104

Using an RIHD-compatible TV, Player, or Recorder

... 105

Video Resolution Chart................................................ 107

To reset the AV receiver to its factory defaults, turn it

on and, while holding down VCR/DVR, press

On/Standby (➔97).

Features

Amplifier

• 135 Watts/Channel @ 8 ohms (FTC)

• 180 Watts/Channel @ 6 ohms (IEC)

• 230 Watts/Channel @ 6 ohms (JEITA)

• WRAT–Wide Range Amplifier Technology

(5 Hz to 100 kHz bandwidth)

• Linear Optimum Gain Volume Circuitry

• H.C.P.S. (High Current Power Supply) Massive High

Power Transformer

Processing

• THX Select2 Plus*1 Certified

• HDMI Video Upscaling (to 1080p Compatible) with

Faroudja DCDi Cinema Enhancement

• HDMI (Ver.1.4a with Audio Return Channel, 3D), Deep-

Color, x.v.Color*10, Lip Sync, DTS*2-HD Master Audio,

DTS-HD High Resolution Audio, Dolby TrueHD*3,

Dolby Digital Plus, DSD and Multi-CH PCM

• Dolby Pro Logic IIz*3 – New Surround Format (front-

high)

• Audyssey DSX™*4 for New Surround Channels (front-

wide/front-high)

• 4 DSP Modes for Gaming; Rock/Sports/Action/RPG

• Non-Scaling Configuration

•A-Form Listening Mode Memory

• Direct Mode

• Music Optimizer*5 for Compressed Digital Music files

• 192 kHz/24-bit D/A Converters

• Powerful and Highly Accurate 32-bit Processing DSP

• Jitter Cleaning Circuit Technology

Connections

• 7 HDMI*6 Inputs (1 on front panel) and 2 Outputs

• Onkyo p for System Control

• 6 Digital Inputs (3 Optical/3 Coaxial)

• Component Video Switching (3 Inputs/1 Output)

• Universal Port for the Optional Dock for iPod*9/HD

Radio™*7 tuner module (North American models)/

DAB+ tuner module (Australian models)

• Dual Subwoofer Pre Out

• Powered Zone 2

• Internet Radio* Connectivity (SIRIUS Internet Radio*8/

vTuner/Pandora/Rhapsody*11/Slacker/Mediafly/Nap-

ster)

*Services available may vary depending on the region.

• Network Capability for Streaming Audio Files

• Front-Panel USB Input for Memory Devices and iPod®/

iPhone® models

• Bi-Amping Capability for FL/FR with SBL/SBR

• Analog RGB Video Input (D-sub 15) for PC

Miscellaneous

• 40 SIRIUS*8/FM/AM Presets (North American mod-

els)

• 40 FM/AM Presets (Australian models)

• Audyssey MultEQ®*4 to Correct Room Acoustic Prob-

lems

• Audyssey Dynamic EQ®*4 for Loudness Correction

• Audyssey Dynamic Volume®*4 to Maintain Optimal

Listening Level and Dynamic Range

• Crossover Adjustment

(40/45/50/55/60/70/80/90/100/110/120/130/150/200 Hz)

• A/V Sync Control Function (up to 250 ms)

• Auto Power-down Function

• Bi-Directional Preprogrammed (with onscreen display

setup) RI-Compatible Learning Remote with 4 Activities

and Mode-Key LEDs

• ISF (Imaging Science Foundation) Video Calibration

THX and the THX logo are trademarks of THX Ltd. which

Manufactured under license under U.S. Patent #'s: 5,451,942;

5,956,674; 5,974,380; 5,978,762; 6,226,616; 6,487,535;

7,212,872; 7,333,929; 7,392,195; 7,272,567 & other U.S. and

worldwide patents issued & pending. DTS and the Symbol are

registered trademarks, & DTS-HD, DTS-HD Master Audio,

and the DTS logos are trademarks of DTS, Inc. Product

includes software.

Manufactured under license from Dolby Laboratories.

“Dolby”, “Pro Logic”, “Surround EX” and the double-D sym-

bol are trademarks of Dolby Laboratories.

Manufactured under license from Audyssey Laboratories™.

U.S. and foreign patents pending. Audyssey MultEQ®,

Audyssey DSX™, Audyssey Dynamic Volume® and

Audyssey Dynamic EQ® are registered trademarks and trade-

marks of Audyssey Laboratories.

*5 Music Optimizer™ is a trademark of Onkyo Corporation.

“HDMI, the HDMI Logo, and High-Definition Multimedia

Interface are trademarks or registered trademarks of HDMI

Licensing LLC in the United States and other countries.”

HD Radio™ and the HD Radio Ready logo are proprietary

trademarks of iBiquity Digital Corporation.

To receive HD Radio broadcasts, you must install an Onkyo

UP-HT1 HD Radio tuner module (sold separately).

SIRIUS, XM and all related marks and logos are trademarks

of Sirius XM Radio Inc. and its subsidiaries. All rights

reserved. Service not available in Alaska and Hawaii.

iPhone, iPod, iPod classic, iPod nano, iPod shuffle, and iPod

touch are trademarks of Apple Inc., registered in the U.S. and

other countries.

“Made for iPod” and “Made for iPhone” mean that an elec-

tronic accessory has been designed to connect specifically to

iPod or iPhone, respectively, and has been certified by the

developer to meet Apple performance standards. Apple is not

responsible for the operation of this device or its compliance

with safety and regulatory standards.

*10 “x.v.Color” is a trademark of Sony Corporation.

*11 Rhapsody and the Rhapsody logo are registered trademarks of

RealNetworks, Inc.

*“Xantech” is a registered trademark of Xantech Corporation.

*“Niles” is a registered trademark of Niles Audio Corporation.

*“DLNA®, the DLNA Logo and DLNA CERTIFIED™ are

trademarks, service marks, or certification marks of the Digi-

tal Living Network Alliance.”

*This product incorporates copyright protection technology

that is protected by U.S. patents and other intellectual prop-

erty rights. Use of this copyright protection technology must

be authorized by Macrovision Corporation, and is intended for

home and other limited consumer uses only unless otherwise

authorized by Macrovision. Reverse engineering or disassem-

bly is prohibited.

*Windows and the Windows logo are trademarks of the

Microsoft group of companies.

THX Select2 Plus

Before any home theater component can be THX Select2

Plus certified, it must pass a rigorous series of quality and

performance tests. Only then can a product feature the

THX Select2 Plus logo, which is your guarantee that the

Home Theater products you purchase will give you

superb performance for many years to come. THX

Select2 Plus requirements define hundreds of parameters,

including power amplifier performance, and pre-ampli-

fier performance and operation for both digital and ana-

log domains. THX Select2 Plus receivers also feature

proprietary THX technologies (e.g., THX Mode) which

accurately translate movie soundtracks for home theater

playback.

Front & Rear Panels

The actual front panel has various logos printed on it. They are not shown here for clarity.

The page numbers in parentheses show where you can find the main explanation for each item.

aOn/Standby button (➔24)

bStandby indicator (➔24)

cZone 2 indicator (➔80)

dZone 3 indicator (➔80)

eRemote control sensor/transmitter (➔4)

fMonitor Out button (➔48)

gTone and –/+ buttons (➔64, 81)

hDisplay (➔9)

iMovie/TV button (➔41)

jMusic button (➔41)

kGame button (➔41)

lDimmer button (North American models) (➔25)

mMemory button (➔32)

nTuning Mode button (➔31)

oDisplay button (➔25)

pSetup button (➔47)

qTuning, Preset (➔31 to 38), arrow and

Enter buttons

rReturn button

sMaster Volume control (➔25)

tZone 2 and Off buttons (➔80)

uZone 3 and Off buttons (➔80)

vPhones jack (➔27)

wSetup Mic jack (➔29)

xZone Level buttons (➔81)

yInput selector buttons (➔25)

zUSB port (➔75, 84)

AAUX Input HDMI jack (➔18)

BAUX Input jacks (Video, Audio L/R and Digital)

(➔19)

CRT/PTY/TP button (Australian models) (➔38)

Front Panel

bcdefhgijklmn op

vtu w z

rsq

North American models

Australian models

For detailed information, see the pages in parentheses.

aSpeaker/channel indicators

bZ2 (Powered Zone 2) indicator (➔80)

cListening mode and format indicators (➔41, 65)

dNETWORK indicator (➔68, 69, 73)

eTuning indicators

RDS indicator (Australian models) (➔38)

AUTO indicator (➔31)

TUNED indicator (➔31)

FM STEREO indicator (➔31)

fSLEEP indicator (➔26)

gBi AMP indicator (➔15)

hHeadphone indicator (➔27)

iAudyssey indicator (➔28, 53)

Dynamic EQ indicator (➔56)

Dynamic Vol indicator (➔56)

jMessage area

kUSB indicator (➔75, 84)

lVolume level (➔25)

mMUTING indicator (➔26)

nAudio input indicators

Display

bc ea f

ghi jklm

aDIGITAL IN COAXIAL and OPTICAL jacks

bRS232 terminal

Terminal for control.

cu REMOTE CONTROL jack

dETHERNET port

eUNIVERSAL PORT jack

fMONITOR OUT V and S jacks

gCOMPONENT VIDEO IN and MONITOR OUT

jacks

hHDMI IN and HDMI output (HDMI OUT MAIN and

HDMI OUT SUB) jacks

iCOMPONENT VIDEO ZONE 2 OUT jacks

jIR IN (A/B) and OUT jacks

k12V TRIGGER OUT (A/B/C) jacks

lZONE 2 OUT V jack

mFM ANTENNA jack and AM ANTENNA terminal

nPC IN port

oAC INLET

pGND screw

qSIRIUS antenna jack (North American models)

rComposite, S-Video and analog audio jacks

(BD/DVD IN, VCR/DVR IN and OUT, CBL/SAT IN,

GAME IN, PC IN, TV/CD IN and PHONO IN)

sMultichannel input jacks

(FRONT L/R, CENTER, SURR L/R, SURR BACK

L/R and SUBWOOFER)

tPRE OUT jacks

(FRONT L/R, CENTER, SURR L/R,

SB/FH/FW L/R, SUBWOOFER, ZONE 2 L/R and

ZONE 3 L/R)

* SB···Surround Back, FH···Front High, FW···Front Wide

uSpeaker Terminals

(FRONT L/R, CENTER, SURR L/R,

SURR BACK L/R, FRONT HIGH L/R and

FRONT WIDE/ZONE 2 L/R)

Rear Panel

ab e mfdg n oh k

prstu

cj l

See “Connecting the AV Receiver” for connection infor-

mation (➔13 to 23).

Remote Controller

For detailed information, see the pages in parentheses.

aStandby button (➔24)

bOn button (➔24)

cActivities buttons (All Off, My Movie, My TV and

My Music) (➔27, 96)

dRemote Mode/Input Selector buttons

(BD/DVD, VCR/DVR, CBL/SAT, Game, PC, AUX,

Tape, Tuner, Phono, Port and NET/USB) (➔25)

eSP Layout button (➔26)

fArrow q/w/e/r and Enter buttons

gSetup button (➔47)

hListening Mode buttons (Movie/TV, Music,

Game and THX) (➔41)

iDimmer button (➔25)

jDisplay button (➔25)

kMuting button (➔26)

lVOL q/w button (➔25)

mReturn button

nHome button (➔26)

oSleep button (➔26)

■Controlling the tuner

To control the AV receiver’s tuner, press Tuner (or

Receiver).

You can select AM or FM by pressing Tuner repeatedly.

aArrow q/w buttons (➔31)

bD.TUN button (Tuner remote mode only) (➔31)

cCH +/– button (➔32)

dNumber buttons (➔31)

*1 When you want to change the remote controller mode without

changing the current input source, press Mode and within

about 8 seconds, press Remote Mode. Then, with the AV

receiver’s remote controller, you can control the component

corresponding to the button you pressed.

*2 These buttons can be used when not in receiver mode, and

when a Remote Mode other than receiver mode is selected.

(Pressing Home switches to Receiver mode.)

*3 Video functions as a short cut of Home.

Controlling the AV Receiver

*1 *2

To control the AV receiver, press Receiver to select

Receiver mode.

You can also use the remote controller to control

Onkyo Blu-ray Disc/DVD player, CD player and

other components.

See “Entering Remote Control Codes” for more

details (➔91).

About Home Theater

Thanks to the AV receiver’s superb capabilities, you can enjoy surround sound with a real sense of movement in your

own home—just like being in a movie theater or concert hall. With Blu-ray Discs or DVDs, you can enjoy DTS and

Dolby Digital. With analog or digital TV, you can enjoy Dolby Pro Logic IIx, DTS Neo:6, or Onkyo’s original DSP lis-

tening modes.

You can also enjoy THX Surround EX (THX-certified THX speaker system recommended).

Enjoying Home Theater

abFront speakers (Left and Right)

These output the overall sound. Their role in a home theater is to pro-

vide a solid anchor for the sound image. They should be positioned

facing the listener at about ear level, and equidistant from the TV.

Angle them inward so as to create a triangle, with the listener at the

apex.

cCenter speaker

This speaker enhances the front speakers, making sound movements

distinct and providing a full sound image. In movies it’s used mainly

for dialog. Position it close to your TV facing forward at about ear

level, or at the same height as the front speakers.

deSurround speakers (Left and Right)

These speakers are used for precise sound positioning and to add real-

istic ambience. Position them at the sides of the listener, or slightly

behind, about 2 to 3 feet (60 to 100 cm) above ear level. Ideally they

should be equidistant from the listener.

fSubwoofer(s)

The subwoofer handles the bass sounds of the LFE (Low-Frequency

Effects) channel. The volume and quality of the bass output from your

subwoofer will depend on its position, the shape of your listening

room, and your listening position. In general, a good bass sound can be

obtained by installing the subwoofer in a front corner, or at one-third

the width of the wall, as shown.

ghSurround back speakers (Left and Right)

These speakers are necessary to enjoy Dolby Digital EX, DTS-ES

Matrix, DTS-ES Discrete, THX Surround EX, etc. They enhance the

realism of surround sound and improve sound localization behind the

listener. Position them behind the listener about 2 to 3 feet (60 to

100 cm) above ear level.

ijFront high speakers (Left and Right)

These speakers are necessary to enjoy Dolby Pro Logic IIz Height, and

Audyssey DSX™. They significantly enhance the spatial experience.

Position them at least 3.3 feet (100 cm) above the front speakers (pref-

erably as high as possible) and at an angle slightly wider than the front

speakers.

klFront wide speakers (Left and Right)

These speakers are necessary to enjoy Audyssey DSX. They signifi-

cantly enhance the spatial experience. Position them well outside of the

front speakers. See also

http://www.audyssey.com/technology/dsx.html

about optimum speaker placement for Audyssey DSX.

Corner

position

1/3 of wall

position

Tip

• To find the best position for your subwoofer, while

playing a movie or some music with good bass,

experiment by placing your subwoofer at various

positions within the room, and choose the one that

provides the most satisfying results.

Connections

Connecting the AV Receiver

Speaker Configuration

The following table indicates the channels you should use

depending on the number of speakers that you have.

For 7.1-channel surround-sound playback, you need 7

speakers and a powered subwoofer.

*1 If you’re using only one surround back speaker, connect it to

the SURR BACK L terminals.

*2 Front high, surround back and front wide speakers cannot be

used at the same time.

No matter how many speakers you use, a powered sub-

woofer is recommended for a really powerful and solid

bass.

To get the best from your surround sound system, you

need to set the speaker settings. You can do this automati-

cally (➔28) or manually (➔51).

Attaching the Speaker Cable Labels

The AV receiver’s positive (+) speaker terminals are all

red (the negative (–) speaker terminals are all black).

The supplied speaker cable labels are also color-coded and

you should attach them to the positive (+) side of each

speaker cable in accordance with the table above. Then all

you need to do is to match the color of each label to the

corresponding speaker terminal.

Speaker Connection Precautions

Read the following before connecting your speakers:

• You can connect speakers with an impedance of between

4 and 16 ohms. If the impedance of any of the connected

speakers is 4 ohms or more, but less than 6 ohms, be sure

to set the minimum speaker impedance to “4ohms”

(➔51). If you use speakers with a lower impedance, and

use the amplifier at high volume levels for a long period

of time, the built-in protection circuit may be activated.

• Disconnect the power cord from the wall outlet before

making any connections.

• Read the instructions supplied with your speakers.

• Pay close attention to speaker wiring polarity. In other

words, connect positive (+) terminals only to positive (+)

terminals, and negative (–) terminals only to negative (–)

terminals. If you get them the wrong way around, the

sound will be out of phase and will sound unnatural.

• Unnecessarily long, or very thin speaker cables may

affect the sound quality and should be avoided.

• Be careful not to short the positive and negative wires.

Doing so may damage the AV receiver.

• Make sure the metal core of the wire does not have con-

tact with the AV receiver’s rear panel. Doing so may

damage the AV receiver.

• Don’t connect more than one cable to each speaker ter-

minal. Doing so may damage the AV receiver.

• Don’t connect one speaker to several terminals.

Connecting Your Speakers

Number of

speakers

23456777889991011

Front speakers ✔✔✔✔✔✔✔✔✔✔✔✔✔✔ ✔

Center

speaker

✔ ✔✔✔✔✔✔✔✔✔✔✔ ✔

Surround

speakers

✔✔✔✔✔✔✔✔✔✔✔✔ ✔

Surround back

speaker*1*2

✔✔✔✔

Surround back

speakers*2

✔✔✔✔

Front high

speakers*2

✔✔✔✔✔✔

Front wide

speakers*2

✔✔✔✔✔✔

Speaker Color

Front left, Front high left, Front wide left,

Zone 2 left

White

Front right, Front high right, Front wide right,

Zone 2 right

Red

Center Green

Surround left Blue

Surround right Gray

Surround back left Brown

Surround back right Tan

Connecting the Speaker Cables

Screw-type speaker terminals

Using Banana Plugs (North American models)

• If you are using banana plugs, tighten the speaker terminal before inserting the banana plug.

• Do not insert the speaker code directly into the center hole of the speaker terminal.

The following illustration shows which speaker should be connected to each pair of terminals. If you’re using only one

surround back speaker, connect it to the SURR BACK L terminals.

Strip 1/2" to 5/8" (12 to 15 mm) of

insulation from the ends of the

speaker cables, and twist the bare

wires tightly, as shown.

1/2" to 5/8"(12 to 15 mm)

Surround

back left

speaker

Surround

left

speaker

Surround

right

speaker

Front high

left

speaker

Front high

right

speaker

Front left

speaker

Front right

speaker

Center

speaker

Front wide

right

speaker

Front wide

left

speaker

Surround

back right

speaker

Using Dipole Speakers

You can use dipole speakers for the surround and surround

back speakers. Dipole speakers output the same sound in two

directions.

Dipole speakers typically have an arrow printed on them to

indicate how they should be positioned. The surround dipole

speakers should be positioned so that their arrows point

toward the TV/screen, while the surround back dipole speak-

ers should be positioned so that their arrows point toward

each other, as shown.

ab Front speakers

cCenter speaker

de Surround speakers

fSubwoofer(s)

gh Surround back speakers

ij Front high speakers

kl Front wide speakers

Connecting the Powered Subwoofers

Using a suitable cable, connect the AV receiver’s

SUBWOOFER PRE OUT jack to an input on

your powered subwoofer, as shown. If your sub-

woofer is unpowered and you’re using an external

amplifier, connect the SUBWOOFER PRE OUT

jack to an input on the amp.

You can connect the powered subwoofer with two

SUBWOOFER PRE OUT jacks respectively.

The same signal is output from each jack.

Bi-amping the Front Speakers

The FRONT L/R and SURR BACK L/R terminal posts can be

used with front speakers and surround back speakers respec-

tively, or bi-amped to provide separate tweeter and woofer feeds

for a pair of front speakers that support bi-amping, providing

improved bass and treble performance.

• When bi-amping is used, the AV receiver is able to drive up to

a 5.1 speaker system in the main room.

• For bi-amping, the FRONT L/R terminal posts connect to the

front speakers’ woofer terminals; the SURR BACK L/R ter-

minal posts connect to the front speakers’ tweeter terminals.

• Once you’ve completed the bi-amping connections shown

below and turned on the AV receiver, you must set the “Speak-

ers Type(Front)” setting to “Bi-Amp” to enable bi-amping

(➔51).

Important:

• When making the bi-amping connections, be sure to remove the jumper bars that link the speakers’ tweeter (high) and woofer (low)

terminals.

• Bi-amping can be used only with speakers that support bi-amping. Refer to your speaker manual.

TV/screen TV/screen

Dipole speakers Normal speakers

Powered subwoofer

Woofer (low)

Left

speaker

Tweeter (high)

Right

speaker

If you want to use a more powerful power amplifier and use the AV receiver as a preamp, connect it to the PRE OUT

jacks, and connect all speakers and the subwoofer to the power amplifier. If you have a powered subwoofer, connect it to

this AV receiver’s SUBWOOFER PRE OUT jack. You can connect the powered subwoofer with two SUBWOOFER

PRE OUT jacks respectively. The same signal is output from each jack.

Connecting a Power Amplifier

b c d e f g a

Power amplifier

Powered subwoofer

See “Connecting the Powered

Subwoofers” for more informa-

tion (➔15).

aFront left speaker

bCenter speaker

cFront right speaker

dSurround left speaker

eSurround right speaker

fSurround back/Front high/Front wide left speaker*1

gSurround back/Front high/Front wide right speaker*1

Note

*1 Specify “None” for the channel that you don’t want to output (➔51).

SB···Surround Back, FH···Front High, FW···Front Wide

Connected image with AV components

• Before making any AV connections, read the manuals supplied with your AV components.

• Don’t connect the power cord until you’ve completed and double-checked all AV connections.

• Push plugs in all the way to make good connections (loose connections can cause noise or malfunc-

tions).

• To prevent interference, keep audio and video cables away from power cords and speaker cables.

AV Cables and Jacks

*Available sampling rate for PCM input signal is 32/44.1/48/88.2/96 kHz. Even 176.4/192 kHz is effective in case of the HDMI con-

nection.

Note

• The AV receiver does not support SCART plugs.

• The AV receiver’s optical digital jacks have shutter-type covers that open when an optical plug is inserted and close when it’s removed.

Push plugs in all the way.

Caution

• To prevent shutter damage, hold the optical plug straight when inserting and removing.

About AV Connections

Signal Cable Jack Description

Video and

Audio

HDMI HDMI connections can carry digital video and audio.

Video Component video Component video separates the luminance (Y) and color

difference signals (PB/CB, PR/CR), providing the best pic-

ture quality (some TV manufacturers label their compo-

nent video sockets slightly differently).

Analog RGB This is a conventional analog interface to connect a PC and

a display device (also called D-Sub or D-subminiature).

S-Video S-Video separates the luminance and color signals and pro-

vides better picture quality than composite video.

Composite video Composite video is commonly used on TVs, VCRs, and

See also:

• “Controlling Other Components” (➔89)

• “Controlling iPod” (➔84)

• “Listening to the Radio” (➔31)

3To adjust the volume, use the Master Volume

control.

4Select a listening mode and enjoy!

See also:

• “Using the Listening Modes” (➔41)

• “Audyssey” (➔56)

1Press Receiver followed by Input Selector.

2Start playback on the source component.

See also:

• “Controlling Other Components” (➔89)

• “Controlling iPod” (➔84)

• “Listening to the Radio” (➔31)

3To adjust the volume, use VOL q/w.

4Select a listening mode and enjoy!

See also:

• “Using the Listening Modes” (➔41)

• “Audyssey” (➔56)

Displaying Source Information

Press Receiver followed by Display repeatedly to

cycle through the available information.

Setting the Display Brightness

Press Receiver followed by Dimmer repeatedly

to select: dim, dimmer, or normal brightness.

Sampling

frequency

Input source

Signal format*2

Input signal

resolution

Output

resolution

Listening

mode*1

You can temporarily mute the output of the AV receiver.

Tip

• To unmute, press Muting again or adjust the volume.

• The Mute function is cancelled when the AV receiver is set to

Standby.

With the sleep timer, you can set the AV receiver to turn

off automatically after a specified period.

Tip

• If you need to cancel the sleep timer, press Sleep repeatedly

until the SLEEP indicator goes off.

• To check the time remaining until the AV receiver sleeps, press

Sleep. Note that if you press Sleep while the sleep time is

being displayed, you’ll shorten the sleep time by 10 minutes.

You can prioritize which speakers you want to use.

Note

•If the “Speakers Type(Front)” setting is set to “Bi-Amp”

(➔51), or Powered Zone 2 is being used (➔80), this setting

cannot be selected.

• When the listening mode that doesn’t support front high, front

wide or surround back speakers is used, the setting cannot be

selected.

The Home menu provides you quick access to frequently

used menus without having to go through the long stan-

dard menu. This menu enables you to change settings and

view the current information.

Muting the AV Receiver

Press Receiver followed by Muting.

The output is muted and the MUTING indicator

flashes on the display.

Using the Sleep Timer

Press Receiver followed by Sleep repeatedly to

select the required sleep time.

The sleep time can be set from 90 to 10 minutes in

10 minute steps.

The SLEEP indicator lights on the display when the

sleep timer has been set. The specified sleep time

appears on the display for about 5 seconds, then the

previous display reappears.

Selecting Speaker Layout

Press Receiver followed by SP Layout repeat-

edly.

`Speaker Layout:FH:

The sound from front high speakers is output

by priority.

`Speaker Layout:FW:

The sound from front wide speakers is output

by priority.

`Speaker Layout:SB:

The sound from surround back speakers is out-

put by priority.

Using the Home Menu

1Press Receiver followed by Home.

The following information will be superimposed on

the TV screen.

2Use q/w/e/r to make the desired selection.

■Audio*1

`You can change the following settings: “Bass”,

“Treble”, “Subwoofer Level”, “Center Level”,

“Dynamic EQ”, “Dynamic Volume”, “Late

Night”, “Music Optimizer”, “Re-EQ”, “Re-

EQ(THX)” and “Audio Selector”.

See also:

• “Audyssey” (➔56)

• “Using the Audio Settings” (➔64)

■Video*2

`You can change the following settings: “Wide

Mode”, “Picture Mode”, “Brightness”, “Con-

trast”, “Hue” and “Saturation”.

The remote controller’s Video acts as a shortcut

for this menu.

See also:

• “Picture Adjust” (➔58)

■Info*3*4

`You can view the information of the following

items: “Audio”, “Video” and “Tuner”.

■Input*4*5

`You can select the input source while viewing

the information as follows: the name of input

selectors, input assignments, and radio informa-

tion, and ARC function setting.

Press Enter to display the current input source,

followed by q/w to select the desired input

source. Pressing Enter again switches to the

selected input source.

■Listening Mode

`You can select the listening modes that are

grouped in the following categories: “MOVIE/

TV”, “MUSIC”, “GAME” and “THX”.

Use q/w to select the category and e/r to

select the listening mode. Press Enter to

switch to the selected listening mode.

BD/DVD

Audio

Video

Info

Input

Listening Mode

Bass

Treble

Subwoofer Level

Center Level

Dynamic EQ

Dynamic Volume

0dB

Note

*1 If Direct listening mode is selected, “Dynamic EQ” and

“Dynamic Volume” cannot be selected.

*2 Only when you have selected “Custom” in the “Picture

Mode” (➔59), pressing Enter allows you to adjust the fol-

lowing items via the Home menu; “Brightness”, “Contrast”,

“Hue” and “Saturation”. Press Return to return to the origi-

nal Home menu.

*3 Depending on the input source and listening mode, not all

channels shown here output the sound.

*4 When you have entered a custom name in “Name Edit”

(➔57), the input source is displayed with that name. But

even if not, the component name may be displayed if the AV

receiver receives it via HDMI connection (➔18).

*5 For the Port input selector, the name of Universal Port Option

Dock will be displayed.

When you connect an u-capable Onkyo component, you

must configure the input display so that u can work

properly.

This setting can be done only from the front panel.

Note

•DOCK can be selected for the TV/CD, Game or VCR/DVR

input selector, but not at the same time.

• Enter the appropriate remote control code before using the

remote controller for the first time (➔89).

Note

• Always turn down the volume before connecting your head-

phones.

• While the headphones plug is inserted in the Phones jack, the

Headphone indicator, speaker/channel indicator FL and FR

lights. (The Powered Zone 2 speakers are not turned off.)

• When you connect a pair of headphones, the listening mode is

set to Stereo, unless it’s already set to Stereo, Mono or Direct.

• Only the Stereo, Direct, and Mono listening modes can be used

with headphones.

You can use Activities to execute a number of remote

control operations with a single button.

This button has the following two modes.

`Easy Macro mode:

You can turn on and off the AV receiver, playback

components and TV.

`Normal Macro mode:

You can assign desired operations (➔94, 96).

Note

• If you set any one of the Activities to Normal Macro mode, all

the Activities will be set to Normal Macro mode.

• To use Activities, first assign the remote control codes of the

AV components you are using (➔91).

Starting Components Using Activities

Changing the Input Display

1Press TV/CD, Game or VCR/DVR so that “TV/

CD”, “GAME” or “VCR/DVR” appears on the

display.

2Press and hold down TV/CD, Game or VCR/DVR

(about 3 seconds) to change the input display.

Repeat this step to select “MD”, “CDR”, “DOCK”

or “TAPE”.

For the TV/CD input selector, the input display

changes in this order:

For the Game input selector, the setting changes in

this order:

For the VCR/DVR input selector, the setting

changes in this order:

TV/CD → MD → CDR

DOCK

→

TAPE

→

GAME ↔ DOCK

VCR/DVR ↔ DOCK

Using Headphones

Connect a pair of stereo headphones with a stan-

dard plug (1/4 inch or 6.3 mm) to the Phones

jack.

Using Activities to Start Easy Macros

Press My Movie, My TV, or My Music.

At purchase, Activities are set to Easy Macro mode

as the default setting.

The default actions are described below.

My Movie:

1. The TV turns on.

2. The playback component assigned to BD/DVD

of Remote Mode turns on.

3. The AV receiver turns on.

4. The input selector of the AV receiver is set to

BD/DVD.

5. Playback begins on the playback component

assigned to BD/DVD.*1

My TV:

1. The TV turns on.

2. The playback component assigned to CBL/SAT

of Remote Mode turns on.

3. The AV receiver turns on.

4. The input selector of the AV receiver is set to

CBL/SAT.

*1 Depending on the start-up time of the playback component,

the AV receiver may not be able to activate the playback com-

mand. In this case, press 1 on the remote controller.

Turning Off the Components

*2 When the last-pressed Activities is My Music, the TV will

not turn off.

Changing the Playback Components

Assigned to Activities

You can change the playback components assigned to the

Activities of Easy Macro mode using the following pro-

cedure.

Restoring Default

With the supplied calibrated microphone,

Audyssey MultEQ automatically determines the number

of speakers connected, their size for purposes of bass man-

agement, optimum crossover frequencies to the subwoofer

(if present), and distances from the primary listening posi-

tion.

Audyssey MultEQ then removes the distortion caused by

room acoustics by capturing room acoustical problems

over the listening area in both the frequency and time

domain. The result is clear, well-balanced sound for every-

one. Enabling Audyssey MultEQ allows you to also use

Audyssey Dynamic EQ®, which maintains the proper

octave-to-octave balance at any volume level (➔56).

Before using this function, connect and position all of

your speakers.

If “Dynamic EQ” is set to “On” (➔56), the “Equalizer”

setting will be set to “Audyssey” (➔53). On the other

hand, if it is set to “Off”, the “Dynamic Volume” setting

will be set to “Off” (➔56).

It takes about 30 minutes to complete Audyssey MultEQ

Room Correction and Speaker Setup for 6 positions. Total

measurement time varies depending on the number of

speakers.

Using Audyssey MultEQ

Using Audyssey MultEQ to create a listening environment

in your home theater that all listeners will enjoy,

Audyssey MultEQ takes measurements at up to six posi-

tions within the listening area. Position the microphone at

ear height of a seated listener with the microphone tip

pointed directly at the ceiling using a tripod. Do not hold

the microphone in your hand during measurements as this

will produce inaccurate results.

■First measurement position

Also referred to as the Main Listening Position this

refers to the most central position where one would nor-

mally sit within the listening environment. MultEQ uses

the measurements from this position to calculate

speaker distance, level, polarity, and the optimum cross-

over value for the subwoofer.

■Second−Sixth measurement positions

These are the other listening positions (i.e., the places

where the other listeners will sit). You can measure up

to 6 positions.

The following examples show some typical home theater

seating arrangements. Choose the one that best matches

yours, and position the microphone accordingly when

prompted.

My Music:

1. The playback component assigned to TV/CD of

Remote Mode turns on.

2. The AV receiver turns on.

3. The input selector of the AV receiver is set to

TV/CD.

4. Playback begins on playback component

assigned to TV/CD.*1

Note

• After pressing one of the Activities, you cannot use other

Activities until the assigned actions have been com-

pleted.

• If you wish to use another of the Activities after starting,

press All Off and then press the desired Activities.

Press All Off.

The playback component assigned to the last-

pressed Activities, the AV receiver, and the TV turn

off.*2

While holding down Remote Mode for the rele-

vant playback component, press and hold down

Activities to which you wish to assign this compo-

nent for about 3 seconds.

Activities will flash twice, indicating that the

change is complete.

Examples:

If you wished to use My Movie to start the playback

component assigned to VCR/DVR of Remote

Mode, you would press and hold down My Movie

for about 3 seconds while pressing down VCR/DVR

of Remote Mode.

Tip

• This procedure can also be performed via onscreen menu

(➔94).

1While holding down Home, press and hold down

All Off until All Off lights (about 3 seconds).

2Release Home and All Off and press All Off

again.

All Off flashes twice.

Audyssey MultEQ® Room Correction

and Speaker Setup

Note

• Make the room as quiet as possible. Background noise and Radio

Frequency Interference (RFI) can disrupt the room measure-

ments. Close windows, televisions, radios, air conditioners, flu-

orescent lights, home appliances, light dimmers, or other

devices. Turn off the cell phone (even if it is not in use) or place

it away from all audio electronics.

• The microphone picks up test tones which played through each

speaker as Audyssey MultEQ® Room Correction and Speaker

Setup run.

• Audyssey MultEQ Room Correction and Speaker Setup cannot

be performed while a pair of headphones is connected.

1Turn on the AV receiver and the connected TV.

On the TV, select the input to which the AV receiver

is connected.

2Set the speaker setup microphone at the Main Lis-

tening Position a, and connect it to the Setup

Mic jack.

The speaker setting menu appears.

3When you’ve finished making the settings, press

Enter.

• If your front speakers are bi-amped, you must

select “Bi-Amp” in the “Speakers Type(Front)”

setting (➔51). For hookup information, see “Bi-

amping the Front Speakers” (➔15).

• If you change “Powered Zone 2” setting, refer to

“Setting the Powered Zone 2” for more details

(➔79).

• If you are using a subwoofer(s), select “Yes ” in the

“Subwoofer” (➔51). If not, select “No” and skip

step 4.

def

cab

: Listening area a to f: Listening position

Speaker setup microphone

Setup Mic jack

MultEQ: Auto Setup

Speakers Type(Front)

Powered Zone 2

Subwoofer

Normal

Not Act

Yes

4If you use a powered subwoofer(s), adjust the sub-

woofer volume level to 75dB.

Test tones are played through the subwoofer. Use the

volume control on the subwoofer.

Note

• If your subwoofer does not have a volume control, disre-

gard the level displayed and press Enter to proceed to the

next step.

• If you set the subwoofer’s volume control to its maximum

and the displayed level is lower than 75 dB, leave the sub-

woofer’s volume control at its maximum and press Enter

to proceed to the next step.

5Press Enter.

Audyssey MultEQ Room Correction and Speaker

Setup starts.

Test tones are played through each speaker as

Audyssey MultEQ Room Correction and Speaker

Setup runs. This process takes a few minutes. Please

refrain from talking during measurements and do

not stand between speakers and the microphone.

Do not disconnect the speaker setup microphone

during Audyssey MultEQ Room Correction and

Speaker Setup, unless you want to cancel the setup.

6Place the setup microphone at the next position,

and then press Enter.

Audyssey MultEQ performs more measurements.

This takes a few minutes.

7When prompted, repeat step 6.

8Use q/w to select an option, and then press Enter.

The options are:

`Save:

Save the calculated settings and exit

Audyssey MultEQ Room Correction and Speaker

Setup.

`Cancel:

Cancel Audyssey MultEQ Room Correction and

Speaker Setup.

Note

• You can view the calculated settings for the speaker con-

figuration, speaker distances, and speaker levels by using

e/r.

9Disconnect the speaker setup microphone.

MultEQ: Auto Setup

Subwoofer Yes

Front 40Hz

Center 40Hz

Surround 100Hz

Front Wide None

Front High 100Hz

Surr Back 120Hz

Surr Back Ch 2ch

Save

Cancel

- - Review Speaker Configuration - -

Note

• When Audyssey MultEQ® Room Correction and Speaker Setup

is complete, the “Equalizer” will be set to “Audyssey” (➔53).

The Audyssey indicator will light (➔9).

• You can cancel Audyssey MultEQ Room Correction and

Speaker Setup at any point in this procedure simply by discon-

necting the setup microphone.

• Do not connect or disconnect any speakers during

Audyssey MultEQ Room Correction and Speaker Setup.

• If the AV receiver is muted, it will be unmuted automatically

when Audyssey MultEQ Room Correction and Speaker Setup

starts.

• Changes to the room after Audyssey MultEQ Room Correction

and Speaker Setup requires you run Audyssey MultEQ Room

Correction and Speaker Setup again, as room EQ characteristics

may have changed.

Error Messages

While Audyssey MultEQ Room Correction and Speaker

Setup is in progress, one of the error messages below may

appear.

The options are:

`Retry:

Try again.

`Cancel:

Cancel Audyssey MultEQ Room Correction and

Speaker Setup.

• Ambient noise is too high.

The background noise is too loud. Remove the source of

the noise and try again.

• Speaker Matching Error!

The number of speakers detected was different from

that of the first measurement. Check the speaker con-

nection.

•Writing Error!

This message appears if saving fails. Try saving again.

If this message appears after 2 or 3 attempts, contact the

dealer from whom you purchased this unit.

•Speaker Detect Error

This message appears if a speaker is not detected. “No”

means that no speaker was detected.

Tip

• See “Speaker Configuration” for appropriate settings (➔13).

Changing the Speaker Settings Manually

You can manually make changes to the settings found dur-

ing Audyssey MultEQ Room Correction and Speaker

Setup.

See also:

• “Speaker Configuration” (➔51)

• “Speaker Distance” (➔52)

• “Level Calibration” (➔52)

• “Equalizer Settings” (➔53)

Note

• Please note that THX recommends any THX main speakers be

set to “80Hz(THX)”. If you set up your speakers using

Audyssey MultEQ Room Correction and Speaker Setup,

please make sure manually that any THX speakers are set to

80 Hz (THX) crossover (➔51).

• Sometimes due to the electrical complexities of subwoofers and

the interaction with the room, THX recommends setting the level

and the distance of the subwoofer manually.

• Sometimes due to interaction with the room, you may notice

irregular results when setting the level and/or distance of the

main speakers. If this happens, THX recommends setting them

manually.

Using a Powered Subwoofer

If you’re using a powered subwoofer and it outputs very

low-frequency sound at a low volume level, it may not be

detected by Audyssey MultEQ Room Correction and

Speaker Setup.

If the “Subwoofer” appears on the “Review Speaker

Configuration” screen as “No”, increase the subwoofer’s

volume to the half-way point, set it to its highest crossover

frequency, and then try running Audyssey MultEQ Room

Correction and Speaker Setup again. Note that if the vol-

ume is set too high and the sound distorts, detection issues

may occur, so use an appropriate volume level. If the sub-

woofer has a low-pass filter switch, set it to Off or Direct.

Refer to your subwoofer’s instruction manual for details.

Ambient noise is too high.

Retry

Cancel

MultEQ: Auto Setup

Error message

Listening to the Radio

With the built-in tuner you can enjoy AM and FM radio

stations. You can store your favorite stations as presets for

quick selection.

This model changes frequency steps (➔62).

Listening to the Radio

Tuning into Radio Stations

■Auto tuning mode

When tuned into a station, the TUNED indicator lights.

When tuned into a stereo FM station, the FM STEREO

indicator lights on the display, as shown.

■Manual tuning mode

In manual tuning mode, FM stations will be in mono.

Tuning into weak FM stereo stations

If the signal from a stereo FM station is weak, it may be

impossible to get good reception. In this case, switch to

manual tuning mode and listen to the station in mono.

■Tuning into stations by frequency

You can tune into AM and FM stations directly by enter-

ing the appropriate frequency.

This section describes the procedure using the but-

tons on the front panel unless otherwise specified.

Using the Tuner

Press Tuner to select either “AM” or “FM”.

In this example, FM has been selected.

Each time you press Tune r, the radio band changes

between AM and FM.

(Actual display depends on the country.)

1Press Tuning Mode so that the AUTO indicator

lights on the display.

2Press Tuning q/w.

Searching stops when a station is found.

Band Frequency

TUNED

TERE

AUTO

1Press Tuning Mode so that the AUTO indicator

goes off on the display.

2Press and hold Tuning q/w.

The frequency stops changing when you release the

button.

Press the buttons repeatedly to change the frequency

one step at a time.

1On the remote controller, press Tuner repeatedly

to select “AM” or “FM”, followed by D.TUN.

(Actual display depends on the country.)

2Within 8 seconds, use the number buttons to enter

the frequency of the radio station.

For example, to tune to 87.5 (FM), press 8, 7, 5.

If you have entered the wrong number, you can retry

after 8 seconds.

You can store a combination of up to 40 of your favorite

FM/AM radio stations as presets.

Note

• You can name your radio presets for easy identification (➔57).

Its name is displayed instead of the band and frequency.

Selecting Presets

Tip

• You can also use the remote controller’s number buttons to select

a preset directly.

Deleting Presets

To listen to Satellite Radio, you’ll need to connect a SIR-

IUS Satellite Radio tuner (sold separately) to your Sirius-

Ready receiver. SIRIUS Satellite Radio is available to res-

idents of the US (except Alaska and Hawaii) and Canada.

Satellite Radio delivers a variety of commercial-free

music from categories ranging from Pop, Rock, Country,

R&B, Dance, Jazz, Classical and many more plus cover-

age of all the top professional and college sports including

play by play games from select leagues and teams. Addi-

tional programming includes expert sports talk, uncen-

sored entertainment, comedy, family programming, local

traffic and weather and news from your most trusted

sources.

Once you’ve purchased a SIRIUS tuner you’ll need to

activate it and subscribe to begin enjoying the service.

Easy to follow installation and setup instructions are pro-

vided with the SIRIUS tuner. There are a variety of pro-

gramming packages available, including the option of

adding “The Best of XM” programming to the SIRIUS

service. The Best of XM service is not available to SIR-

IUS Canada subscribers at this time. Please check with

SIRIUS Canada for any updates using the numbers and

web address below.

Family friendly packages are also available to restrict

channels featuring content that may be inappropriate for

children.

To subscribe to SIRIUS, U.S. and Canadian customers can

call 1-888-539-SIRIUS (1-888-539-7474) or

visit sirius.com (US) or siriuscanada.ca (Canada).

Presetting FM/AM Stations

1Tune into the FM/AM station that you want to

store as a preset.

See the previous section.

2Press Memory.

The preset number flashes.

3While the preset number is flashing (about 8 sec-

onds), use Preset e/r to select a preset from 1

through 40.

4Press Memory again to store the station or chan-

nel.

The station or channel is stored and the preset num-

ber stops flashing.

Repeat this procedure for all of your favorite FM/

AM radio stations.

To select a preset, use Preset e/r on the AV

receiver, or the remote controller’s CH +/–.

1Select the preset that you want to delete.

See the previous section.

2While holding down Memory, press Tuning

Mode.

The preset is deleted and its number disappears from

the display.

Listening to SIRIUS Satellite Radio®

(North American models)

SIRIUS, XM and all related marks

and logos are trademarks of Sirius

XM Radio Inc. and its subsidiaries.

Hawaii.

Setting Up the SiriusConnect™ Home Tuner

The optional SiriusConnect Home tuner kit includes

everything for easy home installation, including the Sirius-

Connect receiver, indoor/outdoor antenna with 21-foot

cable, 8-pin mini DIN connector cable, and an AC power

adapter. See the SiriusConnect Home tuner’s instructions

for more information.

Use the 8-pin mini DIN connector cable to connect the

SiriusConnect receiver to the SIRIUS jack on the rear of

the AV receiver.

To use the included antenna indoors, you must place it at a

north-, west-, or east-facing window, depending on where

you live. If this isn’t possible, you’ll need to install it out-

side, away from any overhead obstructions.

Positioning the Antenna

For a consistent satellite signal, the antenna must be posi-

tioned correctly. Use the following map to determine

which area you are in and position the antenna accord-

ingly.

Area 1: Point the antenna toward the sky in the east,

northeast, or southeast, either through a window or out-

side.

Area 2: Point the antenna toward the sky in the north or

northeast, either through a window or outside.

Area 3: Point the antenna toward the sky in the north or

northwest, either through a window or outside.

Area 4: Point the antenna toward the sky in the west,

northwest, or southwest, either through a window or out-

side.

Area 5: Put the antenna outside and point it straight up.

The antenna cannot be used indoors.

Setting the Satellite Radio Mode

Before you can listen to SIRIUS Satellite Radio, you must

set the “SAT Radio Mode” setting to “SIRIUS”.

SiriusConnect

receiver

8-pin mini DIN

connector cable

AC power

Indoor/outdoor antenna

with 21-foot cable

SIRIUS jack on the rear of

the AV receiver

HORIZON

SKY

SOUTH

WEST EAST

NORTH

1Press Receiver followed by Setup.

The main menu appears onscreen.

2Use q/w to select “Hardware Setup”, and then

press Enter.

The “Hardware Setup” menu appears.

3Use q/w to select “Tuner”, and then press Enter.

Number buttons

Display

Tuner

Receiver

CH +/–

q/w/e/r

Return

D.TUN

Enter

Setup

7. Hardware Setup

1. Remote ID

2. Multi Zone

3. Tuner

4. HDMI

5. Auto Power Down

6. Network

7. Firmware Update

Tip

• Alternatively, you can use the AV receiver’s Setup, arrow but-

tons, and Enter.

Selecting SIRIUS Satellite Radio

Tip

• Alternatively, you can use the AV receiver’s Tune r.

Signing Up for SIRIUS Satellite Radio

Before you can use SIRIUS Satellite Radio, you must first

your SIRIUS Satellite Radio ID, which you can get from

the AV receiver, as explained below, or from the Sirius-

Connect Home tuner package.

Note

• Your ID is also displayed on the Satellite Radio screen. See

“Positioning the SiriusConnect Home Antenna” (➔37).

Selecting Channels using the Remote

Controller

There are three ways to select SIRIUS Satellite Radio

channels:

1. Channel Search mode: select any channel.

2. Category Search mode: select channels by category.

3. Direct tuning: enter channel number.

■Channel Search mode

■Category Search mode

■Direct tuning

You can select a SIRIUS Satellite Radio channel directly

by entering its number.

Note

• If you select an unavailable channel, “INVALID CHANNEL”

appears on the display.

• If you select a channel that you are not subscribed to, “CALL

SIRIUS” appears on the display.

• Channels that are locked must be unlocked before you can listen

to them. See “SIRIUS Parental Lock” (➔35) for more informa-

tion.

4Use q/w to select “SAT Radio Mode”, and e/r to

select “SIRIUS”.

Pressing e/r cycles through the following options:

`None:

Select if you’re not using Satellite Radio.

`SIRIUS:

Select to use SIRIUS Satellite Radio.

5When you’ve finished, press Setup.

Setup closes.

Press Tune r repeatedly to select “SIRIUS”.

If “CHECK SIRIUS TUNER” appears on the dis-

play, make sure the SiriusConnect receiver is con-

nected properly. If “ANTENNA ERROR” appears,

make sure the antenna is connected properly.

1Use Tuning q/w on the AV receiver to select

channel 0.

Your SIRIUS Satellite Radio ID number is dis-

played. Write it below.

2To sign up, go to: http://activate.siriusradio.com

or call: 1-888-539-SIRIUS (7474)

7–3. Tuner

FM/AM Frequency Step

SAT Radio Mode

Antenna Aiming

SIRIUS Parental Lock

200kHz/10kHz

SIRIUS

1Press Enter repeatedly to select Channel Search

mode.

2Use q/w to select a channel.

You can also use e/r to select a category.

1Press Tuner, and then press Enter repeatedly to

select Category Search mode.

2Use e/r to select a category, and q/w to select a

channel in that category.

1Press D.TUN.

2Within 8 seconds, use the number buttons to enter

the channel number.

For example, to select channel #20, press 0, 2, 0, or

2, 0, Enter.

Channel name

Channel number

■Selecting the previously selected channel

Selecting Channels on the AV Receiver

Presetting Channels

You can store a combination of up to 40 of your favorite

SIRIUS Satellite Radio channels and FM/AM radio sta-

tions as presets.

■Selecting presets

Tip

• You can also use the number buttons to select a preset directly.

■Deleting presets

SIRIUS Parental Lock

With SIRIUS Parental Lock, you can lock out channels

that you do not want to receive and use a 4-digit PIN num-

ber to prevent others from unlocking them.

Press Return to select the previously selected

channel.

1Press Tuner repeatedly to select “SIRIUS”.

2Press Tuning Mode repeatedly to select Channel

Search mode or Category Search mode.

3Press Enter repeatedly to select a category.

4Use Tuning q/w to select a channel.

In Channel Search mode, you can select any channel.

In Category Search mode, you can only select chan-

nels from the currently selected category.

1Tune into the SIRIUS channel that you want to

store as a preset.

2Press Memory on the AV receiver.

The preset number flashes.

3While the preset number is flashing (about 8 sec-

onds), use Preset e/r on the AV receiver to

select a preset from 1 through 40.

4Press Memory on the AV receiver again to store

the channel.

The channel is stored and the preset number stops

flashing.

Repeat this procedure for all of your favorite SIRIUS

Satellite Radio channels.

To select a preset, use Preset e/r on the AV

receiver or the remote controller’s CH +/–.

1Select the preset that you want to delete.

See the previous section.

2While holding down Memory press Tuning

Mode on the AV receiver.

The preset is deleted and its number disappears from

the display.

1Press Receiver followed by Setup.

The main menu appears onscreen.

2Use q/w to select “Hardware Setup”, and then

press Enter.

The “Hardware Setup” menu appears.

3Use q/w to select “Tuner”, and then press Enter.

4Use q/w to select “SIRIUS Parental Lock”, and

then press Enter.

The following screen appears.

Note

•If the “SAT Radio Mode” is set to “None” (➔33), the

“SIRIUS Parental Lock” setting is not available.

5Use e/r to select a number on the screen, and

then press Enter.

Repeat this for each of the four digits in the PIN

number.

If you’re entering the PIN number for the very first

time, the default is “0000”. The following screen

appears.

If you’ve already set a PIN number, you must enter

the correct PIN to get to this screen. If you enter the

wrong PIN, the message “Wrong Code!” appears

and you’ll have to enter the PIN again.

Note

•The “SIRIUS Parental Lock” setting cannot be set unless

the AV receiver and the SiriusConnect receiver are con-

nected.

7. Hardware Setup

1. Remote ID

2. Multi Zone

3. Tuner

4. HDMI

5. Auto Power Down

6. Network

7. Firmware Update

SIRIUS Parental Lock

Enter Code

01 2 3 4 5 6 7 8 9

SIRIUS Parental Lock

Edit Code

Parental Lock

Note

• You can temporarily release the parental lock by selecting the

locked channel directly by entering the number (Direct tuning)

or selecting the preset.

• To unlock a channel, you must enter the correct PIN number and

change it to Unlocked in step 6.

Tip

• Alternatively, you can use the AV receiver’s Setup, arrow but-

tons, and Enter.

Changing the PIN Number

6Use q/w to select “Parental Lock”, and then press

Enter.

The channel number, channel name, and the current

status are displayed.

7Use q/w to select a channel, and e/r to select

“Locked” or “Unlocked”.

8Press Enter to save your changes, or press Return

to return to the previous screen without saving.

When Enter is pressed, the confirmation message

“Locked” or “Unlocked” appears.

9Press Setup.

Setup closes.

1Press Receiver followed by Setup.

The main menu appears onscreen.

2Use q/w to select “Hardware Setup”, and then

press Enter.

The “Hardware Setup” menu appears.

3Use q/w to select “Tuner”, and then press Enter.

4Use q/w to select “SIRIUS Parental Lock”, and

then press Enter.

The following screen appears.

Note

•If the “SAT Radio Mode” is set to “None” (➔33), the

“SIRIUS Parental Lock” setting is not available.

7. Hardware Setup

1. Remote ID

2. Multi Zone

3. Tuner

4. HDMI

5. Auto Power Down

6. Network

7. Firmware Update

SIRIUS Parental Lock

Enter Code

01 2 3 4 5 6 7 8 9

5Use e/r to select a number on the screen, and

then press Enter.

Repeat this for each of the four digits in the PIN

number.

If you’re entering the PIN number for the very first

time, the default is “0000”. The following screen

appears.

If you’ve already set a PIN number, you must enter

the correct PIN to get to this screen. If you enter the

wrong PIN, the message “Wrong Code!” appears

and you’ll have to enter the PIN again.

Note

•The “SIRIUS Parental Lock” setting cannot be set unless

the AV receiver and the SiriusConnect receiver are con-

nected.

6Use q/w to select “Edit Code”, and then press

Enter.

The following screen appears.

7Use e/r to select a number on the screen, and

then press Enter.

Repeat this for each of the four digits in the new

PIN number.

The following screen appears.

8Confirm the new PIN number by entering it again.

If you confirm the PIN number correctly, the new

PIN is saved and the message “Complete” appears.

If you confirm the PIN number incorrectly, “Wrong

Code!” appears, and you’ll be returned to step 5 to

try again.

9Press Setup.

Setup closes.

SIRIUS Parental Lock

Edit Code

Parental Lock

SIRIUS Parental Lock

New Code

01 2 3 4 5 6 7 8 9

SIRIUS Parental Lock

Confirm

01 2 3 4 5 6 7 8 9

Displaying SIRIUS Satellite Radio

Information

The following information can be displayed:

Note

• If the category, artist/composer, or song title is not available,

“---” will be displayed instead.

Positioning the SiriusConnect Home

Antenna

You can check the strength of the SIRIUS Satellite Radio

signal and adjust the position of the SiriusConnect Home

antenna accordingly.

Note

• So long as the signal strength is good, you can enjoy SIRIUS

Satellite Radio by using either satellite or terrestrial reception.

• Terrestrial signals are only available in certain areas.

• The SIRIUS information on the Satellite Radio screen is only

displayed when the “SAT Radio Mode” setting is set to “SIR-

IUS” (➔33).

SIRIUS Satellite Radio Messages

The following messages may appear while using SIRIUS

Satellite Radio.

■ACQUIRING SIGNAL

The SiriusConnect receiver is acquiring the signal or no

signal is present. Make sure the SiriusConnect Home

tuner is connected properly and that there are no obsta-

cles nearby.

■ANTENNA ERROR

Make sure the SiriusConnect Home tuner is connected

properly.

■SUBSCRIPTION UPDATED

Displayed while your subscription is being updated. No

operations can be performed until this message has

cleared.

■UPDATING CHANNELS XXX%

Displayed while the channel map is being updated. Wait

until the updating is complete.

■SIRIUS UPDATING

Displayed while the SiriusConnect receiver’s firmware

is being updated.

■INVALID CHANNEL

Displayed if you select an unavailable channel.

■CALL SIRIUS

Displayed when you select a channel to which you are

not subscribed. Call SIRIUS if you want to subscribe.

■CHECK SIRIUS TUNER

Displayed if the SiriusConnect receiver is not con-

nected. Make sure the SiriusConnect receiver is con-

nected properly, and make sure its AC adapter is

plugged in.

Press Display repeatedly to cycle through the

available information.

1Press Receiver followed by Tuner, and Setup.

The main menu appears onscreen.

2Use q/w to select “Hardware Setup”, and then

press Enter.

The “Hardware Setup” menu appears.

Note

• If the “SAT Radio Mode” setting is set to “None”

(➔33), the “Antenna Aiming” setting is not available.

3Use q/w to select “Tuner”, and then press Enter.

4Use q/w to select “Antenna Aiming”, and then

press Enter.

The signal strength meter and your SIRIUS Satellite

Radio ID are displayed.

Category

Artist/composer

Song title

Listening mode

anne

name an

anne

num

7. Hardware Setup

1. Remote ID

2. Multi Zone

3. Tuner

4. HDMI

5. Auto Power Down

6. Network

7. Firmware Update

5Position the SiriusConnect Home antenna so that

as many bars as possible (up to 3) appear on the

Satellite signal strength meter.

If you cannot receive a satellite signal, position the

SiriusConnect Home antenna so that as many bars as

possible (up to 3) appear on the Terrestrial signal

strength meter.

SIRIUS ID

112233445566

Satellite Terrestrial

SIRIUS

Antenna Aiming

When tuned into an RDS station, the RDS indicator lights.

What is RDS?

RDS stands for Radio Data System and is a method of

transmitting data in FM radio signals. It was developed by

the European Broadcasting Union (EBU) and is available

in most European countries. Many FM stations use it these

days. In addition to displaying text information, RDS can

also help you find radio stations by type (e.g., news, sport,

rock, etc.).

The AV receiver supports four types of RDS information:

■PS (Program Service)

When tuned to an RDS station that’s broadcasting PS

information, the station’s name will be displayed. Press-

ing Display will display the frequency for 3 seconds.

■RT (Radio Text)

When tuned to an RDS station that’s broadcasting text

information, the text will be shown on the display as

described in the next section.

■PTY (Program Type)

This allows you to search for RDS radio stations by type

(➔38).

■TP (Traffic Program)

This allows you to search for RDS radio stations that

broadcast traffic information (➔38).

Note

• In some cases, the text characters displayed on the AV receiver

may not be identical to those broadcast by the radio station. Also,

unexpected characters may be displayed when unsupported

characters are received. This is not a malfunction.

• If the signal from an RDS station is weak, RDS data may be

displayed intermittently or not at all.

When tuned to an RDS station that’s broadcasting text

information, the text can be displayed.

Displaying Radio Text (RT)

Note

•The message “Waiting” may appear while the AV receiver waits

for the RT information.

• If the message “No Text Data” appears on the display, no RT

information is available.

Finding Stations by Type (PTY)

You can search for radio stations by type.

Listening to Traffic News (TP)

You can search for stations that broadcast traffic news.

Using RDS (Australian models)

RDS works only in areas where RDS broadcasts are

available.

Press RT/PTY/TP once.

The RT information scrolls across the display.

1Press RT/PTY/TP twice.

The current program type appears on the display.

2Use Preset e/r to select the type of program you

want.

See the table shown later in this chapter.

3To start the search, press Enter.

The AV receiver searches until it finds a station of

the type you specified, at which point it stops briefly

before continuing with the search.

4When a station you want to listen to is found, press

Enter.

If no stations are found, the message “Not Found”

appears.

1Press RT/PTY/TP three times.

If the current radio station is broadcasting TP (Traf-

fic Program), “[TP]” will appear on the display, and

traffic news will be heard as and when it’s broadcast.

If “TP” without square brackets appears, this means

that the station is not broadcasting TP.

2To locate a station that is broadcasting TP, press

Enter.

The AV receiver searches until it finds a station that’s

broadcasting TP.

If no stations are found, the message “Not Found”

appears.

■RDS program types (PTY)

Type Display

None None

News reports News

Current affairs Affairs

Information Info

Sport Sport

Education Educate

Drama Drama

Culture Culture

Science and technology Science

Varied Varied

Pop music Pop M

Rock music Rock M

Middle of the road music Easy M

Light classics Light M

Serious classics Classics

Other music Other M

Weather Weather

Finance Finance

Children’s programmes Children

Social affairs Social

Religion Religion

Phone in Phone In

Travel Travel

Leisure Leisure

Jazz music Jazz

Country music Country

National music Nation M

Oldies music Oldies

Folk music Folk M

Documentary Document

Alarm test TEST

Alarm Alarm!

Recording

This section explains how to record the selected input source to a component with recording capability, and how to record

audio and video from different sources.

Connecting a Recording Component

Note

• The AV receiver must be turned on for recording. Recording is

not possible while it’s in Standby mode.

• If you want to record directly from your TV or playback VCR to

the recording VCR without going through the AV receiver, con-

nect the TV/VCR’s audio and video outputs directly to the

recording VCR’s audio and video inputs. See the manuals sup-

plied with your TV and VCR for details.

• Video signals connected to composite video inputs can be

recorded only via composite video outputs. If your TV/VCR is

connected to a composite video input, the recording VCR must

be connected to a composite video output.

• The surround sound and DSP listening modes cannot be

recorded.

• Copy-protected Blu-ray Disc/DVDs cannot be recorded.

• Sources connected to a digital input cannot be recorded. Only

analog inputs can be recorded.

• DTS signals will be recorded as noise, so don’t attempt analog

recording of DTS CDs or LDs.

AV Recording

Audio sources can be recorded to a recorder (e.g., cassette

deck, CDR, MD) connected to the VCR/DVR OUT jacks.

Video sources can be recorded to a video recorder (e.g.,

VCR, DVD recorder) connected to the VCR/DVR OUT

jack.

Recording Separate AV Sources

Here you can record audio and video from completely

separate sources, allowing you to overdub audio onto your

video recordings. This function takes advantage of the fact

that when an audio-only input source (TV/CD, Phono,

etc.) is selected, the video input source remains

unchanged.

In the following example, audio from the CD player con-

nected to the TV/CD IN and video from the camcorder

connected to the AUX Input Video jack are recorded by

the VCR connected to the VCR/DVR OUT jacks.

1Use the input selector buttons to select the source

that you want to record.

You can watch the source while recording. The AV

receiver’s Master Volume control has no effect on

recording.

2On your recorder, start recording.

3On the source component, start playback.

If you select another input source during recording,

that input source will be recorded.

AUDIO

L R

VIDEO

Cassette, CDR, MD,

etc.

VCR, DVD recorder

1Prepare the camcorder and CD player for play-

back.

2Prepare the VCR for recording.

3Press AUX input selector.

4Press TV/CD input selector.

This selects the CD player as the audio source, but

leaves the camcorder as the video source.

5Start recording on the VCR and start playback on

the camcorder and CD player.

The video from the camcorder and the audio from

the CD player are recorded by the VCR.

Camcorder

VCRCD player

: Video signal

: Audio signal

Using the Listening Modes

See “About Listening Modes” for detailed information about the listening modes (➔42).

Listening Mode Buttons

Movie/TV button

This button selects the listening modes intended for use

with movies and TV.

Music button

This button selects the listening modes intended for use

with music.

Game button

This button selects the listening modes intended for use

with video games.

THX button

This button selects the THX listening modes.

Selecting Listening Modes

Press Receiver first.

Game

THX

Music

Movie/TV

Movie/TV, Music, Game

• The Dolby Digital and DTS listening modes can only be selected if your Blu-ray Disc/DVD player is connected to the AV

receiver with a digital audio connection (coaxial, optical, or HDMI).

• The listening modes you can select depend on the format of the input signal. To check the format, see “Displaying Source

Information” (➔25).

• While a pair of headphones is connected, you can select the following listening modes: Mono, Direct, and Stereo.

• The listening modes cannot be used while you are listening to sound through your TV speakers coming from components

connected to the AV receiver (“TV Sp On” appears on the front panel).

The AV receiver’s listening modes can transform your listening room into a movie theater or concert hall, with high fidel-

ity and stunning surround sound.

Explanatory Notes

■Input Source

The following audio formats are supported by the listening mode.

■Speaker Layout

The illustration shows which speakers are activated in each channel. See “Speaker Configuration” for the speaker setup

(➔51).

About Listening Modes

AThis is mono (monophonic) sound.

SThis is stereo (stereophonic) sound. Two independent audio signal channels are reproduced through two

speakers.

DThis is 5.1-channel surround sound. This surround system has five main channels of sound and a sixth sub-

woofer channel (called the point-one channel).

FThis is 7.1-channel surround sound. This is a further sound enhancement to 5.1 channel sound with two

additional speakers that provide greater sound envelopment and more accurate positioning of sounds.

GThis is DTS-ES surround sound. This surround system can produce a discrete or a matrix-encoded sixth

channel from existing DTS 5.1 encoded material.

HThis is Dolby Digital EX surround sound. This provides a center back surround channel from 5.1-channel

sources.

ZXC

Press Receiver followed by SP Layout repeatedly to select the speakers you want to use; front high, front wide, or surround

back.

abFront speakers

cCenter speaker

deSurround speakers

fSubwoofer(s)

ghSurround back speakers

ijFront high speakers

klFront wide speakers

SP Layout

Listening

Mode

Listening Modes

Listening Mode Description Input

Source

Speaker

Layout

Direct In this mode, audio from the input source is output without surround-sound

processing. The “Speaker Configuration” (presence of speakers),

“Sp Distance” and “A/V Sync” settings are enabled, but much of the process-

ing set via Home is disabled. See “Advanced Setup” for more details

(➔47).

ZXC

N*1

Stereo Sound is output by the front left and right speakers and subwoofer. A

ZXC

Mono Use this mode when watching an old movie with a mono soundtrack, or use

it with the foreign language soundtracks recorded in the left and right chan-

nels of some movies. It can also be used with DVDs or other sources contain-

ing multiplexed audio, such as karaoke DVDs.

Multichannel This mode is for use with PCM multichannel sources. D

XCN

Dolby Pro Logic IIx*2

Dolby Pro Logic II

Dolby Pro Logic IIx expands any 2-channel source for 7.1-channel play-

back. It provides a very natural and seamless surround-sound experience that

fully envelops the listener. As well as music and movies, video games can

also benefit from the dramatic spatial effects and vivid imaging. If you’re not

using any surround back speakers, Dolby Pro Logic II will be used instead

of Dolby Pro Logic IIx.

• Dolby PLIIx Movie

Use this mode with any stereo or Dolby Surround (Pro Logic) movie (e.g.,

TV, DVD, VHS).

• Dolby PLIIx Music

Use this mode with any stereo or Dolby Surround (Pro Logic) music source

(e.g., CD, radio, cassette, TV, VHS, DVD).

• Dolby PLIIx Game

Use this mode with video games, especially those that bear the Dolby Pro

Logic II logo.

SXCN

•Dolby PLIIx Movie and Dolby PLIIx Music

These modes use the Dolby Pro Logic IIx modes to expand 5.1-channel

sources for 7.1-channel playback.

Dolby Pro Logic IIz

Height

Dolby Pro Logic IIz Height is designed to more effectively use existing

program material when height channel speaker outputs are present. Dolby

Pro Logic IIz Height can be used to upmix a variety of sources from movies

and music, but are particularly well-suited to upmix game content.

N*3

Dolby EX These modes expand 5.1-channel sources for 6.1/7.1-channel playback.

They’re especially suited to Dolby EX soundtracks that include a matrix-

encoded surround back channel. The additional channel adds an extra dimen-

sion and provides an enveloping surround sound experience, perfect for

rotating and fly-by sound effects.

N*4

Dolby Digital In this mode, audio from the input source is output without surround-sound

processing. “Speaker Configuration” (presence of speakers), “Crossover”,

“Sp Distance”, “A/V Sync” and much of the processing set via Home are

enabled. See “Advanced Setup” for more details (➔47).

DXCN

Dolby Digital Plus*5 DXCN

FXCN

Dolby TrueHD DXCN

FXCN

DTS DXCN

Di rectdioPPoPP

StereodioPPoPP

Monoeod i oPPoPP

MultichioPPoPP

PL bMo v i ePP PP

PL bMu s i c PP PP

PL bGame cPPcPP

PL xGMo v i ePP

PL xGMu s i c PP

PL xGGame cP cP

PL zGHe i gh t

DolbycEXoPPoPP

DolbycDiEXPP

DolbycDioPPoPP

DolbycDoPPoPP

DD lTeHDPPPPPPru

DTS d

di o P P o P P

DTS-HD High

Resolution Audio

(Continued from the previous page.) D XCN

F XCN*1

DTS-HD Master

Audio

D XCN

F XCN*1

DTS Express S

XCN

DSD*6 D XCN

DTS 96/24*7 This mode is for use with DTS 96/24 sources. This is high-resolution DTS

with a 96 kHz sampling rate and 24-bit resolution, providing superior fidel-

ity. Use it with DVDs that bear the DTS 96/24 logo.

D XCN

DTS-ES Discrete*8 This mode is for use with DTS-ES Discrete soundtracks, which use a dis-

crete surround back channel for true 6.1/7.1-channel playback. The seven

totally separate audio channels provide better spatial imaging and 360-

degree sound localization, perfect for sounds that pan across the surround

channels. Use it with DVDs that bear the DTS-ES logo, especially those with

a DTS-ES Discrete soundtrack.

DTS-ES Matrix*8 This mode is for use with DTS-ES Matrix soundtracks, which use a matrix-

encoded back-channel for 6.1/7.1-channel playback. Use it with DVDs that

bear the DTS-ES logo, especially those with a DTS-ES Matrix soundtrack.

DTS Neo:6 This mode expands any 2-channel source for up to 7.1-channel playback. It

uses seven full-bandwidth channels of matrix decoding for matrix-encoded

material, providing a very natural and seamless surround sound experience

that fully envelops the listener.

•Neo:6 Cinema

Use this mode with any stereo movie (e.g., TV, DVD, VHS).

•Neo:6 Music

Use this mode with any stereo music source (e.g., CD, radio, cassette, TV,

VHS, DVD).

S XCN

This mode uses Neo:6 to expand 5.1-channel sources for 6.1/7.1-channel

playback.

Audyssey DSX*9 Audyssey DSX™ is a scalable system that adds new speakers to improve sur-

round impression. Starting with a 5.1 system Audyssey DSX first adds Wide

channels for the biggest impact on envelopment. Research in human hearing

has proven that information from the Wide channels is much more critical in

the presentation of a realistic soundstage than then Back Surround channels

found in traditional 7.1 systems. Audyssey DSX then creates a pair of Height

channels to reproduce the next most important acoustical and perceptual

cues. In addition to these new Wide and Height channels, Audyssey DSX

applies Surround Envelopment Processing to enhance the blend between the

front and surround channels.

The combination of Dolby Pro Logic II and Audyssey DSX modes can be

used.

The combination of Neo:6 Cinema/Music and Audyssey DSX modes can

be used.

Listening Mode Description Input

Source

Speaker

Layout

DTS–HD HR

DTS–HD MSTR

DTS Ex p r e s s

DSD

DTSe

96 / 24PP PP

ESSDiscrete

ESSMa t r i x te te

Neo:6trixtexte

Neo:6trixtexteNeo:6 Cinema

Neo:6tMu s i c

Audy ssey DSX

PL bMo v ieDSX

PL bMu s icDSX

PL bGameDSX

Neo:6trixtexteNeo:6CCinDSX

Neo:6tMusDSX

THX Founded by George Lucas, THX develops stringent standards that ensure

movies are reproduced in movie theaters and home theaters just as the direc-

tor intended. THX Modes carefully optimize the tonal and spatial character-

istics of the soundtrack for reproduction in the home-theater environment.

They can be used with 2-channel matrixed and multichannel sources. Sur-

round back speaker output depends on the source material and the selected

listening mode.

•THX Cinema

THX Cinema mode corrects theatrical soundtracks for playback in a home

theater environment. In this mode, THX Loudness Plus is configured for

cinema levels and Re-EQ, Timbre Matching, and Adaptive Decorrelation

are active.

•THX Music

THX Music mode is tailored for listening to music, which is typically mas-

tered at significantly higher levels than movies. In this mode, THX Loud-

ness Plus is configured for music playback and only Timbre Matching is

active.

•THX Games

THX Games mode is meant for spatially accurate playback of game audio,

which is often mixed similarly to movies but in a smaller environment. THX

Loudness Plus is configured for game audio levels, with Timbre Matching

active.

The combination of Dolby Pro Logic II/IIx*2 and THX Cinema/Music/

Games modes can be used.

The combination of Dolby Pro Logic IIz Height*3 and THX Cinema/

Music/Games modes can be used.

The combination of DTS Neo:6 and THX Cinema/Music/Games modes

can be used.

• THX Select2 Cinema

This mode expands 5.1-channel sources for 7.1- channel playback. It does

this by analyzing the composition of the surround source, optimizing the

ambient and directional sounds to produce the surround back channel out-

put.

•THX Select2 Music

This mode is designed for use with music. It expands 5.1-channel sources

for 7.1-channel playback.

•THX Select2 Games

This mode is designed for use with video games. It can expand 5.1-channel

sources for 6.1/7.1-channel playback.

• THX Surround EX

This mode expands 5.1-channel sources for 6.1/7.1- channel playback. It’s

especially suited to Dolby Digital EX sources. THX Surround EX, also

known as Dolby Digital Surround EX, is a joint development between

Dolby Laboratories and THX Ltd.

Listening Mode Description Input

Source

Speaker

Layout

THXeCinemaPP

Neo:6trixtexteTHXeMu s i c aP aP

THXeGame s aP aP

Neo:6trixtexteTHXeS2mCiCnema

THXeS2mMu s ic

THXeS2mGames

THXeSu rraEXa

Onkyo-Original DSP Listening Modes

Note

*1 Based on the audio channels contained in the source, the corresponding speakers will output the sound.

*2 If Powered Zone 2 is being used, Dolby Pro Logic II is used.

*3 Surround back and front wide speakers are not supported.

*4 Front high and front wide speakers are not supported.

*5 For the Blu-ray Discs, Dolby Digital is used in a 3.1/5.1-channel speaker system.

*6 AV receiver can input the DSD signal from HDMI IN. Setting the output setting on the player side to PCM might obtain a better

sound according to the player. In that case, set the output setting on the player side to PCM.

*7 DTS is used depending on the configuration of the AV receiver (e.g., Audyssey Dynamic EQ® is on or Powered Zone 2 is being

used).

*8 If there are no surround back speakers or Powered Zone 2 is being used, DTS is used.

*9 • This listening mode can be selected only when all the following conditions are satisfied:

a. Center speaker is connected.

b. Either of front high or front wide speakers is connected.

• Output can be switched between front high or front wide speakers by pressing SP Layout [depending on the “Speaker Configu-

ration” setting (➔51)].

*10 Output can be switched between front high, front wide or surround back speakers by pressing SP Layout [depending on the

“Speaker Configuration” setting (➔51)].

• The listening modes cannot be selected with some source formats.

Listening Mode Description Input

Source

Speaker

Layout

Orchestra Suitable for classical or operatic music, this mode emphasizes the surround

channels in order to widen the stereo image, and simulates the natural rever-

beration of a large hall.

CN*10

Unplugged Suitable for acoustic instruments, vocals, and jazz, this mode emphasizes the

front stereo image, giving the impression of being right in front of the stage.

Studio-Mix Suitable for rock or pop music, listening to music in this mode creates a

lively sound field with a powerful acoustic image, like being at a club or rock

concert.

TV Logic This mode adds realistic acoustics to TV shows produced in a TV studio,

surround effects to the entire sound, and clarity to voices.

Game-RPG Use this mode when playing role playing game discs.

Game-Action Use this mode when playing action game discs.

Game-Rock Use this mode when playing rock game discs.

Game-Sports Use this mode when playing sports game discs.

All Ch Stereo Ideal for background music, this mode fills the entire listening area with ste-

reo sound from the front, surround, and surround back speakers.

XCN*10

Full Mono In this mode, all speakers output the same sound in mono, so the sound you

hear is the same regardless of where you are within the listening room.

T-D (Theater-

Dimensional)

With this mode you can enjoy a virtual surround sound even with only two or

three speakers. This works by controlling how sounds reach the listener’s left

and right ears. Good results may not be possible if there’s too much reverb,

so we recommend that you use this mode in an environment with little or no

natural reverb.

ZXC

Or ches t ra

Unp l ugged

Studio–Mix

TV Log i c

Game –RPG

Game – Ac t i o n

Game –Ro c k

Game – Sp o r t s

Al l Ch Stereo

Fu l l Mono

T–D

Advanced Operations

Advanced Setup

The on-screen setup menus appear on the connected TV

and provide a convenient way to change the AV receiver’s

various settings. Settings are organized into 9 categories

on the main menu.

Carry out the settings by using the on-screen display.

Note

• This procedure can also be performed on the AV receiver by

using Setup, arrow buttons, and Enter.

• During Audyssey MultEQ® Room Correction and Speaker

Setup, messages, etc., that are displayed on the TV screen will

appear in the Display.

On-screen Setup Menus

This manual describes the procedure using the

remote controller unless otherwise specified.

aInput/Output Assign

(➔48)

fMiscellaneous

(➔61)

bSpeaker Setup

(➔51)

gHardware Setup

(➔61)

cAudio Adjust

(➔54)

hRemote Controller

Setup (➔89, 94)

dSource Setup (➔56)iLock Setup (➔64)

eListening Mode Preset

(➔60)

1. Input/Output Assign

2. Speaker Setup

3. Audio Adjust

4. Source Setup

5. Listening Mode Preset

6. Miscellaneous

7. Hardware Setup

8. Remote Controller Setup

9. Lock Setup

1. Monitor Out

2. HDMI Input

3. Component Video Input

4. Digital Audio Input

5. Analog Audio Input

1. Input/Output Assign

1. Volume Setup

2. OSD Setup

3. 12V Trigger A Setup

4. 12V Trigger B Setup

5. 12V Trigger C Setup

6. Miscellaneous

1. Speaker Settings

2. Speaker Configuration

3. Speaker Distance

4. Level Calibration

5. Equalizer Settings

6. THX Audio Setup

2. Speaker Setup

1. Remote ID

2. Multi Zone

3. Tuner

4. HDMI

5. Auto Power Down

6. Network

7. Firmware Update

7. Hardware Setup

1. Multiplex/Mono

2. Dolby

3. DTS

4. Audyssey DSX

5. Theater-Dimensional

6. LFE Level

3. Audio Adjust

1. Remote Mode Setup

2. Activities Setup

8. Remote Controller Setup

1. Audyssey

2. IntelliVolume

3. A/V Sync

4. Name Edit

5. Picture Adjust

4. Source Setup

Setup

9. Lock Setup

1. BD/DVD

2. VCR/DVR

3. CBL/SAT

4. GAME

5. PC

6. AUX

5. Listening Mode Preset

Common Procedures in Setup Menu

1Press Receiver followed by Setup.

The following menu appears.

Tip

• If the main menu doesn’t appear, make sure the appropri-

ate external input is selected on your TV.

2Use q/w to select a menu, and then press Enter.

3Use q/w to select target and then press Enter.

4Use q/w to select option and use e/r to change

the setting.

Press Setup to close the menu.

Press Return to return to the previous menu.

Return

Enter

q/w/e/r

Setup

Receiver

1. Input/Output Assign

2. Speaker Setup

3. Audio Adjust

4. Source Setup

5. Listening Mode Preset

6. Miscellaneous

7. Hardware Setup

8. Remote Controller Setup

9. Lock Setup

Explanatory Notes

Main Menu Input/Output Assign

Monitor Out

On the “Monitor Out” settings, you can select whether or

not to have the video sources’ images output through the

HDMI output, as well as whether to have the onscreen

setup menu output through the HDMI output or through

an analog output.

If you connect your TV to HDMI output, “Monitor Out”

setting is automatically set so that the onscreen setup

menus are displayed and composite video, S-Video, and

component video sources are upconverted* and output.

If you connect your TV to the COMPONENT VIDEO

MONITOR OUT (not the HDMI output), “Monitor Out”

setting is automatically set so that the onscreen setup

menus are displayed and composite video and S-Video

sources are upconverted* and output.

Note

• See “Video Connection Formats” (➔22) for charts showing

how the “Monitor Out” (➔48) and “Resolution” settings

(➔49) affect the video signal flow through the AV receiver.

■Monitor Out

`Analog:

Select this if your TV is connected to the COMPO-

NENT VIDEO MONITOR OUT, MONITOR OUT

S, or MONITOR OUT V.

`HDMI Main:

Select this if your TV is connected to the HDMI

OUT MAIN.

`HDMI Sub:

Select this if your TV is connected to the HDMI

OUT SUB.

`Both:

Select this if your TVs are connected to the HDMI

OUT MAIN and HDMI OUT SUB. Video signals

are output from both HDMI outputs at the resolution

supported by both TVs.

`Both(Main):

Select this if your TVs are connected to the HDMI

OUT MAIN and HDMI OUT SUB. Video signals

are output from both HDMI outputs but HDMI OUT

MAIN will become a priority; depending on the reso-

lution, video signals may not be output from HDMI

OUT SUB.

`Both(Sub):

Select this if your TVs are connected to the HDMI

OUT MAIN and HDMI OUT SUB. Video signals

are output from both HDMI outputs but HDMI OUT

SUB will become a priority; depending on the reso-

lution, video signals may not be output from HDMI

OUT MAIN.

Note

• If not connected to the same output you have selected in the

“Monitor Out” setting, the “Monitor Out” setting will be auto-

matically switched to “Analog” (➔23).

• When you select other than “Analog”, the onscreen setup menus

are output by only the HDMI output. If you’re not using the

HDMI output and select settings by mistake and the menus

disappear, press AV receiver’s Monitor Out to select “Ana-

log”.

• For Deep Color output, if the “Monitor Out” setting is set to

“Both(Main)” or “Both(Sub)”, the number of bit may be lim-

ited due to the capability of your TV connected to a priority out-

put.

Changing “Monitor Out” setting manually

Input/Output Assign

a Menu selection

b Setting target

c Setting options (default setting underlined)

Main Menu Speaker Setup

■Subwoofer

`Yes :

Select if a subwoofer is connected.

`No:

Select if no subwoofer is connected.

OUT

Composite video, S-Video,

component video

Composite video, S-Video,

component video

HDMI

OUT

Composite video, S-Video

Component video

1Press Monitor Out on the front panel.

The current setting is displayed.

2Press Monitor Out on the AV receiver

repeatedly to select:

`Analog, HDMI Main, HDMI Sub, Both,

Both(Main) or Both(Sub)

For details on each item, in the “Monitor Out”

settings (➔48).

■Resolution

You can specify the output resolution for the HDMI output

and COMPONENT VIDEO MONITOR OUT and have

the AV receiver upconvert the picture resolution as neces-

sary to match the resolution supported by your TV.

`Through*1:

Select this to pass video through the AV receiver at

the same resolution and with no conversion.

`Auto*2:

Select this to have the AV receiver automatically

convert video at resolutions not supported by your

TV.

`480p (480p/576p):

Select this for 480p or 576p output and video con-

version as necessary.

`720p:

Select this for 720p output and video conversion as

necessary.

`1080i:

Select this for 1080i output and video conversion as

necessary.

`1080p*2:

Select this for 1080p output and video conversion as

necessary.

`Source:

Output will be according to the resolution level

which was set in the “Picture Adjust” setting

(➔58).

Tip

•The “Resolution” setting can be set for each “Monitor Out”

setting.

Note

•If the “Monitor Out” setting is set to “Both”, this setting is fixed

at “Auto”.

*1 PC IN (Analog RGB) input signal is output at 720p resolution

when the “Monitor Out” setting is set to “Analog” and the

“Resolution” setting is set to “Through” (➔49).

*2 These settings are not available when the “Monitor Out” set-

ting is set to “Analog”.

HDMI Input

If you connect a video component to an HDMI input, you

must assign that input to an input selector. For example, if

you connect your Blu-ray Disc/DVD player to HDMI

IN 2, you must assign “HDMI 2” to the “BD/DVD” input

selector.

If you’ve connected your TV to the AV receiver with an

HDMI cable, composite video, S-video and component

video sources can be upconverted* and output by the

HDMI output*1. You can set this for each input selector by

selecting the “-----” option.

*1 This applies only when “Monitor Out” setting is set to other

than “Analog” (➔48).

Here are the default assignments.

■BD/DVD, VCR/DVR, CBL/SAT, GAME, PC,

TV/CD, PHONO, PORT

`HDMI 1, HDMI 2, HDMI 3, HDMI 4, HDMI 5,

HDMI 6:

Select the HDMI IN to which the video component

has been connected.

`-----:

Output composite video, S-Video, and component

video sources from the HDMI output. The video out-

put signal from the HDMI output is the one config-

ured in “Component Video Input” (➔50).

•“AUX” is used only for input from the front panel.

• Each HDMI input cannot be assigned to two input selec-

tors or more. When HDMI 1 - HDMI 6 have already

been assigned, you must set first any unused input selec-

tors to “-----” or you will be unable to assign HDMI 1

- HDMI 6 to input selector.

Input selector Default assignment

BD/DVD HDMI 1

VCR/DVR HDMI 2

CBL/SAT HDMI 3

GAME HDMI 4

PC HDMI 5

AUX FRONT (Fixed)

TUNER ----- (Fixed)

TV/CD -----

PHONO -----

PORT -----

OUT

Composite video, S-Video,

component video

Composite video, S-Video,

component video

HDMI

Note

• For composite video, S-Video, and component video upconver-

sion for the HDMI output, the “HDMI Input” setting must be

set to “-----”. See “Video Connection Formats” for more infor-

mation on video signal flow and upconversion (➔22).

• If no video component is connected to HDMI output (even if the

HDMI input is assigned), the AV receiver selects the video

source based on the setting of “Component Video Input”.

• When an HDMI IN is assigned to an input selector as explained

here, the same HDMI IN will be set as a priority in the “Digital

Audio Input” (➔50). In this case, if you want to use the coaxial

or optical audio input, make the selection in the Audio Selector

in the Home menu (➔26).

•“TUNER” selector cannot be assigned and is fixed at the

“-----” option.

• If you connect a component (such as UP-A1 Dock that seated

iPod) to UNIVERSAL PORT jack, you cannot assign any input

to “PORT” selector.

• Do not assign the component connected with the HDMI input to

“TV/CD” selector when you set “TV Control” setting to “On”

(➔63). Otherwise, appropriate CEC (Consumer Electronics

Control) operation will not be guaranteed.

Component Video Input

If you connect a video component to a component video

input, you must assign that input to an input selector. For

example, if you connect your Blu-ray Disc/DVD player to

COMPONENT VIDEO IN 2, you must assign “IN 2” to

the “BD/DVD” input selector.

If you’ve connected your TV to the AV receiver with a

component video cable, you can set the AV receiver so

that composite video and S-Video sources are upcon-

verted* and output by the COMPONENT VIDEO MONI-

TOR OUT*1. You can set this for each input selector by

selecting the “-----” option.

*1 Only when “Monitor Out” setting is set to “Analog” (➔48).

Here are the default assignments.

■BD/DVD, VCR/DVR, CBL/SAT, GAME, PC, AUX,

TV/CD, PHONO, PORT

`IN 1, IN 2, IN 3:

Select a corresponding component video input that

the video component has been connected.

`-----:

Select if you are using HDMI output, rather than the

COMPONENT VIDEO MONITOR OUT, for the

output from composite video, S-Video, and compo-

nent video sources.

Note

• For composite video and S-Video upconversion for the COM-

PONENT VIDEO MONITOR OUT, the “Monitor Out” set-

ting must be set to “Analog” (➔48), and the “Component

Video Input” setting must be set to “-----”. See “Video Con-

nection Formats” for more information on video signal flow and

upconversion (➔22).

• If not connected to the same output you have selected in the

“Monitor Out” setting, the “Monitor Out” setting will be auto-

matically switched to “Analog” (➔48).

• If you connect a component (such as UP-A1 Dock that seated

iPod) to the UNIVERSAL PORT jack, you cannot assign any

input to “PORT” selector.

Digital Audio Input

If you connect a component to a digital audio input, you

must assign that input to an input selector. For example, if

you connect your CD player to the OPTICAL IN 1, you

must assign “OPT 1” to the “TV/CD” input selector.

Here are the default assignments.

■BD/DVD, VCR/DVR, CBL/SAT, GAME, PC,

TV/CD, PHONO, PORT

`COAX 1, COAX 2, COAX 3, OPT 1, OPT 2:

Select a corresponding digital audio input that the

component has been connected.

`-----:

Select if the component is connected to an analog

audio input.

Note

•When an HDMI IN is assigned to an input selector in “HDMI

Input” (➔49), the same HDMI IN will be set as a priority in this

assignment. In this case, if you want to use the coaxial or optical

audio input, make the selection in the Audio Selector in the

Home menu (➔66).

• Available sampling rate for PCM signals from a digital input

(optical and coaxial) is 32/44.1/48/88.2/96 kHz/16, 20, 24 bit.

• If you connect a component (such as UP-A1 Dock that seated

iPod) to the UNIVERSAL PORT jack, you cannot assign any

input to “PORT” selector.

Input selector Default assignment

BD/DVD IN 1

VCR/DVR -----

CBL/SAT IN 2

GAME IN 3

PC -----

AUX -----

TUNER ----- (Fixed)

TV/CD -----

PHONO -----

PORT -----

OUT

Composite video, S-Video

Component video

Input selector Default assignment

BD/DVD COAX 1

VCR/DVR COAX 2

CBL/SAT COAX 3

GAME OPT 1

PC -----

AUX FRONT (Fixed)

TUNER ----- (Fixed)

TV/CD OPT 2

PHONO -----

PORT -----

Analog Audio Input

Some DVD players output the LFE channel from their

analog subwoofer output at 15 dB higher than normal.

With this setting, you can change the AV receiver’s sub-

woofer sensitivity to match your DVD player.

■Subwoofer Input Sensitivity

`0dB to 15dB in 5 dB step.

Note

• This setting only affects signals connected to the AV receiver’s

multichannel input SUBWOOFER jack.

• If you find that your subwoofer is too loud, try the 10 dB or

15 dB setting.

Main menu Speaker Setup

Here you can check the settings made by

Audyssey MultEQ Room Correction and Speaker Setup

function, or set them manually, which is useful if you

change one of the connected speakers after using

Audyssey MultEQ Room Correction and Speaker Setup

function.

Note

• These settings are disabled when:

– a pair of headphones is connected, or

–the “Audio TV Out” setting is set to “On” (➔62) and an

input selector other than HDMI is selected.

Speaker Settings

If the impedance of any speaker is 4 ohms or more but less

than 6, set the minimum speaker impedance to 4 ohms.

If you bi-amp the front speakers, you must change the

“Speakers Type(Front)” setting (➔51).

For hookup information, see “Bi-amping the Front Speak-

ers” (➔15).

Note

• When bi-amping is used, the AV receiver is able to drive up to

5.1 speakers in the main room.

• Before you change these settings, turn down the volume.

■Speaker Impedance

`4ohms:

Select if the impedance of any speaker is 4 ohms or

more but less than 6.

`6ohms:

Select if the impedances of all speakers are between

6 and 16 ohms.

■Speakers Type(Front)

`Normal:

Select this if you’ve connected your front speakers

normally.

`Bi-Amp:

Select this if you’ve bi-amped your front speakers.

Note

• Powered Zone 2 cannot be used if “Speakers Type(Front)” is

set to “Bi-Amp” (➔79).

■Powered Zone 2

See “Setting the Powered Zone 2” (➔79).

Speaker Configuration

With these settings, you can specify which speakers are

connected and a crossover frequency for each speaker.

Specify “Full Band” for speakers that can output low fre-

quency bass sounds adequately, for example, speakers

with a good sized woofer. For smaller speakers, specify a

crossover frequency. Sounds below the crossover fre-

quency will be output by the subwoofer instead of the

speaker. Refer to your speaker’s manuals to determine the

optimum crossover frequencies. If you set up your speak-

ers using Audyssey MultEQ Room Correction and

Speaker Setup, please make sure manually that any THX

speakers are set to “80Hz(THX)” crossover.

■Subwoofer

`Yes :

Select if a subwoofer is connected.

`No:

Select if no subwoofer is connected.

■Front

`Full Band

`40Hz, 45Hz, 50Hz, 55Hz, 60Hz, 70Hz, 80Hz(THX)

to 130Hz, 150Hz, 200Hz

Note

• If the “Subwoofer” setting is set to “No”, the “Front” setting is

fixed at “Full Band”.

■Center*1, Surround*1, Surr Back*2*3*4*5

`Full Band

`40Hz, 45Hz, 50Hz, 55Hz, 60Hz, 70Hz, 80Hz(THX)

to 130Hz, 150Hz, 200Hz

`None:

Select if no speaker is connected.

Speaker Setup

Some of the settings in this section are set automatically

by Audyssey MultEQ® Room Correction and Speaker

Setup function (➔28).

If you change these settings, you must run

Audyssey MultEQ Room Correction and Speaker

Setup again (➔28).

This setting is set automatically by Audyssey MultEQ

Room Correction and Speaker Setup function (➔28).

■Front Wide*1*2*4*6, Front High*1*2*4*5

`Full Band

`40Hz, 45Hz, 50Hz, 55Hz, 60Hz, 70Hz, 80Hz(THX)

to 130Hz, 150Hz, 200Hz

`None:

Select if no speaker is connected.

Note

*1 “Full Band” can be selected only when “Full Band” is

selected in the “Front” setting.

*2 If the “Surround” setting is set to “None”, this setting cannot

be selected.

*3 If the “Surround” setting is set to anything other than “Full

Band”, “Full Band” cannot be selected here.

*4 If the “Speakers Type(Front)” setting is set to “Bi-Amp”

(➔51), this setting cannot be selected.

*5 If the Powered Zone 2 is being used (➔80), this setting can-

not be selected.

*6 If the “Powered Zone 2” setting is set to “Act” (➔79), this

setting cannot be selected.

■Surr Back Ch

`1ch:

Select if only one surround back speaker is con-

nected.

`2ch:

Select if two (left and right) surround back speakers

are connected.

Note

•If the “Surr Back” setting is set to “None” (➔51), this setting

cannot be selected.

■LPF of LFE

(Low-Pass Filter for the LFE Channel)

`80Hz, 90Hz, 100Hz, 110Hz, 120Hz

With this setting, you can specify the cutoff frequency

of the LFE channel’s low-pass filter (LPF), which can

be used to filter out unwanted hum. The LPF only

applies to sources that use the LFE channel.

■Double Bass

With the Double Bass function, you can boost bass out-

put by feeding bass sounds from the front left, right, and

center channels to the subwoofer.

`On:

Double Bass function on.

`Off(THX):

Double Bass function off.

Note

• This function can be set only if the “Subwoofer” setting is set to

“Ye s ”, and the “Front” setting is set to “Full Band”.

• If you’re using THX-certified speakers, select “Off(THX)”.

Speaker Distance

Here you can specify the distance from each speaker to the

listening position so that the sound from each speaker

arrives at the listener’s ears as the sound designer

intended.

■Unit

`feet:

Distances can be set in feet. Range: “0.2ft” to

“30.0ft” in 0.2 foot steps.

`meters:

Distances can be set in meters. Range: “0.06m” to

“9.00m” in 0.06 meter steps.

(The default setting varies from country to country.)

■Left, Front Wide Left, Front High Left, Center,

Front High Right, Front Wide Right, Right, Surr

Right, Surr Back Right, Surr Back Left, Surr

Left, Subwoofer

`Specify the distance from the each speaker to your lis-

tening position.

Note

• Speakers that you set to “No” or “None” in the “Speaker Con-

figuration” cannot be selected (➔51).

Level Calibration

Here you can adjust the level of each speaker with the

built-in test tone so that the volume of each speaker is the

same at the listening position.

■Left, Front Wide Left, Front High Left, Center*1,

Front High Right, Front Wide Right, Right, Surr

Right, Surr Back Right, Surr Back Left, Surr Left

`–12.0dB to 0.0dB to +12.0dB in 0.5 dB step.

■Subwoofer*1

`–15.0dB to 0.0dB to +12.0dB in 0.5 dB step.

Note

• Speakers that you set to “No” or “None” in the “Speaker Con-

figuration” cannot be selected (➔51).

• The speakers cannot be calibrated while the AV receiver is

muted.

• The test tone is output at the standard level for THX, which is

0 dB (absolute volume setting 82). If you normally listen at vol-

ume settings below this, be careful because the test tone will be

much louder.

*1 For the center speaker and subwoofer, the level settings made

by using the Home menu are saved (➔26).

Tip

• If you’re using a handheld sound level meter, adjust the level of

each speaker so that it reads 75 dB SPL at the listening position,

measured with C-weighting and slow reading.

This setting is NOT set automatically by

Audyssey MultEQ® Room Correction and Speaker

Setup function (➔28).

This setting is set automatically by Audyssey MultEQ

Room Correction and Speaker Setup function (➔28).

This setting is set automatically by Audyssey MultEQ

Room Correction and Speaker Setup function (➔28).

Equalizer Settings

With the Equalizer settings, you can adjust the tone of

speakers individually with a 15-band equalizer. The vol-

ume of each speaker can be set (➔52).

■Equalizer

`Manual:

You can adjust the equalizer for each speaker manu-

ally. If you selected “Manual”, continue with this

procedure.

`Audyssey:

This is selected automatically by Audyssey MultEQ

Room Correction and Speaker Setup function. The

Audyssey indicator will light (➔9) and

“Dynamic EQ” (➔56) and “Dynamic Volume”

(➔56) become available.

`Off:

Tone off, response flat.

THX Audio Setup

With the “SurrBack Speaker Spacing” setting, you can

specify the distance between your surround back speakers.

If you’re using a THX-certified subwoofer, set the “THX

Ultra2/Select2 Subwoofer” setting to “Ye s ”. You can

then apply THX’s Boundary Gain Compensation (BGC)

to compensate the perceived exaggeration of low frequen-

cies for listeners sitting very close to a room boundary

(i.e., wall).

You can also set the THX Loudness Plus. When the

“Loudness Plus” is set to “On”, it is possible to enjoy

even subtle nuances of audio expression at low volume.

This result is only available when the THX listening mode

is selected.

■SurrBack Speaker Spacing

`< 1ft (< 0.3m):

Select this if your surround back speakers are

between 0 and 1 foot (0–30 cm) apart.

`1ft - 4ft (0.3m - 1.2m):

Select this if your surround back speakers are

between 1 and 4 feet (0.3–1.2 m) apart.

`> 4ft (> 1.2m):

Select this if your surround back speakers are more

than 4 feet (1.2 m) apart.

Note

• Cannot be set if “Surr Back Ch” is set to “1ch” (➔52),

“Speakers Type(Front)” is set to “Bi-Amp” (➔51), “Surr

Back” is set to “None” (➔51), or Powered Zone 2 is being used

(➔80).

■THX Ultra2/Select2 Subwoofer

`No:

Select this if you do not have a THX-certified sub-

woofer.

`Yes :

Select this if you have a THX-certified subwoofer.

Note

• If the “Subwoofer” setting is set to “No”, this setting cannot be

selected (➔51).

■BGC

`Off:

Select this to turn off BGC.

`On:

Select this to turn on BGC.

Note

• This setting is only available if “THX Ultra2/Select2 Sub-

woofer” is set to “Ye s ”.

■Loudness Plus

`Off:

Select this to turn off Loudness Plus.

`On:

Select this to turn on Loudness Plus.

This setting is set automatically by Audyssey MultEQ®

Room Correction and Speaker Setup function (➔28).

1Press w to select “Channel”, and then use e/

r to select a speaker.

2Use q/w to select a frequency, and then use

the e/r to adjust the level at that frequency.

The volume at each frequency can be adjusted

from –6dB to 0dB to +6dB in 1 dB steps.

Note

• You can select: “25Hz”, “40Hz”, “63Hz”,

“100Hz”, “160Hz”, “250Hz”, “400Hz”, “630Hz”,

“1000Hz”, “1600Hz”, “2500Hz”, “4000Hz”,

“6300Hz”, “10000Hz”, or “16000Hz”. And for the

subwoofer, “25Hz”, “40Hz”, “63Hz”, “100Hz”, or

“160Hz”.

• While the Direct listening mode is selected, the

equalizer settings have no effect.

Tip

• Low frequencies (e.g., 63Hz) affect bass sounds;

high frequencies (e.g., 16000Hz) affect treble

sounds.

3Use q to select “Channel”, and then use e/r

to select another speaker.

Repeat steps 1 and 2 for each speaker.

You cannot select speakers that you set to “No”

or “None” in the “Speaker Configuration”

(➔51).

■Preserve THX Settings

`Yes:

Audyssey Dynamic EQ® /

Audyssey Dynamic Volume® will not be active in

THX listening mode.

`No:

Audyssey Dynamic EQ /

Audyssey Dynamic Volume will be active in THX

listening mode depending on the setting.

Note

• This setting is fixed at “Ye s ” if “Loudness Plus” is set to “On”.

Main menu Audio Adjust

With the Audio Adjust functions and settings, you can

adjust the sound and listening modes as you like.

Multiplex/Mono

■Multiplex

This setting determines which channel of a stereo multi-

plex source is output. Use it to select audio channels or

languages with multiplex sources, multilingual TV

broadcasts, and so on.

Input Channel

`Main:

The main channel is output.

`Sub:

The sub channel is output.

`Main/Sub:

Both the main and sub channels are output.

■Mono

This setting specifies the channel to be used for playing

any 2-channel digital source such as Dolby Digital, or

2-channel analog/PCM source in the Mono listening

mode.

Input Channel

`Left + Right:

Both the left and right channels are output.

`Left:

Only the left channel is output.

`Right:

Only the right channel is output.

Output Speaker

`Center:

Mono audio is output by the center speaker.

`Left / Right:

Mono audio is output by the front left and right

speakers.

This setting determines which speakers output mono

audio when the Mono listening mode is selected.

Note

•If the “Center” setting is set to “None” (➔51), this setting is

fixed at “Left / Right”.

Dolby

■PLIIx Music (2ch Input)

These settings apply to only 2-channel stereo sources.

If you’re not using any surround back speakers, these

settings apply to Dolby Pro Logic II, not Dolby Pro

Logic IIx.

Panorama

`On:

Panorama function on.

`Off:

Panorama function off.

With this setting, you can broaden the width of the front

stereo image when using the Dolby Pro Logic IIx Music

listening mode.

Dimension

`–3 to 0 to +3

With this setting, you can move the sound field forward

or backward when using the Dolby Pro Logic IIx Music

listening mode. Higher settings move the sound field

backward. Lower settings move it forward.

If the stereo image feels too wide, or there’s too much

surround sound, move the sound field forward to

improve the balance. Conversely, if the stereo image

feels like it’s in mono, or there’s not enough surround

sound, move it backward.

Center Width

`0 to 3 to 7

With this setting, you can adjust the width of the sound

from the center speaker when using the Dolby Pro

Logic IIx Music listening mode. Normally, if you’re

using a center speaker, the center channel sound is out-

put by only the center speaker. (If you’re not using a

center speaker, the center channel sound will be distrib-

uted to the front left and right speakers to create a phan-

tom center). This setting controls the front left, right,

and center mix, allowing you to adjust the weight of the

center channel sound.

THX Loudness Plus

THX Loudness Plus is a new volume control technology

featured in THX Ultra2 Plus™ and THX Select2 Plus™

Certified receivers. With THX Loudness Plus, home

theater audiences can now experience the rich details in

a surround mix at any volume level. A consequence of

turning the volume below Reference Level is that cer-

tain sound elements can be lost or perceived differently

by the listener. THX Loudness Plus compensates for the

tonal and spatial shifts that occur when the volume is

reduced by intelligently adjusting ambient surround

channel levels and frequency response. This enables

users experience the true impact of soundtracks regard-

less of the volume setting. THX Loudness Plus is auto-

matically applied when listening in any THX listening

mode. The new THX Cinema, THX Music, and THX

Games modes are tailored to apply the proper THX

Loudness Plus settings for each type of content.

Audio Adjust

■PLIIz Height Gain

The Height Gain Control in Dolby Pro Logic IIz

enables the listener to select how much gain is applied

to the front high speakers. There are three settings,

“Low”, “Mid” and “High”, and the front high speakers

are accentuated in that order. While “Mid” is the default

listening setting, the listener may adjust the Height Gain

Control to their personal preference.

`Low:

Low PLIIz Height Gain becomes active.

`Mid:

Medium PLIIz Height Gain becomes active.

`High:

High PLIIz Height Gain becomes active.

Note

•If the “Front High” settings is set to “None” (➔52), this setting

cannot be selected.

■Dolby EX

This setting determines how Dolby EX encoded signals

are handled. This setting is unavailable if no surround

back speakers are connected. This setting is effective

with Dolby Digital, Dolby Digital Plus and Dolby

TrueHD only.

`Auto:

If the source signal contains a Dolby EX flag, the

Dolby EX or THX Surround EX listening mode is

used.

`Manual:

You can select any available listening mode.

Note

•If the “Surr Back” setting is set to “None” (➔51), this setting

cannot be selected.

•If the “Front High” or “Front Wide” setting is enabled (➔52),

this setting is fixed at “Manual”.

DTS

■Neo:6 Music

Center Image

`0 to 2 to 5

The DTS Neo:6 Music listening mode creates 6-channel

surround sound from 2-channel stereo sources. With

this setting, you can specify by how much the front left

and right channel output is attenuated in order to create

the center channel.

Setting a value “0” in the middle is set to hear a sound.

Sound is spread in left and right (the outside) so that the

set value is made big. Please adjust by liking.

Audyssey DSX™

■Soundstage

`–3dB to Reference to +3dB

With this setting, you can adjust the soundstage when using

Audyssey DSX™.

Note

•If the “Center” setting is set to “None”, or both “Front High”

and “Front Wide” settings are set to “None” (➔52), this setting

cannot be selected.

Theater-Dimensional

■Listening Angle

`Wide:

Select if the listening angle is 40 degrees.

`Narrow:

Select if the listening angle is 20 degrees.

With this setting, you can optimize the Theater-Dimen-

sional listening mode by specifying the angle of the

front left and right speakers relative to the listening

position. Ideally, the front left and right speakers should

be equidistant from the listening position and at an

angle close to one of the two available settings.

LFE Level

■Dolby Digital*1, DTS*2, Multich PCM, Dolby

TrueHD, DTS-HD Master Audio, DSD*3

`–QdB, –20dB, –10dB, or 0dB

With these settings, you can set the level of the LFE (Low

Frequency Effects) channel individually for each input

sources.

If you find that low-frequency effects are too loud when

using one of these sources, change the setting to –20 dB or

–Q dB.

*1 Dolby Digital and Dolby Digital Plus sources.

*2 DTS and DTS-HD High Resolution Audio sources.

*3 DSD (Super Audio CD) sources.

20°/40°

Front left speaker Front right speaker

Items can be set individually for each input selector.

Main menu Source Setup

Audyssey

When Audyssey MultEQ® Room Correction and Speaker

Setup is complete, the “Equalizer” (➔53) will be set to

“Audyssey” and the “Dynamic EQ” will be set to “On”.

■Dynamic EQ

`Off:

Audyssey Dynamic EQ® off.

`On:

Audyssey Dynamic EQ on.

The Dynamic EQ indicator will light (➔9).

With Audyssey Dynamic EQ, you can enjoy great

sound even when listening at low volume levels.

Audyssey Dynamic EQ solves the problem of deterio-

rating sound quality as volume is decreased by taking

into account human perception and room acoustics. It

does so by selecting the correct frequency response and

surround volume levels moment-by-moment so that the

content sounds the way it was created at any volume

level — not just at reference level.

Note

• If Direct listening mode is selected, this setting cannot be

selected.

■Reference Level

Audyssey Dynamic EQ Reference Level Offset

`0dB:

It should be used when listening to movies.

`5dB:

Select this setting for content that has a very wide

dynamic range, such as classical music.

`10dB:

Select this setting for jazz or other music that has a

wider dynamic range. This setting should also be

selected for TV content as that is usually mixed at

10 dB below film reference.

`15dB:

Select this setting for pop/rock music or other pro-

gram material that is mixed at very high listening

levels and has a compressed dynamic range.

Movies are mixed in rooms calibrated for film refer-

ence. To achieve the same reference level in a home the-

ater system each speaker level must be adjusted so that

–30 dBFS band-limited (500 Hz to 2000 Hz) pink noise

produces 75 dB sound pressure level at the listening

position. A home theater system automatically cali-

brated by Audyssey MultEQ will play at reference level

when the master volume control is set to the 0 dB posi-

tion. At that level you can hear the mix as the mixers

heard it.

Audyssey Dynamic EQ is referenced to the standard

film mix level. It makes adjustments to maintain the ref-

erence response and surround envelopment when the

volume is turned down from 0 dB. However, film refer-

ence level is not always used in music or other non-film

content. Audyssey Dynamic EQ Reference Level Offset

provides three offsets from the film level reference

(5 dB, 10 dB, and 15 dB) that can be selected when the

mix level of the content is not within the standard.

Note

•If “Dynamic EQ” setting is set to “Off”, this setting cannot be

selected.

■Dynamic Volume

`Off:

Audyssey Dynamic Volume® off.

`Light:

Light Compression Mode becomes active.

`Medium:

Medium Compression Mode becomes active.

`Heavy:

Heavy Compression Mode becomes active. This set-

ting affects volume the most, causing all sounds to

be of equal loudness.

Note

• Even if you have selected other than “Audyssey” in “Equalizer”

setting after performing Audyssey MultEQ Room Correction

and Speaker Setup, selecting “On” in the “Dynamic EQ” will

change the “Equalizer” setting to “Audyssey” (➔53).

• If you would like to use Audyssey Dynamic Volume, when

using THX listening modes, set “Loudness Plus” setting to

“Off” (➔53) and set “Preserve THX Settings” setting to “No”

(➔54).

•When “Dynamic Volume” is set to effective, “Equalizer” is set

to “Audyssey” (➔53) and “Dynamic EQ” is set to “On”.

When “Dynamic EQ” is set to “Off”, “Dynamic Volume”

becomes “Off” automatically.

•When “Dynamic Volume” is set to effective, the Dynamic Vol

indicator will light (➔9).

• If Direct listening mode is selected, this setting cannot be

selected.

Audyssey MultEQ then removes the distortion caused by

room acoustics by capturing room acoustical problems

over the listening area in both the frequency and time

domain. The result is clear, well-balanced sound for every-

one. Enabling Audyssey MultEQ allows you to also use

Audyssey Dynamic EQ, which maintains the proper

octave-to-octave balance at any volume level.

Before using this function, connect and position all of

your speakers.

Source Setup

Preparation

Press the input selector buttons to select an input source.

IntelliVolume

■IntelliVolume

`–12dB to 0dB to +12dB in 1 dB steps.

With IntelliVolume, you can set the input level for each

input selector individually. This is useful if one of your

source components is louder or quieter than the others.

Use e/r to set the level.

If a component is noticeably louder than the others, use e

to reduce its input level. If it’s noticeably quieter, use r to

increase its input level.

A/V Sync

■A/V Sync

`0ms to 250ms in 2 ms steps.

When using your DVD player’s progressive scanning

function, you may find that the picture and sound are out

of sync. With the A/V Sync setting, you can correct this

by applying a delay to the audio signal.

To view the TV picture while setting the delay, press

Enter.

To return to the previous screen, press Return.

If HDMI Lip Sync is enabled (➔62) and your TV or dis-

play supports HDMI Lip Sync, the displayed delay time

will be the summation of the A/V Sync delay time and the

HDMI Lip Sync delay time. The HDMI Lip Sync delay

time is displayed underneath in parentheses.

Note

• A/V Sync is disabled when the Direct listening mode is used

with an analog input source.

•“A/V Sync” is not operable when the input selector is set to

“NET/USB”.

Name Edit

You can enter a custom name for each individual input

selector (excluding Tuner) and radio preset for easy iden-

tification. When entered, the custom name will appear on

the display.

The custom name is edited using the character input

screen.

■Name

About Audyssey Dynamic EQ®

Audyssey Dynamic EQ solves the problem of deterio-

rating sound quality as volume is decreased by taking

into account human perception and room acoustics.

Dynamic EQ selects the correct frequency response and

surround levels moment-by-moment at any user-

selected volume setting. The result is bass response,

tonal balance, and surround impression that remain con-

stant despite changes in volume. Dynamic EQ combines

information from incoming source levels with actual

output sound levels in the room, a prerequisite for deliv-

ering a loudness correction solution.

Audyssey Dynamic EQ works in tandem with

Audyssey MultEQ® to provide well-balanced sound for

every listener at any volume level.

About Audyssey Dynamic Volume®

Audyssey Dynamic Volume solves the problem of large

variations in volume level between television programs,

commercials, and between the soft and loud passages of

movies. Dynamic Volume looks at the preferred volume

setting by the user and then monitors how the volume of

program material is being perceived by listeners in real

time to decide whether an adjustment is needed. When-

ever necessary, Dynamic Volume makes the necessary

rapid or gradual adjustments to maintain the desired

playback volume level while optimizing the dynamic

range. Audyssey Dynamic EQ is integrated into

Dynamic Volume so that as the playback volume is

adjusted automatically, the perceived bass response,

tonal balance, surround impression, and dialog clarity

remain the same whether watching movies, flipping

between television channels, or changing from stereo to

surround sound content.

1Use q/w/e/r to select a character, and then

press Enter.

Repeat this step to enter up to 10 characters.

2When you’ve finished, to store a name, be sure

to use q/w/e/r to select “OK”, and then press

Enter. Otherwise it will not be saved.

To correct a character:

Note

• To name a radio preset, use Tuner to select AM or FM, and then

select the preset (➔32).

•(North American models) You cannot enter a custom name for

SIRIUS radio presets.

•“Name Edit” is not operable when the input selector is set to

“NET/USB”.

To restore a custom name to the default, erase the custom

name by entering an empty white space for each letter.

Picture Adjust

Using “Picture Adjust”, you can adjust the picture qual-

ity and reduce any noise appearing on the screen.

To view the TV picture while setting, press Enter. To

return to the previous screen, press Return.

Note

• If you are using the analog RGB input, the following settings

have no effect: “Film Mode”, “Edge Enhancement”, and

“Noise Reduction”.

•“Picture Adjust” is not operable when the input selector is set

to “NET/USB”.

■Game Mode

`Off:

Game Mode off.

`On:

Game Mode on.

If video signal delay occurs during playback on a video

component (i.e. game console), select the corresponding

input source and set the “Game Mode” setting to “On”.

The delay will decrease but in return the picture quality

will become poor.

■Wide Mode*1*3

This setting determines the aspect ratio.

Note

•When the “Game Mode” is set to “On”, this setting is fixed at

“Full”.

`4:3:

`Full:

`Zoom:

`Wide Zoom:

`Auto:

According to the input signals and monitor output

setting, the AV receiver automatically selects the

“4:3”, “Full”, “Zoom” or “Wide Zoom” mode. For

the monitor output setting (➔48).

1Use q/w/e/r to select “ ”(Left) or

“ ”(Right), and then press Enter.

2Press Enter several times to select the incorrect

character (The cursor moves one letter each

time Enter is pressed).

3Use q/w/e/r to select the correct character,

and then press Enter.

BD/DVD

Shift All Erase

4-4. Name Edit

Name

abcde f gh i j k lm

nopq r s t uvwxy z

1234567890

–`

Space Back SpaceShift OK

{}|: <>

ABCDEFGH I J KLM

NOPQRS TUVWXY Z

;

’,

[]

Space Back SpaceShift OK

#$%

^& ()_ ~

+10 CLR

Name input area

Shift*1:

Switches the displayed character.

Space:

Enters a space character.

(Left)/ (Right):

Selected when the cursor is moved within the Name

input area.

BackSpace*2:

“BackSpace” moves the cursor backward one char-

acter space. In addition, “BackSpace” deletes the

character to the left of the cursor.

OK:

Selects when the entry is complete.

Tip

*1 You can also be performed on the remote controller by

using +10.

*2 Press CLR on the remote controller, you can delete all

characters in the input.

■Picture Mode*1

`Custom:

All settings can be performed manually.

`ISF Day:

Setting when a room is bright.

`ISF Night:

Setting when a room is dark.

`Cinema:

Selected when the picture source is movie film, etc.

`Game:

Selected when the picture source is game console.

`Through:

Default values are adapted for all settings.

With “Picture Mode”, you can change the following set-

tings to be suitable for the movie or game screen by one

operation; “Film Mode”, “Edge Enhancement”, “Noise

Reduction”, “Resolution”, “Brightness”, “Contrast”,

“Hue”, “Saturation”, “Gamma”, “Red Brightness”,

“Red Contrast”, “Green Brightness”, “Green Con-

trast”, “Blue Brightness”, “Blue Contrast”.

The receiver has been designed to incorporate setup and

calibration standards established by the Imaging Science

Foundation (ISF). The ISF has developed carefully

crafted, industry-recognized standards for optimal video

performance and has implemented a training program for

technicians and installers to use these standards to obtain

optimal picture quality from the receiver. Accordingly,

Onkyo recommends that setup and calibration be per-

formed by an ISF Certified installation technician.

■Film Mode*2*4*5

`Video:

Does not process in either “3:2” or “2:2”.

`Auto:

Adjusts to the picture source, automatically selecting

“Film Mode”.

`3:2:

Selected when the picture source is movie film, etc.

`2:2:

Selected when the picture source is computer graph-

ics, animation, etc.

The AV receiver will adjust to the picture source, process-

ing in either “3:2” or “2:2” (Film Mode). It automatically

converts the source to the appropriate progressive signal

and reproduces the natural quality of the original picture.

When the “Film Mode” setting is set to “Auto”, the AV

receiver automatically detects the picture source and in

either “3:2” or “2:2”. However, there may be times when

you will get a better picture by setting “Film Mode” your-

self.

■Edge Enhancement*2*4

`0 to +10

With this setting you can adjust the sharpness of edges in

the picture. “0” is the softest. “+10” is the sharpest.

■Noise Reduction*2*4*6

`Off:

Noise reduction off.

`Low:

Low noise reduction.

`Mid:

Medium noise reduction.

`High:

High noise reduction.

With this setting, you can reduce noise appearing on the

screen.

■Resolution*2*4

`Through:

Select this to pass video through the AV receiver at

the same resolution and with no conversion.

`Auto:

Select this to have the AV receiver automatically

convert video at resolutions not supported by your

TV. When the “Monitor Out” is set to “Analog”,

this setting will be changed to “Through”.

`480p (480p/576p):

Select this for 480p or 576p output and video con-

version as necessary.

`720p:

Select this for 720p output and video conversion as

necessary.

`1080i:

Select this for 1080i output and video conversion as

necessary.

`1080p:

Select this for 1080p output and video conversion as

necessary. When the “Monitor Out” is set to “Ana-

log”, this setting will be changed to “1080i”.

You can specify the output resolution for the HDMI out-

puts and have the AV receiver upconvert the picture reso-

lution as necessary to match the resolution supported by

your TV.

Available only when “Source” has been selected in the

“Resolution” of the “Monitor Out” setting (➔49).

■Brightness*1*2*4

`–50 to 0 to +50

With this setting you can adjust the picture bright-

ness. “–50” is the darkest. “+50” is the brightest.

■Contrast*1*2*4

`–50 to 0 to +50

With this setting you can adjust contrast. “–50” is the

least. “+50” is the greatest.

■Hue*1*2*4

`–20 to 0 to +20

With this setting you can adjust the red/green bal-

ance. “–20” is the strongest green. “+20” is the

strongest red.

■Saturation*1*2*4

`–50 to 0 to +50

With this setting you can adjust saturation. “–50” is

the weakest color. “+50” is the strongest color.

■Gamma*2*4

`–3 to 0 to +3

Adjust the balance of incoming picture R (red), G

(green), and B (blue) color data signal to the output

color data signal.

■Red Brightness*2*4

`–50 to 0 to +50

With this setting you can adjust the picture red

brightness. “–50” is the darkest. “+50” is the bright-

est.

■Red Contrast*2*4

`–50 to 0 to +50

With this setting you can adjust red contrast. “–50” is

the least. “+50” is the greatest.

■Green Brightness*2*4

`–50 to 0 to +50

With this setting you can adjust the picture green

brightness. “–50” is the darkest. “+50” is the bright-

est.

■Green Contrast*2*4

`–50 to 0 to +50

With this setting you can adjust green contrast.

“–50” is the least. “+50” is the greatest.

■Blue Brightness*2*4

`–50 to 0 to +50

With this setting you can adjust the picture blue

brightness. “–50” is the darkest. “+50” is the bright-

est.

■Blue Contrast*2*4

`–50 to 0 to +50

With this setting you can adjust blue contrast. “–50”

is the least. “+50” is the greatest.

Tip

*1 This procedure can also be performed on the remote controller

by using the Home menu (➔26).

*2 Press CLR if you want to reset to the default value.

Note

• If you are using the analog RGB input, the following settings

have no effect: “Film Mode”, “Edge Enhancement”, and

“Noise Reduction”.

•“Picture Adjust” is not operable when the input selector is set

to “NET/USB”.

*3 When the “Game Mode” is set to “On” (➔58), this setting is

fixed at “Full”.

*4 When the “Picture Mode” setting is set to anything other than

“Custom”, this setting cannot be used.

*5 When the “Game Mode” is set to “On” (➔58), this setting is

fixed at “Video”.

*6 When the “Game Mode” is set to “On” (➔58), this setting is

fixed at “Off”.

You can assign a default listening mode to each input

source that will be selected automatically when you select

each input source. For example, you can set the default lis-

tening mode to be used with Dolby Digital input signals.

You can select other listening modes during playback, but

the mode specified here will be resumed once the AV

receiver has been set to Standby.

Main menu Listening Mode Preset

■Analog/PCM

With this setting, you can specify the listening mode to

be used when an analog (CD, TV, LD, VHS, MD, turn-

table, radio, cassette, cable, satellite, etc.) or PCM digi-

tal (CD, DVD, etc.) audio signal is played.

■Mono/Multiplex Source

With this setting, you can specify the listening mode to

be used when a mono digital audio signal is played

(DVD, etc.).

■2ch Source

With this setting, the default listening mode for 2-chan-

nel (2/0) stereo sources in a digital format, such as

Dolby Digital or DTS.

■Dolby D/Dolby D +/TrueHD

With this setting, you can specify the listening mode to

be used when a Dolby Digital or Dolby Digital Plus for-

mat digital audio signal is played (DVD, etc.). Specifies

the default listening mode for Dolby TrueHD sources,

such as Blu-ray or HD DVD (input via HDMI).

Listening Mode Preset

1Use q/w to select the input source that you want to

set, and then press Enter.

The following menu appears.

For “TUNER” input selector only “Analog” will be

available. For “NET/USB” input source only “Digi-

tal” will be available.

Note

• If you connect an input component (such as UP-A1 series

Dock that seated iPod) to the UNIVERSAL PORT jack,

you can assign only listening modes for the analog sound

to “PORT” selector.

2Use q/w to select the signal format that you want

to set, and then use e/r to select a listening mode.

Only listening modes that can be used with each

input signal format can be selected (➔42 to 46).

The “Last Valid” option means that the listening

mode selected last will be used.

The “Straight Decode” option means that straight

decoding listening mode (Dolby Digital, DTS, etc.)

is selected.

1. BD/DVD

2. VCR/DVR

3. CBL/SAT

4. GAME

5. PC

6. AUX

5. Listening Mode Preset

■DTS/DTS-ES/DTS-HD

With this setting, you can specify the listening mode to

be used when a DTS or DTS-HD High Resolution

Audio format digital audio signal is played (DVD, LD,

CD, etc.). Specifies the default listening mode for DTS-

HD Master Audio sources, such as Blu-ray or HD DVD

(input via HDMI).

■Other Multich Source

Specifies the default listening mode for multichannel

PCM sources from HDMI IN such as DVD-Audio, and

DSD multichannel sources such as Super Audio CD.

Main menu Miscellaneous

Volume Setup

■Volume Display

`Absolute:

Display range is “Min”, “0.5” through “99.5”,

“Max”.

`Relative (THX):

Display range is “–QdB”, “–81.5dB” through

“+18.0dB”.

With this setting, you can choose how the volume level is

displayed.

The absolute value 82 is equivalent to the relative value

0dB.

■Muting Level

`–QdB (fully muted), –50dB to –10dB in 10 dB steps.

This setting determines how much the output is muted

when the muting function is used (➔26).

■Maximum Volume

`Off, 50 to 99 (Absolute display)

`Off, –32dB to +17dB (Relative display)

With this setting, you can limit the maximum volume.

To disable this setting, select “Off”.

■Power On Volume

`Last, Min, 1 to 99 or Max (Absolute display)

`Last, –QdB, –81dB to +18dB (Relative display)

With this preference, you can specify the volume setting to

be used each time the AV receiver is turned on.

To use the same volume level that was used when the AV

receiver was turned off, select “Last”.

The “Power On Volume” cannot be set higher than the

“Maximum Volume” setting.

■Headphone Level

`–12dB to 0dB to +12dB

With this preference, you can specify the headphone vol-

ume relative to the main volume. This is useful if there’s a

volume difference between your speakers and your head-

phones.

OSD Setup

■On Screen Display

This preference determines whether operation details

are displayed onscreen when an AV receiver function is

adjusted.

`On:

Displayed.

`Off:

Not displayed.

Even when “On” is selected, operation details may not be

output if the input source is connected to an HDMI IN.

■TV Format (Australian models)

For the on-screen setup menus to display properly, you

must specify the TV system used in your area.

`Auto:

Select this to automatically detect the TV system

from the video input signals.

`NTSC:

Select this if the TV system in your area is NTSC.

`PAL:

Select this if the TV system in your area is PAL.

■Language

`English, Deutsch, Français, Español, Italiano,

Nederlands, Svenska, Chinese

This setting determines the language used for the on-

screen setup menus.

12V Trigger A/B/C Setup

See “Using the 12V Triggers” (➔82).

Main menu Hardware Setup

Remote ID

■Remote ID

`1, 2, or 3

When several Integra/Onkyo components are used in

the same room, their remote ID codes may overlap. To

differentiate the AV receiver from the other compo-

nents, you can change its remote ID from “1”, to “2” or

“3”.

Note

• If you do change the AV receiver’s remote ID, be sure to change

the remote controller to the same ID (see below), otherwise, you

won’t be able to control it with the remote controller.

Changing the Remote Controller’s ID

Miscellaneous

Hardware Setup

1While holding down Receiver, press and hold

down Setup until Receiver lights (about 3 sec-

onds).

2Use the number buttons to enter ID 1, 2, or 3.

Receiver flashes twice.

Multi Zone

See “Setting the Multi Zone” (➔79).

Tuner

For FM/AM tuning to work properly, you must specify the

FM/AM frequency step used in your area. Note that when

this setting is changed, all radio presets will be deleted.

■FM/AM Frequency Step (North American

models)

`200kHz/10kHz:

Select if 200 kHz/10 kHz steps are used in your area.

`50kHz/9kHz:

Select if 50 kHz/9 kHz steps are used in your area.

■AM Frequency Step (Australian models)

`10kHz:

Select if 10 kHz steps are used in your area.

`9kHz:

Select if 9 kHz steps are used in your area.

SIRIUS Settings (North American models)

See “Listening to SIRIUS Satellite Radio®” (➔32) for

more information.

■SAT Radio Mode

If you connect a SIRIUS Satellite Radio antenna to the

AV receiver (sold separately), set this setting to “SIR-

IUS”.

■Antenna Aiming

■SIRIUS Parental Lock

These items are for use with SIRIUS Satellite Radio.

It’s not available if “SAT Radio Mode” is set to

“None”.

HDMI

■Audio TV Out

`Off:

The audio is not output from the HDMI output.

`On:

The audio is output from the HDMI output.

This preference determines whether the incoming audio

signal is output from the HDMI output. You may want to

turn this preference on if your TV is connected to the

HDMI output and you want to listen to the audio from a

connected component through your TV’s speakers. Nor-

mally, this should be set to “Off”.

Note

• Listening mode cannot be changed when this setting is set to

“On” and the input source is not HDMI.

•If

“On” is selected and the audio can be output from the TV, the

AV receiver will output no sound through its speakers. In this

case, “TV Sp On” appears on the display.

• When “TV Control” is set to “On”, this setting is fixed to

“Auto”.

• With some TVs and input signals, no sound may be output even

when this setting is set to “On” (➔63).

• When the “Audio TV Out” setting is set to “On”, or “TV Con-

trol” is set to “On” (➔63) and you’re listening through your

TV’s speakers (➔18), if you turn up the AV receiver’s volume

control, the sound will be output by the AV receiver’s front left

and right speakers. To stop the AV receiver’s speakers producing

sound, change the settings, change your TV’s settings, or turn

down the AV receiver’s volume.

•If the “Monitor Out” setting is set to “Both(Main)” or

“Both(Sub)” (➔48) and if your TV connected to a priority out-

put cannot output the audio, the sound will be heard from AV

receiver’s speakers.

■Lip Sync

`Disable:

HDMI lip sync disabled.

`Enable:

HDMI lip sync enabled.

The AV receiver can be set to automatically correct any

delay between the video and the audio, based on the data

from the connected monitor.

Note

• This function works only if your HDMI-compatible TV supports

HDMI Lip Sync.

• You can check the amount of delay being applied by the HDMI

Lip Sync function on the A/V Sync screen.

•If the “Monitor Out” setting is set to “HDMI Main”,

“Both(Main)” or “Both” (➔48), the delay will be corrected in

accordance with the monitor connected to HDMI OUT MAIN.

On the other hand, if “HDMI Sub” or “Both(Sub)” is selected,

the delay will be corrected in accordance with the monitor con-

nected to HDMI OUT SUB.

■HDMI Control (RIHD)

`Off:

p disabled.

`On:

p enabled.

This function allows p-compatible components

connected via HDMI to be controlled with the AV receiver

(➔105 to 106).

Note

• When set to “On” and close the menu, the name of connected

p-compatible components and “RIHD On” are dis-

played on the AV receiver.

“Search...” → “(name)” → “RIHD On”

When the AV receiver cannot receive the name of the compo-

nent, it is displayed as “Player*” or “Recorder*”, etc (“*”

means the number of two or more component).

When set to “Off” and close the menu, “RIHD Off” are dis-

played on the AV receiver.

“Disconnect” → “RIHD Off”

•When an p-compatible component is connected to the

AV receiver via the HDMI cable, the name of the connected

component is displayed on the AV receiver display. For example,

while you are watching TV broadcasting, if you operate a

Blu-ray Disc/DVD player (being powered on) by the remote

control of the AV receiver, the name of the Blu-ray Disc/DVD

player is displayed on the AV receiver.

• Set to

“

Off

”

when a connected piece of equipment is not compat-

ible or it is unclear whether the equipment is compatible or not.

• If movement is unnatural when set to “On”, change the setting

to “Off”.

• Refer to the connected component’s instruction manual for details.

•The p control does not support HDMI OUT SUB. Use

HDMI OUT MAIN instead.

• When the source equipment is connected with the

connection,

it may malfunction if “

HDMI Control (RIHD)

” is set to

“

”

■Audio Return Channel

`Off:

Select “Off” if you don’t want to use audio return

channel (ARC) function.

`Auto:

The audio signal from your TV tuner can be sent to

the HDMI OUT MAIN of the AV receiver.

Audio return channel (ARC) function enables an HDMI

(Audio Return Channel) capable TV to send the audio

stream to the HDMI OUT MAIN of the AV receiver. To

use this function, you must select the TV/CD input selec-

tor and your TV must support ARC function.

Note

•The “Audio Return Channel” setting can be set only when the

“HDMI Control (RIHD)” setting is set to “On”.

• This setting is set to “Auto” automatically when the “HDMI

Control (RIHD)” is set to “On” first time.

■Power Control

`Off:

Power Control disabled.

`On:

Power Control enabled.

To link the power functions of p-compatible com-

ponents connected via HDMI, select “On”.

This setting is set to “On” automatically when the

“HDMI Control (RIHD)” is set to “On” first time.

Note

•The

“Power Control” setting can be set only when the “HDMI

Control (RIHD)” setting is set to “On”.

• HDMI power control only works with p-compatible

components that support it and may not work properly with

some components due to their settings or compatibility.

• When set to “On”, power consumption will increase.

• When set to “On”, regardless of whether the AV receiver is On

or in Standby, both audio and video stream from an HDMI input

will be output to the TV or other components via HDMI connec-

tion (HDMI pass through function).

• The power consumption during standby mode will increase dur-

ing the HDMI pass through function; however if your TV sup-

ports CEC (Consumer Electronics Control), the power

consumption can be saved in the following cases:

1. The TV is in standby mode.

2. You are watching a TV program.

• Refer to the connected component’s instruction manual for

details.

■TV Control

`Off:

TV Control disabled.

`On:

TV Control enabled.

Set to “On” when you want to control the AV receiver

from an p-compatible TV that is connected to

HDMI.

Note

• Do not assign the component connected with the HDMI input to

the TV/CD selector when you set “TV Control” setting to “On”.

Otherwise, appropriate CEC (Consumer Electronics Control)

operation is not guaranteed.

•Set to “Off” when the TV is not compatible or when it is unclear

whether the TV is compatible or not.

•The

“TV Control” setting can be set only when the “HDMI

Control (RIHD)” (➔62) and “Power Control” (➔63) set-

tings are both set to “On”.

• Refer to the connected component’s instruction manual for

details.

Auto Power Down

■Auto Power Down

`Off:

Auto Power Down disabled.

`On:

Auto Power Down enabled.

The AV receiver will automatically perform STANDBY

operation when “Auto Power Down” is set to “On”, with

no audio and video signal input, and if there is no opera-

tion for 30 minutes.

“Auto Power Down” will display on the display and OSD

from 30 seconds before the Auto Power Down functions.

Default setting: On (Australian models), Off (North

American models)

Note

• Depending on some sources, the auto power-down function may

activate during playback.

• The Auto Power Down function does not work when Zone 2 or

Zone 3 is on.

Network

See “Network Settings” (➔73).

After changing the settings of the “HDMI Control

(RIHD)”, “Audio Return Channel”, “Power Control”,

or “TV Control”, turn off the power to all connected

pieces of equipment and then turn them on again. Refer

to the user’s manuals for all connected pieces of equip-

ment.

Firmware Update

Note

• Perform the firmware update only when an announcement is

posted on the Integra web site. See the Integra web site for latest

information.

• It takes about 30 minutes to complete the firmware update.

■Version

The current version of the firmware is displayed.

■Receiver

`via NET:

You can update the firmware via Internet. Check the

network connection before update.

`via USB:

You can update the firmware from a USB mass stor-

age device.

You can update the AV receiver’s firmware. Do not shut-

down the power of the AV receiver while update.

■Universal Port

`via NET:

You can update the firmware via Internet. Check the

network connection before update.

`via USB:

You can update the firmware from a USB mass stor-

age device.

You can update the Onkyo dock’s firmware. Do not shut-

down the power of the AV receiver while update.

Note

• This update shall not be performed when no dock is connected

to UNIVERSAL PORT jack.

With this preference, you can protect your settings by

locking the setup menus.

Main menu Lock Setup

■Setup

`Locked:

Setup menus locked.

`Unlocked:

Setup menus not locked.

When the setup menus are locked, you cannot change any

setting.

You can change various audio settings from the Home

menu (➔26).

Note

• These settings are disabled when:

– a pair of headphones is connected, or

–the “Audio TV Out” setting is set to “On” (➔62) and an

input selector other than HDMI is selected.

Tone Control Settings

You can adjust the bass and treble for the front speakers,

except when the Direct or THX listening mode is selected.

■Bass

`–10dB to 0dB to +10dB in 2 dB steps.

You can boost or cut low-frequency sounds output

by the front speakers.

■Treble

`–10dB to 0dB to +10dB in 2 dB steps.

You can boost or cut high-frequency sounds output

by the front speakers.

Operating on the AV receiver

Note

• This setting is not available when the multichannel analog input

is selected.

Speaker Levels

You can adjust the volume of each speaker while listening

to an input source.

These temporary adjustments are cancelled when the AV

receiver is set to Standby. To save the setting you made

here, go to “Level Calibration” (➔52) before setting the

AV receiver to Standby.

■Subwoofer Level

`–15.0dB to 0.0dB to +12.0dB in 1 dB steps.

■Center Level

`–12.0dB to 0.0dB to +12.0dB in 1 dB steps.

Note

• You cannot use this function while the AV receiver is muted.

• Speakers that are set to “No” or “None” in the “Speaker Config-

uration” (➔51) cannot be adjusted.

Lock Setup

Using the Audio Settings

1Press Receiver followed by Home.

2Useq/w to select “Audio”, and then use q/w/e/r

to make the desired selection.

1Press Tone on the AV receiver repeatedly to

select either “Bass” or “Treble”.

2Use –/+ to adjust the bass, treble or balance.

Audyssey Settings

■Dynamic EQ

See “Dynamic EQ” of “Source Setup” (➔56).

■Dynamic Volume

See “Dynamic Volume” of “Source Setup” (➔56).

Late Night

With the Late Night function, you can reduce the dynamic

range of Dolby Digital material so that you can still hear

quiet parts even when listening at low volume levels—

ideal for watching movies late at night when you don’t

want to disturb anyone.

■Late Night

For Dolby Digital and Dolby Digital Plus sources, the

options are:

`Off:

Late Night function off.

`Low:

Small reduction in dynamic range.

`High:

Large reduction in dynamic range.

For Dolby TrueHD sources, the options are:

`Auto:

The Late Night function is set to “On” or “Off”

automatically.

`Off:

Late Night function off.

`On:

Late Night function on.

Note

• The effect of the Late Night function depends on the material

that you are playing and the intention of the original sound

designer, and with some material there will be little or no effect

when you select the different options.

• The Late Night function can be used only when the input source

is Dolby Digital, Dolby Digital Plus, or Dolby TrueHD.

• The Late Night function is set to “Off” when the AV receiver is

set to Standby. For Dolby TrueHD sources, it will be set to

“Auto”.

Music Optimizer

The Music Optimizer function enhances the sound quality

of compressed music files. Use it with music files that use

“lossy” compression, such as MP3.

■Music Optimizer

`Off:

Music Optimizer off.

`On:

Music Optimizer on. The M.Opt indicator will light

(➔9).

Note

• The Music Optimizer function only works with PCM digital

audio input signals with a sampling rate below 48 kHz and ana-

log audio input signals. The Music Optimizer is disabled when

the Direct listening mode is selected.

• The setting is stored individually for each input selector.

Re-EQ

With the Re-EQ function, you can compensate a

soundtrack whose high-frequency content is too harsh,

making it more suitable for home theater viewing.

■Re-EQ

`Off:

Re-EQ Function off.

`On:

Re-EQ Function on.

This function can be used with the following listening

modes: Dolby Digital, Dolby Digital Plus,

Dolby TrueHD, Multichannel, DTS, DTS-HD High Reso-

lution Audio, DTS-HD Master Audio, DTS Express,

DSD, Dolby EX, Dolby Pro Logic IIz Height, Dolby

PLIIx Movie, Neo:6 Cinema and 5.1-channel source +

Neo:6.

■Re-EQ(THX)

`Off:

Re-EQ (THX) Function off.

`On:

Re-EQ (THX) Function on.

This function can be used with the following listening

modes: THX Cinema, THX Surround EX, and

THX Select2 Cinema.

Note

• Settings for the Re-EQ function are kept in each listening mode.

However, in THX listening mode, when the AV receiver is

turned off, it will return to “On”.

Audio Selector

You can set priorities of audio output when there are both

digital and analog inputs.

■Audio Selector

`ARC:

The audio signal from your TV tuner can be sent to

the HDMI OUT MAIN of the AV receiver.*1

With this selection the TV’s audio can be automati-

cally selected as a priority among other assignments.

`HDMI:

This can be selected when HDMI IN has been

assigned as an input source. If both HDMI (HDMI

IN) and digital audio inputs (COAXIAL IN or OPTI-

CAL IN) have been assigned, HDMI input is auto-

matically selected as a priority.

`COAX:

This can be selected when COAXIAL IN has been

assigned as an input source. If both coaxial and

HDMI inputs have been assigned, coaxial input is

automatically selected as a priority.

`OPT:

This can be selected when OPTICAL IN has been

assigned as an input source. If both optical and

HDMI inputs have been assigned, optical input is

automatically selected as a priority.

`Multich:

The AV receiver always outputs analog signals from

multichannel analog input.

`Analog:

The AV receiver always outputs analog signals.

Note

• The setting is stored individually for each input selector.

• This setting can be made only for the input source that is

assigned as HDMI IN, COAXIAL IN, or OPTICAL IN.

• To select the digital audio input, see “Digital Audio Input” for

more detail (➔50).

•“Multich” can be selected only when the selector is set to “BD/

DVD”.

*1 You can select “ARC” if you select the TV/CD input selector.

But you cannot select it if you’ve selected “Off” in the “Audio

Return Channel” setting (➔63).

Setting the Incoming Digital Signal (Fixed

Mode)

By pressing Enter while selecting “HDMI”, “COAX”,

“OPT” in the “Audio Selector”, you can specify the input

signal in the Fixed Mode. Pressing Enter again allows

you to return to the “Audio Selector” setting.

Normally, the AV receiver detects the signal format auto-

matically. However, if you experience either of the follow-

ing issues when playing PCM or DTS material, you can

manually set the signal format to PCM or DTS.

• If the beginnings of tracks from a PCM source are cut

off, try setting the format to PCM.

• If noise is produced when fast forwarding or reversing a

DTS CD, try setting the format to DTS.

`Auto:

The format is detected automatically. If no digital

input signal is present, the corresponding analog

input is used instead.

`PCM:

Only 2-channel PCM format input signals will be

heard. If the input signal is not PCM, the PCM indi-

cator will flash and noise may also be produced.

`DTS:

Only DTS (but not DTS-HD) format input signals

will be heard. If the input signal is not DTS, the DTS

indicator will flash and there will be no sound.

Note

• The setting is stored individually for each input selector.

• The setting will be reset to “Auto” when you change the setting

in the “Audio Selector” (➔66).

NET/USB

The AV receiver is network-ready, which means you can

hook it up to your home network with a standard Ethernet

cable and enjoy the music files stored on your computer or

media server. If your network is connected to the Internet,

you can also enjoy Internet radio.

Network Requirements

■Ethernet Network

For best results, a 100Base-TX switched Ethernet network

is recommended. Although it’s possible to play music on a

computer that’s connected to the network wirelessly, play-

back may be unreliable, so wired connections are recom-

mended.

■Ethernet Router

A router manages the network, routing data and supplying

IP addresses. Your router must support the following:

• NAT (Network Address Translation). NAT allows sev-

eral networked computers to access the Internet simulta-

neously via a single Internet connection. The AV

receiver needs Internet access for Internet radio.

• DHCP (Dynamic Host Configuration Protocol). DHCP

supplies IP addresses to network devices, allowing them

to configure themselves automatically.

• A router with a 100Base-TX switch built-in is recom-

mended.

Some routers have a modem built-in, and some ISPs

require you to use specific routers. Please consult your ISP

or computer dealer if you’re unsure.

■CAT5 Ethernet cable

Use a shielded CAT5 Ethernet cable (straight-type) to con-

nect the AV receiver to your home network.

■Internet Access (for Internet radio)

To receive Internet radio, your Ethernet network must

have Internet access. A narrowband Internet connection

(e.g., 56K modem, ISDN) will not provide satisfactory

results, so a broadband connection is strongly recom-

mended (e.g., cable modem, xDSL modem, etc). Please

consult your ISP or computer dealer if you’re unsure.

Note

• To receive Internet radio with the AV receiver, your broadband

Internet connection must be working and able to access the Web.

Consult your ISP if you have any problems with your Internet

connection.

• The AV receiver uses DHCP to configure its network settings

automatically. If you want to configure these settings manually,

see “Network Settings” (➔73).

• The AV receiver does not support PPPoE settings, so if you have

a PPPoE-type Internet connection, you must use a PPPoE-com-

patible router.

• Depending on your ISP, you may need to specify a proxy server

to use Internet radio. If your computer is configured to use a

proxy server, use the same settings for the AV receiver (➔73).

To connect the AV receiver to your home network, plug

one end of a shielded CAT5 Ethernet cable into the AV

receiver’s ETHERNET port, and plug the other end into a

LAN port on your router or switch.

The following diagram shows how you can connect the

AV receiver to your home network. In this example, it’s

connected to a LAN port on a router, which has a 4-port

100Base-TX switch built-in.

About NET Connecting the AV Receiver

Internet radio

Modem

Router

Computer or media server

LAN/Ethernet port

WAN port

LAN port

To receive Internet radio, you must connect the AV

receiver to a network with Internet access (➔67).

You can select Internet radio stations by connecting to the

AV receiver from your computer and selecting stations in

your Web browser. Preset up to 40 Internet radio stations.

Internet radio URLs in the following formats are sup-

ported: PLS, M3U, and podcast (RSS). However, depend-

ing on the type of data or audio format used by the Internet

radio station, you may not be able to listen to some sta-

tions.

Note

• If you’re using a narrowband Internet connection (e.g., 56K

modem or ISDN), depending on the station, Internet radio may

not work satisfactorily. For best results, use a broadband connec-

tion (e.g., cable modem, xDSL modem, etc).

Listening to vTuner Internet Radio

This unit includes the full vTuner Internet Radio Service

at no additional charge. Once you have connected your

unit to the Internet you can select vTuner Internet Radio to

search for and play Internet radio stations and podcasts at

any time. To enhance your Internet radio experience, the

http://onkyo.vtuner.com/ portal is available to you as an

easy way to browse to find stations, set up/organize your

favorites, add your own stations, get help, etc. After the

first time you try Internet radio/vTuner on your unit you

can use the MAC Address of your unit to create a member

onkyo.vtuner.com/ portal. To verify your MAC Address,

please see “Network Settings” (➔73).

Listening to Internet Radio

Display

NET/USB

Top Menu

Enter

q/w/e/r

1Press NET/USB repeatedly to select the Internet

Radio screen.

The NETWORK indicator lights (➔9).

Note

• When the NETWORK indicator flashes, confirm that the

Ethernet cable is firmly connected to the AV receiver.

• Services available may vary depending on the region. See

the separate instructions for more information.

*1 MENU:

When menu operations are enabled, “MENU” appears.

Press Menu to display the menu.

TOP MENU:

Press Top Menu to go to the top menu of the Internet

Radio services.

2Use q/w to select “vTuner Internet Radio”, and

then press Enter.

3Use q/w to select a program, and then press

Enter.

Playback starts and the following screen appears.

*2 Press Menu to allow selection from the following menu

items.

`Stations like this:

Stations like the one currently being played

back are displayed.

Tip

• If you press Display, you can toggle between the play-

back screen and the list screen.

Internet Radio

1. vTuner Internet Radio

2. Pandora Internet Radio

3. Rhapsody

4. SIRIUS Internet Radio

5. Slacker Internet Radio

6. Mediafly Internet Radio

7. Napster Internet Radio

8. ---

9. ---

10. ---

Go to Menu

0:00:00

WMA 128kbps 16bit/44.1kHz

1. fm indie 104

The internet’s best source for i

- - -

All Stations

Go to Menu

Listening to Other Internet Radio

To listen to other internet radio stations, insert the follow-

ing step after step 1 in the “Listening to vTuner Internet

Radio”.

Registering Presets*1

Once you’ve added a station to the list, simply select it on

the Internet Radio screen, and then press Enter to start

playback.

*1 From the search results you can preset the stations and songs

but cannot listen to them directly.

■Items on the Internet Radio Top Menu

`Create new preset:

Add a favorite station or Internet Radio to the pre-

sets.

`Rename this preset:

You can rename the preset.

`Delete this preset:

This will delete the preset.

■Station and Song Presets

You can add the currently playing song or station to the

presets.

1. Press Menu with the station selected or while a song

is playing.

2. Use q/w to select “Add this station to preset”, and

press Enter.

This section explains how to play music files on a com-

puter or media server through the AV receiver. See “Sup-

ported Audio File Formats” to “About DLNA” for details

on supported music servers and music file formats.

For Windows Media® Player 11, see “Windows Media®

Player 11 Setup” (➔70).

1On your computer, start your Web browser and

enter the AV receiver’s IP address in the browser’s

Internet address (URL) field.

The browser connects to the AV receiver (WEB

Setup Menu).

Note

• The AV receiver’s IP address is shown on the “Network”

screen (➔73).

• If you’re using DHCP, your router may not always allocate

the same IP address to the AV receiver, so if you find that

you can’t connect to the AV receiver, recheck the AV

receiver’s IP address on the “Network” screen.

2Click on the “Preset Internet Radio” tab.

Set the username and password in the “Custom Set-

ting”.

3Enter the preset name and Internet address

(URL).

4Click “Save” to save the Internet radio station.

Unit Information

WEB Setup Menu

Preset Internet Radio

Save Refresh

1 Internet Radio Information 2

Network setting

Delete

Name

Tuner Internet Radio

URL

Playing Music Files on a Server

1Start your computer or media server.

2Press NET/USB to select the “Server” screen.

The NETWORK indicator lights (➔9).

Note

•When the NETWORK indicator flashes, confirm the net-

work connection.

• To update the screen, press Return.

Display

NET/USB

Enter

q/w/e/r

Return

1, 3, 2, 5,

4, 7, 6

Repeat

Random

1 / 10

Server

Server1

Server2

Server3

Server4

Server5

Server6

Server7

Server8

Server9

Server10

Random Playback

The Random function can only be set while the PLAY

screen is displayed.

To play songs in random order, during playback (or while

playback is paused or stopped), press Random. All of the

songs in the current folder will be played in random order.

When all of the songs in the folder have been played once,

they’ll all be played again in a different random order. To

cancel random playback, press Random again.

Random playback supports up to 20000 songs per folder.

If a folder contains more than this, songs over 20000 are

not included in random playback.

Repeat Playback

The Repeat function can only be set while the PLAY

screen is displayed.

To play songs repeatedly, during playback (or while play-

back is paused or stopped), press Repeat repeatedly to

select: Repeat1, Repeat Folder, Repeat All, or Off.

In Repeat1 mode, the current song is played repeatedly.

In Repeat Folder mode, all of the songs in the current

folder are played repeatedly.

In Repeat All mode, all of the songs on the current server

are played repeatedly.

To cancel repeat playback, press Repeat repeatedly to

select Off.

Note

• If the message “No Item.” appears, this means that no informa-

tion can be retrieved from the server. In this case, check your

server, network, and AV receiver connections.

Windows Media® Player 11 Setup

This section explains how to configure Windows Media

Player 11 so that the AV receiver can play the music files

stored on your computer.

Note

• Windows Media Player 11 can be downloaded for free from the

Microsoft Web site.

3Use q/w to select a server, and then press Enter.

A list of items on the server appears.

You can search for music by Artist, Album, or Track.

Note

• The search function does not work with media servers

which do not support this function.

• Depending on the sharing settings in the media server, the

AV receiver may not able to access the content. Refer to

the instruction manual of the media server.

4Use q/w to select an item, and then press Enter.

A list of music files appears.

5Use q/w to select a music file, and press Enter or

1 to start playback.

Playback starts and the following screen appears.

To return to the previous menu during playback,

press Return.

To stop playback, press 2.

To select the next song, press 6. To select the

beginning of the current song, press 7. To select

the previous song, press 7 twice.

To pause playback, press 3. To fast forward the cur-

rent song, press 4. To fast reverse the current

song, press 5.

Tip

• If you press Display, you can toggle between the play-

back screen and the list screen.

Note

• For some sort of media server, Fast Forward/Fast Reverse/

Pause operations do not work.

1 / 8

Recently Added

Artists

Album

Songs

Genre

Year

Rating

Server1

All Music

Song 1

1 / 10

Song 2

Song 3

My favorite song 1

My favorite song 2

My favorite song 3

My favorite song 4

My favorite song 5

My favorite song 6

My favorite song 7

My favorite song 1

Artist name

My favorite album

4 / 10

MP3 128kbps 44.1kHz

0:00:00

ALL

1Start Windows Media Player 11.

2On the Library menu, select Media Sharing.

The Media Sharing dialog box appears.

3Select the Share my media check box, and then

click OK.

4Select the AV receiver in the list, and then click

Allow.

5Click OK to close the dialog box.

This completes the Windows Media Player 11 con-

figuration.

You can now play the music files in your Windows

Media Player 11 library through the AV receiver

(➔69).

Supported Audio File Formats

For server playback, the AV receiver supports the follow-

ing music file formats: MP3, WMA, WAV, FLAC, Ogg

Vorbis, AAC and LPCM. Not all servers support all for-

mats.

■MP3

• MP3 files must be MPEG-1/MPEG-2 Audio Layer 3 for-

mat with a sampling rate of 8 kHz, 11.025 kHz, 12 kHz,

16 kHz, 22.05 kHz, 24 kHz, 32 kHz, 44.1 kHz, 48 kHz

and a bit-rate of between 8 kbps and 320 kbps. Incom-

patible files cannot be played.

• Number of channels: 2

• Variable bit-rate (VBR) MP3 files are supported. (Play-

ing times may not display correctly.)

• MP3 files must have a “.mp3” or “.MP3” filename

extension.

■WMA

WMA stands for Windows Media Audio and is an audio

compression technology developed by Microsoft Corpora-

tion. Audio can be encoded in WMA format by using

Windows Media® Player.

• WMA files must have the copyright option turned off.

• Sampling rates of 8 kHz, 11.025 kHz, 12 kHz, 16 kHz,

22.05 kHz, 24 kHz, 32 kHz, 44.1 kHz, 48 kHz and

bitrates of between 5 kbps and 320 kbps, and WMA

DRM are supported. Incompatible files cannot be

played.

• Number of channels: 2

• Variable bit-rates (VBR) are supported. (Playing times

may display incorrectly with VBR.)

• WMA Pro/Voice formats are not supported.

• WMA files must have a “.wma” or “.WMA” filename

extension.

■WMA Lossless

• Sampling rates of 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz

and bitrates of between 5 kbps and 320 kbps are sup-

ported. Incompatible files cannot be played.

• Quantization bit: 16 bit, 24 bit

• Number of channels: 2

• Variable bit-rates (VBR) are supported. (Playing times

may display incorrectly with VBR.)

• WMA files must have a “.wma” or “.WMA” filename

extension.

■WAV

WAV files contain uncompressed PCM digital audio.

• Sampling rates of 8 kHz, 11.025 kHz, 12 kHz, 16 kHz,

22.05 kHz, 24 kHz, 32 kHz, 44.1 kHz, 48 kHz, 64 kHz,

88.2 kHz, and 96 kHz are supported. Incompatible files

cannot be played.

• Quantization bit: 8 bit, 16 bit, 24 bit

• Number of channels: 2

• WAV files must have a “.wav” or “.WAV” filename

extension.

■AAC

AAC stands for MPEG-2/MPEG-4 Audio.

• Sampling rates of 8 kHz, 11.025 kHz, 12 kHz, 16 kHz,

22.05 kHz, 24 kHz, 32 kHz, 44.1 kHz, 48 kHz, 64 kHz,

88.2 kHz, 96 kHz and bitrates of between 8 and

320 kbps, are supported. Incompatible files cannot be

played.

• Number of channels: 2

• Variable bit-rate (VBR) files are supported. (Playing

times may not display correctly.)

• AAC files must have a “.aac”, “.m4a”, “.mp4”, “.3gp”,

“.3g2”, “.AAC”, “.M4A”, “.MP4”, “.3GP” or “.3G2”

filename extension.

■FLAC

FLAC is a file format for lossless audio data compression.

• Sampling rates of 8 kHz, 11.025 kHz, 12 kHz, 16 kHz,

22.05 kHz, 24 kHz, 32 kHz, 44.1 kHz, 48 kHz, 64 kHz,

88.2 kHz, and 96 kHz are supported. Incompatible files

cannot be played.

• Quantization bit: 8 bit, 16 bit, 24 bit

• Number of channels: 2

• Variable bit-rates (VBR) are supported. (Playing times

may display incorrectly with VBR.)

• FLAC files must have a “.flac” or “.FLAC” filename

extension.

Note

• Not all servers support all formats.

■Ogg Vorbis

• Sampling rates of 8 kHz, 11.025 kHz, 12 kHz, 16 kHz,

22.05 kHz, 24 kHz, 32 kHz, 44.1 kHz, 48 kHz and

bitrates of between 48 kbps and 500 kbps are supported.

Incompatible files cannot be played.

• Number of channels: 2

• Variable bit-rates (VBR) are supported. (Playing times

may display incorrectly with VBR.)

• Ogg Vorbis files must have a “.ogg” or “.OGG” file-

name extension.

■LPCM (Linear PCM)

• Sampling rates of 8 kHz, 11.025 kHz, 12 kHz, 16 kHz,

22.05 kHz, 24 kHz, 32 kHz, 44.1 kHz, 48 kHz, 64 kHz,

88.2 kHz, and 96 kHz are supported.

• Quantization bit: 8 bit, 16 bit, 24 bit

• Number of channels: 2

Server Requirements

The AV receiver can play digital music files stored on a

computer or media server and supports the following tech-

nologies:

• Windows Media® Player 11

• Windows Media Connect 2.0

• DLNA-certified media server

If the operating system of your computer is Windows

Vista, Windows Media Player 11 is already installed.

Windows Media Player 11 for Windows XP can be down-

loaded for free from the Microsoft Web site.

• The computer or media server must be on the same net-

work as the AV receiver.

• Each folder may contain up to 20000 music files, and

folders may be nested up to 16 levels deep.

Note

• For some sort of media server, the AV receiver may not able to

recognize it, or may not able to play stored music files.

About DLNA

The Digital Living Network Alliance is an international,

cross-industry collaboration. Members of DLNA develop

a concept of wired and wireless interoperable networks

where digital content such as photos, music, and videos

can be shared through consumer electronics, personal

computers, and mobile devices in and beyond the home.

The AV receiver certificate the DLNA Interoperability

Guidelines version 1.5.

Remote Playback means you can play the music files

stored on the DLNA-certified device such as media server

with this product by operating the controller device in the

home network.

Server Requirements

• Windows Media Player 12

• DLNA-certified (the DLNA Interoperability Guidelines

version 1.5) media server or controller device

Setting varies depending on the device. Refer to your

device’s instruction manual for details.

If the operating system of your personal computer is Win-

dows 7, Windows Media Player 12 is already installed.

For more information, see the Microsoft Web site.

Supported Music File Formats

See “Supported Audio File Formats” (➔71).

Note

• For remote playback, this product does not support the following

music file formats: FLAC and Ogg Vorbis.

Windows Media Player 12 Setup

This section explains how to configure Windows Media

Player 12 so that the product can play the music files

stored on your personal computer.

Minimum system requirements for Windows Media

Player 11 for Windows XP

Operating system

Windows XP Home Edition (SP2), Windows XP Profes-

sional (SP2), Windows XP Tablet PC Edition (SP2),

Update Rollup 2 for Windows XP Media Center Edition

2005 (KB900325), October 2006 Update Rollup for

Windows XP Media Center Edition (KB925766)

Processor: 233 MHz Intel Pentium II, Advanced

Micro Devices (AMD), etc.

Memory: 64 MB

Hard disk: 200 MB of free space

Drive: CD or DVD drive

Modem: 28.8 kbps

Sound card: 16-bit sound card

Monitor: Super VGA (800 x 600)

Video card: 64 MB VRAM, DirectX 9.0b

Software: Microsoft ActiveSync (only when

using a Windows Mobile-based Pocket

PC or smartphone)

Web browser: Microsoft Internet Explorer 6 or

Netscape 7.1

Remote Playback from Media Server/

Personal Computer

1Start Windows Media Player 12.

2On the “Stream” menu, select “Turn on media

streaming”.

A dialog box appears.

3Move your cursor and click on “Turn on media

streaming”.

A list of media server appears. Wording may vary

slightly depending on the network location.

4Select the product in the list, and then click

“Allowed”.

5Click “OK” to close the dialog box.

This completes the Windows Media Player 12 con-

figuration.

You can now play the music files in your Windows

Media Player 12 library through the product.

Using Remote Playback

Note

• When modifying network settings, after modifying it is neces-

sary to execute “Save”.

This section explains how to configure the AV receiver’s

network settings manually.

If your router’s DHCP server is enabled, you don’t need to

change any of these settings, as the AV receiver is set use

DHCP to configure itself automatically by default (i.e.,

DHCP is set to Enable). If, however, your router’s DHCP

server is disabled, for example, you’re using static IP

addresses, you’ll need to configure these settings yourself,

in which case, a knowledge of Ethernet networking is

essential.

What’s DHCP?

DHCP (Dynamic Host Configuration Protocol) is used by

routers, computers, the AV receiver, and other devices to

automatically configure themselves on a network.

What’s DNS?

The DNS (Domain Name System) translates domain

names into IP addresses. For example, when you enter a

domain name such as www.onkyousa.com in your Web

browser, before accessing the site, your browser uses DNS

to translate this into an IP address, in this case

63.148.251.142.

1Start Windows Media® Player 12.

Before remote playback, setup on Windows Media

Player 12 is required.

2On the product, press NET/USB to select the

server screen.

A list of media server appears.

Tip

•The NETWORK indicator on the product’s display lights

up. When it flashes, confirm the network connection.

Note

• While the music files on another media server are being

played, remote playback cannot be used. Stop playback on

another media server.

3On Windows Media Player 12, right-click on

music file.

Right-click menu appears. For selecting another

media server, select media server from “Other

Libraries” menu on Windows Media Player 12.

4Select the product from right-click menu.

“Play to” window appears and playback on the prod-

uct starts. Operations during remote playback can be

made from “Play to” window of Windows 7 on your

personal computer. During remote playback, opera-

tions (such as Playback, Pause, Fast Forward, Fast

Rewind, Previous, Next, Repeat, Random) cannot be

made on the product.

Tip

• To stop playback and return to the previous menu during

remote playback, press Return on the product or remote

controller. To stop playback during remote playback, press

Stop [2] on the remote controller.

Remote Playback

My favorite song 1

Artist name

My favorite album

MP3 128kbps 44.1kHz

1:00:00

5Adjusting the Volume.

You can adjust the volume of your AV receiver by

adjusting the volume bar in the “Remote Playback”

window. The default maximum volume for the AV

receiver is 82 (0dB). If you wish to change this, enter

the maximum volume value from the Web Setup

Menu in your browser. See “Listening to Other Inter-

net Radio” for WEB Setup Menu information

(➔69)

The volume value of the remote window and the vol-

ume value of the AV receiver may not always match.

Adjustments you make to the volume in the AV

receiver will not be reflected in the “Remote Play-

back” window.

Network Settings

Unit Information

WEB Setup Menu

Preset Internet Radio

Save Refresh

Network setting

Machine Name XXXXXXXX

Friendly Name XXXXXXXX

MAC Address xx : xx : xx − yy : yy : yy

DMR Max Volume 82

(0-100)

Auto Play Yes

Product info

Note

• This procedure can also be performed on the AV receiver by

using its Setup, arrows, and Enter.

■Mac Address

This is the AV receiver’s MAC (Media Access Control)

address. This address cannot be changed.

■DHCP

This setting determines whether or not the AV receiver

uses DHCP to automatically configure its IP Address,

Subnet Mask, Gateway, and DNS Server settings.

`Enable:

DHCP enabled.

`Disable:

DHCP disabled.

If you select “Disable”, you must configure the “IP

Address”, “Subnet Mask”, “Gateway”, and “DNS

Server” settings yourself.

■IP Address

If you set the “DHCP” setting to “Disable”, you must

specify an IP address. Enter a static IP address provided

by your ISP.

The IP address must be within the following ranges.

`Class A:

10.0.0.0 to 10.255.255.255

`Class B:

172.16.0.0 to 172.31.255.255

`Class C:

192.168.0.0 to 192.168.255.255

Most routers use Class C IP addresses.

■Subnet Mask

If you set the “DHCP” setting to “Disable”, you must

specify a subnet mask address.

Enter the subnet mask address provided by your ISP (typi-

cally: 255.255.255.0).

■Gateway

If you set the “DHCP” setting to “Disable”, you must

specify a gateway address.

Enter the gateway address provided by your ISP.

■DNS Server

If you set the “DHCP” setting to “Disable”, you must

specify a DNS server.

Enter the DNS server addresses provided by your ISP.

■Proxy URL

To use a Web proxy, enter its URL here.

■Proxy Port

If you’re using a Web proxy, enter a proxy port number

here.

■Control

This setting enables or disables control over the network.

`Enable:

Control over the network enabled.

`Disable:

Control over the network disabled.

Note

• When set to “Enable”, power consumption on standby mode

increases.

■Port Number

This is the network port used for control over the network.

Note

• Set the port number between from “49152” to “65535”.

1Press Receiver, followed by Setup.

The main menu appears onscreen.

If the main menu doesn’t appear, make sure the

appropriate external input is selected on your TV.

2Use q/w to select “Hardware Setup”, and then

press Enter.

The “Hardware Setup” menu appears.

3Use q/w to select “Network”, and then press

Enter.

The “Network” screen appears.

4Use q/w to select the setting, and use e/r to set

them.

To enter an IP address, select the setting, and then

press Enter. The arrow can then be used to enter

numbers. Press Enter again to set the number.

The settings are explained below.

5When you’ve finished, press Return.

The save confirmation screen appears.

6Use q/w to select “Save”, and then press Enter.

When modifying network settings, after modifying it

is necessary to execute “Save”.

7When you’ve finished, press Setup.

The setup menu closes.

7. Hardware Setup

1. Remote ID

2. Multi Zone

3. Tuner

4. HDMI

5. Auto Power Down

6. Network

7. Firmware Update

7-6. Network

MAC Address

DHCP

IP Address

Subnet Mask

Gateway

DNS Server

Proxy URL

Proxy Port

xx : xx : xx − yy : yy : yy

Enable

aaa.bbb.ccc.ddd

8080

Save

Cancel

7-6. Network

USB can be used to play music files stored on USB mass

storage devices (e.g., USB flash drives and MP3 players),

which can be plugged into the AV receiver’s USB port.

Supported Audio File Formats

For USB mass storage device playback, the AV receiver

supports music file formats.

See “Supported Audio File Formats” (➔71).

USB Mass Storage Device Requirements

• The AV receiver supports USB devices that support the

USB mass storage device class.

• Playback may not be possible with some USB devices

even if they conform to the USB mass storage device

class.

• USB devices formatted with the FAT16 or FAT32 file

system are supported.

• If the storage device has been partitioned, each section

will be treated as an independent device.

• Each folder may contain up to 20000 music files and

folders, and folders may be nested up to 16 levels deep.

• USB hubs and USB devices with hub functions are not

supported.

Playing Music Files on a USB Device

This section explains how to play music files on a USB

mass storage device.

About USB

Display

NET/USB

Enter

q/w/e/r

Return

1, 3, 2, 5,

4, 7, 6

Repeat

Random

1Plug your USB mass storage device into the AV

receiver’s USB port.

2Press NET/USB repeatedly to select the “USB”

input.

The USB indicator lights (➔9) if the AV receiver is

able to read the USB mass storage device. The USB

indicator flashes if the AV receiver cannot read the

USB mass storage device.

3Use q/w to select a USB mass storage device, and

then press Enter.

A list of the device’s contents appears.

To open a folder, use q/w to select it, and then press

Enter.

4Use q/w to select a music file, and press Enter or

1 to start playback.

Playback starts and the following screen appears.

To return to the previous menu during playback,

press Return.

To stop or pause playback, press 2 or 3, respec-

tively.

To select the next song, press 6. To select the

beginning of the current song, press 7. To select

the previous song, press 7 twice.

To fast forward the current song, press 4. To fast

reverse the current song, press 5.

Tip

• If you press Display, you can toggle between the play-

back screen and the list screen.

USB

USB Storage

1 / 1

USB Storage

Folder1

Folder2

01_Song_Track1

02_Song_Track2

03_Song_Track3

04_Song_Track4

05_Song_Track5

06_Song_Track6

07_Song_Track7

08_Song_Track8

1 / 10

00:10

01:12:34

Folder1

Album

Artist

02_Song_Track2

MP3 128kbps 16bit/44.1kHz

1/17

Random Playback

The Random function can only be set while the PLAY

screen is displayed.

To play songs in random order, while the list of songs is

displayed, press Random. All of the songs in the current

folder will be played in random order. When all of the

songs in the folder have been played once, they’ll all be

played again in a different random order. To cancel ran-

dom playback, press Random again.

Random playback supports up to 20,000 songs per folder.

If a folder contains more than this, songs over 20,000 are

not included in random playback.

Repeat Playback

The Repeat function can only be set while the PLAY

screen is displayed.

To play songs repeatedly, during playback (or while play-

back is paused or stopped), press Repeat repeatedly to

select: Repeat1, Repeat Folder, Repeat All, or Off.

In Repeat1 mode, the current song is played repeatedly.

In Repeat Folder mode, all of the songs in the current

folder are played repeatedly.

In Repeat All mode, all of the songs on the USB mass

storage device (in the same partition) are played repeat-

edly.

To cancel repeat playback, press Repeat repeatedly to

select Off.

Note

• If you connect a USB hard disk drive to the AV receiver’s USB

port, we recommend that you use its AC adapter to power it.

• Do not connect the AV receiver’s USB port to a USB port on

your computer. Music on your computer cannot be played

through the AV receiver in this way.

• The AV receiver supports USB MP3 players that support the

USB Mass Storage Class standard, which allows USB storage

devices to be connected to computers without the need for spe-

cial drivers or software. Note that not all USB MP3 players sup-

port the USB Mass Storage Class standard. Refer your USB

MP3 player’s instruction manual for details.

• Protected WMA music files on an MP3 player cannot be played.

• Onkyo accepts no responsibility whatsoever for the loss or dam-

age to data stored on a USB mass storage device when that

device is used with the AV receiver. We recommend that you

back up your important music files beforehand.

• MP3 players containing music files that are managed with spe-

cial music software, and the iPod containing music files man-

aged with iTunes are not supported.

• Operation with all USB mass storage devices including the abil-

ity to power them is not guaranteed.

• Do not connect your USB mass storage device via a USB hub.

The USB mass storage device must be connected directly to the

AV receiver’s USB port.

• If the USB mass storage device contains a lot of data, the AV

receiver make take a while to read it.

• USB memory devices with security functions cannot be played.

Multi Zone

In addition to your main listening room, you can also enjoy playback in the other room, or as we call Multi Zone. And,

you can select a different source for each room.

There are two ways you can connect Zone 2 speakers:

1. Connect them directly to the AV receiver.

2. Connect them to an amp in Zone 2.

Connecting Your Zone 2 Speakers Directly

to the AV receiver

This setup allows 5.1-channel playback in your main room

and 2-channel stereo playback in Zone 2, with a different

source in each room. This is called Powered Zone 2, as the

Zone 2 speakers are powered by the AV receiver. Note that

when Powered Zone 2 is turned off, you can enjoy 7.1-

channel playback in your main room.

Note

• With this setup, the Zone 2 volume is controlled by the AV

receiver.

• Powered Zone 2 cannot be used if “Speakers Type(Front)” is

set to “Bi-Amp” (➔51).

Connecting Your Zone 2 Speakers to an

Amp in Zone 2

This setup allows 7.1-channel playback in your main lis-

tening room and 2-channel stereo playback in Zone 2,

with a different source in each room.

Note

• With the default settings, the Zone 2 volume must be set on the

Zone 2 amp. If your Zone 2 amp has no volume control, set the

“Zone 2 Out” setting to “Variable” so that you can set the

Zone 2 volume on the AV receiver (➔79).

Connecting Zone 2

To use this setup, you must set the “Powered Zone 2”

setting to “Act” (➔79).

Hookup

• Connect your Zone 2 speakers to the AV receiver’s FRONT

WIDE/ZONE 2 L/R terminals.

R L

Main room

Zone 2

AV receiver

Hookup

• Use an RCA audio cable to connect the AV receiver’s ZONE

2 PRE OUT L/R jacks to an analog audio input on your Zone

2 amp.

• Connect your Zone 2 speakers to the speaker terminals on

your Zone 2 amp.

R L

Main room

Zone 2

AV receiver

Receiver/

integrated amp

Zone 2 Video Output

The AV receiver features a composite video output for con-

nection to a TV in Zone 2, so you can enjoy both audio and

video in that zone.

Note

• If you use the COMPONENT VIDEO ZONE 2 OUT, you

must set the “Zone 2 Component Out” setting to “Use” (➔80).

•The COMPONENT VIDEO ZONE 2 OUT outputs video only

from components connected to component video inputs.

•The ZONE 2 OUT V jack outputs video from components con-

nected to composite video inputs.

Connecting Your Zone 3 Speakers to an

Amp in Zone 3

This setup allows 7.1-channel playback in your main lis-

tening room and 2-channel stereo playback in Zone 3,

with a different source in each room.

Note

• With the default settings, the Zone 3 volume must be set on the

Zone 3 amp. If your Zone 3 amp has no volume control, set the

“Zone 3 Out” setting to “Variab le ” so that you can set the

Zone 3 volume on the AV receiver (➔79).

Hookup

• Use a composite video cable to connect the AV receiver’s

ZONE 2 OUT V jack to a composite video input on your

Zone 2 TV.

• Alternatively, use a component video cable to connect the AV

receiver’s COMPONENT VIDEO ZONE 2 OUT jacks to a

component video input on your Zone 2 TV.

Main room

Zone 2

AV receiver

Connecting Zone 3

Hookup

• Use an RCA audio cable to connect the AV receiver’s

ZONE 3 PRE OUT L/R jacks to an analog audio input on

your Zone 3 amp.

• Connect your Zone 3 speakers to the speaker terminals on

your Zone 3 amp.

Main room

Zone 3

AV receiver

Receiver/

integrated amp

If you’ve connected your Zone 2 speakers to the AV

receiver, as explained in “Connecting Your Zone 2 Speak-

ers Directly to the AV receiver” (➔77), you must set the

“Powered Zone 2” setting to “Act” (Activated).

Note

• Powered Zone 2 cannot be used if “Speakers Type(Front)” is

set to “Bi-Amp” (➔51).

• This procedure can also be performed on the AV receiver by

using Setup, arrows, and Enter.

Note

• This procedure can also be performed on the AV receiver by

using Setup, arrows, and Enter.

■Zone 2 Out, Zone 3 Out

`Fixed:

The Zone 2/3 volume must be set on the amp in that

zone.

`Variable:

The Zone 2/3 volume can be set on the AV receiver.

If you’ve connected your Zone 2/3 speakers to an amp

with no volume control, set the “Zone 2 Out” and“Zone 3

Out” setting, respectively, to “Variable” so that you can

set the volume, balance, and tone of Zone 2 and volume of

Zone 3 on the AV receiver.

■Zone 2 Maximum Volume,

Zone 3 Maximum Volume

`Off, 50 to 99 (Absolute display)

`Off, –32dB to +17dB (Relative display)

With this setting, you can limit the maximum volume for

Zone 2/3.

Setting the Powered Zone 2

1Press Receiver followed by Setup.

The main menu appears onscreen.

Tip

• If the main menu doesn’t appear, make sure the appropri-

ate external input is selected on your TV.

2Use q/w to select “Speaker Setup”, and then press

Enter.

The “Speaker Setup” menu appears.

3Use q/w to select “Speaker Settings”, and then

press Enter.

The “Speaker Settings” menu appears.

4Use q/w to select “Powered Zone 2”, and use e/r

to select:

`Not Act:

Use FRONT WIDE/ZONE 2 L/R terminals to

connect front wide speakers. (Powered Zone 2

disabled.)

`Act:

Use FRONT WIDE/ZONE 2 L/R terminals to

connect Zone 2 speakers. (Powered Zone 2

enabled.)

5Press Setup.

The setup menu closes.

2. Speaker Setup

1. Speaker Settings

2. Speaker Configuration

3. Speaker Distance

4. Level Calibration

5. Equalizer Settings

6. THX Audio Setup

2–1. Speaker Settings

Speaker Impedance

Speakers Type(Front)

Powered Zone 2

6ohms

Normal

Not Act

Setting the Multi Zone

1Press Receiver followed by Setup.

The main menu appears onscreen.

Tip

• If the main menu doesn’t appear, make sure the appropri-

ate external input is selected on your TV.

2Use q/w to select “Hardware Setup”, and then

press Enter.

The “Hardware Setup” menu appears.

3Use q/w to select “Multi Zone”, and then press

Enter.

The “Multi Zone” menu appears.

4Use q/w to select an item, and use e/r to change

it.

The items are explained below.

5Press Setup.

The setup menu closes.

7. Hardware Setup

1. Remote ID

2. Multi Zone

3. Tuner

4. HDMI

5. Auto Power Down

6. Network

7. Firmware Update

7-2. Multi Zone

Zone 2 Out

Zone 2 Maximum Volume

Zone 2 Power On Volume

Zone 2 Component Out

Zone 3 Out

Zone 3 Maximum Volume

Zone 3 Power On Volume

Fixed

Off

Last

Use

Fixed

Off

Last

■Zone 2 Power On Volume,

Zone 3 Power On Volume

`Last, Min, 1 to 99 or Max (Absolute display)

`Last, –QdB, –81dB to +18dB (Relative display)

This setting determines what the volume will be for

Zone 2/3 each time the AV receiver is turned on.

To use the same volume level as when the AV receiver was

last turned off, select “Last”.

The “Zone 2 Power On Volume” and “Zone 3 Power On

Volum e ” cannot be set higher than the “Zone 2 Maxi-

mum Volume” and “Zone 3 Maximum Volume” setting.

■Zone 2 Component Out

`Use:

Select if a TV in Zone 2 is connected the COMPO-

NENT VIDEO ZONE 2 OUT.

`Not Use:

Select if no TV in Zone 2 is connected the COMPO-

NENT VIDEO ZONE 2 OUT.

If you’ve connected the COMPONENT VIDEO ZONE 2

OUT to a TV in Zone 2, this setting is set to “Use”.

Note

•If the “Zone 2 Component Out” setting is set to “Not Use”, the

same video signal as COMPONENT VIDEO MONITOR OUT

is output from ZONE 2 OUT (component).

This section explains how to turn Zone 2/3 on and off,

how to select an input source for Zone 2/3, and how to

adjust the volume for Zone 2/3.

Controlling Zone 2/3 from the AV receiver

Note

• When Zone 2 is turned off, the output from the 12V TRIGGER

OUT goes low (0 volts).

Using Zone 2/3

1To turn on Zone 2/3 and select an input source,

press Zone 2 or Zone 3 followed by an input

selector button within 8 seconds.

Zone 2/3 turns on, the Zone 2/3 indicator lights.

Tip

•12V TRIGGER OUT goes high (+12 V).

To select AM or FM, press Tuner input selector and

Zone 2 or Zone 3 repeatedly.

(North American models) You can also select SIR-

IUS.

To select the same source as that of the main room,

press Zone 2 or Zone 3 twice. “Zone 2 Selector:

Source” or “Zone 3 Selector: Source” appears on

the display.

2To turn off Zone 2/3, press Off.

The zone is turned off, and the Zone 2 or Zone 3

indicator goes off.

Zone 3 indicator

Input selector buttons

Zone 2

Off

Zone 2 indicator

Zone 3

Off

Controlling Zone 2/3 with the Remote

Controller

Note

• To control Zone 2/3, you must press the remote controller’s

Zone first.

•Zone turns red while Zone 2 is on, and green while Zone 3 is on.

Note

• Only analog input sources are output by the ZONE 2/3 PRE

OUT and FRONT WIDE/ZONE 2 L/R terminals. Digital input

sources are not output. If no sound is heard when an input source

is selected, check if it’s connected to an analog input.

• You cannot select different AM or FM radio stations for your

main room and Zone 2/3. The same AM/FM radio station will be

heard in each room. For example, if you have an FM station for

the main room, that station will also be used in Zone 2.

• When you connect Zone 2 speakers directly to the AV receiver,

listening modes that require surround back speakers or front high

speakers or front wide speakers (6.1/7.1), such as Dolby Digital

EX, DTS-ES, THX Select2 Cinema, Dolby Pro Logic IIz

Height, and Audyssey DSX™ are unavailable.

• When the input selector of Zone 2/3 is selected, power consump-

tion on standby mode slightly increases.

• While Zone 2/3 is on, u functions will not work.

Adjusting the Volume for Zones

Muting Zones

Adjusting the Tone and Balance of Zone 2

Note

• Zones can also be unmuted by adjusting the volume.

• The Zone 2 volume, tone, and balance function have no effect on

ZONE 2 PRE OUT when the “Zone 2 Out” setting is set to

“Fixed” (➔79).

• The Zone 3 volume function has no effect on ZONE 3 PRE

OUT when the “Zone 3 Out” setting is set to “Fixed” (➔79).

• Even if you repeatedly press the remote controller’s Zone to

select zones, the last zone selection will be retained once you

have switched to other components by pressing other Remote

Mode after pressing Zone.

1Press Zone repeatedly, then point the remote con-

troller at the AV receiver and press On.

Tip

•The 12V TRIGGER OUT goes high (+12 V).

2To select an input source for Zone 2/3, press Zone

repeatedly, followed by Input Selector.

To select AM or FM, press Tuner input selector and

Zone repeatedly.

(North American models) You can also select SIR-

IUS.

3To turn off Zone 2/3, press Zone repeatedly, fol-

lowed by Standby.

Zone

Standby

Input

Selector

On the remote controller, press Zone repeatedly,

and then use VOL q/w.

On the AV receiver, press Zone 2 or Zone 3, and

then press Zone Level Down w and Up q.

On the remote controller, press Zone repeatedly,

and then press Muting.

To unmute a zone, on the remote controller, press

Zone, and then press Muting again.

1On the AV receiver, press Zone 2.

2Press the AV receiver’s Tone repeatedly to select

“Bass”, “Treble” or “Balance”.

3Use –/+ to adjust the bass, treble or balance.

• You can boost or cut the bass or treble from –10 dB

to +10 dB in 2 dB steps.

• You can adjust the balance from 0 in the center to

+10 dB to the right or +10 dB to the left in 2 dB

steps.

The 12V triggers A, B, and C can be used to turn on 12V

trigger-capable components automatically when they are

selected as the input source. The triggers can be set so that

they activate when a connected component is selected as

the input source for the main room, Zone 2, Zone 3 or any

combination of rooms. When triggered, the output from a

12V TRIGGER OUT goes high (+12 volts and 150 milli-

amperes max. at TRIGGER OUT A; +12 volts and 25 mil-

liamperes max. at TRIGGER OUT B and C).

When several components are turned on simultaneously

by using triggers A, B, and C, depending on the type of

components, a large amount of current may be drawn

momentarily. To prevent this, you can delay trigger signals

A, B, and C individually. Another application for trigger

delay is eliminating the “thump” noise that’s sometimes

heard when a source component is turned on. Delaying the

trigger signal for your power amplifier so that it’s the last

component to be turned on will accomplish this.

Using the 12V Triggers

Hookup

• Use a miniplug cable to connect the AV receiver’s 12V TRIG-

GER OUT A, B, or C jack to the 12 V trigger input on a con-

nected component.

1Press Receiver followed by Setup.

The main menu appears on screen.

2Use q/w to select “Miscellaneous”, and then press

Enter.

The “Miscellaneous” menu appears.

3Use q/w to select “12V Trigger A, B or C Setup”,

and then press Enter.

The “12V Trigger A, B or C Setup” screen appears.

6-3. 12V Trigger A Setup

Delay

BD/DVD

VCR/DVR

CBL/SAT

GAME

AUX

0sec

Main

4Use q/w to select “Delay”, and use e/r to select:

0sec (Trigger A: default),

1sec (Trigger B: default),

2sec (Trigger C: default),

or 3sec.

When 0 sec is selected, the trigger signal is output as

soon as the input source is changed.

5Use q/w to select an input source, and use e/r to

select an option.

`Off:

No trigger signal is output. A 12-volt trigger

signal is output when the connected component

is selected as the source for:

`Main (Trigger A: default):

Main room.

`Zone 2 (Trigger C: default):

Zone 2.

`Main/Zone 2:

Main room or Zone 2.

`Zone 3:

Zone 3.

`Main/Zone 3:

Main room or Zone 3.

`Zone 2/Zone 3:

Zone 2 or Zone 3.

`Main/Zone 2/Zone 3:

Main room, Zone 2, or Zone 3.

6When you’ve finished, press Setup.

The setup menu closes.

To control the AV receiver with the remote controller

while you’re in Zone 2 or Zone 3, you’ll need a commer-

cially available multiroom remote control kit for each

zone.

• Multiroom kits are made by Niles and Xantech.

These kits can also be used when there isn’t a clear line of

sight to the AV receiver’s remote sensor, such as when it’s

installed inside a cabinet.

Using a Multiroom Kit with Zone 2/3

In this setup, the IR receiver in Zone 2/3 picks up the

infrared signals from the remote controller and feeds them

through to the AV receiver in the main room via the con-

necting block.

The miniplug cable from the connecting block should be

connected to the AV receiver’s IR IN A or B jack, as

shown below. The IR IN A and B jacks are identical. Up to

two IR receivers can be connected.

Using a Multiroom Kit with a Cabinet

In this setup, the IR receiver picks up the infrared signals

from the remote controller and feeds them to the AV

receiver located in the cabinet via the connecting block.

Using a Multiroom Kit with Other

Components

In this setup, an IR emitter is connected to the AV

receiver’s IR OUT jack and placed in front of the other

component’s remote control sensor. Infrared signals

received at the AV receiver’s IR IN A or B jack are fed

through to the other component via the IR emitter. Signals

picked up by the AV receiver’s remote control sensor are

not output.

The IR emitter should be connected to the AV receiver’s

IR OUT jack, as shown below.

Using the Remote Controller in

Zone 2/3 and Multiroom Control Kits

IR IN

A or B

Connecting

block

IR receiver

Remote controller

Main room Zone 2/3

Signal flow

From the Connecting block

Miniplug cable

AV receiver

IR receiver

Connecting

block

IR IN

A or B

Remote controller

Signal flow

Inside

cabinet

IR receiver

Connecting

block

IR IN

A or B AV receiver

IR Emitter

IR OUT

Remote controller

Other component

Signal flow

Miniplug cable

Remote controller

sensor

Emitter

IR Emitter

Miniplug

Signal flow

AV receiver

Controlling iPod & Other Components

Controlling iPod

USB can be used to play music files stored on iPod/iPhone,

which can be plugged into the AV receiver’s

USB

port.

Playing Music Files on the iPod/iPhone

This section explains how to play music files on the iPod/

iPhone*1.

*1 Compatible iPod models

Standard Mode control

The content information is not displayed onscreen, but can

be manipulated using the iPod/iPhone or the Remote Con-

trol.

Note

• The audio of video content can be played back but no video will

be displayed onscreen.

Connecting the iPod Directly to the

USB Port

Made for:

• iPod touch (1st and 2nd generation)

• iPod classic

• iPod (5th generation)

• iPod nano (1st, 2nd, 3rd, 4th and 5th generation)

• All iPhone models

USB port

Display

NET/USB

Album +/–

q/w, Enter,

Playlist e/r

Return

1, 3, 2, 5,

4, 7, 6

Repeat

Random

1Press NET/USB repeatedly to select the USB

input.

2Connect the USB cable that comes with the iPod/

iPhone to the USB port at the front of the AV

receiver.

• The USB indicator lights (➔9) if the AV receiver

is able to read the iPod/iPhone.

• The USB indicator flashes if the AV receiver can-

not read the iPod/iPhone.

3Press Display to switch to Extended Mode*3.

A list of your iPod model’s contents appears. To

open a folder, use q/w to select it, and then press

Enter.

Tip

• With the default settings, the iPod/iPhone can be manipu-

lated as Standard Mode*2.

• Pressing Display again switches back to Standard Mode.

*2 The following iPod models are not supported in Stan-

dard Mode. These iPod models can only be controlled

in Extended Mode.

• iPod (5th generation)

• iPod nano (1st generation)

*3 When you disconnect the iPod/iPhone, the AV receiver

stores the mode. This means that if you disconnect

when in Extended Mode, the AV receiver will start in

Extended Mode when you next connect the iPod/

iPhone.

4Use q/w to select a music file, and press Enter or

1 to start playback.

• To return to the previous menu during playback,

press Return.

• To stop or pause playback, press 2 or 3, respec-

tively.

• To select the next song, press 6. To select the

beginning of the current song, press 7. To select

the previous song, press 7 twice.

• To fast forward the current song, press 4. To

fast reverse the current song, press 5.

• To switch the repeat mode, press Repeat. To

switch the random mode, press Random.

iPod(STD)

Push “DISPLAY” button switch to Extended mode.

Extended Mode control

The content information is displayed (lists are displayed)

on the on-screen, and you can select and manipulate the

content while looking at the screen.

Top screen list:

• Playlists*4

• Artists*4

•Albums

•Genres

• Songs*4

• Composers*4

• Shuffle Songs*5

•Now Playing

*4 Displays a list.

*5 Plays all tracks in random order.

*6 Displays information about currently playing track.

Models sold are different depending on the region.

Connecting an Onkyo Dock

*1 BA

No. Onkyo Dock Cable Note Page

AUP-A1 Dock

(Universal Port Option Dock)

— • When UP-A1 Dock that seated iPod is con-

nected, the power consumption on standby

mode slightly increases.

• You can control your iPod when “Port” is

selected as the input source.

• See the UP-A1 Dock’s instruction manual for

more information.

BRI Dock Analog audio (RCA) • See the RI Dock’s instruction manual for more

information.

*1 To use u (Remote Interactive), you must

make an analog audio connection (RCA)

between the AV receiver and the RI Dock.

Component video

Composite video

u cable*1

PB/CB

PR/CR

UP-A1 Dock

With the UP-A1 Dock, you can easily play the music,

photo, or movie stored on your Apple iPod through the AV

receiver and enjoy great sound.

You can use the AV receiver’s remote controller to operate

your iPod.

■Basic Operation

Auto Power On

If you start iPod playback while the AV receiver is on

Standby, the AV receiver will automatically turn on and

select your iPod as the input source.

Direct Change

If you start iPod playback while listening to another input

source, the AV receiver will automatically select your iPod

as the input source.

Using the AV receiver’s Remote Controller

You can use the AV receiver’s remote controller to control

basic iPod functions (➔87).

■Using Your iPod models Alarm Clock

You can use your iPod models Alarm Clock function to

automatically turn on your iPod and the AV receiver at a

specified time. The AV receiver’s input source will auto-

matically be set to the Port selector.

Note

• To use this function, your iPod must be in the UP-A1 Dock, and

the UP-A1 Dock must be connected to the AV receiver.

• This function works only in the Standard mode (➔88).

• When you use this function, be sure to set the AV receiver’s vol-

ume control to a suitable level.

• When Zone 2/3 is turned on, you can’t use this function.

• You cannot use this function for sound effects on your iPod.

■Charging Your iPod models Battery

The UP-A1 Dock charges your iPod models battery while

your iPod is in the UP-A1 Dock and connected to the

UNIVERSAL PORT jack on the AV receiver. While your

iPod is seated in the UP-A1 Dock, its battery will be

charged when the AV receiver is set to “On” or “Standby”.

Note

• When UP-A1 Dock that seated iPod is connected, the power

consumption on standby mode slightly increases.

■Status Messages

• PORT Reading

The AV receiver is checking the connection with the

dock.

• PORT Not Support

The AV receiver do not support the connected dock.

•PORT UP-A1

UP-A1 Dock is connected.

Note

• The AV receiver displays the message “UP-A1” for several sec-

onds after recognizing the UP-A1.

• When the status message is not displayed on the AV receiver’s

display, check the connection to your iPod.

RI Dock

With the RI Dock, you can easily play the music stored on

your Apple iPod through the AV receiver and enjoy great

sound, and watch iPod slideshows and videos on your TV.

In addition, the onscreen display (OSD) allows you to

view, navigate, and select your iPod model’s contents on

your TV, and with the supplied remote controller, you can

control your iPod from the comfort of your sofa. You can

even use the AV receiver’s remote controller to operate

your iPod.

Note

• Enter the appropriate remote control code before using the AV

receiver’s remote controller for the first time (➔91).

• Connect the RI Dock to the AV receiver with an u cable

(➔85).

• Set the RI Dock’s RI MODE switch to “HDD” or “HDD/

DOCK”.

• Set the AV receiver’s Input Display to “DOCK” (➔27).

Using the Onkyo Dock

Dock is sold separately.

For the latest information on the Onkyo Dock compo-

nents, see the Onkyo web site at:

http://www.onkyo.com

Before using the Onkyo Dock components, update

your iPod with the latest software, available from the

Apple web site.

For supported iPod models, see the instruction man-

ual of the Onkyo Dock.

The AV receiver may take several seconds to startup, so

you might not hear the first few seconds of the first

song.

■Operating Notes

• Functionality depends on your iPod model and generation.

• Before selecting a different input source, stop iPod playback

to prevent the AV receiver from selecting the iPod input

source by mistake.

• If any accessories are connected to your iPod, the AV receiver

may not be able to select the input source properly.

• When connecting UP-A1 Dock to the radio tuner UP-HT1

(North American models)/UP-DT1 (Australian models)

with AUTO selected by the tuner’s Mode Selector switch, you

can switch the input source between UP-A1 Dock and the

tuner, by pressing Port repeatedly on the front panel.

• While your iPod is in the UP-A1 Dock, its volume control has

no effect. If you adjust your iPod models volume control while

it’s in the UP-A1 Dock, make sure it’s not set too high before

you reconnect your headphones.

• The Auto Power On function will not work if you set your

iPod in the UP-A1 Dock while it is playing.

• When Zone 2/3 is turned on, you can’t use Auto Power On and

Direct Change functions.

• Do not turn off the power with the iPod still connected to this

unit via the UP-A1 Dock.

• Set your iPod in the UP-A1 Dock after the AV receiver turns

on.

■System Function

System On

When you turn on the AV receiver, RI Dock and iPod turn

on automatically. In addition, when the RI Dock and iPod

are on, the AV receiver can be turned on by pressing On/

Standby.

Auto Power On

If you press the remote controller’s 1 while the AV

receiver is on Standby, the AV receiver will automatically

turn on, select your iPod as the input source, and your

iPod will start playback.

Direct Change

If you start iPod playback while listening to another input

source, the AV receiver will automatically switch to the

input to which the RI Dock is connected.

Using the AV receiver’s Remote Controller

You can use the AV receiver’s remote controller to control

basic iPod functions.

Using Your iPod models Alarm Clock

If you use the Alarm Clock function on your iPod to start

playback, the AV receiver will automatically turn on at the

specified time and select your iPod as the input source.

Note

• Linked operations do not work with video playback or when the

alarm is set to play a sound.

• If you use your iPod with any other accessories, iPod playback

detection may not work.

• This function works only in the Standard mode (➔88).

By pressing Remote Mode that’s been programmed with

the remote control code for your Dock, you can control

your iPod in the Dock.

See “Entering Remote Control Codes” for details on

entering a remote control code (➔91).

See the Dock’s instruction manual for more information.

■UP-A1 Dock

Port is preprogrammed with the remote control code for

controlling a Dock with Universal Port connector.

You can control your iPod when “Port” is selected as the

input source.

Without the RI Control

You must enter a remote control code 82990 first (➔91).

■RI Dock

• Set the RI Dock’s RI MODE switch to “HDD” or “HDD/

DOCK”.

•On/Standby may not work with a remote control code

(without u). In this case, make an u connection and

enter a remote control code 81993 (with u).

With the RI Control

In this case, make an u connection and enter a remote

control code 81993 (with u).

• Set the AV receiver’s Input Display to “DOCK” (➔27).

■Operating Notes

• Use the AV receiver’s volume control to adjust the playback

volume.

• While your iPod is inserted in the RI Dock, its volume control

has no effect. If you adjust your iPod models volume control

while it’s in the UP-A1 Dock, make sure it’s not set too high

before you reconnect your headphones.

Controlling Your iPod

✔: Available buttons

• With some iPod models, generations and RI Docks, certain buttons may not work as expected.

• For detailed operation of the iPod, please refer to the instruction manual of RI Dock.

*1 This button does not turn the Onkyo DS-A2 or DS-A2X RI Dock on or off. Your iPod may not respond the first time you press this

button, in which case you should press it again.

This is because the remote controller transmits the On and Standby commands alternately, so if your iPod is already on, it will

remain on when the remote controller transmits an On command.

Similarly, if your iPod is already off, it will remain off when the remote controller transmits an Off command.

*2 Press Display to change the following modes:

Standard mode

Nothing is displayed on your TV and you navigate and select your contents by using your iPod models display.

Only this mode can playback the video.

Extended mode (Music)

Playlists (artists, albums, songs, and so on) are displayed on your TV, and you can navigate and select your music while looking at

your TV.

Extended mode (Video)

Playlists (Movies, Music Videos, TV Shows, Video Podcasts, or Rentals) are displayed on your TV, and you can navigate and select

your video while looking at your TV.

*3 In Extended mode (see *2), Playlist is used as the page jump button.

With the page modes, you can quickly locate your favorite songs even when your song lists, artist lists, and so on are very long.

*4 Resume mode

With the Resume function, you can resume playback of the song that was playing when you removed your iPod from the RI Dock or

Standard mode is selected.

*5 Top Menu works as a Mode button when used with a DS-A2 RI Dock.

*6 Display turns on backlight for 30 seconds.

Note

• In Extended mode (see *2), the playback will be continued even if the AV receiver is turned off.

• In Extended mode (see *2), you cannot operate your iPod directly.

• In Extended mode (see *2), it may take some time to acquire the contents.

Press the appropriate Remote Mode first.

UP-A1 Dock

u Dock

aOn, Standby ✔*1

bTop Menu ✔*5

cq/w/e/rEnter ✔✔

Playlist e/r✔*3 ✔

d1, 3, 2, 5, 4, 7, 6✔✔

eRepeat ✔✔

Random ✔✔

Play Mode ✔*4 ✔*4

fDisplay*6 ✔*2 ✔

gMuting ✔✔

hAlbum +/– ✔✔

iVOL q/w✔✔

jMenu ✔

kReturn ✔

Onkyo Dock

Buttons

Controlling Other Components

You can use the AV receiver’s remote controller

(RC-772M) to control your other AV components, includ-

ing those made by other manufacturers. This section

explains how to enter the remote control code (with the

default underlined) for a component that you want to con-

trol: DVD, TV, CD, etc.

• Learn commands directly from another component’s

remote controller. (➔95)

• Program Activities to perform a sequence of up to 32

remote control actions. (➔94, 96)

The following Remote Mode are preprogrammed with

remote control codes for controlling the components

listed. You do not need to enter a remote control code to

control these components.

For details on controlling these components, see the pages

indicated.

You can look up for appropriate remote control code from

on-screen setup menu.

Note

• This setting can be carried out by using on-screen setup menu

only.

Preprogrammed Remote Control

Codes

BD/DVD Integra/Onkyo Blu-ray Disc player (➔92)

TV/CD Integra/Onkyo CD player (➔92)

Port Onkyo Universal Port Option (➔87)

Looking up for Remote Control Code

1Press Receiver followed by Setup.

The main menu appears onscreen.

Tip

If the main menu doesn’t appear, make sure the

appropriate external input is selected on your TV.

2Use q/w to select “Remote Controller Setup”,

and then press Enter.

The “Remote Controller Setup” menu appears.

3Use q/w to select “Remote Mode Setup”, and

then press Enter.

The “Remote Mode Setup” menu appears.

1. Remote Mode Setup

2. Activities Setup

8. Remote Controller Setup

BD/DVD

VCR/DVR

CBL/SAT

GAME

AUX

TV/CD

PHONO

8–1. Remote Mode Setup

4Use q/w to select remote mode, and then press

Enter.

The category selection menu appears.

5Use q/w to select category, and then press

Enter.

The brand name input panel appears.

6Use q/w/e/r to select a character, and then

press Enter.

Repeat this step from the 1st character to the 3rd

character of the brand name.

When you have entered the 3rd character, select

“Search” and press Enter.

After searching, a list of the brand name appears.

7Use q/w to select the brand name, and press

Enter.

Go to step 8.

If you cannot find the brand name, use r to

select “Search DB”, and then press Enter to

access the database on the network.

The AV receiver accesses and searches the data-

base. After searching, a list of the brand name

appears.

TV/DVD

TV/VCR

8–1. Remote Mode Setup TV

ABCDEFGH I JKLM

NOPQRS T UVWXYZ

1234567890 &@

–

Space

Back Space

8–1. Remote Mode Setup TV

Category

Brand

8–1. Remote Mode Setup TV

TVCategory

Brand

Search DB

Sonawa

Sonber

Songba

Sonic

Soniko

8–1. Remote Mode Setup TV

TVCategory

Brand

Not Listed

Sonawa

Sonber

Songba

Sonic

Soniko

Tip

• If you cannot access the database, a message “Cannot

connect to database.” will appear. Press Enter to

return to the previous step.

• If the brand name is not found, use r to select “Not

Listed”, and then press Enter.

The following screen appears.

Use

to select “Search by model number( via

network )”, and then press

Enter

The model number input panel appears.

When you do NOT have a network connection

or if you are not sure about the exact model,

select “Skip”, and then press Enter.

If you select “Skip”, you will go to step 11.

9Enter the model in a similar manner as in the

case of the brand name (step 6).

Tip

• After entering the 3rd character, press Enter to start

searching.

• You cannot enter a space character.

10 Use q/w to select brand, and then press Enter.

If the model is not found, use r to select “Not

Listed”, and then press Enter.

After searching is completed, a message for

remote control code transfer will appear.

11 While pointing the remote controller at the AV

receiver’s remote control sensor, press Enter.

8–1. Remote Mode Setup TV

Skip

Search by model number (via network)

Category

Brand

Model

Sonic

(Option)

8–1. Remote Mode Setup TV

Category

Brand

Model

XXXXX

xxxxx

Now we are ready to transfer data to the remote.

Please hold the remote so that it is facing the receiver.

Use ENTER button of your remote to activate “OK”.

Ready?

Approx.

16ft. (5 m)

Incoming sensor

Remote control sensor (Transmitter)

15° off center

(Left/Right/Up/Down)

12 When you searched for the model, a message

“Successful” will appear. Now the transfer is

successful!

Go to step 15.

When you did NOT search for the model, the

following screen appears.

Push any key (except for arrow buttons and

Enter) to see if the component responds.

*1 When category other than TV have been selected,

the content is different.

*2 Asterisks in [***/***] mean the order of the candi-

date code and the total number of the codes for the

brand.

13 If you can control component, press Receiver,

use q/w to select “Works”, and then press

Enter.

If you cannot control component, press

Receiver, use q/w to select “Doesn’t work

(Retry)” and press Enter.

The next code appears.

14 Press Enter to transfer the determined code.

15 Press Enter.

You’ll return to the category selection menu.

Press Setup to end the remote mode setup.

8–1. Remote Mode Setup TV

Works

Doesn’t work (Retry)

1. Push some key to see if the TV responds.

(except Arrow and Enter.)

2. Choose “Works” or “Doesn’t work”.

Category

Brand

Code

XXXXX

xxxxx[***/***]

*1 *2

8–1. Remote Mode Setup TV

Now we are ready to transfer data to the remote.

Please hold the remote so that it is facing the receiver.

Use ENTER button of your remote to activate “OK”.

Ready?

Category

Brand

Code

XXXXX

xxxxx[***/***]

Approx.

16ft. (5 m)

Incoming sensor

Remote control sensor (Transmitter)

15° off center

(Left/Right/Up/Down)

You’ll need to enter a code for each component that you

want to control.

Note

• The remote control codes provided are correct at the time of

printing, but are subject to change.

Integra/Onkyo components that are connected via u are

controlled by pointing the remote controller at the AV

receiver, not the component. This allows you to control

components that are out of view, in a rack, for example.

If you want to control an Integra/Onkyo component by

pointing the remote controller directly at it, or you want to

control an Integra/Onkyo component that’s not connected

via u, use the following remote control codes:

•BD/DVD

`30627:

Integra/Onkyo DVD player without u

•TV/CD

`71817:

Integra/Onkyo CD player without u

`11807:

TV with p

Entering Remote Control Codes

1Look up the appropriate remote control code in

the separate Remote Control Codes list.

The codes are organized by category (e.g., DVD

player, TV, etc.).

2While holding down Remote Mode to which you

want to enter a code, press and hold down Dis-

play (about 3 seconds).

The Remote Mode button lights.

Note

• Remote control codes cannot be entered for Receiver

and Zone.

• Only TV remote control codes can be entered for TV.

• Except for Receiver, TV and Zone, remote control

codes from any category can be entered as Remote

Mode. However, these buttons also work as input selector

buttons (➔25), so choose a Remote Mode that corre-

sponds with the input to which you connect your compo-

nent. For example, if you connect your CD player to the

CD input, choose TV/CD when entering its remote control

code.

3Within 30 seconds, use the number buttons to

enter the 5-digit remote control code.

Remote Mode button flashes twice.

If the remote control code is not entered success-

fully, Remote Mode button will flash once slowly.

Remote Control Codes for Integra/

Onkyo Components Connected via u

1Make sure the Integra/Onkyo component is con-

nected with an u cable and an analog audio

cable (RCA).

See “Connecting Integra/Onkyo u Components”

for details (➔20).

2Enter the appropriate remote control code for

Remote Mode.

•BD/DVD

`31612:

Integra/Onkyo DVD player with u

•TV/CD

`71327:

Integra/Onkyo CD player with u

`42157:

Onkyo cassette tape deck with u

•Port

`81993:

Onkyo Dock with u

See the previous section for how to enter remote

control codes.

Note

• When using a cassette tape deck connected via u, press

and hold TV/CD to switch to TAPE.

3Press Remote Mode, point the remote controller

at the AV receiver, and operate the component.

If you want to control an Integra/Onkyo component by

pointing the remote controller directly at it, use the follow-

ing remote control codes:

`32900:

Integra/Onkyo Blu-ray Disc player

`32901:

Integra/Onkyo HD-DVD player

`70868:

Onkyo MD recorder without u

`71323:

Onkyo CD recorder without u

`82990:

Onkyo Dock without u

Note

• If you connect a cassette tape deck to the TV/CD IN jack, or

connect an RI Dock to the to the TV/CD IN or VCR/DVR IN or

GAME IN jacks, for u to work properly, you must set the Input

Display accordingly (➔27).

You can reset a Remote Mode to its default remote con-

trol code.

You can reset the remote controller to its default settings.

By pressing Remote Mode that’s been programmed with

the remote control code for your component, you can con-

trol your component as below.

For details on entering a remote control code for other

components, see “Entering Remote Control Codes”

(➔91).

Controlling a TV

TV is preprogrammed with the remote control code for

controlling a TV that supports the p*1 (limited to

some models). The TV must be able to receive remote

control commands via p and be connected to the

AV receiver via HDMI. If controlling your TV via

p doesn’t work very well, program your TV’s

remote control code into TV and use the TV remote mode

to control your TV.

Controlling a Blu-ray Disc/DVD Player, HD

DVD Player or DVD Recorder

BD/DVD is preprogrammed with the remote control code

for controlling a component that supports the p*1

(limited to some models). The component must be able to

receive remote control commands via p and be

connected to the AV receiver via HDMI.

*1 The p supported by the AV receiver is the CEC

system control function of the HDMI standard.

Resetting Remote Mode Buttons

1While holding down Remote Mode that you want

to reset, press and hold down Home until Remote

Mode button lights (about 3 seconds).

2Within 30 seconds, press Remote Mode again.

Remote Mode button flashes twice, indicating that

the button has been reset.

Each of Remote Mode is preprogrammed with a

remote control code. When a button is reset, its pre-

programmed code is restored.

Note

• The learning command is also reset.

Resetting the Remote Controller

1While holding down Receiver, press and hold

down Home until Receiver lights (about 3 sec-

onds).

2Within 30 seconds, press Receiver again.

Receiver flashes twice, indicating that the remote

controller has been reset.

Controlling Other Components

Note

• With some components, certain buttons may not work as

expected, and some may not work at all.

✔: Available buttons

*1 The p function is not supported. The p sup-

ported by the AV receiver is the CEC system control function

of the HDMI standard.

*2 These buttons function as colored buttons or A, B, C, D but-

tons.

*3 3 (Pause) functions as reverse playback.

Tip

• See the “Controlling Your iPod” about the operation of iPod

(➔87).

Press the appropriate Remote

Mode first.

DVD player/DVD recorder

Blu-ray Disc player

HD DVD player

VCR/PVR

Satellite receiver

Cable receiver

CD player/CD recorder

MD recorder

Cassette tape deck

aOn, Standby ✔✔ ✔✔✔✔

b9, Input,

TV VOL q/w

✔

cGuide ✔✔✔

Top Menu ✔

dq/w/e/r

Enter

✔✔ ✔✔✔

eSetup ✔✔ ✔✔✔

f1, 3, 2, 5,

4, 7, 6

✔*1 ✔✔✔✔

✔*3

gSearch ✔*1*2 ✔*1 ✔*2 ✔*2 ✔

Repeat ✔*1*2 ✔✔*2 ✔*2 ✔

Random ✔*1*2 ✔*1 ✔*2 ✔*2 ✔

Play Mode ✔*1*2 ✔*1 ✔*2 ✔*2 ✔

hNumber: 1 to 9, 0✔✔ ✔✔✔

Number: +10 ✔*1 ✔*1 ✔✔ ✔

iDisplay ✔✔ ✔✔✔

jMuting ✔✔ ✔✔✔✔

kCH +/– ✔✔ ✔✔

Disc +/– ✔✔

lPREV CH ✔✔✔

Menu ✔

mReturn ✔✔ ✔✔

nCLR ✔✔ ✔✔✔

Components

Buttons

Via onscreen menu, you can specify what actions will be

taken by the Easy macro command in the Easy macro

mode (➔27).

Here are the default settings.

Activities Setup

1Press Receiver followed by Setup.

The main menu appears onscreen.

Tip

• If the main menu doesn’t appear, make sure the appropri-

ate external input is selected on your TV.

2Use q/w to select “Remote Controller Setup”, and

then press Enter.

The “Remote Controller Setup” menu appears.

3Use q/w to select “Activities Setup”, and then

press Enter.

The “Activities Setup” menu appears.

4Use q/w to select “My Movie”, “My TV”, or “My

Music”, and then press Enter.

■My Movie:

Actions for My Movie is changed.

■My TV:

Actions for My TV is changed.

■My Music:

Actions for My Music is changed.

5Use q/w to select an item, and use e/r to change

the settings.

The items are explained below.

■Source

`BD/DVD, VCR/DVR, CBL/SAT, GAME, PC,

AUX, TUNER, TV/CD, PHONO, PORT,

NET/USB

With this setting, you can choose the input source.

■TV Power On

`Enable:

TV to turn on “Enable”.

`Disable:

TV to turn on “Disable”.

This option enables the TV to turn on when

Activities is pressed.

1. Remote Mode Setup

2. Activities Setup

8. Remote Controller Setup

My Movie

My TV

My Music

8–2. Activities Setup

8–2. Activities Setup My Movie

Source

TV Power On

Source Power On

Receiver Power On

Receiver Source Change

Source Play

BD/DVD

Enable

■Source Power On

`Enable:

Source to turn on “Enable”.

`Disable:

Source to turn on “Disable”.

This option enables the Source to turn on when

Activities is pressed.

■Receiver Power On

`Enable:

AV receiver to turn on “Enable”.

`Disable:

AV receiver to turn on “Disable”.

This option enables the AV receiver to turn on

when Activities is pressed.

■Receiver Source Change

`Enable:

AV receiver input selector is change.

`Disable:

AV receiver input selector is not change.

This option enables the AV receiver input selector

to change when Activities is pressed.

■Source Play

`Enable:

Start playback the source of “Enable”.

`Disable:

Start playback the source of “Disable”.

This option enables the Source to start playback

when Activities is pressed.

Item Default Settings

My Movie My TV My Music

Source BD/DVD CBL/SAT TV/CD

TV Power On Enable Enable Disable

Source Power On Enable Enable Enable

Receiver Power On Enable Enable Enable

Receiver Source

Change

Enable Enable Enable

Source Play Enable Disable Enable

The AV receiver’s remote controller can learn the com-

mands of other remote controllers. By transmitting, for

example, the Play command from your CD player’s

remote controller, the remote controller can learn it, and

then transmit the exact same command when its 1 is

pressed in the CD remote mode.

This is useful when you’ve entered the appropriate remote

control code (➔91) but some buttons don’t work as

expected.

6Press Enter.

A message for transfer will appear.

To use the remote controller, point it at the AV

receiver’s remote control sensor, as shown below.

7Press Enter.

When the transfer is successful, the following screen

appears.

8Press Enter.

The “Activities Setup” menu appears onscreen.

9Press Setup.

The setup menu closes.

8–2. Activities Setup My Movie

Now we are ready to transfer data to the remote.

Please hold the remote so that it is facing the receiver.

Use ENTER button of your remote to activate “OK”.

Ready?

AV receiver

Approx.

16ft. (5 m)

Incoming sensor

Transmitter

15° off center

(Left/Right/Up/Down)

8–2. Activities Setup My Movie

Wait...

8–2. Activities Setup My Movie

Return

Successful

Learning Commands

1While holding down Remote Mode for the mode

in which you want to use the command, press and

hold down On until Remote Mode button lights

(about 3 seconds).

2On the supplied remote controller, press the but-

ton you want to learn the new command.

3Point the remote controllers at each other, about 2

to 6 inches (5 to 15 cm) apart, and then press and

hold the button whose command you want to learn

until Remote Mode button flashes.

If the command is learned successfully, Remote

Mode button flashes twice.

4To learn more commands, repeat steps 2 and 3.

Press any Remote Mode when you’ve finished.

Remote Mode button flashes twice.

Remote

Mode

DIMMER SUR

MODE

C D

PHONO

MULTI-CH

INPUT

POWER SLEEP

VIDEO-1 VIDEO-2

TAPEDVD

C D DV D

TUNER

INPUT SELECTOR

DISC

VOLUME

CH SEL

PRESET

ING

TEST

TONE

GROUP

About 2 to 6 inches

(5 to 15 cm)

Supplied remote

controller

Note

• The following buttons cannot learn new commands: Remote

Mode, All Off, My Movie, My TV, My Music and Mode.

• The remote controller can learn approximately 70 to 90 com-

mands, although this will be less if commands that use a lot of

memory are learned.

• Remote controller buttons such as Play, Stop, Pause, and so on

are preprogrammed with commands for controlling Onkyo CD

players, cassette decks, and DVD players. However, they can

learn new commands, and you can restore the preprogrammed

commands at any time by resetting the remote controller (➔92).

• To overwrite a previously learned command, repeat this proce-

dure.

• Depending on the remote controller that you are using, there may

be some buttons that won’t work as expected, or even some

remotes that cannot be learned at all.

• Only commands from infrared remote controllers can be learned.

• When the remote controller’s batteries expire, all learned com-

mands will be lost and will have to be learned all over again, so

don’t discard your other remote controllers.

■Deleting Learning Commands

1. While holding down Remote Mode for the mode in

which you want to delete the command, press and hold

down TV 9 until Remote Mode button lights

(about 3 seconds).

2. Press Remote Mode or the button from which you

want to delete the commands.

Remote Mode button flashes twice.

When you press Remote Mode, all commands

learned in that remote mode will be deleted.

You can program the remote controller’s Activities to

perform a sequence of remote control actions.

Example:

To play a CD you typically need to perform the following

actions:

1. Press Receiver to select the Receiver remote control-

ler mode.

2. Press On to turn on the AV receiver.

3. Press TV/CD to select the TV/CD input source.

4. Press 1 to start playback on the CD player.

You can program Activities so that all four actions are

performed with just one button press.

Making Macros

Each Activities can store one macro, and each macro can

contain up to 32 commands.

Running Macros

Deleting Macros

Using Normal Macros

All Off My Movie,

My TV,

My Music

Receiver

1While holding down Receiver, press and hold

down My Movie, My TV or My Music until

My Movie, My TV, or My Music lights (about 3

seconds).

2Press the buttons whose actions you want to pro-

gram into the macro in the order you want them

performed.

For the CD example above, you’d press the following

buttons: On, TV/CD, 1.

Note

•MODE is invalid at macro making operation.

3When you’ve finished, press Activities again.

Activities button flashes twice.

If you enter 32 commands, the process will finish

automatically.

Note

• Once you have taught a new macro commands, the origi-

nal macro will no longer work. If you retrieve it, you will

have to taught again.

Press My Movie, My TV or My Music.

The commands in the macro are transmitted in the

order in which they were programmed. Keep the

remote controller pointed at the AV receiver until all

of the commands have been transmitted.

Macros can be run at any time, regardless of the cur-

rent remote controller mode.

1While holding down Home, press and hold down

All Off until All Off lights (about 3 seconds).

2Press All Off again.

All Off flashes twice.

Note

• It changes into Easy macro mode when the macro is

deleted (➔27).

• When you using Normal macro mode, you cannot use the

easy macro command including the change of the source

component.

Others

Troubleshooting

If you have any trouble using the AV receiver, look for a

solution in this section. If you can’t resolve the issue your-

self, contact the dealer from whom you purchased this

unit.

■Can’t turn on the AV receiver

■The Standby indicator flashes red

■There’s no sound, or it’s very quiet

■Audio Return Channel audio can be heard via

the TV/monitor speakers connected to the HDMI

OUT SUB jack

■Only the front speakers produce sound

If you can’t resolve the issue yourself, try resetting the

AV receiver before contacting the dealer from whom

you purchased this unit.

To reset the AV receiver to its factory defaults, turn it

on and, while holding down VCR/DVR, press On/

Standby. “Clear” will appear on the display and the

AV receiver will enter Standby mode.

Note that resetting the AV receiver will delete your

radio presets and custom settings.

To reset the remote controller to its factory defaults,

while holding down Receiver, press and hold down

Home until Receiver button lights (about 3 seconds).

Within 30 seconds, press Receiver again.

Power

Make sure that the power cord is properly plugged

into the wall outlet.

—

Unplug the power cord from the wall outlet, wait five

seconds or more, then plug it in again.

—

The protection circuit has been activated. Remove

the power cord from the wall outlet immediately.

Disconnect all speaker cables and input sources, and

leave the AV receiver with its power cord discon-

nected for 1 hour. After that, reconnect the power

cord and set the volume to maximum. If the AV

receiver stays on, set the volume to minimum, dis-

connect the power cord, and reconnect your speakers

and input sources. If the AV receiver turns off when

you set the volume to maximum, disconnect the

power cord, and contact the dealer from whom you

purchased this unit.

—

Receiver

Home

Audio

Make sure that the digital input source is selected

properly.

Make sure that all audio connecting plugs are pushed

in all the way.

Make sure that the inputs and outputs of all compo-

nents are connected properly.

18-20

Make sure that the polarity of the speaker cables is

correct, and that the bare wires are in contact with

the metal part of each speaker terminal.

Make sure that the input source is properly selected. 25

Make sure that the speaker cables are not shorting. 13

Check the volume. The AV receiver is designed for

home theater enjoyment. It has a wide volume range,

allowing precise adjustment.

—

If the MUTING indicator is flashing on the display,

press the remote controller’s Muting to unmute the

AV receiver.

While a pair of headphones is connected to the

Phones jack, no sound is output by the speakers.

If there’s no sound from a DVD player connected to

an HDMI IN, check the DVD player’s output set-

tings, and be sure to select a supported audio format.

—

Check the digital audio output setting on the con-

nected device. On some game consoles, such as

those that support DVD, the default setting is off.

—

With some DVD-Video discs, you need to select an

audio output format from a menu.

—

If your turntable uses an MC cartridge, you must

connect an MC head amp, or an MC transformer.

—

Make sure that none of the connecting cables are

bent, twisted, or damaged.

—

Not all listening modes use all speakers. 42

Specify the speaker distances and adjust the individ-

ual speaker levels.

Make sure that the speaker setup microphone is not

still connected.

—

The input signal format is set to “PCM” or “DTS”.

Set it to “Auto”.

Change the “Audio Selector” settings of the TV/CD

input selector.

When the Stereo or Mono listening mode is selected,

only the front speakers and subwoofer produce

sound.

—

In the Mono listening mode, only the front speakers

output sound if the “Output Speaker” setting is set

to “Left / Right”.

Check the Speaker Configuration. 51

■Only the center speaker produces sound

■The surround speakers produce no sound

■The center speaker produces no sound

■The front high, front wide and surround back

speakers produce no sound

■The subwoofer produces no sound

■There’s no sound with a certain signal format

■Can’t get 6.1/7.1 playback

■The speaker volume cannot be set as required

(The volume cannot be set to Max(100.0))

■Noise can be heard

■The Late Night function doesn’t work

■About DTS signals

■The beginning of audio received by an HDMI IN

can’t be heard

If you use the Dolby Pro Logic IIx Movie, Dolby Pro

Logic IIx Music, or Dolby Pro Logic IIx Game lis-

tening mode with a mono source, such as an AM

radio station or mono TV program, the sound is con-

centrated in the center speaker.

—

In the Mono listening mode, only the front speakers

output sound if the “Output Speaker” setting is set

to “Center”.

Make sure the speakers are configured correctly. 51

When the T-D (Theater-Dimensional), Stereo or

Mono listening mode is selected, the surround

speakers produce no sound.

—

Depending on the source and current listening mode,

not much sound may be produced by the surround

speakers. Try selecting another listening mode.

—

Make sure the speakers are configured correctly. 51

When the Stereo or Mono listening mode is selected,

the center speaker produces no sound.

—

In the Mono listening mode, only the front speakers

output sound if the “Output Speaker” setting is set

to “Left / Right”.

Make sure the speakers are configured correctly. 51

Depending on the current listening mode, no sound

may be produced by the front high, front wide and

surround back speakers. Select another listening

mode.

Not much sound may be produced by the front high,

front wide and surround back speakers with some

sources.

—

Make sure the speakers are configured correctly. 51

While Powered Zone 2 is being used, playback in the

main room is reduced to 5.1-channels and the front

high, front wide and surround back speakers produce

no sound.

When you play source material that contains no

information in the LFE channel, the subwoofer pro-

duces no sound.

—

Make sure the speakers are configured correctly. 51

Check the digital audio output setting on the con-

nected device. On some game consoles, such as

those that support DVD, the default setting is off.

—

With some DVD-Video discs, you need to select an

audio output format from a menu.

—

Depending on the input signal, some listening modes

cannot be selected.

42–46

If no surround back speakers, front wide and front

high speakers are connected, or the Zone 2 speakers

are being used, 6.1/7.1 playback is not possible.

—

You can not always select all of the listening modes,

depending on the number of the speakers connected.

42–46

Check to see if a maximum volume has been set. 61

If the volume level of each individual speaker has

been adjusted to high positive values, then the maxi-

mum master volume possible may be reduced. Note

that the individual speaker volume levels are set

automatically after Audyssey MultEQ® Room Cor-

rection and Speaker Setup function has been com-

pleted.

28, 52

Using cable ties to bundle audio cables with power

cords, speaker cables, and so on may degrade the

audio performance, so don’t do it.

—

An audio cable may be picking up interference. Try

repositioning your cables.

—

Make sure the source material is Dolby Digital,

Dolby Digital Plus, and Dolby TrueHD.

When DTS program material ends and the DTS bit-

stream stops, the AV receiver remains in DTS listen-

ing mode and the DTS indicator remains on. This is

to prevent noise when you use the pause, fast for-

ward, or fast reverse function on your player. If you

switch your player from DTS to PCM, because the

AV receiver does not switch formats immediately,

you may not hear any sound, in which case you

should stop your player for about three seconds, and

then resume playback.

—

With some CD and LD players, you won’t be able to

playback DTS material properly even though your

player is connected to a digital input on the AV

receiver. This is usually because the DTS bitstream

has been processed (e.g., output level, sampling rate,

or frequency response changed) and the AV receiver

doesn’t recognize it as a genuine DTS signal. In such

cases, you may hear noise.

—

When playing DTS program material, using the

pause, fast forward, or fast reverse function on your

player may produce a short audible noise. This is not

a malfunction.

—

Since it takes longer to identify the format of an

HDMI signal than it does for other digital audio sig-

nals, audio output may not start immediately.

—

■There’s no picture

■There’s no picture from a source connected to

an HDMI IN

■The on-screen menus don’t appear

■The picture is distorted

■The on screen display does not appear

■Reception is noisy, FM stereo reception is

noisy, or the FM STEREO indicator doesn’t light

■The remote controller doesn’t work

■Can’t control other components

Video

Make sure that all video connecting plugs are pushed

in all the way.

Make sure that each video component is properly

connected.

18, 19,

If your TV is connected to the HDMI output, set the

“Monitor Out” setting other than “Analog”, and

select “-----” in the “HDMI Input” to watch com-

posite video, S-Video, and component video sources.

48, 49

If your TV is connected to the COMPONENT

VIDEO MONITOR OUT, MONITOR OUT S, or

MONITOR OUT V, set the “Monitor Out” setting

to “Analog”, and select “-----” in the “Component

Video Input” to watch composite video and S-Video

sources.

48, 50

If the video source is connected to a component

video input, you must assign that input to an input

selector, and your TV must be connected to either

the HDMI output or COMPONENT VIDEO MON-

ITOR OUT.

19, 50

If the video source is connected to a composite video

input, your TV must be connected to the HDMI out-

put or the corresponding composite video output.

If the video source is connected to an HDMI input,

you must assign that input to an input selector, and

your TV must be connected to the HDMI output.

18, 49

While the Pure Audio listening mode is selected, the

video circuitry is turned off and only video signals

input through HDMI IN can be output.

—

On your TV, make sure that the video input to which

the AV receiver is connected is selected.

—

Reliable operation with an HDMI-to-DVI adapter is

not guaranteed. In addition, video signals from a PC

are not guaranteed.

104

When the “Monitor Out” setting is set to “Analog”,

and the “Resolution” setting is set to anything other

than “Through”, no video is output by the HDMI

outputs.

48, 49

When the “Resolution” is set to any resolution not

supported by the TV, no video is output by the

HDMI outputs.

If the message “Resolution Error” appears on the

AV receiver’s display, this indicates that your TV

does not support the current video resolution and

you need to select another resolution on your DVD

player.

—

(Australian models) Specify the TV system used in

your area in the “TV Format”.

On your TV, make sure that the video input to which

the AV receiver is connected is selected.

—

If your TV is connected to the analog outputs, set the

“Monitor Out” setting to “Analog”.

(Australian models) Specify the TV system used in

your area in the “TV Format”.

Depending on the input signal, the on screen display

may not appear when the input signal from the

HDMI IN is output to a device connected to the

HDMI output.

Tuner

Relocate your antenna. —

Move the AV receiver away from your TV or com-

puter.

—

Listen to the station in mono. 31

When listening to an AM station, operating the

remote controller may cause noise.

—

Passing cars and airplanes can cause interference. —

Concrete walls weaken radio signals. —

If nothing improves the reception, install an outdoor

antenna.

—

Remote Controller

Before operating this unit, be sure to press

Receiver.

—

Make sure that the batteries are installed with the

correct polarity.

Install new batteries. Don’t mix different types of

batteries, or old and new batteries.

Make sure that the remote controller is not too far

away from the AV receiver, and that there’s no

obstruction between the remote controller and the

AV receiver’s remote control sensor.

Make sure that the AV receiver is not subjected to

direct sunshine or inverter-type fluorescent lights.

Relocate if necessary.

—

If the AV receiver is installed in a rack or cabinet

with colored-glass doors, the remote controller may

not work reliably when the doors are closed.

—

Make sure you’ve selected the correct remote con-

troller mode.

11, 92

When using the remote controller to control other

manufacturers’ AV components, some buttons may

not work as expected.

—

Make sure you’ve entered the correct remote control

code.

Make sure to set the same ID on both the AV receiver

and remote controller.

If it’s an Integra/Onkyo component, make sure that

the u cable and analog audio cable are connected

properly. Connecting only an u cable won’t work.

Make sure you’ve selected the correct remote con-

troller mode.

11, 92

If you’ve connected a cassette tape deck, to the TV/

CD IN jack, or an RI Dock to the TV/CD IN or

GAME IN or VCR/DVR IN jacks, for the remote

controller to work properly, you must set the input

display.

If you cannot operate it, you will need to enter the

appropriate remote control code.

100

■Can't learn commands from another remote

controller

■Can’t record

■There’s no sound

■The Zone 2 speakers produce no sound

■Can’t access the server or Internet radio

■Playback stops while listening to music files on

the server

■Can’t connect to the AV receiver from a Web

browser

■Can’t access the music files on a USB device

■Stand-by power consumption

■The sound changes when I connect my

headphones

■The speaker distance cannot be set as required

■How do I change the language of a multiplex

source

To control another manufacturer’s component, point

the remote controller at that component.

If none of the codes work, use the Learning function

to learn the commands of the other component's

remote controller.

To control an Integra/Onkyo component that’s con-

nected via u, point the remote controller at the AV

receiver. Be sure to enter the appropriate remote con-

trol code first.

To control an Integra/Onkyo component that’s not

connected via u, point the remote controller at the

component. Be sure to enter the appropriate remote

control code first.

The entered remote control code may not be correct.

If more than one code is listed, try each one.

—

When learning commands, make sure that the trans-

mitting ends of both remote controllers are pointing

at each other.

—

Are you trying to learn from a remote controller that

cannot be used for learning? Some commands can-

not be learned, especially those that contain several

instructions.

—

Recording

On your recorder, make sure the correct input is

selected.

—

To prevent signal loops and damage to the AV

receiver, input signals are not fed through to outputs

with the same name (VCR/DVR IN to VCR/DVR

OUT).

—

Zone 2/3

Only components connected to analog inputs can be

played in Zone 2/3.

—

Powered Zone 2 cannot be used if “Speakers

Type(Front)” is set to “Bi-Amp”.

To use the Zone 2 speakers, you must set the “Pow-

ered Zone 2” setting to “Act”.

Music Server and Internet Radio

Check the network connection between the AV

receiver and your router or switch.

—

Make sure that your modem and router are properly

connected, and make sure they are both turned on.

—

Make sure the server is up and running and compati-

ble with the AV receiver.

Check the “Network Settings”. 73

Make sure your server is compatible with the AV

receiver.

If you download or copy large files on your com-

puter, playback may be interrupted. Try closing any

unused programs, use a more powerful computer, or

use a dedicated server.

—

If the server is serving large music files to several

networked devices simultaneously, the network may

become overloaded and playback may be inter-

rupted. Reduce the number of playback devices on

the network, upgrade your network, or use a switch

instead of a hub.

—

If you’re using DHCP, your router may not always

allocate the same IP address to the AV receiver, so if

you find that you can’t connect to a server or Internet

radio station, recheck the AV receiver’s IP address

on Network screen.

—

Check the “Network Settings”. 73

USB Mass Storage Device Playback

Make sure the USB device is plugged in properly. —

The AV receiver supports USB devices that support

the USB mass storage device class. However, play-

back may not be possible with some USB devices

even if they conform to the USB mass storage device

class.

—

USB memory devices with security functions cannot

be played.

—

Others

In the following cases, the power consumption may

reach up to a maximum of 55W:

1. You are using the Universal Port jack.

2. “Control” is set to “Enable” in the “Network”

setting.

3. “HDMI Control (RIHD)” setting is set to

“On”. (Depending on the TV status, the AV

receiver will enter Standby mode as usual.)

62, 74,

When a pair of headphones is connected, the listen-

ing mode is set to Stereo, unless it’s already set to

Stereo, Mono or Direct.

—

In some cases, corrected values suitable for home

theater use may be set automatically.

—

Use the “Multiplex” setting on the “Audio Adjust”

menu to select “Main” or “Sub”.

101

■The u functions don’t work

■The functions System On/Auto Power On and

Direct Change don’t work for components

connected via u

■When performing “Audyssey MultEQ® Room

Correction and Speaker Setup”, the

measurement fails showing the message

“Ambient noise is too high.”.

■The following settings can be made for the

S-Video and composite video inputs

You must use the buttons on the unit to make these set-

tings.

1. While holding down the input selector button for the input

source that you want to set, press Setup.

2. Use e/r to change the setting.

3. Press the input selector button for the input source that you

want to set when you’ve finished.

• Video Attenuation

This setting can be made for the BD/DVD, VCR/DVR,

CBL/SAT, Game, or AUX input.

If you have a games console connected to the composite

video input, and the picture isn’t very clear, you can

attenuate the gain.

Video ATT:OFF: (default).

Video ATT:ON: Gain reduced by 2dB.

The AV receiver can upconvert component video, S-

Video, and composite video sources for display on a TV

connected to the HDMI output. However, if the picture

quality of the source is poor, upconversion may make the

picture worse or disappear altogether.

In this case, try the following:

Note

• If “Monitor Out” setting is set to “Analog”, press VCR/DVR

and Return on the AV receiver at the same time. Select “Skip”

in the “VideoProcessor” setting on the display. To reset back to

the original setting, press the same button at the same time. If

you select “Use”, the AV receiver will output video signals from

the video processor.

To use u, you must make an u connection and an

analog audio connection (RCA) between the compo-

nent and AV receiver, even if they are connected dig-

itally.

While Zone 2/3 is selected, the u functions don't

work.

—

While Zone 2/3 is selected, the u functions don't

work.

—

This can be caused by any malfunction in your

speaker unit. Check if the unit produces normal

sounds.

—

The AV receiver contains a microcomputer for signal

processing and control functions. In very rare situations,

severe interference, noise from an external source, or

static electricity may cause it to lockup. In the unlikely

event that this happens, unplug the power cord from the

wall outlet, wait at least five seconds, and then plug it

back in again.

Onkyo is not responsible for damages (such as CD

rental fees) due to unsuccessful recordings caused by

the unit’s malfunction. Before you record important

data, make sure that the material will be recorded cor-

rectly.

Before disconnecting the power cord from the wall out-

let, set the AV receiver to Standby.

Important Note Regarding Video Playback

1If the video source is connected to a component

video input, connect your TV to the COMPO-

NENT VIDEO MONITOR OUT.

If the video source is connected to an S-Video input,

connect your TV to a MONITOR OUT S.

If the video source is connected to a composite video

input, connect your TV to MONITOR OUT V.

2On the main menu, select “Input/Output Assign”,

and then select “HDMI Input”.

Select the relevant input selector, and assign it to

“-----” (➔49).

3On the main menu, select “Input/Output Assign”,

and then select “Component Video Input” (➔50):

If the video source is connected to COMPO-

NENT VIDEO IN 1, select the relevant input

selector, and assign it to “IN 1”.

If the video source is connected to COMPO-

NENT VIDEO IN 2, select the relevant input

selector, and assign it to “IN 2”.

If the video source is connected to COMPO-

NENT VIDEO IN 3, select the relevant input

selector, and assign it to “IN 3”.

If the video source is connected to an S-Video

input or composite video input, select the relevant

input selector, and assign it to “-----”.

102

Specifications

Amplifier Section

Video Section

Tuner Section

General

■HDMI

■Video Inputs

■Video Outputs

■Audio Inputs

Rated Output Power

All channels: (North American)

135 watts minimum continuous power

per channel, 8 ohm loads, 2 channels

driven from 20 Hz to 20 kHz, with a

maximum total harmonic distortion of

0.08% (FTC)

145 watts minimum continuous power

per channel, 8 ohm loads, 2 channels

driven at 1 kHz, with a maximum total

harmonic distortion of 0.7% (FTC)

160 watts minimum continuous power

per channel, 6 ohm loads, 2 channels

driven at 1 kHz, with a maximum total

harmonic distortion of 0.1% (FTC)

(Australian)

7 ch × 180 W at 6 ohms, 1 kHz, 1 ch driven

(IEC)

Maximum Effective Output Power

7 ch × 230 W at 6 ohms, 1 kHz, 1 ch driven

(JEITA)

Dynamic Power 300 W (3 Ω, Front)

250 W (4 Ω, Front)

150 W (8 Ω, Front)

THD (Total Harmonic Distortion)

0.08% (Power Rated)

Damping Factor 60 (Front, 1 kHz, 8 Ω)

Input Sensitivity and Impedance

200 mV/47 kΩ (LINE)

2.5 mV/47 kΩ (PHONO MM)

Rated RCA Output Level and Impedance

200 mV/470 Ω (PRE OUT)

Maximum RCA Output Level and Impedance

4.6 V/470 Ω (PRE OUT)

Phono Overload 70 mV (MM 1 kHz 0.5%)

Frequency Response 5 Hz - 100 kHz/+1 dB, -3 dB (Direct mode)

Tone Control Characteristics

±10 dB, 50 Hz (BASS)

±10 dB, 20 kHz (TREBLE)

Signal to Noise Ratio 110 dB (LINE, IHF-A)

80 dB (PHONO, IHF-A)

Speaker Impedance 4or6Ω - 16 Ω

Input Sensitivity/Output Level and Impedance

1 Vp-p/75 Ω (Component and S-Video Y)

0.7 Vp-p/75 Ω (Component PB/CB, PR/CR)

0.25 Vp-p/75 Ω (S-Video C)

1 Vp-p/75 Ω (Composite)

Component Video Frequency Response

5 Hz - 100 MHz/+0 dB, -3 dB

FM Tuning Frequency Range

(North American) 87.5 MHz - 107.9 MHz

(Australian) 87.5 MHz - 108.0 MHz, RDS

AM Tuning Frequency Range

(North American) 530 kHz - 1710 kHz

(Australian) 522/530 kHz - 1611/1710 kHz

Preset Channel 40

Digital Tuner (North American)

SIRIUS

Power Supply (North American) AC 120 V, 60 Hz

(Australian) AC 220 - 240 V, 50/60 Hz

Power Consumption (North American) 7.5 A

(Australian) 710 W

Stand-by Power Consumption

(North American) 0.2 W

(Australian) 0.3 W

Dimensions

(W × H × D)

435 mm × 198.5 mm × 427.5 mm

17-1/8" × 7-13/16" × 16-13/16"

Weight 17.9 kg (39.5 lbs.)

Input IN 1, IN 2, IN 3, IN 4, IN 5, IN 6,

AUX INPUT

Output OUT MAIN, OUT SUB

Video Resolution 1080p

Audio Format Dolby TrueHD, DTS Master Audio,

DVD-Audio, DSD

Supported 3D, Audio Return Channel, Deep Color,

x.v.Color, LipSync, CEC

Component IN 1, IN 2, IN 3

S-Video BD/DVD, VCR/DVR, CBL/SAT, GAME

Composite BD/DVD, VCR/DVR, CBL/SAT, GAME,

AUX

Analog RGB input PC IN

Component MONITOR OUT, ZONE 2 OUT

S-Video MONITOR OUT, VCR/DVR OUT

Composite MONITOR OUT, VCR/DVR OUT,

ZONE 2 OUT

Digital Optical: 2 (Rear), 1 (Front)

Coaxial: 3

Analog BD/DVD, VCR/DVR, CBL/SAT, GAME,

PC, TV/CD, AUX, PHONO

Multichannel Inputs 7.1

103

■Audio Outputs

■Others

Specifications and features are subject to change

without notice.

Analog VCR/DVR, ZONE 2/3 PRE OUT

Analog Multichannel Pre Outputs

Subwoofer Pre Outputs 2

Speaker Outputs Main (L, R, C, SL, SR, SBL, SBR, FHL,

FHR) + ZONE2/Front Wide (L, R)

Phones 1 (6.3 ø)

SETUP MIC 1

RS232 1

Ethernet 1

IR Input 2

IR Output 1

12 V Trigger Out 3

USB 1

Universal Port 1

RI 1

104

About HDMI

Designed to meet the increased demands of digital TV, HDMI (High Definition Multimedia Interface) is a new digital

interface standard for connecting TVs, projectors, Blu-ray Disc/DVD players, set-top boxes, and other video compo-

nents. Until now, several separate video and audio cables have been required to connect AV components. With HDMI, a

single cable can carry control signals, digital video, and up to eight channels of digital audio (2-channel PCM, multichan-

nel digital audio, and multichannel PCM).

The HDMI video stream (i.e., video signal) is compatible with DVI (Digital Visual Interface)*1, so TVs and displays with

a DVI input can be connected by using an HDMI-to-DVI adapter cable. (This may not work with some TVs and displays,

resulting in no picture.)

The AV receiver uses HDCP (High-bandwidth Digital Content Protection)*2, so only HDCP-compatible components can

display the picture.

Supported Audio Formats

• 2-channel linear PCM (32–192 kHz, 16/20/24 bit)

• Multichannel linear PCM (up to 7.1 ch, 32–192 kHz, 16/20/24 bit)

• Bitstream (DSD, Dolby Digital, Dolby Digital Plus, Dolby TrueHD, DTS, DTS-HD High Resolution Audio, DTS-HD

Master Audio)

Your Blu-ray Disc/DVD player must also support HDMI output of the above audio formats.

About Copyright Protection

The AV receiver supports HDCP (High-bandwidth Digital Content Protection)*2, a copy-protection system for digital

video signals. Other devices connected to the AV receiver via HDMI must also support HDCP.

*1 DVI (Digital Visual Interface): The digital display interface standard set by the DDWG*3 in 1999.

*2 HDCP (High-bandwidth Digital Content Protection): The video encryption technology developed by Intel for HDMI/DVI. It’s

designed to protect video content and requires a HDCP-compatible device to display the encrypted video.

*3 DDWG (Digital Display Working Group): Lead by Intel, Compaq, Fujitsu, Hewlett Packard, IBM, NEC, and Silicon Image, this

open industry group’s objective is to address the industry’s requirements for a digital connectivity specification for high-performance

PCs and digital displays.

Note

• The HDMI video stream is compatible with DVI (Digital Visual Interface), so TVs and displays with a DVI input can be connected by

using an HDMI-to-DVI adapter cable. (Note that DVI connections only carry video, so you’ll need to make a separate connection for

audio.) However, reliable operation with such an adapter is not guaranteed. In addition, video signals from a PC are not supported.

• The HDMI audio signal (sampling rate, bit length, etc.) may be restricted by the connected source component. If the picture is poor or

there’s no sound from a component connected via HDMI, check its setup. Refer to the connected component’s instruction manual for

details.

The AV receiver’s HDMI interface is based on the following:

Audio Return Channel, 3D, x.v.Color, Deep Color, Lip Sync, DTS-HD Master Audio, DTS-HD High Resolution

Audio, Dolby TrueHD, Dolby Digital Plus, DSD and Multichannel PCM

105

Using an RIHD-compatible TV, Player, or Recorder

p, which stands for Remote Interactive over HDMI, is the name of the system control function found on Integra/

Onkyo components. The AV receiver can be used with CEC (Consumer Electronics Control), which allows system con-

trol over HDMI and is part of the HDMI standard. CEC provides interoperability between various components, however,

operation with components other than p-compatible components cannot be guaranteed.

■About p-compatible components

The following components are p-compatible. (As

of February 2010) See the Onkyo web site for latest infor-

mation.

• Panasonic VIERA Link compatible TV

• Toshiba REGZA-LINK compatible TV

• Sharp TV (See Onkyo web site for latest information on

compatible models.)

Players/Recorders

• Onkyo and Integra p-compatible players

• Panasonic VIERA Link compatible players and record-

ers (only when used together with Panasonic VIERA

Link compatible TV)

• Toshiba REGZA-LINK compatible players and record-

ers (only when used together with Toshiba REGZA-

LINK compatible TV)

• Sharp players and recorders (only when used together

with Sharp TV)

*Models other than those mentioned above may have some

interoperability if compatible with CEC which is part of the

HDMI Standard, but operation cannot be guaranteed.

Note

• Do not connect the p-compatible component more than

the following number to the HDMI input terminal so that the

linked operations work properly.

–Blu-ray Disc/DVD player is up to three.

–Blu-ray Disc recorder/DVD recorder/Digital Video Recorder is

up to three.

–Cable/Satellite Set-top box is up to four.

• Do not connect the AV receiver to the other AV receiver/AV

amplifier via HDMI.

•When the p-compatible component more than the

above-mentioned is connected, the linked operations are not

guaranteed.

■Operations that can be performed with p

connection

For p-compatible TV

The following linked operation is possible by connecting

the AV receiver to an p-compatible TV.

• The AV receiver will enter Standby mode when the

power of the TV is turned to Standby.

• You can set on the menu screen of the TV to either out-

put the audio from the speakers connected to the AV

receiver, or from the speakers of the TV.

• It is possible to output the video/audio from the antenna

or from the input jack of the TV from the speakers con-

nected to the AV receiver. (A connection such as optical

digital cable or similar is required above the HDMI

cable.)

• Input to the AV receiver can be selected with the remote

controller of the TV.

• Operations such as volume adjustment or similar for the

AV receiver can be performed from the remote controller

of the TV.

For p-compatible players/recorders

The following link operation is possible by connecting the

AV receiver to an p-compatible player/recorder.

• When the playback is started on the player/recorder,

input of the AV receiver will switch to the HDMI input

of the player/recorder that is playing back.

• Operation of the player/recorder is possible with the

remote controller supplied with the AV receiver.

*Not all functions may operate depending on the model.

106

■How to connect and setup

1Confirm the connecting and setting.

1. Connect the HDMI OUT MAIN jack to the

HDMI input jack of the TV.

2. Connect the audio output from the TV to the

OPTICAL IN 2 jack of the AV receiver using an

optical digital cable.

Note

• When you use the audio return channel (ARC) function

with TV an HDMI (Audio Return Channel) capable TV,

this connection is not required (➔63).

3. Connect the HDMI output of the Blu-ray Disc/

DVD player/recorder to the HDMI IN 1 jack of

the AV receiver.

Note

• It is necessary to assign the HDMI input when connecting

the Blu-ray Disc/DVD player/recorder to other jacks

(➔49). Do not assign the components connected to the

HDMI IN to the TV/CD input at this time. Appropriate

CEC (Consumer Electronics Control) operation can not be

guaranteed.

2Change each item in the “HDMI” as below:

•HDMI Control (RIHD): On

•Audio Return Channel (ARC): Auto

•Power Control: On

•TV Control: On

See details of each setting (➔62, 63).

Blu-ray Disc/DVD player, etc.

AV receiver

TV, projector, etc.

DIGITAL AUDIO

connection

(OPTICAL)

HDMI

connection

HDMI

connection

3Confirm the settings.

1. Turn on the power for all connected components.

2. Turn off the power of the TV, and confirm that

the power of the connected components is turned

off automatically with the link operation.

3. Turn on the power of the Blu-ray Disc/DVD

player/recorder.

4. Start playback of the Blu-ray Disc/DVD player/

recorder, and confirm the following.

• The power of the AV receiver is turned on

automatically, and input with the Blu-ray

Disc/DVD player/recorder connected is

selected.

• The power of the TV is turned on automati-

cally, and input with the AV receiver con-

nected is selected.

5. Following the operating instructions of the TV,

select “Use the TV speakers” from the menu

screen of the TV, and confirm that the audio is

output from the speakers of the TV, and not from

the speakers connected to the AV receiver.

6. Select “Use the speakers connected from the AV

receiver” from the menu screen of the TV, and

confirm that the audio is output from the speak-

ers connected to the AV receiver, and not from

the TV speakers.

Note

• Perform the above operations when you initially use the

AV receiver, when the settings of each component are

changed, when the main power of each component is

turned off, when the power cable is disconnected from the

power supply, or when there has been a power outage.

4Operate with the remote controller.

See the list of available buttons (➔93).

Note

• Audio from DVD-Audio or Super Audio CD may not out-

put from the TV speakers. You will be able to output the

audio from the TV speakers by setting the audio output of

the DVD player to 2ch PCM. (It may not be possible

depending on the player models.)

• Even if you set to output audio on the TV speakers, audio

will be output from the speakers connected to the AV

receiver when you adjust the volume or switch the input

on the AV receiver. To output audio from the TV speakers,

re-do the operations on the TV.

• Do not connect the u cable when connecting to the u

and u audio control compatible components.

• When you select anything other than the HDMI jack

where the AV receiver is connected as the input on the TV,

input on the AV receiver will be switched to “TV/CD”.

• The AV receiver will automatically power on in conjunc-

tion when it determines it to be necessary. Even if the AV

receiver is connected to an p compatible TV or

player/recorder, it will not power on if it is not necessary.

It may not power on in conjunction when the TV is set to

output audio from the TV.

• Linked functions with the AV receiver may not work

depending on the model. Operate the AV receiver directly

in such cases.

107

Video Resolution Chart

The following tables show how video signals at different resolutions are output by the AV receiver.

NTSC/PAL

✔: Output

*1 Available resolution:

[640 × 480 60/72/75 Hz]

[800 × 600 56/60/72/75 Hz]

[1024 × 768 60/70/75 Hz]

[1280 × 1024 60 Hz]

*2 The output is limited to 480p/576p for an effective signal in the effect of Macrovision.

*3 PC IN (Analog RGB) input signal is output at 720p resolution when you select “Analog” in the “Monitor Out” setting (➔48) and

“Through” in the “Resolution” setting (➔49).

HDMI Component S-Video

Composite

1080p 1080i 720p 480p/

576p

480i/

576i

1080p 1080i 720p 480p/

576p

480i/

576i

480i/576i

HDMI 1080p ✔

1080i ✔✔✔

720p ✔✔✔

480p/576p ✔✔✔✔

480i/576i ✔✔✔✔✔

Component 1080p ✔✔

1080i ✔✔✔ ✔✔

720p ✔✔✔ ✔✔

480p/576p ✔✔✔✔ ✔*2 ✔*2 ✔

480i/576i ✔✔✔✔✔ ✔*2 ✔*2 ✔✔

S-Video

Composite

480i/576i ✔✔✔✔✔ ✔*2 ✔*2 ✔✔✔

PC IN (Analog RGB)*1 ✔✔✔✔ ✔*3 ✔*3 ✔*3

Output

Input

SN 29400359

Y1006-1

Integra Division of

ONKYO U.S.A. CORPORATION

18 park Way, Upper Saddle River, N.J. 07458, U.S.A.

Tel: 800-225-1946, 201-818-9200 Fax: 201-785-2650 http://www.integrahometheater.com

Integra Division of

ONKYO CORPORATION

Sales & Product Planning Div.: 2-1, Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN

Tel: 072-831-8023 Fax: 072-831-8163
